Funai LCD-D2006, LCD-C2006, LCD-B2006, LCD-A2006 Service Manual

Download
SERVICE MANUAL
20" COLOR LCD TELEVISION
LCD-A2006/LCD-B2006/
LCD-C2006/LCD-D2006
20″ COLOR LCD TELEVISION
LCD-A2006/LCD-B2006/
LCD-C2006/LCD-D2006
TABLE OF CONTENTS
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Important Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Electrical Adjustment Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Schematic Diagrams / CBA’s and Test Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
Mechanical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
Electrical Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-1
The LCD panel is manufactured to provide many years of useful life. Occasionally a few non active pixels may appear as a tiny spec of color. This is not to be considered a defect in the LCD screen.
SPECIFICATIONS
<TUNER> ANT. Input ------------------- 80 dBµV, Video: PAL 87.5%, Audio: 30 kHz dev (1 kHz Sin)
Test Input Signal----------- 400Hz 30% modulation
Description Condition Unit Nominal Limit
1. Intermediate Freq. Picture
2. Video S/N (White 50%) CH-3 dB 45 40
3. Audio S/N (Output Level 500mV)
<LCD PANEL>
Description Condition Unit Nominal Limit
1. Number of Pixels Horizontal
2. Brightness
3. Response Time - msec 16 -
4. Support Color - - 16mil.(8bit) -
5. Viewing Angle Horizontal
PAL-BG/I/DK, SECAM-L SECAM-L’
Sound
PA L- B G PA L- I PAL-DK, SECAM-L SECAM-L’
–dB5347
Vert i c al
Vert i c al
MHz MHz
MHz MHz MHz MHz
pixels pixels
cd/m
° °
38.9
33.9
33.4
32.9
32.4
40.4
640 x 3
480
2
420 -
-85 to 85
-85 to 70
-
-
-
-
-
-
-
-
-
<VIDEO>
Description Condition Unit Nominal Limit
1. Over Scan Horizontal
2. Color Temperature -
3. Resolution Horizontal
<AUDIO>
Description Condition Unit Nominal Limit
1. Audio Output Power 10% THD: Lch/Rch W 0.95/0.95 0.75/0.75
2. Audio Distortion 500mW: Lch/Rch % 0.6/0.6 <4
3. Audio Freq. Response
4. Audio S/N VIDEO 1
Note:
Nominal specifications represent the design specifications. All units should be able to approximate these. Some will exceed and some may drop slightly below these specifications. Limit specifications represent the absolute worst condition that still might be considered acceptable. In no case should a unit fail to meet limit specifications.
All items are measured across 8Ω load at speaker output terminal with L.P.F.
Vert i c al
Vert i c al
-
6dB: Lch
-
6dB: Rch
VIDEO 2
x y
% %
°K 8500
line line
Hz Hz
dB dB
8.5
6.5
0.29
0.30
400 350
50 to 12K 50 to 12K
43 55
10±5 10±5
-
0.29±0.03
0.30±0.03
<250 <300
-
-
40 40
1-1 L4620SP
IMPORTANT SAFETY PRECAUTIONS
Prior to shipment from the factory, our products are strictly inspected for recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced.
Safety Precautions for LCD TV Circuit
1. Before returning an instrument to the customer, always make a safety check of the
entire instrument, including, but not limited to, the following items:
a. Be sure that no built-in protective devices are
defective and have been defeated during servicing. (1) Protective shields are provided on this chassis to protect both the technician and the customer. Correctly replace all missing protective shields, including any removed for servicing convenience. (2) When reinstalling the chassis and/or other assembly in the cabinet, be sure to put back in place all protective devices, including but not limited to, nonmetallic control knobs, insulating fishpapers, adjustment and compartment covers/shields, and isolation resistor/capacitor networks. Do not operate this instrument or
permit it to be operated without all protective devices correctly installed and functioning. Servicers who defeat safety features or fail to perform safety checks may be liable for any resulting damage.
b. Be sure that there are no cabinet openings
through which an adult or child might be able to insert their fingers and contact a hazardous voltage. Such openings include, but are not limited to, (1) spacing between the LCD module and the cabinet mask, (2) excessively wide cabinet ventilation slots, and (3) an improperly fitted and/or incorrectly secured cabinet back cover.
c. Antenna Cold Check - With the instrument AC
plug removed from any AC source, connect an electrical jumper across the two AC plug prongs. Place the instrument AC switch in the on position. Connect one lead of an ohmmeter to the AC plug prongs tied together and touch the other ohmmeter lead in turn to each tuner antenna input exposed terminal screw and, if applicable, to the coaxial connector. If the measured resistance is less than 1.0 megohm or greater than 5.2 megohm, an abnormality exists that must be corrected before the instrument is returned to the customer. Repeat this test with the instrument AC switch in the off position.
d. Leakage Current Hot Check - With the
instrument completely reassembled, plug the AC line cord directly into a 230 V AC outlet. (Do not use an isolation transformer during this test.) Use a leakage current tester or a metering system that complies with American
National Standards Institute (ANSI) C101.1 Leakage Current for Appliances and Underwriters Laboratories (UL) 1410, (50.7). With the instrument AC switch first in the on position and then in the off position, measure from a known earth ground (metal water pipe, conduit, etc.) to all exposed metal parts of the instrument (antennas, handle brackets, metal cabinet, screw heads, metallic overlays, control shafts, etc.), especially any exposed metal parts that offer an electrical return path to the chassis. Any current measured must not exceed 0.5 milli-ampere. Reverse the instrument power cord plug in the outlet and repeat the test.
READING SHOULD NOT BE ABOVE 0.5 mA
LEAKAGE
DEVICE
BEING
TESTED
TEST ALL EXPOSED METAL SURFACES
ALSO TEST WITH PLUG REVERSED USING AC ADAPTER PLUG AS REQUIRED
ANY MEASUREMENTS NOT WITHIN THE LIMITS SPECIFIED HEREIN INDICATE A POTENTIAL SHOCK HAZARD THAT MUST BE ELIMINATED BEFORE RETURNING THE INSTRUMENT TO THE CUSTOMER OR BEFORE CONNECTING THE ANTENNA OR ACCESSORIES.
2. Read and comply with all caution and safety-
related notes on or inside the receiver cabinet, on the receiver chassis, or on the LCD module.
3. Design Alteration Warning - Do not alter or add to the mechanical or electrical design of this LCD TV receiver. Design alterations and additions, including, but not limited to circuit modifications and the addition of items such as auxiliary audio and/or video output connections, might alter the safety characteristics of this receiver and create a hazard to the user. Any design alterations or additions will void the manufacturer's warranty and may make you, the servicer, responsible for personal injury or property damage resulting therefrom.
CURRENT
TESTER
+
EARTH GROUND
_
2-1 LTVP_ISP
4. Hot Chassis Warning -
a. Some TV receiver chassis are electrically
connected directly to one conductor of the AC power cord and maybe safety-serviced without an isolation transformer only if the AC power plug is inserted so that the chassis is connected to the ground side of the AC power source. To confirm that the AC power plug is inserted correctly, with an AC voltmeter, measure between the chassis and a known earth ground. If a voltage reading in excess of
1.0V is obtained, remove and reinsert the AC power plug in the opposite polarity and again measure the voltage potential between the chassis and a known earth ground.
b. Some TV receiver chassis normally have 85V
AC(RMS) between chassis and earth ground regardless of the AC plug polarity. This chassis can be safety-serviced only with an isolation transformer inserted in the power line between the receiver and the AC power source, for both personnel and test equipment protection.
c. Some TV receiver chassis have a secondary
ground system in addition to the main chassis ground. This secondary ground system is not isolated from the AC power line. The two ground systems are electrically separated by insulation material that must not be defeated or altered.
5. Observe original lead dress. Take extra care to assure correct lead dress in the following areas: a. near sharp edges, b. near thermally hot parts-be sure that leads and components do not touch thermally hot parts, c. the AC supply, d. high voltage, and, e. antenna wiring. Always inspect in all areas for pinched, out of place, or frayed wiring. Check AC power cord for damage.
6. Components, parts, and/or wiring that appear to have overheated or are otherwise damaged should be replaced with components, parts, or wiring that meet original specifications. Additionally, determine the cause of overheating and/or damage and, if necessary, take corrective action to remove any potential safety hazard.
7. Product Safety Notice - Some electrical and mechanical parts have special safety-related characteristics which are often not evident from visual inspection, nor can the protection they give necessarily be obtained by replacing them with components rated for higher voltage, wattage, etc.. Parts that have special safety characteristics are identified by a ! on schematics and in parts lists. Use of a substitute replacement that does not have the same safety characteristics as the recommended replacement part might create shock, fire, and/or other hazards. The product's safety is under review continuously and new instructions are issued whenever appropriate. Prior to shipment from the factory, our products are strictly inspected to confirm they comply with the recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced.
2-2 LTVP_ISP
Precautions during Servicing
A. Parts identified by the ! symbol are critical for
safety. Replace only with part number specified.
B. In addition to safety, other parts and assemblies
are specified for conformance with regulations applying to spurious radiation. These must also be replaced only with specified replacements. Examples: RF converters, RF cables, noise blocking capacitors, and noise blocking filters, etc.
C. Use specified internal wiring. Note especially:
1) Wires covered with PVC tubing
2) Double insulated wires
3) High voltage leads
D. Use specified insulating materials for hazardous
live parts. Note especially:
1) Insulation Tape
2) PVC tubing
3) Spacers
4) Insulators for transistors.
E. When replacing AC primary side components
(transformers, power cord, etc.), wrap ends of wires securely about the terminals before soldering.
F. Observe that the wires do not contact heat
producing parts (heat sinks, oxide metal film resistors, fusible resistors, etc.)
G. Check that replaced wires do not contact sharp
edged or pointed parts.
H. When a power cord has been replaced, check that
5~6 kg of force in any direction will not loosen it.
I. Also check areas surrounding repaired locations.
J. Use care that foreign objects (screws, solder
droplets, etc.) do not remain inside the set.
K. Crimp type wire connector
The power transformer uses crimp type connectors which connect the power cord and the primary side of the transformer. When replacing the transformer, follow these steps carefully and precisely to prevent shock hazards. Replacement procedure
1) Remove the old connector by cutting the wires at a point close to the connector. Important: Do not re-use a connector (discard it).
2) Strip about 15 mm of the insulation from the ends of the wires. If the wires are stranded, twist the strands to avoid frayed conductors.
3) Align the lengths of the wires to be connected. Insert the wires fully into the connector.
4) Use the crimping tool to crimp the metal sleeve at the center position. Be sure to crimp fully to the complete closure of the tool.
L. When connecting or disconnecting the internal
connectors, first, disconnect the AC plug from the AC supply outlet.
M. When installing parts or assembling the cabinet
parts, be sure to use the proper screws and tighten certainly.
2-3 LTVP_ISP
Safety Check after Servicing
Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts and wires have been returned to original posi­tions. Afterwards, perform the following tests and con­firm the specified values in order to verify compliance with safety standards.
1. Clearance Distance
When replacing primary circuit components, confirm specified clearance distance (d) and (d') between sol­dered terminals, and between terminals and surround­ing metallic parts. (See Fig. 1)
Table 1 : Ratings for selected area
AC Line Voltage Clearance Distance (d), (d’)
230 V
Note: This table is unofficial and for reference only. Be sure to confirm the precise values.
≥ 3mm(d)
≥ 6 mm(d’)
2. Leakage Current Test
Confirm the specified (or lower) leakage current be­tween B (earth ground, power cord plug prongs) and externally exposed accessible parts (RF terminals, an­tenna terminals, video and audio input and output ter­minals, microphone jacks, earphone jacks, etc.).
Chassis or Secondary Conductor
Primary Circuit
d' d
Exposed Accessible Part
Z
AC Voltmeter (High Impedance)
Fig. 1
Measuring Method : (Power ON)
Insert load Z between B (earth ground, power cord plug prongs) and exposed accessible parts. Use an AC voltmeter to measure across both terminals of load Z. See Fig. 2 and following table.
Table 2: Leakage current ratings for selected areas
AC Line Voltage Load Z Leakage Current (i)
2kΩ RES.
Connected in
parallel
230 V
50kΩ RES.
Connected in
parallel
Note: This table is unofficial and for reference only. Be sure to confirm the precise values.
i≤0.7mA AC Peak
i≤2mA DC
i≤0.7mA AC Peak
i≤2mA DC
One side of
B
Power Cord Plug Prongs
One side of power cord plug
prongs (B) to:
Antenna terminals
A/V Input, Output
Fig. 2
RF or
2-4 LTVP_ISP
STANDARD NOTES FOR SERVICING
Circuit Board Indications
1. The output pin of the 3 pin Regulator ICs is indicated as shown.
Top View
Out
2. For other ICs, pin 1 and every fifth pin are indicated as shown.
Pin 1
3. The 1st pin of every male connector is indicated as shown.
Pin 1
Input
In
Bottom View
5
10
Pb (Lead) Free Solder
Pb free mark will be found on PCBs which use Pb free solder. (Refer to figure.) For PCBs with Pb free mark, be sure to use Pb free solder. For PCBs without Pb free mark, use standard solder.
Pb free mark
How to Remove / Install Flat Pack-IC
1. Removal
With Hot-Air Flat Pack-IC Desoldering Machine:
1. Prepare the hot-air flat pack-IC desoldering machine, then apply hot air to the Flat Pack-IC (about 5 to 6 seconds). (Fig. S-1-1)
Fig. S-1-1
2. Remove the flat pack-IC with tweezers while applying the hot air.
3. Bottom of the flat pack-IC is fixed with glue to the CBA; when removing entire flat pack-IC, first apply soldering iron to center of the flat pack-IC and heat up. Then remove (glue will be melted). (Fig. S-1-6)
4. Release the flat pack-IC from the CBA using tweezers. (Fig. S-1-6)
CAUTION:
1. The Flat Pack-IC shape may differ by models. Use an appropriate hot-air flat pack-IC desoldering machine, whose shape matches that of the Flat Pack-IC.
2. Do not supply hot air to the chip parts around the flat pack-IC for over 6 seconds because damage to the chip parts may occur. Put masking tape around the flat pack-IC to protect other parts from damage. (Fig. S-1-2)
3. The flat pack-IC on the CBA is affixed with glue, so be careful not to break or damage the foil of each pin or the solder lands under the IC when removing it.
Hot-air Flat Pack-IC Desoldering
CBA
Masking Tape
Tweezers
3-1 TVP_SN
Machine
Flat Pack-IC
Fig. S-1-2
With Soldering Iron:
1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder flux which is applied to all pins of the flat pack-IC, you can remove it easily. (Fig. S-1-3)
Flat Pack-IC
Desoldering Braid
Soldering Iron
Fig. S-1-3
2. Lift each lead of the flat pack-IC upward one by one, using a sharp pin or wire to which solder will not adhere (iron wire). When heating the pins, use a fine tip soldering iron or a hot air desoldering machine. (Fig. S-1-4)
With Iron Wire:
1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder flux which is applied to all pins of the flat pack-IC, you can remove it easily. (Fig. S-1-3)
2. Affix the wire to a workbench or solid mounting point, as shown in Fig. S-1-5.
3. While heating the pins using a fine tip soldering iron or hot air blower, pull up the wire as the solder melts so as to lift the IC leads from the CBA contact pads as shown in Fig. S-1-5.
4. Bottom of the flat pack-IC is fixed with glue to the CBA; when removing entire flat pack-IC, first apply soldering iron to center of the flat pack-IC and heat up. Then remove (glue will be melted). (Fig. S-1-6)
5. Release the flat pack-IC from the CBA using tweezers. (Fig. S-1-6)
Note: When using a soldering iron, care must be
taken to ensure that the flat pack-IC is not being held by glue. When the flat pack-IC is removed from the CBA, handle it gently because it may be damaged if force is applied.
Sharp Pin
Fine Tip Soldering Iron
3. Bottom of the flat pack-IC is fixed with glue to the CBA; when removing entire flat pack-IC, first apply soldering iron to center of the flat pack-IC and heat up. Then remove (glue will be melted). (Fig. S-1-6)
4. Release the flat pack-IC from the CBA using tweezers. (Fig. S-1-6)
Fig. S-1-4
To Solid Mounting Point
CBA
Hot Air Blower
or
Iron Wire
Soldering Iron
Fig. S-1-5
Fine Tip Soldering Iron
Flat Pack-IC
Tweezers
Fig. S-1-6
3-2 TVP_SN
2. Installation
1. Using desoldering braid, remove the solder from the foil of each pin of the flat pack-IC on the CBA so you can install a replacement flat pack-IC more easily.
2. The “●” mark on the flat pack-IC indicates pin 1. (See Fig. S-1-7.) Be sure this mark matches the 1 on the PCB when positioning for installation. Then presolder the four corners of the flat pack-IC. (See Fig. S-1-8.)
3. Solder all pins of the flat pack-IC. Be sure that none of the pins have solder bridges.
Example :
Pin 1 of the Flat Pack-IC is indicated by a " " mark.
Fig. S-1-7
Instructions for Handling Semi­conductors
Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work.
1. Ground for Human Body
Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be charged on the body.
2. Ground for Workbench
Be sure to place a conductive sheet or copper plate with proper grounding (1 MΩ) on the workbench or other surface, where the semi-conductors are to be placed. Because the static electricity charge on clothing will not escape through the body grounding band, be careful to avoid contacting semi-conductors with your clothing.
<Incorrect>
CBA
Presolder
Flat Pack-IC
Fig. S-1-8
<Correct>
1MΩ
CBA
Grounding Band
1MΩ
CBA
Conductive Sheet or Copper Plate
3-3 TVP_SN
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the cabinet parts, and the CBA in order to gain access to item(s) to be serviced. When reassembling, follow the steps in reverse order. Bend, route and dress the cables as they were.
[10] IR Sensor CBA
[9] Speaker (s)
[4] Inverter CBA
[1] Tilt Stand Assembly
[2] Rear Cabinet
[3] Jack Holder
[5] Main CBA
[6] Tilt Stand Holder
[7] LCD Main CBA Unit & Liquid Crystal Panel Unit
[8] Function CBA
[11] Front Cabinet
[12] Stand Cover
[13] Arm Holder
[14] Sheet L, R
[15] Arm Assembly
2. Disassembly Method
Removal
Step/
Loc.
Part
No.
Tilt Stand
[1]
Assembly
Rear
[2]
Cabinet
[3] Jack Holder D2 3(S-4), (S-5) ---
Remove/*Unhook/
Fig.
No.
Unlock/Release/
Unplug/Unclamp/
Note
Desolder
D1 4(S-1) ---
D1 9(S-2), 2(S-3) ---
Removal
Step/
Loc.
No.
Part
Remove/*Unhook/
Fig.
No.
Unlock/Release/
Unplug/Unclamp/
Note
Desolder
[9] Speaker (s) D2
IR Sensor
[10]
CBA
Front
[11]
Cabinet
Stand
[12]
Cover
4(S-11), Speaker Holder (s)
---
D2 (S-12) ---
D2 --------------- ---
D3 6(S-13) ---
[13] Arm Holder D3 2(S-14) ---
[14] Sheet L, R D3 --------------- ---
Arm
[15]
↓
(1)
Assembly
↓
(2)
D3 --------------- ---
↓
(3)
↓
(4)
↓
(5)
Note:
(1) Order of steps in procedure. When reassembling,
follow the steps in reverse order. These numbers are also used as the Identification (location) No. of parts in figures.
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or desoldered. P = Spring, L = Locking Tab, S = Screw, CN = Connector * = Unhook, Unlock, Release, Unplug, or Desolder e.g. 2(S-2) = two Screws (S-2), 2(L-2) = two Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the
Ta b le . "
Inverter
[4]
CBA
[5] Main CBA
Tilt Stamd
[6]
Holder
LCD Main CBA Unit &
[7]
Liquid Crystal Panel Unit
Function
[8]
CBA
4(S-6), *CN301,
D2
*CN302, *CN303,
D4
*CN304, *CN310
9(S-7), *CN53,
D2
*CN101B, *CN102B,
D4
*CN103B, *CN801
---
---
D2 2(S-8) ---
D2 11(S-9), *CN106 ---
D2 5(S-10) ---
4-1 L4620DC
S-2
[1] Tilt Stand Assembly
[2] Rear Cabinet
S-2
S-3
S-2
S-2
S-3
S-1
S-2
Fig. D1
[11] Front Cabinet
[9] Speaker
Speaker Holders
[7] LCD Main CBA Unit & Liquid Crystal Panel Unit
[6] Tilt Stand Holder
[9] Speaker
Speaker Holders
[10] IR Sensor CBA
S-12
S-11
S-9
S-9
S-5
S-11
S-10
S-10
[8] Function CBA
S-10
S-9
S-9
S-8
S-4
S-7
S-7
S-7
S-6
[4] Inverter CBA
S-6
[3] Jack Holder
4-2 L4620DC
[5] Main CBA
S-4
Fig. D2
[13] Arm Holder
[15] Arm Assembly
[12] Stand Cover
S-14
[14] Sheet R
S-13
[14] Sheet L
S-13
Fig. D3
4-3 L4620DC
TV Cable Wiring Diagram
To Liquid Crystal Panel Unit
LCD Main CBA Unit
Function CBA
CN31B
CN801
CN311 CN312
CN103B
CN103A
CN53
CN102B
CN102A
CN106
CN101B
CN101A
Main CBA
CN404
Inverter CBA
CN301
CN304
CN302
CN303
CN310
To Liquid Crystal Panel Unit
To Speaker
IR Sensor CBA
CLN53
To Speaker
Fig. D4
4-4 L4620DC
HOW TO INITIALIZE THE LCD TELEVISION
To put the program back at the factory-default, initialize the LCD television as the following procedure.
How to initialize the LCD television:
1. Turn the power on. (Use main power on the TV unit.)
2. To enter the service mode, press [STANDBY], [2], [7], [1], and [MUTE] buttons on the remote control unit in that order within 5 seconds.
- To cancel the service mode, press [STANDBY]
button on the remote control.
3. To initialize the LCD television, press “DISPLAY” button on the remote control unit.
4. Confirm "FF" indication on the upper right of the screen.
5-1 L4620INT
ELECTRICAL ADJUSTMENT INSTRUCTIONS
General Note: “CBA” is abbreviation for “Circuit Board Assem-
bly.” NOTE:
Electrical adjustments are required after replacing circuit components and certain mechanical parts. It is important to perform these adjustments only after all repairs and replacements have been completed. Also, do not attempt these adjustments unless the proper equipment is available.
Test Equipment Required
1. DC Voltmeter
2. Pattern Generator
3. Color Analyzer
How to Set up the Service mode:
1. Turn the power on. (Use main power on the TV unit.)
2. Press [STANDBY], [2], [7], [1], and [MUTE] buttons on the remote control unit in that order within 5 seconds.
- To cancel the service mode, press [STANDBY] button on the remote control.
1. Initial Setting
General
Enter the Service mode.
Set the each initial data as shown on table 1 below.
Table 1: Initial Data
BUTTON
ITEM
BRT(PAL) CNT(PAL) 140 CLR-R(PAL) 70 CLR-B(PAL) 70 SHR(PAL) 143 S-BRT(PAL) S-CNT(PAL) 140 S-CLR-R(PAL) 70 S-CLR-B(PAL) 70 S-SHR(PAL) 143 C-BRT(PAL) C-CNT(PAL) 128 C-CLR-R(PAL) 120 C-CLR-B(PAL) 120 C-SHR(PAL) 143 BRT(SECAM) CNT(SECAM) 140 CLR-R(SECAM) 70 CLR-B(SECAM) 70 SHR(SECAM) 143 S-BRT(SECAM) S-CNT(SECAM) 140 S-CLR-R(SECAM) 70 S-CLR-B(SECAM) 70 S-SHR(SECAM) 143 C-BRT(SECAM) C-CNT(SECAM) 128 C-CLR-R(SECAM) 120 C-CLR-B(SECAM) 120 C-SHR(SECAM) 143 BRT(NTSC) CNT(NTSC) 138 CLR-R(NTSC) 77 CLR-B(NTSC) 77 TNT(NTSC) 120 SHR(NTSC) 143 S-BRT(NTSC) S-CNT(NTSC) 138 S-CLR-R(NTSC) 74 S-CLR-B(NTSC) 74 S-TNT(NTSC) 120 S-SHR(NTSC) 143
(on the remote
control)
MENU → 1
MENU → 2
MENU → 3
MENU → 4
MENU → 5
MENU → 6
MENU → 7
MENU → 8
DATA
VALUE
130
133
128
130
133
128
128
128
6-1 L4620EA
BUTTON
ITEM
C-BRT(NTSC) C-CNT(NTSC) 128 C-CLR-R(NTSC) 150 C-CLR-B(NTSC) 150 C-TNT(NTSC) 120 C-SHR(NTSC) 143 BRIGHT 0 0 NORMAL 0 65 DARK 0 98 COR(C/D/S-1) VOL. p → 1 128 COG(C/D/S-1) VOL. p → 2 128 COB(C/D/S-1) VOL. p → 3 128 DR(C/D/S-1) VOL. p → 4 180 DG(C/D/S-1) VOL. p → 5 180 DB(C/D/S-1) VOL. p → 6 180 SBR(C/D/S-1) VOL. p → 70 SBB(C/D/S-1) VOL. p → 90 C-COR(C/D/S-2) VOL. p → 1 128 C-COG(C/D/S-2) VOL. p → 2 128 C-COB(C/D/S-2) VOL. p → 3 128 C-DR(C/D/S-2) VOL. p → 4 140 C-DG(C/D/S-2) VOL. p → 5 140 C-DB(C/D/S-2) VOL. p → 6 140 C-SBR(C/D/S-2) VOL. p → 70 C-SBB(C/D/S-2) VOL. p → 90 7F LAST POWER OFF SYSTEM *1 NCM ON ASPECT OFF RUSSIAN OFF
(on the remote
control)
MENU → 9
VOL. p
DATA
VALUE
128
FF
2. Flicker Adjustment
1. Enter the Service mode. (See page 6-1.)
2. Press [2] button on the remote control unit. The following screen appears.
VCOM
128
3. If Flicker Adjustment is not fit, the screen becomes the following.
VCOM
128
FLASH (Go and Off)
4. Press [CH. o / p] buttons on the remote control unit so that flash stops.
*1 PAL-BG (LCD-A2006), PAL-I (LCD-B2006),
SECAM-L (LCD-C2006), PAL-BG/DK (LCD-D2006)
6-2 L4620EA
The following adjustment normally are not attempted in the field. Only when replacing the LCD Panel then adjust as a preparation.
3. White Balance Adjustment
Purpose: To mix red, green and blue beams correctly
for pure white. Symptom of Misadjustment: White becomes bluish
or reddish.
Test Point Adj. Point Mode Input
[RF/AV2(CVBS)]
Screen
VOL. p buttons
M. EQ. Spec.
C/D/S-1
[AV1(RGB)]
C/D/S-2
White Purity
(APL 80%)
or
(APL 40%)
6. [AV1(RGB)]----(APL 80%) Press “6” button to select “C-DB(C/D/S-2)” for Blue adjustment. Press “4” button to select “C-DR(C/D/ S-2)” for Red adjustment.When “x” value and “y” value are not within specification, adjust “C-DB(C/ D/S-2)” or “C-DR(C/D/S-2)”. Refer to “1. Initial Setting.”
[AV1(RGB)]----(APL 40%)
Press “3” button to select “C-COB(C/D/S-2)” for Blue adjustment. Press “1” button to select “C­COR(C/D/S-2)” for Red adjustment.When “x” value and “y” value are not within specification, a d j u s t “ C - C O B ( C / D / S - 2 ) ” o r “ C - C O R ( C / D / S - 2 ) ” . Refer to “1. Initial Setting.”
7. Turn the power off and on again. (Main power button on the TV unit.)
Pattern Generator,
Color analyzer
Figure
x: 285 to 295,
y: 295 to 305
It carries out in a darkroom.
Perpendicularity
L = 3 cm
INPUT: WHITE 80%
1. Operate the unit for more than 20 minutes.
2. Input the White Purity.
3. Set the color analyzer to the CHROMA mode and bring the optical receptor to the center on the LCD-Panel surface after zero point calibration as shown above. Note: The optical receptor must be set perpendicularly to the LCD Panel surface.
4. [RF/AV2(CVBS)] Enter the Service mode. Press “VOL p” button on the remote control unit and select “C/D/S-1” mode.
[AV1(RGB)]
Enter the Service mode. Press “VOL p” button on the remote control unit and select “C/D/S-2” mode.
5. [RF/AV2(CVBS)]----(APL 80%) Press “6” button to select “DB(C/D/S-1)” for Blue adjustment. Press “4” button to select “DR(C/D/S-
1)” for Red adjustment. When “x” value and “y” value are not within specification, adjust “DB (C/D/ S-1)” or “DR (C/D/S-1)”. Refer to “1. Initial Setting.”
[RF/AV2(CVBS)]----(APL 40%)
Press “3” button to select “COB(C/D/S-1)” for Blue adjustment. Press “1” button to select “COR(C/D/ S-1)” for Red adjustment. When “x” value and “y” value are not within specification, adjust “COB (C/ D/S-1)” or “COR (C/D/S-1)”. Refer to “1. Initial Setting.”
Color Analyzer
6-3 L4620EA
BLOCK DIAGRAMS
System Control Block Diagram
AL+5V
FUNCTION CBA
KEY SWITCH
KEY SWITCH
CN31B
KEY-IN-122
KEY-IN-211
CN106
RCV51
CLN53
CN53
POWER
IR SENSOR CBA
D51
SENSOR
REMOTE
RCV-IN33
TO LCD BACKLIGHT
PROTECT-1
BACKLIGHT-ADJ
CN102A
RCV-IN11
TO POWER SUPPLY
BLOCK DIAGRAM
BACKLIGHT-ADJ 22
BLOCK DIAGRAM
SCL
SDA
P-ON-H
PROTECT-1
PROTECT-113 13
P-25V-ON
PROTECT-2
P-ON-H66
PROTECT-214 14
AFT-IN11 11
INPUT-099
S-SW15 15
SCL18 18
SDA19 19
AFT-IN
S/C-JACK-MUTE
INPUT-110 10
TO IF/VIDEO
BLOCK DIAGRAM
FBIN
S-SW
INPUT-0
INPUT-1
RAPID-SW
VOLUME77
P-25V-ON21 21
SLOW-SW
RAPID-SW16 16
INSEL-MUTE
S/C-JACK-MUTE
SLOW-SW17 17
S/C-JACK-MUTE
14 14
SP-MUTE
INSEL-MUTE
15 15
TO AUDI O
BLOCK DIAGRAM
SCL
SDA
NICAM-RESET
NICAM-RESET
SP-MUTE18 18
FBIN22 22
20 20
VOLUME
MAIN CBALCD MAIN CBA UNIT
X151
10MHz
IC151
(MICRO COMPUTER)
CN301(NO CONNECTION)
5
DVP-RESET-PC8DVP-CLK-PC
DVP-SOUT-PC6DVP-SIN-PC7DVP-CS-PC4MPSEL-0 3
13
XIN
BUS-OPEN 2
11
XOUT
AL+5V
VCOM
TO LCD
5
IC153
VCOM
20
BLOCK DIAGRAM
4
RESET
83
MPSEL-0
LCD DRIVE / LCD
SIGNAL PROCESS
IC301
10
RESET
2DVP-RESET
79
AL+3.3V
3.3V<-->5V
Q152
RESET
2DVP-CLK
5
CONVERTER
Q153
57
MPWEH
2DVP-SIN
4
3.3V<-->5V
CONVERTER
Q154
59
MPOE
93
92
KEY-IN-1
KEY-IN-2
2DVP-SOUT
3
3.3V<-->5V
CONVERTER
Q155
585060
MPWEL
CN102B
16
26
RCV-IN
BUS-OPENV
2DVP-CS
2
3.3V<-->5V
CONVERTER
Q156
MPCE
895922
88
PROTECT-1
PROTECT-2
BACKLIGHT-ADJ
H-SYNC
25
3.3V<-->5V
CONVERTER
7
89
QH
HDIN/FBIN
91
AFT-IN
P-ON-H
277845
SCL
S-SW
CN103B CN103A
1
P-25V-ON
AL+5V
IC152
(MEMORY)
838519
23
87
SLOW-SW-IN
RAPID-SW-IN
SC-VIDEO-MUTE
EEP-SCL
34
6
7
WP
SCL
84INSEL-MUTE
SP-MUTE
NICAM-RESET
EEP-SDA
33
5
SDA
CN105(NO CONNECTION)
EEP-SDA 2
EEP-SCL 1
BUS-OPEN 4
CN105 IS
USED FOR
ADJUSTMENT
AT FACTORY
24
46
28
SDA
INPUT-0
INPUT-1
VOLUME
7-1
L4620BLS
IF/Video Block Diagram
K
TO
LCD BLOC
DIAGRAM
CN103B
CVBS18
S-VIDEO-C5
VIDEO-R1
S-VIDEO-Y6
VIDEO-G2
VIDEO-B3
CVBS29
AUDIO SIGNAL
MAIN CBA
VIDEO SIGNAL
TO AUDIO BLOCK
DIAGRAM
SIF
AUDIO
14
IC781 (INPUT SELECT)
12
13
WF3
Q781
3
BUFFER
4
5
CN103A
WF6
TO
AUDI O
BLOCK DIAGRAM
15
INPUT-0(INV)
Q872
INPUT-0
TO
SYSTEM CONTROL
INPUT-1(INV)
Q871
INPUT-1
BLOCK DIAGRAM
11
10
SW
CONTROL
9
2
1
WF2
WF4
WF5
WF7
WF8
7
SIF
TU1
(TUNER UNIT)
6
AUDIO
Q11
BUFFER
17
16
AFT
VIDEO
9
SCL
BUFFER
Q744
Q730
10
SDA
SCL
SDA
AFT-IN
RAPID-SW
TO SYSTEM
CONTROL
BLOCK
FBIN
DIAGRAM
Q734
SLOW-SW
S/C-JACK-MUTE
S-SW
7-2
JK722
VIDEO1
-IN
Q791
CY
JK721
S-VIDEO
-IN
JK751
8
SLOW-SW
Q731
Q792
16
RAPID-SW
BUFFER
15
19
VIDEO-R
VIDEO-OUT
7
11
VIDEO-B
VIDEO-G
L4620BLIF
20
VIDEO-IN
Audio Block Diagram
SP802
SPEAKER
L-CH
CLN310
GND 2
SP-L 1
CN310
INVERTER CBA
CN304
SP-L22
GND11
CN404
JK801
HEADPHONE
JACK
WF1
SP801
SP-R 1
CN801
SPEAKER
R-CH
CLN801
GND 2
TO SYSTEM
CONTROL
S/C-JACK-MUTE
SP-MUTE
INSEL-MUTE
BLOCK
VOLUME
TO IF/VIDEO
BLOCK
DIAGRAM
INPUT-0(INV)
INPUT-1(INV)
AUDIO SIGNAL
AUTOMATIC
FM/AM
PRESCALE
dBX/MNR
PANDA1
DEMODULATOR
A/D
CONVERTER
SOUND
SELECT
NICAM
PRESCALE
DEEMPHASIS
STANDERD
AND SOUND
DETECTION
I2C
SOUND
SELECT
I2C READ
REGISTER
DECORDER
SCART1
CHANNEL
MATRIX
VOLUME
D/A
CONVERTER
SCART1 OUTPUT SELECT
11
AMP
TUNER
AUDIO1
421
(L-CH)
6
3
AUDIO2
IC801 (AUDIO AMP)
IC871 (INPUT SELECT)
(L-CH)
VOLUME
MUTE
/STANDBY
14
AMP
7
2
CONTROL
(R-CH)
1
13
9 10
AUDIO2
12
SW CTL
INH
6
(R-CH)
TUNER
AUDIO1
11
15
IC831 (SOUND PROCESSOR)
MAIN CBA
JK751
Q733
Q732
6
AUDIO2(L)
-IN2AUDIO2(R)
-IN
Q741
Q742
BUFFER
1
AUDIO2(R)
-OUT
BUFFER
3
AUDIO2(L)
-OUT
L4620BLA
AGC
2
12
13
SCL
SDA
TO SYSTEM
CONTROL
BLOCK
RESET
22
NICAM-RESET
DIAGRAM
R-CH
43
30
SIF
AUDI O
TO IF/VIDEO
BLOCK
DIAGRAM
L-CH
31
AUDIO1(L)
JK723
-IN
JK724
AUDIO1(R)
-IN
7-3
LCD Block Diagram
LCD MODULE
OR(3)31OR(4)30OR(5)
OR(0)34OR(1)33OR(2)
32
29
CN311
VIDEO SIGNAL
TP322
TP323
182
181
180
179
175
174
173
169
OG(0)27OG(1)26OG(2)
25
168
167
166
OG(3)24OG(4)23OG(5)
165
161
160
OB(0)20OB(1)19OB(2)
22
TP318
TP319
159
158
OB(3)17OB(4)16OB(5)
18
155
154
153
152
15
151
ER(0)6ER(1)5ER(2)
4
TP320
TP321
150
146
145
ER(3)3ER(4)2ER(5)
1
143
142
141
140
139
135
TP316
TP317
134
133
EG(0)50EG(1)49EG(2)
CN312
132
131
130
48
129
EG(3)47EG(4)46EG(5)
45
TP312
128
127
123
EB(0)43EB(1)42EB(2)
41
TP313
121
120
122
EB(3)40EB(4)39EB(5)
38
119
116
115
114
TP314
TP315
113
106
LCD MAIN CBA UNIT
IC301 (LCD DRIVE / LCD SIGNAL PROCESS)
R
CVBSYC
A/D
21
G
VIDEO
SIGNAL
A/D
33
44
OUTPUT
CONTROL
B
PROCESS
A/D
31
B
SECAM PDM
QDRVVA
103
R905
WF14WF13
R907
QDRVHE
98
PANEL
SIGNAL
TV
SIGNAL
XIN XOUT
PROCESS
PROCESS
85
84
TO
Q971
IC981
X301
54MHz
SYSTEM
CONTROL
VCOM
VCOM
R
PANEL+10.8V
BLOCK
DIAGRAM
CONTROL
G
B
WF12
WF11
WF10
WF9
BURST
QDRVHC
97
R904
G
LOCKED
QDRVHB
QDRVHA/QDE
95
91
R901
R902
QDRVHC
96
R997
CHROMA
DECODER
RCO
QDRVVB
QCLKL
104
105
R
NTSC/PAL
SEPARATION
INPUT
CONTROL
A/D
134240
CN103B
VIDEO-R 1
2
VIDEO-B 3
VIDEO-G
S-VIDEO-C 5
TO
IF/VIDEO
BLOCK
6
CVBS1 8
CVBS2 9
S-VIDEO-Y
DIAGRAM
CN103A
CN311
LP 44
POL 43
LCD MODULE
CN312
STH1 42
CLKH 10
HMS1-E 7
HMS1-O 13
STV1 13
CLKV 14
VREF(0) 32
VREF(4) 28
VREF(1) 31
VREF(2) 30
VREF(3) 29
VREF(7) 24
VREF(5) 26
VREF(6) 25
7-4
4
36
VCOM 35
VCOM
VCOM 3
VCOM
VREF(8) 23
VREF(9) 22
L4620BLLCD
Power Supply Block Diagram
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
CAUTION !
For continued protection against fire hazard,
replace only with the same type fuse.
REG+3.3V
REG+1.8V
LCD MAIN CBA UNIT
CN103B
CN103A
AL+3.3V
AL+3.3V10 10
AL+5V11 11 AL+5V
IC101
AL+5V(D)12 12
+3.3V
AL+4V(D)13 13
REG
IC102
+1.8V
REG
IC606
+3.3V REG.
IC602
+5V REG.
PANEL+10.8V
PANEL+25V
PANEL+3.3V
CN101B
PANEL-6V
PANEL+25V
PANEL+3.3V
PANEL+10.8V
99PANEL-6V
66
33
11
CN101A
+10.8V REG.
Q503
AL+33V
AL+3.3V
AL+7.5V
AL+5V
+5V REG.
Q633
IC605
T-ON+5V
AL+12V
+5V REG.
TO INVERTER
BLOCK DIAGRAM
AL+40V
INV+22V
Q506
Q507
-6V REG.
Q505
Q504
P-ON-H
+25V REG.
Q501
P-25V-ON
Q502
TO SYSTEM CONTROL
BLOCK DIAGRAM
PROTECT-1
PROTECT-2
MAIN CBA
Q632
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F601) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
HOT CIRCUIT. BE CAREFUL.
T601
HOT COLD
D605-D608
L601
F601
T4A L 250V
AC601
AC CORD
16
4
BRIDGE
RECTIFIER
LINE
FILTER
13
10
12
2
Q608
15
14
6
Q603
7-5
9
11
1
4
7
IC601
2
3
ERROR
VOLTAGE
DET
L4620BLP
LCD Backlight Block Diagram
BACK
LIGHT
1
2
CN301
OVER VOLTAGE
PROTECTOR
Q322,323
BACK
1
CN302
LIGHT
2
OVER VOLTAGE
PROTECTOR
Q342,343
BACK
1
CN303
LIGHT
2
OVER VOLTAGE
PROTECTOR
Q362,363
LCD MODULEINVERTER CBA
OVER VOLTAGE
PROTECTOR
Q304
Q305
+22V44
+10V REG.
Q306
+22V77
+22V66
+22V55
+22V88
+22V99
9
10
T301
3
614
CURRENT
CONTROL
Q321
PROTECT-133
8
5
SWITCH
7
2
Q324
T302
9
3
10
614
CURRENT
CONTROL
Q341
8
5
SWITCH
Q344
7
2
T303
9
3
10
614
CURRENT
CONTROL
Q361
8
5
SWITCH
Q364
7
2
OVER CURERENT
PROTECTOR
Q325
MAIN CBA
CN404 CN304
Q401
INV+22V
TO
POWER
SUPPLY
Q402
AL+40V
BLOCK
DIAGRAM
Q403
BACKLIGHT
-ADJ
TO
SYSTEM
CONTROL
PROTECT-1
BLOCK
DIAGRAM
7-6
L4620BLLB
SCHEMATIC DIAGRAMS / CBA'S AND TEST POINTS
Standard Notes
Many electrical and mechanical parts in this chassis have special characteristics. These characteristics often pass unnoticed and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts that have these special safety characteristics are identified in this manual and its supplements; electrical components having such features are identified by the mark “!” in the schematic diagram and the parts list. Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement parts that do not have the same safety characteristics as specified in the parts list may create shock, fire, or other hazards.
Notes:
1. Do not use the part number shown on these drawings for ordering. The correct part number is shown in the parts list, and may be slightly different or amended since these drawings were prepared.
2. All resistance values are indicated in ohms (K = 10
3. Resistor wattages are 1/4W or 1/6W unless otherwise specified.
4. All capacitance values are indicated in µF (P = 10
5. All voltages are DC voltages unless otherwise specified.
Note of Capacitors:
ML --- Mylar Cap. PP --- Metallized Film Cap. SC --- Semiconductor Cap. L --- Low Leakage type
Temperature Characteristics of Capacitors are noted with the following:
B --- ±10% CH --- 0±60 ppm/°C CSL --- +350~-1000 ppm/°C
3
, M = 106).
-6
µF).
Tolerance of Capacitors are noted with the following:
Z --- +80~-20%
Note of Resistors:
CEM --- Cement Res. MTL --- Metal Res. F --- Fuse Res.
Capacitors and transistors are represented by the following symbols.
CBA Symbols
(Top View) (Bottom View)
+
Electrolytic Capacitor
(Bottom View)
Transistor or Digital Transistor
E C B
(Top View)
NPN Transistor
E C B
(Top View)
(Top View)
PNP Transistor
E C B
(Top View)
Schematic Diagram Symbols
Digital Transistor
E C B
NPN Digital Transistor
PNP Digital Transistor
E C B
8-1 LC4P_SC
LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES:
1. CAUTION:
FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE.
2. CAUTION:
Fixed Voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F601) is blown, first check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail.
3. Note:
1. Do not use the part number shown on the drawings for ordering. The correct part number is shown in the parts list, and may be slightly different or amended since the drawings were prepared.
2. To maintain original function and reliability of repaired units, use only original replacement parts which are listed with their part numbers in the parts list section of the service manual.
4. Voltage indications on the schematics are as shown below:
Plug the TV power cord into a standard AC outlet.:
2
(Unit: Volt)
1
5.0 5.0
3
Power on mode
5. How to read converged lines
1-D3
Distinction Area
Line Number (1 to 3 digits)
Examples:
1. "1-D3" means that line number "1" goes to the line number "1" of the area "D3".
2. "1-B1" means that line number "1" goes to the line number "1" of the area "B1".
6. Test Point Information
: Indicates a test point with a jumper wire across a hole in the PCB.
: Used to indicate a test point with a component lead on foil side.
: Used to indicate a test point with no test pin.
: Used to indicate a test point with a test pin.
Voltage
Indicates that the voltage is not consistent here.
3
2
1
AREA D3
1-B1
AREA B1
1-D3
ABCD
8-2 LC4P_SC
Main 1/4 Schematic Diagram
8-3
L4620SCM1
Main 2/4 Schematic Diagram
CN103A
10.1
20.4
30.2 40
52.6
62.6 70
81.7
90.2 10 0 11 3.5 12 5.2 13 6.9 14 3.1 15 0 16 4.8 17 0 18 5.2 19 0 20 5.2 21 3.3 22 3.1 23 0
VOLTAGE CHART
Pin No. Voltage
8-4
L4620SCM2
Main 3/4 Schematic Diagram
CN101A
1 10.8 20
33.4
40 50 6 25.9 70 80 9-6.3
VOLTAGE CHART
Pin No. Voltage
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F601) is blown , check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail.
CAUTION !
For continued protection against fire hazard, replace only with the same type fuse.
NOTE:
The voltage for parts in hot circuit is measured using hot GND as a common terminal.
8-5 L4620SCM3
Main 4/4 & IR Sensor Schematic Diagram
CN102A
13.8
20
30.1
45.2
55.2
63.3
70.2
80
92.0 10 0 11 4.4 12 0.4 13 3.8 14 1.5 15 3.4 16 0 17 0 18 5.2 19 5.2 20 0 21 0 22 0 23 0
VOLTAGE CHART
Pin No. Voltage
8-6
L4620SCM4
Function Schematic Diagram
8-7
L4620SCF
Inverter Schematic Diagram
8-8
L4620SCINV
LCD Main 1/2 Schematic Diagram
8-9
L4620SCL1
LCD Main 2/2 Schematic Diagram
8-10
L4620SCL2
Main CBA Top View
Because a hot chassis ground is present in the power supply circut, an isolation transformer must be used. Also, in order to have the ability to increase the input slowly, when troubleshooting this type power supply circuit, a variable isolation transformer is required.
CAUTION !
For continued protection against fire hazard, replace only with the same type fuse.
NOTE:
The voltage for parts in hot circuit is measured using hot GND as a common terminal.
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F601) is blown , check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail.
8-11
BL4520F01011-1
Main CBA Bottom View
Because a hot chassis ground is present in the power supply circut, an isolation transformer must be used. Also, in order to have the ability to increase the input slowly, when troubleshooting this type power supply circuit, a variable isolation transformer is required.
CAUTION !
For continued protection against fire hazard, replace only with the same type fuse.
NOTE:
The voltage for parts in hot circuit is measured using hot GND as a common terminal.
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F601) is blown , check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail.
WF8
PIN 8 OF CN103A
WF7
PIN 9 OF CN103A
WF4
PIN 3 OF CN103A
WF6
PIN 1 OF CN103A
WF5
PIN 2 OF CN103A
WF2
PIN 1 OF IC781
WF3
PIN 13 OF IC781
8-12
WF1
PIN 14 OF IC801
BL4520F01011-1
IR Sensor CBA Top & Bottom ViewFunction CBA Top View
BL4520F01011-3
Function CBA Bottom View
BL4520F01011-2
8-13
Inverter CBA Top View
Inverter CBA Bottom View
8-14
BL2500F01021
WAVEFORMS
WF1 ~ WF8 = Waveforms to be observed at
Waveform check points. (Shown in Schematic Diagram.)
Input: PAL Color Bar Signal (with 1kHz Audio Signal)
WF1
Pin 14 of IC801
WF4
Pin 3 of CN103A
WF7
Pin 9 of CN103A
AUDIO 0.1V 0.5ms
WF2
Pin 1 of IC781
S-VIDEO-Y 0.2V 10µs
WF3
Pin 13 of IC781
B 0.5V 5µs
WF5
Pin 2 of CN103A
G 0.5V 20µs
WF6
Pin 1 of CN103A
CVBS2 0.2V 20µs
WF8
Pin 8 of CN103A
CVBS1 0.2V 20µs
S-VIDEO-C 0.2V 20µs
R 0.5V 10µs
9-1
L4620WF
WF9 ~ WF14 = Waveforms to be observed at
Waveform check points. (Shown in Schematic Diagram.)
Input: PAL Color Bar Signal (with 1kHz Audio Signal)
WF9
R997
WF12
R904
CTKH 1V 20ns
WF10
WF11
R902
STH1 1V 1µs
R901
LP 1V 10µs
WF13
R907
STV1 1V 5ms
WF14
R905
POL 1V 20µs
9-2
CLKV 1V 10µs
L4620WF
WIRING DIAGRAMS
LCD MAIN CBA UNIT
CN103B
VIDEO-B
VIDEO-G
VIDEO-R
CN103A
CN102A
RCV-IN
NU
BACKLIGHT-ADJ
1325476
CN102B
SP-R2GND
CN801
1
CLN801
SP801
SPEAKER
R CH
6
8
7
51342
GND
CVBS1
S-VIDEO-Y
GND
S-VIDEO-C
6
8
7
51342
6
8
7
51342
NUNUP-ON-H
VOLUME
AUDIO-MUTE(NU)
8
123456789
JK751
CN105 IS
USED FOR
ADJUSTMENT
AT FACTORY
< NO CONNECTION >
132
4
GND
CN105
EEP-SCL
EEP-SDA
BUS-OPEN
9
CVBS2
9
9
INPUT-0
9
13
12
11
10
AL+5V
AL+4V(D)
AL+3.3V
AL+5V(D)
13
12
11
10
10
12
13
11
PROTECT-1
AGC-IN
INPUT-1
AFT-IN
10131211141517161918212022
1325476
GND
CN301
BUS-OPEN
17
16
RAPID-SW
SP-MUTE
SLOW-SW
17
16
172220
18
16
GND
PROTECT-3(NU)
SCL
DVP-SIN-PC
DVP-CLK-PC
DVP-SOUT-PC
19
NU
19
19
SDA
8
DVP-RESET-PC
152018
14
S/C-JACK-MUTE
INSEL-MUTE
152018
14
15
14
PROTECT-2
S-SW
1011121314151617181920
< NO CONNECTION >
MPSEL-0
DVP-CS-PC
23
22
21
P-25V-ON
NU
FBIN
NICAM-RESET
23
22
21
23
21
NU
NU
GND
NU
23
21
132
CN31B
KEY-IN-2
132
CN106
2
PANEL+10.8V
GND
1
24365
CN101A CN101B
FUNCTION
CBA
4
5
KEY-IN-1
AL+5VNUGND
4
5
413
GND
GND
PANEL+3.3V
PANEL+25V
GND
GND
789
CN404
CN304
95786
PANEL-6V
153
2
SP-L
SP-GND
153
2
4
+22V
PROTECT-1
4
1
CN301
+22V
2
AC CORD
AC601
6
+22V
+22V
6
7
978
+22V
+22V
9
8
CN302
CLN53
AL+5V
1
CN53
AL+5V
MAIN CBA
10
GND
10
2
1
GND
2
GND
GND
11
RCV-IN
P-ON-H(NU)
3
4
RCV-IN
P-ON-H(NU)
121113
GND
GND
12
13
IR SENSOR
CBA
GND
51342
5
GND
TU1 TUNER UNIT
14
15
GND
GND
14
15
2
1
CN303
AUDIO(R)
-IN
AUDIO(L)
-IN
VIDEO
-IN
S-VIDEO
IN
SP802
SPEAKER
CLN310
1
2
GND
SP-L
CN310
L CH
INVERTER CBA
ER(3)
ER(4)
ER(5)
CN311
1325476
1
2NU3
GND
VCOM4VCOM
CN312
ER(2)
ER(0)
ER(1)
5
6
TEST
PANEL+25V
HMS1-E
8
7
8
TEST
PANEL+3.3V
GND
HMS1-O
GND
OB(5)
OB(4)
OB(3)
OB(2)
OB(1)
OB(0)
GND
OG(5)
9
101312111415171619182120222324272625282930
9
10
11NU12
13
14
15NU16
17NU18NU19NU20NU21
NU
PANEL-6V
OFFEV
STV1
CLKV
GND
OG(4)
22
GND
VREF(9)23VREF(8)24VREF(7)25VREF(6)26VREF(5)
GND
CLKH
GND
GND
OG(3)
OG(2)
10-1
OG(1)
OG(0)
GND
27
28
GND
VREF(4)29VREF(3)30VREF(2)31VREF(1)
OR(5)
OR(4)
OR(3)
OR(2)
OR(1)
33
323134353736393840
32
333435
VREF(0)
PANEL+3.3V PANEL+10.8V
BACK
LIGHT
OR(0)
GND
GND
PANEL+3.3V
36
37
GND
VCOM
VCOM
PANEL+10.8V
BACK
PANEL+3.3V
PANEL+3.3V
PANEL+3.3V
38
EB(5)39EB(4)40EB(3)
LIGHT
GND
STH1
4241444345
41
42
EB(2)
EB(1)
POLLPGND
434445
GND
EB(0)
EG(5)
PANEL+3.3V
BACK
LIGHT
46
EG(4)47EG(3)48EG(2)49EG(1)50EG(0)
LCD MODULE
L4620WI
Cabinet
EXPLODED VIEWS
A1
B18
B18
B18
SP801
LCD Main CBA Unit & Liquid Crystal Panel Unit
B5
B14
A18
B5
L4
IR Sensor CBA
B18
L25
CLN801
L22
See Electrical Parts List for parts with this mark.
Comparison Chart of Models and Marks
Model Mark
LCD-A2006 LCD-B2006 LCD-C2006 LCD-D2006
A B C D
B18
SP802
B5
B5
A7
CLN310
B14
B17
L22
B14
L4
B12
L9
L4
B4
L4
B9
A3
Function CBA
L4
B13
B17
L7
L21
Main CBA
L21
AC601
L4
L22
L22
L21
B18
B34
L21
L21
[ B ]
B3
L23
B5
L9
L21
Inverter CBA
L21
B10
L16
B22
AC601
[ A, C, D ]
B18
B18
L9
A9-2
B5
A9-4
A9-7
A9-3
L17
A9
L9
A9-5
L27
B18
A9-5
A9-4
A6
A4
L9
L9
L17
L9
S5
A9-1
A9-4
A9-6
A9-5
11-1 L4620CEX
Packing
X5
X3
[ A ]
X2-1, X2-2, X2-3, X2-4, X2-5, X2-6, X2-7, X2-12
[ B ]
X2-1
Tape
[ C ]
X2-2, X2-3, X2-4
X1
[ D ]
X2-1, X2-3, X2-8, X2-9, X2-10, X2-11, X2-16, X2-17
S4
Packing Tape
Comparison Chart of Models and Marks
Model Mark
LCD-A2006 LCD-B2006 LCD-C2006 LCD-D2006
S2
A B C D
Packing Tape
FRONT
S1
Some Ref. Numbers are not in sequence.
S5
S3
Packing Tape
Packing Tape
11-2 L4620PEX
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety. Before replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing.
NOTE: Parts that are not assigned part numbers (---------) are not available.
Comparison Chart of Models and Marks
Model Mark
LCD-A2006 A
LCD-B2006 B
LCD-C2006 C
LCD-D2006 D
PARTS produced in CHINA
Ref. No. Mark Description Part No.
A1 FRONT CABINET L4620EA 1EM021481
A3 CONTROL PLATE L4520EA 1EM322205
A4 REAR CABINET L4620EA 1EM021437
A7 FUNCTION KNOB L4520EA 1EM322204
A9 TILT STAND ASSEMBLY L4620EA 1ESA13376
A9-1 STAND COVER L3216UJ 1EM221416
A9-2 ARM HOLDER L3219UK 1EM221304
A9-3 ARM ASSEMBLY L3219UK 1EM221283
A9-4 STAND RUBBER FOOT L4300UA 1EM422534
A9-5 SCREW P-TIGHT M3X8 BIND HEAD+
A9-6 SHEET R L3219UK 1EM322093
A9-7 SHEET L L3219UK 1EM322098
A18 FRONT PLATE L4620EA 1EM221414
B3 STAND HOLDER L2500UA 1EM321428
B4 JACK HOLDER L4520EA 1EM121697
B5 CLOTH(10X30XT0.5) B5900UA 0EM404486
B9 INSULATION SHEET L4520EA 1EM423590
B12 TILT STAND HOLDER L3253UD 1EM321693
B13 CLOTH(15X10XT0.5) L9700UA 0EM405038
B14 SPEAKER HOLDER L4620EA 1EM423593
B17 WASHER 10X5XT0.5 L4620EA 1EM423834
B18 CLOTH(10X190XT0.3) L0200UA 1EM420019
B34 CLOTH 10X150XT1.0 1EM421092
CLN310 WIRE ASSEMBLY 2PIN SPEAKER 2PIN
CLN801 WIRE ASSEMBLY 2PIN 2PIN 360MM
L4 SCREW P-TIGHT M3*10
L9 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L23 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L25 ASSEMBLED SCREW M3X10 1EM420633A
SP801 SPEAKER S0407F10 DSD0807XQ002
SP802 SPEAKER S0407F10 DSD0807XQ002
BLK
310MM WHITE RED
AWG2 6
WASHERHEAD+
ACCESSORY
X1 REMOTE CONTROL NF007RD 192/
ERC001/NF007RD
GBHP3080
WX1L4620-004
WX1L4620-003
GCJP3100
NF007RD
PARTS produced in EU
Ref. No. Mark Description Part No.
A6 A RATING LABEL L4620EA ----------
A6 B RATING LABEL L4621BB ----------
A6 C RATING LABEL L4622FC ----------
A6 D RATING LABEL L4623RD ----------
L7 DOUBLE SEMS SCREW M4X12 + BLAK FPH34120
L9 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L17 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L21 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L22 SCREW P-TIGHT 3X14 WASHER
L27 SCREW P-TIGHT M4X18 BIND HEAD+ GBHP4180
HEAD+
PACKING
S1 A CARTON L4620EA 1EM423567
S1 B CARTON L4621BB 1EM423734
S1 C CARTON L4622FC 1EM423737
S1 D CARTON L4623RD 1EM423740
S2 STYROFOAM TOP L4620EA 1EM121694
S3 STYROFOAM BOTTOM L4620EA 1EM121695
S4 SET BAG L0301UB 1EM320014A
S5 A SERIAL NO. LABEL L4620EA ----------
S5 B SERIAL NO. LABEL L4621BB ----------
S5 C SERIAL NO. LABEL L4622FC ----------
S5 D SERIAL NO. LABEL L4623RD ----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2-1! A,B,D OWNERS MANUAL(EN) L4520EA 1EMN21927
X2-2! A,C OWNERS MANUAL(FR) L4520EA 1EMN21928
X2-3! A,C,D OWNERS MANUAL(DE) L4520EA 1EMN21929
X2-4! A,C OWNERS MANUAL(IT) L4520EA 1EMN21930
X2-5! A OWNERS MANUAL(ES) L4520EA 1EMN21931
X2-6! A OWNERS MANUAL(NL) L4520EA 1EMN21932
X2-7! A OWNERS MANUAL(SV) L4520EA 1EMN21933
X2-8! D OWNERS MANUAL(RU) L4523RD 1EMN21936
X2-9! D OWNERS MANUAL(PL) L4523RD 1EMN21937
X2-10! D OWNERS MANUAL(HU) L4622FC 1EMN21938
X2-11! D OWNERS MANUAL(CS) L4523RD 1EMN21939
X2-12! A OWNERS MANUAL(EL) L4520EA 1EMN21934
X2-16! D OWNERS MANUAL(SK) L4523RD 1EMN21940
X2-17! D OWNERS MANUAL(AR) L4523RD 1EMN21942
GCJP3140
20060619 12-1 L4620CA
Service Manual Supplement
k
A
k
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
20070719
LCD-A2006/LCD-B2006/LCD-D2006(L4650EA/51BB/53RD) Factory Changed Model
Mar
Model
LCD-A2006(L4650EA) B LCD-B2006(L4651BB) C LCD-D2006(L4653RD)
This service manual is for the LCD-A2006(L4650EA)/LCD-B2006(L4651BB)/LCD-D2006(L4653RD) Factory Changed Model, which is different from the LCD-A2006(L4620EA)/LCD-B2006(L4621BB)/LCD­D2006(L4623RD) model. For the LCD-A2006(L4650EA)/LCD-B2006(L4651BB)/LCD-D2006(L4653RD) Factory Changed Model, the letter (L4650EA/L4651BB/L4653RD) is printed on the Serial No. Label. Refer to the Serial No. Label illustration below. The different parts are shown below, and the rest of the parts are the same as the previous model. Refer to the original Service Manual for the other information.
LCD-B2006LCD-A2006
Serial No. Label
"L4650EA"
Serial No. Label
"L4651BB"
LCD-D2006
Serial No. Label
"L4653RD"
Ref. No.
Mar
Description Parts No.
MECHANICAL PARTS S1
CARTON L4620E
1EM423567 S1 B CARTON L4621BB 1EM423734 S1 C CARTON L4623RD 1EM423740 S5 SERIAL NO. LABEL L9750U X2-1 ! X2-2 ! X2-3 ! A,C X2-4 ! X2-5 ! X2-6 ! X2-7 !
OWNERS MANUAL(EN) L4520E OWNERS MANUAL(FR) L4520E OWNERS MANUAL(DE) L4520E OWNERS MANUAL(IT) L4520EA 1EMN21930B OWNERS MANUAL(ES) L4520E OWNERS MANUAL(NL) L4520E OWNERS MANUAL(SV) L4520E
----------
1EMN21927B
1EMN21928B
1EMN21929B
1EMN21931B
1EMN21932B
1EMN21933B X2-8 ! C OWNERS MANUAL(RU) L4523RD 1EMN21936B X2-9 ! C OWNERS MANUAL(PL) L4523RD 1EMN21937B X2-10 ! C OWNERS MANUAL(HU) L4622FC 1EMN21938B X2-11 ! C OWNERS MANUAL(CS) L4523RD 1EMN21939B X2-12 !
OWNERS MANUAL(EL) L4520E
1EMN21934B X2-16 ! C OWNERS MANUAL(SK) L4523RD 1EMN21940B X2-17 ! C OWNERS MANUAL(AR) L4523RD 1EMN21942B
1 / 1 page
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety. Before replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------) are not available.
2. Tolerance of Capacitors and Resistors are noted with the following symbols.
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Comparison Chart of Models and Marks
Model Mark
LCD-A2006 A
LCD-B2006 B
LCD-C2006 C
LCD-D2006 D
PARTS produced in CHINA
LCD MAIN CBA UNIT & LIQUID CRYSTAL PANEL UNIT
Ref. No. Description Part No.
LCD MAIN CBA UNIT & LIQUID CRYSTAL PANEL UNIT
MMA CBA
Ref. No. Description Part No.
MMA CBA Consists of the following:
MAIN CBA FUNCTION CBA IR SENSOR CBA
MAIN CBA
Ref. No. Description Part No.
MAIN CBA Consists of the following:
CAPACITORS
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C12 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M or CA0K101SP085
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101 C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C15 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M or CA1A101SP085
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTM101 C16 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C17 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M or CA1J1R0SP085
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0 C18 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
1FSA10148
1ESA13367
----------
----------
----------
----------
Ref. No. Description Part No.
C20 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M or CA1C100SP085 ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C21 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085 ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C501 ELECTROLYTIC CAP. 22µF/50V M H7 or CE1JMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/50V H7 CE1JMAVSM220 C502 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C503 ELECTROLYTIC CAP. 220µF/16V M H7 or CE1CMASSL221
ELECTROLYTIC CAP. 220µF/16V M H7 CE1CMASSM221 C504 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C505 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C506 ELECTROLYTIC CAP. 100µF/10V M H7 or CE1AMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/10V H7 CE1AMAVSM101 C507 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C512 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C513 ELECTROLYTIC CAP. 220µF/6.3V M H7 or CE0KMAVSL221
ALUMINUM ELECTROLYTIC CAP 220µF/6.3V H7 CE0KMAVSM221 C517 ELECTROLYTIC CAP. 100µF/16V M H7 or CE1CMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/16V H7 CE1CMAVSM101 C527 ELECTROLYTIC CAP. 10µF/50V M H7 or CE1JMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/50V H7 CE1JMAVSM100 C536 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331 C601! METALIZED FILM CAP. 0.1µF/250V or CT2E104MS037
! ACROSS THE LINE CAP. 0.1µF/250V K or CT2E104DC011
! ACROSS THE LINE CAP. 0.1U/250V CT2E104DC015 C602! METALIZED FILM CAP. 0.1µF/250V or CT2E104MS037 ! ACROSS THE LINE CAP. 0.1µF/250V K or CT2E104DC011
! ACROSS THE LINE CAP. 0.1U/250V CT2E104DC015
C608 CERAMIC CAP. BN 470pF/2KV or CCD3DKA0B471
CERAMIC CAP. 470pF/2KV or CA3D471PAN04
CERAMIC CAP. RB 470pF/2KV or CA3D471TE006
CERAMIC CAP. BL 470pF/2KV CA3D471XF003 C610! CAP ELE LQ SERIES 150µF/400V/M/85 CA2H151NC234 C612 FILM CAP.(P) 0.01µF/50V J or CMA1JJS00103
FILM CAP.(P) 0.01µF/50V J or CA1J103MS029
POLYESTER FILM CAP. (PB FREE) 0.01µF/100V JCA2A103DT018
C613 FILM CAP.(P) 0.068µF/50V J or CMA1JJS00683
FILM CAP.(P) 0.068µF/50V J or CA1J683MS029
POLYESTER FILM CAP. (PB FREE) 0.068µF/
100V J C614 FILM CAP.(P) 0.001µF/50V J or CMA1JJS00102
FILM CAP.(P) 0.001µF/50V J or CA1J102MS029
POLYESTER FILM CAP. (PB FREE) 0.001µF/
100V J C631! ELECTROLYTIC CAP. 2200µF/25V M or CE1EMZPDL222
! ALUMINUM ELECTROLYTIC CAP 2200µF/25V M orCE1EMZNTM222
! ELECTROLYTIC CAP. 2200µF/25V M CE1EMZNDL222 C632! ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100 ! ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085 ! ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100 C633! ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221 ! ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085 ! ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221 C635! ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471 ! ELECTROLYTIC CAP. 470µF/16V M or CA1C471SP085 ! ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471 C636! ELECTROLYTIC CAP. 220µF/50V M or CE1JMASDL221 ! ELECTROLYTIC CAP. 220µF/50V M or CA1J221SP085 ! ELECTROLYTIC CAP 220µF/50V M CE1JMASTM221 C637! ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471 ! ELECTROLYTIC CAP. 470µF/16V M or CA1C471SP085
CA2A683DT018
CA2A102DT018
20060619 13-1 L4620EL
Ref. No. Description Part No.
! ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C641! SAFETY CAP. 2200pF/250V KX CA2E222MR050 C643 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224 C645 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331
C646 FILM CAP.(P) 0.082µF/50V J or CMA1JJS00823
FILM CAP.(P) 0.082µF/50V J or CA1J823MS029 POLYESTER FILM CAP. (PB FREE) 0.082µF/
100V J
C647 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331 C648 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224 C649 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 470µF/10V M or CA1A471SP085
ELECTROLYTIC CAP. 470µF/10V M CE1AMASTM471 C650 ELECTROLYTIC CAP. 330µF/25V M or CE1EMASDL331
ELECTROLYTIC CAP. 330µF/25V M or CA1E331SP085
ALUMINUM ELECTROLYTIC CAP 330µF/25V M CE1EMASTM331 C651 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/6.3V H7 CE0KMAVSM470 C652 ELECTROLYTIC CAP. 10µF/50V M H7 or CE1JMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/50V H7 CE1JMAVSM100 C653 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 470µF/10V M or CA1A471SP085
ELECTROLYTIC CAP. 470µF/10V M CE1AMASTM471 C654 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C655 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M or CA0K471SP085
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471 C656 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M or CA1J1R0SP085
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0 C657 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C659 FILM CAP.(P) 0.022µF/50V J or CMA1JJS00223
FILM CAP.(P) 0.022µF/50V J or CA1J223MS029
POLYESTER FILM CAP. (PB FREE) 0.022µF/
100V J C660 FILM CAP.(P) 0.0068µF/50V J or CMA1JJS00682
FILM CAP.(P) 0.0068µF/50V J or CA1J682MS029
POLYESTER FILM CAP. (PB FREE) 0.0068µF/
100V J C663 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224 C664 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331
C702 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101 C703 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C707 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C710 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101 C711 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C712 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562 C713 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C714 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562 C715 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C716 CERAMIC CAP.(AX) CH J 560pF/50V CCK1JJTCH561 C717 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C718 CERAMIC CAP.(AX) CH J 560pF/50V CCK1JJTCH561 C719 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225 C720 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225 C721 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225 C722 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225 C723 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225 C730 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473 C742 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
CA2A823DT018
CA2A223DT018
CA2A682DT018
Ref. No. Description Part No.
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470 C743 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225 C745 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470 C746 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225 C747 ELECTROLYTIC CAP. 33µF/16V M H7 or CE1CMAVSL330
ALUMINUM ELECTROLYTIC CAP 33µF/16V H7 CE1CMAVSM330 C751 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470 C753 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470 C756 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470 C758 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470 C761 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/6.3V H7 CE0KMAVSM101 C762 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C766 ELECTROLYTIC CAP. 100µF/16V M H7 or CE1CMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/16V H7 CE1CMAVSM101 C767 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104 C768 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331 C781 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C782 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470 C783 ELECTROLYTIC CAP. 10µF/50V M H7 or CE1JMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/50V H7 CE1JMAVSM100 C784 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104 C785 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470 C787 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470 C791 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C792 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/6.3V H7 CE0KMAVSM101 C801 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221 C802 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221 C810 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105 C811 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M or CA1C101SP085
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTM101 C812 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C813 PCB JUMPER D0.6-P5.0 JW5.0T
C814 PCB JUMPER D0.6-P5.0 JW5.0T C815 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M or CA1J1R0SP085
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0 C818 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M or CA1C471SP085
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C819 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C820 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102 C831 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103 C832 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C833 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C834 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C835 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C836 CHIP CERAMIC CAP. CH D 3pF/50V or CHD1JD3CH3R0
CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
20060619 13-2 L4620EL
Ref. No. Description Part No.
CHIP CERAMIC CAP. CJ C 3pF/50V CHD1JC3CJ3R0
C837 CHIP CERAMIC CAP. CH D 3pF/50V or CHD1JD3CH3R0
CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V CHD1JC3CJ3R0
C838 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C839 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101 C840 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M or CA1C100SP085
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100 C841 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103 C843 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M or CA0K101SP085
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101 C844 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C845 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C846 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C847 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M or CA1C100SP085
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100 C848 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104 C850 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M or CA1C100SP085
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100 C851 ELECTROLYTIC CAP. 3.3µF/50V M or CE1JMASDL3R3
ELECTROLYTIC CAP. 3.3µF/50V M or CA1J3R3SP085
ALUMINUM ELECTROLYTIC CAP 3.3µF/50V M CE1JMASTM3R3 C852 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104 C853 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104 C854 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M or CA1C100SP085
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100 C855 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474 C860 ELECTROLYTIC CAP. 2.2µF/50V M H7 or CE1JMAVSL2R2
ALUMINUM ELECTROLYTIC CAP 2.2µF/50V H7 CE1JMAVSM2R2
C861 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102 C871 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100 C872 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104 C873 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105 C874 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105 C875 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C876 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C877 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
CONNECTORS
CN53 CONNECTOR PRINT OSU B5B-PH-K-S (LF)(SN) J3PHC05JG029
CN101A TWG CONNECTOR 09P TWG-P09P-A1 J3TWA09TG001
CN102A TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN103A TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN404 TWG CONNECTOR 15P TWG-P15P-A1 J3TWA15TG001
CN801 CONNECTOR BASE 008283021100000S+ J383C02UG003
DIODES
D11 ZENER DIODE MTZJT-776.8B or QDTB0MTZJ6R8
ZENER DIODE DZ-6.8BSBT265 NDTB0DZ6R8BS
D12 ZENER DIODE MTZJT-776.8B or QDTB0MTZJ6R8
ZENER DIODE DZ-6.8BSBT265 NDTB0DZ6R8BS
D401 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D402 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D403 ZENER DIODE MTZJT-7718B or QDTB00MTZJ18
ZENER DIODE DZ-18BSBT265 NDTB00DZ18BS
D404 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D405 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D501 SWITCHING DIODE 1SS400 or QD1Z001SS400
Ref. No. Description Part No.
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D502 ZENER DIODE MTZJT-7724B or QDTB00MTZJ24
ZENER DIODE DZ-24BSBT265 NDTB00DZ24BS
D503 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D504 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D505 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D506 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D507 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D516 ZENER DIODE MTZJT-778.2B or QDTB0MTZJ8R2
ZENER DIODE DZ-8.2BSBT265 NDTB0DZ8R2BS
D524! ZENER DIODE MTZJT-778.2B or QDTB0MTZJ8R2
! ZENER DIODE DZ-8.2BSBT265 NDTB0DZ8R2BS
D605! DIODE 1N5399-B/P or NDLZ001N5399
! RECTIFIER DIODE ERB12-06 or QDQZ0ERB1206
! DIODE 1N5399BE NDL1001N5399
D606! DIODE 1N5399-B/P or NDLZ001N5399
! RECTIFIER DIODE ERB12-06 or QDQZ0ERB1206
! DIODE 1N5399BE NDL1001N5399
D607! DIODE 1N5399-B/P or NDLZ001N5399
! RECTIFIER DIODE ERB12-06 or QDQZ0ERB1206
! DIODE 1N5399BE NDL1001N5399
D608! DIODE 1N5399-B/P or NDLZ001N5399
! RECTIFIER DIODE ERB12-06 or QDQZ0ERB1206
! DIODE 1N5399BE NDL1001N5399
D609 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
ZENER DIODE DZ-5.6BSBT265 NDTB0DZ5R6BS
D611! ZENER DIODE MTZJT-7722B or QDTB00MTZJ22
! ZENER DIODE DZ-22BSBT265 NDTB00DZ22BS
D612 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D613 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D615 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D616! ZENER DIODE MTZJT-7733B or QDTB00MTZJ33
! ZENER DIODE DZ-33BSBT265 NDTB00DZ33BS
D620 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D624 DIODE ZENER 1ZC18(Q) QDLZ001ZC18Q
D631! DIODE SCHOTTKY 30PHA20 QDLZ030PHA20
D632! DIODE FR104-B or NDLZ000FR104
! DIODE FR104BB NDL1000FR104
D633! DIODE FR154 or NDLZ000FR154
! DIODE FR154BD NDL1000FR154
D635! DIODE FR154 or NDLZ000FR154
! DIODE FR154BD NDL1000FR154
D636! DIODE FR154 or NDLZ000FR154
! DIODE FR154BD NDL1000FR154
D637 DIODE 1ZC43(Q) QDLZ001ZC43Q
D638! SCHOTTKY BARRIER DIODE ERB84-009 QD7Z000ERB84
D639 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D640 DIODE 1N5397-B NDLZ001N5397
D641 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D642 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D643 ZENER DIODE MTZJT-7715B or QDTB00MTZJ15
ZENER DIODE DZ-15BSBT265 NDTB00DZ15BS
D644 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D645 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D646 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D647! IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D648 SWITCHING DIODE 1SS400 or QD1Z001SS400
20060619 13-3 L4620EL
Ref. No. Description Part No.
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D649! ZENER DIODE MTZJT-7739B or QDTB00MTZJ39
! ZENER DIODE DZ-39BSBT265 NDTB00DZ39BS
D650 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D651 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D653 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D654 ZENER DIODE MTZJT-7736B or QDTB00MTZJ36
ZENER DIODE DZ-36BSBT265 NDTB00DZ36BS
D655 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D656 SCHOTTKY BARRIER DIODE ERA81-004Q QDLZRA81004Q
D657 DIODE 1N5397-B NDLZ001N5397
D660 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D663 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D664 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D665 DIODE 1N5397-B NDLZ001N5397
D666 ZENER DIODE MTZJT-775.1B or QDTB0MTZJ5R1
ZENER DIODE DZ-5.1BSBT265 NDTB0DZ5R1BS
D667 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D668 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D712 PCB JUMPER D0.6-P5.0 JW5.0T
D713 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D714 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D730 SWITCHING DIODE 1SS400 or QD1Z001SS400
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D751 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D752 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D753 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D754 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D755 ZENER DIODE MTZJT-775.1B or QDTB0MTZJ5R1
ZENER DIODE DZ-5.1BSBT265 NDTB0DZ5R1BS
D756 ZENER DIODE MTZJT-775.1B or QDTB0MTZJ5R1
ZENER DIODE DZ-5.1BSBT265 NDTB0DZ5R1BS
D802! SWITCHING DIODE 1SS400 or QD1Z001SS400
! SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
D803! ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
! ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D804 PCB JUMPER D0.6-P5.0 JW5.0T D808 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
ICS
IC601! PHOTO COUPLER PS2561L1-1-A-V(L) QPEL561L11AV
IC602 VOLTAGE REGULATOR LD1117SC-R or NSZBA0TSS229
VOLTAGE REGULATOR LM1117S-ADJ NSZBA0T2T001
IC605 IC VOLTAGE REGULATOR 5V KIA7805API/P or NSZBA0SJY041
VOLTAGE REGULATOR KA7805A NSZBA0SF3052
IC606! IC VOLTAGE REGULATOR 5V KIA7805API/P or NSZBA0SJY041
! VOLTAGE REGULATOR KA7805A NSZBA0SF3052
IC781 IC SWITCH TC4053BF(EL N F) QSZBA0TTS163
IC801 IC AN17812A QSZBA0SMS017
IC831 IC AUDIO PROCESSOR MSP3417G-QG-B8-V3 NSZBA0SP3005
IC871 IC SWITCHING TC4052BF(ELNF) or QSZBA0TTS162
IC SWITCHING CD4052BCSJX_NL or NSZBA0TF3137
Ref. No. Description Part No.
IC SWITCHING CD4052BNSR NSZBA0TTY091
COILS
L11 PCB JUMPER D0.6-P5.0 JW5.0T L12 INDUCTOR 22µH-K-5FT LLARKBSTU220 L14 INDUCTOR 22µH-J-26T LLAXJATTU220
L601! LINE FILTER ELF17N008A LLBG00ZMS048 L631 INDUCTOR 47µH-K-5FT LLARKBSTU470 L632 INDUCTOR 22µH-J-26T LLAXJATTU220 L741 INDUCTOR 12µH-J-26T LLAXJATTU120 L760 INDUCTOR 100µH-K-5FT LLARKBSTU101
L761 PCB JUMPER D0.6-P5.0 JW5.0T L781 INDUCTOR 22µH-J-26T LLAXJATTU220 L831 INDUCTOR 18µH-J-26T LLAXJATTU180 L832 INDUCTOR 10µH-J-26T LLAXJATTU100 L833 INDUCTOR 47µH-K-5FT LLARKBSTU470
L834 PCB JUMPER D0.6-P5.0 JW5.0T L835 INDUCTOR 10µH-J-26T LLAXJATTU100
L836 PCB JUMPER D0.6-P5.0 JW5.0T L838 INDUCTOR 2.2µH-K-5FT LLARKBSTU2R2 L839 INDUCTOR 2.2µH-K-5FT LLARKBSTU2R2 L840 INDUCTOR 2.2µH-K-5FT LLARKBSTU2R2
L841 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q11 TRANSISTOR 2SA1576A T106R QQ1R2SA1576A
Q401 NPN TRANSISTOR POWER 2SC4881F HFE
Q402 TRANSISTOR 2SA950-O (TE2 F T) or QQS002SA950F
Q403 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q501 TRANSISTOR 2SA1175(F) or QQSF02SA1175
Q502 RES. BUILT-IN TRANSISTOR BA1F4M-T or QQSZ00BA1F4M
Q503 TRANSISTOR 2SD1666R or QQER02SD1666
Q504 TRANSISTOR 2SA1175(F) or QQSF02SA1175
Q505 RES. BUILT-IN TRANSISTOR BA1F4M-T or QQSZ00BA1F4M
Q506 TRANSISTOR 2SC2785(F) or QQSF02SC2785
Q507 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q603! TRANSISTOR 2SC2120-O(TE2 F T) or QQS02SC2120F
! TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q608! MOS FET 2SK3798(Q) QFWZ2SK3798Q
Q632 TRANSISTOR 2SC2785(F) or QQSF02SC2785
Q633 TRANSISTOR 2SC2120-O(TE2 F T) or QQS02SC2120F
Q730 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q731 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q732 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q733 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
MAX320
TRANSISTOR 2SA950-Y(TE2 F T) or QQSY02SA950F
TRANSISTOR (PB FREE) KTA1271-Y-AT/P NQSYKTA1271P
TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P
TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1318(T)-AANP or 2SA1318TZ
TRANSISTOR 2SA1318(U)-AANP 2SA1318UZ
NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
TRANSISTOR 2SD1666S or QQES02SD1666
TRANSISTOR KTD2059-Y/P NQEYKTD2059P
TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P
TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1318(T)-AANP or 2SA1318TZ
TRANSISTOR 2SA1318(U)-AANP 2SA1318UZ
NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
QQWZ2SC4881F
20060619 13-4 L4620EL
Ref. No. Description Part No.
Q734 RES. BUILT-IN TRANSISTOR KRA103M-AT/P or NQSZ0KRA103M
RES. BUILT-IN TRANSISTOR BN1F4M-T QQSZ00BN1F4M
Q741 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q742 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q743 TRANSISTOR 2SA1576A T106R QQ1R2SA1576A
Q744 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q781 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q791 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q792 TRANSISTOR 2SA1576A T106R QQ1R2SA1576A
Q871 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
Q872 TRANSISTOR 2SC4081 T106 Q QQ1Q02SC4081
RESISTORS
R11 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R12 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R13 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472 R14 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472 R15 CHIP RES. 1/10W J 470 Ω or RRXAJR5Z0471
RES CHIP 1608 1/10W J 470 Ω RRXA471YF002 R17 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R18 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R401 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002 R402 CARBON RES. 1/4W J 27k Ω RCX4JATZ0273 R403 CARBON RES. 1/4W J 33 Ω RCX4JATZ0330 R404 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562 R406 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002 R407 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R408 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821 R414 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681 R415 CARBON RES. 1/4W J 33 Ω RCX4JATZ0330 R416 CARBON RES. 1/4W J 33 Ω RCX4JATZ0330 R417 CARBON RES. 1/4W J 33 Ω RCX4JATZ0330 R419 CARBON RES. 1/4W J 33 Ω RCX4JATZ0330
R420 PCB JUMPER D0.6-P5.0 JW5.0T R502 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002 R503 CARBON RES. 1/4W J 27k Ω RCX4JATZ0273 R504 CARBON RES. 1/4W J 470 Ω or RCX4JATZ0471
CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152 R505 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002
R507 PCB JUMPER D0.6-P5.0 JW5.0T R509 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101 R510 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472 R511 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002 R512 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002 R513 CHIP RES. 1/10W J 27k Ω or RRXAJR5Z0273
RES CHIP 1608 1/10W J 27k Ω RRXA273YF002 R514 CHIP RES. 1/10W F 10k Ω or RRXAFR5H1002
CHIP RES. 1/10W F 10k Ω or RRXAFR5Z1002
RES CHIP 1608 1/10W F 10.0k Ω RTW1002YF002 R515 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R516 CHIP RES. 1/10W F 3k Ω or RRXAFR5H3001
CHIP RES. 1/10W F 3.0k Ω or RRXAFR5Z3001
RES CHIP 1608 1/10W F 3.00k Ω RTW3001YF002 R517 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103 R518 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
Ref. No. Description Part No.
R519 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151 R520 CHIP RES. 1/10W J 56k Ω or RRXAJR5Z0563
RES CHIP 1608 1/10W J 56k Ω RRXA563YF002
R521 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
R526 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R601! CARBON RES. 1/2W J 3.3M Ω or RCX2335DP001 ! GLASS GLAZE RES. 1/2W J 3.3M Ω RXX2JZLZ0335 R602! CEMENT RESISTOR 5W K 1.2 Ω or RW051R2PG001 ! CEMENT RESISTOR 5W J 1.2 Ω H 10MM RW051R2PAK10 R603 CARBON RES. 1/4W J 820k Ω RCX4JATZ0824 R604 CARBON RES. 1/4W J 680k Ω RCX4JATZ0684 R605 CARBON RES. 1/4W J 680k Ω RCX4JATZ0684 R606 CARBON RES. 1/4W J 820k Ω RCX4JATZ0824 R607 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221 R608 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221 R609 CARBON RES. 1/4W J 680k Ω RCX4JATZ0684 R610 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151 R611 CARBON RES. 1/4W J 470 Ω or RCX4JATZ0471
CARBON RES. 1/4W J 470 Ω RCX4JATZ0471 R613! METAL OXIDE FILM RES. 2W J 0.68 Ω or RN02R68ZU001 ! METAL OXIDE FILM RES. 2W J 0.68 Ω RN02R68DP004 R620 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151 R621 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122 R623 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222 R631 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562 R632 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002 R633 CARBON RES. 1/4W J 12k Ω RCX4JATZ0123 R635 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682 R636 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223 R638 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2 R640 CHIP RES. 1/10W F 1.8k Ω or RRXAFR5H1801
CHIP RES. 1/10W F 1.8k Ω or RRXAFR5Z1801
RES CHIP 1608 1/10W F 1.80k Ω RTW1801YF002 R641 CHIP RES. 1/10W F 1.1k Ω or RRXAFR5H1101
CHIP RES. 1/10W F 1.1k Ω or RRXAFR5Z1101
RES CHIP 1608 1/10W F 1.10k Ω RTW1101YF002 R645 CHIP RES. 1/10W F 2.2k Ω or RRXAFR5H2201
CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5Z2201
RES CHIP 1608 1/10W F 2.20k Ω RTW2201YF002 R646 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122 R647! CHIP RES. 1/10W F 3.9k Ω or RRXAFR5H3901
! CHIP RES.(1608) 1/10W F 3.9k Ω or RRXAFR5Z3901 ! RES CHIP 1608 1/10W F 3.90k Ω RTW3901YF002 R648! CHIP RES. 1/10W F 3.9k Ω or RRXAFR5H3901 ! CHIP RES.(1608) 1/10W F 3.9k Ω or RRXAFR5Z3901 ! RES CHIP 1608 1/10W F 3.90k Ω RTW3901YF002 R649! CHIP RES. 1/10W F 4.7k Ω or RRXAFR5H4701 ! CHIP RES.(1608) 1/10W F 4.7k Ω or RRXAFR5Z4701 ! RES CHIP 1608 1/10W F 4.70k Ω RTW4701YF002 R650! CHIP RES. 1/10W F 4.7k Ω or RRXAFR5H4701 ! CHIP RES.(1608) 1/10W F 4.7k Ω or RRXAFR5Z4701 ! RES CHIP 1608 1/10W F 4.70k Ω RTW4701YF002 R651! CHIP RES. 1/10W F 1.5k Ω or RRXAFR5H1501 ! CHIP RES. 1/10W F 1.5k Ω or RRXAFR5Z1501 ! RES CHIP 1608 1/10W F 1.50k Ω RTW1501YF002 R652! CHIP RES. 1/10W F 1.5k Ω or RRXAFR5H1501 ! CHIP RES. 1/10W F 1.5k Ω or RRXAFR5Z1501 ! RES CHIP 1608 1/10W F 1.50k Ω RTW1501YF002 R653! CHIP RES. 1/10W F 1.5k Ω or RRXAFR5H1501 ! CHIP RES. 1/10W F 1.5k Ω or RRXAFR5Z1501 ! RES CHIP 1608 1/10W F 1.50k Ω RTW1501YF002 R654! CHIP RES. 1/10W F 1.5k Ω or RRXAFR5H1501 ! CHIP RES. 1/10W F 1.5k Ω or RRXAFR5Z1501 ! RES CHIP 1608 1/10W F 1.50k Ω RTW1501YF002
20060619 13-5 L4620EL
Ref. No. Description Part No.
R655 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103 R656 CHIP RES. 1/10W J 100k Ω or RRXAJR5Z0104
RES CHIP 1608 1/10W J 100k Ω RRXA104YF002 R657 CARBON RES. 1/4W J 390 Ω RCX4JATZ0391 R659! CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103 ! RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R661 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122 R663 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2 R664 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2
R665 PCB JUMPER D0.6-P5.0 JW5.0T R667 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222 R669 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331 R670 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331 R671 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331 R672 METAL OXIDE FILM RES. 2W J 5.6 Ω or RN025R6ZU001
METAL OXIDE FILM RES. 2W J 5.6 Ω RN025R6DP004 R701 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002 R702 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R707 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002 R708 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R714 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R716 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002 R717 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R718 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002 R719 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002 R720 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R721 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002 R722 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152 R723 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152 R724 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R725 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002 R726 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R727 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002 R729 CHIP RES. 1/10W J 68k Ω or RRXAJR5Z0683
RES CHIP 1608 1/10W J 68k Ω RRXA683YF002 R730 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R731 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R732 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002 R733 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002 R735 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002 R736 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R737 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R738 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R740 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
Ref. No. Description Part No.
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002 R741 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561 R743 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002 R744 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002 R745 CHIP RES. 1/10W J 39k Ω or RRXAJR5Z0393
RES CHIP 1608 1/10W J 39k Ω RRXA393YF002 R746 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561 R748 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002 R749 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002 R750 CHIP RES. 1/10W J 39k Ω or RRXAJR5Z0393
RES CHIP 1608 1/10W J 39k Ω RRXA393YF002 R751 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002 R752 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R756 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472 R757 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002 R758 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002 R759 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R763 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002 R764 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750 R765 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002 R766 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R770 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002 R771 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R775 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R776 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R777 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002 R778 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002 R780 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R781 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002 R783 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002 R784 CHIP RES. 1/10W J 39k Ω or RRXAJR5Z0393
RES CHIP 1608 1/10W J 39k Ω RRXA393YF002 R785 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002 R786 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R791 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002 R792 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R793 CHIP RES. 1/10W J 12k Ω or RRXAJR5Z0123
RES CHIP 1608 1/10W J 12k Ω RRXA123YF002 R794 CHIP RES. 1/10W J 820 Ω or RRXAJR5Z0821
RES CHIP 1608 1/10W J 820 Ω RRXA821YF002 R795 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103 R796 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
20060619 13-6 L4620EL
Ref. No. Description Part No.
R797 CARBON RES. 1/4W J 470 Ω or RCX4JATZ0471
CARBON RES. 1/4W J 470 Ω RCX4JATZ0471
R798 CARBON RES. 1/4W J 470 Ω or RCX4JATZ0471
CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R799 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R801 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181 R802 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181 R805! METAL OXIDE FILM RES. 2W J 2.2 Ω or RN022R2ZU001 ! METAL OXIDE FILM RES. 2W J 2.2 Ω RN022R2DP004 R807! METAL OXIDE FILM RES. 2W J 2.2 Ω or RN022R2ZU001 ! METAL OXIDE FILM RES. 2W J 2.2 Ω RN022R2DP004 R812! CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222 ! RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002 R813 CHIP RES. 1/10W J 2.7k Ω or RRXAJR5Z0272
RES CHIP 1608 1/10W J 2.7k Ω RRXA272YF002 R814 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002 R815 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002 R816 CHIP RES. 1/10W J 2.7k Ω or RRXAJR5Z0272
RES CHIP 1608 1/10W J 2.7k Ω RRXA272YF002 R817 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002 R831 CHIP RES. 1/10W J 1.2k Ω or RRXAJR5Z0122
RES CHIP 1608 1/10W J 1.2k Ω RRXA122YF002 R832 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R833 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R834 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R835 CHIP RES. 1/10W J 6.8k Ω or RRXAJR5Z0682
RES CHIP 1608 1/10W J 6.8k Ω RRXA682YF002 R838 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002 R851 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R853 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R862 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R863 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R871 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R872 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R873 CARBON RES. 1/4W J 15k Ω RCX4JATZ0153 R874 CARBON RES. 1/4W J 15k Ω RCX4JATZ0153 R875 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223 R876 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223 R877 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002 R878 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223 R879 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002 R880 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223 R881 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002 R882 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002 R883 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002 R884 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002 R885 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
Ref. No. Description Part No.
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002
R886 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω or RRXA223YF002
CARBON RES. 1/4W J 22k Ω RCX4JATZ0223 R887 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223 R888 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223 R901 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R903 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R904 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R905 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R907 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R908 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R910 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103 R911 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
MISCELLANEOUS
B10 POW HEAT SINK PKG ASSEMBLY L3201UB 1EM420650
B22 HEAT SINK PLW ASSEMBLY L4520EA 1EM423670
BC602 BEAD INDUCTOR FBR07HA121TB-00 LLBF00ZTU021
F601! FUSE 4A/250V(PB FREE) 0215004.MXP PBGZ20BAG021
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
JK721 JACK SW DIN PCB L DIN-435C or JYEL040YUQ02
Y/C JACK 1P(SW) DMDC1-01-021 JYEL040RP001
JK722 JACK RCA PCB L RCA-112(2)-04(YL) JXRL010YUQ10
JK723 JACK RCA PCB L RCA-112(2)-04(WH) JXRL010YUQ11
JK724 JACK SW RCA PCB L RCA-112-03(RD) JYRL010YUQ02
JK751 JACK RGB PCB L MRC-021V-26 ABS (B11 JXGL210LY010
JK801 MINIATURE JACK(PB FREE) CKX-035-318AZ4 or JYSL010SNJ01
JACK SW HPEP SML PCB L PJ-350 JYSL010YUQ03
JS381 PCB JUMPER D0.6-P7.0 JW7.0T
JS601 PCB JUMPER D0.6-P10.0 JW10.0T
JS602 PCB JUMPER D0.6-P10.0 JW10.0T
JS603 PCB JUMPER D0.6-P10.0 JW10.0T
JS604 PCB JUMPER D0.6-P10.0 JW10.0T JS703 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 JS706 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 JS707 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 JS708 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 JS709 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 JS710 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 JS711 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 JS810 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
JS813 PCB JUMPER D0.6-P15.0 JW15.0T
L16 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA601! SURGE ABSORBER 470V+-10PER or NVQZ10D471KB
! VARISTOR 10D 471K SVR NVQZVR10D471
T601! TRANS POWER 6740 LTT3PE0KT012
TM601 EYELET TYPE D-1 0VM406868
TM602 EYELET TYPE D-1 0VM406868
X831 XTAL 18.432MHz FXD186LLN001
20060619 13-7 L4620EL
FUNCTION CBA
Ref. No. Description Part No.
FUNCTION CBA Consists of the following:
----------
CAPACITOR
C33 CERAMIC CAP.(AX) F Z 0.01µF/25V CCA1EZTFZ103
CONNECTOR
CN31B WIRE ASSEMBLY 5PIN 5PIN 110MM AWG26 WX1L4620-001
RESISTORS
R24 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R25 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101 R26 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152 R27 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002 R28 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002 R29 CHIP RES. 1/10W J 2.7k Ω or RRXAJR5Z0272
RES CHIP 1608 1/10W J 2.7k Ω RRXA272YF002 R30 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472 R31 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002 R32 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103 R33 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
SWITCHES
SW30 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW31 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW32 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW33 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW34 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW36 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW37 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
IR SENSOR CBA
Ref. No. Description Part No.
IR SENSOR CBA Consists of the following:
CAPACITORS
C53 ELECTROLYTIC CAP. 47µF/10V M or CE1AMASDL470
ELECTROLYTIC CAP. 47µF/10V M or CA1A470SP085 ALUMINUM ELECTROLYTIC CAP 47µF/10V M CE1AMASTM470
DIODE
D51 LED L-53HT NP4Z000L53HT
RESISTORS
R63 CHIP RES. 1/10W J 68 Ω or RRXAJR5Z0680
RES CHIP 1608 1/10W J 68 Ω RRXA680YF002
R64 CHIP RES. 1/10W J 68 Ω or RRXAJR5Z0680
RES CHIP 1608 1/10W J 68 Ω RRXA680YF002
R65 CHIP RES. 1/10W J 150 Ω or RRXAJR5Z0151
RES CHIP 1608 1/10W J 150 Ω RRXA151YF002
R66 CHIP RES. 1/10W J 150 Ω or RRXAJR5Z0151
RES CHIP 1608 1/10W J 150 Ω RRXA151YF002
MISCELLANEOUS
CLN53 WIRE ASSEMBLY 5PIN 5PIN 230MM AWG26 WX1L4620-002 JS52 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
RCV51 REMOCON RECEIVE UNIT PIC-37042SR or USESJRSKK034
REMOCON RESEVER MIM-0BM8DKL-C USESJRSUNT07
----------
INVERTER CBA
Ref. No. Description Part No.
INVERTER CBA Consists of the following:
CAPACITORS
C301 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085 ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C302 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562 C303 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085 ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221
C321 CAP CHIP 5pF 3KV C XC CA3F5R05M016 C322 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C323 CAP CHIP 5pF 3KV C XC CA3F5R05M016 C325 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C326 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100 C327 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C328 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100 C329 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C330 CAP METALIZED FILM 0.068µF/250V/J or CT2E683MS041
CAP METALIZED FILM 0.068/250VDC/J/MPEF CT2E683DT051 C331 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220 C332 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C341 CAP CHIP 5pF 3KV C XC CA3F5R05M016 C342 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C343 CAP CHIP 5pF 3KV C XC CA3F5R05M016 C345 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C346 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100 C347 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C348 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100 C349 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C350 CAP METALIZED FILM 0.068µF/250V/J or CT2E683MS041
CAP METALIZED FILM 0.068/250VDC/J/MPEF CT2E683DT051 C351 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
C361 CAP CHIP 5pF 3KV C XC CA3F5R05M016 C362 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C363 CAP CHIP 5pF 3KV C XC CA3F5R05M016 C365 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C366 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100 C367 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C368 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100 C369 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103 C370 CAP METALIZED FILM 0.068µF/250V/J or CT2E683MS041
CAP METALIZED FILM 0.068/250VDC/J/MPEF CT2E683DT051 C371 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
CONNECTORS
CN301 BACK LIGHT CONNECTOR 1717369-1 JB17D02AP001
CN302 BACK LIGHT CONNECTOR 1717369-1 JB17D02AP001
CN303 BACK LIGHT CONNECTOR 1717369-1 JB17D02AP001
1ESA13345
20060619 13-8 L4620EL
Ref. No. Description Part No.
CN304 CONNECTOR PRINT MES C/15/S/127301115K2 JCTWA15TG004
CN310 CONNECTOR PRINT OSU 008283021200000S+ orJ383C02UG004
CONNECTOR PRINT OSU 2P 292161-2 J31FC02AP001
DIODES
D306 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D307 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D308 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D309 ZENER DIODE MTZJT-7710B or QDTB00MTZJ10
ZENER DIODE DZ-10BSBT265 NDTB00DZ10BS
D321 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D322 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D323 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D324 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D325 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D326 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D327 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D328 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D329 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D330 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D331 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D332 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D333 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D334 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D341 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D342 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D343 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D344 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D345 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D346 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D347 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D348 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D349 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D350 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D351 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D352 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D353 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D354 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D361 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D362 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D363 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D364 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D365 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D366 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D367 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D368 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D369 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D370 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D371 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D372 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D373 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D374 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
COILS
L301 COIL CHOKE ELC10D101EL LLC101KMS003
L302 COIL CHOKE ELC10D101EL LLC101KMS003
L303 COIL CHOKE ELC10D101EL LLC101KMS003
TRANSISTORS
Q304 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q305 TRANSISTOR 2SA1175(F) or QQSF02SA1175
TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P
TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1318(T)-AANP or 2SA1318TZ
Ref. No. Description Part No.
TRANSISTOR 2SA1318(U)-AANP 2SA1318UZ
Q306 TRANSISTOR 2SC2120-O(TE2 F T) or QQS02SC2120F
TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q321! FET MOS SMD HAT2215R01-EL-E QF2ZHAT2215R
Q322 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q323 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q324 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q325 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q341! FET MOS SMD HAT2215R01-EL-E QF2ZHAT2215R
Q342 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q343 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q344 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q361! FET MOS SMD HAT2215R01-EL-E QF2ZHAT2215R
Q362 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q363 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
Q364 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P NQS4KTC3198P
RESISTORS
R309 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103 R310 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122 R311 CHIP RES. 1/10W J 47 Ω or RRXAJR5Z0470
RES CHIP 1608 1/10W J 47 Ω RRXA470YF002 R312 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R313 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002 R318 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122 R321 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
20060619 13-9 L4620EL
Ref. No. Description Part No.
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002
R322 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002
R323 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R324 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R325 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R326 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R327 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R328 CHIP RES. 1/10W J 22 Ω or RRXAJR5Z0220
RES CHIP 1608 1/10W J 22 Ω RRXA220YF002
R329 CHIP RES. 1/10W J 22 Ω or RRXAJR5Z0220
RES CHIP 1608 1/10W J 22 Ω RRXA220YF002
R330 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R331 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R332 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R333 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R334 CHIP RES. 1/10W J 15k Ω or RRXAJR5Z0153
RES CHIP 1608 1/10W J 15k Ω RRXA153YF002
R335 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R336 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R337 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R341 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002
R342 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002
R343 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R344 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R345 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R346 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R347 CHIP RES. 1/10W J 22 Ω or RRXAJR5Z0220
RES CHIP 1608 1/10W J 22 Ω RRXA220YF002
R348 CHIP RES. 1/10W J 22 Ω or RRXAJR5Z0220
RES CHIP 1608 1/10W J 22 Ω RRXA220YF002
R349 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R350 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R351 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R352 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R353 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R356 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R357 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R361 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002
R362 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002
Ref. No. Description Part No.
R363 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R364 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R365 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002 R366 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R367 CHIP RES. 1/10W J 22 Ω or RRXAJR5Z0220
RES CHIP 1608 1/10W J 22 Ω RRXA220YF002 R368 CHIP RES. 1/10W J 22 Ω or RRXAJR5Z0220
RES CHIP 1608 1/10W J 22 Ω RRXA220YF002 R369 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002 R370 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002 R371 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R372 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R373 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R376 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002 R377 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
MISCELLANEOUS
JS326 PCB JUMPER D0.6-P5.0 JW5.0T
JS346 PCB JUMPER D0.6-P5.0 JW5.0T
JS366 PCB JUMPER D0.6-P5.0 JW5.0T
T301! TRANS INVERTER ETJV27ZJ24AC LTZ2PC0MS003
T302! TRANS INVERTER ETJV27ZJ24AC LTZ2PC0MS003
T303! TRANS INVERTER ETJV27ZJ24AC LTZ2PC0MS003
PARTS produced in EU
Ref. No. Mark Description Part No.
MISCELLANEOUS
AC601! A,C,D AC CORD CEE 1800MM BLACK WAE0182LW003
AC601! B AC CORD BS 1800MM BLACK WAB0182LW018
TU1 A,B,D TUNER UNIT BS TMFE6-301A UTUNPLGAL018
TU1 C TUNER UNIT BS TMFE6-401A UTUNPSGAL011
20060619 13-10 L4620EL
LCD-A2006/LCD-B2006/LCD-C2006/LCD-D2006
L4620EA/21BB/22FC/23RD
2006-07-24
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
