EDE 36150W
user manual
Tumble Dryer
136904120.qxp 2007-10-02 08:44 Page 1
136904120.qxp 2007-10-02 08:44 Page 2
electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class product from
Electrolux, which hopefully will provide you with lots of
pleasure in the future. The Electrolux ambition is to
offer a wide variety of quality products that make your
life more comfortable. You find some examples on
the cover in this manual. Please take a few minutes
to study this manual so that you can take advantage
of the benefits of your new machine. We promise that
it will provide a superior User Experience delivering
Ease-of-Mind. Good luck!
GB
136904120.qxp 2007-10-02 08:44 Page 3
4 contents electrolux
Contents
Safety information..............................5
Product description ...........................7
Control panel.....................................8
Use ..............................................9-10
Drying hints ................................11-12
Drying programme...........................13
Care and cleaning ...........................14
Something not working ..............15-16
Technical data .................................17
Consumption values ........................18
Installation ..................................19-21
Environment concerns .....................22
Guarante/Customer Service .......23-24
The following symbols are used in this manual:
Important information concerning your personal safety and information on how
to avoid damaging the appliance.
General information and tips
Environmental information
136904120.qxp 2007-10-02 08:44 Page 4
safety information electrolux 5
Safety Information
In the interest of your safety and to
ensure the correct use, before
installing and first using the
appliance, read this user manual
carefully, including its hints and
warnings. To avoid unnecessary
mistakes and accidents, it is
important to ensure that all people
using the appliance are thoroughly
familiar with its operation and safety
features. Save these instructions
and make sure that they remain
with the appliance if it is moved or
sold, so that everyone using it
through its life will be properly
informed on appliance use and safety.
General safety
● It is dangerous to alter the
specifications or attempt to modify
this product in any way.
● This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
● Make sure that small pets do not climb
into the drum. To avoid this, please
check into the drum before using.
● Any objects such as coins, safety
pins, nails, screws, stones or any
other hard, sharp material can cause
extensive damage and must not be
placed into the machine.
● In order to avoid danger of fires
caused by excessive drying, do not
use appliance to dry the following
items: Cushions, quilts and the like
(these items accumulate heat).
● Items such as foam rubber (latex foam),
shower caps, waterproof textiles, rubber
backed articles and clothes or pillows
fitted with foam rubber pads should
not be dried in the tumble dryer.
● Always unplug the appliance after
use, clean and maintenance.
● Under no circumstances should you
attempt to repair the machine
yourself. Repairs carried out by
inexperienced persons may cause
injury or serious malfunctioning.
Contact your local Service Centre.
Always insist on genuine spare parts.
● Items that have been soiled with sub-
stances such as cooking oil acetone,
petrol, kerosene, spot removers, turpentine, waxes and wax removers
should be washed in hot water with
an extra amount of detergent before
being dried in the tumble dryer.
●
DDaannggeerr ooff eexxpplloossiioonn::
Never tumble dry
items that have been in contact with
inflammable solvents (petrol, methylated
spirits, dry cleaning fluid and the
like). As these substance are volatile,
they could cause an explosion. Only
tumble dry items washed with water.
●
RRiisskk ooff ffiirree
: items that have been
spotted or soaked with vegetable or
cooking oil constitute a fire hazard
and should not be placed in the
tumble dryer.
● If you have washed your laundry
with stain remover you must
execute an extra rinse cycle before
loading your tumble dryer.
● Please make sure that no gas lighters
or matches have accidentally been left
in pockets of garments to be loaded
into appliance
Installation
● This appliance is heavy. Care should
be taken when moving it.
● When unpacking the appliance, check
GB
136904120.qxp 2007-10-02 08:44 Page 5
6 electrolux safety information
that it is not damaged. If in doubt, do not
use it and contact the Service Centre.
● All packing and transit bolts must be
removed before use. Serious damage
can occur to the product and to
property if this is not adhered to. See
relevant section in the user manual.
● The final part of a tumble dryer cycle
occurs without heat ( cool down
cycle ) to ensure that the items are
left at a temperature that ensures
that items will not be damaged.
● Any electrical work required to
install this appliance should be
carried out by a qualified electrician
or competent person.
● Care must be taken to ensure that
the appliance does not stand on the
electrical supply cable.
● If the machine is situated on a
carpeted floor, please adjust the feet
in order to allow air to circulate freely
● After having installed the appliance,
check that it is not pressing or
standing on its electrical supply
cable, inlet hose and drain hose.
● If the tumble dryer is placed on top of a
washing machine, it is compulsory to
use the stacking kit (optional accessory).
Use
● This appliance is designed for domestic
use. It must not be used for purposes
other than those for which it was
designed.
● Only wash fabrics which are designed
to be machine dried. Follow the
instructions on each garment label.
● Do not dry unwashed items in the
tumble dryer.
● Fabric softeners, or similar products,
should be used as specified by the
fabric softener instructions.
● Do not overload the appliance. See
the relevant section in the user
manual.
● Clothes which are dripping wet
should not be placed in the dryer.
● Garments which have been in
contact with volatile petroleum
products should not be machine
dried. If volatile cleaning fluids are
used, care should be taken to
ensure that the fluid is removed from
the garment before placing in the
machine.
● Never pull the power supply cable to
remove the plug from the socket;
always take hold of the plug itself.
● Never use the tumble dryer if the
power supply cable, the control
panel, the working surface or the
base are damaged so that the inside
of the tumble dryer is accessible.
WWAARRNNIINNGG::
Never stop a tumble dry before the
end of the drying cycle.
Child safety
● This machine is not intended for use
by young children or infirm persons
without supervision.
● Children should be supervised to ensure
that they do not play with the appliance.
● The packaging components (e.g.
plastic film, polystyrene) can be
dangerous to children - danger of
suffocation! Keep them out of
children’s reach
● Keep all detergents in a safe place
out of children’s reach.
● Make sure that children or pets do
not climb into the drum.
136904120.qxp 2007-10-02 08:44 Page 6
product description electrolux 7
Product description
Control panel
Fluff filters
Rating Plate
Adjustable feet
Side vent outlets
Ring nut
Rear vent outlet
7
6
5
4
3
2
1
1
2
2
3
4
GB
5
6
7
136904120.qxp 2007-10-02 08:44 Page 7
8 electrolux control panel
Control panel
Programme Chart
Half power button
Start button
3
2
1
1 2 3 4 5
Mains on Light
Programme selector dial
5
4
136904120.qxp 2007-10-02 08:44 Page 8
use electrolux 9
Use
First Use
● Ensure that the electrical connections
comply with the installation instructions.
● Remove the polystryrene block and
any material from the drum.
● Before using your tumble dryer for
the first time, were commend that
you to place a few damp cloths
inside the appliance and dry for 30
minutes.
There may be dust inside a brand
new tumble dryer.
Daily Use
Connect the appliance.
Open the door (see picture).
Place the laundry in the drum, one item
at a time, shaking them out as much
as possible. Close the door. Please check
the laundry does not get caught
between the door and filter.
P1108
P1104
Select the required programme
Turn the programme selector dial to the
required programme.
The light Start starts to flash.
The selector dial is divided into following
sections:
Cottons
Synthetics
Around the knob there are two drying
cycles, one of up to 150 minutes at a
high temperature for cotton and linen,
and one of up to 100 minutes at a low
temperature for synthetic fabrics. To set
the machine to the selected time, turn
the dial clockwise until the the knob
pointer coincides exactly with the time
you want.
NNEEVVEERR aatttteemmpptt ttoo ttuurrnn tthhee ddiiaall iinn aann
aannttiicclloocckkwwiissee ddiirreeccttiioonn..
This phase should not be shortened,
stopped or avoided, as this could cause skin
burns or damages to the laundry.
Programme Option buttons
Depending on the programme, different
functions can be combined. These must
be selected after choosing the desired
programme and before depressing the
Start button. When these buttons are
pressed, the corresponding pilot lights come
on. When they are pressed again, the pilot
lights go out.
Program Time
0
150
120
100
80
60
40
20
20
40
60
80
100
0
GB
136904120.qxp 2007-10-02 08:44 Page 9
10 electrolux use
AAfftteerr eeaacchh uussee
• Clean the filters.
IImmppoorrttaanntt!!
The machine stops automatically. The
selector dial is on “O”, the mains-on
light is off.
If the laundry is still too damp, select
a further brief drying time, bearing in
mind that during the last 10 minutes
the dryer carries out the cooling and
anti-crease treatment phase.
136904120.qxp 2007-10-02 08:44 Page 10
Select the Half power
Press this button to reduce the temperature when drying particularly delicate cotton or linen items.
In this case you should select a longer
drying time.
Select the Start
Depress Start-button , the mains-on light
comes on and the machine starts operating.
MMaaiinnss oonn LLiigghhtt
This lights up when the machine starts
operating and goes out when the
selector dial is on position “0” and
when you open the door of the
appliance.
drying hints electrolux 11
Drying hints
Before loading the laundry
Never tumble dry the following:
Particularly delicate items such as
net curtains, woollen, silk, fabrics
with metal trim, nylon tights, bulky
materials such as anoraks, blankets,
eiderdowns, sleeping bags, feather
quilts and any items containing rubber foam or materials similar to rubber foam.
• Always follow the instructions on garment labels:
may be tumble dried
normal drying (high tempera-
ture)
delicate drying (low tempera-
ture)
do not tumble dry
• Close pillowcases and covers with
fasteners to prevent small laundry
items getting tangled inside them.
Close press studs, zips and hooks
and tie belts and apron strings.
• Sort laundry according to type and
degree of drying required.
• Do not over-dry laundry, this avoids
creasing and saves energy.
• Avoid drying dark clothes with light
coloured fluffy items such as towels
as they could attract the fluff.
• The laundry must be thoroughly spun
before tumble drying.
•
EEaassyy--ccaarree iitteemmss
, too, e.g. shirts,
should be briefly pre-spun before
drying (depending on crease resistance approx. 30 seconds or using
the special brief spin programme of
your washing machine).
• Knitted textiles (knitted underwear)
may shrink a little during drying.
Please do not overdry items of this
type. It is advisable to allow for
shrinkage when choosing the size of
new purchases.
• You can also put starched items into
your dryer. However, to achieve the
desired starched effect, choose the
programme “iron dry”. To remove any
starch residues, wipe out the internal
drum after drying with a moist cloth
and then rub it dry.
• To avoid a static charge when drying
is completed, use either a fabric softener when you are washing the
laundry or a fabric conditioner specifically for tumble dryers.
• Remove the laundry when the dryer
has finished drying.
• If individual items are still damp after
drying, set a brief post-drying time,
but
aatt lleeaasstt 3300 mmiinnuutteess
. This will be
necessary particularly for multilayered
items (e.g. collars, pockets, etc.).
Make sure that no metal objects
are left in the laundry (e.g. hair
clips, safety pins, pins).
Button up pillowcases, close zip
fasteners, hooks and poppers. Tie any
belts or long tapes.
Remove persistent stains before
washing.
Rub particularly soiled areas with a
special detergent or detergent paste.
Treat curtains with special care. Remove
hooks or tie them up in a bag or net.
GB
136904120.qxp 2007-10-02 08:45 Page 11
Maximum loads
Recommended loads are indicated in
the programme charts.
General rules:
Cotton, linen: drum full but not too
tightly packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum
no more than one third full.
Try to load to the maximum capacity
of the machine as small loads are
uneconomical.
Laundry weights
The following weights are indicative:
1200 gbathrobe
100 gnapkin
700 gquilt cover
500 gsheet
200 gpillow case
250 gtablecloth
200 gtowelling towel
100 gtea cloth
200 gnight dress
100 gladies’ briefs
600 gman’s work shirt
200 gman’s shirt
500 gman’s pyjamas
100 gblouse
100 gmen’s underpants
12 electrolux drying hints
136904120.qxp 2007-10-02 08:45 Page 12
drying programmes electrolux 13
Drying programmes
Programme
Type of
laundry
Options
Description of programme
Cotton and
linen
Cotton and
linen
Synthetics
Cotton and
linen
Cotton and
linen
Drying thick or multi-layered textiles,
e.g. terry towelling items.
MMaaxx llooaadd:: 66 kkgg
Drying thick textiles, e.g. terry towelling
items, towels.
MMaaxx llooaadd:: 33 kkgg
Drying textiles of even thicknesses,
e.g. terry towelling items, knitted
items, towels.
MMaaxx llooaadd:: 66 kkgg
Drying thick or multi-layered textiles,
e.g. pullovers, bedding, table linen.
MMaaxx llooaadd:: 33 kkgg
For thin textiles which are still to be
ironed, e.g. knitted items, cotton
shirts.
MMaaxx llooaadd:: 33 kkgg
Synthetics
For thin textiles which are still to be
ironed, e.g. knitted items, cotton
shirts.
MMaaxx llooaadd:: 11 kkgg
GB
800/1000
1200/1400
800/1000
1200/1400
1200
1200
800/1000
1200/1400
800/1000
1200/1400
136904120.qxp 2007-10-02 08:45 Page 13
CUPBOARD
105' - 135'
95' - 120'
CUPBOARD
65' - 85'
50' - 70'
IRON DRY
95' - 115'
80' - 100'
IRON DRY
50' - 70
35' - 55'
CUPBOARD
25' - 35'
CUPBOARD
15' - 20'
14 electrolux care and cleaning
removed for cleaning.
Do not be alarmed by the amount of fluff. It is not
due to excessive wear caused by the dryer.
All fabric loses fluff when drying but it goes
un-noticed in the air. In a tumble dryer it simply collects in the filter. After a while, a withish
patina due to detergent residue on laundry
forms on the filters. When this occurs, clean
the filters with warm water using a brush.
Remove the filter in the door opening as per
picture (it can be positioned with the tooth
facing to the left or to the right).
DDoo nnoott uussee tthhee aapppplliiaannccee wwiitthhoouutt ffiilltteerrss..
Cleaning the drum
When your laundry does not reach the desired
degree of dryness, in other words, when it
turns out either too dry or too damp, we
advise you to clean the inside of the drum with
a cloth soaked with vinegar.
This will eliminate the slight patina that has
formed in the drum (due to residues of
detergent and softeners used in the washing, and to the lime contained in the water),
which prevents the probes from detecting
the correct degree of dryness.
AU T O R E V ER S E
kg
5
kg 2,5
800 / 900
7
0
' - 9
0
'
35' - 50
'
1000 / 1200
65' - 85'
30
' - 4
5'
800 / 900
80
' - 10
0
'
55' - 70
'
1000 / 1200
7
5' - 9
5'
50
' - 6
5'
650
50
' - 6
0
'
3
0
' - 3
5'
kg
2,5
kg 1
P1112
AUTOREVE R S E
kg 5
kg 2,5
800 / 900
70
' - 9
0
'
3
5' - 5
0
'
1000 / 1200
65' - 8
5'
3
0
' - 45
'
800 / 900
8
0
' - 10
0
'
5
5' - 70
'
1000 / 1200
7
5
' - 9
5'
5
0
' -
65
'
650
50
' - 6
0
'
3
0
' - 3
5'
kg
2,5
kg
1
P1111
136904120.qxp 2007-10-02 08:45 Page 14
Care and cleaning
You must DISCONNECT the appliance from
the electricity supply, before you can carry
out any cleaning or maintenance work.
External cleaning
Use only soap and water and then dry
thoroughly.
IImmppoorrttaanntt::
diluents or similar products.
Cleaning the door
Clean periodically the interior part of
the door to remove any fluff from the
seals around the filter. Accurate cleaning ensures correct drying.
E
S
0
R
5
E
6
V
E
R
O
T
50' - 60'
U
A
0
kg 2,5
0
/ 12
0
0
10
30' - 35'
0
0
kg 1
/ 9
0
0
8
75' - 95'
0
0
2
/ 1
0
0
10
80' - 100'
50' - 65'
0
0
9
/
0
0
8
65' - 85'
55' - 70'
70' - 90'
30' - 45'
kg 5
35' - 50'
kg 2,5
P1109
do not use methylated spirit,
Cleaning the filters
Your dryer will only function well if the filters are clean.
The filters collect all the fluff which
accumulates during drying and they
must therefore be cleaned
ooff eeaacchh pprrooggrraammmmee
, before removing
the laundry, with a damp cloth.
P1110
The filter in the inner door must be
aatt tthhee eenndd
something not working electrolux 15
Something not working
Certain problems are due to lack of simple maintenance or oversights, which can be
solved easily without calling out an engineer. Before contacting your local Service
Centre, please carry out the checks listed below.
During machine operation it is possible that the Start pilot light flashes to indicate that
the machine is not working.Once the problem has been eliminated, press the Start
button to restart the programme. If after all checks, the problem persists, contact
your local Service Centre.
Malfunction Possible cause Solution
Dryer does not work.
● Mains plug is not plugged in
or fuse is not working
correctly.
● Loading door is open.
● Have you pressed the Start
button?
● Plug in at mains socket.
Check fuse in fuse box
(domestic installation).
● Close loading door.
● Press the Start button again.
Drying results
unsatisfactory.
● Wrong programme selected.
● Lint filter clogged.
● Incorrect volume of laundry.
● Ventilation slots in base area
covered up.
●Residue on inside surface of
drum or drum ribs.
● Select a different programme the
next time you dry (see “Overview
of programmes” section).
● Clean lint filter.
● Observe recommended
loading volumes.
● Uncover ventilation slots in
base area.
● Clean inside surface of drum
and drum ribs
.
Loading door does not
close.
● Fine strainer not in place
and/or large mesh filter not
locked in place.
● Install fine strainer and/or
snap large mesh filter into
place.
GB
136904120.qxp 2007-10-02 08:45 Page 15
16 electrolux something not working
If you are unable to identify or solve the
problem, contact our service centre.
Before telephoning, make a note of the
model, serial number and purchase date
of your machine: the Service Centre will
require this information.
P1206
Mod. ..........
Prod. No. ...........
Ser. No. .........
Mod. ..........
Prod. No. ...........
Ser. No. .........
IMPORTANT: if you call out an engineer
to a fault listed below, or to repair a fault
caused by incorrect use or installation, a
charge will be made even if the
appliance is under guarantee.
136904120.qxp 2007-10-02 08:45 Page 16
technical data electrolux 17
Technical data
Dimensions Width 60 cm
85 cm
58 cm
Height
Depth
Depth with loading door open 109 cm
Cotton
Synthetics
Maximum Load 6 kg
3 kg
Electrical connection
Voltage - Overall power Fuse
Information on the electrical connection is given
on the rating plate on the inner edge of the
appliance door
This appliance conforms with the following EU Directives:
– 73/23/EEC dated 19.02.1973 Low Voltage Directive
– 89/336/EEC dated 03.05.1989 EMC Directive inclusive of
Amending
Directive 92/31/EEC
– 93/68/EEC dated 22.07.1993 CE Marking Directive
Use
Domestic
+ 5°C + 35°C
GB
136904120.qxp 2007-10-02 08:45 Page 17
18 electrolux consumption values
The consumption values have been
established under standard conditions.
They may deviate when the machine is
operated in domestic circumstances.
Consumption values
Programme
duration
(in minutes)
Programme Energy
consumption
(in kWh)
Revolutions
per
minute
1)
Max Cottons load: 6 kg
2)
Max Synthetics oad: 3 kg
Cottons Cupboard
1)
Cottons Iron
1)
Cottons Cupboard
1)
Synthetics Cupboard
2)
1000
1000
1400
1200
112 3.3
89 2.6
2,9
35 1.18
136904120.qxp 2007-10-02 08:45 Page 18
98
Installation
Unpacking
All transit bolts and packing must be
removed before using the appliance.
Slide out the polythene bag with the
polystyrene stuffing before using the
appliance Pull off adhesive strips from
inside machine on top of drum.
SShhoouulldd tthhee aapppplliiaannccee bbee mmoovveedd,, iitt mmuusstt
bbee ttrraannssppoorrtteedd vveerrttiiccaallllyy
.
Do not install the appliance behind
– a door that locks
– a sliding door
– a door with a hinge that lies opposite
the hinge of the appliance.
Positioning
It is recommended that, for your
convenience, the machine is positioned
close to your washing machine. Whilst
drying, the tumble dryer will expel a
certain amount of warm, very moist air,
and this should be removed from the
room as quickly as possible to prevent
condensation. In an extremely well
ventilated room or close to an open
window, this may occur naturally.
However, in general, it is better to carry
the dryer's exhaust outside via the 100
mm diameter flexible hose supplied
with the appliance; ending either
temporarily at an open window, or
permanently at a fixed ventilation grille,
fitted to an exterior wall or window.
The tumble dryer must be installed in a
clean place, where dirt does not build up.
Make sure there are no obstructing
items or material near the air-intake
louvres provided at the back (e.g. paper,
rags etc.). To keep vibration and noise to
a minimum when the dryer is in use, it
should be placed on a firm, level surface.
Once in its permanent operating
position, check that the dryer is
absolutely level with the aid of a spirit
level. If it is not, raise or lower the feet
until it is.
TThhee ffeeeett mmuusstt nneevveerr bbee rreemmoovveedd..
DDoo nnoott rreessttrriicctt tthhee fflloooorr cclleeaarraannccee
tthhrroouugghh ddeeeeppppiillee ccaarrppeettss,, ssttrriippss ooff
wwoooodd oorr ssiimmiillaarr.. TThhiiss mmiigghhtt ccaauussee hheeaatt
bbuuiilldd--uupp wwhhiicchh wwoouulldd iinntteerrffeerree wwiitthh tthhee
ooppeerraattiioonn ooff tthhee aapppplliiaannccee..
IImmppoorrttaanntt
The hot air emitted by the tumble dryer
can r
each temperatures of up to 60°C.
The appliance must therefore not be
installed on floors which are not resistant
to high temperatur
es.
When operating the tumble dryer, the
room temperature must not be lower
P0046
GB
installation electrolux 19
136904120.qxp 2007-10-02 08:45 Page 19
20 electrolux installation
than +5°C and higher than +35°C, as it
may affect the performance of the
appliance.
Fitting the vent hose
A special stacking kit is available
throughTo simplify the installation, there
is a choice of vent outlets: one at the
back, the others in the left and righthand side.
Connect the hose to whichever is the
more convenient by pulling the ring nut
(A) from the vent outlet at the back,
screwing it on to the hose and pushing it
firmly back into place. The unused vents
should now be sealed with the special
snap covers provided.
Advice: If the hose is long and the
room temperature low, the moisture
might condense to water inside the
hose. This is an unavoidable natural
phenomenon. To prevent this water
from Iying in the hose or flowing back
into the tumble dryer, it is advisable to
drill a small hole (dia. 3 mm) in the
lowest point of the hose and to place a
small container below it.(See picture,
point B).
P1056
B
P1027
A
A
P1028
Once connected to the dryer, run the
vent hose to the desired outlet point,
ensuring that the run’s overall length is
less than 2 m, and that it contains no
more than two bends. As to the outlet
itself, if you have decided on a fixed
wall/window grille, a good local
builder’s merchant should be able to
supply you with the necessary fittings
and installation advice.
It is important not to connect the
vent hose to, for example, a cooker
hood, or a chimney or flue pipe
designed to carry the exhaust from
a fuel burning appliance.
Note that to avoid condensation
problems, it is essential that the dryer
be fitted with the flexible hose to carry
its “exhaust” at least beyond the
kitchen units; preferable outside the
kitchen.
In order to prevent the appliance from
overheating, it is important that the
steam exhaust is unobstructed.
Therefore, in case of a permanent hose
fitted to an exterior wall or ceiling, it
must be ensured an exhaust capacity
of at least 150 m3/h.
If the dryer is fitted next to kitchen
units, make sure that the vent hose is
not squashed. If the hose is partially
P0055
136904120.qxp 2007-10-02 08:45 Page 20
squashed, drying efficiency will be
reduced, resulting in longer drying
times and higher energy consumption.
If the hose is completely squashed, the
safety cut-outs with which the machine
is fitted may operate.
When operating the tumble dryer, the
room temperature must not be lower
than +5°C and higher than +35°C, as it
may affect the performance of the
appliance.
Stacking kit
A special stacking kit is available through
your dealer, to enable the mounting of
the dyer on top of a front loading
washing machine with cover’s depth
between 48 and 60 cm.
Read carefully the instructions supplied
with the kit.
Door reversal
To make it easier to load or unload the
laundry the door can be reversed.
This operation must be carried out by
qualified personnel.
Please contact the nearest Service
Centre.
P1107
installation electrolux 21
GB
Electrical connection
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any
other appliances in use.
Connect the machine to an earthed
socket, in accordance with current
wiring regulations.
THIS APPLIANCE MUST BE
EARTHED.
The manufacturer declines any
liability should this safety measure
not be observed.
The manufacturer declines any
responsibility for damage or injury
through failure to comply with the
above safety precaution. Should
the appliance power supply cable
need to be replaced, this must be
carried out by our Service Centre.
IImmppoorrttaanntt!!
TThhee ppoowweerr ssuuppppllyy ccaabbllee mmuusstt bbee
aacccceessssiibbllee aafftteerr iinnssttaalllliinngg tthhee mmaacchhiinnee
.
136904120.qxp 2007-10-02 08:45 Page 21
22 electrolux environment concerns
Environment concerns
Packaging materials
The materials marked with the symbol
are recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by
disposing of them properly in
appropriate collection containers.
Old machine
Use authorised disposal sites for your
old appliance. Help to keep your country
tidy!
The symbol on the product or on its
packaging indicates that this product
may not be treated as household waste.
Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the
environment and human health, which
could otherwise be caused by inappropriate waste handling of this product.
For more detailed information about
recycling of this product, please contact
your local city office, your household
waste disposal service or the shop
where you purchased the product.
Ecological hints
To save energy and to help protect the
environment,we recommend that you
follow these hints:
• Normally soiled laundry may be
washed without prewashing in order
to save detergent, water and time
(the nvironment is protected too!).
• The machine works more
economically if it is fully loaded.
• With adequate pre-treatment, stains
and limited soiling can be removed;
the laundry can then be washed at
a lower temperature.
• Measure out detergent according to
the water hardness, the degree of
soiling and the quantity of laundry
being washed..
• To utilize the maximum load, laundry
which is tobe dried ready to put away
(store dry) can be dried together with
items to be ironed. To do this, select
the programme for iron-dry, remove
the iron-dry items at the end of the
programme and then finish-dry the
rest of the load.
• Clean the filters regularly to avoid
excessive drying times and high
electricity consumption.
• Ventilate the room well. The room
temperature should not exceed +35°C
during.
136904120.qxp 2007-10-02 08:45 Page 22
guarantee/customer service electrolux 23
Guarantee conditions
IINNDDOONNEESSIIAA
PT. Electrolux Indonesia
Wisma Staco 8th Floor
Jalan Casablanca Kav 8
Jakarta 12870
Office Tel: (+62 21) 8317140-1
Fax: (+62 21) 8317041
Call Center Tel: (+62 21) 6331350
(+62 21) 6328025
Operating Hours:
0830 to 1630 Mondays to Fridays
0830 to 1200 Saturdays
TTHHAAIILLAANNDD
Electrolux Thailand Co., Ltd.
Electrolux Building, 14th Floor
1910 New Petchburi Road
Bangkapi, Huay Kwang
Bangkok 10320 Thailand
Office Tel: (+66 2) 7259100
Fax: (+66 2) 7259099
Call Center Tel: (+62 2) 7259000
Operating Hours:
0800 to 1800 Mondays to Sundays
VVIIEETTNNAAMM
Electrolux Vietnam Ltd.
Sai Gon Trade Center Building
Suite 2606, 26th Floor
37 Ton Duc Thang Street, District 1
Ho Chi Minh City, Vietnam
Office Tel: (+84 8) 9105645
Fax: (+84 8) 9105470
Call Center Tel: 1 800 588899
Operating Hours:
0800 to 1800 Mondays to Sundays
GB
136904120.qxp 2007-10-02 08:45 Page 23
24 electrolux guarantee/customer service
136904120.qxp 2007-10-02 08:45 Page 24
136904120.qxp 2007-10-02 08:45 Page 25
136 904 121-00-02102007
Loading...
