User’s Guide

Notations Used in This Guide

f Safety indications

So that you can use the product safely and correctly, symbols are applied in the User's Guide and on the product to indicate possible harm to the user or to others and the risk of damage to property. The indications and their meaning are as follows. Make sure you understand them properly before reading the guide.

Warning

Caution

f General information indications

Attention

This symbol indicates information that, if ignored, could possibly result in death or personal injury due to incorrect handling.

This symbol indicates information that, if ignored, could possibly result in personal injury or physical damage due to incorrect handling.

Indicates procedures which may result in damage or injury if sufficient care is not taken.

Indicates additional information and points which may be useful to know regarding a topic.

Procedure

[ (Name) ]

Indicates a page where detailed information regarding a topic can be found.

Indicates that an explanation of the underlined word or words in front of this symbol appears in the glossary of terms. See the "Glossary" section of the "Appendices". s p.112

Indicates operating methods and the order of operations. The procedure indicated should be carried out in the order of the numbered steps.

Indicates the name of the buttons on the remote control or the control panel. Example: [Esc] button

"(Menu Name)"

Indicates configuration menu items. Example: "Image" - "Brightness"

Projector Features......................................................................................5

Features Common to Each Model ....................................................................... 5

EB-1735W/1725/1723 Features...........................................................................6

Part Names and Functions ........................................................................7

Front/Top.............................................................................................................. 7

Rear ..................................................................................................................... 8

Base ................................................................................................................... 10

Control Panel ..................................................................................................... 11

Remote Control .................................................................................................. 12

Useful Functions

Changing the Projected Image................................................................15

Automatically Detect Incoming Signals and Change the Projected Image

(Source Search) ................................................................................................. 15

Changing Directly from the Remote Control ...................................................... 16

Functions for Enhancing Projection.......................................................17

Selecting the Projection Quality

(Selecting Color Mode) ...................................................................................... 17

Setting the Auto Iris............................................................................................ 18

Hiding the Image and Sound Temporarily (A/V Mute) .......................................18

Freezing the Image (Freeze).............................................................................. 19

Changing the Aspect Ratio ................................................................................ 20

Pointer Function (Pointer) .................................................................................. 24

Enlarging Part of the Image (E-Zoom) ............................................................... 25

Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)..... 27

Restrictions in the Target Projector when Using

Multiple Projectors ...................................................................................29

Setting the Projector ID ...................................................................................... 30

Setting the Projector ID on the Remote Control................................................. 30

Correcting Color for Multiple Projectors (Multi-Screen Color

Adjustment)...............................................................................................31

Summary of Correction Procedure.....................................................................31

Correction Method.............................................................................................. 31

Security Functions ...................................................................................33

Managing Users (Password Protect) ................................................................. 33

Restricting Operation (Control Panel Lock)........................................................35

Configuration Menu

Using the Configuration Menu................................................................38

List of Functions ...................................................................................... 39

Image Menu....................................................................................................... 39

Signal Menu....................................................................................................... 41

Settings Menu.................................................................................................... 43

Extended Menu.................................................................................................. 45

Network Menu (EB-1735W/1725/1723 only) ..................................................... 47

Info Menu (Display Only) ................................................................................... 60

Reset Menu ....................................................................................................... 61

Troubleshooting

Using the Help .......................................................................................... 63

Problem Solving.......................................................................................64

Reading the Indicators ....................................................................................... 64

When the Indicators Provide No Help................................................................ 67

Appendices

Installation Methods ................................................................................ 77

Cleaning ....................................................................................................78

Cleaning the Projector's Surface ....................................................................... 78

Cleaning the Lens .............................................................................................. 78

Cleaning the Air Filter ........................................................................................ 78

Replacing Consumables ......................................................................... 79

Replacing the Remote Control Batteries ........................................................... 79

Replacing the Lamp ........................................................................................... 80

Replacing the Air Filter ...................................................................................... 84

Optional Accessories and Consumables .............................................. 85

Saving a User's Logo............................................................................... 86

Making a WPS (Wi-Fi Protected Setup) Connection

with a Wireless LAN Access Point (EB-1735W/1725/1723 only).......... 88

Connection Setup Method ................................................................................. 88

Screen Size and Distance........................................................................ 92

Projection Distance for EB-1725/1723/1720...................................................... 92

Projection Distance for EB-1735W/1730W........................................................ 93

Contents

Connecting and Removing USB Devices

(EB-1735W/1725/1723 only) .....................................................................94

Connecting USB Devices................................................................................... 94

Removing USB Devices..................................................................................... 94

Connecting with a USB Cable and Projecting

(USB Display EB-1735W/1725/1723 only)..............................................95

Connecting ......................................................................................................... 95

Reading Problem Mail Notification Function

(EB-1735W/1725/1723 only) .....................................................................98

ESC/VP21 Commands..............................................................................99

Command List .................................................................................................... 99

Cable Layouts .................................................................................................... 99

USB Connection Setup .................................................................................... 100

Regarding Network Projector (EB-1735W/1725/1723 only) ................101

About PJLink ..........................................................................................102

List of Supported Monitor Displays......................................................103

Supported Monitor Displays for EB-1725/1723/1720....................................... 103

Supported Monitor Displays for EB-1735W/1730W ......................................... 105

Specifications .........................................................................................107

Projector General Specifications...................................................................... 107

Software Requirement ..................................................................................... 109

Appearance .............................................................................................111

Glossary ..................................................................................................112

Index ........................................................................................................114

Projector Features

Features Common to Each Model

Ease of use

f Compact and lightweight

Easy to carry with its compact B5 file size body (202 mm (D) x 284 (W) x 65 mm (H)) and lightweight body (1.7 kg ~ 1.8 kg). *EB-1735W/1725/1723:Approx. 1.8kg

EB-1730W/1720:Approx. 1.7kg

f The A/V mute slide makes it easy to project and store

You can stop and resume projection easily by opening and closing the A/V mute slide which makes giving clear presentations easier.

f A single foot design means you do not have to make any difficult

leveling adjustments

You can easily make height adjustments with one hand.

s Quick Start Guide

Enhanced security functions

f Password Protect to restrict and manage users

By setting a password you can restrict who can use the projector.

s p.33

f Control Panel Lock restricts button operation on the control panel

You can use this to prevent people changing projector settings without permission at events, in schools, and so on. s p.35

Easy to handle

f Short distance projection

The recommended shortest projection distance with the WXGA is 62 cm

(24 in.)* and 65 cm (26 in.) with the XGA, so projector can be placed close to the screen. Therefore, even in a small meeting room, you can easily setup the projector. *The projection screen size at this distance, for example, with a 16:10

screen size, is approximately 66 x 41 cm (26 x 16 in.).

f No cool down delay

After turning the projector’s power off, you can disconnect the projector’s power cable without having to wait for the projector to cool down first.

f Projection screen for WXGA (EB-1735W/1730W only)

With a computer that has a 16:10 wide LCD display, the image can be projected in the same aspect, whiteboards and other landscape format screens can be used.

Projector Features

EB-1735W/1725/1723 Features

You can make effective use of your network by using the supplied "EPSON Projector Software for Meeting & Presentation" to perform efficient and varied presentations and meetings.

Multi-connection

f Connect a computer to the projector via a network

By connecting the projector to an already constructed network system via a specific wireless LAN unit, you can have efficient meetings and so on as follows.

• From a conference room, you can open and project a file stored on a computer or file server in another room.

• You can use the Internet.

• You can monitor and control projectors on a network from the computer.

When you install the optional wired LAN unit in the projector, you can connect that to a computer via a network cable. s EasyMP Operation

Guide

f Projecting with network connection

The projector can be used in the following three ways.

• Quick Wireless Connection

Using the specific USB key for Quick Wireless Connection, you can quickly connect one computer to one projector for projection. s EasyMP Operation Guide s Quick Start Guide

• Quick Connection Mode/Advanced Connection Mode

With EMP NS Connection, the computer and projector are connected via a network. s EasyMP Operation Guide

f Connect using a USB cable

(USB display)

Simply by connecting a commercially available USB cable to a Windows computer you can project images from the computer's screen. You can also get audio output without connecting an audio

cable. s Quick Start Guide s p.95

Presentations without a computer

Without computers, you can make presentations using JPEG images, movies, and scenarios stored on USB devices, such as digital cameras or hard disks. s EasyMP Operation Guide

Second and third screen projection (Multi-screen display)

You can project a different image from up to four projectors from one computer. This allows you to project a report and so on as a landscape screen. s EasyMP Operation Guide

Internet

f Connection with Windows Vista's "Network Projector"

By connecting the projector to a network and using the "Network Projector" function in Windows Vista, multiple users on the network can share the projector.

Part Names and Functions

Front/Top

Name Function

A/V mute slide Close when not using the projector to protect

the lens. By closing during projection you can hide the image and the sound (A/V Mute).

s Quick Start Guide, s p.18

Foot adjust lever Pull out the foot lever to extend and retract the

front foot. s Quick Start Guide

Front adjustable

foot

Remote receiver Receives signals from the remote control.

Air intake vent

(Air filter)

Extend and adjust the position of the projected image when the projector is placed on a surface such as a desk. s Quick Start Guide

s Quick Start Guide

Air is taken in through this opening to cool the inside of the projector. If dust collects here it can cause the internal temperature of the projector to rise, and this can lead to problems with operation and shorten the optical engine's service life. Clean the air filter regularly.

s p.78, p.84

Name Function

Air exhaust vent

A/V mute slide

knob

Caution

Do not place objects that may become warped or otherwise affected by heat near the air exhaust vent and do not put your face or hands near the air exhaust vent while projection is in progress.

Slide the knob to open and close the A/V mute slide.

Wireless LAN unit

cover (EB-1735W/1725/ 1723 only)

Focus ring Adjusts the image focus. s Quick Start

Zoom ring Adjusts the image size. s Quick Start Guide

USB indicator

(EB-1735W/1725/ 1723 only)

When making a wireless connection between the projector and computer, remove this cover to install the specific wireless LAN unit.

s Quick Start Guide

Guide

Indicates USB Type A access status. OFF: USB device is not connected Orange Light ON: USB device is connected Green Light ON: PC Free is in operation Red Light ON: Error

Part Names and Functions

Name Function

Control panel s p.11

Lamp cover Open this cover when replacing the projector's

lamp. s p.80

Rear

Name Function

S-video input port For S-video signals from video sources.

Power inlet Connects to the power cable. s Quick Start

Guide

Video input port For composite video signals from video

sources.

Remote receiver Receives signals from the remote control.

s Quick Start Guide

Security slot The security slot is compatible with the

Microsaver Security System manufactured by Kensington. You can find details about the Microsaver Security System on the Kensington homepage http://www.kensington. com/

Screw hole for

the lamp cover

Screw hole to fix the lamp cover in place.

s p.80

Part Names and Functions

Name Function

USB port (Type A)

(EB-1735W/1725/ 1723 only)

USB port (Type B) Connects the projector to a computer by a

Audio-L/R input

port

Computer

(Component Video) input port

Connects the memory for compatible digital cameras and USBs, and projects image/movie files and scenarios with the PC Free of EasyMP. s p.94

USB cable, and the image on the computer is projected. (EB-1735W/1725/1723 only)

s Quick Start Guide

Use this port also to connect with a computer to use the wireless mouse function. s p.27

For the audio signal of connected equipment. When projecting with the PC Free function of EasyMP, you can output the audio to an external speaker by setting "EasyMP Audio Out" from the configuration menu. (EB-1735W/ 1725/1723 only)

For video signals from a computer and component video signals from other video sources.

Part Names and Functions

Base

Name Function

Screw hole for

the wireless LAN unit cover

Screw hole to fix the wireless LAN unit cover.

s Quick Start Guide

Name Function

Ceiling mount

fixing points (3 points)

Rear foot When setup on a desk, turn to extend and

Attach the optional ceiling mount here when suspending the projector from a ceiling.

s p.77, 85

retract to adjust the horizontal tilt. s Quick Start Guide

Part Names and Functions

Control Panel

Name Function

Status indicators The color of the indicators and whether they

are flashing or lit indicate the status of the projector. s p.64

[t] button Turns the projector power on or off. s Quick

Start Guide

[Source Search]

button

Changes to the next input source that is connected to the projector and is sending an image. s p.15

Name Function

[Enter] button If pressed during projection of computer signal

images, it automatically adjusts the tracking, synchronization, and position to project the optimum image. When a configuration menu or a help screen is displayed, it accepts and enters the current selection and moves to the next level. s p.38

[] [] buttons

[Help] button Displays and closes the help screen which

[Esc] button Stops the current function.

[] [] buttons

Corrects keystone distortion. In the following cases, however, these buttons only have the

[ ] and [ ] functions.

• When the projected image is being sent through a network connection

• When the PC Free function is being used for projection

If pressed when a configuration menu or a help screen is displayed, these buttons select menu items and setting values. s Quick Start Guide, p.38

shows you how to deal with problems if they occur. s p.63

If pressed when a configuration menu is displayed, it moves to the previous menu level.

s p.38

Adjusts the volume. If pressed while a configuration menu or a help screen is

displayed, these buttons only have the [ ] and [ ] functions which select menu items

and setting values. s Quick Start Guide,

p.38

[Menu] button Displays and closes the configuration

menu.s p.38

Part Names and Functions

Remote Control

Name Function

[t] button Turns the projector power on or off. s Quick

Start Guide

[Computer]

button

[S-Video] button Changes to images from the S-video input

Numeric buttons Use when specifying password entry or remote

[A/V Mute] button Turns the video and audio on or off. s p.18

[Freeze] button Images are paused or unpaused. s p.19

[Auto] button If pressed during projection of computer signal

[Aspect] button The aspect ratio changes each time the button

Changes to images from the computer input port. s p.16

port. s p.16

control ID. s p.33, p.30

images, it automatically adjusts the tracking, synchronization, and position to project the optimum image.

is pressed. s p.20

[Page] buttons

([) (])

[E-zoom] buttons

[z] [x]

[Menu] button Displays and closes the configuration menu.

Moves to the next/previous slide when using the wireless mouse function, or projecting a PowerPoint file or a scenario from EasyMP as input source. (EB-1735W/1725/1723 only)

s EasyMP Operation Guide

(z) Enlarges the image without changing the projection size. (x) Reduces parts of images that have been enlarged using the [z] button.

s p.38

Part Names and Functions

Name Function

[ ] button

[Enter] button When a configuration menu or a help screen is

[Esc] button Stops the current function. If pressed when a

[Volume] buttons

[a] [b]

[Pointer] button Press to activate the on screen pointer.

[Help] button Displays and closes the help screen which

When a configuration menu or help screen is displayed, it selects menu items and setting values. s p.38, p.63

displayed, it accepts and enters the current selection and moves to the next level. s p.38,

p.63

Acts as a mouse's left button when using the wireless mouse function.

configuration menu is displayed, it moves to the previous level. s p.38, p.63 Acts as a mouse's right button when using the wireless mouse function.

(a) Decreases the volume. (b) Increases the volume.

s Quick Start Guide

s p.24

shows you how to deal with problems if they occur. s p.63

Name Function

[User] button Press to assign a frequently used item from

the six available Configuration menu items. By pressing the button the assigned menu item selection/adjustment screen is displayed, allowing you to make one-touch settings/ adjustments. s p.43 "Brightness Control" is assigned as the default setting.

[ID] button Press to set the remote control ID. s p.30

[Video] button Changes to images from the video input port.

s p.16

[EasyMP] button Changes to the EasyMP image. (EB-1735W/

1725/1723 only) s p.16 When using EB-1730W/1720, this does not function even if the button is pressed.

[Search] button Changes to the next input source that is

connected to the projector and is sending an image. s p.15

Remote control

light-emitting area

Outputs remote control signals.

[Color Mode]

button

[Num] button Use when entering a password. s p.33

Each time the button is pressed, the color mode changes. s p.17

Useful Functions

This chapter explains useful functions for giving presentations and so on, and the security functions.

Changing the Projected Image .......................... 15

• Automatically Detect Incoming Signals and

Change the Projected Image (Source Search)................15

• Changing Directly from the Remote Control .................16

Functions for Enhancing Projection................. 17

• Selecting the Projection Quality

(Selecting Color Mode) .....................................................17

• Setting the Auto Iris..........................................................18

• Hiding the Image and Sound Temporarily

(A/V Mute) .........................................................................18

• Freezing the Image (Freeze).............................................19

• Changing the Aspect Ratio...............................................20

Changing methods..........................................................................20

Changing the aspect for video equipment images..........................20

Changing the aspect for computer images

(For EB-1725/1723/1720) .........................................................21

Changing the aspect for computer images

(For EB-1735W/1730W)...........................................................22

Restrictions in the Target Projector when

Using Multiple Projectors...................................29

• Setting the Projector ID ................................................... 30

• Setting the Projector ID on the Remote Control ........... 30

Correcting Color for Multiple Projectors

(Multi-Screen Color Adjustment) .......................31

• Summary of Correction Procedure ................................ 31

• Correction Method ........................................................... 31

Security Functions..............................................33

• Managing Users (Password Protect)............................... 33

Type of Password Protect .............................................................. 33

Setting Password Protect................................................................ 33

Entering the Password.................................................................... 35

• Restricting Operation (Control Panel Lock) ................. 35

• Pointer Function (Pointer) ...............................................24

• Enlarging Part of the Image (E-Zoom) ...........................25

• Using the Remote Control to Operate the Mouse

Pointer (Wireless Mouse) .................................................27

Changing the Projected Image

You can change the projected image in the following two ways.

• Changing by Source Search The projector automatically detects signals being input from connected equipment, and the image being input from the equipment is projected.

• Changing directly You can use the remote control buttons to change to the target input port.

Automatically Detect Incoming Signals and Change the Projected Image (Source Search)

You can project the target image quickly as input ports with no image signal being input are ignored when you change by pressing the [Source Search] button.

Computer Video

The input port where no image signal is being input is skipped.

S-video

Procedure

When your video equipment is connected, start playback before beginning this operation.

Using the remote control Using the control panel

When two or more pieces of equipment are connected, press the [Source Search] button until the target image is projected.

The following screen showing the status of image signals is

displayed when only the image that the projector is currently displaying is available, or when no image signal can be found. You can select the input port where the connected equipment you want to use is projecting. If no operation is performed after about 10 seconds, the screen closes.

*Only EB-1735W/1725/1723 changes to EasyMP.

EasyMP

Changing the Projected Image

Changing Directly from the Remote Control

You can change directly to the target image by pressing the following buttons on the remote control.

Remote control

Changes to images from the computer input port.

Changes to images from the S-video input port.

Changes to the EasyMP image. (EB-1735W/1725/ 1723 only) When using EB-1730W/ 1720, this does not function even if the button is pressed.

Changes to images from the video input port.

Functions for Enhancing Projection

Selecting the Projection Quality (Selecting Color Mode)

You can easily obtain the optimum image quality simply by selecting the setting that best corresponds to your surroundings when projecting. The brightness of the image varies depending on the mode selected.

Mode Application

Game Ideal for use in a bright room. This is the brightest

mode, and reproduces shadow tones well. If you are worried about image delays during projection for games involving speed, try turning setting "Progressive" from the configuration menu to "Off". s p.41

Presentation Ideal for making presentations using color materials

in a bright room.

Tex t Ideal for making presentations using black-and-

white materials in a bright room.

Theatre Ideal for watching films in a dark room. Gives

images a natural tone.

Photo (When computer images are input)

Ideal for projecting still pictures, such as photos, in a bright room. The images are vivid and brought into contrast.

Sports (When component video, S-video, or composite

video images are input) Ideal for watching TV programmes in a bright room. The images are vivid and brought to life.

Mode Application

Customized Select "Customized" to adjust "R,G,B,C,M,Y" from

"Color Adjustment" in the configuration menu.

s p.39

Procedure

Remote control

Each time you press the button, the color mode name is displayed on the screen and the color mode changes.

If you press the button while the color mode name is displayed on the screen, it changes to the next color mode.

The color mode can also be set using "Color Mode" in the

"Image" menu from the configuration menu.

p.39

sRGBg Ideal for images that conform to the sRGB color

standard.

Blackboard Even if you are projecting onto a blackboard

(greenboard), this setting gives your images a natural tint, just like when projecting onto a screen.

Functions for Enhancing Projection

Setting the Auto Iris

By automatically setting the luminance according to the brightness of the displayed image, it lets you enjoy deep and rich images.

Procedure

Press the [Menu] button and select "Image" - "Auto Iris" from the configuration menu. s "Using the Configuration Menu" p.38

Using the remote control Using the control panel

Select "On".

The setting is stored for each color mode.

Hiding the Image and Sound Temporarily (A/V Mute)

You can use this when you want to focus the audience's attention on what you are saying, or if you do not want to show details such as when you are changing between files during presentations from a computer.

Procedure

Remote control

Press the [Menu] button to close the configuration menu.

Auto Iris can be set only when the color mode is Game, Theatre or Customized.

Each time you press the button, A/V Mute turns on or off.

Functions for Enhancing Projection

• If you use this function when projecting moving images,

the images and sound continue to be played back by the source, and you cannot return to the point where A/V Mute was activated.

• You can choose to display black, blue, or logo as the A/V mute display using the "Extended"-"Display"-"A/V Mute" setting from the configuration menu.

• You can set so that the projector automatically turns off about 30 minutes after the A/V mute slide is closed and A/V mute begins. To make the setting, use "Extended" "Sleep Mode" of the configuration menu.

p.46

Freezing the Image (Freeze)

When the moving image on the screen is frozen, the image continues to project, so you can project a moving image one frame at a time like a still photo. Also, you can perform operations such as changing between files during presentations from a computer without projecting any images if the freeze function is activated beforehand.

p.45

Procedure

Remote control

Each time you press the button, Freeze turns on or off.

• Audio does not stop.

• The image source continues to playback the moving images even while the screen is frozen, and so it is not possible to resume projection from the point where it was paused.

• If the [Freeze] button is pressed while the configuration menu or a help screen is displayed, the menu or help screen being displayed is cleared.

• Freeze still works while E-Zoom is being used.

Functions for Enhancing Projection

l16

Changing the Aspect Ratio

Change the aspect ratiog when video equipment is connected so that images that have been recorded in digital video or onto DVDs can be viewed in 16:9 wide-screen format. Change the aspect ration when projecting computer images at full size. The changing methods and the types of aspect ratio are as follows.

f Changing methods

Procedure

Remote control

f Changing the aspect for video equipment images

For EB-1725/1723/1720

4:3

For EB-1735W/1730W

orma

16:9

Through

Zoom

Each time you press the button, the aspect name is displayed on the screen and the aspect changes.

If you press the button while the aspect name is displayed on the screen, it changes to the next aspect mode.

The aspect ratio can also be set using "Aspect" in the

"Signal" menu from the configuration menu.

p.41

Functions for Enhancing Projection

f Changing the aspect for computer images (For EB-1725/1723/1720)

When projecting images input from a computer image input port, you can change the aspect as follows.

Set Values Operation Projection example

Normal When images are

input from the computer input port

4:3 Projects to the full projection size at an aspect of

Projects to the full projection size retaining the aspect of the input image.

When a 1280 ^ 1024 signal is input

4:3. This is ideal for when you want to project images at an aspect of 5:4 (1280 ^ 1024) to the full projection size.

16:9 Projects at a 16:9 aspect. This is ideal for

projecting at full screen size when using a 16:9 screen.

When projecting computer images, if parts of the image are missing or it cannot project everything, set "Wide" or "Normal" in

"Resolution" from the configuration menu depending on the size of the computer panel.

Normal

When a 1280 ^ 1024 signal is input

p.41

4:3

Functions for Enhancing Projection

f Changing the aspect for computer images (For EB-1735W/1730W)

When projecting images input from a computer image input port, you can change the aspect as follows. EB-1735W/1730W offer WXGA 1280 x 800 resolution (aspect ratio 16:10). When projecting onto 16:9 screens, set the aspect to "16:9".

Set Values Operation Projection example

Normal When images are

input from the computer input port

Projects to the full projection size retaining the aspect of the input image.

When a 1024 ^ 768 signal is input

16:9 Projects to the full projection size at an aspect of

16:9.

Full Project at full size. When a 1024 ^ 768 signal is input

Zoom Projects the input image at the lateral direction

aspect size as it is. Parts that extend beyond the projection size are not projected.

When a 1024 ^ 768 signal is input

Functions for Enhancing Projection

Set Values Operation Projection example

Through Projects at the resolution of the input image size

to the center of the screen. This is ideal for projecting clear images. If the image resolution exceeds 1280 ^ 800, the edges of the image are not projected.

When projecting computer images, if parts of the image are missing or it cannot project everything, set "Wide" or "Normal" in

"Resolution" from the configuration menu depending on the size of the computer panel.

When an 800 ^ 600 signal is

input

p.41

When a 1400 ^ 1050 signal is

input

Functions for Enhancing Projection

Pointer Function (Pointer)

This allows you to move a pointer icon on the projected image, and helps you draw attention to the area you are talking about.

Procedure

Display the pointer.

Remote control

When pressed in conjunction with the adjacent [ ] button, the pointer can be moved diagonally in addition to up/down and left/right.

Move the pointer icon.

Remote control

Pointer icon

You can choose from three different kinds of pointer ( · · ) in "Settings

configuration menu.

" - "Pointer Shape" from the

p.43

icon

Each time you press the button, the pointer appears or disappears.

Functions for Enhancing Projection

Enlarging Part of the Image (E-Zoom)

This is useful when you want to expand images to see them in greater detail, such as graphs and tables.

Procedure

Start E-Zoom.

Remote control

When pressed in conjunction with the adjacent [ ] button, the pointer can be moved diagonally in addition to up/down and left/right.

Move the cross to the area of the image that you want to enlarge.

Remote control

Cross

Functions for Enhancing Projection

Enlarge.

Remote control

Each time the button is pressed, the area is expanded. You can expand quickly by holding the button down. You can reduce the enlarged image by pressing the [x] button. Press the [Esc] button to cancel.

• The enlargement ratio appears on the screen. The selected area can be enlarged to between 1 to 4 times in 25 incremental steps.

• Press the [ ] button to scroll the image.

• If E-Zoom is selected when Progressive is being performed, the function currently being performed is temporarily cancelled.

Functions for Enhancing Projection

Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)

Connect the USB port of a computer and the USB port (TypeB) on the

rear of the projector with a commercially available USB cable*. If the "Extended" - "USB TypeB" setting in the configuration menu is set to "Wireless Mouse", you can use the projector's remote control like a wireless mouse to control the computer's mouse pointer. s p.46

Computer

Windows:98/98SE/2000/Me/XP Home Edition/ XP Professional/Vista Home Basic/Vista Home Premium/ Vista Business/Vista Enterprise/Vista Ultimate

Macintosh:OS8.6-9.2/10.0-10.5

* Supplied with the EB-1735W/1725/1723.

• It may not be possible to use the mouse function under some versions of both the Windows and Macintosh operating systems.

• Some computer settings may have to be changed in order for the mouse function to be used. Consult the documentation for the computer for further details.

To USB port

USB cable

To USB port (Type B)

Functions for Enhancing Projection

Once the connection has been made, the mouse pointer can be operated as follows.

Moving the mouse pointer Mouse clicks

Left click Right click When pressed in conjunction with the adjacent [ ] button, the pointer can be moved diagonally in addition to up/down and left/right.

Double-click: Press twice in rapid succession.

Drag and drop This is useful for displaying

the previous or next slide in a PowerPoint slideshow.

• If the mouse button settings are set to reverse on the computer, the operation of the remote control buttons will also be reversed.

• The wireless mouse function cannot be used while the following functions are being used.

· While a configuration menu is being displayed

· While a help menu is being displayed

· While the E-Zoom function is being used

· While a user's logo is being captured

· While a pointer function is being used

· While adjusting sound volume

When pressed in conjunction with the adjacent [ ] button, the pointer can be moved diagonally in addition to up/down and left/right.

1. While holding down the [Enter] button, press the [ ] button.

2. Release the [Enter] button to drop at the desired location.

To previous slide

To next slide

Restrictions in the Target Projector when Using Multiple Projectors

When an ID is set for the projector and the remote control, you can use the remote control to operate only the projector with a matching ID. This is very useful when managing multiple projectors. You can set an ID for the projector within a range of "1" to "9". While the projector’s ID setting is "OFF" (default setting), the remote control can be used regardless of the ID setting on the remote control. You can set a projector ID on the remote control within a range of "0" to "9". While the ID setting is "0" (default setting), the remote control can be used regardless of the projector’s ID setting. The ID setting on the remote control is reset to "0" each time you switch off the projector.

Remote Control: On (enabled) Remote Control: Off (disabled) Remote Control: On (enabled) Remote Control: On (enabled)

Projector ID: 1

Remote control ID: 1

The ID is matched between the projector and remote control

Projector ID: 1

Remote control ID: 3

The ID is mismatched between the projector and remote control

Projector ID: Off

Remote control ID: 1

Projector ID: any of 1 to 9

Remote control ID: 0

When the projector ID is Off When the ID setting on the

remote control is "0"

Restrictions in the Target Projector when Using Multiple Projectors

Setting the Projector ID

Procedure

During projection, press the [Menu] button on the projector and select "Extended" - "Projector ID" from the configuration menu. s "Using the Configuration Menu" p.38

Using the remote control Using the control panel

Setting the Projector ID on the Remote Control

Set the ID on the remote control each time you switch the projector power on.

Procedure

During projection, point the remote control at the remote receiver of the target projector. When you press the [ID] button on the remote control, the projector ID and remote control operation On/Off display is shown at the top right of the projection screen.

When remote control operations are

enabled:

When the display reads Off

While holding the [ID] button, press a number button to select a number to match the ID of the projector you want to operate.

B C

Choose the ID you want to set and press the [Enter] button.

Press the [Menu] button to close the configuration menu.

Keep pressed

Once this setting has been made, the projector that can be operated by the remote control is limited.

Correcting Color for Multiple Projectors (Multi-Screen Color Adjustment)

When multiple projectors are lined up and projecting images, you can correct the brightness and color tone of each projector's image with multi-screen color adjustment so that the colors of images from each projector match closely. In some cases the brightness and color tone may not match completely even after correction.

Summary of Correction Procedure

When multiple projectors are setup and you need to make corrections, use the following procedure to correct one projector at a time.

1. Set the projector ID and the remote control ID

To limit operation to one target projector, set a Projector ID for the target projector, and set the same ID for the remote control. s p.29

2. Correct the color difference

You can carry out color correction when projecting from multiple projectors. You can adjust from black to white in five stages called levels 1 to 5, and in each of these 5 levels you can adjust the following two points.

• Correcting brightness You can correct the image brightness to make them all equal.

• Correcting color You can adjust the image color to make them match more closely by using "Color Correct. (G/R)" and "Color Correct. (B/Y)".

Correction Method

After setting up the projectors, correct the brightness and tone for each projector to reduce the differences.

Procedure

Press the [Menu] button and select "Extended" "Multi-screen" from the configuration menu. s "Using the Configuration Menu" p.38

Select the level to be corrected in "Adjustment Level".

• Each time a level is selected, the pattern of the level selected is displayed.

• You can start correcting from any level, usually you can make it darker or lighter by correcting 1 to 5 or 5 to 1.

Correct the brightness with "Brightness Correct.".

• When you select level 5, it adjusts to the darkest image from multiple projectors.

• When you select level 1, it adjusts to the brightest image from multiple projectors.

• When you select level 2 to 4, it adjusts to the mid-range brightness image from multiple projectors.

• Each time the [Enter] button is pressed the image displayed changes between the pattern display and the actual image, and you can check the correction results and make corrections in the actual image.

Correcting Color for Multiple Projectors (Multi-Screen Color Adjustment)

E F

Correcting "Color Correct. (G/R)" and "Color Correct. (B/Y)".

Each time the [Enter] button is pressed the image displayed changes between the pattern display and the actual image, and you can check the correction results and make corrections in the actual image.

Repeat procedures 2 to 4 until corrections are finished.

When all corrections are finished, press the [Menu] button to close the configuration menu.

Security Functions

The projector has the following enhanced security functions.

• Password protect You can limit who can use the projector.

• Control Panel Lock You can prevent people changing the settings on the projector without permission.

• Anti-Theft Lock The projector is equipped with various types of anti-theft security devices. s p.8

Managing Users (Password Protect)

When Password Protect is activated, people who do not know the password cannot use the projector to project images even if the projector power is on. Furthermore, the user's logo that is displayed when you turn on the projector cannot be changed. This acts as an anti-theft device as the projector cannot be used even if it is stolen. At the time of purchase, Password Protect is not activated.

f Type of Password Protect

The following three kinds of password protect settings can be made according to how the projector is being used.

3. Network Protect (EB-1735W/1725/1723 only)

When "Network Protect" is set to "On" setting changes for "Network" in the configuration menu are prohibited.

f Setting Password Protect

Use the following procedure to set Password Protect.

Procedure

During projection, hold down the [Freeze] button for about five seconds.

The password protect setting menu is displayed.

Remote control

1. Power on protect

When "Power On Protect" is "On", the password must be entered whenever the projector is turned on after it has been disconnected from the power supply it was connected to the last time the password was entered. If the correct password is not entered, projection does not start.

2. User's logo protect

Even if someone tries to change the user's logo set by the owner of the projector, it cannot be changed. When "User's Logo Protect" is set to "On", the following setting changes for the user's logo are prohibited.

• Capturing a user's logo

• Settings for "Display Background", "Startup Screen", and "A/V Mute" from "Display" in the configuration menu.

• If Password Protect is already activated, you must enter the password. If the password is entered correctly, the password protect

setting menu is displayed.

p.35

• When the password is set, stick the password protect sticker in a visible position on the projector as a further theft deterrent.

"Entering the Password"

Security Functions

Turn on "Power On Protect".

(1) Select "Power On Protect", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button.

Turn on "User's Logo Protect".

(1) Select "User's Logo Protect", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button.

Turn on "Network Protect". (EB-1735W/1725/1723 only)

(1) Select "Network Protect", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button.

Set the password.

(1) Select "Password", and then press the [Enter] button. (2) The message "Change the password?" is displayed, select

"Yes" and then press the [Enter] button. The default setting for the password is "0000". Change this to your own desired password. If you select "No", the screen shown in step 1 is displayed again.

(3) While holding down the [Num] button, enter a four digit

number using the numeric buttons. The number entered is displayed as "* * * *". When you enter the fourth digit, the confirmation screen is displayed.

Remote control

Numeric buttons

Keep pressed

(4) Re-enter the password.

The message " Password accepted." is displayed. If you enter the password incorrectly, a message is displayed prompting you to re-enter the password.

Security Functions

f Entering the Password

When the password entry screen is displayed, enter the password using the numeric buttons on the remote control.

Procedure

While holding down the [Num] button, enter the password by pressing the numeric buttons.

When you enter the correct password, projection begins.

Attention

• If an incorrect password is entered three times in succession, the message "The projector's operation will be locked." is displayed for about five minutes, and then the projector switches to standby mode. If this happens, disconnect the power plug from the electrical outlet and then reinsert it and turn the projector's power back on. The projector displays the password entry screen again so that you can enter the correct password.

• If you have forgotten the password, make a note of the "Request Code: xxxxx" number that appears on the screen and contact the nearest address provided in the Support and Service Guide.

Epson Projector Contact List

• If you continue to repeat the above operation and input the wrong password thirty times in succession, the following message is displayed and the projector does not accept any more password entries. The projector's operation will be locked. Contact Epson as described in your documentation.

Epson Projector Contact List

Restricting Operation (Control Panel Lock)

Do one of the following to lock the operation buttons on the control panel.

•Full lock All of the buttons on the control panel are locked. You cannot perform any operations from the control panel, including turning the power on or off.

• Partial lock

All of the buttons on the control panel, except for the [t] button, are

locked.

This is useful at events or shows when you want to deactivate all buttons and only project, or at schools when you want to limit button operation. The projector can still be operated using the remote control.

Procedure

During projection, press the [Menu] button and select "Settings" - "Control Panel Lock" from the configuration menu. s "Using the Configuration Menu" p.38

Using the remote control Using the control panel

Security Functions

Select either "Full Lock" or "Partial Lock".

Select "Yes" when the confirmation message is displayed.

The control panel buttons are locked according to the setting you chose.

You can release the control panel lock by one of the following two methods.

• From the remote control, select "Off" in "Settings" "Control Panel Lock" from the configuration menu.

• Press and hold down the [Enter] button on the control panel for about seven seconds, a message is displayed and the lock is released.

Configuration Menu

This chapter explains how to use the configuration menu and its functions.

Using the Configuration Menu .......................... 38

List of Functions................................................. 39

• Image Menu .......................................................................39

• Signal Menu .......................................................................41

• Settings Menu ....................................................................43

• Extended Menu .................................................................45

• Network Menu (EB-1735W/1725/1723 only)..................47

Notes on operating the network menu............................................48

Soft keyboard operations................................................................48

Basic Menu.....................................................................................49

Wireless LAN menu.......................................................................50

Security menu.................................................................................52

Wired LAN Menu ..........................................................................56

Mail menu.......................................................................................57

Others menu ...................................................................................58

Reset Menu.....................................................................................59

• Info Menu (Display Only)................................................ 60

• Reset Menu........................................................................ 61

Using the Configuration Menu

Selecting from the top menu

Top menu

Guide

Selecting from the sub menu

Sub menu (Settings)

Changing the selected item

Exit

Buttons used

Using the control panel

Using the remote control

Select the setting to change

List of Functions

Image Menu

Items that can be set vary depending on the image signal currently being projected as shown in the following screen shots. Setting details are saved for each image signal.

Computer image/EasyMP (EB-1735W/1725/1723 only)

Sub Menu Function

Color Mode You can select the quality of the image to suit your surroundings. s p.17

Brightness You can adjust the image brightness. Contrastg You can adjust the difference between light and shade in the images.

Color Saturation You can adjust the color saturation for the images.

Tint (Adjustment is only possible when NTSC signals are being input if you use composite video/S-video.)

You can adjust the image tint.

Sharpness You can adjust the image sharpness. Abs. Color Temp. (This item cannot be selected if "sRGBg" is selected as the "Color Mode" setting from the "Image" menu.)

You can adjust the overall tint of the image. You can adjust tints in 10 stages from 5000 K to 10000 K. When a high value is selected the image becomes tinged with blue, when a low value is selected the image becomes tinged with red.

Color Adjustment You can make adjustments by choosing one of the following(This item cannot be selected if "sRGBg" is selected as the "Color Mode" setting

from the "Image" menu.) Red, Green, Blue: You can adjust the saturation of each color individually.

(This item cannot be displayed if "Customized" is selected as the "Color Mode" setting from the "Image" menu.)

R, G, B, C, M, Y: You can adjust the hue and saturation of each color R (red), G (green), B (blue), C (cyan), M (magenta), Y (yellow)

individually. (This item is only displayed if "Customized" is selected as the "Color Mode" setting from the "Image" menu.)

Auto Iris (This item is only displayed if "Game", "Theatre" or "Customized" is selected as the "Color Mode" setting from the "Image" menu.)

To optimally adjust luminance to match the image, set to On; otherwise set to Off. s p.18

Component videog/Composite videog/S-videog

List of Functions

Sub Menu Function

Reset You can reset all adjustment values for the "Image" menu functions to their default settings. To return all menu items to their default settings, see

s p.61

List of Functions

Signal Menu

Items that can be set vary depending on the image signal currently being projected as shown in the following screen shots. Setting details are saved for each image signal. You cannot make settings on the "Signal" menu when the source is EasyMP. (EB-1735W/1725/1723 only)

Computer image

Sub Menu Function

Auto Setup You can select whether or not (On/Off) the image is automatically adjusted to the optimum state when the input signal changes. s p.70 Resolution When set to "Auto", the resolution of the input signal is automatically identified. If the projected images cannot be projected correctly when set to

"Auto", such as when some of the image is missing, adjust to "Wide" depending on the connected computer for wide screens, or set to "Normal" for 4:3 or 5:4 screens.

Trackingg You can adjust computer images when vertical stripes appear in the images. s p.70 Sync.g You can adjust computer images when flickering, fuzziness, or interference appear in the images. s p.70 Position You can adjust the display position up, down, left, and right when a part of the image is missing so that all of the image is projected. Progressiveg (With component video, only 480i/576i signal input can set this.)

Off: IP conversion is carried out for each field in the screen. This is ideal for viewing images with a large amount of movement. On: Interlace

Input Signal You can select input signal from computer input port.

If set to "Auto" the input signal is set automatically according to the connected equipment. If colors do not appear correctly when set to "Auto", select the appropriate signal according to the connected equipment.

Video signal You can select input signal from video input port. If set to "Auto", video signals are recognized automatically. If interference appears in the image

or a problem occurs such as no image is being projected when set to "Auto", select the appropriate signal according to the connected equipment.

Aspect You can set the aspect ratiog for projected images. s p.20

g (i) signal is converted to Progressiveg (p). Applies to still images.

Component videog Composite videog/S-videog

List of Functions

Sub Menu Function

Reset You can reset all adjustment values on the "Signal" menu to their default settings, except for "Input Signal".

To return all menu items to their default settings, see s p.61

List of Functions

Settings Menu

EB-1735W/1725/1723 EB-1730W/1720

Sub Menu Function

Keystone You can correct keystone distortion in the vertical directions. s Quick Start Guide

Auto Keystone Turn "On" to perform Auto Keystone. (Executed only when "Front" is selected from the "Extended" - "Projection" menu.)

Control Panel Lock You can use this to restrict operation of the projector's control panel. s p.35

Pointer shape You can select the shape of the pointer. s p.24

Pointer 1: Pointer 2: Pointer 3:

Brightness Control You can set the lamp brightness to one of two settings.

Select "Low" if the images being projected are too bright such as when projecting images in a dark room or onto a small screen. When "Low" is selected, the amount of electricity consumed and the lamp's operating life are changed as follows, and fan rotation noise during projection is reduced. Electrical consumption: about a 25% decrease, lamp life: about 1.3 times longer

Volu m e You can adjust the volume. Setting details are saved for each image signal.

EasyMP Audio Out (EB-1735W/1725/ 1723 only)

Remote Receiver You can limit the reception of the operation signal from the remote control.

When the input source is EasyMP, you can change audio input port to audio output port. Internal: Audio input External: Audio output

When you want to prohibit operation by remote control, or if the remote receiver has a fluorescent light too close to it, you can make settings to deactivate the remote receiver you do not want to use or that is experiencing interference.

List of Functions

Sub Menu Function

User Button You can select the item assigned from the configuration menu with the remote control's [User] button. By pressing the button the assigned menu

item selection/adjustment screen is displayed, allowing you to make one-touch settings/adjustments. You can assign one of the following six items to the [User] button. Brightness Control, Info, Progressive, Test Pattern, Multi-screen, or Resolution

Te s t Pa t t e r n When the projector is setup, a test pattern is displayed so that you can adjust the projection without connecting other equipment. While the test

pattern is displayed, zoom, focus adjustments, and keystone correction can be performed. To cancel the test pattern, press the [Esc] button on the remote control or the control panel.

Reset You can reset all adjustment values on the "Settings" menu to their default settings, except for "User Button".

To return all menu items to their default settings, see s p.61

List of Functions

Extended Menu

EB-1735W/1725/1723 EB-1730W/1720

Sub Menu Function

Display You can make settings related to the projector's display.

Messages: You can set whether or not (On/Off) to display the source name when you change the input source, the color mode name when you

change the color mode, a message when no image signal is input, and so on.

Display Background*: You can set the screen status for when no image signal is available to "Black", "Blue", or "Logo". Startup Screen*: You can set whether or not (On/Off) the startup screen (the image projected when starting the projector) is displayed. A/V Mute*: You can set the screen displayed during A/V Mute as "Black", "Blue", or "Logo".

User's Logo

You can change the user's logo that is displayed as a background and displayed during A/V Mute. s p.86

Projection You can set from the following according to the way the projector is setup. s p.77

Front" "Front/Ceiling" "Rear" "Rear/Ceiling" You can change the setting as follows by pressing down the [A/V Mute] button on the remote control for about five seconds. Front"W"Front/Ceiling" Rear"W"Rear/Ceiling"

* When "User's Logo Protect" is set to "On" in "Password Protect", settings relating to user's logo cannot be changed. You can make changes after setting "User's

Logo Protect" to "Off". s p.33

List of Functions

Sub Menu Function

Operation Direct Power On: You can set whether or not (On/Off) to enable Direct Power On.

When it is set to "On" and the projector power cable is connected to an electrical outlet, be aware that sudden surges of electricity when power comes back on after a power outage may cause the projector to turn on automatically.

Sleep Mode: When set to "On", this automatically stops projection when no image signal is being input and no operations are carried out. Sleep Mode Timer: When Sleep Mode is set to "On", you can set the time before the projector automatically turns off within a range of 1 to 30

minutes.

Lens Cover Timer: When set to "On", this turns off the power automatically 30 minutes after the lens cover is closed. Lens Cover Timer is set to

"On" at the time of purchase.

High Altitude Mode: Set to "On" when using the projector above an altitude of 1500 m.

Standby mode (EB-1735W/1725/ 1723 only)

USB Type B (EB-1735W/1725/ 1723 only)

Link 21L Set "USB Type B" to "Link 21L". When set to "On", you can use the Link 21L utility software.

Projector ID Set the ID within a range of "1" to "9". "Off" indicates that no ID is set. s p.30

Multi-screen You can adjust the hue and brightness of each projected image when multiple projectors are lined up and projecting. s p.31

Language You can set the language for message displays.

Reset You can reset "Display*1" and "Operation*2" from the "Extended" menu to their default settings.

*1 When "User's Logo Protect" is set to "On" in "Password Protect", settings relating to user's logo cannot be changed. You can make changes after setting "User's

Logo Protect" to "Off". s p.33

*2 Except for "High Altitude Mode".

You can use network monitoring and control functions while the projector is in standby mode when this is set to "Network On". You can use SNMP this product.

Set to "USB Display" when the projector and a computer are connected by a USB cable and computer images are projected.

s Quick Start Guide Set to "Link 21L" when the mouse pointer is to be operated by the remote control. s p.27

Adjustment Level: You can adjust from black to white in five stages called levels 1 to 5, and in each of these 5 levels you can adjust "Brightness

Correct." and "Color Correct".

Brightness Correct.: Corrects the difference in the brightness of each product. Color Correct. (G/R) / Color Correct. (B/Y): You can correct the difference in the color of each product.

To return all menu items to their default settings, see s p.61

g to monitor and control the status of the projector over the network, or by using the "EMP Monitor"

software

supplied with

List of Functions

Network Menu (EB-1735W/1725/1723 only)

When "Network Protect" is set to "On" in "Password Protect", a message is displayed and the settings cannot be changed. You can make changes after setting "Network Protect" to "Off". s p.33

Sub Menu Function

Network Configuration

By using the Web browser of a computer connected to the projector on a network, you can set the projector's functions and control the

projector. This function is called "Web control". You can easily enter text using a keyboard to make settings for Web control such as security settings.

The following menus are available for setting network items. "Basic", "Wireless LAN", "Security", "Wired LAN", "Mail", "Others", "Reset" and "Setup complete".

EasyMP Operation Guide "Changing Settings Using a Web Browser (Web Control)"

List of Functions

f Notes on operating the network menu

Selecting from the top menu and sub menus, and changing of selected items are the same as operations in the configuration menu. When done, make sure you go to the "Complete menu", and select one of "Yes", "No", or "Cancel". When you select "Yes" or "No", you return to the configuration menu.

Yes: Saves the settings and exits the network menu.

No: Exits to the network menu without saving the settings.

Cancel: Continues displaying the network menu.

f Soft keyboard operations

The network menu contains items that require input of alphanumerics during setup. In this case, the following software keyboard is displayed.

Use the [ ] button on the remote control or [ ], [ ],

[ ], and [ ] on the projector to move the cursor to the desired key, and then press the [Enter] button to enter the alphanumeric. Enter

figures by holding down the [Num] button on the remote control, and pressing the numeric buttons. After inputting, press [Finish] on the keyboard to confirm your input. Press [Cancel] on the keyboard to cancel your input.

Each time this key is selected, it sets and changes between upper case and lower case letters.

Each time this key is selected, it sets and changes the symbol keys for the section enclosed by the frame.

List of Functions

f Basic Menu

Sub Menu Function

Projector name Displays the projector name used to identify the projector when connected to a network.

When editing, you can enter up to 16 single-byte alphanumeric characters.

PJLink Password Set a password to use when you access the projector using compatible PJLink software. s p.102

You can enter up to 32 single-byte alphanumeric characters.

Web Control Password

Projector Keyword When set to "On", you have to enter the keyword when you try to connect the projector to a computer on a network. As a result, you can prevent

Set a password to use when making settings and controlling the projector using Web control.*You can enter up to 8 single-byte alphanumeric characters. Web control is a computer function that allows you to set up and control the projector by using the Web browser on a computer connected on a network. s EasyMP Operation Guide "Changing Settings Using a Web Browser (Web Control)"

presentations from being interrupted by unscheduled connections from the computer. Normally this should be set to "ON". s EasyMP Operation Guide "Connecting to a Projector on a Network and Projecting"

List of Functions

f Wireless LAN menu

Sub Menu Function

Connection mode Use EMP NS Connection to set the mode, how the computer connect to the projector. Set to "Quick Connection Mode" when you want make a

quick wireless connection. Set to "Advanced Connection Mode" when you want to connect to a network system via an access point.

Setup by WPS When using a WPS (Wi-Fi Protected Setup) compatible access point via a wireless LAN, you can easily connect the projector to the access point

and make security settings. s p.88

Antenna level Displays the wireless LAN wave strength.

Wireless LAN system

SSIDg Enter an SSID. When an SSID is provided for the wireless LAN system in which the projector participates, enter the SSID.

DHCPg You can set whether or not (On/Off) to use DHCP.

IP Addressg You can input the IP address assigned to the projector.

Subnet Maskg You can input the subnet mask for the projector. You can input a number from 0 to 255 in each field of the address. However, the following subnet

Gateway Addressg You can input the IP address for the gateway for the projector.

Sets the wireless LAN system.

You can enter up to 32 single-byte alphanumeric characters.

If this is set to "On" you cannot set any more addresses.

You can input a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.

0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

masks cannot be used.

0.0.0.0, 255.255.255.255

You can input a number from 0 to 255 in each field of the address. However, the following gateway addresses cannot be used.

0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

List of Functions

Sub Menu Function

MAC Address Displays the MAC address.

SSID Display To prevent the SSID from being displayed on the EasyMP Standby screen, set this to Off.

IP Address Display To prevent the IP address from being displayed on the EasyMP Standby screen, set this to Off.

List of Functions

f Security menu

Sub Menu Function

Security Select the security type from the items that are displayed.

When setting up security, follow the instructions from the administrator of the network system you are about to access.

Type of security

When the specific wireless LAN unit is installed and being used in Manual Mode, it is strongly recommended that you set security. Select one of the following security methods.

•WEP Data is encrypted with a code key (WEP key) This mechanism prevents communication unless the encrypted keys for the access point and the projector match.

•WPA/WPA2 This is an encryption standard that improves security which is a weak point of WEP. Although there are multiple kinds of WPA encryption methods, this projector uses "TKIPg". TKIP uses PSK (Pre-Shared Key) to automatically update the encryption key at regular fixed intervals, which makes it harder to break compared to WEP which uses a constant encryption key. WPA also includes user authentication functions. WPA authentication provides two methods: using an authentication server, or authenticating between a computer and an access point without a server. This projector supports the latter method, without a server.

•EAP EAP is a protocol used for communication between clients and authentication severs. These are multiple protocols, such as EAP-TLS which uses electronic certification for user authentication, LEAP which uses user ID and password, and EAP-TTLS.

List of Functions

System Authentication

EAP-TLS Electronic certification, CA

EAP-TTLS User ID, Password

PEAP/MS-CHAPv2 User ID, Password

PEAP/EAP-GTC User ID, Password

LEAP User ID, Password

EAP-Fast User ID, Password

• For setting details, follow the directions from the network administrator of your network.

• If using EAP, you need to make settings at the projector that match the authentication server settings. Check with your network administrator for details on RADIUS settings.

• Register an electronic certificate and a CA certificate to the projector. Only one set of an electronic certificate and a CA certificate can be registered to the projector. These certificates are used with EAP-TLS.

certification

List of Functions

f When WEP is selected

Sub Menu Function

WEP encryption You can set the encryption for WEP encoding.

128 bit: Uses 128 (104) bit encoding 64 bit: Uses 64 (40) bit encoding

Format You can set the input method for the WEP encrypted key.

ASCII: Input text. The method of inputting the encrypted WEP with text differs depending on the access point. Check with the network

administrator for the network in which the projector participates, and then set to "ASCII". HEX: Input in hexadecimal.

Key ID Selects the WEP encryption ID key.

Encrypted key 1/ Encrypted key 2/ Encrypted key 3/ Encrypted key 4

You can enter the key used for WEP encryption. Enter the key in single-byte characters following instructions from the network administrator for the network in which the projector participates. The type of character and the number that can be entered differ according to the "WEP Encryption" and "Format" settings. If the number of characters you enter is shorter than the required character length, no character is encrypted. If the number of characters you enter is longer than the required character length, characters that exceed the permitted number are not encrypted.

"128 bit" - "ASCII": Single-byte alphanumerics, 13 characters. "64 bit" - "ASCII": Single-byte alphanumerics, 5 characters. "128 bit" - "HEX": 0 to 9 and A to F, 26 characters "64 bit" - "HEX": 0 to 9 and A to F, 10 characters

List of Functions

f When WPA-PSK (TKIP) or WPA2-PSK (AES) are selected

Sub Menu Function

PSK (Encryption key)

You can enter a Pre-Shared Key (encrypted key) in single-byte alphanumeric characters. Enter at least 8 and up to 63 characters. When the PreShared Key is entered and the [Enter] button is pressed, the value is set and displayed as an asterisk (*). You cannot enter more than 32 characters on the configuration menu. When setting from Web Control, you can enter more than 32 characters.

s EasyMP Operation Guide "Changing Settings Using a Web Browser (Web Control)"

f When EAP-TLS is selected

Sub Menu Function

Issued to/Issued by/ Validity period

Information in the certificate is displayed. You cannot enter.

f When EAP-TTLS/MD5, EAP-TTLS/MS-CHAPv2, PEAP/MS-CHAPv2, PEAP/GTC, LEAP, EAP-Fast/MS-CHAPv2 or EAP-FAST/GTC are selected

Sub Menu Function

User name You can enter a user name to be used for authentication in single-byte alphanumeric characters (no spaces). You can enter up to 64 characters.

You cannot enter more than 32 characters on the configuration menu. When setting from Web Control, you can enter more than 32 characters. s EasyMP Operation Guide "Changing Settings Using a Web Browser (Web Control)"

Password You can enter an authentication password in single-byte alphanumeric characters. You can enter up to 64 characters. When the password is entered

and the [Enter] button is pressed, the value is set and displayed as an asterisk (*). You cannot enter more than 32 characters on the configuration menu. When setting from Web Control, you can enter more than 32 characters. s EasyMP Operation Guide "Changing Settings Using a Web Browser (Web Control)"

List of Functions

f Wired LAN Menu

Sub Menu Function

DHCPg You can set whether or not (On/Off) to use DHCP.

If this is set to "On" you cannot set any more addresses.

IP Addressg You can input the IP address assigned to the projector.

You can input a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.

0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

Subnet Maskg You can input the subnet mask for the projector. You can input a number from 0 to 255 in each field of the address. However, the following subnet

masks cannot be used.

0.0.0.0, 255.255.255.255

Gateway Addressg You can input the IP address for the gateway for the projector.

You can input a number from 0 to 255 in each field of the address. However, the following gateway addresses cannot be used.

0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

MAC Address Displays the MAC address.

IP Address Display To prevent the IP address from being displayed on the EasyMP Standby screen, set this to Off.

List of Functions

f Mail menu

When this is set, you receive an e-mail notification if a problem or warning occurs in the projector. For information on the contents of the sent e-mail, s "Reading Problem Mail Notification Function (EB-1735W/1725/1723 only)" p.98

Sub Menu Function

Mail Notification function

SMTP server You can input the IP addressg for the SMTP server for the projector.

Port Number You can input the port number for the SMTP server. The default value is 25 You can input numbers between 1 to 65535.

Email Address 1/ Email Address 2/ Email Address 3

Setting a Notification Event

You can set whether or not (On/Off) to be notified by e-mail.

You can input a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.

127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

You can input the e-mail address of the destination to send the notification e-mail to. You can register up to three destinations. You can enter up to 32 single-byte alphanumeric characters for the e-mail addresses.

You can select the problems or warnings to be notified about by e-mail. When the selected problem or warning occurs in the projector, an e-mail is sent to the specified "Destination address" notifying that a problem or warning has occurred. You can select multiple items from the displayed items.

List of Functions

f Others menu

Sub Menu Function

SNMP trap IP addressg 1/ SNMP trap IP address 2

AMX Device Discoveryg

You can register up to two for the SNMPg trap notification destination. You can input a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.

127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255) To use SNMP to monitor the projector, you need to install the SNMP manager program on your computer. SNMP should be managed by a network administrator.

When the projector is connected to a network, set this to "On" to allow the projector to be detected by AMX Device Discovery. Set this to "Off" if you are not connected to an environment controlled with a controller from AMX or AMX Device Discovery.

List of Functions

f Reset Menu

Resets all of the network settings.

Sub Menu Function

Reset all network settings.

To reset all of the network settings, select Yes. After you reset all the settings, the Basic menu appears.

List of Functions

Info Menu (Display Only)

Lets you check the status of the image signals being projected and the status of the projector. Items displayed vary depending on the image signal currently being projected as shown in the following screen shots.

Computer image/Component videog Composite videog/S-videog

Sub Menu Function

Lamp hours You can display the cumulative lamp operating time*.

When it reaches the lamp warning time, the characters are displayed in yellow.

Source You can display the input port name for the connected equipment currently being projected.

Input signal You can display the content of "Input Signal" set in the "Signal" menu according to the "Source".

Resolution You can display the input resolution.

Video signal You can display the content of "Video Signal" set in the "Signal" menu. Refresh Rateg You can display the refresh rate.

EasyMP(EB-1735W/1725/1723 only)

Syncg Info You can display the image signal information.

This information may be needed if service is required.

Status This is information about errors that have occurred on the projector.

This information may be needed if service is required.

* The cumulative use time is displayed as "0H" for the first 10 hours. 10 hours and above is displayed as "10H", "11H", and so on.

List of Functions

Reset Menu

Sub Menu Function

Reset all You can reset all items in all menus to their default settings.

The following items are not reset to their defaults: "Input Signal", "User's Logo", "Multi-screen", all items for "Network" menus, "Lamp Hours", and "Language".

Reset Lamp Hours You can clear the cumulative lamp hours use time, and return it to "0H". Reset when you replace the lamp.

Troubleshooting

This chapter describes how to identify problems and what to do if a problem is found.

Using the Help..................................................... 63

Problem Solving ................................................. 64

• Reading the Indicators......................................................64

[t] Power indicator lights red .......................................................65

m o Indicator is lit or flashing orange...........................................66

• When the Indicators Provide No Help ............................67

Problems relating to images ...........................................................68

Problems when projection starts.....................................................72

Other problems ...............................................................................73

Using the Help

If a problem occurs with the projector, Help uses on-screen displays to assist you in solving the problem. You can solve problems by answering the questions.

Procedure

Confirm the selection.

Using the remote control Using the control panel

Press the [Help] button.

The help screen is displayed.

Using the remote control Using the control panel

Select a menu item.

Using the remote control Using the control panel

Questions and solutions are displayed as shown on the screen below. Press the [Help] button to exit Help.

If Help does not provide a solution to the problem, refer to

"Problem Solving".

p.64

Problem Solving

If you are having a problem with the projector, first check the projector's indicators and refer to "Reading the Indicators" below. If the indicators do not show clearly what the problem might be, refer to "When the Indicators Provide No Help". s p.67

Reading the Indicators

The projector is provided with the following three indicators that indicate the operating status of the projector.

Indicates the operating status.

Orange : Standby condition

When the [t] button is pressed in this condition, projection starts.

Green : Warm-up in progress

Warm-up time is about 30 seconds. After warm-up is complete, the indicator stops flashing.

Green : Projection in progress

Indicates the internal temperature status.

Indicates the projection lamp status.

Refer to the following table to see what the indicators mean and how to remedy problems that they indicate. If all indicators are off, check that the power cable is connected correctly and that the power is being supplied normally. Sometimes, when the power cable is unplugged, the [t] indicator remains lit for a short period, this is not a fault.

Problem Solving

f [t] Power indicator lights red

Status Cause Remedy or Status

Red Red Red

Red Red

Internal Error Stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest

Fan Error Sensor Error

High Temp Error (overheating)

Lamp Error Lamp Failure

Abnormal

: Lit : Flashing: : Off

address provided in the Support and Service Guide.

Stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest address provided in the Support and Service Guide.

The lamp turns off automatically and projection stops. Wait for about five minutes. After about five minutes the projector switches to standby mode, so check the following two points.

• Check that the air filter and air exhaust vent are clear, and that the projector is not positioned against a wall.

• If the air filter is clogged, clean or replace it. s p.78, 84 If the error continues after checking the points above, stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest address provided in the Support and Service Guide.

Projector Contact List

When using at an altitude of 1500 m or more, set "High Altitude Mode" to "On". s p.46

Check the following two points.

• Take out the lamp and check if it is cracked. s p.81

• Clean the air filter. s p.78

Epson Projector Contact List

Epson

If it is not cracked _ Re-fit the lamp and turn on the power.

If the error continues _ Replace the lamp with a new lamp and turn on the power.

If the error continues _ Stop using the projector, disconnect the power cable from the electrical outlet, and contact

your local dealer or the nearest address provided in the Support and Service Guide.

Epson Projector Contact List

If it is cracked _ Replace it with a new lamp, or contact your local dealer for further advice. If replacing the lamp yourself,

be careful to avoid pieces of broken glass (you cannot continue projecting until the lamp is replaced).

Epson Projector Contact List

When using at an altitude of 1500 m or more, set "High Altitude Mode" to "On". s p.46

Problem Solving

Status Cause Remedy or Status

: Lit : Flashing: : Off

Red Red Red

Auto Iris Error Stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest

address provided in the Support and Service Guide.

f m o Indicator is lit or flashing orange

Status Cause Remedy or Status

Orange Red

Orange

High Temp Warning (This is not an abnormality. However, if the temperature rises too high again, projection stops automatically.)

• Check that the air filter and air exhaust vent are clear, and that the projector is not positioned against a wall.

• If the air filter is clogged, clean or replace it. s p.78, 84

Replace Lamp Replace it with a new lamp. s p.81

If you continue to use the lamp after the replacement period has passed, the possibility that the lamp may explode increases. Replace it with a new lamp as soon as possible.

Warning

Epson Projector Contact List

: Lit : Flashing : Off : Varies according to the projector status

• If the projector is not operating properly, even though the indicators are all showing normal, refer to "When the Indicators Provide No Help".

p.67

• If the error is not indicated in this table, stop using the projector, disconnect the power cable from the electrical outlet, and contact your local dealer or the nearest address provided in the Support and Service Guide.

Epson Projector Contact List

Problem Solving

When the Indicators Provide No Help

If any of the following problems occur and the indicators do not offer a solution, refer to the pages given for each problem.

Problems relating to images

f No images appear s p.68

Projection does not start, the projection area is completely black, the projection area is completely blue, and so on.

f Moving images are not displayed s p.68

Moving images being projected from a computer appear black and nothing is projected.

f Projection stops automatically s p.68 f The message "Not supported." is displayed. s p.69 f The message "No Signal."is displayed. s p.69 f Images are fuzzy or out of focus s p.69 f Interference or distortion appear in images s p.70

Problems such as interference, distortion, or black & white checked patterns appear.

f The image is truncated (large) or small, or the aspect is not

suitable s p.70

Only part of the image is displayed, or the height and width ratios of the image are not correct, and so on.

f Image colors are not right s p.71

The whole image appears purplish or greenish, images are black & white, colors appear dull, and so on. (Computer monitors and LCD screens have different color reproduction performance, so that the colors projected by the projector and the colors appearing on the monitor may not necessarily match, but this is not a sign of a problem.)

f Images appear dark s p.71

Problems when projection starts

f Power does not turn on s p.72

Appendices

This chapter provides information on maintenance procedures to ensure the best level of performance from the projector for a long time to come.

Installation Methods ...........................................77

Cleaning ...............................................................78

• Cleaning the Projector's Surface .....................................78

• Cleaning the Lens..............................................................78

• Cleaning the Air Filter......................................................78

Replacing Consumables ....................................79

• Replacing the Remote Control Batteries ........................79

• Replacing the Lamp..........................................................80

Lamp replacement period .............................................................. 80

How to replace the lamp ................................................................ 81

Resetting the lamp operating time ................................................. 83

• Replacing the Air Filter....................................................84

Air filter replacement period.......................................................... 84

How to replace the air filter ........................................................... 84

Optional Accessories and Consumables .........85

Optional accessories....................................................................... 85

Consumables .................................................................................. 85

Making a WPS (Wi-Fi Protected Setup) Connection with a Wireless LAN Access Point

(EB-1735W/1725/1723 only) ............................... 88

• Connection Setup Method ............................................... 88

Making a Connection Using the Push Button Method...................89

Making a connection using the PIN Code Method ........................90

Screen Size and Distance .................................. 92

• Projection Distance for EB-1725/1723/1720................... 92

• Projection Distance for EB-1735W/1730W.................... 93

Connecting and Removing USB Devices

(EB-1735W/1725/1723 only) ............................... 94

• Connecting USB Devices.................................................. 94

• Removing USB Devices .................................................... 94

Connecting with a USB Cable and Projecting

(USB Display EB-1735W/1725/1723 only)........ 95

• Connecting ........................................................................ 95

Saving a User's Logo..........................................86

Connecting for the first time...........................................................96

From the second time .....................................................................97

Reading Problem Mail Notification Function

Specifications ................................................... 107

(EB-1735W/1725/1723 only)................................98

ESC/VP21 Commands ........................................ 99

• Command List................................................................... 99

• Cable Layouts.................................................................... 99

USB connection ............................................................................. 99

• USB Connection Setup ...................................................100

Regarding Network Projector

(EB-1735W/1725/1723 only)..............................101

About PJLink.....................................................102

List of Supported Monitor Displays ................ 103

• Supported Monitor Displays

for EB-1725/1723/1720 ..................................................103

Computer signals (analog RGB).................................................. 103

Component Video........................................................................ 104

Composite video/S-video............................................................. 104

• Projector General Specifications .................................. 107

• Software Requirement ................................................... 109

Appearance....................................................... 111

Glossary ............................................................ 112

Index .................................................................. 114

• Supported Monitor Displays

for EB-1735W/1730W ...................................................105

Computer signals (analog RGB).................................................. 105

Component Video........................................................................ 106

Composite video/S-video............................................................. 106

Installation Methods

The projector supports the following four different projection methods. Install according to the conditions of the installation location.

Caution

• A special method of installation is required when suspending the

projector from a ceiling (ceiling mount). If it is not installed correctly, it could fall causing an accident and injury.

• If you use adhesives on the ceiling mount to prevent the screws

from loosening, or if you use things such as lubricants or oils on the projector, the projector case may crack causing it to fall from its ceiling mount. This could cause serious injury to anyone under the ceiling mount and could damage the projector. When installing or adjusting the ceiling mount, do not use adhesives to prevent the screws from loosening and do not use oils or lubricants and so on.

Attention

Do not use the projector on its side. This may cause malfunctions to occur.

• Project images from in front of the screen. (Front projection)

• Suspend the projector from the ceiling and project images from in front of the screen. (Front/Ceiling projection)

• Project images from behind a translucent screen. (Rear projection)

• Suspend the projector from the ceiling and project images from behind a translucent screen. (Rear/Ceiling projection)

• An optional ceiling mount is required when suspending the projector from a ceiling.

• You can change the setting as follows by pressing down the [A/V Mute] button on the remote control for about five seconds. "Front" Set "Rear" or "Rear/Ceiling" from the configuration menu.

"Front/Ceiling"

p.45

p.85

Cleaning

You should clean the projector if it becomes dirty or if the quality of projected images starts to deteriorate.

Cleaning the Projector's Surface

Clean the projector's surface by wiping it gently with a soft cloth. If the projector is particularly dirty, moisten the cloth with water containing a small amount of neutral detergent, and then firmly wring the cloth dry before using it to wipe the projector's surface.

Attention

Do not use volatile substances such as wax, alcohol, or thinner to clean the projector's surface. The quality of the case may change or become discolored.

Cleaning the Lens

Attention

• If dust collects on the air filter it can cause the internal temperature of the projector to rise, and this can lead to problems with operation and shorten the optical engine's service life. Clean the air filter immediately when the message is displayed.

• Do not rinse the air filter in water. Do not use detergents or solvents.

Use a commercially available cloth for cleaning glasses to gently wipe the lens.

Attention

Do not rub the lens with harsh materials or subject the lens to shocks, as it can easily become damaged.

Cleaning the Air Filter

Clean the air filter and the air intake vent when the following message is displayed. "The projector is overheating. Make sure nothing is blocking the air vent, and clean or replace the air filter."

• If a message is frequently displayed, even after cleaning, it is time to replace the air filter. Replace it with a new air filter.

• It is recommended that you clean these parts at least once every three months. Clean them more often than this if using the projector in a particularly dusty environment.

p.84

Replacing Consumables

This section explains how to replace the remote control batteries, the lamp, and the air filter.

Replacing the Remote Control Batteries

If delays in the responsiveness of the remote control occur or if it does not operate after it has been used for some time, it probably means that the batteries are becoming flat. When this happens, replace them with new batteries. Have two AA-size manganese or alkaline batteries ready. You cannot use other batteries except for the AA size manganese or alkaline.

Attention

Make sure you read the Safety Instructions/Support and Service

Guide before handling the batteries.

Procedure

Remove the battery cover.

While pushing the battery compartment cover catch, lift the cover up.

Safety Instructions

Replace the old batteries with new batteries.

Caution

Check the positions of the (+) and (-) marks inside the battery holder to ensure the batteries are inserted the correct way.

Replace the battery cover.

Press the battery compartment cover until it clicks into place.

Catch

Replacing Consumables

Replacing the Lamp

f Lamp replacement period

It is time to replace the lamp when:

• The message "Replace the lamp. Replace the lamp. "is displayed when you start projecting.

A message is displayed.

• The lamp indicator flashes orange.

Attention

• The lamp replacement message is set to appear after the following time periods in order to maintain the initial brightness and quality of the projected images. When used continually at high brightness: About 2900 hours When used continually at low brightness: About 3900 hours

• If you continue to use the lamp after the replacement period has passed, the possibility that the lamp may explode increases. When the lamp replacement message appears, replace the lamp with a new one as soon as possible, even if it is still working.

• Depending on the characteristics of the lamp and the way it has been used, the lamp may become darker or stop working before the lamp warning message appears. You should always have a spare lamp ready incase it is needed.

"Brightness Control" p.43

Flashing orange

• The projected image gets darker or starts to deteriorate.

Replacing Consumables

f How to replace the lamp

The lamp can be replaced even when the projector is suspended from a ceiling.

Warning

When replacing the lamp because it has stopped illuminating, there is a possibility that the lamp may be broken. If replacing the lamp of a projector which has been installed on the ceiling, you should always assume that the lamp is broken, and you should stand to the side of the lamp cover, not underneath it. Remove the lamp cover gently.

Caution

Wait until the lamp has cooled down sufficiently before removing the lamp cover. If the lamp is still hot, burns or other injuries may result. It takes about one hour after the power has been turned off for the lamp to be cool enough.

Procedure

Wait until the lamp has cooled down, then remove the lamp cover.

Loosen the lamp cover fixing screw with the screwdriver supplied with the new lamp or a + head screwdriver. Then slide the lamp cover straight forward and lift it to remove.

After you turn off the projector's power and the confirmation buzzer beeps twice, disconnect the power cable.

Replacing Consumables

Loosen the two lamp fixing screws.

Take out the old lamp by pulling the handle.

If the lamp is cracked, replace it with a new lamp, or contact your local dealer for further advice.

Epson Projector Contact List

Install the new lamp.

Insert the new lamp along the guide rail in the correct direction so that it fits in place, push down firmly at the location marked "PUSH", and once it is fully inserted tighten the two screws. Press the replacement lamp in by the handle until it clicks into place.

Replacing Consumables

Attention

• Make sure you install the lamp securely. If the lamp cover is

• This product includes a lamp component that contains mercury

Replace the lamp cover.

removed, the lamp turns off automatically as a safety precaution. If the lamp or the lamp cover is not installed correctly, the lamp does not turn on.

(Hg). Please consult your local regulations regarding disposal or recycling. Do not dispose of it with normal waste.

f Resetting the lamp operating time

The projector records how long the lamp is turned on and a message and indicator notify you when it is time to replace the lamp. After replacing the lamp, make sure you reset the lamp hours from the configuration menu. s p.61

Only reset the lamp operating time after the lamp has been

replaced. Otherwise the lamp replacement period is not indicated correctly.

Replacing Consumables

Replacing the Air Filter

f Air filter replacement period

It is time to replace the air filter when:

• The air filter has been turned brown.

• The message is displayed even though the air filter has been cleaned.

f How to replace the air filter

The air filter can be replaced even when the projector is suspended from a ceiling.

Procedure

After you turn off the projector's power and the confirmation buzzer beeps twice, disconnect the power cable.

Remove the air filter.

Grip the air filter cover tab and pull it straight to outside.

Install the new air filter.

Slide the air filter from the outside and press in until it firmly clicks into place.

Dispose of used air filters properly in accordance with your local regulations. Material of the frame part: Polyphenylene ether, Polystyrene Material of the filter part: Polyurethane foam

Optional Accessories and Consumables

The following optional accessories and consumables are available. Please purchase these products as and when needed. The following list of optional accessories and consumables is current as of: 2009.10. Details of accessories are subject to change without notice and availability may vary depending on the country of purchase.

f Optional accessories

Soft carrying case ELPKS16B

Use this case if you need to travel with the projector.

60" portable screen ELPSC07 80" portable screen ELPSC08 100" screen ELPSC10

Portable roll-type screens (Aspect ratio

50" portable screen ELPSC06

A compact screen that can be carried easily. (Aspect ratio 4:3)

HD-15 cable ELPKC02 (1.8 m - for mini D-Sub15-pin/mini D-Sub 15pin)

This is the same as the computer cable supplied with the projector.

HD-15 cable ELPKC09 (3 m - for mini D-Sub15-pin/mini D-Sub 15pin) HD-15 PC cable ELPKC10 (20 m - for mini D-Sub15-pin/mini D-Sub 15pin)

Use one of these longer cables if the computer cable supplied with the projector is too short.

Component video cable ELPKC19 (3 m - for mini D-Sub 15-pin/RCA male^3)

Use to connect a component video

Ethernet unit ELPAP02B

Use this when connecting to a network by using a LAN cable.

Ceiling pipe (450 mm (18 in.))* ELPFP13 Ceiling pipe (700 mm (28 in.))

Use when installing the projector on a high ceiling.

Ceiling mount* ELPMB23

Use when installing the projector on a ceiling.

g 4:3)

g source

ELPFP14

Wireless LAN unit ELPAP03

Use when connecting the projector to a computer wirelessly and projecting.

Quick Wireless Connection USB key ELPAP04

Use this key to connect to a Windows computer and project images from the computer. However, the projector needs to be connected to a network before it can be used.

* A special method of installation is required to suspend the projector from a

ceiling. Contact your dealer or the nearest address provided in the Support and

Service Guide if you want to use this installation method.

Contact List

Epson Projector

f Consumables

Lamp unit ELPLP48

Use as a replacement for used lamps.

Air filter (by 2) ELPAF19

Use as a replacement for used air filters.

Saving a User's Logo

You can save the image that is currently being projected as a user's logo.

When a user's logo is saved, the previous user's logo is

Procedure

erased.

Project the image you want to use as the user's logo, and then press the [Menu] button.

Using the remote control Using the control panel

Select "Extended" - "User's Logo" from the configuration menu. s "Using the Configuration Menu" p.38

Check the buttons you can use and the operations they perform in the guide under the menu.

• If "User's Logo Protect" from "Password Protect" is set to "On", a message is displayed and the user's logo cannot be changed. You can make changes after setting "User's Logo Protect" to "Off".

• If "User's Logo" is selected when Keystone, E-Zoom, Aspect, or Progressive are being performed, the function currently being performed is cancelled.

p.33

When "Choose this image as the User's Logo?" is displayed, select "Yes".

When you press the [Enter] button on the remote control or the control panel, the screen size may change according to the signal as it changes to the resolution of the image signal. The image is recorded and a selection marquee box is displayed.

Saving a User's Logo

Move the box to select the part of the image to use as the user's logo.

Using the remote control Using the control panel

E F

When "Select this image?" is displayed, select "Yes".

Select the zoom factor from the zoom setting screen.

When the message "Save this image as the User's Logo?" is displayed, select "Yes".

The image is saved. After the image has been saved, the message "Completed." is displayed.

• Once a user's logo has been saved, the logo cannot be returned to the factory default.

•

Saving the user's logo may take approximately 15 seconds. Do not use the projector or any connected equipment while it is saving, otherwise malfunctions may occur.

You can save at up to 400 ^ 300 dots in size.

Making a WPS (Wi-Fi Protected Setup) Connection with a Wireless LAN Access Point (EB-1735W/1725/1723 only)

There are two methods for setting WPS.

•Push Button Method SSID and security are set automatically when the [Enter] button is pressed on the projector's control panel and the dedicated button on the access point equipment. This method is recommended when the projector and access point are close together.

•PIN Code Method SSID and security are set automatically by inputting an 8-digit code that was assigned to the projector from the computer to the access point in advance. Make connection settings between the computer and the access point in advance. For details on how to make this connection, refer to the manual provided with the access point. This method is recommended when the projector is mounted on the ceiling.

Connection Setup Method

Procedure

Press the [Menu] button on the projector, and then select "Network" - "Network Configuration" from the configuration menu.

From "Wireless LAN" select "Setup Wizard".

The following screen is displayed.

When connecting using the Push Button Method, follow the steps given below. Go to "Making a connection using the PIN Code Method" when connecting using the "PIN Code Method". s p.90

The Network Configuration screen is displayed.

Making a WPS (Wi-Fi Protected Setup) Connection with a Wireless LAN Access Point (EB-1735W/1725/1723 only)

f Making a Connection Using the Push Button Method

Procedure

Select "Push Button Method".

The Push Button Method screen is displayed.

Press the [Enter] button on the projector's control panel when prompted by the screen.

Press the button on the access point when prompted by the screen.

This completes the setup.

Press the [Enter] button or the [Esc] button.

Then, the Push Button Method screen is displayed.

It returns to the Wireless LAN menu screen.

Making a WPS (Wi-Fi Protected Setup) Connection with a Wireless LAN Access Point (EB-1735W/1725/1723 only)

Select "Yes" from "Setup complete".

This completes the setup of the connection between the projector and the access point. Press the [Menu] button to close the configuration menu.

f Making a connection using the PIN Code Method

Before you can make a connection using the "PIN Code

Procedure

Method", a connection must have already been setup between the computer and the access point.

Select "PIN Code Method".

The PIN Code Method screen is displayed.

Making a WPS (Wi-Fi Protected Setup) Connection with a Wireless LAN Access Point (EB-1735W/1725/1723 only)

Enter the PIN code displayed on the "PIN Code Method" screen from the computer to the access point, and then select "Start Setup".

The progress is displayed.

The message "Setup by WPS complete. " is displayed. Press the [Enter] button or the [Esc] button.

It returns to the Wireless LAN menu screen.

Select "Yes" from "Setup complete".

This completes the setup of the connection between the projector and the access point. Press the [Menu] button to close the configuration menu.

Screen Size and Distance

To find the appropriate screen size, see the following table to setup the projector. Values are just reference.

Projection Distance for EB-1725/1723/1720

Units:cm(in.) Units:cm(in.)

Projection distance

4:3 Screen Size

30" 61×46 (24×18) 65 to 80 (26 to 32) 7 (2.6) 30" 66×37 (26×15) 71 to 88 (28 to 35) 1 (0.4)

40" 81×61 (32×24) 88 to 108 (35 to 42) 9 (3.4) 40" 89×50 (35×20) 96 to 118 (38 to 46) 1 (0.5)

50" 100×76 (39×30) 111 to 136 (44 to 53) 11 (4.3) 50" 110×62 (43×24) 121 to 148 (48 to 58) 1 (0.6)

60" 120×90 (47×35) 133 to 163 (53 to 64) 13 (5.1) 60" 130×75 (51×25) 146 to 178 (57 to 70) 2 (0.7)

80" 160×120 (63×47) 179 to 218 (70 to 86) 17 (6.9) 80" 180×100 (71×39) 195 to 238 (77 to 94) 2 (0.9)

100" 200×150 (79×59) 224 to 274 (88 to 108) 22 (8.6) 100" 220×120 (87×47) 245 to 298 (96 to 117) 3 (1.2)

120" 240×180 (94×71) 270 to 329 (106 to 129) 26 (10.3) 120" 270×150 (106×59) 294 to 358 (116 to 141) 4 (1.4)

150" 300×230 (118×91) 338 to 412 (133 to 162) 33 (12.9) 150" 330×190 (130×75) 368 to 449 (145 to 177) 4 (1.8)

200" 410×300 (161×118) 451 to 550 (178 to 216) 44 (17.1) 200" 440×250 (173×98) 492 to 599 (194 to 236) 6 (2.3)

300" 610×460 (240×181) 678 to 826 (267 to 325) 65 (25.7) 275" 610×340(240×134) 678 to 826 (267 to 325) 8 (3.2)

Minimum Maximum

(Wide) to (Tele)

90°

Minimum Maximum

(Wide) to (Tele)

Screen

Center of lens

16:9 Screen size

Projection distance

Minimum Maximum

(Wide) to (Tele)

90°

Minimum Maximum

(Wide) to (Tele)

Center of lens

Screen

is the distance from the center of the lens to the base of the screen

Screen Size and Distance

Projection Distance for EB-1735W/1730W

Units:cm(in.) Units:cm(in.) Units:cm(in.)

Projection

distance

4:3 Screen Size

30"

40"

50"

60"

80"

100"

120"

150"

200"

265"

(24×18)

(32×24)

100×76

(39×30)

120×90

(47×35)

160×120

(63×47)

200×150

(79×59)

240×180

(94×71)

300×230

(118×91)

410×300

(161×118)

540×400

(213×157)

61×46

81×61

Minimum (Wide) to

Maximum (Tele)

70 to 86

(28 to 34)

95 to 116

(37 to 46)

119 to 146

(47 to 57)

143 to 175

(56 to 69)

192 to 235

(76

92)

241 to 294 (95

116)

289 to 353

(114

139)

362 to 442

(143

174)

484 to 591

(191

233)

642 to 783

(253

308)

Minimum (Wide)

to Maximum

(Tele)

(2.1)

(2.8)

(3.5)

(4.2)

(5.6)

(7.0)

(8.4)

(10.4)

(13.9)

(18.4)

16:9 Screen size

30"

40"

50"

60"

80"

100"

120"

150"

200"

290"

66×37

(26×15)

89×50

(35×20)

110×62

(43×24)

130×75

(51×25)

180×100

(71×39)

220×120

(87×47)

270×150 (106×59)

330×190 (130×75)

440×250 (173×98)

640×360

142)

(252

Projection

distance

Minimum (Wide) to

Maximum (Tele)

63 to 78

(25 to 31)

86 to 105

(34 to 41)

108 to 132

(42 to 52)

130 to 159

(51 to 63)

174 to 213

(68 to 84)

218 to 267

(86 to 105)

262 to 321

(103 to 126)

329 to 401

(129 to 158)

439 to 536

(173 to 211)

638 to 778

(251 to 306)

Minimum (Wide)

to Maximum

(Tele)

(1.1)

(1.4)

(1.8)

(2.2)

(2.9)

(3.6)

(4.3)

(5.4)

(7.2)

(10.4)

16:10 Screen size

30"

40"

50"

60"

80"

100"

120"

150"

200"

300"

66×41

(26×16)

89×56

(35×22)

110×67

(43×26)

130×81

(51×32)

180×110

(71×43)

220×130

(87×51)

270×169

(106×67)

330×206

(130×81)

440×275

(173×108)

550×344

(267×135)

Projection

distance

Minimum (Wide) to

Maximum (Tele)

62 to 76

(24 to 30)

83 to 102

(33 to 40)

105 to 128

(41 to 51)

126 to 155

(50 to 61)

169 to 207

(67 to 82)

212 to 259 (84 to 102)

255 to 312

(100 to 123)

320 to 390

(126 to 154)

427 to 521

(168 to 205)

642 to 783

(253 to 308)

Minimum (Wide)

to Maximum

(Tele)

(1.8)

(2.5)

(3.1)

(3.7)

(4.9)

(6.1)

(7.4)

(9.2)

(12.3)

(18.4)

90°

Screen

Center of lens

is the distance from the center of the lens to the base of the screen

90°

Center of lens

Screen

Connecting and Removing USB Devices (EB-1735W/1725/1723 only)

USB 2.0/1.1-compatible digital cameras, hard disk drives and USB storage devices can be connected to the projector. Image files that are stored inside the digital camera and scenarios, images and movies that are stored inside USB storage devices can be played back by EasyMP PC Free.

s EasyMP Operation Guide "PC Free Basic Operations"

Connecting USB Devices

The following procedure describes how to connect USB devices, using a digital camera as an example. Connect a digital camera to the projector using a USB cable provided with, or specified for use with your digital camera.

Use a USB cable less than 3m in length. If the cable exceeds

3m, PC Free may not function correctly.

Attention

• If you use a USB hub, the connection may not operate correctly. Devices such as digital cameras and USB storage devices should be connected to the projector directly.

• When connecting and using a USB-compatible hard disk, make sure you connect the AC adaptor supplied with the hard disk.

Removing USB Devices

After finishing projecting, use the following procedure to remove USB devices from the projector.

Procedure

Turn off power for the digital camera or USB storage device.

To digital camera

USB port

USB cable

To USB port

(Type A)

Remove from the projector's USB port (Type A).

Connecting with a USB Cable and Projecting (USB Display EB-1735W/1725/1723 only)

By using a commercially available USB cable to connect the projector to a Windows computer you can project images from the computer. This function is called USB Display. Simply by connecting via a USB cable, images from the computer can be displayed.

Connecting

Procedure

Attention

Connect the projector directly to the computer and not via a USB hub.

Turn the computer on.

Connects to the power cable (supplied).

Connects to the USB cable.

s "Connecting for the first time" p.96 s "From the second time" p.97

Open the A/V mute slide.

Turn the projector on.

Beep

Using the control

panel

Using the remote

control

• Audio is output even when an audio cable is not connected. If you don't want to output audio from the projector, on the computer click "EPSON Projector" "EPSON USB Display" "EPSON USB Display Vx.x Setting", and uncheck "Output audio from the projector".

• If you are running the application software such as Windows Media Player before you connect a USB cable, audio may not be output from the projector. To output audio from the projector, close the application software, and then restart it.

Connecting with a USB Cable and Projecting (USB Display EB-1735W/1725/1723 only)

f Connecting for the first time

When you are using Windows 2000, double-click "My Computer" "EPSON_PJ_UD" - "EMP_UDSE.EXE", on your computer.

Driver installation starts automatically.

When using a computer running Windows 2000 under user authority, a Windows error message is displayed during installation and you may not be able to install the software. In this case, try updating Windows to the latest status, restart, and then try to connect again. For more details, contact the nearest address provided in the

Support and Service Guide. s

Click "Agree".

If the driver is not installed, you cannot start USB Display. Select "Agree". If you want to cancel installation, click "Disagree".

Epson Projector Contact List

Computer images are projected.

It may take a while before computer images are projected. Until computer images are projected, leave the equipment as it is and do not disconnect the USB cable or turn off the power to the projector.

• Applications that use part of DirectX functions may not be displayed correctly.

• If for some reason nothing is projected, click "All Programs" - "EPSON Projector" - "EPSON USB Display" - "EPSON USB Display Vx.x", on your computer.

• If it is not installed automatically, double-click "My Computer" - "EPSON_PJ_UD" - "EMP_UDSE.EXE", on your computer.

• To uninstall the driver, open "Control Panel" - "Add/ Remove Programs" - and uninstall "EPSON USB Display Vx.x".

• Disconnecting The projector can be disconnected simply by disconnecting the USB cable. There is no need to use the "Safely Remove Hardware" feature in Windows.

Connecting with a USB Cable and Projecting (USB Display EB-1735W/1725/1723 only)

f From the second time

Computer images are projected.

It may take a while before computer images are projected. Please wait.

Reading Problem Mail Notification Function (EB-1735W/1725/1723 only)

When the Mail Notification function is set to "On" and a problem/ warning occurs in the projector, the following e-mail is sent. Subject: EPSON Projector Line 1: The name of the projector where the problem has occurred Line 2: The IP address set for the projector where the problem has occurred. Line 3 and on: Details of the problem

The details of the problem are listed line by line. The following table shows the details that are given in the message for each item. To deal with problems/warnings, see "Reading the Indicators" (s p.64).

Message Cause

Internal error Internal Error

Fan related error Fan Error

Sensor error Sensor Error

Lamp timer failure Lamp Failure

Lamp out Lamp Error

Internal temperature error

High-speed cooling in progress High Temp Warning

Lamp replacement notification Replace Lamp

No-signal

Auto Iris Error Auto Iris Error

A (+) or (-) appears at the start of the message. (+): A projector problem has occurred (-): A projector problem has been dealt with

High Temp Error (Overheating)

No Signal No Signal is input to the projector. Check the connection status or check that the power for the signal source is turned on.

ESC/VP21 Commands

Command List

When the power ON command is transmitted to the projector, the power turns on and it enters warm-up mode. When the projector's power has turned on, a colon ":" (3Ah) is returned. When a command is input, the projector executes the command and returns a ":", and then accepts the next command. If the command being processed terminates abnormally, an error message is output and a ":" is returned.

Item Command

Power ON/OFF ON PWR ON

OFF PWR OFF

Signal selection Computer Auto

RGB

Component

Vid eo SOURCE 41

S-video SOURCE 42

A/V Mute ON/ OFF

A/V Mute selection

EasyMP (EB-1735W/1725/ 1723 only)

ON MUTE ON

OFF MUTE OFF

Black MSEL 00

Blue MSEL 01

Logo MSEL 02

SOURCE 50

SOURCE 1F

SOURCE 11

SOURCE 14

Cable Layouts

f USB connection

Connector shape: USB (Type B)

(Type B)

* You cannot use the USB Type A port (EB-1735W/1725/1723 only) as a USB hub.

* Add a Carriage Return (CR) code (0Dh) to the end of each command and

transmit.

ESC/VP21 Commands

USB Connection Setup

To control the projector using ESC/VP21 commands via a USB connection, the following preparations must be carried out.

Procedure

100

Download the USB driver (USB-COM Driver) from the Epson Web site to your computer.

Go to http://www.epson.com and select the support section of your local Epson Web site.

Install the downloaded USB driver onto your computer.

Read the instructions displayed on the download screen.

Set "Extended" - "Link 21L" to "On" from the projector's configuration menu.

For the EB-1735W/1725/1723 Set "Link 21L" to "On" after setting "Extended" - "USB Type B" to "Link 21L" from the projector's configuration menu.

Epson EB-1730W, EB-1720, EB-1725, EB-1723 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

Notations Used in This Guide

Contents

Projector Features

Features Common to Each Model

EB-1735W/1725/1723 Features

Part Names and Functions

Front/Top

Rear

Base

Control Panel

Remote Control

Useful Functions

Changing the Projected Image

Automatically Detect Incoming Signals and Change the Projected Image (Source Search)

Changing Directly from the Remote Control

Functions for Enhancing Projection

Selecting the Projection Quality (Selecting Color Mode)

Setting the Auto Iris

Hiding the Image and Sound Temporarily (A/V Mute)

Freezing the Image (Freeze)

Changing the Aspect Ratio

Pointer Function (Pointer)

Enlarging Part of the Image (E-Zoom)

Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)

Restrictions in the Target Projector when Using Multiple Projectors

Setting the Projector ID

Setting the Projector ID on the Remote Control

Correcting Color for Multiple Projectors (Multi-Screen Color Adjustment)

Summary of Correction Procedure

Correction Method

Security Functions

Managing Users (Password Protect)

Restricting Operation (Control Panel Lock)

Configuration Menu

Using the Configuration Menu

List of Functions

Image Menu

Signal Menu

Settings Menu

Extended Menu

Network Menu (EB-1735W/1725/1723 only)

Info Menu (Display Only)

Reset Menu

Troubleshooting

Using the Help

Problem Solving

Reading the Indicators

When the Indicators Provide No Help

Appendices

Installation Methods

Cleaning

Cleaning the Projector's Surface

Cleaning the Lens

Cleaning the Air Filter

Replacing Consumables

Replacing the Remote Control Batteries

Replacing the Lamp

Replacing the Air Filter

Optional Accessories and Consumables

Saving a User's Logo

Making a WPS (Wi-Fi Protected Setup) Connection with a Wireless LAN Access Point (EB-1735W/1725/1723 only)

Connection Setup Method

Screen Size and Distance

Projection Distance for EB-1725/1723/1720

Projection Distance for EB-1735W/1730W

Connecting and Removing USB Devices (EB-1735W/1725/1723 only)

Connecting USB Devices

Removing USB Devices

Connecting with a USB Cable and Projecting (USB Display EB-1735W/1725/1723 only)

Connecting

Reading Problem Mail Notification Function (EB-1735W/1725/1723 only)

ESC/VP21 Commands

Command List

Cable Layouts

USB Connection Setup
