USER MANUAL
MANUAL DE INSTRUCCIONES NOTICE D’EMPLOI BEDIENUNGSANLEITUNG
LIST OF CONTENTS |
|
|
|
|
1. IMPORTANT NOTE |
04 |
|
|
|
1.1. Precautions |
04 |
|
|
|
2. INTRODUCTION |
04 |
|
|
|
2.1. Main features |
04 |
|
|
|
3. INSTALLATION |
05 |
|
|
|
3.1. Placement, mounting, cooling |
05 |
|
|
|
3.2. Mains connection |
05 |
|
|
|
3.3. Input signal connections |
05 |
|
|
|
3.4. Subsonic filter |
05 |
|
|
|
3.5. Limiter circuit |
06 |
|
|
|
3.6. Output connections |
06 |
|
|
|
4. OPERATION AND USAGE |
06 |
|
|
|
4.1. Start up |
06 |
|
|
|
4.2. Input attenuators |
06 |
|
|
|
4.3. Indicators |
07 |
|
|
|
5. CLEANING |
07 |
|
|
|
6. DIAGRAMS |
23 |
|
|
|
6.1. Connection diagram |
23 |
|
|
|
6.2. Technical characteristics |
24 |
|
|
|
6.3. Block diagram |
25 |
|
|
|
6.4. Function list |
26 |
|
|
|
6.5. Function diagram |
27 |
|
|
|
|
|
|
|
|
|
|
|
|
|
All numbers subject to variation due to production tolerances. ECLER S.A. reserves the right to make changes or improvements in manufacturing or design which may affect specifications.
3
1. IMPORTANT NOTE
Congratulations! You are the owner of a carefully designed and manufactured equipment. We thank you for trusting on us and choosing our amplifier XPA.
In order to obtain maximum operativity and perfect functioning order, it is most important to carefully read all considerations taken into account in this manual before connecting this amplifier.
We recommend our authorised Technical Services if any maintenance task should be needed so that optimum operation shall be achieved.
1.1. Precautions
The XPA11000/7000/5000/3000 amplifiers have a power consumption of 1230, 775, 675 and 575 VA (at 1/8 of maximum power output, as specified by regulation EN 55103-1). We recommend a 2.5mm2 (or bigger) wire cross-section and a magnetothermic circuit breaker that can handle at least 10A@230VAC for XPA3000/5000,15A@230VAC for XPA7000 and 25A for XPA11000) (These values are for one amplifier).
The amplifier should have an earth connection in good conditions (earth resistance, Rg=30 or less). The environment must be dry and dustless. Do not expose the unit to rain or water splashes, and do not place liquid containers or incandescent objects like candles on top of the unit. Do not obstruct the ventilation shafts with any kind of material. In case there is some type of intervention and/or connection-disconnection of the amplifier, it is most important to previously disconnect the mains power supply.
Do not manipulate the output terminals to the loudspeakers when the amplifier is switched on, there are
voltages up to 400Vpp. The output cabling should be connected by a qualified technician. Otherwise only use pre-made flexible cables. There are no user or serviceable parts inside the amplifier.
2. INTRODUCTION
High efficiency mosfet amplifier.
Ecler XPA Power amplifier series offers the renowned professional reliability of all Ecler amplifiers at an affordable price. The line consists of four models with power outputs of 300, 500, 700 and 1100 W per channel at
4 . All models employ mosfet amplification technology, are 2 rack units high and are based on a robust chassis with aluminium front panel. Thanks to their oversized power supply, these amplifiers can operate comfortably with
4 and even 2 loads.
They feature balanced input connections via XLR3 and 1/4’’ Jacks. The outputs offer total versatility thanks to secure connection posts with standardized separation and Speakon® sockets. An electronic limiting system for avoiding signal overloads and a switchable subsonic filter are also on board.
2.1.Main features:
-Highly effective progressive cooling system. Air flow rises as a function of amplifier temperature. “Back to Front” cooling system takes air from the rear and throws it out at the front panel.
-Easily accessible input attenuation controls on the front panel may be locked with Ecler exclusive system.
-Indicators for Signal Present (SP), Clipping (CLIP) and activation of protection circuits (PROT)
-Effective protection systems against short-circuit, excessive temperature due to accidental blocking of air flow or other circumstances, DC at the output… to protect the amplifier and loudspeakers.
-Built-in, always active anticlip circuit
-Switchable subsonic filter, 30 Hz 18dB/oct slope
-Operating mode selector: STEREO, PARALLEL and BRIDGE
-Input sensitivity selector (0.775 / 1 / 1.4V)
-Balanced inputs via XLR3 and, 35mm TRS Jack sockets
-Outputs on connection posts and Speakon® connectors
-Operation with 8, 4 and 2 or 4 in bridged mode.
-2 years warranty
4
3. INSTALLATION
3.1. Placement, mounting, cooling
All XPA amplifier models are presented in standard 19” rack format and are 2 units high.
It is important that the amplifier, as a heat source, is not placed next to other equipment nor exposed to high temperatures. Therefore, the ventilation path should be kept free to allow fresh air entering the forced ventilation tunnel. This system takes air from the unit's backside, bringing it directly to the power amp modules and distributing it to the transformer and capacitors and then obliging it to pass trough the cooling tunnel to finally blow out of the front panel. In case of rack mounting, this system avoids heat accumulation inside the unit and thus increases lifetime of electrolytic capacitors. It is recommended to place power amplifiers on top of other equipment and not underneath.
3.2. Mains connection
The XPA amplifiers are fed with alternate currents, depending on the country, of 110-120, 220-240V 47/63Hz. (see characteristics in the back of the unit).
The mains cables must not be near the shielded cables carrying the audio signal, as this could cause humming.
In order to protect the power amplifier from eventual power consumption overloads it is protected by a set of internal fuses. Should a fuse blow, it must be replaced immediately by one with identical rating. Should it blow again please contact our Technical Service Department. NEVER REPLACE THE FUSE WITH ANOTHER ONE WITH A HIGHER VALUE.
CAUTION: Fuse substitutions have to be performed by a qualified technician.
3.3. Input signal connections
The signal input connectors are of XLR-3 and 1/4’’ TRS Jack type (7,8) and electronically balanced. The pin assignment is as follows:
|
|
XLR-3 |
JACK |
Hot or direct signal |
> |
Pin 2 |
Tip |
Cold or phase inverted signal |
> |
Pin 3 |
Ring |
Ground |
> |
Pin 1 |
Sleeve |
For an unbalanced connection, short pin 3 to ground (XLR) or the ring to ground (Jack).
The input impedance in balanced mode is 20k (10k non-balanced). This impedance makes possible to parallel several amplifiers without losing audio quality. Input sensitivity can be selected via a switch placed on the back panel (9) Selectable values are 0.775V / 1V / 1.4V
3.4. Subsonic filter
This filter cuts off inaudible frequency components which when amplified suppose a risk of damage to the low frequency speakers as they generate excessive excursions of the woofer's diaphragm. The filter of the XPAs, which has a Butterworth shaped response with 18 dB/oct slope, has a cut-off frequency of 30 Hz and can be switched on or off via a switch on the rear panel (11).
Subsonic filters are very important when playing back vinyl records because the phono cartridges are specially sensitive to feedback and acoustic coupling at very low frequencies.
5
3.5. Limiter circuit
This system is an always active protection inside the XPA series of amplifiers. The ANTICLIP circuitry constantly analyses harmonic distortion caused by excessive signal excursion at the power amplifier's output and automatically reduces the input level in order never to exceed 0,5% total harmonic distortion.
The great convenience of such a circuit in any kind of installation has to be remarked: The clear advantage of a limiting system in front of conventional compressors is that the former does practically not alter the dynamic range, acting only when the distortion threshold is reached.
3.6. Output connections
See diagram 6.1 for output connection possibilities
The output section on the rear panel features both Speakon® connectors (13) and threaded connection posts (14).
If you need to operate the amplifier in BRIDGED mode, you should place the “MODE” (10) switch in BRIDGE position. Input signal should be fed into Channel 1 of the amplifier and the output appears at the 2+ and 2- pins of the Speakon® connector and/or at the red connection posts.
ATTENTION: Terminals 1+ and 1- should only be used in case of “STEREO” or “PARALLEL” mode and terminals 2+ and 2- in “BRIDGED” mode. Any other combination may impair final audio quality
When operating in BRIDGED mode, always make sure that the resulting load impedance of the installation is never below 4 .
The connection cable that joins the amplifiers outputs and the loudspeakers must be of good quality, sufficient section and as short as possible. This is most important when the distances to cover are long ones i.e. up to 10 meters it is recommended to use a section not inferior to 2.5mm2 and for superior distances 4mm2.
4. OPERATION AND USAGE
4.1. Start up
Pushing the switch button (5) lights up the integrated pilot light and both red "PROT" (4) LEDs during the approximately 10 seconds needed to stabilize all voltages. The "PROT" LEDs will then turn off meaning that the amplifier is now operative.
In a complete audio installation, it is important to start up the equipment in the following sequence: sound sources, mixer, equalizers, active filters and finally power amplifiers. To turn them off the sequence should follow an inverse pattern.
4.2. Input attenuators
This consists of rotative potentiometers, situated on the front panel (1).
These attenuators enable the connection of different types of mixing tables, independent regulation level and loudspeaker connections that allow an inferior power level that the level already supplied by the power amplifier at its maximum power, with no danger of damaging, by careless handling, the volume of the pre-amplified mixer.
Inside the device's packaging you will find a little plastic bag containing 2 transparent caps which protect the input attenuation settings from unwanted manipulation. These caps are transparent in order to let you visualize the current settings.
Once inserted, they cannot be removed with bare fingers, for this purpose, a small screwdriver is needed.
6
4.3. Indicators
XPA amplifiers include a simple yet effective indication system.
PROT indicators (4) show the absence of loudspeaker output signal. These indicators may light up for following reasons:
1.During start-up, until the STANDBY time has passed. This time period is needed for the internal operating voltages to settle.
2.A short circuit is detected at the loudspeaker terminals.
3.The amplifier is outputting direct current or very low frequency signals that could damage the loudspeaker.
In any case, should these indicators light permanently, this is a sign of malfunction and the causes should be investigated.
The clip indicators (3) light up just before the actual clipping threshold at the loudspeaker output is reached. The clip detection circuit considers supply voltage oscillations, so that a dependable clip reading is achieved, even when operating with unstable mains voltage. It is usual that the CLIP indicators shine following the bass frequencies when the amplifier operates at high power levels, as these frequencies carry the main energy. Take care that the CLIP indicators are not permanently lit.
Signal presence indicators SP (2) show the presence of a signal at the amplifier inputs. They light up when the input level is greater than -40dB.
5. CLEANING
The front panel should not be cleaned with dissolvent or abrasive substances because silk-printing could be damaged. To clean it, use a soft cloth slightly wet with water and neutral liquid soap; dry it with a clean cloth. Be careful that water never gets into the amplifier through the holes of the front panel.
7
ÍNDICE |
|
|
|
|
1. NOTA IMPORTANTE |
09 |
|
|
|
1.1. Precauciones |
09 |
|
|
|
2. INTRODUCCIÓN |
09 |
|
|
|
2.1. Prestaciones |
09 |
|
|
|
3. INSTALACIÓN |
10 |
|
|
|
3.1. Ubicación, montaje, ventilación |
10 |
|
|
|
3.2. Conexión a red |
10 |
|
|
|
3.3. Conexiones de entrada de señal |
10 |
|
|
|
3.4. Filtro subsónico |
10 |
|
|
|
3.5. Circuito limitador |
11 |
|
|
|
3.6. Conexiones de salida |
11 |
|
|
|
4. FUNCIONAMIENTO |
11 |
|
|
|
4.1. Puesta en marcha |
11 |
|
|
|
4.2. Atenuadores de entrada |
11 |
|
|
|
4.3. Indicadores |
12 |
|
|
|
5. LIMPIEZA |
12 |
|
|
|
6. DIAGRAMAS |
23 |
|
|
|
6.1. Diagrama de conexión |
23 |
|
|
|
6.2. Características técnicas |
24 |
|
|
|
6.3. Diagrama de bloques |
25 |
|
|
|
6.4. Lista de funciones |
26 |
|
|
|
6.5. Diagrama de funciones |
27 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Todos los datos están sujetos a variación debida a tolerancias de producción. ECLER S.A. se reserva el derecho de realizar cambios o mejoras en la fabricación o diseño que pudieran afectar las especificaciones.
8
1. NOTA IMPORTANTE
¡Enhorabuena!. Vd. posee el resultado de un cuidadoso diseño y una esmerada fabricación. Agradecemos su confianza por haber elegido nuestro amplificador XPA.
Para que pueda conseguir la máxima operatividad y un funcionamiento perfecto, antes de su conexión es MUY IMPORTANTE que lea detenidamente las consideraciones que se detallan en éste manual.
Para asegurar el óptimo rendimiento del aparato, su mantenimiento debe ser realizado por nuestros Servicios Técnicos.
1.1. Precauciones
El amplificador XPA11000/7000/5000/3000 tiene un consumo de 1230, 775, 675 y 575VA (a 1/8 de la potencia máxima, según especificación de la norma EN 55103-1), se recomienda una acometida de sección no inferior a 2.5mm2 y un disyuntor magnetotérmico igual o superior a 25A@230VAC para XPA11000, 15A@230VAC para XPA7000 y 10A@230V para XPA3000/5000 (datos para una etapa).
La etapa debe conectarse a una toma de tierra en condiciones (Resistencia de tierra, Rg=30 o menos). El ambiente de trabajo deberá ser seco y estar totalmente libre de polvo. No exponga el aparato a la caída de agua o salpicaduras, no ponga encima objetos con líquido ni fuentes de llama desnuda, como velas. No obstruya los orificios de ventilación con ningún tipo de material. En caso de requerir alguna intervención y/o conexión-desconexión del amplificador debe desconectarse previamente la alimentación.
No manipular los terminales de salida hacia el altavoz con la etapa en marcha; se hallan presentes
tensiones de hasta 400Vpp. El cableado de la salida debe ser realizado por personal técnico cualificado o usar cables flexibles ya preparados. En el interior del amplificador no existen elementos manipulables por el
usuario.
2. INTRODUCCIÓN
High efficiency mosfet amplifier.
La línea de amplificadores Ecler XPA ofrece la reconocida fiabilidad profesional de los amplificadores Ecler
a un precio asequible. Está compuesta por 4 modelos de 300, 500, 700 y 1100W RMS por canal a 4 . Todos los modelos emplean tecnología mosfet, de 2 unidades rack de altura y están montados en un robusto chasis con carátula de aluminio. Gracias a su fuente de alimentación sobredimensionada el amplificador puede trabajar
confortablemente a 4 e incluso a 2 .
Equipan entradas balanceadas mediante conectores XLR3 y jack de ¼”. Sus salidas ofrecen una total
versatilidad pues disponen de bornas de seguridad con distancia normalizada así como conectores Speakon . Incorporan asimismo un sistema electrónico de limitación para evitar saturación de señal así como filtro subsónico conmutable.
2.1.Prestaciones
-Efectivo sistema de ventilación progresiva cuyo caudal aumenta en función de la temperatura del amplificador. El aire entra en el amplificador por el posterior y se expele por el frontal.
-Controles de atenuación de entrada en panel frontal fácilmente accesibles y con posibilidad de precintado mediante el sistema exclusivo de Ecler.
-Indicadores de presencia de señal (SP), recorte (CLIP) y activación de protecciones (PROT).
-Efectivo sistema de protecciones contra cortocircuito, sobrecalentamiento por bloqueo accidental de ventilación u otras circunstancias, señal continua... para proteger al amplificador y altavoces.
-Circuito anticlip incorporado siempre activo.
-Filtro subsónico conmutable a 30Hz y con pendiente de 18 dB oct.
-Selector de modo de trabajo: STEREO, PARALLEL y BRIDGE.
-Selector de sensibilidad de entrada (0,775 / 1 / 1,4 V).
-Entradas simétricas mediante conectores XLR3 y jack estéreo 6,35 mm.
-Salidas mediante bornas y conectores Speakon .
-Admiten funcionamiento a 8, 4 y 2 o 4 en modo puente.
-Garantía: 2 años.
9
