The documentation for your EPSON projector is divided into the following two manuals. Refer to the
manuals in the order given below.
Safety Instructions/World-Wide Warranty Terms
This manual contains information on using the projector safely, and also includes a guide for warranty
service, and a troubleshooting check sheet.
Be sure to read this manual thoroughly before using the projector.
User’s Guide (this manual)
This User's Guide contains information on installing the projector, basic operations, using the
configuration menus, troubleshooting and maintenance.
Notations used in this User’s Guide
General information
Indicates procedures where personal injury or damage to the projector may occur if
the procedures are not followed correctly.
Indicates additional information and points which may be useful to know regarding a
TIP
, etc.Indicates buttons on the remote control or projector's control panel.
" (Menu Name) "
[ (Name) ]
topic.
Indicates a page where useful information regarding a topic can be found.
Indicates that an explanation of the underlined word or words in front of this symbol
appears in the glossary of terms.
Refer to the "Glossary" in the "Appendix". p.52
Indicates configuration menu items.
Example: "Picture"-"Color Mode"
Indicates the port name of the projector.
Example: [Video]
Notations Used in This Guide
Meaning of "unit" and "projector"
When "unit" or "projector" appears in the text of this User’s Guide, they may refer to items which are
accessories or optional equipment in addition to the main projector unit itself.
Checking the Components
When you unpack the projector, make sure that you have all these components.
If any of the components are missing or incorrect, please contact the place of purchase.
■ Index ........................................................... 54
projector
Installing the
Basic
operation
Adjustments
Menu
Congiguration
AppendixTroubleshootingImage Quality
3
Features of the Projector
Image appearance can be selected to match the
projection environment (Color Mode)
The optimum images for the location can be projected simply by selecting the desired colour mode from the
following seven preset modes.
If "Natural", "Theatre", "Theatre Black 1", "Theatre Black 2" or "sRGB " is selected, the Epson Cinema
Filter effect is applied automatically to increase the contrast and to make skin tones appear with more natural
tints. p.18
sRGB
Theatre Black1
Theatre Black2
Dynamic
Living Room
Color
Mode
Natural
Theatre
4
Sophisticated colour adjustment
In addition to the "Color Mode", the absolute colour temperature and skin tones can be adjusted by simple
procedures to render the picture even more to your own liking. Further, you can adjust gamma, the offset and
gain for RGB colours, and the hue and saturation of RGBCMY colours, to create colours that match the image.
p.20
Equipped with a wideangle lens shift function
The lens shift function allows the position of the
projected images to be adjusted vertically and
horizontally without distorting the images.
This can allow the projector to be set up with greater
freedom, even if it is suspended from a ceiling or at
an angle to the screen. p.16
Features of the Projector
Equipped with 2.1x short
throw zoom lens
For zoom adjustment, 2.1x short throw zoom lens is provided.
Images can be projected onto an 100" screen (16:9 screen
only) even at a distance of approximately 3 m (10 ft.). p.10
Advanced image quality adjustment functions
Advanced image quality adjustment functions such as "Auto Iris" and "Sharpness (Advanced)" can be used to
enjoy even sharper images. With the Auto Iris function turned on, the amount of light can be automatically
adjusted to match the images being projected, to create images with depth and perspective. The Sharpness function
is used to adjust not only the entire image, but also to emphasize specific regions, such as hair and clothing.
p.23
A variety of image setting functions
Some of the other many functions that are available are as follows.
EPSON Super White is used to prevent overexposure that can result in images that are too bright. p.30
A progressive conversion that lets you obtain ideal results both for images with large amounts of movement
and for still images. p.30
An aspect function that allows images to be viewed in wide-screen format. p.18
Memory functions that allow adjustment results to be stored and later retrieved easily using the remote control.
p.24
Lock settings that can be used to lock the projector's control panel after adjustments have been made so that
they cannot be changed by mistake, or to prevent children from accidentally turning on the power and looking
into the lens. p.31
5
Part Names and Functions
•
Hori
l
16
Front / Top
•
zontal lens adjustment dia
Moves the lens horizontally.
• Control panelSee below
Remote control lightreceiving area
p.13
Receives signals from the
remote control.
p.
• Vertical lens adjustment
dialp.16
Moves the lens vertically.
• Zoom ringp.16
Adjusts the image size.
• Air exhaust vent
Do not touch the exhaust vent
immediately after projecting, or
while projecting, since it
becomes hot.
• Front adjustable feetp.17
Extend to adjust the projection angle so that the
projector is horizontal when placed on a desk top.
• Focus ringp.16
Adjusts the image focus.
• Lens cover
Attach when not using
the projector to prevent
the lens from becoming
dirty or damaged.
Control panel
Buttons with no explanation function in the same way as the corresponding buttons on the remote
control. Refer to "Remote control" for further details on these buttons.
• Source buttonp.15
Selects the image source.
• Power buttonp.14
Turns the projector power
on or off.
• Menu buttonp.34
• Esc button
p.18, 20
, 24,
34
• (Operation) indicator p.35
Flashes or lights in different colours to indicate the operating
status of the projector.
• Aspect buttonp.18
• (Warning) indicator p.35
Flashes or lights in different colours to indicate problems
with the projector.
• Select/Line menu button
p.18
, 24,
34
•//buttons
p.17, 18, 20, 24, 34
Used as up/down buttons to select items in
menus and select menus.
If the menus are not displayed, correct the
keystone distortion.
• buttons p.20,
Used as right/left buttons to
select adjustment values in
menus.
34
6
Part Names and Functions
•
Remote control
• Remote control light-
emitting areap.13
Indicator
Illuminates when remote control
signals are being output.
Outputs remote control signals.
• Memory buttonp.24
Retrieves stored memories.
• Menu button
Displays the full-screen
configuration menus.
button
p.18, 20
Press to select menu items and
adjustment values and to adjust the
zoom and focus.
p.34
,
22, 24, 34
• On/Off buttonsp.14
Turns the projector power on/off.
• Color Mode buttonp.18
Selects the colour mode.
• Aspect
Selects the aspect.
buttonp.18
• Esc button
p.18
, 20, 24,
Pressing [Esc] while viewing a
menu displays the previous menu.
Source buttonsp.15
Changes to the image from the
projector's selected port.
34
• Select/Line menu button
p.18, 24
Displays the line menu.
When viewing a menu, press this
button to select the menu item and
proceed to the next display.
,
34
• Gamma buttonp.20
Adjusts the gamma values.
• Color Temp. buttonp.20
Adjusts the absolute colour
temperature.
• Pattern buttonp.17
The test pattern image appears and
disappears each time this button is
pressed.
• (Illumination) button
All buttons on the remote control illuminate when this button is pressed.
The button illumination switches off automatically after about 10 seconds
have passed.
• HDMI button
• D/SCART button
• Compo. button
• PC button
• S-Video button
• Video button
• Contrast buttonp.28
Adjusts contrast
.
• S.Tone (Skin Tone)
buttonp.20
Adjusts the skin tones of people
who appear in the images.
• Blank button
The projected images switch off
and on each time this button is
pressed.
7
Part Names and Functions
Rear
• [SCART] input portp.12
Connects to the SCART ports of
other video equipment using the
D SCART adaptor that is packed
with the projector.
• [Component] input port p.12
Connects to the component video
of other video equipment.
(YCbCr or YPbPr ) ports
• [PC] input portp.12
Connects to the RGB port
of a computer.
• [HDMI ] input portp.12
Connects to video equipment or a
computer that is HDMIcompatible.
• [Trigger out] port
When the projector power
is turned on, a 12 V DC
signal is output from this port.
When the projector's power is
turned off or a problem with
operation occurs, the output
becomes 0 V to send the
projector's power ON/OFF
status to an external device.
• [Video] input port p.12
Connects to general video ports of
other video equipment.
• [S-Video] input port p.12
Inputs an S-Video
projector from other video equipment.
signal to the
Base
• Main power switch
p.14
• Power inletp.14
Connects the power cable.
• Remote control
light-receiving
areap.13
Receives signals
from the remote
control.
• Security lock
p.53
• [RS-232C] port
Connects the projector to a computer
using an RS-232C cable. This port is
for control use and should not be used
by the customer.
8
• Suspension bracket fixing points (4 points)p.46
Install the optional ceiling mount here when suspending the projector from a ceiling.
• Air filter (air intake vent)
• Lamp coverp.44
Open this cover when replacing the lamp
inside.
p.42, 44
Prevents dust and other foreign particles
from being drawn into the projector.
It should be cleaned periodically.
Appearance
131.5
66
Centre of projector
*1
*2
110
406
*1 Distance from centre of lens to suspension bracket fixing point
(Lens shift amount: Max. 8.8 mm vertically)
*2 Distance from centre of lens to centre of projector
(Lens shift amount: Max. 7.7 mm horizontally)
Centre of lens
Centre of lens
124
19
143
310
300
52.8
77.3
160
4-M4×8
Units:mm
9
Setting up
)
Adjusting the projection size
The size of the projected image is basically determined by the distance from the projector's lens
to the screen.
Lens shift
To p
Offset
Centre of lens
Screen
Adjusting theprojection size
Projection distance
The height from the centre of the lens to the bottom of the screen will vary depending on the lens shift setting.
Offset
Lens shift
Bottom
While referring to the table below, position the projector so that the images are projected onto the
screen at the optimum size.
The values should be used as a guide for setting up the projector.
The lens shift dials can be used to position the image and is especially useful when using the projector in the
following locations. p.16
Hanging from the ceiling
A screen in a high location
Projector situated to the side so that the screen can be viewed sitting right in front of it
Projector situated on a shelf, etc.
When positioning an image using the lens shift dial, hardly any deterioration of the image occurs because the lens
shift correction is adjusted optically. However, for optimal image quality the lens shift function should not be used.
24 (9.4)
10
Projection methods
Avoid setting the projector up in a place which is very dusty or humid, or where there
will be cigarette or other smoke, especially oily smoke.
Clean the air filter at least once every 3 months.
Clean the air filter more frequently if using the projector in a dusty environment.
A special method of installation is required when suspending the projector from the
ceiling (ceiling mount). If it is not installed correctly, it could fall causing an accident
and injury.
If you use adhesives on the ceiling mount to prevent the screws from loosening, or if
you use things such as lubricants or oils on the projector, the projector case may
crack causing it to fall from its ceiling mount. This could cause serious injury to
anyone under the ceiling mount and could damage the projector.
When installing or adjusting the ceiling mount, do not use adhesives to prevent the
screws from loosening and do not use oils or lubricants and so on.
Do not use the projector on its side. This may cause malfunctions to occur.
Setting up
When projecting from directly in front
When projecting from a celling
When projecting from the side of
the screen
* Even if projection will be from the screen
side, set up the screen and projector so that
they are parallel.
* When suspending the projector from a ceiling,
change the configuration menu settings. p.33
Installing the Projector
Configuration menu
Settings
Projection
Front
Front/Ceiling
11
Connecting Image Sources
• Turn the power off for both the projector and the signal source before connecting them.
If the power for either device is on at the time of connection, damage may result.
• Check the shapes of the cable connectors and the device ports before making the
connections. If you try to force a connector to fit a device port with a different shape or
number of terminals, a malfunction or damage to the connector or port may result.
Video equipment (VHS VCR, DVD player, game console, etc.)
*Port names may vary depending on the equipment being connected.
S-Video
S-Video cable
(commercially-
available)
Video
RCA video cable
(commercially-
available)
1
*
SCART
SCART cable
(commercially-
available)
+
D SCART
adapter*
(accessory)
Component output
Component
video cable
(commercially-
available)
2
HDMI
HDMI cable
(commercially-
available)
Computer
Mini D-Sub
15-pin
Computer cable
(commercially-
available)
Mini D-Sub
15-pin
12
*1 If a DVD has been connected using a D SCART adapter, change the "D/SCART" setting in the "Input Signal" to
"SCART". "Selecting the image source" p.15
*2 Some regions may not have the D SCART adapter included as an accessory.
• Some signal sources may have specially-shaped ports. In such cases, use the
accessory or optional cables that are supplied with the signal source to make the
TIP
connections.
• The cable that should be used to connect video equipment to the projector will depend
on the type of video signal that the equipment outputs. Some kinds of video equipment
output several different types of video signal. The image quality ranking of the video
signal types is generally held to be as follows, in descending order of quality:
Digital component video
S-Video
[S-Video] > Composite video [Video]
[HDMI ] > Analog component video [D] [Component] >
You should refer to the documentation provided with the video equipment being used to
check what types of video signal formats the equipment can output. The composite
video format is sometimes simply called "video output".
Preparing the Remote Control
Inserting batteries into the remote control
The remote control is not supplied with batteries already inserted. Insert the accessory batteries
before using the remote control.
Remove the battery cover.
While pressing the knob, lift up.
Insert the batteries.
Check the (+) and (-)
indications inside the
battery compartment and
insert the batteries so that
they face correctly.
If delays in the responsiveness of the remote control occur or if it does not operate
after it has been used for some time, it probably means that the batteries are
TIP
becoming flat. If this happens, replace the batteries with two new batteries. Use two
new AA batteries as replacement batteries.
Install the battery cover.
Insert the tab.
Press down until the battery
cover clicks into place.
Installing the Projector
Using the remote control
Operating range (horizontal)
Operating distance
Approx.10m
Operating range (vertical)
Approx.30
Remote control light-receiving area
Approx.30
Operating distance
Approx.10m
Approx.30Approx.30Approx.30
Remote control
light-emitting area
Operating distance
Approx.10m
Approx.30
Approx.30
Approx.30
13
Projecting Images
Turning the power on and projecting images
Control PanelRemote Control
ON
Turning the power on and projectingimages
If there is a problem with projection even though the projector is set up and connected correctly,
refer to p.15, 35.
If you set the "Direct Power On" to "On", the power of the unit will turn ON when
the main power switch is turned ON, without having to press the power button of
TIP
the remote control or the projector's control panel.
The projector is equipped with a "Child Lock" function that prevents young
children from accidentally turning the power on and looking into the lens, and
also an "Operation Lock" function that prevents mis-operations. p.31
When using above an altitude of about 1500 m, make sure you set the "High
Altitude Mode" to "On". p.32
This projector is equipped with an automatic
adjustment function that automatically optimizes it
when a computer input signal is switched.
If a laptop computer or a computer with a LCD
screen has been connected to the projector, you
may need to use keyboard or function settings to
change the output destination. While holding down
the key, press (the key with a symbol such
as / on it). After the selection is made,
projection will soon start.
Example of output selection
NEC
Panasonic
SOTEC
HP
Toshiba
IBM
SONY
DELL
Fujitsu
Set mirror setting or
Macintosh
display detection.
Depending on OS, you can
change the output
selection by pressing .
Computer documentation
14
Projecting Images
When the expected images are not projected
If more than one signal source has been connected, or if no images are projected, use the remote control or the
projector's control panel buttons to select the signal source. For video devices, press the [Play] button on the video
equipment first, then select the signal source.
Using the remote control
Using the control panel
Press the button that has the name of the port on it that
the desired signal source is connected to.
When you press , the menu is displayed.
Use or to select the signal source.
Press to accept.
When projecting an image from the [Component] port
The default setting is set to "Auto" to select appropriate signals automatically. However, if the colours appear unnatural,
switch the image signal to match the equipment.
Using the remote control
While projecting an image from equipment
connected to the [Component] port, press
to display the menu.
Use or to select the correct signal to
match the equipment.
Press or to accept.
While projecting an image from equipment
connected to the [Component] port, select
"Component" and confirm to display the menu.
Using the control panel
Basic Operations
Turning the power off
Turn the power off for the signal sources
that are connected to the projector.
Press on the remote control or on
the projector's control panel. If you press
on the projector's control panel, the
following message will be displayed.
Press again to continue.
When the projector has cooled down (takes
about 30 seconds), turn off the main power
switch.
Simply pressing or does not stop
electricity consumption.
Attach the lens cover.
15
Adjusting the Projection Screen
Focus adjustment
Turn the focus ring to adjust the
focus.
Projection image position adjustment
(Lens shift)
Use the two lens shift dials to adjust the
image position.
If you cannot position the projector straight
in front of the screen, use the lens shift dial
so that the image is centered on the screen.
When you turn the lens shift dial and hear a
click, the lens position is almost centred.
Focus adjustment
Fine adjustments to image size (Zoom adjustment)
Projection image position adjustment
Fine adjustments to image size
(Zoom adjustment)
Turn the zoom ring to adjust the size of the
projected image.
Wide
Tele
Down
Up
Left
Right
You can shift the image by 102% in the
vertical direction, and 50% in the horizontal
direction. However, you cannot shift the
image to these vertical and horizontal limits
simultaneously.
Ex) When the image is shifted horizontally
by the full amount, it cannot be shifted
vertically.
And when the image is shifted
vertically by the full amount, it cannot
be shifted horizontally by more than
10% of its width.
(Lens shift)
When transporting the
projector, make sure to turn
the lens position down by the
full amount. Otherwise the lens
shift function may be
damaged.
H
Standard
projection position
Range that the picture can be shifted
from the standard projection position
(centre position for
lens shift)
V
16
Loading...
+ 42 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
