FUJITSU U810 User Manual

User’s Guide

Learn how to use

your Fujitsu LifeBook U810 notebook

Fujitsu Computer Systems Corporation has made every effort to ensure the accuracy and completeness of this document; however, as ongoing development efforts are continually improving the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.

Fujitsu, the Fujitsu logo, and LifeBook are registered trademarks of Fujitsu Limited. Intel is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft, Windows, Windows Vista, and OneNote are either registered trademarks or trademar ks of Mic ros oft Corporation in the

United States and/or other countries. ArcSoft WebCam Companion is a trademark of ArcSoft, Inc. Bluetooth is a trademark of Bluetooth SIG, Inc., USA. OmniPass is a trademark of Softex, Inc. Realtek is a trademark of Realtek Semiconductor Corporation. Atheros and Super AG are registered trademarks of Atheros Communications. Adobe, Acrobat, and Acrobat Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States

and/or other countries. All other trademarks mentioned herein are the property of their respective owners.

WARNING

HANDLING THE CORD ON THIS PRODUCT WILL EXPOSE YOU TO LEAD, A CHEMICAL KNOWN TO THE S

TATE OF CALIFORNIA TO CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.

ASH HANDS AFTER HANDLING.

© Copyright 2007 Fujitsu Computer Systems Corporation. All rights reserved. No part of this publication may be copied, reproduced, or translated, without prior written consent of Fujitsu. No part of this publication

may be stored or transmitted in any electronic form without the written consent of Fujitsu. B5FJ-4211-01EN-00

DECLARATION OF CONFORMITY

according to FCC Part 15

Responsible Party Name: Fujitsu Computer Systems Corporation Address: 1250 E. Arques Avenue, M/S 122

Sunnyvale, CA 94085 Telephone: (408) 746-6000 Declares that product: Base Model Configuration:

LifeBook U810 / LifeBook U1010* notebook

Complies with Part 15 of the FCC Rules.

This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation.

*In certain regions, LifeBook U810 may be identified as LifeBook U1010. LifeBook U810 and LifeBook U1010 are identical

models in every way.

IMPORTANT SAFETY INSTRUCTIONS

This unit requires an AC adapter to operate. Use only UL Listed I.T .E. Class II Adapte rs with an output rating of 16 VDC, with a curr ent of 2.5 A (40 W).

AC adapter output polarity:

When using your notebook equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

• Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a

swimming pool.

• A void using a modem during an electrical storm. There may be a remote risk of electric shock from lightning.

• Do not use a modem to report a gas leak in the vicinity of the leak.

• Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with

local codes for possible special disposal instructions.

• To reduce the risk of fire, use only No. 26 AWG or larger UL Listed or CSA Certified Telecommunication Line Cord.

• For TV tuner use: To protect from overvoltages and transients on the Cable Distribution System, make sure that the outer shield of

the coaxial cable is connected to earth (grounded) at the building premise as close to the point of cable entrance as practicable, as required per NEC Article 820.93, ANSI/NFPA 70: 2005. If you have questions about your CATV installation, contact your service provider.

SAVE THESE INSTRUCTIONS

For Authorized Repair Technicians Only

DANGER OF EXPLOSION IF LITHIUM (CLOCK) BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY

WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTION.

OR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH THE SAME TYPE AND

RATING FUSE.

Recycling your battery

Over time, the batteries that run your mobile computer will begin to hold a charge for a shorter amount of time; this is a natural occurrence for all batteries. When this occurs, you may want to replace the battery with a fresh one*. If you replace it, it is important that you dispose of the old battery properly because batteries contain materials that could cause environmental damage if disposed of improperly.

Fujitsu is very concerned with environmental protection, and has enlisted the services of the Rechargeable Battery Recycling Corporation (RBRC)**, a non-profit public service organization dedicated to protecting our environment by recycling old batteries at no cost to you.

RBRC has drop-off points at tens of thousands of locations throughout the United States and Canada. To find the location nearest you, go to www.RBRC.org

If there are no convenient RBRC locations near you, you can also go to the EIA Consumer Education Initiative website (http://EIAE.org/) and search for a convenient disposal location.

Remember – protecting the environment is a cooperative effort, and you should make every effort to protect it for current and future generations.

* To order a new battery for your Fujitsu mobile computer, go to the Fujitsu shopping site at www.shopfujitsu.com in the US or

www.fujitsu.ca/products/notebooks in Canada.

** RBRC is an independent third party to which Fujitsu provides funding for battery recycling; RBRC is in no way affiliated with

Fujitsu.

or call 1-800-822-8837.

Contents

Preface

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Conventions Used in the Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Fujitsu Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Chapter 1 Getting to Know Your LifeBook

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Locating the Controls and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Top Components (notebook mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Top Components (tablet mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Left-Side Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Right-Side Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Bottom Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Status Indicator Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Display Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Opening the Display Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Using the System as a Tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Adjusting Display Panel Brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Changing Touch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Using the Fujitsu Zoom Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Handling the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Using in Notebook Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Using in Tablet Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Using the Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Using the Cursor Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Button Control Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Using the Touch Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Clicking on Touch Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Right-Clicking on Touch Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Double-Clicking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Dragging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Calibrating the Touch Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Volume Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Controlling the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

LifeBook Application/Tablet PC Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . 49

Button functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Changing Tablet PC Button Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Chapter 2 Getting Started with Your LifeBook

Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Connecting the Power Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Starting Your LifeBook Notebook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Boot Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Hard Disk Drive Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Booting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Starting Windows Vista the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Starting Windows XP the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Registering Your LifeBook notebook with Fujitsu . . . . . . . . . . . . . . . . . . 62

Installing ClickMe!. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Fujitsu Driver Update Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Power Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Power/Suspend/Resume Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Standby (Sleep) Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Hibernation (Save-to-Disk) Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Windows Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Restarting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Powering Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Chapter 3 User-Installable Features

Lithium ion Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Recharging the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Secure Digital (SD) Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Inserting/Removing an SD Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Compact Flash (CF) Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Inserting/Removing Compact Flash Cards. . . . . . . . . . . . . . . . . . . . . . . . . 76

Device Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Universal Serial Bus Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Headphone Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Microphone Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

External Video Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

LAN (RJ-45) Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Port Replicator Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Chapter 4 Troubleshooting Your LifeBook

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Identifying the Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Specific Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Power On Self Test Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Restoring Your Pre-installed Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Re-installing Individual Drivers and Applications. . . . . . . . . . . . . . . . . . . 101

Restoring the Operating System for Windows XP Systems. . . . . . . . . . . . 102

Restoring the Operating System for Windows Vista Systems . . . . . . . . . . 104

Automatically Downloading Driver Updates. . . . . . . . . . . . . . . . . . . . . . . 107

Chapter 5 Care and Maintenance

Caring for your LifeBook Notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Cleaning your LifeBook notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Storing your LifeBook notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Traveling with your LifeBook notebook . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Media Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Chapter 6 System Specifications

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Configuration Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Microprocessor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Chipset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Mass Storage Device Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Device Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Popular Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Pre-Installed Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Learning About Your Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Glossary/Regulatory

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Appendix A: WLAN User’s Guide

FCC Regulatory Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Regulatory Notes and Statements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Before Using the Optional Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . 144

Wireless LAN Device Covered by this Document. . . . . . . . . . . . . . . . . . . 144

Characteristics of the WLAN Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Wireless LAN Modes Using this Device . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Deactivating/Disconnecting the WLAN Device . . . . . . . . . . . . . . . . . . . . 147

Deactivation Using the Wireless On/Off Switch . . . . . . . . . . . . . . . . . . . . 148

Disconnection Using the Icon in the Taskbar. . . . . . . . . . . . . . . . . . . . . . . 148

Activating the WLAN Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

Configuring the Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Configuring the WLAN Using Windows Vista . . . . . . . . . . . . . . . . . . . . . 149

Configuring the WLAN Using Windows XP . . . . . . . . . . . . . . . . . . . . . . 150

Connection to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

Troubleshooting the WLAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

WLAN Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Using the Bluetooth Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

What is Bluetooth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Where to Find Information About Bluetooth. . . . . . . . . . . . . . . . . . . . . . . 154

Appendix B: Fingerprint Sensor Device

Introducing the Fingerprint Sensor Device . . . . . . . . . . . . . . . . . . . . . . . . 156

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

Installing OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

User Enrollment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Using OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Configuring OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

OmniPass Control Center. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Index

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

Preface

About This Guide

The LifeBook U810* notebook from Fujitsu Computer Systems Corporation is an ultra-mobile convertible computer. It can be used either as a standard notebook using keyboard input, or in tablet configuration using pen input. It is powered by an Intel® A110 processor, has a built-in color display with a passive digitizer, and brings the computing power of desktop personal computers (PCs) to a handheld, versatile environment.

This manual explains how to operate your LifeBook U810 notebook’s hardware and pre-installed system software. Your LifeBook U810 notebook comes with Windows® XP Tablet PC Edition 2005, Windows Vista® Business, or Windows Vista Home Premium pre-installed.

Conventions Used in the Guide

Keyboard and on-screen keys appear in brackets. Example: [Fn], [F1], [ESC], [ENTER] and [CTRL]. Pages with additional information about a specific topic are cross-referenced within the text.

For example: (“See Installation Procedure on page 43”.) Note that all cross-references are linked to the referenced items, so by clicking the link, you will automatically go to the referenced item or page.

On-screen menu items appear in bold. Example: “Click Fujitsu Menu, and select your choice”.

*Depending upon the region in which it is marketed, LifeBook U810 may be identified as LifeBook U1010. LifeBook U810 and

U1010 are identical models in every way. For purposes of this document, the LifeBook U810 model name will be used.

THE INFORMATION ICON HIGHLIGHTS INFORMATION THAT WILL ENHANCE YOUR UNDERSTANDING OF

THE SUBJECT MATERIAL.

HE CAUTION ICON HIGHLIGHTS INFORMATION THAT IS IMPORTANT TO THE SAFE OPERATION OF YOUR COMPUTER, OR TO THE INTEGRITY OF YOUR FILES. PLEASE READ ALL CAUTION INFORMATION CAREFULLY.

HE WARNING ICON HIGHLIGHTS INFORMATION THAT CAN BE HAZARDOUS TO EITHER YOU, YOUR

T L

IFEBOOK NOTEBOOK, OR YOUR FILES. PLEASE READ ALL WARNING INFORMATION CAREFULLY.

Fujitsu Contact Information

Service and Support

You can contact Fujitsu Service and Support in the following ways:

• Toll free: 1-800-8Fujitsu (1-800-838-5487)

• E-mail: 8fujitsu@us.fujitsu.com

• Website: http://www.computers.us.fujitsu.com/support

Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

• Product name

• Product configuration number

- About This Guide

• Product serial number

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

Fujitsu Shopping Online

You can go directly to the online by going to the website at: www.shopfujitsu.com.

YOU MUST HAVE AN ACTIVE INTERNET CONNECTION TO USE THE ONLINE URL LINKS.

Limited Warranty

Your LifeBook U810 ultra-mobile notebook is backed by a Fujitsu International Limited Warranty. Check the service kit that came with your notebook for the Limited Warranty period and terms and conditions.

- About This Guide

Chapter 1

Getting to Know Your LifeBook

Overview

This section describes the components of your Fujitsu LifeBook U810 notebook. We strongly recommend that you read it before using your notebook – even if you are already familiar with notebook computers.

Figure 1. Fujitsu LifeBook U810 notebook

Locating the Controls and Connectors

Connectors and peripheral interfaces on the LifeBook U810 notebook and the optional port replicator allow you to connect and control a variety of devices. Specific locations are illustrated in Figures 2 through 6. The table below provides a short description of each icon on the LifeBook U810 notebook and/or optional port replicator. Each of the icons is either molded into or printed on the notebook or port replicator chassis.

Connection Notebook

Purpose

Icon

DC in connector Connect an external power source such as the AC adapter or auto/airline

adapter.

Secure Digital (SD) Slot

USB Port Connect Universal Serial Bus 2.0 or 1.1 compliant devices to the

Microphone Jack Connect an external microphone. The internal microphone is disabled

Headphone Jack Connect stereo headphones or powered external speakers. The internal

Suspend/ Resume button

Insert an SD flash memory card for data storage. Flash memory cards allow you to transfer data to and from a variety of different digital devices.

notebook.

when you plug in an external microphone.

speaker is disabled when you plug in external headphones or powered speakers.

The Power/Suspend/Resume button allows you to suspend notebook activity without powering off, resume your notebook from suspend mode, and power on the system when it has been shut down from Windows.

- Locating the Controls and Connectors

Connection Notebook

Icon

Purpose

Local Area Network (LAN)

(Available using optional port replicator or with external monitor/LAN adapter cable only.) The LAN (RJ-45) jack is used to connect the internal 10/100 Base-T/Tx Ethernet to a Local Area Network (LAN) in your office or home, or broadband devices such as a cable modem, DSL, or satellite Internet.

Wireless LAN/ Bluetooth

The wireless LAN/Bluetooth switch allows you to turn power to the wireless LAN device and Bluetooth devices on and off.

On-Off Switch

External Video port

(Available using optional port replicator or with external monitor/LAN adapter cable only.) The external video port allows you to connect an external monitor or LCD projector to your computer.

Volume C o n t r ol The volume control allows you to increase, decrease, or mute the system

volume.

- Locating the Controls and Connectors

Web camera

Built-in Microphone

Pen/Pen Holder

Display Panel

Keyboard Light

LifeBook Application/ Tablet Buttons

Fingerprint Sensor

Keyboard Light

Status Indicator Panel

Keyboard

Port Replicator or

External Monitor/

LAN Adapter Cable Connector

Figure 2. LifeBook U810 notebook in notebook mode

Status Indicator Panel

- Locating the Controls and Connectors

Top Components (notebook mode)

The following is a brief description of your LifeBook notebook’ s top components when it is in notebook mode. (See Figure 2 on page 18 for location)

Web Camera

The web camera allows you to take pictures of yourself to send over the internet.

Built-in Microphone

The built-in microphone allows you to input audio.

Pen/Pen Holder

The pen is used as the interface with the display.

Display Panel

The display panel is a color LCD panel with backlighting for the display of text and graphics and passive digitizer functionality.

Keyboard Lights

The two keyboard lights allow you to illuminate the keyboard under low-light conditions.

LifeBook Application/Tablet Buttons

The LifeBook Application/T ablet buttons provide one-touch application launch capability as well as tabletspecific functions. See “LifeBook Application/Tablet PC Buttons” on page 49

Fingerprint Sensor

The fingerprint sensor device allows you to log onto your system as well as password-protected websites and applications by swiping your finger over the sensor. See “Introducing the Fingerprint Sensor Device” on page 156

- Locating the Controls and Connectors

Status Indicator Panels

The Status Indicator Panels display symbols that correspond with a specific component of your LifeBook notebook. The indicators above the keyboard relate to the keyboard states, while the indicator panel below the keyboard relates to power and hard drive access. See “Status Indicator Panel” on page 29

Keyboard

A keyboard with dedicated Windows keys. See “Keyboard” on page 39

Port Replicator or External Monitor/LAN Adapter Cable Connector

This connector allows you to connect the optional Port Replicator or the adapter cable to your notebook.

Top Components (tablet mode)

The following is a brief description of your LifeBook notebook’s top components when it is in tablet mode. (See Figure 3 on page 21 for location)

Fingerprint Sensor

Ctrl-Alt-Del Button

Holding the button down for approximately two seconds causes it to act as if Ctl-Alt-Del had actually been entered from a keyboard.

Left Button

This button acts the same as the left button on a mouse.

Right Button

This button acts the same as the right button on a mouse.

- Locating the Controls and Connectors

Right Button

Left Button

Ctrl-Alt-Del

Button

Fingerprint

Sensor

Speaker

Rotation Button

Button 1

Button 2

Down/Page Down

Function (Fn) Button

Up/Page Up

Cursor Control

Figure 3. LifeBook U810 notebook in tablet mode

- Locating the Controls and Connectors

Speaker

The built-in speaker allows for mono sound.

Screen Orientation Button

When you press the Screen Orientation button, the system screen orientation changes from portrait (vertical) to landscape (horizontal) or from landscape to portrait. When you would like to use the Tablet PC as an eBook, for example, you would use the portrait orientation, when accessing spreadsheets, you would more typically use a landscape orientation.

Application Buttons 1 and 2

The Application Buttons can be used to automatically open pre-selected applications. These buttons can also be used with the [Fn] button to perform additional tasks. See “LifeBook Application/Tablet PC Buttons” on page 49 for more information about using the Application Buttons.

Down and Up Buttons

The Down and Up Buttons can be used to navigate through multiple pages. They can also be used to automatically open pre-selected applications. When used with the [Fn] button, they can be used to Page Down and Page Up. See “LifeBook Application/Tablet PC Buttons” on page 49 for more information about using these buttons.

Function Button

The Function Button is used in conjunction with the other Application and Tablet Buttons to perform specified tasks such as opening applications or utilities. When pressed twice in succession, the [Fn] button will open the Fujitsu menu.

Cursor Control

The cursor control is used to move the cursor around the screen.

- Locating the Controls and Connectors

DC Power Jack

Volume Control

Headphone Jack

Wireless LAN/

Bluetooth Switch

Figure 4. LifeBook notebook left-side panel

SD Card Slot

Microphone Jack

Left-Side Panel Components

The following is a brief description of your LifeBook notebook’s left-side components.

Wireless LAN/Bluetooth Switch

The wireless LAN/Bluetooth switch is used to turn the WLAN and Bluetooth devices on and off. Switching the device off when not in use will help to extend battery life. See “Activating the WLAN Device” on page 148

DC Power Jack

The DC power jack allows you to plug in the AC adapter to power your LifeBook notebook and charge the internal Lithium ion battery.

- Locating the Controls and Connectors

Secure Digital (SD) Card Slot

The Secure Digital (SD) card slot allows you to install an SD card for data storage. This architecture allows you to transfer data from a variety of different digital devices. See “Inserting an SD Card” on page 74.

Volume Control

The volume control allows you to increase, decrease, or mute the system volume. See “Controlling the Volume” on page 48.

Microphone Jack

The microphone jack allows you to connect an external mono microphone. See “Microphone Jack” on page 80

Headphone Jack

The headphone jack allows you to connect headphones. See “External Video Port” on page 80

- Locating the Controls and Connectors

Suspend/Resume Button

USB 2.0 Port (behind cover)

Compact Flash Card Slot

Figure 5. LifeBook notebook right-side panel

Air Vents

Right-Side Panel Components

The following is a brief description of your LifeBook notebook’s right-side components.

Compact Flash (CF) Card Slot

Allows you to insert a Compact Flash card. See “Compact Flash (CF) Cards” on page 75

Suspend/Resume Button

The Power/Suspend/Resume button allows you to suspend notebook activity without powering off, resume your LifeBook notebook from standby mode, and power on your notebook when it has been shut down from Windows.

See “Power/Suspend/Resume Button” on page 64

- Locating the Controls and Connectors

Air Vents

The air vents are used to cool the system to prevent overheating.

TO PROTECT YOUR NOTEBOOK FROM DAMAGE AND TO OPTIMIZE PERFORMANCE, BE SURE TO KEEP ALL

AIR ALL VENTS UNOBSTRUCTED, CLEAN, AND CLEAR OF DEBRIS. THIS MAY REQUIRE PERIODIC

CLEANING, DEPENDING UPON THE ENVIRONMENT IN WHICH THE SYSTEM IS USED.

O NOT OPERATE THE NOTEBOOK IN AREAS WHERE THE AIR VENTS CAN BE OBSTRUCTED, SUCH AS IN

TIGHT ENCLOSURES OR ON SOFT SURFACES LIKE A BED OR CUSHION.

USB 2.0 Port

The USB 2.0 port allows you to connect Universal Serial Bus devices. USB 2.0 transfers data at up to 480 Mbps and is backward-compatible with USB 1.1 devices, which transfer data at up to 12 Mbps. See “Universal Serial Bus Ports” on page 78

- Locating the Controls and Connectors

Lithium ion Battery

Battery Latch

Air Vents

Wireless LAN/Hard Disk Drive Compartment

Air Vents

Figure 6. LifeBook notebook bottom panel

Bottom Components

The following is a brief description of your LifeBook notebook’s bottom panel components.

Lithium ion Battery

The battery bay contains the internal Lithium ion battery. It can be unlatched to remove for the battery when stored over a long period of time or for swapping a discharged battery with a charged Lithium ion battery.

See “Lithium ion Battery” on page 68

- Locating the Controls and Connectors

Battery Latch

The battery latch is used to secure the Lithium ion battery in the battery bay.

Air Vents

The air vents allow air to circulate through the system to cool down the components.

TO PROTECT YOUR NOTEBOOK FROM DAMAGE AND TO OPTIMIZE SYSTEM PERFORMANCE, BE SURE TO

KEEP ALL AIR ALL VENTS UNOBSTRUCTED, CLEAN, AND CLEAR OF DEBRIS. THIS MAY REQUIRE PERIODIC CLEANING, DEPENDING UPON THE ENVIRONMENT IN WHICH THE SYSTEM IS USED.

O NOT OPERATE THE NOTEBOOK IN AREAS WHERE THE AIR VENTS CAN BE OBSTRUCTED, SUCH AS IN

TIGHT ENCLOSURES OR ON SOFT SURFACES LIKE A BED OR CUSHION.

Wireless LAN/Hard Disk Drive Compartment

This compartment houses the wireless LAN device and the Hard Disk Drive. Typically, you should not open this compartment to avoid contamination and possible damage to the system.

- Locating the Controls and Connectors

CapsLk

Charge/ DC In

Battery Level

Status Indicator Panel

The Status Indicators display symbols that correspond to specific components of your Fujitsu LifeBook notebook. The LEDs below each symbol tell you how each of those components is operating. The Status Indicators are located in two different areas (Figure 7). Keyboard-related indicators are above the keyboard on the right, and the remaining indicators are below the keyboard on the right. Note that when the system is in tablet mode, it is not possible to see the keyboard-related indicators; this is fine, since the keyboard is not accessible when the system is in tablet mode.

Hard Drive Access

Power

Figure 7. Status Indicator Panel

NumLk

ScrLk

- Status Indicator Panel

Battery Charge/DC-In Indicator

• Orange, solid: AC adapter and battery are available and system is being charged.

• Green, solid: AC adapter and battery are available and system is fully charged, or AC adapter is

plugged in but battery is not installed.

• Orange, blinking: AC adapter and battery are available and waiting to charge battery (battery is

out of thermal range).

• Off: AC adapter is not plugged in.

Battery Level Indicator

The Battery Level indicators display the charge level of the indicated battery pack, as follows:

• Green, solid: Battery is between 51% and 100% charged.

• Orange, solid: Battery is between 13% and 50% charged.

• Red, solid: Battery is 12% or less charged.

• Orange, blinking: Blinks during battery status measurement (Four seconds after the battery is

installed).

• Red, blinking: There is a problem with the battery.

• Off: There is no battery installed or the battery has no charge.

• If the battery pack is installed and the AC adapter is connected while the power is turned off, the

battery level indicator will display the charge level for five seconds after it blinks orange.

• If the AC adapter is not connected or the battery pack is not fully charged when the computer is

switched to standby mode, the indicator will blink. The LED blinks at the rate of one second on/six seconds off.

- Status Indicator Panel

+ 146 hidden pages
