Primo 405 by Doro
Operating Instructions
1
2
3
4
5
6
7
8
9
10
11
12
13
14
17
16
15
18
20
19
21
U2
1. Receiver
loudspeaker Making phone calls holding the cell phone to the ear
2. Display
3. Left soft key Selection of the main menu
Right soft key Opening the telephone directory
4. Call button Dialling and answering call; opening the call log.
5. Arrow keys In idle state for opening the quick access list.
for opening the message.
Scrolling up and down in menus and lists.
6. Speed-dial buttons Speed-dialling of the numbers saved under
M1 and M2 with one keystroke
7. * key In idle state: to enter: “*”/ “+” / “P”/“W“;
Input of text: input of special characters
8. # key In idle state: long keystroke to toggle between ring tone
on/off; For inputs: shifting between input modes.
9. Microphone
10. Numerical keys In idle state: input of phone number;
long keystroke on 1: calling the voice mail box (telephone number must be saved);
11. Torch button Switches the torch on/off
12. Exit key Exiting a call, returning to idle state; switching the phone
on/off
13. Headset connector For standard headset with 3.5 mm phone jack
14. +/- keys Sets the volume of ring tone/loudspeaker
15. LEDs Notification of missed calls and received text mes-
sages
Charging of battery
16. Camera lens
17. Flash LED / Torch
18. Loudspeaker For hands-free mode and ringing
19. Micro USB port For battery charger or connection to PC
20. Charging contact To charge the device in the charging cradle
21. Charging cradle To charge the telephone
i
ii
Contents
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Inserting the SIM card, memory card and rechargeable battery . . . . . . . . . .4
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Auxiliary functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Display status symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Activating the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Standby (Idle mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Changing the language, time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Making phone calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Selecting phone numbers from the phone directory . . . . . . . . . . . . . . . . . . . .9
Answering a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Volume control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Entering text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Call options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Call information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Silent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Telephone book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Creating an entry in the telephone book . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
My number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Creating ICE entry (In Case of Emergency) . . . . . . . . . . . . . . . . . . . . . . . . .14
Managing phonebook entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
ICE (In Case of Emergency) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
1
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Creating and sending SMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Creating and sending MMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Inbox, Sent, Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Call history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Camera (take photos) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Image viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Audio player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
File manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Connecting the phone to a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Drag and drop content between phone and a computer . . . . . . . . . . . . . . .25
Disconnect the USB cable safely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Basic settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Voice mail (Mailbox) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Network settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Security settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Restore factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Bluetooth® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Data accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
SMS settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
MMS settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Settings for service message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
User profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
2
Organizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
File manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Magnifying glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Network services and fees . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Operating environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Medical devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Cardiac pacemakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Explosive areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Protection from too high volume at the ear . . . . . . . . . . . . . . . . . . . . . . . . . .46
Emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Warranty and service information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Specific Absorption Rate (SAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .U3
Approval and Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .U3
3
Installation
Package contents
• 1 mobile phone
• 1 energy-efficient switch-mode power supply
• 1 charging cradle
• 1 rechargeable battery Li-Ion 3.7 V / 1.000 mAh
• 1 micro-SD memory card (128 MB/already installed)
• 1 stereo headset
• 1 operating instructions
IMPORTANT!
First switch the phone off and disconnect it from the battery charger before you
remove the cover of the battery compartment.
Inserting the SIM card, memory card and rechargeable battery
The SIM card and memory card holder are located behind the rechargeable battery.
1. Remove the cover of the battery compartment by placing a thumb on the
cover’s riffle on the rear of the telephone casing and pushing the cover
downwards. If the rechargeable battery is inserted, remove it by lifting it on
the notch at the top using a finger nail.
2. Insert the SIM card by carefully pushing it under the metal bracket on the
lower side. Make sure the contacts of the SIM card point downwards and the
cut-off corner fits exactly in the recessed shaping of the holder. The contacts
of the SIM card must not be scratched or bent. Try not to touch the contacts
with your fingers.
4
3. Micro-SD card
To use the performance features of your phone that require more memory, in
particular photos, music etc., a micro SD memory card is needed. In your
phone a 128 MB memory card is already installed.
For replacing proceed as follows:
Slightly press onto card holder on the left side and carefully push it in
towards the left hand casing edge. The memory card holder now can be folded up vertically. Remove the old memory card and place the new memory
card in the black plastic holder in a form- locking manner. Make sure the
contacts of the memory card point downwards and the "lug" is placed in the
marked area. The contact of the memory card must not be scratched or
bent.
Push the metal bracket back down, pressing it flat and slide it away from the
edge of the housing until it snaps into place.
4. Insert the rechargeable battery by pushing it into the battery compartment
ensuring that the three contacts on the front touch the three spring contacts
on the bottom in the battery compartment.
5. Replace the cover and push it upward using gentle pressure with the thumb
until it snaps securely into place again.
IMPORTANT!
Use memory cards that are compatible with this device only. Compatible card
types are: micro SD, micro SDHC. Incompatible cards may damage the card
itself, the device as well as the data saved on the card.
5
Charging
CAUTION
Use rechargeable batteries, battery chargers and accessories that are
approved for this specific model only. Connecting other accessories involves
risks and may lead to the lapse of the approval of the device type and the loss
of warranty.
When the battery performance is low, the empty battery symbol flashes to indicate the battery state and an alarm signal will sound. To recharge the battery,
connect the mains adapter to the micro USB connector on the bottom side of the
phone. Alternatively, you can place the telephone into the charging cradle connected to the mains adapter.
When the battery charger is connected to the phone, the red charging LED is
on. The battery charge status moves when the battery is charging (visible in the
upper right corner of the display).
A complete charging process of the rechargeable battery takes approximately 3
hours. When the battery is fully charged the animation of the battery charging
status stops.
Note!
To save energy, the lighting goes out after a while. Press any key to activate
the display lighting.
The full battery power is reached once the rechargeable battery has been
charged 3 - 4 times. The battery performance decreases over time. This
means calling and stand- by times become shorter with regular use.
Saving energy
When the rechargeable battery is fully charged and you have disconnected the
battery charger from the device, remove the plug of the charger from the main
socket.
6
Symbols
Auxiliary functions
The following symbols refer to information on auxiliary functions in the operating
instructions for:
visibility handling
listening safety
Display status symbols
Signal strength
Battery charging status
New entries in the call log (missed calls)
An alarm time is set
Bluetooth enabled
Existing GPRS connection
Headset connected
USB connection
MMS is being sent
Only vibration
Sound and vibration
First vibration, then sound
Unread SMS
Unread MMS
Indicates that a micro SD card is inserted.
7
Operation
Activating the phone
Hold the read button on the telephone for approx. 5 seconds to turn it
on/off.
If the SIM card is valid but protected with a PIN code (Personal Identification
Number), Enter PIN is displayed.
Enter the SIM PIN code and press OK ( upper left corner of keypad). Delete
with Delete ( upper right corner of keypad).
Note!
If no PIN and PUK codes were delivered with your SIM card or you no longer
have the PIN or PUK codes, please contact your provider.
Remaining attempts shows the number of PIN attempts left. If no attempts are
left, PIN blocked will be shown. The SIM card then must be unblocked using
the PUK code (Personal Unblocking Key).
1. Enter the PUK code and confirm with OK.
2. Enter a new PIN code and confirm with OK.
3. Enter the new PIN code again and confirm it with OK.
Standby (Idle mode)
When the phone is operational and you have not performed any keystroke, the
phone is in the standby mode.
The left soft key in the standby mode is for Menu.
The right soft ke y in the standby mode is for Names.
Tip:
You can press at any time, to return to the standby mode.
8
Changing the language, time and date
The default language is determined by the SIM card. See Telephone settings,
starting from page 27, for changing the language, time and date.
Making phone calls
1. Enter the phone number with the area code. You can delete digits with
Delete.
2. Press to dial. Press Cancel to cancel dialling.
3. Press to end the call.
Tip:
For international calls, always enter a + symbol before the country code to be
able to use the address book optimally in any country.
Press the * button twice to enter an international area code.
Selecting phone numbers from the phone directory
1. Press Names to open the phone directory.
2. Use the arrow buttons to scroll through the telephone directory or
perform a quick search by pressing the key that corresponds to the initial letter of the entry in the directory, see Entering text , p. 10.
3. To dial the desired entry, press Call or press Back, to return to standby
mode.
Answering a call
1. Press or Answer to accept the call or press Reject to reject the call
(busy signal).
Alternatively, you can press to reject the call directly.
2. Press to end the call.
9
Volume control
You can adjust the volume during a call using the side buttons +/–. The volume
will be shown on the display.
Entering text
You can enter texts by repeatedly pressing the numeric keys for selection of the
characters. Repeatedly press the corresponding key until the desired character
is displayed. Wait until the blue background of the current character has disappeared until you enter the next one.
With * you can display a list of special characters. Select the desired character
using or * and # to move left or right and press OK to enter.
Use the keys , to move the cursor within the text.
With # you can shift between upper-case and lower-case letters and numeric
characters. The symbol at the top left in the display indicates the input mode:
Abc Capitalization of the first letter after a full stop (beginning of sentence).
ABC CAPITALISATION
abc lower-case letters
123 numeric characters
Call options
During a call, you can access other functions using the soft keys ( ):
Options (left soft key)
A menu with the following options will be displayed:
Hold/Retrieve Hold/continue current call.
End single call End current call (as with ).
Phonebook Search telephone book.
Call history Open call history.
Messaging Read or write SMS messages.
Mute Turn off microphone.
10
H-Free (right soft key)
Activates the loudspeaker so you do not have to hold the
phone to your head while speaking. Speak clearly into the
microphone from a distance of maximum 1 m. Using the side
buttons +/-, you can set the volume of the loudspeaker.
Press H-Held to return to normal mode.
Attention:
Before you switch to loudspeaker, hold the device at least 1 m from
your ear to avoid loud noises that might accidentally damage your
ear!
Note!
The handsfree function allows only one person at a time to talk. Switching between talk/listen is triggered by the sound of the person talking. Loud noises
(music, etc.) in the background may interfere with the function.
Call waiting
An alert tone will be heard if there is an incoming call while talking. To put the
current call on hold and answer the incoming call, press Options, select Ans-
wer and press OK.
Tip:
Call waiting must be activated, see Call waiting, p. 30.
Call information
During a call, the outgoing or incoming phone number and the elapsed call time
is displayed. If the identity of the caller is withheld, Unknown is displayed.
11
Silent
Silent is a fixed profile with Keypad tone, Message tone and Ring tone disabled,
while Vibration, Tasks and Alarm are unchanged.
Tip:
Press and hold shortcut button # to activate/deactivate Silent.
Headset
When a headset is connected, the internal microphone in the phone is automatically disconnected.
When receiving a call you can use the answer key on the headset cable (if it has
one) to answer and end calls.
CAUTION
Using a headset at high volume may damage your hearing. Adjust the volume
level carefully when using a headset.
Emergency calls
If the telephone is switched on, you can make an emergency call at any time by
entering the emergency number valid in the respective country and then pressing .
In some networks emergency calls are permitted even without a valid SIM card.
For more information contact your network provider.
Note!
Please also note that since 2009 it is no longer possible to call the emergency
number 112 in Germany without an activated SIM card.
Credit is not required – however, the SIM card must be registered and activated.
The misuse of the emergency number 112 may be persecuted and punished with a fine.
12
Telephone book
300 entries can be stored in the phone's telephone book. The number of entries
that can be stored on the SIM card depends on the respective SIM card.
Creating an entry in the telephone book
1. Press Menu, scroll to Phonebook and press OK.
2. Select Add new contact and press Add.
3. Select whether you want to save the contact on the SIM card or in the telephone.
4. Enter a name for the contact, see Entering text , p. 10. You can delete
with Clear.
5. Press .
6. Enter the telephone number including the area code.
7. Press .
8. As an option, you can select a different caller image for the contact using the
keys * and #. You have the choice between standard or an image saved
as file in the telephone.
9. Press .
10. Optionally, you can select a different ring tone for the contact by using the
keys * and #.
11. Then press Options, select Save and press Select.
Tip:
For international calls, always enter a + symbol before the country code to be
able to use the address book optimally in any country.
Press the * button twice to enter the international area code +.
13
My number
Here, you enter your own mobile number or landline number.
Select View -> OK, press Add…, then enter your name and number and press
Options to Save the number or to end the process with Cancel.
Creating ICE entry (In Case of Emergency)
With this additional information and medical information, first responders can
access this information from the victim's phone in case of emergency. In the
event of a trauma, it is critical to have this information as early as possible which
can increase the chances of survival. All fields are optional, but the more information you provide, the better. See ICE (In Case of Emergency) , p.16 for configuring your ICE information.
Managing phonebook entries
1. Press Menu, scroll to Phonebook and press OK.
2. Select a contact and press Options.
3. Select one of the following options and press OK:
View - Show details for the selected contact.
Send text message - Press Select to create an SMS message, see Create
and send SMS, p. 17.
Send multimedia message - Press Select to create an MMS message,
see Create and send MMS, p. 18.
Call - Press Select to call the contact.
Edit
1. Edit the entry. Delete characters with Clear.
2. Then press Options, select Save and press Select.
Delete - Press Select to remove the selected entry from the telephone
book. Press Yes to confirm or No to cancel.
Copy - Press Select to copy the selected entry from the telephone to the
SIM card or vice versa.
14
Phonebook settings
In this menu, you will find the following options:
Preferred storage - Set the storage location and the view settings for
the contacts (Phone/SIM/ Both). When Both is selected, contacts from
both the SIM and the telephone's memory are displayed.
Top 10 Settings - Defining the ten most important telephone numbers.
Select one of the ten memory locations and press Add … to include the
number in the top 10 list. Contacts from the top 10 list will always be displayed at the top of the phone directory, independent of the initial letter
of the name.
To delete a top 10 entry, select the entry in the top 10 list and press
Options, then select Delete and press OK. The contact will be deleted
from the top 10 list only, and not from the telephone memory or the SIM
card!
Extra numbers - Here, you have the option to define three other numbers as well as a fixed dial-up. For the entry of the Owner numbers
please select a storage space, press Options and then confirm Edit
with OK to enter names and telephone numbers. Confirm each entry
with Save. Fixed dial - The fixed dial-up allows the telephone user to
call only those phone numbers which are saved in the fixed dial-up list.
In order to call other numbers the user has to enter a PIN2. If the SIM
card inserted does not have a PIN2, this function will not be supported.
Memory status - Displays the memory used (Phone/SIM)
Copy contacts - Option to copy selected contacts from the telephone to
the SIM card and vice versa
Move contacts - Option to move selected contacts from the telephone
to the SIM card and vice versa
ATTENTION: The contacts will be deleted from their original location
when moved!
Delete all contacts - All contacts will be deleted from the telephone or
SIM card. This cannot be undone!
15
Add to direct key- Here, you have the option to assign one selected con-
tact each to the direct dialling keys M1 and M2 to be able to call them in the
future through one-touch dialling.
Select one of the storage spaces M1 or M2 for the current contact and then
press on Save. Conform the following query with Yes or cancel the process
with No.
ICE (In Case of Emergency)
In case of emergency, first aiders can get additional, very useful information
through the telephone of the patient. In medical emergencies it is important that
this information is available as fast as possible in order to increase the chances
of survival. All input fields are optional, however, the following applies: The more
information you provide, the better.
1. Press Menu.
2. Select ICE and press OK, then use to scroll the list of entries.
3. Press Edit, to add or edit information in each entry, see Entering text ,
p. 10.
Delete with Clear. After every entry in the ICE menu, press Save.
Name: Your own name.
Birth: Your date of birth.
Height: Your height.
Weight: Your weight.
Language: Your language.
Insurance: Your insurance provider and policy number.
Contact 1/ Contact 2 / Doctor: Press Options, select Add and press OK
to add a contact from the phonebook, select Delete to delete the entry, or
Save to accept the current entry.
Condition: Any medical conditions/medical devices (e.g. diabetic, pacema-
ker).
Allergies: Any known allergies (e.g. penicillin, bee stings).
16
Blood type: Your blood type.
Vaccination: Any relevant vaccination.
Medication: Any medication that you are treated with.
Other info: Other information (e.g. organ donor, living will, consent to treat).
Messaging
Creating and sending SMS
1. Press shortcut button or press Menu, scroll to Messaging and press
OK.
2. Select New and press OK.
3. Type your message, see Entering text , p. 10, then press Options.
4. Select Send to and then Add from Phonebook, select an existing recipient
from the telephone book and press OK.
Alternatively, you can also select Enter number and press OK to manually
add a recipient and then press OK.
5. Press Options again and select Send, to send the message.
6. You can also change the recipient by selecting Edit recipient or delete the
recipient with Remove recipient or Remove all recipients. Selecting Save
to Drafts saves the SMS in the drafts folder for later use.
Note!
If you choose to add multiple recipients, you will be charged for each recipient
(maximum 10). For international calls, always use + before the country code
for best operation. Press * twice for the international prefix +.
Note!
Before you can send any SMS, you need to save your message centre number. The number to your service centre is supplied by your service provider
and is usually set on the SIM card. If not, you can enter the number yourself.
See SMSC address, p. 38.
17
Creating and sending MMS
MMS may contain text and media objects such as images or sound recordings.
Therefore, both you and the recipient need the mobile radio option for MMS and
also a mobile phone which supports sending and receiving of MMS. The setting
parameters for MMS are preset by the large network providers in Germany. With
other mobile radio communication providers these parameters must be modified
manually, if and where required. Contact your provider regarding the parameters
required for this.
For this, select Menu -> Connectivity -> Data accounts. Select the data
account suitable for your provider or adjust it to the settings of your network provider with Options and Edit. Only your network provider will be able to give you
the data necessary for this. After editing press Options and then Save. Afterwards you can return to the start screen using the key. If your provider is
not in the list, see page 36, for setting your MMS account.
1. Press Menu, scroll to Messaging and press OK.
2. Select Multimedia message and press OK.
3. Enter the message, see Entering text , p. 10, then press Options.
4. Add additional elements to your message using the Add picture, Add
sound, Add subject options.
Under Input method select between En (Upper-case letter at the beginning
of sentence), EN (capitalisation), en (lower-case letters) and Numeric
(numerical entry).
With Preview MMS, you can preview the MMS; with the Slide options, you
can add slides before/after and set their time control; under Advanced, you
can add an attachment or with Save to Drafts, save the MMS in the drafts
folder for later use.
5. Select Send to and, using Add from Phonebook, search for an already
existing recipient from the telephone book and press OK.
Alternatively, you can also select Enter recipient and press OK to manually
add a recipient and then press OK.
18
5. Press Options and select Send, to send the message.
Additional options include:
Send options - Settings for Delivery report, Read report, Priority, Delivery time.
Edit recipient - Editing option for the recipient's number
Remove recipient - Delete recipient
Remove all recipients - Delete all recipients
Change to Cc - Recipient get a copy
Change to Bcc - Recipient get a blind copy (not visible for other recipients)
Selecting Save saves the MMS in the drafts folder for later use.
19
Inbox, Sent, Outbox
1. Press shortcut button or press Menu, scroll to Messaging and press
OK.
2. Select Inbox / Outbox / Sent and press OK.
3. Select a message and press View. Use to scroll through the message.
4. Press Options for the following options:
Reply by SMS - Create an SMS to the sender
Reply by MMS - Create an MMS to the sender
Call sender - Call the sender
Forward - Forward the message to another recipient
Delete - Delete the message
Save as template - Save the message as template
Advanced
Use number - The sender's number is available for further use, e.g. to
directly save the number as a contact
Use USSD - If the SMS contains a USSD, this is displayed for further
options.
Copy to phone/SIM - You can copy the SMS from the SIM card to the
telephone and vice versa.
Move to phone/SIM - You can move the SMS from the SIM card to the
telephone and vice versa.
Call history
Missed calls, dialled numbers and answered calls are saved in the call log. 10
calls of each type can be saved. Only the latest call will be saved for multiple
calls to and from the same number.
The total number of call attempts is indicated in brackets.
1. Press to see a list of all calls.
or
Press Menu, scroll to Call history and press OK. Select Call history and
press OK. Select a list and press OK.
20
2. Use to scroll through the list.
3. Press to dial the telephone number or press Options, to access the
following settings:
View - Display details about the selected entry.
Call - Call the number.
Send text message - Send an SMS to the number.
Send multimedia message - Send an MMS to the number.
Save to phonebook - Save the phone number in the telephone book.
Delete - Delete the entry.
Camera (take photos)
To get sharp photos, wipe the lens clean with a dry cloth.
1. Press Menu, scroll to Multimedia and press OK or press to access the
camera using the shortcut.
2. Select Camera and press OK.
3. To take a photo, press 5. With , you can enlarge or reduce the
image prior to taking the photo using digital zoom.
Note!
Zooming can negatively impact the image quality.
4. Press Back to exit the camera or Options, to access the following options:
Photos - Display all saved photos. Scroll through the list using * and #.
Camera settings
LED Light - (Flash) automatic, on and off
Shutter sound - Selection between three different shutter sounds and
off.
EV - adjustment of the light values.
Contrast - low, medium, high
Anti-flicker - 60 Hz are set as default and ideal.
Delay timer - Selection between Off and release delays between 5 and
15 seconds.
21
Image settings
Settings for the Image size and Image quality. The best results are with
the following setting: image size: 640x480 / image quality: good.
For MMS an image size of 640x480 is ideal.
White balance - Select between different profiles for different lighting condi-
tions (e.g. daylight, artificial light …)
Scene mode - setting option Autom. or Night. The night mode enables an
improved picture quality in darkness.
Effect settings - Select between different colour effects.
Restore default - Reset the camera settings to the factory settings.
Image viewer
View your saved images.
1. Press Menu, scroll to Multimedia and press OK.
2. Select Image viewer and press OK.
3. Select an image and press Options.
4. Select one of the following options and press OK to confirm:
View - displays the image. In the image view you can rotate the image using
Options or for example, access image data (file size, recording date etc.)
Use as - Use the image as wallpaper. The photo will be displayed behind
the clock in the lock screen.
Rename - rename the image.
Delete - delete the image.
Image informationen - Display of the different parameters of the image.
22
Audio player
Play sound files that are stored on the telephone.
1. Press Menu, scroll to Multimedia and press OK.
2. Select Audio player and press OK.
3. Press List, select a song and press Options - Play - Select. The song will
play. With , you can pause and start the playback. To stop playback,
press . Using the * and # buttons, you can switch to the previous or
next song. Control the volume using the +/- buttons.
4. If you press List - Options, the following options are available:
Play - play the selected entry.
Details - details like the size and length of the song.
Add - add a new song.
Remove - delete the song from the list.
Remove all - delete all titles from the list.
Settings
Repeat - Select Off, if the selected song should not be repeated. Select
One to repeat only the selected song or select All to play the contents of
the list in an infinite loop.
Shuffle - Plays all of the songs in random order.
Background play - Select On to continue listening to the audio play-
back when exiting the player. To exit, open the audio player and end the
background playback.
23
FM radio
Listen to the radio on your mobile telephone.
Hint
The reception is significantly improved when using a headset because the
cable functions as an antenna.
1. Press Menu, scroll to Multimedia and press OK or press .
2. Select FM radio and press OK.
3. After pressing Options, the following options are available to you:
Volume - Press OK and set the volume using . Press Back.
Save frequency - Enter a name for the set station and press OK.
Switch off - Switches the radio off.
Manual input - Here, you can manually select a frequency by fine tuning or
you can perform a scan of the frequencies using the Auto search function.
Channel list - List of stored channels. The options include: Play, Delete and
Edit.
Auto search - Scan stations and save the stations found.
Settings
Background play - Select On to continue listening to the radio when
exiting the menu. To deactivate the radio, end the background playback
in the FM radio menu.
Important
If the radio is inadvertently to hear, even though you are not in
radio mode, you should switch OFF the background playback
(factory setting is ON).
24
File manager
Edit the contents of the memory card.
1. Press Menu, scroll to Organizer and press OK.
2. Select File manager and press OK.
3. After pressing Options, the following options are available to you:
Open - Displays the file structure. The options include: Open, New folder,
Rename, Delete.
Format - Formats the memory card. ATTENTION: All files will be deleted.
Details - Information about the memory card.
Connecting the phone to a computer
Connect the phone to a computer and start transferring pictures and sounds. All
you have to do is connect an optional available USB cable between the phone
and computer. From your computer's file explorer, you can drag and drop content between your phone and the computer.
Note!
You might not be able to transfer some copyright-protected material.
Drag and drop content between phone and a computer
1. Connect your phone to a computer using an optional available USB cable.
A Mass storage query appears on the cell phone's display. Confirm this on
the cell phone by pressing OK.
2. Wait until the phone/memory card appears as external disks in the file explorer.
3. Drag and drop selected files between the phone and the computer.
25
Note!
When the memory card is mounted to the computer, the phone cannot access
the memory card. Some functionality and applications in the phone, such as
the camera, may not be accessible.
You can transfer files by using a USB cable on most devices and operating
systems supporting a USB Mass Storage interface.
Disconnect the USB cable safely
1. Make sure to enable the hardware to be safely removed. There are settings
for this on the computer (as a symbol in the task bar).
2. Disconnect the USB cable.
Note!
Do not disconnect the USB cable when transferring content as this may corrupt the content. Computer instructions may vary depending on your operating
system. See the documentation of your computer's operating system for more
information.
26
Settings
Note!
The settings described in this chapter are carried out in standby mode.
Press to return to standby mode.
Basic settings
Time and date
Setting the time and date
1. Press Menu, scroll to Settings and press OK.
2. Select Time and date and press OK.
3. Select Set home city and press OK.
4. Select a city from the list using * and # and press OK.
5. Select Set time/date and press OK.
6. Enter the time (HH:MM) and press .
7. Enter the date (DD/MM/YYYY) and press .
8. Select Set format and press OK.
9. Set the time format (12 or 24 hours) with * and # and press .
10. Set the date format with * and # and press OK.
Flight mode
Flight mode means the radio part of the cell phone is turned off. Telephone calls
cannot be placed and SMS or MMS cannot be sent or received. All other functions in the menu are available.
1. Press Menu, scroll to Settings and press OK.
2. Select Flight mode and press OK.
3. Mark Flight mode or Normal mode and press OK.
Language
The default language of the telephone menu, messages and so on is determined by the SIM card used (Automatic). You can always switch between the
languages supported by the telephone.
27
1. Press Menu, scroll to Settings and press OK.
2. Select Phone settings and press OK.
3. Select Language and press OK.
4. Select a language from the list and press OK.
Preferred input method
Select the preferred input method for entries into the telephone book and for
SMS/MMS. You can shift the input method using the # button while entering
text.
1. Press Menu, scroll to Settings and press OK.
2. Select Phone settings and press OK.
3. Select Pref. input method and press OK.
4. Select Abc (first character is capitalized after a period), ABC (ALL CAPS),
abc (all lower case) or Numeric (numbers) and press OK.
Display
You can set the display for the standby display.
1. Press Menu, scroll to Settings and press OK.
2. Select Phone settings and press OK.
3. Select Display and press OK.
4. Select Wallpaper and press OK.
5. Select the source for the image you want to select and press OK.
System is the telephone memory in which the black standard background
image, Image 1, is saved, or select User defined and look at a preview via
View. To accept, press OK. User defined allows you to access the memory
card for setting your own background images from photos you took using
the camera or copied from the computer to the memory card.
6. Select the desired file and press View, to see the image. Press OK to
accept the image or Back to return to the selection screen.
7. Select Show date and time and press OK.
8. Switch the date and time display in the standby display On or Off and press
OK.
28
LCD backlight
Settings for brightness and duration of the display backlight.
1. Press Menu, scroll to Settings and press OK.
2. Select Phone settings and press OK.
3. Select LCD backlight and press OK.
4. Using , mark the Brightness or Time (sec) and set the desired
values using * and #.
Backlit keys
Settings for the keypad backlight.
1. Press Menu, scroll to Settings and press OK.
2. Select Phone settings and press OK.
3. Select Backlit keys and press OK.
4. Select On or Off and press OK.
Call settings
To some extent, the services depend on the network support and the subscription. You can obtain more information from your network operator.
Send caller ID
You can select whether or not the recipient will see your phone number in the
display during calls.
1. Press Menu, scroll to Settings and press OK.
2. Select Call settings and press OK.
3. Select Caller ID and press OK.
4. Select one of the following options and press OK:
Set by network - Use the network default settings.
Hide ID - Your telephone number will never be displayed.
Send ID - Your telephone number will always be displayed.
29
Call waiting
You can answer more than one call simultaneously. If there is an incoming call
during a telephone conversation, a signal tone is emitted. To hold the active call
and to answer the incoming call, press Options, select Accept and then OK.
1. Press Menu, scroll to Settings and press OK.
2. Select Call settings and press OK.
3. Select Call waiting and press OK.
4. Select one of the following options and press OK:
Activate - Activates call waiting.
Deactivate - Deactivates call waiting.
Query status - Displays whether call waiting is activated or deactivated.
Call divert
You can divert calls to an answering service or another telephone number. Set
which calls should be diverted. Select a condition and press OK, select Acti-
vate, Deactivate or Query status (see Call waiting for all of the options).
1. Press Menu, scroll to Settings and press OK.
2. Select Call settings and press OK.
3. Select Call divert and press OK.
4. Select one of the following options and press OK:
Divert all voice calls - Diverts all voice calls.
Divert if unreachable - Incoming calls are diverted if the telephone is swit-
ched off or outside of the network.
Divert if no answer - Incoming calls are diverted if they are not accepted.
Divert if busy - Incoming calls are diverted if the line is busy.
Divert all data calls - Diverts all data calls.
Cancel all diverts - Calls are not diverted.
30
Call barring
To restrict the use of your telephone, specific types of calls can be blocked.
Note!
To use the call barring function, a password is required. You have to request
this password from your network operator.
1. Press Menu, scroll to Settings and press OK.
2. Select Call settings and press OK.
3. Select Call barring and press OK.
4. Select one of the following options and press OK:
Outgoing calls - Press OK and select:
All voice calls - The user can accept incoming calls but not place calls.
International voice calls - The user cannot call any international num-
bers.
International voice calls except to home - The user cannot call any
international numbers with the exception of telephone numbers in the
country assigned to the SIM card.
Incoming calls - Press OK and select:
All voice calls - The user can place calls, but not accept incoming calls.
Voice calls when roaming - The user cannot accept any incoming calls
when roaming (use on other networks).
Cancel all - Delete all call blocking functions (password required).
Change barring password - Option for changing the lock password.
Voice mail (Mailbox)
If your service provider has set up a mailbox (answering machine in the mobile
phone network) for you, callers will be able to leave a voice message if you are
unable to answer a call. Voice mail is a service offered by your network operator
and you may have to subscribe to this service first. More information and the
number for the voice mail are available from your service provider.
1. Press Menu, select Settings and press OK.
2. Select Call settings and press OK.
3. Select Mailbox and press OK.
31
4. Define the name (freely selectable) and the number of your mailbox ser-
vices with Name and Number. Confirm with OK.
Tip: To call your mailbox press and hold the 1 key for approx. 3 seconds.
The mailbox must be pre-defined (name and number)
Auto redial
This function performs a redial automatically.
1. Press Menu, scroll to Settings and press OK.
2. Select Call settings and press OK.
3. Select Advanced settings and press OK.
4. Select Auto redial and press OK.
5. Switch the function On or Off and press OK.
Call time reminder
If this function is enabled, you will be notified via a notification sound once or
repeatedly about the call time that has elapsed so far.
1. Press Menu, scroll to Settings and press OK.
2. Select Call settings and press OK.
3. Select Advanced settings and press OK.
4. Select Call time reminder and press OK.
5. Select one of the following options and press OK:
Off - Function is switched off.
Single - Enter a time for the single signal (1…3000 s).
Periodic - Enter a time for the regularly recurring signal (30…60 s).
Answer mode
Settings options for accepting incoming calls.
1. Press Menu, scroll to Settings and press OK.
2. Select Call settings and press OK.
3. Select Advanced settings and press OK.
4. Select Answer mode and press OK.
5. Select one of the following options and press OK:
Cover answer - incoming call will be automatically accepted if the flap is
opened.
32
Any key - incoming calls can be accepted by pressing any key (except the
right soft key and the red hang up button).
Auto answer when headset mode - if a headset is plugged in, the inco-
ming call will be automatically accepted after a short time.
Network settings
Your telephone selects the network operator automatically if this operator can be
received in your area. If your network operator is not available you can also use
a different network if your network operator has a corresponding agreement with
other operators. This then is called “Roaming”. You can obtain more information
from your network operator.
1. Press Menu, scroll to Settings and press OK.
2. Select Network settings and press OK.
3. Select Network selection and press OK.
4. Automatic - The network is selected automatically (default setting).
Manual - The network is selected manually. After a short time the list of avai-
lable network providers is shown. Select the desired provider and press
OK.
Attention:
Fees may be incurred if an incorrect selection is made.
5. Select GPRS connection. and press OK. Choose between Always and
When needed.
6. Select GPRS transfer pref. and press OK. Choose between Data prefer
and Call prefer.
Note
A GPRS connection is required for sending/receiving MMS.
33
Security settings
PIN lock
You can select whether or not the SIM card PIN should be required when turning
the phone on. Several SIM card providers do not allow the PIN query to be shut
off.
1. Press Menu, scroll to Settings and press OK.
2. Select Security settings and press OK.
3. Select SIM security and press OK.
4. Select PIN lock and press OK.
5. Enter the PIN for your SIM card and press OK.
6. The following message will inform you whether the PIN entry is necessary
(locked) or not necessary (unlocked).
Change PIN
You can change the PIN for your SIM card.
1. Press Menu, scroll to Settings and press OK.
2. Select Security settings and press OK.
3. Select SIM security and press OK.
4. Select Change PIN and press OK.
5. Enter the PIN for your SIM card and press OK.
6. Follow the instructions on the display.
Change PIN2
You can change the PIN2 for your SIM card. To do this, you must enter the PIN2
(PUK) you received with the documentation for you SIM card.
1. Press Menu, scroll to Settings and press OK.
2. Select Security settings and press OK.
3. Select SIM security and press OK.
4. Select Change PIN2 and press OK.
5. Enter the PIN2 for your SIM card and press OK.
6. Follow the instructions on the display.
34
Phone lock
If the telephone lock is activated, you will need the code to unlock the telephone
when switching the phone on. To this end, you have to enter the blocking code
(factory setting is 0000). You can change this blocking code (see below).
1. Press Menu, scroll to Settings and press OK.
2. Select Security settings and press OK.
3. Select Phone security and press OK.
4. Select Phone lock and press OK.
5. Enter the lock code and press OK.
6. The following message will inform you whether the telephone is locked
(locked) or not (unlocked).
Change password
Changing the blocking code for the telephone (factory setting is 0000).
1. Press Menu, scroll to Settings and press OK.
2. Select Security settings and press OK.
3. Select Phone security and press OK.
4. Select Change password and press OK.
5. Enter the old lock code and press OK.
6. Enter the new lock code and then confirm it again.
Restore factory settings
Reset the telephone to the factory settings.
1. Press Menu, scroll to Settings and press OK.
2. Select Restore settings and press OK.
3. Enter the current telephone lock code (default 0000) and confirm the reset.
Important
When restoring the phone to factory settings, all contacts of the phone
will be permanently deleted. Create a backup of your contacts or write
them down prior to performing this process. Contacts saved on your
SIM card will remain unaffected.
35
Bluetooth®
IMPORTANT
If you are not using a Bluetooth connection, select Power/ off. Do not connect
to unknown devices.
You can establish a wireless connection to other Bluetooth-compatible devices
such as headsets.
1. Press Menu, scroll to Connectivity and press OK.
2. Select Bluetooth and press OK to display the following settings:
Power - Switch the function On or Off using the left soft key .
Visibility - Switch the function On or Off using the left soft key .
My device - Press OK and select from the following options:
Search new device - Starts a search for available devices.
[Device xy] - After pressing Options, you have the following options:
Rename - Change the name of the device.
Authorize - Set the connection options for this device.
Important
You may assign an authorisation to a Bluetooth device. This is
practical, for example with a hands-free equipment in the car to
avoid the constantly repeated request. For this purpose, set the authorisation to Always connect.
My name - Change the name.
Data accounts
This menu contains information about your data account. This information is
needed for the MMS function. The settings for MMS will be provided from your
service provider. The setting parameters for MMS are preset for the large network operators in Germany. With other mobile service providers these may have
to be changed manually. You can get the parameters necessary for this from
your provider.
36
1. Press Menu, scroll to Connectivity and press OK.
2. Select Data accounts and press OK.
3. Select the entry of your service provider and press Options.
4. Select Set as default and press OK. Following this, the profile is created.
Note:
An automatic configuration by your mobile service provider via SMS is not
possible. An SMS that you might receive automatically from the service provider regarding the automatic configuration does not apply.
If your services provider is not on the list, proceed as follows:
1. Press Menu, scroll to Connectivity and press OK.
2. Select Data account and press OK.
3. Select any entry and press Options.
4. Select Add PS account and press OK, to display the following settings.
Set the settings for your service provider. You can get the correct settings
from your service provider.
Account name - Add an account name.
APN - Add the APN address.
Username - Enter a user name.
Password - Enter a password.
Auth. type - Select an authentication type.
Advanced settings
Homepage - Enter the home page.
Connection type - Select the type of connection HTTP or WAP.
Use proxy - Select whether or not a proxy server should be used.
Proxy address - Address of the proxy server.
Proxy port - Enter the proxy port.
Proxy user name - Enter the proxy user.
Proxy password - Enter the proxy password.
Primary DNS - Address of the primary DNS server.
Secondary DNS - Address of the secondary DNS server.
37
IP address - IP address provided by the network provider.
Subnet mask - Subnet mask provided by the network provider.
5. Press OK.
6. Select your new profile and press Options.
7. Select Set as default and press OK.
You can also activate or edit an MMS profile by selecting it and pressing Opti-
ons to Activate/Edit/Delete the account.
Note!
With some service providers you first have send an MMS message before you
are able to receive MMS. Send an MMS with text only to enable the service.
Some service providers have to be contacted first, before the MMS function for
your account is activated. Contact the customer support of your service provider. To end the setup without saving your settings, press .
SMS settings
1. Press Menu, scroll to Messaging and press OK.
2. Select Message settings and press OK.
3. Select Text message and press OK.
4. Select one of the following menu points and press Select:
SIM
Profile settings
- Select Profile 1 or Profile 2 and press Options.
- Select Activate to activate this profile.
or Edit to edit this profile.
- SMSC address - This number is required to use the SMS
function. The number of your SMS center is provided by your
network provider and is normally preassigned to the SIM card.
When the number of your SMS center is stored on the SIM card,
it will be displayed. If not, you can enter the number yourself.
You can get additional information from your provider.
38
Validity period - select the desired validity period with * and #.
Message type - select the message type with * and #.
Delivery report - set the delivery report to on or off with * and #.
Reply path - set the reply path to on or off with * and #.
Memory status - display of the available/used memory for SMS on the SIM
card and in the telephone.
Text msg. counter - display the sent and received SMS. You can reset the
counter with Reset.
Save sent message - select whether sent SMS should be saved in the
"Sent" folder (On) or not (Off) using the * and # buttons.
Preferred storage - define the memory location for received SMS message
(SIM/Phone) using the * and # buttons.
MMS settings
1. Press Menu, scroll to Messaging and press OK.
2. Select Message settings and press OK.
3. Select Multimedia message and press OK.
4. Select one of the following menu points and press OK:
Data account - Select the correct data account for your network provider
and confirm with OK.
Note: These settings will be required for the use of the MMS function.
The settings for MMS are provided by your network provider. For the
setting of a new account or changes to existing accounts, see page 36.
Common settings
Compose - settings options for Slide time, Creation mode, Auto sig-
nature and Signature.
Sending - settings options for Delivery report, Read report, Priority,
Delivery time and Send and save.
Retrieval - settings options for different query criteria.
Preferred storage - storage location for received MMS (Memory
card/Phone)
Memory status - display of the available/used memory for MMS.
39
Settings for service message
1. Press Menu, scroll to Messaging and press OK.
2. Select Message settings and press OK.
3. Select Service message and press OK.
4. Setting options for different criteria. Contact your network operator for more
information, if required.
User profiles
You can save different profiles (special settings depending on the user or environment), into which you can switch when necessary.
Note
The profile with the green checkmark is the active profile. If you make changes
to one of the profiles, the selected settings only have an effect when the profile
is activated!
1. Press Menu, scroll to Profiles and press OK.
2. Select one of the profiles and press Options.
3. Select one of the following options and press Select:
Activate: The profile is activated with the corresponding settings.
Customize: Edit the settings for the selected profile. Select one of the follo-
wing menu points using and press Options. Select Change, edit
the settings and press OK. Once you have changed the settings to what you
want, press Options, select Save and press Select.
Alert type - Select whether a call should be signalized by only a ring-
tone, only vibration, a ringtone and vibration or vibration with a delayed
ringtone.
Ring type - You can choose between Beep once and Repeat.
Ringtone- Select the melody for an incoming call.
Ringtone volume - Select the volume for an incoming call.
Message - Select the melody for an incoming message.
Message volume - Select the volume for an incoming message.
Keypad - Select the tone for key strokes or Silent.
40
Keytone volume - Select the volume for key strokes.
Cover open / Cover close - Select tones for flipping open or closing the
mobile phone or Silent.
System alert - Select whether or not system notifications should be dis-
played.
Reset: The profile will be reset to the factory settings.
Organizer
Calendar
1. Press Menu, scroll to Organizer and press OK.
2. Select Calendar and press OK.
3. Press Options.
4. Select one of the following options and press OK:
View - Displays the tasks for the selected date.
View all - Displays all saved tasks.
Add event - Enter the parameter for the event and then press Save. When
the set date / set time is reached, a signal tone will sound and the description of the task will be displayed. Press Stop to shut off the alarm or press
Snooze and the alarm will repeat in 6 minutes.
Delete event - Delete the event from the list.
Jump to date - Enter the date and press OK.
Go to today - Displays the current date in the calendar.
Go to weekly view/ Go to monthly view - Change the display between
week and month view.
Start of week - Select the start of week (Sunday/Monday).
41
Calculator
The calculator can perform basic arithmetic functions.
1. Press Menu, scroll to Organizer and press OK.
2. Select Calculator and press OK.
3. Enter the first number. Use # to enter decimal points.
4. Using , select the calculation type (+, -, x, ÷).
5. Enter the next number and press OK.
The result will be shown.
6. Repeat steps 3 to 5, as required.
Alarm
1. Press Menu, scroll to Organizer and press OK.
2. Select Alarm and press OK.
3. Select an entry from the list and press Edit.
4. Using the * and # buttons select on or off and press .
5. Using the keyboard, enter the alarm time and press .
6. Select the Snooze time (time for repaeting the alarm) and press .
7. Go to Repeat and press Select. For a one-time notification, select Once
and press OK. For a daily repeated notification select Everyday and press
OK. To repeat on certain weekdays, select Custom and press OK. Scroll
through the list of the weekdays and press Options / On/Off to turn the
alarm on/off for each weekday, then select Done and press Select.
8. To edit an alarm, press Select, mark a ringtone and press OK.
9. Using the * and # buttons, select the type of signal and then press Save.
42
Stopwatch
1. Press Menu, scroll to Organizer and press OK.
2. Select Stopwatch and press OK.
3. Select a kind of stopwatch and press OK.
4. Depending on your selection you can make a sub-selection.
5. Start and Stop the function with the softkeys or with the keys ( / * /
# when using the n-way stopwatch.
Note
The stopwatch is running in the background if you exit the menu with the
end call key. A blue stopwatch icon appears in the display when the stopwatch is running.
File manager
See page 25.
Magnifying glass
Use the built-in camera as a magnifying glass.
Zoom in / zoom out with the keys .
43
Appendix
Safety instructions
CAUTION
The device and its accessories may contain small parts.
Keep the device out of the reach of small children. The power supply is used
as separating unit between product and main connection.
The main socket must be in close proximity to the device and should be easily
accessible.
Network services and fees
Your device is approved for GSM 900/1800 MHz networks.
To be able to use the device, you have to insert a SIM card that has been unlocked and activated by the network operator. When you use network services
you may incur costs. Some of the functions are only available after requesting
them from your operator and they may bring about fees.
Operating environment
Please observe all regulations applicable to your country/ place of residence,
and switch the device off if its use is prohibited or if it can cause interference or
risks. Always use the device in the normal position of use.The device complies
with the guidelines and directives for radiation when it is used at the ear at normal position or at a distance of at least 1.5 cm from your body. If you carry the
device close to your body, in a bag or belt bag or in storing equipment or similar
means, these storing means must not contain metal parts and the product
should be carried at the distance from the body as specified above. Make sure
the distance guidelines are observed until you put the device into operation.
Parts of the device are magnetic. Therefore, it may attract metal objects. Do not
keep credit cards or other magnetic data carriers close to the device. There is a
risk of losing all data saved on data carrier.
Medical devices
The use of devices that transmit radio signals, such as mobile phones, may
impair the function and operation of medical devices if they are not sufficiently
44
shielded. Consult a doctor or the manufacturer of the device to find out if
it is sufficiently protected against external radio signals or if you have any other
questions.
Cardiac pacemakers
The manufacturers of cardiac pacemakers recommend a distance of at least 15
cm between the mobile phone and the cardiac pacemaker in order to avoid malfunctions of the pacemaker. Persons using cardiac pacemakers should keep the
following in mind:
• They should always keep the telephone at a distance of 15 cm from their
pacemaker when the telephone is switched on.
• They should never wear the telephone in a breast pocket.
• They should use the ear on the half of the body opposite to the one with the
cardiac pacemaker to reduce the risk of malfunctions.
They should turn the telephone off immediately if there is a reason to assume
that there is a malfunction.
Explosive areas
Always turn the device off when you are in explosive areas.
Follow all of the instructions and guidelines. A risk of explosion also exists, for
example, in places where you normally have to switch off the engine of your
vehicle. In these areas sparking may lead to explosion or fire; this involves risks
of injury and danger to life. Switch the device off at petrol stations and all other
places where there are petrol pumps or vehicle garages and workshops.
Adhere to the restrictions regarding the use of radio-controlled devices in places
where fuels are stored and sold, in the area of chemical factories and places
where blasting is in progress. Areas with risk of explosion are often – but not
always – clearly marked.
The same applies below deck on ships, to the transport or storage of chemicals,
to vehicles operated by liquid fuel (such as propane or butane) as well as to
areas containing chemicals or particles in the air, such as fibres, dust or metal
powder.
45
Protection from too high volume at the ear
This device has been tested and it complies with the requirements for the noise
level according to the norms EN 50332-1 and/or EN 50332-2.
WARNING
Loud noises over an extended period of time may cause damage to
hearing. Loud noises while driving or steering a vehicle may distract
you or cause an accident. Enjoy music via a headset at a moderate
volume. Do not hold the device to your ear when it is switched to
handsfree mode.
Emergency calls
IMPORTANT!
Mobil telephones use radio signals, the mobile phone network, the land line network and user-programmed functions.
This means a connection cannot be guaranteed under all circumstances. Thus,
never rely on mobile phones only if very important calls are necessary, e.g. in
medical emergencies.
Vehicles
Radio signals may impair the electronic system of motor vehicles (e.g. electronic
fuel injection, anti-lock brake system (ABS), speed control, air-bags) if the system was incorrectly installed or if it is not sufficiently protected.
For more information about vehicles or possible additional equipment please
contact the manufacturer or its subsidiary.
Combustible liquids, gases or explosive substances must not be stored or transported together with the device or its accessories.
For vehicles with air-bags please keep in mind that in the event of a crash the
air-bags will be filled with air using a considerable force. Therefore, do not place
objects or stationary or hand-held radio-controlled devices directly above the airbag or within the range where it inflates. If the mobile phone is improperly installed, the inflating of the air-bag may lead to severe injuries. The use of the device
on aircrafts is prohibited. Switch the phone off before boarding the airplane. The
46
use of wireless telecommunication devices in airplanes may impair the flight
security and disturb the on-board telecommunication system. Furthermore, the
use of these devices might be forbidden by law.
Care and maintenance
Your telephone is a technically advanced product and it must be handled with
utmost care. Negligent behaviour may lead to loss of warranty.
• Protect the device from humidity. Rain/snow and all types of liquid may contain substances that lead to corrosion of the electronic system. If the device
gets wet, remove the rechargeable battery and let the device dry completely
before you insert the battery again.
• Do not store the device in dusty, dirty environments. The moveable device
components and the electronic system might get damaged.
• Protect the device from heat. High temperatures may reduce the lifespan of
the electronic system, damage the rechargeable battery and deform plastic
parts or even cause them to melt.
• Protect the device from cold. While warming up to normal temperatures,
condensation may form inside the device which can damage the electronic
system.
• Do not attempt to open the device in a way other than described in this
manual.
• Do not drop the device. Protect it from blows, jolts and vibrations. If the
device is handled improperly, conductors and precision-mechanical parts
might be damaged.
• Do not clean the device with abrasive cleaning agents. These notes apply to
the device, the rechargeable battery, the network adapter and other accessories. If the telephone does not work properly, please contact your retailer.
Bring along your sales receipt or a copy of the invoice.
47
Warranty and service information
If the product shows any defect resulting from manufacturing and/or material
faults within 24 months starting from the purchase date, we kindly ask you to
contact our Hotline at 0180 5 00 50 60 (This call will involve connection fees of
0.14 EUR/Min calling from the German land line network – maximum 0.42 EUR/
Min calling from the German mobile phone network – as of 01/05/2014).
Availability: Monday to Thursday from 08h00 to 17h00 and Friday from 08h00
to 15h30.
The rechargeable battery is a replacable part and has a warranty of 6 months.
Replaced products shall become the property of IVS GmbH.
We ask you to
- send the product in its original package incl. accessories
- with a copy of the sales receipt
- and a detailed error description
- immediately notify our hotline after noticing the defect.
If we do not find any fault or defect, the product will be returned to you with a
corresponding note.
Defects and damages caused by improper handling of the product or the noncompliance with the operating instructions, modifications or conversions to the
product performed by the retailer or the client himself (e.g. installations, software
downloads) and total losses are excluded from the warranty. In such cases, IVS
GmbH reserves the right to charge the client for the replacement or repair. IVS
GmbH shall inform the client of this in advance. Total losses are e.g.
- Fire damage (e.g. caused by short-circuit)
- Corrosion damage (e.g. caused by liquid that entered the device)
- Unauthorised modifications (e.g. improperly performed soldering, mechanically incorrect mounting, destroyed seals)
- Mechanical damage (e.g. plastic deformations, tearing off of soldered joints)
- Damages which indicate a use that was not in accordance with the manufacturer’s instructions (e.g. foreign objects inside the product, deposits of
chemicals)
- Lightning and surge damages
48
A change of the regulation regarding the burden of proof to the detriment of the
client is not part of the above regulations.
Operating instructions and software provided are excluded from the warranty.
This warranty is valid for new goods purchased in Germany. Warrantor is:
IVS GmbH
Im Frauental 14
92224 Amberg
Further or other claims under the manufacturer warranty shall be excluded. IVS
GmbH is not liable for the disruption of services and operation, lost profits or the
loss of data, additional software or information downloaded by the client. The
backup of this software is the client’s responsibility.
The exclusion of liability shall not apply in cases where our liability is mandatory,
e.g. product liability act, in cases of deliberate intention, gross negligence,
claims based on liability for danger to human life, physical injury or danger to
health or due to violation of essential contractual obligations. However, claims
for the violation of essential contractual obligations shall be limited to foreseeable damages that are typical for this type of contract, provided there is no liability for danger to human life, physical injury or danger to human health or liability
pursuant to product liability law. The duration of the warranty shall not be extended by services rendered under the terms of the warranty.
The receipt with purchase date is valid as warranty certificate.
Warranty claims must be made within two weeks after noticing a warranty case.
49
Technical data
Network: Dualband GSM 900 / 1800
Display: 2.2”, 220 x 176 Pixels
Bluetooth®: BT 3.0
Camera: 0.3 MP
MMS: yes
FM radio: yes
Torch: yes
Rechargeable battery: Li-Ionen 3,7V, 1000 mAh
Standby time: up to 10 days
Call duration: up to 5 hours
Phone directory entries: 300
ICE function: yes
Card slot, upgradeable: 128 MB micro-SD (interchangeable)
Connectors: micro-USB, stereo jack 4-pin 3.5 mm
Organiser: alarm function, calendar, calculator
Vibration alarm: yes
Direct dialling keys: 2
Illuminated keypad: yes
Languages: DE, EN, CZ, ES, PL, PT, IT
Dimensions: 102 x 50 x 20 mm
Weight: 115g
Bluetooth® is a registered trademark of Bluetooth SIG, inc.
50
Specific Absorption Rate (SAR)
0700
This device meets applicable international safety requirements for exposure to
radio waves.
900MHz:
Head 0.408 W/kg 10g
Body 0.660 W/kg 10g
1800MHz:
Head 0.163 W/kg 10g
Body 0.255 W/kg 10g
The maximum limit according to WHO is 2.0 W/kg measured over 10 g tissue.
Approval and Conformity
This mobile phone complies with the fundamental requirements of the R&TTE
Directive 1999/5/EC for radio installations and telecommunication transmission
devices and is suitable for the connection and operation in the respective country where the device was sold.
The declaration of conformity is available on the following website:
www.ivsgmbh.de
The CE symbol confirms the conformity of the telephone with the above
directive.
Internet:
www.ivsgmbh.de
IVS GmbH
Im Frauental 14
92224 Amberg
© IVS GmbH 2014
All rights reserved
IVSUMEN_Primo 405 by Doro - V 1.0
Loading...
