XP-7100 Small-in-One® Printer
Turn on and configure
2
Start Here
IMPORTANT: Before using this product, make sure you read these
instructions and the safety instructions in the online User’s Guide.
Unpack
1
Ink cap
storage bag
Note:
• Do not open ink cartridge packages until you are ready to install the
ink. Cartridges are vacuum packed to maintain reliability.
• The CD/DVD tray is stored underneath cassette 2.
1 Remove all protective materials from the product.
1 Connect the power cord to the back of the product and to
an electrical outlet.
Caution: Do not connect to your computer yet.
2 Turn on the product, then adjust the control panel.
3 Select your language.
Note:
• You can change the language later using the product’s control
panel. For more information, see the online User’s Guide.
• If an error message appears, turn off the product and check
that no protective material has been left inside the product.
2 Lift up the scanner unit and remove all protective
materials from inside the product.
3 Lower the scanner unit.
Install ink cartridges
3
Caution: Keep the ink cartridges out the reach of children and do not
drink the ink.
1 Lift up the scanner unit until it locks into place.
Caution: Do not touch the flat, white cable.
2 Gently shake the Black (BK) ink cartridge. Do not shake
the Photo Black (PB) or other ink cartridges.
XP7100_SH_E_CPD55769.indd 1
3 Unpack the ink cartridges.
Caution: Do not touch the areas shown below. Doing so may
prevent normal operation and printing.
4 Remove cap from each ink cartridge. Store the caps in the
included plastic bag.
Note: Save the caps and use them to recap the ink cartridges
after removing them for storage or disposal.
5 Insert the cartridges at an angle in the holder for each
color. Press each cartridge down until it clicks.
Load paper
4
Output tray
Cassette 1
Cassette 2/front cover
You can load the following paper sizes:
• Cassette 1: 3.5 × 5-, 4 × 6-, or 5 × 7-inch photo paper
• Cassette 2: Letter-, A4-, legal-size, or 8 × 10-inch paper
See the online User’s Guide for information about available
paper types and sizes, loading capacities, and printing on
CD/DVD/Blu-ray® discs.
1 Lower the front cover and raise the control panel.
6 Lower the scanner unit.
7 Select Installed to start charging the ink. Ink charging
takes approximately 7 minutes. When you see a
completion message on the printer’s LCD screen,
charging is complete.
Caution: Don’t turn off the printer or raise the scanner unit while
the printer is charging or you’ll waste ink.
Note:
• The printer is designed for use with Epson® cartridges only, not
third-party cartridges or ink.
• The cartridges included with the printer are designed for
printer setup and not for resale. After some ink is used for
charging, the rest is available for printing.
• As part of setup, your product’s serial number will be sent to a
secure Epson server so that you can be eligible to participate
in programs we may offer from time to time, including the
Epson ink replenishment program. You will have a separate
opportunity to consent to participating in such programs.
2 Pull out a paper cassette.
Cassette 1 Cassette 2
3 Slide the side edge guides outward and set the front edge
guide to the paper size you are using.
Cassette 1 Cassette 2
4 Insert the paper with the glossy or printable side
facedown.
8 Follow the on-screen instructions to adjust the print
quality of your product.
Note:
• You need to load paper before you can adjust the print quality.
See “Load paper” below for details.
• Select Adjust Later on the printer’s LCD screen if you want
to adjust the print quality later. For more information, see the
online User’s Guide.
Cassette 1 Cassette 2
Note: Make sure the paper is loaded against the back of the
cassette and not sticking out from the front of the cassette.
5 Slide the side edge guides against the paper, but not too
tight. Make sure the paper is under the tabs on the side
edge guides.
Cassette 1 Cassette 2
6 Keep the cassette flat as you insert it all the way.
4 When you see the Select Your Connection screen, select
one of the following and follow the on-screen instructions:
• Wireless connection
In most cases, the software installer automatically
attempts to set up your wireless connection. If setup
is unsuccessful, you may need to enter your network
name (SSID) and password.
• Direct USB connection
Make sure you have a USB cable (not included).
• Wired network connection
Make sure you have an Ethernet cable (not included).
Mobile printing
Cassette 1 Cassette 2
7 Lower the control panel.
8 Select the paper settings on the product’s control panel.
Install software
5
Note: If you are using a Mac or your computer does not have a
CD/DVD drive, an Internet connection is required to obtain the product
software.
To print from a Chromebook™, go to www.epson.com/support/gcp
(U.S.) or www.epson.ca/support/gcp (Canada) for instructions.
1 Make sure the product is NOT CONNECTED to your
computer.
Windows®: If you see a Found New Hardware screen, click
Cancel and disconnect the USB cable.
2 Insert the product CD (Windows only) or download and
run your product’s software package. For the latest
software, visit: www.epson.com/support/xp7100 (U.S.)
or www.epson.ca/support/xp7100 (Canada).
3 Follow the instructions on the computer screen to run the
setup program.
Connect wirelessly from your smartphone, tablet, or computer.
Print documents and photos from across the room or around
the world:
• Print directly from your iOS device. Simply connect your
printer and device to the same network and tap the action
icon to select the print option.
• Use Epson Print Enabler (free from Google Play™) with
Android™ devices (v4.4 or later). Then connect your printer
and device to the same network and tap the menu icon to
select the print option.
• Print remotely with Epson Connect™ and Google Cloud
Print™. See your online User’s Guide for instructions or
learn more at www.epson.com/connect (U.S.) or
www.epson.ca/connect (Canada).
Any problems?
Network setup was unsuccessful.
• Make sure you select the right network name (SSID).
• Restart your router (turn it off and then on), then try to
connect to it again.
• The printer can only connect to a network that supports
2.4 GHz connections. If your router offers both 2.4 GHz and
5 GHz connections, make sure the 2.4 GHz connection is
enabled.
• If you see a firewall alert message, click Unblock or Allow
to let setup continue.
• If your network has security enabled, make sure you enter
your network password (WEP key or WPA passphrase)
correctly. Be sure to enter your password in the correct
case.
There are lines or incorrect colors in my printouts.
Run a nozzle check to see if there are any gaps in the printout.
Then clean the print head, if necessary. See the online User’s
Guide for more information.
The product’s screen is dark.
Make sure your product is turned on, and press any button to
wake it from sleep mode.
Setup is unable to find my printer after connecting it
with a USB cable.
Make sure the printer is turned on and that it is securely
connected as shown:
Need paper and ink?
Ensure brilliant results with Epson specialty
papers, engineered specifically for Epson
printers. Find specialty papers and Epson
Genuine Ink at www.epson.com (U.S. sales) or
www.epson.ca (Canadian sales) and at Epson
authorized resellers. Call 800-GO-EPSON
(800-463-7766).
XP-7100 replacement ink cartridges
Color Standard-capacity High-capacity
Any questions?
Quick Guide
Basic information and troubleshooting.
User’s Guide
Windows: Click the icon on your desktop or Apps screen to
access the online User’s Guide.
Mac: Click the icon in Applications/Epson Software/Guide to
access the online User’s Guide.
If you don’t have a User’s Guide icon, go to the Epson website,
as described below.
Support
Visit www.epson.com/support/xp7100 (U.S.) or
www.epson.ca/support/xp7100 (Canada) to download
drivers, view manuals, get FAQs, or contact Epson.
Call (562) 276-4382 (U.S.) or (905) 709-3839 (Canada), 6 am to
8 pm, Pacific Time, Monday through Friday, and 7 am to 4 pm,
Pacific Time, Saturday. Days and hours of support are subject
to change without notice. Toll or long distance charges may
apply.
Black 410 410XL
Cyan 410 410XL
Magenta 410 410XL
Yellow 410 410XL
Photo Black 410 410XL
Recycling
Epson offers a recycling program for end of life hardware and
ink cartridges. Please go to www.epson.com/recycle (U.S.)
or www.epson.ca/recycle (Canada) for information on how to
return your products for proper disposal.
EPSON and Claria are registered trademarks, EPSON Exceed Your Vision is a registered
logomark, and Epson Connect is a trademark of Seiko Epson Corporation.
Small-in-One is a registered trademark and Designed for Excellence is a trademark of
Epson America, Inc.
Mac is a trademark of Apple Inc., registered in the U.S. and other countries. iOS is a trademark
or registered trademark of Cisco in the U.S. and other countries and is used under license.
Windows is a registered trademark of Microsoft Corporation in the United States and/or other
countries.
Android, Chromebook, Google Cloud Print, and Google Play are trademarks of Google LLC.
General Notice: Other product names used herein are for identication purposes only and may
be trademarks of their respective owners. Epson disclaims any and all rights in those marks.
This information is subject to change without notice.
© 2018 Epson America, Inc., 5/18
Printed in XXXXXX CPD-55769
