GE
Oil & Gas
RPS/DPS 8000
High Accuracy Resonant
Pressure Sensor
Since 1972, Druck has manufactured precision
pressure sensors with a capability to meet critical
applications in industrial, aerospace, oil and gas,
and research environments. Today, Druck is
part of GE Oil & Gas and has continually worked
to develop and improve on the performance of
our pressure sensors to meet our customers’
requirements.
The RPS/DPS 8000 is the rst product to
incorporate the exciting new TERPS technology.
TERPS is a resonant silicon pressure sensor
technology platform that provides an order of
magnitude greater accuracy and stability than
current pressure measurement technologies
available. The new TERPS technology also extends
the pressure range capability to high pressures
and, by incorporating true pressure media
isolation, greatly improves its suitability for use in
harsh environments.
Features:
• High Precision, ±0.01% FS over compensated
temperature range
• High Stability, ±100 ppm FS/year
• Wide temperature range, up to -40°C to +125°C
(-40° to 257°F)
In addition to providing the performance and
packaging improvements available with TERPS,
the RPS/DPS 8000 product line takes advantage
of best practices to oer a wide range of pressure
and electrical connections to enable a level of
customization for your specic requirements never
before available in the performance class of this
sensor.
The combination of the power of the TERPS
technology and the quality, reliability and exibility
of the RPS/DPS 8000 Series oers a truly unique
solution for high accuracy and high stability
pressure measurement requirements.
• Media isolated construction, suitable for use in
harsh environments
• Multiple Output congurations, RS-232, RS-485,
USB 2.0, CAN Bus, Frequency & Diode (TTL)
• Wide selection of pressure & electrical
connections to suit specic requirements
Specications
Measurement
Base Pressure Ranges
• 0 to 2 bar (0 to 30 psi) absolute
• 0 to 7 bar (0 to 100 psi) absolute
• 0 to 14 bar (0 to 200 psi) absolute
• 0 to 20 bar (0 to 300 psi) absolute
• 0 to 35 bar (0 to 500 psi) absolute
• 0 to 70 bar (0 to 1000 psi) absolute
Note: Values in psi are approximate.
The base range selected is the next range up from
the requested calibrated range.Units are converted to
bar for selection; e.g., 30 psi = 2.07 bar. A 7 bar base
pressure range will be selected.
Calibrated Ranges
Any zero-based range between 1 and 70 bar (14.5 to
1000 psi) can be specied. (Performance will be of the
full scale of the base pressure range selected.)
Barometric ranges are available in the RPS/DPS 8100
series. The lowest calibrated pressure is 35 mbar
absolute.
Overpressure
1.5X FS
Sensor Failure Pressure
2.0X FS
Pressure Containment
• Ranges to 7 bar (100 psi), 70 bar (1,000 psi)
• Ranges to 70 bar (1,000 psi), 200 bar (3,000 psi)
Supply and Output
Electronics
Option
1 6 to 28 Frequency &
A 7 to 28 RS485 16.5 quiescent, 32 max
B 9 to 28 RS232 16.5 quiescent, 32 max
C 7.5 to 30 CAN Bus 25 quiescent, 32 max
U 4.8 to 5.2 USB 2.0 40 quiescent, 100 max
1. Jitter less than 20 ns
2. Full temparature range
3. Square wave pressure signal, 25 kHz nominal, 4-10 kHz span
4. Forward voltage diode, 0.5 to 0.7 V @ 25°C (77°F), typically
–2 mV/°C nominal
Supply
Voltage
(V DC)
Output Current
Consumption
(mA)
3.5
Diode TTL
(1,3,4)
(2)
Response Time
< 300 msec for pressure change from 10% to 90% FS
Supply Response
TTL: Accurate to specication within 500 ms of power
up, over all operating temperatures
RS232/RS485/CAN Bus/USB: Accurate to specication
within 10 min of power-up
Electrical Protection
RS232/485/CAN Bus/TTL:Connecting V
between any combinations of pins on the connector will
not damage the unit
supply
and GND
Insulation
500 V DC
Performance
There are two levels of performance specication:
standard and Improved
Specications include combined eects of non-linearity,
hysteresis, repeatability and temperature errors over
the compensated temperature range, and over the base
pressure range of 35 mbar to the full scale pressure.
Accuracy Code Precision
A1- Standard 0.02% FS
A2- Improved 0.01% FS
• For Frequency & Diode output, the above accuracies
are achievable by using a polynomial curve t
algorithm and coecient data supplied with sensor.
• Sensors are calibrated against standards traceable to
UKAS operating to better than 100 ppm.
Compensated Temperature Ranges:
There are four compensated temperature ranges
available:
-10 to +50°C
-40 to +85°C
-40 to +125°C (TTL and CAN bus only)
-55 to 125°C (TTL and CAN bus only)
Temperature Eects
All temperature eects are included in the accuracy
statement.
Long Term Stability
Standard: ±0.02% FS/annum
Improved: ±0.01% FS/annum
Note: Unless otherwise specied, specications are at the
reference conditions of 25°C (77°F) ±5°C (±9°F) and 1 bar
(14 psi).
Orientation (g) Sensitivity
Less than 0.2 mbar/g
Physical Specications
Storage Temperature Range
As compensated temperature range.
Please ensure that only the intended sealing face is
used when mounting the sensor. Failure to comply with
this requirement may aect performance or calibration
accuracy.
Operating Temperature Range
As compensated temperature range.
Pressure Media
Fluids compatible with 316L stainless steel and
Hastelloy C276
Ingress Protection
See Electrical Connector section
Vibration
BS EN 60068-2-6 (2008) Sine sweeps 5 Hz to 2 kHz,
levels to 20g
n
BS EN 60068-2-64 random 10 Hz to 2kHz to 4gn RMS for
1 hour each axis
Less than 0.02% FS effect at any time
Shock
DO-160E 9 (Figure 7.2) 20 gn 11 ms terminal
saw-tooth prole
Humidity
MIL-STD-810D Method 507.2 Procedure III
(Aggravated humidity environment, 65°C, 95% RH)
Pressure Connector
Available Options are:
• G1/4 Female
• G1/4 Male Flat
• G1/4 Male 60° Internal Cone
• G1/8 Male 60° Internal Cone
• 1/4 NPT Female
• 1/4 NPT Male
• 1/8 NPT Male
• M20 x 1.5 Male (3mm bore)
• M14 x 1.5 60° Internal Cone
• M12 x 1 Internal Cone
• 7/16-20 UNF Male 74° External Cone
• G1/2 Male
• G1/4 Quick Connect
• 1/2 NPT Male
• G1/4 Male Flat Long
• 7/16-20 UNF Female
• Depth Cone (G1/4 Female)
• 7/16-20 UNF Male Short Flat
• 3/8-24 UNJF
• Other pressure connectors may be available.
Contact GE to discuss your requirement.
Male threaded pressure connectors must not be sealed
or constrained against the face at the base of the
thread. The forward cone or at face should always be
used, as indicated below.
Electrical Connector
Code
Description Max Operating
No.
0 No Connector -55 to +125 -67 to +257 -
1 Cable Gland -40 to +80 -40 to +176 65
2 Raychem Cable -55 to +125 -67 to +257 65
3 Polyurethane Depth -40 to +80 -40 to +176 68
4 Hytrel Depth -40 to +80 -40 to +176 68
6 Bayonet MIL-C-26482 -55 to +125 -67 to +257 *
C 1/2 NPT Conduit -40 to +80 -40 to +176 67
G M12 X 15-pin -55 to +125 -67 to +267 *
H PTFE Cable (Orange) -55 to +125 -67 to +267 54
M Micro USB socket -40 to +85 -40 to +176 -
Temp. Range
°C °F
IP
Rating
* Hermetically sealed connectors with a maximum leak
rate of 1 x 10
-6
cc/s at 1 atmosphere. High IP rated
mating connectors are available.
Certications
• CE Marked
• RoHS
• EMC Standards:
BS EN 61000-6-1: 2007, Susceptibility - Light Industrial
BS EN 61000-6-2: 2005, Susceptibility - Heavy
Industrial
BS EN 61000-6-3: 2007, Emissions - Light Industrial
BS EN 61000-6-4: 2007, Emissions - Heavy Industrial
BS EN 61326-1: 2013, Electrical Equipment for
Measurement, Control and Laboratory Use EMC requirements
BS EN 61326-2-3:2013 Requirements for pressure
transducers
Connection Details
Option Code Connection Function
Frequency
& Diode
Flying Leads 0 RED SUPPLY +VE SUPPLY +VE SUPPLY +VE SUPPLY +VE
YELLOW FREQ RS485 B Rx CAN Hi
GREEN +VE TEMP RS485 A Tx CAN Lo
BLUE GROUND GROUND GROUND SUPPLY -VE
BLACK -VE TEMP - - CAN 0V
ORANGE EEPROM - - -
Option Code Connection Function
Frequency
& Diode
CABLE 1, 3, 4, C RED SUPPLY +VE SUPPLY +VE SUPPLY +VE SUPPLY +VE
YELLOW FREQ RS485 B Rx CAN Hi
BLUE +VE TEMP RS485 A Tx CAN Lo
WHITE GROUND GROUND GROUND SUPPLY -VE
BLACK -VE TEMP - - CAN 0V
ORANGE EEPROM - - -
SCREEN - - - -
DigitalRS485
DigitalRS485
Digital RS232
Digital RS232
Digital CAN Bus
Digital CAN Bus
Option Code Connection Function
Frequency
& Diode
M12 G 1 SUPPLY +VE SUPPLY +VE SUPPLY +VE N/C
2 FREQ RS485 B Rx SUPPLY +VE
3 GROUND GROUND GROUND SUPPLY -VE
4 +VE TEMP RS485 A Tx CAN HI
5 EEPROM - - CAN LO
Option Code Connection Function
Frequency
& Diode
PTFE H RED SUPPLY +VE SUPPLY +VE SUPPLY +VE SUPPLY +VE
YELLOW FREQ RS485 B Rx CAN Hi
GREEN +VE TEMP RS485 A Tx CAN Lo
BLUE GROUND GROUND GROUND SUPPLY -VE
BLACK EEPROM
WHITE -VE TEMP
SCREEN CASE CASE CASE CASE
DigitalRS485
DigitalRS485
Digital RS232
Digital RS232
- - -
- -
Digital CAN Bus
/CAN 0V
Digital CAN Bus
CAN 0V
Option Code Connection Function
Frequency
& Diode
RAYCHEM 2 RED SUPPLY +VE SUPPLY +VE SUPPLY +VE SUPPLY +VE
WHITE FREQ RS485 B Rx CAN Hi
GREEN +VE TEMP RS485 A Tx CAN Lo
BLUE GROUND GROUND GROUND SUPPLY -VE
BLACK EEPROM - - -
SCREEN - - - -
Option Code Connection Function
Frequency
& Diode
MIL-C 6 A SUPPLY +VE SUPPLY +VE SUPPLY +VE SUPPLY +VE
B FREQ RS485 B Rx CAN Hi
C +VE TEMP RS485 A Tx CAN Lo
D GROUND GROUND GROUND SUPPLY -VE
E EEPROM - - -
F -VE TEMP - - CAN 0V
DigitalRS485
DigitalRS485
Digital RS232
Digital RS232
Digital CAN Bus
/CAN 0V
Digital CAN Bus
Option Code Connection Function
Frequency
& Diode
Micro-USB M 1 - - +5 V -
2 - - D-VE
3 - - D+VE
4 - - ID
5 - - GROUND
Maximum
Cable length
(m)
Frequency &
Diode
10 10 1000 1000 2
DigitalRS232
DigitalRS485
Digital RS485
Digital RS232
CAN Bus USB*
Note 1: Cable not provided with USB option.
Digital CAN Bus
1
MALE PRESSURE CONNECTION
Dimensional Drawings
FEMALE PRESSURE CONNECTION
8 (0.31)
22 A/F
(0.86)
14.5
(0.57)
16
(0.62)
DEPTH CONE
PRESSURE ADAPTOR
25 TYP
(0.98)
Ø
25 (0.98)
MEDIUM PRESSURE CONSTRUCTION
LOW PRESSURE CONSTRUCTION
42 (1.65)
32
(1.25)
CONDUIT WITH POLYURETHANE CABLE
22 A/F
(0.86)
Ø 25
(0.98)
15.5 (0.61)
81 (3.18)
Supply: *** T
Output: *** T
Temp. Range: DRUCK LTD. GR
84 (3.30)
Supply: *** T
Output: *** T
Temp. Range: DRUCK LTD. GR
25.5 (1.00)
MICRO USB SOCKET
*** TO *** ba
*** TO *** ba
S/N *******
S/N *******
RPS800
PRESSU #### 8000
25
Ø 25 (0.98)
(0.98)
RPS800
PRESSU #### 8000
25
Ø
(0.98)
Ø
7 (0.27)
4 (0.16) 24 (0.94) TYP
CRIMP & BOOT PU CABLE IP65
21 TYP
(0.82)
RAYCHEM CABLE
60 (2.36)
25
Ø
(0.98)
DEPTH CABLE
7 (0.27)
25
Ø
(0.98)
24 AWG 7/0.2 PTFE CABLE
15 TYP (0.53)
17
(0.66)
22 A/F
(0.86)
25
25 (0.98)Ø
Ø
(0.98)
Notes:
1. All dimensions are nominal lengths and are subject to change.
2. All dimensions are in millimeters (inches).
3. Other pressure and electrical connectors may be available, please contact GE.
4. Low Pressure < 7 bar (100 psi)
5. Medium Pressure >7 bar (100 psi) and < 70 bar (1,000 psi)
Ordering Information
(1) Select model code
Main Product Variant
RPS Resonant Pressure Sensor - Frequency & Diode Output (Note 1)
DPS Digital Pressure Sensor - Digital Output (Note 1)
Diameter, Material and Isolation
80 25mm Stainless Steel Oil isolated
Electrical Connector
0 No Electrical Connector (Flying leads)
1 Polyurethane Cable IP65
2 Raychem Cable
3 Polyurethane Cable (Depth) IP68
4 Hytrel Cable (Depth) IP68
6 MIL-C-26482 (6-pin Shell Size 10)
C 1/2” NPT Conduit with Polyurethane Cable (Non-Exd Only)
G M12x1 5-Pin
H Orange PTFE Cable
M Micro USB socket (Note 4)
Output Option (Note 6)
1 Frequency & Diode (TTL)
A RS485
B RS232
C CAN Bus
U USB 2.0 (Note 5)
Compensated Temperature Range
TA -10 to +50 °C
TB -40 to +85 °C (Note 2)
TC -40 to +125 °C (Note 2 & 3)
TD -55 to +125 °C (Note 2 & 3)
Accuracy
A1 - Standard 0.02%
A2 - Improved 0.01%
Calibration
CC Full Thermal Calibration
Hazardous Area Approval
H0 None
Pressure Connector
PA G1/4 Female
PB G1/4 Male Flat
PC G1/4 Male 60° internal Cone
PD G1/8 Male 60° internal Cone
PE 1/4 NPT Female
PF 1/4 NPT Male
PG 1/8 NPT Male
PH M20x1.5
PJ M14x1.5 60° Internal Cone
PK M12x1 Internal Cone
PL 7/16-20 UNJF Male 74 degree external cone
PN G1/2 Male
PQ G1/4 Quick Connect
PR 1/2 NPT Male
PT G1/4 Male Flat Long
PV 7/16-20 UNF Female)
PW Depth Cone (G1/4 Female)
PX 7/16-20 UNF Male Flat
PY 3/8-24 UNJF
RA 1/4 VCR Female
RF 1/4 VCR Male
RPS 80 4 1 - TA - A2 - CC - H0 - PA [Typical Model Code]
Note 1: RPS variants require Output Option Code ‘1’. DPS variants require Output Option Code ‘A’, ‘B’, ‘C’ or ‘U’.
Note 2: Pressure ranges 2 and 7 bar (30 and 100 psi) are not available at this temperature range.
Note 3: Requires Output Option Code ‘1’ or ‘C’ and Electrical Connector Codes ‘0’, ’2’, ’6’, ’G’, or ’H’.
Note 4: Only available with USB output option.
Note 5: Only available with micro USB socket connector.
Ordering Information (cont.)
2) State pressure range and units (e.g., 0 to 20 bar, 0 to 100 psi):
Unit options are:
Symbol Description
bar bar
mbar millibar
psi pounds/sq. inch
Pa Pascal
hPa hectoPascal
kPa kiloPascal
MPa megaPascal
mmH2O mm water
cmH2O cm water
mH2O metres water
inH2O inches water
ftH2O feet water
mmHg mm mercury
inHg inches mercury
kgf/cm2 kg force/sq. cm
atm atmosphere
Torr torr
3) State cable lengths and units e.g., 1 m cable, 3 ft cable (only required on certain electrical connectors):
Note 6: Maximum Cable length: (1) Frequency & Diode - 10 m, (A) RS485 - 1000 m, (B) RS232 - 10 m, (C) CAN Bus - 1000 m.
Integer values only, e.g. 1m (3 ft) cable. Minimum cable length is 1m (3 ft) if cable is supplied.
Typical order examples:
RPS 8011-TA-A1-CC-H0-PA, 0-7 bara, 5 m cable
DPS 806A-TB-A2-CC-H0-PL, 0-1,000 psia
www.gemeasurement.com
920-519H
© 2016 General Electric Company. All Rights Reserved. Specications are subject to change without notice. GE is a registered trademark of General Electric Company. Other company or product names
mentioned in this document may be trademarks or registered trademarks of their respective companies, which are not aliated with GE.
Loading...
