Fujifilm X-T5 User guide

Download
FF220001
Owner’s Manual
BL00005204-200
EN

Introduction

Thank you for your purchase of this product. Be sure that you have read this manual and understood its contents be­fore using the camera. Keep the manual where it will be read by all who use the product.

For the Latest Information

The latest versions of the manuals are available from:
https://fujifilm-dsc.com/en/manual/
The website can be accessed not only from your computer but also from smartphones and tablets. It also contains information on the software license.
For information on  rmware updates, visit:
https://fujifilm-x.com/support/download/firmware/cameras/
ii
Chapter Index
P
Menu List
1 Before You Begin 1
2 First Steps 33
3 Basic Photography and Playback 51
4 Movie Recording and Playback 61
5 Taking Photographs 71
6 The Shooting Menus 117
7 Playback and the Playback Menu 219
8 Network/USB Features and Settings 247
9 The Setup Menus 271
iv
10 Shortcuts 311
11 Peripherals and Optional Accessories 333
12 Technical Notes 355
iii

Menu List

1⁄
2⁄
3⁄
4⁄
Camera menu options are listed below.

Shooting Menus

Adjust settings when shooting photos or movies.
Menu List
See page 117 for details.
N
Photo Menus
Items marked with both x and F icons are available in both the still
N
photography and movie shooting menus. Changes to these items in either menu also apply to the item in the remaining menu.
H IMAGE QUALITY SETTING
IMAGE SIZE 118 IMAGE QUALITY 119 RAW RECORDING 120 SELECT JPEG/HEIF 121
1⁄
FILM SIMULATION 122 MONOCHROMATIC COLOR 124 GRAIN EFFECT 124 COLOR CHROME EFFECT 125 COLOR CHROME FX BLUE 125 SMOOTH SKIN EFFECT 125 WHITE BALANCE 126 DYNAMIC RANGE 130
2⁄
D RANGE PRIORITY 130 TONE CURVE 131 COLOR 131 SHARPNESS 131
iv
P
H IMAGE QUALITY SETTING
HIGH ISO NR 132 CLARITY 132 LONG EXPOSURE NR 132 LENS MODULATION OPTIMIZER 133
3⁄
COLOR SPACE 133 PIXEL MAPPING 133
x SELECT CUSTOM SETTING x EDIT/SAVE CUSTOM SETTING
AUTO UPDATE CUSTOM SETTING 139
4⁄
xF MOUNT ADAPTOR SETTING
P
134 134
140
Menu List
1⁄
2⁄
3⁄
1⁄
2⁄
3⁄
G AF/MF SETTING
FOCUS AREA 143 AF MODE 143 AF-C CUSTOM SETTINGS 144 STORE AF MODE BY ORIENTATION 148
1⁄
AF POINT DISPLAY
yz
xF WRAP FOCUS POINT NUMBER OF FOCUS POINTS 149 PRE-AF 149
xF AF ILLUMINATOR g FACE/EYE DETECTION SETTING
SUBJECT DETECTION SETTING 153 AF+MF 155
2⁄
MF ASSIST 156 FOCUS CHECK 156 INTERLOCK SPOT AE & FOCUS AREA 157
xF INSTANT AF SETTING xF DEPTH-OF-FIELD SCALE
RELEASE/FOCUS PRIORITY 158
3⁄
xF AF RANGE LIMITER TOUCH SCREEN MODE 160
P
A SHOOTING SETTING
DRIVE SETTING 162 SPORTS FINDER MODE 167 PRE-SHOT sJ SELF-TIMER 168
1⁄
148
SAVE SELF-TIMER SETTING 169 SELF-TIMER LAMP 169
148
PHOTOMETRY 169 SHUTTER TYPE 170 INTERVAL TIMER SHOOTING 171
150
INTERVAL TIMER SHOOTING
151
EXPOSURE SMOOTHING INTERVAL PRIORITY MODE 173 FLICKER REDUCTION 173
2⁄
FLICKERLESS S.S. SETTING 174 IS MODE 174 ISO AUTO SETTING 175
157
DIGITAL TELE-CONV. 175
157
MULTI EXPOSURE 176 PIXEL SHIFT MULTI SHOT 177
3⁄
159
WIRELESS COMMUNICATION
xF
F FLASH SETTING
FLASH FUNCTION SETTING 180 RED EYE REMOVAL 180 TTL-LOCK MODE 181 LED LIGHT SETTING 181 COMMANDER SETTING 182 CH SETTING 182
B MOVIE SETTING
MOVIE MODE 183 HIGH SPEED REC 183 MEDIA REC SETTING 183
F IS MODE F IS MODE BOOST
AUDIO SETTING 184 F REC FRAME INDICATOR
P
168
Menu List
172
179
P
P
184 184
186
v
Movie Menus
1⁄
2⁄
3⁄
1⁄
2⁄
Items marked with both x and F icons are available in both the still
N
photography and movie shooting menus. Changes to these items in either menu also apply to the item in the remaining menu.
Menu List
B MOVIE SETTING
1⁄
2⁄
3⁄
P
MOVIE SETTING LIST 187 MOVIE MODE 188 HIGH SPEED REC F SELF-TIMER MEDIA REC SETTING HDMI OUTPUT SETTING FIX MOVIE CROP MAGNIFICATION F-Log/HLG RECORDING 194 DATA LEVEL SETTING 195
F PHOTOMETRY F FLICKERLESS S.S. SETTING F IS MODE F IS MODE BOOST
ZEBRA SETTING 197 ZEBRA LEVEL 197 MOVIE OPTIMIZED CONTROL oL F REC FRAME INDICATOR TALLY LIGHT 199
F SELECT CUSTOM SETTING F EDIT/SAVE CUSTOM SETTING F AUTO UPDATE CUSTOM SETTING
WIRELESS COMMUNICATION
xF
189 190 190 192 193
195 195 196 196
198 198
200 200 200 200
H IMAGE QUALITY SETTING
F FILM SIMULATION F MONOCHROMATIC COLOR F WHITE BALANCE F DYNAMIC RANGE
1⁄
F TONE CURVE F COLOR F SHARPNESS F HIGH ISO NR
INTERFRAME NR
PERIPHERAL LIGHT CORRECTION
F
2⁄
xF MOUNT ADAPTOR SETTING
P
201 201 202 202 202 202 203 203 203 204 204
vi
Menu List
1⁄
2⁄
G AF/MF SETTING
F FOCUS AREA F AF MODE F AF-C CUSTOM SETTING
xF WRAP FOCUS POINT xF AF ILLUMINATOR
1⁄
Fg FACE /EYE DETECTION SETTING
F SUBJECT DETECTION SETTING
F AF+MF F MF ASSIST F FOCUS CHECK
xF INSTANT AF SETTING
2⁄
xF DEPTH-OF-FIELD SCALE xF AF RANGE LIMITER
F TOUCH SCREEN MODE FOCUS CHECK LOCK 212
P
P AUDIO SETTING
INTERNAL MIC LEVEL ADJUSTMENT 213
205
EXTERNAL MIC LEVEL ADJUSTMENT 213
205
MIC JACK SETTING 214
206
MIC LEVEL LIMITER
206
WIND FILTER 214
207
LOW CUT FILTER 214
207
HEADPHONES VOLUME 214 XLR MIC ADAPTER SETTING 215
207
Q TIME CODE SETTING
207
TIME CODE DISPLAY 216
208
START TIME SETTING 216
208
COUNT UP SETTING 217
208
DROP FRAME
209
HDMI TIME CODE OUTPUT 218
209 210
P
214
Menu List
P
217
vii
1⁄
2⁄
3⁄

The Playback Menu

Adjust playback settings.
See page 225 for details.
N
Menu List
C PLAY BACK MENU
SWITCH SLOT 225 RAW CONVERSION 226 HEIF TO JPEG/TIFF CONVERSION 229 ERASE 230
1⁄
SIMULTANEOUSDELETE 232 CROP 232 RESIZE 233 PROTECT 234
P
C PLAY BACK MENU
IMAGE ROTATE 235 VOICE MEMO SETTING 236 RATING 237 COPY 238
2⁄
TRANSFER IMAGE TO SMARTPHONE 239
WIRELESS COMMUNICATION
xF
SLIDE SHOW 241 PHOTOBOOK ASSIST 242 PRINT ORDER (DPOF) 244
3⁄
instax PRINTER PRINT 245 DISP ASPECT 246
P
241
viii

Setup Menus

1⁄
2⁄
1⁄
2⁄
1⁄
2⁄
3⁄
4⁄
Adjust basic camera settings.
See page 271 for details.
N
Menu List
D USER SETTING
FORMAT 272
b AREA SETTING DATE/TIME 273
TIME DIFFERENCE 274
1⁄
Q a
x MY MENU SETTING
F MY MENU SETTING SENSOR CLEANING 276 BATTERY AGE 276
2⁄
RESET 277 REGULATORY 277
D SOUND SETTING
AF BEEP VOL. 278 SELF-TIMER BEEP VOL. 278 OPERATION VOL. 279 F REC START/STOP VOLUME tt ELECTRONIC SHUTTER
1⁄
VOLUME tt ELECTRONIC SHUTTER
SOUND
s ELECTRONIC SHUTTER VOLUME s ELECTRONIC SHUTTER SOUND
PLAYBACK VOLUME 281
2⁄
4ch AUDIO PLAYBACK 281
P
D SCREEN SETTING
VIEW MODE SETTING 282 EVF BRIGHTNESS 282
273
EVF COLOR 282 EVF COLOR ADJUSTMENT 283
1⁄
LCD BRIGHTNESS 284
275
LCD COLOR 284
275
LCD COLOR ADJUSTMENT 284
275
IMAGE DISP. 285 AUTOROTATE DISPLAYS 285 PREVIEW EXP./WB IN MANUAL MODE 286 NATURAL LIVE VIEW 286 F-Log VIEW ASSIST 287
P
2⁄
ELECTRONIC LEVEL SETTING 287 FRAMING GUIDELINE 288 AUTOROTATE PB 289 FOCUS SCALE UNITS 289
279
APERTURE UNIT FOR CINEMA LENS 289
279
DUAL DISPLAY SETTING 290 DISP. CUSTOM SETTING 290
280
LARGE INDICATORS MODE(EVF) 291
3⁄
LARGE INDICATORS MODE(LCD) 291
280
LARGE INDICATORS DISP. SETTING 292
280
INFORMATION CONTRAST ADJ. 292 LOCATION INFO 293
Q MENU BACKGROUND
x
4⁄
F
Q MENU BACKGROUND
P
293 293
Menu List
ix
1⁄
2⁄
3⁄
Menu List
D BUTTON/DIAL SETTING
FOCUS LEVER SETTING 294 x EDIT/SAVE QUICK MENU
F EDIT/SAVE QUICK MENU FUNCTION (Fn) SETTING 295
1⁄
Menu List
POWER ZOOM LENS FUNCTION (Fn) SETTING
SELECTOR BUTTON SETTING 295 COMMAND DIAL SETTING 296 o S.S OPERATION COMMAND DIAL DIRECTION 297
SHUTTER AF 298 SHUTTER AE 298
SHOOT WITHOUT LENS 299
2⁄
SHOOT WITHOUT CARD 299 LENS ZOOM/FOCUS SETTING 300 AE/AF-LOCK MODE 302 AWB-LOCK MODE 302 APERTURE RING SETTING (A) 303 APERTURE SETTING 303
3⁄
a Fn1 BUTTON SETTING TOUCH SCREEN SETTING 304 LOCK 305
P
D POWER MANAGEMENT
AUTO POWER OFF 306 PERFORMANCE 306
295
EVF/LCD BOOST SETTING 307
295
AUTO POWER OFF TEMP. 307
D SAVE DATA SETTING
295
FRAME NO. 308 EDIT FILE NAME 309
x CARD SLOT SETTING
297
SELECT SLOT(xSEQUENTIAL) SELECT FOLDER 310 COPYRIGHT INFO 310 GEOTAGGING 310
303
P
P
309 309
x

The Network/USB Settings Menu

Adjust settings for network and USB connections.
See page 264 for details.
N
I NETWORK/USB SETTING
Bluetooth/SMARTPHONE SETTING 264 AIRPLANE MODE 267 NETWORK SETTING 267 instax PRINTER CONNECTION
SETTING CONNECTION MODE 268 USB POWER SUPPLY/
COMM SETTING INFORMATION 270 RESET WIRELESS SETTING 270
P
267
270
Menu List
Menu List
xi
Table of Contents
Before You Begin 1
P
Introduction ..........................................................................................................ii
For the Latest Information .......................................................................................... ii
Menu List ...............................................................................................................iv
Shooting Menus ..............................................................................................................iv
The Playback Menu ......................................................................................................viii
Setup Menus ...................................................................................................................... ix
The Network/USB Settings Menu ......................................................................... xi
Supplied Accessories ....................................................................................xxv
About This Manual ........................................................................................xxvi
Symbols and Conventions ...................................................................................xxvi
Terminology ..................................................................................................................xxvi
Before You Begin 1
1
Parts of the Camera ............................................................................................2
The Serial Number Plate ..............................................................................................4
The Focus Stick (Focus Lever) ...................................................................................4
The Selector .........................................................................................................................4
The Shutter Speed and Sensitivity Dials ............................................................5
STILL/MOVIE mode dial ....................................................................................................5
The Exposure Compensation Dial ......................................................................... 6
The Drive Dial .....................................................................................................................6
The Command Dials .......................................................................................................7
The Indicator Lamp .........................................................................................................9
The LCD Monitor ...........................................................................................................10
The Eye Cup ......................................................................................................................11
Focusing the View nder ........................................................................................... 11
Camera Displays ...............................................................................................12
The Electronic View nder ........................................................................................ 12
The LCD Monitor ...........................................................................................................14
Choosing a Display Mode ........................................................................................16
Adjusting Display Brightness ................................................................................. 18
Display Rotation ............................................................................................................. 18
The DISP/BACK Button ...............................................................................................19
The Dual Display ............................................................................................................ 20
xii
Table of Contents
First Steps 33
Basic Photography and Playback 51
Movie Recording and Playback 61
Customizing the Standard Display .....................................................................21
Virtual Horizon ................................................................................................................23
Using the Menus ..............................................................................................24
The Menus ......................................................................................................................... 24
Selecting a Menu Tab ................................................................................................. 25
Touch Screen Mode ......................................................................................... 26
Shooting Touch Controls .........................................................................................26
Playback Touch Controls ........................................................................................... 31
First Steps 33
2
Attaching the Strap .........................................................................................34
Attaching a Lens ............................................................................................... 35
Inserting the Battery .......................................................................................36
Inserting Memory Cards ................................................................................38
Using Two Cards ............................................................................................................40
Compatible Memory Cards ....................................................................................41
Charging the Battery ......................................................................................42
Turning the Camera On and O .................................................................46
Checking the Battery Level ...........................................................................47
Basic Setup .........................................................................................................48
Choosing a Di erent Language ...........................................................................50
Changing the Time and Date ................................................................................ 50
Basic Photography and Playback 51
3
Taking Photographs (Mode P) .....................................................................52
Viewing Pictures ............................................................................................... 56
HDMI Output ................................................................................................................... 57
Deleting Pictures .............................................................................................. 59
Movie Recording and Playback 61
4
Recording Movies ............................................................................................62
Recording Movies ......................................................................................................... 62
Adjusting Movie Settings ......................................................................................... 68
Viewing Movies .................................................................................................69
xiii
Taking Photographs 71
Taking Photographs 71
5
P, S, A, and M Modes ........................................................................................ 72
Mode P: Program AE ...................................................................................................72
Mode S: Shutter-Priority AE.....................................................................................74
Mode A: Aperture-Priority AE ................................................................................78
Mode M: Manual Exposure .....................................................................................80
Autofocus ............................................................................................................ 82
Focus Mode ...................................................................................................................... 83
Autofocus Options (AF Mode) .............................................................................. 85
Focus-Point Selection .................................................................................................87
Manual Focus .....................................................................................................91
Checking Focus .............................................................................................................. 93
Sensitivity ............................................................................................................ 96
AUTO .....................................................................................................................................97
Metering .............................................................................................................. 98
Exposure Compensation ...............................................................................99
C (Custom) ...................................................................................................................... 100
Focus/Exposure Lock ....................................................................................101
Other Controls ............................................................................................................. 102
Bracketing .........................................................................................................103
O AE BKT ........................................................................................................................ 103
W ISO BKT ..................................................................................................................... 103
X FILM SIMULATION BKT .................................................................................... 104
V WHITE BALANCE BKT ....................................................................................... 104
Y DYNAMIC RANGE BKT ..................................................................................... 104
Z FOCUS BKT ............................................................................................................. 104
Continuous Shooting (Burst Mode).........................................................105
HDR .....................................................................................................................107
Advanced Filters .............................................................................................109
Advanced Filter Options ........................................................................................ 110
Panoramas ........................................................................................................111
Multiple Exposures ........................................................................................114
xiv
Table of Contents
The Shooting Menus 117
The Shooting Menus 117
6
IMAGE QUALITY SETTING (Still Photography) .....................................118
IMAGE SIZE ..................................................................................................................... 118
IMAGE QUALITY .......................................................................................................... 119
RAW RECORDING ....................................................................................................... 120
SELECT JPEG/HEIF ...................................................................................................... 121
FILM SIMULATION ...................................................................................................... 122
MONOCHROMATIC COLOR .................................................................................. 124
GRAIN EFFECT ..............................................................................................................124
COLOR CHROME EFFECT ....................................................................................... 125
COLOR CHROME FX BLUE ..................................................................................... 125
SMOOTH SKIN EFFECT ............................................................................................ 125
WHITE BALANCE ......................................................................................................... 126
DYNAMIC RANGE ....................................................................................................... 130
D RANGE PRIORITY .................................................................................................... 130
TONE CURVE.................................................................................................................. 131
COLOR ...............................................................................................................................131
SHARPNESS .................................................................................................................... 131
HIGH ISO NR .................................................................................................................. 132
CLARITY ............................................................................................................................ 132
LONG EXPOSURE NR ................................................................................................ 132
LENS MODULATION OPTIMIZER ....................................................................... 133
COLOR SPACE ...............................................................................................................133
PIXEL MAPPING ........................................................................................................... 133
x SELECT CUSTOM SETTING ............................................................................ 134
x EDIT/SAVE CUSTOM SETTING ..................................................................... 134
AUTO UPDATE CUSTOM SETTING .................................................................... 139
xF MOUNT ADAPTOR SETTING ..................................................................140
AF/MF SETTING (Still Photography) ........................................................143
FOCUS AREA .................................................................................................................143
AF MODE ......................................................................................................................... 143
AF-C CUSTOM SETTINGS .......................................................................................144
STORE AF MODE BY ORIENTATION .................................................................. 148
AF POINT DISPLAY yz ...................................................................................... 148
xF WRAP FOCUS POINT .................................................................................. 148
NUMBER OF FOCUS POINTS ................................................................................ 149
xv
PRE-AF ............................................................................................................................... 149
xF AF ILLUMINATOR .......................................................................................... 150
g FACE/EYE DETECTION SETTING .................................................................151
SUBJECT DETECTION SETTING ..........................................................................153
AF+MF .............................................................................................................................. 155
MF ASSIST .......................................................................................................................156
FOCUS CHECK .............................................................................................................. 156
INTERLOCK SPOT AE & FOCUS AREA ..............................................................157
xF INSTANT AF SETTING .................................................................................157
xF DEPTH-OF-FIELD SCALE ........................................................................... 157
RELEASE/FOCUS PRIORITY ................................................................................... 158
xF AF RANGE LIMITER.......................................................................................159
TOUCH SCREEN MODE ........................................................................................... 160
SHOOTING SETTING (Still Photography) ................................................162
DRIVE SETTING ............................................................................................................. 162
SPORTS FINDER MODE ........................................................................................... 167
PRE-SHOT sJ .......................................................................................................... 168
SELF-TIMER .....................................................................................................................168
SAVE SELF-TIMER SETTING .................................................................................... 169
SELF-TIMER LAMP ....................................................................................................... 169
PHOTOMETRY ............................................................................................................... 169
SHUTTER TYPE .............................................................................................................. 170
INTERVAL TIMER SHOOTING ................................................................................ 171
INTERVAL TIMER SHOOTING EXPOSURE SMOOTHING ........................172
INTERVAL PRIORITY MODE ................................................................................... 173
FLICKER REDUCTION ................................................................................................ 173
FLICKERLESS S.S. SETTING ..................................................................................... 174
IS MODE ........................................................................................................................... 174
ISO AUTO SETTING ....................................................................................................175
DIGITAL TELE-CONV. ................................................................................................. 175
MULTI EXPOSURE ....................................................................................................... 176
PIXEL SHIFT MULTI SHOT ....................................................................................... 177
xF WIRELESS COMMUNICATION................................................................ 179
FLASH SETTING (Still Photography) ........................................................180
FLASH FUNCTION SETTING ................................................................................. 180
RED EYE REMOVAL.....................................................................................................180
xvi
Table of Contents
TTL-LOCK MODE ......................................................................................................... 181
LED LIGHT SETTING .................................................................................................. 181
COMMANDER SETTING .......................................................................................... 182
CH SETTING ................................................................................................................... 182
MOVIE SETTING (Still Photography) ........................................................183
MOVIE MODE ................................................................................................................ 183
HIGH SPEED REC ......................................................................................................... 183
MEDIA REC SETTING ................................................................................................. 183
F IS MODE .................................................................................................................... 184
F IS MODE BOOST ................................................................................................... 184
AUDIO SETTING ........................................................................................................... 184
F REC FRAME INDICATOR ................................................................................... 186
MOVIE SETTING (Movie Recording) .........................................................187
MOVIE SETTING LIST ................................................................................................. 187
MOVIE MODE ................................................................................................................ 188
HIGH SPEED REC ......................................................................................................... 189
F SELF-TIMER .............................................................................................................. 190
MEDIA REC SETTING ................................................................................................. 190
HDMI OUTPUT SETTING ......................................................................................... 192
FIX MOVIE CROP MAGNIFICATION .................................................................. 193
F-Log/HLG RECORDING ......................................................................................... 194
DATA LEVEL SETTING ............................................................................................... 195
F PHOTOMETRY ....................................................................................................... 195
F FLICKERLESS S.S. SETTING .............................................................................. 195
F IS MODE .................................................................................................................... 196
F IS MODE BOOST ...................................................................................................196
ZEBRA SETTING ........................................................................................................... 197
ZEBRA LEVEL .................................................................................................................197
MOVIE OPTIMIZED CONTROL oL ................................................................ 198
F REC FRAME INDICATOR ................................................................................... 198
TALLY LIGHT ................................................................................................................... 199
F SELECT CUSTOM SETTING............................................................................. 200
F EDIT/SAVE CUSTOM SETTING ...................................................................... 200
F AUTO UPDATE CUSTOM SETTING ............................................................ 200
xF WIRELESS COMMUNICATION................................................................ 200
xvii
IMAGE QUALITY SETTING (Movie Recording) ......................................201
F FILM SIMULATION ............................................................................................... 201
F MONOCHROMATIC COLOR .......................................................................... 201
F WHITE BALANCE .................................................................................................. 202
F DYNAMIC RANGE ................................................................................................ 202
F TONE CURVE .......................................................................................................... 202
F COLOR ........................................................................................................................ 202
F SHARPNESS ............................................................................................................. 203
F HIGH ISO NR ........................................................................................................... 203
INTERFRAME NR .......................................................................................................... 203
F PERIPHERAL LIGHT CORRECTION ............................................................. 204
xF MOUNT ADAPTOR SETTING ..................................................................204
AF/MF SETTING (Movie Recording) .........................................................205
F FOCUS AREA .......................................................................................................... 205
F AF MODE .................................................................................................................. 205
F AF-C CUSTOM SETTING .................................................................................. 206
xF WRAP FOCUS POINT .................................................................................. 206
xF AF ILLUMINATOR .......................................................................................... 207
Fg FACE/EYE DETECTION SETTING .......................................................... 207
F SUBJECT DETECTION SETTING ................................................................... 207
F AF+MF ....................................................................................................................... 207
F MF ASSIST ................................................................................................................ 208
F FOCUS CHECK ....................................................................................................... 208
xF INSTANT AF SETTING .................................................................................208
xF DEPTH-OF-FIELD SCALE ........................................................................... 209
xF AF RANGE LIMITER.......................................................................................209
F TOUCH SCREEN MODE ....................................................................................210
FOCUS CHECK LOCK ................................................................................................ 212
AUDIO SETTING (Movie Recording).........................................................213
INTERNAL MIC LEVEL ADJUSTMENT ............................................................... 213
EXTERNAL MIC LEVEL ADJUSTMENT .............................................................. 213
MIC JACK SETTING ..................................................................................................... 214
MIC LEVEL LIMITER ....................................................................................................214
WIND FILTER .................................................................................................................. 214
LOW CUT FILTER .......................................................................................................... 214
HEADPHONES VOLUME ......................................................................................... 214
XLR MIC ADAPTER SETTING ................................................................................. 215
xviii
Table of Contents
Playback and the Playback Menu 219
Network/USB Features and Settings 247
TIME CODE SETTING (Movie Recording) ................................................216
TIME CODE DISPLAY ................................................................................................. 216
START TIME SETTING ................................................................................................ 216
COUNT UP SETTING.................................................................................................. 217
DROP FRAME ................................................................................................................ 217
HDMI TIME CODE OUTPUT ...................................................................................218
Playback and the Playback Menu 219
7
The Playback Display ....................................................................................220
The DISP/BACK Button ............................................................................................221
Viewing Pictures .............................................................................................223
Playback Zoom ............................................................................................................ 224
Multi-Frame Playback .............................................................................................. 224
The Playback Menu .......................................................................................225
SWITCH SLOT ................................................................................................................ 225
RAW CONVERSION ....................................................................................................226
HEIF TO JPEG/TIFF CONVERSION ...................................................................... 229
ERASE ................................................................................................................................. 230
SIMULTANEOUS DELETE......................................................................................... 232
CROP .................................................................................................................................. 232
RESIZE ................................................................................................................................ 233
PROTECT .......................................................................................................................... 234
IMAGE ROTATE ............................................................................................................. 235
VOICE MEMO SETTING............................................................................................ 236
RATING ..............................................................................................................................237
COPY .................................................................................................................................. 238
TRANSFER IMAGE TO SMARTPHONE .............................................................. 239
xF WIRELESS COMMUNICATION ................................................................ 241
SLIDE SHOW .................................................................................................................. 241
PHOTOBOOK ASSIST ................................................................................................242
PRINT ORDER (DPOF) ............................................................................................... 244
instax PRINTER PRINT ............................................................................................... 245
DISP ASPECT.................................................................................................................. 246
Network/USB Features and Settings 247
8
Overview ...........................................................................................................248
Supported Features .................................................................................................. 248
xix
Connecting to Smartphones (Bluetooth) ..............................................249
The Setup Menus 271
Installing Smartphone Apps ............................................................................... 249
Connecting to a Smartphone ............................................................................249
Using the Smartphone App ................................................................................251
Connecting to Smartphones (USB) .........................................................252
Copying Pictures to a Smartphone ................................................................252
Connecting the Camera and Computer ..................................................... 255
Using the Camera as a Webcam ...............................................................257
instax SHARE Printers ...................................................................................258
Establishing a Connection.................................................................................... 258
Printing Pictures .......................................................................................................... 259
Tethered Photography .................................................................................260
Tethered Photography via USB.......................................................................... 260
Tethered Photography via Wireless LAN .....................................................261
RAW Processing ..............................................................................................262
Saving and Loading Settings .....................................................................263
Saving and Loading Settings Using a Computer ................................... 263
Network/USB Setting Menus .....................................................................264
Bluetooth/SMARTPHONE SETTING .................................................................264
AIRPLANE MODE ........................................................................................................267
NETWORK SETTING .................................................................................................. 267
instax PRINTER CONNECTION SETTING ........................................................ 267
CONNECTION MODE ............................................................................................... 268
USB POWER SUPPLY/COMM SETTING .......................................................... 270
INFORMATION .............................................................................................................. 270
RESET WIRELESS SETTING ..................................................................................... 270
The Setup Menus 271
9
USER SETTING .................................................................................................272
FORMAT ............................................................................................................................ 272
b AREA SETTING ..................................................................................................... 273
DATE/TIME ...................................................................................................................... 273
TIME DIFFERENCE ....................................................................................................... 274
Qa ............................................................................................................... 275
x MY MENU SETTING ............................................................................................ 275
F MY MENU SETTING ............................................................................................275
xx
Table of Contents
SENSOR CLEANING ................................................................................................... 276
BATTERY AGE ................................................................................................................ 276
RESET ................................................................................................................................. 277
REGULATORY ................................................................................................................. 277
SOUND SETTING .............................................................................................278
AF BEEP VOL. ................................................................................................................. 278
SELF-TIMER BEEP VOL. ............................................................................................. 278
OPERATION VOL. ......................................................................................................... 279
F REC START/STOP VOLUME ............................................................................. 279
tt ELECTRONIC SHUTTER VOLUME ........................................................279
tt ELECTRONIC SHUTTER SOUND .......................................................... 280
s ELECTRONIC SHUTTER VOLUME ............................................................... 280
s ELECTRONIC SHUTTER SOUND .................................................................280
PLAYBACK VOLUME .................................................................................................. 281
4ch AUDIO PLAYBACK ............................................................................................. 281
SCREEN SETTING ............................................................................................282
VIEW MODE SETTING ............................................................................................... 282
EVF BRIGHTNESS ......................................................................................................... 282
EVF COLOR ..................................................................................................................... 282
EVF COLOR ADJUSTMENT .....................................................................................283
LCD BRIGHTNESS ........................................................................................................ 284
LCD COLOR .................................................................................................................... 284
LCD COLOR ADJUSTMENT ....................................................................................284
IMAGE DISP. ....................................................................................................................285
AUTOROTATE DISPLAYS .......................................................................................... 285
PREVIEW EXP./WB IN MANUAL MODE ........................................................... 286
NATURAL LIVE VIEW .................................................................................................. 286
F-Log VIEW ASSIST ..................................................................................................... 287
ELECTRONIC LEVEL SETTING ..............................................................................287
FRAMING GUIDELINE ............................................................................................... 288
AUTOROTATE PB .......................................................................................................... 289
FOCUS SCALE UNITS ................................................................................................289
APERTURE UNIT FOR CINEMA LENS................................................................ 289
DUAL DISPLAY SETTING ......................................................................................... 290
DISP. CUSTOM SETTING .......................................................................................... 290
xxi
LARGE INDICATORS MODE(EVF) ....................................................................... 291
LARGE INDICATORS MODE(LCD) ...................................................................... 291
LARGE INDICATORS DISP. SETTING .................................................................. 292
INFORMATION CONTRAST ADJ. .........................................................................292
LOCATION INFO ...........................................................................................................293
x Q MENU BACKGROUND ................................................................................. 293
F Q MENU BACKGROUND ................................................................................. 293
BUTTON/DIAL SETTING ................................................................................294
FOCUS LEVER SETTING ........................................................................................... 294
x
EDIT/SAVE QUICK MENU ................................................................................ 295
F
EDIT/SAVE QUICK MENU ................................................................................ 295
FUNCTION (Fn) SETTING........................................................................................ 295
POWER ZOOM LENS FUNCTION (Fn) SETTING ........................................ 295
SELECTOR BUTTON SETTING ..............................................................................295
COMMAND DIAL SETTING ................................................................................... 296
o S.S OPERATION .................................................................................................... 297
COMMAND DIAL DIRECTION .............................................................................. 297
SHUTTER AF ................................................................................................................... 298
SHUTTER AE ................................................................................................................... 298
SHOOT WITHOUT LENS ..........................................................................................299
SHOOT WITHOUT CARD ......................................................................................... 299
LENS ZOOM/FOCUS SETTING ............................................................................300
AE/AF-LOCK MODE ................................................................................................... 302
AWB-LOCK MODE ...................................................................................................... 302
APERTURE RING SETTING (A) .............................................................................. 303
APERTURE SETTING .................................................................................................. 303
a Fn1 BUTTON SETTING .....................................................................................303
TOUCH SCREEN SETTING ......................................................................................304
LOCK ...................................................................................................................................305
POWER MANAGEMENT ................................................................................306
AUTO POWER OFF ..................................................................................................... 306
PERFORMANCE ............................................................................................................ 306
EVF/LCD BOOST SETTING .....................................................................................307
AUTO POWER OFF TEMP. .......................................................................................307
xxii
Table of Contents
Shortcuts 311
Peripherals and Optional Accessories 333
SAVE DATA SETTING ......................................................................................308
FRAME NO. ..................................................................................................................... 308
EDIT FILE NAME ........................................................................................................... 309
x CARD SLOT SETTING .........................................................................................309
SELECT SLOT(xSEQUENTIAL) ........................................................................... 309
SELECT FOLDER ........................................................................................................... 310
COPYRIGHT INFO ........................................................................................................ 310
GEOTAGGING ................................................................................................................ 310
Shortcuts 311
10
Shortcut Options ............................................................................................312
MY MENU ..........................................................................................................313
MY MENU SETTING ................................................................................................... 313
The Quick Menu .............................................................................................315
The Quick Menu Display ........................................................................................ 315
Viewing and Changing Settings ....................................................................... 317
Editing the Quick Menu ......................................................................................... 318
Function Controls...........................................................................................321
The Function Buttons .............................................................................................. 321
Touch-Function Gestures ...................................................................................... 326
Lens Function Buttons ............................................................................................ 329
Peripherals and Optional Accessories 333
11
Lenses .................................................................................................................334
Lens Parts ........................................................................................................................ 334
Lens Care ......................................................................................................................... 335
Removing Lens Caps ............................................................................................... 335
Attaching Lens Hoods ............................................................................................ 336
Lenses with Aperture Rings ................................................................................. 337
Lenses with No Aperture Rings ......................................................................... 338
Lenses with O.I.S. Switches ...................................................................................338
Manual Focus Lenses ............................................................................................... 339
Power Zoom Lenses ................................................................................................. 340
xxiii
Table of Contents
Technical Notes 355
External Flash Units .......................................................................................341
Flash Settings ................................................................................................................ 342
EF-X8 .................................................................................................................................. 343
SYNC TERMINAL .......................................................................................................... 345
SHOE MOUNT FLASH ............................................................................................... 346
COMMANDER(OPTICAL) ........................................................................................ 349
Handgrips .........................................................................................................353
Technical Notes 355
12
Accessories from Fuji lm .............................................................................356
Software for Use with Your Camera .........................................................359
Smartphone Apps ..................................................................................................... 359
RAW FILE CONVERTER EX powered by SILKYPIX ..................................... 359
Capture One Express for Fuji lm ...................................................................... 360
Capture One for Fuji lm ........................................................................................ 360
FUJIFILM Tether Shooting Plug-in (Exclusively for Lightroom) ...... 360
FUJIFILM X Acquire ................................................................................................... 361
FUJIFILM X RAW STUDIO ....................................................................................... 361
FUJIFILM Pixel Shift Combiner ...........................................................................361
For Your Safety ................................................................................................362
Product Care ....................................................................................................373
Cleaning the Image Sensor ........................................................................374
Firmware Updates ..........................................................................................375
Checking the Firmware Version ........................................................................375
Troubleshooting .............................................................................................376
Warning Messages and Displays ..............................................................389
Memory Card Capacity ................................................................................394
Speci cations ..................................................................................................395
xxiv

Supplied Accessories

The following are included with the camera:
NP-W235 rechargeable battery
•
For reasons of safety, the battery is not charged at shipment.
O
The camera will not function if the battery is not charged; be sure to charge the battery before use (P 42).
AC-5VJ AC power adapter
•
Plug adapter
•
USB cable (approx. 0.6m/2ft.)
•
Body cap (comes attached to camera)
•
Shoulder strap
•
Hot shoe cover (comes attached to hot shoe)
•
Sync terminal cap (comes attached to camera)
•
Headphone adapter
•
Basic Manual
•
If you purchased a lens kit, check that a lens is included.
•
N
The plug adapter supplied varies with the country or region.
•
The headphone adapter converts the USB Type-C connector to a
•
⌀3.5 mm headphone jack.
For information on compatible computer software, see “Software for
•
Use with Your Camera” (P 359).
xxv

About This Manual

This manual contains instructions for your FUJIFILM X-T5 dig­ital camera. Be sure you have read and understood its con­tents before proceeding.

Symbols and Conventions

The following symbols are used in this manual:
Information that should be read to prevent damage to the
O
product.
Additional information that may be helpful when using the
N
product.
Pages on which related information may be found.
P
Menus and other text in the displays are shown in bold. Illustrations are for explanatory purposes only; drawings may be simpli ed, while photographs are not necessarily taken with the model of camera described in this manual.

Terminology

The optional SD, SDHC, and SDXC memory cards the camera uses to store pictures are referred to as “memory cards”. The elec­tronic view nder may be referred to as the “EVF” and the LCD monitor as the “LCD”. Smartphones and tablets are referred to as “smartphones”.
xxvi

Before You Begin

1

Parts of the Camera

1
Before You Begin
Fn1 button .....................................................321
A
Exposure compensation dial .................. 6, 99
B
Shutter button .................................................55
C
Shutter speed dial
D
.................................................5, 72, 74, 78, 80
Dial lock release ................................................5
E
Hot shoe .........................................................342
F
Microphone ......................................................62
G
Diopter adjustment control (lockable)
H
..........................................................................11
Sensitivity dial .............................................5, 96
I
Drive dial .............................................................6
J
Strap clip............................................................34
K
Connector cover
L
Sync terminal ................................................345
M
Focus mode selector ......................................83
N
Lens signal contacts
O
2
Lens release button ........................................35
P
Fn2 button .....................................................321
Q
AF-assist illuminator................................... 150
R
Self-timer lamp ............................................ 168
Tally light ........................................................ 199
STILL/MOVIE mode dial ..................... 5, 62, 72
S
Front command dial ...............................7, 296
T
ON/OFF switch .................................................46
U
Hot shoe cover ..............................................342
V
Body cap ............................................................35
W
Microphone jack (⌀3.5mm) .......................67
X
Remote release connector (⌀2.5mm)
Y
..........................................................................77
USB connector (Type-C) ...............................42
Z
HDMI Micro connector (Type D) ................57
a
Speaker .................................................... 69, 281
b
Parts of the Camera
1
Before You Begin
b (delete) button ...........................................59
c
a (playback) button ...................................56
d
Electronic viewfi nder (EVF)
e
.....................................................12, 16, 18, 26
Eye cup (lockable) ...........................................11
f
VIEW MODE button .........................................16
g
AFON button .........................................102, 321
h
Rear command dial .......................7, 223, 296
i
Q (quick menu) button ............................... 315
j
Indicator lamp .......................................... 9, 199
k
Tally light ........................................................ 199
AEL (exposure lock) button ..............102, 321
l
Focus stick (focus lever)...................4, 87, 294
m
Memory card slot cover latch ......................38
n
Memory card slot cover ................................38
o
Selector buttons ................................................4
p
MENU/OK button .............................................24
q
Battery-chamber cover latch ......................36
r
Battery-chamber cover .................................36
s
DISP (display)/BACK button ............... 19, 221
t
x(Bluetooth) button ..................................249
Tripod mount
u
LCD monitor .......................................10, 14, 16
v
Touch screen ................................. 26, 160, 210
Eye sensor ..........................................................16
w
Memory card slot 2 ........................................38
x
Memory card slot 1 ........................................38
y
Battery chamber .............................................36
z
Battery latch .....................................................37
0
Serial number plate..........................................4
1
3

The Serial Number Plate

Do not remove the serial number plate, which provides the CMIITID, serial num­ber, and other important information.
1
Before You Begin

The Focus Stick (Focus Lever)

Tilt or press the focus stick to select the fo­cus area. The focus stick can also be used to navigate the menus.
To choose the role played by the focus stick, press and hold the cen-
N
ter of the stick or use D BUTTON/DIAL SETTING> FOCUS LEVER SETTING.

The Selector

Press the selector up, right, down, or left to highlight items. The up, right, down, and left buttons also double as function buttons Fn3 through Fn6 (P 295, 321).
Serial number plate
4

The Shutter Speed and Sensitivity Dials

Press the dial lock release to release the dial before rotating it to the desired set­ting. Press the release again to lock the dial in place.
Parts of the Camera

STILL/MOVIE mode dial

Rotate the STILL/MOVIE mode dial to STILL to take photos and to MOVIE to record movies.
Shutter speed
Sensitivity
1
Before You Begin
5

The Exposure Compensation Dial

Mode
P
u
ADV.
BKT
CH
Mode
P
CL
S
h
Rotate the dial to choose an exposure compensation amount.
1
Before You Begin

The Drive Dial

Rotate the dial to choose from the follow­ing the drive modes.
Mode
Panorama 111
u
ADV. Advanced filter 109
BKT Bracketing 103
CH High-speed burst 105
6
P
CL Low-speed burst 105
S Single frame 52
h
Mode
HDR 107
P
Parts of the Camera
Rotate
Press

The Command Dials

Rotate or press the command dials to:
Front command dial Rear command dial
Highlight menu items
•
Choose the desired combina-
Select menu tabs or page
•
through menus Adjust aperture
•
Adjust exposure compensation
•
Adjust sensitivity
Press
•
View other pictures during
•
playback
Switch back and forth between
•
aperture and sensitivity Press and hold to choose the op-
•
tion selected for D BUTTON/
DIAL SETTING > COMMAND DIAL SETTING in the D (setup)
menu
Rotate
1 Lens not equipped with aperture ring; lens equipped with aperture ring and aperture set
to A(auto) and COMMAND selected for D BUTTON/DIAL SETTING> APERTURE RING SETTING (A); or ON selected for MOVIE OPTIMIZED CONTROL oL.
2 Can be changed using D BUTTON/DIAL SETTING> COMMAND DIAL SETTING. 3 Sensitivity dial rotated to C or ON selected for MOVIE OPTIMIZED CONTROL oL.
1, 2
2, 3
2, 3, 6
•
tion of shutter speed and aper­ture (program shift) Choose a shutter speed
•
2, 5
Adjust settings in the quick menu
•
Choose the size of the focus frame
•
Zoom in or out in full frame play-
•
back Zoom in or out in multi-frame
•
playback Perform the function assigned
•
to the DIAL function button Zoom in on the active focus point
•
Press and hold to choose the
•
manual focus mode focus display Zoom in on the active focus
•
point during playback
2
1
Before You Begin
4
4
7
4 Available only if FOCUS CHECK is assigned to a function button. 5 Exposure compensation dial rotated to C or ON selected for MOVIE OPTIMIZED
CONTROL oL.
6 Can be used to switch back and forth between aperture, sensitivity, and exposure com-
pensation when exposure compensation dial is rotated to C or ON is selected for MOVIE OPTIMIZED CONTROL oL.
The rotation direction for the command dials can be selected using
N
1
Before You Begin
D BUTTON/DIAL SETTING> COMMAND DIAL DIRECTION.
8
Parts of the Camera
Indicator lamp
Camera status

The Indicator Lamp

Camera status is shown by the indicator lamp.
Indicator lamp
Glows green Focus locked.
Blinks green
Blinks green and
orange
Glows orange
Blinks orange Flash charging; fl ash will not fi re when picture is taken.
Blinks red Lens or memory error.
* Displayed only if pictures are selected for upload.
Focus or slow shutter speed warning. Pictures can be taken.
Camera on: Recording pictures, or picture displayed for
•
confi rmation after being taken with option other than OFF selected for D SCREEN SET-UP> IMAGE DISP. (additional pictures can be taken). Camera o : Uploading pictures to a smartphone or tab-
•
*
let.
Recording pictures. No additional pictures can be taken at this time.
Camera status
1
Before You Begin
Warnings may also appear in the display.
•
N
The indicator lamp remains o while your eye is to the view nder.
•
The B MOVIE SETTING> TALLY LIGHT option can be used to
•
choose the lamp (indicator or AF-assist) that lights during movie re­cording and whether the lamp blinks or remains steady. The indicator lamp blinks green whenever the displays are o during
•
interval-timer photography.
9

The LCD Monitor

The LCD monitor can be tilted for eas­ier viewing, but be careful not to touch the wires or trap  ngers or other objects behind the monitor. Touching the wires could cause camera malfunction.
1
Before You Begin
The LCD monitor also functions as a touch screen that can be used for:
N
Touch photography (P 27)
•
Focus area selection (P 26)
•
Function selection (P 29)
•
Movie optimized control oL (P 28)
•
Playback (P 31)
•
“Tall” (Portrait) Orientation
The display can also be tilted to take pictures from high or low angles when the camera is rotated to take pictures in “tall” (portrait) orientation.
Press the tilt lock release and tilt the display as shown in Figure 1.
•
To take high-angle shots, hold the camera in the orientation shown in
•
Figure 2.
Figure 1 Figure 2
10
Parts of the Camera

The Eye Cup

To remove the eye cup, hold the buttons on either side and slide eye cup up.
Focusing the View nder
If the indicators displayed in the view nder are blurred, put your eye to the view nder and rotate the diopter adjustment control until the display is in sharp focus.
To focus the view nder:
Lift the diopter adjustment control.
A
Rotate the control to adjust view nder focus.
B
Return the control to its original position and lock it in place.
C
1
Before You Begin
Lift the control before use. Failure to observe this precaution could
O
cause product malfunction.
11

Camera Displays

This section lists the indicators that may be displayed during shooting.
For illustrative purposes, displays are shown with all indicators lit.
O
The Electronic View nder
1
Before You Begin
E F L M N O P Q S T XY
GHI JK U V W
5 4 3 2 1 0
z
y x w
nqr
opstuv
R
Z
a b
c
d
e
f
hi gjklm
12
Camera Displays
Crop factor .....................................................193
A B C D E F G H I J K L M N O P Q R S T U
V W X Y Z a b c
1 Shows “9999” if there is space for over 9999 frames. 2 Not displayed when ON is selected for D SCREEN SET-UP> LARGE INDICATORS
MODE(EVF).
3 Displayed when controls have been locked by pressing and holding the MENU/OK button.
Control lock can be ended by pressing and holding the MENU/OK button again.
2
IS mode
......................................................... 174
Flash (TTL) mode .........................................346
Flash compensation ................................... 346
Movie compression .....................................191
Digital teleconverter ...................................175
Self-timer indicator ............................168, 190
Continuous mode ........................................ 105
Shutter type ................................................... 170
AF+MF indicator Bluetooth ON/OFF
White balance ..............................................126
AWB lock ........................................................302
Film simulation ............................................122
F-Log/HLG recording ..................................194
Dynamic range ............................................130
D-range priority ...........................................130
Image transfer status ........................249, 264
Movie mode ........................................... 62, 188
High-speed recording indicator .............. 189
Recording time available/
elapsed recording time ..............................62
Card slot options ................................... 40, 309
Number of available frames
Image size ...................................................... 118
File format ...................................................... 191
Image quality................................................ 119
HEIF format ...................................................121
Date and time ..................................48, 50, 273
Touch screen mode .............................. 26, 160
2
....................................... 155
1
................... 394
Temperature warning ......................... 39, 393
d
Control lock
e
Boost mode ...................................................307
f
Power supply ....................................................44
g
Histogram .........................................................22
h
Battery level ......................................................47
i
Sensitivity ..........................................................96
j
Exposure compensation ...............................99
k
Aperture ............................................... 73, 78, 80
l
Distance indicator
m
Shutter speed .....................................73, 74, 80
n
TTL lock ..................................................181, 325
o
AE lock .................................................... 102, 302
p
Metering ............................................................98
q
Shooting mode ...............................................72
r
Focus mode
s
Focus indicator
t
Manual focus indicator
u
AF lock .................................................... 102, 302
v
Time code ....................................................... 216
w
Microphone input channel .............. 186, 215
x
Recording level
y
Exposure indicator ...................................80, 99
z
Virtual horizon .................................................23
0
Focus frame ............................................ 87, 101
1
Bluetooth host .............................................. 249
2
Location data download status .............. 310
3
Depth-of-fi eld preview ........................... 79, 93
4
Focus check ............................................94, 156
5
3
................................................. 305
2
........................................93
2
....................................................83
2
..............................................84
2
.......................83, 91
2
........................................... 213
1
Before You Begin
13

The LCD Monitor

J KF G Q R
A C D E MH N PO S T U
B
L
I
7 6
1
5 4
Before You Begin
3 2
1
0 z y
qruvwx
hgijm klnopst
f
V W
X Y
Z a
b c
d
e
14
Camera Displays
Crop factor .....................................................193
A
Location data download status .............. 310
B
Focus check ............................................94, 156
C
Depth-of-fi eld preview ........................... 79, 93
D
Image transfer status ........................249, 264
E
Movie compression .....................................191
F
Digital teleconverter ...................................175
G
Bluetooth ON/OFF
H
Bluetooth host .............................................. 249
I
Movie mode ........................................... 62, 188
J
High-speed recording indicator .............. 189
K
Focus frame ............................................ 87, 101
L
Recording time available/
M
elapsed recording time ..............................62
Date and time ..................................48, 50, 273
N
Card slot options ................................... 40, 309
O
Number of available frames
P
Image size ...................................................... 118
Q
File format ...................................................... 191
R
Image quality................................................ 119
S
HEIF format ...................................................121
T
Touch screen mode
U
AWB lock ........................................................302
V
White balance ..............................................126
W
Film simulation ............................................122
X
F-Log/HLG recording ..................................194
Y
Dynamic range ............................................130
Z
D-range priority ...........................................130
a
Movie optimized control
b
Virtual horizon .................................................23
c
Boost mode ...................................................307
d
1 Shows “9999” if there is space for over 9999 frames. 2 Not displayed when ON is selected for D SCREEN SET-UP> LARGE INDICATORS
MODE(LCD).
3 Camera functions can also be accessed via touch controls. 4 Displayed when controls have been locked by pressing and holding the MENU/OK button.
Control lock can be ended by pressing and holding the MENU/OK button again.
1
................... 394
3
............................ 26, 160
3
.............................28
Touch zoom
e
Temperature warning ......................... 39, 393
f
Control lock
g
Battery level ......................................................47
h
Power supply ....................................................44
i
Sensitivity ..........................................................96
j
Histogram .........................................................22
k
Exposure compensation ...............................99
l
Distance indicator
m
Aperture ............................................... 73, 78, 80
n
Time code ....................................................... 216
o
Shutter speed .....................................73, 74, 80
p
TTL lock ..................................................181, 325
q
AE lock .................................................... 102, 302
r
Metering ............................................................98
s
Shooting mode ...............................................72
t
Focus mode
u
Focus indicator
v
Manual focus indicator
w
AF lock .................................................... 102, 302
x
Microphone input channel .............. 186, 215
y
AF+MF indicator
z
Shutter type ................................................... 170
0
Recording level
1
Continuous mode ........................................ 105
2
Self-timer indicator ............................168, 190
3
Exposure indicator ...................................80, 99
4
Flash (TTL) mode .........................................346
5
Flash compensation ................................... 346
6
IS mode
7
3
....................................................30
4
..................................................305
2
........................................93
2
....................................................83
2
..............................................84
2
.......................83, 91
2
....................................... 155
2
........................................... 213
2
......................................................... 174
1
Before You Begin
15

Choosing a Display Mode

Option
Description
EE EYE SENSOR
LCD ONLY
EVF ONLY
EVF ONLY +
EE EYE SENSOR + LCD
IMAGE DISP.
Press the VIEW MODE button to cycle through the following display modes. You can choose separate display modes for shooting and playback.
1
Before You Begin
Use D SCREEN SET-UP > VIEW MODE SETTING in the setup menu to
N
choose a display mode for the EVF and LCD monitor.
SHOOTING
Option
Putting your eye to the viewfi nder turns the viewfi nder
EYE SENSOR
LCD ONLY LCD monitor on, viewfi nder off .
EVF ONLY Viewfi nder on, LCD monitor off .
EVF ONLY + EE
EYE SENSOR + LCD
IMAGE DISP.
Go to D SCREEN SET-UP > VIEW MODE SETTING in the setup menu
N
and press the Q button to choose the view modes available.
on and the LCD monitor off ; taking your eye away turns the viewfi nder off and LCD monitor on.
Putting your eye to the viewfi nder turns the viewfi nder on; taking it away turns the viewfi nder off . The LCD monitor remains off .
Putting your eye to the viewfi nder during shooting turns the viewfi nder on, but the LCD monitor is used for the display of images once you remove your eye from the viewfi nder after shooting. The options selected for D SCREEN SET-UP> IMAGE DISP. apply to display in the LCD monitor.
Description
16
PLAYBACK
Option
Description
EE EYE SENSOR
LCD ONLY EVF ONLY
Camera Displays
Option
Description
Putting your eye to the viewfi nder turns the viewfi nder
EYE SENSOR
on and the LCD monitor off ; taking your eye away turns the viewfi nder off and LCD monitor on.
LCD ONLY LCD monitor on, viewfi nder off . EVF ONLY Viewfi nder on, LCD monitor off .
The Eye Sensor
The eye sensor may respond to objects other than your eye or to light shining directly on the sensor.
1
Before You Begin
Eye sensor
17

Adjusting Display Brightness

The brightness and saturation of the view nder and LCD monitor can be adjusted using the items in the D SCREEN SET-UP menu. Choose EVF BRIGHTNESS or EVF COLOR to adjust view nder brightness or saturation, LCD BRIGHTNESS or LCD COLOR to do the same for the LCD monitor.
1

Display Rotation

Before You Begin
When ON is selected for D SCREEN SET-UP> AUTOROTATE DISPLAYS, the indicators in the view nder and LCD monitor au­tomatically rotate to match camera orientation.
18

The DISP/BACK Button

The DISP/BACK button controls the display of indicators in the view nder and LCD monitor.
Indicators for the EVF and LCD must be
N
selected separately. To choose the EVF dis­play, place your eye to the view nder while using the DISP/BACK button.
Viewfi nder
Full screen Standard indicators
Dual display
(manual focus mode only)
Camera Displays
1
Before You Begin
19
LCD Monitor
Standard indicators No indicators
1
Before You Begin
Dual display
12800
12800
Info display
(manual focus mode only)

The Dual Display

The dual display consists of a large full-frame window and a smaller close-up of the focus area.
20
Camera Displays
Item
Default
Item
Default

Customizing the Standard Display

To choose the items shown in the standard indicator display:
Display standard indicators.
1
Use the DISP/BACK button to display standard indicators.
Select DISP. CUSTOM SETTING.
2
Select D SCREEN SET-UP> DISP. CUSTOM SETTING in the
setup menu.
Choose items.
3
Highlight items and press MENU/OK to select or deselect.
Item
FRAMING GUIDELINE FOCUS FRAME FOCUS INDICATOR AF DISTANCE INDICATOR MF DISTANCE INDICATOR HISTOGRAM LIVE VIEW HIGHLIGHT ALERT SHOOTING MODE APERTURE/S-SPEED/ISO INFORMATION BACKGROUND Expo. Comp. (Digit) Expo. Comp. (Scale) FOCUS MODE PHOTOMETRY SHUTTER TYPE FLASH
CONTINUOUS MODE
Default
R
R R
R
R
R R
R R R
R
R R R R R
R
Item
DUAL IS MODE TOUCH SCREEN MODE WHITE BALANCE FILM SIMULATION DYNAMIC RANGE BOOST MODE FRAMES REMAINING IMAGE SIZE/QUALITY MOVIE MODE & REC. TIME DIGITAL TELE-CONV. COMMUNICATION STATUS MIC LEVEL GUIDANCE MESSAGE NO MEMORY CARD WARNING DATE/TIME BATTERY LEVEL FRAMING OUTLINE
Default
R R R R R R R R R R R R R R R R
R
1
Before You Begin
Press DISP/BACK to save changes.
4
Press DISP/BACK as needed to exit the menus and return to the
5
shooting display.
21
Framing Outline
Enable FRAMING OUTLINE to make the borders of the frame easier to see against dark backgrounds.
Histograms
Histograms show the distribution of tones in the image. Brightness is shown by the horizontal axis, the number of pixels by the vertical axis.
1
Before You Begin
Number of pixels
Shadows Highlights
Optimal exposure: Pixels are distributed in an even curve
•
throughout the tone range.
Overexposed: Pixels are clustered on the right side of
•
the graph.
Underexposed: Pixels are clustered on the left side of
•
the graph.
To view separate RGB histograms and a dis­play showing areas of the frame that will be overexposed at current settings superimposed on the view through the lens, press the func­tion button to which HISTOGRAM is assigned (P 295, 321).
Overexposed areas blink
A
RGB histograms
B
Pixel brightness
BA
22
Camera Displays

Virtual Horizon

Check whether the camera is level. The display type can be cho­sen using D SCREEN SET-UP> ELECTRONIC LEVEL SETTING. Use the virtual horizon to level the camera when mounting it on a tripod or the like.
2D 3D
Pitch Roll
OFF: The virtual horizon is not displayed.
•
2D: A white line shows the amount the camera is tilted
•
left or right. The line turns green when the camera is level. The line may vanish if the camera is tilted forward or back. 3D: The display shows whether the camera is tilted left or
•
right and forward or back.
ELECTRONIC LEVEL SWITCH can be assigned to a function button
N
and the button then used to switch between the 2D and 3D displays.
1
Before You Begin
23

Using the Menus

Shooting
Playback
To display the menus, press MENU/OK.
1
Before You Begin

The Menus

Di erent menus are displayed during still photography, movie recording, and playback.
IMAGE QUALITY SETTING
IMAGE SIZE IMAGE QUALITY RAW RECORDING SELECT JPEG/HEIF FILM SIMULATION MONOCHROMATIC COLOR GRAIN EFFECT COLOR CHROME EFFECT
STILL/MOVIE mode dial
Shooting
Playback
rotated to STILL
STILL/MOVIE mode dial
rotated to MOVIE
During playback
MOVIE SETTING
MOVIE SETTING LIST MOVIE MODE HIGH SPEED REC FSELF-TIMER MEDIA REC SETTING HDMI OUTPUT SETTING FIX MOVIE CROP MAGNIFICATION F-Log/HLG RECORDING
PLAY BACK MENU
SWITCH SLOT RAW CONVERSION HEIF TO JPEG/TIFF CONVERSION ERASE SIMULTANEOUS DELETE CROP RESIZE
PROTECT
EXIT
EXIT
EXIT
24

Selecting a Menu Tab

To navigate the menus:
Press MENU/OK to display the menus.
1
Press the selector left to highlight the
2
tab for the current menu.
IMAGE SIZE
IMAGE QUALITY RAW RECORDING SELECT JPEG/HEIF FILM SIMULATION MONOCHROMATIC COLOR GRAIN EFFECT COLOR CHROME EFFECT
IMAGE SIZE IMAGE QUALITY RAW RECORDING SELECT JPEG/HEIF FILM SIMULATION MONOCHROMATIC COLOR GRAIN EFFECT COLOR CHROME EFFECT
Ta b
Using the Menus
1
Before You Begin
IMAGE QUALITY SETTING
EXIT
IMAGE QUALITY SETTING
EXIT
Press the selector up or down to highlight the tab containing
3
the desired item.
Press the selector right to place the cursor in the menu.
4
Use the front command dial to select menu tabs or page through
N
menus and the rear command dial to highlight menu items.
25

Touch Screen Mode

The LCD monitor also functions as a touch screen.

Shooting Touch Controls

To enable touch controls, select ON for
D BUTTON/DIAL SETTING> TOUCH SCREEN SETTING> x TOUCH SCREEN
1
Before You Begin
SETTING.
EVF
The LCD monitor can be used to select the focus area while pic­tures are being framed in the electronic view nder (EVF). Use
D BUTTON/DIAL SETTING> TOUCH SCREEN SETTING> EVF TOUCH SCREEN AREA SETTINGS to choose the area of the mon-
itor employed for touch controls.
TOUCH SCREEN SETTINGS
TOUCH SCREEN SETTING
DOUBLE TAP SETTING TOUCH FUNCTION
TOUCH ZOOM
TOUCH SCREEN SETTING
EVF TOUCH SCREEN AREA SETTINGS
ON
OFF
When FACE DETECTION ON is selected for GAF/MF SETTING>
•
N
g FACE/EYE DETECTION SETTING, you can choose the face used for focus. You can choose the type of subject on which the camera preferential-
•
ly focuses when SUBJECT DETECTION ON is selected for G AF/MF SETTING> SUBJECT DETECTION SETTING.
26
LCD Monitor
Mode
Description
TOUCH SHOOTING
AF
AFOFF
AREA
OFF
The operation performed can be selected by tapping the touch screen mode indica­tor in the display. Touch controls can be used for the following operations:
Touch Screen Mode
Mode
TOUCH SHOOTING
AF
AFOFF
AREA
OFF
The behavior of the touch screen varies with the AF mode.
•
O
Di erent touch controls are used during focus zoom (P 161).
•
Tap your subject in the display to focus and release the shutter. In burst mode, pictures will be taken while you keep your fi nger on the display.
In focus mode S (AF-S), the camera focuses when you tap your
•
subject in the display. Focus locks at the current distance until you tap the AFOFF icon. In focus mode C (AF-C), the camera initiates focus when you
•
tap your subject display. The camera will continue to adjust focus for changes in the distance to the subject until you tap the AFOFF icon. In manual focus mode (MF), you can tap the display to focus
•
on the selected subject using autofocus.
Tap to select a point for focus or zoom. The focus frame will move to the selected point.
Touch screen mode off .
Description
1
Before You Begin
27
To disable touch controls and hide the touch screen mode indica-
•
N
tor, select OFF for DBUTTON/DIAL SETTING> TOUCH SCREEN SETTING> x TOUCH SCREEN SETTING.
Touch control settings can be adjusted using G AF/MF SETTING>
•
TOUCH SCREEN MODE. For information on the touch controls available during movie recording, see “Movie Recording (FTOUCH SCREEN MODE; P 210)”.
1
MOVIE OPTIMIZED CONTROL oL
Before You Begin
Selecting ON for B MOVIE SETTING> MOVIE OPTIMIZED CONTROLoL or tapping the movie-optimized mode but­ton in the shooting display optimizes the command dials and touch controls for movie recording. This can be used to pre­vent camera sounds being recorded with movie footage.
Movie-optimized
mode button
SHUTTER SPEED
•
APERTURE
•
EXPOSURE COMPENSATION
•
ISO
•
INTERNAL MIC LEVEL
•
ADJUSTMENT/EXTERNAL MIC LEVEL ADJUSTMENT
Enabling movie-optimized controls disables the aperture ring and
•
N
the shutter-speed, sensitivity, and exposure compensation dials. When movie-optimized control is enabled, the movie-optimized
•
mode button can be used to change shooting settings or disable movie-optimized control.
28
WIND FILTER
•
HEADPHONES VOLUME
•
F FILM SIMULATION
•
F WHITE BALANCE
•
F IS MODE
•
F IS MODE BOOST
•
Touch Screen Mode
Touch Function
Functions can be assigned to the follow­ing  ick gestures in much the same way as function buttons (P 321):
Flick up: T-Fn 1
•
Flick left: T-Fn 2
•
Flick right: T-Fn 3
•
Flick down: T-Fn4
•
In some cases, touch-function  ick ges-
•
N
tures display a menu; tap to select the desired option.
Touch-function gestures are disabled by default. To enable
•
touch-function gestures, select ON for D BUTTON/DIAL SETTING> TOUCH SCREEN SETTING> c TOUCH FUNCTION.
INTERNAL MIC LEVEL ADJUSTMENT
SET CANCEL
LR
1
Before You Begin
0
-6
-12
-20
-40
-50 dB
29
Touch Zoom
Button
Description
Touch zoom
Zoom in
Zoom out
Rocker switch
Disable
If the lens supports touch zoom, you can zoom in and out by touching the display. Tap the touch zoom button in the display to enable touch zoom.
1
Touch zoom is controlled using the but-
Before You Begin
tons in the display.
Button
Touch zoom Enable touch zoom.
Zoom in
Zoom out
Rocker switch
Disable Disable touch zoom.
The rate at which the camera zooms in and out in response to the T
N
and W buttons can be selected using D BUTTON/DIAL SETTING> LENS ZOOM/FOCUS SETTING> CONSTANT SPEED ZOOM (Fn).
Zoom in or out. Touch and hold to zoom in or out at a constant speed.
The camera zooms in or out at a speed corresponding to the position of the rocker switch.
Description
30
Touch Screen Mode

Playback Touch Controls

When ON is selected for D BUTTON/DIAL SET TING > TOUCH SCREEN SETTING> a TOUCH SCREEN SETTING, touch controls
can be used for the following playback operations:
Swipe: Swipe a  nger across the display to
•
view other images.
Pinch-out: Place two  ngers on the display
•
and spread them apart to zoom in.
Pinch-in: Place two  ngers on the display
•
and slide them together to zoom out.
Pictures can be zoomed out until the entire image is visible but no
N
further.
Double-tap: Tap the display twice to zoom in
•
on the focus point.
1
Before You Begin
Drag: View other areas of the image during
•
playback zoom.
31
MEMO
32

First Steps

33

Attaching the Strap

Attach the strap.
Attach the strap to the two strap clips as shown below.
2
First Steps
To avoid dropping the camera, be sure the strap is correctly secured.
O
34

Attaching a Lens

The camera can be used with lenses for the FUJIFILM X-mount.
Remove the body cap from the camera and the rear cap from the lens. Place the lens on mount, keeping the marks on the lens and camera aligned ( rotate the lens until it clicks into place (B).
When attaching lenses, ensure that dust or other foreign matter does
•
O
not enter the camera. Be careful not to touch the camera’s internal parts.
•
Rotate the lens until it clicks securely into place.
•
Do not press the lens release button while attaching the lens.
•
Removing Lenses
To remove the lens, turn the camera o , then press the lens release button (A) and rotate the lens as shown (B).
To prevent dust accumulating on the lens
O
or inside the camera, replace the lens caps and camera body cap when the lens is not attached.
Lenses and Other Optional Accessories
The camera can be used with lenses and accessories for the FUJIFILM X-mount.
), and then
A
2
First Steps
Observe the following precautions when attaching or removing (ex-
O
changing) lenses.
Check that the lenses are free of dust and other foreign matter.
•
Do not change lenses in direct sunlight or under another bright light
•
source. Light focused into the interior of the camera could cause it to malfunction. Attach the lens caps before exchanging lenses.
•
See the manual provided with the lens for information on use.
•
35
First Steps

Inserting the Battery

Insert the battery in the camera as described below.
Open the battery-chamber cover.
1
Slide the battery-chamber cover latch as shown and open the bat­tery-chamber cover.
Do not open the battery-chamber
•
O
2
2
cover when the camera is on. Fail­ure to observe this precaution could damage image  les or memory cards. Do not use excessive force when
•
handling the battery-chamber cover.
Insert the battery as shown.
Insert the battery in the orientation
•
O
shown. Do not use force or attempt to insert the battery upside down or backwards.
Con rm that the battery is securely
•
latched.
36
Close the battery-chamber cover.
3
Close and latch the cover.
If the cover does not close, check that
O
the battery is in the correct orienta­tion. Do not attempt to force the cov­er shut.
Inserting the Battery
Removing the Battery
Before removing the battery, turn the camera o and open the battery-cham- ber cover. To remove the battery, press the battery latch to the side, and slide the battery out of the camera as shown.
The battery may become hot when used in high-temperature environ-
O
ments. Observe caution when removing the battery.
2
First Steps
37
First Steps

Inserting Memory Cards

Pictures are stored on memory cards (sold separately).
The camera can be used with two cards, one in each of its two slots.
N
Open the memory card slot cover.
1
Unlatch and open the cover.
2
Do not turn the camera o or remove the memory card while the
O
memory card is being formatted or data are being recorded to or de­leted from the card. Failure to observe this precaution could dam-
age the card.
Insert the memory card.
2
Holding the card in the orientation shown, slide it in until it clicks into place at the back of the slot. Close and latch the memory card slot cover.
Be sure card is in the correct orientation; do not insert at an angle
O
or use force.
38
Inserting Memory Cards
Removing Memory Cards
Turn the camera o and open the memory card slot cover. Eject the card by pressing it in with a  nger and then slowly releasing it; the card can then be removed by hand.
Press the center of the card.
•
O
Suddenly removing your  nger from the card could cause the card to
•
fall from the slot. Remove your  nger slowly. If the camera displays a p icon, the memory card may be hot to the
•
touch. Wait for the card to cool before removing it.
2
First Steps
39

Using Two Cards

Option
Description
Display
The camera can be used with two cards, one in each of its two slots. At default settings, photos are saved to the card in the sec­ond slot only when the card in the  rst slot is full. This can be changed using D SAVE DATA SET-UP> x CARD SLOT SETTING.
2
First Steps
Option
The card in the second slot is used only when the card in the fi rst slot is full. If the second slot is selected for D SAVE
SEQUENTIAL
(default)
BACKUP Each picture is recorded twice, once to each card.
SEPARATE
DATA SET-UP> SELECT SLOT(xSEQUENTIAL), recording will start on the card in the second slot and switch to the fi rst slot when the card in the second slot is full.
RAW pictures are recorded to the card in the fi rst slot and JPEG or HEIF pictures to the card in the second slot. This setting takes eff ect only when FINE + RAW or
NORMAL+ RAW is selected for H IMAGE QUALITY SETTING> IMAGE QUALITY.
Description
The card used to store movies can be selected using B MOVIE SETTING> MEDIA REC SETTING.
Display
RAW+JPEG
RAW+HEIF
40
Inserting Memory Cards

Compatible Memory Cards

The camera can be used with SD, SDHC, and SDXC memory
•
cards. Both the UHS-I and UHS-II bus interfaces are supported. UHS-II cards are recommended for high-speed burst photography.
•
The types of memory cards suitable for movie recording vary
•
with the settings selected (P 68). A list of supported memory cards is available on the Fuji lm
•
website. For details, visit:
https://fujifilm-x.com/support/compatibility/cameras/
Do not turn the camera o or remove the memory card while the memo-
•
O
ry card is being formatted or data are being recorded to or deleted from the card. Failure to observe this precaution could damage the card.
Memory cards can be locked, making it
•
impossible to format the card or to record or delete images. Before inserting a mem­ory card, slide the write-protect switch to the unlocked position. Memory cards are small and can be swallowed; keep out of reach of
•
children. If a child swallows a memory card, seek medical assistance immediately. miniSD or microSD adapters that are larger or smaller than memory
•
cards may not eject normally; if the card does not eject, take the cam­era to an authorized service representative. Do not forcibly remove the card. Do not a x labels or other objects to memory cards. Peeling labels
•
can cause camera malfunction. Movie recording may be interrupted with some types of memory card.
•
Formatting a memory card in the camera creates a folder in which
•
pictures are stored. Do not rename or delete this folder or use a com­puter or other device to edit, delete, or rename image  les. Always use the camera to delete pictures; before editing or renaming  les, copy them to a computer and edit or rename the copies, not the originals. Renaming the  les on the camera can cause problems during playback.
.
2
First Steps
41
First Steps

Charging the Battery

For reasons of safety, the battery is not charged at ship­ment. The camera will not function if the battery is not charged; be sure to charge the battery before use. Before charging the battery, turn the camera o .
An NP-W235 rechargeable battery is supplied with the camera.
•
O
Charging takes about 180minutes.
•
Attach the plug adapter to the AC power adapter.
1
2
Attach the plug adapter as shown, making sure that it is fully inserted and clicks into place on the AC power adapter terminals.
The supplied plug adapter is for use exclu-
•
O
sively with the AC-5VJ AC power adapter. Do not use it with other devices. The shape of the plug adapter varies with
•
the country of sale.
Charge the battery.
2
Connect the camera to the supplied AC power adapter using the supplied USB cable. Then plug the AC power adapter into an indoor power outlet.
42
Connect the cable to the camera’s USB connector (Type-C).
•
O
Be sure the connectors are fully inserted.
•
Charge Status
Indicator lamp
Battery status
The indicator lamp shows battery charge status as follows:
Indicator lamp
Battery status
On Battery charging Off Charging complete
Blinks Charging error
Charging the Battery
2
First Steps
43
First Steps
The supplied AC power adapter is compatible with power supplies of
•
O
100 to 240 V (a plug adapter may be needed for overseas use). Do not use the AC power adapter or USB cable with other devices, as
•
this could cause malfunction. Do not a x labels or other objects to the battery. Failure to observe
•
this precaution could make it impossible to remove the battery from the camera. Do not short the battery terminals. The battery could overheat.
•
Read the cautions in “The Battery and Power Supply”.
•
Use only genuine Fuji lm rechargeable batteries designated for use
2
•
in this camera. Failure to observe this precaution could result in prod­uct malfunction. Do not remove the labels from the battery or attempt to split or peel
•
the outer casing. The battery gradually loses its charge when not in use. Charge the
•
battery one or two days before use. If the battery fails to hold a charge, it has reached the end of its
•
charging life and must be replaced. Unplug the AC power adapter from the power outlet when it is not
•
in use. If the battery is left for long periods without charging, you may  nd
•
that its quality degrades or that it no longer holds a charge. Charge the battery regularly. Remove dirt from the battery terminals with a clean, dry cloth. Failure
•
to observe this precaution could prevent the battery from charging. Note that charging times increase at low or high temperatures.
•
Selecting ON for Bluetooth/SMARTPHONE SETTING> Bluetooth
•
ON/OFF in the network/USB settings menu increases the drain on the battery.
If the camera is turned on during charging,
•
N
charging will end and the USB connection will instead be used to power the camera. The battery level will begin to gradually decline (P 270). The camera will display a “power supply” icon when powered via USB.
•
44
Charging the Battery
Charging via Computer
The camera can be charged via USB. USB charging is available with com­puters with a manufacturer-approved operating system and USB interface.
Leave the computer on during charging.
The battery will not charge while the camera is on.
•
O
Connect the supplied USB cable.
•
Connect the camera directly to the computer; do not use a USB hub
•
or keyboard. Charging stops if the computer enters sleep mode. To resume
•
charging, activate the computer and disconnect and reconnect the USB cable. Charging may not be supported depending on the model of com-
•
puter, computer settings, and the computer’s current state. The battery takes about 600 minutes to charge with a charging input
•
of 5 V/500 mA.
2
First Steps
45
Turning the Camera On and O
Use the ON/OFF switch to turn the camera on and o .
Slide the switch to ON to turn the camera on, or to OFF to turn the camera o .
First Steps
2
Fingerprints and other marks on the lens or view nder can a ect pic-
O
tures or the view through the view nder. Keep the lens and view nder clean.
Pressing the a button during shooting starts playback.
•
N
Press the shutter button halfway to return to shooting mode.
•
The camera will turn o automatically if no operations are performed
•
for the length of time selected for D POWER MANAGEMENT> AUTO POWER OFF. To reactivate the camera after it has turned o automatically, press the shutter button halfway or turn the ON/OFF switch to OFF and then back to ON.
46

Checking the Battery Level

Indicator
Description
After turning the camera on, check the battery level in the display.
Battery level is shown as follows:
Indicator
e f g h i i
(red)
j
(blinks red)
Battery partially discharged. Battery about 80% full. Battery about 60% full. Battery about 40% full. Battery about 20% full.
Low battery. Charge as soon as possible.
Battery exhausted. Turn camera off and recharge battery.
Description
2
First Steps
47
First Steps

Basic Setup

When you turn the camera on for the  rst time, you can choose a language and set the camera clock. Follow the steps below when turning the camera on for the  rst time.
Turn the camera on.
1
A language-selection dialog will be displayed.
2
Choose a language.
2
Highlight a language and press MENU/OK.
Choose a time zone.
3
When prompted, choose a time zone and turn daylight savings time on or o using the selector, then highlight SET and press MENU/OK.
AREA SETTING
BERLIN/PARIS
AREA SETTING
DAYLIGHT SAVINGS
SET
GMT ±0:00
OFF
NO
48
To skip this step, press DISP/BACK.
N
Basic Setup
Set the clock.
4
View information on the smartphone app.
5
The camera will display a QR code
•
you can scan with your smartphone to open a website where you can download the smartphone app. Press MENU/OK to exit to the shoot-
•
DATE/TIME
GMT +1:00
BERLIN/PARIS
..
2022 31 12 12hAM12 00
SET
APPLICATION
IMAGES CAN BE EASILY TRANSFERRED TO THE SMARTPHONE.
SCAN QR CODE TO ACQUIRE THE APP.
ing display.
Use the smartphone app to download pictures from the camera
N
or control the camera remotely (P 249).
Format the memory card (P 272).
6
Format memory cards before  rst use, and be sure to reformat all
O
memory cards after using them in a computer or other device.
If the battery is removed for an extended period, the camera clock will
N
be reset and the language-selection dialog will be displayed when the camera is turned on.
NO
2
First Steps
SET
49
Choosing a Di erent Language
To change the language:
Display language options.
1
Select D USER SETTING> Qa.
Choose a language.
2
Highlight the desired option and press MENU/OK.

Changing the Time and Date

2
To set the camera clock:
First Steps
Display DATE/TIME options.
1
Select D USER SETTING> DATE/TIME.
Set the clock.
2
Press the selector left or right to highlight the year, month, day, hour, or minute and press up or down to change. Press MENU/OK to set the clock.
Basic Setup
50
Basic Photography and
Playback
51
3
Basic Photography and Playback

Taking Photographs (Mode P)

This section describes how to take pictures using program AE (mode P). See pages 72–81 for information on S, A, and M modes.
Rotate the STILL/MOVIE mode dial to
1
STILL.
Slide the lens aperture mode switch
2
to A.
Rotate the shutter speed dial to A.
3
To use the shutter speed dial, press the
O
dial lock release and rotate the dial to the desired setting.
P will appear in the display.
52
Rotate the drive dial to S.
4
Rotate the sensitivity dial to A.
5
Rotate the focus mode selector to S.
6
Taking Photographs (Mode P)
3
Basic Photography and Playback
53
3
Basic Photography and Playback
Ready the camera.
7
Hold the camera steady with both
•
hands and brace your elbows against your sides. Shaking or un­steady hands can blur your shots.
To prevent pictures that are out of
•
focus or too dark (underexposed), keep your  ngers and other objects away from the lens and AF-assist illuminator.
Frame the picture.
8
Lenses with Zoom Rings
Use the zoom ring to frame the picture in the display. Rotate the ring left to zoom out, right to zoom in.
A
54
Taking Photographs (Mode P)
Focus.
9
Press the shutter button halfway to
set focus and exposure.
Focus indicator
Focus frame
If the camera is able to focus, the focus frame and focus indicator
•
will glow green. If the camera is unable to focus, the focus frame will turn red, s
•
will be displayed, and the focus indicator will blink white.
If the subject is poorly lit, the AF-assist illuminator may light to
•
N
assist the focus operation. Focus and exposure will lock when the shutter button is
•
pressed halfway. Focus and exposure remain locked while the button is kept in this position (AF/AE lock). The camera will focus on subjects at any distance in the macro
•
and standard focus ranges for the lens.
Shoot.
10
Smoothly press the shutter button the rest of the way down
to take the picture.
3
Basic Photography and Playback
55

Viewing Pictures

Pictures can be viewed in the view nder or LCD monitor.
To view pictures full frame, press a.
100-0001
Additional pictures can be viewed by pressing the selector left
3
or right or rotating the front command dial. Press the selector or
Basic Photography and Playback
rotate the dial right to view pictures in the order recorded, left to view pictures in reverse order. Keep the selector pressed to scroll rapidly to the desired frame.
Pictures taken using other cameras are marked with a m (“gift image”)
N
icon to warn that they may not display correctly and that playback zoom may not be available.
Two Memory Cards
If two memory cards are inserted, you can press and hold the a button to choose a card for playback. You can also select a card using the C PLAY BACK MENU> SWITCH SLOT option.
56
Viewing Pictures

HDMI Output

Camera shooting and playback displays can be output to HDMI devices.
Connecting to HDMI Devices
Connect the camera to TVs or other HDMI devices using a third-party HDMI cable.
Turn the camera o .
1
Connect the cable as shown below.
2
Insert into HDMI connector
Insert into HDMI Micro connector (Type D)
Con gure the device for HDMI input as described in the doc-
3
umentation supplied with the device.
Turn the camera on. The contents of the camera display will
4
be shown on the HDMI device. The camera display turns o
in playback mode (P 58).
Making sure the connectors are fully inserted.
•
O
Use an HDMI cable no more than 1.5m (4.9ft.) long.
•
3
Basic Photography and Playback
57
Viewing Pictures
Shooting
Display live view or movie footage on a TV or save it to an exter­nal recorder that supports HDMI input.
Playback
To start playback, press the camera a button. The camera mon­itor turns o and pictures and movies are output to the HDMI device. Note that the camera volume controls have no e ect on sounds played on the TV; use the television volume controls to adjust the volume.
Some televisions may brie y display a black screen when movie play-
N
3
Basic Photography and Playback
back begins.
58

Deleting Pictures

Use the b button to delete pictures.
Deleted pictures cannot be recovered. Protect important pictures or
O
copy them to a computer or other storage device before proceeding.
With a picture displayed full frame, press the b button and
1
select FRAME.
ERASE
FRAME
SELECTED FRAMES
ALL FRAMES
Press the selector left or right to scroll through pictures and
2
press MENU/OK to delete (a con rmation dialog is not dis-
played). Repeat to delete additional pictures.
Protected pictures cannot be deleted. Remove protection from any
•
N
pictures you wish to delete (P 234). Pictures can also be deleted from the menus using the C PLAY BACK
•
MENU> ERASE option (P 230).
3
Basic Photography and Playback
59
MEMO
60
Movie Recording and
Playback
61

Recording Movies

Record movies with sound.

Recording Movies

Movies can be recorded by pressing the shutter button when the STILL/MOVIE mode dial is rotated to MOVIE or by pressing a function button to which MOVIE RECORDING RELEASE is assigned.
The STILL/MOVIE Mode Dial (MOVIE)
For access to a full range of camera settings when  lming movies, rotate the STILL/MOVIE mode dial to MOVIE and record movies by pressing the shutter button.
Rotate the STILL/MOVIE mode dial to
1
4
Movie Recording and Playback
MOVIE.
Slide the lens aperture mode switch
2
to A.
62
Rotate the shutter speed dial to A.
3
AUTO will appear in the display.
Rotate the sensitivity dial to A.
4
Rotate the focus mode selector to C.
5
Recording Movies
4
Movie Recording and Playback
To use the shutter speed and sensitivity dials, press the dial lock
O
release and rotate the dial to the desired setting.
These settings can also be adjusted using touch controls (P 28).
N
63
4
Movie Recording and Playback
Press the shutter button all the way
6
down. Recording will start.
A recording indicator (V) is dis-
•
played while recording is in prog­ress. The borders of the display turn
•
red during movie recording, green during high-speed recording. The time remaining is shown by a countdown display, while
•
another display counts up to show the recording time.
Press the button again to end recording. Recording ends
7
automatically when the maximum length is reached or the memory card is full.
Recording time
Time remaining
64
Recording Movies
Using a Function Button (MOVIE RECORDING RELEASE)
Use the function button to which MOVIE RECORDING RELEASE is assigned to quickly and easily record movies while in still pho­tography mode.
The camera automatically selects focus mode C (AF-C); exposure is
N
adjusted automatically.
Assign MOVIE RECORDING RELEASE to a function button
1
(P 321).
Press the selected button to start re-
2
cording.
A recording indicator (V) is dis-
•
played while recording is in prog­ress. The borders of the display turn
•
red during movie recording, green during high-speed recording.
The time remaining is shown by a countdown display, while
•
another display counts up to show the recording time.
Press the button again to end recording. Recording ends
3
automatically when the maximum length is reached or the
memory card is full.
Recording time
Time remaining
4
Movie Recording and Playback
65
4
Movie Recording and Playback
Sound is recorded via the built-in microphone or an optional external
•
O
microphone. Do not cover the microphone during recording. Note that the microphone may pick up lens noise and other sounds
•
made by the camera during recording. Vertical or horizontal streaks may appear in movies containing very
•
bright subjects. This is normal and does not indicate a malfunction.
To monitor audio with headphones during recording, you will need
•
N
to convert the USB connector to an audio jack using the supplied headphone adapter. The indicator lamp lights while recording is in progress (the B MOVIE
•
SETTING> TALLY LIGHT option can be used to choose the lamp— indicator or AF-assist—that lights during movie recording and whether the lamp blinks or remains steady). During recording, you can change exposure compensation by up to ±2EV and adjust zoom using the zoom ring on the lens (if available). To prevent the borders of the display changing color during mov-
•
ie recording, select OFF for B MOVIE SETTING> F REC FRAME INDICATOR. While recording is in progress, you can:
•
Adjust sensitivity
-
Refocus using any of the following methods:
-
Press the shutter button halfway
•
Press a function button to which AF-ON is assigned
•
Use touch screen controls
•
Display a histogram or arti cial horizon by pressing the button to
-
which HISTOGRAM or ELECTRONIC LEVEL SWITCH has been as­signed
Recording may be unavailable at some settings, while in other cases
•
settings may not apply during recording. To choose the focus area for movie recording, select G AF/MF
•
SETTING> FOCUS AREA and use the focus stick (focus lever) and rear command dial (P 87).
66
Recording Movies
Temperature Warnings
The camera automatically turns o to protect itself when its temperature or the temperature of the battery rises. If a temperature warning is displayed, image noise may increase. Turn the camera o and wait for it to cool before turning it on again.
Using an External Microphone
Sound can be recorded with external micro­phones that connect using jacks 3.5 mm in diameter; microphones that require plug-in power cannot be used. See the microphone manual for details.
XLR Microphone Adapters
The camera can be used with TEAC TASCAM CA-XLR2d-F XLR microphone adapters. For more information, visit the TASCAM website.
https://tascam.jp/int/product/ca-xlr2d/#CA-XLR2d_Website
4
Movie Recording and Playback
67
Recording Movies

Adjusting Movie Settings

Movie settings can be adjusted from the movie menus or using the B MOVIE SETTING item in the photo menus (P 24).
Use the B MOVIE SETTING item in the photo menus to quickly
•
adjust settings when recording movies via a button to which MOVIE RECORDING RELEASE has been assigned (P 183). The movie menus contain options for use when recording mov-
•
ies via the shutter button with the STILL/MOVIE mode dial rotated to MOVIE (P 187). Settings such as frame rate and frame size can be adjusted us-
•
ing MOVIE MODE. Use MEDIA REC SETTING for such tasks as choosing the  le
•
type, bit rate, and the destination card slot. Focus mode is selected using the focus mode selector. Regard-
•
4
less of the option selected, the camera will automatically switch
Movie Recording and Playback
to C when FACE DETECTION ON or SUBJECT DETECTION ON is chosen for G AF/MF SETTING> g FACE/EYE DETECTION SETTING or SUBJECT DETECTION SETTING. Note, howev­er, that choosing M when FACE DETECTION ON or SUBJECT DETECTION ON is selected disables face and subject detection.
Changes made using the B MOVIE SETTING item in the photo
•
O
menus also apply to the movie menus. Changes made in one set of menus automatically apply in the other. The type of memory card supported varies with the option select for
•
B MOVIE SETTING> MEDIA REC SETTING.
Movies with a bit rate of 360Mbps can be recorded to cards with a
-
Video Speed Class of V60 or better. Movies with a bit rate of 100 or 200Mbps can be recorded to cards
-
with a UHS Speed Class of 3 or better.
Depth of Field
To soften backgrounds, set aperture as wide as possible. Aperture can be adjusted manually at settings other than A.
68

Viewing Movies

Selector
Full-frame playback
Playback in
progress (
Playback
paused (
View movies on the camera.
In full-frame playback, movies are identi­ ed by a W icon. Press the selector down to start movie playback.
AUDIO SET.PLAY
The following operations can be per­formed while a movie is displayed:
Playback in
Selector
Up
Down Start playback Pause playback Start/resume playback
Left/right
Full-frame playback
View photo information
View other pictures
progress (xx))
Adjust speed
End playback
Progress is shown in the display during playback.
Do not cover the speaker during playback.
O
Playback
paused (yy))
Single frame rewind/
advance
4
Movie Recording and Playback
29m59s
Press MENU/OK to pause playback and display volume controls. Press
•
N
the selector up or down to adjust the volume; press MENU/OK again to resume playback. Volume can also be adjusted using DSOUND SET-UP> PLAYBACK VOLUME. To listen to audio with headphones, you will need to convert the USB
•
connector to an audio jack using the supplied headphone adapter. To view movies on a television connected via HDMI instead of in the
•
camera monitor, press the a button (P 57).
PAUSESTOP
69
Viewing Movies
Playback Speed
Press the selector left or right to adjust play­back speed during playback. Speed is shown by the number of arrows (M or N).
4
Movie Recording and Playback
29m59s
Arrows
70

Taking Photographs

71

P, S, A, and M Modes

P, S, A, and M modes give you varying degrees of control over shutter speed and aperture.

Mode P: Program AE

Let the camera choose shutter speed and aperture for optimal exposure. Other values that produce the same exposure can be selected with program shift.
Rotate the STILL/MOVIE mode dial to
1
STILL.
Slide the lens aperture mode switch
2
5
Taking Photographs
to A.
Rotate the shutter speed dial to A.
3
P will appear in the display.
72
P, S, A, and M Modes
If the subject is outside the metering range of the camera, the shutter
•
O
speed and aperture displays will show “– – –”. To use the shutter speed dial, press the dial lock release and rotate the
•
dial to the desired setting. If the lens is not equipped with an aperture ring, select AUTO for
•
D BUTTON/DIAL SETTING> APERTURE SETTING.
Program Shift
If desired, you can rotate the rear command dial to select other combinations of shutter speed and aperture without altering exposure (pro­gram shift).
Aperture
Shutter speed
Program shift is not available in any of the following circumstances:
O
When TTL is selected for FFLASH SETTING > FLASH FUNCTION
•
SETTING
When an auto option is selected for H IMAGE QUALITY SETTING>
•
DYNAMIC RANGE
In movie mode
•
To cancel program shift, turn the camera o .
N
5
Taking Photographs
73

Mode S: Shutter-Priority AE

Choose a shutter speed and let the camera adjust aperture for optimal exposure.
Rotate the STILL/MOVIE mode dial to
1
STILL.
Slide the lens aperture mode switch
2
to A.
Rotate the shutter speed dial to se-
3
5
Taking Photographs
lect a shutter speed.
S will appear in the display.
74
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
