Epson VS345, VS240, VS340 User manual

EX3240/EX5240/EX5250 Pro/
EX7240 Pro/EX9200 Pro/VS240/
VS340/VS345 User's Guide

Contents

EX3240/EX5240/EX5250 Pro/EX7240 Pro/EX9200 Pro/VS240/VS340/VS345 User's Guide ................... 9
Introduction to Your Projector ................................................................................................................. 10
Setting Up the Projector ........................................................................................................................... 26
Projector Features.............................................................................................................................. 10
Product Box Contents.................................................................................................................... 11
Warranty and Registration Information .......................................................................................... 15
Notations Used in the Documentation ................................................................................................ 15
Where to Go for Additional Information .............................................................................................. 15
Projector Part Locations ..................................................................................................................... 16
Projector Parts - Rear .................................................................................................................... 19
Projector Parts - Control Panel ...................................................................................................... 22
Projector Placement........................................................................................................................... 26
Projector Connections........................................................................................................................ 31
Connecting to a Computer for USB Video and Audio................................................................ 32
Connecting to a Computer for VGA Video................................................................................. 34
Connecting to a Computer for HDMI Video and Audio .............................................................. 35
Connecting to a Computer for USB Mouse Control................................................................... 35
Connecting to a Computer for Sound........................................................................................ 36
Connecting to an HDMI Video Source ...................................................................................... 37
Connecting to an MHL-Compatible Device ............................................................................... 38
Connecting to a Component-to-VGA Video Source .................................................................. 39
3
Connecting to an S-Video Video Source................................................................................... 40
Connecting to a Composite Video Source ................................................................................ 41
Connecting to a Video Source for Sound .................................................................................. 42
USB Device Projection.............................................................................................................. 43
Connecting a USB Device or Camera to the Projector.............................................................. 43
Selecting the Connected USB Source ...................................................................................... 44
Disconnecting a USB Device or Camera From the Projector .................................................... 45
Connecting to a Document Camera .............................................................................................. 45
Installing Batteries in the Remote Control .......................................................................................... 46
Opening the Lens Cover .................................................................................................................... 48
Using the Projector on a Network ............................................................................................................ 50
Wireless Network Projection .............................................................................................................. 50
Connecting Directly to a Laptop or Computer................................................................................ 51
Connecting Directly to a Smartphone or Tablet ............................................................................. 54
Installing the Wireless LAN Module ............................................................................................... 57
Using Quick Wireless Connection (Windows Only) ....................................................................... 59
Wireless LAN Menu Settings .................................................................................................... 64
Selecting Wireless Network Settings in OS X ................................................................................ 65
Setting Up Wireless Network Security ........................................................................................... 65
Wireless Security Menu Settings .............................................................................................. 66
Setting Up Projector Network E-Mail Alerts ........................................................................................ 67
Setting Up Monitoring Using SNMP ................................................................................................... 69
Controlling a Networked Projector Using a Web Browser .................................................................. 70
Using Basic Projector Features ............................................................................................................... 73
Turning On the Projector .................................................................................................................... 73
Turning Off the Projector .................................................................................................................... 75
Selecting the Language for the Projector Menus................................................................................ 77
Adjusting the Image Height ................................................................................................................ 78
4
Image Shape...................................................................................................................................... 80
Correcting Image Shape with the Horizontal Keystone Slider ....................................................... 80
Correcting Image Shape with the Keystone Buttons...................................................................... 81
Correcting Image Shape with Quick Corner .................................................................................. 84
Resizing the Image............................................................................................................................. 86
Focusing the Image Using the Focus Ring......................................................................................... 87
Remote Control Operation ................................................................................................................. 88
Using the Remote Control as a Wireless Mouse ........................................................................... 89
Using the Remote Control as a Pointer.......................................................................................... 90
Selecting an Image Source ................................................................................................................ 91
Projection Modes ............................................................................................................................... 93
Image Aspect Ratio ............................................................................................................................ 95
Changing the Image Aspect Ratio ................................................................................................. 95
Available Image Aspect Ratios ...................................................................................................... 96
Color Mode......................................................................................................................................... 97
Controlling the Volume with the Volume Buttons................................................................................ 99
Projecting a PC Free Presentation ................................................................................................... 100
Supported PC Free File Types .................................................................................................... 100
Starting a PC Free Slide Show .................................................................................................... 101
Starting a PC Free Movie Presentation ....................................................................................... 103
PC Free Display Options ............................................................................................................. 105
Adjusting Projector Features ................................................................................................................. 107
Shutting Off the Picture and Sound Temporarily .............................................................................. 107
Stopping Video Action Temporarily .................................................................................................. 108
Zooming Into and Out of Images ...................................................................................................... 108
Projector Security Features.............................................................................................................. 109
Password Security Types ............................................................................................................ 110
Setting a Password ................................................................................................................. 110
5
Selecting Password Security Types........................................................................................ 111
Entering a Password to Use the Projector............................................................................... 112
Saving a User's Logo Image to Display................................................................................... 113
Locking the Projector's Buttons ................................................................................................... 116
Unlocking the Projector's Buttons ........................................................................................... 116
Installing a Security Cable ........................................................................................................... 117
Projector Identification System for Multiple Projector Control........................................................... 117
Setting the Projector ID................................................................................................................ 118
Setting the Remote Control ID..................................................................................................... 118
Matching Multiple-Projector Display Quality ................................................................................ 119
Projecting Two Images Simultaneously............................................................................................ 120
Copying Menu Settings Between Projectors .................................................................................... 122
Saving Settings to a USB Flash Drive.......................................................................................... 122
Transferring Settings From a USB Flash Drive............................................................................ 124
Saving Settings To a Computer................................................................................................... 125
Transferring Settings From a Computer ...................................................................................... 127
Adjusting the Menu Settings .................................................................................................................. 131
Using the Projector's Menus............................................................................................................. 131
Image Quality Settings - Image Menu .............................................................................................. 133
Input Signal Settings - Signal Menu.................................................................................................. 136
Projector Feature Settings - Settings Menu...................................................................................... 138
Projector Setup Settings - Extended Menu....................................................................................... 141
Projector Network Settings - Network Menu..................................................................................... 144
Projector Setup Settings - ECO Menu .............................................................................................. 145
Projector Information Display - Info Menu ........................................................................................ 147
Event ID Code List....................................................................................................................... 148
Projector Reset Options - Reset Menu ............................................................................................. 149
Maintaining and Transporting the Projector ......................................................................................... 151
Projector Maintenance ..................................................................................................................... 151
Cleaning the Lens........................................................................................................................ 151
Cleaning the Projector Case ........................................................................................................ 152
Air Filter and Vent Maintenance .................................................................................................. 152
Cleaning the Air Filter and Vents............................................................................................. 153
6
Replacing the Air Filter ............................................................................................................ 153
Projector Lamp Maintenance....................................................................................................... 156
Replacing the Lamp ................................................................................................................ 156
Resetting the Lamp Timer....................................................................................................... 160
Replacing the Remote Control Batteries ..................................................................................... 161
Transporting the Projector................................................................................................................ 163
Solving Problems .................................................................................................................................... 164
Projection Problem Tips ................................................................................................................... 164
Projector Light Status ....................................................................................................................... 165
Using the Projector Help Displays .................................................................................................... 168
Solving Image or Sound Problems ................................................................................................... 168
Solutions When No Image Appears............................................................................................. 169
Solutions When Image is Incorrect Using the USB Display Function .......................................... 170
Solutions When "No Signal" Message Appears........................................................................... 170
Displaying From a PC Laptop ................................................................................................. 171
Displaying From a Mac Laptop ............................................................................................... 171
Solutions When "Not Supported" Message Appears ................................................................... 171
Solutions When Only a Partial Image Appears ............................................................................ 172
Solutions When the Image is Not Rectangular ............................................................................ 172
Solutions When the Image Contains Noise or Static ................................................................... 173
Solutions When the Image is Fuzzy or Blurry .............................................................................. 174
Solutions When the Image Brightness or Colors are Incorrect .................................................... 175
Solutions to Sound Problems ...................................................................................................... 175
Solving Projector or Remote Control Operation Problems ............................................................... 176
Solutions to Projector Power or Shut-Off Problems ..................................................................... 176
Solutions to Problems with the Remote Control........................................................................... 177
Solutions to Password Problems ................................................................................................. 178
Solving Network Problems ............................................................................................................... 178
Solutions When You Cannot Access the Projector Through the Web ......................................... 179
Solutions When Network Alert E-Mails are Not Received............................................................ 179
Where to Get Help............................................................................................................................ 180
Technical Specifications ........................................................................................................................ 181
General Projector Specifications ...................................................................................................... 181
7
Projector Lamp Specifications.......................................................................................................... 186
Remote Control Specifications ......................................................................................................... 186
Projector Dimension Specifications.................................................................................................. 186
Projector Electrical Specifications .................................................................................................... 187
Projector Environmental Specifications............................................................................................ 188
Projector Safety and Approvals Specifications................................................................................. 188
Supported Video Display Formats.................................................................................................... 188
USB Display System Requirements................................................................................................. 192
Notices ..................................................................................................................................................... 194
Recycling.......................................................................................................................................... 194
Important Safety Information ............................................................................................................ 194
Important Safety Instructions............................................................................................................ 195
Restriction of Use ........................................................................................................................ 197
FCC Compliance Statement............................................................................................................. 198
Open Source Software License........................................................................................................ 199
Trademarks...................................................................................................................................... 248
Copyright Notice............................................................................................................................... 249
A Note Concerning Responsible Use of Copyrighted Materials................................................... 249
Copyright Attribution.................................................................................................................... 249
8
EX3240/EX5240/EX5250 Pro/EX7240 Pro/EX9200 Pro/VS240/VS340/VS345 User's Guide
Welcome to the EX3240/EX5240/EX5250 Pro/EX7240 Pro/EX9200 Pro/VS240/VS340/VS345 User's Guide.
9

Introduction to Your Projector

Refer to these sections to learn more about your projector and this manual.
Projector Features Notations Used in the Documentation Where to Go for Additional Information Projector Part Locations

Projector Features

Your projector includes these special features:
Bright, high-resolution projection system
• VS340: Up to 2800 lumens of color brightness (color light output) and 2800 lumens of white brightness (white light output)
• VS240/VS345: Up to 3000 lumens of color brightness (color light output) and 3000 lumens of white brightness (white light output)
• EX3240/EX5240/EX7240 Pro/EX9200 Pro: Up to 3200 lumens of color brightness (color light output) and 3200 lumens of white brightness (white light output)
• EX5250 Pro: Up to 3600 lumens of color brightness (color light output) and 3600 lumens of white brightness (white light output)
Note: Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
• EX3240/VS240: Native resolution of 800 × 600 pixels (SVGA)
• EX5240/EX5250 Pro/VS340: Native resolution of 1024 × 768 pixels (XGA)
• EX7240 Pro/VS345: Native resolution of 1280 × 800 pixels (WXGA)
• EX9200 Pro: Native resolution of 1920 × 1080 pixels (WUXGA)
Flexible connectivity
• Plug-and-play 3-in-1 USB projection, audio, and mouse control for instant setup
• Built-in wireless LAN for projection, monitoring, and control via remote network computer (EX7240 Pro/EX9200 Pro)
10
• Wireless LAN module for projection, monitoring, and control via remote network computer (EX5250 Pro)
• Projection from iOS or Android devices and free Epson iProjection app; visit epson.com/projectorapp (U.S.) or epson.ca/projectorapp (Canada) for more information (EX3240/EX5240/VS240/VS340/VS345 require the optional wireless LAN module)
• PC Free photo slide shows via connected USB memory devices or Epson document camera
• Two HDMI ports for multiple high-definition AV devices, including MHL support (EX9200 Pro)
• HDMI/MHL port for computer or video device connection, including MHL-enabled devices (EX7240 Pro)
• HDMI port for computer or video device connection (EX3240 Pro/VS240/VS340/VS345)
Easy-to-use setup and operation features
• Epson's quick-connect on-screen QR code feature for easy wireless setup
• Low total cost of ownership with longer lamp life
• Automatic vertical keystone correction and innovative horizontal keystone correction slider for flexible projector placement
• 1.2× optical zoom ratio for improved zooming capability (EX5240/EX5250 Pro/EX7240 Pro/EX9200 Pro/VS340/VS345)
• Built-in closed captioning decoder
• Epson's Instant Off and Direct Power On features for quick setup and shut down
Product Box Contents Additional Components Optional Equipment and Replacement Parts Warranty and Registration Information
Parent topic: Introduction to Your Projector

Product Box Contents

Save all the packaging in case you need to ship the projector. Always use the original packaging (or equivalent) when shipping.
11
Make sure your projector box included all of these parts:
1 Projector
2 Remote control
3 Remote control batteries (two AA alkaline)
4 Power cord
5 VGA computer cable
6 USB cable
7 Carrying case (EX3240/EX5240/EX5250 Pro/EX7240 Pro/EX9200 Pro)
8 Wireless LAN module (EX5250 Pro)
9 French control panel stickers (included for Canada only)
10 Projector documentation CD
12
Parent topic: Projector Features

Additional Components

Depending on how you plan to use the projector, you may need to obtain the following additional components:
• To receive a composite video signal, you need an RCA-style video or A/V cable. See your local computer or electronics dealer for purchase information.
• To receive an S-Video signal, you need an S-Video cable compatible with your device. See your local computer or electronics dealer for purchase information.
• To receive a component video signal, you need a D-sub, 15-pin, component-to-VGA video cable. You can purchase one from Epson or an authorized Epson reseller.
• To receive an HDMI signal, you need a compatible HDMI cable. You can purchase one from Epson or an authorized Epson reseller.
Note: To connect a Mac that includes only a Mini DisplayPort, Thunderbolt port, or Mini-DVI port for video output, you need to obtain an adapter that allows you to connect to the projector's HDMI port. Contact Apple for compatible adapter options. Older Mac computers (2009 and earlier) may not support audio through the HDMI port.
• To receive an HDMI signal via MHL, you need an MHL-compatible device, an MHL cable, or an HDMI cable and an MHL adapter compatible with your device (EX7240 Pro/EX9200 Pro). Devices with an integrated MHL connector may not require a cable. You can purchase an HDMI cable from Epson or an authorized Epson reseller.
• To project with audio from certain ports, you may need a commercially available audio cable compatible with your device. See your local computer or electronics dealer for purchase information.
• To connect a Mac that includes only a Mini DisplayPort, Thunderbolt port, or Mini-DVI port for video output to the projector's VGA video port, you need to obtain an adapter. Contact Apple for compatible adapter options.
Parent topic: Projector Features
Related references
Optional Equipment and Replacement Parts
13

Optional Equipment and Replacement Parts

You can purchase screens, other optional accessories, and replacement parts from an Epson authorized reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766). Or you can purchase online at epsonstore.com (U.S. sales) or epson.ca (Canadian sales).
Epson offers the following optional accessories and replacement parts for your projector:
Option or part Part number
Genuine Epson replacement lamp (ELPLP88) V13H010L88
Replacement air filter (ELPAF32) V13H134A32
Wireless LAN module (ELPAP10) V12H731P02
Quick wireless connection USB key (ELPAP09) V12H005M09
Epson DC-06 document camera V12H321005
Epson DC-11 document camera V12H377020
Epson DC-12 document camera V12H594020
Epson DC-20 document camera V12H500020
Universal projector ceiling mount ELPMBPJF
Accolade Duet ultra portable projector screen ELPSC80F
ES1000 ultra portable tabletop projection screen V12H002S4Y
ES3000 ultra portable projection screen V12H002S3Y
Belkin PureAV HDMI audio video cable, 3 ft AV22300-03
Belkin PureAV HDMI audio video cable, 6 ft AV22300-06
Belkin PureAV HDMI audio video cable, 12 ft AV22300-12
Remote control 1648806
1-Year Extended Exchange Service Plan EPPEXPA1
2-Year Extended Exchange Service Plan EPPEXPA2
1-Year Extended Depot Repair Service Plan EPPFTPA1
2-Year Extended Depot Repair Service Plan EPPFTPA2
Parent topic: Projector Features
14

Warranty and Registration Information

Your projector comes with a basic warranty that lets you project with confidence. For details, see the warranty that came with your projector.
In addition, Epson offers free Extra Care Road Service. In the unlikely event of an equipment failure, you won’t have to wait for your unit to be repaired. Instead, Epson will ship you a replacement unit anywhere in the United States, Canada, or Puerto Rico. See the Extra Care Road Service brochure for details.
Register your product online using the projector CD or at this site: epson.com/webreg.
Registering also lets you receive special updates on new accessories, products, and services.
Parent topic: Projector Features

Notations Used in the Documentation

Follow the guidelines in these notations as you read your documentation:
• Warnings must be followed carefully to avoid bodily injury.
• Cautions must be observed to avoid damage to your equipment.
• Notes contain important information about your projector.
• Tips contain additional projection information.
Parent topic: Introduction to Your Projector

Where to Go for Additional Information

Need quick help on using your projector? Here's where to look for help:
• Built-in help system
Press the Home button on the remote control or projector, select Help and press Enter to get quick solutions to common problems.
• epson.com/support (U.S) or epson.ca/support (Canada)
View FAQs (frequently asked questions) and e-mail your questions to Epson technical support 24 hours a day.
• For detailed instructions on using your projector in a network environment, see the EasyMP Network Projection Operation Guide.
• For detailed instructions on monitoring your projector in a network environment (Windows only), see the EasyMP Monitor Operation Guide.
15
• For detailed instructions on using your projector to hold interactive meetings in a network environment, see the EasyMP Multi PC Projection Operation Guide.
• If you still need help after checking this manual and the sources listed above, you can use the Epson PrivateLine Support service to get help fast. For details, see "Where to Get Help".
Parent topic: Introduction to Your Projector
Related references
Where to Get Help
Related tasks
Using the Projector Help Displays

Projector Part Locations

Check the projector part illustrations to learn about the parts on your projector.
Projector Parts - Front/Top Projector Parts - Rear Projector Parts - Base Projector Parts - Control Panel Projector Parts - Remote Control
Parent topic: Introduction to Your Projector
16

Projector Parts - Front/Top

EX5240/EX5250 Pro/EX7240 Pro/EX9200 Pro/VS340/VS345
17
EX3240/VS240
1 Exhaust vent
2 A/V Mute slide lever
3 Foot release lever
4 A/V Mute slide (lens cover)
5 Front adjustable foot
6 Lens
7 Remote receiver
8 Horizontal keystone slider
9 Air filter and intake vent
10 Air filter cover
11 Security lock slot
12 Control panel
18
13 Focus ring
14 Zoom ring (EX5240/EX5250 Pro/EX7240 Pro/EX9200 Pro/VS340/VS345)
15 Lamp cover
Parent topic: Projector Part Locations

Projector Parts - Rear

EX3240/EX5240/EX5250 Pro/EX7240 Pro/VS240/VS340/VS345
1 AC input port
2 Wireless LAN module cover screw (EX3240/EX5240/EX5250 Pro/VS240/VS340/VS345)
3 Audio ports
4 Video port
5 Remote receiver
6 Speaker
7 HDMI port (EX3240/EX5240/EX5250 Pro/VS240/VS340/VS345)
HDMI/MHL port (EX7240 Pro)
8 Computer port
9 S-Video port
10 USB-B port
19
11 USB-A/document camera/wireless LAN module port
EX9200 Pro
1 AC input port
2 Audio ports
3 Video port
4 Remote receiver
5 Speaker
6 HDMI1 and HDMI2/MHL ports
7 Computer port
8 S-Video port
9 USB-B port
10 USB-A/document camera port
Parent topic: Projector Part Locations
20

Projector Parts - Base

1 Mounting bracket holes
2 Security cable attachment point
3 Rear adjustable feet
4 Front adjustable foot
Parent topic: Projector Part Locations
21

Projector Parts - Control Panel

EX5240/EX5250 Pro/EX7240 Pro/EX9200 Pro/VS340/VS345
1 Source Search button (searches for connected sources)
2 Enter button (selects options)
3 Vertical keystone adjustment buttons (adjust screen shape) and arrow buttons
4 Esc button (cancels/exits functions)
5 Volume adjustment buttons (adjust speaker volume) and arrow buttons
6 Menu button (accesses projector menu system)
7 Home button (accesses source selection, projector help information, and other features)
8 Power button and light
9 Projector status lights
22
EX3240/VS240
1 Source Search button (searches for connected sources)
2 Enter button (selects options)
3 Vertical keystone adjustment buttons (adjust screen shape) and arrow buttons
4 Esc button (cancels/exits functions)
5 W (Wide)/T (Tele) buttons (adjust projected image size), horizontal keystone adjustment buttons
(adjust screen shape), and arrow buttons
6 Menu button (accesses projector menu system)
7 Home button (accesses source selection, projector help information, and other features)
8 Power button and light
9 Projector status lights
Parent topic: Projector Part Locations
Related references
Projector Light Status
23

Projector Parts - Remote Control

1 Power button
2 Computer button (cycles through connected computer sources)
3 Video button (cycles through connected video sources)
4 Numeric buttons (enter numbers)
24
5 Auto button (automatically adjusts position, tracking, and sync settings)
6 Aspect button (selects the image aspect ratio)
7 Num button (switches buttons to number function for entering numbers)
8 Menu button (accesses projector menu system)
9 Arrow buttons (move through on-screen options and control wireless mouse functions)
10 Enter button (selects options and controls wireless mouse functions)
11 User button (customizable for different functions)
12 Page Up/Down buttons (control presentation slides and projected document pages )
13 E-Zoom +/– buttons (zoom into and out of the image)
14 A/V Mute button (turns off picture and sound)
15 Split button (splits the screen between two image sources)
16 Home button (accesses source selection, projector help information, and other features)
17 Freeze button (stops video action)
18 Volume up and down buttons (adjust speaker volume)
19 Pointer button (activates on-screen pointer)
20 Esc button (cancels/exits functions and controls wireless mouse functions)
21 ID button (selects projector and remote control ID numbers)
22 Color Mode button (selects display modes)
23 MHL Menu button (displays settings or performs functions for the MHL device) (EX7240
Pro/EX9200 Pro)
24 LAN button (switches to available network sources)
25 USB button (cycles through connected USB sources)
26 Source Search button (searches for connected sources)
27 Infrared emitter
Parent topic: Projector Part Locations
25

Setting Up the Projector

Follow the instructions in these sections to set up your projector for use.
Projector Placement Projector Connections Installing Batteries in the Remote Control Opening the Lens Cover

Projector Placement

You can place the projector on almost any flat surface to project an image.
You can also install the projector in a ceiling mount if you want to use it in a fixed location.
Keep these considerations in mind as you select a projector location:
• Place the projector on a sturdy, level surface or install it using a compatible mount.
• Leave plenty of space around and under the projector for ventilation, and do not place it on top of or next to anything that could block the vents.
• Position the projector within reach of a grounded electrical outlet or extension cord.
Projector Setup and Installation Options Projection Distance
Parent topic: Setting Up the Projector

Projector Setup and Installation Options

You can set up or install your projector in the following ways:
Front
26
Rear
Front Ceiling
Rear Ceiling
Wherever you set up the projector, make sure to position it squarely in front of the center of the screen, not at an angle, if possible.
If you project from the ceiling or from the rear, be sure to select the correct Projection option in the projector's menu system.
Parent topic: Projector Placement
27
Related references
Projector Setup Settings - Extended Menu

Projection Distance

The distance at which you place the projector from the screen determines the approximate size of the image. The image size increases the farther the projector is from the screen, but can vary depending on the zoom factor, aspect ratio, and other settings.
Use the tables here to determine approximately how far to place the projector from the screen based on the size of the projected image. (Conversion figures may have been rounded up or down.) You can also use the projector Throw Distance Calculator at epson.com/support (U.S.) or epson.ca/support (Canada).
EX3240/VS240
4:3 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Offset from lens center (2)
Wide to Tele
50 inches (127 cm) 58 to 79 inches –3.3 inches (–8 cm)
(147 to 200 cm)
80 inches (203 cm) 93 to 126 inches –5.2 inches (–13 cm)
(237 to 321 cm)
100 inches (254 cm) 117 to 158 inches –6.5 inches (–17 cm)
(297 to 401 cm)
28
4:3 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Offset from lens center (2)
Wide to Tele
150 inches (381 cm) 176 to 237 inches –9.8 inches (–25 cm)
(446 to 603 cm)
EX5240/VS340
4:3 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Offset from lens center (2)
Wide to Tele
50 inches (127 cm) 59 to 71 inches –3.3 inches (–8 cm)
(150 to 180 cm)
80 inches (203 cm) 95 to 114 inches –5.3 inches (–14 cm)
(241 to 290 cm)
100 inches (254 cm) 119 to 143 inches –6.7 inches (–17 cm)
(302 to 363 cm)
150 inches (381 cm) 179 to 215 inches –10 inches (–25 cm)
(454 to 546 cm)
EX5250 Pro
4:3 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Offset from lens center (2)
Wide to Tele
50 inches (127 cm) 56 to 67 inches –3.1 inches (–8 cm)
(142 to 171 cm)
80 inches (203 cm) 90 to 108 inches –5 inches (–13 cm)
(229 to 275 cm)
29
4:3 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Offset from lens center (2)
Wide to Tele
100 inches (254 cm) 113 to 136 inches –6.3 inches (–16 cm)
(287 to 345 cm)
150 inches (381 cm) 170 to 204 inches –9.4 inches (–24 cm)
(432 to 519 cm)
EX7240 Pro/VS345
16:10 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Offset from lens center (2)
Wide to Tele
50 inches (127 cm) 55 to 66 inches –2.4 inches (–6 cm)
(139 to 168 cm)
80 inches (203 cm) 88 to 106 inches –3.8 inches (–10 cm)
(225 to 270 cm)
100 inches (254 cm) 111 to 133 inches –4.7 inches (–12 cm)
(281 to 338 cm)
150 inches (381 cm) 167 to 200 inches –7.1 inches (–18 cm)
(424 to 509 cm)
EX9200 Pro
16:10 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Offset from lens center (2)
Wide to Tele
50 inches (127 cm) 58 to 71 inches –2.4 inches (–6 cm)
(148 to 180 cm)
30
Loading...
+ 219 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
