530C
g
PC-E567-01EN
i-4
Ima
Getting Started
e Scanner
CONTENTS
■ Regulatory Information ........................................................ ii
■ Note, Liability ....................................................................... iv
■ Safety Precautions ................................................................ v
Chapter1 PREPARING THE SCANNER.................................. 1
1.1 Checking the Contents of the Scanner Package............. 1
1.2 Names of Parts ................................................................... 1
1.3 Operator panel.................................................................... 1
Chapter2 INSTALLATION OF THE SCANNER...................... 3
2.1 Installing the Scanner ........................................................ 3
2.2 Connecting the Scanner to Your PC................................. 3
Connecting the USB Interface Cable.................................................... 3
Connecting the SCSI Interface Cable................................................... 4
Setting the SCSI ID............................................................................... 4
2.3 Installing the Scanner Application ................................... 5
Installing the FUJITSU TWAIN32 Scanner Driver ............................... 5
Installing ScandAll 21 ........................................................................... 7
Installing the FUJITSU ISIS Scanner Driver ......................................... 9
Installing QuickScanTM Pro ................................................................ 10
Installing Error Recovery Guidance .................................................... 12
Installing Image Processing Software Option (Trial)........................... 13
Installing Adobe Acrobat..................................................................... 13
Appendix1 TROUBLESHOOTING........................................ AP-1
Appendix2 DAILY CARE ...................................................... AP-4
Appendix3 REPLACING CONSUMABLES.......................... AP-5
fi-4530C Image Scanner Getting Started i
INTRODUCTION
Thank you for purchasing the fi-4530C Duplex Color
Scanner product.
This document describes how to handle fi-4530C
Duplex Color and basic operation methods. Before you
start using fi4530C Duplex Color be sure to thoroughly
read this manual to ensure correct use.
The "Operator’s Guide" is stored on the Setup Disk.
The guide provides useful and detailed information on
Operations when you would like to use advanced features, Daily Care for maintenance of the scanner,
Replacing Consumables to maintain conditions for
smooth scanning. Please also read the Operator’s Guide
for your reference.
■ Regulatory Information
FCC declaration
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not
occur in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
Changes or modifications not
WARNING
NOTICE
expressly approved by the party
responsible for compliance could
void the user’s authority to operate the equipment.
The use of a shielded interface cable
is required to comply with the Class B
limits of Part 15 of FCC rules.
The length of the AC cable must be 3
meters (10 feet) or less.
Canadian DOC Regulations
This digital apparatus does not exceed the Class B
limit for radio noise emissions from digital
apparatus set out in the Radio interference
Regulations of the Canadian Department of
Communications.
This Class B digital apparatus complies with
Canadian ICES-003.
Le pésent appareil numérique n’ément pas de
bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe
B prescridtes dans le Réglesment sur le brouillage
radioélectrique dicté par le ministere des
Communications du Canada.
Cet appareil numérique de la classe B est
conformme à la norme NMB-003 du Canada.
Bescheimigung des Herstellers /
Importeurs
Hiermit wird bescheinigt, daß der/die/das
•Increase the separation between the equipment
and receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
located.
•Consult your dealer or an experienced radio/TV
technician.
FCC warning: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
ii
fi-4530C
•In Übereinsstimmung mit den Bestimmungen
der EN45014(CE) funkentstört ist.
•Laut Maschinenlärminformationsverordnung 3.
GS GV, 18.01.1991:Der höchste
Schalldruckpegel beträgt 70 dB (A) oder
weniger gemäß ISO/7779.
International ENERGY STAR® Program
•Do not put the substance in the lamp in your
mouth as it contains mercury.
As an ENERGY STAR®
Partner, PFU LIMITED has
determined that this product
meets the
ENERGY STAR
®
guidelines for energy efficiency.
The International
ENERGY STAR
®
Office
Equipment Program is an international program
that promotes energy saving through the
penetration of energy efficient computers and
other office equipment. The program backs the
development and dissemination of products with
functions that effectively reduce energy
consumption. It is an open system in which
business proprietors can participate voluntarily.
The targeted products are office equipment such
as computers, monitors, printers, facsimiles,
copiers, scanners, and multifunction devices.
Their standards and logos ( ) are uniform
among participating nations.
Use in High-safety Applications
•Do not incinerate, crush, or shred the scanner.
•Do not breathe the chemical liquid contained in
the scanner parts.
Disposing of the scanner should be conducted as
required by local ordinances or regulations.
Trademarks
Microsoft, Windows, and Windows NT are
registered trademarks of Microsoft Corporation in
the United States and/or other countries.
ISIS, QuickScan and their respective logos are
trademarks or registered trademarks of Pixel
Translations, a division of Captiva Software
Corporation in the United States.
Adobe, the Adobe logo, and Acrobat are either
registered trademarks of Adobe Systems
Incorporated in the United States and/or other
countries.
Other product names are the trademarks or
registered trademarks of the respective companies.
This product has been designed and manufactured
on the assumption that it will be used in office,
personal, domestic, regular industrial, and
general-purpose applications. It has not been
designed and manufactured for use in applications
(simply called "high-safety applications" from
here on) that directly involve danger to life and
health when a high degree of safety is required,
for example, in the control of nuclear reactions at
nuclear power facilities, automatic flight control
of aircraft, air traffic control, operation control in
mass-transport systems, medical equipment for
sustaining life, and missile firing control in
weapons systems, and when provisionally the
safety in question is not ensured. The user should
use this product with adopting measures for
ensuring safety in such high-safety applications.
PFU LIMITED assumes no liability whatsoever
for damages arising from use of this product by
the user in high-safety applications, and for any
claims or compensation for damages by the user
or a third party.
About the use of mercury
The scanner lamp contains mercury.
To avoid unexpected injury, read the following
carefully.
Doing the following actions may result in serious
personal injuries:
How Trademarks Are Indicated In
This Manual
References to operating systems (OS) are
indicated as follows:
®
Windows 95
Windows 98
Windows Me
WindowsNT
4.0
Windows 2000
Windows XP
Microsoft
ating system
Microsoft
ating system.
Microsoft
nium Edition operating system.
Microsoft
Server operating system,
Microsoft
Workstation operating system.
Microsoft
fessional operating system.
Microsoft
fessional operating system,
Microsoft
Edition operating system.
Where there is no distinction between the different
versions of the above operating system, the
general term "Windows " is used.
Windows® 95 oper-
®
Windows® 98 oper-
®
Windows® Millen-
®
Windows®NT 4.0
®
Windows®NT 4.0
®
Windows® 2000 Pro-
®
Windows® XP Pro-
®
Windows® XP Home
fi-4530C Image Scanner Getting Started iii
Manufacturer
PFU LIMITED
Image Products Sales Dept., Imaging Products
Division, Products Group
Solid Square East Tower, 580 Horikawa-cho,
Saiwai-ku, Kawasaki-shi Kanagawa 212-8563,
Japan
Phone : (81-44) 540-4538
All Rights Reserved, Copyright© PFU LIMITED 2003
■ Note, Liability
Symbols Used In This Manual
ATTENTION
HINT
This symbol alerts operators to particularly important information. Be sure to
read this information.
This symbol alerts operators to helpful
advice regarding operation.
READ ALL OF THIS MANUAL CAREFULLY
BEFORE USING THIS PRODUCT. IF THIS
PRODUCT IS NOT USED CORRECTLY,
UNEXPECTED INJURY MAY BE CAUSED
TO USERS OR BYSTANDERS.
Also, store this manual in a safe place so that it
can be easily referred to during use of this
product.
While all efforts have been made to ensure the
accuracy of all information in this manual, PFU
assumes no liability to any party for any damage
caused by errors or omissions or by statements of
any kind in this manual, its updates or
supplements, whether such errors are omissions or
statements resulting from negligence, accidents,
or any other cause. PFU further assumes no
liability arising from the application or use of any
product or system described herein; nor any
liability for incidental or consequential damages
arising from the use of this manual. PFU disclaims
all warranties regarding the information contained
herein, whether expressed, implied, or statutory.
Warning Indications Used In This
Manual
This indication alerts operators
WARNING
to an operation that, if not strictly
observed, may result in severe
injury or death.
A TRIANGLE symbol indicates that special
care and attention is required.
The drawing inside the triangle shows the
specific caution.
A CIRCLE with a diagonal line inside
shows action which users may not perform.
The drawing inside or under the circle
shows the specific action that is not
allowed.
Outline characters on a colored
background show instructions users should
R
follow.
It may also include the drawing that shows
the specific instruction.
Screen Examples In This Manual
The screen examples in this manual are subject to
change without notice in the interest of product
improvement. If the actual displayed screen
differs from the screen examples in this manual,
operate by following the actual displayed screen
while referring to the User's Manual of the scanner
application you are using. Furthermore, the
screenshots in this manual are for the FUJITSU
TWAIN32 scanner driver, ScandAll 21 Image
Capturing Utility Software, FUJITSU ISIS
scanner driver, QuickScan™ image capturing
software and Adobe
®
Acrobat®.
About Maintenance
iv
CAUTION
This indication alerts operators
to an operation that, if not strictly
observed, may result in safety
hazards to personnel or damage
to equipment.
The user must not perform repairs on this scanner.
Contact the store where you purchased the scanner
or an authorized FUJITSU Image Scanner service
provider to make repairs to this product.
■ Safety Precautions
WARNING
Do not damage the AC cable.
A damaged AC cable may cause fire or
electric shock. Do not place heavy objects
on AC cables, or pull, bend, twist, heat,
damage or modify AC cables. Also, do not
use damaged AC cables or power plugs,
and AC cables or power plugs when the
wall socket is loose.
Turn the scanner OFF if it is
damaged.
If the scanner is damaged for any reason,
turn off the scanner and unplug the power
cable before contacting the store where
you purchased the scanner.
Do not put liquids inside the scanner.
Do not insert or drop metal objects in to the
scanner. Do not scan wet documents or
documents with paper clips or staples. Do
not splash or allow the scanner to get wet.
Use only specified AC cables and
connector cables
Use only specified AC cables and
connector cables. Failure to use the
correct cables might cause electric shock
and equipment failure.
Use this scanner only at the
indicated power voltage. Do not
connect to multiple-power strips.
Use this scanner only at the indicated
power voltage and current. Improper
power voltage and current might cause
fire or electric shock. Also, do not connect
to multiple-power strips.
Do not touch the AC cable with wet
hands.
Do not touch the power plug with wet
hands. Doing so might cause electric
shock.
Wipe any dust from the power plug.
Wipe off any dust from metal parts on the
power plug or metal fittings with a soft, dry
cloth. Accumulated dust might cause fire
or electric shock.
If foreign objects (water, small metal
objects, liquids, etc.) get inside the scanner,
immediately turn off the scanner and disconnect the power plug from the power outlet, then contact the store where you bought
the scanner or the Maintenance Service
Center. Pay particular attention to this warning in households where there are small
children.
Do not touch the inside of the
scanner unless necessary.
Do not take apart or modify the scanner.
The inside of the scanner contains highvoltage components. Touching these
components might cause fire or electric
shock.
Do not use the scanner if you smell a
strange odor.
If you detect heat coming from the device or
detect other problems such as smoke,
strange smells or noises, immediately turn
off the scanner and then disconnect its
power plug. Make sure that the smoking
has stopped, and then contact the store
where you bought the scanner or an
authorized FUJITSU scanner service
provider.
Do not install the device in locations
subject to oil smoke, steam,
humidity, and dust.
Do not install the scanner in locations
subject to oil smoke, steam, humidity, and
dust. Doing so might cause a fire or
electric shock.
fi-4530C Image Scanner Getting Started v
CAUTION
Do not install the scanner on
unstable surfaces.
Install the scanner on a desk so that none
of its parts protrude outside of the
desktop. Also, make sure that the scanner
is installed on a flat, level surface. Do not
install the scanner on unstable surfaces.
Install the scanner on a level surface that
is free of vibration to prevent it from falling.
Install the scanner on a strong surface that
will support the weight of the scanner and
other devices.
Do not block the ventilation ports.
Do not block the ventilation ports. Blocking
the ventilation ports generates heat inside
of scanner, which may results in fire or
scanner failure.
Do not place heavy objects or climb
on top of the scanner.
Do not place heavy objects on the scanner
or use the scanner's top surface for
performing other work. Improper
installation might cause injuries.
Before moving the scanner,
disconnect the power plug from the
power outlet.
Do not move the scanner with the power
and interface cables connected as this
might damage the cables, causing fire,
electric shock or injuries. Before moving
the scanner, be sure to disconnect the
power plug from the power outlet, and
disconnect data cables. Also, make sure
that the floor is free of obstructions.
Protect the scanner from static
electricity.
Install the scanner away from strong
magnetic fields and other sources of
electronic noise. Also, protect the scanner
from static electricity as this might cause
the scanner to malfunction.
Do not use aerosol sprays near the
scanner.
Do not use aerosol sprays to clean the
scanner. Aerosol sprays cause dirt and dust
to enter the scanner, resulting scanner
failure and malfunction.
Disconnect the power plug from the
Firmly insert the power plug.
Firmly insert the power plug into the power
outlet as far it can go.
Avoid any contact when scanner is in
use.
Avoid touching any scanner mechanism
when scanning as this may cause injuries.
Do not use the scanner immediately
after moving it from a cold place into
a warm room.
Do not use the device immediately after
moving it from a cold place into a cold
room. This may cause condensation,
which might lead to scanning errors. Let
the device dry about one or two hours
before you use it.
power outlet when the scanner is not
used for a long period of time.
When the scanner is not used for a long
period of time, be sure to disconnect the
power plug from the power outlet for safety.
Do not install the scanner in the
direct sunlight.
Do not install the scanner in the direct
sunlight or near heating apparatus. Doing so
might cause excessive heat to build up
inside the scanner, causing fire or scanner
trouble. Install the scanner in a wellventilated location.
vi
Chapter1 PREPARING THE SCANNER
1.1 Checking the Contents of the Scanner Package
When you unpack the scanner package, make sure that
the package contains all the parts on the list included in
the package.
If any parts are missing or defective, contact your sales
representative. Handle the scanner and accessories with
care.
1.2 Names of Parts
This section describes the names of parts and their functions.
■ Front side
(2) ADF paper chute
(3) Side guide
(1) Automatic document
feeder (ADF)
■ Removable Parts
The following shows the parts that can be removed from
the scanner.
ADF paper chute
Sheet guide
Pad ASSY
Pick roller
Can be removed
■ Rear side
(4) ADF button
(5) Operator panel
(6) Stacker
1.3 Operator panel
The operator panel is located on the right side of the
scanner. The panel consists of a Function No. display,
four buttons and a LED.
Function No.
display
Function
Send to
Scan
Power button
LED
(11) EXT connector
(8) SCSI Interface connector
(10) DC inlet
(9) USB Interface connector
(7) SCSI ID switch
fi-4530C Image Scanner Getting Started 1
.
Name Function
Function No. display Indicates the function No. and
error status.
Buttons
LED - Lights when the scanner is
Function Changes the Function activated
by the Send to button (*).
Send to Launches the linked application
Scan
Power button Turns the scanner ON and OFF.
software (*).
turned ON.
*) About the settings on the launcher, refer to FUJITSU
TWAIN32 scanner driver help and the "fi-4530C
Operator’s Guide" on the Setup CD-ROM.
■ Indications on the Function No.
display
z E
Indicates that a device alarm (that users can not
solve) has occurred during the initialization or
scanning of documents.
"E" and an alarm number (2 to 9, and A, c, d, F) are
indicated alternately.
To return the scanner to the ready status ("1"),
press "Scan" or "Send to" button while the alarm is
indicated.
If this alarm occurs, turn the power off and then on
again. If the alarm is indicated after turning on the
power again, contact your service engineer.
The following shows the indications on the Function
No. display.
z 8
Blinks only one time upon turning on the scanner.
z P
Indicates that the scanner has been turned ON and
is being initialized.
z 0
Indicates that initialization will soon be completed.
z 1
Indicates that initialization has been completed
successfully.
This status is called "Ready Status".
z U
Indicates that a temporary error (that users can
solve) has occurred during the initialization or
scanning of documents.
"U" and an error number (1, 2, 6) are displayed
alternately.
To return the scanner to the ready status ("1"),
press the "Scan" or "Send to" button while the error
is indicated.
2
Chapter2
INSTALLATION OF THE SCANNER
2.1 Installing the Scanner
1. Place the scanner at its installation site.
For details on the scanner's dimensions and
required installation space, refer to "fi-4530C
Operator’s Guide" "7.2 Installation Specifications" on the Setup CD-ROM.
2. Attach the ADF paper chute.
Hold the ADF paper chute and insert its tabs into
the holes on the rear side of the scanner as shown
in the figure below so that the side guides face up.
ADF paper chute
3) Insert the AC cable into the power outlet.
Ta b
Side guide
3. Connect the AC adapter.
ATTENTION
1) Connect the AC cable to the AC adapter.
Use only the AC adapter provided by
the manufacturer.
2.2 Connecting the Scanner to Your PC
When running Windows 95 or Windows NT 4.0, connect the scanner to your PC by the SCSI cable.
When running Windows 98, Windows Me, Windows
2000, or Windows XP, connect the scanner to your PC
by either the USB interface cable or the SCSI cable.
ATTENTION
■ Connecting the USB Interface
Cable
1. Connect the USB interface cable to the USB
interface connector of the scanner.
Do not connect both the USB interface
cable and the SCSI cable at the same time.
It is not possible to use the USB interface
with Windows 95 and Winows NT 4.0.
2) Connect the connector of AC adapter to the DC
inlet of the scanner.
fi-4530C Image Scanner Getting Started 3
2. Connect the other end of the USB interface
cable to your PC.
3. Press down the power button on the operator
panel to turn on the scanner.
4. Turn on your PC.
ATTENTION
Use the USB interface cable provided as
an accessory for the scanner.
Operation with a commercially available
USB cable is not guaranteed.
When connecting to a USB hub, be sure to
connect to the hub nearest your computer
(first stage). If you connect it to a USB
hub from the second stage onwards the
scanner may not operate correctly.
This device is equiped with SCSI and
USB interfaces. The SCSI and the USB
interfaces are controled not to be used
simultaneously. Do not connect both the
USB interface cable and the SCSI cable at
the same time.
■ Connecting the SCSI Interface
Cable
When using the scanner with the SCSI interface, you
need to purchase a commercially available SCSI cable
and a SCSI card.
2. Connect the other end of the cable to your PC.
ATTENTION
HINT
When using the scanner with the SCSI
interface, connect the scanner so that it is
the terminated device on the SCSI daisy
chain.
The factory default setting for SCSI ID is
"ID 5". If the SCSI ID of another device
has already been set to the same ID, change
either the scanner's SCSI ID or that of the
other device. For details on how to change
the SCSI ID, refer to " Setting the SCSI
ID" in this section.
• SCSI cable
Use the cable that has connectors fit to the 50
Pin Contact Shielded High-Density SCSI Device
Connector and to the connector of your SCSI
card.
• SCSI card
Use the recommended SCSI card noted on the
Web site below.
http://imagescanner.fujitsu.com/
ATTENTION
When connecting the SCSI interface
cable, be sure to first connect the SCSI
interface cable then turn on the scanner
and your PC. Connect the scanner so that
it is the terminated device on the SCSI
daisy chain.
1. Insert the SCSI cable into the interface connector.
3. Push the power button to turn on the scanner.
4. Turn on the PC.
■ Setting the SCSI ID
The factory default setting for SCSI ID is "ID 5".
1. Press the power button at least for two seconds to turn OFF the scanner when it is ON.
Disconnect the AC cable from the outlet.
2. Set the device address by using the SCSI ID
switch on the back of the scanner.
Click
4
ID No. Description
0 to 7 Can be set as the ID
8, 9 Used for the factory default value
(SCSI ID = 5).
3. Press the power button to turn ON the scanner.
When the scanner is turned ON, the SCSI ID set
at step 2 is enabled.
• There are two types of FUJITSU TWAIN 32:
One of the following driver software will be
automatically installed according to your Operating System (OS).
For Windows 98, Windows Me, Windows 2000,
and Windows XP:
FUJITSU TWAIN32 V9
For Windows 95, Windows NT 4.0
:
FUJITSU TWAIN32 V8
2.3 Installing the Scanner Application
For scanning documents with this scanner, both scanner
driver and image capturing application software (called
"application" hereafter) must be installed on your PC.
Two types of scanner driver (FUJITSU TWAIN 32
Scanner Driver or FUJITSU ISIS Scanner Driver) and
application (ScandAll 21 and QuickScan Pro) are provided for this product. The following sections describe
installation of each driver and application.
For FUJITSU TWAIN32 Scanner Driver
■ Preparation
Confirm the following items before starting to install the
application.
• Prepare the Setup CD-ROM.
• Confirm that the scanner is correctly connected
to your PC.
• When using Windows 95 or Windows NT 4.0:
ASPI Manager V4.01 or later is required (generally comes with SCSI board products).
■ Installing the FUJITSU TWAIN32
Scanner Driver
HINT
1. Press the power button to turn ON the scanner.
2. Turn on your PC and log on to Windows.
ATTENTION
Windows XP screenshots are used in
this section. The windows and operations may slightly vary depending on
your OS
When using Windows NT 4.0, Windows
2000 or Windows XP, log on as a user
with "Administrator" privileges (privileges of the administrator of your PC)
.
HINT
For details on how to connect the scanner,
refer to "2.2 Connecting the Scanner to
Your PC" on page 3.
• Uninstall an older version of FUJITSU TWAIN
32 driver if it has already been installed.
ATTENTION
Uninstall [Scanner Utility for Microsoft
Windows] from [Add/Remove Programs]
on the control panel.
fi-4530C Image Scanner Getting Started 5
HINT
The scanner may be detected automatically. If so, [Found New Hardware Wizard] (or [Add/Remove Hardware Wizard])
dialog box will appear. Click [Cancel] to
close the Wizard window. Windows XP
screenshots are used in this section. The
windows and operations may slightly vary
depending on your OS.
.
3. Insert the Setup CD-ROM into the CD drive.
⇒ <SETUP DISK START UP SCREEN> appears.
ATTENTION
This screen may not appear when the
"Autoplay" setting of your PC is OFF. In
this case, run "Install.exe" in this CDROM directly by the "Explorer" or "My
Computer".
5. Click [TWAIN Driver] on the window below.
6. Select a language used for installation on
[Choose Setup Language] window and click
[OK].
4. Click [INSTALL PRODUCTS].
7. Install the application following the instructions
on the window.
8. When the [InstallShield Wiizard Complete] window appears, click [Finish].
9. Your computer is restarted and the scanner will
be detected. Do not remove the Setup
CD-ROM from the CD drive until your PC will
be completely restarted.
6
2. Click [INSTALL PRODUCTS].
ATTENTION
Depending on the OS, the following operations may be necessary.
For Windows 98:
When a request for inserting the CDROM of Windows 98 appears, insert it
into the CD drive and click the [OK] button.
For Windows 2000:
When [Digital Signature not Found]
appears, click [Yes].
For Windows XP:
1. When [Found New Hardware Wizard]
appears, confirm that the Setup
CD-ROM is set in the CD drive, then
click the [Next] button.
2. When any alarm is displayed on [Hardware Installation] window, click the
[Continue Anyway] button.
3. Click the [Finish] button.
3. Click [ScandAll 21] on the window below.
Now the installation of the scanner driver is completed.
ATTENTION
For confirming if the installation was successful, perform a scanning operation by
using an application that complies with
the TWAIN regulations such as ScandAll
21.
■ Installing ScandAll 21
"Scandall 21" is image capturing software that complies
with the TWAIN standard. With the FUJITSU TWAIN
32 scanner driver, you can capture images by using a
FUJITSU image scanner fi-series product.
ATTENTION
When using Windows NT 4.0, Windows
2000 or Windows XP, log on as a user
with "Administrator" privileges (privileges of the administrator of your PC).
4. Select a language used for installation on
[Choose Setup Language] window and click
[OK].
5. Install the application following the instructions
on the window.
1. Insert the Setup CD-ROM into a CD drive.
⇒ <SETUP DISK START UP SCREEN> appears.
fi-4530C Image Scanner Getting Started 7
6. When the [InstallShield Wizard Complete] window appears, click [Finish]
4. Select "FUJITSU fi-4530Cdj" or "FUJITSU
TWAIN32" on the dialog box appeared.
ATTENTION
For finishing the installation, it may be
necessary restart to your computer. Follow
the instructions on the window.
■ Confirming Installation
1. Set documents on the ADF paper chute.
For details on how to set documents, refer to the
"1.2 Loading Documents on the ADF for Scanning" in the fi-4530 Operator’s Guide provided in
the CD-ROM.
HINT
For Windows 98, Windows Me, Win-
dows 2000, Windows XP:
[FUJITSU fi-4530Cdj]
For Windows 95, Windows NT 4.0:
[FUJITSU TWAI32]
5. Select [To View...] from the [Scan] menu.
6. Set scanning resolution, document size, etc. on
the [TWAIN driver] window (for setting details
of scanning) and click the [Scan] button.
2. Start ScandAll21
Select [Start] - [Programs] - [Scanner Utility for
Microsoft Windows] - [ScandAll 21].
3. Specify the scanner to use
Select [Select Source...]from the [Scan] menu of
ScandAll 21.
8
HINT
For details on [TWAIN driver], refer to the
"FUJITSU TWAIN32 Scanner Driver
Help" provided on the Setup CD-ROM
7. Documents are scanned, and the scanned
images are displayed on the [ScandAll 21] window.
2. Turn on your PC and log on to Windows.
.
If the scanning is completed without any troubles, the
installation was performed successfully.
For details on various types of scanning, refer to the
"fi-4530C Operator’s Guide" on the Setup CD-ROM.
For FUJITSU ISIS Scanner Driver
ATTENTION
HINT
When using Windows NT 4.0, Windows
2000 or Windows XP, log on as a user
with "Administrator" privileges (privileges of the administrator of your PC).
The scanner may be detected automatically. If so, [Found New Hardware Wizard]
(or [Add/Remove Hardware Wizard]) will
appear. Click [Cancel] to close the Wizard
window. The window may slightly vary
depending on your OS.
The window below is a screenshot for Windows XP.
■ Preparation
Confirm the following items before starting to install the
application. Prepare the Setup CD-ROM.
Confirm that the scanner is correctly connected to your
PC.
HINT
For details on how to connect the scanner,
refer to "2.2 Connecting the Scanner to
Your PC" on page 3.
■ Installing the FUJITSU ISIS Scan-
ner Driver
HINT
Windows XP screenshots are used in this
section. The windows and operations may
slightly vary depending on your OS.
3. Insert the "Setup CD-ROM" into the CD drive.
⇒ <SETUP DISK START UP SCREEN> appears.
ATTENTION
This screen may not appear when the
"Autoplay" setting of your PC is OFF. In
this case, run "Install.exe" in this CDROM directly by the "Explorer" or "My
Computer".
1. Turn on the scanner.
fi-4530C Image Scanner Getting Started 9
4. Click [INSTALL PRODUCTS].
5. Click [ISIS Driver] on the window below.
ATTENTION
Depending on the OS, the following operations may be necessary.
For Windows 98:
When a request for inserting the CDROM of Windows 98 appears, insert it
into the CD drive and click the [OK] button.
For Windows 2000:
When [Digital Signature not Found]
appears, click [Yes].
For Windows XP:
1. When [Found New Hardware Wizard]
appears, confirm that the Setup
CD-ROM is set in the CD drive, then
click the [Next] button..
2. When any alarm is displayed on [Hardware Installation] window, click the
[Continue Anyway] button.
3. Click the [Finish] button when the installation is finished.
6. Select a language used for installation on
[Choose Setup Language] window and click
[OK].
7. Install the application following the instructions
on the window.
8. When the [InstallShield Wiizard Complete] window appears, click [Finish].
9. Your computer is restarted and the scanner will
be detected. Do not remove the Setup
CD-ROM from the CD drive until your PC will
be completely restarted.
■ Installing QuickScanTM Pro
"QuickScan Pro" is image capturing software that complies with the ISIS standard. With the FUJITSU ISIS
scanner driver, you can capture images by using a
FUJITSU image scanner fi-series product.
ATTENTION
1. Insert the Setup CD-ROM into a CD drive.
⇒ <SETUP DISK STARTUP SCREEN> appears.
When using Windows NT 4.0, Windows
2000 or Windows XP, log on as a user
with "Administrator" privileges (privileges of the administrator of your PC).
10
2. Click [INSTALL PRODUCTS]
.
3. Click [QuickScan PRO (Trial)] on the window
below.
5. Enter required information, then click [Next >]
button.
4. Install the application following the instructions
on the window.
ATTENTION
"QuickScanTM Pro" included in the Setup
CD-ROM is an evaluation version. For
further use after expiration of the evaluation period (up to 30 launches), it is necessary to purchase a fully functional version
of QuickScan
the evaluation version, do not change the
Serial Number already displayed.)
TM
Pro. (When you install
6. Install the application following the instructions
on the window.
■ Confirming Installation
Confirm whether or not the scanner works normally as
follows.
1. Start QuickScan
From [Start] menu select [Programs]-[QuickScan]-[QuickScan].
TM
Pro.
2. Select [Select Scanner...] from [Scan] menu in
QuickScan
TM
Pro.
And select fi-4530C from the list of [Scanner:],
and then click [OK] button.
fi-4530C Image Scanner Getting Started 11
3. Select [Preview Settings...] from the [Scan]
menu. Set the scan resolution, paper size and
other scanning conditions, and then click [OK].
4. Load the documents on the scanner.
For details on loading documents, refer to "1.2
Loading Documents on the ADF for Scanning" in
the fi-4530C Operator's Guide on the Setup CDROM
.
Error Recovery Guidance
■ Installing Error Recovery Guidance
When any error occurs in the scanner, this Guidance
automatically displays the solutions for troubleshooting
on its window.
1. Insert the Setup CD-ROM into the CD drive.
⇒ <SETUP DISK STARTUP SCREEN> appears.
2. Click [INSTALL PRODUCTS].
5. Select [Preview Scan] from the [Scan] menu.
And then the document is scanned.
If the scanning is completed without any troubles the
installation was performed successfully.
3. Click [Error Recovery Guidance] on the window
below.
HINT
12
Refer to "QuickScan Overview" or
"QuickScan Help" for information about
QuickScan functions and operations. On
the [Start] menu, point to [Programs][QuickScan] and click the file.
4. Select a language used for installation on
[Choose Setup Language] window and click
[OK].
5. Install the application following the instructions
on the window.
6. When the [InstallShield Wiizard Complete] window appears, click [Finish].
Adobe
®
Acrobat
®
■ Installing Adobe Acrobat
Install Adobe Acrobat by the following procedure from
the "Adobe Acrobat 5.0 CD-ROM" provided with the
scanner.
HINT
1. Insert the Adobe Acrobat 5.0 CD-ROM into the
CD-ROM drive.
Adobe Acrobat is required for displaying
the manuals stored on the Setup CD-ROM.
It is also possible to set Adobe Acrobat to
display scanned images working together
with the scanner.
*Installation of Adobe Acrobat is not necessary if it is already installed on your PC.
Image Processing Software Option
(Trial)
■ Installing Image Processing Software Option (Trial)
For details on the installation of the Image Processing
Software Option, refer to the "Image Processing Software Option USER’S GUIDE".
⇒ The CD-ROM is automatically recognized, and
the "Adobe Acrobat 5.0 AutoPlay" screen is displayed.
ATTENTION
2. The following window appears. Click the [Next]
button.
If the "Adobe Acrobat 5.0 AutoPlay"
screen is not displayed even after the
Adobe Acrobat 5.0 CD-ROM is
inserted into the CD-ROM drive, double-click the "AutoPlay.exe" icon at
the CD-ROM drive in Explorer
.
fi-4530C Image Scanner Getting Started 13
3. The following window appears. Click the [Acrobat 5.0] button, then click the [Install Adobe
Acrobat 5.0] button shown below.
⇒ The Setup window appears and the installation
will be started.
4. The setup window appears. Install Adobe Acrobat following the instructions on the window.
HINT
For details on installation of Adobe
Acrobat 5.0, read the description that is
displayed by clicking the [Before you
install] button in the screen at Operation 3. For details on how to use Adobe
Acrobat 5.0, refer to "Adobe Acrobat
5.0 Help."
14
Appendix1 TROUBLESHOOTING
■ Troubleshooting checklist
Symptom Check this item Remedy
Scanner does not turn on. Have you pushed the power button? Push the power button.
Are the AC cable and AC adapter
properly connected to the scanner?
Is Windows normally started up? Push the power button again after completely
Scanning does not start. Are the documents loaded correctly on
the ADF paper chute?
Is the ADF closed completely? Close the ADF completely.
Is the USB cable or SCSI cable prop-
erly connected?
(When using SCSI interface) Is SCSI
ID set correctly?
Does the Function No. display indi-
cates an alarm or an error?
Does the alarm state remain displayed
even after the scanner has been turned
off and back on again?
Vertical lines appear in the
printed image.
The printed scanned image
shifts or is distorted.
Quality of scanned image
is unsatisfactory.
Is the glass dirty? Clean the glass following the instructions in
Are the documents loaded correctly? Load the documents correctly.
Are the glass or sheet guides (a white
location) clean?
Correctly connect the AC cable and the AC
adapter.
Disconnect the AC cable and the AC adapter
from the scanner, then connect them again.
If this does not restore the power supply, contact the store where you purchased the scanner
or an authorized FUJITSU scanner service provider.
starting up Windows.
Load the document correctly on ADF paper
chute.
Correctly connect the cable. (When a USB hub
is used, check the hub's power supply.)
Set SCSI ID correctly by SCSI ID switch on
rear of scanner.
When the Function No. display indicates an
alarm or an error, refer to the "Chapter 5.
TROUBLESHOOTING" in the fi-4530C Operator’s Guide for removing the alarm or the
error.
Turn off and on the power button.
If this does not eliminate the alarm state, contact the store where you purchased the scanner
or an authorized FUJITSU scanner service provider.
Operator's Guide "3. Daily Care".
Clean dirty locations.
fi-4530C Image Scanner Getting Started AP-1
Symptom Check this item Remedy
Double-feed frequently
occurs.
Paper is not fed (pick error
occurs frequently, or document stops midway).
Are the scanned images
elongated?
Is there a shadow on the
leading edge of the
scanned image?
Do the documents qualify the "Document Quality" and the "Double-feed
Detection Conditions" in the chapter 6
of the fi-4530C Operator’s Guide?
Are the documents set properly in the
ADF paper chute?
Is the document stack thicker than
10mm?
Is the Pad ASSY dirty? Clean the Pad ASSY. Refer to Operator's Guide
Is the Pad ASSY worn out? Replace the Pad ASSY. Refer to Operator's
Do the documents qualify the "Document Quality" and the "Double-feed
Detection Conditions" in the chapter 6
of the fi-4530C Operator’s Guide?
Is the Pick roller dirty? Clean the Pick roller. Refer to Operator's Guide
Is the Pick roller worn out? Clean the Pick roller. Refer to Operator's Guide
Is there any debris on the document
feed path?
Are the Feed rollers dirty? Clean the Feed rollers. Refer to Operator's
Have you adjusted the scan scale? For Windows 98, Windows Me, Windows
Are the Feed rollers dirty? Clean the Feed rollers. Refer to Operator's
Adjust the offset. For Windows 98, Windows Me, Windows
Use the documents that qualify the "Document
Quality" and the "Double-feed Detection Conditions" in the chapter 6 of the fi-4530C Operator’s Guide.
Fan the documents before scanning. Correctly
align the document stack and load them on the
ADF paper chute. Refer to "2.1 Installing the
Scanner" on page 3 for details.
Reduce the number of sheets in the document
sheet to 10 mm thickness or less.
in "3.2. Cleaning the ADF".
Guide in "4.2. Replacing the Pad ASSY".
Use the documents that qualify the "Document
Quality" and the "Double-feed Detection Conditions" in the chapter 6 of the fi-4530C Operator’s Guide.
in "3.2. Cleaning the ADF".
in "4.3. Replacing the Pick Roller".
Remove any debris from the document feed
path.
Guide in "3.2. Cleaning the ADF".
2000, WindowsXP, select "Scanners and Cameras" in the control panel, then click the [Device
Set] tab to adjust scale.
For Windows 95, Windows NT 4.0, right click
the Scanner Control Center in the task tray,
select [Options] and adjust the scan scale.
Guide in "3.2. Cleaning the ADF".
2000, WindowsXP, adjust the [Sub-scan Setting] on [Scanners and Cameras] in the control
panel.
For Windows 95, Windows NT 4.0, right click
the Scanner Control Center, select [Options][Sub-scan Setting] and adjust the offset.
AP-2
■ Temporary error
■ Device alarm (Permanent error)
Indication Meaning
U1 A paper feed error occurred.
U2 A double feed error occurred.
U6 The print cartridge is not set.
The following shows the procedure for releasing of each
temporary error.
• "U1" error
Remove jammed documents.
Confirm that the documents meet the paper conditions for scanning.
Refer to fi-4530C Operator’s Guide "6.2 Document
Quality" on the Setup CD-ROM.
• "U2" error
Remove jammed documents.
Confirm that the documents meet the paper conditions for scanning.
Refer to fi-4530C Operator’s Guide "6.2 Document
Quality" on the Setup CD-ROM.
Indication Meaning
E2 A trouble in the optical system (front).
E3 A trouble in the optical system (back).
E4 The motor fuse has blown out.
E6 A trouble in the operator panel.
E7 A trouble occurred in the EEPROM.
E8 The SCSI interface fuse has blown
out.
E9 An error in the image memory.
Ec An alarm in the memory.
Ed A trouble in the SCSI interface con-
troller.
EF A trouble in the Background switching
mechanism.
When you encounter any alarm, turn off and on the scanner. If the alarm is still displayed on the Function No. display, contact the store where you purchased the scanner or
an authorized FUJITSU scanner service provider.
• "U6" error
This error may occur only when the Imprinter
option is installed on your scanner.
Open the ink cover and confirm if the print cartridge is firmly attached.
fi-4530C Image Scanner Getting Started AP-3
Appendix2 DAILY CARE
The glass of the inside of the
WARNING
ADF becomes hot during operation.
When you clean the inside of the
scanner, turn off the power and
unplug the AC adapter from the
outlet and wait for at least three
minutes.
Do not turn off the scanner when
you clean the Feed rollers or
Eject rollers.
■ Cleaning Materials
Cleaning
Materials
Cleaner F1
(or isopropyl
alcohol)
Lint-free dry
cloth
For details about the cleaning materials, contact the
FUJITSU scanner dealer where you purchased the scanner.
Parts No. Remarks
CA995010013
- Commercially available one
1 bottle
Moisten a cloth with
this fluid and wipe the
scanner clean.
■ Cleaning Method
■ Locations and Cycle for Cleaning
Part to clean Standard Cleaning Cycle
Pad ASSY Clean these parts after every
Pick roller
Feed rollers
Plastic rollers
Eject rollers
Sheet guides
Glass
Ultra sonic sensor
ATTENTION
The scanner must be cleaned more frequently if you scan any of the following
type of sheets:
• Documents of coated paper
• Documents that are almost com-
• Chemically treated documents such as
• Documents containing a large amount
• Handwritten documents
5,000 scans.
pletely covered with printed text or
graphics
carbonless paper
of calcium carbonate
The ADF must be cleaned with a lint-free cloth moistened with the Cleaner F1.
AP-4
For details on the cleaning the ADF, refer to "3.2 cleaning the ADF" in fi-4530C Operator’s Guide on the Setup
CD-ROM".
Appendix3 REPLACING CONSUMABLES
r
The glass of the inside of the
WARNING
ADF becomes hot during operation.
When you clean the inside of the
scanner, turn off the power and
unplug the AC adapter from the
outlet and wait for at least three
minutes.
Do not turn off the scanner when
you clean the Feed rollers or
Eject rollers.
■ Consumables and Replacement
Cycle
The following table shows the specifications of
consumables and guidelines for the replacement
cycle.
Folowing illustration shows the locations of the parts to
be replaced. Refer to "Chapter 4 Replacing Consumables" fi-4530C Operator’s Guide on the Setup
CD-ROM.
■ Replacing the Pad ASSY
To remove
Pad ASSY
To attach
■ Replacing the Pick Roller
Standard
Description Parts No.
Replacement
Cycle
Pad ASSY PA03334-
0002
Pick roller PA03334-
0001
For purchase of consumables,
you purchased the scanner or an authorized FUJITSU
scanner service provider.
After 100,000 scans
or one year
After 200,000 sheets
or one year
contact the store where
The replacement cycles above are rough guidelines for
the case of using A4/Letter woodfree or wood contain-
2
ing paper 64 g/m
(17 lb). This cycle varies according to
the type of the used paper and how frequently the scanner is used and cleaned.
ATTENTION
Use only the specified consumables.
Do not use other consumables.
Sheet guide
Pick rolle
fi-4530C Image Scanner Getting Started AP-5
This Manual uses recycled paper.
Loading...
