Ford B Max 2014 User Manual

FORD B-MAX Owner's Manual

The information contained in this publication was correct at the time of going to print. In the interest of continuous development, we reserve the right to change specifications, design or equipment at any time without notice or obligation. No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted.

Part Number: CG3573en 08/2013 20130903113628

Introduction

About This Manual...........................................5

Symbols Glossary.............................................5

Replacement Parts

Recommendation.........................................7

Mobile Communications

Equipment......................................................8

At a Glance

At a Glance..........................................................9

Child Safety

Installing Child Seats.....................................15

Child Seat Positioning...................................18

Child Safety Locks.........................................20

Safety Belts

Fastening the Safety Belts...........................21

Safety Belt Minder..........................................22

Supplementary Restraints

System

Principle of Operation...................................23

Driver Airbag.....................................................23

Passenger Airbag...........................................24

Side Airbags.....................................................24

Driver Knee Airbag.........................................25

Side Curtain Airbags......................................25

Keys and Remote Controls

General Information on Radio

Frequencies..................................................26

Remote Control..............................................26

Replacing a Lost Key or Remote

Control...........................................................29

MyKey™

Principle of Operation..................................30

Creating a MyKey...........................................30

Programming a MyKey..................................31

Clearing All MyKeys........................................31

Checking MyKey System Status................31

Using MyKey With Remote Start

Systems.........................................................32

MyKey Troubleshooting...............................32

Locks

Locking and Unlocking.................................34

Sliding Door......................................................35

Manual Liftgate...............................................36

Keyless Entry....................................................36

Security

Passive Anti-Theft System.........................39

Anti-Theft Alarm............................................39

Steering Wheel

Adjusting the Steering Wheel....................42

Audio Control...................................................42

Voice Control...................................................43

Cruise Control..................................................43

Wipers and Washers

Windshield Wipers........................................44

Autowipers.......................................................44

Windshield Washers.....................................45

Rear Window Wiper and Washers...........45

Lighting

General Information......................................47

Lighting Control...............................................47

Autolamps........................................................48

Instrument Lighting Dimmer.....................49

Headlamp Exit Delay....................................49

Daytime Running Lamps............................49

Front Fog Lamps............................................49

Rear Fog Lamps.............................................50

Headlamp Leveling.......................................50

Direction Indicators........................................51

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Table of Contents

Interior Lamps..................................................51

Windows and Mirrors

Power Windows..............................................53

Exterior Mirrors................................................54

Interior Mirror...................................................55

Childminder Mirror.........................................56

Global Opening and Closing......................56

Instrument Cluster

Gauges...............................................................58

Warning Lamps and Indicators................58

Audible Warnings and Indicators..............61

Information Displays

General Information......................................63

Clock...................................................................66

Trip Computer.................................................66

Personalized Settings...................................67

Information Messages..................................67

Climate Control

Principle of Operation...................................75

Air Vents.............................................................75

Manual Climate Control..............................76

Automatic Climate Control.........................77

Hints on Controlling the Interior

Climate...........................................................79

Heated Windows and Mirrors....................82

Seats

Sitting in the Correct Position...................83

Head Restraints..............................................83

Manual Seats..................................................85

Rear Seats........................................................86

Heated Seats...................................................87

Front Seat Armrest........................................87

Auxiliary Power Points

Auxiliary Power Points.................................88

Cigar Lighter.....................................................88

Storage Compartments

Cup Holders.....................................................89

Glasses Holder................................................89

Starting and Stopping the

Engine

General Information.....................................90

Ignition Switch................................................90

Keyless Starting.............................................90

Steering Wheel Lock - Vehicles Without:

Keyless Entry and Push Button

Start/Push Button Start..........................92

Steering Wheel Lock - Vehicles With:

Keyless Entry and Push Button

Start/Push Button Start..........................92

Starting a Gasoline Engine.........................93

Starting a Diesel Engine..............................94

Diesel Particulate Filter...............................94

Switching Off the Engine............................95

Unique Driving Character-

istics

Auto-Start-Stop.............................................96

Fuel and Refueling

Safety Precautions........................................98

Fuel Quality - Gasoline................................99

Fuel Quality - Diesel.....................................99

Running Out of Fuel......................................99

Catalytic Converter.....................................100

Refueling...........................................................101

Fuel Consumption.......................................102

Technical Specifications............................103

Transmission

Manual Transmission.................................104

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Table of Contents

Automatic Transmission...........................104

Hill Start Assist..............................................107

Brakes

General Information....................................109

Hints on Driving With Anti-Lock

Brakes...........................................................109

Parking Brake.................................................109

Stability Control

Principle of Operation...................................111

Using Stability Control..................................111

Parking Aids

Principle of Operation..................................112

Parking Aid.......................................................112

Rear View Camera.........................................114

Cruise Control

Principle of Operation..................................117

Using Cruise Control.....................................117

Driving Aids

Active City Stop..............................................119

Load Carrying

General Information.....................................121

Luggage Anchor Points................................121

Rear Under Floor Storage...........................121

Cargo Nets.......................................................122

Luggage Covers.............................................122

Dog Guard........................................................122

Towing

Towing a Trailer.............................................124

Tow Ball............................................................125

Towing Points.................................................127

Towing the Vehicle on Four Wheels -

Vehicles With: Manual

Transmission..............................................128

Towing the Vehicle on Four Wheels -

Vehicles With: Automatic

Transmission..............................................128

Driving Hints

Breaking-In.....................................................130

Cold Weather Precautions........................130

Driving Through Water...............................130

Floor Mats.......................................................130

Roadside Emergencies

Hazard Warning Flashers...........................132

First Aid Kit......................................................132

Warning Triangle...........................................132

Jump-Starting the Vehicle.........................132

Fuses

Fuse Box Locations......................................134

Fuse Specification Chart - Vehicles Built

Up To: 04-01-2013...................................135

Fuse Specification Chart - Vehicles Built

From: 05-01-2013....................................144

Changing a Fuse...........................................150

Maintenance

General Information....................................152

Opening and Closing the Hood...............152

Under Hood Overview - 1.0L

EcoBoost™.................................................154

Under Hood Overview - 1.4L Duratec-16V

(Sigma)/1.6L Duratec-16V Ti-VCT

(Sigma)........................................................155

Under Hood Overview - 1.5L

Duratorq-TDCi/1.6L Duratorq-TDCi

(DV) Diesel.................................................156

Engine Oil Dipstick - 1.0L

EcoBoost™.................................................157

Engine Oil Dipstick - 1.4L Duratec-16V

(Sigma)/1.6L Duratec-16V Ti-VCT

(Sigma)........................................................157

Engine Oil Dipstick - 1.5L

Duratorq-TDCi/1.6L Duratorq-TDCi

(DV) Diesel..................................................157

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Table of Contents

Engine Oil Check...........................................157

Engine Coolant Check................................158

Brake and Clutch Fluid Check..................159

Washer Fluid Check.....................................159

Changing the 12V Battery..........................159

Checking the Wiper Blades......................160

Changing the Wiper Blades.....................160

Adjusting the Headlamps..........................161

Removing a Headlamp................................161

Changing a Bulb............................................162

Bulb Specification Chart...........................168

Technical Specifications...........................169

Vehicle Care

Cleaning the Exterior....................................172

Cleaning the Interior.....................................172

Repairing Minor Paint Damage................173

Cleaning the Alloy Wheels.........................173

Wheels and Tires

General Information....................................174

Temporary Mobility Kit................................174

Tire Care............................................................177

Using Winter Tires.........................................177

Using Snow Chains......................................178

Tire Pressure Monitoring System............178

Changing a Road Wheel............................179

Technical Specifications............................183

Capacities and Specific-

ations

Vehicle Identification Plate......................186

Vehicle Identification Number.................187

Technical Specifications............................187

Audio System

General Information....................................190

Audio unit - Vehicles With:

AM/FM/CD..................................................191

Audio unit - Vehicles With:

AM/FM/CD/Bluetooth...........................196

Audio unit - Vehicles With:

AM/FM/CD/Navigation System........202

Audio unit - Vehicles With: Sony

AM/FM/CD................................................208

Audio unit - Vehicles With: Navigation

System/Sony AM/FM/CD.....................214

Audio System Security...............................219

Digital Audio...................................................219

Compact Disc Player - Vehicles With:

AM/FM/CD..................................................221

Compact Disc Player - Vehicles With:

AM/FM/CD/Bluetooth/Sony

AM/FM/CD.................................................224

Auxiliary Input Jack.....................................228

Audio Troubleshooting..............................229

Navigation

Navigation......................................................230

SYNC™

General Information...................................239

Using Voice Recognition...........................240

Using SYNC™ With Your Phone............243

SYNC™ Applications and Services......253

Using SYNC™ With Your Media

Player...........................................................256

SYNC™ Troubleshooting.........................260

Appendices

Electromagnetic compatibility..............268

End User License Agreement.................269

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Table of Contents

ABOUT THIS MANUAL

Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.

WARNING

Driving while distracted can result in loss of vehicle control, crash and

injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any handheld device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

Note: This manual describes product features and options available throughout the range of available models, sometimes even before they are generally available. It may describe options not fitted to your vehicle.

Note: Some of the illustrations in this manual may be used for different models, so may appear different to you on your vehicle. However, the essential information in the illustrations is always correct.

Note: Always use and operate your vehicle in line with all applicable laws and regulations.

Note: Pass on this manual when selling your vehicle. It is an integral part of the vehicle.

This manual may qualify the location of a component as left-hand side or right-hand side. The side is determined when facing forward in the seat.

Right-hand sideA Left-hand sideB

Protecting the Environment

You must play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim.

SYMBOLS GLOSSARY

These are some of the symbols you may see on your vehicle.

Safety alert

See Owner's Manual

Air conditioning system

Anti-lock braking system

Avoid smoking, flames or sparks

Battery

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Introduction

Battery acid

Brake fluid - non petroleum based

Brake system

Cabin air filter

Check fuel cap

Child safety door lock or unlock

Child seat lower anchor

Child seat tether anchor

Cruise control

Do not open when hot

Engine air filter

Engine coolant

Engine coolant temperature

Engine oil

Explosive gas

Fan warning

Fasten safety belt

Front airbag

Front fog lamps

Fuel pump reset

Fuse compartment

Hazard warning flashers

Heated rear window

Heated windshield

Interior luggage compartment release

Jack

Keep out of reach of children

Lighting control

Low tire pressure warning

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Introduction

Maintain correct fluid level

Note operating instructions

Panic alarm

Parking aid

Parking brake

Power steering fluid

Power windows front/rear

Power window lockout

Service engine soon

Side airbag

Shield the eyes

Stability control

Windshield wash and wipe

REPLACEMENT PARTS RECOMMENDATION

Your vehicle has been built to the highest standards using quality parts. We recommend that you demand the use of genuine Ford and Motorcraft parts whenever your vehicle requires scheduled maintenance or repair. You can clearly identify genuine Ford and Motorcraft parts by looking for the Ford, FoMoCo or Motorcraft branding on the parts or their packaging.

Scheduled Maintenance and Mechanical Repairs

One of the best ways for you to make sure that your vehicle provides years of service is to have it maintained in line with our recommendations using parts that conform to the specifications detailed in this Owner’s Manual. Genuine Ford and Motorcraft parts meet or exceed these specifications.

Collision Repairs

We hope that you never experience a collision, but accidents do happen. Genuine Ford replacement collision parts meet our stringent requirements for fit, finish, structural integrity, corrosion protection and dent resistance. During vehicle development we validate these parts deliver the intended level of protection as a whole system. A great way to know for sure you are getting this level of protection is to use genuine Ford replacement collision parts.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Introduction

Warranty on Replacement Parts

Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, refer to the terms and conditions of the Ford Warranty.

MOBILE COMMUNICATIONS EQUIPMENT

Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits. Mobile communication equipment includes, but is not limited to, cellular phones, pagers, portable email devices, text messaging devices and portable two-way radios.

WARNING

Driving while distracted can result in loss of vehicle control, crash and

injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Introduction

Front Exterior Overview

See Locking and Unlocking (page 34). See Keyless Entry (page 36).A See Active City Stop (page 119).B See Changing the Wiper Blades (page 160).C See Maintenance (page 152).D See Towing Points (page 127).E See Changing a Bulb (page 162).F Tire pressures. See Technical Specifications (page 183).G See Changing a Road Wheel (page 179).H

9

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

At a Glance

Vehicle Interior Overview

See Transmission (page 104).A See Locking and Unlocking (page 34).B See Power Windows (page 53). See Exterior Mirrors (page 54).C See Head Restraints (page 83).D See Fastening the Safety Belts (page 21).E See Rear Seats (page 86).F See Manual Seats (page 85).G See Parking Brake (page 109).H See Opening and Closing the Hood (page 152).I

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

At a Glance

Instrument Panel Overview

Left-Hand Drive

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

At a Glance

Right-Hand Drive

Air vents. See Air Vents (page 75).A Direction indicators. See Direction Indicators (page 51). High beam. See

Lighting Control (page 47).

Instrument cluster. See Gauges (page 58). See Warning Lamps and Indicators (page 58).

Start button. See Starting and Stopping the Engine (page 90).D Wiper lever. See Wipers and Washers (page 44).E Information and entertainment display. See Information Displays (page 63).F Audio unit. See Audio System (page 190).G Power door lock button. See Locking and Unlocking (page 34).H Hazard warning flasher switch. See Hazard Warning Flashers (page 132).I Climate controls. See Climate Control (page 75).J Heated rear window switch. See Climate Control (page 75).J Heated windshield switch. See Climate Control (page 75).J

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

At a Glance

Parking aid switch. See Parking Aids (page 112).K Start-stop switch. See Auto-Start-Stop (page 96).L Card holder or airbag warning lamp. See Passenger Airbag (page 24).M Ignition switch. See Ignition Switch (page 90).N Cruise control switches. See Using Cruise Control (page 117).O Horn.P Driver knee airbag. See Driver Knee Airbag (page 25).Q Steering wheel adjustment. See Adjusting the Steering Wheel (page 42).R Audio control. See Audio System (page 190). Voice control. See Voice Control

(page 43).

Hood release lever. See Opening and Closing the Hood (page 152).T Lighting control. See Lighting Control (page 47). Front fog lamps. See Front

Fog Lamps (page 49). Rear fog lamp. See Rear Fog Lamps (page 50). Instrument lighting dimmer. See Instrument Lighting Dimmer (page 49).

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

At a Glance

Rear Exterior Overview

See Changing a Bulb (page 162).A See Changing the Wiper Blades (page 160).B See Changing a Bulb (page 162).C See First Aid Kit (page 132). See Warning Triangle (page 132). See Temporary

Mobility Kit (page 174). Spare wheel, jack, and wheel brace. See Changing a Road Wheel (page 179). Towing eye. See Towing Points (page 127).

See Towing Points (page 127).E Tire pressures. See Technical Specifications (page 183).F See Changing a Road Wheel (page 179).G See Refueling (page 101).H

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

At a Glance

INSTALLING CHILD SEATS

WARNINGS

Use an approved child seat to secure children less than 59 inches (150 centimeters) tall in the rear seat.

Extreme Hazard! Do not use a rearward facing child seat on a seat protected by an air bag in front of it!

Read and follow the manufacturer’s instructions when you are installing a child seat.

Do not modify child seats in any way.

Do not hold a child on your lap when your vehicle is moving.

Do not leave unattended children in your vehicle.

WARNINGS

If your vehicle has been involved in a crash, have the child seats checked by an authorized dealer.

Note: Mandatory use of child seats varies from country to country.

Only child seats certified to ECE-R44.03 (or later) have been tested and approved for use in your vehicle. A choice of these are available from an authorized dealer.

Child Seats for Different Mass Groups

Use the correct child seat as follows:

Baby Safety Seat

Secure children that weigh less than 29 pounds (13 kilograms) in a rearward facing baby safety seat (Group 0+) on the rear seat.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Child Safety

Child Safety Seat

Secure children that weigh between 29 and 40 pounds (13 and 18 kilograms) in a child safety seat (Group 1) on the rear seat.

Booster Seats

WARNINGS

Do not install a booster seat or a

booster cushion with only the lap

strap of the safety belt.

Do not install a booster seat or a

booster cushion with a safety belt

that is slack or twisted.

Do not put the safety belt under your

child’s arm or behind their back.

Do not use pillows, books or towels

to boost your child’s height.

Make sure that your children sit in an

upright position.

Note: When using a child seat on a rear seat, make sure that the child seat rests tightly against the vehicle seat. It may be necessary to lift or remove the head restraint. See Head Restraints (page 83).

Booster Seat (Group 2)

Secure children that weigh more than 33 pounds (15 kilograms) but are less than 59 inches (150 centimeters) tall in a booster seat or a booster cushion.

We recommend that you use a booster seat that combines a cushion with a backrest instead of a booster cushion only. The raised seating position will allow you to position the shoulder strap of the adult safety belt over the center of your child’s shoulder and the lap strap tightly across their hips.

Booster Cushion (Group 3)

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Child Safety

ISOFIX Anchor Points

WARNING

Use an anti-rotation device when using the ISOFIX system. We recommend the use of a top tether

or support leg.

Note: When you are purchasing an ISOFIX seat, make sure that you know the correct mass group and ISOFIX size class for the intended seating locations. See Child Seat Positioning (page 18).

Your vehicle has ISOFIX anchor points that accommodate universally approved ISOFIX child seats.

The ISOFIX system comprises two rigid attachment arms on the child seat that attach to anchor points on the outboard rear seats, where the cushion and backrest meet. Tether anchor points are located behind the outboard rear seats for child seats with a top tether.

Top Tether Anchor Points

Attaching a Child Seat with Top Tethers

WARNINGS

Do not attach a tether strap to anything other than the correct tether anchor point.

Make sure that the top tether strap is not slack or twisted and is properly located on the anchor point.

Note: Where applicable, remove the luggage cover to ease installation. See Luggage Covers (page 122).

Note: You may need to raise or remove the head restraint to ease installation. See Head Restraints (page 83).

1. Route the tether strap under the head restraint to the anchor point.

2. Push the child seat back firmly to engage the ISOFIX lower anchor points.

3. Tighten the tether strap in line with the child seat manufacturer's instructions.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Child Safety

CHILD SEAT POSITIONING

WARNINGS

See an authorized dealer for the latest details relating to our recommended child seats.

Extreme Hazard! Do not use a rearward facing child seat on a seat protected by an air bag in front of it!

When using a child seat with a support leg, the support leg must rest securely on the floor.

When using a child seat with a safety belt, make sure that the safety belt is not slack or twisted.

WARNINGS

The child seat must rest tightly against the vehicle seat. It may be necessary to lift or remove the head

restraint. See Head Restraints (page 83).

Note: When using a child seat on a front seat, always adjust the front passenger's seat to its fully rearward position. If it proves difficult to tighten the lap section of the safety belt without slack remaining, adjust the seatback to the fully upright position and raise the height of the seat. See Seats (page 83).

Mass group categories

Seating positions

3210+0

46 - 79 lbs

(22 - 36 kg)

33 - 55 lbs

(15 - 25 kg)

20 - 40 lbs

(9 - 18 kg)

Up to 29

lbs (13 kg)

Up to 22

lbs (10 kg)

UF¹UF¹UF¹XX

Front passenger's seat with airbag ON

U¹U¹U¹U¹U¹

Front passenger's seat with airbag OFF

UUUUURear seats

X Not suitable for children in this mass group. U Suitable for universal category child seats approved for use in this mass group. U¹ Suitable for universal category child seats approved for use in this mass group. However,

we recommend that you secure children in a government approved child seat, on the rear seat.

UF¹ Suitable for universal category forward facing child seats approved for use in this mass group. However, we recommend that you secure children in a government approved child seat, on the rear seat.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Child Safety

ISOFIX Child Seats

Mass group categories

Seating positions

10+

Forward facingRear facing

20 - 40 lbs (9 - 18 kg)Up to 29 lbs (13 kg)

Not ISOFIX equipped

Size classFront seat

Seat type

A, B, B1

C, D, E

Size class

Rear outboard seat ISOFIX

IL, IUF

Seat type

Not ISOFIX equipped

Size classRear center seat

Seat type

IL Suitable for particular ISOFIX child seat systems of the semi-universal category. Please see child seat systems suppliers' vehicle recommendation lists.

IUF Suitable for ISOFIX forward facing child seat systems of universal category approved for use in this mass group and ISOFIX size class.

The ISOFIX size class for both universal and semi-universal child seat systems is defined

by the capital letters A to G. These identification letters are displayed on the ISOFIX child seat.

At time of publishing the recommended Group O+ ISOFIX baby safety seat is the Britax

Romer Baby Safe. See an authorized dealer for the latest details relating to our recommended child seats.

At time of publishing the recommended Group 1 ISOFIX child seat is the Britax Romer

Duo. See an authorized dealer for the latest details relating to our recommended child seats.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Child Safety

CHILD SAFETY LOCKS

WARNING

You cannot open the doors from inside if you have put the child safety locks on.

Left-Hand Side

Turn counterclockwise to lock and clockwise to unlock.

Right-Hand Side

Turn clockwise to lock and counterclockwise to unlock.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Child Safety

FASTENING THE SAFETY BELTS

WARNINGS

Insert the tongue into the buckle until you hear a distinct click. You have not fastened the safety belt correctly

if you do not hear a click.

Make sure that your safety belt is securely stored away and is not outside your vehicle when closing the

door.

Pull the belt out steadily. It may lock if you pull it sharply or if your vehicle is on a slope.

Press the red button on the buckle to release the belt. Let it retract completely and smoothly.

Note: When not in use, place the safety belts in to the slots on the outboard trim.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Safety Belts

Using Safety Belts During Pregnancy

WARNING

Position the safety belt correctly for your safety and that of your unborn child. Do not use only the lap strap

or the shoulder strap.

Pregnant women should always wear their safety belt. The lap belt portion of a combination lap and shoulder belt should be positioned low across the hips below the belly and worn as tight as comfort will allow. The shoulder belt should be positioned to cross the middle of the shoulder and the center of the chest.

SAFETY BELT MINDER

WARNING

The system will only provide protection when you use the safety belt correctly.

The warning lamp illuminates and an audible warning will sound when the following conditions have been met:

• The front safety belts have not been fastened.

• Your vehicle exceeds a relatively low speed.

It will also illuminate when a front safety belt is unfastened when your vehicle is moving.

If you do not fasten your safety belt both the audible and visual warnings will switch off automatically after approximately five minutes.

Turning the Safety Belt Minder Off

See an authorized dealer.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Safety Belts

PRINCIPLE OF OPERATION

WARNINGS

Extreme Hazard! Never use a rearward facing child restraint on a

seat protected by an active airbag in front of it. Death or serious injury to the child can occur.

Do not modify the front of your

vehicle in any way. This could

adversely affect deployment of the airbags. Failure to adhere to this warning could result in serious personal injury or death.

Wear a safety belt and keep

sufficient distance between yourself

and the steering wheel. Only when you use the safety belt correctly, can it hold you in a position that allows the airbag to achieve its optimum effect. See Sitting in the Correct Position (page 83). Failure to adhere to this warning could result in serious personal injury or death.

Repairs to the steering wheel,

steering column, seats, airbags and

safety belts must be carried out by an authorized dealer. Failure to adhere to this warning could result in serious personal injury or death.

Keep the areas in front of the airbags

free from obstruction. Do not affix

anything to or over the airbag covers. In the event of a crash, hard objects could cause serious personal injury or death.

Do not puncture the seat with sharp

objects. This could damage and

adversely affect deployment of the airbags. Failure to adhere to this warning could result in serious personal injury or death.

Use seat covers designed for seats

with side airbags. Have these fitted

by an authorized dealer. Failure to adhere to this warning could result in serious personal injury or death.

Note: You will hear a loud bang and see a cloud of harmless powdery residue if an airbag deploys. This is normal.

Note: Only wipe airbag covers with a damp cloth.

DRIVER AIRBAG

The airbag will deploy during significant frontal collisions or collisions that are up to 30 degrees from the left or the right. The airbag will inflate within a few thousandths of a second and deflate on contact with the occupant, thus cushioning forward body movement. During minor frontal collisions, overturns, rear collisions and side collisions, the airbag will not deploy.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Supplementary Restraints System

PASSENGER AIRBAG

Switching the Passenger Airbag Off

WARNING

You must switch the airbag off when using a rearward facing child seat on the front seat.

Switch offA Switch onB

Turn the switch to position A. When you switch the ignition on, check that

the airbag deactivation warning lamp illuminates.

Switching the Passenger Airbag On

WARNING

You must switch the airbag on when you are not using a child seat on the front seat.

Turn the switch to position B.

SIDE AIRBAGS

WARNING

Use seat covers designed for seats with side airbags. Have these fitted by an authorized dealer.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Supplementary Restraints System

The airbags are located inside the seatback of the front seats. There is a label attached to the side of the seatback to indicate this.

The airbag will deploy during significant lateral collisions. The airbag will not deploy in minor lateral and frontal collisions, rear collisions, or overturns.

DRIVER KNEE AIRBAG

WARNING

Do not attempt to open the airbag

cover.

The airbag will deploy during frontal collisions or collisions that are up to 30 degrees from the left or the right. The airbag will inflate within a few thousandths of a second and deflate on contact with the occupants, thus providing a cushion between the driver’s knees and the steering column. During overturns, rear collisions and side collisions, the knee airbag will not deploy.

For item location: See At a Glance (page

9).

Note: The airbag has a lower deployment threshold than the front airbags. During a minor collision, it is possible that only the knee airbag will deploy.

SIDE CURTAIN AIRBAGS

The airbags are located over the front and rear side windows.

The airbag will deploy during significant lateral collisions. It will also deploy during significant frontal angled collisions. The curtain airbag will not deploy in minor lateral and frontal collisions, rear collisions, or overturns.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Supplementary Restraints System

GENERAL INFORMATION ON RADIO FREQUENCIES

Note: Changes or modifications not

expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

The typical operating range for your transmitter is approximately 33 ft (10 m).

A decrease in operating range could be caused by:

• weather conditions

• nearby radio towers

• structures around your vehicle

• other vehicles parked next to your

vehicle.

The radio frequency used by your remote control can also be used by other short distance radio transmissions (e.g. amateur radios, medical equipment, wireless headphones, remote controls and alarm systems). If the frequencies are jammed, you will not be able to use your remote control. You can lock and unlock the doors with the key.

Note: Make sure your vehicle is locked before leaving it unattended.

Note: If you are in range, the remote control will operate if you press any button unintentionally.

REMOTE CONTROL

You can program a maximum of eight remote controls to your vehicle. This includes any that were supplied with your vehicle. The remote controls must remain inside your vehicle during the programming procedure. Fasten the front safety belts and close all doors to make sure that conflicting chimes do not sound during programming.

Programming a New Remote Control

1. Turn the ignition key from position 0 to position II four times within six seconds.

2. Turn the ignition to position 0. A tone sounds to indicate that it is now possible to program a remote control.

3. Press any button on a new remote control within 10 seconds. A tone will sound as confirmation.

4. Repeat step three within 10 seconds for each new remote control. Do not remove the key from the ignition when pressing the button on the remote control.

5. Switch the ignition back on (position II) or wait for 10 seconds without programming another remote control to end the key programming. Only the remote controls which you have just programmed are now able to lock and unlock your vehicle.

Reprogramming the Unlocking Function

Note: When you press the unlock button

either all the doors are unlocked or only the driver’s door and the liftgate are unlocked. Pressing the unlock button again unlocks all the doors.

Press and hold the unlock and lock buttons on the remote control simultaneously for at least four seconds with the ignition off. The direction indicators will flash twice to confirm the change.

To return to the original unlocking function, repeat the process.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Keys and Remote Controls

Changing the Remote Control Battery

Make sure that you dispose of old batteries in an

environmentally friendly way. Seek advice from your local authority regarding recycling.

Remote Control With a Folding Key Blade

1. Insert a screwdriver as far as possible

into the slot on the side of the remote control, push it toward the key blade and remove the key blade.

2. Twist the screwdriver in the position

shown to start separating the two halves of the remote control.

3. Twist the screwdriver in the position shown to separate the two halves of the remote control.

Note: Do not touch the battery contacts or the printed circuit board with the screwdriver.

4. Carefully remove the battery with the screwdriver.

5. Install a new battery (3V CR 2032) with the + facing downwards.

6. Assemble the two halves of the remote control.

7. Install the key blade.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Keys and Remote Controls

Remote Control Without a Folding Key Blade

1. Press and hold the buttons on the edges to release the cover. Carefully remove the cover.

2. Remove the key blade.

3. Twist the screwdriver in the position shown to start separating the two halves of the remote control.

4. Twist the screwdriver in the position shown to separate the two halves of the remote control.

Note: Do not touch the battery contacts or the printed circuit board with the screwdriver.

5. Carefully remove the battery with the screwdriver.

6. Install a new battery (3V CR 2032) with the + facing downwards.

7. Assemble the two halves of the remote control.

8. Install the key blade.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Keys and Remote Controls

+ 268 hidden pages
