Fire-Lite MS-9050UDC, MS-9050UD, MS-9050UDE User Manual

Download

PN: 52413:D ECN 08-287

Addressable Fire Alarm Control Panel

MS-9050UD

MS-9050UDC

MS-9050UDE

IMPORTANT! The SLC Manual Document #51309 must be referenced in addition to this

manual when installing or servicing the Fire Alarm Control Panel.

Document #52413 12/15/08 Revision:

Fire Alarm System Limitations

While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance!

An automatic fire alarm system–typically made up of smoke detectors, heat detectors, manual pull stations, audible warning devices, and a fire alarm control panel with remote notification capability–can provide early warning of a developing fire. Such a system, however, does not assure protection against property damage or loss of life resulting from a fire.

The Manufacturer recommends that smoke and/or heat detectors be located throughout a protected premise following the recommendations of the current edition of the National Fire Protection Association Standard 72 (NFPA 72), manufacturer's recommendations, State and local codes, and the recommendations contained in the Guides for Proper Use of System Smoke Detectors, which are made available at no charge to all installing dealers. These documents can be found at http:/www.systemsensor.com/html/ applicat.html. A study by the Federal Emergency Management Agency (an agency of the United States government) indicated that smoke detectors may not go off in as many as 35% of all fires. While fire alarm systems are designed to provide early warning against fire, they do not guarantee warning or protection against fire. A fire alarm system may not provide timely or adequate warning, or simply may not function, for a variety of reasons:

Smoke detectors may not sense fire where smoke cannot reach the detectors such as in chimneys, in or behind walls, on roofs, or on the other side of closed doors. Smoke detectors also may not sense a fire on another level or floor of a building. A second-floor detector, for example, may not sense a first-floor or basement fire.

Particles of combustion or "smoke" from a developing fire may not reach the sensing chambers of smoke detectors because:

• Barriers such as closed or partially closed doors, walls, or chimneys may inhibit particle or smoke flow.

• Smoke particles may become "cold," stratify, and not reach the ceiling or upper walls where detectors are located.

• Smoke particles may be blown away from detectors by air outlets.

• Smoke particles may be drawn into air returns before reaching the detector.

The amount of "smoke" present may be insufficient to alarm smoke detectors. Smoke detectors are designed to alarm at various levels of smoke density. If such density levels are not created by a developing fire at the location of detectors, the detectors will not go into alarm.

Smoke detectors, even when working properly, have sensing limitations. Detectors that have photoelectronic sensing chambers tend to detect smoldering fires better than flaming fires, which have little visible smoke. Detectors that have ionizing-type sensing chambers tend to detect fast-flaming fires better than smoldering fires. Because fires develop in different ways and are often unpredictable in their growth, neither type of detector is necessarily best and a given type of detector may not provide adequate warning of a fire.

Smoke detectors cannot be expected to provide adequate warning of fires caused by arson, children playing with matches (especially in bedrooms), smoking in bed, and violent explosions (caused by escaping gas, improper stor-

age of flammable materials, etc.). Heat detectors do not sense particles of combustion and

alarm only when heat on their sensors increases at a predetermined rate or reaches a predetermined level. Rate-of-rise heat detectors may be subject to reduced sensitivity over time. For this reason, the rate-of-rise feature of each detector should be tested at least once per year by a qualified fire protection specialist. Heat

detectors are designed to protect property, not life. IMPORTANT! Smoke detectors must be installed in the

same room as the control panel and in rooms used by the system for the connection of alarm transmission wiring, communications, signaling, and/or power. If

detectors are not so located, a developing fire may damage the alarm system, crippling its ability to report a fire.

Audible warning devices such as bells may not alert people if these devices are located on the other side of closed or partly open doors or are located on another floor of a building. Any warning device may fail to alert people with a disability or those who have recently consumed drugs, alcohol or medication. Please note that:

• Strobes can, under certain circumstances, cause seizures in people with conditions such as epilepsy.

• Studies have shown that certain people, even when they hear a fire alarm signal, do not respond or comprehend the meaning of the signal. It is the property owner's responsibility to conduct fire drills and other training exercise to make people aware of fire alarm signals and instruct them on the proper reaction to alarm signals.

• In rare instances, the sounding of a warning device can cause temporary or permanent hearing loss.

A fire alarm system will not operate without any electrical power. If AC power fails, the system will operate from standby batteries only for a specified time and only if the batteries have been properly maintained and replaced regularly.

Equipment used in the system may not be technically compatible with the control. It is essential to use only equipment listed for service with your control panel.

Telephone lines needed to transmit alarm signals from a premise to a central monitoring station may be out of service or temporarily disabled. For added protection against telephone line failure, backup radio transmission systems are recommended.

The most common cause of fire alarm malfunction is inadequate maintenance. To keep the entire fire alarm system in excellent working order, ongoing maintenance is required per the manufacturer's recommendations, and UL and NFPA standards. At a minimum, the requirements of NFPA 72 shall be followed. Environments with large amounts of dust, dirt or high air velocity require more frequent maintenance. A maintenance agreement should be arranged through the local manufacturer's representative. Maintenance should be scheduled monthly or as required by National and/or local fire codes and should be performed by authorized professional fire alarm installers only. Adequate written records of all inspections should be kept.

PrecauLarge.PMD 02/26/2007

Installation Precautions

Adherence to the following will aid in problem-free installation with long-term reliability:

WARNING - Several different sources of power can be connected to the fire alarm control panel. Disconnect all

sources of power before servicing. Control unit and associated equipment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while the unit is energized. Do not attempt to install, service, or operate this unit until this manual is read and understood.

CAUTION - System Reacceptance Test after Software Changes. To ensure proper system operation, this product

must be tested in accordance with NFPA 72 after any programming operation or change in site-specific software. Reacceptance testing is required after any change, addition or deletion of system components, or after any modification, repair or adjustment to system hardware or wiring.

All components, circuits, system operations, or software functions known to be affected by a change must be 100% tested. In addition, to ensure that other operations are not inadvertently affected, at least 10% of initiating devices that are not directly affected by the change, up to a maximum of 50 devices, must also be tested and proper system operation verified.

This system meets NFPA requirements for indoor dry operation at 0-49° C/32-120° F 93 ±2% RH (non-condensing) at 32 ±2° C/90 ±3° F. However, the useful life of the system's standby batteries and the electronic components may be adversely affected by extreme temperature ranges and humidity. Therefore, it is recommended that this system and all peripherals be installed in an environment with a nominal room temperature of 15-27° C/60-80° F.

Verify that wire sizes are adequate for all initiating and indicating device loops. Refer to manual Specifications section for maximum allowable I.R. drop from the specified device voltage.

and at a relative humidity of

Like all solid state electronic devices, this system may operate erratically or can be damaged when subjected to lightning-induced transients. Although no system is completely immune from lightning transients and interferences, proper grounding will reduce susceptibility.

Overhead or outside aerial wiring is not recommended, due to an increased susceptibility to nearby lightning strikes.

Consult with the Technical Services Department if any problems are anticipated or encountered.

Disconnect AC power and batteries prior to removing or inserting circuit boards. Failure to do so can damage circuits.

Remove all electronic assemblies prior to any drilling, filing, reaming, or punching of the enclosure. When possible, make all cable entries from the sides or rear. Before making modifications, verify that they will not interfere with battery, transformer, and printed circuit board location.

Do not tighten screw terminals more than 9 in-lbs. Over-tightening may damage threads, resulting in reduced terminal contact pressure and difficulty with screw terminal removal.

This system contains static-sensitive components.

Always ground yourself with a proper wrist strap before handling any circuits so that static charges are removed from the body. Use static-suppressive packaging to protect electronic assemblies removed from the unit.

Follow the instructions in the installation, operating, and programming manuals. These instructions must be followed to avoid damage to the control panel and associated equipment. FACP operation and reliability depend upon proper installation by authorized personnel.

FCC Warning

WARNING: This equipment generates, uses, and can

radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for class A computing device pursuant to Subpart B of Part 15 of FCC Rules, which is designed to provide reasonable protection against such interference when operated in a commercial environment. Operation of this equipment in a residential area is likely to cause interference, in which case the user will be required to correct the interference at their own expense.

PrecauLarge.PMD 02/26/2007

Canadian Requirements

This digital apparatus does not exceed the Class A limits for radiation noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. This Class A digital apparatus complies with Canadian ICES-003.

Le present appareil numerique n'emet pas de bruits radioelectriques depassant les limites applicables aux appareils numeriques de la classe A prescrites dans le Reglement sur le brouillage radioelectrique edicte par le ministere des Communications du Canada. Cet appareil numerique de la Classe A est conforme a la norme NMB-003 du Canada.

Table of Contents

Product Description ................................................................................................................................................12

Features and Options .........................................................................................................................................12

Specifications .....................................................................................................................................................13

Current A vailability ....................................................................................................................................14

Controls and Indicators ......................................................................................................................................15

Circuits ...............................................................................................................................................................15

Digital Alarm Communicator/Transmitter ........................................................................................................16

Components .......................................................................................................................................................17

Intelligent Addressable Detectors: Newer Series .......................................................................................17

Intelligent Addressable Modules: Newer Series ........................................................................................17

300 Series Intelligent Addressable Devices ...............................................................................................17

Device Accessories .....................................................................................................................................17

Optional Modules ............................... ................................................... ............................................................18

Accessories ........................................................................................................................................................18

PK-CD Programming Utility ......................................................................................................................18

Dress Panel .................................................................................................................................................18

Trim Ring ...................................................................................................................................................18

Battery Box ................................................................................................................................................. 19

Battery Charger ..........................................................................................................................................19

CHG-75 Battery Charger ....................................................................................................................19

CHG-120F Battery Charger ................................................................................................................19

ANN-BUS Devices ............................................................................................................................................20

ANN-BUS Wiring ......................................................................................................................................20

Calculating Wiring Distance for ANN-BUS Modules ........................................... .............................20

Wiring Configuration .............................................................. ............................................................22

Powering ANN-BUS Devices from Auxiliary Power Supply ............................................................23

ANN-BUS Device Addressing .....................................................................................................

..............23

ANN-80 Remote Fire Annunciator ............................................................................................................24

Specifications ......................................................................................................................................24

Installation ...........................................................................................................................................24

Mounting .............................................................................................................................................24

Opening/Closing Annunciator ............................................................................................................24

Wiring ANN-80 to FACP ...................................................................................................................25

ANN-S/PG Serial/Parallel Interface Module .............................................................................................27

Specifications ......................................................................................................................................27

PRN-6F Printer Installation .................................................................................................................27

Connecting PRN-6F Printer ................................................................................................................28

Setting Printer Options ................................................. .......................................................................28

ANN-I/O LED Driver Module ...................................................................................................................29

ANN-I/O Board Layout ......................................................................................................................29

Specifications ......................................................................................................................................29

ANN-I/O Connection to FACP ...........................................................................................................30

ANN-I/O Module LED Wiring ...........................................................................................................31

ANN-LED Annunciator Module ................................................................................................................32

ANN-LED Board Layout ....................................................................................................................32

Specifications ......................................................................................................................................32

ANN-LED Connection to FACP ....................................................................................................

....33

ANN-RLY Relay Module ...........................................................................................................................34

ANN-RLY Board Layout ....................................................................................................................34

Specifications ......................................................................................................................................34

Mounting/Installation ..........................................................................................................................34

ANN-RLY Connection to FACP ........................................................................................................35

Getting Started ...................................................................................................................................................35

Telephone Requirements and Warnings ............................................................................................................36

Telephone Circuitry ....................................................................................................................................36

MS-9050UD Series P/N: 52413:D 12/15/08

Table of Contents

Digital Communicator ....................................................... .........................................................................36

T elephone Company Rights and Warnings ................................................................................................37

For Canadian Applications .........................................................................................................................38

Installation ...............................................................................................................................................................39

Mounting Backbox ............................................................................................................................................39

Mounting Chassis/Transformer/Main Circuit Board .........................................................................................40

Power .................................................................................................................................................................43

AC Power and Earth Ground Connection ..................................................................................................43

Battery Power .............................................................................................................................................43

Relays ................................................................................................................................................................44

Notification Appliance Circuits .........................................................................................................................44

Configuring NACs .....................................................................................................................................45

UL Power-limited Wiring Requirements ...........................................................................................................46

Digital Communicator ................................................................................................ .......................................47

Optional Modules/Accessories Installation .......................................................................................................48

4XTMF Transmitter Module Installation ...................................................................................................48

Programming .........................................................................................................................................................51

Programming Data Entry ...................................................................................................................................51

User Programming ............................................................................................................................................52

Initial Power-up .................................................................................................................................................53

Programming Screens Description ....................................................................................................................53

Programming and Passwords ............................................................................................................................53

Master Programming Level ........................................... ....................................................................................55

Autoprogram ..............................................................................................................................................56

Point Program .............................................................................................................................................57

Detector Programming ............................................. ...........................................................................57

Add Detector .......................................................................................................................................57

Delete Detector ...................................................................................................................................58

Edit Detector .......................................................................................................................................58

Module Programming .........................................................................................................................67

Add Module ........................................................................................................................................67

Delete Module .....................................................................................................................................68

Edit Module Screen for Monitor Module ...........................................................................................68

Edit Module Screen for Control Modules ................................... ........................................................77

Zone Setup ..................................................................................................................................................84

Enable ..................................................................................................................................................84

Disable ................................................................................................................................................85

Zone 17, 18 and 19 ..............................................................................................................................85

Zones Installed ....................................................................................................................................86

Zones Enabled .....................................................................................................................................86

Zones Disabled ....................................................................................................................................86

Zone Type ...........................................................................................................................................86

Zones Available ..................................................................................................................................88

Loop Setup .................................................................................................................................................88

Style ....................................................................................................................................................88

Loop Protocol ......................................................................................................................................88

System Setup .................................................... ..........................................................................................89

Trouble Reminder ...............................................................................................................................90

Banner .................................................................................................................................................90

Time-Date ...........................................................................................................................................91

Time ....................................................................................................................................................91

Date .....................................................................................................................................................92

Clock Format .......................................................................................................................................92

Daylight Savings Time ........................................................................................................................92

Timers .................................................................................................................................................93

MS-9050UD Series P/N: 52413:D 12/15/08 5

Table of Contents

PAS (Positive Alarm Sequence) Delay ...............................................................................................93

Pre-signal Delay ..................................................................................................................................94

Waterflow Delay ................................................................................................................................. 94

AC Loss Delay ....................................................................................................................................95

NAC (Notification Appliance Circuit) ................................................................................................95

Enabled ................................................................................................................................................96

Type .....................................................................................................................................................97

Silenceable ..........................................................................................................................................97

Auto Silence .............................................................. ..........................................................................98

Coding (only for NACs not programmed as Sync Strobe Type) ........................................................98

Zone .....................................................................................................................................................100

Silence Inhibited ..................................................................................................................................100

Sync Type ............................................................................................................................................100

Relays ..................................................................................................................................................101

Canadian Option ..................................................................................................................................102

Waterflow Silenceable ........................................................................................................................102

Verify Loop .................................................................................................................................................102

History ........................................................................................................................................................103

View Events ........................................................................................................................................103

Erase History ............................................... ................................................... .....................................103

Walktest ......................................................................................................................................................104

Option Modules .........................................................................................................................................105

ANN-BUS ...........................................................................................................................................106

ANN-BUS Enabled .............................................................................................................................106

Modules Installed .............................................................. ..................................................................106

Auto-Configure ...................................................................................................................................116

ANN-S/PG (Print) Options Screen .....................................................................................................116

ANN-80 Options Screen .....................................................................................................................117

Onboard DACT ..................................................................................................................

.................118

Onboard DACT Enable .......................................................................................................................118

Primary Phone .....................................................................................................................................118

Secondary Phone .................................................................................................................................119

Central Station .....................................................................................................................................120

Trouble Call Limit (Dialer Runaway Prevention) ..............................................................................121

Manual Dial Mode ..............................................................................................................................133

Password Change .......................................................................................................................................134

Clear Program .............................................................................................................................................135

Program Check ...........................................................................................................................................136

Maintenance Programming Level .....................................................................................................................138

Disable Point ..............................................................................................................................................139

History ........................................................................................................................................................140

Program Check ...........................................................................................................................................141

Walktest ......................................................................................................................................................142

System ........................................................................................................................................................143

Zone Setup ..................................................................................................................................................144

Operating Instructions ...........................................................................................................................................147

Panel Control Buttons ........................................................................................................................................147

Acknowledge/Step ......................................................................................................................................147

Alarm Silence .............................................................................................................................................147

Drill/Hold 2 Sec ..........................................................................................................................................147

Reset ...........................................................................................................................................................147

Status Indicators and LEDs ...............................................................................................................................148

Normal Operation ........................................................... ...................................................................................149

Trouble Operation ..............................................................................................................................................149

Alarm Operation ................................................................................................................................................151

MS-9050UD Series P/N: 52413:D 12/15/08

Table of Contents

Supervisory Operation .......................................................................................................................................152

Process Monitor Operation ................................................................................................................................ 153

Hazard/Tornado Condition Operation ...............................................................................................................153

Medical Alert Condition Operation ...................................................................................................................153

NAC Operation ..................................................................................................................................................153

Programmed Zone Operation ................................ ............................................................................................154

Disable/Enable Operation ..................................................................................................................................154

Waterflow Circuits Operation ............................................................................................................................ 154

Detector Functions ............................................................................................................................................154

Time Functions: Real-Time Clock ....................................................................................................................154

Synchronized NAC Operation ...........................................................................................................................155

Coded Operation ................................................................................................................................................155

Presignal ............................................................................................................................................................155

Positive Alarm Sequence ...................................................................................................................................156

Special System Timers ......................................................................................................................................157

Silence Inhibit Timer ..................................................................................................................................157

Autosilence Timer ......................................................................................................................................157

Trouble Reminder .................................................................... ...................................................................157

Waterflow Retard Timer ............................................................................................................................. 157

Alarm Verification (None or One Minute) .................................................................................................158

Walktest .............................................................................................................................................................158

Read Status ........................................................................................................................................................159

System Point ...............................................................................................................................................160

Zones ..........................................................................................................................................................161

Power ..........................................................................................................................................................162

Trouble Reminder .................................................................... ...................................................................163

Timers .........................................................................................................................................................163

NAC ...........................................................................................................................................................164

Relays .........................................................................................................................................................164

Program Check ......................................... ..................................................................................................165

History ........................................................................................................................................................165

ANN-BUS ..................................................................................................................................................166

Phone Line ..................................................................................................................................................167

Central Station ............................................................................................................................................167

Service Terminal ........................................................................................................................................168

Print ............................................................................................................................................................ 168

Time-Date ...................................................................................................................................................170

Central Station Communications ..........................................................................................................................171

Transmittal Priorities .........................................................................................................................................174

Local/Remote Site Upload/Download ...................................................................................................................176

Remote Download ...............................................................................................................

..............................176

Transferring a Program .............................................................................. ........................................................177

Security Features ...............................................................................................................................................178

Power Supply Calculations ....................................................................................................................................179

Overview ...........................................................................................................................................................179

Calculating the AC Branch Circuit ...................................................................................................................179

Calculating the System Current Draw ...............................................................................................................180

Overview ....................................................................................................................................................180

How to Use Table 7.3 on page 181 to Calculate System Current Draw ....................................................180

Calculating the Battery Size ..............................................................................................................................182

NFPA Battery Requirements ......................................................................................................................182

Selecting and Locating Batteries ................................................................................................................182

Software Zones ........................................................................................................................................................183

Correlations .......................................................................................................................................................183

MS-9050UD Series P/N: 52413:D 12/15/08 7

Table of Contents

Default Programming .............................................................................................................................................188

NFPA Standard-Specific Requirements ...............................................................................................................189

Central Station/Remote Station Transmitter: Connection to FACP Dry Contacts ............................................193

MBT-1 Municipal Box Trip - Silenceable ........................................................................................................194

FACP with Keltron ................................................................................................ .................................................195

Wire Requirements .................................................................................................................................................196

HVAC Control ........................................................................................................................................................197

Control Module Operation .................................................................................................................................197

HVAC SHUTDN .......................................................................................................................................197

Monitor Module Operation ................................................................................................................................197

HVAC RESTART ......................................................................................................................................197

HVAC OVRRIDE ......................................................................................................................................198

Ademco Contact ID Format Event Code Descriptions ............................................... ........................................199

Transmission Format Between DACT and Receiver ........................................................................................199

Ademco Contact ID Typical Printout ................................................................................................................199

Canadian Application .............................................................................................................................................204

ANN-LED Annunciator Installation for Canadian Applications ......................................................................204

AC Power Connections for Canadian Applications ..........................................................................................205

MS-9050UD Series P/N: 52413:D 12/15/08

It is imperative that the installer understand the requirements of the Authority Having Jurisdiction (AHJ) and be familiar with the standards set forth by the following regulatory agencies:

• Underwriters Laboratories Standards

• NFPA 72 National Fire Alarm Code

• CAN/ULC - S527-99 Standard for Control Units for Fire Alarm Systems

Before proceeding, the installer should be familiar with the following documents.

NFPA Standards

NFPA 72 National Fire Alarm Code NFPA 70 National Electrical Code

Underwriters Laboratories Documents:

UL 38 Manually Actuated Signaling Boxes UL 217 Smoke Detectors, Single and Multiple Station UL 228 Door Closers–Holders for Fire Protective Signaling Systems UL 268 Smoke Detectors for Fire Protective Signaling Systems UL 268A Smoke Detectors for Duct Applications UL 346 Waterflow Indicators for Fire Protective Signaling Systems UL 464 Audible Signaling Appliances UL 521 Heat Detectors for Fire Protective Signaling Systems UL 864 Standard for Control Units for Fire Protective Signaling Systems UL 1481 Power Supplies for Fire Protective Signaling Systems UL 1610 Central Station Burglar Alarm Units UL 1638 Visual Signaling Appliances UL 1971 Signaling Devices for Hearing Impaired UL 2017 General-Purpose Signaling Devices and System

CAN/ULC - S524-01 Standard for Installation of Fire Alarm System CAN/ULC - S561-03 Installation and Services for Fire Signal Receiving Centers and Systems CAN/ULC - S527-99 Standard for Control Units for Fire Alarm Systems CAN/ULC - S559-04 Equipment for Fire Signal Receiving Centers and Systems

This Class (A) digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe (A) est conforme à la norme NMB-003 du Canada.

Other:

EIA-232E Serial Interface Standard EIA-485 Serial Interface Standard NEC Article 250 Grounding NEC Article 300 Wiring Methods NEC Article 760 Fire Protective Signaling Systems Applicable Local and State Building Codes Requirements of the Local Authority Having Jurisdiction (LAHJ)

Fire-Lite Documents:

Fire-Lite Device Compatibility Document #15384 SLC Wiring Manual Document #51309 CHG-120F Battery Charger Document #50888 CHG-75 Battery Charger Document #51315 ANN-80 Product Installation Doc. Document #52749 ANN-(R)LED Product Installation Doc. Document #53032 ANN-I/O Product Installation Doc. Document #151416 ANN-RLY Product Installation Doc. Document #53033 ANN-S/PG Product Installation Doc. Document #151417

Software Downloads

In order to supply the latest features and funtionality in fire alarm and life safety technology to our customers, we make frequent upgrades to embedded software in our products. To ensure that you are installing and programming the latest features, we strongly recommend that you download the most current version of software for each product prior to commissioning any system. Contact Technical Support with any questions about softw are and the appropriate version for a specific application.

This product has been certified to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, 9th Edition. Operation of this product with products not tested for UL 864, 9th Edition has not been evaluated. Such operation requires the approval of the local Authority Having Jurisdiction (AHJ).

MS-9050UD Series PN 52413:D 12/15/08 9

9050udlayo90.cdr

Basic System Connections

Special A p plic atio n Powe r

Black

Red

Green

White

EIA-232 to

personal computer

(Nonsupervised,

Upload/Download Utility.

personal computer with FACP

Power-limited (Class 2) Circuit)

50 foot maximum within same room.

1 Fixed Trouble Relay

Nonsuper v ised Conta ct Ratings :

2.0 amps @ 30 VDC (resistive)

2 Programmable Relays &

NAC #1

0.5 amps @ 30 VAC (resistive)

NAC #2

9 8 7 6

DB9F

5 4 3 2 1

NC NO C

A Fail Safe Trouble

relay switches t o the

NO position during

troubl e co nd i tions and

Contacts sho wn below in normal

condition (AC power with no alarm,

trouble or supervisory activity).

SLC Loop

Manual for detail ed

information on wiring

Refer to the SLC Wiring

under loss of all power.

Supervised Circuit)

for Style 4, 6 and 7.

addressable dev ices

(Power- Limited, Clas s 2

(* )Factory default relay programming

G DTR X

Supervisory*

Alarm* Troubl e

7 6

RCV XMT DTR GND

PWR

ANN-BUS

C NC

NO NC C

NONC

NC NO C

NO NC C

SHIELD

SLC

2 1

B+ A+ B- A-

NAC2

NAC1

B+ B- B-B+A+ A- A+ A-

Remove this jumper to enable

Supervisory relay when

4XTMF module is installed

TB7 TB3

JP2

TB6

Cut JP28 to

supervise

4XTMF

JP1

JP28

TB5

LCD DISPLAY

4XTMF

TB2

TB1

SW1

FIRE ALARM

AC POWER

Charger Disable Jumper

J11

TROUBLE

(cut to disable FACP

onboard battery charger)

KISSOFF

ALARM

DEF

ABC

LED1

LED2

LED3

2 1

CLEAR

JKL

GHI

JP30

ENTER

DRILL

ESC

MODE

_/.

QZ_

PRS TUV

PH2

(nonpower-limited,

supervised)

DACT Phone

Line Jacks

PH1

RESET

PS2 Keyboard Interface

BATTERY

Battery

24 VDC, nonp ow er-limited,

supervised, 18 Amp Hour max.

Notification Appliance Circuits

ELR 4.7K, ½W

2.5 amps ma x. per ci r cui t . Total avai la bl e current 2.5 amps. Connector

Supervised

NAC #2 Shown Style Z (Class A) (Power-Limited, Class 2, Supervised)

NAC #1 Show n S t yle Y (Class B) (Pow er- Limited, Class 2, Su pe rvised)

For specific UL wiring

information, refer to "UL

Power-limited Wiring

Requirements" on page 46

Transformer

CAUTION!

HIGH VOLTAGE

Nonpower-limited,

10 MS-9050UD Series PN 52413:D 12/15/08

Peripheral Devices

ANN-BUS

ANN-80

Text Annunciator

Doc. #52749

PH1 & PH2

Telephone

ANN-RLY

10 Form-C Relay Card

Doc. #53033

LED Driver Doc. #151416

Municipal Box Transmitter

SLC Loop

ANN-(R)LED

LED Display

Doc. #53032

ANN-I/O

Printer Driver

Doc. #151417

IPDACT

Internet Protocol Communicator

Doc. #53109

4XTMF

Addressable Devices and SLC Wiring

Doc. #51309

ANN-S/PG

Battery Connector

CHG-120F Charger

Doc. #50888

RS-232

Local PC

9050UDperi.cdr

CHG-75 Charger

Doc. #51315

MS-9050UD Series PN 52413:D 12/15/08 11

Product Description

SECTION 1 Product Description

The MS-9050UD is a combination FACP (Fire Alarm Control Panel) and DACT (Digital Alarm Communicator/Transmitter) all on one circuit board. This compact, cost effective, intelligent addressable control panel has an extensive list of powerful features. The combination of Fire-Lite’s newer series devices and legacy 300 Series devices, along with the MS-9050UD FACP, offer the latest in fire protection technology. The power supply and all electronics are contained on a single circuit board housed in a metal cabinet, providing a complete fire control system for most applications. Available accessories include local and remote upload/download software, remote annunciators and reverse polarity/city box transmitter.

The integral DACT transmits system status (alarms, troubles, AC loss, etc.) to a Central Station via the public switched telephone network. It also allows remote programming or interrogation of the control panel using the PK-CD Upload/Download utility via the public switched telephone network. Any personal computer with Windows speed of 2400 baud or faster and Upload/Download software kit PK-CD, may serve as a Service T erminal. This allows download of the entire program or upload of the entire program, history file, walktest data and current status.

The MS-9050UDC is a ULC approved Canadian version of the FACP which offers the same features as the MS-9050UD, but is supplied standard with a dress panel and one built-in ANN-LED annunciator. Refer to "Canadian Option" on page 102 for a full description.

™

XP or newer, and compatible modem with a

The MS-9050UDE offers the same features as the MS-9050UD but allows connection to 220/240 VAC power.

Note: Unless otherwise specified, the terms FACP and MS-9050UD are used in this manual to refer to all versions of the FACPs.

Inventory

When the MS-9050UD shipment is received, check to make certain that all parts have been included in the shipment. The MS-9050UD shipment should consis t of one of each of the following:

 main circu it board with display  chassis with transformer  backbox wit h doo r  plastic bag containing screws, cables, key, etc.  manual

1.1 Features and Options

• Built-in DACT (Digital Alarm Communicator/Transmitter) with remote upload/download

• Single addressable SLC loop which meets NFPA Style 4, 6 and 7 requirements

• 50 addressable device capacity (any combination of addressable detectors and addressable control/relay/monitor modules totalling 50)

• 20 software zones

• Two onboard NACs (Notification Appliance Circuits) which can be configured as Style Y (Class B) or Style Z (Class A) circuits

• 2.5 amps total power for NACs

• 2.7 amps total system power (includes battery charger)

• Two programmable relays and one fixed trouble relay

• Built-in Programmer

• Telephone Line Active LEDs

• Communication Confirmation (Kissoff) LED

• Touchtone/Rotary dialing

• EIA-232 PC interface for local upload/download

12 MS-9050UD Series PN 52413:D 12/15/08

Product Description

• 80-character LCD display (backlit)

• Real-time clock/calendar with daylight savings time control

• History file with 500 event capacity

• Advanced fire technology features:

 Automatic drift compensation  Maintenance alert  Detector sensitivity test capability (NFPA 72 compliant)  Automa tic devi ce type-code veri fication  Point trouble identification

• Waterflow selection per module point

• Alarm verification selection per detector point

• Walktest, silent or audible

• PAS (Positive Alarm Sequence) per addressable detector and Pre-signal per point (NFPA 72 compliant)

• Silence inhibit timer option per NAC

• Autosilence timer option per NAC

• Continuous, March Time, Temporal or California code for main circuit board NACs with two-stage capability

• Selectable strobe synchronization per NAC

• Remote Acknowledge, Alarm Silence, Reset and Drill via addressable modules or remote annunciator

• Auto-program (learn mode) reduces installation time. Reports two devices set to the same address

• Password and key-protected nonvolatile memory

• User programmable password

• Fully programmable from local keypad or optional keyboard

• SLC operates up to 10,000 ft. (3,000 m) with twisted, unshield ed fire wire

• Compatible with Fire-Lite addressable devices (refer to SLC Wiring Manual)

• Compatible with legacy Fire-Lite 300 Series addressable devices (refer to SLC Wiring Manual)

• Optional 4XTMF module (conventional reverse polarity/city box transmitter)

• Optional ANN-I/O LED Driver module

• Optional ANN-S/PG printer interface module

• Optional ANN-80 remote LCD annunciator

• Optional ANN-LED Annunciator Module annunciates alarm, trouble and supervisory

• Optional ANN-RLED Annunciator Module annunciates alarms only

• Optional ANN-RLY Form-C Relay Module

• Optional Dress Panel DP-51050 (a modified dress panel is included standard with the MS-9050UDC)

• Optional PRN-6F Serial Printer (requires ANN-S/PG module)

1.2 Specifications

Refer to Illustration on page 10 for terminal locations and connections. For wire specifications, refer to "Wire Requirements" on page 196.

AC Power - Transformer Connection

MS-9050UD: 120 VAC, 60 Hz, 3.0 amps MS-9050UDE: 240 VAC, 50 Hz, 1.5 amps Wire size: minimum 14 AWG (2.00 mm Nonpower-limited, supervised

MS-9050UD Series PN 52413:D 12/15/08 13

) with 600 V insulation

Product Description

Battery (Lead Acid Only) - J1

Maximum Charging Circuit: Normal Flat Charge - 27.6 VDC @ 1.2 amp Maximum Battery Charger Capacity: 18 Amp Hour, (FACP cabinet holds maximum of two 18 Amp Hour batteries) For greater than 18 Amp Hour up to 120 Amp Hour batteries, use the CHG-75 or CHG-120F Battery Charger and BB-55F Battery Box. Note: Jumper JP30 on the FACP main circuit board, must be removed to disable the FACP ba ttery charger when using an external battery charger. Minimum Battery: 7 Amp Hour Nonpower-limited, supervised

SLC Communication Loop - TB2

24 VDC nominal, 27.6 VDC maximum Maximum length is 10,000 ft. (3,000 m) total twisted, unshielded fire wire Maximum loop current is 400 mA (short circuit) or 100 mA (normal) Maximum loop resistance is 40 ohms Supervised and power-limited circuit Refer to SLC Loop manual for wiring information

Notification Appliance Circuits/Special Application (Auxiliary) Power - TB1

Terminal Block provides connections for up to two NACs, Style Y (Class B) or Style Z (Class A) Special Application power Power-limited, supervised circuitry For wire specifications, refer to "NAC Wiring" on page 197. Nominal operating voltage: 24 VDC Current-limit: fuseless, electronic, power-limited circuitry Maximum signaling current per circuit: 2.5 amps End-of-Line Resistor: 4.7 kΩ, ½ watt (P/N 71252 UL listed) for Style Y (Class B) NAC Refer to Fire-Lite Device Compatibility Document for listed compatible devices Note: a circuit programmed for door holders or auxiliary power does not support notification appliances.

Two Programmable Relays and One Fixed Trouble Relay - TB5, TB6 & TB7

Contact rating: 2.0 amps @ 30 VDC (resistive), 0.5 amps @ 30 VAC (resistive) Form-C relays, nonpower-limited, nonsupervised Refer to Figure 2.5 on page 44 for information on power-limited relay circuit wiring

EIA-232 - TB3

EIA-232 PC applications connections: Terminal 5 (Receive), 6 (Transmit), 7 (DTR), 8 (Ground) Power-limited, supervised

ANN-BUS (EIA-485) - TB3

Annunciator connector: Terminal 1 (Ground), 2 (Power), 3 (A), 4 (B) Nominal Operating Voltage: 24 VDC Maximum Current (Terminals 1 & 2): 500 mA Power-limited, supervised

1.2.1 Current Availability

The Notification Appliance Circuits can provide 2.5 amps maximum per circuit. Total available current for the FACP is 2.7 amps.

14 MS-9050UD Series PN 52413:D 12/15/08

1.3 Controls and Indicators

LCD Display

The FACP uses an 80-character (4 lines X 20 characters) high viewing angle LCD display. The display includes a long life LED backlight that remains illuminated. If AC power is lost and the system is not in alarm, the LED backlight will turn off to conserve batteries.

LED Indicators

LED indicators are provided to annunciate the following conditions:

• AC Power (green)

• Fire Alarm (red)

• Supervisory (yellow)

• Trouble (yellow)

• Alarm Silenced signals (yellow)

Key Panel

Mounted on the main circuit board, the key panel includes a window for the LCD display and LED indicators as listed above. The key panel, which is visible with the cabinet door closed, has 25 keys, including a 16 key alpha-numeric pad similar to a telephone keypad.

Function keys:

• Acknowledge/Step

• Alarm Silenced

• Drill (Manual Evacuate)

• Reset (lamp test)

Service/program keys:

Product Description

SYSTEM ALL NORMAL 10:00A 092105

1.4 Circuits



Reference

Manual

• Keys labeled 1 to 9

• * key

• # key

• 0 (recall) key

• 1st Event key

• Clear key

• Escape key

• Mode key

• Four cursor keys (up, down, left and right)

• Enter key

Local Piezo Sounder

A piezo sounder provides separate and distinct pulse rates for alarm, trouble and supervisory conditions.

SLC Communication Loop

One SLC loop is provided on the FACP main circuit board. The SLC loop, configurable for NFPA Style 4, 6 or 7, provides communication to addressable detectors, monitor (initiating device) and control (output device) modules. Refer to the SLC Wiring manual for information on wiring devices.

Figure 1.1 Membrane/Display Panel

9050udkypd.cdr

MS-9050UD Series PN 52413:D 12/15/08 15

Product Description

Output Circuits

The following output circuits are available on the FACP:

Relays

One fixed and two fully programmable Form-C dry contact relays are provided. The fixed fail-safe relay monitors system trouble and the two programmable relays are factory default programmed for system alarm and system supervisory. Contacts are rated 2.0 amps @ 30 VDC (resistive) and 0.5 amps @ 30 VAC (resistive). The programmable relays can be programmed for the following operations:

• Charger

24 VDC Battery Charger (up to 18 AH batteries)

• NAC (Notification Appliance Circuits)

Two NACs configurable for Style Y (Class B) or Style Z (Class A), are provided with various programmable features.

• fire alarm

• silenceable alarm

• trouble

• supervisory

• supervisory auto-resettable

• DACT communication failure

• process monitor

• process monitor auto-resettable

• hazard alert

• medical alert

•AC loss

1.5 Digital Alarm Communicator/Transmitter

T wo modular phone jacks allow easy connection to telephone lines. Modular jacks are labeled PH1 for Primary Phone Line and PH2 for Secondary Phone Line. Two telephone line active red LEDs are provided as well as a green Kissoff LED. The integral digital communicator provides the following functions:

• Line Seizure: takes control of the phone lines disconnecting any premises phones

• Off/On Hook: performs on and off-hook status to the phone lines

• Dialing the Central Station(s) number: default is Touch-Tone

• For tone burst or touchtone type formats: discern proper Ack and Kissoff tone(s). The frequency and time duration of the tone(s) varies with the transmission format. The control panel will adjust accordingly.

• Communicate in the following formats:  12 Tone Burst types: 20 pps

(3+1, 4+1, 4+2, 3+1 Exp., 4+1 Exp., 4+2 Exp.)

 3 Touchtone Types

4+1 Ademco Express 4+2 Ademco Express Ademco Contact ID

, programmable to rotary

16 MS-9050UD Series PN 52413:D 12/15/08

1.6 Components

Main Circuit Board

The main circuit board contains the system’s CPU, power supply, other primary components and wiring interface connectors. The 4XTMF option module plugs in and is mounted to the main circuit board. The circuit board is delivered mounted to a chassis in the MS-9050UD backbox



See Page

(refer to circuit board illustration on page 10).

Cabinet

The MS-9050UD backbox provides space for two batteries (up to 18 Amp Hour). Ample knockouts are provided for system wiring. Also available is an optional dress panel, which mounts to the inside of the cabinet (required by ULC for Canadian installations).

Product Description

MS_9050UD.cdr



Reference

Manual

Batteries

The MS-9050UD cabinet provides space for two batteries (up to 18 Amp Hour). Batteries larger than 18 Amp Hour require an external charger such as the CHG-75 or CHG-120F and a UL listed battery box

Battery Cable P/N 75203

9200batt.cdr

such as the BB-55F . Batteries must be ordered separately.

1.6.1 Intelligent Addressable Detectors: Newer Series

Intelligent, addressable detectors provide information to the control panel on an SLC Signaling Line Circuit (refer to the SLC Wiring Manual for detailed information on addressable devices, device installation, wiring and operation). This allows the control panel to continually process the information to determine the status (alarm, trouble, maintenance or normal) of each detector . Each detector responds to an SLC address that is set in the detector head using built-in rotary decimal switches. Note that a blinking LED on an intelligent detector indicates communication between the detector and the control panel. Refer to the Fire-Lite Device Compatibility Document for a list of approved conventional detectors.

1.6.2 Intelligent Addressable Modules: Newer Series

The newer series of Control Modules and Monitor Modules provide an interface between the control panel and conventional notification and initiating devices. Each module can be set to respond to an address with built-in rotary switches. A blinking LED on a monitor module indicates communication between the module and the control panel. These devices can also be used when installed on older systems. Refer to the SLC Wiring Manual for information on addressable

devices. Refer to the Fire-Lite Device Compatibility Document for a list of approved conventional notification and initiating devices.

1.6.3 300 Series Intelligent Addressable Devices

Fire-Lite’s 300 Series Intelligent Addressable Devices are fully compatible with the MS-9050UD FACP. Refer to the SLC Wiring Manual for device information.

1.6.4 Device Accessories

End-of-Line Resistor Assembly

Refer to the SLC Wiring Manual for device information. The 47 kΩ End-of-Line Resistor assembly (P/N: R-47K) is used to supervise the MMF-300, MDF-300, MMF-301 and CMF-300 module circuits. The 3.9 kΩ End-of-Line Resistor assembly is used to supervise the MMF-302 module circuit. The End-of-Line resistors are included with each module.

MS-9050UD Series PN 52413:D 12/15/08 17

Product Description

Power Supervision Relay

The UL listed End-of-Line power supervision relay is used to supervise the power to 4-wire smoke detectors and notification appliances.

EOL-C(R/W) Mounting Plate

The EOL-CR (red) and EOL-CW (white) are single End-of-Line resistor plates which are required for use in Canada. An ELR, which is supplied with each module and fire alarm control panel, is mounted to the EOL-C(R/W) plate. Resistors mounted to the plate can be used for the supervision of a monitor and control module circuit.

1.7 Optional Modules

The MS-9050UD main circuit board includes option module connectors for the following module:

4XTMF Transmitter Module

The 4XTMF provides a supervised output for local energy municipal box transmitter, alarm and trouble reverse polarity. It includes a disable switch and disable trouble LED. A jumper on the module is used to select an option which allows the reverse polarity circuit to open with a system trouble condition if no alarm condition exists. The module plugs into connectors J8 and J9 which are located near the top center of the main circuit board. When the 4XTMF module is installed, Jumper JP28, on the main circuit board, must be cut to allow supervision of the module.

1.8 Accessories

1.8.1 PK-CD Programming Utility

The PK-CD Programming Utility can be used to locally or remotely program an MS-9050UD & MS-9050UDC directly from most IBM compatible personal computers (PC), running Windows XP (or newer). MS-9050UD & MS-9050UDC program files can also be created and stored on the

PC and then downloaded to the control panel. The PK-CD Kit includes the Windows-based Programming Utility software on CD-ROM with on-line help file. A serial cable (P/N: PRT/PKCABLE), which must be purchased separately, is required for local connection of the PC to the RS232 (PC/Printer) terminals at TB3 of the MS-9050UD & MS-9050UDC main circuit board. Remote programming requires that the PC have a 2400 baud (or faster) modem.

Important: Remote modification of FACP programming requires that the panel be enabled for remote download (refer to "Remote Download" on page 176). Remote interrogation of panel programming, history logs, detector status, etc., is possible without enabling the remote download option.

1.8.2 Dress Panel

An optional dress panel (DP-51050) is available for the MS-9050UD. A modified dress panel is supplied standard with the MS-9050UDC. The dress panel restricts access to the system wiring while allowing access to the key panel.

1.8.3 Trim Ring

™

An optional Trim Ring (TR-CE) is available for semi-flush mounting of the FACP backbox.

18 MS-9050UD Series PN 52413:D 12/15/08



Reference

Manual

Product Description

1.8.4 Battery Box

BB-26

The BB-26 battery box may be used to house up to two 26 AH batteries and the CHG-75 Battery Charger. The battery box, which is red and is provided with knockouts, was designed specifically to compliment mounting below the FACP.

BB-55F

The BB-55F battery box may be used to house two 26 AH bat teries, two 60 AH batteries or one 100 AH battery. When the CHG-120F is mounted in the BB-55F, two 26 AH or one 60 AH battery may also be housed in the battery box.

1.8.5 Battery Charger

1.8.5.1 CHG-75 Battery Charger

The CHG-75 is capable of charging up to 75 AH lead-acid batteries with the FACP. The F ACP battery charger must be disabled, by removing jumper JP30, when using the CHG-75. The charger and up to 26 AH batteries can be housed in the BB-26 battery box. Larger batteries and the charger can be housed in the BB-55F battery box which can be mounted up to 20 feet away from the control panel. Refer to the CHG-75 Manual for additional information.

1.8.5.2 CHG-120F Battery Charger

The CHG-120F is capable of charging up to 120 AH lead-acid batteries with the FACP. The F ACP battery charger must be disabled, by removing jumper JP30, when using the CHG-120F . The batteries and charger can be housed in the BB-55F battery box which can be mounted up to 20 feet away from the control panel. Note that when using the BB-55F for housing the charger and batteries greater than 26AH, multiple BB-55Fs are required. Refer to the CHG-120F Manual for additional information.

1.8.6 IPDACT, IPDACT-2, IPDACT-2UD - IP Communicator

The IPDACT, IPDACT-2, and IPDACT-2UD are a compact, Internet Protocol Communicators designed to allow FACP status communication to a Central Station via the internet. No telephone lines are required when using any IPDACT. Using Contact ID protocol from the FACP, any IPDACT converts the standard DACT phone communication to a protocol that can be transmitted and received via the internet. It also checks connectivity between the FACP and Central Station. Refer to the IPDACT Series Product Installation Document P/N 53109 for additional information.

MS-9050UD Series PN 52413:D 12/15/08 19

Product Description

1.9 ANN-BUS Devices

WARNING! Disconnect all sources of power (AC and DC) before installing or removing any modules or wiring.

A variety of optional devices can be connected to the FACP ANN-BUS communication circuit. Compatible devices include:

• ANN-80 LCD Annunciator

• ANN-S/PG Serial/Parallel Printer Interface Module

• ANN-I/O LED Driver Module

• ANN-LED Annunciator Module (alarm, trouble, supervisory LEDs)

• ANN-RLED Annunciator Module (red alarm LEDs only)

• ANN-RLY Relay Module

Note: Canadian applications support up to two ANN-RLY devices installed within the cabinet.

1.9.1 ANN-BUS Wiring

This section contains information on calculating ANN-BUS wire distances and the types of wiring configurations (Class B).

1.9.1.1 Calculating Wiring Distance for ANN-BUS Modules

The following instructions will guide the installer in determining the type of wire and the maximum wiring distance that can be used with FACP ANN-BUS accessory modules.

To calculate the wire gauge that must be used to connect ANN-BUS modules to the FACP, it is necessary to calculate the total worst case current draw for all modules on a single 4-conductor bus. The total worst case current draw is calculated by adding the individual worst case currents for each module. The individual worst case values are shown in the following table:

Model Number Worst Case Current Draw

ANN-80 LCD Annunciator 0.040 amps ANN-S/PG Serial/Parallel Printer Interface Module 0.040 amps ANN-I/O LED Driver Module 0.200 amps ANN-RLY Relay Module 0.075 amps ANN-(R)LED Annunciator Module 0.068 amps

Note: Total worst case current draw on a single ANN-BUS cannot exceed 0.5 amp. If current draw exceeds 0.5 amps, refer to "Powering ANN-BUS Devices fr om Auxiliary Power Supply" on page 23.

20 MS-9050UD Series PN 52413:D 12/15/08

After calculating the total worst case current draw, Table 1.1 specifies the maximum distance the modules can be located from the FACP on a single wire run. The table ensures 6.0 volts of line drop maximum. In general, the wire length is limited by resistance, but for heavier wi re gauges, capacitance is the limiting factor. These cases are marked in the chart with an asterisk (*). Maximum length can never be more than 6,000 feet (1,800 m), regardless of gauge used. The formula used to generate this chart is shown in the note below.

Total Worst Case

Current Draw (amps)

0.100 1,852 ft. 4,688 ft. * 6,000 ft. *6,000 ft.

0.200 926 ft. 2,344 ft. 3,731 ft. 5,906 ft.

0.300 617 ft. 1,563 ft. 2,488 ft. 3,937 ft.

0.400 463 ft. 1,172 ft. 1,866 ft. 2,953 ft.

0.500 370 ft. 938 ft. 1,493 ft. 2,362 ft.

Note: The following formulas were used to generate the wire distance chart:

Product Description

Wiring Distance: ANN-BUS Modules to FACP

22 Gauge 18 Gauge 16 Gauge 14 Gauge

Table 1.1 Wiring Distances

6.0 Volts

Maximum Resistance (Ohms) = Total Worst Case Current Draw (amps)

Maximum Wire Length (feet) = Ma ximum Resistance (Ohms) *500

(6,000 feet maximum) Rpu

where: Rpu = Ohms per 1,000 feet for various Wire Gauges (see table below)

Wire Gauge Ohms per 1,000 feet (Rpu)

22 16.2 18 6.4 16 4.02 14 2.54

Exception: When using the ANN-RLY module, the installer must ensure that the maximum 24VDC power line drop does not exceed 0.3 volts. This results in the following wiring limitations:

Wire Gauge Maximum Wire Length

18 312 feet 16 497 feet 14 787 feet 12 1,250 feet

MS-9050UD Series PN 52413:D 12/15/08 21

Product Description

Wiring Distance Calculation Example:

Suppose a system is configured with the following ANN-BUS modules:

• 3 ANN-80 Remote Fire Annunciators

• 1 ANN-S/PG Serial/Parallel Printer Interface Module

• 1 ANN-I/O LED Driver Module

The total worst case current is calculated as follows:

ANN-80 Current Draw = 3 X 0.040 amps = 0.120 amps ANN-S/PG Current Draw = 1 X.0.040 amps = 0.040 amps ANN-I/O Current Draw = 1 X.0.200 amps = 0.200 amps Total Worst Case Current Draw = 0.360 amps

Using this value and referring to the Wiring Distance Table 1.1 on page 21, it can be found that the available options are:

 463 feet maximum using 22 Gauge wire  1,172 feet maximu m using 18 Gauge wire  1,866 feet maximu m using 16 Gauge wire  2,953 feet maximu m using 14 Gauge wire

1.9.1.2 Wiring Configuration

Figure 1.2 illustrates the wiring between the FACP and ANN-BUS devices.

ANN-BUS and power wiring are supervised and power-limited

ANN-BUS Device

MS-9050UD

Figure 1.2 FACP wiring to ANN-BUS Device

22 MS-9050UD Series PN 52413:D 12/15/08

Product Description

1.9.1.3 Powering ANN-BUS Devices from Auxiliary Power Supply

Figure 1.3 illustrates the powering of ANN-BUS devices from an auxiliary power supply such as the FCPS-24FS6/8, when the maximum number of ANN-BUS devices exceeds the ANNBUS power requirements.

Cut Ground Fault Detection jumper JP1 (FACP monitors for ground faults)

ANN-BUS and power wiring are supervised and power-limited

-24 VDC

+24 VDC

ANN-BUS

ANN-80

MS-9050UD

FCPS-24FS6/8

Figure 1.3 Powering ANN-BUS Devices from FCPS-24FS6/8

1.9.2 ANN-BUS Device Addressing

Each ANN-BUS device requires a unique address (ID Number) in order to communicate with the F ACP. A 5-position DIP switch on each device is used to set this address. The address set for these devices must also be programmed at the FACP for the specific device (refer to the programming section titled "ANN-BUS" on page 106).

A maximum of 8 devices can be connected to the FACP ANN-BUS communication circuit. Device addresses do not need to be sequential and can be set to any number between 01 and 08. Note that 00 is not a valid address. The following table shows the DIP switch setting for each address.

Address Switch 5 Switch 4 Switch 3 Switch 2 Switch 1

not valid OFF OFF OFF OFF OFF 01 OFF OFF OFF OFF ON 02 OFF OFF OFF ON OFF 03 OFF OFF OFF ON ON 04 OFF OFF ON OFF OFF 05 OFF OFF ON OFF ON 06 OFF OFF ON ON OFF 07 OFF OFF ON ON ON 08 OFF ON OFF OFF OFF

Note: Switch 5 must be set to OFF for ANN-BUS devices to be recognized.

MS-9050UD Series PN 52413:D 12/15/08 23

Product Description

1.9.3 ANN-80 Remote Fire Annunciator

The ANN-80 Annunciator is a compact, 80 character, backlit LCD remote fire annunciator which mimics the FACP display. It also provides system status indicators for AC Power, Alarm, Trouble, Supervisory and Alarm Silenced conditions. Communication between the ANN-80 and FACP is accomplished over a two wire serial interface employing the ANN-BUS communication format. The devices are powered, via two additional wires, from either the host FACP or remote UL-listed, filtered, power supply.

1.9.3.1 Specifications

• Operating Voltage Range: 18 VDC to 28 VDC

• Current Consumption @ 24 VDC nominal (filtered and nonresettable):

 Normal/Standby (no activity): 37.0 mA  Trouble: 39.0 mA  Alarm: 40.0 mA  AC Fail ( not backlit): 15.0 mA

• For use indoors in a dry location

1.9.3.2 Installation

Ensure that all power (AC and DC) has been removed from the FACP before installing the annunciator.

1.9.3.3 Mounting

The ANN-80(-W) can be surface or semi-flush mounted using an ANN-SB80KIT-(R/W) or to a single, double or 4” square electrical box. Select and remove the appropriate knockout(s), pull the necessary wires through the knockouts and mount the annunciator in or on the wall depending on the type of installation desired.

The ANN-80 cover must be attached to the annunciator backplate before mounting the annunciator to the electrical box/wall. The cover cannot be reattached or removed after the annunciator has been mounted.

1.9.3.4 Opening/Closing Annunciator

The following procedure details the steps used to open the annunciator in order to access the terminal block and DIP switches (refer to figure below):

1. Turn the key switch to the ON (Unlocked) position by turning the key counter-clockwise

2. Push in the snap latch located on the right side of the unit while pulling the cover open

3. T o close the cover, make certain the key switch is in the ON (Unlocked) position. Swing the cover closed, snapping it shut

4. Turn the key switch to the OFF (Locked) position by turning clockwise and remove the key

Annunciator cover with LCD display

Annunciator backplate

Press in latch and Pull annunciator

Key switch shown in OFF/Locked position

24 MS-9050UD Series PN 52413:D 12/15/08

cover open

Product Description

1.9.3.5 Wiring ANN-80 to FACP

The following steps can be used as a guide to wire the annunciator . Make certain all power has been removed from the FACP prior to annunciator installation.

1. Route wires from hole in backplate, through wiring chan nel and then to ANN-80 terminal block TB1

wiring channel

wires

TB1

2. Remove appropriate amount of wire insulation

3. Connect the wiring from the F ACP ANN-BUS to annunciator TB1 terminals 3 (A) & 4 (B). Make certain to connect A to A and B to B

4. If appropriate, connect the wiring going to the next device on the ANN-BUS to TB1 terminals 3 & 4. Make certain to connect A to A and B to B

5. Connect the wiring from the 24 VDC power source to annunciator TB1 terminals 1 (-) & 2 (+). Make certain to observe proper polarity

6. If appropriate, connect the power wiring going to the next device to terminals 1 (-) & 2 (+). Make certain to observe proper polarity

7. After all connections are made, remove extra wire from inside of annunciator by dressing it neatly through wire channel, with any excess wire pushed back through hole into electrical box

MS-9050UD Series PN 52413:D 12/15/08 25

Product Description

The following table shows the ANN-80 connections to the MS-9050UD.

ANN-BUS and power wiring are supervised and power-limited

ANN-80

FACP

Figure 1.4 ANN-80 Wiring to FACP

MS-9050UD (TB3) ANN-80 (TB1)

Terminal 1 GND (-) Terminal 1 (-) Terminal 2 PWR (+) Terminal 2 (+) Terminal 3 A (ANN-BUS) Terminal 3 (A) Terminal 4 B (ANN-B US) Terminal 4 (B)

Programming

Following installation and wiring of the ANN-80 LCD annunciator to the FACP, the annunciator must be added to the system via FACP programming. Refer to the programming section titled "ANN-BUS" on page 106 in this manual for detailed programming information. Select the LCD option for programming.

Trouble Response

If the ANN-80 is installed but the ANN-BUS is not enabled at the F ACP, the ANN-80 will indicate a trouble condition by NOT turning on its AC Power indicator. The LCD will also display Key Bus Trouble and the piezo will sound approximately once every 10 seconds. Note that the FACP will provide no indication of an ANN-80 trouble.

To clear the ANN-80 trouble condition, enable the ANN-BUS and program th e add ress corresponding to the address set on the ANN-80 at the FACP.

26 MS-9050UD Series PN 52413:D 12/15/08

Product Description

1.9.4 ANN-S/PG Serial/Parallel Interface Module

The ANN-S/PG Serial/Parallel Interface module allows the connection of a serial or parallel printer to the FACP for a real-time log of system events, detector status reports and event history. The module is provided with a plastic enclosure for surface mounting. Proceed with the installation as described in the following:

1. Ensure that all power (AC and DC) has been removed from the FACP.

2. Connect the ANN-S/PG to the FACP as illustrated in Figure 1.5

ANN-BUS and power wiring are supervised and power-limited

ANN-S/PG Module

MS-9050UD

Parallel

Cable

Connectors for

connection to

printer

Serial

Figure 1.5 ANN-S/PG Connection to FACP

3. Using the DIP switches on the back of the ANN-S/PG module, assign an ID number (address) to the module

4. Select the address and configuration options for the ANN-S/PG module as described in the Programming section of this manual (refer to "ANN-BUS" on page 106) Note that the Auto-configure feature allows the programmer to quickly bring all installed ANN-BUS modules online (refer to "Auto-Configure" on page 116)

5. Connect a printer to the ANN-S/PG Parallel or Serial connectors (refer to Figure 1.5). Only one printer can be connected.

1.9.4.1 Specifications

• Operating Voltage: 24 VDC

• Current (Alarm and Standby): 45 mA

• Ambient Temperature: 32

F to 120oF (0oC to 49oC)

• Max. Wiring Distance from FACP: 6,000 ft. (1,800 m)

• Mounting: Surface

• Dimensions: 6”W x 7-3/4”H x 1-7/16”D (15.2 cm W x 19.7 cm H x 3.7 cm D)

• For indoor use in a dry location only

1.9.4.2 PRN-6F Printer Installation

When connected to the FACP via the ANN-S/PG module, the PRN prints the status changes within the control panel and time-stamps the printout with the time of day and date that the event occurred. It provides 80 columns of data on standard 9” x 11” tractor-feed paper. This section contains information on connecting a printer to the control panel and setting the printer options.

MS-9050UD Series PN 52413:D 12/15/08 27

Product Description

1.9.4.2.1 Connecting PRN-6F Printer

Remote printers require a primary AC power source. If required for the fire alarm system configuration (for example, a Proprietary Fire Alarm System), a remote printer requires a secondary power source (battery backup). Since a secondary power source is not provided as a standard feature, a separate UL-listed Uninterruptible Power Supply (UPS) should be used. The building emergency power supply may be used, as long as it meets the power continuity requirements of NFPA 72. Refer to NFPA 72 for further details.

Connect the remote printer to the FACP via the ANN-S/PG module using a standard DB-25 cable. One end of the cable will plug into the DB-25 connector on the PRN printer and the other end plugs into the parallel connector on the ANN-S/PG module. Note that the 9-pin DB9 port on the ANN-S/PG is used to connect a serial printer. The 25-pin port is used for a Centronics parallel printer cable. Connect either a serial or parallel printer, but not both at the same time.

1.9.4.2.2 Setting Printer Options

Refer to the documentation supplied with the PRN-6F printer for instructions on using the printer menu controls. Set the printer options (under the menu area) as shown in the following table:

TABLE 1-3:PRN Setup Options

Option Setting Option Setting

Font HS Draft CPI 10CPI LPI 6 LPI Skip 0.5 ESC Character ESC Emulate Epson FX-850 Bidirectional Copy ON I/O CG-TAB Graphic Buffer 40K Country E-US ASCII Serial Auto CR OFF Baud 9600 or 2400 Color Option Not Installed Format 7 Bit, Even, 1 Stop Formien Protocol XON/XOFF Lines 6LPI=60 Character Set Standard Standard Exec 10.5 SI.Zero On

Auto LF On PAPER BIN 1 12/72” BIN 2 12/72” SINGLE 12/72” PUSH TRA 12/72” PULL TRA 12/72” PAP ROLL 12/72”

28 MS-9050UD Series PN 52413:D 12/15/08

Product Description

1.9.5 ANN-I/O LED Driver Module

The ANN-I/O is an LED driver module that can be used in a wide variety of applications, including as an interface with most customized graphic annunciators. The ANN-I/O can drive up to 40 LEDs. The module is provided with a plastic enclosure for mounting inside the annunciator or accessory box. The following sections describe hardware installation. Refer to the section titled "ANN-BUS" on page 106 for programming information.

1.9.5.1 ANN-I/O Board Layout

Figure 1.1 illustrates the ANN-I/O board showing locations of screw terminals for connection to the FACP, pin connectors for connecting LEDs and the DIP switch for selecting the ANNBUS ID number.

Terminals not used (future)

ANN-BUS Connector

Figure 1.1 ANN-I/O Board Layout

1.9.5.2 Specifications

• Max. ANN-BUS Voltage: 28 VDC

• Max. Current:

 Alarm: 200 mA  Standby: 35 mA  Each LED: 10 mA

• Operating Temperature: 32

• For indoor use in a dry location only

F to 120oF (0oC to 49oC)

ANN-BUS (ID#) Address DIP switch

ann-IObrd.cdr

MS-9050UD Series PN 52413:D 12/15/08 29

Product Description

1.9.5.3 ANN-I/O Connection to FACP

The ANN-I/O connects to the FACP via the ANN-BUS as illustrated in Figure 1.2. After the ANN-I/O is connected to the panel, it must be added to the system via FACP programming. Refer to the section titled "Modules Installed" on page 106.

ANN-I/O Module

MS-9050UD

Figure 1.2 ANN-I/O Connection to FACP

ANN-BUS and power wiring are supervised and power-limited

ann-IOtoFACP.cdr

30 MS-9050UD Series PN 52413:D 12/15/08

+ 186 hidden pages

Fire-Lite MS-9050UDC, MS-9050UD, MS-9050UDE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
