Emerson 299Hs, 299H Data Sheet

Bulletin 71.2:299H

299H Series Pressure Reducing Regulators

January 2014

• Inlet Pressure up to

175 psig / 12.1 bar

• Compact

• Integral Pilot

• ±1% Accuracy for Fixed Factor Billing (PFM)

• Rugged Construction

• Easy to Maintain

W7513

Figure 1. 299H Series Pressure Reducing Regulators

• High Capacity

• Robust

• Outlet Pressures up

to 60 psig / 4.1 bar

• Optional Slam-Shut Conguration

• No Bleed Monitor

• External, Internal or

Dual Registration

• Optional Token Relief

D102683X012

www.sherregulators.com

Bulletin 71.2:299H

Specications

Specications for 299H Series constructions are given below. Some specications for a given regulator as it originally

comes from the factory are stamped on a nameplate located on the actuator upper casing.

Available Constructions

Type 299H: Pilot-operated pressure reducing

regulator with a pilot integrally mounted to the actuator casing. Type 299HR: A Type 299H with a token internal relief valve to relieve minor overpressure caused by thermal expansion. Type 299HS: Same as the Type 299H with a Type VSX-2 slam-shut valve which provides overpressure or overpressure and underpressure protection. Type 299HSR: Same as the Type 299HS with an internal token relief valve.

Body Size and End Connection Styles

See Table 1

Maximum Operating Inlet Pressure by Orice Size

1/4 x 3/8 inch / 6.4 x 9.5 mm ......... 175 psig / 12.1 bar

3/8 inch / 9.5 mm ........................... 175 psig / 12.1 bar

1/2 inch / 13 mm ............................ 175 psig / 12.1 bar

3/4 inch / 19 mm ......................... 150 psig / 10.3 bar

7/8 inch / 22 mm 1 inch / 25 mm 1-3/16 inch / 30 mm

(5)

...........................125 psig / 8.6 bar

(5)

..............................100 psig / 6.9 bar

(5)

..........................80 psig / 5.5 bar

Maximum Casing and Emergency Outlet Pressure

66 psig / 4.5 bar

Outlet (Control) Pressure Ranges

(1)(2)

See Table 2

Maximum Set Pressure for Type 299HS

(1)

16 psig / 1.1 bar

Maximum Set Pressure for Slam-Shut Device

(1)

23 psig / 1.6 bar

Minimum and Maximum Trip Pressure Ranges

See Table 4

Type VSX-2 Sensing Line Connection

1/4 NPT

Flow Coefcients

See Table 3

Flow Capacities

See Tables 5 through 10

Pressure Control Accuracy (Fixed Factor) (PFM)

(3)

±1%

of absolute control pressure

Minimum Differential Pressure For Full Stroke

1.5 psid / 0.10 bar d

Control Line Connections

3/4 NPT; See Figures 8 and 9

Temperature Capabilities

(1)

-20 to 150°F / -29 to 66°C

Approximate Weight

21 pounds / 10 kg

Pressure Registration

Internal, External or Dual Registration

See Figure 3

(1)

Fixed Restriction Sizes

0.044 inch / 1.1 mm, Red (standard gain)

0.071 inch / 1.8 mm, Green (low gain)

0.082 inch / 2.1 mm, Blue (lower gain)

Options

• Filter

(3)

: A P590 Series lter installed in the pilot

supply tubing between main body and pilot

• Filtered pilot supply regulator

(1)

supply regulator with integral 5 micron

(3)(4)

: A Type 67CF

Polyethylene lter

Construction Materials

Actuator Upper Casings: Aluminum Actuator Lower Casing: Aluminum Pilot Spring Case: Aluminum Actuator Diaphragm: Nitrile (NBR) Pilot Diaphragm: Nitrile (NBR) Pilot Inlet Screen: Stainless steel Valve Body: Cast iron, Ductile iron or Steel Orice and Valve Stem: Aluminum Disk Holder: Aluminum holder with Nitrile (NBR) disk Main Disk Construction: Nitrile (NBR) Metal Trim Parts For Pilot: Aluminum Pilot Disk Construction: Nitrile (NBR) O-rings: Nitrile (NBR) Fittings: Steel (standard) or Stainless steel Tubing: Stainless steel

1. The pressure/temperature limits in this Bulletin and any applicable standard or code limitation should not be exceeded.

2. For optimum performance, a pilot supply regulator may be installed in the pilot supply tubing between the main valve and pilot.

3. A pilot supply regulator or a P590 Series lter (only one may be used, not both) may be ordered with the Type 299H, but not both.

4. For inch w.c., use a pilot supply regulator if actual inlet pressure varies more than ±20 psi / ±1.4 bar and published accuracy is required.

5. This orice size is not available for Types 299HS and 299HSR.

2

3/4 NPT

CONTROL LINE

Bulletin 71.2:299H

W7527-1

TYPE 299H WITH EXTERNAL REGISTRATION TYPE 299HR PILOT WITH OPTIONAL TOKEN RELIEF

Figure 2. 299H Series Sectional Views

Features

• Compact in Size—Small envelope because of the

built-in pilot and internal registration.

• Unique No Bleed Monitor System—Flexible worker/monitor system setup that allows for bleed to be piped to the intermediate piping thus eliminating downstream bleed which reduces lost and unaccounted for gas. Another advantage of this

conguration is that the system lockup pressure is

that of the worker instead of the monitor.

• Not an Adaptation of Existing Regulators—

New design of integrated cases and internal registration ports.

• Wide Variety of Applications—Natural gas distribution systems, gas supply to industrial boilers, furnaces, ovens, mixers, plant air service.

• Highest Quality— Designed and manufactured to ISO 9001 standards.

• Accuracy—Keeps constant inlet pressures to downstream equipment by accurately controlling

distribution system pressures at widely varying ow rates and supply pressures for maximum efciency

and best operation or by eliminating the need for pressure-compensating meters by holding a steady pressure to the meter inlet.

• Optional Token Relief—The Types 299HR and 299HSR with an integral token relief in the pilot is

designed to relieve minor overpressure caused by thermal expansion.

• High-Capacity Pressure Control—Actuator diaphragm responds quickly to downstream pressure change, causing immediate correction in

W7528-1

main valve position. Pilot responds simultaneously

and controls nal positioning of main valve. This

action permits full main valve travel, resulting in higher capacity than could be obtained without an external pilot regulator.

• Easy Registration Conversion—Two screws and O-rings change internal registration to external or dual registration.

• Easy Startup—No special procedure required.

• Easy to Maintain—Main valve disk and orice can

be inspected without removing body from pipeline.

Easy access two bolt ange permits quick removal

of actuator and pilot from body.

• Economical, Labor-Saving Installation—Supply pressure to pilot is factory-piped directly from inlet side of main regulator body, thus requiring no upstream pilot supply line on standard installations.

• Rugged Construction—With a two bolt connection of the regulator to the body and no union ring, the 299H Series regulators are designed for longer service life with minimal maintenance requirements.

• No gaskets—Reusable O-rings at all serviceable joints.

• Startup Protection—The main valve and the pilot are designed with reverse pressure mechanisms to prevent damage during startup or sudden increase in downstream pressure.

• Fewer Parts—Fewer recommended parts needed for spare parts inventory.

3

Bulletin 71.2:299H

Introduction

Description

WARNING

!

Since a pilot-operated regulator is constructed of both a pilot and a main valve, do not exceed the maximum inlet pressure shown on the nameplate.

The 299H Series pressure reducing regulators provide a broad capacity of controlled pressure ranges and capacities in a wide variety of distribution, industrial and commercial applications. A 299H Series regulator has a pilot integrally mounted to the actuator casing. The 299H Series regulators can handle inlet pressures

up to 175 psig / 12.1 bar depending on orice size.

The integral token relief on the Types 299HR and 299HSR regulators is located in the pilot and alerts you to an increase in downstream pressure beyond the regulator setpoint.

The Type 299HS provides overpressure or overpressure and underpressure protection by

completely shutting off the ow of gas to the

downstream system. It comes with a Type VSX-2

slam-shut device which can be congured for

Ovepressure Shutoff (OPSO) or Overpressure and Underpressure Shutoff (OPSO/UPSO). The slam-shut device’s actions are independent of the main valve and of variations to the inlet pressure. The Type VSX-2 slam-shut device has internal or external registration. External registration requires a downstream sensing line.

Options

P590 Series Pilot Supply Filter

The optional P590 Series pilot supply lter prevents

pipeline debris from entering the pilot; a primary cause of pilot clogging. When the upstream system is free of debris, the 299H Series regulators may be installed

without a pilot supply lter.

Type 67CF Filtered Pilot Supply Regulator

When it is necessary to install a pilot supply regulator,

an optional Type 67CF ltered pilot supply regulator

may be installed. For example, on applications with inches of water column setpoints and inlet pressure variations of more than ±20 psig / ±1.4 bar it may be necessary to install a Type 67CF to maintain published accuracy.

Principle of Operation

Letter keys in this section refer to Figure 3 unless otherwise noted. Fast response and accuracy are made possible by the amplifying effect of the pilot and by the two-path control system. The function of the pilot is to sense change in the controlled outlet pressure and amplify it into a larger change in the loading pressure. Any changes in outlet pressure act quickly on both the actuator diaphragm and the loading pilot, thus providing the precise pressure control and fast speed of response that is characteristic of a two-path system.

Upstream or inlet pressure is utilized as the operating

medium, which is reduced through pilot operation to load the main diaphragm chamber. Tubing connects the inlet pressure to the pilot. Downstream or outlet pressure registers underneath main diaphragm (E) and on top of pilot diaphragm (F). There are three different versions of pressure registration for the Type 299H.

Internal registration (screws and O-rings (J) removed)—Outlet pressure is registered through the

throat to the main diaphragm chamber and through a small port (G) to the top of the pilot diaphragm. Internal registration is used for ease of installation. Capacity is somewhat limited because of droop and/or boost associated with sensing pressure within the body.

External registration—Screws and O-rings (J) block the throat and a downstream control line is connected to the pilot diaphragm chamber which is connected to the lower main diaphragm chamber by a small port (G). The other end of the control line connects to the downstream pipeline. External registration is used for higher capacity and/or the upstream regulator in a monitor set. It also allows monitoring for inlet pressures over 66 psig /

4.5 bar. Capacity is increased because of better registration of pipeline pressure when a control line is used. The alternate 3/4 NPT control line connection (on the side of the pilot) can be used for piping convenience, see Figures 8 and 9.

Dual registration (screws and O-rings (J) removed)— The lower main diaphragm chamber registers outlet pressure through the throat and the pilot diaphragm chamber registers downstream pressure by use of a downstream control line. The port (G) between the chambers is blocked by inserting a screw and O-ring (J) that was removed from the throat and the control line runs from the pilot to the downstream pipeline. Dual

registration, with its larger orice (control line must be

piped to the primary 3/4 NPT connection on the side of the pilot), provides an improved performance as compared to internal pressure registration when used in

low ow rate and high pressure drop applications. It is

also used for no downstream bleed monitoring systems with inlet pressures up to 66 psig / 45 bar.

4

Bulletin 71.2:299H

B

J

A7268_1

OUTLET

INLET

3/4 NPT CONTROL LINE CONNECTION

K

G

F

TYPE 299H WITH INTERNAL REGISTRATION

E

H

PILOT SUPPLY SCREEN

A

C

J

G

A7269

3/4 NPT DOWNSTREAM CONTROL LINE CONNECTION

EXTERNAL REGISTRATION

INLET PRESSURE

OUTLET PRESSURE

ATMOSPHERIC PRESSURE

LOADING PRESSURE

Figure 3. Type 299H Operational Schematic

A7271

TOKEN RELIEF CLOSED

Figure 4. Type 299HR Operational Schematic

A7270

J

3/4 NPT DOWNSTREAM CONTROL LINE CONNECTION

DUAL REGISTRATION

A7272

TOKEN RELIEF OPEN

G

5

Bulletin 71.2:299H

Type 299HS

EXTERNAL REGISTRATION

INTERNAL REGISTRATION

E0072

INLET PRESSURE

OUTLET PRESSURE

ATMOSPHERIC PRESSURE

LOADING PRESSURE

Figure 5. Type 299HS Operational Schematic

EXTERNAL REGISTRATION

INTERNAL REGISTRATION

Type 299H

In operation, assume the outlet pressure is less than the setting of pilot control spring (A). The top side of pilot diaphragm assembly (F) will have a lower pressure than the setting of spring (A). Spring (A) forces the diaphragm assembly upward, opening the

pilot orice (C). Additional loading pressure is supplied

to the top side of the main diaphragm (E).

This creates a higher pressure on the top side of main diaphragm (E) than on the bottom side, forcing the diaphragm downward. This motion is transmitted through a lever, which pulls the valve disk (K) open,

allowing more gas to ow through the valve.

When the gas demand in the downstream system

has been satised, the outlet pressure increases.

The increased pressure is transmitted through the downstream control line (for external or dual registration) or through the port (G) (for internal registration) and acts on top of the pilot diaphragm (F). This pressure exceeds the pilot spring setting and forces the diaphragm down,

closing the orice (C). The loading pressure acting on

main diaphragm (E) bleeds to the downstream system through a bleed restriction (H).

With a decrease in loading pressure on top of main diaphragm (E), main spring (B) exerts an upward force on the diaphragm post connected to main

diaphragm (E), pulling it upward. This moves the

main valve disk (K) toward its seat, decreasing ow

to the downstream system.

Type 299HR

Refer to Figure 4. The Type 299HR provides an integral

token relief valve. During an overpressure condition the spring on the pilot post will allow the diaphragm head to travel to the spring case. As the diaphragm head moves a small amount of gas is relieved.

Note

The Type 299HR is not a full capacity relief device. Approximate start-todischarge pressure is dependent on set pressure, see Figure 7.

During normal operation the Type 299HR performance

is identical to the Type 299H. If an overpressure condition occurs, the pilot diaphragm head will separate from the pilot diaphragm post and travel until it contacts the pilot spring case. The movement of the diaphragm head creates a path and a token or noticeable amount of gas will be released.

When the overpressure condition ceases, the pilot diaphragm head will return to the diaphragm post and the regulator will return to normal operation.

6

Bulletin 71.2:299H

Table 1. Body Sizes and End Connection Styles

BODY SIZE,

NPS / DN

1-1/4 1-1/2

2 / 50 NPT, CL125 FF Flanged

1. This ange is available with a face-to-face dimension of 7.5 or 10 inches / 191 or 254 mm.

(For Types 299H and 299HR only)

Cast Iron

NPT NPT

Table 2. Outlet Pressure Ranges

OUTLET (CONTROL)

PRESSURE RANGE

Inch w.c. mbar Inch mm Inch mm

(1)

3.5 to 6

(1)

5 to 9

(1)

7 to 20

(1)

16 to 40

1 to 3.25 psig

2.75 to 6 psig 5 to 16 psig

14 to 35 psig 30 to 60 psig

1. Use a pilot supply regulator if actual inlet pressure varies more than ±20 psi / ±1.4 bar and the published accuracy is required.

69 mbar to 0.22 bar

0.19 to 0.41 bar

0.34 to 1.1 bar

0.97 to 2.4 bar

(1)

9 to 15

(1)

12 to 22

(1)

17 to 50

(1)

40 to 99

2.1 to 4.1 bar

TYPE PILOT CONTROL SPRING

X X X X

X X X X X

299HR,

299HS and

299HSR

- - - -

299H

BODY MATERIAL AND END CONNECTION STYLES

Ductile Iron

- - - NPT

(1)

X X X X

X X X

NPT, CL125 FF and CL250 RF Flanged,

Part Number Color

T13707T0012 T13589T0012 1N3112X0012 1B413727222

T13593T0012 T13671T0012 T13600T0012 19B0432X012 19B0432X022

PN 10/16 Flanged

Black

Yellow

Unpainted

Purple

Light blue

Orange

Red

Zinc

Green

(For Types 299H and 299HR only)

Free Length Wire Diameter

1.86

2.05

2.18

2.12

2.40

2.10

2.15

2.75

47.2

52.1

55.4

53.8

61.0

53.3

54.6

69.8

Steel

- - - NPT

NPT, CL150 RF Flanged

0.055

0.051

0.075

0.092

0.105

0.120

0.142

0.207

0.225

1.40

1.30

1.90

2.34

2.67

3.05

3.61

5.26

5.71

Type 299HS

Refer to Figure 5. The Type VSX-2 slam-shut device

on the Type 299HS regulator is a fast acting slam-shut valve which provides overpressure or overpressure and underpressure protection by completely shutting

off the ow of gas to the downstream system. The

slam-shut module’s actions are independent of the Type 299HS main regulator and of variations to the inlet pressure. The Type VSX-2 has internal or external registration. External registration requires a downstream sensing line.

The slam-shut disk is held in the open position (reset position) by a small ball holding the disk stem. If the pressure below the diaphragm increases (or decreases) reaching the Type VSX-2 setpoint, the diaphragm will travel upwards (or downwards) operating a lever which in turn releases the ball.

Once the ball is released, the spring force on the stem will push the stem and disk to the closed position against

the seat shutting off all gas ow. The pilot supply pressure

is also shut off when the Type VSX-2 is closed. The

manual reset has an internal bypass to equalize the reset

pressure on either side on the slam-shut disk.

In order for the Underpressure Shutoff (UPSO) of any slam shut to be triggered, the downstream pipe pressure must drop below the UPSO setpoint. In the case of a downstream line break, numerous factors can prevent the downstream pipe pressure from decreasing below the slam-shut UPSO setpoint. These factors include the distance of pipe to the break, the

diameter of the pipe, size of the break and the number

of restrictions, such as valves, elbows and bends,

downstream of the regulator and/or slam-shut device. Due to these factors additional protections should be

installed to stop ow in the event of a line break.

Overpressure Protection

Like most regulators, the Type 299H has outlet pressure ratings lower than the inlet pressure ratings. Complete downstream overpressure protection is needed if the actual inlet pressure exceeds the outlet pressure rating.

Overpressure protection for internal parts is built into the main and pilot diaphragms by means of a small spring on each post. The springs will allow the diaphragm heads to move farther on the posts avoiding damage to or bending of the valve trim.

Overpressuring any portion of a regulator or associated equipment may cause leakage, parts damage or personal injury due to bursting of pressurecontaining parts or explosion of accumulated gas.

Regulator operation within ratings specied in the Specications section and on the regulator nameplate

does not preclude the possibility of damage from external sources or from debris in the pipeline. A regulator should be inspected for damage periodically and after any overpressure condition. The pilot vent is provided with a 1/4 NPT tapped connection in the spring case.

Monitoring Systems

Monitoring regulators serve as overpressure protection devices to limit system pressure in the event of open failure of a working regulator feeding the system.

7

Bulletin 71.2:299H

OPTIONAL PILOT SUPPLY FILTER OR FILTERED PILOT SUPPLY REGULATOR

WORKING REGULATOR

A7136A

NOTE: IF USED, THE PILOT SUPPLY REGULATOR SHOULD BE SET TO

3 psig / 0.21 bar ABOVE THE MONITOR OUTLET PRESSURE SETTING.

OPTIONAL PILOT SUPPLY REGULATOR

WIDE-OPEN MONITOR

WIDE-OPEN DOWNSTREAM MONITOR

OPTIONAL PILOT SUPPLY REGULATOR

WIDE-OPEN MONITOR

OPTIONAL PILOT SUPPLY FILTER OR FILTERED PILOT SUPPLY REGULATOR

WORKING REGULATOR

OPTIONAL PILOT SUPPLY REGULATOR

A7136B

NOTE: IF USED, THE PILOT SUPPLY REGULATOR SHOULD BE SET TO

3 psig / 0.21 bar ABOVE THE MONITOR OUTLET PRESSURE SETTING.

WIDE-OPEN MONITOR

OPTIONAL PILOT SUPPLY FILTER OR FILTERED PILOT SUPPLY REGULATOR

WORKING REGULATOR

WIDE-OPEN UPSTREAM MONITOR

OPTIONAL PILOT SUPPLY FILTER OR FILTERED PILOT SUPPLY REGULATOR

WIDE-OPEN MONITOR

OPTIONAL PILOT SUPPLY REGULATOR

WORKING REGULATOR

A7136C

NOTE: THE PILOT SUPPLY REGULATOR SHOULD BE SET TO

3 psig / 0.21 bar ABOVE THE MONITOR OUTLET PRESSURE SETTING.

WIDE-OPEN UPSTREAM MONITOR

Figure 6. Typical Monitor Installations

APPROXIMATE START-TO-DISCHARGE, bar

0.10

40

35

30

25

20

15

SET INCHES W.C.

10

5

0

1.5 2.0 2.5 3.0 3.5 4.0

0.14

YELLOW SPRING 5 TO 9 INCHES W.C. / 12 to 22 mbar T13589T0012

BLACK SPRING

3.5 TO 6 INCHES W.C. / 9 to 15 mbar T13707T0012

APPROXIMATE START-TO-DISCHARGE, psig

0.17

0.21 0.24

PURPLE SPRING 16 TO 40 INCHES W.C. / 40 to 99 mbar 1B41372722

UNPAINTED SPRING 7 TO 20-INCHES W.C. / 17 to 50 mbar 1N3112X0012

Figure 7. Type 299HR Approximate Start-to-Discharge

0.28

A7273

NOTE: THE PILOT SUPPLY REGULATOR SHOULD BE SET TO

3 psig / 0.21 bar ABOVE THE MONITOR OUTLET PRESSURE SETTING.

NO DOWNSTREAM BLEED MONITOR SYSTEM

APPROXIMATE START-TO-DISCHARGE, bar

0.14 0.28

SET psig

16

14

12

10

8

6

4

2

0

ORANGE SPRING

2.75 TO 6 psig /

0.19 to 0.41 bar T13671T0012

LIGHT BLUE SPRING 1 TO 3.25 psig / 69 mbar to

0.22 bar T13593T0012

0 2 4

99

87

75

62

50

SET mbar

37

25

12

0.55

0.41

6

APPROXIMATE START-TO-DISCHARGE, psig

0.83 0.97 1.10

0.69

10

8

12 14 16 18 20 22

1.24

RED SPRING 5 TO 16 psig /

0.34 to 1.1 bar T13600T0012

1.38

1.52

1.10

0.97

0.83

0.69

0.55

0.41

0.28

0.14

SET bar

8

Table 3. Flow Coefcients

Bulletin 71.2:299H

TYPE

ORIFICE DIAMETER WIDE-OPEN REGULATING

Inch mm

1/4 x 3/8

3/8 1/2

299H / 299HR

3/4 7/8

1

1-3/16

1/4 x 3/8

299HS /

299HSR

3/8 1/2 3/4

1. For external/dual registration only.

6.4 x 9.5

9.5 13 19 22 25 30

6.4 x 9.5

9.5 13 19

C

53 117 203 437 544 725 910

53 117 184 421

g

C

v

2.0

4.2

7.0

14.1

16.5

20.7

25.3

2.0

4.1

5.0

11.9

C

50 115 200 430 534 710 885

50 115 180 415

g

(1)

C

1.9

4.0

6.9

13.9

16.2

20.3

24.6

1.9

4.0

4.9

11.7

C1 WHEN ∆P < 10 psi /

v

0.69 bar

26 30 30 32 34 36 37

26 30 38 36

C1 WHEN ∆P > 10 psi /

0.69 bar

26 28 28 30 32 34 35

26 28 36 35

Table 4. Type VSX-2 High and Low Trip Pressure Ranges

RANGE

High

Pressure

Trip

Low

Pressure

Trip

Low

Pressure

Trip

1. Low Pressure Trip cannot be used with this main valve spring range for an internally registered Type VSX-2 to provide underpressure shutoff under owing conditions. If protection against

loss of inlet pressure is the only required function for the Type VSX-2 then an internally registered Type VSX-2 may be used with the same minimum trip pressures as an externally registered Type VSX-2.

2. 70% of regulator setpoint is the minimum allowable Low Pressure Trip setting for an internally registered Type VSX-2 used with this main valve spring range. If protection against loss of inlet pressure is the only required function for the Type VSX-2 then an internally registered Type VSX-2 may be used with the same minimum trip pressures as an externally registered Type VSX-2.

3. 75% of regulator setpoint is the minimum allowable Low Pressure Trip setting for an internally registered VSX-2 used with this main valve spring range. If protection against loss of inlet pressure is the only required function for the Type VSX-2 then an internally registered Type VSX-2 may be used with the same minimum trip pressures as an externally registered Type VSX-2.

Note: Other spring combinations are available. Please contact your local Sales Ofce for additional information.

SLAM-SHUT

REGISTRATION

Internal or

External

Internal

FOR USE WITH MAIN VALVE

SPRING RANGE

Inch w.c.

3.5 to 6 9 to 15

5 to 9 12 to 22

3.5 to 6 9 to 15

5 to 9 12 to 22

7 to 20 17 to 50

16 to 40 40 to 99

2.75 to 6 psig 0.19 to 0.41 bar

5 to 16 psig 0.34 to 1.1 bar

5 to 16 psig 0.34 to 1.1 bar 11.6 to 23 psig 800 to 1586 T14167T0012 3.15 80.0 0.17 4.32

5 to 9 12 to 22

7 to 20 17 to 50

16 to 40 40 to 99

1 to 3.25 psig 69 mbar to 0.22 bar

2.75 to 6 psig 0.19 to 0.41 bar

5 to 16 psig 0.34 to 1.1 bar

(1)

5 to 9

(1)

7 to 20

(1)

7 to 20

(1)

16 to 40

1 to 3.25 psig

2.75 to 6 psig

5 to 16 psig

(2)

(3)

mbar Inch w.c. mbar

(1)

12 to 22

(1)

17 to 50

(1)

17 to 50

(1)

40 to 99

69 mbar to 0.22 bar

0.19 to 0.41 bar

0.19 to 0.4 1 bar

0.34 to 1.1 bar

(2)

(3)

MINIMUM TO MAXIMUM

TRIP PRESSURE

12 to 25 30 to 62 T14162T0012 3.15 80.0 0.07 1.70

20 to 52 50 to 129 T14163T0012 3.15 80.0 0.08 2.03

1.4 to 3.9 psig 97 to 269 T14164T0012 3.15 80.0 0.09 2.31

3.8 to 8.7 psig 262 to 600 T14165T0012 3.15 80.0 0.12 3.051 to 3.25 psig 69 mbar to 0.22 bar

5.8 to 16 psig 400 to 1103 T14166T0012 3.15 80.0 0.14 3.51

2 to 12 5 to 30 T14168T0012 3.15 80.0 0.04 1.09

4 to 30 10 to 75 T14169T0012 3.15 80.0 0.06 1.40

0.36 to 2.3 psig 25 to 159 T14170T0012 3.15 80.0 0.07 1.70

1.5 to 10.8 psig 103 to 745 T14171T0012 3.15 80.0 0.13 3.17

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

70% of regulator

setpoint to 2.3 psig

70% of regulator

setpoint to 10.8 psig

75% of regulator

setpoint to 10.8 psig

70% of regulator

setpoint to 159 mbar

70% of regulator

setpoint to 745 mbar

75% of regulator

setpoint to 745 mbar

TYPE VSX-2

SPRING PART

NUMBER

T14170T0012 3.15 80.0 0.07 1.70

T14171T0012 3.15 80.0 0.13 3.17

SPRING FREE

LENGTH

Inch mm Inch mm

SPRING WIRE

DIAMETER

9

Bulletin 71.2:299H

Wide-Open Monitor

The control line of the upstream regulator is connected downstream of the second regulator (Figure 6), so that during normal operation the monitoring regulator is standing wide open with the reduction to distribution pressure being taken across the working regulator. Only in case of open failure of the working regulator does the wide-open monitoring regulator take control at its slightly higher setting. A pressure build-up above the monitor set pressure is required for the monitor to take control in the event of an overpressure situation. Installing a pilot supply

regulator on the monitor will minimize the pressure build-

up. The pilot supply regulator should be set to 3 psig / 0.21 bar above the monitor setpoint.

The minimum set pressure difference between the worker and monitor should be greater than the proportional band. Small set pressure differences may cause the worker and monitor to function independently.

The upstream regulator can easily be eld converted

or ordered with screws and O-rings in the throat (Figure 6). This seals off the path that otherwise would let line pressure ahead of the working regulator inlet and try to close the wide-open monitoring regulator.

No Downstream Bleed Monitor

The no bleed monitor is a wide-open upstream monitor which works like a conventional wide-open upstream monitor except for registration. The no bleed

monitor utilizes a dual registration construction as

opposed to the external registration construction of the conventional monitor. This ensures that the lockup of the monitor system is the lockup of the downstream

working monitor at zero ow during normal operation.

Installation

Although the actuator and pilot can be mounted in 90° increments relative to the body, the normal installation

is with the body in a horizontal run of pipe and the pilot

hanging vertically from the bottom of the actuator.

Control and vent lines necessary for installation are not supplied with a Type 299H regulator. Control and vent connection locations are shown in Figures 8 and 9. In many instances good piping practice will require

that outlet piping be swaged up above the body size

to prevent excessive pressure drop along the outlet line. The piping should be expanded as close to the regulator outlet as possible.

Capacity Information

Tables 5 through 10 give the 299H Series natural gas regulating capacities at selected inlet pressures and outlet pressure settings. Flows are in SCFH (60°F and

14.7 psig) and Nm³/h (0°C and 1.01325 bar) of 0.6

specic gravity natural gas. To determine equivalent

capacities for air, propane, butane or nitrogen, multiply the capacity number in the tables by the following appropriate conversion factor: 0.775 for air, 0.628 for propane, 0.548 for butane or 0.789 for nitrogen. For

gases of other specic gravities, multiply the given

capacity by 0.775 and divide by the square root of the

appropriate specic gravity.

For critical ow:

To determine wide-open ow capacities for relief sizing of 0.6 specic gravity natural gas at 60°F at

critical pressure drops (absolute outlet pressure equal to approximately one-half or less than one-half of the absolute inlet pressure), use the following formula:

Q = P

1(abs)(Cg

For subcritical ow:

If pressure drops are lower than critical (absolute outlet pressure greater than approximately one-half the absolute inlet pressure), use the following formula and convert according to the factors in the preceding paragraph if necessary:

520

Q = CgP1SIN

GT

where:

C1 = Cg/C

v

Cg = Gas sizing coefcient (see Table 3)

G = Gas specic gravity (air = 1.0)

P1 = Regulator inlet pressure, psia

∆P = Pressure drop across regulator, psi Q = Gas ow rate, SCFH

T = Absolute temperature of gas at

inlet, °Rankine

Due to boost, the above formulas cannot be used to obtain correct regulating capacities for regulators with internal registration.

)(1.29)

3417

C

1

(see Table 3)

Note

∆P

P

DEG

1

10

The published capacities were obtained using inlet and

outlet piping the same size as the regulator body size.

Bulletin 71.2:299H

Table 5. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

3.5 to 6 inches w.c. / 9 to 15 mbar

3.5 inches w.c. / 9 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13707T0012

Black

5 to 9 inches w.c. /

12 to 22 mbar

7 inches w.c. /

17 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13589T0012

Yellow

7 to 20 inches w.c. /

17 to 50 mbar

14 inches w.c. /

35 mbar

±2 inches w.c./

±5 mbar

1N3112X0012

Unpainted

16 to 40 inches w.c. /

40 to 99 mbar

28 inches w.c. /

70 mbar

±4 inches w.c. /

±10 mbar

1B413727222

Purple

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19 7/8 / 22 1 / 25 1-3/16 / 30

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

2

10 15

20 25 30 40

50 60 80

100

125 150 175

10 15

20 25 30 40

50 60 80

100

125 150 175

10 15

20 25 30 40

50 60 80

100

125 150 175

10 15 20

25 30 40 50 60

80 100 125 150 175

0.14

5

0.34

0.69

10.3

12.1

2

0.14

5

0.34

0.69

10.3

12.1

2

0.14

5

0.34

0.69

10.3

12.1

5

0.34

0.69

10.3

12.1

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

760 1160 1590 1920

2240 2570 2890 3530

4180 4820 6110 7400

9020

10,630 12,240

750 1160 1590 1920

2240 2570 2890 3530

4180 4820 6110 7400

9020

10,630 12,240

700 1140 1580 1920

2240 2570 2890 3530

4180 4820 6110 7400

9020

10,630 12,240

1110 1570 1920 2240

2570 2890 3530 4180 4820

6110 7400 9020

10,630 12,240

(1)

for 1-1/2 NPT and NPS 2 / DN 50 External/Dual Registration

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size, Inch / mm

20.4

1560

41.8

2700

72.4

5490

31.1

42.6

51.4

60.0

68.9

77.4

94.6

112 129 164 198

242 285 328

20.1

31.1

42.6

51.4

60.0

68.9

77.4

94.6

112 129 164 198

242 285 328

18.8

30.5

42.3

51.4

60.0

68.9

77.4

94.6

112 129 164 198

242 285 328

29.7

42.1

51.4

60.0

68.9

77.4

94.6 112 129

164 198 242 285 328

2460 3580 4410

5150 5890 6640 8120

9600 11,090 14,050 17,020

20,730 24,440 28,150

1520

2440

3580

4410

5150

5890

6640

8120

9600 11,090 14,050 17,020

20,730 24,440 28,150

1430

2400

3560

4410

5150

5890

6640

8120

9600 11,090 14,050 17,020

20,730 24,440 28,150

2320

3530

4410

5150

5890

6640

8120

9600 11,090

14,050 17,020 20,730 24,440 28,150

65.9

95.9 118

138 158 178 218

257 297 377 456

556 655 754

40.7

65.4

95.9 118

138 158 178 218

257 297 377 456

556 655 754

38.3

64.3

95.4 118

138 158 178 218

257 297 377 456

556 655 754

62.2

94.6 118 138

158 178 218 257 297

377 456 556 655 754

4270 6230 7670

8960 10,250 11,540 14,120

16,700 19,280 24,440 29,600

36,050 42,500 48,950

2650

4240

6220

7670

8960 10,250 11,540 14,120

16,700 19,280 24,440 29,600

36,050 42,500 48,950

2480

4170

6190

7670

8960 10,250 11,540 14,120

16,700 19,280 24,440 29,600

36,050 42,500 48,950

4020

6140

7670

8960

10,250 11,540 14,120 16,700 19,280

24,440 29,600 36,050 42,500 48,950

114 167 206

240 275 309 378

448 517 655 793

966 1139 1312

71.0 114 167 206

240 275 309 378

448 517 655 793

966

1139 1312

66.5 112 166 206

240 275 309 378

448 517 655 793

966

1139 1312

108 165 206 240

275 309 378 448 517

655 793 966

1139 1312

13,060 16,480

19,250 22,030 24,800 30,350

35,890 41,440 52,540 63,630

77,500 91,360

13,040 16,480

19,250 22,030 24,800 30,350

35,890 41,440 52,540 63,630

77,500 91,360

12,970 16,480

19,250 22,030 24,800 30,350

35,890 41,440 52,540 63,630

77,500 91,360

12,830 16,170 19,250

22,030 24,800 30,350 35,890 41,440

52,540 63,630 77,500 91,360

8790

5380 8730

5040 8570

8250

147 236 350 442

516 590 665 813

962 1111 1408 1705

2077 2448

144

234

349

442

516

590

665

813

962 1111 1408 1705

2077 2448

135

230

348

442

516

590

665

813

962 1111 1408 1705

2077 2448

221

344

433

516

590

665

813

962 1111

1408 1705 2077 2448

6460

173

10,350

277

15,270

409

19,450

521

24,110

646

27,110

727

31,110

834

38,100

1021

44,100

1182

51,090

1369

65,080

1744

79,060

2119

96,050 2574

6270

168

10,250

275

15,220

408

19,420

520

24,110

646

27,110

727

31,110

834

38,100

1021

44,100

1182

51,090

1369

65,080

1744

79,060

2119

96,050 2574

5850

157

10,040

269

15,110

405

19,350

519

24,110

646

27,110

727

31,110

834

38,100

1021

44,100

1182

51,090

1369

65,080

1744

79,060

2119

96,050 2574

9580

257

14,870

399

19,220

515

24,110

646

27,110

727

31,110

834

38,100

1021

44,100

1182

51,090

1369

65,080

1744

79,060

2119

96,050

2574

8170 13,310 20,300 25,780

31,790 36,370 40,950 50,100

59,260 68,420 86,740

105,060

8000 13,220 20,250 25,750

31,790 36,370 40,950 50,100

59,260 68,420 86,740

105,060

7480 12,950 20,110 25,660

31,790 36,370 40,950 50,100

59,260 68,420 86,740

105,060

12,430 19,830 25,480 30,670

36,370 40,950 50,100 59,260 68,420

86,740

105,060

219 357 544 691

852

975 1097 1343

1588 1834 2325 2816

214

354

543

690

852

975 1097 1343

1588 1834 2325 2816

200

347

539

688

852

975 1097 1343

1588 1834 2325 2816

333

531

683

822

975 1097 1343 1588 1834

2325 2816

9940

266

16,250

436

24,900

667

31,730

850

39,620

1062

45,330

1215

51,040

1368

62,450

1674

73,870

1980

85,290

2286

108,120

2898

9730

261

16,130

432

24,830

665

31,690

849

39,620

1062

45,330

1215

51,040

1368

62,450

1674

73,870

1980

85,290

2286

108,120

2898

9090

244

15,800

423

24,640

660

31,560

846

39,620

1062

45,330

1215

51,040

1368

62,450

1674

73,870

1980

85,290

2286

108,120

2898

15,150

406

24,290

651

31,320

839

37,820

1014

45,330

1215

51,040

1368

62,450

1674

73,870

1980

85,290

2286

108,120 2898

- continued -

11

Bulletin 71.2:299H

Table 5. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

1 to 3.25 psig /

69 mbar to 0.22 bar

2 psig / 0.14 bar

±1% psia / bar

T13593T0012

Light Blue

2.75 to 6 psig /

0.19 to 0.41 bar

5 psig / 0.34 bar

±1% psia / bar

T13671T0012

Orange

5 to 16 psig /

0.34 to 1.1 bar

10 psig / 0.69 bar

±1% psia / bar

T13600T0012

Red

5 to 16 psig /

0.34 to 1.1 bar

15 psig / 1.0 ba

±1% psia / bar

T13600T0012

Red

14 to 35 psig /

0.97 to 2.4 bar

20 psig / 1.4 bar

±1% psia / bar

19B0432X012

Zinc

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19 7/8 / 22 1 / 25 1-3/16 / 30

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

5

0.34 10 15 20

25 30 40 50 60

80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

15 20 25 30

40 50 60 80

100 125 150 175

20 25 30 40

50 60 80

100

125 150 175

25 30 40 50 60

80

100 125 150 175

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1020 1550 1920 2240

2570 2890 3530 4180 4820

6110 7400

9020 10,630 12,240

1390

1870

2240

2570

2890

3530

4180

4820

6110

7400

9020 10,630 12,240

1580

2130

2540

2890

3530

4180

4820

6110

7400

9020 10,630 12,240

1750

2360

2820

3530

4180

4820

6110

7400

9020 10,630 12,240

1920

2580

3480

4180

4820

6110

7400

9020 10,630 12,240

(1)

for 1-1/2 NPT and NPS 2 / DN 50 External/Dual Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size, Inches / mm

27.3

2100

56.4

3640

97.5

7440

41.5

51.4

60.0

68.9

77.4

94.6 112 129

164 198 242 285 328

37.2

50.1

60.0

68.9

77.4

94.6 112 129 164

198 242 285 328

42.3

57.1

68.1

77.4

94.6 112 129 164

198 242 285 328

46.9

63.2

75.6

94.6

112 129 164 198

242 285 328

51.4

69.1

93.3 112 129

164 198 242 285 328

3340 4360 5150

5890 6640 8120 9600

11,090

14,050 17,020 20,730 24,440 28,150

2910 4190 5090 5890

6640 8120

9600 11,090 14,050

17,020 20,730 24,440 28,150

3280

4720

5710

6640

8120

9600 11,090 14,050

17,020 20,730 24,440 28,150

3620

5220

6290

8120

9600 11,090 14,050 17,020

20,730 24,440 28,150

3930

5680

7830

9600 11,090

14,050 17,020 20,730 24,440 28,150

89.5 117 138

158 178 218 257 297

377 456 556 655 754

78.0 112 136 158

178 218 257 297 377

456 556 655 754

87.9 126 153 178

218 257 297 377

456 556 655 754

97.0 140 169 218

257 297 377 456

556 655 754

105 152 210 257 297

377 456 556 655 754

5810 7580 8960

10,250 11,540 14,120 16,700 19,280

24,440 29,600 36,050 42,500 48,950

5050 7280 8850

10,250

11,540 14,120 16,700 19,280 24,440

29,600 36,050 42,500 48,950

5690 8210 9930

11,540

14,120 16,700 19,280 24,440

29,600 36,050 42,500 48,950

6290

9070 10,940 14,120

16,700 19,280 24,440 29,600

36,050 42,500 48,950

6840

9870 13,610 16,700 19,280

24,440 29,600 36,050 42,500 48,950

156 203 240

275 309 378 448 517

655 793

966 1139 1312

135

195

237

275

309

378

448

517

655

793

966 1139 1312

152

220

266

309

378

448

517

655

793

966 1139 1312

169

243

293

378

448

517

655

793

966 1139 1312

183

265

365

448

517

655

793

966 1139 1312

12,040 15,990 19,250

22,030 24,800 30,350 35,890 41,440

52,540 63,630 77,500 91,360

10,350 15,150 18,640 22,030

24,800 30,350 35,890 41,440 52,540

63,630 77,500 91,360

11,640 17,000 20,790 24,150

30,350 35,890 41,440 52,540

63,630 77,500 91,360

12,830 18,700 22,790 29,650

35,890 41,440 52,540 63,630

77,500 91,360

13,930 20,280 28,440 35,140 41,440

52,540 63,630 77,500 91,360

199 323 429 516

590 665 813 962

1111

1408 1705 2077 2448

277 406 500 590

665 813

962 1111 1408

1705 2077 2448

312

456

557

647

813

962 1111 1408

1705 2077 2448

344

501

611

795

962 1111 1408 1705

2077 2448

373

544

762

942 1111

1408 1705 2077 2448

8650

232

14,410

386

18,950

508

24,110

646

27,110

727

31,110

834

38,100

1021

44,100

1182

51,090

1369

65,080

1744

79,060

2119

96,050

2574

12,700

340

17,950

481

22,970

616

27,110

727

31,110

834

38,100

1021

44,100

1182

51,090

1369

65,080

1744

79,060

2119

96,050

2574

12,640

339

20,380

546

24,570

658

29,540

792

38,100

1021

44,100

1182

51,090

1369

65,080

1744

79,060

2119

96,050

2574

15,830

424

22,040

591

27,870

747

36,530

979

44,100

1182

51,090

1369

65,080

1744

79,060

2119

96,050 2574

14,960

401

24,090

646

34,480

924

41,940

1124

51,090

1369

65,080

1744

79,060

2119

96,050

2574

11,140

299

18,460

495

25,050

671

30,380

814

36,370

975

40,950

1097

50,100

1343

59,260

1588

68,420

1834

86,740

2325

105,060

2816

15,600

418

23,310

625

29,180

782

34,550

926

40,950

1097

50,100

1343

59,260

1588

68,420

1834

86,740

2325

105,060 2816

17,470

468

25,940

695

32,220

863

37,900

1016

50,100

1343

59,260

1588

68,420

1834

86,740

2325

105,060 2816

19,190

514

28,360

760

35,050

939

46,610

1249

57,080

1530

68,420

1834

86,740

2325

105,060

2816

20,800

557

30,630

821

43,980

1179

55,310

1482

65,780

1763

86,740

2325

105,060

2816

13,560

363

22,570

605

30,760

824

37,410

1003

45,330

1215

51,040

1368

62,450

1674

73,870

1980

85,290

2286

108,120 2898

19,030

510

28,530

765

35,820

960

42,530

1140

51,040

1368

62,450

1674

73,870

1980

85,290

2286

108,120

2898

21,280

570

31,690

849

39,480

1058

46,550

1248

62,450

1674

73,870

1980

85,290

2286

108,120

2898

23,360

626

34,610

928

42,890

1149

57,270

1535

70,350

1885

85,290

2286

108,120

2898

25,310 37,340 53,880 67,980 81,060

108,120

12

- continued -

Bulletin 71.2:299H

Table 5. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

14 to 35 psig /

0.97 to 2.4 bar

25 psig / 1.7 bar

±1% psia / bar

19B0432X012

Zinc

14 to 35 psig /

0.97 to 2.4 bar

30 psig / 2.1 bar

±1% psia / bar

19B0432X012

Zinc

14 to 35 psig /

0.97 to 2.4 bar

35 psig / 2.4 bar

±1% psia / bar

19B0432X012

Zinc

30 to 60 psig /

2.1 to 4.1 bar

40 psig / 2.8 bar

±1% psia / bar

19B0432X022

Green

30 to 60 psig /

2.1 to 4.1 bar

50 psig / 3.4 bar

±1% psia / bar

19B0432X022

Green

30 to 60 psig /

2.1 to 4.1 bar

60 psig / 4.1 bar

±1% psia / bar

19B0432X022

Green

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET

PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

30 40 50 60

80 100 125 150 175

40

50

60

80

100 125 150 175

40

50

60

80

100 125 150 175

50

60

80 100

125 150 175

60

80 100

125 150 175

80 100 125

150 175

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19 7/8 / 22 1 / 25 1-3/16 / 30

2.1

2070

2.8

3320

3.4

4140

4.1

4820

5.5

6110

6.9

7400

8.6

9020

10.3

10,630

12.1

12,240

2.8

2980

3.4

4020

4.1

4800

5.5

6110

6.9

7400

8.6

9020

10.3

10,630

12.1

12,240

2.8

2350

3.4

3770

4.1

4700

5.5

6110

6.9

7400

8.6

9020

10.3

10,630

12.1

12,240

3.4

3340

4.1

4500

5.5

6100

6.9

7400

8.6

9020

10.3

10,630

12.1

12,240

4.1

3680

5.5

5900

6.9

7400

8.6

9020

10.3

10,630

12.1

12,240

5.5

5380

6.9

7260

8.6

9020

10.3

10,630

12.1

12,240

(1)

for 1-1/2 NPT and NPS 2 / DN 50 External/Dual Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size, Inch / mm

55.5

4230

113

7360

197

14,980

89.0 111 129

164 198 242 285 328

79.9 108 129 164

198 242 285 328

63.0 101 126 164

198 242 285 328

89.5 121 163 198

242 285 328

98.6 158 198

242 285 328

144 195 242

285 328

7350 9340

11,090

14,050 17,020 20,730 24,440 28,150

6520

8950 10,850 14,050

17,020 20,730 24,440 28,150

4790

8300 10,510 14,050

17,020 20,730 24,440 28,150

7290

9970 13,840 17,020

20,730 24,440 28,150

7990 13,170 16,830

20,730 24,440 28,150

11,810 16,270 20,730

24,440 28,150

197 250 297

377 456 556 655 754

175 240 291 377

456 556 655 754

128 222 282 377

456 556 655 754

195 267 371 456

556 655 754

214 353 451

556 655 754

317 436 556

655 754

12,780 16,250 19,280

24,440 29,600 36,050 42,500 48,950

11,330 15,560 18,870 24,440

29,600 36,050 42,500 48,950

8330 14,430 18,270 24,440

29,600 36,050 42,500 48,950

12,670 17,340 24,070 29,600

36,050 42,500 48,950

13,900 22,900 29,260

36,050 42,500 48,950

20,540 28,290 35,860

42,500 48,950

343 436 517

655 793

966 1139 1312

304

417

506

655

793

966 1139 1312

223

387

490

655

793

966 1139 1312

340

465

645

793

966 1139 1312

373

614

784

966 1139 1312

550

758

961

1139 1312

401

26,420

708

34,040

912

40,630

1089

52,540

1408

63,630

1705

77,500

2077

91,360

2448

23,190

621

32,300

866

39,600

1061

52,540

1408

63,630

1705

77,500

2077

91,360

2448

16,920

453

29,690

796

38,050

1020

51,600

1383

63,630

1705

77,500

2077

91,360

2448

25,840

693

35,820

960

50,670

1358

63,630

1705

77,500

2077

91,360

2448

28,290

758

47,570

1275

61,700

1654

77,500

2077

91,360

2448

42,160

1130

59,000

1581

75,900

2034

91,360 2448

18,330

491

32,120

861

40,400

1083

48,920

1311

65,080

1744

79,060

2119

96,050

2574

27,330

732

37,410

1003

46,980

1259

65,080

1744

79,060

2119

96,050

2574

20,530

550

34,220

917

44,960

1205

62,470

1674

79,060

2119

96,050

2574

30,500

817

42,700

1144

61,300

1643

77,250

2070

95,700 2565

33,300

892

57,000

1528

74,800

2005

94,400 2530

50,000

1340

70,900

1900

92,300

2474

22,310

598

40,220

1078

52,830

1416

64,010

1715

86,740

2325

105,060

2816

34,790

932

49,460

1326

61,630

1652

83,170

2229

105,060 2816

25,150

674

44,890

1203

58,520

1568

81,400

2182

105,060 2816

38,590

1034

54,480

1460

79,160

2121

100,560

2695

42,110

1129

72,950

1955

96,630

2590

63,540

1703

90,970

2438

27,140

727

49,120

1316

64,770

1736

78,690

2109

108,120 2898

42,370

1136

60,480

1621

75,590

2026

102,470

2746

30,580

820

54,750

1467

71,620

1919

100,090

2682

46,950

1258

66,530

1783

97,160

2604

51,210

1372

89,220

2391

77,440 2075

13

Bulletin 71.2:299H

760 1200 1700 2000

2350 2700 3040 3700

4400 5100 4700 4300

4300 4320 5600

750 1300 1600 2000

2300 2600 2970 3700

4400 5100 4850 4600

4600 4600 5400

700 1100 1700 1900

2150 2400 2740 3400

4250 5100 5250 5400

5400 5900

555

1200 1600 2000 2300

2600 2800 3200 4100 5000

6300 7600 9200

5510

(1)

for 1-1/2 NPT Internal Registration

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size, Inch / mm

20.4

1560

41.8

32.2

45.6

53.6

63.0

72.4

81.5

99.2

118 137 126 115

115 116 150

20.1

34.8

42.9

53.6

61.6

69.7

79.6

99.2

118 137 130 123

123 123 145

18.8

29.5

45.6

50.9

57.6

64.3

73.4

91.1

114 137 141 145

145 158 149

32.2

42.9

53.6

61.6

69.7

75.0

85.8 110 134

169 204 247 287 148

2600 3800 4600

5300 6000 6740 8200

9700

11,200

4680 3040

3200 3200 5050

1520 2600 3800 4400

5100 5800 6600 8200

9700

11,200

4700 2800

3200 3640 5050

1430 2200 3600 4600

5300 6000 6740 8200

9700

11,000

5210 4580

4400 5020 5200

2400 3700 4400 5100

5800 6600 8200 9750

11,100

5910 5220 5690 7380 5100

69.7 102 123

142 161 181 220

260 300 125

81.5

85.8

85.8 135

40.7

69.7 102 118

137 155 177 220

260 300 126

75.0

85.8

97.5 135

38.3

59.0

96.5 123

142 161 181 220

260 295 140 123

118 135 139

64.3

99.2 118 137

155 177 220 261 297

158 140 152 198 137

2700 4500 6500 8000

9250 10,010 10,330 11,640

11,650 11,380

4510

3990

4390

4810

7300

2650

4250

6500

8000

9500 10,660 10,410 10,170

11,170 11,710

4570

3790

4190

4590

7300

2480

4000

6500

8000

8500

9000 10,000 10,900

10,210

9650

4060

4410

5290

6170

6500

4000

6500

8000

9250

10,500 11,840 14,060 14,010 14,040

6140

5420

6010

5970

7250

72.4 121 174 214

248 268 277 312

312 305 121 107

118 129 196

71.0 114 174 214

255 286 279 273

299 314 122 102

112 123 196

66.5 107 174 214

228 241 268 292

274 259 109 118

142 165 174

107 174 214 248

281 317 377 375 376

165 145 161 160 194

4050 8490 7140 7120

7060 7100 8030 9610

10,530 11,590 15,210 14,510

8640 2650

5380 7110 8150 6180

6520 6190 7420

12,030

12,160 10,620

3610 3380

3440 2400

5040 7180 8310 7000

7410 6900 6500 9220

12,580 11,750

4970 4970

4330 3130

6010

8130 10,340 11,980

12,390 12,500 13,350 14,530 13,440

9950

7780

8220

4900

Table 6. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

3.5 to 6 inches w.c. / 9 to 15 mbar

3.5 inches w.c. / 9 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13707T0012

Black

5 to 9 inches w.c. /

12 to 22 mbar

7 inches w.c. /

17 mbar

-1 to 2 inches w.c. /

-2 to 5mbar

T13589T0012

Yellow

7 to 20 inches w.c. /

17 to 50 mbar

14 inches w.c. /

35 mbar

±2 inches w.c. /

±5 mbar

1N3112X0012

Unpainted

16 to 40 inches w.c. /

40 to 99 mbar

28 inches w.c. /

70 mbar

±4 inches w.c. /

±10 mbar

1B413727222

Purple

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19 1 / 25 1-3/16 / 30

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

2

0.14

5

0.34

10

0.69

15

1.0

20

1.4

25

1.7

30

2.1

40

2.8

50

3.4

60

4.1

80

100

125 150 175

100

125 150 175

100

125 150 175

100 125 150 175

5.5

6.9

8.6

10.3

12.1

2

0.14

5

0.34

10

0.69

15

1.0

20

1.4

25

1.7

30

2.1

40

2.8

50

3.4

60

4.1

80

5.5

6.9

8.6

10.3

12.1

2

0.14

5

0.34

10

0.69

15

1.0

20

1.4

25

1.7

30

2.1

40

2.8

50

3.4

60

4.1

80

5.5

6.9

8.6

10.3

12.1

5

0.34

10

0.69

15

1.0

20

1.4

25

1.7

30

2.1

40

2.8

50

3.4

60

4.1

80

5.5

6.9

8.6

10.3

10,700

12.1

109 228 191 191

189 190 215 258

282 311 408 389

232

71.0

144 191 218 166

175 166 199 322

326 285

96.7

90.6

92.2

64.3

135 192 223 188

199 185 174 247

337 315 133 133

116

83.9

161 218 277 321

332 335 358 389 360

267 209 220 131

4340

10,690

8570

10,860

11,250 11,170 11,660 10,790

9460 9010 6250 7700

5610 7600 8210

10,770

11,510 10,920 10,850 10,310

10,430

8230 8000 6400

6900 7280 9330

11,940

11,850 11,330 11,270 10,820

10,820

8840 8550 6780

9210 10,300 13,020 14,790

14,570 14,050 13,290 12,860 13,020

8500

6500

116 286 230 291

302 299 312 289

254 241 168 206

150 204 220 289

308 293 291 276

280 221 214 172

185 195 250 320

318 304 302 290

290 237 229 182

247 276 349 396

390 377 356 345 349

228 174

4540 7290

10,570

9020

9810 9760 9700

11,150

10,100 10,200

8900

5790 6620

10,320

9040

9510

9850 10,080 10,170

10,000 10,200

8500

7050

8860 10,320

9530

11,060 11,080 10,780 11,220

10,450 11,100

9400

9070 10,650 12,890 13,170

14,180 13,770 14,110 12,050 10,950

10,200 273

122 195 283 242

263 262 260 299

271 273 239

155 177 277 242

255 264 270 273

268 273 228

189 237 277 255

296 297 289 301

280 297 252

243 285 345 353

380 369 378 323 293

14

- continued -

Bulletin 71.2:299H

Table 6. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

1 to 3.25 psig /

69 mbar to 0.22 bar

2 psig / 0.14 bar

±1% psia / bar

T13593T0012

Light Blue

2.75 to 6 psig /

0.19 to 0.41 bar

5 psig / 0.34 bar

±1% psia / bar

T13671T0012

Orange

5 to 16 psig /

0.34 to 1.1 bar

10 psig / 0.69 bar

±1% psia / bar

T13600T0012

Red

5 to 16 psig /

0.34 to 1.1 bar

15 psig / 1.0 bar

±1% psia / bar

T13600T0012

Red

14 to 35 psig /

0.97 to 2.4 bar

20 psig / 1.4 bar

±1% psia / bar

19B0432X012

Zinc

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19 1 / 25 1-3/16 / 30

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

5

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1020 1550 1920 2240

2570 2890 3530 4180 4820

6110 7400 8170 8450 7750

1390 1870 2240 2570

2890 3530 4180 4820 6110

7400 9020

10,630

6800

1580 2130 2540 2890

3530 4180 4820 6110

7400 9020 6790 6200

1750 2360 2820 3540

4180 4820 6110 7400

9020

10,630

7400

1920 2580 3480 4180

4820 6110 7400

9020

10,630

7500

10 15 20

25 30 40 50 60

80 100 125 150 175

10

15

20

25

30

40

50

60

80

100 125 150 175

15

20

25

30

40

50

60

80

100 125 150 175

20

25

30

40

50

60

80 100

125 150 175

25

30

40

50

60

80 100

125 150 175

(1)

for 1-1/2 NPT Internal Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size, Inch / mm

27.3

41.5

51.4

60.0

68.9

77.4

94.6 112 129

164 198 219 226 208

37.2

50.1

60.0

68.9

77.4

94.6 112 129 164

198 242 285 182

42.3

57.1

68.1

77.4

94.6 112 129 164

198 242 182 166

46.9

63.2

75.6

94.9

112 129 164 198

242 285 198

51.4

69.1

93.3 112

129 164 198

242 285 201

2100 3340 4360 5150

5890 6640 8120 9600

10,890

9000 5200 5040 5870 5250

2910 4190 5090 5890

6640 8120

9600 11,090 14,050

17,020

7690

6330

6050

3280

4720

5740

6580

8120

9600 11,090 14,050

17,020 20,730

6790

5600

3620

5220

6290

8070

9600 11,090 14,050 17,020

20,730 24,440

6750

3930

5690

7830

9550

11,090 14,050 17,020

20,730 24,440

8200

56.4

89.5 117 138

158 178 218 257 292

241 139 135 157 141

78.0 112 136 158

178 218 257 297 377

456 206 170 162

87.9 126 154 176

218 257 297 377

456 556 182 150

97.0 140 169 216

257 297 377 456

556 655 181

105 152 210 256

297 377 456

556 655 220

3640 5840 7580 8960

10,250 11,540 14,120 15,010 15,740

12,230

5200 5200 5200 5730

5050 7280 8850

10,250

11,540 14,120 16,700 16,290 14,000

9020 7690 6360 8200

5690 8210 9940

11,440

14,120 16,700 17,200 16,950

15,350 16,740

6830 5700

6290

9070 10,940 14,020

16,700 18,110 19,910 21,710

23,960 26,210

7100

6840

9870 13,610 16,610

18,080 20,980 23,680

26,980 30,280

8600

97.5 157 203 240

275 309 378 402 422

328 139 139 139 154

135 195 237 275

309 378 448 437 375

242 206 170 220

152 220 266 307

378 448 461 454

411 449 183 153

169 243 293 376

448 485 534 582

642 702 190

183 265 365 445

485 562 635

723 812 230

7020

8990 11,260 12,950

13,090 14,830 13,500 13,780 14,050

11,100

5200

5600

8470 11,290 12,590 13,210

13,820 15,060 15,400 15,750 13,620

9610

7890

5500

9930 11,990 13,400 14,810

17,640 18,110 18,580 17,810

15,900 16,270

5800

11,380 13,590 15,810 20,230

20,820 21,410 22,000 22,600

23,190 21,200

12,840 15,200 22,820 20,950

23,330 25,120 26,930

28,020 21,600

188 241 302 347

351 397 362 369 377

297 139 139 150

227 303 337 354

370 404 413 422 365

258 211 147

266 321 359 397

473 485 498 477

426 436 155

305 364 424 542

558 574 590 606

621 568

344 407 612 561

625 673 722

751 579

10,790 12,180 13,580 13,630

13,890 13,740 13,470 13,970 14,080

12,750

6400

12,010 14,300 13,820 14,500

15,290 15,650 16,010 16,370 14,000

14,000 375

13,230 14,130 15,990 17,850

18,630 19,400 20,170 15,750

15,950 427

114,450

17,440 20,430 21,610

22,800 23,890 19,500 22,200

15,670 20,740 24,600 23,620

26,120 24,500 26,200

3067

289 326 364 365

372 368 361 374 377

342 172

322 383 370 389

410 419 429 439 375

355 379 429 478

499 520 541 422

467 548 579

611 640 523 595

420 556 659 633

700 657 702

10,820 11,180 11,960 12,750

13,370 14,000 15,250 12,500 12,300

10,500 281

12,190 12,400 13,260 14,310

15,370 16,630 14,000 13,250 14,000

13,570 14,100 15,870 17,640

18,920 16,400 16,600 17,600

14,980 17,430 19,910 21,220

20,500 21,600 19,900

16,320 20,760 23,510 22,200

25,000 24,900

290 300 321 342

358 375 409 335 330

327 332 355 384

412 446 375 355 375

364 378 425 473

507 440 445 472

401 467 534 569

549 579 533

437 556 630 595

670 667

- continued -

15

Bulletin 71.2:299H

1/4 x 3/8 /

6.4 x 9.5

2070 3320 4140 4830

6110 7400 9020

2980 4020 4800 6110

7400 9020

2350 3770 4700 6120

7400 9020

2400 3470 5600 6400

7600 9500

3000 5250 6750

8250 9500

2750 2750 3250

3130 3000

(1)

for 1-1/2 NPT Internal Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size, Inch / mm

3/8 / 9.5 1/2 / 13 3/4 / 19 1 / 25 1-3/16 / 30

55.5

89.0 111 129

164 198 242 285 273

79.9 108 129 164

198 242 285 284

63.0 101 126 164

198 242 285 292

64.3

93.0 150 172

204 255 306

80.4 141 181

221 255 288

73.7

87.1

83.9

80.4

4230 7350 9340

11,030

14,050 17,020 20,730 24,440 25,200

6520

8950 10,850 14,050

17,020 20,730 24,440 24,500

4790

8300 10,510 14,000

17,020 20,730 24,440 24,800

6000

8000 12,000 14,500

19,500 22,750 26,000

6500 10,750 15,000

17,500 21,750 26,000

7200 10,600

3000

2900

2800

113 197 250 296

377 456 556 655 675

175 240 291 377

456 556 655 657

128 222 282 375

456 556 655 665

161 214 322 389

523 610 697

174 288 402

469 583 697

193 284

80.4

77.7

75.0

7360 12,780 16,250 18,050

22,050 25,650 30,000 34,360

7900

11,330 15,560 18,020 23,130

27,630 33,030 38,430 31,500

8330 14,430 18,270 24,350

29,600 36,050 42,500 37,000

10,000 13,670 21,000 27,000

33,000 37,000 41,000

9500 17,750 26,000

32,500 37,750 43,000

13,000 15,500 22,000

18,000 14,000

197 343 436 484

591 687 804 921 212

304 417 483 620

740 885

1030

844

223 387 490 653

793 966

1139

992

268 366 563 724

884 992

1099

255 476 697

871 1012 1152

348

415

590

482

375

14,300 16,810 21,090 25,240

28,250 31,260 32,840 27,000

15,750 21,220 27,150 31,370

35,690 37,670 32,000

13,640 21,350 29,060 34,490

39,920 42,500 32,100

14,000 22,000 38,000 38,000

38,000 42,000

16,250 28,750 41,250

43,750 46,250

18,750 25,000 46,250

11,250 302

Table 6. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

14 to 35 psig /

0.97 to 2.4 bar

25 psig / 1.7 bar

±1% psia / bar

19B0432X012

Zinc

14 to 35 psig /

0.97 to 2.4 bar

30 psig / 2.1 bar

±1% psia / bar

19B0432X012

Zinc

14 to 35 psig /

0.97 to 2.4 bar

35 psig / 2.4 bar

±1% psia / bar

19B0432X012

Zinc

30 to 60 psig /

2.1 to 4.1 bar

40 psig / 2.8 bar

±1% psia / bar

19B0432X022

Green

30 to 60 psig /

2.1 to 4.1 bar

50 psig / 3.4 bar

±1% psia / bar

19B0432X022

Green

30 to 60 psig /

2.1 to 4.1 bar

60 psig / 4.1 bar

±1% psia / bar

19B0432X022

Green

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

30 40 50 60

80 100 125 150 175

40

50

60

80

100 125 150 175

40

50

60

80

100 125 150 175

50

60

80 100

125 150 175

60

80 100

125 150 175

80 100 125

150 175

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

3.4

4.1

5.5

6.9

8.6

10.3

12.1

4.1

5.5

6.9

8.6

10.3

12.1

5.5

6.9

8.6

10.3

12.1

10,630 10,200

10,630 10,600

10,630 10,900

11,400

10,750

383 451 565 676

757 838 880 724

422 569 728 841

956

1010

858

366 572 779 924

1070 1139

860

375

590 1018 1018

1018 1126

436

771 1106

1173 1240

503

670 1240

16,880 24,040 24,430 28,260

30,200 27,000

18,100 25,240 30,390 30,500

32,500 871

19,570 26,060 32,530 34,500

38,200 1024

20,000 26,000 30,000 34,000

22,500 31,250 40,000

27,500 40,000

452 644 655 757

809 724

485 676 814 817

524 698 872 925

536 697 804 911

603 838

1072

737

1072

17,700 24,090 23,500 27,400

28,500 764

19,080 22,500 28,000 32,300

20,850 22,000 29,000 33,600

20,000 22,667 28,000

25,000 32,500

32,500 871

474 646 630 734

511 603 750 866

559 590 777 900

536 607 750

670 871

16

Bulletin 71.2:299H

Table 7. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

3.5 to 6-inches w.c. / 9 to 15 mbar

3.5-inches w.c. / 9 mbar

-1 to 2-inches w.c. /

-2 to 5 mbar

T13707T0012

Black

5 to 9-inches w.c. /

12 to 22 mbar

7-inches w.c. / 17 mbar

-1 to 2-inches w.c. /

-2 to 5 mbar

T13589T0012

Yellow

7 to 20-inches w.c. /

17 to 50 mbar

14-inches w.c. / 35 mbar ±2-inches w.c. / ±5 mbar

1N3112X0012

Unpainted

16 to 40-inches w.c. /

40 to 99 mbar

28-inches w.c. / 70 mbar

±4-inches w.c. / ±10 mbar

1B413727222

Purple

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19 1 / 25 1-3/16 / 30

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

2

10 15

20 25 30 40

50 60 80

100

125 150 175

10 15

20 25 30 40

50 60 80

100

125 150 175

10 15

20 25 30 40

50 60 80

100

125 150 175

10 15 20

25 30 40 50 60

80 100 125 150 175

0.14

5

0.34

0.69

10.3

12.1

2

0.14

5

0.34

0.69

10.3

12.1

2

0.14

5

0.34

0.69

10.3

12.1

5

0.34

0.69

10.3

12.1

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

760 1200 1700 2000

2350 2700 3030 3700

4400 5100 4700 4300

4300 4300 4300

750 1300 1600 2000

2300 2600 2970 3700

4400 5100 4850 4600

4600 4600 4600

700 1100 1700 1900

2150 2400 2740 3400

4250 5100 5250 5400

5400 5900 6400

1200 1600 2000 2300

2600 2800 3200 4100 5000

6300 7600 9200

10,700 12,200

(1)

for NPS 2 / DN 50 Internal Registration

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size, Inch / mm

20.4

32.2

45.6

53.6

63.0

72.4

81.2

99.2

118 137 126 115

115 115 115

20.1

34.8

42.9

53.6

61.6

69.7

79.6

99.2

118 137 130 123

123 123 123

18.8

29.5

45.6

50.9

57.6

64.3

73.4

91.1

114 137 141 145

145 158 172

32.2

42.9

53.6

61.6

69.7

75.0

85.8 110 134

169 204 247 287 327

1560 2600 3800 4600

5300 6000 6730 8200

9700

11,200

7500 3800

4000 4000 4000

1520 2600 3800 4400

5100 5800 6600 8200

9700

11,200

7350 3500

4000 4560 5120

1430 2200 3600 4600

5300 6000 6740 8200

9700

11,200

8200 5200

5000 5700 6400

2400 3700 4400 5100

5800 6600 8200 9750

11,300

9150 7000 7000 9300

11,600

41.8

69.7 102 123

142 161 180 220

260 300 201 102

107 107 107

40.7

69.7 102 118

137 155 177 220

260 300 197

93.8

107 122 137

38.3

59.0

96.5 123

142 161 181 220

260 300 220 139

134 153 172

64.3

99.2 118 137

155 177 220 261 303

245 188 188 249 311

2700 4500 6500 8000

9250 10,500 11,500 13,500

17,000 20,500 12,750

5000

5500

6000

6500

2650

4250

6500

8000

9500 11,000 11,170 11,500

15,750 20,000 12,380

4750

5250

5750

6500

2480

4000

6500

8000

8500

9000 10,000 12,000

13,500 15,000 10,000

5000

6000

7000

4000

6500

8000

9250

10,500 11,830 14,500 16,500 18,500

12,880

7250

7380

7500 15,250

72.4 121 174 214

248 281 308 362

456 549 342 134

147 161 174

71.0 114 174 214

255 295 299 308

422 536 332 127

141 154 174

66.5 107 174 214

228 241 268 322

362 402 268 134

161 188 188

107 174 214 248

281 317 389 442 496

345 194 198 201 409

4050 8600 9500

10,600

11,400 12,200 14,630 19,500

20,000 20,500 19,600 18,700

11,150

3600

5380

8500 12,500 10,500

11,500 12,500 16,830 25,500

22,500 19,500

4500

5040

8500 12,500 11,500

12,500 13,250 14,000 19,500

25,000 22,050

5620

6000

7500 11,750 16,000 19,000

21,750 24,500 26,750 29,000 24,170

14,500 14,500 14,500 15,500

109 230 255 284

306 327 392 523

536 549 525 501

299

96.5

144 228 335 281

308 335 451 683

603 523 121 121

121 121

135 228 335 308

335 355 375 523

670 591 151 161

161 161

201 315 429 509

583 657 717 777 648

389 389 389 415

5740 11,500 14,750 18,000

19,700 20,400 21,100 20,400

19,700 14,833

5100

3500

6260 10,500 14,350 18,200

20,600 20,500 20,400 20,200

20,000 14,800

4400

2800

7440 11,800 15,850 19,900

21,000 21,150 21,300 21,150

21,000 16,330

7000

8300

9500 14,850 20,200 24,500

25,600 25,230 24,500 24,000 23,500

24,500 22,400

154 308 395 482

528 547 565 547

528 398 137

93.8

168 281 385 488

552 549 547 541

536 397 118

75.0

199 316 425 533

563 567 571 567

563 438 188 222

255 398 541 657

686 676 657 643 630

657 600

6350 12,000 17,000 15,500

16,000 17,300 18,600 21,800

25,000 12,500 12,000

6680 10,000 17,000 16,000

16,000 17,750 19,500 20,200

20,900 12,500 12,500

8460 12,400 17,000 17,000

19,100 19,750 20,400 21,650

22,900 14,100 12,400

11,400 16,850 22,300 21,800

23,900 24,130 24,600 26,000 27,200

30,000 804

170 322 456 415

429 464 498 584

670 335 322

179 268 456 429

429 476 523 541

560 335 335

227 332 456 456

512 529 547 580

614 378 332

306 452 598 584

641 647 659 697 729

- continued -

17

Bulletin 71.2:299H

Table 7. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

1 to 3.25 psig /

69 bar to 0.22 bar

2 psig / 0.14 bar

± 1% psia / bar

T13593T0012

Light Blue

2.75 to 6 psig /

0.19 to 0.41 bar

5 psig / 0.34 bar

±1 % psig / bar

T13671T0012

Orange

5 to 16 psig /

0.34 to 1.1 bar

10 psig / 0.69 bar

± 1% psia / bar

T13600T0012

Red

5 to 16 psig /

0.34 to 1.1 bar

15 psig / 10 bar

± 1% psia / bar

T13600T0012

Red

14 to 35 psig /

0.97 to 2.4 bar

20 psig / 14 bar

± 1% psia / bar

19B0432X012

Zinc

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

5

0.34

10

0.69

100

125 150 175

100

125 150 175

100

125 150 175

100 125 150 175

15

20 25 30 40

50 60 80

10 15

20 25 30 40

50 60 80

15 20 25 30 40

50 60 80

20 25 30 40 50 60

80

25 30 40 50 60

80

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

(1)

for NPS 2 / DN 50 Internal Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size Inch / mm

1/4 x 3/8 / 6.4 x 9.5 3/8 / 95 1/2 / 13 3/4 / 19 1 / 25 1-3 / 16/30

1020

27.3 1550 1920

2240 2670 2890 3530

4180 4820 6110 7400

8170 8450

12,400

1390 1870

2240 2570 2890 3530

4180 4820 6110 7400

9020

10,630 11,800

1580 2130 2540 2890 3530

4180 4820 6110 7400

9020

10,630 11,200

1750 2360 2820 3540 4180 4820

6110 7400 9020

10,630 11,800

1920 2580 3480 4180 4820

6110 7400 9020

10,630 11,600

41.5

51.4

60.0

71.5

77.4

94.6

112 129 164 198

219 226 332

37.2

50.1

60.0

68.9

77.4

94.6

112 129 164 198

242 285 316

42.3

57.1

68.1

77.4

94.6

112 129 164 198

242 285 300

46.9

63.2

75.6

94.9

112 129

164 198 242 285 316

51.4

69.1

93.3

112 129

164 198 242 285 311

2100 3340 4360

5150 5890 6640 8120

9600 11,090 14,050 17,020

12,360 13,750

7100

2910

4190

5090

5890

6640

8120

9600 11,090 14,050 17,020

20,730 17,170 15,400

3280

4720

5740

6580

8120

9600 11,090 14,050 17,020

20,730 20,590 18,100

3620

5220

6290

8070

9600 11,090

14,050 17,020 20,730 24,440 27,400

3930

5680

7830

9550 11,090

14,050 17,020 20,730 24,440 26,300

56.4

89.5 117

138 158 178 218

257 297 377 456

331 369 190

78.0 112

136 158 178 218

257 297 377 456

556 460 413

87.9 126 154 176 218

257 297 377 456

556 552 485

97.0 140 169 216 257 297

377 456 556 655 734

105 152 210 256 297

377 456 556 655 705

3640 5840 7580

8960 10,250 11,540 14,120

16,700 19,280 24,440 29,840

17,520 18,580 20,000

5050

7280

8850 10,250 11,540 14,120

16,700 19,280 24,440 29,600

36,050 26,560 21,500

5690

8210

9940 11,440 14,120

16,700 19,280 24,440 29,600

36,050 34,530 25,000

6290

9070 10,940 14,020 16,700 19,280

24,440 29,600 36,050 42,500 48,000

6840

9870 13,610 16,610 19,280

24,440 29,600 36,050 42,500 47,000

97.5 157 203

240 275 309 378

448 517 655 800

470 498 536

135 195

237 275 309 378

448 517 655 793

966 712 576

152 220 266 307 378

448 517 655 793

966 925 670

169 243 293 376 448 517

655 793 966

1139 1286

183 265 365 445 517

655 793 966

1139 1260

7440 12,040 15,990

19,250 22,030 27,800 27,070

28,970 25,770 25,500 14,260

13,260 17,000

10,350 15,150

18,640 21,260 24,340 27,670

30,570 29,390 31,410 22,150

21,590 17,000

11,640 17,000 20,790 24,150 28,660

33,230 35,410 41,270 35,310

35,740 22,000

12,830 18,700 22,790 29,650 35,890 41,440

51,120 48,470 49,780 60,000

13,930 20,280 28,440 35,140 41,440

51,240 52,260 56,710 65,000

199 323 429

516 590 745 725

776 691 683 382

355 456

277 406

500 570 652 742

819 788 842 594

579 456

312 456 557 647 768

891 949

1106

946

958 590

344 501 611 795 962

1111

1370 1299 1334 1608

373 544 762 942

1111

1373 1401 1520 1742

10,980 15,460 20,900

22,470 24,000 24,860 25,640

26,390 26,000 12,800 28,300

13,200 21,850

21,350 24,540 26,500 28,300

29870 30,390 28,000 32,000

15,420 19,500 25,440 29,250 32,780

35,680 37,700 38,000 35,000

17,640 26,350 31,990 37,270 41,490 45,020

49,000 46,000

20,800 30,630 33,040 41,800 47,530

41,800 41,800

294 414 560

602 643 666 687

707 697 343 758

354 586

572 658 710 758

801 814 750 858

413 523 682 784 879

956 1010 1018

938

473

706

857

999 1112 1207

1313 1233

557

821

885 1120 1274

1120 1120

13,800 17,710 20,670

21,620 22,410 24,170 26,160

26,900 29,000 30,000

16,070 21,370

21,390 22,740 25,870 28,930

30,000 31,000 34,000

18,340 21,000 23,290 28,700 33,540

33,100 33,100 37,000

20,640 23,850 31,540 38,150 43,000 39,000

43,000 1152

21,940 32,630 35,700 40,520 40,520

41,000 1099

370 475 554

579 601 648 701

721 777 804

431 573

573 609 693 775

804 831 911

492 563 624 769 899

887 887 992

553 639

845 1022 1152 1045

588

874

957 1086 1086

18

- continued -

Bulletin 71.2:299H

Table 7. Types 299H and 299HR Flow Capacities

OUTLET PRESSURE

RANGE, SETTING,

ACCURACY, SPRING PART

NUMBER AND COLOR

14 to 35 psig /

0.97 to 2.4 bar

25 psig / 1.7 bar

±1% psia / bar

19B0432X012

Zinc

14 to 35 psig /

0.97 to 2.4 bar

30 psig / 2.1 bar

±1% psia / bar

19B0432X012

Zinc

14 to 35 psig /

0.97 to 2.4 bar

35 psig / 2.4 bar

±1% psia / bar

19B0432X012

Zinc

30 to 60 psig /

2.1 to 4.1 bar

40 psig / 2.8 bar

±1% psia / bar

19B0432X022

Green

30 to 60 psig /

2.1 to 4.1 bar

50 psig / 3.4 bar

±1% psia / bar

19B0432X022

Green

30 to 60 psig /

2.1 to 4.1 bar

60 psig / 4.1 bar

±1% psia / bar

19B0432X022

Green

1. Downstream piping may affect actual capacity. It may be necessary to use enlarged downstream piping to obtain published capacities.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

30 40 50 60

80 100 125 150 175

40

50

60

80

100 125 150 175

40

50

60

80

100 125 150 175

50

60

80 100

125 150 175

60

80 100

125 150 175

80 100 125

150 175

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

3.4

4.1

5.5

6.9

8.6

10.3

12.1

4.1

5.5

6.9

8.6

10.3

12.1

5.5

6.9

8.6

10.3

12.1

(1)

for NPS 2 / DN 50 Internal Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

Orice Size, Inch / mm

1/4 x 3/8 / 6.4

x 9.5

2070 3320 4140 4830

6110 7400

9020 10,630 11,000

2980

4020

4800

6110

7400

9020 10,630 10,200

2350

3770

4700

6120

7400

9020 10,630 11,200

1600

2800

5200

7600

8200

9800 11,400

3400

5800

6200

8400

9600 10,800

2800

3600

2800

4600

6400

55.5

89.0 111 129

164 198 242 285 295

79.9 108 129 164

198 242 285 273

63.0 101 126 164

198 242 285 300

42.9

75.0 139 204

220 263 306

91.1 155 166

225 257 289

75.0

96.5

75.0

123 172

3/8 / 9.5 1/2 / 13 3/4 / 19 1 / 25 1-3/16 / 30

4230

113 7350 9340

11,030

14,050 17,020 20,730 24,440 26,500

6520 8950

10,850 14,050

17,020 20,730 24,440 25,000

4790 8300

10,510 14,000

17,020 20,730 24,440 25,500

6500 8170

11,500 13,500

19,000 22,750 26,500

7000

11,000 15,000

19,500 23,000 26,500

3500 9500

15,000

11,000

7000

197

250

296

377

456

556

655

710

175

240

291

377

456

556

655

670

128

222

282

375

456

556

655

683

174

219

308

362

509

610

710

188

295

402

523

616

710

93.8 255 402

295 188

7360 12,780 16,250 19,190

24,440 29,600 36,050 42,500 46,000

11,330 15,560 18,870 24,440

29,600 36,050 42,500 48,000

8330 14,430 18,270 24,350

29,600 36,050 42,500 49,000

9000 17,000 23,000 29,000

35,000 42,000 47,000

10,000 21,000 26,000

35,000 42,000 49,000

17,000 23,000 22,000

18,000 18,000

197 343 436 514

655 793

966 1139 1233

304

417

506

655

793

966 1139 1286

223

387

490

653

793

966 1139 1313

241

456

616

777

938 1126 1260

268

563

697

938 1126 1313

456

616

590

482

14,980 23,420 34,040 40,630

51,360 56,050 63,640 77,000

23,190 32,300 39,600 51,480

59,840 70,570 84,000

16,920 29,690 38,050 51,600

63,630 77,500 87,000

20,000 33,000 48,000 31,000

76,000 91,000

21,000 45,000 59,000

77,000 89,000

36,000 50,000 69,000

89,000 2385

401 628 912

1089

1376 1502 1706 2064

621

866 1061 1380

1604 1891 2251

453

796 1020 1383

1705 2077 2332

536

884 1286

831

2037 2439

563 1206 1581

2064 2385

965 1340 1849

22,310 40,220 42,110 50,050

62,000 60,000

24,580 42,430 52,560 72,000

76,000 2037

20,350 42,740 55,080 70,000

76,000 2037

28,000 48,000 66,000 76,000

32,000 69,000 88,000

52,000 64,000 90,000

598 1078 1129 1341

1662 1608

659 1137 1409 1930

545 1145 1476 1876

750 1286 1769 2037

858 1849 2358

1394 1715 2412

23,270 33,260 50,000 54,000

60,000 1608

30,810 50,000 54,000 72,000

28,360 48,000 60,000 74,000

34,000 52,000 68,000

45,000 74,000

53,000 1420

624

891 1340 1447

826 1340 1447 1930

760 1286 1608 1983

911 1394 1822

1206 1983

19

Bulletin 71.2:299H

Table 8. Types 299HS and 299HSR Flow Capacities

OUTLET PRESSURE

RANGE AND SETTING,

CONTROL SPRING PART

NUMBER AND COLOR

3.5 to 6 inches w.c. / 9 to 15 mbar

3.5 inches w.c. / 9 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13707T0012

Black

5 to 9 inches w.c. /

12 to 22 mbar

7 inches w.c. / 17 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13589T0012

Yellow

7 to 20 inches w.c. /

17 to 50 mbar

14 inches w.c. /

35 mbar

±2 inches w.c. / ±5 mbar

1N3112X0012

Unpainted

16 to 40 inches w.c. /

40 to 99 mbar

28 inches w.c. /

70 mbar

±4 inches w.c. / ±10 mbar

1B413727222

Purple

1. Capacities are limited to 15,000 SCFH / 402 Nm³/h when the Type VSX-2 is used without a control line.

2. Due to slam-shut properties, capacities cannot be calculated with critical ow equation.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

2 5

5

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

(1)(2)

for 1-1/2 NPT and NPS 2 / DN 50 External/Dual Registration

CAPACITIES IN SCFH/ Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19

750 1150 1580 1910 2230 2560

2880 3520 4170 4810 6100

7390 9010

10,620 12,230

730 1150 1580 1910 2230 2560

2880 3520 4170 4810 6100

7390 9010

10,620 12,230

690 1130 1570 1910 2230 2560

2880 3520 4170 4810 6100

7390 9010

10,620 12,230

1100 1560 1910 2230 2560

2880 3520 4170 4810 6100

7390 9010

10,620 12,230

20.1

30.8

42.3

51.2

59.8

68.6

77.2

94.3 112 129 163

198 241 285 328

19.6

30.8

42.3

51.2

59.8

68.6

77.2

94.3 112 129 163

198 241 285 328

18.5

30.3

42.1

51.2

59.8

68.6

77.2

94.3 112 129 163

198 241 285 328

29.5

41.8

51.2

59.8

68.6

77.2

94.3 112 129 163

198 241 285 328

1540 2440 3570 4400 5140 5880

6630 8110

9590 11,080 14,040

17,010 20,720 24,430 28,140

1490

2420

3570

4400

5140

5880

6630

8110

9590 11,080 14,040

17,010 20,720 24,430 28,140

1410

2390

3550

4400

5140

5880

6630

8110

9590 11,080 14,040

17,010 20,720 24,430 28,140

2310

3420

4400

5140

5880

6630

8110

9590 11,080 14,040

17,010 20,720 24,430 28,140

Orice Size, Inch / mm

41.3

65.4

95.7 118 138 158

178 217 257 297 376

456 555 655 754

39.9

64.9

95.7 118 138 158

178 217 257 297 376

456 555 655 754

37.8

64.1

95.1 118 138 158

178 217 257 297 376

456 555 655 754

61.9

91.7 118 138 158

178 217 257 297 376

456 555 655 754

1960 3230 4970 6890 8050 9210

10,370 12,700 15,020 17,340 21,980

26,630 32,430 38,240 44,040

1900 3190 4950 6890 8050 9210

10,370 12,700 15,020 17,340 21,980

26,630 32,430 38,240 44,040

1790 3130 4920 6890 8050 9210

10,370 12,700 15,020 17,340 21,980

26,630 32,430 38,240 44,040

3010 4680 6890 8050 9210

10,370 12,700 15,020 17,340 21,980

26,630 32,430 38,240 44,040

52.5

86.6 133 185 216 247

278 340 403 465 589

714 869

1025 1180

50.9

85.5 133 185 216 247

278 340 403 465 589

714 869

1025 1180

48.0

83.9 132 185 216 244

278 340 403 465 589

714 869

1025 1180

80.7 125 185 216 247

278 340 403 465 589

714 869

1025 1180

4750

7760 11,660 15,890 18,570 21,250

23,930 29,280 34,630 39,990 50,690

61,400 74,780 88,170

4610

7690 11,620 15,890 18,570 21,250

23,930 29,280 34,630 39,990 50,690

61,400 74,780 88,170

4340

7550 11,540 15,890 18,570 21,250

23,930 29,280 34,630 39,990 50,690

61,400 74,780 88,170

7260 11,180 14,680 18,570 21,250

23,930 29,280 34,630 39,990 50,690

61,400 74,780 88,170

127 208 312 426 498 570

641 785

928 1072 1358

1646 2004 2363

124

206

311

426

498

570

641

785

928 1072 1358

1646 2004 2363

116

202

309

426

498

570

641

785

928 1072 1358

1646 2004 2363

195

300

393

498

570

641

785

928 1072 1358

1646 2004 2363

20

- continued -

Bulletin 71.2:299H

Table 8. Types 299HS and 299HSR Flow Capacities

OUTLET PRESSURE

RANGE AND SETTING,

CONTROL SPRING PART

NUMBER AND COLOR

1 to 3.25 psig /

69 mbar to 0.22 bar

2 psig / 0.14 bar

±1% psia / bar

T13593T0012

Light blue

2.75 to 6 psig /

0.19 to 0.41 bar

5 psig / 0.34 bar

±1% psia / bar

T13671T0012

Orange

5 to 16 psig /

0.34 to 1.1 bar

10 psig / 0.69 bar

±1% psia / bar

T13600T0012

Red

5 to 16 psig /

0.34 to 1.1 bar

15 psig / 1.0 bar

±1% psia / bar

T13600T0012

Red

1. Capacities are limited to 15,000 SCFH / 402 Nm³/h when the Type VSX-2 is used without a control line.

2. Due to slam-shut properties, capacities cannot be calculated with critical ow equation.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

15 20 25 30

40 50 60 80

100 125 150 175

20 25 30

40 50 60 80

100 125 150 175

5

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

(1)(2)

for 1-1/2 NPT and NPS 2 / DN 50 External/Dual Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19

1010 1540 1910 2230 2560

2880 3520 4170 4810 6100

7390

9010 10,620 12,230

1380

1860

2230

2560

2880

3520

4170

4810

6100

7390

9010 10,620 12,230

1570

2120

2530

2880

3520

4170

4810

6100

7390

9010 10,620 12,230

1740

2350

2810

3520

4170

4810

6100

7390

9010 10,620 12,230

27.1

41.3

51.2

59.8

68.6

77.2

94.3 112 129 163

198 241 285 328

37.0

49.8

59.8

68.6

77.2

94.3 112 129 163

198 241 285 328

42.1

56.8

67.8

77.2

94.3 112 129 163

198 241 285 328

46.6

63.0

75.3

94.3 112 129 163

198 241 285 328

2090 3330 4350 5140 5880

6630 8110

9590 11,080 14,040

17,010 20,720 24,430 28,140

2890

4180

5080

5880

6630

8110

9590 11,080 14,040

17,010 20,720 24,430 28,140

3270

4710

5700

6630

8110

9590 11,080 14,040

17,010 20,720 24,430 28,140

3610

5210

6280

8110

9590 11,080 14,040

17,010 20,720 24,430 28,140

Orice Size, Inch / mm

56.0

89.2 117 138 158

178 217 257 297 376

456 555 655 754

77.5 112 136 158

178 217 257 297 376

456 555 655 754

87.6 126 153 178

217 257 297 376

456 555 655 754

96.7 139 168

217 257 297 376

456 555 655 754

2690 4500 6160 8050 9210

10,370 12,700 15,020 17,340 21,980

26,630 32,430 38,240 44,040

3780 5690 7170 9210

10,370 12,700 15,020 17,340 21,980

26,630 32,430 38,240 44,040

4220 6310 7890

10,370

12,700 15,020 17,340 21,980

26,630 32,430 38,240 44,040

4640 6890 8560

12,700 15,020 17,340 21,980

26,630 32,430 38,240 44,040

72.1 121 165 216 247

278 340 403 465 589

714 869

1024 1180

101 152 192 247

278 340 403 465 589

714 869

1024 1180

113 169 211 278

340 403 465 589

714 869

1025 1180

124 185 229

340 403 464 589

714 869

1025 1180

6500 10,780 14,420 18,570 21,250

23,930 29,280 34,630 39,990 50,690

61,400 74,780 88,170

9110 13,370 16,790 21,250

23,930 29,280 34,630 39,990 50,690

61,400 74,780 88,170

10,200 14,850 18,510 21,820

29,280 34,630 39,990 50,690

61,400 74,780 88,170

11,210 16,220 20,110

26,850 34,630 39,990 50,690

61,400 74,780 88,170

174 289 386 498 570

641 785

928 1072 1358

1646 2004 2363

244

358

450

570

641

785

928 1072 1358

1646 2004 2363

273

398

496

585

785

928 1072 1358

1646 2004 2363

300

435

539

720

928 1072 1358

1646 2004 2363

21

Bulletin 71.2:299H

Table 9. Types 299HS and 299HSR Flow Capacities

OUTLET PRESSURE

RANGE AND SETTING,

CONTROL SPRING PART

NUMBER AND COLOR

3.5 to 6 inches w.c. / 9 to 15 mbar

3.5 inches w.c. / 9 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13707T0012

Black

5 to 9 inches w.c. /

12 to 22 mbar

7 inches w.c. / 17 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13589T0012

Yellow

7 to 20 inches w.c. /

17 to 50 mbar

14 inches w.c. / 35 mbar ±2 inches w.c. / ±5 mbar

1N3112X0012

Unpainted

16 to 40 inches w.c. /

40 to 99 mbar

28 inches w.c. / 70 mbar

±4 inches w.c. / ±10 mbar

1B413727222

Purple

1. Capacities are limited to 15,000 SCFH / 402 Nm³/h when the Type VSX-2 is used without a control line.

2. Due to slam-shut properties, capacities cannot be calculated with critical ow equation.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

2 5

5

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

(1)(2)

for 1-1/2 NPT and NPS 2 / DN 50 Internal Registration

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19

760 1160 1590 1920 2240 2570

2890 3530 3880 4090 3110

4790 5210 5640 7310

750 1120 1590 1920 2240 2570

2890 3530 4180 4820 4020

4670 5070 5480 6430

700 1110 1580 1920 2240 2570

2890 3530 4180 4820 4600

4970 5200 5430 4700

1110 1570 1920 2240 2570

2890 3530 4180 4820 6110

6360 6450 6540 2950

20.4

31.1

42.6

51.5

60.0

68.9

77.5

94.6 104 110

83.3

128 140 151 196

20.1

30.0

42.6

51.5

60.0

68.9

77.5

94.6 112 129 108

125 136 147 172

18.8

29.7

42.3

51.5

60.0

68.9

77.5

94.6 112 129 123

133 139 146 126

29.7

42.1

51.5

60.0

68.9

77.5

94.6 112 129 164

170 173 175

79.1

1780 2450 3560 4400 5100 5450

5800 7550 9300 7700 2800

3600 3600 3600 5680

1890 2460 3400 4320 5060 5800

6500 7900 7800 6560 2620

3420 3600 3870 5120

1420 2200 3500 4300 5000 5700

6500 7900 9300 7490 2730

3900 3900 3900 3900

2600 3500 4400 5100 5800

6500 7900 9300 8250 4260

5150 5930 6110 3560

Orice Size, Inch / mm

47.7

65.7

95.4 118 137 146

155 202 249 206

75.0

96.5

96.5 152

50.7

65.9

91.1 116 136 155

174 212 209 176

70.2

91.7

96.5 104 137

38.1

59.0

93.8 115 134 153

174 212 249 201

73.2

105 105 105 105

69.7

93.8 118 137 155

174 212 249 221 114

138 159 164

95.4

2800 4000 6000 7500 9000 7620

9880 12,070 11,300

6660

1230

2990

4090

5210

7300

2800

4000

6000

7000

9000

9690

10,480 11,490 10,280

7170

1200

2990

5180

7300

3440

4000

6000

7600

9000 10,000

11,200 11,620 12,400 12,090

2030

4410

5990

6310

3600

6000

7200

8800 10,000

11,600 13,570 13,920 14,410

3090

4850

5290

5570

3320

75.0 107 161 201 241 204

265 323 303 178

33.0

80.1 110 140 196

75.0 107 161 188 241 260

281 308 276 192

32.2

80.1 139 139 196

92.2 107 161 204 241 268

300 311 332 324

54.4

118 161 161 169

96.5 161 193 236 268

311 364 373 386

82.8

130 142 149

89.0

6460 7140 7140 8320

10,830

9870

9870 6400 6840 7010 9000

4650 3230 3230

5520 6020 6520 8000 7930 7420

7050 4900 5940 6310 8340

3900 3360 2340

4790 6080 7440 9250

10,670

8950

8450 6800 7240 7400 7420

4970 4330 3120

5200 6910

9370 11,030 11,390

11,980 11,220 10,020

9170 11,320

3750

3960

2520

173 191 191 223 290 265

265 172 183 188 241

125

86.6

148 161 175 214 213 199

189 131 159 169 224

105

90.0

62.7

128 163 199 248 286 240

226 182 194 198 199

133 116

83.6

139 185 251 296 305

321 301 269 246 303

101 106

67.5

22

- continued -

Bulletin 71.2:299H

Table 9. Types 299HS and 299HSR Flow Capacities

OUTLET PRESSURE

RANGE AND SETTING,

CONTROL SPRING PART

NUMBER AND COLOR

1 to 3.25 psig /

69 mbar to 0.22 bar

2 psig / 0.14 bar

±1% psia / bar

T13593T0012

Light blue

2.75 to 6 psig /

0.19 to 0.41 bar

5 psig / 0.34 bar

±1% psia / bar

T13671T0012

Orange

5 to 16 psig /

0.34 to 1.1 bar

10 psig / 0.69 bar

±1% psia / bar

T13600T0012

Red

5 to 16 psig /

0.34 to 1.1 bar

15 psig / 1.0 bar

±1% psia / bar

T13600T0012

Red

1. Capacities are limited to 15,000 SCFH / 402 Nm³/h when the Type VSX-2 is used without a control line.

2. Due to slam-shut properties, capacities cannot be calculated with critical ow equation.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

15 20 25

30 40 50 60 80

100 125 150 175

20 25 30

40 50 60 80

100 125 150 175

5

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

(1)(2)

for 1-1/2 NPT and NPS 2 / DN 50 Internal Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19

1020 1550 1920 2240 2570

2890 3530 4180 4820 6110

6850 7070 7300 4560

1390 1870 2240 2570

2890 3530 4180 4790 5740

6680 7170 7650 4400

1800 2200 2600

3000 3650 4300 4950 6250

7600 9300 6320 5810

1900 2450 3000

3700 4320 4950 6200

7350 8800

10,220

7300

27.3

41.5

51.5

60.0

68.9

77.5

94.6 112 129 164

184 189 196 122

37.3

50.1

60.0

68.9

77.5

94.6 112 128 154

179 192 205 118

48.2

59.0

69.7

80.4

97.8 115 133 168

204 249 169 156

50.9

65.7

80.4

99.2 116 133 166

197 236 274 196

2900 3600 4300 5000 5550

6100 7750 9400

10,530

8580

3290 3050 3200 5540

2800 3750 4700 5700

6430 7900

9300 10,700 13,350

16,000

4740

3530

3200

4300

5400

6600

7800

9000 10,460 13,400

16,110 19,500

4960

3270

3400

4550

5700

7600

8900 10,330 13,200

16,000 19,500 22,950

6500

Orice Size, Inch / mm

77.7

96.5 115 134 149

163 208 252 282 230

88.2

81.7

85.8 148

75.0 101 126 153

172 212 249 287 358

429 127

94.6

85.8 115 145

177 209 241 280 359

432 553 133

87.6

91.1 122 153

204 239 277 354

429 523 615 174

4000 5500 7500 8500

10,000

11,000 14,000 14,380 15,510 12,000

1130 2220 2090 2090

5000 7000 8500 9500

11,000 13,000 16,000 15,200 13,170

2430 1700 1910 3050

4000

12,000

9000

10,000 13,000 16,000 16,050 15,950

15,030 16,250

1970 1970

6000 8000

10,000

13,000 15,000 16,900 18,730

21,260 23,920 25,900

5910

107 147 201 228 268

295 375 385 416 322

30.3

59.5

56.0

134 188 228 255

295 348 429 407 353

65.1

45.6

51.2

81.7

107 322 241

268 348 429 430 427

403 436

52.8

161 214 268

348 402 453 502

570 641 694 158

5660

7840 10,210 12,100 11,880

12,800 13,960 10,940

9810

3700

2910

6540

9680 11,480 12,420

13,050 15,780 15,110 10,710

8670

7300

6470

7250

9870 12,240

13,490 17,230 18,520 20,460 10,780

11,250 11,250

6590

8860 10,900 13,870

19,100 20,300 20,660 21,940

16,310 13,970 10,600

152 210 273 324 318

343 374 293 263

99.2

78.0

175 259 308 333

350 423 405 287 232

232 196 173

194 265 328

362 462 496 548 289

302 302 177

237 292 372

512 544 554 588

437 374 284

23

Bulletin 71.2:299H

Table 10. Types 299HS and 299HSR Flow Capacities

OUTLET PRESSURE

RANGE AND SETTING,

CONTROL SPRING PART

NUMBER AND COLOR

3.5 to 6 inches w.c. / 9 to 15 mbar

3.5 inches w.c. / 9 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13707T0012

Black

5 to 9 inches w.c. /

12 to 22 mbar

7 inches w.c. / 17 mbar

-1 to 2 inches w.c. /

-2 to 5 mbar

T13589T0012

Yellow

7 to 20 inches w.c. /

17 to 50 mbar

14 inches w.c. /

35 mbar

±2 inches w.c. /

±5 mbar

1N3112X0012

Unpainted

16 to 4 inches w.c. /

40 to 99 mbar

28 inches w.c. /

70 mbar

±4 inches w.c. /

±10 mbar

1B413727222

Purple

1. Capacities are limited to 15,000 SCFH / 402 Nm³/h when the Type VSX-2 is used without a control line.

2. Due to slam-shut properties, capacities cannot be calculated with critical ow equation.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

2 5

5

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.14

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

(1)(2)

for 2 NPT Internal Registration

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19

760 1160 1590 1920 2240 2570

2890 3530 3880 4090 3110

4790 5210 5620 5620

750 1120 1590 1920 2240 2570

2890 3530 4180 4180 4020

4670 5070 5480 5480

700 1110 1580 1920 2240 2570

2890 3530 4180 4820 4600

4970 5200 5430 5430

1110 1570 1920 2240 2570

2890 3530 4180 4820 6110

6360 6450 6540 6540

20.4

31.1

42.6

51.5

60.0

68.9

77.5

94.6 104 110

83.3

128 140 151 151

20.1

30.0

42.6

51.5

60.0

68.9

77.5

94.6 112 112 108

125 136 147 147

18.8

29.7

42.3

51.5

60.0

68.9

77.5

94.6 112 129 123

133 139 146 146

29.7

42.1

51.5

60.0

68.9

77.5

94.6 112 129 164

170 173 175 175

1780 2450 3560 4400 5100 5450

5800 7550 9300 7700 4500

4500 4500 4500 4500

1890 2460 3400 4320 5060 5800

6500 7900 7800 6560 4100

4270 4500 4850 5200

1420 2200 3500 4300 5000 5700

6500 7900 9300 7630 4300

4430 4600 4850 5100

2600 3500 4400 5100 5800

6500 7900 9300 8400 6600

6910 7300 7700 8100

Orice Size, Inch / mm

47.7

65.7

95.4 118 137 146

155 202 249 206 121

121 121 121 121

50.7

65.9

91.1 116 136 155

174 212 209 176 110

114 121 130 139

38.1

59.0

93.8 115 134 153

174 212 249 204 115

119 123 130 137

69.7

93.8 118 137 155

174 212 249 225 177

185 196 206 217

2800 4000 6000 7500 9000 8000

11,000 14,000 16,500 12,000

3500

3750 5120 6500 6500

2800 4000 6000 7000 9000

10,000

11,250 13,000 14,500 12,250

3250

3750 6500 6500 6500

3440 4000 6000 7600 9000

10,000

11,200 12,800 16,400 18,800

5000

5000 6800 6800 6800

3600 6000 7200 8800

10,000

11,600 14,000 16,400 19,000

6500

6500 6500 7000 7000

75.0 107 161 201 241 214

295 375 442 322

93.8

101 137 174 174

75.0 107 161 188 241 268

302 348 389 328

87.1

101 174 174 174

92.2 107 161 204 241 268

300 343 440 504 134

134 182 182 182

96.5 161 193 236 268

311 375 440 509 174

174 174 188 188

6460 7600

9500 12,400 17,500 17,000

17,000 13,000 13,000 12,400 11,600

6000

4400

5520

7200 10,000 13,600 14,000 15,000

16,000 10,400 10,400 10,400 10,400

5200

4400

4800

7200 11,200 15,200 18,000 17,200

18,200 14,400 14,400 14,000

8400

6000

6500 10,000 14,500 17,500 20,000

23,500 22,500 20,000 16,500 16,500

7000

173 204 255 332 469 456

456 348 348 332 311

161 118 118

148 193 268 364 375 402

429 279 279 279 279

139 118 118

129 193 300 407 482 461

488 386 386 375 225

161 161 161

174 268 389 469 536

630 603 536 442 442

188 188 188

24

- continued -

Bulletin 71.2:299H

Table 10. Types 299HS and 299HSR Flow Capacities

OUTLET PRESSURE

RANGE AND SETTING,

CONTROL SPRING, PART

NUMBER AND COLOR

1 to 3.25 psig /

69 mbar to 0.22 bar

2 psig / 0.14 bar

±1% psia / bar

T13593T0012

Light blue

2.75 to 6 psig /

0.19 to 0.41 bar

5 psig / 0.34 bar

±1% psia / bar

T13671T0012

Orange

5 to 16 psig /

0.34 to 1.1 bar

10 psig / 0.69 bar

±1% psia / bar

T13600T0012

Red

5 to 16 psig /

0.34 to 1.1 bar

15 psig / 1.0 bar

±1% psia / bar

T13600T0012

Red

1. Capacities are limited to 15,000 SCFH / 402 Nm³/h when the Type VSX-2 is used without a control line.

2. Due to slam-shut properties, capacities cannot be calculated with critical ow equation.

- Blank areas indicate where maximum operating inlet pressure for a given orice size is exceeded.

INLET PRESSURE

psig bar SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h SCFH Nm3/h

10 15 20 25

30 40 50 60 80

100 125 150 175

10 15 20 25

30 40 50 60 80

100 125 150 175

15 20 25 30

40 50 60 80

100 125 150 175

20 25 30

40 50 60 80

100 125 150 175

5

0.34

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

0.69

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.0

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

1.4

1.7

2.1

2.8

3.4

4.1

5.5

6.9

8.6

10.3

12.1

(1)(2)

for 2 NPT Internal Registration (continued)

CAPACITIES IN SCFH / Nm3/h OF 0.6 SPECIFIC GRAVITY NATURAL GAS

1/4 x 3/8 / 6.4 x 9.5 3/8 / 9.5 1/2 / 13 3/4 / 19

1020 1550 1920 2240 2670

2890 3530 4180 4820 6110

6850 7070 7300 7300

1390 1870 2240 2570

2890 3530 4180 4790 5740

6680 7170 7650 7650

1800 2200 2600 3000

3650 4300 4950 6250

7600 9300 9900

10,500

1900 2450 3000

3700 4320 4950 6200

7350

8800 10,220 11,650

27.3

41.5

51.5

60.0

71.6

77.5

94.6 112 129 164

184 189 196 196

37.3

50.1

60.0

68.9

77.5

94.6 112 128 154

179 192 205 205

48.2

59.0

69.7

80.4

97.8 115 133 168

204 249 265 281

50.9

65.7

80.4

99.2 116 133 166

197 236 274 312

2900 3600 4300 5000 5550

6100 7750

9400 10,730 13,400

10,770

7500

2800

3750

4700

5700

6430

7900

9300 10,700 13,350

16,000 12,800

9600

3200

4300

5400

6600

7800

9000 10,460 13,400

16,110 19,500 15,050 10,600

3400

4550

5700

7600

8900 10,330 13,200

16,000 19,500 22,950 26,400

Orice Size, Inch / mm

77.7

96.5 115 134 149

163 208 252 288 359

289 201 201 201

75.0 101 126 153

172 212 249 287 358

429 343 257 257

85.8 115 145 177

209 241 280 359

432 523 403 284

91.1 122 153

204 239 277 354

429 523 615 708

4000 5500 7500 8500

10,000

11,000 14,000 16,000 19,000 24,000

6500 7500 7500 7500

5000 7000 8500 9500

11,000 13,000 16,000 18,000 23,000

8000 8000 8000 8000

4000

12,000

9000

10,000

13,000 16,000 18,000 23,000

29,000 35,000 10,000 10,000

6000 8000

10,000

13,000 15,000 18,000 23,000

29,000 36,000 40,000 40,000

107 147 201 228 268

295 375 429 509 643

174 201 201 201

134 188 228 255

295 348 429 482 616

214 214 214 214

107 322 241 268

348 429 482 616

777 938 268 268

161 214 268

348 402 482 616

777

965 1072 1072

6000 10,500 14,500 18,000 20,000

24,000 28,000 23,000 18,000

8000

9500

8000 13,000 17,000 20,000

23,000 29,000 30,000 20,000 20,000

20,000 20,000 20,000

8500 14,000 19,000 22,000

28,000 34,000 39,000 25,000

25,000 25,000 25,000

10,000 15,000 20,000

28,000 35,000 40,000 51,000

35,000 30,000 30,000

161 281 389 482 536

643 750 616 482 214

214 214 255

214 348 456 536

616 777 804 536 536

536 536 536

228 375 509 590

750 911

1045

670

670 670 670

268 402 536

750

938 1072 1367

938

804

25

Bulletin 71.2:299H

4.9 / 124

1/4 NPT VENT

3/4 NPT CONTROL LINE CONNECTION

3/4 NPT ALTERNATE CONTROL LINE CONNECTION

A7274

5.8 / 147

Figure 8. Types 299H and 299HR Dimensions

Table 12. Types 299H and 299HR Dimensions

DIMENSION

A 6.12 155 7.50 199 10.00 254 10.00 254 10.50 267 9.06 230

1. Available in Cast iron only.

2. Available in Ductile iron only.

NPT CL125 FF

Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm

4.9 / 124

3.1 / 79

TYPE P590

8.6 / 218

12.1 / 307

13.7 / 348

END CONNECTION STYLE AND FACE-TO-FACE DIMENSION

(1)

FILTER OPTION

TYPE 67CF FILTERED

PILOT SUPPLY

REGULATOR OPTION

CL125 FF CL150 RF CL250 RF

9.0 / 229

A

4.3 / 109

(2)

A

(BODY LENGTH)

7.9 / 201

PN 10 or 16

(2)

4.3 / 109

6.7 / 170

1/4 NPT VENT

3/4 NPT

CONTROL LINE

CONNECTION

ALTERNATIVE

CONTROL LINE

CONNECTION

T14021

3/4 NPT

5.8 / 147

8.6 / 218

12.1 / 307

13.7 /

TYPE P590 FILTER OPTION

348

FILTERED PILOT SUPPLY

REGULATOR OPTION

TYPE 67CF

9.0 / 229

Figure 9. Types 299HS and 299HSR Dimensions

Table 13. Types 299HS and 299HSR Dimensions

DIMENSION

1-1/2 NPT 2 NPT NPS 2 / DN 50 CL125 FF NPS 2 / DN 50 CL250 RF NPS 2 / DN 50 PN 10/16 RF

Inch mm Inch mm Inch mm Inch mm Inch mm

A 6.12 / 155 6.12 / 155 10.00 / 254 10.50 / 267 9.06 / 230

BODY SIZE AND END CONNECTION

7.9 / 201

INCH / mm

26

POSITION 1 POSITION 2

Figure 10. Body and Vent Positions

Ordering Information

POSITION 3 POSITION 4

(STANDARD)

POSITION F

Bulletin 71.2:299H

POSITION C

POSITION D

POSITION E (STANDARD)

To order, complete the Ordering Guide on pages 27

and 28. Carefully review the Specications section on

page 2 and specify the desired selection whenever

there is a choice to be made.

Ordering Guide

Type (Select One)

299H*** 299HR*** 299HS*** 299HSR***

Body Size, Material and End Connection Style (Select One)

1-1/4 NPT

Cast iron (For Types 299H and 299HR only)***

1-1/2 NPT

Cast iron (For Types 299H and 299HR only)*** Ductile iron*** Steel (For Types 299H and 299HR only)***

NPS 2 / DN 50

Cast iron (For Types 299H and 299HR only)

NPT*** CL125 FF - 7.5 inches / 191 mm*** CL125 FF - 10 inches / 254 mm***

Ductile iron NPT*** CL125 FF - 10 inches / 254 mm*** CL250 RF*** PN 10 RF* PN 16 RF*

Steel (For Types 299H and 299HR only)

NPT*** CL150 RF***

Orice Size (Select One) 1/4 x 3/8 inch / 6.4 x 9.5 mm*** 3/8 inch / 9.5 mm*** 1/2 inch / 13 mm*** 3/4 inch / 19 mm*** 7/8 inch / 22 mm (For Types 299H and 299HR only)*** 1 inch / 25 mm (For Types 299H and 299HR only)*** 1-3/16 inch / 30 mm (For Types 299H and 299HR only)***

Outlet Pressure Range (Select One)

3.5 to 6 inches w.c. / 9 to 15 mbar, Black*** 5 to 9 inches w.c. / 12 to 22 mbar, Yellow*** 7 to 20 inches w.c. / 17 to 50 mbar, Unpainted*** 16 to 40 inches w.c. / 40 to 99 mbar, Purple*** 1 to 3.25 psig / 69 mbar to 0.22 bar, Light Blue***

2.75 to 6 psig / 0.19 to 0.41 bar, Orange*** 5 to 16 psig / 0.34 to 1.1 bar, Red*** 14 to 35 psig / 0.97 to 2.4 bar (Type 299H only), Zinc*** 30 to 60 psig / 2.1 to 4.1 bar (Type 299H only), Green***

Pressure Registration (Select One) Internal*** External*** Dual***

Fixed Restriction (Select One)

0.044 inch / 1.1 mm, Red (standard gain)***

0.071 inch / 1.8 mm, Green (low gain)***

0.082 inch / 2.1 mm, Blue (lower gain)***

Type VSX-2 Trip Pressure Range

High Pressure Trip (Select One)

(For OPSO or OPSO/UPSO) 12 to 25 inches w.c. / 30 to 62 mbar*** 20 to 52 inches w.c. / 50 to 129 mbar***

1.4 to 3.9 psig / 97 to 269 mbar***

3.8 to 8.7 psig / 262 to 600 mbar***

5.8 to 16 psig / 400 to 1103 mbar***

11.6 to 23 psig / 800 to 1586 mbar***

27

Bulletin 71.2:299H

Ordering Guide (continued)

Low Pressure Trip (Select One) (For OPSO/UPSO only)

2 to 12 inches w.c. / 5 to 30 mbar*** 4 to 30 inches w.c. / 10 to 75 mbar***

0.36 to 2.3 psig / 25 to 159 mbar***

1.5 to 10.8 psig / 103 to 745 mbar***

Type P590 Pilot Supply Filter (Optional) Type P593-1, Aluminum

Type 594-1, Brass

Type 67CF Filtered Pilot Supply Regulator (Optional) Yes, please add a Type 67CF regulator to this order.

Main Valve Parts Kit (Optional) Yes, please send one parts kit to match this order.

Pilot Parts Kit (Optional) Yes, please send one parts kit to match this order.

Regulators Quick Order Guide

* * * Standard - Readily Available for Shipment

* * Non-Standard - Allow Additional Time for Shipment

Special Order, Constructed from Non-Stocked Parts.

*

Consult your local Sales Ofce for Availability.

Availability of the product being ordered is determined by the component with the longest shipping time for the requested construction.

Specication Worksheet

Application (Please designate units):

Specic Use Line Size Gas Type and Specic Gravity

Gas Temperature

Does the Application Require Overpressure Protection?

No Yes, if so, which is preferred: Relief Valve Monitor Regulator Shutoff Device

Is overpressure protection equipment selection assistance

desired?

Pressure (Please designate units):

Maximum Inlet Pressure (P Minimum Inlet Pressure (P

1max

1min

)

) Downstream Pressure Setting(s) (P2) Maximum Flow (Q

max

)

Performance Required:

Accuracy Requirements? Need for Extremely Fast Response?

Other Requirements:

Industrial Regulators

Emerson Process Management Regulator Technologies, Inc.

USA - Headquarters McKinney, Texas 75070 USA Tel: +1 800 558 5853 Outside U.S. +1 972 548 3574

Asia-Pacic

Shanghai 201206, China Tel: +86 21 2892 9000

Europe Bologna 40013, Italy Tel: +39 051 419 0611

Middle East and Africa Dubai, United Arab Emirates Tel: +011 971 4811 8100

For further information visit www.emersonprocess.com/regulators

The Emerson logo is a trademark and service mark of Emerson Electric Co. All other marks are the property of their prospective owners. Fisher is a mark owned by Fisher Controls International LLC, a business of Emerson Process Management.

The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not to be construed as warranties or

guarantees, express or implied, regarding the products or services described herein or their use or applicability. We reserve the right to modify or improve the designs or specications of such

products at any time without notice.

Emerson Process Management Regulator Technologies, Inc. does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, use and maintenance of any Emerson Process Management Regulator Technologies, Inc. product remains solely with the purchaser.

Natural Gas Technologies

Emerson Process Management Regulator Technologies, Inc.

USA - Headquarters McKinney, Texas 75070 USA Tel: +1 800 558 5853 Outside U.S. +1 972 548 3574

Asia-Pacic

Singapore 128461, Singapore Tel: +65 6770 8337

Europe Bologna 40013, Italy Tel: +39 051 419 0611 Chartres 28008, France Tel: +33 2 37 33 47 00

Middle East and Africa Dubai, United Arab Emirates Tel: +011 971 4811 8100

TESCOM

Emerson Process Management Tescom Corporation

USA - Headquarters Elk River, Minnesota 55330-2445, USA Tels: +1 763 241 3238 +1 800 447 1250

Europe Selmsdorf 23923, Germany Tel: +49 38823 31 287

Asia-Pacic

Shanghai 201206, China Tel: +86 21 2892 9499

Emerson 299Hs, 299H Data Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual
