Page 1
th
G
eneration
HR
3.1M
Effective
Pixels
22✕
ZOOM
10 ✕ Optical
2.2✕ Digital
New
Page 2
th
G
eneration
HRHR
22✕
ZOOM
10 ✕ Optical
2.2✕ Digital
The FinePix S5000:
Designed for Photographic Performance,
Engineered for
Exceptional Image Quality
The 4th-Generation Super CCD HR
Incorporating the latest 1/2.7-inch 4th-
Generation Super CCD HR, the FinePix
S5000 utilizes 3.1 million effective
pixels for superb quality images of up
to 2816 × 2120 (6.0 million) recording pixels. By
boosting resolution through Fujifilm’s proprietary
advanced miniaturization technology, the 4th-
Generation Super CCD HR excels at reproducing
highly detailed subject information. Together with its
highly optimized image processor, this new photosen-
sor ensures greater sensitivity, higher signal-to-noise
ratio, and superbly true-to-life color reproduction, for
Sample images in this brochure were taken with the FinePix S5000. (Excepting product shots)
images that are simply breathtaking.
Massive 22✕zoom range
(10✕optical, 2.2✕digital)
The FinePix S5000 features a new,
high-performance 10✕ Fujinon zoom
lens covering a remarkable focal length
range of 37 – 370mm (35mm camera
equivalent). Need to zoom in even more? The 2.2✕*
digital zoom boosts total magnification up to 22✕, or
a focal length equivalent of approximately 814mm.
The optional 0.79✕ Wide Conversion lens and 1.5✕
Tele Conversion lens extend your shooting range even
further. And newly designed Fujinon optics minimize
chromatic aberration to assure crisp, clear, sharp
images at all zoom settings.
* 1280 ×960-pixel mode
Page 3
JPEG mode, 2816
×
2120 pixels, 1/100 sec, f/5.6, ISO 200 equivalent
JPEG mode, 2816 ×2120 pixels, 1/13 sec, f/5.6, ISO 200 equivalent
Page 4
Astonishing 22✕ Zooming Performance and SLR-like Came
A Digital Camera That Inspires Photographic Confidence
30 mm (full wide with an optional
✕
wide conversion lens)
0.79
Versatile exposure controls
Scene Position
four special preset program modes: Portrait, Landscape, Sports
and Night Scene. To handle the widest possible variety of light
conditions, the camera also offers three light metering choices:
64-TTL Multi, Spot, and Average.
Accurate, high-speed AF system
The FinePix S5000 employs a state-of-the-art AF system to make
autofocus quicker and more precise than ever. An AF-Assist
Illuminator* ensures accurate focus in low light or night scenes.
And the AF Area Focus system lets you focus on specific areas
within the frame, making composition easier and more flexible.
* Effective at 2m range
Wide range of ISO settings
With the FinePix S5000, you’re free to select an ISO-equivalent
sensitivity of AUTO, 200, 400 or a very high-speed 800*, depending on subject and shooting conditions. The higher ISO settings
excel at fast action and non-flash shooting in low-light conditions,
as well as helping to prevent camera shake.
* When ISO 800 is selected, resolution is automatically set to 1280 x 960 pixels.
37 mm 185 mm 370 mm 555 mm (10
optional 1.5
High-speed continuous shooting
The FinePix S5000 provides a choice of six
exposure modes: Auto mode
ultimate in ease, plus Programmed AE
Aperture-Priority AE
[A] (a range of 13 aperture
[AUTO] for the
[P],
settings, from F2.8 to F8), Shutter-Priority AE
[S] (1/1000 to 2 seconds), Manual [M], and
[SP] mode. The latter gives you instant access to
To capture fast-moving subjects, the FinePix S5000 offers three
high-speed continuous shooting modes: “Top 5-frame”
Continuous Shooting (5 frames/second when shutter button is
pressed), “Final 5-frame” Continuous Shooting (5 frames/second
just before shutter button is released*), and 1280
“Long-period” Continuous Shooting (1.6 frames/second for up to
40 frames).
* While you can shoot up to 40 frames (5 frames/second for 8 seconds) in this continuous
mode, only the five frames just before the shutter button is released are actually
captured.
Manual shooting functions
For total creative freedom, the FinePix S5000 gives you a
wide range of manual controls. They include manual white
balance, exposure compensation (–2 to +2 EV in 1/3-EV increments), ISO sensitivity setting, auto-exposure bracketing,
macro shooting (as close as 10cm), slow-synchro shooting,
and more.
CCD-RAW data recording
In addition to the standard JPEG format, the FinePix S5000 can
save captured images in CCD-RAW file format*. This option is
especially valuable when you want to preserve the uncompressed
image data.
* CCD-RAW files can be converted into TIFF files with the included RAW File Converter LE
software.
✕
optical zoom with an
✕
tele conversion lens)
1221 mm (33
2.2
and an optional 1.5
✕
magnification effect;
✕
digital zoom with 10✕optical zoom
✕
tele conversion lens)
× 960-pixel
JPEG mode, 2816 ×2120 pixels, 1/105 sec, f/4.0, ISO 200 equivalent
SLR-like body design and great opera
Flash
Flash Control Sensor
AF-Assist Illuminator
Self-Timer Lamp
Microphone
Page 5
Photo Mode button
A new Photo Mode button gives you control over all
image quality parameters, including sensitivity (AUTO
or MANUAL: ISO equivalent 200, 400, and 800), and
color (Standard, Chrome, and B&W). The Chrome color setting, for
example, slightly boosts contrast and saturation for a look that
resembles color slide film. When reviewing images, this control can
also be used to set DPOF for printing.
Movie recording function
The FinePix S5000’s movie mode offers about 14.6 minutes* of
continuous video at a full 30 frames/second and including sound.
Captured video images are smooth and highly detailed, and
recorded in the Motion JPEG (AVI) format, so that you can also
enjoy viewing each frame as a high-quality still image.
* When using a 512MB xD-Picture Card™ (DPC-512)
User-friendly 110,000-pixel electronic
viewfinder
Scene Position Monitor Brightness ControllAll Information
The user-friendly, high-resolution 110,000-pixel LCD electronic
viewfinder (EVF) gives you a clear, bright preview of fully 90% of
the frame. It also displays full information for each shot, including
shot number, shutter speed, aperture, and ISO setting. For optimal viewing for any eyesight, the EVF includes a diopter adjustment dial.
Alternatively, you can switch the view to the large LCD display
on the back of the camera. It employs a high-resolution 1.5-inch
LCD monitor for crystal-clear, glare-free images.
JPEG mode, 2816 ×2120 pixels, 1/9 sec, f/2.8, ISO 200 equivalent
Multi-language LCD display
The LCD menu can be displayed in any of six languages: English,
French, German, Spanish, Chinese, or Japanese. In addition to
its multilingual talents, the FinePix S5000 is compatible with both
PAL and NTSC video formats, so your camera is at home anywhere in the world.
xD-Picture Card™ support
The FinePix S5000 is designed around the
xD-Picture Card™ memory standard.
Capacity of up to 512MB lets you record highresolution images without worrying about
memory limitations. With a compatible USB
Actual size
card reader or PC/CompactFlash™ card
adaptor, xD-Picture Cards can be swapped freely among a wide
range of computers and other devices.
Low power consumption for long battery life
Thanks to its power-saving design, the FinePix S5000 is capable of
taking up to 260 shots* on a single set of four AA alkaline batteries.
* With the LCD turned off and using the flash for 50% of shots
EVF/LCD (Viewfinder/Monitor)
Selector Button
Viewfinder (EVF)
Photo Mode Button
Diopter
Adjustment Dial
Slot Cover
LCD Monitor
Indicator Lamp
Exposure
Compensation
BACK Button
Zoom Button
DISP Button MENU/OK Button
Four-Direction Button
The new body styling of FinePix S5000 combines smooth contours and comfortable ergonomics. The intelligent layout of the dial and buttons on top cover of camera makes
operation remarkably simple and straightforward. Even high-end SLR camera enthusiasts will feel that here at last is a digital camera that inspires real photographic confidence.
Focus Mode Selector Button
Focus Mode Selector Lock Switch
Button
Shutter Button
Power Switch
Mode Dial
Continuous
Shooting Button
Lens Adapter
Flash Pop-Up Button
Strap Mount
xD-Picture Card™
Slot/Speaker
A/V Out SocketUSB Socket
Power Input Socket
Page 6
SPECIFICATIONS
G
3.1M
Effective
Pixels
22
ZOO
10 ✕
2.2✕
DIGITAL CAMERA FinePix S5000
Number of effective pixels*
CCD sensor 1/2.7-inch Super CCD HR
Number of recorded pixels
Storage media xD-Picture Card™ (16MB to 512MB)
File format Still image: CCD-RAW/JPEG (Exif Ver. 2.2**)
Modes Still images Movie
Image quality mode displayed
Number of recorded pixels
DPC-16 (16MB) 2 10 19 25 33 Approx. 26 sec.
DPC-32 (32MB) 4 21 40 50 68 Approx. 54 sec.
DPC-64 (64MB) 9 43 81 101 137 Approx. 109 sec.
DPC-128 (128MB) 18 86 162 204 275 Approx. 219 sec.
DPC-256 (256MB) 37 173 325 409 550 Approx. 7.3 min.
DPC-512 (512MB) 75 347 651 818 1,101 Approx. 14.6 min.
Lens Fujinon 10✕ zoom lens, F2.8 – F8 (wide-angle), F3.2 – F9 (telephoto)
Lens focal length Equivalent to 37 – 370mm on a 35mm camera
Focus Autofocus (Single, Continuous), Manual Focus
Focus distance Normal: Wide; 90cm/3.0 ft. to infinity
Shutter speed 2 sec.– 1/2000 sec.
Aperture F2.8 – F8, 10 steps in 1/3EV increments (Manual/Auto)
Sensitivity Auto: Equivalent to ISO 160 – 200 (at flash off)
Exposure control 64-zone TTL metering-multi, spot, average
Exposure modes Programmed AE, Aperture-Priority AE, Shutter-Priority AE, Manual
White balance Automatic
Viewfinder 0.33-inch 110,000 pixel electronic viewfinder, built-in diopter adjustment
LCD monitor 1.5-inch low temperature polysilicon TFT (110,000 pixels)
Flash Auto flash using flash control sensor
Self-timer Approx. 10sec.
Video output NTSC/PAL selectable
Terminal Mini-B for USB ø2.5mm jack for AV output, power input socket
Power source 4 alkaline or Ni-MH batteries or AC power adapter
Dimensions 112.7 (W) × 81.1 (H) × 79.3 (D) mm/4.4(W) × 3.2(H) × 3.1(D) in.
Weight 337g/11.9 oz. (excluding batteries and media)
Camera functions
Digital zoom 2.2✕ (1280 × 960 pixels), 1.8✕ (1600 × 1200 pixels),
Shooting modes Normal:Auto, Scene Position (Portrait, Landscape, Sports, Night Scene)
Color modes STANDARD/CHROME/B&W
Movie recording 320 × 240 pixels (30 frames/sec.)
Voice Memo Up to 30 sec., WAV format
Playback Single frame (with max.18✕ Playback zoom), 9 Multi-frame
3.1 million pixels
(Number of total pixels: 3.14 million pixels)
Still image: 2816 × 2120 (6.0 million)/2048 × 1536/
1600 × 1200/1280 × 960 pixels
Movie: 320 × 240pixels (30 frames/sec.)
With monaural sound
Movie:AVI (Motion JPEG )
Audio: WAV
(Design rule for Camera File system compliant/DPOF-compatible)
CCD-RAW
The number of images and recording time will vary slightly depending on the type of the subject.
AF-Assist Illuminator incorporated
Macro: Wide; Approx. 0.1 m – 2.0 m/0.3 ft. – 6.6 ft.
Manual: Equivalent to ISO 200/400/800 (resolution fixed at 1M for
Manual: Fine, Shade, Fluorescent light (Daylight),
Effective range:Wide angle; Approx. 0.3 m – 6.0 m/1.0 ft. – 19.7 ft.
Flash mode:Auto, Red-eye Reduction, Forced Flash, Suppressed Flash,
1.4✕ (2048 × 1536 pixels )
Continuous: 1. Top-5 ( a t i n t e r vals as short as 0.2 sec .,up to 5 frames )
With monaural sound,AVI format (Motion JPEG)
6M 3M 2M 1M 320
2816 × 2120 2048 × 1536 1600 ×1200 1280 × 960 320 × 240 (30fps)
Telephoto; 2m/6.6 ft. to infinity
Telephoto; 0.9 m – 2.0 m/3.0 ft. – 6.6 ft.
Equivalent to ISO 200 – 400 (at flash on)
shots taken at ISO 800)
Fluorescent light (Warm White), Fluorescent light (Cool White),
Incandescent light
Telephoto; Approx. 0.8 m – 5.5 m/2.6 ft. – 18 ft.
Slow Synchro., Red-eye Reduction + Slow Synchro.
2. Final-5 (at intervals as short as 0.2 sec., up to 5 frames )
3. Long-period (at intervals as short as 0.6 sec. up to
40 frames. Only at 1,280 × 960 pixels)
4. Auto bracketing (automatically shoots 3 continuous frames)
Accessories included 16 MB xD-Picture Card™
* Number of effective pixels: The number of pixels on the image sensor which receive input
** Exif 2.2 is a newly revised digital camera file format that contains
a variety of shooting information for optimal printing.
4 AA alkaline batteries
Shoulder strap
USB cable
AV cable
Adapter ring (AR-FX5)
Lens cap
CD-ROM
• USB driver
• FinePixViewer
• ImageMixer VCD for FinePix
• RAW File Converter LE
light through the optical lens, and which are effectively reflected
in the final output data of the still image.
Windows®XP compatible
Specifications are subject to change without notice.
OPTIONAL ACCESSORIES
xD-Picture Card™
DPC-16 (16MB)
DPC-32 (32MB)
DPC-64 (64MB)
DPC-128 (128MB)
DPC-256 (256MB)
DPC-512 (512MB)
PC Card Adapter
DPC-AD
Image Memory
Card Reader
DPC-R1
(USB)
CompactFlash™
Card Adapter
DPC-CF
AC Power Adapter
AC-5VH/5VHS
Battery Charger
with Battery
BK-NH/BK-NH2
• Charged in approx.
2 hours,
• With Euro type or
UK type plug
Rechargeable
battery
2HR-3UF
• 2 × AA-type Ni-MH
Wide Conversion
Lens
WL-FX9B***
• 0.79✕
• ø55mm thread
• with Adapter Ring****
Tele Conversion
Lens
TL-FX9B***
• 1.50✕
• ø55mm thread
• with Adapter Ring****
Soft Case
SC-FXS5
Microsoft, Windows, and Windows logo are trademarks, or registered trademarks
of Microsoft Corporation in the United States and/or other countries.
Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in
the U.S. and other countries.
All other trademarks are the property of their respective holders.
*** The Wide Conversion and Tele Conversion
lenses are not recommended for flash photography
as they may block the flash.
**** The FinePix S5000 comes with a dedicated
Adapter Ring as an included accessory.
For more information on the full range of Fujifilm digital products, please visit
our Website:
http://home.fujifilm.com
Ref.No. EB-309E(SK·03·07·DT·MW) Printed in Japan © 2003 Fuji Photo Film Co., Ltd.
Loading...
