Frymaster MPH14, BIPH14 User Manual

OPERATOR’S MANUAL

FRYMASTER BIPH14/MPH14 SERIES

ELECTRIC FRYER

This equipment chapter is to be

installed in the Fryer Section of the

Equipment Manual.

MANUFACTURED

P.O. BOX 51000

SHREVEPORT, LOUISIANA 71135-1000

PHONE: [phone]

TOLL FREE: 1-800-551-8633

1-800-24 FRYER

FAX: [phone]

BY

Do Not Store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

FOR YOUR SAFETY

TABLE OF CONTENTS

WARRANTY STATEMENT...................................................................................................Page i

INTRODUCTION...................................................................................................................Page 1-1

INSTALLATION INSTRUCTIONS .......................................................................................Page 2-1

OPERATING INSTRUCTIONS.............................................................................................Page 3-1

OPERATING THE BUILT-IN FILTRATION SYSTEM...........................................................Page 4-1

PREVENTIVE MAINTENANCE............................................................................................Page 5-1

OPERATOR TROUBLESHOOTING.....................................................................................Page 6-1

Frymaster L.L.C., 8700 Line Avenue 71106, 5489 Campus Drive 71129

P.O. Box 51000, Shreveport, Louisiana 71135-1000

PHONE [phone] FAX [phone]

PRINTED IN THE UNITED STATES SERVICE HOTLINE 1-800-24-FRYER FEBRUARY 2005

*8195976*

NOTICE

DANGER

The front ledge of this appliance is not a step! Do not stand on the appliance. Serious

injury can result from slips or contact with the hot oil.

DANGER

Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or

any other appliance.

DANGER

The crumb tray in fryers equipped with a filter system must be emptied into a fireproof

container at the end of frying operations each day. Some food particles can spontaneously
combust if left soaking in certain shortening material.

WARNING

Do not bang fry baskets or other utensils on the fryer’s joiner strip. The strip is present to

seal the joint between the fry vessels. Banging fry baskets on the strip to dislodge
shortening will distort the strip, adversely affecting its fit. It is designed for a tight fit and
should only be removed for cleaning.

DANGER
Single fryers equipped with legs must be stabilized by installing anchor straps. All fryers
equipped with casters must be stabilized by installing restraining chains

WARNING
No structural material on the fryer should be altered or removed to accommodate placement
of the fryer under a hood. Questions? Call the Frymaster Dean Service Hotline at 1-800­551-8633.

DANGER
Adequate means must be provided to limit the movement of this appliance without
depending on or transmitting stress to the electrical conduit. A restraint kit is provided with
the fryer. If the restraint kit is missing contact your local Frymaster Factory Authorized
Service Center (FASC) for part number 826-0900.

DANGER
This fryer has two power cords and prior to movement, testing, maintenance and any repair
on your Frymaster fryer; disconnect BOTH electrical power cords from the electrical power
supply.

NOTICE
All fryers shipped without factory supplied cords and plug assemblies must be hardwired
using flexible conduit to the terminal block located on the rear of the fryer. These fryers
should be wired to NEC specifications. Hardwired units must include installation of restraint
devices.

WARRANTY STATEMENT

Frymaster, L.L.C. makes the following limited warranties to the original purchaser only for this
equipment and replacement parts:

A. WARRANTY PROVISIONS - FRYERS

1. Frymaster L.L.C. warrants all components against defects in material and workmanship for a
period of one year.

2. All parts, with the exception of the frypot, heating elements and fuses, are wa rranted for one
year after installation date of fryer.

3. If any parts, except fuses, become defective during the first year after installation date,
Frymaster will also pay straight-time labor costs to replace the part, plus up to 100 miles/160
km of travel (50 miles/80 km each way).

B. WARRANTY PROVISIONS - FRYPOTS

(Applies to fryers manufactured after December 1, 2003, only.)

If a frypot develops a leak within ten years after installation, Frymaster will, at its option, either
replace the entire battery or replace the frypot, allowing up to the maximum time per the
Frymaster time allowance chart hours of straight-time labor plus up to 100 miles/160 km of
travel (50 miles/80 km each way) to change the frypot.

C. WARRANTY PROVISIONS - HEATING ELEMENTS

1. Frymaster L.L.C. warrants th e heating elements against defective material or workmanshi p
for a period of three years from the original installation date, parts only.

2. This warranty does not cover ancillary components, including the hi-limit, temperature
probe, and contactors.

D. WARRANTY PROVISIONS - COOKING COMPUTER

1. Frymaster L.L.C. warrants the M-2000 Cooking Computer against defective material or
workmanship for a period of one year from the original installation date, parts and labor.
Replacements for defective units during the second and third year are available at a reduced
rate.

2. During this warranty period, Frymaster will, at its option, repair or replace defective cookin g
computer returned with new or factory rebuilt and functionally operative units.

3. For replacement of defective computers under warranty, call your local Frymaster Factory
Authorized Service Center. All computers replaced under the Fr ymaster exchange pro gram
are covered by a one-year (parts only) warranty.

i

E. PARTS RETURN

All defective in-warranty parts must be returned to a Frymaster Authorized Factory Service
Center within 60 days for credit. After 60 days, no credit will be allowed.

F. WARRANTY EXCLUSIONS

This warranty does not cover equipment that has been damaged due to misuse, abuse, alteration,
or accident such as:

• improper or unauthorized repair (including any frypot which is welded in the field);

• failure to follow proper installation instructions and/or scheduled maintenance procedures as

prescribed in your MRC cards. Proof of scheduled maintenance is required to maintain the
warranty;

• improper maintenance;

• damage in shipment;

• abnormal use;

• removal, alteration, or obliteration of either the rating plate or the date code on the heating

elements;

• operating the frypot without shortening or other liquid in the frypot;

• no fryer will be warranted under the seven-year program for which a pro per sta rt-up form h as not

been received.

This warranty also does not cover:

• transportation or travel over 100 miles/160 km (50 miles/80 km each way), or travel over two

hours;

• overtime or holiday charges;

• consequential damages (the cost of repairing or replacing other property which is damaged), loss

of time, profits, use or any other incidental damages of any kind.

There are no implied warranties of merchantability or fitness for any particular use or purpose.

ii

BIPH14 / MPH14 SERIES ELECTRIC FRYER

CHAPTER 1: INTROD UCTION

1.1 General

Read the instructions in this manual thoroughly before attempting to operate this equipment. This
manual covers all configurations of McDonald’s PH14 models. The fryers in this model family have
most parts in common, and when discussed as a group, will be referred to as “PH14” fryers.

Although similar in appearance to the BIH14 McDonald’s electric fryers, the BIPH14 fryers feature
a significantly different built-in filtration system. The new Euro-Look incorporates round ed topcaps
and large round drains, which ensures that fries and other debris will be washed into the filter pan.
Other features, including the deep cold-zones and easy to clean, open frypots remain essentially
unchanged. Other features, including the deep cold-zones and open frypots with tilt-up elements
remain essentially unchanged. The PH14 fryers are controlled with the M2000 computer. Fryers in
this series come in full- or split-vat arrangements, and can be purchased as single units or in batteries
of up to five fryers.

1.2 Safety Information

Before attempting to operate your unit, read the instructions in this manual thoroughly.

Throughout this manual, you will find notations enclosed in double-bordered boxes similar to the
one below.

DANGER
Hot cooking oil causes severe burns. Never attempt to move a fryer containing hot
cooking oil or to transfer hot cooking oil from one container to another.

CAUTION boxes contain information about actions or conditions that may cause or result in a

malfunction of your system.

WARNING boxes contain information about actions or conditions that may cause or result in

damage to your system, and which may cause your system to malfunction.

DANGER boxes contain information about actions or conditions that may cause or result in

injury to personnel, and which may cause damage to your system and/or cause your system to

malfunction.

Fryers in this series are equipped with the following automatic safety features:

1. Two high-temperature detection features shut off power to the elements should the temper ature

controls fail.

2. A safety switch built into the drain valve prevents the elements from heating with the drain valve

even partially open.

1-1

1.3 Computer Information for the M2000 Computers

This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. While this device is a verified Class A device, it has been
shown to meet the Class B limits. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio fr equency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of
the equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.

The user is cautioned that any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.

If necessary, the user should consult the dealer or an experienced radio and television technician for
additional suggestions.

The user may find the following booklet prepared by the Federal Communications Commission
helpful: "How to Identify and Resolve Radio-TV Interference Problems". This booklet is available
from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4.

1.4 European Community (CE) Specific Information

The European Community (CE) has established certain specific standards regarding equipment of
this type. Whenever a difference exists between CE and non-CE standards, the information or
instructions concerned are identified by means of shadowed boxes similar to the one below.

CE Standard

Example of box used to distinguish CE and

Non-CE specific information.

1.5 Installation, Operating, and Service Personnel

Operating information for Frymaster equipment has been prepared for use by qualified and/or
authorized personnel only, as defined in Section 1.7. All installation and service on Frymaster

equipment must be performed by qualified, certified, licensed, and/or authorized installation
or service personnel, as defined in Section 1.7.

1.6 Definitions

QUALIFIED AND/OR AUTHORIZED OPERATING PERSONNEL

Qualified/authorized operating personnel are those who have carefully read the information in this
manual and have familiarized themselves with the equipment functions, or who have had previous
experience with the operation of the equipment covered in this manual.

1-2

QUALIFIED INSTALLATION PERSONNEL

Qualified installation personnel are individuals, firms, corporations, and/or companies which, either
in person or through a representative, a re engaged in and are responsible fo r the installation of gas­fired appliances. Qualified personnel must be experienced in such work, be familiar with all gas
precautions involved, and have complied with all requirements of applicable national and local
codes.

QUALIFIED SERVICE PERSONNEL

Qualified service personnel are those who are familiar with Frymaster equipment and who hav e been
authorized by Frymaster, L.L.C. to perform service on the equipment. All authorized service
personnel are required to be equipped with a complete set of service and parts manuals, and to stock
a minimum amount of parts for Frymaster equipment. A list of Frymaster Factory Authorized
Service Centers (FASC) is included with the fr yer when shipped from the factory. Failure to use

qualified service personnel will void the Frymaster warranty on your equipment

1.7 Shipping Damage Claim Procedure

What to do if your equipment arrives damaged:

Please note that this equipment was carefully inspected and packed by skilled personnel before
leaving the factory. The freight company assumes full responsibility for safe delivery upon
acceptance of the equipment.

1. File Claim for Damages Immediately, regardless of extent of damage.

2. Inspect For and Record All Visible L oss or Damage, and ensure that this information is noted

on the freight bill or express receipt and is signed by the person making the delivery.

3. Concealed Loss or Damage, that was unnoticed until equipment is unpacked should be recorded

and reported to the freight company or carrier immediately upon discovery. A concealed
damage claim must be submitted within 15 days o f date of delivery. Be sure to retain container
for inspection.

Frymaster

DOES NOT ASSUME RESPONSIBILITY FOR DAMAGE OR LOSS

INCURRED IN TRANSIT.

1-3

1.8 Service Information

For non-routine maintenance or repairs, or for service information, contact your local Frymaster
Authorized Service Center (FASC). In order to assist you quickly, the Frymaster Factory
Authorized Service Center (FASC) or Service Department representative requires certain
information about your equipment. Most of this information is printed on a data plate affixed to the
inside of the fryer door. Part numbers are found in the Installation, Operation, Service, and Parts
Manual. Parts orders may be placed directly with your local FASC or distributor. Included with
fryers when shipped from the factory is a list of Frymaster FASCs. If you do not have access to this
list, contact the Frymaster Service Department at 1-800-551-8633 or 1-318-865-1711.

The following information will be needed in order to assist you efficiently:

Model Number_________________________
Serial Number _________________________
Voltage ______________________________
Nature of the Problem ___________________

____________________________________
____________________________________

RETAIN AND STORE THIS MANUAL IN A SAFE PLACE FOR FUT URE USE.

1-4
