Follett 110FB425ALI, 110FB425WL Specifications

Removable ice machine for easy service

Model configurations

Ice storage
capacity Dispense

90 lb
(40.9 kg)

¹ Ice-only available, add -I
Example: 110FB425A-LI

Ice production

Temperatures
air/water

Air-cooled 425 lb (193.0 kg) 325 lb (147.6 kg)

Water-cooled 486 lb (220.6 kg) 408 lb (185.2 kg)

Energy
consumption
per 100 lb
(45.4 kg) ice

Condenser
water
consumption

Water
consumption

Lever

SensorSAFE

70/50 F (21/10 C) 90/70 F (32/21 C)

N/A 6.0 kWh air-cooled

N/A 0.5 gpm (1.9 Lpm) at

12.0 gal (45.4 L) of potable water per 100 lb
(45.4 kg) of ice

Ice machine
cooling

air
water
air
water

Item number
110FB425A-L¹

110FB425W-L
110FB425A-S¹
110FB425W-S

4.3 kWh water-cooled

70 F (21 C) water

™

Symphony Plus

ice and water dispenser

110 FB series freestanding with Chewblet® ice machine

Features

90 lb (40.9 kg) ice storage capacity
Removable air- or water-cooled ice machine with up to

425lb(193.0kg) daily production of Chewblet ice

- soft, chewable, compressed nugget ice is preferred over cubes1
and is ideal for patient care

™

- Quiet Night

sleep mode turns o ice machine when idle

Designed with sanitation in mind

- automatic self-flushing of ice machine removes impurities

- drain cup provides internal air gap for added protection of
food zone components from drain linecontaminants

- Agion® silver-based antimicrobial provides protection of key ice
and water contact components

2

- one-hand lever or SensorSAFE™ infrared ice dispense

Dependable design, easy to service and clean

- cleaning and sanitizing of entire machine takes only1 hour

- LED control board provides at-a-glance machine status

- panels are easily removed for accessibility to all components

- ice machine parts are common across all
Symphony Plus dispensers

- stainless steel evaporator and auger deliver long life

Environmentally responsible

- meets Consortium for Energy Eciency Tier 2 specifications

- R404a refrigerant has zero ozonedepletion potential

- continuous ice making process uses less electricity and water

Durable, attractive dispenser

- stainless steel cabinet with accent trim

- poly drain pan, grille and dispenser lid are corrosion-resistant

- secured top lid

Easy installation

- comes fully assembled and installs with three easy
connections– electric, water and drain

Warranty

- 3 years parts and labor, 5 years compressorparts

Accessories

Chilled water option (item# 01063205)
Pressurized water sanitizing kits (refer to form# 6830)
SafeCLEAN Plus

1 x 8 oz (237 ml) bottle (item#01147826)
6 x 8 oz (237 ml) bottles(item#01149954)
Carton of 24 x 8 oz (237 ml) bottles (item#01149962)

Nu-Calgon
Additional filters (refer to form#9905 and 8320)
Additional Symphony Plus accessories (refer to price list)

™

ice machine cleaner

®

IMS-III sanitizer, 16 oz (0.5 L) bottle (item# 00979674)

Job

Item

801 Church Lane | Easton, PA 18040, USA

1.800.523.9361 | 1.610.252.7301 | follettice.com

Specification

Ice storage capacity 90 lb (40.9 kg)

W1 Width, top 25.00" (63.5 cm)
W2 Width, bottom 26.25" (66.7 cm)
D1 Depth, top 28.25" (71.8 cm)
D2 Depth, drain pan 7.00" (17.8 cm)
D3 Depth, bottom 29.44" (74.8 cm)
H1 Height 68.12" (173.0 cm)
H2 Dispense height clearance 7.75" (19.68 cm)

Ventilation clearance air-cooled models only –

4.00"(10.16cm)rear

Service clearance 12.00" (30.5 cm) top
C1 115 V/60/1

electrical

C2 Potable water inlet, ice machine
and dispenser

C3 Drain, dispenser 3/4" MPT
Water-cooled ice machine connections

C4 condenser inlet
C5 condenser drain

C6 Ice machine drain 3/4" MPT

Air temperature 50 -100 F (10 - 38 C)
Water temperature 45 - 90 F (7 - 32 C)
Potable water pressure 10 - 70 psi (69 - 483 kpa)
Condenser water pressure 10 - 125 psi (69-861 kpa)
Heat rejection air-cooled models – 5000 BTU/hr

Water flow requirement for
water-cooled models

Approximate net weight 253 lb (115 kg)
Approximate ship weight 290 lb (132 kg)
NOTE: For indoor use only

SHORT FORM SPECIFICATION: (Choose one) ___ Ice and water or ___ ice-only

dispenser to be Follett® automatic load in freestanding configuration, with 90 lb
(40.9 kg) of storage, water station and (choose one) ___ air- or ___water-cooled
ice machine in base. Environmentally responsible R404a ice machine mounted in
base and to be removable as one unit for cleaning and maintenance. Ice machine
to produce approximately 425 lb (193.0 kg) per day of Chewblet compressed
nugget ice at air temp. of 70 F (21 C), water temp. of 50 F (10 C). Ice machine
equipped withautomatic self-flushing and Quiet Night sleep mode. Dispenser to
have automatic bin level control to start and stop ice machine and separate circuitry
to allow dispensing to continue with ice machine removed. Dispenser equipped with

6.00"(15.24cm) adjustable legs, flanged feet and lightweight plastic top that allows
full access to the ice storage area for manual loading of back-up ice. Storage area to
be insulated with CARB compliant non-HFC foam. 7'(2.1m) cord and NEMA 5-15
90º hospital-grade plug provided. NSF and ETLlisted.

11 amps, 0.8 kW
7' (2.1 m) cord, NEMA 5-15 90º
hospital-grade plug

3/8" FPT

3/8" FPT
3/8" FPT

water-cooled models – 1400 BTU/hr
to air, 3600 BTU/hr to water

0.25 gpm (0.95 lpm) at 50 F (10 C)

0.5 gpm (1.90 lpm) at 70 F (21 C)

1.25 gpm (4.73 lpm) at 90 F (32 C)

Dimensional drawing

D1

D2

H1

air

exhaust

D3

access panel

C3

12.28"

(31.2 cm)

4.69"

(11.91 cm)

3.69"

(9.37 cm)

2.69"

(6.83 cm)

4.50"

(11.43 cm)

¹ Independent third party studies. Contact Follett for details.
² Disclaimer: Antimicrobial protection is limited to the treated components and does not treat water or ice.

Agion is a registered trademark of Sciessent LLC.
Calgon is a licensed tradename distributed by Nu-Calgon, in the United States.
SYMPHONY PLUS, SENSORSAFE, SAFECLEAN PLUS and QUIET NIGHT are trademarks of Follett LLC.
CHEWBLET and FOLLETT are registered trademarks of Follett LLC, registered in the US.
Follett reserves the right to change specifications at any time without obligation. Certifications may
vary depending on country of origin.

C5

C2

C4

C6

W1

W2

C1

9.60"

(24.38 cm)

H2

intake

14.06"

(35.7 cm)

12.38"

(31.4 cm)

air

31.50"

(80.0 cm)

33.78"

(85.8 cm)

110 FB series freestanding
