Follett 110CT425WL, 110CT425ALI Specifications

SensorSAFE™ infrared dispense (optional)

SensorSAFE not recommended for use with clear containers or
for applications in direct sunlight

Model configurations

Ice storage
capacity Dispense

90 lb
(40.9 kg)

¹ Ice-only available, add -I
Example: 110CT425A-LI

Ice production

Temperatures
air/water

Air-cooled 425 lb (193.0 kg) 325 lb (147.6 kg)

Water-cooled 486 lb (220.6 kg) 408 lb (185.2 kg)

Energy
consumption
per 100 lb
(45.4 kg) ice

Condenser
water
consumption

Water
consumption

Lever

SensorSAFE

70/50 F (21/10 C) 90/70 F (32/21 C)

N/A 6.0 kWh air-cooled

N/A 0.5 gpm (1.9 Lpm) at

12.0 gal (45.4 L) of potable water per 100 lb
(45.4 kg) of ice

Ice machine
cooling

air
water
air
water

Item number
110CT425A-L¹

110CT425W-L
110CT425A-S¹
110CT425W-S

4.3 kWh water-cooled

70F (21 C) water

™

Symphony Plus

ice and water dispenser

110 CT series countertop with Chewblet® ice machine

Features

90 lb (40.9 kg) ice storage capacity
Removable air- or water-cooled ice machine with up to

425lb(193.0 kg) dailyproduction of Chewblet ice

- soft, chewable, compressed nugget ice is preferred over cubes
and is ideal for patient care

- Quiet Night™ sleep mode turns o ice machine when idle

Designed with sanitation in mind

- automatic self-flushing of ice machine removes impurities

- drain cup provides internal air gap for added protection of
food zone components from drain linecontaminants

- Agion

®

silver-based antimicrobial provides protection of key ice

and water contact components

2

- one-hand lever or SensorSAFE infrared ice dispense

Dependable design, easy to service and clean

- cleaning and sanitizing of entire machine takes only1 hour

- LED control board provides at-a-glance machine status

- panels are easily removed for accessibility to all components

- ice machine parts are common across all
Symphony Plus dispensers

- stainless steel evaporator and auger deliver long life

Environmentally responsible

- meets Consortium for Energy Eciency Tier 2 specifications

- R404a refrigerant has zero ozonedepletion potential

- continuous ice making process uses less electricity and water

Durable, attractive dispenser

- stainless steel cabinet with accent trim

- poly drain pan, grille and dispenser lid are corrosion-resistant

- secured top lid

Easy installation

- comes in two boxes – ice machine and dispenser

Warranty

- 3 years parts and labor, 5 years compressorparts

Accessories

Base stand with or without factory installed filter (refer to form# 7010)
Chilled water option (item# 01063205)
Pressurized water sanitizing kits (refer to form# 6830)
SafeCLEAN Plus

1 x 8 oz (237 ml) bottle (item#01147826)
6 x 8 oz (237 ml) bottles(item#01149954)
Carton of 24 x 8 oz (237 ml) bottles (item#01149962)

Nu-Calgon
Additional filters (refer to form#9905 and 8320)
Additional Symphony Plus accessories (refer to price list)

™

ice machine cleaner

®

IMS-III sanitizer, 16 oz (0.5 L) bottle (item# 00979674)

1

Job

Item

801 Church Lane | Easton, PA 18040, USA

1.800.523.9361 | 1.610.252.7301 | follettice.com

Specification

)

(114.3 cm

air

Ice storage capacity 90 lb (40.9 kg)

W1 Width, dispenser 25.00" (63.5 cm)
W2 Width, base stand accessory 26.25" (66.7 cm)
D1 Depth, entire dispenser 28.75" (73.0 cm)
D2 Depth, drain pan 7.00" (17.78 cm)
D3 Depth, base stand accessory 29.00" (73.7 cm)
H1 Height, dispenser 53.00" (134.6 cm)
H2 Dispense height clearance 7.75" (19.68 cm)
H3 Height, base stand accessory 33.00" (83.8 cm)

Ventilation clearance air-cooled models only –

6.00"(15.24cm)top

Service clearance 12.00" (30.5 cm) top
C1 115 V/60/1

dispenser electrical

Utility connection location internal connection

C2 Potable water inlet, dispenser 3/8" FPT
C3 Drain, dispenser 3/4" MPT
C4 Potable water inlet, ice machine 3/8" FPT internal connection –

Water-cooled ice machine connections

C5 condenser inlet
C6 condenser drain

C7 Drain, ice machine 3/4" MPT

Air temperature 50 -100 F (10 - 38 C)
Water temperature 45 - 90 F (7 - 32 C)
Potable water pressure 10 - 70 psi (69 - 483 kpa)
Condenser water pressure 10 - 125 psi (69 - 861 kpa)
Heat rejection air-cooled models – 5000 BTU/hr

Water flow requirement for
water-cooled models

Approximate net weight 243 lb (110 kg) (two boxes)
Approximate ship weight 290 lb (132 kg) (two boxes)
Approximate ship weight,

base stand accessory
NOTE: For indoor use only

11 amps, 0.8 kW
7' (2.1 m) cord, NEMA 5-15 90º
hospital-grade plug.

1.5"(3.81cm) knockout provided in back
or bottom

3/8" FPT
3/8" FPT

water-cooled models – 1400 BTU/hr
to air, 3600 BTU/hr to water

0.25 gpm (0.95 lpm) at 50 F (10 C)

0.5 gpm (1.90 lpm) at 70 F (21 C)

1.25 gpm (4.73 lpm) at 90 F (32 C)

140 lb (64 kg)

Dimensional drawing

exhaust

D1

H1

D2

H3

D3

8.25" (21.00 cm)

6.06" (15.39 cm)

45.00"
)

42.00"

(106.7 cm)

39.00"

(99.1 cm)

(91.2 cm)

35.90"

W1

air

intake

H2

BS*

W2

C5
C6
C4

C7

C1

access panel

SHORT FORM SPECIFICATION: (Choose one) ___ Ice and water or ___ ice-only

dispenser to be Follett® automatic load in countertop configuration, with 90lb
(40.9 kg) of storage. Environmentally responsible R404a ice machine (choose one)
___ air- or ___ water-cooled and to be removable for cleaning and maintenance.
Ice machine to produce approximately 425 lb (193.0 kg) of Chewblet compressed
nugget ice at air temp. of 70 F (21 C), water temp. of 50 F (10C). Ice machine
equipped with automatic self-flushing and Quiet Night sleep mode. Storage area
to be insulated with CARB compliant non-HFC foam. 7'(2.1m) cord and NEMA
5-15 90º hospital-grade plug provided. NSF and ETLlisted.

110 CT series countertop

6655-201912 | © Follett LLC

801 Church Lane | Easton, PA 18040, USA

1.800.523.9361 | 1.610.252.7301 | follettice.com

C3

C2

1.34" (3.40 cm)

8.22" (20.88 cm)

12.25" (31.1 cm)

BS*– Base stand sold separately; measurements shown are with base
stand legs at lowest position.
See dispenser detail sheet, form# 6675, for counter cut outs.

¹ Independent third party studies. Contact Follett for details.
² Disclaimer: Antimicrobial protection is limited to the treated components and does not treat water or ice.

Agion is a registered trademark of Sciessent LLC.
Calgon is a licensed tradename distributed by Nu-Calgon, in the United States.
SYMPHONY PLUS, SENSORSAFE, SAFECLEAN PLUS and QUIET NIGHT are trademarks of Follett LLC.
CHEWBLET and FOLLETT are registered trademarks of Follett LLC, registered in the US.
Follett reserves the right to change specifications at any time without obligation. Certifications may
vary depending on country of origin.

0.78" (1.98 cm
