Epson WorkForce WF-2810 User Manual

Download

User's Guide

NPD6101-00 EN

User's Guide

Contents

About This Manual

Introduction to the Manuals...................7

Using the Manual to Search for Information. . . . . . . 7

Marks and Symbols.........................8

Descriptions Used in this Manual...............9

Operating System References..................9

Important Instructions

Safety Instructions.........................10

Safety Instructions for Ink................. 10

Printer Advisories and Warnings.............. 11

Advisories and Warnings for Setting Up the

Printer................................11

Advisories and Warnings for Using the Printer. . 11 Advisories and Warnings for Transporting or

Storing the Printer.......................12

Advisories and Warnings for Using the

Printer with a Wireless Connection...........12

Advisories and Warnings for Using the LCD

Screen................................12

Protecting Your Personal Information...........12

Printer Basics

Part Names and Functions...................13

Guide to the Control Panel...................15

Control Panel.......................... 15

Guide to the Home Screen.................16

Entering Characters......................17

Viewing Animations......................17

Network Settings

Network Connection Types.................. 19

Wi-Fi Connection....................... 19

Wi-Fi Direct (Simple AP) Connection.........19

Connecting to a Computer...................20

Connecting to a Smart Device................ 21

Connecting to a smart device over a wireless

router................................21

Connecting to an iPhone, iPad, or iPod touch

using Wi-Fi Direct.......................21

Connecting to Android Devices using Wi-Fi

Direct................................25

Connecting to Devices other than iOS and

Android using Wi-Fi Direct................ 27

Making Wi-Fi Settings from the Printer..........30

Making Wi-Fi Settings by Entering the SSID

and Password...........................30

Making Wi-Fi Settings by Push Button Setup. . . . 31

Making Wi-Fi Settings by PIN Code Setup

(WPS)................................32

Checking the Network Connection Status........33

Network Icon...........................33

Printing a Network Connection Report........33

Printing a Network Status Sheet...............39

Replacing or Adding New Wireless Routers.......39

Changing the Connection Method to a Computer. . 40

Changing the Wi-Fi Direct (Simple AP) Settings. . . 40

Disabling Wi-Fi from the Control Panel..........41

Disconnecting Wi-Fi Direct (Simple AP)

Connection from the Control Panel............ 42

Restoring the Network Settings from the

Control Panel............................ 42

Preparing the Printer

Loading Papers........................... 43

Available Paper and Capacities..............43

Loading Paper in the Rear Paper Feed.........46

Loading Envelopes and Precautions.......... 48

Loading Long Papers.....................49

List of Paper Type....................... 49

Placing Originals..........................49

Placing Originals on the Scanner Glass. . . . . . . . 49

Managing Contacts........................51

Registering or Editing Contacts............. 51

Registering or Editing Grouped Contacts. . . . . . 52

Menu Options for Settings...................53

Menu Options for Supply Status.............53

Menu Options for Maintenance............. 54

Menu Options for Printer Setup.............54

Menu Options for Network Settings..........57

Menu Options for Epson Connect Services. . . . . 57

Menu Options for Google Cloud Print Services. . 58

Menu Options for Contacts Manager......... 58

Menu Options for Fax Settings..............59

Menu Options for Print Status Sheet..........59

Menu Options for Print Counter.............59

Menu Options for Customer Research.........59

Menu Options for Restore Default Settings. . . . . 60

Menu Options for Firmware Update..........60

User's Guide

Contents

Saving Power.............................60

Saving Power - Control Panel...............60

Fax Settings

Before Using Fax Features....................62

Connecting to a Phone Line..................62

Compatible Telephone Lines................62

Connecting the Printer to a Phone Line........63

Connecting Your Phone Device to the Printer. . . 64

Making the Printer Ready to Send and Receive

Faxes (Using Fax Setting Wizard)..............65

Making Settings Individually for Printer's Fax

Features.................................67

Setting Receive Mode.....................67

Making Settings When You Connect an

External Phone Device....................69

Making Settings for Blocking Junk Faxes.......70

Making Settings to Send and Receive Faxes

on a Computer..........................70

Menu Options for Fax Settings................71

Check Fax Connection....................71

Fax Setting Wizard.......................72

Basic Settings Menu......................72

Receive Settings Menu....................73

Report Settings Menu.....................74

Security Settings Menu....................75

User Default Settings Menu................ 75

Printing

Printing from the Printer Driver on Windows. . . . . 76

Accessing the Printer Driver................76

Printing Basics..........................76

Printing on 2-Sides.......................78

Printing Several Pages on One Sheet..........79

Printing and Stacking in Page Order (Reverse

Order Printing).........................80

Printing a Reduced or Enlarged Document. . . . . 80

Printing One Image on Multiple Sheets for

Enlargement (Creating a Poster).............81

Printing with a Header and Footer........... 87

Printing a Watermark.....................88

Printing Multiple Files Together.............89

Printing Using the Color Universal Print

Feature...............................89

Adjusting the Print Color..................90

Printing to Emphasize in Lines............91

Printing Clear Bar Codes..................91

Canceling Printing.......................92

Menu Options for the Printer Driver..........92

Printing from the Printer Driver on Mac OS......94

Printing Basics..........................94

Printing on 2-Sides.......................96

Printing Several Pages on One Sheet..........97

Printing and Stacking in Page Order (Reverse

Order Printing).........................97

Printing a Reduced or Enlarged Document.....98

Adjusting the Print Color..................99

Canceling Printing.......................99

Menu Options for the Printer Driver..........99

Making Operation Settings for the Mac OS

Printer Driver......................... 101

Printing from Smart Devices.................102

Using Epson iPrint......................102

Using Epson Print Enabler................103

Using AirPrint.........................104

Canceling the Ongoing Job..................105

Copying

Copying................................106

Copying on 2-Sides....................... 107

Copying Multiple Originals onto One Sheet. . . . . .107

Menu Options for Copying..................107

Scanning

Scanning Using the Control Panel.............110

Scanning to a Computer..................110

Scanning Using WSD....................114

Scanning from a Computer..................116

Scanning Using Epson Scan 2..............116

Scanning from Smart Devices................119

Installing Epson iPrint...................119

Scanning Using Epson iPrint...............119

Faxing

Before Using Fax Features...................121

Sending Faxes Using the Printer..............121

Sending Faxes Using the Control Panel.......121

Various Ways of Sending Faxes.............123

Receiving Faxes on the Printer............... 125

Receiving Incoming Faxes.................125

Receiving Faxes by Making a Phone Call......127

Menu Options for Faxing...................128

Fax.................................128

Scan Settings..........................128

Fax Send Settings.......................128

More................................129

User's Guide

Contents

Contacts Manager......................130

Sending a Fax from a Computer..............130

Sending Documents Created Using an

Application (Windows)...................130

Sending Documents Created Using an

Application (Mac OS)....................133

Receiving Faxes on a Computer...............134

Saving Incoming Faxes on a Computer.......134

Canceling the Feature that Saves Incoming

Faxes to the Computer...................135

Checking for New Faxes (Windows)......... 135

Checking for New Faxes (Mac OS)..........136

Using Other Faxing Features.................137

Printing Fax Report Manually..............137

Replacing Ink Cartridges and Other Consumables

Checking the Status of the Remaining Ink and

the Maintenance Box......................138

Checking the Status of the Remaining Ink

and the Maintenance Box - Control Panel. . . . . 138

Checking the Status of the Remaining Ink

and the Maintenance Box - Windows.........138

Checking the Status of the Remaining Ink

and the Maintenance Box - Mac OS X........138

Ink Cartridge Codes.......................139

Ink Cartridge Handling Precautions...........140

Replacing Ink Cartridges................... 142

Maintenance Box Code.....................142

Maintenance Box Handling Precautions. . . . . . . . 143

Replacing a Maintenance Box................143

Temporarily Printing with Black Ink...........144

Temporarily Printing with Black Ink -

Control Panel..........................145

Temporarily Printing with Black Ink - Windows 145 Temporarily Printing with Black Ink - Mac OS. .146

Conserving Black Ink when the Black Ink Is

Low (for Windows Only)................... 147

Maintaining the Printer

Preventing the Print Head from Drying.........149

Checking and Cleaning the Print Head.........149

Checking and Cleaning the Print Head -

Control Panel..........................149

Checking and Cleaning the Print Head -

Windows.............................150

Checking and Cleaning the Print Head - Mac

OS..................................150

Aligning the Print Head....................151

Aligning the Print Head - Control Panel. . . . . . 151

Cleaning the Paper Path for Ink Smears.........151

Cleaning the Scanner Glass..................152

Cleaning the Translucent Film............... 152

Network Service and Software Information

Application for Conguring Printer Operations

(Web Cong)............................155

Running Web Cong on a Web Browser. . . . . . 155

Running Web Cong on Windows.......... 156

Running Web Cong on Mac OS............156

Application for Scanning Documents and

Images (Epson Scan 2).....................156

Adding the Network Scanner..............157

Application for Conguring Scanning Operations from the Control Panel (Epson

Event Manager)..........................158

Application for

Sending Faxes (FAX Utility).................158

Application for Sending Faxes (PC-FAX Driver). . 159

Application for Printing Images (Epson Photo+). . 159

Soware Update Tools (EPSON Soware

Updater)...............................160

Application for Conguring Multiple Devices

(EpsonNet Cong)........................161

Installing the Latest Applications..............161

Updating Applications and Firmware.......... 162

Uninstalling Applications...................163

Uninstalling Applications - Windows.........163

Uninstalling Applications - Mac OS..........164

Printing Using a Network Service.............164

Conguring

Fax Operations and

Solving Problems

Checking the Printer Status..................166

Checking Error Codes on the LCD Screen. . . . . 166

Checking the Printer Status - Windows.......167

Checking the Printer Status - Mac OS........167

Checking the Soware Status. . . . . . . . . . . . . . . . 168

Removing Jammed Paper...................168

Removing Jammed Paper from the Rear

Paper Feed............................168

Removing Jammed Paper from Inside the

Printer...............................168

Removing Jammed Paper from Rear Cover. . . . 170

Paper Does Not Feed Correctly...............171

User's Guide

Contents

Paper Jams............................171

Paper Feeds at a Slant....................172

Several Sheets of Paper are Fed at a Time. . . . . . 172

Paper Out Error Occurs..................172

Paper is Ejected During Printing............172

Power and Control Panel Problems............172

Power Does Not Turn On.................172

Power Does Not Turn O.................172

Power Turns O Automatically.............172

LCD Screen Gets Dark...................173

Cannot Print from a Computer...............173

Checking the Connection (USB)............173

Checking the Connection (Network).........173

Checking the Soware and Data. . . . . . . . . . . . 174

Checking the Printer Status from the

Computer (Windows)....................176

Checking the Printer Status from the

Computer (Mac OS).....................176

When You Cannot Make Network Settings......177

Cannot Connect from Devices Even ough

Network Settings are No Problems.......... 177

Checking the SSID Connected to the Printer. . . 179

Checking the SSID for the Computer.........179

Wireless LAN (Wi-Fi) Connections Become Unstable When Using USB 3.0 Devices on a

Mac.................................180

Cannot Print from an iPhone, iPad, or iPod touch. 180

Printout Problems........................181

Printout is Scued or Color is Missing........181

Banding or Unexpected Colors Appear.......181

Colored Banding Appears at Intervals of

Approximately 2.5 cm....................181

Blurry Prints, Vertical Banding, or

Misalignment..........................182

Print Quality is Poor.....................182

Paper Is Smeared or Paper is Smeared During Automatic 2-Sided

Printing..............................184

Printed Photos are Sticky.................184

Images or Photos are Printed in Unexpected

Colors...............................184

Cannot Print Without Margins.............184

Edges of the Image are Cropped During

Borderless Printing......................185

e Position, Size, or Margins of the Printout

Are Incorrect..........................185

Printed Characters Are Incorrect or Garbled. . . 185

e Printed Image Is Inverted..............186

Mosaic-Like Patterns in the Prints...........186

Uneven Colors, Smears, Dots, or Straight

Lines Appear in the Copied Image...........186

Scued

...............183

Moiré (Cross-Hatch) Patterns Appear in the

Copied Image......................... 186

An Image of the Reverse Side of the Original

Appears in the Copied Image..............186

e Printout Problem Could Not be Cleared. . . 187

Other Printing Problems................... 187

Printing Is Too Slow.....................187

Printing or Copying Slows Down Dramatically During Continuous Operation. . . 187

Cannot Cancel Printing from a Computer

Running Mac OS X v10.6.8................188

Cannot Start Scanning.....................188

Cannot Start Scanning when Using the

Control Panel..........................188

Scanned Image Problems...................189

Uneven Colors, Dirt, Spots, and so on Appear

when Scanning from the Scanner Glass.......189

e Image Quality Is Rough...............189

Oset Appears in the Background of Images. . . 189

Text is Blurred.........................189

Moiré Patterns (Web-Like Shadows) Appear. . . 190 Cannot Scan the Correct Area on the

Scanner Glass..........................190

Text is Not Recognized Correctly when

Saving as a Searchable PDF................190

Cannot Solve Problems in the Scanned Image. . 191

Other Scanning Problems...................192

Scanning Is Too Slow....................192

Scanning Slows Down Dramatically During

Continuous Scanning....................192

Scanning Stops when Scanning to PDF/

Multi-TIFF........................... 192

Problems when Sending and Receiving Faxes. . . . .192

Cannot Send or Receive Faxes..............193

Cannot Send Faxes......................194

Cannot Send Faxes to a Specic Recipient. . . . . 194

Cannot Send Faxes at a Specied Time....... 194

Cannot Receive Faxes....................195

Memory Full Error Occurs................195

Sent Fax Quality Is Poor..................195

Faxes Are Sent at the Wrong Size............196

Received Fax Quality Is Poor...............196

Received Faxes Are Not Printed............ 196

Pages are Blank or only a Small Amount of Text is Printed on the Second Page in

Received Faxes.........................196

Other Faxing Problems.....................197

Cannot Make Calls on the Connected

Telephone............................197

Answering Machine Cannot Answer Voice

Calls................................197

User's Guide

Contents

Sender's Fax Number Not Displayed on

Received Faxes or the Number Is Wrong......197

Other Problems..........................197

Slight Electric Shock when Touching the

Printer...............................197

Operation Sounds Are Loud...............197

e Date and Time Are Incorrect...........197

Application Is Blocked by a Firewall (for

Windows Only)........................198

Appendix

Te ch n i ca l

Printer Specications....................199

Scanner Specications...................200

Interface Specications...................200

Fax Specications.......................200

Network Function List...................201

Wi-Fi Specications.....................202

Security Protocol.......................202

Supported ird Party Services.............202

Dimensions...........................203

Electrical Specications..................203

Environmental Specications..............204

System Requirements....................204

Regulatory Information....................205

Standards and Approvals................. 205

German Blue Angel.....................206

Restrictions on Copying..................206

Transporting and Storing the Printer...........206

Trademarks.............................209

Where to Get Help........................210

Technical Support Web Site................210

Contacting Epson Support................210

Specications

....................199

User's Guide

About This Manual

Introduction to the Manuals

e following manuals are supplied with your Epson printer. As well as the manuals, check the various types of help information available from the printer itself or from the Epson soware applications.

❏ Start Here (paper manual)

Provides you with information on setting up the printer, installing the soware, using the printer, solving problems, and so on.

❏ User's Guide (digital manual)

is manual. Provides overall information and instructions on using the printer, on network settings when using the printer on a network, and on solving problems.

You can obtain the latest versions of the above manuals with the following methods.

❏ Paper manual

Visit the Epson Europe support website at http://www.epson.eu/Support, or the Epson worldwide support website at http://support.epson.net/.

❏ Digital manual

Start EPSON Soware Updater on your computer. EPSON Soware Updater checks for available updates of Epson soware applications and the digital manuals, and allows you to download the latest ones.

Related Information

&“Soware

Update Tools (EPSON

Soware

Updater)” on page 160

Using the Manual to Search for Information

e PDF manual allows you to search for information you are looking for by keyword, or jump directly to specic sections using the bookmarks. You can also print only the pages you need. is section explains how to use a PDF manual that has been opened in Adobe Reader X on your computer.

Searching by keyword

Click Edit > Advanced Search. Enter the keyword (text) for information you want to and then click Search. Hits are displayed as a list. Click one of the displayed hits to jump to that page.

in the search window,

nd

User's Guide

About This Manual

Jumping directly from bookmarks

Click a title to jump to that page. Click + or > to view the lower level titles in that section. To return to the previous page, perform the following operation on your keyboard.

❏ Wi n d o w s : H o ld down Alt, and then press ←.

❏ Mac OS: Hold down the command key, and then press ←.

Printing only the pages you need

You can extract and print only the pages you need. Click Print in the File menu, and then specify the pages you want to print in Pages in Pages to Print.

❏ To specify a series of pages, enter a hyphen between the start page and the end page.

Example: 20-25

❏ To specify pages that are not in series, divide the pages with commas.

Example: 5, 10, 15

Marks and Symbols

Caution:

Instructions that must be followed carefully to avoid bodily injury.

Important:

Instructions that must be observed to avoid damage to your equipment.

Note:

Provides complementary and reference information.

User's Guide

About This Manual

Related Information

& Links to related sections.

Descriptions Used in this Manual

❏ Screenshots of the printer driver and the Epson Scan 2 (scanner driver) screens are from Windows 10 or macOS

Mojave. e content displayed on the screens varies depending on the model and situation.

❏ Illustrations used in this manual are examples only. Although there may be slight dierences depending on the

model, the method of operation is the same.

❏ Some of the menu items on the LCD screen vary depending on the model and settings.

❏ You can read the QR code using dedicated app.

Operating System References

Windows

In this manual, terms such as "Windows 10", "Windows 8.1", "Windows 8", "Windows 7", "Windows Vista", "Windows XP", "Windows Server 2016", "Windows Server 2012 R2", "Windows Server 2012", "Windows Server 2008 R2", "Windows Server 2008", "Windows Server 2003 R2", and "Windows Server 2003" refer to the following operating systems. Additionally, "Windows" is used to refer to all versions.

❏ Microso

❏

Microso

❏ Microso

❏

Microso

❏ Microso

Wi n d o w s® 10 operating system

Wi n d o w s® 8.1 operating system

Wi n d o w s® 8 operating system

Wi n d o w s® 7 operating system

Wi n d o w s Vis ta® operating system

Wi n d o w s® XP operating system

Wi n d o w s® XP Professional x64 Edition operating system

Wi n d o w s Ser v e r® 2016 operating system

Wi n d o w s Ser v e r® 2012 R2 operating system

Wi n d o w s Ser v e r® 2012 operating system

Wi n d o w s Ser v e r® 2008 R2 operating system

Wi n d o w s Ser v e r® 2008 operating system

Wi n d o w s Ser v e r® 2003 R2 operating system

Wi n d o w s Ser v e r® 2003 operating system

Mac OS

In this manual, "Mac OS" is used to refer to macOS Mojave, macOS High Sierra, macOS Sierra, OS X El Capitan, OS X Yosemite, OS X Mavericks, OS X Mountain Lion, Mac OS X v10.7.x, and Mac OS X v10.6.8.

User's Guide

Important Instructions

Safety Instructions

Read and follow these instructions to ensure safe use of this printer. Make sure you keep this manual for future reference. Also, be sure to follow all warnings and instructions marked on the printer.

❏ Some of the symbols used on your printer are to ensure safety and proper use of the printer. Visit the following

Web site to learn the meaning of the symbols.

http://support.epson.net/symbols

❏ Use only the power cord supplied with the printer and do not use the cord with any other equipment. Use of

other cords with this printer or the use of the supplied power cord with other equipment may result in re or electric shock.

❏ Be sure your AC power cord meets the relevant local safety standard.

❏ Never disassemble, modify, or attempt to repair the power cord, plug, printer unit, scanner unit, or options by

yourself, except as specically explained in the printer's manuals.

❏ Unplug the printer and refer servicing to qualied service personnel under the following conditions:

e power cord or plug is damaged; liquid has entered the printer; the printer has been dropped or the casing damaged; the printer does not operate normally or exhibits a distinct change in performance. Do not adjust controls that are not covered by the operating instructions.

❏ Place the printer near a wall outlet where the plug can be easily unplugged.

❏ Do not place or store the printer outdoors, near excessive dirt or dust, water, heat sources, or in locations

subject to shocks, vibrations, high temperature or humidity.

❏ Take care not to spill liquid on the printer and not to handle the printer with wet hands.

❏ Keep the printer at least 22 cm away from cardiac pacemakers. Radio waves from this printer may adversely

aect the operation of cardiac pacemakers.

❏ If the LCD screen is damaged, contact your dealer. If the liquid crystal solution gets on your hands, wash them

thoroughly with soap and water. If the liquid crystal solution gets into your eyes, ush them immediately with water. If discomfort or vision problems remain aer a thorough ushing, see a doctor immediately.

❏ Avoid using a telephone during an electrical storm.

❏ Do not use a telephone to report a gas leak in the vicinity of the leak.

may be a remote risk of electric shock from lightning.

ere

Safety Instructions for Ink

❏ Be careful when you handle used ink cartridges, as there may be some ink around the ink supply port.

❏ If ink gets on your skin, wash the area thoroughly with soap and water.

❏ If ink gets into your eyes, ush them immediately with water. If discomfort or vision problems continue aer

a thorough ushing, see a doctor immediately.

❏ If ink gets into your mouth, see a doctor right away.

❏ Do not disassemble the ink cartridge and the maintenance box; otherwise ink may get into your eyes or on your

skin.

User's Guide

Important Instructions

❏ Do not shake ink cartridges too vigorously and do not drop them. Also, be careful not to squeeze them or tear

their labels. Doing so may cause ink leakage.

❏ Keep ink cartridges and maintenance box out of the reach of children.

Printer Advisories and Warnings

Read and follow these instructions to avoid damaging the printer or your property. Make sure you keep this manual for future reference.

Advisories and Warnings for Setting Up the Printer

❏ Do not block or cover the vents and openings in the printer.

❏ Use only the type of power source indicated on the printer's label.

❏ Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on and o.

❏ Avoid electrical outlets controlled by wall switches or automatic timers.

❏ Keep the entire computer system away from potential sources of electromagnetic interference, such as

loudspeakers or the base units of cordless telephones.

❏ e power-supply cords should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place

objects on top of the power-supply cords and do not allow the power-supply cords to be stepped on or run over. Be particularly careful to keep all the power-supply cords straight at the ends and the points where they enter and leave the transformer.

❏ If you use an extension cord with the printer, make sure that the total ampere rating of the devices plugged into

the extension cord does not exceed the cord's ampere rating. Also, make sure that the total ampere rating of all devices plugged into the wall outlet does not exceed the wall outlet's ampere rating.

❏ If you plan to use the printer in Germany, the building installation must be protected by a 10 or 16 amp circuit

breaker to provide adequate short-circuit protection and over-current protection for the printer.

❏ When connecting the printer to a computer or other device with a cable, ensure the correct orientation of the

connectors. Each connector has only one correct orientation. Inserting a connector in the wrong orientation may damage both devices connected by the cable.

❏ Place the printer on a

will not operate properly if it is tilted at an angle.

❏ Allow space above the printer so that you can fully raise the document cover.

stable surface that extends beyond the base of the printer in all directions. e printer

at,

❏ Leave enough space in front of the printer for the paper to be fully ejected.

❏ Avoid places subject to rapid changes in temperature and humidity. Also, keep the printer away from direct

sunlight, strong light, or heat sources.

Advisories and Warnings for Using the Printer

❏ Do not insert objects through the slots in the printer.

❏ Do not put your hand inside the printer during printing.

❏ Do not touch the white at cable inside the printer.

❏ Do not use aerosol products that contain ammable gases inside or around the printer. Doing so may cause re.

User's Guide

Important Instructions

❏ Do not move the print head by hand; otherwise, you may damage the printer.

❏ Be careful not to trap your

❏ Do not press too hard on the scanner glass when placing the originals.

❏ Always turn the printer o using the

until the

❏ If you are not going to use the printer for a long period, be sure to unplug the power cord from the electrical

outlet.

light stops

ashing.

when closing the scanner unit.

ngers

button. Do not unplug the printer or turn o the power at the outlet

Advisories and Warnings for Transporting or Storing the Printer

❏ When storing or transporting the printer, avoid tilting it, placing it vertically, or turning it upside down;

otherwise ink may leak.

❏ Before transporting the printer, make sure that the print head is in the home (far right) position.

Advisories and Warnings for Using the Printer with a Wireless Connection

❏ Radio waves from this printer may negatively aect the operation of medical electronic equipment, causing

them to malfunction. When using this printer inside medical facilities or near medical equipment, follow directions from the authorized personnel representing the medical facilities, and follow all posted warnings and directions on the medical equipment.

❏ Radio waves from this printer may negatively

automatic doors or automatically controlled devices, follow all posted warnings and directions on these devices.

alarms, and could lead to accidents due to malfunction. When using this printer near

re

the operation of automatically controlled devices such as

aect

Advisories and Warnings for Using the LCD Screen

❏ e LCD screen may contain a few small bright or dark spots, and because of its features it may have an uneven

brightness. ese are normal and do not indicate that it is damaged in any way.

❏ Only use a dry,

❏ e exterior cover of the LCD screen could break if it receives a heavy impact. Contact your dealer if the

screen's surface chips or cracks, and do not touch or attempt to remove the broken pieces.

cloth for cleaning. Do not use liquid or chemical cleaners.

so

Protecting Your Personal Information

When you give the printer to someone else or dispose of it, erase all the personal information stored in the printer's memory by selecting Settings > Restore Default Settings > Clear All Data and Settings on the control panel.

User's Guide

Printer Basics

Part Names and Functions

Rear paper feed Loads paper.

Paper support Supports loaded paper.

Edge guide Feeds the paper straight into the printer. Slide to the edges of the paper.

Feeder guard Prevents foreign substance from entering the printer.

Usually keep this guard closed.

Output tray Holds the ejected paper.

Stopper Prevents printouts from falling from the output tray.

Document cover Blocks external light while scanning.

Scanner glass Place the originals.

Control panel Indicates the printer's status and allows you to make print settings.

User's Guide

Scanner unit support Supports the scanner unit.

Scanner unit Scans placed originals. Open when replacing ink cartridges or removing

Printer Basics

jammed paper inside the printer.

Ink cartridge holder Install the ink cartridges. Ink is ejected from the print head nozzles.

Maintenance box cover Remove when replacing the maintenance box. The maintenance box is a

container that collects a very small amount of surplus ink during cleaning or printing.

Rear cover Remove when removing jammed paper.

AC inlet Connects the power cord.

EXT. port Connects external phone devices.

LINE port Connects a phone line.

USB port Connects a USB cable to connect with a computer.

Related Information

& “Control Panel” on page 15

User's Guide

Printer Basics

Guide to the Control Panel

Control Panel

Turns the printer on or o.

Unplug the power cord after checking that the power light is o.

Displays menus and messages. Use buttons on the control panel to select a menu or to make settings.

Displays the solutions when you are in trouble.

Use the u d l r buttons to select a menu, and then press the OK button to enter the selected menu.

Stops the current operation.

Enters numbers, characters, and symbols.

Clears number settings such as the number of copies.

Starts an operation such as printing or copying.

Applies to a variety of functions depending on the situation.

Returns to the previous screen.

Turns on when received documents that have not yet been printed or saved are stored in the printer's memory.

Displays the home screen.

User's Guide

Guide to the Home Screen

Icons that show the network status are displayed.

Indicates that a wireless (Wi-Fi) network is disabled, or that the printer is processing a wireless network connection.

Printer Basics

Indicates a problem with the printer's wireless (Wi-Fi) network connection, or that the printer is searching for a wireless (Wi-Fi) network connection.

Indicates that the printer is connected to a wireless (Wi-Fi) network.

The number of bars indicates the signal strength of the connection. The more bars there are, the stronger the connection.

Indicates that Wi-Fi Direct (Simple AP) is enabled.

Indicates that Wi-Fi Direct (Simple AP) is disabled.

When l and r are displayed, you can scroll right or left by pressing the l or r button.

Function icons and names are displayed as menu icons.

Select an icon by pressing the

Scan Allows you to scan a document or a photo.

Copy Allows you to copy a document.

Wi-Fi Setup Allows you to set up the printer for use on a wireless network. This is a shortcut to the following

menu.

Settings > Network Settings > Wi-Fi Setup

Fax Allows you to send faxes.

u d l r

buttons, and then press the OK button to enter the menu.

Quiet Mode

Settings Allows you to make settings related to maintenance, printer setup, and network settings.

Maintenance Displays the menus recommended to improve the quality of your printouts such as un-

Displays Quiet Mode setting that allows you to reduce the noise the printer makes. However, enabling this may reduce print speed. Depending on the paper type and print quality settings you selected, there may be no dierence in the printer's noise level.

This is a shortcut to the following menu.

Settings > Printer Setup > Quiet Mode

clogging nozzles by printing a nozzle check pattern and performing head cleaning, and improving blurring or banding in your printouts by aligning the print head. This is a shortcut to the following menu.

Settings > Maintenance

User's Guide

Printer Basics

Available buttons are displayed. In this example, you can proceed to the selected menu by pressing the OK button.

Entering Characters

To enter characters and symbols for network settings and register contacts from the control panel, use the u, d,

, and r buttons and the soware keyboard on the LCD screen. Press the u, d, l, or r button to select a character or function button on the keyboard, and then press the OK button. When you have nished entering characters, select OK, and then press the OK button.

Function button Descriptions

l r

A 1 # Switches the character type. You can enter alphanumerics or symbols.

OK Enters the selected characters.

Moves the cursor to the left or right.

You can also switch them by using the

Enters a space.

Deletes a character to the left (backspace).

button.

Viewing Animations

You can view animations of operating instructions such as loading paper or removing jammed paper on the LCD screen.

❏ Press

button: Displays the help screen. Select How To and then select the items that you want to view.

User's Guide

Printer Basics

❏ Select How to at the bottom of the operation screen: Displays the context-sensitive animation.

Indicates your progress through the current step. The animation repeats when the progress bar reaches the end.

Press l button to return to the previous step.

Indicates the total number of steps and the current step number.

In the example above, it shows step 2 from 3 steps.

Press r button to move to the next step.

User's Guide

Network Settings

Network Connection Types

You can use the following connection methods.

Wi-Fi Connection

Connect the printer and the computer or smart device to the wireless router. is is the typical connection method for home or oce networks where computers are connected by Wi-Fi through the wireless router.

Related Information

“Connecting to a Computer” on page 20

“Connecting to a smart device over a wireless router” on page 21

& & “Making Wi-Fi Settings from the Printer” on page 30

Wi-Fi Direct (Simple AP) Connection

Use this connection method when you are not using Wi-Fi at home or at the oce, or when you want to connect the printer and the computer or smart device directly. In this mode, the printer acts as an wireless router and you

User's Guide

Network Settings

can connect the devices to the printer without having to use a standard wireless router. However, devices directly connected to the printer cannot communicate with each other through the printer.

e printer can be connected by Wi-Fi and Wi-Fi Direct (Simple AP) connection simultaneously. However, if you start a network connection in Wi-Fi Direct (Simple AP) connection when the printer is connected by Wi-Fi, the Wi-Fi is temporarily disconnected.

Related Information

& “Connecting to an iPhone, iPad, or iPod touch using Wi-Fi Direct” on page 21 & “Connecting to Android Devices using Wi-Fi Direct” on page 25 & “Connecting to Devices other than iOS and Android using Wi-Fi Direct” on page 27

Connecting to a Computer

We recommend using the installer to connect the printer to a computer. You can run the installer using one of the following methods.

❏ Setting up from the website

Access the following website, and then enter the product name. Go to Setup, and then start setting up.

http://epson.sn

❏ Setting up using the soware disc (only for the models that come with a soware disc and users with Windows

computers with disc drives.)

Insert the soware disc into the computer, and then follow the on-screen instructions.

Selecting the Connection Methods

Follow the on-screen instructions until the following screen is displayed, and then select the connection method of the printer to the computer.

User's Guide

Select the connection type and then click Next.

Network Settings

Follow the on-screen instructions.

Connecting to a Smart Device

Connecting to a smart device over a wireless router

You can use the printer from a smart device when you connect the printer to the same Wi-Fi network (SSID) as the smart device. To use the printer from a smart device, set up from the following website. Access to the website from the smart device that you want to connect to the printer.

http://epson.sn > Setup

Note:

If you want to connect a computer and a smart device to the printer at the same time, we recommend setting up from the computer rst by using the installer.

Related Information

& “Printing from Smart Devices” on page 102

Connecting to an iPhone, iPad, or iPod touch using Wi-Fi Direct

is method allows you to connect the printer directly to an iPhone, iPad, or iPod touch without a wireless router. e following conditions are required to connect using this method. If your environment does not match these

User's Guide

Network Settings

conditions, you can connect by selecting Other OS Devices. See "Related Information" below for details on connecting.

❏ iOS 11 or later

❏ Using the standard camera application to scan the QR code

❏ Epson iPrint version 7.0 or later

Epson iPrint is used to print from a smart device. Install Epson iPrint on the smart device in advance.

Note:

You only need to make these settings for the printer and the smart device that you want to connect to once. Unless you disable Wi-Fi Direct or restore the network settings to their defaults, you do not need to make these settings again.

1. Select Wi - F i S etup on the home screen.

To select an item, use the

2. Select Wi - F i D irec t .

3. Check the message, and then press the OK button to proceed.

Check the message, and then press the OK button to proceed.

5. Select iOS.

u d l r

buttons, and then press the OK button.

User's Guide

Network Settings

6. Check the message, and then press the OK button to proceed.

QR code is displayed on the printer's control panel.

e

7. On your iPhone, iPad, or iPod touch, start the standard Camera app, and then scan the QR code displayed on

the printer's control panel in PHOTO mode.

Use the Camera app for iOS 11 or later. You cannot connect to the printer using the Camera app for iOS 10 or

earlier. Also, you cannot connect using an app for scanning QR codes. If you cannot connect, press the button. See "Related Information" below for details on connecting.

8. Tap the notication displayed on the screen of the iPhone, iPad, or iPod touch.

9. Tap Join.

User's Guide

Network Settings

10. On the printer's control panel, press the OK button.

11. On the iPhone, iPad, or iPod touch, start Epson printing app.

Examples of Epson printing apps

12. On the Epson printing app screen, tap Printer is not selected..

13. Select the printer that you want to connect to.

See the information displayed on the printer's control panel to select the printer.

14. On the printer's control panel, press the OK button.

For smart devices that have been connected to the printer before, select the network name (SSID) on the smart device's Wi-Fi screen to connect them again.

User's Guide

Network Settings

Related Information

& “Connecting to Devices other than iOS and Android using Wi-Fi Direct” on page 27 & “Printing from Smart Devices” on page 102

Connecting to Android Devices using Wi-Fi Direct

is method allows you to connect the printer directly to your Android device without a wireless router. e following conditions are required to use this function.

❏ Android 4.4 or later

❏ Epson iPrint version 7.0 or later

Epson iPrint is used to print from a smart device. Install Epson iPrint on the smart device in advance.

Note:

1. Select Wi - F i S etup on the home screen.

To select an item, use the

2. Select Wi - F i D irec t .

Check the message, and then press the OK button to proceed.

4. Check the message, and then press the OK button to proceed.

5. Select Android.

u d l r

buttons, and then press the OK button.

User's Guide

Network Settings

6. On the smart device, start Epson iPrint.

7. On the Epson iPrint screen, tap Printer is not selected..

8. Select the printer that you want to connect to.

See the information displayed on the printer's control panel to select the printer.

Note:

Printers may not been displayed depending on the Android device. If printers are not displayed, connect by selecting Other OS Devices. See "Related Information" below for connecting.

9. When the device connection approval screen is displayed, select Approve.

10. On the printer's control panel, press the OK button.

For smart devices that have been connected to the printer before, select the network name (SSID) on the smart device's Wi-Fi screen to connect them again.

Related Information

& “Connecting to Devices other than iOS and Android using Wi-Fi Direct” on page 27

User's Guide

Network Settings

& “Printing from Smart Devices” on page 102

Connecting to Devices other than iOS and Android using Wi-Fi Direct

is method allows you to connect the printer directly to smart devices without a wireless router.

Note:

Select Wi-Fi S e t u p on the home screen.

To select an item, use the

2. Select Wi - F i D irec t .

3. Check the message, and then press the OK button to proceed.

4. Check the message, and then press the OK button to proceed.

5. Select Other OS Devices.

u d l r

buttons, and then press the OK button.

e Network Name and Password for Wi-Fi Direct for the printer are displayed.

User's Guide

Network Settings

6. On the smart device's Wi-Fi screen, select the SSID shown on the printer's control panel, and then enter the

password.

e screenshot is an example on iPhone.

7. On the printer's control panel, press the OK button.

User's Guide

Network Settings

8. On the smart device, start Epson printing app.

Examples of Epson printing apps

9. On the Epson printing app screen, tap Printer is not selected..

10. Select the printer that you want to connect to.

See the information displayed on the printer's control panel to select the printer.

11. On the printer's control panel, press the OK button.

For smart devices that have been connected to the printer before, select the network name (SSID) on the smart device's Wi-Fi screen to connect them again.

User's Guide

Network Settings

Related Information

& “Printing from Smart Devices” on page 102

Making Wi-Fi Settings from the Printer

You can make network settings from the printer's control panel in several ways. Choose the connection method that matches the environment and conditions that you are using.

If you know the information for the wireless router such as SSID and password, you can make settings manually.

If the wireless router supports WPS, you can make settings by using push button setup.

connecting the printer to the network, connect to the printer from the device that you want to use (computer,

Aer smart device, tablet, and so on.)

Related Information

Making Wi-Fi Settings by Entering the SSID and Password

You can set up a Wi-Fi network by entering the information necessary to connect to a wireless router from the printer's control panel. To set up using this method, you need the SSID and password for a wireless router.

Note:

If you are using an wireless router with its default settings, the SSID and password are on the label. If you do not know the SSID and password, contact the person who set up the wireless router, or see the documentation provided with the wireless router.

1. Select Wi - F i S etup on the home screen.

To select an item, use the

2. Select Wi-Fi (Recommended).

Press the OK button to proceed.

4. Select Wi-Fi Setup Wizard.

u d l r

buttons, and then press the OK button.

User's Guide

Network Settings

5. Select the SSID for the wireless router from printer's control panel, and then press the OK button.

Note:

❏ If the SSID you want to connect to is not displayed on the printer's control panel, press the

list. If it is still not displayed, select Other SSIDs, and then enter the SSID directly.

❏ If you do not know the SSID, check if it is written on the label of the wireless router. If you are using the wireless

router with its default settings, use the SSID written on the label.

6. Enter the password.

Select whether or not you print a network connection report aer nishing the settings.

Note:

❏ e password is case-sensitive.

❏ If you do not know the network name (SSID) check if the information is written on the label of the wireless router. If

you are using the wireless router with its default settings, use the SSID on the label. If you cannot nd any information, see the documentation provided with the wireless router.

When you have setup nished, and then press the

button.

button to update the

Note:

If you fail to connect, load paper, and then press the

Related Information

& “Entering Characters” on page 17 & “Checking the Network Connection Status” on page 33 & “When You Cannot Make Network Settings” on page 177

button to print a network connection report.

Making Wi-Fi Settings by Push Button Setup

You can automatically set up a Wi-Fi network by pressing a button on the wireless router. If the following conditions are met, you can set up by using this method.

❏ e wireless router is compatible with WPS (Wi-Fi Protected Setup).

❏ e current Wi-Fi connection was established by pressing a button on the wireless router.

1. Select Wi - F i S etup on the home screen.

To select an item, use the

2. Select Wi-Fi (Recommended).

u d l r

buttons, and then press the OK button.

3. Press the OK button to proceed.

4. Select Push Button Setup (WPS).

User's Guide

Network Settings

5. Hold down the [WPS] button on the wireless router until the security light ashes.

If you do not know where the [WPS] button is, or there are no buttons on the wireless router, see the documentation provided with your wireless router for details.

6. Press the OK button on the printer's control panel. Follow the on-screen instruction

Note:

If connection fails, restart the wireless router, move it closer to the printer, and try again. If it still does not work, print a network connection report and check the solution.

Related Information

& “Checking the Network Connection Status” on page 33 & “When You Cannot Make Network Settings” on page 177

hereaer.

Making Wi-Fi Settings by PIN Code Setup (WPS)

You can automatically connect to an wireless router by using a PIN code. You can use this method to set up if an wireless router is capable of WPS (Wi-Fi Protected Setup). Use a computer to enter a PIN code into the wireless router.

1. Select Wi - F i S etup on the home screen.

To select an item, use the

2. Select Wi-Fi (Recommended).

u d l r

buttons, and then press the OK button.

3. Press the OK button to proceed.

4. Select Others.

Select PIN Code (WPS).

6. Use your computer to enter the PIN code (an eight digit number) displayed on the printer's control panel into

the wireless router within two minutes.

Note:

See the documentation provided with your wireless router for details on entering a PIN code.

User's Guide

Network Settings

7. Press the OK button on the printer.

Setup is complete when the setup completion message is displayed.

Note:

If connection fails, restart the wireless router, move it closer to the printer, and try again. If it still does not work, print a connection report and check the solution.

Related Information

& “Checking the Network Connection Status” on page 33 & “When You Cannot Make Network Settings” on page 177

Checking the Network Connection Status

You can check the network connection status in the following way.

Network Icon

You can check the network connection status and strength of the radio wave using the network icon on the printer's home screen.

Related Information

& “Guide to the Home Screen” on page 16

Printing a Network Connection Report

You can print a network connection report to check the status between the printer and the wireless router.

1. Load papers.

2. Select Settings on the home screen, and then press the OK button.

To select an item, use the

Select Network Settings > Connection Check.

e connection check starts.

4. Press the

If an error has occurred, check the network connection report, and then follow the printed solutions.

button to print the network connection report.

u d l r

buttons, and then press the OK button.

User's Guide

Network Settings

Related Information

& “Messages and Solutions on the Network Connection Report” on page 34

Messages and Solutions on the Network Connection Report

Check the messages and error codes on the network connection report, and then follow the solutions.

a. Error code

b. Messages on the Network Environment

Related Information

& “E-1” on page 35 & “E-2, E-3, E-7” on page 35 & “E-5” on page 36

“E-6” on page 36

“E-8” on page 36

“E-9” on page 37

“E-10” on page 37

“E-11” on page 37

& & “E-12” on page 38

User's Guide

Network Settings

& “E-13” on page 38 & “Message on the Network Environment” on page 39

E-1

Solutions:

❏ Make sure the Ethernet cable is securely connected to your printer and to your hub or other network device.

❏ Make sure your hub or other network device is turned on.

❏ If you want to connect the printer by Wi-Fi, make Wi-Fi settings for the printer again because it is disabled.

E-2, E-3, E-7

Solutions:

❏ Make sure your wireless router is turned on.

❏ Conrm that your computer or device is connected correctly to the wireless router.

❏ Turn o the wireless router. Wait for about 10 seconds, and then turn it on.

❏ Place the printer closer to your wireless router and remove any obstacles between them.

❏ If you have entered the SSID manually, check if it is correct. Check the SSID from the Network Status part on

the network connection report.

❏ If an wireless router has multiple SSIDs, select the SSID that is displayed. When the SSID is using a non-

compliant frequency, the printer does not display them.

❏ If you are using push button setup to establish a network connection, make sure your wireless router supports

WPS. You cannot use push button setup if your wireless router does not support WPS.

❏ Makes sure your SSID uses only ASCII characters (alphanumeric characters and symbols). e printer cannot

display an SSID that contains non-ASCII characters.

❏ Makes sure you know your SSID and password before connecting to the wireless router. If you are using a

wireless router with its default settings, the SSID and password are located on a label on the wireless router. If you do not know your SSID and password, contact the person who set up the wireless router, or see the documentation provided with the wireless router.

❏ If you are connecting to an SSID generated from a tethering smart device, check for the SSID and password in

the documentation provided with the smart device.

❏ If your Wi-Fi connection suddenly disconnects, check for the conditions below. If any of these conditions are

applicable, reset your network settings by downloading and running the

http://epson.sn > Setup

❏ Another smart device was added to the network using push button setup.

❏ e Wi-Fi network was set up using any method other than push button setup.

Related Information

& “Connecting to a Computer” on page 20 & “Making Wi-Fi Settings from the Printer” on page 30

soware

from the following website.

User's Guide

Network Settings

E-5

Solutions:

Make sure the wireless router’s security type is set to one of the following. If it is not, change the security type on the wireless router, and then reset the printer’s network settings.

❏ WEP-64 bit (40 bit)

❏ WEP-128 bit (104 bit)

❏ WPA PSK (TKIP/AES)

❏ WPA2 PSK (TKIP/AES)

❏ WPA (TKIP/AES)

❏ WPA2 (TKIP/AES)

* WPA PSK is also known as WPA Personal. WPA2 PSK is also known as WPA2 Personal.

E-6

Solutions:

❏ Check if MAC address

ltered. See the documentation provided with the wireless router for details. You can check the printer’s MAC address from the Network Status part on the network connection report.

❏ If your wireless router is using shared authentication with WEP security, make sure the authentication key and

index are correct.

❏ If the number of connectable devices on the wireless router is less than the number of network devices that you

want to connect, make settings on the wireless router to increase the number of connectable devices. See the documentation provided with the wireless router to make settings.

Related Information

& “Connecting to a Computer” on page 20

ltering

is disabled. If it is enabled, register the printer’s MAC address so that it is not

E-8

Solutions:

❏ Enable DHCP on the wireless router if the printer’s Obtain IP Address setting is set to Auto.

❏ If the printer’s Obtain IP Address setting is set to Manual, the IP address you manually set is invalid due to out

of range (for example: 0.0.0.0). Set a valid IP address from the printer’s control panel or by using Web Cong.

Related Information

“Printing a Network Status Sheet” on page 39

User's Guide

Network Settings

E-9

Solutions:

Check the following.

❏ Devices are turned on.

❏ You can access the Internet and other computers or network devices on the same network from the devices you

want to connect to the printer.

If still does not connect your printer and network devices aer conrming the above, turn o the wireless router. Wait for about 10 seconds, and then turn it on. en reset your network settings by downloading and running the installer from the following website.

http://epson.sn > Setup

Related Information

& “Connecting to a Computer” on page 20

E-10

Solutions:

Check the following.

❏ Other devices on the network are turned on.

❏ Network addresses (IP address, subnet mask, and default gateway) are correct if you have set the printer’s

Obtain IP Address to Manual.

Reset the network address if they are incorrect. You can check the IP address, subnet mask, and default gateway from the Network Status part on the network connection report.

If DHCP is enabled, change the printer’s Obtain IP Address setting to Auto. If you want to set the IP address manually, check the printer’s IP address from the Network Status part on the network connection report, and then select Manual on the network settings screen. Set the subnet mask to [255.255.255.0].

If still does not connect your printer and network devices, turn o the wireless router. Wait for about 10 seconds, and then turn it on.

Related Information

& “Printing a Network Status Sheet” on page 39

E-11

Solutions:

Check the following.

❏

default gateway address is correct if you set the printer’s TCP/IP Setup setting to Manual.

e

❏ e device that is set as the default gateway is turned on.

Set the correct default gateway address. You can check the default gateway address from the Network Status part on the network connection report.

User's Guide

Network Settings

Related Information

& “Printing a Network Status Sheet” on page 39

E-12

Solutions:

Check the following.

❏ Other devices on the network are turned on.

❏ e network addresses (IP address, subnet mask, and default gateway) are correct if you are entering them

manually.

❏ e network addresses for other devices (subnet mask and default gateway) are the same.

❏

IP address does not

e

If still does not connect your printer and network devices aer conrming the above, try the following.

conict

with other devices.

❏ Turn o the wireless router. Wait for about 10 seconds, and then turn it on.

❏ Make network settings again using the installer. You can run it from the following website.

http://epson.sn > Setup

❏ You can register several passwords on a wireless router that uses WEP security type. If several passwords are

registered, check if the rst registered password is set on the printer.

Related Information

“Printing a Network Status Sheet” on page 39

& “Connecting to a Computer” on page 20

E-13

Solutions:

Check the following.

❏ Network devices such as a wireless router, hub, and router are turned on.

❏ e TCP/IP Setup for network devices has not been set up manually. (If the printer’s TCP/IP Setup is set

automatically while the TCP/IP Setup for other network devices is performed manually, the printer’s network may

from the network for other devices.)

dier

If it still does not work

❏ Turn o the wireless router. Wait for about 10 seconds, and then turn it on.

❏ Make network settings on the computer that is on the same network as the printer using the installer. You can

run it from the following website.

http://epson.sn > Setup

❏ You can register several passwords on a wireless router that uses the WEP security type. If several passwords are

registered, check if the rst registered password is set on the printer.

checking the above, try the following.

aer

User's Guide

Network Settings

Related Information

& “Printing a Network Status Sheet” on page 39 & “Connecting to a Computer” on page 20

Message on the Network Environment

Message Solution

The Wi-Fi environment needs to be

improved. Turn the wireless router o and

then turn it on. If the connection does not

improve, see the documentation for the

wireless router.

*No more devices can be connected.

Disconnect one of the connected devices if

you want to add another one.

The same SSID as Wi-Fi Direct exists in the

environment. Change the Wi-Fi Direct SSID

if you cannot connect a smart device to the

printer.

After moving the printer closer to the wireless router and removing any obstacles between them, turn o the wireless router. Wait for about 10 seconds, and then turn it on. If it still does not connect, see the documentation supplied with the wireless router.

Computer and smart devices that can be connected simultaneously are connected in full in the Wi-Fi Direct (Simple AP) connection. To add another computer or smart device, disconnect one of the connected devices or connect it to the other network rst.

You can conrm the number of wireless devices which can be connected simultaneously and the number of connected devices by checking the network status sheet or the printer’s control panel.

On the printer’s control panel, go to Wi-Fi Direct Setup screen and select the menu to change the setting. You can change the network name following after DIRECT-XX-. Enter within 32 characters.

Printing a Network Status Sheet

You can check the detailed network information by printing it.

Load papers.

2. Select Settings on the home screen.

To select an item, use the

Select Network Settings > Print Status Sheet.

4. Press the

e

button.

network status sheet is printed.

u d l r

buttons, and then press the OK button.

Replacing or Adding New Wireless Routers

If the SSID changes due to the replacement of a wireless router, or a wireless router is added and a new network environment is established, re-set the Wi-Fi settings.

User's Guide

Network Settings

Related Information

& “Changing the Connection Method to a Computer” on page 40

Changing the Connection Method to a Computer

Using the installer and re-set up in a dierent connection method.

❏ Setting up from the website

Access the following website, and then enter the product name. Go to Setup, and then start setting up.

http://epson.sn

❏ Setting up using the soware disc (only for the models that come with a soware disc and users with Windows

computers with disc drives.)

Insert the

soware

disc into the computer, and then follow the on-screen instructions.

Selecting Change the Connection Methods

Follow the on-screen instructions until the following screen is displayed.

Select Set up Printer connection again (for new network router or changing USB to network, etc.) on the Install Soware screen, and then click Next.

Changing the Wi-Fi Direct (Simple AP) Settings

When a Wi-Fi Direct (Simple AP) connection is enabled, you can change the Wi-Fi Direct settings such as the network name and the password.

User's Guide

1. Select Wi - F i S etup on the home screen.

Network Settings

To select an item, use the

2. Select Wi - F i D irec t .

3. Press the OK button to proceed.

Press the OK button to proceed.

5. Press the

6. Select the menu item that you want to change.

You can select the following menu items.

❏ Change Network Name

Change the Wi-Fi Direct (simple AP) network name (SSID) used for connecting to the printer to your arbitrary name. You can set the network name (SSID) in ASCII characters that is displayed on the soware keyboard on the control panel.

When changing the network name (SSID), all connected devices are disconnected. Use the new network name (SSID) if you want to re-connect the device.

❏ Change Password

Change the Wi-Fi Direct (simple AP) password for connecting to the printer to your arbitrary value. You can set the password in ASCII characters that is displayed on the

When changing the password, all connected devices are disconnected. Use the new password if you want to re-connect the device.

button to display the setting screen.

u d l r

buttons, and then press the OK button.

soware

keyboard on the control panel.

❏ Disable Wi-Fi Direct

Disable Wi-Fi Direct (simple AP) settings of the printer. When disabling it, all devices connected to the printer in Wi-Fi Direct (Simple AP) connection are disconnected.

❏ Restore Default Settings

Restore all Wi-Fi Direct (simple AP) settings to their defaults.

e Wi-Fi Direct (simple AP) connection information of the smart device saved to the printer is deleted.

7. Follow the on-screen instruction.

Disabling Wi-Fi from the Control Panel

When Wi-Fi is disabled, the Wi-Fi connection is disconnected.

Select Wi-Fi S e t u p on the home screen.

To select an item, use the

2. Select Wi-Fi (Recommended).

3. Press the OK button to proceed.

u d l r

buttons, and then press the OK button.

4. Select Others.

5. Select Disable Wi-Fi.

User's Guide

Network Settings

6. Check the message, and then press the OK button.

Disconnecting Wi-Fi Direct (Simple AP) Connection from the Control Panel

ere are two methods available to disable a Wi-Fi Direct (Simple AP) connection; you can disable all connections by using the printer's control panel, or disable each connection from the computer or the smart device. is section explains how to disable all connections.

Important:

When Wi-Fi Direct (Simple AP) connection disabled, all computers and smart devices connected to the printer in Wi-Fi Direct (Simple AP) connection are disconnected.

Note:

If you want to disconnect a specic device, disconnect from the device instead of the printer. Use one of the following methods to disconnect the Wi-Fi Direct (Simple AP) connection from the device.

❏ Disconnect the Wi-Fi connection to the printer's network name (SSID).

❏ Connect to another network name (SSID).

1. Select Wi - F i S etup on the home screen.

To select an item, use the

2. Select Wi - F i D irec t .

3. Press the OK button to proceed.

4. Press the OK button to proceed.

5. Press the

6. Select Disable Wi-Fi Direct.

7. Check the message, and then press the OK button.

button to display the setting screen.

u d l r

buttons, and then press the OK button.

Restoring the Network Settings from the Control Panel

You can restore all network settings to their defaults.

1. Select Settings on the home screen.

To select an item, use the

2. Select Restore Default Settings > Network Settings.

Check the message, and then press the OK button.

u d l r

buttons, and then press the OK button.

User's Guide

Preparing the Printer

Loading Papers

Available Paper and Capacities

Note:

e paper size displayed diers depending on the driver.

Genuine Epson Paper

Epson recommends using genuine Epson paper to ensure high-quality printouts.

Note:

e availability of paper varies by location. For the latest information on paper available in your area, contact Epson support.

Paper suitable for printing documents

Media Name Size Loading Capacity (Sheets)

Epson Bright White Ink Jet Paper A4 Up to the line indicated by the triangle

symbol on the edge guide.

Paper suitable for printing documents and photos

Media Name Size Loading Capacity (Sheets)

Epson Matte Paper-Heavyweight A4 20

Epson Photo Quality Ink Jet Paper A4 80

Paper suitable for printing photos

Media Name Size Loading Capacity

(Sheets)

Epson Ultra Glossy Photo Paper A4, 13×18 cm (5×7 in.), 10×15 cm (4×6 in.)

Epson Premium Glossy Photo Paper A4, 13×18 cm (5×7 in.), 10×15 cm (4×6 in.)

Epson Premium Semigloss Photo Paper A4, 13×18 cm (5×7 in.), 10×15 cm (4×6 in.)

Epson Photo Paper Glossy A4, 13×18 cm (5×7 in.), 10×15 cm (4×6 in.)

* Load one sheet of paper at a time if the paper does not feed correctly or if the printout has uneven colors or smears.

User's Guide

Preparing the Printer

Related Information

& “Paper for Borderless Printing” on page 44 & “Paper for 2-Sided Printing” on page 45

Commercially Available Paper

Plain papers

Media Name Size Loading Capacity (Sheets)

Plain paper

Copy paper

Letterhead

*1 Load one sheet of paper at a time if the paper does not feed correctly or if the printout has uneven colors or smears.

*2 Paper on which information such as the sender's name or corporation name are pre-printed in the header. There must be a

margin of 3 mm or more at the top of the paper. 2-sided printing and borderless printing are not available for letterhead paper.

Letter, A4, B5, 16K (195×270 mm), A5, A6,B6Up to the line indicated by the triangle symbol

on the edge guide.

Legal, 8.5×13 in., Indian-Legal 1

User Dened (mm)

54×86 to 215.9×1200

Envelopes

Media Name Size Loading Capacity (Envelopes)

Envelope Envelope #10, Envelope DL, Envelope C6 10

Related Information

& “Paper for Borderless Printing” on page 44 & “Paper for 2-Sided Printing” on page 45

Paper for Borderless Printing

Genuine Epson Paper

❏ Epson Bright White Ink Jet Paper

❏ Epson Photo Quality Ink Jet Paper

❏ Epson Matte Paper-Heavyweight

❏ Epson Ultra Glossy Photo Paper

❏ Epson Premium Glossy Photo Paper

❏ Epson Premium Semigloss Photo Paper

❏ Epson Photo Paper Glossy

User's Guide

Preparing the Printer

Commercially Available Paper

Plain paper, Copy paper (A4, Letter)

Paper for 2-Sided Printing

Genuine Epson Paper

Epson Bright White Ink Jet Paper

Commercially Available Paper

Plain paper, Copy paper

* For automatic 2-sided printing, you can use Letter, A4, B5, 16K, and User Dened (182 x 257 to 215.9 x 297 mm) paper sizes.

Paper Handling Precautions

❏ Read the instruction sheets supplied with the paper.

❏ To achieve high-quality printouts with genuine Epson paper, use the paper in the environment stated on the

sheets supplied with the paper.

❏ Fan and align the edges of the paper before loading. Do not fan or curl photo paper. Doing so may damage the

printable side.

❏ If the paper is curled, atten it or curl it slightly in the opposite direction before loading. Printing on curled

paper may cause paper jams and smears on the printout.

❏ Do not use paper that is wavy, torn, cut, folded, damp, too thick, too thin, or paper that has stickers stuck to it.

Using these types of paper causes paper jams and smears on the printout.

❏ Make sure you are using long-grain paper. If you are not sure what type of paper you are using, check the paper

packaging or contact the manufacturer to conrm the paper specications.

User's Guide

Preparing the Printer

Related Information

& “Printer Specications” on page 199

Loading Paper in the Rear Paper Feed

1. Open the feeder guard and pull out the paper support.

2. Slide the edge guides.

3. Load paper at the center of the paper support with the printable side facing up.

Important:

❏ Do not load more than the maximum number of sheets specied for the paper. For plain paper, do not load

above the line just under the

symbol inside the edge guide.

❏ Load paper short edge rst. However, when you have set the long edge as the width of the user dened size,

load paper long edge

rst.

User's Guide

Preparing the Printer

❏ Pre-punched paper

Note:

❏ Load a single sheet of dened size plain paper with binding holes at the le or right.

❏ Adjust the print position of your le to avoid printing over the holes.

❏ Automatic 2-sided printing is not available for pre-punched paper.

4. Slide the edge guides to the edges of the paper, and then close the feeder guard.

Important:

Do not place objects on the feeder guard. Doing so may prevent paper from feeding.

On the control panel, set the size and type of the paper you loaded in the rear paper feed.

To select an item, use the

Note: ❏ You can also display the paper size and paper type settings screen by selecting Settings > Printer Setup > Paper

Source Settings > Paper Setting.

❏ For letterhead paper, select Letterhead as the paper type.

❏ For letterhead paper, if you print on paper that is smaller than the setting in the printer driver, the printer may print

beyond the edges of the paper which can lead to ink smears on your printouts and excess ink building up inside the printer. Make sure you select the correct paper size setting.

❏ 2-sided printing and borderless printing are not available for letterhead paper. Also, the print speed may be slower.

u d l r

buttons, and then press the OK button.

User's Guide

Preparing the Printer

6. Slide out the output tray.

Note:

Return the remaining paper to its package. If you leave it in the printer, the paper may curl or the print quality may decline.

Related Information

& “Paper Handling Precautions” on page 45 & “Available Paper and Capacities” on page 43 & “Loading Envelopes and Precautions” on page 48 & “Loading Long Papers” on page 49

Loading Envelopes and Precautions

Loading envelopes short edge rst at the center with the ap facing down, and slide the edge guides to the edges of the envelopes.

❏ Fan and align the edges of the envelopes before loading. When the stacked envelopes are

press them down to atten them before loading.

pued

up with air,

❏ Do not use envelopes that are curled or folded. Using these envelopes causes paper jams and smears on the

printout.

❏ Do not use envelopes with adhesive surfaces on the aps or window envelopes.

❏ Avoid using envelopes that are too thin, as they may curl during printing.

User's Guide

Preparing the Printer

Related Information

& “Available Paper and Capacities” on page 43 & “Loading Paper in the Rear Paper Feed” on page 46

Loading Long Papers

When loading paper longer than legal size, store the paper support, and then atten the leading edge of the paper.

Related Information

& “Available Paper and Capacities” on page 43 & “Loading Paper in the Rear Paper Feed” on page 46

List of Paper Type

To obtain optimum printing results, select the paper type that suits the paper.

Media Name Media Type

Control Panel Printer Driver

Epson Bright White Ink Jet Paper Plain paper Plain paper

Epson Ultra Glossy Photo Paper Ultra Glossy Epson Ultra Glossy

Epson Premium Glossy Photo Paper Prem. Glossy Epson Premium Glossy

Epson Premium Semigloss Photo Paper Prem. Semigloss Epson Premium Semigloss

Epson Photo Paper Glossy Glossy Photo Paper Glossy

Epson Matte Paper-Heavyweight Matte Epson Matte

Epson Photo Quality Ink Jet Paper Photo Quality Ink Jet Epson Photo Quality Ink Jet

Placing Originals

Placing Originals on the Scanner Glass

Important:

When placing bulky originals such as books, prevent exterior light from shining directly onto the scanner glass.

User's Guide

1. Open the document cover.

Preparing the Printer

2. Remove any dust or stains on the surface of the scanner glass using a

Note:

If there is any trash or dirt on the scanner glass, the scanning range may expand to include it, so the image of the original may be displaced or reduced.

Place the original face-down and slide it to the corner mark.

dry, clean cloth.

so,

Note:

A range of 1.5 mm from the corner of the scanner glass is not scanned.

4. Close the cover gently.

Important:

Do not apply too much force to the scanner glass or the document cover. Otherwise, they may be damaged.

5. Remove the originals aer scanning.

Note:

If you leave the originals on the scanner glass for a long time, they may stick to the surface of the glass.

User's Guide

Preparing the Printer

Placing an ID Card for Copying

Place an ID card 5 mm away from the corner mark of the scanner glass.

Managing Contacts

Registering a contacts list allows you to easily enter destinations. You can register up to 100 entries, and you can use the contacts list when you enter a fax number.

Registering or Editing Contacts

Select Settings on the home screen.

To select an item, use the

2. Select Contacts Manager.

3. Do one of the following.

❏ To register a new contact, select Add Entry, and then select the registry number.

❏ To edit a contact, select Edit, and then select the target contact .

❏ To delete a contact, select Delete, select the target contact, and then select Ye s . No further steps are

necessary.

4. Make the necessary settings.

u d l r

buttons, and then press the OK button.

Note:

When entering a fax number, enter an external access code at the beginning of the fax number if your phone system is PBX and you need the access code to get an outside line. If the access code has been set in the Line Type setting, enter a

hash (#) instead of the actual access code. To add a pause (pause for three seconds) during dialing, press the to enter a hyphen (-).

5. Select Add Entry to complete registering or editing.

Related Information

& “Entering Characters” on page 17

button

User's Guide

Preparing the Printer

Registering or Editing Grouped Contacts

Adding contacts to a group allows you to send a fax to multiple destinations at the same time.

1. Select Settings on the home screen.

To select an item, use the

2. Select Contacts Manager.

3. Do one of the following.

❏ To register a new group of contacts, select Add Group, and then select the registry number.

❏ To edit a group of contacts, select Edit, and then select the target group.

❏ To delete a group of contacts, select Delete, select the target group, and then select Ye s . No further steps are

necessary.

4. Enter or edit the Group Name, and then select OK.

5. Enter or edit the Index Word, and then select OK.

Select the contacts that you want to register in the group.

Each time you press the

Note:

You can register up to 99 contacts.

7. Sselect Add Entry to complete registering or editing.

u d l r

button, the contact is selected and deselected alternatively.

buttons, and then press the OK button.

Related Information

& “Entering Characters” on page 17

Register Contacts on a Computer

Using Web Cong, you can create a contact list on your computer and import it to the printer.

1. Access Web Cong.

2. Select Advanced Settings from the list at the top right of the window.

Select Contacts.

4. Select the number that you want to register, and then click Edit.

5. Enter Name, Index Word, Fax Number, and Fax Speed.

6. Click Apply.

User's Guide

Preparing the Printer

Destination Setting Items

Items Settings and Explanation

Name Enter a name displayed in the contacts in 30 characters or less in Unicode (UTF-8).

If you do not specify this, leave it blank.

Index Word Enter words to search in 30 characters or less in Unicode (UTF-8). If you do not

specify this, leave it blank.

Typ e

Fax Number Enter between 1 and 64 characters using 0-9 - * # and space.

Fax Speed Select a communication speed for a destination.

This item is xed as Fax. You cannot change this setting.

Registering Destinations as a Group

1. Access Web Cong.

2. Select Advanced Settings from the list at the top right of the window.

Select Contacts.

4. Select the number that you want to register, and then click Edit.

5. Enter a Name and Index Word.

6. Select a group from Typ e.

7. Click Select for Contact(s) for Group.

e available destinations are displayed.

8. Select the destination that you want to register to the group, and then click Select.

Note:

Destinations can be registered to multiple groups.

9. Click Apply.

Menu Options for Settings

Select Settings on the home screen of the printer to make various settings.

Menu Options for Supply Status

Select the menu on the control panel as described below.

Settings > Supply Status

User's Guide

Ink Level:

Preparing the Printer

Displays the approximate levels of the ink cartridges. When is displayed, the ink cartridge is

running low. When

You can replace ink cartridges from this screen.

is displayed, the ink cartridge is expended.

Maintenance Box Service Life:

Displays the approximate service life of the maintenance box. When is displayed, the

maintenance box is nearly full. When

is displayed, the maintenance box is full.

Menu Options for Maintenance

Select the menus on the control panel as described below.

Settings > Maintenance

Nozzle Check:

Select this feature to check if the print head nozzles are clogged. e printer prints a nozzle check pattern.

Head Cleaning:

Select this feature to clean clogged nozzles in the print head.

Print Head Alignment:

Select this feature to adjust the print head to improve print quality.

❏ Vertical Alignment

Select this feature if your printouts look blurry or text and lines are misaligned.

❏ Horizontal Alignment

Select this feature if horizontal banding appears at regular intervals in your printouts.

Ink Cartridge(s) Replacement:

Use this feature to replace the ink cartridge before the ink is expended.

Paper Guide Cleaning:

Select this feature if there are ink stains on the internal rollers. e printer feeds paper to clean the internal rollers.

Related Information

& “Checking and Cleaning the Print Head” on page 149 & “Replacing Ink Cartridges” on page 142 & “Cleaning the Paper Path for Ink Smears” on page 151

Menu Options for Printer Setup

Select the menus on the control panel as described below.

User's Guide

Settings > Printer Setup

Paper Source Settings:

Paper Setting:

Select the paper size and paper type you loaded in the paper source.

A4/Letter Auto Switching:

Select On to feed paper from the paper source set as A4 size when there is no paper source set as Letter, or feed from the paper source set as Letter size when there is no paper source set as A4.

Error Notice:

Select On to display an error message when the selected paper size or type does not match the loaded paper.

Preparing the Printer

Paper Setup Auto Display:

Select On to display the Paper Setting screen when loading paper in the paper source. If you disable this feature, you cannot print from an iPhone, iPad, or iPod touch using AirPrint.

Sound:

Adjust the volume.

❏ Mute

Select On to mute all sound.

❏ Normal Mode

Select the volume such as Button Press.

❏ Quiet Mode

Select the volume such as Button Press in Quiet Mode.

Quiet Mode:

Your product may not have this feature depending on the location of purchase.

Select On to reduce noise during printing, however, this may lower the print speed. Depending on the paper type and print quality settings you selected, there may be no dierence in the printer's noise level.

Power O Timer:

Your product may have this feature or the Power O Settings feature depending on the location of purchase.

Select this setting to turn the printer o automatically when it is not used for a specied period of time. You can adjust the time before power management is applied. Any increase will aect the product’s energy eciency. Please consider the environment before making any change.

Power O Settings:

Your product may have this feature or the Power O Timer feature depending on the location of purchase.

User's Guide

Date/Time Settings:

Preparing the Printer

❏ Power O If Inactive

Select this setting to turn the printer o automatically if it is not used for a specied period of time. Any increase will aect the product’s energy eciency. Please consider the environment before making any change.

❏ Power O If Disconnected

Select this setting to turn the printer o aer 30 minutes when all ports including the LINE port are disconnected.

❏ Date/Time

Enter the current date and time.

❏ Daylight Saving Time

Select the summer time setting that applies to your area.

❏ Time Di  e rence

Enter the time dierence between your local time and UTC (Coordinated Universal Time).

feature may not be available depending on your region.

is

Country/Region:

Select the country or region in which you are using your printer. If you change the country or region, your fax settings return to their defaults and you must select them again.

Language:

Select the language used on the LCD screen.

Keyboard

Change the layout of the keyboard on the LCD screen.

Sleep Timer:

Adjust the time period to enter a sleep mode (energy saving mode) when the printer has not performed any operations. e LCD screen turns black when the setting time passes.

Auto Error Solver:

Select an action to perform when a 2-sided printing error or a memory full error occurs.

❏ On

Displays a warning and prints in single-sided mode when a 2-sided printing error occurs, or prints only what the printer could process when a memory full error occurs.

❏ O

Displays an error message and cancels printing.

Ink Drying Time:

Select the ink drying time you want to use when performing 2-sided printing. e printer prints the other side

printing one side. If your printout is smeared, increase the time setting.

aer

PC Connection via USB:

Select Enable to allow a computer to access the printer when connected by USB. When Disable is selected, printing and scanning that is not sent over a network connection is restricted.

User's Guide

Preparing the Printer

Related Information

& “Saving Power - Control Panel” on page 60 & “Entering Characters” on page 17

Menu Options for Network Settings

Select the menus on the control panel as described below.

Settings > Network Settings

Print Status Sheet:

Prints a network status sheet.

Wi-Fi Setup:

Set up or change wireless network settings. Choose the connection method from following and then follow the instructions on the control panel.

❏ Wi-Fi (Recommended)

❏ Wi - F i D irect

Connection Check:

Checks the status of the network connection and prints the network connection report. If there are any problems with the connection, see the check report to solve the problem.

Related Information

& “Making Wi-Fi Settings by Entering the SSID and Password” on page 30 & “Making Wi-Fi Settings by Push Button Setup” on page 31 & “Making Wi-Fi Settings by PIN Code Setup (WPS)” on page 32 & “Wi-Fi Direct (Simple AP) Connection” on page 19 & “Printing a Network Status Sheet” on page 39 & “Checking the Network Connection Status” on page 33

Menu Options for Epson Connect Services

Select the menus on the control panel as described below.

Settings > Epson Connect Services

For usage guides, see the following portal website.

https://www.epsonconnect.com/

http://www.epsonconnect.eu (Europe only)

User's Guide

Preparing the Printer

Suspend/Resume:

Select whether to suspend or resume Epson Connect services.

Email Address:

Check the printer's email address that is registered to the Epson Connect services.

Status:

Check whether or not the printer is registered and connected to the Epson Connect services.

Related Information

& “Printing Using a Network Service” on page 164

Menu Options for Google Cloud Print Services

Select the menus on the control panel as described below.

Settings > Google Cloud Print Services

Suspend/Resume:

Select whether to suspend or resume the Google Cloud Print services.

Unregister:

Unregister the Google Cloud Print services.

Status:

Check whether or not the printer is registered and connected to the Google Cloud Print services.

For registration and usage guides, see the following portal website.

https://www.epsonconnect.com/

http://www.epsonconnect.eu (Europe only)

Menu Options for Contacts Manager

Select the menus on the control panel as described below.

Settings > Contacts Manager

Add Entry:

Add Group:

Edit:

Edit the entries and groups registered in contacts.

User's Guide

Preparing the Printer

Delete:

Delete the entry or group registered in contacts.

Print Contacts:

Print the entry information and group information for the contacts in the list.

Menu Options for Fax Settings

Select the menu on the control panel as described below.

Settings > Fax Settings

See Related Information below.

Related Information

& “Menu Options for Fax Settings” on page 71

Menu Options for Print Status Sheet

Select the menus on the control panel as described below.

Settings > Print Status Sheet

Conguration Status Sheet:

Print information sheets showing the current printer status and settings.

Supply Status Sheet:

Print information sheets showing the status of consumables.

Usage History Sheet:

Print information sheets showing the usage history of the printer.

Menu Options for Print Counter

Select the menus on the control panel as described below.

Settings > Print Counter

Displays the total number of prints, B&W prints, and color prints including items such as the status sheet from the time you purchased the printer.

Menu Options for Customer Research

Select the menus on the control panel as described below.

Settings > Customer Research

User's Guide

Preparing the Printer

Select Approve to provide product usage information such as the number of prints to Seiko Epson Corporation.

Menu Options for Restore Default Settings

Select the menus on the control panel as described below.

Settings > Restore Default Settings

Resets the following menus to their defaults.

❏ Network Settings

❏ Copy Settings

❏ Scan Settings

❏ Fax Settings

❏ Clear All Data and Settings

Menu Options for Firmware Update

Select the menus on the control panel as described below.

Settings > Firmware Update

Update:

Checks if the latest version of the rmware has been uploaded to the network server. If an update is available, you can select whether or not to start updating.

Current Version:

Displays the current rmware version of your printer.

Notication

Checks for

rmware

updates periodically and

noties

you if an update is available.

Saving Power

e printer enters sleep mode or turns o automatically if no operations are performed for a set period. You can adjust the time before power management is applied. Any increase will consider the environment before making any change.

the product's energy

aect

eciency.

Please

Depending on the location of purchase, the printer may have a feature that turns it o automatically if it is not connected to the network for 30 minutes.

Saving Power - Control Panel

1. Select Settings on the home screen.

To select an item, use the

u d l r

buttons, and then press the OK button.

User's Guide

Preparing the Printer

2. Select Printer Setup.

3. Do one of the following.

Note: Your produ c t may h ave th e Power O Settings or Power O Timer feature depending on the location of purchase.

❏ Select Sleep Timer or Power O Settings > Power O If Inactive or Power O If Disconnected, and then

make settings.

❏ Select Sleep Timer or Power O Timer, and then make settings.

User's Guide

Fax Settings

Before Using Fax Features

Set up the following to use the fax features.

❏ Connect the printer correctly with the phone line and, if necessary, with a phone

❏ Complete the Fax Setting Wizard, which is required to make basic settings.

Set the following as necessary.

❏ Contacts registration

❏ User Default Settings that

❏ Report Settings to print reports when faxes are sent or received

Related Information

& “Connecting to a Phone Line” on page 62 & “Making the Printer Ready to Send and Receive Faxes (Using Fax Setting Wizard)” on page 65 & “Making Settings Individually for Printer's Fax Features” on page 67

“Menu Options for Fax Settings” on page 71

“Network Settings” on page 19

“Managing Contacts” on page 51

“User Default Settings Menu” on page 75

“Report Settings Menu” on page 74

default values for Fax menu items

dene

Connecting to a Phone Line

Compatible Telephone Lines

You can use the printer over standard analogue telephone lines (PSTN = Public Switched Telephone Network) and PBX (Private Branch Exchange) telephone systems.

You may not be able to use the printer with the following phone lines or systems.

❏ VoIP phone line such as DSL or

❏ Digital phone line (ISDN)

❏ Some PBX telephone systems

❏ When adapters such as terminal adapters, VoIP adapters, splitters, or DSL router are connected between the

telephone wall jack and the printer

ber-optic

digital service

User's Guide

Fax Settings

Connecting the Printer to a Phone Line

Connect the printer to a telephone wall jack using an RJ-11 (6P2C) phone cable. When connecting a telephone to the printer, use a second RJ-11 (6P2C) phone cable.

Depending on the area, a phone cable may be included with the printer. If it is included, use that cable.

You may need to connect the phone cable to an adapter provided for your country or region.

Note:

Remove the cap from the EXT. port of the printer only when connecting your telephone to the printer. Do not remove the cap if you are not connecting your telephone.

In areas where lightning strikes occur frequently, we recommend that you use a surge protector.

Connecting to a Standard Phone Line (PSTN) or PBX

Connect a phone cable from the telephone wall jack or PBX port to the LINE port on the back of the printer.

Connecting to DSL or ISDN

Connect a phone cable from the DSL modem or the ISDN terminal adapter to the LINE port on the back of the printer. See the documentation provided with the modem or the adapter for more details.

Note:

If your DSL modem is not equipped with a built-in DSL lter, connect a separate DSL lter.

User's Guide

Fax Settings

Connecting Your Phone Device to the Printer

When using the printer and your telephone on a single phone line, connect the telephone to the printer.

Note:

❏ If your phone device has a fax function, disable the fax function before connecting. See the manuals that came with the

phone device for details.

❏ If you connect an answering machine, make sure the printer's Rings to Answer setting is set higher than the number of

rings your answering machine is set to answer a call.

Remove the cap from the EXT. port on the back of the printer.

Connect the phone device and the EXT. port with a phone cable.

Note:

When sharing a single phone line, make sure you connect the phone device to the EXT. port of the printer. If you split the line to connect the phone device and the printer separately, the phone and the printer do not work correctly.

User's Guide

3. Select Fax on the home screen.

Fax Settings

To select an item, use the

4. Pick up the handset.

A connection has been established when the message to press on the screen.

Related Information

& “Making the Printer Ready to Send and Receive Faxes (Using Fax Setting Wizard)” on page 65 &

“Making Settings to Use an Answering Machine” on page 69

& “Making Settings to Receive Faxes Operating Only a Connected Phone (Remote Receive)” on page 69 & “Setting Receive Mode” on page 67

u d l r

buttons, and then press the OK button.

to start sending or receiving a fax is displayed

Making the Printer Ready to Send and Receive Faxes (Using Fax Setting Wizard)

Fax Setting Wizard congures the basic fax features to make the printer ready to send and receive faxes.

e Wizard is displayed automatically when the printer is turned on for the rst time. You can also display the wizard manually from the printer's control panel. You need to run the wizard again in case the wizard is skipped when the printer is

❏ e items below are what you can set through the wizard.

❏ Header (Your Phone Number and Fax Header)

❏ Receive Mode (Auto or Manual)

❏ e items below are set automatically according to the connection environment.

❏ Dial Mode (such as Ton e or Pulse)

❏ Line Type (PSTN or PBX)

❏ Dial Tone Detection

❏ DRD Setting

❏ Other items in Basic Settings remain as they are.

turned on or when the connection environment has changed.

rst

Start Fax Setting Wizard to make Basic Settings, following the on-screen instructions.

User's Guide

Fax Settings

1. Make sure the printer is connected to the phone line.

Note:

Because an automatic fax connection check runs at the end of the wizard, the printer must be connected to the phone line before starting the wizard.

2. Select Settings on the home screen on the printer's control panel.

To select an item, use the

u d l r

buttons, and then press the OK button.

3. Select Fax Settings > Fax Setting Wizard.

Check the message on the screen displayed, and then select Proceed.

e wizard begins.

5. On the fax header entry screen, enter the sender name such as your company name, and then select OK.

Note:

Your sender name and your fax number appear as the header for outgoing faxes.

On the phone number entry screen, enter your fax number, and then select Proceed

7. On the DRD Setting screen, make the following settings.

❏ If you have subscribed to a distinctive ring service from your telephone company: Select Settings, and then

select the ring pattern to be used for incoming faxes.

- If you select All, go to step 8.

- If you select any other setting, Receive Mode is automatically set to Auto. Go to step 10.

❏ If you do not need to set this option: Select Skip, and then go to step 8.

Note:

❏ Distinctive ring services, oered by many telephone companies (the service name diers by company), allows you to

have several phone numbers on one phone line. Each number is assigned a dierent ring pattern. You can use one number for voice calls and another for fax calls. Select the ring pattern assigned to fax calls in DRD.

❏ Depending on the region, On and O are displayed as the DRD options. Select On to use the distinctive ring feature.

8. On the Receive Mode Setting screen, select whether you are using your phone device connected to the printer.

❏ When connected: Select Ye s , and then go to the next step.

❏ When not connected: Select No, and then go to step 10. Receive Mode is set to Auto.

9. On the Receive Mode Setting screen, select whether you want to receive faxes automatically.

❏ To r eceive a utom a t ically : S e l ect Ye s . Receive Mode is set to Auto.

❏ To receive manually: Select No. Receive Mode is set to Manual.

10. Check the settings you made on the conrmation screen displayed, and then select Proceed.

To correct or change settings, press the

button.

11. On the Check Fax Connectionscreen, select Start Checking to run the fax connection check, and when the

screen prompts you to print the check result, select Print.

A report of the check result that shows the connection status is printed.

User's Guide

Fax Settings

Note:

❏ If there are any errors reported, follow the instructions on the report to solve them.

❏ If the Select Line Type screen is displayed, select the line type.

- When you are connecting the printer to a PBX phone system or terminal adapter, select PBX.

- When you are connecting the printer to a standard phone line, select PSTN. When the message to disable dial tone detection is shown on the screen, press the OK button. However, disabling dial tone detection may cause the printer to skip the

Related Information

& “Connecting the Printer to a Phone Line” on page 63 & “Setting Receive Mode” on page 67 & “Making Settings to Use an Answering Machine” on page 69 & “Making Settings to Receive Faxes Operating Only a Connected Phone (Remote Receive)” on page 69 & “Basic Settings Menu” on page 72

digit of a fax number when dialing and send the fax to the wrong number.

rst

Making Settings Individually for Printer's Fax Features

You c a n Fax Setting Wizard can also be changed. For more details, see the descriptions of the Fax Settings Menu.

Related Information

& “Menu Options for Fax Settings” on page 71

congure

Setting Receive Mode

ere are two options in Receive Mode for receiving incoming faxes. You can make settings in the menu below.

Settings > Fax Settings > Basic Settings > Receive Mode

Receive Mode Use of Phone Line

Manual Mainly for phoning, but also for faxing

Auto Only for faxing (external phone device is not required)

the printer's fax features individually using the printer's control panel. e settings made using

Mainly for faxing, and sometimes phoning

Related Information

& “Usage of Auto Mode” on page 68 & “Usage of Manual Mode” on page 68 & “Basic Settings Menu” on page 72

User's Guide

Fax Settings

Usage of Manual Mode

Receiving Faxes

When the telephone rings, you can answer the ringing manually by picking up the handset.

❏ When you hear a fax signal (baud):

Select Fax on the printer's home screen, press the # button to select receiving a fax, and then select hang up the handset.

❏ If the ringing is for a voice call:

You can answer the phone as normal.

Receiving Faxes Using only a Connected Telephone

When Remote Receive is set, you can receive faxes by simply entering the start code.

When the telephone rings, pick up the handset. When you hear a fax tone (baud), dial the two digit start code, and then hang up the handset.

. Next,

Related Information

“Making Settings to Receive Faxes Operating Only a Connected Phone (Remote Receive)” on page 69

Usage of Auto Mode

Receiving Faxes Without an External Phone Device

printer automatically switches to receive faxes when the number of rings you set in Rings to Answer is

e complete.

Note: We recommend setting Rings to Answer to as low a number as possible.

Receiving Faxes With an External Phone Device

A printer with an external phone device works as follows.

❏ If your phone device is the answering machine and when it answers within the number of rings set in Rings to

Answer:

- If the ringing is for a fax: e printer automatically switches to receive faxes.

- If the ringing is for a voice call: e answering machine can receive voice calls and record voice messages.

❏ When you pick up the handset within the number of rings set in Rings to Answer:

- If the ringing is for a fax: You can receive the fax using the same steps as Manual.

- If the ringing is for a voice call: You can answer the phone as normal.

❏ When the printer automatically switches to receive faxes:

- If the ringing is for a fax: e printer starts receiving faxes.

- If the ringing is for a voice call: You cannot answer the phone. Ask the person to call you back.

Note:

Set the Rings to Answer settings of the printer to a higher number than the number of rings for the answering machine. Otherwise, the answering machine cannot receive voice calls to record voice messages. For details on setting up the answering machine, see the manual supplied with the answering machine.

User's Guide

Fax Settings

Related Information

& “Making Settings to Use an Answering Machine” on page 69 & “Usage of Manual Mode” on page 68

Making Settings When You Connect an External Phone Device

Making Settings to Use an Answering Machine

You need settings to use an answering machine.

1. Select Settings on the home screen on the printer's control panel.

To select an item, use the

2. Select Fax Settings > Basic Settings.

3. Set Receive Mode to Auto.

4. Set the Rings to Answer setting of the printer to a higher number than the number of rings for the answering

machine.

If Rings to Answer is set lower than the number of rings for the answering machine, the answering machine cannot receive voice calls to record voice messages. See the manuals that came with the answering machine for its settings.

printer's Rings to Answer setting may not be displayed, depending on the region.

e

Related Information

& “Usage of Auto Mode” on page 68 & “Basic Settings Menu” on page 72

u d l r

buttons, and then press the OK button.

Making Settings to Receive Faxes Operating Only a Connected Phone (Remote Receive)

You can start receiving incoming faxes by only picking up the handset and operating the phone, without operating the printer at all.

e Remote Receive feature is available for telephones that support tone dialing.

1. Select Settings on the home screen on the printer's control panel.

To select an item, use the

2. Select Fax Settings > Basic Settings > Remote Receive.

3. Select On.

4. Enter a two digit code (you can enter 0 to 9, *, and #) as the start code, and then press the OK button to apply

the settings.

u d l r

buttons, and then press the OK button.

User's Guide

Fax Settings

Related Information

& “Usage of Manual Mode” on page 68 & “Basic Settings Menu” on page 72

Making Settings for Blocking Junk Faxes

You can block junk faxes.

1. Select Settings on the home screen on the printer's control panel.

To select an item, use the

2. Select Fax Settings > Basic Settings > Rejection Fax.

Set the condition to block junk faxes.

Select Rejection Fax, and then enable the following options.

❏ Rejection Number List: Rejects faxes that are in the Rejection Number List.

❏ Fax Header Blank: Rejects faxes that have blank header information.

❏ Caller not in Contacts: Rejects faxes that have not been added to the contact list.

Press

5. If you are using the Rejection Number List, select Edit Blocked Number list, and then edit the list.

Related Information

& “Basic Settings Menu” on page 72

to return to the Rejection Fax screen.

u d l r

buttons, and then press the OK button.

Making Settings to Send and Receive Faxes on a Computer

To send and receive faxes on a computer,FAX Utility must be installed on the computer connected by network or USB cable .

Making Save to Computer Setting to Receive Faxes

You can receive faxes on a computer by using the FAX Utility. Install FAX Utility on the client computer and make the setting. For details, see Basic Operations in the FAX Utility help (displayed on the main window).

e setting item below on the printer's control panel is set to Ye s , and the faxes received can be saved on the computer.

Settings > Fax Settings > Receive Settings > Save to Computer

Related Information

& “Receive Settings Menu” on page 73

User's Guide

Fax Settings

Making Save to Computer Setting to Also Print on the Printer to Receive Faxes

You can make the setting to print received faxes on the printer as well as save them on a computer.

1. Select Settings on the home screen on the printer's control panel.

To select an item, use the

2. Select Fax Settings > Receive Settings.

Select Save to Computer > Yes and Pr in t.

Related Information

& “Receive Settings Menu” on page 73

u d l r

buttons, and then press the OK button.

Making Save to Computer Setting not to Receive Faxes

To set the printer not to save received faxes on the computer, change the settings on the printer.

Note:

You can also change the settings using the FAX Utility. However, if there are any faxes that have been unsaved to the computer, the feature does not work.

1. Select Settings on the home screen on the printer's control panel.

To select an item, use the

2. Select Fax Settings > Receive Settings.

u d l r

buttons, and then press the OK button.

3. SelectSave to Computer > No.

Related Information

& “Receive Settings Menu” on page 73

Menu Options for Fax Settings

Selecting Settings > Fax Settings from the printer's control panel displays this menu.

Check Fax Connection

You can nd the menu on the printer's control panel below:

Settings > Fax Settings > Check Fax Connection

Selecting Check Fax Connection checks that the printer is connected to the phone line and ready for fax transmission. You can print the check result on A4 size plain paper.

User's Guide

Fax Settings

Fax Setting Wizard

You can nd the menu on the printer's control panel below:

Settings > Fax Settings > Fax Setting Wizard

Selecting Fax Setting Wizard makes basic fax settings. Follow the on-screen instructions.

Related Information

& “Making the Printer Ready to Send and Receive Faxes (Using Fax Setting Wizard)” on page 65

Basic Settings Menu

You can nd the menu on the printer's control panel below:

Settings > Fax Settings > Basic Settings

Item Description

Fax Speed

ECM Automatically corrects errors in the fax transmission (Error Correction Mode), mostly caused by

Dial Tone Detection Detects a dial tone before starting to dial. If the printer is connected to a PBX (Private Branch

Dial Mode

Line Type Select the line type to which you have connected the printer.

Select the fax transmission speed. We recommend selecting Slow(9,600bps) when a communication error occurs frequently, when sending/receiving a fax to/from abroad, or when you are using an IP (VoIP) phone service.

telephone line noise. If this is disabled, you cannot send or receive documents in color.

Exchange) or digital phone line, the printer may fail to start dialing. In this situation, change the Line Type setting to PBX. If this does not work, disable this feature. However, disabling this feature may drop the

Select the type of phone system to which you have connected the printer. When set to Pulse, you can temporarily switch the dialing mode from pulse to tone by pressing while entering numbers on the fax top screen. This setting may not be displayed depending on your region or country.

When using the printer in an environment that uses extensions and requires an external access code, such as 0 and 9, to get an outside line, select PBX and register the access code. Once you have registered the access code, enter # (hash) instead of the access code when sending a fax to an outside fax number. For an environment that uses a DSL modem or terminal adapter, setting to PBX is also recommended.

You cannot send faxes to recipients in Contacts in which an external access code such as 0 or 9 is set. If you have added recipients in Contacts using an external access code such as 0 or 9, set the access code to Do Not Use. Otherwise, you must change the code to # in Contacts.

digit of a fax number and send the fax to the wrong number.

rst

("T" is entered)

Header Enter your sender name and fax number. These appear as a header on outgoing faxes.

❏ Your Phone Number: You can enter up to 20 characters using 0-9 + or space.

❏ Fax Header: You can register up to 21 sender names as necessary. You can enter up to 40

characters for each sender name.

Receive Mode Select the receive mode. For details, see the related Information below.

User's Guide

Fax Settings

Item Description

DRD If you have subscribed to a distinctive ring service from your telephone company, select the ring

pattern to be used for incoming faxes. The distinctive ring service, companies (the service name diers by company), allows you to have several phone numbers on one phone line. Each number is assigned dierent ring pattern. You can use one number for voice calls and another for fax calls. Depending on the region, this option may be On or O.

Rings to Answer Select the number of rings that must occur before the printer automatically receives a fax.

Remote Receive When you answer an incoming fax call on a phone connected to the printer, you can start

receiving the fax by entering the code using the phone.

To set or change the start code, set Remote Receive to On and enter two characters using 0-9, *, #.

Rejection Fax ❏ Rejection Fax: Select options to reject receiving junk faxes.

by many telephone

oered

❏ Rejection Number List: If the other party's phone number is in the rejection

number list, set whether to reject the incoming faxes.

❏ Fax Header Blank: If the other party's phone number is blocked, set whether to

reject receiving the faxes.

❏ Caller not in Contacts: If the other party's phone number is not in the contacts,

set whether to reject receiving the faxes.

❏ Edit Blocked Number list: You can register up to 30 fax numbers to reject the faxes and calls.

Enter up to 20 characters using 0-9, *, #, or space.

Related Information

& “Making the Printer Ready to Send and Receive Faxes (Using Fax Setting Wizard)” on page 65 & “Setting Receive Mode” on page 67 & “Making Settings to Receive Faxes Operating Only a Connected Phone (Remote Receive)” on page 69 & “Making Settings for Blocking Junk Faxes” on page 70

Receive Settings Menu

You can nd the menu on the printer's control panel below:

Settings > Fax Settings > Receive Settings

Item Description

Save to Computer

Auto Reduction Prints received faxes with large-size documents reduced to t on the paper in the paper source.

Split Page Settings Prints received faxes with the page split when the size of the received documents is larger than

Saves received faxes as PDF les on a computer connected to the printer. You can set this to Ye s by using only the FAX Utility. Install FAX Utility on the computer in advance. After setting this to Ye s , you can change this to Ye s a nd Pr in t.

Reducing may not always be possible depending on the received data. If this is turned o, large documents are printed at their original size on multiple sheets, or a blank second page may be ejected.

the size of the paper loaded in the printer.

User's Guide

Fax Settings

Item Description

Auto Rotation Rotates faxes received as landscape-orientated, A5 size documents so that they are printed on

A5 size paper. This setting is applied when A5 size is set in Settings > Printer Setup > Paper Source Settings > Paper Setting > Paper Size.

Selecting O, faxes received as landscape-orientated A5 size, the same width as A4 portrait documents, are assumed and printed as A4 size faxes.

Add Reception

Information

2-Sided Prints multiple pages of received faxes on both sides of the paper.

Print Start Timing Select options to start printing the faxes to receive.

Collation Stack Since the rst page is printed last (output to the top), the printed documents are stacked in the

Print Suspend Time

Quiet Mode Reduces the noise the printer makes when printing faxes, however, print speed may be reduced.

Prints reception information in the received fax, even if the sender does not set the header information. The reception information includes the received date and time, sender's ID, and page number (such as "P1"). When Split Page Settings is enabled, the split page number is also included.

❏ All Pages Received: Printing starts after receiving all of the pages. To start printing from the

rst page or last page depends on the setting of Collation Stack feature. See the explanation for Collation Stack.

❏ First Page Received: Starts printing when the

as the pages are received. If the printer cannot start printing, such as when it is printing other jobs, the printer starts printing received pages as a batch when it is available.

correct page order. When the printer is running low on memory, this feature may not be available.

During the time period you specied from Stop through Restart you specied, the printer saves documents received in the printer's memory without printing them. This feature can be used for noise prevention at night or to prevent condential documents from being disclosed while you are away. Before using this feature, make sure there is enough free memory. When you set this to O, you can print the received documents even before the restart time.

page is received, and then prints in order

rst

Report Settings Menu

You c a n

Settings > Fax Settings > Report Settings

Item Description

Fax Log Auto Print

Attach Fax image to

report

Report Format

the menu on the printer's control panel below:

nd

Prints the fax log automatically. Select On(Every 30) to print a log every time 30 fax jobs are completed. Select On(Time) to print the log at a specied time. However, if the number of fax jobs exceeds 30, the log is printed before the specied time.

Prints a Transmission Report with an image of the rst page of the sent document. Select

On(Large Image) to print the upper part of the page without reducing. Select On(Small Image) to print the entire page reducing it to t onto the report.

Selects a format for fax reports in Fax > Menu > More > Fax Report other than Protocol Trace. Select Detail to print with error codes.

User's Guide

Fax Settings

Security Settings Menu

You can nd the menu on the printer's control panel below:

Settings > Fax Settings > Security Settings

Item Description

Direct Dialing

Restrictions

Conrm Address List

Backup Data Auto Clear

Clear Backup Data Erases all backup copies temporarily stored in the printer's memory. Run this before you give the

Selecting On disables manual entry of the recipient's fax numbers allowing the operator to select recipients only from the contacts list or sent history.

Selecting Enter Twice requires the operator to enter the fax number again when the number was manually entered.

Selecting O enables manual entry of the recipient's fax numbers.

Selecting On displays a recipient conrmation screen before starting the transmission.

Selecting On automatically erases the backups when sending or receiving a document completes successfully and the backups become unnecessary.

Selecting O, to prepare for an unexpected power o due to an electricity failure or an incorrect operation, temporarily stores backup copies of sent and received documents in its memory.

printer to someone else or dispose of it.

User Default Settings Menu

You c a n

Settings > Fax Settings > User Default Settings

e settings made in this menu become your default settings for in the Fax > Menu. For details, see the related information below.

the menu on the printer's control panel below:

nd

Related Information

& “Scan Settings” on page 128 & “Fax Send Settings” on page 128

User's Guide

Printing

Printing from the Printer Driver on Windows

Accessing the Printer Driver

When accessing the printer driver from the computer's control panel, the settings are applied to all of the applications.

Accessing the printer driver from the control panel

❏ Windows 10/Windows Server 2016

Click on the start button, and then select Windows System > Control Panel > Vie w d evi c es and p r inters in Hardware and Sound. Right-click on your printer, or press and hold it and then select Printing preferences.

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Select Desktop > Settings > Control Panel > Vi e w de v ices a nd pri n t e r s in Hardware and Sound. Right-click on your printer, or press and hold it and then select Printing preferences.

❏ Windows 7/Windows Server 2008 R2

Click the start button, and select Control Panel > Vie w dev i ces a n d pr inte r s in Hardware and Sound. Right- click on your printer and select Printing preferences.

❏ Windows Vista/Windows Server 2008

Click the start button, and select Control Panel > Printers in Hardware and Sound. Right-click on your printer and select Printing preferences.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Click the start button, and select Control Panel > Printers and Other Hardware > Printers and Faxes. Right- click on your printer and select Printing preferences.

Accessing the printer driver from the printer icon on the task bar

e printer icon on the desktop task bar is a shortcut icon allowing you to quickly access the printer driver.

If you click the printer icon and select Printer Settings, you can access the same printer settings window as the one displayed from the control panel. If you double-click this icon, you can check the status of the printer.

Note: If the printer icon is not displayed on the task bar, access the printer driver window, click Monitoring Preferences on the Maintenance tab, and then select Register the shortcut icon to the taskbar.

Printing Basics

Note:

Operations may dier depending on the application. See the application's help for details.

1. Open the

Load paper in the printer if it has not already been loaded.

you want to print.

le

User's Guide

Printing

2. Select Print or Page Setup from the File menu.

3. Select your printer.

4. Select Preferences or Properties to access the printer driver window.

Change the settings as necessary.

See the menu options for the printer driver for details.

Note:

❏ You can also see the online help for explanations of the setting items. Right-clicking an item displays Help.

❏ When you select Print Preview, you can see a preview of your document before printing.

6. Click OK to close the printer driver window.

7. Click Print.

Note:

When you select Print Preview, a preview window is displayed. To change the settings, click Cancel, and then repeat the procedure from step 2.

Related Information

“Available Paper and Capacities” on page 43

& & “Loading Paper in the Rear Paper Feed” on page 46 & “Main Tab” on page 92

User's Guide

Printing

Printing on 2-Sides

You can print on both sides of the paper. You can also print a booklet that can be created by re-ordering the pages and folding the printout.

Note:

❏ is feature is not available for borderless printing.

❏ You can use automatic and manual 2-sided printing. During manual 2-sided printing, ip the paper over to print on the

other side when the printer has nished printing the rst side.

❏ If you do not use paper that is suitable for 2-sided printing, the print quality may decline and paper jams may occur.

❏ Depending on the paper and the data, ink may bleed through to the other side of the paper.

Related Information

& “Available Paper and Capacities” on page 43

Print Settings

Manual 2-sided printing is available when EPSON Status Monitor 3 is enabled. However, it may not be available when the printer is accessed over a network or is used as a shared printer.

Note: To enable EPSON Status Monitor 3, click Extended Settings on the Maintenance tab, and then select Enable EPSON Status Monitor 3.

1. On the printer driver's Main tab, select an option from 2-Sided Printing.

2. Click Settings, make the appropriate settings, and then click OK.

Make settings for Print Density if necessary. is setting is not available when you select manual 2-sided printing.

Note:

❏ To print a folded booklet, select Booklet.

❏ When setting Print Density, you can adjust print density according to the document type.

❏ Printing may be slow depending on the combination of options selected for Select Document Type in the Print

Density Adjustment window and for Quality on the Main tab.

User's Guide

Printing

3. Click Print.

For manual 2-sided printing, when the rst side has nished printing, a pop-up window is displayed on the computer. Follow the on-screen instructions.

Related Information

& “Printing Basics” on page 76 & “Main Tab” on page 92

Printing Several Pages on One Sheet

You can print two or four pages of data on a single sheet of paper.

Print Settings

On the printer driver's Main tab, select 2-Up or 4-Up as the Multi-Page setting.

Note:

is feature is not available for borderless printing.

Related Information

& “Printing Basics” on page 76 & “Main Tab” on page 92

User's Guide

Printing

Printing and Stacking in Page Order (Reverse Order Printing)

You can print from the last page so that the documents are stacked in page order.

Print Settings

On the printer driver's Main tab, select Reverse Order.

Related Information

& “Printing Basics” on page 76 & “Main Tab” on page 92

Printing a Reduced or Enlarged Document

You can reduce or enlarge the size of a document by a specic percentage or to t the paper size you loaded in the printer.

Print Settings

On the printer driver's More Options tab, select the document size from the Document Size setting. Select the paper size you want to print on from the Output Paper setting. Select Reduce/Enlarge Document, and then select Fit to Page or Zoom to. When you select Zoom to, enter a percentage.

Select Center to print the images in the center of the page.

User's Guide

Printing

Note:

is feature is not available for borderless printing.

Related Information

& “Printing Basics” on page 76 &

“More Options Tab” on page 93

Printing One Image on Multiple Sheets for Enlargement (Creating a Poster)

is feature allows you to print one image on multiple sheets of paper. You can create a larger poster by taping them together.

Note:

is feature is not available for borderless printing.

Print Settings

On the printer driver's Main tab, select 2x1 Poster, 2x2 Poster, 3x3 Poster, or 4x4 Poster as the Multi-Page setting. If you click Settings, you can select the panels that you do not want to print. You can also select the cutting guide options.

Related Information

& “Printing Basics” on page 76 & “Main Tab” on page 92

User's Guide

Printing

Making Posters Using Overlapping Alignment Marks

Here is an example of how to make a poster when 2x2 Poster is selected, and Overlapping Alignment Marks is selected in Print Cutting Guides.

1. Prepare Sheet 1 and Sheet 2. Cut o the margins of Sheet 1 along the vertical blue line through the center of

the top and bottom cross marks.

User's Guide

Printing

2. Place the edge of Sheet 1 on top of Sheet 2 and align the cross marks, then temporarily tape the two sheets

together from the back.

Cut the taped sheets in two along the vertical red line through the alignment markers (this time, the line to the le of the cross marks).

User's Guide

Printing

4. Tape the sheets together from the back.

5. Repeat steps 1 to 4 to tape Sheet 3 and Sheet 4 together.

6. Cut o the margins of Sheet 1 and Sheet 2 along the horizontal blue line through the center of the le and right

side cross marks.

User's Guide

Printing

7. Place the edge of Sheet 1 and Sheet 2 on top of Sheet 3 and Sheet 4 and align the cross marks, and then

temporarily tape them together from the back.

User's Guide

Printing

8. Cut the taped sheets in two along the horizontal red line through the alignment markers (this time, the line

above the cross marks).

9. Tape the sheets together from the back.

User's Guide

Printing

10. Cut o the remaining margins along the outer guide.

Printing with a Header and Footer

You can print information such as a user name and printing date in headers or footers.

Print Settings

On the printer driver's More Options tab, click Watermark Features, and then select Header/Footer. Click Settings, and then select the items you want to print.

User's Guide

Printing

Related Information

& “Printing Basics” on page 76 & “More Options Tab” on page 93

Printing a Watermark

You can print a watermark such as "Condential" or an anti-copy pattern on your printouts. If you print with an anti-copy pattern, the hidden letters appear when photocopied in order to distinguish the original from the copies.

e anti-copy pattern is available in the following conditions:

❏ Paper: Plain paper, Copy paper

❏ Borderless: Not selected

❏ Quality: Standard

❏ Automatic 2-sided printing: Not selected

❏ Color Correction: Automatic

Note:

You can also add your own watermark or anti-copy pattern.

Print Settings

On the printer driver's More Options tab, click Watermark Features, and then select Anti-Copy Pattern or Water ma rk. Cli c k Settings to change details such as the size, density, or position of the pattern or the mark.

Related Information

& “Printing Basics” on page 76 & “More Options Tab” on page 93

User's Guide

Printing

Printing Multiple Files Together

Job Arranger Lite allows you to combine several les created by dierent applications and print them as a single print job. You can specify the print settings for combined les, such as multi-page layout, and 2-sided printing.

Print Settings

On the printer driver's Main tab, select Job Arranger Lite. When you start printing, the Job Arranger Lite window is displayed. With the Job Arranger Lite window opened, open the le that you want to combine with the current le, and then repeat the above steps.

When you select a print job added to Print Project in the Job Arranger Lite window, you can edit the page layout.

Click Print from the File menu to start printing.

Note:

If you close the Job Arranger Lite window before adding all the print data to the Print Project, the print job you are currently working on is canceled. Click Save from the File menu to save the current job. e extension of the saved les is "ecl".

To open a Print Project, click Job Arranger Lite on the printer driver's Maintenance tab to open the Job Arranger Lite window. Next, select Open from the File menu to select the le.

Related Information

& “Printing Basics” on page 76 & “Main Tab” on page 92

Printing Using the Color Universal Print Feature

You can enhance the visibility of texts and images in printouts.

Color Universal Print is only available when the following settings are selected.

❏ Paper Type: Plain paper

❏ Quality: Standard or a higher quality

❏ Print Color: Color

❏ Applications: Microso® Oce 2007 or later

User's Guide

Printing

❏ Text Size: 96 pts or smaller

Print Settings

On the printer driver's More Options tab, click Image Options in the Color Correction setting. Select an option from the Color Universal Print setting. Click Enhancement Options to make further settings.

Note:

❏ Certain characters may be altered by patterns, such as "+" appearing as "±".

❏ Application-specic patterns and underlines may alter content printed using these settings.

❏ Print quality may decrease in photos and other images when using Color Universal Print settings.

❏ Printing is slower when using Color Universal Print settings.

Related Information

& “Printing Basics” on page 76 & “More Options Tab” on page 93

Adjusting the Print Color

You can adjust the colors used in the print job. ese adjustments are not applied to the original data.

Print Settings

On the printer driver's More Options tab, select Custom as the Color Correction setting. Click Advanced to open the Color Correction window, and then select the method of color correction.

Note:

❏ Automatic is selected as default on the More Options tab. With this setting, the colors are automatically adjusted to

match the paper type and print quality settings.

❏ PhotoEnhance on the Color Correction window adjusts the color by analyzing the location of the subject. erefore, if

you have changed the location of the subject by reducing, enlarging, cropping, or rotating the image, the color may change unexpectedly. Selecting the borderless setting also changes the location of the subject resulting in changes in color. If the image is out of focus, the tone may be unnatural. If the color is changed or becomes unnatural, print in a mode other than PhotoEnhance.

Related Information

& “Printing Basics” on page 76 & “More Options Tab” on page 93

User's Guide

Printing

Printing to Emphasize Thin Lines

You can thicken thin lines that are too thin to print.

Print Settings

On the printer driver's More Options tab, click Image Options in the Color Correction setting. Select Emphasize in Lines.

Related Information

& “Printing Basics” on page 76 & “More Options Tab” on page 93

Printing Clear Bar Codes

You can print a bar code clearly and make it easy to scan. Only enable this feature if the bar code you printed cannot be scanned.

You can use this feature under the following conditions.

❏ Paper: Plain paper, Copy paper, Letterhead, or Envelope

❏ Quality: Standard

e print quality may be changed when printing. e print speed may become slower and print density may become higher.

Note:

Deblurring may not always be possible depending on the circumstances.

Print Settings

On the printer driver's Maintenance tab, click Extended Settings, and then select Barcode mode.

User's Guide

Printing

Related Information

& “Printing Basics” on page 76 & “Maintenance Tab” on page 94

Canceling Printing

You can cancel a print job from the computer. However, you cannot cancel a print job from the computer once it has been completely sent to the printer. In this case, cancel the print job by using the printer's control panel.

Canceling

On your computer, right-click on your printer in Devices and Printers, Printer, or in Printers and Faxes. Click See what's printing, right-click on the job you want to cancel, and then select Cancel.

Menu Options for the Printer Driver

Open the print window in an application, select the printer, and then access the printer driver window.

Note:

Menus vary depending on the option you selected.

Main Tab

Printing Presets Add/Remove Presets You can add or remove your own presets for frequently used print

settings. Select the preset you want to use from the list.

Show Settings

Reset Defaults

Ink Levels Displays the approximate ink levels.

Paper Source

Document Size

Displays a list of items currently set on the Main and More Options tabs.

Return all settings to their factory default values. The settings on the More Options tab are also reset to their defaults.

Select the paper source from which the paper is fed. Select Auto Select to automatically select the paper source selected in the print settings on the printer's control panel.

If the printer has only one paper source, this item is not displayed.

Select the paper size on which you want to print. If you select User-Dened, enter the paper width and height.

Borderless Enlarges the print data slightly more than the paper size so that no margins are printed around the

edges of the paper. Click Settings to select the amount of enlargement.

Orientation Select the orientation you want to use to print.

Paper Type Select the type of paper on which you print.

Quality Select the pint quality you want to use for printing. Available settings depend on the paper type

you select. Click More Settings to make further settings.

Color Select the color for your print job.

User's Guide

Printing

2-Sided Printing Allows you to perform 2-sided printing.

Settings You can specify the binding edge and the binding margins. When

printing multi-page documents, you can select to print starting from either the front or the back side of the page.

Print Density Select the document type to adjust the print density. If the appropriate

print density is selected, you can prevent images from bleeding through to the reverse side. Select User Dened to adjust the print density manually.

Multi-Page

Copies Set the number of copies you want to print.

Quiet Mode Reduces the noise the printer makes. However, enabling this may reduce print speed.

Print Preview Displays a preview of your document before printing.

Job Arranger Lite Select to print using the Job Arranger Lite feature.

Allows you to print several pages on one sheet or perform poster printing. Click Page Order to specify the order in which pages are printed.

Collate Prints multi-page documents collated in order and sorted into sets.

Reverse Order Allows you to print from the last page so that the pages are stacked in the

correct order after printing.

More Options Tab

Printing Presets Add/Remove Presets You can add or remove your own presets for frequently used print

settings. Select the preset you want to use from the list.

Show Settings

Reset Defaults

Displays a list of items currently set on the Main and More Options tabs.

Return all settings to their factory default values. The settings on the Main tab are also reset to their defaults.

Document Size Select the size of your document.

Output Paper

Reduce/Enlarge

Document

Color Correction Automatic Adjusts the colors of images automatically.

Select the paper size on which you want to print. If the Output Paper diers from the Document Size, Reduce/Enlarge Document is selected automatically. You do not have to select it when printing without reducing or enlarging the size of a document.

Allows you to reduce or enlarge the size of a document.

Fit to Page Automatically reduce or enlarge the document to t to the paper size

selected in Output Paper.

Zoom to Prints with a specic percentage.

Center Prints images in the center of the paper.

Custom

Image Options Enables print quality options such as Color Universal Print or Fix Red-

Allows you to perform manual color correction. Click Advanced for further settings.

Eye. You can also thicken thin lines to make them visible on the printouts.

User's Guide

Printing

Watermark Features Allows you to make settings for anti-copy pattern or watermarks.

Additional Settings Rotate 180° Rotates pages 180 degrees before printing. This feature is helpful when

printing on paper such as envelopes that are loaded in xed direction in the printer.

High Speed Prints when the print head moves in both directions. The print speed is

faster, but the quality may decline.

Mirror Image Inverts an image to print as it would appear in a mirror.

Maintenance Tab

Nozzle Check Prints a nozzle check pattern to check if the print head nozzles are clogged.

Head Cleaning Cleans the clogged nozzles in the print head. Because this feature uses some ink, clean the print

head only if the nozzles are clogged.

Job Arranger Lite Opens the Job Arranger Lite window. You can save and edit data.

EPSON Status

Monitor 3

Monitoring

Preferences

Extended Settings Allows you to make a variety of settings. Right-click each item to view the Help for more details.

Print Queue Displays the jobs waiting to be printed. You can check, pause, or resume print jobs.

Language Changes the language to be used on the printer driver window. To apply the settings, close the

Software Update Starts EPSON Software Updater to check for the latest version of applications on the Internet.

Online Order Allows you to access the site where you can purchase Epson's ink cartridges.

Technical Support Allows you to access the Epson technical support website.

Opens the EPSON Status Monitor 3 window. Here you can conrm the status of the printer and the consumables.

Allows you to make settings for items on the EPSON Status Monitor 3 window.

printer driver, and then open it again.

Printing from the Printer Driver on Mac OS

Printing Basics

Note:

Operations dier depending on the application. See the application's help for details.

1. Open the le you want to print.

Load paper in the printer if it has not already been loaded.

2. Select Print from the File menu or another command to access the print dialog.

If necessary, click Show Details or

3. Select your printer.

to expand the print window.

User's Guide

4. Select Print Settings from the pop-up menu.

Printing

Note:

On OS X Mountain Lion or later, if the Print Settings menu is not displayed, the Epson printer driver has not been installed correctly.

Select System Preferences from the printer, and then add the printer again. See the following to add a printer.

http://epson.sn

menu > Printers & Scanners (or Print & Scan, Print & Fax), remove the

5. Change the settings as necessary.

See the menu options for the printer driver for details.

6. Click Print.

Related Information

& “Available Paper and Capacities” on page 43 & “Loading Paper in the Rear Paper Feed” on page 46 & “Menu Options for Print Settings” on page 100

User's Guide

Printing on 2-Sides

You can print on both sides of the paper.

Printing

Note:

❏ is feature is not available for borderless printing.

❏ If you do not use paper that is suitable for 2-sided printing, the print quality may decline and paper jams may occur.

❏ Depending on the paper and the data, ink may bleed through to the other side of the paper.

Related Information

& “Available Paper and Capacities” on page 43

Print Settings

Select Two-sided Printing Settings from the pop-up menu. Select the method of 2-sided printing, and then make the Document Type settings.

Note:

❏ Printing speed may be reduced depending on the document type.

❏ When printing photos with dense data, select Text & G raph i c s or Text & Photos in the Document Type setting. If the

printouts are smeared or ink bleeds through to the other side of the paper, adjust the Print Density and Increased Ink Drying Time in Adjustments.

Related Information

& “Printing Basics” on page 94 & “Menu Options for Two-sided Printing Settings” on page 101

User's Guide

Printing

Printing Several Pages on One Sheet

You can print two or four pages of data on a single sheet of paper.

Print Settings

Select Layout from the pop-up menu. Set the number of pages in Pages per Sheet, the Layout Direction (page order), and Border.

Related Information

& “Printing Basics” on page 94 & “Menu Options for Layout” on page 99

Printing and Stacking in Page Order (Reverse Order Printing)

You can print from the last page so that the documents are stacked in page order.

Print Settings

Select Paper Handling from the pop-up menu. Select Reverse as the Page Order setting.

Related Information

& “Printing Basics” on page 94

User's Guide

Printing

& “Menu Options for Paper Handling” on page 100

Printing a Reduced or Enlarged Document

You can reduce or enlarge the size of a document by a specic percentage or to t the paper size you loaded in the printer.

Print Settings

When printing to t to the paper size, select Paper Handling from the pop-up menu, and then select Scale to t paper size. Select the paper size you loaded in the printer in Destination Paper Size. When reducing the size of

the document, select Scale down only.

When printing at a

❏ Select Print from the File menu of the application. Select Printer, enter a percentage in Scale, and then click

Print.

❏ Select Page Setup from the File menu of the application. Select your printer in Format For, enter a percentage

in Scale, and then click OK.

Note: Select the paper size you set in the application as the Paper Size setting.

Related Information

“Printing Basics” on page 94

“Menu Options for Paper Handling” on page 100

specic

percentage, do one of the following.

User's Guide

Printing

Adjusting the Print Color

You can adjust the colors used in the print job. ese adjustments are not applied to the original data.

Print Settings

Select Color Matching from the pop-up menu, and then select EPSON Color Controls. Select Color Options from the pop-up menu, and then select one of the available options. Click the arrow next to Advanced Settings, and then make more detailed settings.

Related Information

& “Printing Basics” on page 94 & “Menu Options for Color Matching” on page 100 & “Menu Options for Color Options” on page 101

Canceling Printing

Canceling

Click the printer icon in the Dock. Select the job you want to cancel, and then do one of the following.

❏ OS X Mountain Lion or later

Click

❏ Mac OS X v10.6.8 to v10.7.x

Click Delete.

next to the progress meter.

Menu Options for the Printer Driver

Open the print window in an application, select the printer, and then access the printer driver window.

Note:

Menus vary depending on the option you selected.

Menu Options for Layout

Pages per Sheet Select the number of pages to be printed on one sheet.

User's Guide

Printing

Layout Direction Specify the order in which the pages will be printed.

Border Prints a border around the pages.

Reverse page

orientation

Flip horizontally Inverts an image to print as it would appear in a mirror.

Rotates pages 180 degrees before printing. Select this item when printing on paper such as envelopes that are loaded in

direction in the printer.

xed

Menu Options for Color Matching

ColorSync Select the method for color adjustment. These options adjusts colors between the printer and the

computer display to minimize the dierence in color.

EPSON Color Controls

Menu Options for Paper Handling

Collate pages Prints multi-page documents collated in order and sorted into sets.

Pages to Print Select to print only odd pages or even pages.

Page Order Select to print from the top or the last page.

Scale to t paper size Prints to t to the paper size you loaded.

Destination Paper Size

Select the paper size to print on.

Scale down only Select when reducing the size of the document.

Menu Options for Cover Page

Print Cover Page

Cover Page Type Select the contents of the cover page.

Select whether or not to print a cover page. When you want to add a back cover, select After

document.

Menu Options for Print Settings

Paper Source Select the paper source from which the paper is fed. If the printer has only one paper source, this

item is not displayed. Selecting Auto Select selects the paper source that matches the paper setting on the printer automatically.

Media Type Select the type of paper on which you print.

Print Quality Select the pint quality you want to use for printing. The options vary depending on the paper type.

Borderless This checkbox is selected when you select a borderless paper size.

Expansion In borderless printing, the print data is enlarged slightly more than the

paper size so that no margins are printed around the edges of the paper. Select the amount of enlargement.

100

Epson WorkForce WF-2810 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

About This Manual

Introduction to the Manuals

Using the Manual to Search for Information

Marks and Symbols

Descriptions Used in this Manual

Operating System References

Important Instructions

Safety Instructions

Safety Instructions for Ink

Printer Advisories and Warnings

Advisories and Warnings for Setting Up the Printer
