Doro 6530

English

23 2420

26 27

The items supplied with your phone might vary depending on the software and accessories available in your region or offered by your service provider. You can obtain additional accessories from your local Doro dealer. The supplied accessories provide the best performance with your phone.

English

1. Earpiece

2. Headset socket

3. Charging socket

4. Left selection button

5. Call button

6. Torch button

7. Top 10

8. Voice mail

9. Microphone

10. International prefix/Symbols

11. Input method/Silent

12. Camera shortcut

13. Message shortcut

14. End call/Power on/off

16. Right selection button

17. Volume control

18. Red light = Battery level low/ Charging

19. Green light = New message/ Missed call

20. Second microphone

21. Camera flash/Torch

22. Camera lens

23. Assistance button

24. Loudspeaker

25. External display

26. Charging stand

27. Strap mount eyelet (strap not included)

15. Arrow buttons/Navigation buttons

English

Contents

Congratulations on your purchase ............................................................... 1

Get started..................................................................................................... 1

Insert SIM card, memory card and the battery ................................... 1

Charge the phone.................................................................................. 2

Get to know your phone ................................................................................ 3

Assistive functions................................................................................. 3

Turn the phone on and off .................................................................... 3

Start-up wizard ...................................................................................... 3

External display ..................................................................................... 4

Phone indicators ................................................................................... 4

How to navigate the phone Enter text

Volume control....................................................................................... 6

Hearing aid compatible......................................................................... 7

Phone settings ....................................................................................... 8

Calls.............................................................................................................. 10

Make a call........................................................................................... 10

Call from the phonebook .................................................................... 10

Receive a call....................................................................................... 10

Call information ...................................................................................10

Call options ..........................................................................................11

Speed dial

SOS calls ..............................................................................................12

Call log..................................................................................................12

Call settings ......................................................................................... 12

Phonebook...................................................................................................15

Add contact..........................................................................................15

Manage phonebook contacts.............................................................16

Phonebook settings ............................................................................ 17

ICE (In Case of Emergency)

Assistance button

Make an assistance call .....................................................................20

Activation .............................................................................................20

Number list .......................................................................................... 21

Activate text messages (SMS) ............................................................ 21

Position SMS........................................................................................22

.......................................................................................... 5

......................................................................................11

...................................................................................19

............................................................. 4

...........................................................18

English

Assistance settings .............................................................................22

Messages.....................................................................................................23

Create and send text message (SMS) ...............................................23

Create and send picture message (MMS) .........................................23

Create and send voice message ........................................................ 24

Create and send e-mail....................................................................... 24

Inbox, Outbox and Sent.......................................................................26

Message settings ................................................................................ 27

Camera.........................................................................................................32

Camera.................................................................................................32

Video camera.......................................................................................33

Picture gallery and Video gallery ........................................................34

Camera settings ..................................................................................34

Connectivity .................................................................................................35

Bluetooth

............................................................................................35

Internet profile ..................................................................................... 37

Mobile data, data counter and data roaming ................................... 37

Network setup .....................................................................................38

Connect the phone to a computer .....................................................39

Sound & Display ..........................................................................................40

Audio setup

......................................................................................40

Tone setup (ringtone) .......................................................................... 40

Ringtone volume

.............................................................................. 41

Silent .................................................................................................... 41

Alert type .............................................................................................. 41

Extra tone............................................................................................. 41

Main menu........................................................................................... 42

Wallpaper.............................................................................................42

Text size

.......................................................................................42

Idle display ...........................................................................................42

Themes

........................................................................................42

LCD backlight.......................................................................................42

Brightness

Doro Connect & Care

Introduction .........................................................................................43

How to use the Connect & Care Set the Assistance Button to Connect & Care

....................................................................................43

.................................................................................43

service on your Doro phone ......... 44

..................................44

English

My Doro Manager®.......................................................................................45

Create account ....................................................................................45

Options.................................................................................................46

Sync. intervals .....................................................................................46

Account details .................................................................................... 46

File manager ................................................................................................ 47

Internet.........................................................................................................48

Use the web browser...........................................................................48

Use the Facebook application ............................................................49

More .............................................................................................................49

FM radio ...............................................................................................50

Torch..................................................................................................... 51

Calculator.............................................................................................52

Games..................................................................................................52

Status................................................................................................... 52

Organiser......................................................................................................52

Alarm ....................................................................................................53

Calendar...............................................................................................53

Daily reminder .....................................................................................54

Notes.................................................................................................... 54

Weather........................................................................................................55

Additional functions ....................................................................................55

Display status symbols .......................................................................55

Display main symbols .........................................................................56

Reset settings ......................................................................................56

Safety instructions....................................................................................... 57

Network services and costs................................................................ 57

Operating environment ....................................................................... 57

Medical units ....................................................................................... 57

Areas with explosion risk .................................................................... 58

Li-ion battery........................................................................................ 58

Protect your hearing ............................................................................58

Emergency calls...................................................................................59

GPS/Location based functions .......................................................... 59

Vehicles................................................................................................59

Protect your personal data ................................................................. 59

Malware and viruses ...........................................................................60

English

Care and maintenance ...............................................................................60

Warranty....................................................................................................... 61

Specifications ..............................................................................................62

Hearing aid compatibility ....................................................................63

Specific Absorption Rate (SAR) ..........................................................64

Correct disposal of this product .........................................................64

Correct disposal of batteries in this product .....................................65

Declaration of Conformity ...................................................................65

English

Congratulations on your purchase

Enjoy an elegant camera phone made simple, with convenient ways to communicate and enjoy access to e-mail and the Internet for staying connected everywhere. Share photos and listen to your favourite MP3 music or FM radio. Other practical features include weather, reminders, wakeup alarm, vibrating ringer and more. For more information about accessories or other Doro products please visit www.doro.com.

Get started

Insert SIM card, memory card and the battery

IMPORTANT!

Turn off the phone and disconnect the charger before removing the battery cover.

1. Remove the battery cover. Be careful not to damage your fingernails when you remove the cover. Do not bend or twist the cover excessively as it may be damaged. Remove the battery if it is already installed.

2. Optional: Locate the SD card holder and gently slide the card in the holder. The device works with or without a SD card installed. Compatible card type: microSD, microSDHC.

3. Locate the SIM card holder and gently slide the card in the holder. See the label right next to the holder for guidance on how to insert the card. This device accepts micro SIM or 3FF SIM card. If you have problem to remove/replace the SIM card, use adhesive tape on the exposed part of the SIM card to pull it out.

English

4. Insert the battery by sliding it into the battery compartment with the contacts facing downwards to the right. Replace the battery cover.

IMPORTANT!

This device accepts micro SIM or 3FF SIM card. Use of incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card.

IMPORTANT!

Use only compatible memory cards for use with this device. Compatible card type: microSD, microSDHC. Incompatible cards may damage the card itself, the device and corrupt data stored on the card. Depending on the market some phones may have a pre-installed memory card.

Charge the phone

CAUTION

Only use batteries, chargers and accessories that have been approved for use with this particular model. Connecting other accessories may be dangerous and may invalidate the phone's type approval and warranty.

When the battery is running low,

is displayed and a warning signal is

heard.

1. Connect the mains adapter to a wall socket and to the charging socket y. The battery charge indicator is animated while charging. It takes approximately 3 hours to fully charge the battery. When

the charger is connected to the phone,

is displayed briefly, and

when it is disconnected.

2. When charging is completed,

is displayed on the screen. If the phone is turned off when the charger is connected to the phone only the battery charge indicator will be shown on the display.

Note! To save power the LCD backlight goes off after a while. Press any button to illuminate the display. Full battery capacity will not be reached until the battery has been charged 3–4 times. Batteries degrade over time, which means that call time and standby time will normally decrease with regular use.

English

Save energy

When you have fully charged the battery and disconnected the charger from the device, unplug the charger from the wall socket.

Get to know your phone

Assistive functions

Use the symbols below to guide you through supporting sections in the manual.

Seeing

Hearing

Handling

Safety

Turn the phone on and off

1. Press and hold on the phone to turn it on or off. Confirm with Yes to power off.

2. If the SIM card is valid but protected with a PIN code (Personal Identification Number), PIN is displayed. Enter the PIN code and press OK ( right corner of keypad).

Note! If PIN and PUK codes were not provided with your SIM card, please contact your service provider.

Attempts: # shows the number of PIN attempts left. When no more at- tempts remain, PIN blocked is displayed. The SIM card must then be unlocked with the PUK code (Personal Unblocking Key).

1. Enter the PUK code and confirm with OK.

2. Enter a new PIN code and confirm with OK.

3. Re-enter new PIN code and confirm with OK.

upper left corner of keypad). Delete with Clear ( upper

Start-up wizard

When starting the phone for the first time, you can use the Start-up wizard to set some basic settings.

• Press Yes to change or No if you do not want to change.

The default language is determined by the SIM card. See Phone settings, p.8 on how to change language, time and date.

English

Tip: You can run the start-up wizard later if you want. From standby mode, press Menu

Settings General Start-up wizard.

External display

The external display shows the time, a number of status indicators, and notifications for incoming calls. The external display can only display characters in black and white. If the external display times out, press and hold any of the side keys +/– to turn it back on.

Phone indicators

Lights on the phone will:

• Flash green when you have a new message or a missed call. After reading the new message/missed call, the flashing will stop.

• Flash red when the battery is running low and during charging.

How to navigate the phone

Standby (idle mode)

When the phone is ready to use, and you have not keyed in any characters, the phone is in standby.

Tip: You can always press

Navigation buttons

• Press (A)

• Alternatively press selection button OK.

• Press (A)

menu.

• Alternatively press left selection button Menu to access the phone menu or right selection button saved contacts in the phonebook.

• Press the arrow buttons (B)

, to scroll and to select.

to confirm.

from standby to open the phone

to return to standby.

Name to access your

, and

English

Step-by-step instructions

The arrow ( ) indicates next action in step-by-step instructions. To confirm an action, press OK. To select an item, scroll or highlight the item us-

ing

Example:

/ and then press OK.

• Press Menu

To perform the example on your Doro 6530 you should do the following:

Example 1 (use the selection buttons)

1. Press Menu, scroll to Phonebook and press OK.

2. Select -New contact- and press Add.

Example 2 (use the navigation buttons)

1. Press

2. Select -New contact- and press

, scroll to Phonebook and press .

Phonebook -New contact- Add.

to confirm.

Enter text

Enter text manually

Select character

• Press a numerical key repeatedly until the desired character is shown. Wait a few seconds before entering the next character.

Special characters

1. Press*for a list of special characters.

2. Select the desired character with the arrow keys and press OK to confirm.

Move the cursor within text

• Use

Upper case, lower case and numerals

• Press#to choose between upper case, lower case and numerals. See Input mode, p.6.

Change writing language

1. Press and hold#for a list of available languages.

2. Select language with

or to move the cursor within the text.

/ and press OK to confirm.

English

Enter text with predictive text

In some languages you can use the Smart ABC (eZiType™) input method which uses a dictionary to suggest words.

• Press each key once, even if the displayed character is not the one you want. The dictionary will suggest words based on the keys you have pressed.

Example

1. Press3,7,3,

to write the word “Fred”. Complete the word be-

fore looking at the suggestions.

2. Use

, and , to view the suggested words.

3. Press Select and continue with the next word. Alternatively, press0to continue with the next word.

4. If none of the suggested words are correct, use manual input mode.

Note! See Predictive text, p.27 for more information.

Input mode

Press#to change input mode. The icon on the top left of the display indicates the input mode.

Abc ABC

abc Abc ABC UPPER CASE abc lower case 123

Sentence case with predictive text UPPER CASE with predictive text lower case with predictive text Sentence case

Numerals

Volume control

During a call

• Use the side buttons +/– or

/ to adjust the sound volume.

The volume level is indicated on the display.

If you use a hearing aid or have hearing difficulties when using the telephone in a noisy environment, you can adjust the phone's audio settings, see Audio setup

, p.40.

English

Silent

Silent is a fixed profile with Keypad tone, Message tone and Ringtone disabled, while Vibration, Tasks, Daily reminder and Alarm are unchanged.

• Press and hold shortcut button#to activate or deactivate silent mode.

Headset

When a headset is connected, the internal microphone in the phone is automatically disconnected. If available, use the answer key on the headset to answer and end calls.

CAUTION

Using a headset at high volume may damage your hearing. Adjust the volume level carefully when using a headset.

Hearing aid compatible

This phone is hearing aid compatible. Hearing aid compatibility is not a guarantee that a specific hearing aid will work with a specific phone. Mobile phones contain radio transmitters that may interfere with hearing aid performance. This phone has been tested for use with hearing aids, for some of the wireless technologies that it uses, but there may be some newer wireless technologies that have not been tested yet for use with hearing aids. To ensure that a specific hearing aid works well with this phone, test them together before making a purchase.

The standard for hearing aid compatibility contains two types of ratings:

• M: To use your hearing aid in this mode, make sure that your hearing aid is set to "M-mode" or acoustic coupling mode, and position the phones receiver near the hearing aid’s built-in microphone. For the best results, try using the phone in different positions relative to your hearing aid—for example, placing the receiver slightly above the ear may result in better performance for hearing aids with microphones positioned behind the ear.

• T: To use your hearing aid in this mode, make sure that your hearing aid is set to "T-mode" or telecoil coupling mode (not all hearing aids have this mode). For the best results, try using the phone in different positions relative to your hearing aid—for example, placing the

English

receiver slightly below or in front of the ear may result in better performance.

Phone settings

Time & date

Set the time and date

1. Press Menu

• Set time to enter the time (HH:MM).

• Set date to enter the date (DD/MM/YYYY).

2. Press OK to confirm.

Tip: You can also set the phone to automatically update the time and date according to the current time zone. In Time & date select Auto time

On. Automatic update of date and time does not change the time you

have set for the alarm clock or the calendar. They are in local time. Updating may cause some alarms you have set to expire depending on network support and subscription.

Settings General Time & date:

Set the time and date format

1. Press Menu format:

• Time format

• Date format and select the desired date format.

2. Press OK to confirm.

Settings General Time & date Set

12 hours or 24 hours.

Language

The default language for the phone menus, messages, etc. is determined by the SIM card. You can change this to any other language supported by the phone.

1. Press Menu

2. Use

3. Press OK to confirm.

/ to select a language.

Settings General Language.

Block function

1. Press Menu Settings General Block function.

2. Select each function you want to disable and press Off.

English

3. Press Done to confirm.

PIN code options

1. Press Menu Settings Security SIM lock:

• On to activate the PIN code. You need to enter the PIN code every time the phone is started.

• Off to deactivate the PIN code.

IMPORTANT!

If enabling Off-mode and the SIM card is lost or stolen, it is unprotected.

• Automatic to start the phone without the PIN code. The phone remembers it automatically, but if the SIM card is moved to another phone (lost or stolen) the PIN code needs to be entered when the phone is started.

2. Press OK to confirm.

Change PIN code

1. Press Menu

Settings Security Passwords PIN.

2. Enter current PIN code and press OK.

3. Enter new PIN and press OK. Repeat to confirm.

Phone lock

The phone lock protects your phone from unwanted usage. If activated, phone is locked after restart and the phone code needs to be entered to unlock.

1. Press Menu

Settings Security Phone lock.

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

Note! You need to enter current phone code. Default phone code is 1234.

Whitelist

A whitelist works much like a spam filter, once activated, you can only receive incoming calls from contacts saved in the phonebook. People not stored in the phonebook gets a busy signal when trying to call you.

1. Press Menu

2. Select On to enable, or Off to disable.

Settings Security Whitelist.

English

3. Press OK to confirm.

Calls

Make a call

1. Enter the phone number including the area code. Delete with Clear.

2. Press

3. Press

Tip: For international calls, always use + before the country code for best operation. Press*twice for the international prefix +.

to make a call. Press Abort to cancel the call. to end the call.

Call from the phonebook

1. Press Name to open the phonebook.

2. Use pressing the key corresponding to the first letter of the entry, see En-

ter text

3. Press Options the number. Alternatively, press

4. Press Abort or

/ to scroll through the phonebook, or quick search by

, p.5.

Call to dial the selected entry. If needed, select

to dial.

to cancel the call.

Receive a call

1. Open the flip and press to answer. Alternatively press Silent to switch off the ringsignal or press

2. Press

To answer an incoming call by opening the flip, see Answer mode, p.13.

Tip: Press and hold +/– to temporarily switch off the ringsignal without opening the flip.

/close the flip to reject directly (busy signal).

to end the call.

Call information

During a call, the outgoing or incoming phone number and the elapsed call time is displayed. If the identity of the caller is withheld, Unknown is displayed.

English

Call options

During a call the selection buttons1( ) give access to additional functions.

Options (left selection button)

• Volume to adjust the volume.

• Hold/Retrieve to hold/retrieve the current call.

• End single call to end the current call (same as

• New call to call another number (Conference).

• Phonebook to search the phonebook.

• Messages to write or read text messages.

• Mute to disable the microphone.

SPK on (right selection button)

The loudspeaker allows you to speak without holding the phone close to the ear.

1. Press SPK on to activate. Speak clearly into the phone microphone at a maximum distance of 1 m. Use

speaker volume.

2. Press SPK off to return to normal mode.

/ to adjust the loud-

Note! Loud background noises (music, etc.) may interfere with the sound quality.

Speed dial

Use0and2–9to speed dial an entry from standby.

• Press and hold the corresponding key.

Add speed dial numbers

1. Press Menu

2. Select

3. Press OK to confirm.

4. Repeat to add speed dial entries for buttons2–9.

1. Selection buttons have multiple functions. The current function is shown

above the selection button on the display.

Settings Phonebook Speed dial.

Add and select an entry from the phonebook.

English

Tip: To edit or delete an existing entry, select it and press Options Edit or Delete.

SOS calls

As long as the phone is switched on, it is always possible to place an SOS call by entering the main local emergency number for your present location followed by

Some networks accept calls to emergency numbers without a valid SIM card. Contact your service provider for more information.

Call log

Received, missed and made calls are saved in a combined call log. 20 calls of each type can be stored in the log. For multiple calls related to the same number, only the most recent call is saved.

1. Press Alternatively, press Menu

2. Use

3. Press to call, or Options:

• View to show details for the selected call.

• Send SMS to send a text message.

• Send MMS to send a picture message.

• Delete to delete the call.

• Delete all to delete all calls in the call log.

• Save to save the number in the phonebook

Call log.

/ to select:

Received call

Dialled call

Missed call

Create new cre-

ate new contact, or Update update existing contact.

Call settings

Call time

During a call, the duration of the call is shown. You can check the duration of your calls.

1. Press Menu

Settings Calls Call time:

English

• Last call to show the elapsed time of the most recent call.

• Outgoing calls to show the elapsed time of all made calls.

• Received calls to show the elapsed time of all received calls.

• Reset all

Yes to reset all.

2. Press OK to confirm.

Answer mode

1. Press Menu Settings Calls Answer mode:

• Open to answer

On to answer incoming calls by opening the

flip.

• Any key

any key (exemption

On to be able to answer incoming calls by pressing

2. Press OK to confirm.

Caller ID

Display or hide your phone number on the recipient's phone when you call.

1. Press Menu

Settings Calls Call setup Caller ID:

• Set by network to use default setting by the network.

• Hide ID to never show your number.

• Send ID to always show your number.

2. Press OK to confirm.

Call waiting

You can handle more than one call at a time, put the current call on hold and answer the incoming call. When activated, an alert tone is heard if there is an incoming call while talking.

• During a call, press Options

Answer.

Activate call waiting

1. Press Menu

2. Select Call waiting

Settings Calls Call setup.

Activate.

3. Press OK to confirm.

Tip: Repeat and select Deactivate to disable call waiting, or Query status

to display if call waiting is active or not.

English

Call divert

You can divert calls to an answering service or to another phone number. Set up which calls should be diverted. Select a condition and press OK, then select Activate, Deactivate or Query status for each.

1. Press Menu

Settings Calls Call setup Call divert:

• Voice calls to divert all voice calls.

• Unreachable to divert incoming calls if the phone is turned off

or out of range.

• No reply to divert incoming calls if unanswered.

• If busy to divert incoming calls if the line is busy.

• Cancel diverts to cancel all call divert settings.

2. Press OK to confirm.

Call barring

Your phone can be restricted to disallow certain types of calls.

Note! A password is needed to apply call barring. Contact your service provider to get the password.

1. Press Menu

2. Select Outgoing calls:

• All calls to answer incoming calls but not calling.

• Internat.calls to block calls to international numbers.

• Int. except home to block international calls except to the coun-

try associated with the SIM card.

3. Press OK to confirm.

4. Select Incoming calls:

• All calls to call but not to receive incoming calls.

• When roaming to block incoming calls while roaming (operating

in other networks).

5. Press OK to confirm.

6. Select Cancel all to cancel all call barring (password needed). Press

OK to confirm.

Settings Calls Call setup Call barring.

Fixed dial (FDN)

You can limit calls to certain numbers saved on the SIM card. The list of allowed numbers is protected by your PIN2-code.

English

Note! The PIN2-code is needed to apply fixed dial. Contact your service provider to get the PIN2-code.

1. Press Menu

• Mode

• Fixed numbers

Alternatively, select an entry and press Options Delete.

2. If needed, enter PIN2 and press OK to confirm.

Note! You can save parts of phone numbers. For example, if you save

01234, allows calls to all numbers starting with 01234. It is possible to place an SOS call by entering the main local emergency number followed by are not allowed to view or manage any phone numbers saved on the SIM card. You are not able to send any text messages either.

even when fixed dial is activated. When fixed dial is activated you

Settings Security Fixed dial:

On to enable or Off to disable.

Add and enter the first allowed number.

Add, Edit or

Phonebook

Add contact

1. Press Menu Phonebook -New contact- Add.

2. Enter a Clear.

3. Use the phone number(s) including the area code.

Name for the contact, see Enter text , p.5. Delete with

/ to select Mobile, Home or Office and enter

4. Select mail settings, p.30.

5. Select Phonebook picture, p.17.

• Take picture to use the camera to take a picture.

• My pictures to select an existing picture.

6. Select Tone setup (ringtone), p.40.

• System to select from preinstalled files.

• User to select from your downloads.

7. Press Save.

E-mail to associate e-mail address to the contact, see E-

Picture Edit to associate picture to the contact, see

Ringtone Edit to associate ringtone to the contact, see

English

Tip: For international calls, always use + before the country code for best operation. Press*twice for the international prefix +.

Manage phonebook contacts

1. Press Menu Phonebook.

2. Select a contact, then press Options:

• View to show details for the selected contact. age set to Phone and

SIM = storage set to SIM, see Phone-

Phone = stor-

book storage, p.17.

• Edit to edit the contact. Use

/ to scroll. Delete with

Clear. Press Save when done.

• Top 10 to set the entry as one of the first 10 contacts listed in the phonebook. See Top 10, p.18.

• Call to call the contact.

• Add to add contact. See Add contact, p.15.

• Send SMS to create text message, see Create and send text

message (SMS), p.23.

• Send MMS to create picture message, see Create and send pic- ture message (MMS), p.23.

• Send e-mail to create e-mail message, see Create and send e- mail, p.24.

• Delete to delete the selected contact. Press Yes to confirm or No to abort.

• Delete all

From SIM/From phone to delete all phonebook

contacts from the SIM card or phone memory. Enter the phone code and press OK to confirm. The default phone code is 1234.

• Copy all

From SIM to copy all phonebook contacts from the

SIM card to the phone memory, or From phone to copy all contacts from the phone memory to the SIM card. Press Yes to confirm or No to abort.

• Send vCard:

• Send by SMS, see Create and send text message (SMS),

p.23.

• Send by MMS, see Create and send picture message (MMS), p.23.

• Send by Bluetooth, see Bluetooth

, p.35.

English

• Send by e-mail, see Create and send e-mail, p.24.

3. Press OK to confirm.

Phonebook settings

Owner number

The phone number assigned to your SIM card is saved as Owner number if this is allowed by the card.

Add numbers

1. Press Menu

2. Enter name and number, see Enter text

3. When done, press OK.

Phonebook storage

1. Press Menu Settings Phonebook Storage:

• SIM to save up to 3 phone numbers and one e-mail address per contact.

• Phone to save 500 contacts with 3 phone numbers each Mo- bile, Home, Office. As well as one e-mail address, and Phonebook picture to assign images to contacts and Ringtone to

assign specific ringtones to contacts.

2. Press OK to confirm.

Phonebook Owner number Empty Add.

, p.5.

Note! Number and length of the phone numbers/contacts that can be stored will vary depending on SIM card/service provider preferences.

Phonebook picture

You can change the phonebook view mode.

1. Press Menu

• On to display the contact’s associate picture if existing.

• Off to display only the names of contacts.

2. Press OK to confirm.

Settings Phonebook Phonebook picture:

Voice mail

If your subscription includes an answering service, callers can leave a voice mail message when you are unable to answer a call. Voice mail is a network service and you may need to subscribe to it first. For more information and for the voice mail number, contact your service provider.

English

1. Press Menu Settings Phonebook Voice mail:

2. Select Empty

• Phonebook to add a contact from the Phonebook. Press OK to confirm.

• Manual and enter name and number.

3. Press OK to confirm. To edit or delete an existing entry, select it and press Options

Delete.

Call voice mail

• Press and hold shortcut button1.

Add:

Edit or

Top 10

Set an entry as one of the first 10 contacts listed in the phonebook.

1. Press Menu

2. Select one of the empty entries and press Add.

3. Use pressing the key corresponding to the first letter of the entry.

4. Press OK to save the selected entry, or press Back to discard changes.

To edit or delete an existing entry, select Options

Tip: You can also add an contact and press Options

/ to scroll through the phonebook, or quick search by

Settings Phonebook Top 10.

Edit or Delete.

entry from the phonebook. Select the

Top 10.

ICE (In Case of Emergency)

First responders can access additional information such as medical information from the victim's phone of a trauma, it is critical to have this information as early as possible to increase the chances of survival. All fields are optional, but the more information provided the better.

1. Press Menu

2. Use

3. Press Edit to add or edit information in each entry, see Enter text p.5. Delete with Clear.

/ to scroll the list of entries.

Phonebook ICE.

in case of emergency. In the event

English

• Name: enter your name.

• Birth: enter your date of birth.

• Height: enter your height.

• Weight: enter your weight.

• Address enter your home address.

• Language: enter your preferred language.

• Insurance: enter your insurance provider and policy number.

Contact 1:, Contact 2: and Doctor:

• Press Options to Add or Delete a contact from the phonebook, or Save to accept the current entry. If possible, add your relationship to your ICE contacts in the phonebook, such as “ICE Wife Mary Smith”.

Important info

• Condition: enter any medical conditions or medical devices (e.g. diabetic, pacemaker).

• Allergies: enter any known allergies (e.g. penicillin, bee stings).

• Blood type: enter your blood type.

• Vaccination: enter any relevant vaccination.

• Medication: enter any medication that you are treated with.

• Other info: enter other information (e.g. organ donor, living will,

consent to treat).

4. When done, press Save.

Assistance button

CAUTION

When an assistance call is activated the phone is pre-set to handsfree/ speakerphone mode. Do not hold the device near your ear when the handsfree mode is in use, because the volume may be extremely loud.

The assistance button allows easy access to contact your predefined help numbers (Number list) should you need help. Make sure that the assistance function is activated before use, enter recipients in the numbers list and edit the text message.

English

Make an assistance call

1. When help is needed, press and hold the assistance button for 3 seconds, or press it twice within 1 second. The assistance call begins after a delay of 5 seconds. In this time you can prevent a possible false alarm by pressing

2. An assistance text message (SMS) is sent to all recipients.

3. A positioning text message (SMS) is sent to all recipients.

4. The first recipient in the list is called. If the call is not answered within 25 seconds, the next number is called. Calling is repeated 3 times or until the call is answered, or until

Note! Some private security companies can accept automatic calls from their clients. Always contact the security company before using their phone number. Programming '999' into the assistance button is blocked.

Tip: The assistance function may be configured so that the recipient of the call must press0(zero) to confirm, in order to stop the alarm

sequence. See Confirm with "0", p.22.

is pressed.

IMPORTANT!

Information to the recipient of an assistance call, when Confirm with "0" is activated.

• After receiving the assistance message, each number in the Number list is called sequentially.

• To confirm the assistance call, the recipient needs to press0.

• If the recipient doesn’t press

answering) the call will be disconnected and the next number in the sequence will be called.

• If the recipient presses0within 60 seconds, the call is confirmed and no further call attempts will be made (assistance sequence interrupted).

within 60 seconds (after

Activation

Select how to activate the assistance function using the assistance button.

1. Press Menu

Settings Assistance Activation:

English

• On Normal to press and hold the button for approximately 3 seconds, or press it twice within 1 second.

• On (3) to press the button 3 times within 1 second.

• Off to disable the assistance button.

2. Press OK to confirm.

Number list

Add numbers to the list that is called when the assistance button is pressed.

IMPORTANT!

Always inform recipients in the Number list that they are listed as your assistance contacts.

1. Press Menu

2. Select Empty phonebook. Alternatively, press Manual to add names or numbers manually. See Add contact, p.15.

3. Press OK to confirm.

4. Repeat until you have 5 contacts (maximum).

Tip: To edit or delete an existing entry, select it and press Options Edit or Delete.

Settings Assistance Number list.

Add Phonebook to add a contact from the

Activate text messages (SMS)

A text message can be sent to the contacts in the numbers list when the assistance button is pressed.

Activation

1. Press Menu

• On to send a text message before calling.

• Off to call without sending a text message first.

2. Press OK to confirm.

Create assistance message

Settings Assistance SMS Activation:

1. Press Menu

2. Select Edit and write the message, see Enter text

3. Press OK to confirm.

Settings Assistance SMS Message.

, p.5.

English

Note! You must write a message if you activate the SMS function.

Position SMS

This function sends a text message with the users position to the recipients in Number list when an assistance call occurs. The message contains date, time, and the positioning information of the Doro user. The message is not editable. If no position can be found the message contains the latest known position. The positioning message is sent after the editable assistance message, but before the assistance call sequence starts.

Activation

1. Press Menu Settings Assistance Position SMS .

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

Assistance settings

Confirm with "0"

You can activate the Confirm with "0" function. This is especially recommended if there is a risk that the assistance call is answered by a voice

mail or answering service. If the recipient doesn’t press0within 60 seconds the call will be disconnected and the next number in the sequence

will be called. If the recipient presses0within 60 seconds, the call is confirmed and no further call attempts will be made (assistance sequence interrupted).

1. Press Menu

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

Settings Assistance Confirm with "0".

Signal type

Select the notification signal type for the assistance sequence.

1. Press Menu

• High to use loud signals (default).

• Low to use one low signal.

• Silent no sound indication, like a normal call.

2. Press OK to confirm.

Settings Assistance Signal type:

English

Messages

Create and send text message (SMS)

Note! Before you can send any text messages, you need to save your

message centre number. The number to your service centre is supplied by your service provider and is usually set on the SIM card. If not, you can enter the number yourself. See SMS centre, p.28.

1. Press shortcut button or press Menu

2. Write your message, see Enter text

3. Select a recipient from Phonebook. Alternatively, select Enter number to add recipient manually and press Done.

4. Press Add to add more recipients.

Tip: You can modify the recipients by selecting one, press Options

Edit/Delete/Delete all.

5. When done, press Send.

Note! If you choose to add multiple recipients, you will be charged for

each recipient (maximum 10). For international calls, always use + before the country code for best operation. Press*twice for the

international prefix +.

Messages Create new SMS.

, p.5, then press To.

Create and send picture message (MMS)

A picture message can contain text and media objects such as pictures, sound recordings and video. Both you and the recipient must have subscriptions that support picture message. The settings for picture message are supplied by your service provider and can be sent to you automatically via text message. If not, see MMS settings, p.28 on how to set your MMS profile.

1. Press shortcut button

or press Menu

2. Write your message, see Enter text

3. Press Options

• My pictures to select a file.

• Take picture to use the camera to take a picture.

Messages Create new MMS.

Add picture:

, p.5.

English

Note! If you add more than one picture, the following pictures are increasingly compressed by the phone (scaled down). This to allow you to send more pictures in one message. To keep best picture quality, send only one picture per message.

You can also Add sound, Add video and, Preview MMS using the Op- tions menu.

4. Press Options Done.

5. Press Options Alternatively, select Enter number to add recipient manually and press Done.

6. Press Add to add more recipients.

7. Press Send to send.

Add subject and enter your subject, then press

To and select recipient from Phonebook.

Create and send voice message

A voice message uses the same technology as a picture message. Both you and the recipient must have subscriptions that support picture message. The settings for picture message are supplied by your service provider and can be sent to you automatically via text message. If not, see MMS settings, p.28 on how to set your MMS profile.

1. Press the shortcut button or press Menu

2. Select Create new

3. Recording starts immediately. Press Stop when done and press Yes to save.

4. Select recipient from Phonebook. Alternatively, select Enter number to add recipient manually and press Done.

5. Press Add to add more recipients

6. Press Send to send.

Messages.

Voice message.

Create and send e-mail

IMPORTANT!

Using data services can be costly. We recommend that you check your data rates with your service provider.

English

You can send or view e-mail messages using your personal or company email account. See E-mail settings, p.30 on how to setup your e-mail.

1. Press the shortcut button or press Menu

Messages Create new E-mail.

2. Write your message, see Enter text

, p.5,

3. Select Options.

4. Select To and select recipient from Phonebook. Alternatively, select Enter recipient to add recipient manually and press Done.

5. Press Add to add more recipients.

6. Press Back.

7. From Options

8. From Options

Add subject. Add picture:

• My pictures to select a file.

• Take picture to use the camera to take a picture.

You can also Add sound and Add video using the Options menu.

9. Press Send to send.

Switch between accounts

If you create more than two e-mail accounts, you can switch between them.

1. Press Menu

Messages E-mail Change account

Accounts.

2. Use

/ to select account.

Download e-mail

• Press Menu

Messages E-mail Inbox.

Note! After configuring your account, you can view previously retrieved e-

mail offline or connect to the e-mail server to view new messages. After you retrieve e-mail messages, you can view them offline.

Signing in on Gmail / Yahoo

E-mail accounts, like Gmail and Yahoo require you to change an account setting before you are able to access e-mails on your new Doro phone. To avoid problems signing in, you may need to log-into your Gmail / Yahoo account. Please use the following process to activate the use of your

English

account on your Doro phone or you may receive a ‘pop up’ message that the ‘authentication process has failed’.

Account settings

1. Use a computer web browser to log in to your Gmail/Yahoo account.

2. Click your name (top right corner) curity section click) Connected apps & sites/Account security

low less secure apps

Set the switch to ON.

My Account (Under the se-

Al-

3. Try to log in with your device again

Gmail still not working?

1. Use a computer web browser to log in to your Gmail account.

2. Use the shortcut link: https://accounts.google.com/b/0/

DisplayUnlockCaptcha

3. Click Continue.

4. Try to log in with your device again.

Inbox, Outbox and Sent

1. Press shortcut button . Alternatively press Menu

2. Select Inbox, Outbox or Sent.

Messages.

3. Select a message and press Read. Use

/ to scroll up/down.

4. Press Options:

• View (MMS only) to view the message.

• Call to call the contact.

• Resend to send again to the same recipient.

• Reply to write your reply, then press Send. The message is sent

immediately.

• Delete to delete. Press Yes to delete or No to return.

• Download/Cancel download. If the message is not downloaded

yet, press Download.

• Edit to edit the message, then press Send.

• Forward to forward the message. Edit the message (if desired),

then press Send.

• Use address to display e-mail addresses contained in the message.

• Options

Save Create new or Update.

English

• Options Send mail to write a new e-mail.

• Use number to display all phone numbers contained in the

message as well as the sender's number.

• Call to call the selected number.

• Save to save the number in the phonebook.

• Send SMS to write a new text message.

• Send MMS to write a new picture message.

• Save objects (MMS only) to save text and media objects such

as pictures, sound recordings and video.

• Details (MMS only) to view details of the message.

5. Press OK to confirm.

Message settings

Predictive text

1. Press Menu Settings Messages Predictive text.

2. Select On (default) to enable, or Off to disable.

3. Press OK to confirm.

Writing language

1. Press Menu Settings Messages Writing language.

2. Use

3. Press OK to confirm.

/ to select a language.

Write speed

You can change the speed at which keypad characters repeat before the cursor moves on to the next character.

1. Press Menu

2. Select Write speed

3. Press OK to confirm.

Settings Messages.

Slow, Normal or Fast.

SMS settings

• Press Menu Settings Messages SMS settings.

English

Memory status

1. From SMS settings, select Memory status to display the memory space used on the SIM card and in the phone memory. Phone memory can store up to 450 messages.

2. Press Back to return.

Storage

1. From SMS settings, select Storage:

• SIM (default) to store messages on the SIM card.

• Phone to store messages in the phone memory.

2. Press OK to confirm.

SMS centre

1. From SMS settings, select SMS centre

Edit.

2. Enter the service centre number. Press Clear to delete.

3. Press OK to confirm.

Cell broadcast

You can receive messages on various topics from your service provider, such as weather or traffic conditions in a particular region. For available channels and relevant channel settings, contact your service provider. Cell broadcast messages cannot be received when the device is roaming.

1. From SMS settings, select Cell broadcast:

• Activation to turn information On or Off.

• Read messages to read the message.

• Languages to select language On or Off.

• Channel settings to select from which channels to receive or

subscribe messages. Use the options Subscribe, Cancel subscription, Add, Edit and Delete to define your channels.

2. Press OK to confirm.

MMS settings

• Press Menu Settings Messages MMS settings.

Memory status

1. From MMS settings, select Memory status to display the memory space used on the memory card (if inserted) and in the phone memory. Phone memory can store up to 8 MB.

English

2. Press Back to return.

Storage

Picture messages are saved by default in the phone memory. When the memory becomes full you will need to either delete a picture message (see Inbox, Outbox and Sent, p.26) or select to save your picture messages to the memory card. When the memory is full you will see a message when you try to send or receive a picture message.

Note! Make sure to insert a compatible memory card before saving to it (see Insert SIM card, memory card and the battery, p.1). The storage menu only appears if you have inserted a card.

1. From MMS settings select Storage:

• Phone to store in the phone memory.

• Memory card to store picture messages to the memory card.

2. Press OK to confirm.

MMS profile

These settings are needed to use the picture messages function. The settings for picture messages is supplied by your service provider and can be sent to you automatically.

1. From MMS settings, select MMS profile.

2. Select your service provider and press Options

Activate.

Add new MMS profile

Follow the steps below if your service provider is not in the list. Contact your service provider for correct settings.

1. From MMS profile, select Add:

• Account name to add account name.

• APN to add APN (Access Point Name).

• User name to add user name.

• Password to add password.

• Homepage to add homepage.

• Connection type use the side buttons +/- to select connection

enter HTTP or WAP.

• Proxy address to add proxy address.

English

• Proxy port to add proxy port.

• User name to add proxy user name.

• Password to add proxy password.

2. Press OK to confirm.

3. Press Yes to save or No to exit without saving.

4. Select your new profile and press Options

Activate.

5. Press OK to confirm.

To edit or delete an existing entry, select it and press Options

Edit or

Delete.

Note! Some service providers require you to send a picture message

before you will be able to receive one. Send a picture message with text only to activate the service. Some service providers require that you contact them before enabling picture message for your account. Contact your service provider’s Customer Service. Press

during set up to exit

without saving.

E-mail settings

Enables you to review and create e-mails using your personal or company e-mail account. In order to utilize the e-mail service on your Doro 6530 you need to have an already configured e-mail account such as Google Mail, Yahoo or Hotmail.

Note! You can add up to 10 different e-mail accounts.

• Press Menu

Settings Messages E-mail:

The first time you configure an account you are prompted Start to create account?. Press Yes.

Set up general e-mail accounts

For general e-mail accounts such as (Google Mail, Yahoo or Hotmail).

1. From E-mail

Select:

• Gmail

• Hotmail

• Yahoo

2. Enter your E-mail address and your Password.

English

3. Press OK to confirm.

Set up other accounts

Follow the steps below if your service provider is not in the list. Contact your service provider for correct settings.

1. From E-mail

Select:

2. Select Other e-mail accounts.

• Enter E-mail address.

• Select POP3 or IMAP4.

• Enter Incoming server.

• Enter Outgoing server.

• Enter User name.

• Enter Password.

• Enter Account name.

3. Select Check interval.

IMPORTANT!

Using data services can be costly. We recommend that you check your data rates with your service provider before selecting any of below intervals.

• Off is default.

• 5 min

• 30 min

• 1 hour

• 2 hours

4. Press OK to confirm.

To edit or delete an existing entry, select it and press Options

Delete. Select E-mail setup wizard to configure new accounts.

Edit/

Vibration

The text message vibration alert is several short vibrations.

1. Press Menu

2. Select Messages:

• Short (4 seconds)

• Long (12 seconds)

Settings Messages Vibration.

English

3. Press OK to confirm.

Note! If Alert type is set to Ring only the phone will not vibrate.

Reminder

The reminder alerts you once if you haven't checked your messages or listened to your voice mail within 10 minutes from receipt. When notified, press

to end the notification and no more reminder is heard.

1. Press Menu

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

Settings Messages Reminder.

Delivery report

You can select if you want the phone to notify you when your text message has reached the recipient.

Note! Contact your service provider for detailed subscription costs before activating.

1. Press Menu

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

Settings Messages Delivery report:

Camera

You can take photos, record videos and view your photos and videos using the

Camera menu.

Camera

Camera (take photos)

To get sharp photos, wipe the lens clean with a dry cloth.

1. Press shortcut button Alternatively press Menu

2. Press

3. Press Options:

• Send

to take photo.

Send by MMS, see Create and send picture message

(MMS), p.23.

Send by Bluetooth, see Bluetooth®, p.35.

Camera Camera.

English

• Send Send by e-mail, see Create and send e-mail, p.24.

• Delete to delete. Press Yes to confirm or No to return.

• Use

Wallpaper to save as display background. Phonebook picture to save as phonebook contact.

4. Press Back to take a new photo. If you do not make any selection the picture is saved.

Camera adjustments

• Use

/ to zoom in and out.

• Use the side buttons +/– to adjust EV/Light sensitivity.

• Use Flash to set the flash as Auto, Off, On or Red-eye reduction.

Note! Zoom may reduce picture quality.

For more camera settings, see Camera settings, p.34.

Video camera

To get sharp videos, wipe the lens clean with a dry cloth.

1. Press Menu

2. Press

3. Press

4. Press Options:

• Play

• Send

(MMS), p.23.

• Send

• Delete to delete. Press Yes to confirm or No to return.

5. Press Back to return.

Camera Video camera.

to start recording.

to stop recording. Select Yes to save.

Send by MMS, see Create and send picture message

Send by e-mail, see Create and send e-mail, p.24. Send by Bluetooth, see Bluetooth®, p.35.

Video camera adjustments

• Use

/ to zoom in and out.

• Use the side buttons +/– to adjust EV/Light sensitivity.

• Use Lamp to switch the lamp on or off.

Note! Zoom may reduce video quality.

English

For more video camera settings, see Camera settings, p.34.

Picture gallery and Video gallery

View your saved pictures or videos .

1. Press Menu

2. Use

/ or / to select a picture or video.

Camera Picture gallery or Video gallery.

3. Press Options:

• View for single view. Press Back to return. Use

• Send

/ to play and stop the video (video only).

Send by MMS to send as picture message. See Create

and send picture message (MMS), p.23.

• Send

Bluetooth

• Send

Send by Bluetooth to send to a Bluetooth device, see

, p.35.

Send by e-mail, see Create and send e-mail, p.24.

• Delete to delete. Press Yes to confirm or No to return.

• Use (picture only)

Wallpaper to save as display background. Phonebook picture to save as phonebook

contact.

• Details to view detailed information about the file, e.g. date, size, copyright.

• Rename to rename picture.

• Browse style (picture only) to change view. Select Large, List or

Medium.

4. Press OK to confirm.

Camera settings

1. Press Menu Settings Camera:

• EV information: EV/Light sensitivity can be adjusted by pushing volume keys up and down when in camera mode.

• Browse style to change view. Select Large, List or Medium.

• Sort by to sort pictures and videos by Name or Time.

• Storage to save pictures and videos on Phone or Memory card.

Note! This option is only available when a compatible external memory is inserted in the device.

English

• Delete all to delete all saved pictures and videos.

• Image size to set as Small (lowest quality), 1 MP or 2 MP (high-

est quality).

• Video camera

• Shutter sound

Quality to set as High or Low. Record time to set as No limit or 1 min.

Off, Low or High.

2. Press OK to confirm.

Note! With higher quality, less pictures or videos can be stored in the

internal memory.

If you insert a compatible external memory (micro SD) card into your Doro 6530, you can change the default storage location, see Storage, p.29. This allows you to save more files on your device, like pictures and videos.

Connectivity

Bluetooth

IMPORTANT! When you are not using Bluetooth connectivity, select Function on/off

Off or select Visibility Off. Do not pair with an unknown device.

Activate Bluetooth

1. Press Menu

Settings Bluetooth Function on/off.

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

Bluetooth settings

Visibility

1. Press Menu Settings Bluetooth Visibility.

2. Select On to make your device visible to other devices, or Off to be invisible.

3. Press OK to confirm.

Note! To prevent other devices from finding your device, select Off. Even if you select Off, paired devices can still detect your device.

Device name

English

1. Press Menu Settings Bluetooth Device name.

2. Enter the name your Doro 6530 should appear with for other Bluetooth devices.

3. Press Done to confirm.

Search device

Search for available Bluetooth audio devices.

1. Press Menu

Settings Bluetooth Search device.

2. Select a device from the list and press Bond to connect. If Bluetooth is not enabled, press Yes to activate.

3. When connecting to another Bluetooth device you need a shared password. Enter the password and press OK.

My devices

Add new devices or view saved.

1. Press Menu

Settings Bluetooth My devices.

2. Select a device from the list and press Options:

• Connect/Disconnect to connect/disconnect with the selected device. This may require a profile, usually a headset.

• Rename to change the name of the device.

• Delete to delete the device from the list.

• Delete all to delete all devices from the list.

• Security to select an option.

Audio path

1. Press Menu

Settings Bluetooth Audio path:

• Phone to answer incoming calls with the phone.

• Forward BT to forward incoming calls to the Bluetooth device.

2. Press OK to confirm. Security

1. Press Menu

Settings Bluetooth Security:

• Normal (All paired devices are allowed full access automatically.)

• High (Confirmation may be needed for full access for paired devices.)

• Information

2. Press OK to confirm.

English

Internet profile

The Internet settings are used by services that communicates using Internet. The Internet settings for most major service providers are already inserted from start. Another way is to ask your service provider to send the settings directly to your phone.

Follow the steps below if your service provider profile is not in the list. Contact your service provider for correct settings.

1. Press Menu

2. Use

/ to select a profile.

3. Press Options

Settings Connectivity Internet profile.

Edit to enter settings for your service provider:

• Account name to enter the account name.

• APN to enter the APN address.

• User name to enter user name.

• Password to enter password.

• Homepage to enter homepage.

• Connection type select HTTP/WAP.

• Proxy address to enter proxy address.

• Proxy port to enter proxy port.

• User name to enter user name.

• Password to enter password.

4. Press OK, and press Yes to save or No to return.

5. Select your new profile and press Options

Activate.

You can also activate/modify a profile by selecting one and press Options

Activate/Edit/Delete.

Mobile data, data counter and data roaming

IMPORTANT!

Using data services can be costly. We recommend that you check your data rates with your service provider.

Function on or off

Restricts features like internet browser, Facebook, Connect & Care, Weather, My Doro Manager charges.

, MMS and e-mail. Select Off to avoid data

English

1. Press Menu Settings Connectivity Mobile data Func- tion on/off.

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

Data counter

The data counter gathers traffic information from internet browser, Weather, My Doro Manager

, MMS and e-mail.

1. Press Menu

Settings Connectivity Mobile data Data

counter.

• Sent.

• Received.

• Reset all.

Data roaming

Your phone automatically selects your (service providers) home network if within range. If not within range, you can use another network, provided your network operator has an agreement that allows you to do so. This is called roaming. Contact your service provider for more information.

1. Press Menu

Settings Connectivity Mobile data Data

roaming.

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

IMPORTANT!

Using data services while roaming can be costly. Contact your service provider for data roaming rates before you use data roaming.

Network setup

1. Press Menu Settings General Network setup:

Select network

• New search to perform new search if connection is lost.

• Select network to view available network, a list of available net-

work operators is displayed (after a short delay). Select desired operator.

English

• Network mode to select another network. Select Automatic to select network automatically or Manual to select network manually.

Service selection

• GSM service only.

• 3G service only.

• Automatic: switch between GSM and 3G for best service.

IMPORTANT!

If you set your phone to use GSM only or 3G only, you will not be able to make any calls, including emergency calls, or use other features requiring a network connection, if the selected network is unavailable.

Network information

• View your current network settings.

Services

This menu may contain pre-programmed services from your network provider depending on network support and subscription.

• Press Menu

Settings General Services.

Connect the phone to a computer

Connect the phone to a computer and start transferring pictures, music and other file types. All you have to do is connect a USB cable between the phone and computer. From your computer's file explorer, you can drag and drop content between your phone and the computer.

Note! You might not be able to transfer some copyright protected material.

Drag and drop content between phone and a computer

1. Connect your phone to a computer using a USB cable.

2. Wait until the phone or memory card appears as external disks in the file explorer.

3. Drag and drop selected files between the phone and the computer.

Note! You can transfer files using a USB cable on most devices and operating systems supporting a USB Mass Storage interface.

English

Disconnect the USB cable safely

1. Make sure to enable the hardware to be safely removed.

2. Disconnect the USB cable.

Note! Computer instructions may vary depending on your operating system. See the documentation of your computer's operating system for more information.

Sound & Display

Note! Silent needs to be set to Off to access Tone setup, Volume, Alert

type and Extra tone.

Audio setup

If you use a hearing aid or have hearing difficulties when using the device in a noisy environment, you can adjust the audio settings.

1. Press Menu

• Normal for normal hearing in normal conditions.

• Medium for mild hearing impairment or use in a noisy

environment.

• High for moderate hearing impairment or use in a very noisy environment.

• HAC mode for use with hearing aid.

2. Press OK to confirm.

Note! Try different settings to find the one that suits your hearing the best.

Settings Sound Audio setup:

Tone setup (ringtone)

Select a ringtone with the best tone curve adjustments and frequencies to best fit your needs.

1. Press Menu Ringtone:

• System to select from preinstalled files.

• User to select from your downloads.

2. Use will be played.

/ to select one of the available melodies, the melody

Settings Sound Tone setup Ringtone

English

3. Press OK to confirm or Back to discard changes.

Tip: Set up the Alarm, Message tone, Keypad tone, E-mail tone, Closing tone, Opening tone, Power on and Power off in the same way.

Ringtone volume

1. Press Menu Settings Sound Volume.

2. Use

3. Press OK to confirm.

/ to change the ringtone volume.

Silent

1. Press Menu Settings Sound Silent.

2. Select On to enable, or Off to disable.

3. Press OK to confirm.

Tip: From standby mode, press and hold shortcut button#to activate or deactivate silent mode.

Alert type

Select to use ringtone and/or vibration for incoming calls.

1. Press Menu

• Ring only for ringtone only.

• Vib. only for vibration only.

• Vib. and ring for vibration and ringtone.

• Vib. then ring to start with vibration and adds ringtone after a

short while.

• Silent for no sound or vibration, the display light is lit.

2. Press OK to confirm.

Settings Sound Alert type:

Extra tone

You can select to enable warning and error tones to alert you of low battery power, phone and SIM card errors, etc.

1. Press Menu

2. Select Extra tone

3. Select On to enable, or Off to disable.

4. Press Done to save.

Settings Sound.

Warning or Error.

English

Main menu

You can select different styles for the main menu.

1. Press Menu

2. Select Grid or List.

3. Press OK to confirm.

Settings Display Main menu:

Wallpaper

1. Press Menu Settings Display Wallpaper.

2. Use

3. Press OK to confirm.

/ to display available wallpapers.

Idle display

In standby mode the display can show clock only, clock and the service provider, or all information.

1. Press Menu

2. Select Idle display

3. Press OK to confirm.

Settings Display.

Clock only, Clock & Operator or All info.

Themes

You can select different themes to adjust the phone's texts and background.

1. Press Menu

2. Use

3. Press OK to confirm.

/ to select a theme.

Settings Display Themes.

LCD backlight

Select the delay time for the display backlight.

1. Press Menu

Settings Display.

English

2. Select LCD backlight 15 sec., 30 sec. or 1 min.

3. Press OK to confirm.

Brightness

You can adjust the brightness of the display.

1. Press Menu

2. Select Brightness

Settings Display.

Level 1, Level 2 or Level 3.

3. Press OK to confirm.

Doro Connect & Care

Creates a circle of care around you.

Introduction

Your new Doro phone comes with an application called Doro Connect &

. This application is an easy-to-use service that helps you enjoy life

Care while keeping you connected and in touch. It simply makes sure everything is fine without cramping your lifestyle, creating a network of Carers – friends, family and people you trust. Doro Connect & Care helpful hand whenever support is needed, and keeps you closer to your loved ones.

When you need urgent help

Emergency help is never far away. One touch of the Doro Assistance But-

ton alerts everyone in your network that support is urgently needed.

When you run out

More milk, pick up dry cleaning, put the bins out…a little extra help is always nearby. Anyone in your network can create a shared To Do List; reassuring for you if you need a helping hand. Doro Connect & Care comes preinstalled in your new Doro phone so it’s here ready to go. It is easy for your family too, they just need to download the Doro Connect &

app on to their phone and together you can select and set up your

Care circle of care. For more information on how to do this, see www.doro.com. The Doro Connect & Care first year. After the first year, there is a monthly fee.

service is completely free of charge for the

offers a

already

English

How to use the Connect & Care®service on your Doro phone

Activate the Doro Connect & Care®the first time

1. When your Carer admin has setup the Doro Connect & Care®service you will receive a message on your Doro phone asking Would you

like to join the Doro Connect & Care?

2. Press Yes.

3. You will then after a short while receive a second message on your Doro phone asking you to confirm that you want to join the contact list.

4. Press Yes.

5. The Doro Connect & Care phone. You can verify that Doro Connect & Care

pressing Menu

and you will now see the new option Help

request.

Requesting help

Once the Doro Connect & Care®service is activated and you want to request help or assistance:

service is now activated on your Doro

is activated by

1. Press Menu

Help request OK e.g. Shopping.

2. Select the type of help you need; Shopping, Transport, Practical is- sues. Personal matters, or if none of the predefined help request types correspond to the kind of assistance you are looking for, simply select Enter free text to write free text to describe what you need help with.

3. SelectOK, to send the help request your Carers.

Check who administers your Connect & Care

1. Press Menu

2. You now see who has activated and administers your Connect &

Care

service and also the date for activation.

Help request C & C Details.

service

3. Press Back to confirm and return to the previous menu.

Set the Assistance Button to Connect & Care

Your Doro phone comes with an Assistance Button on the rear of the handset. The Assistance Button can be configured to automatically

English

trigger an assistance call to contact your predefined help numbers. For more info on how to set this up, see Assistance button

If you have activated the Connect & Care

service, the Assistance Button

on your Doro phone can be incorporated into the Doro Connect & Care

, p.19.

service instead of triggering an assistance call to your predefined help numbers. This means that when you press and hold the Assistance Button, an automatic alarm is sent to your Carers through the Doro Connect & Care

service instead of making the assistance call. In this way, your Carers phones will automatically display an alarm and a notification that you have pressed the Assistance Button on your Doro phone.

To set the Assistance Button to Connect & Care

1. Press Menu Settings Assistance Mode Connect & Care.

2. Press OK to confirm.

My Doro Manager

Create an Doro Experience®account to get the most out of your phone. Access the phone using any web browser, www.doro.com. Easily view and share your photos or videos.

Note! You need to have Internet access to use most of the features in My

Doro Manager

. Depending on how you use your phone, it can use up a lot of Internet bandwidth really quickly, and it can be costly. Before you use your phone, we strongly recommend that you contact your service provider about data rates.

Create account

1. Press Menu Settings My Doro Manager Create account.

2. Your username is automatically set to your phone number/owner

number. The owner number is supplied by your service provider and is usually set on the SIM card. If not, you can enter the number yourself.

3. Enter password and press

/ .

4. Re-enter the password in the field below and press OK.

English

Note! The username may contain letters (a-z) and numbers (0-9), but (+) is not allowed. Keep the owner number in a safe place, since it will be needed if you need to reset.

Log in/Log out

1. Press Menu Settings My Doro Manager Log in.

2. Enter your phone number as user name.

3. Enter your password and press Log in.

Options

You can select to synchronise your phone with My Doro Manager®.

1. Press Menu

• Minimal synchronisation to synchronise your contacts, calendar and phone settings.

• Full synchronisation to synchronise the same content as above and photos.

• Information to view more information.

2. Press OK to confirm.

Settings My Doro Manager Options:

Sync. intervals

You can select different synchronisation intervals.

1. Press Menu

• Manual to synchronise manually. No automatic synchronising.

• Every 15 minutes to synchronise automatically every 15

minutes.

• Hourly to synchronise automatically every hour.

• Daily to synchronise automatically every day.

2. Press OK to confirm.

Tip: You can also synchronise manually by pressing Synchronise now.

Settings My Doro Manager Sync. intervals:

Account details

Tip: If you misplace or forget your account details such as user name and

you password you can always follow these instructions to retrieve it.

1. Press Menu

Settings My Doro Manager.

English

2. Select Account to view your account information details. Enter the phone code and press OK to confirm. The default phone code is 1234.

3. Press Back to return.

File manager

Manage the contents and properties of files. You can open, delete, move, copy and rename files.

1. Press Menu

2. Select Phone/Memory card

Settings File manager.

Open.

3. Select a folder, eg Photos and press Open.

4. Select a file and press Options:

• Play (audio/video/music), press

to Play or to Stop.

• View (photos/images) for single view.

• Send

and send picture message (MMS), p.23)/Send by Bluetooth to send to a Bluetooth device (Bluetooth

Send by MMS to send as picture message (Create

, p.35)/Send by e-mail

(Create and send e-mail, p.24).

• Details to view detailed information about the file, e.g. date, size, copyright protection.

• Use

Wallpaper to save as display background/Phonebook

picture to send to a phonebook contact.

• Rename to rename the file.

• Delete to delete the file.

• Delete all to delete all files in selected folder.

• Sort by

• Copy/Move

lect a folder, eg Photos and press Options

Name/Time.

Phone/Memory card Options Open. Se-

Paste.

5. Press OK to confirm. Supported formats:

• Picture format: BMP/GIF/JPG/PNG. Photos taken with the built in camera are saved as JPG.

• Audio format: WAV/AMR/MIDI/MP3/AAC/AAC+. Recordings made with the built in sound recorder are saved as AMR.

• Video format: AVI/MP4/3GPP.

English

A B D EC

Internet

IMPORTANT!

This service requires an Internet connection. Using data services can be costly. We recommend that you check your data rates with your service provider.

Use the web browser

1. Press Menu Browser.

2. Press Accept to accept the End User License for using the Opera Mobile browser. If not, press Exit.

Navigate the web browser

• Use the navigation buttons to navigate the browser. The blue frame shows the selected area. Press

Enter website address (URL)

• Select www. and press (URL) and press Go.

to select Edit. Enter a website address

to select.

™

• Press

to select , located to the right of the screen, to search the

web. Enter your search and press Search.

Options menu

• Press Menu to access:

• A to close the current tab, if multiple tabs are used.

• B to go to previous or next website.

• C to access Bookmarks, History, Saved Pages, Downloads, Set-

tings, Find in Page, Homepage and Help.

• D to refresh current website.

• E to exit the web browser. Press Yes to confirm.

English

• + located at the top right corner, to open new tab. Use the navi- gation buttons to switch between tabs.

Add browser speed dials

1. Use the navigation buttons to select + and press Add.

2. Press Edit to enter a web address or use the navigation buttons to scroll the list of visited pages and select Done.

Tip: Select the browser speed dial and press Open to view.

Use the Facebook application

1. Press Menu Internet.

2. Press Facebook. Press OK to accept the data charges, or press

Cancel.

To use this app you must have a Facebook account, you can create one using the link Create New Account on the login screen.

Note! The fields are case sensitive.

1. Once you have an account, select to enter your Email or your Mobile Number and press

2. Select Password and press

3. Select Log in and press

Log out

1. Press Menu and select Settings.

2. Scroll to Log out and press

Language

• Use Press

to scroll down to change the language of the Facebook app.

to select.

to enter your password.

. Confirm with Yes.

The More menu contains:

FM radio

Calculator Status

Games

English

FM radio

The FM radio has a frequency range from 87.5 to 108.0 MHz. To listen to the radio you need to connect a compatible headset that works as antenna.

Turning the radio on

1. Connect a headset to the headset socket

2. Press Menu

FM radio. The radio is turned on. The tuned fre-

quency is displayed.

3. Select channel using

Tip: Press

to return to standby mode. The radio will continue to play.

or .

Volume

1. Press Menu

2. Use

or to adjust the volume.

FM radio Options Volume.

3. Press OK to confirm.

Save frequency

1. Press Menu

FM radio Options Save frequency.

2. Enter a name for the new channel, see Enter text

3. When done, press OK.

Switch off

• Press Menu

FM radio Options Switch off.

Tip: Disconnecting the headset will also turn off the radio.

Loudspeaker

, p.5.

1. Press Menu

FM radio Options Loudspeaker On.

2. Select On.

3. Use

/ to adjust the sound volume.

4. To turn off, select Off.

Channel list (editing the channel list)

1. Press Menu FM radio

Options Channel list.

2. Select the channel you wish to edit and press Options:

• Play to play the selected channel.

English

• Delete to delete the channel. Press Yes to confirm or No to re- turn to the channel list.

• Edit to edit the channel name, then press quency, use

to enter the decimal point. When done, press

to edit the fre-

Save.

3. Press Yes to confirm.

Manual input (change the search mode)

1. Press Menu

• Fine tune to tune manually with

• Auto search to use automatic station search with

FM radio Options Manual input:

or .

2. Press OK to confirm.

Note! This will overwrite all previously saved channels.

Auto save

1. Press Menu

FM radio Options.

2. Select Auto save to automatically install available radio stations in channels1-9.

3. Press OK to confirm.

Note! This will overwrite all previously saved channels.

Torch

1. Press Menu Torch.

2. Select Off to turn off.

Tip: Press and hold shortcut button turn off.

Set automatic switch off time

1. Press Menu

Settings General Torch:

• 1 min to turn off automatically after 1 min.

• 2 min to turn off automatically after 2 min.

• No limit to turn of manually.

2. Press OK to confirm.

to turn on the torch. Release to

Note! The torch will drain the battery very quickly. Remember to turn off the torch after use.

English

Calculator

The Calculator can perform basic mathematical operations.

1. Press Menu

2. Enter the first number. Use#to enter decimal points.

3. Use the arrow buttons to select an operation (+, -, x, ÷) and press OK.

4. Enter the next number and press OK.

5. Repeat steps 2–4 as necessary. Select = and press OK to calculate the result.

Calculator.

Games

The Games menu contains 2 games.

1. Press Menu

• Continue to continue game.

• Restart level to restart game at the same level as before.

• Start game to start a new game.

• Game level to select difficulty level.

• Best grades to view your best results. Press Back to return or

Reset to reset the scores.

• Help to view instructions for the game. Press Back to return.

• Settings

buttons +/- to select On or Off.

• Settings

buttons +/–.

2. Press OK to confirm.

More Games

Sound effect to enable or disable by using the side

Volume to adjust the sound volume using the side

Status

Scroll through the Status list to get further information about the icons shown on top of your display. Icons shown on the display varies depending on your phone status.

1. Press Menu

2. Use

3. Press Back to return to standby mode.

or to scroll the list.

More Status.

Organiser

The Organizer menu contains:

English

Alarm

Calendar

Daily reminder

Notes

Alarm

1. Press Menu Organiser Alarm On.

2. Enter the alarm time using the keypad.

• For a single occurrence, select Single.

• For a repeated alarm, select Repeated. Scroll through the list of

days and press On to enable or Off to disable the alarm for each day.

3. Press Save to confirm.

Snooze or turn off

• When the alarm goes off a signal will sound. Press Stop to turn off the alarm or press Snooze to repeat the alarm after 9 minutes.

Note! The alarm will work even when the phone is switched off. Do not press Yes to power on if wireless phone use is prohibited or when it may cause interference or danger.

Tip: To edit an alarm, press Edit or Off to stop the alarm.

Calendar

Add task

1. Press Menu

2. Enter date, then press

3. Enter time, then press

4. Enter subject, see Enter text

5. When done, press OK.

Options

1. Press Menu

• Select View to show tasks for the selected date.

• Select Jump to date and enter the date.

2. Press OK to confirm.

Organiser Calendar Options Add task.

, p.5.

Organiser Calendar Options:

English

View all

1. Press Menu

2. Select a task and press Options

3. Press Options

4. Press OK to confirm.

Note! The calendar reminders will work even when the phone is powered off. Do not power on your phone if wireless phone use is prohibited or when it may cause interference or danger.

Organiser Calendar.

View all.

Edit, Delete or Delete all.

Daily reminder

1. Press Menu Organiser Daily reminder Add.

2. Enter time, then press

3. Enter subject, see Enter text

4. Press OK to confirm.

Snooze or stop

When the alarm sounds:

• Select Stop to stop.

• Select Snooze to repeat after 9 minutes.

Note! The reminder will work even when the phone is powered off. Do not power on your phone if wireless phone use is prohibited or when it may cause interference or danger.

Tip: For more options select an existing entry, and press Options reminder, Add, Edit, Delete or Delete all.

, p.5

Skip

Notes

1. Press Menu Organiser Notes Add.

2. Enter your note using the keypad, see Enter text

3. Press OK to confirm.

Tip: For more options select an existing entry, and press Options View, Edit, Delete or Delete all.

, p.5.

English

Weather

IMPORTANT!

Using data services can be costly. We recommend that you check your data rates with your service provider.

View the

1. Press Menu

Weather for your chosen city.

Weather.

2. Press Back to return to standby mode.

Note! In order to see the weather, you must first select a city.

Weather settings

1. Press Menu

Settings Weather.

2. Select City and enter the name of the city.

3. Use

or to select the city in the list.

4. Select Wallpaper and select On (to view the weather in standby mode).

5. Press OK to confirm.

For more options select an existing entry, and press Options

Edit or

Delete.

Additional functions

Display status symbols

Signal strength

No network coverage

Ring only

Ring + vibration

Vibration only Battery level

Silent Call divert activated

Roaming (in other network)

Missed call

Headset connected Bluetooth connected

Data transmission

Alarm active

Bluetooth on, visible to others

Bluetooth on, invisible to others

English

Voice mail message received

Unread e-mail

Display main symbols

Mute

Message sending success

Message sending failed

Error Headset out

Warning

Query

Done (confirmed)

New message

Battery level low

Searching

vCard message

Unread text message/SMS

Unread picture message/ MMS

Charger connected

Charger removed

Headset in

Speaker on

Speaker off

Incoming call

Outgoing call

Call ended Missed call. Press Read to

see the missed calls. Call on-hold

Volume control

Processing, please wait

SMS/MMS unread

SMS/MMS unsent

E-mail without and with at-

tachment unread

SOS calls only

Assistance button call

SMS/MMS read

SMS/MMS sent

E-mail without and with at-

tachment read

Reset settings

1. Press Menu Settings Security.

2. Select Reset settings to reset the phone settings. All the changes that you have made to the phone settings will be reset to default settings.

3. Enter the phone code and press OK to reset.

English

Tip: The default phone code is 1234.

Reset all

1. Press Menu

Settings Security.

2. Select Reset all to delete phone settings and content such as contacts, number lists and messages (SIM memory is not affected).

3. Enter the phone code and press OK to reset.

Tip: The default phone code is 1234.

Safety instructions

CAUTION

The unit and the accessories can contain small parts. Keep all of the equipment out of the reach of small children. The mains adapter is the disconnect device between the product and mains power. The mains socket outlet must be close to the equipment and easily accessible.

Network services and costs

Your device is approved for use on the WCDMA 900/2100 MHz, GSM 900/1800/1900 MHz networks. To use the device, you need a subscription with a service provider.

Using network services may result in traffic costs. Some product features require support from the network, and you may need to subscribe to them.

Operating environment

Follow the rules and laws that apply wherever you are, and always turn off the unit whenever its use is prohibited or can cause interference or hazards. Only use the unit in its normal user position.

Parts of the unit are magnetic. The unit can attract metal objects. Do not keep credit cards or other magnetic media near the unit. There is a risk that information stored on them can be erased.

Medical units

The use of equipment that transmits radio signals, for example, mobile phones, can interfere with insufficiently protected medical equipment. Consult a doctor or the manufacturer of the equipment to determine if it has adequate protection against external radio signals, or if you have any questions. If notices have been put up at health care facilities instructing you to turn off the unit while you are there, you should comply. Hospitals and other health care facilities sometimes use equipment that can be sensitive to external radio signals.

English

Implanted medical devices

To avoid potential interference, manufacturers of implanted medical devices recommend a minimum separation of 15 cm between a wireless device and the medical device. Persons who have such devices should:

• Always keep the wireless device more than 15 cm from the medical device.

• Should not carry the phone in a breast pocket.

• Hold the wireless device to the ear opposite the medical device.

If you have any reason to suspect that interference is taking place, turn the phone off immediately If you have any questions about using your wireless device with an implanted medical device, consult your health care provider.

Areas with explosion risk

Always turn off the unit when you are in an area where there is a risk of explosion. Follow all signs and instructions. There is a risk of explosion in places that include areas where you are normally requested to turn off your car engine. In these areas, sparks can cause explosion or fire which can lead to personal injury or even death.

Turn off the unit at filling stations, and any other place that has fuel pumps and auto repair facilities.

Follow the restrictions that apply to the use of radio equipment near places where fuel is stored and sold, chemical factories and places where blasting is in progress.

Areas with risk for explosion are often – but not always – clearly marked. This also applies to below decks on ships; the transport or storage of chemicals; vehicles that use liquid fuel (such as propane or butane); areas where the air contains chemicals or particles, such as grain, dust or metal powder.

Li-ion battery

This product contains a Li-ion battery. There is a risk of fire and burns if the battery pack is handled improperly.

WARNING

Danger of explosion if battery is incorrectly replaced. To reduce risk of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 60° C (140° F), or dispose of in fire or water. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product.

Protect your hearing

This device has been tested to comply with the Sound Pressure Level requirement laid down in the applicable EN 50332-1 and/or EN 50332-2 standards.

English

WARNING

Excessive exposure to loud sounds can cause hearing damage. Exposure to loud sounds while driving may distract your attention and cause an accident. Listen to a headset at a moderate level, and do not hold the device near your ear when the loudspeaker is in use.

Emergency calls

IMPORTANT!

Mobile phones use radio signals, the mobile phone network, the terrestrial network and user-programmed functions. This means that connection cannot be guaranteed in all circumstances. Therefore, never rely only on a mobile phone for very important calls such as medical emergencies.

GPS/Location based functions

Some products provide GPS/Location based functions. Location determining functionality is provided “As is”. No representation or warranty are made as to the accuracy of such location information. Use of location-based information by the device may not be uninterrupted or error free and may additionally be dependent on network service availability. Please note that functionality may be reduced or prevented in certain environments such as building interiors or areas adjacent to buildings.

CAUTION

Do not use GPS functionality in a manner which causes distraction from driving.

Vehicles

Radio signals can affect electronic systems in motor vehicles (for example, electronic fuel injection, ABS brakes, automatic cruise control, air bag systems) that have been incorrectly installed or are inadequately protected. Contact the manufacturer or its representative for more information about your vehicle or any additional equipment.

Do not keep or transport flammable liquids, gases or explosives together with the unit or its accessories. For vehicles equipped with air bags: Remember that air bags fill with air with considerable force.

Do not place objects, including fixed or portable radio equipment in the area above the airbag or the area where it might expand. Serious injuries may be caused if the mobile phone equipment is incorrectly installed and the airbag fills with air.

It is prohibited to use the unit in flight. Turn off the unit before you board a plane. Using wireless telecom units inside a plane can pose risks to air safety and interfere with telecommunications. It may also be illegal.

Protect your personal data

Protect your personal data and prevent leakage or misuse of sensitive information

English

• While using your device, be sure to back up important data.

• When disposing of your device, back up all data and then reset your device to pre-

vent misuse of your personal information.

• Carefully read the permissions screen when downloading applications. Be particularly cautious with applications that have access to many functions or to a significant amount of your personal information.

• Check your accounts regularly for unapproved or suspicious use. If you find any sign of misuse of your personal information, contact your service provider to delete or change your account information.

• In the event your device is lost or stolen, change the passwords on your accounts to protect your personal information.

• Avoid using applications from unknown sources and lock your device with a pattern, password, or PIN.

Malware and viruses

To protect your device from malware and viruses, follow these usage tips. Failure to do so may result in damages or loss of data that may not be covered by the warranty service.

• Do not download unknown applications.

• Do not visit untrusted websites.

• Delete suspicious messages or email from unknown senders.

• Set a password and change it regularly.

• Deactivate wireless features, such as Bluetooth, when not in use.

• If the device behaves abnormally, run an antivirus program to check for infection.

• Run an antivirus program on your device before you launch newly-downloaded ap-

plications and files.

• Do not edit registry settings or modify the device’s operating system.

Care and maintenance

Your unit is a technically advanced product and should be treated with the greatest care. Negligence may void the warranty.

• Protect the unit from moisture. Rain, snow, humidity, and all types of liquids can contain substances that corrode the electronic circuits. If the unit gets wet, you should immediately power off the phone, remove the battery and allow the unit to dry completely before you replace it.

• Do not use or keep the unit in dusty, dirty environments. The unit’s moving parts and electronic components can be damaged.

• Do not keep the unit in warm places. High temperatures can reduce the lifespan for electronic equipment, damage batteries and distort or melt certain plastics.

• Do not keep the unit in cold places. When the unit warms up to normal temperature, condensation can form on the inside and can damage the electronic circuits.

• Do not try to open the unit in any other way than that which is indicated here.

English

• Do not drop or shake the unit. If it is treated roughly the circuits and precision mechanics can be broken.

• Do not use strong chemicals to clean the unit.

• Do not disassemble, open, crush, bend, deform, puncture or shred.

• Do not modify or remanufacture, attempt to insert foreign objects into the battery,

immerse or expose to water or other liquids, expose to fire, explosion or other hazard.

• Only use the battery for the system for which it is specified.

• Only use the battery with a charging system that has been qualified with the system

per IEEE-Std-1725. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

• Do not short circuit a battery or allow metallic conductive objects to contact battery terminals.

• Replace the battery only with another battery that has been qualified with the system per this standard, IEEE-Std-1725. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard.

• Promptly dispose of used batteries in accordance with local regulations.

• Battery usage by children should be supervised.

• Improper battery use may result in a fire, explosion or other hazard.

For devices that utilize a USB port as a charging source, the device's user manual shall include a statement that the device shall only be connected to CTIA certified adapters, products that bear the USB-IF logo or products that have completed the USB-IF compliance program.

The advice applies to the unit, battery, power adapter and other accessories. If the phone is not working as it should, please contact the place of purchase for service. Don’t forget the receipt or a copy of the invoice.

Warranty

This product is guaranteed for a period of 24 months from the date of purchase. In the unlikely event of a fault occurring during this period, please contact the place of purchase. Proof of purchase is required for any service or support needed during the guarantee period.

This guarantee will not apply to a fault caused by an accident or a similar incident or damage, liquid ingress, negligence, abnormal usage, non-maintenance or any other circumstances on the user’s part. Furthermore, this guarantee will not apply to any fault caused by a thunderstorm or any other voltage fluctuations. As a matter of precaution, we recommend disconnecting the charger during a thunderstorm.

Please note that this is a voluntary manufacturer’s warranty and provides rights in addition to, and does not affect statutory rights of end-users.

Batteries are consumables and are not included in any guarantee.

This guarantee does not apply if batteries other than DORO original batteries are used.

English

Specifications

Network: Dimensions

Weight Battery Operating ambient

temperature Charging ambient

temperature Storage temperature

WCDMA 900/2100 MHz, GSM 900/1800/1900 MHz 104 mm x 55 mm x 19 mm

108 g (including battery)

3.7 V / 800 mAh Li-ion battery Min: 0° C (32° F)

Max: 40° C (104° F) Min: 0° C (32° F)

Max: 40° C (104° F) Min:–20° C (–4° F)

Max: 60° C (140° F)

Copyright and other notices

Bluetooth®is a registered trademark of Bluetooth SIG, Inc.

vCard is a trademark of the Internet Mail Consortium.

™

eZiType

Wi-Fi is a trademark or a registered trademark of the Wi-Fi Alliance.

microSD is a trademark of SD Card Association.

Java, J2ME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Doro reserves the right to revise this document or withdraw it at any time without prior notice.

Google, Google Maps™, Gmail, Google Calendar, Google Checkout, Hangouts, YouTube, the YouTube logo, Picasa and Android are trademarks or registered trademarks of Google, Inc.

This product is licensed under the MPEG-4 visual and AVC patent portfolio licenses for the personal and noncommercial use of a consumer for (i) encoding video in compliance with the MPEG-4 visual standard ("MPEG-4 video") or the AVC standard ("AVC video") and/or (ii) decoding MPEG- 4 or AVC video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a video provider licensed by MPEG LA to provide MPEG-4 and/or AVC video. No license is granted or shall be implied for any other use. Additional information including that relating to promotional, internal and commercial uses and licensing may be obtained from MPEG LA, L.L.C. See www.mpegla.com. MPEG Layer-3 audio decoding technology licensed from Fraunhofer IIS and Thomson.

Other product and company names mentioned herein may be the trademarks of their respective owners.

is a trademark of Zi Corporation.

English

Any rights not expressly granted herein are reserved. All other trademarks are property of their respective owners.

To the maximum extent permitted by applicable law, under no circumstances shall Doro or any of its licensors be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

Doro does not provide a warranty for or take any responsibility for the functionality, content, or end-user support of third-party apps provided with your device. By using an app, you acknowledge that the app is provided as is. Doro does not make any representations, provide a warranty, or take any responsibility for the functionality, content, or enduser support of third-party apps provided with your device.

Content copyright

The unauthorised copying of copyrighted materials is contrary to the provisions of the Copyright Laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright, or materials which you are authorised or legally permitted to copy. If you are uncertain about your right to copy any material, please contact your legal advisor.

Open source licenses

You are entitled to receive a copy of the source code of software licensed under an open source license that gives you the right to receive the source code for that software (for example GPL or LGPL) to you on an appropriate media, against an administrative fee covering Doro AB’s cost for handling the distribution and costs for media. Please direct such request to Doro AB, Open Source Software Operations, Magistratsvagen 10, SE 226 43 Lund, Sweden. To be valid, such a request must be made within three (3) years from the date of the distribution of this product by Doro AB, or in the case of code licensed under the GPL v3 for as long as Doro AB offers spare parts or customer support for this product model.

Hearing aid compatibility

Note! For hearing aid compatibility, turn off Bluetooth connectivity.

The standard for hearing aid compatibility contains two types of ratings:

English

above the ear may result in better performance for hearing aids with microphones positioned behind the ear.

• T: To use your hearing aid in this mode, make sure that your hearing aid is set to "T- mode" or telecoil coupling mode (not all hearing aids have this mode). For the best results, try using the phone in different positions relative to your hearing aid—for example, placing the receiver slightly below or in front of the ear may result in better performance.

Your device meets the M4/T4 level rating.

Specific Absorption Rate (SAR)

This device meets applicable international safety requirements for exposure to radio waves. Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) recommended by international guidelines from the independent scientific organization ICNIRP (International Commission of Non-Ionizing Radiation Protection).

The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg averaged over 10 grams of tissue and include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

This device meets RF exposure guidelines when used against the head or when positioned at least 0.5 cm away from the body. When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above stated separation distance from the body.

The World Health Organization (WHO) has stated that current scientific information does not indicate the need for any special precautions when using mobile devices. If you are interested in reducing your exposure, they recommend you reduce your usage or use a hands-free accessory to keep the device away from your head and body.

Correct disposal of this product

(Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems)

This marking on the product, accessories or manual indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. This product is RoHS compliant.

English

Correct disposal of batteries in this product

(Applicable in countries with separate collection systems)

The marking on the battery, manual or packaging indicates that the battery in this product should not be disposed of with other household waste. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.

Declaration of Conformity

Hereby, Doro declares that the radio equipment type DSB-0030 (Doro 6530) is in compliance with Directives: 1999/05/EC or 2014/53/EU and 2011/65/EU. The full text of the EU declaration of conformity is available at the following internet address: www.doro.

com/dofc.

English

DFC-0030 (Doro 6530) (2011,2021,2031,2051)

English

Version 3.0

www.doro.com

REV 17923 — STR 20160622

Doro 6530 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Congratulations on your purchase

Get started

Insert SIM card, memory card and the battery

Charge the phone

Save energy

Get to know your phone

Assistive functions

Turn the phone on and off

Start-up wizard

External display

Phone indicators

How to navigate the phone

Standby (idle mode)

Navigation buttons

Step-by-step instructions

Enter text

Enter text manually

Enter text with predictive text

Input mode

Volume control

Silent

Headset

Hearing aid compatible

Phone settings

Time & date

Language

Block function

PIN code options

Phone lock

Whitelist

Calls

Make a call

Call from the phonebook

Receive a call

Call information

Call options

Options (left selection button)

SPK on (right selection button)

Speed dial

SOS calls

Call log

Call settings

Call time

Answer mode

Caller ID

Call waiting

Call divert

Call barring

Fixed dial (FDN)

Phonebook

Add contact

Manage phonebook contacts

Phonebook settings

Owner number

Phonebook storage

Phonebook picture

Voice mail

Top 10

ICE (In Case of Emergency)

Assistance button

Make an assistance call

Activation

Number list

Activate text messages (SMS)

Position SMS

Activation

Assistance settings

Confirm with "0"

Signal type

Messages

Create and send text message (SMS)

Create and send picture message (MMS)

Create and send voice message

Create and send e-mail

Signing in on Gmail / Yahoo

Inbox, Outbox and Sent
