FOXCONN Q189082Q User Manual
QBOOK
User’s Manual
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.1 for QBOOK.
Symbol description:
Caution : refers to important information that can help you to use QBOOK bet-
ter, and tells you how to avoid problems.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
CAUTION
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical QBOOK for specic features.
TaBle Of COnTenTs
Chapter 1 Introduction to Your QBOOK
External Appearance ....................................................................2
Setting Up Your Computer ............................................................7
Using the Touchpad .................................................................... 11
Chapter 2 Getting started with Your QBOOK - first Boot ..............13
Chapter 3 Introduction to the QBOOK Windows Desktop
Overview ....................................................................................17
Chinese Input Method ................................................................18
Computer ....................................................................................18
My Documents............................................................................19
DVD Drive ..................................................................................19
Recycling Bin ..............................................................................20
Chapter 4 applications
Internet
Web Browsing ....................................................................................22
Receive/Send E-mail ..........................................................................22
Instant Messaging ..............................................................................23
OfceApplications
FOXOfce Writer ................................................................................24
FOXOfce Calc ..................................................................................24
FOXOfce Impress .............................................................................25
FOXOfce Draw .................................................................................25
FOXOfce Base .................................................................................26
FOXOfce Math ..................................................................................26
Text Editor ..........................................................................................27
education and learning
FreeMind ............................................................................................28
StarDict ...............................................................................................28
Mtpaint................................................................................................29
Multimedia applications
Rhythmbox Music Player....................................................................30
CD Recording .....................................................................................30
Video Player .......................................................................................31
Web Camera ......................................................................................31
gThumb Picture Manager ...................................................................32
Other applications
Smarthelper .......................................................................................33
Package Updater................................................................................33
Sound Settings ...................................................................................34
Date and
Time ....................................................................................34
The QBOOK is a compact and easy to use portable computer. It
is equipped with an intuitive graphical interface and full wireless
connectivity so you can use the QBOOK and access the Internet
at any time and in any place.
This chapter includes the following information:
■ External Appearance
■ Setting Up Your Computer
■ Using the Touchpad
1
2
1-1 external appearance
The QBOOK is a compact and easy to use portable computer. It is equipped with an intuitive graphical
interface and full wireless connectivity so you can use the QBOOK and access the Internet at any
time and in any place. Provided below is an introduction to each product function.
1. Top View
Your QBOOK keyboard may vary depending on the country/region of purchase.
CAUTION
!
1
2
3
4
5
6
7
8
9
1
3
2. Rear View
No. Purpose Description
1 CCD Camera Records videos or take photos
2 Color LCD Display QBOOK's screen
3 Power Button Button for turning the computer's power on/off
4 Keyboard Input device used for controlling the QBOOK's
various functions
5 Touchpad Works the same way as a mouse and is used for
controlling the computer cursor
6 Right Touchpad Button Works the same way as the right mouse button
7 Left Touchpad Button Works the same way as the left mouse button
8 Computer Status Light From left to right:
Power icon
Num Lock icon
Caps Lock icon
Wireless Network icon
9 Microphone QBOOK's built-in microphone
No. Purpose Description
1 Battery Replaceable battery that serves as QBOOK's power supply
1
1
4
3. Bottom View
When the computer is running or charging, heat is produced inside the QBOOK and
transferred to the back of the chassis by the heat dissipation system for cooling. The
transformer may also produce a lot of heat during normal use as well. The QBOOK
and its transformer should therefore not be placed in the lap or on any other body part
for prolonged periods during use. Also avoid placing the QBOOK on a soft surface
(e.g. sofa) as it might block the heat vents and interfere with cooling.
CAUTION
!
No. Purpose Description
1 Battery Lock Slide inwards to lock the battery in place. Slide outwards to
unlock battery.
2 Battery Replaceable battery. Serves as the QBOOK's power
supply
3 Battery Latch Push outwards to release battery for removal
2
3
4
1
1
5
4. left View
1 2 3 4 5
6
No. Purpose Description
1 Vent QBOOK's cooling vent
2 Power Port Connects to the external power supply transformer
3 External Display Port Connects to an externally display
4 USB Port Connects to USB 2.0 device
5 Microphone Connects to external microphone
6 Headphone Connects to external headphone
1 2 3 4 5
6
No. Purpose Description
1 Multi-Function Card Reader Supports MMC/SD/MS memory cards
2 USB Port Connects to USB 2.0 device
3 USB Port Connects to USB 2.0 device
4 Modem Port Connects to telephone line. Used for dial-up
Internet access via modem
5 Network Port Standard RJ-45 network port
6 Anti-Theft Lock Slot Connects to anti-theft lock
5. Right View
1
6
Please carefully read the following information about modem port :
■ Disconnect TNV circuit connector before removing cover or equivalent.
■ To reduce the risk of re, use only No. 26 AWG or larger (e.g., 24 AWG) UL
Listed or CSA Certied Telecommunication Line Cord.
■
Always disconnect all telephone lines from the wall outlet before servicing or
disassembling this equipment.
CAUTION
!
When using your telephone equipment, basic safety precautions should
always be followed to reduce the risk of re, electric shock and injury to
persons, including the following:
■ Do not use this product near water for example, near a bathtub, washbowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool.
■
Avoid using a telephone (other than a cordless type) during an electrical
storm .There mey be a remote risk of electric shock from lightning.
■ Do not use the telephone to report a gas leak in the vicinity of the leak.
■ Use only the power cord and batteries indicated in this manual. Do not
dispose of batteries in a re. They may explode. Check with local codes for
possible special disposal instructions.
CAUTION
!
Please carefully read the following information about battery :
■ Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
■
Use only the power cord and batteries indicated in this manual. Do not
dispose of batteries in a re. They may explode. Check with local codes for
possible special disposal instructions.
CAUTION
!
1
7
1-2 setting Up Your Computer
1. Installing/Removing the Battery
Please install the battery before using the QBOOK and connect the external power supply transformer.
The QBOOK can be powered by the battery or the external transformer. If you are in an ofce
environment, we recommend using the external transformer as much as possible. If you are away
from the ofce and no power socket is available, use the battery instead.
Installing the Battery
Step 1: Turn the QBOOK over and have the back of the battery facing upwards as well. Now push
the end of the battery with the metal contacts into the QBOOK's battery slot evenly and
slowly along the battery rails.
Step 2: Push the end of the QBOOK battery with the metal contacts completely into the battery slot.
When there is a "click", this means the battery latch has engaged and the battery is now
secured to the QBOOK.
Step 3: Push the Battery Lock inwards lightly to lock the battery in place.
1
1
8
2
3
1
2
3
■ Do not remove the battery while the QBOOK is still running. This may damage the
data on the hard disk.
CAUTION
!
Removing the Battery
Step 1: Shut down the QBOOK. Disconnect all cables and devices.
Step 2: Turn the QBOOK over and unlock the battery by pushing the Battery Lock outwards.
Step 3: Push the Battery Latch outwards and hold it in place with your nger. Now use the other
hand to pull the battery out.
