Foxconn nT-A3550 User Manual

nT-A3000 Series Nettop
User’s Manual
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.0 for nT-A3000 Series Nettop.
P/N: 3A223A900-000-G
N
O
I
T
U
A
C
Caution : refers to important information that can help you to use NETTOP
!
better, and tells you how to avoid problems.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could other-
wise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical product for specic features.
Safety Notice :
N
O
I
T
U
A
C
!
Before using this product, please read the below safety notice carefully,
this will help to extend the product’s lifecycle, and work normally.
■ When NETTOP is working, please make sure its ventilation system is
working.
■ The power adapter is dissipating heat during normal use, please be sure
not to cover it and keep it away from your body to prevent discomfort or
injury by heat exposure.
■ Please use the power adapter that comes with the product’s package,
wrong power adapter may damage your device.
■ Make sure all the peripherals are properly connected before using NET-
TOP.
■ This product should only be used in an environment with ambient tem-
peratures between 0◦C and 40◦C.
■ To reduce the risk of re, use only No. 26 AWG or larger UL listed or
CSA certied telecommunication line cord.
■ Always shut down the computer before installing or uninstalling the pe-
ripheral which does not support hot plug.
■ Disconnect all peripherals before servicing or disassembling this equip-
ment.
■ Please do not disassemble this product by yourself, any disassembly
not approved by the original manufacturer may result in malfunction, and
void warranty.
■ Risk of explosion if battery is replaced by an incorrect type, please dis-
pose of used batteries according to the instructions.
TABLE OF CONTENTS
Chapter 1 Introducing the NETTOP
Top ViewView ...................................................................................................2
Front Side ViewView ........................................................................................2
Back Side ViewView ........................................................................................3
Bottom ViewBottom View .............................................................................................3
Chapter 2 Placing and connecting the NETTOP
Placement of NETTOP
On the Desk .........................................................................................5
On the Display Back .............................................................................5
Connection of NETTOP
Connect the MonitorMonitor .............................................................................7
Connect the USB DevicesConnect the USB DevicesUSB Devices ....................................................................7
Connect the Network CableConnect the Network CableNetwork Cable .................................................................8
Connect the Power CordConnect the Power CordPower Cord ......................................................................8
Chapter 3 BIOS Setup
Enter BIOS Setup ...................................................................................10
Main .......................................................................................................11
Advanced ...............................................................................................13
Boot ........................................................................................................15
Security ..................................................................................................17
Save & Exit .............................................................................................18
Chapter 4 Install Windows 7 in NETTOP
Install Windows 7 ...................................................................................21
Install Drivers in Windows 7 ...................................................................25
Accessory List
Thanks for choosing our products. Please check the accessories listed below. If there is anything broken or lost, please contact with your distributors as soon as possible.
DVI to VGA Adapter Power Adapter Power Cord
magnet rubber foot Vesa mount Seatbase
Opening Tool Mini PCIe Half Card Support Screw Cover
8.00mm
9.70mm
Screw for VESA Mounting
(M8.0X9.7mm)(4X)
4.40mm
4.85mm
Screw for Half MiniPCI Half
Card Support Bracket
(M:4.4X4.85mm)(1X)
3.90mm
4.70mm
2.85mm
Screw for HDD Support Bracket
(M:4.7X2.85mm)(4X)
2.43mm
2.92mm
4.40mm
Screw for Half MiniPCI Card
2.42mm
2.85mm
(M:4.4X2.85mm)(1X)
This chapter introduces NETTOP’s outlook :
■ Top View
Front Side View
Back Side View
Bottom View

1-1 Top View

1
135mm
No. Name Description
1 Kensington Lock Attach a Kensington security system or a compatible lock to
secure your Nettop
190mm

1-2 Front Side View

24mm
1
2
1
No. Name Description
1 Headphone Port Connects to a headphone
2
Microphone In and S/PDIF In
Port
3 Multi-Function Card Reader Support SD/SDHC/MS/MS Pro/MMC memory cards
4 USB 3.0 Ports Connect to USB devices
5 Suspend Button Enter suspend mode in operating system
6 Power Button with
Integrated LED Indicator
3 64 5
Connects to a microphone or playback devices with
optical connectors(3.5mm jack)
Caution:Before using it, you need to install the “AS-
Media USB3.0 driver” in the Driver CD.
Turning the power on/off, Indicates system statesIndicates system states
2

1-3 Back Side View

1
No. Name Description
1 USB 2.0 Ports Connects to USB devices
2 Display Output Port Connects to display device
3 HDMI Port Connects to HDMI audio and video
4 Network Port Standard RJ-45 network port
5
Line Out and S/PDIF Out Port
Connects to powered analog speakers or record-
ing devices with optical connectors(3.5mm jack)
6 Power Input Port Connects to the power adapter
3 652

1-4 Bottom View

1
4
1
No. Name Description
1 Sheet Metal NETDVD(optional accessary) or Magnet-Metal-Feet can mag-
N
O
I
T
U
A
!
C
There are four Magnet-Metal-Feet in the package. Just align them to the sheet metal
on the bottom, then they can magnetize the NETTOP easily. The feet can seat and
protect NETTOP when it is placed on the tabletop.
netize them to seat rmly
3
In this chapter, the placement and the connection of some neces-
sary peripherals will be introduced.
This chapter includes the following information:
■ Placement of NETTOP
Connection of NETTOP
2-1 Placement of NETTOP

1. On the Desk

1.1.You can install your NETTOP in the mount like the right image.
1.2. If there is enough space on your desk, you can simply put your NETTOP on the tabletop as shown below.

2. On the Display Back

This is the best space-saving way.
2.1. Use four screws to fasten the bracket onto the display back.
2
N
O
I
T
U
A
!
C
To install this bracket, your display must follow VESA75/VESA100 standard. The two
groups of holes on your dispaly have different space between, and they help you
easily fasten the bracket onto your display.
5
2.2. Fit the NETTOP into the bracket with power button locating at the top for easy touch.
2
2
1
N
O
I
T
U
A
!
C
Lift up the NETTOP straightly to take it out.
6
2-2 Connection of NETTOP

1. Connect the Monitor

Connect a monitor to the NETTOP through DVI connector.

2. Connect the USB Devices

Connect USB devices to the USB ports of the NETTOP, for example, mouse and keyboard.
2

3. Connect the Network Cable

Connect LAN cable to the RJ-45 port, with the other end connected to a hub or switch.
Hub
or
Switch
7

4. Connect the Power Cord

Connect the power adapter to the power input port of the NETTOP, and push the power but ton to start it.
2
Outlet
N
O
I
T
U
A
!
C
1
3
2
The power adapter is dissipating heat during normal use, please make sure not to
cover it and keep it away from your body to prevent discomfort or injury from heat
exposure.
8
This chapter tells how to change system settings through the
BIOS Setup menus. Detailed descriptions of the BIOS parameters
are also provided.
You have to run the Setup Program when the following cases
occur :
1. An error message appears on the screen during the system
Power On Self Test (POST) process.
2. You want to change the default CMOS settings.
This chapter includes the following information:
■ Enter BIOS Setup
■ Main
■ Advanced
■ Boot
■ Security
■ Save & Exit
Since BIOS could be updated some other times, the BIOS information described
in this manual is for reference only. We do not guarantee the content of this
manual will remain consistent with the newly released BIOS at any given time in
the future. Please visit our website for updated manual if it is available.

Enter BIOS Setup

The BIOS is the communication bridge between hardware and software, correctly setting up the BIOS parameters is critical to maintain optimal system performance. Power on the computer, when the message "Press <DEL> or <F2> to enter setup, Press <F9> to enter boot menu" appears at the bottom of the screen, you can press <DEL> or <F2> key to enter Setup.
N
O
I
T
U
A
C
!
We do not suggest that you change the default values in the BIOS Setup, and we
3
Use the arrow right/left keys to select a specic function and go to the submenu. Each function is explained below:
Main
Advanced
Boot
Security
Save&Exit
shall not be responsible for any damage which resulted from the change you made.
It displays the basic system conguration, such as CPU Name, memory size, system date,
time and so on. They all can be viewed or set up through this menu.
The advanced system features can be set up through this menu.
Boot features can be set up through this menu. You can set the boot device priority and enable "Quiet Boot" feature here.
The Administrator/User password can be set up through this menu to prevent unauthorized use of your computer. If you set a password, the system will ask you to key in correct password before boot or access to Setup.
The optimal performance settings can be loaded through this menu. However, it may offer better performance in some ways (such as less I/O cards, less memory ...etc.), still, it may cause problem if you have more memory or I/O cards installed. It means, if your system loading is heavy, set to optimal default may sometimes come out an unstable system. What
you need now is to adjust BIOS setting one by one, trial and error, to nd out the best setting
for your current system. You also can save or discard the changes and exit BIOS setup here.
10
Main
The BIOS Setup is accessed by pressing the <DEL> or <F2> button after the Power-On Self-Test
(POST) memory test begins and before the operating system boot begins. Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. The Main Menu provides System Overview information and allows you to set the System Time and Date. Use the “←” and “→” cur­sor keys to navigate between menu screens.
Main
Advanced Boot Security Save & Exit
BIOS Information BIOS Vendor American Megatrends
BIOS Build Date 07/21/2011 18:05:46
Embedded Control Version 12.F1.07
System BIOS Version B11F1P03
CPU Information
AMD E-350 Processor
Processor Speed 1600 MHz
Microcode Revision 5000028
MemoryInformationMemory Information
Total Memory 2048 MB (DDR3 1333)
System Date [Thu 07/22/2011]
System Time [18:51:02]
Access Level Administrator
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Set the Date. Use Tab to switch between Data elements
→ ←: Select Screen ↑ ↓: Select Item
Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Information
► BIOS Vendor
This item shows the BIOS vendor information.
► BIOS Build Date
This item shows the BIOS building date and time.
►Embedded Control Version
This item shows the Embedded Control Version.
► System BIOS Version
It displays the current BIOS version. User can check this information and discuss with the eld
service people if a BIOS upgrade is needed.
CPU Information
► AMD E-350 Processor
This item shows the current CPU name. (The CPU name are for reference only, please refer to
the physical nettop for specic features).
► Processor Speed
This item shows the processor speed value.
► Microcode Revision
This item shows the microcode revision number.
3
11
Memory Information
► Total Memory
This item displays the total memory size. The size is depending on how many memory mod-
ules are installed in your system before powering on.
► System Date
<weekday><month><date> <year> format. Day—weekday from Sun. to Sat., this message is automatically displayed by BIOS (Read
Only).
Month—month from 1 to 12. Date—date from 1 to 31. Year—year, set up by users.
3
Use [ENTER], [TAB] to select a eld. Use [+] or [-] to input the value.
► System Time
This item allows you to congure the desired time. Use [ENTER], [TAB] to select a eld. Use [+] or [-] to input the value. The three elds of the setting are <hour> : <minute> : <second> respectively.
► Access Level
It displays your current access level. If you enter system with a user password, it will dispaly “User”. If no password is set or you enter system with administrator password, this item will dispaly “Administrator”.
12

Advanced

Main Advanced Boot Security Save & Exit
Advanced
SATA Mode [AHCI Mode]
Deep Sleep Support [Enabled] USB 2.0 Port S3 Wakeup [Enabled] LAN / USB 3.0 Port S3 Wakeup [Enabled] Launch LAN PXE OpROM [Disabled] Restore on AC Power Loss [Last State] Supporting C6 power Loss [Disabled]
Integrated GPU UMA Frame Buffer [Auto]
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Select the SATA Mode
Option:
(1) IDE Mode
(2) AHCI Mode
→ ←: Select Screen ↑ ↓: Select Item
Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
► SATA Mode
This item is used to set the operating mode of your SATA ports. Setting options: [IDE Mode];
[AHCI Mode].
[IDE Mode] - This congures the SATA ports to support IDE mode.
[AHCI Mode] - The Advanced Host Controller Interface (AHCI) specication describes the reg-
ister level interface for a Host Controller for Serial ATA. The specication includes a description
of the hardware/software interface between system software and the host controller hardware.
AHCI provides more advanced features including SATA features, but some SATA drives may
not support AHCI, unless they are labeled with AHCI support in its specication.
If your motherboard supporting AHCI, and you have a SATA device, which also supports AHCI,
then you can select IDE option to have fair performance (only PATA, SATA level), or you can
select AHCI to get its best performance.
► Deep Sleep Support
This item is used to enable or disable Deep Sleep Support function.When entering deep sleep
mode system(S4/S5) only can wake up from power button.
► USB 2.0 Port S3 Wakeup
This item is used to enable or disable USB 2.0 Port S3 Wakeup Function.
► LAN / USB 3.0 Port S3 Wakeup
This item is used to enable or disable Onboard LAN / USB 3.0 Port S4 Wakeup Function.
► Launch LAN PXE OpROM
This item is used to enable or disable Boot Option ROM for legacy network devices.
► Restore on AC Power Loss
This item is used to set which state the PC will take with when it resumes after an AC power loss.
3
13
► Supporting C6 power Loss
This item is used to enable or disable C6 power state,which is featured in Fusion processors.
► Integrated GPU UMA Frame Buffer
This item is used to set Integrate Graphics UMA Frame Buffer Size.
3
14

Boot

Main Advanced Boot Security Save & Exit
Boot Configuration
Bootup Numlock State [On]
Quiet Boot [Disabled] Fast Boot [Disabled]
Set Boot Priority
1st Boot [USB CD/DVD] 2nd Boot [Hard Disk: WDC WD1...] 3rd Boot [USB KEY] 4th Boot [USB Floppy:Generic...] 5th Boot [USB Hard Disk] 6th Boot [Network] 7th Boot [UEFI] 8th Boot [CD/DVD]
Hard Disk Drive BBS Priorities ▶ USB
Floppy Drive BBS Priorities
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Boot
select the keyboard numlock state
→ ←: Select Screen ↑ ↓: Select Item
Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
► Bootup Numlock State
This item is used to select the keyboard numlock state. The defaulte setting is [On].
► Quiet Boot
This item is used to enable/disable the quiet boot.
[Disabled] : Displays the normal POST messages. [Enabled] : Displays OEM customer logo instead of POST messages.
► Fast Boot
This item is used to enable or disable boot with initialization of a minimal set of devices required
to launch active boot option. This is no effect for BBS boot options.
3
If you connect external devices, the following item will appear:
► 1st/2nd/3rd/4th/5th/6th/7th/8th Boot Option
These items are used to set the system boot order.
► Hard Disk Drive BBS Priorities/ USB Floppy Drive BBS Priorities
Press <Enter> to go to its submenu.
15

Hard Disk Drive BBS Priorities

Boot
Hard Disk Drive BBS Priorities
1st Boot [SATA:WDC Wd1600BE...]
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Boot
3
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
► 1st Boot
This item shows the priority for the boot device.This item shows the priority for the boot device.

USB Floppy Drive BBS Priorities

Boot
USB Floppy Drive BBS Priorities
1st Boot [Generic-Multi-Card...]
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Boot
Set Boot Priority
→ ←: Select Screen ↑ ↓: Select Item
Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit ESC: Exit
Set Boot Priority
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
► 1st Boot
This item shows the priority for the boot device.
16
→ ←: Select Screen ↑ ↓: Select Item
Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit ESC: Exit

Security

Main Advanced Boot Save & Exit
Password Description
If ONLY the Administrator’s password is set,
then this only limits access to Setup and is only asked for when entering Setup.
If ONLY the User’s password is set, then this
is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights.
Administrator Password
User Password
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Security
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
► Administrator Password
This item is used to install or change administrator password. After you input administrator password, it then will ask you to
conrm the password.
► User Password
This item is used to install or change user password.
Set Setup Administrator Password
→ ←: Select Screen ↑ ↓: Select Item
Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit ESC: Exit
3
17

Save & Exit

Main Advanced Boot Security Save & Exit
Save Changes and Exit
Discard Changes and Exit
Save Changes and Reset
Discard Changes and Reset
Save Options Save Changes
Discard Changes
Restore Defaults Save as User Defaults
3
Restore User Defaults
Launch EFI Shell from lesystem device
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Save & Exit
Exit system setup after saving the changes.
→ ←: Select Screen ↑ ↓: Select Item
Enter: Select
+/-: Change Opt. F1: General Help F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit ESC: Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
► Save Changes and Exit
If you select this option and press <Enter>, a message will be displayed in the screen.
Select [Yes] to save your changes and exit, select [No] or <ESC> to return to the main menu.
► Discard Changes and Exit
If you select this option and press <Enter>, a message will be displayed in the screen.
Select [Yes] to exit setup utility without saving your modications, select [No] or <ESC> to
return to the main menu.
► Save Changes and Reset
If you select this option and press <Enter>, a message will be displayed in the screen. Select [Yes] to save your changes and reset computer, select [No] or <ESC> to return to the
main menu.
► Discard Changes and Reset
If you select this option and press <Enter>, a message will be displayed in the screen. Select [Yes] to exit setup utility and reset computer without saving your modications, select [No] or <ESC> to return to the main menu.
Save Options
► Save Changes
If you select this option and press <Enter>, a message will be displayed in the center of the
screen. Select [Yes] to save your changes, select [No] or <ESC> to return to the main menu.
► Discard Changes
If you select this option and press <Enter>, a message will be displayed in the center of the
screen. Select [Yes] to discard your modications, select [No] or <ESC> to return to the main
menu.
► Restore Defaults
Optimal defaults are the best settings of this motherboard.
Always load the Optimal defaults after updating the BIOS or after clearing the CMOS values.
18
Select this option and press Enter, it will pop out a dialogue box to let you load the defaults.
Select <Yes> and then press <Enter> to load the defaults. Select <No> and press <Enter>, it
will not load. By this default, BIOS have set the optimal performance parameters of system to improve the performances of system components. But if the optimal performance parameters to be set cannot be supported by your hardware devices (for example, too many expansion cards were installed), the system might fail to work.
► Save as User Defaults
If you select this option and press <Enter>, a message will be displayed in the screen.
Select [Yes] to save the changes done so far as user defaults, select [No] or <ESC> to return
to the main menu.
► Restore User Default
If you select this option and press <Enter>, a message will be displayed in the screen.
Select [Yes] to restore/load the user defaults to all the setup options, select [No] or <ESC> to
return to the main menu.
►Launch EFI Shell from lesystem device
This item is used to launch EFI shell application (Shellx64. e) from one of the available
lesystem devices.
3
19
This chapter introduces the Windows installation :
■ Install Windows 7
■ Install Drivers in Windows 7
Make sure you have these ready :
1. NETDVD. (It is an optional accessory. If there is no NETDVD in this package, you need other
purchase an external USB DVD-ROM drive.)
2. NETTOP driver CD. (In this package)
3. Windows 7 Install CD. (Other purchase)
Before we continue :
Your NETTOP power is off.
Connect the NETDVD or USB DVD-ROM drive to one USB port of NETTOP and power it on.
4-1 Install Windows 7
1. Push power on button to turn on your computer, then press <Del> key to enter BIOS Setup.
2. Put the Windows 7 Install CD into the NETDVD or USB DVD-ROM drive.
3. Select and go to the “Boot” menu, set the “Boot Option #1” to DVD drive, press <F4> key to
save change and exit BIOS.
4
Main Advanced Boot Security Save & Exit
Boot Configuration Quiet Boot [Disabled]
Fast Boot [Disabled]
Bootup Numlock State [On]
Boot Option Priorities
Boot Option #1 [USB: Optical DVD RW] Boot Option #2 [TEAC DV-W28SS-R W.OA]
Hard Drive BBS Priorities CD/DVD ROM Drive BBS Priorities
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Boot
Version 2.10.1206. Copyright (C) 2010 American Megatrends, Inc.
21
Enables/Disables Quiet Boot option
→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values
F3: Optimized Defaults F4: Save & Exit ESC: Exit
4.
The computer will reboot, and it will start loading the les for installing the Windows 7 Operating
System.
5. After the computer reboots it will start loading the les for installing Windows 7. Click “Next” to
continue and click “Install now” button to start the setup.
6. When the license terms appear choose accept and click “Next” to continue.
7.
It will then ask you to select the installation type. Click “Custom (advanced)” to install a new copy
of Windows.
4
8. The setup will the display the hard disk partitions (160GB, in this example) of your system. If
there were other systems (such as Linux) installed previously, you need select them and click
“Drive options (advanced)” to delete them. When all partitions are clean, setup will display the
biggest size of your hard drive.
22
9. In the hard disk size screen, you can click the “new” button to create partitions as you need. In
this example we are creating a 70GB partition to install Windows. Make your modications
and click “Apply”.
To ensure that all Windows features work correctly, Windows might create additional
partitions for system les. So you will see a 100MB partition reserved by system after you
create a partition. Select the 70GB partition and click “Next” to continue.
4
23
10. The setup program will then start to install Windows 7 on your hard disk. During the installa
tion, your computer will restart several times.
4
11. When the installation is complete, setup will prepare your computer for it’s rst use. You can
then follow the steps to select system settings, create an account, set a password...etc, until
the whole process is complete.
24
4-2 Install Drivers in Windows 7
1. When the Windows 7 is completely installed, you have to install the necessary drivers before
using the NETTOP. Take out the Windows 7 Install CD from the USB DVD-ROM drive, and put
the NETTOP driver CD inside.
2. Waiting for a few seconds, the main menu will be displayed on the screen.
3. Use these options to install all the drivers for your system. You must click "AMD Chipset Driver"
to install it rst. After that, you can click ”One Click Setup” and then choose the items you want
to install, or you can click on each individual driver to install it manually.
4. After all the drivers are installed, you need to restart your NETTOP, then you can start using it.
4
25
Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Warning:
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
▪ Reorient or relocate the receiving antenna.
▪ Increase the separation between the equipment and receiver.
▪ Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
▪ Consult the dealer or an experienced radio/ TV technician for help.
Caution:
Any changes or modications not expressly approved by the grantee of this device could
void the user’s authority to operate the equipment.
RF exposure warning:
This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20
cm from all persons and must not be co-located or operating in conjunction with any other antenna
or transmitter. End-users and installers must be provide with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure compliance.
Warning statement for Europe:
Also, put in the manual which directive to full and also which countries to sell the product.
Example of a text to tell which directive has been fullled:
Hereby, Foxconn, declares that this nT-A3000 series is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.”
Loading...
