Engl E810 Operator's Manual

E810

Tube Poweramp 20/20

Operator´s Manual

In addition to delivering with that , the
compact, offers a number of in
a potent 2 x 20-watt package:

-> An to adjust the amp's input sensitivity and
to and . At the higher setting, the input is

for signals sent from the .

-> Each Left and Right stereo channel features that let
you dial in . Volume A/B may be selected via a
footswitch or an external MIDI Switcher (e.g. ENGL Z11-S.A.C.).
You're sure to find that comes in very handy, especially when
playing .

-> The , yet another .
It offers with controls
for and controls for .
You can dial in and with a

on the connected preamp to

. Sound Set A/B is selected via a footswitch or an external

MIDI Switcher (e.g. the ENGL Z11-S.A.C.).

-> The power amp is equipped with

each channel.

-> for the power amp's left and right channels
enable single-sided operation.

-> Four power tube fuses protect the amp from damage
brought on by power tube defects/failure and ensure the amp does not shut
down. It continues to function on both channels, though the defective channel
operates at a perceptibly reduced output level. LEDs indicate which channel's
tube fuse has triggered. In addition, a thermal overload protector powers the
amp down if the it overheats because of a problem with the fan.

This power amp's hallmarks include intelligent design features, superior
craftsmanship, impeccable finishing and highest quality components. Bear in mind,
though, that a few precautions will dramatically extend tube life (see handling
and care guide). The ENGL team would like

. We certainly enjoyed engineering this fine work of audio art for you,

and hope the brings you just as

Read the Operator's Manual carefully and thoroughly! You'll find
guidelines on care and maintenance of tube amps on page 9 and 10.
Avoid operating errors and potential damage to the Power Amp by heeding the
guidelines and cautionary remarks in this manual. Under the heading Tips from the
designer, you'll come across practical tips on the aforementioned features
throughout the manual.
All critical information concerning the operation of this Power Amp is preceded by
" ", " ", " " or some other eye-catching comment. We're
calling your attention to these remarks for reasons of safety or other compelling
motives, so please give them due consideration.

top-notch tone typical EL84-driven flavor

all-tube ENGL 810 Power Amp practical features

Input Gain switch match gain levels

various preamps FX processors

sensitive enough pickups on guitars

A and B volume controls

different volume settings

Volume A/B

alternating rhythm and lead parts

Sound Set circuit trademark ENGL innovation

two independent EQ systems Presence A and Depth A

Sound Set A Presence B and Depth B Sound Set B

two different power amp setups match them up
clean and a lead configuration achieve excellent
tonal results

impedance-matched 8 and 16-ohm speaker

outputs

Dedicated Standby switches

Two safety systems:

to thank you for your confidence in

our product

ENGL TUBE POWER AMP 810 much joy and

satisfaction.

PLEASE NOTE:

NOTE CAUTION Read and heed

3

CAUTION! Please read and heed the following:

1 GAIN P.A.

A tip from the designer:

2 VOLUME LEFT A

You'll find an ancillary pamphlet accompanying this owner's manual entitled
Instructions for the Prevention of Fire, Electrical Shock and Injury. Be sure to read it
before you plug in and power up the Power Amp!

This button's setting determines the input sensitivity for both the left and right
channels of the power amp;

The 810 Power Amp offers quite a lot of gain, so you can plug a guitar straight into
it. If you set the Volume controls to 12 o'clock or higher and select High Gain mode
by pressing the Gain P.A. button (1), you will be able to push the power amp into
the overdrive zone, with plenty of saturation for certain styles such as snarling rock
riffs.
Use the Presence and Depth tone controls in combination with the Volume A and B
knobs to dial in four different sounds on the power amp and then access them via
footswitch. For example, you could configure a clean sound for single-coil pickups
by setting the Volume knobs (2 & 5) to around 12 o'clock, (7) in the 1-
to-4 o'clock range, and (8) to somewhere between 11 and 3 o'clock. You
can coax vintage sounds with that typical EL84 flavor and moderate overdrive out
of the amp by setting (3 & 6) to somewhere between 1 and 3 o'clock in
combination with (10) and (11) set anywhere from 8 to 12
o'clock. If you add the guitar's volume knob to the sonic equation, you get a vast
spectrum of fine tonal distinctions. If you want to hit the input section a little
harder to strike a more aggressive note, set the L & R channels' Volume controls
between 3 and 5 o'clock. In combination with humbuckers, this should give you
enough juice for a lower gain lead sound. Be sure to dial back the activated Depth
knob to a position lower than 10 o'clock so the bottom end doesn't get muddy. If
you're aiming for a pristine clean sound with humbucking pickups, you will have to
back off the Volume knobs to a relatively low setting or select Low Gain mode on
the Gain P.A. This is done by ensuring the button is not pressed in.

Volume control A for the left power amp channel.

Contents:

1. ENGL Power Amp 810, 19" stereo rack power amp;

2. mains cord;

3. this manual;

4. a pamphlet entitled
.

"on position" (button engaged): .

Instructions for the Prevention of Fire,

Electrical Shock and Injury

Input Gain High

Front Panel Features

Presence A

Depth A

Volume B

Presence B Depth B

On page 15 of the manual, you'll find diagrams of the front and rear panels.

4

3 VOLUME LEFT B

4 VOLUME A/B

A tip from the designer:

5 VOLUME RIGHT A

6 VOLUME RIGHT B

7 PRESENCE A

8 DEPTH A

9 SOUND SET A/B

A tip from the designer:

Volume control B for the left power amp channel.

switches between Volume A controls and Volume B controls,

"off position" (button not engaged): Volume A controls activated, red LED off;

"on position" (button engaged): Volume B controls activated, red LED lights up;
This feature can also be remote-controlled via a footswitch or a MIDI Switcher
connected to jack 20; the Volume A/B pushbutton is deactivated once a footswitch
is connected.

Volume A/B switching serves to activate two different volumes:
In combination with a preamp, you can dial in one level for rhythm work,
and the other for leads, or even two different levels for soloing.

Volume control A for the right power amp channel.

Volume control B for the right power amp channel.

Power amp treble control A; affects both left and right channels.

Power amp bass control A; affects both left and right channels.

Switches between (Presence A control and Depth A control)
and (Presence B control and Depth B control);

"off position" (button not engaged): active, red LED off;

"on position" (button engaged): active, red LED lights up;
This feature can also be remote-controlled via a footswitch or a MIDI Switcher
connected to jack 20; the Sound Set A/B pushbutton is deactivated once
a footswitch is connected.

Benefits and practical application of Sound Set A/B switching:
This unique feature lets you combine various preamp configurations with the two
power amp EQ setups and , easily and conveniently. You
can tweak the power amp to shape the tone in different ways using the two
Sound Set EQs, thereby considerably extending your sonic spectrum.
The two power amp EQs let you sculpt different basic sounds, say clean and lead,
with great precision, so you can dial in exactly the sound you wish to hear. Let's
look at a typical example using a multi-channel preamp (that is, a dual clean/lead-
channel device):

Sound Set A

Sound Set B

Sound Set A

Sound Set B

Sound Set A Sound Set B

5

Sound Set A

Sound Set B

Sound Set A

Sound Set B

:
Presence A knob setting between 1 and 4 o'clock;
Depth A knob setting around 12 o'clock;

:
Presence B knob setting between 9 and 1 o'clock;
Depth B knob setting somewhere in the 12-to-3 o'clock range;

Activate the preamp's clean channel and : Lots of high end and a
moderate amount of low end yield crisp clean tone. Activate for the
preamp's lead channel (that is, overdriven preamp). Reduced treble and plenty of
low-end punch yield warm, assertive lead tone.

Power amp treble control B; affects both left and right channels.

Power amp bass control B; affects both left and right channels.

This LED lights up as soon as the amp's left channel is activated via the Standby
switch (14). This tells you the left channel is ready to go. A flashing LED indicates
that a power tube fuse has triggered because of an overload or a defect in either
the V4 or V5 power tubes. See the tube map on page 13 for the positions of the
two tubes and their fuses in the chassis.

This LED lights up as soon as the amp's right channel is activated via the Standby
button (15). This tells you the right channel is ready to go. A flashing LED indicates
that a power tube fuse has tripped because of an overload or a defect in either the
V6 or V7 power tubes. See the tube map on page 13 for the positions of the two
tubes and their fuses in the chassis.

Left channel standby switch. Use this switch to silence ("0" indicated) the left
channel when you take a longer break. The power amp's tubes stay nice and
toasty, and the channel is ready to roll immediately when you ramp it back up to
full power. If you wish to use the right channel only, you must deactivate the left
channel with the Standby switch (14).

Right channel standby switch. Use this switch to silence ("0" indicated) the right
channel when you take a longer break. The power amp's tubes stay nice and
toasty, and the channel is ready to roll immediately when you ramp it back up to
full power. If you wish to use the left channel only, you must deactivate the right
channel with the Standby switch (15).

10 PRESENCE B

11 DEPTH B

12 LEFT Ch. V4 & V5

13 RIGHT Ch. V6 & V7

14 STAND BY LEFT

15 STAND BY RIGHT

6
