Fagor MW3 245GEX User Manual
45
Contents
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
General description . . . . . . . . . . . . . . . . . . . . . . . . .48
The control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Setting the clock / Microwave power settings . . . . . . . . . . .50
The display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
The selector knobs / Programming . . . . . . . . . . . . . . .52
Microwave programming . . . . . . . . . . . . . . . . . . . . . .53
The Duo Function . . . . . . . . . . . . . . . . . . . . . . . . . . .54
The grilling racks* . . . . . . . . . . . . . . . . . . . . . . . . . .56
The grill function* / Programming the grill* . . . . . . . . .57
The microwave + grill function / Programming* . . . . . . . . .58
The fan functions* . . . . . . . . . . . . . . . . . . . . . . . . . .59
Programming the fan function* . . . . . . . . . . . . . . . . .60
Programming the fan + microwave function* . . . . . . . .61
Security / Child lock / Recommendations . . . . . . . . . . .62
Care & cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . .64
After Sales Service . . . . . . . . . . . . . . . . . . . . . . . . . .65
*for certain models
Important safety instructions.
Read carefully and keep for future reference.
46
Installation
**For full-built in model
MW3-309 CEX
refer to the installation instructions furnished
with the microwave oven.
Leave sufficient space around the oven :
- 5 cm between the sides of the oven
and any walls or objects
- 14 cm above the oven
- 10 cm behind the oven.
LOCATION
BEFORE CONNECTION
•
The oven must be set on a work surface at least 85 cm above floor level.
•
Place the oven on a flat and horizontal surface, away from any source of heat or
steam. To ensure the stability of the microwave oven, the front left foot is
adjustable (5 positions). Turn it to raise or lower the appliance.
•
Make sure that air may circulate freely around the oven.
•
Allow nothing to obstruct the ventilation
louvers at the back of the appliance.
•
Make sure the electrical plug will be accessible after installation.
•
Check whether your oven has suffered any damage during transport (deformed door or
door seal, etc.). If you see any signs of damage, contact your dealer before use.
•
Verify the power voltage. If there is a PERMANENT undervoltage (200-210 volts), consult your
electrical installer.
•
Your installation must be protected by a 16 Amp thermal fuse.
•
It is mandatory to use a power point with a ground terminal, connected in accordance with
current safety regulations.
•
In your electrical installation, provide a device that is accessible to the installer, capable of
separating the appliance from the mains power and whose contact opening is at least 3 mm
at all of the poles.
•
Never operate the oven if the supply cord and/ or its plug are damaged. In case of damage,
call in a specialised technician trained by the manufacturer.
ELECTRICAL CONNECTION
5 cm
14 cm
10 cm
5 cm
47
Warning
• Your appliance is designed exclusively for the domestic purposes of defrosting, heating or
cooking foods. The manufacturer bears no responsibility in the case of improper usage.
• Only use ustensils that are suitable for use in microwave ovens.
• To avoid deterioration of your microwave oven, never operate it empty or without the
turntable.
• Never tamper with the lock mechanism of your microwave oven; you could cause damage
requiring repair by an authorised technician.
• When heating food in plastic or paper containers, keep an eye on the oven due to the
possibility of ignition.
• It is not advisable to use metal recipients, forks, spoons, knives, metal ties or staples for
deep-freeze bags.
• The contents of feeding bottles are baby food jars shall be stirred or shaken and the
temperature checked before consumption in order to avoid burns.
• Only allow children to use the oven without supervision when adequate instructions
have been given so that the child is able to use the oven in a safe way and understands
the hazards of improper use.
• Liquids and other foods must not be heated in sealed containers they are liable to explode.
• Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens
since they may explode, even after microwave heating has ended.
• Microwave heating of beverages can result in delayed eruptive boiling, therefore care
must be taken when handling the container.
• For small amounts (one sausage, a single croissant, etc.), place a glass of water alongside the food item.
• Time settings that are too long may dry out and burn the food. To avoid such incidents,
never use the same cooking times as those recommended for traditional ovens.
• If smoke is observed, switch off or unplug the appliance and keep the door closed in
order to stifle any flames.
• In order to evacuate moisture, your appliance is fitted with a delayed ventilation function. Depending on the applied cooking mode (solo/grill/combination), the oven ventilation will continue to operate after the cooking end.
48
AUTO
M
/
C
General description
•
THE TURNTABLE :
ensures equal cooking of food throughout with no need to stir or turn the dish.
- It may be used as a cooking platter.
- Rotation is controlled by the drive shaft and the wheel support.
- The turntable revolves in both directions.
- If it does not turn, verify that all components are properly positioned.
- For easy removal, wells are provided on either side.
•
TURNTABLE OFF :
stops the turntable from revolving in order to use platters which require the entire oven
space.
•
THE WHEEL SUPPORT :
Do not try to rotate the roller ring manually, as you could damage the drive system. If
it does not turn smoothly, make sure that there is nothing in the well beneath the turn-
table.
TurntableDrive shaft Wheel
upport
Identification
label
49
A Display window :
to simplify programming, the display indicates : the time of day, the types of food and
fucntions, the the minutes / seconds or
weight programmed .
B The selector knob :
to choose the food type or function.
C The selector knob :
to choose the programme time or weight.
D-E-F The “AUTO” keys :
automatically set the appropriate prograame
time according to the weight and the selected food type.
G The MODE key M:
to choose the appropriate function, with
the selector knob .
H The HOT AIR key *: to cook as if with
a traditional oven, with or without microwave power.
The GRIL key *:
to directly programme the grill function.
I The DUO key :
for dual level reheating; to be used with the
steam effect plate stackers.
J The PAUSE/CANCEL key :
to interrupt (press once) or cancel a programme (press twice).
Also used to set the clock.
K
STOP-TURNTABLE key :
to stop the turntable from revolving.
L START key :
to start all programmes.
M DOOR OPEN button :
press this button to open the door or
stop the appliance.
The control panel
B
G
F
A
K
D
E
C
H
J
I
/
1 2 : 3 0
2 0 0 ° C
L
M
*according to model
/
M
C
50
POWER SETTING APPLICATION
Microwave power settings
DEFROST
To defrost all frozen food or to top off cooking of
delicate dishes or to cook very slowly.
SIMMER
To finish programmes begun with the HIGH
COOK power setting, for instance beans,
lentils, ordairy products.
(This power setiing is available when you program-
me the function using the mode M key.)
HEAT
To heat up all liquids and all fresh or frozen
pre-cooked dishes.
HIGH COOK
To cook vegetables, fish, poultry and soup.
When you select the type of food, the appropriate
power setting is automatically programmed.
Microwave output power : 900 W
After first plugging in your microwave oven or after a power outage,
the clock reads 00:00and the two dots flash.
To set the clock :
- Press the PAUSE / CANCEL key for 5 seconds.
"00:00" flashes, and a tone sounds requesting the hour be set.
- Turn the selector knob to display the correct time.
- Validate by pressing the PAUSE / CANCEL key .
Your clock is set.
00:00
12:00
00:00
Setting the clock
51
*
12:30
*for certain models
The display and the selector knobs guide you in your choice of :
les aliments
the functions
DEFROST SIMMER REHEAT COOK
DUO MICROWAVE FAN HEAT* FAN HEAT
+ GRILL* + MICROWAVE*
the 2 level grill*
LOW GRILL HIGH GRILL
the weight for an AUTO programme
the length of the programme (or time of day)
The food type or function being selected will flash in the display.
12:00
beverages
beef,
lamb
vegetables
poultry
frozen
ready-
made
dishes
fresh
ready-
made
dishes
pork,
veal
fish
turkey
The display
200° C
*
*
*
*
