Electrolux EAS-C-E-18C2ASK-W-S-M, EAS-C-E-24P5ASK-W-S-M, EAS-C-E-12C2ASK-W-S-M, EAS-C-E-09C2ASK-W-S-M, EAS-C-E-09P5ASK-W-S-M User Manual

...
INSTRUCTIONS MANUAL
SPLIT TYPE ROOM AIR CONDITIONER
110823P S(351-358)EM_ENGLISH
MODELS:
EAS(C,E)09C2ASK(W,S,M) / EAS(C,E)12C2ASK(W,S,M) EAS(C,E)18C2ASK(W,S,M) / EAS(C,E)24C2ASK(W,S,M)
EAS(C,E)09P5ASK(W,S,M) / EAS(C,E)12P5ASK(W,S,M) EAS(C,E)18P5ASK(W,S,M) / EAS(C,E)24P5ASK(W,S,M)
Please read this manual completely before operating your room air conditioner.
01 electrolux welcome
contents electrolux 02
Welcome to the world of simple handling and no worries.
Please read all of the instructions before using the air conditioner and keep this manual for future reference.
We know you will enjoy your new air conditioner and thank you for choosing our product. We hope you will consider us for future purchase.
Environmental Advices
The packaging material used is recyclable; we recommend that you separate plastic, paper and cardboard and give them to recycling companies. According to WEEE (Waste of Electrical and Electronic Equipment) guidelines, waste from electrical and electronic devices should be collected separately. If you need to dispose of this appliance in the future, do NOT throw it away with the rest of your domestic garbage. Instead, please take the appliance to the nearest WEEE collection point, where available.
The air conditioner you purchased has R410a gas refrigerant a environmental friendly gas which does not damage the ozone layer.
The air conditioner that you have bought may be slightly different from the one illustrated in this manual. Please refer to the information related to the model you have. This air conditioner is for domestic use only. It is not reccomended for commercial or industrial use. The air conditioner you have may carry a different plug than the one illustrated in this manual. The plug that comes with the product follows the electrical specification of the country where it is sold.
Contents
01. Welcome.........................................................................................................01
02. Environmental advices....................................................................................01
03. Contents..........................................................................................................02
04. Safety precautions..........................................................................................04
05. Installation.......................................................................................................08
5.1 Choosing the installation site..............................................................08
5.2 Parts list...............................................................................................10
5.3 Indoor unit installation..........................................................................12
5.4 Outdoor unit installation.......................................................................16
5.5 Refrigerant pipe connection................................................................18
5.6 Electrical work......................................................................................20
5.7 Electrical safety....................................................................................28
5.8 Gas leak check....................................................................................28
5.9 Operation test.......................................................................................29
06. Operation........................................................................................................30
6.1 Preparing the device for operation......................................................30
6.2 Product description.............................................................................31
6.3 Remote control....................................................................................33
- Remote control operation
- Remote control battery
- When should the batteries be replaced
- To replace batteries
- Remote control instructions
6.4 Remote control description.................................................................35
- On/off
- Mode
- Swing
- Sleep
- Follow me
- Direction
- Restart
- Temperature
- Fan speed
- Timer
- Cancel
- Turbo
- LED
- Clock
- Lock
6.5 LCD display indicators........................................................................38
6.6 Clock adjustment.................................................................................39
03 electrolux contents
safety precautions electrolux 04
Safety precautions
6.7 How the air conditioner works.............................................................40
- Automatic operation
- Cool/Heat and Fan only operation
- Dry operation
- Air flow direction adjustment
- Sleep mode
- Timer
- Cancel timer operation
- Optimal operation
6.8 How to use the indoor unit...................................................................44
- Adjusting the air flow direction
- Adjusting the vertical air flow direction (up-down)
- To set the horizontal air flow direction (left-right)
- To automatically swing the air flow direction (up-down)
6.9 Manual operation..................................................................................46
07. Maintenance.........................................................................................47
08. Operation tips.......................................................................................49
09. Solutions for problems.........................................................................51
10. Technical specifications.......................................................................52
To prevent injury to the user or other people and property damage, the following instructions must be followed.
Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications.
1. Connect with the power properly. Otherwise, it may cause electric shock or fire due to excess heat generation.
2. Do not modify power cord length or share the outlet with other appliances. It may cause electric shock or fire due to heat generation.
3. Always ensure effective earthing. No earthing may cause electric shock.
4. Disconnect the power if strange sounds, smell, or smoke comes from it. It may cause fire and electric shock.
5. Keep firearms away. It may cause fire.
6. Do not operate or stop the unit by switching on or off the power. It may cause electric shock or fire due to heat generation.
7. Do not operate with wet hands or in damp environment. It may cause electric shock.
8. Do not allow water to run into electric parts. It may cause failure of machine or electric shock.
9. Do not drink water drained from air
05 electrolux safety precautions
safety precautions electrolux 06
conditioner. It contains contaminants and could make you sick.
10.Do not use the power cord close to heating appliances. It may cause fire and electric shock.
11.Do not damage or use an unspecified power cord. It may cause electric shock or fire.
12.Do not direct airflow at room occupants only. This could damage your health.
13.Always install circuit breaker and a dedicated power circuit. No installation may cause fire and electric shock.
14.Do not open the unit during operation. It may cause electric shock.
15.Do not use the power cord near flammable gas or combustibles, such as gasoline, benzene, thinner, etc. It may cause an explosion or fire.
16.Ventilate room before operating air conditioner if there is a gas leakage from another appliance. It may cause explosion, fire and, burns.
17.Do not disassemble or modify unit. It may cause failure and electric shock.
18.When the air filter is to be removed, do not touch the metal parts of the unit. It may cause an injury.
19.Do not clean the air conditioner with water. Water may enter the unit and degrade the insulation. It
may cause an electric shock.
20.Ventilate the room well when used together with a stove, etc. An oxygen shortage may occur.
21.When the unit is to be cleaned, switch off, and turn off the circuit breaker. Do not clean unit when power is on as it may cause fire and electric shock, it may cause an injury.
22.Do not put a children, pet or house plant where it will be exposed to direct air flow. This could injure the pet or plant.
23.Do not use for special purposes. Do not use this air conditioner to preserve precision devices, food, pets, plants, and art objects. It may cause deterioration of quality, etc.
24.Stop operation and close the window in storm or hurricane. Operation with windows opened may cause wetting of indoor and soaking of household furniture.
25.Turn off the main power switch when not using the unit for a long time. It may cause failure of product or fire.
26.Do not use strong detergent such as wax or thinner. Use a soft cloth for cleaning. Appearance may be deteriorated due to change of product color or scratching of its surface.
27.Ensure that the installation bracket of the outdoor appliance is not damaged due to prolonged exposure. If bracket is damaged,
07 electrolux safety precautions
choosing the installation site electrolux 08
Choosing the installation site
there is concern of damage due to falling of unit.
28.Always insert the filters securely. Clean filter once every two weeks. Operation without filters may cause failure.
29.Do not place heavy object on the power cord and take care so that the cord is not compressed. There is danger of fire or electric shock.
30.Do not place obstacles around air­inlets or inside of air-outlet. It may cause failure of appliance or accident.
Precautions for Installation
Installation at the following sites may cause problems. If you must inevitably install the unit at one of these sites, please consult your local distributor beforehand:
1. Site with machine oil.
2. Sites with a high concentration of salinity, such as coastal areas.
3. Sites with sulfuric gas, such as hot water springs.
4. Sites with high frequency equipment, such as wireless equipment, welding machines and medical installations.
5. Sites with flammable gases or volatile material.
6. Sites with special environmental conditions.
7. Laundry rooms.
Indoor Unit
1. The unit must be installed at a site
that does not obstruct the flow of air.
2. The site must support the weight
of the indoor unit.
3. The site must be easily accessible
7. The indoor unit must be at least 2.3 meters (7.5 feet) from the ground.
8. The site must allow for the easy removal of the connector pipe and drain hose.
9. The unit must be installed at a site protected from direct sunlight.
for maintenance and replacement of the air filter.
4. The site must allow for the necessary space around the indoor unit, as shown in the following figure.
5. There should be at least 1 meter (3
More than 12cm
More than 15cm
feet) between the unit and radio and television devices. It is ideal that the unit be installed at the center of the environment.
More than 200cm
More than 12cm
6. It must be far from fire, smoke or flammable gases.
09 electrolux outdoor unit
parts list electrolux 10
Parts list
Outdoor Unit
1. The outdoor unit must be installed at a convenient site that is not exposed to strong winds. The site should be dry and well ventilated.
2. The site must support the weight of the outdoor unit and allow for vertical installation.
3. There must not be the possibility of increased noise and vibration at the site.
4. The unit must be installed at a site where the noise produced by its operation and air discharge does not disturb the neighbors or animals.
5. The site cannot have any leakage of flammable gases.
6. The site must allow for a piping extension of no less than 5 meters (16 feet) and for pipes measuring at least 10 meters (33 feet) in length.
7. The site must provide enough space around the unit, as shown in the diagram.
8. Children must not be able to access the installation site.
More than 30cm
More than 200cm
More than 60cm
More than 30cm
More than 60cm
NUMBERING PART NAME
1
2
3
4
5
6
7
8
9
Indoor unit
Installation plate
Clip anchor
Self-tapping screw A ST3.9x25
Seal
Drain Joint
Connecting pipe assembly*
Remote controller
Self-tapping screw B ST2.9x10
Remote controller holder
Liquid side
Gas side
Ø6,35
Ø9,52
Ø12,7
54
(< modelos 12000 Btu’s)
(> modelos 12000 Btu’s)
9
8
8 7
QTY.
1
8
8
1
1
Parts you must
purchase
1
2
1
1
3
2
Outdoor unit
11 electrolux parts list
indoor unit installation electrolux 12
Indoor unit installation
More than 12cm
7
More than 15cm
Indoor unit
Air filter
More than 30cm
4
5
More than 200cm
A
B
6
More than 12cm
More than 60cm
1
2
6
More than 60cm
C
Outdoor
unit
Installation plate description
3
Indo
or un tlin
a m
bove 120m
from the wall
it
ou
e
45
0
45
4
o s
M del
45
Model
R
f
ig
er
nt
e
h (
above 120mm
Refrigerant pipe
hole (left) Ø 65
pi
r a
lef
t
Ø
o
le )
Indoor unit outline
from the wall
p
e
6
5
293
abov t
A
<
12000 B (
tu’
12000 B
tu’
above 150mm from the ceiling
e
15 m fr
0m
c
i inghee
l
:
s
A B 0)
( :
s
A B
920
om
710, : 790, : 26
5)
n
ion plaI
stallat te
90
25
Installation plate
B
0 4
above 120mm from the wall
90
Refrigerant pipe
45
hole (right) Ø 65
above
120mm
om fr
the wall
f ant piRe riger pe
(
i )
hole
r ght
Ø
65
(A)
Indoor unit outline
above 120mm
from the wall
above 150mm from the ceiling
45
305
Installation plate
272
above 120mm from the wall
90
1. This illustration is for explanation purposes only.
2. Copper lines must be insulated independently
Refrigerant pipe
hole (left) Ø 65
Refrigerant pipe
45
80
489 850
45
hole (right) Ø 65
(B)
Modelos 18000 Btu’s
13 electrolux indoor unit installation
indoor unit installation electrolux 14
150mm del techo
above 120mm
from the wall
Refrigerant pipe
hole (left) Ø 65
293
130
50
Modelos 24000 Btu’s
Fixing the installation plate
1. Install the installation plate
horizontally over the structural parts on the wall using the spaces indicated on the plate, as shown in the figure above.
2. In the case of tiled, concrete or
similar walls, create 5 mm­diameter holes. Place anchorage supports for the appropriate assembly screws.
3. If expansion screws are used, the
holes must measure 11x20 or 11x26, with a distance of 450 mm between each.
4. Fix the installation plate to the wall.
Drilling the Hole
1. Determine the position of the hole
for the pipe using the installation plate and drill the pipe hole (ø 65mm) so that it is titled slightly downward.
2. Always use a pipe cover with an
opening when drilling a metal bar.
998
119380380
above 120mm
41
from the wall
130
50
Indoor unit outline
Fit the Installation Plate and drill holes in the wall according to the wall structure and corresponding mounting points on the installation plate (Dimensions are in “mm” unless otherwise stated).
Placa de instalación
Wall
Indoor unit
Outdoor unit
5-7m m
Connective pipe and drainage installation
Drainage
1. Run the drain hose sloping downward. Do not install the drain hose as illustrated below.
2. When connecting extension drain hose, insulate the connecting part of extension drain hose with a shield pipe, do not let the drain hose slack.
Connective pipe installation
1. For the left-hand and right-hand piping, remove the pipe cover from the side panel.
2. For the rear-right-hand and rear-left­hand piping, install the piping as shown. Bend the connective pipe to be laid at 43mm height or less from the wall.
3. Fix the end of the connective pipe.
Fastening the Indoor Unit
1. Pass the piping through the hole in the wall.
2. Put the upper claw at the back of the indoor unit on the upper hook of the installation plate, move the indoor unit from side to side to see that it is securely hooked (see Fig.10 & Fig.11).
Pipe cover (right)
Right piping
Indoor unit outline
Do not block water flow by a rise.
Do not put the end of drain hose into water.
Pipe holder
Right back piping
Connective pipe
Upper hook
Lower hook
Do not block water flow by a rise.
Pipe cover (left)
43mm
15 electrolux indoor unit installation
outdoor unit installation electrolux 16
Outdoor unit installation
3. Piping can easily be made by lifting the indoor unit with a cushioning material between the indoor unit and the wall. Get it out after finish piping.
4. Push the lower part of the indoor unit up on the wall, then move the indoor unit from side to side, up and down to check if it is hooked securely.
Piping and wrapping
1. Bundle the tubing, connecting cable, and drain hose with tape securely, evenly as shown.
2. Because the condensed water from rear of the indoor unit is gathered in ponding box and is piped out of room. Do not put anything else in the box.
Indoor unit
Drain hose
Cushioning material
Cable de conexión
Ponding box
Pipe room
Connective pipe
Wrapping belt
1. Install the outdoor unit on a rigid base to prevent increasing noise level and vibration.
2. Determine the air outlet direction where the discharged air is not blocked. In the case that the installation place is exposed to strong wind such as a seaside, make sure the fan operating properly by putting the unit lengthwise along the wall or using a dust or shield plates.
3. Specially in windy area, install the unit to prevent the admission of wind. If need suspending installation, the installation bracket should accord with technique requirement in the installation bracket diagram.
4. The installation wall should be solid brick, concrete or the same intensity construction, or actions to reinforce, damping supporting should be taken. The connection between bracket and wall, bracket and the air conditioner should be firm, stable and reliable.
5. Be sure there is no obstacle which block radiating air.
Strong wind
1. Connect the indoor unit first, then the outdoor unit.
2. Do not allow the piping to let out from the back of the indoor unit.
3. Be careful not to let the drain hose slack.
4. Heat insulated both of the auxiliary piping.
5. Be sure that the drain hose is located at the lowest side of the bundle. Locating at the upper side can cause drain pan to overflow inside the unit.
6. Never intercross nor intertwist the power wire with any other wiring.
7. Run the drain hose sloped downward to drain out the condensed water smoothly.
Loading...
+ 19 hidden pages
