Introduction
Putting it all Together…
• X Board 25/49
• Proteus X LE
• Ableton Live Lite 4 for E-MU
Introduction
This guide contains a basic walk-through of Ableton Live Lite 4 for E-MU and the E-MU
X Board. We encourage you to perform the steps on your computer as you read so that
you become familiar with the process.
Before you Begin:
•You should have already installed the E-MU X Board and software on your computer
according to the instructions in your printed “Getting Started” manual.
•You should have already installed the Ableton Live Lite 4 for E-MU software on your
computer according to the instructions provided with the Ableton software.
•You should hear sounds from Ableton Live Lite 4 for E-MU when you play the
Ableton demo.
Ableton Live Lite 4 for E-MU
Ableton Live Lite 4 is an innovative composition and performance tool. Ableton Live
combines digital recording, virtual instruments, digital effects with an original interface
design that many people find more intuitive than traditional designs.
The following step by step tutorials are designed to get you recording as quickly as
possible. After you have finished the tutorial we encourage you to follow Ableton Live’s
excellent interactive Lessons and read the Ableton Live reference manual pdf in order to
learn more about the program.
1 - Setting up the Preferences
Follow the
(Options menu, Preferences) Play the Ableton demo to make sure the audio path is
correctly configured before continuing. Ableton will remember these settings, so you’ll
only have to do this once.
Set up the Plug-ins
The following steps allow Ableton Live Lite 4 to find the VST Plug-ins and Proteus X LE
VST.
1.
Click on the
The following screen appears.
Preference Setup
Plug-ins
tab of the Preferences dialog box under the Options menu.
instructions provided with Ableton Live Lite 4 for E-MU.
6 Creative Professional
Putting it all Together…
1 - Setting up the Preferences
Locate:
2.
Press the
3.
After selecting the VST plug-ins folder, press OK . (You may have to wait a few
Browse
button, then locate
VST Plugins
located in the
Steinberg\VSTplugins
Steinberg folder.
seconds while Ableton locates the plug-ins.)
Set up the MIDI Parameters
Click on the MIDI/Sync tab of the Preferences dialog box. The MIDI screen appears.
4.
Select E-MU
MIDI-USB if
you have an
E-MU X Board
connected.
E
Live enables every
MIDI input by default
5.
Select E-MU-USB Device to connect the E-MU X Board.
Putting it all Together - X Board, Proteus X LE, Ableton Live Lite 4 for E-MU 7
Putting it all Together…
2 - Running Proteus X LE VSTi from Ableton Live
2 - Running Proteus X LE VSTi from Ableton Live
These instructions explain how to run Proteus X LE from within Ableton Live Lite 4.
Ableton Live’s forte is making it easy to combine pre-recorded audio and MIDI clips in
new and exciting ways. In this tutorial, you’ll learn how to use a MIDI keyboard or the
excellent pre-recorded MIDI loops that come with Ableton Live Lite 4 to play
Proteus X LE.
Select the Virtual Instrument
1.
If you began with Tutorial 1- S etting up the Preferences , you should have a new set
open with two audio tracks and two MIDI tracks such as the one shown below. (If
you have another set open select New Live Set (Ctrl+N) from the File menu.)
3. Drop Here
1. Click
Here
to open
Plug-ins
2. Drag
Proteus X LE
E
These instructions also
apply to Proteus X or
Emulator X.
Click on the Plug-in Device Browser button on the left side of the window.
2.
The list of Ableton Plug-ins appears at the left side of the window.
3.
Select Proteus X LE from the Plug-ins list and drag it over the MIDI Track heading
as shown above. Wait a second or two, then you’ll see the Proteus X LE VSTi appear
in the MIDI Track View area below the mixer.
Load the Proteus X LE Bank
4.
Click on the wrench icon on Proteus X LE in the MIDI
Track View area.
8 Creative Professional
5.
The Proteus X LE editor screen shown below appears.
Putting it all Together…
2 - Running Proteus X LE VSTi from Ableton Live
Load the Proteus X Composer Bank
Proteus X LE is now running, but you need to load a bank of sounds.
6.
7.
Choose Open from the File menu on Proteus X LE. Locate and load the Proteus X
Composer bank, which is located here: (“Program Files/Creative Professional/E-MU
Sound Central”) The bank takes a few seconds to load.
Play the Proteus X Composer Bank
Click on the mini keyboard at the bottom of the window. You should be hearing
8.
sound. If not, close Ableton Live Lite 4, and verify that you have the PatchMix DSP
Product Default session loaded. Then close and restart Ableton Live Lite 4. Try out
the X Board 25/49 keyboard and controller knobs.
9.
Change the Preset using the preset inc/dec keys.
10.
Feel free to play around for awhile—turn some knobs, change presets. Don’t worry
about losing anything. Nothing is made permanent until you Save the bank.
11.
When you’re ready to move on, select preset, P0004 A KuStq , then close the Proteus
X LE editor by clicking on the close box .
Play MIDI Clips
12.
Locate MIDI Loops by Keyfax in the Factory Content section of the Ableton Live
Lite 4 Browser.
13.
Click on the folder to open it. You’ll see a bunch of other folders.
Putting it all Together - X Board, Proteus X LE, Ableton Live Lite 4 for E-MU 9
Putting it all Together…
2 - Running Proteus X LE VSTi from Ableton Live
14.
The first folder, BRK_120 contains a nice bass riff. Open it, then open the next
folder BRK-Bass.mid . Now, you’ll see a MIDI file named BRK-Bass .
Click and drag BRK-Bass over one of the clip slots in the 3 MIDI strip as shown
15.
below.
Stop
Show/Hide In/Out Section
Now click on the Clip Launch Button (little triangle) on the MIDI clip you just
16.
dragged over. The MIDI bass loop begins playing the bass preset on Proteus X LE. To
stop playing, press the Stop button.
17.
Find some other MIDI loops and drop them into the other slots of the track. Hint:
look in different folders. Click on the Clip Launch Buttons to switch between clips.
Add Another MIDI Track
Ableton Live Lite 4 allows four MIDI tracks, so let’s play a different MIDI loop and
sound on track 4 MIDI.
Choose a different MIDI loop such as House-Lead , (located in the HOUSE-120
18.
folder) and drop it onto one of the 4 MIDI clip slots.
Click on the Show/Hide In/Out Section button shown above. The Input/Output
19.
options now appear in the track strips.
Currently, the MIDI To box reads “No Output”. Instead, select 3-MIDI . Another
20.
option box labeled “Track In” now appears beneath 3-MIDI.
10 Creative Professional
Select
3-MIDI
2 - Running Proteus X LE VSTi from Ableton Live
21.
Click on the Track In box to see the list of MIDI channels.
Select MIDI Channel 2 as shown at right.
22.
23.
Click on the Clip Launch Button on the 4 MIDI clip to get it started. You won’t
hear anything because you haven’t yet assigned a preset to MIDI channel 2 on
Proteus X LE.
Choose a Sound for MIDI Channel 2
Click on the 3 MIDI heading to show the Proteus X LE VSTi. Next, click on the
24.
wrench icon again (in the MIDI Track View) to open Proteus X LE.
Select MIDI Channel 2 using the channel inc/dec keys .
25.
26.
Select a Preset on Channel 2 . Place the cursor in the preset number field and use
the up/down arrow keys on your computer keyboard to scroll through the list.
• Note: There are several ways to select presets. See the Proteus X LE Operation
manual for details.
27.
Now you should be hearing the beat. If not, check to make sure both clips are
playing (green triangle). Each clip plays a different preset.
Putting it all Together…
Add MIDI Clips
28.
Drop a few more MIDI clips into both MIDI channel slots. Play around with the
Clip Launch buttons.
Preset Change
Here’s another way to change the MIDI Program (Preset in E-MU speak) without going
into the Proteus X LE editor.
Double-click on one of the currently playing MIDI clips. The Clip View appears at
29.
the bottom of the window.
Select the Show/Hide Notes Box located in the lower left corner of the
30.
Clip View window. The Notes box appears in the Clip View section.
Select a Program number. You’ll hear the Proteus X LE sound change. Keep
31.
selecting until you find one you like.
• Hint: Use the Up/Down Arrow keys to select Programs. Use Sub-Bank to select
presets higher than 128.
32.
As an added bonus, the program (sound) you selected is now associated with the
MIDI clip. Whenever you select this MIDI clip, the sound will also be selected.
33.
Select another clip and assign a different program number. Notice that the Preset
changes when you switch back and forth between clips.
Save the Set
Save your work by selecting Save Live Set As… from the File menu. The next time
34.
you load the set, the Proteus X LE bank will automatically load as well.
Proteus X LE sounds
E
are called Presets or
Programs. Ableton Live
Programs are offset by +1
from Proteus X LE.
Select
Preset
Setup to Record a MIDI Track
Now let’s record a MIDI track using the E-MU X Board. If the X Board isn’t already
connected, you’ll have to quit Ableton Live Lite 4, connect the X Board, then restart
Ableton Live Lite 4 before continuing.
You can use the MIDI Track you set up on MIDI channel 2. Make sure there is at
35.
least one empty slot in the MIDI track. (Select and hit backspace to delete a clip.)
Putting it all Together - X Board, Proteus X LE, Ableton Live Lite 4 for E-MU 11
Click on the Show/Hide In/Out Section button if it’s not already selected.
a
b
c
d
e
f
36.
The Input/Output options now appear in the track strips.
Set up the MIDI track as shown at right.
37.
a. Select the X Board in “MIDI from”.
b. Set the input to listen to MIDI channel 2.
c. Monitor should be On (for now).
d. This routes the MIDI data to track 3 (which contains Proteus X LE).
e. Set the output to MIDI channel 2.
f. Turn record On (red).
38.
Set your X Board to transmit on MIDI channel 2 .
(Press the MIDI Channel button, select Channel 2 , then press Enter .)
Play the keyboard. You should hear Proteus X LE playing the last sound you
39.
selected on channel 2. Go ahead and change the sound if you wish. (Double-click
the top of Track 3, then click the Wrench icon on the Device Title Bar. Make sure
you’re changing the sound on channel 2.)
Ready to Record
Start up the bass line on track 3 MIDI and practice playing along with it.
40.
Optional: You can set the
41.
Global Quantization
value to time correct your playing.
Set it to anything other than “None”.
Quantize
42.
Click on any of the
43.
Click the
Clip Launch
MIDI Clip Record
button, the C
buttons to begin recording.
lip Stop
button, or the
Spacebar
to stop
recording.
On Your Own
Now you’ve had a taste of what Proteus X LE and Ableton Live Lite 4 can do. But don’t
stop now! Read the Proteus X LE Operation Manual pdf to learn all about this exceptional instrument.
Ableton Live Lite 4 for E-MU includes several excellent hands-on tutorials to help you
learn all the features of this ground breaking music application.
Note:
The “Assignable X-Y Controls” are not enabled in this version of Proteus X LE.
