C A R V E X
GB
Original operating manual
1Symbols
2 Machine features
The illustrations specified are located at the beginning and end of the operating manual.
3 Intended use
Jigsaws are designed for sawing wood and similar
materials similar to wood. With the special saw
blades offered by Festool, these machines can also
be used for sawing plastic, steel, aluminium, nonferrous metal and ceramic plates.
The charger TRC 3 is designed for charging the battery packs listed.
The user is liable for improper or non-intended use.
4Technical data
1 Symbols ................................................ 14
2 Machine features.................................. 14
3 Intended use......................................... 14
4 Technical data....................................... 14
5 Safety instructions................................ 15
6 Operation .............................................. 16
7 Settings................................................. 17
8 Working with the machine.................... 18
9 Service and maintenance..................... 19
10 Accessories........................................... 20
11 Transport .............................................. 21
12 Environment ......................................... 21
13 EU Declaration of Conformity .............. 21
Warning of general danger
Risk of electric shock
Read the Operating Instructions/Notes!
Wear a dust mask.
Wear ear protection.
Wear protective goggles.
Wear protective gloves.
Do not throw in the household waste.
[1-1]
Chip guard
[1-2]
On/Off switch
[1-3]
Variable speed trigger (only PSBC 420 EB)
[1-4]
Switch lock (only PSBC 420 EB)
[1-5]
Adjusting wheel for stroke speed control
[1-6]
Buttons for releasing the battery pack
[1-7]
Extractor connector
[1-8]
Saw table change lever
[1-9]
Saw blade ejection
[1-10]
Replaceable saw table
[1-11]
Pendulum stroke switch
[1-12]
Base runner
Cordless jigsaws PSC 420 EB PSBC 420 EB
Motor voltage 10,8 - 18 V
Stroke speed 1500 - 3800 rpm 1000 - 3800 rpm
Stroke length 26 mm
Pendulum stroke 4 steps
max. inclination (only with accessory angle
table WT-PS 400)
45° to both sides
max. cutting depth (depending on saw blade)
Wood 120 mm
Aluminium 20 mm
Steel 10 mm
Weight without battery pack 1,8 kg
Safety class /II
C A R V E X
15
GB
5 Safety instructions
5.1 General safety instructions
WARNING! Read all safety warnings and all
instructions.
Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or battery-operated (cordless) power tool.
5.2 Machine-related safety instructions
–
Hold power tool by insulated gripping surface,
when performing an operation where the cutting accessory may contact hidden wiring.
Cutting accessory contacting "live" wire may make
exposed metal parts of the power tool "live" and
could give the operator an electric shock.
–
The charger and power tool are not intended for
use by persons (including children) with limited
physical, sensory or mental ability or without
sufficient experience and/or knowledge, unless
they are supervised by a person responsible for
their safety or have been instructed on how the
charger or power tool is to be used.
Children
should always be supervised to ensure that they
do not play with the charger or the power tools.
–
Festool electric power tools must only be installed on work tables provided by Festool for
this purpose.
If the tool is installed in another, or
self-made, work table, it can become unstable
and result in serious accidents.
–
Wait until the power tool stops completely until
placing it down.
The tool can become entangled
and lead to a loss of control of the power tool.
– Do not open the battery pack or the charger. Even
after disconnection from the mains, there is still
a high capacitor voltage inside the charger.
– Make sure that metal objects (such as metal
chips) or fluids do not enter the machine through
the battery pack retaining slots (danger of short
circuit).
– Do not charge battery packs from other manu-
facturers. The charger is designed for charging
original battery packs only. Never charge the battery packs in chargers from other manufacturers. Otherwise there is a danger of fire and
explosion.
–
Protect the battery pack from excessive heat or
constant heat sources such as sunlight or naked
flames.
There is a risk of explosion.
–
Never use water to extinguish burning li-ion
battery packs, always use sand
or a fire blanket.
– Deformed or cracked saw blades and saw blades
with blunt or broken cutting edges must not be
used.
– Always place the pendulum jigsaw on the work-
piece with the saw blade running.
– Wear suitable protection such as ear protection,
safety goggles, a dust mask for work which gen-
Charger TRC 3
Mains voltage (input) 220 - 240 V ~
Mains frequency 50/60 Hz
Charging voltage (output) 7.2 - 18 V=
Rapid charging max. 3 A
Conservation charging current, pulsating (only NiCd, NiHM) approx. 0.06 A
Charging times for LiIon 1.5 Ah/ 3.0 Ah, 80 % approx. 25/ 55 min
LiIon 1.5 Ah/ 3.0 Ah, 100 % approx. 35/ 70 min
Permitted charging temperature range -5 °C to +45 °C
Temperature monitoring via NTC resistor
Battery pack BPS 15 Li BPC 15 Li BPC 18 Li
Voltage 14,4 V 14.4 V 18 V
Capacity 2,6 Ah 3.0 Ah 2,6 Ah/ 3.0 Ah
Weight 0,58 kg 0,55 kg 0,67 kg
16
C A R V E X
GB
erates dust, and protective gloves when working
with raw materials and when changing tools.
– Always secure the workpiece in such a manner
that it cannot move while being sawed.
– Always connect the machine to a dust extractor
when work involves dust generation.
–
Stroboscopic light can cause epileptic seizures.
Do not use this machine if you are susceptible to
epileptic seizures.
– Do not look into the stroboscope light. Looking
into the light source can damage your vision.
5.3 Metal processing
When processing metal, the following measures must be taken for safety reasons:
–Connect the machine to a suitable dust ex-
tractor.
– Regularly remove dust deposits in the motor
housing.
– Use a metal saw blade.
– Close the chip guard.
5.4 Emission levels
Levels determined in accordance with EN 60745 are
typically:
Vibration emission value ah (vector sum for three
directions) and uncertainty K measured in accordance with EN 60745:
The specified emissions values (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary esti-
mates regarding vibration and noise loads during
operation.
– They represent the primary applications of the
power tool.
Increase possible for other applications, with other
insertion tools or if not maintained adequately. Take
note of idling and downtimes of machine!
6Operation
6.1 Changing the battery pack [2]
The cordless jigsaws can be charged using any
Festool battery pack from the
BPC
series.
Risk of injury!
Always remove the belt clip
from battery packs from the BPC series prior to use.
6.2 Switch on/off
The electric power tool has one button
[1-2]
on
each side for switching on/off.
The PSBC 420 EB also has a variable speed trigger
[1-3]
with switch lock
[1-4]
. For continuous opera-
tion, use the button
[1-2]
.
6.3 Charging the battery pack [3]
The battery pack is delivered partially charged.
To guarantee the full battery power, charge it
completely before using it for the first time.
The charger can be used to charge all Festool battery packs from the BPS and BPC series as well as
all Protool battery packs from the BP series.
The LED
[3-1]
on the charger indicates the respec-
tive operating status of the charger.
Wear protective goggles.
Sound pressure level LPA = 88 dB(A)
Noise level LWA = 99 dB(A)
Measuring uncertainty allow-
ance
K = 3 dB
CAUTION
Operating noise
Damage to hearing
Use ear protection!
PSC 420 EB PSBC 420 EB
Sawing wood
Handle ah=6,0 m/s
2
ah=10,0 m/s
2
K = 2,0 m/s
2
K = 2,0 m/s
2
Gear head ah=11,0 m/s
2
K = 2,0 m/s
2
Sawing metal
Handle ah=7,0 m/s
2
ah=11,0 m/s
2
K = 2,0 m/s
2
K = 2,0 m/s
2
Gear head ah=12,0 m/s
2
K = 2,0 m/s
2
LED yellow - lit continuously
Charger is ready to use.
C A R V E X
17
GB
6.4 Charger wall mount
The charger TRC 3 has two elongated holes on its
back. It can be mounted on a wall using two screws
(e.g. round head or flat head screw with shank diameter of 5 mm) (see Fig.
[3]
).
7 Settings
7.1 Changing tools
Selecting saw blade
Only use saw blades with a T-shank. The
saw blade should not be longer than that re-
quired for the intended cut. To ensure safe
guidance, during the cut the saw blade should
emerge at the bottom of the workpiece at every
point.
Only use cross-set saw blades when using the
angle and adapter table. We recommend Festool saw blade S 105/4 FSG.
Inserting saw blade
Always disconnect the battery pack from the
machine before every tool change!
If necessary, lift up the chip guard
[4-1]
.
Slide the saw blade
[4-4]
into the opening
[4-2]
as far as the stop with its teeth in the cutting direction.
Turn the saw blade
[4-4]
clockwise approx. 30°.
Check that the saw blade is secure. A loose
saw blade can fall out and cause an injury.
If the saw blade is very small, it is advisable to remove the saw base (see chapter 7.4)
before inserting the saw blade.
Adjust the saw blade guide after every saw blade
change:
The saw blade guide was designed to improve guidance of the saw blade.
Remove the saw base (see chapter 7.4).
Tighten the screw
[4-6]
using the Allen key
[4-
5]
until the jaws are
almost
touching the saw
blade.
Ejecting saw blade
When ejecting the saw blade, hold the electric
power tool such that no persons or animals can
be injured.
Push the saw blade ejection
[4-3]
forwards as
far as the stop.
A tool change is only possible when the tool
holder is located in the upper position!
If the saw blade is stuck and cannot be changed:
Operate the jigsaw at high speed for 3 - 10 seconds.
Actuate the saw blade ejection
[4-3]
again.
7.2 Using the chip guard
The chip guard
[4-1]
prevents chips flying away and
improves the efficiency of the chip extraction system.
Using minimal pressure, push the chip guard
[4-1]
downwards.
LED green - flashing quickly
Battery pack is charged to maximum capacity.
LED green - flashing slowly
Battery pack is charged with
reduced current. Li-ion is
charged to 80 %.
LED green - lit continuously
Charging process has finished or
will not resume because the current charging state is more than
80%.
LED red - flashing
General fault indicator, e.g.
incomplete contact, short circuit,
defective battery pack, etc.
LED red - lit continuously
Battery temperature is outside
the permitted range.
WARNING
Risk of injury, electric shock
Always disconnect the battery pack before any
type of work on the machine!
CAUTION
Hot and sharp tools
Risk of injury
Wear protective gloves.
NOTE
Damage to the machine or saw blade
Do not tighten the screw [4-6] too firmly! It must
be possible to move the saw blade slightly.
18
C A R V E X
GB
7.3 Inserting the splinterguard
The splinterguard prevents the edges of the material from splintering during the cut, even at the end
where the saw blade exits the material.
Switch off the machine and slide the splinterguard
[5-1]
into the guide
[5-2]
and up to the
saw blade,
Switch on the jigsaw,
On a level surface, slide in the splinterguard
(not using your hand!)
while the machine is operating until it is flush with the front edge of the
saw base (speed setting 5). This beds in the
splinterguard.
When it is worn, push the splinterguard approx.
3 mm further to the rear and continue using it.
To guarantee reliable operation of the splinterguard, it must seal tightly on both sides of the
saw blade. A new splinterguard should therefore be fitted after every saw blade change to
guarantee splinter-free cuts.
7.4 Changing saw table
Open the change lever
[1-8]
.
Removing the saw table downwards.
Assembly is performed in reverse sequence to
removal. Ensure that the saw table is firmly
seated in the guide.
Instead of the saw table, the angle table WT-PS 400
or adaptation table ADT-PS 400 can be installed at
the support.
Never saw without the saw table, or one of
the other tables offered in the Festool accessories program.
7.5 Dust extraction
The extraction adapter
[6-3]
allows jigsaws to be
connected to a dust extractor (hose diameter 27
mm).
Insert the extraction adapter into the rear opening of the saw table so that the hook
[6-2]
en-
gages in the
[6-1]
recess.
To remove the extraction adapter, press the
hook
[6-2]
.
Due to the low power consumption of the machine (low energy consumption), dust extractors
with an automatic switch-on function will sometimes only start up when the actual cut is made.
Set the dust extractor to continuous operation
for special applications (e.g. low stroke rate,
soft wood).
7.6 Adjusting the pendulum stroke
The pendulum stroke on pendulum jigsaws can be
adjusted to machine different materials with the
correct rate of advance. Select the required setting
using the pendulum stroke switch
[1-11]
:
Position 0 = pendulum stroke off
Position 3 = maximum pendulum stroke
7.7 Stroke speed control
The number of strokes can be adjusted steplessly
with the adjusting wheel
[1-5]
between 1500 and
3800 rpm (PSBC 420 EB: 1000 - 3800 rpm). This enables you to optimise the cutting speed to suit the
respective material.
In position A, the automatic load detection is activated: The stroke speed is reduced in idling and is
controlled to the highest value when the blade enters the workpiece.
8 Working with the machine
WARNING
Dust hazard
Dust can be hazardous to health. Always work
with a dust extractor.
Always read applicable national regulations before extracting hazardous dust.
Recommended pendulum stroke setting
Softwood, chip board, wood fibreboard 1 - 3
Blockboard, plywood, plastic 1 - 2
Ceramics 0
Aluminium, non-ferrous metals 0 - 2
Steel, hardwood 0 - 1
Recommended stroke speed (position of the
adjusting wheel)
Hard and soft wood, plywood board, plywood, chip board
A
Hardboard 4 - A
Plastic 3 - A
Ceramic, aluminium, non-ferrous metals 3 - 5
Steel 2 - 4
CAUTION
Material with high dust generation (e.g. plasterboard)
Damage to machine through dust penetration,
risk of injury
Do not work overhead!
C A R V E X
19
GB
When working on small or thin workpieces, always
use a stable base, or the CMS module (accessory).
When working, hold the electric power tool by the
handle and guide it along the desired cutting line.
For precise cuts and smooth running, use two
hands to guide the electric power tool.
Free saw guidance along a scribe mark
The triangular pointer on the splinterguard
[5-1]
indicates the cutting line of the saw blade. This facilitates sawing along a scribe mark.
8.1 Lighting
A continuous light or stroboscope is installed for illuminating the cutting line:
up to approx. 2100 rpm: continuous light
from approx. 2100 rpm: stroboscope light
In overhead position (+/- 45°), the lighting is
switched off completely.
If required, you can adjust the lighting:
Plug in the electric power tool.
Press both buttons simultaneously
[1-2]
and
hold for approx. 10 s until a beep sounds.
Release both buttons
[1-2]
.
Press the left button (on the pendulum stroke
side) to select the stroke speed and consequently the desired operating mode:
Press the right button to save the setting.
8.2 Acoustic warning signals
Acoustic warning signals sound and the machine
switches off in the following operating states:
9 Service and maintenance
Customer service and repair
only
through manufacturer or service
workshops: Please find the nearest
address at:
www.festool.com/Service
Use only original Festool spare parts!
Order No. at:
www.festool.com/Service
Damaged safety devices and components must be
repaired or replaced in a recognised specialist
workshop, unless otherwise indicated in the operating manual.
Observe the following instructions:
– Keep the air slits on the machine and the charger
free and clean to ensure adequate cooling.
– Keep the contacts on the machine, charger and
battery pack clean.
– Check the guidance roller regularly for wear.
– Regularly remove dust deposits from the chip
guard.
– Regularly clean the base runner to prevent
scratches and cores on the surface.
WARNING
The stroboscope light may make it difficult to determine the saw blade position
Risk of injury
Ensure the work area is well illuminated.
Mode Indication during
configuration
Behaviour
during operation
1 Light flashes With stroboscope
(standard)
2 Light on Permanent light
without stroboscope
3 Light off Light switched off
Battery flat or machine overloaded.
– Change the battery.
– Place the machine under reduced
stress.
Machine is overheating.
– You must allow the machine to
cool before using again.
LiIon battery pack is faulty or has
overheated.
– Once the battery pack has cooled,
perform a functional check using
the charger.
WARNING
Risk of injury, electric shock
Always disconnect the battery pack from the
machine before any maintenance or care work!
All maintenance and repair work which requires
the motor housing to be opened, must only be
carried out by an authorised service workshop.
EKAT
1
2
3
5
4
20
C A R V E X
GB
Information on battery packs
– Where possible, store the battery pack in a cool,
dry place at a temperature between 5 °C and 25
°C.
– Battery packs are most efficient at temperatures
between 20 °C and 30 °C.
– Protect the battery pack from moisture, water
and heat.
– Significantly shorter operating times after each
charge indicate that the battery pack is worn and
should be replaced with a new one.
– The LiIon battery pack is fully compatible with the
charger! Integrated electronics prevent overloading and overheating during the charging process.
– Do not leave flat battery packs in a charger dis-
connected from the mains power supply for longer than one month. There is a risk of total
discharge and the maximum power of the battery
pack may decrease.
– Store the battery pack in its packaging to reduce
the risk of short circuits..
– If LiIon battery packs are to be stored for long pe-
riods without use, they should be charged to 40 %
capacity (approx. 15 mins. charging period).
10 Accessories
The order numbers of the accessories and tools can
be found in the Festool catalogue or on the Internet
under "www.festool.com".
10.1 Saw blades, other accessories
In order to saw different materials quickly and
cleanly, Festool offers saw blades for all applications that are specially designed for your Festool
jigsaw.
10.2 Sawing with special base runners
The special base runners protect high-quality surfaces against scratches and scores.
Press in the base runner at position
[7-1]
.
At the same time, push the base runner forwards.
Mount another base runner and push it to the
rear until it engages.
10.3 Sawing with the angle table
The angle table WT-PS 400 is used for cutting pipes
or interior and exterior angles up to 45°.
Dust extraction is not possible when sawing
with the angle table!
Installing the angle table
Remove the saw base
[1-10]
, (see chapter 7.4).
Position the angle table against the saw base
support.
Close the lever
[1-8]
.
Ensure that the angle table is firmly seated in the
guide.
Setting the angle
Turn the adjusting wheel
[8-1]
to select the re-
quired angle.
You can select the angles -45°, 0° and +45° on the
scale
[8-2]
.
For 90° cuts, we recommend setting the angle
table to a small negative angle to guarantee
smooth operation.
10.4 Sawing with the adaptation table
The adaptation table ADT-PS 400 is used for fitting
your jigsaw on the Festool guide rail and the circle
cutter KS-PS 400.
With guide rail and circle cutter:
do not exceed max. material thickness of 20 mm and
always use cross-set saw blades (FSG).
Installing the adaptation table
Remove the saw table
[1-10]
, (see chapter 7.4).
Mount the adaptation table
[9-1]
on the saw ta-
ble support.
Close the change lever
[1-8]
.
Ensure that the adaptation table is firmly seated in
the guide.
Use the extractor connector
[1-7]
also with the
adaptation table.
Adaptation to the guide rail FS 2
The Festool guide system FS 2 (Fig.
[10]
) makes it
much easier to manufacture straight precision
cuts.
Place the jigsaw with attached adaptation table
[9-1]
on the guide rail.
Adaptation to the circle cutter
The circle cutter can be used to create circular cuts
with a diameter between 120 and 3000 mm. The circle cutter can be installed from both sides on the
adaptation table.
WARNING
Sawing cutting depths
Risk of injury
Select the saw blade length and cutting depth so
that the saw blade remains plunged in the workpiece.
C A R V E X
21
GB
Place the jigsaw with attached adaptation table
on the adapter
[11-1]
on the circle cutter.
Insert the centring mandrel
[11-2]
in the hole
[11-4]
on the circle cutter aligned with the saw
blade.
Clamp the measuring tape to the circle cutter
using the rotary knob
[11-5]
.
Recommended when using the circle cutter:
Cut in an anticlockwise direction.
Work at a slow rate of advance.
Set the pendulum stroke
[1-11]
to 0 - 1.
Set the stroke rate
[1-5]
to 1 - 5.
Store the centring mandrel in the depot
[11-3]
.
11 Transport
The equivalent amount of lithium in the LiIon battery pack is less than the applicable limit value and
certified as per UN manual ST/SG/ AC.10/11/rev. 3
part III, subsection 38.3. The LiIon battery pack is
therefore not subject to national and international
dangerous goods regulations, neither as an individual component nor as a fitted machine component.
However, dangerous goods regulations may apply
when several battery packs are transported, in
which case you may have to fulfil special conditions.
Refer to ADR special regulation 230 for more information relevant for the EU.
12 Environment
Do not dispose of the device in household waste!
Recycle devices, accessories and packaging. Observe applicable country-specific regulations.
EU only:
European Directive 2002/96/
EC stipulates that used electric power tools must
be collected separately and disposed of at an environmentally responsible recycling centre.
Return
used or faulty battery packs
to your local
specialist retailer, Festool after-sales service or a
designated public waste management facility. The
battery packs will then be recycled. (Observe the
regulations applicable in your country). The batteries must be discharged on return.
EU only:
European Directive 91/157/EEC stipulates
that faulty or used battery packs/batteries must be
recycled.
Information on REACh:
www.festool.com/reach
13 EU Declaration of Conformity
We declare under sole responsibility that this product complies with the following directives and standards:
2006/42/EC, 2004/108/EC, 2011/65/EU, EN 607451, EN EN 60745-2-11, EN 55014-1, EN 55014-2.
We declare under sole responsibility that this product complies with the following directives and standards:
2004/108/EC, 2006/95/EC, 2011/65/EU, EN 603351, EN 60335-2-29, EN 61000-3-2, EN 61000-3-3, EN
61204-3.
Festool Group GmbH & Co. KG
Wertstr. 20, D-73240 Wendlingen, Germany
Dr. Martin Zimmer
Head of Research, Development and Technical
Documentation
01.02.2013
Cordless jigsaw Serial no.
PSBC 420 EB 10003824
PSC 420 EB 10003823, 10005015
Year of CE mark: 2012
Charger Serial no.
TRC 3 494635, 494636, 494637
Year of CE mark: 2007
Loading...
