Version 1.0 | 07/22/2016
User Manual
Wireless N 150 Home Router
DIR-608
Preface
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any
person or organization of such revisions or changes.
Manual Revisions
Revision Date Description
1.0 25 July, 2016 DIR-608 Revision A1
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries.
All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.
Copyright © 2016 by D-Link Corporation, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation,
Inc.
iD-Link DIR-608 User Manual
Table of Contents
Table of Contents
Preface ................................................................................. i
Product Overview .............................................................. 1
Package Contents .........................................................................1
System Requirements ................................................................. 2
Introduction ................................................................................... 3
Features ............................................................................................4
Hardware Overview ..................................................................... 5
LEDs ........................................................................................... 5
Back Panel ...............................................................................6
Choosing an Operation Mode ..........................................7
Router Mode .................................................................................. 8
Wireless Repeater Mode ............................................................9
Installation ....................................................................... 11
Before You Begin .........................................................................11
Wireless Installation Considerations ....................................12
Hardware Setup - Router .........................................................13
Hardware Setup - Wireless Repeater ...................................15
PPTP .........................................................................................30
L2TP .........................................................................................31
IPV6 ..........................................................................................33
Wireless ..........................................................................................47
Wireless Basics .....................................................................48
WPS ..........................................................................................54
Advanced Wireless .............................................................55
Wireless Repeater ...............................................................57
Wireless Repeater Setup ..............................................58
Advanced ......................................................................................60
Access Control List..............................................................61
Port Triggering .....................................................................62
DMZ .........................................................................................64
URL Block ...............................................................................65
Dynamic DNS .......................................................................66
Trac Control .......................................................................67
UPnP ........................................................................................69
Telnet .......................................................................................70
Virtual Server ........................................................................ 71
Getting Started ................................................................ 16
Conguration ................................................................... 17
Web UI Table of Contents ........................................................18
Setup ...............................................................................................19
Wizard .....................................................................................20
Local Network ......................................................................24
Internet Setup ......................................................................27
IPv6 Filter ...............................................................................72
IPv6 Routing .........................................................................74
Maintenance ................................................................................75
Reboot ....................................................................................76
Firmware Upgrade ..............................................................77
Backup/Restore ...................................................................78
Admin .....................................................................................79
iiD-Link DIR-608 User Manual
Table of Contents
Time and Date ......................................................................80
Status ..............................................................................................81
Device Info ............................................................................82
Active Client Table ..............................................................83
Statistics .................................................................................84
IPV6 ..........................................................................................85
IPV6 Routing Table .............................................................86
Help .................................................................................................87
Connect a Wireless Client to Your Router ....................... 88
WPS Button ...................................................................................88
Windows® 10 ................................................................................89
Windows® 8 ...................................................................................91
WPA/WPA2 ............................................................................91
Windows® 7 ...................................................................................93
WPA/WPA2 ............................................................................93
WPS ..........................................................................................95
Wireless Security ......................................................... 113
What is WPA? ................................................................ 113
Technical Specications ................................................114
Safety Statements .........................................................115
Windows Vista® ............................................................................99
WPA/WPA2 .........................................................................100
Troubleshooting ............................................................102
Wireless Basics ...............................................................106
What is Wireless? ...................................................................... 107
Tips ................................................................................................ 109
Wireless Modes .........................................................................110
Networking Basics .........................................................111
Check your IP address ............................................................ 111
Statically Assign an IP address ............................................ 112
iiiD-Link DIR-608 User Manual
Section 1 - Product Overview
DIR-608 Wireless N 150 Home Router
Power Adapter
Ethernet Cable
Product Overview
Package Contents
Quick Install Guide
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a dierent voltage rating than the one included with the DIR-608 will cause damage and void the warranty
for this product.
1D-Link DIR-608 User Manual
Section 1 - Product Overview
Network Requirements
Web-based Conguration
Utility Requirements
System Requirements
• An Ethernet-based Cable or DSL modem
• IEEE 802.11n, 802.11g or 802.11b wireless clients
• 10/100 Ethernet
Computer with the following:
• Windows
• An installed Ethernet adapter
Browser Requirements:
• Internet Explorer 10 or higher
• Firefox 28 or higher
• Safari 6.0 or higher
• Chrome 28 or higher
®
, Macintosh, or Linux-based operating system
Windows® Users: Make sure you have the latest version of Java
installed. Visit www.java.com to download the latest version.
2D-Link DIR-608 User Manual
Section 1 - Product Overview
Introduction
The DIR-608 Wireless N 150 Home Router is an attractive, high-performance router that makes it easy to share your broadband
Internet connection with all your devices. Simply connect it to your broadband modem, then use the web-based setup wizard
to guide you step-by-step through the conguration process. Whether you’re surng the web on your desktop or relaxing on
the couch with your laptop, the DIR-608 keeps you connected wherever you are in your home.
The DIR-608 creates a high-speed home network with wireless speeds of up to 150 Mbps1 for fast le transfers, seamless web
surng, and smooth online gaming. The external antenna increases your wireless coverage so you can avoid dead spots and
get a reliable connection in more places throughout your home. The DIR-608 also has a repeater mode, which allows you to
extend the range of your existing wireless network, letting you reach the farthest corners of your home or small oce.
The DIR-608 has a host of security features, meaning you can access the Internet without fear of your network being
compromised. Wi-Fi Protected Access (WPA) / Wi-Fi Protected Access II (WPA2) encryption secures wireless trac across your
network, preventing unauthorized access and eavesdropping. Meanwhile, the NAT rewall protects your network from attacks
and intrusions via the Internet. No matter whether you are shopping online, doing your banking, or accessing your personal
information, the DIR-608 keeps your data and your network safe.
1
Maximum wireless signal rate derived from IEEE Standard 802.11b, 802.11g, and 802.11n specications. Actual data throughput will vary. Network conditions and environmental
factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will
adversely aect wireless signal range.
3D-Link DIR-608 User Manual
Section 1 - Product Overview
• Faster Wireless Networking - The DIR-608 provides wireless connection of up to 150 Mbps* for other 802.11n
wireless clients. This capability allows users to participate in real-time activities online, such as video and audio
streaming or online gaming.
• Compatible with 802.11b and 802.11g Devices - The DIR-608 is fully compatible with the IEEE 802.11b and
IEEE 802.11g standards, so it can connect with existing 802.11b and IEEE 802.11g adapters.
• Advanced Firewall Features - The web-based user interface displays a number of advanced network
management features including:
• Content Filtering - Easily applied content ltering based on URL.
• Secure Multiple/Concurrent Sessions - The DIR-608 can pass through VPN sessions. It supports
multiple and concurrent Point to Point Tunneling Protocol (PPTP) sessions, so users behind the
DIR-608 can securely access corporate networks.
Features
• User-friendly Setup Wizard - Through its easy-to-use web-based user interface, the DIR-608 lets you control what
information is accessible to those on the wireless network, whether from the Internet or from your company’s
server. Congure your router to your specic settings within minutes.
• IPv6 Ready - Fully compliant with IPv6. The DIR-608 supports a variety of IPv6 connection standards preparing
you for the day when your ISP implements IPv6.
* Maximum wireless signal rate derived from IEEE Standard 802.11b, 802.11g, and 802.11n specications. Actual data throughput will vary. Network conditions and environmental
factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will
adversely aect wireless signal range.
4D-Link DIR-608 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 2 3 4
1 Power LED The Power LED indicates that the devices is powered on with a proper connection to the power supply.
The Wireless LED indicates that the wireless is operating. It blinks during wireless data transmission.
2
3
4
Wireless LED
The Wireless LED blinks during the WPS pairing process.
Internet LED The Internet LED indicates that an Internet link is established. It blinks during data transmission.
LAN Port LEDs (1-2) The LAN Port LEDs indicate an Ethernet device is connected. They blink during data transmission.
5D-Link DIR-608 User Manual
Section 1 - Product Overview
Hardware Overview
Back Panel
1 2 3 4
WPS Press and hold for about one second to start the WPS process to automatically connect a WPS client.
1 Reset & WPS Button
Reset To reset the device to its factory default settings, press and hold the reset button for ve seconds.
2 LAN Ports (1-2) Connects to Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
3 Internet Port Using an Ethernet cable, connect your broadband modem to this port.
4 Power Connector Connector for the supplied power adapter.
6D-Link DIR-608 User Manual
Section 1 - Product Overview
Choosing an Operation Mode
The DIR-608 features two modes of operation, giving you more exibility in how to congure your network. You may select
either Router Mode or Repeater Mode.
• Router Mode shares your Internet connection. This is the factory default setting suitable for most users.
• Repeater Mode extends your existing wireless network.
The following pages contain information about the DIR-608's operation modes to help you determine how you wish to use it
before you begin the installation process. This information includes usage scenarios, cable diagrams, and network conguration
information.
7D-Link DIR-608 User Manual
Section 1 - Product Overview
Router Mode
In Router Mode, the DIR-608 Wireless N 150 Home Router operates as the central device of your network. This is the most
common type of installation and is the factory default setting suitable for most users. The DIR-608 connects to your cable
modem, DSL modem, or other Internet source and shares your Internet connection with your wired and wireless devices.
Create a Home Network (Router Mode)
Internet DIR-608
Connection Device
(e.g. DSL/Cable Modem)
Use this mode for:
• Setting up a network for the rst time.
• Replacing an existing router or network equipment.
• Adding a router to share a broadband connection which was previously connected to a single computer.
Place your DIR-608 near your broadband Internet connection device (e.g. DSL/Cable Modem) and connect to it via Ethernet
cable.
To use your DIR-608 as a Router, refer to Hardware Setup - Router on page 13.
Wired and Wireless DevicesBroadband
8D-Link DIR-608 User Manual
Section 1 - Product Overview
Wireless Repeater Mode
What is a Wireless Repeater?
In Repeater Mode, the DIR-608 works with your existing networking equipment to provide Wi-Fi for parts of your home or
oce that may have poor or no reception. It works as a wireless repeater by connecting to your existing wireless network and
rebroadcasting its signals for your devices to connect to. Using the DIR-608 as a wireless repeater will reduce the total amount
of wireless bandwidth available.
Place the DIR-608 in an area where you wish to get Wi-Fi, but is reachable by your existing wireless signal.
Existing Wi-Fi Range Wi-Fi Range with DIR-608
9D-Link DIR-608 User Manual
Section 1 - Product Overview
Wireless Repeater
The DIR-608 operates as a Wireless Repeater when it is connected wirelessly to an uplink network.
Internet DIR-608
Connection Device
(e.g. DSL/Cable Modem)
Use this mode for:
• Extending your current network.
• Bringing Wi-Fi to an area it doesn't currently reach.
• Providing better signal for parts of your home or oce that may have poor reception.
• Connecting wired Ethernet devices which do not have a built-in wireless, such as smart TVs, game consoles, or DVRs.
• Networking areas where cables are impractical.
Note: Extending by Wi-Fi reduces the total available amount of wireless bandwidth available.
Use the DIR-608's Wireless Extender Mode's built-in web UI Setup Wizard to connect to an uplink network.
To use your DIR-608 as a Wireless Repeater, refer to Hardware Setup - Wireless Repeater on page 15.
Existing
Network
Wired and Wireless DevicesBroadband
10D-Link DIR-608 User Manual
Section 2 - Installation
Installation
This section will walk you through the installation process. Placement of the router is very important. Do not place the router
in an enclosed area such as a closet, cabinet, or in the attic or garage.
Before You Begin
• Congure the router with the computer that was last connected directly to your Internet connection. Verify that
it is connected to the Internet before connecting additional devices.
• If your ISP provided you with a modem/router combo, you will need to set it to “bridge” mode so the router can
work properly. Please contact your ISP or refer to the user manual for your modem/router device.
• You can only use the Ethernet port on your modem. If you were using the USB connection before using the router,
then you must turn o your modem, disconnect the USB cable and connect an Ethernet cable to the Internet
port on the router, and then turn the modem back on. In some cases, you may need to call your Internet Service
Provider (ISP) to change connection types (USB to Ethernet).
• If connecting to a DSL modem, make sure to have your DSL service information provided by your ISP handy. This
information is likely to include your DSL account's username and password. Your ISP may also supply you with
additional WAN conguration settings which might be necessary to establish a connection.
• If you are connecting a considerable amount of networking equipment, it may be a good idea to take the time
to label each cable or take a picture of your existing setup before making any changes.
• If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as
WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet.
• If you are using this device as a wireless repeater, you may need to use trial and error to determine an acceptable
placement location.
11D-Link DIR-608 User Manual
Section 2 - Installation
Wireless Installation Considerations
The D-Link wireless router lets you access your network using a wireless connection from virtually anywhere within the
operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings,
or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types
of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to
follow these basic guidelines:
1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum -
each wall or ceiling can reduce your adapter’s range from 3 to 90 feet (1 to 30 meters). Position your devices
so that the number of walls or ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 1.5 feet (0.5 meters) thick, at a
45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters)
thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for
better reception.
3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on
range. Try to position access points, wireless routers, and computers so that the signal passes through drywall
or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks),
mirrors, le cabinets, brick, and concrete will degrade your wireless signal.
4. Keep your product away (at least 3 to 6 feet or 1 to 2 meters) from electrical devices or appliances that generate
RF noise.
5. If you are using 2.4 GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home
security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4
GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the
phone in not in use.
6. Using the device as a wireless repeater will reduce the total amount of wireless bandwidth available.
12D-Link DIR-608 User Manual
Section 2 - Installation
Hardware Setup - Router
1. Position your DIR-608 near your Internet-connected modem and PC. Keep the router in an open area for better wireless
coverage.
Modem
DIR-608
2. Turn o and unplug the power and Ethernet cable to your cable or DSL broadband modem. This is required. In some
cases, you may need to turn it o for up to ve minutes.
Modem
DIR-608
3. Use the included Ethernet cable to connect your modem to the yellow port labeled INTERNET on the router.
Modem
DIR-608
13D-Link DIR-608 User Manual
Section 2 - Installation
4. Turn on or plug your modem back in and wait approximately one minute before proceeding.
Modem
DIR-608
5. Connect the supplied power adapter to the router and a power outlet, verify the power LED is on and wait approximately
one minute before proceeding.
Modem
DIR-608
6. If you are conguring the DIR-608 from a PC with a wired Ethernet connection, plug one end of an Ethernet cable
into the port labeled 1 on the back of the router, and the other end into the Ethernet port on your computer.
If you are conguring the DIR-608 wirelessly from a PC, connect to the Wi-Fi network printed on the label attached
to the bottom your router.
Modem
DIR-608
7. If you are connecting to a broadband service that uses a dynamic connection (not PPPoE), you may be online already.
Try opening a web browser and connecting to a website. If the website does not load, proceed to Getting Started on
page 16.
14D-Link DIR-608 User Manual
Section 2 - Installation
Hardware Setup - Wireless Repeater
1. Position your DIR-608 near where you wish to extend Wi-Fi to. Place it in an open area for better wireless coverage,
but is still within range of your existing wireless network. We recommend using a smartphone or tablet to help gauge
wireless strength. Connect the supplied power adapter to the DIR-608 and a power outlet.
DIR-608
2. If you are conguring the DIR-608 from a PC with a wired Ethernet connection, plug one end of an Ethernet cable
into the port labeled 1 on the back of the router, and the other end into the Ethernet port on your computer.
If you are conguring the DIR-608 wirelessly from a PC, connect to the Wi-Fi network printed on the label attached
to the bottom your router.
DIR-608
3. Proceed to Getting Started on page 16 and then follow the instructions Wireless Repeater Setup on page 58
to complete the installation of your DIR-608 as a wireless repeater.
15D-Link DIR-608 User Manual
Section 3 - Conguration
Getting Started
To access the conguration utility, open a web browser such as Internet Explorer and enter http://192.168.11.1 in the address eld. The rst time
you log in, you will be shown this page.
Congure your WAN and Wireless network. Click the Save and Connect button when you are nished.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
Network Map
LAN IP 192.168.11.1 Internet IP 0.0.0.0 DHCP
WAN Setup
▼
Save and Connect
(8-63 characters or 64 hex digits)
Advanced Network
Settings
Wireless Setup
Connect type:
SSID:
Key:
DHCP
D-Link_DIR-608
Select Language
InternetRouterClient
English
▼
Note: It is recommended to write down the SSID and security key.
16D-Link DIR-608 User Manual
Section 3 - Conguration
Conguration
This section will show you how to congure or change the default settings your D-Link
DIR-608 using the web-based conguration utility.
To access the conguration utility, open a web browser such as Internet Explorer and enter
http://192.168.11.1 in the address eld. Enter Admin as the username and leave the
password blank. Click Login.
After logging in you should see the following Device Info section of the web-based interface.
Proceed to the next page.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
DIR-608
Device Info
Active Client Table
IPV6
IPV6 Routing Table
Setup Wireless Advanced Maintenance Status Help
Wireless Router Status
This page shows the current status and some basic settings of the device.
System
Login
Username:
Password:
Admin
Login
Select Language
English
▼
LAN Conguration
Product Name DIR-608
Uptime 1 06:35:16
Date/Time Tue Jul 5 16:09 2016
IP Address 192.168.11.1
17D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Web UI Table of Contents
The web-based interface is divided into six horizontal tabs, each with a vertical menu bar running along the left side.
You may click on these menus to quickly navigate to a section of this document.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
DIR-608
Setup Wireless Advanced Maintenance Status Help
Wizard
Local Network
Internet Setup
PPTP
L2TP
IPV6
Wireless Basics
WPS
Advanced Wireless
Wireless Repeater
Access Control List
Port Triggering
DMZ
URL Block
Dynamic DNS
Trafc Control
UPnP
Telnet
Virtual Server
IPv6 Filter
IPv6 Routing
Reboot
Firmware Upgrade
Backup/Restore
Admin
Time and Date
Select Language
Device Info
Active Client Table
IPV6
IPV6 Routing Table
English
Menu
Wireless
Advanced
Maintenance
Status
▼
To return to this Web UI Table of Contents page, simply click the D-Link logo on the top
right of each page.
DIR-608
Wizard
Setup
18D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Setup
The Setup tab provides access to congure the basic conguration settings of your DIR-608.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
DIR-608
Wizard
Local Network
Internet Setup
PPTP
L2TP
IPV6
Select Language
Setup Wireless Advanced Maintenance Status Help
English
▼
To return to the Web UI Table of Contents page, simply click the D-Link logo on the top right
of each page.
DIR-608
Wizard
Setup
19D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Wizard
Click Wizard on the navigation menu to set up or repair your Internet connection.
Click Next to begin the Easy Setup Wizard.
Easy Setup
This section allows you to congure the IP address of the router.
Next: Starts the Easy Setup Wizard.
Internet Setup: Redirects you to the Internet Setup page. Refer to Internet Setup
on page 27 for more information.
Easy Setup - WAN Connection Type
Select the connection type your ISP uses: PPPoE, Dynamic IP, or Static IP.
Next: Proceed to the next step.
Back: Go back to the last step.
DIR-608
Wizard
Easy Setup
The easy setup will tell you how to congure the basic
network parameters. To continue, please click the “Next”
button.
Easy Setup - WAN Connection Type
The Easy Setup supports three popular types of connection.
To make sure the connection type your ISP provides, please
refer to the ISP.
PPPoE - Usually for ADSL Modem and you will need a
PPPoE username and password from your ISP.
Dynamic IP - Usually for Cable Modem and the router will
automatically obtain an IP address from the DHCP server.
Static IP - This type of connection uses a permanent, xed
(static) IP address that your ISP assigned.
Setup
Manual Next
Back Next
20D-Link DIR-608 User Manual
Section 3 - Conguration
Wizard (continued)
If you choose PPPoE, please congure the following elds and click Next.
Easy Setup - PPPoE
Enter the account username and password provided by your ISP.
User Name: Enter your username.
Password: Enter your password.
Confirm Password: Enter your password again.
Account Validate: Test that your PPPoE username and password are correct.
Next: Proceed to the next step.
Back: Go back to the last step.
If you choose Static IP, please congure the following elds and click Next.
Easy Setup - Static IP
Enter the account username and password provided by your ISP.
Easy Setup - PPPoE
Enter the account username and password provided by your
ISP.
User Name:
Password:
Conrm Password:
Account Validate
Back Next
Easy Setup - Static IP
Enter the IP parameters provided by your ISP.
IP Address: Enter the IP address provided by your ISP.
Subnet Mask: Enter the subnet mask.
Default Gateway: Enter the default gateway.
Primary DNS: Enter the primary DNS address.
Secondary DNS: Enter the secondary DNS address.
IP Address:
Subnet Mask:
Default Gateway:
Primary DNS:
Secondary DNS:
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0 (Optional)
Back Next
21D-Link DIR-608 User Manual
Section 3 - Conguration
Congure the Wireless settings and click Next.
Wizard (continued)
Wireless Network
Disable the
wireless radio.
Name (SSID): Enter the SSID name of the router.
Channel: Use the dropdown menu to select the wireless channel. Auto is the
Mode: Use the dropdown menu to specify the wireless mode.
Channel Width: Use the dropdown menu to select the channel bandwidth.If you
Disable Security: Disabling encryption and leaving your wireless network open is
Enable SSID broadcast if you want the router to transmit its SSID
publicly so other wireless devices can discover it. Note: Disabling
SSID broadcast is not a form of security alone.
default recommended setting.
selected the 802.11n, 802.11 b/g, or 802.11 b/g/n wireless modes, the
available options are 20 MHz and 20/40 MHz. For the other modes,
20 MHz is the only option.
not recommended. Any wireless client will be able to access your
network, be able to use your Internet connection, and leaves you
open to security threats.
Easy Setup - Wireless
You can congure the wireless parameters and security
settings of router on this step.
Disable the wireless radio.
SSID: D-Link_DIR-608
Channel:
Mode: 2.4 GHz (B+G+N)
Channel Width: Auto 20/40 MHz
Wireless Security
It is recommended strongly that you choose one of following
options to enable security, and select WPA-PSK/WPA2-PSK
AES encryption.
Disable Security
WPA-PSK/WPA-PSK AES
Key:
☐
Auto
(8-63 characters or 64 hex digits)
▼
▼
▼
Back Next
WPA-PSK/WPA-
PSK AES:
Key: Enter a wireless key to use on your wireless network.
Next: Proceed to the next step.
Back: Go back to the last step.
Using WPA-PSK encryption is highly recommended to protect your
wireless network trac.
22D-Link DIR-608 User Manual
Section 3 - Conguration
Wizard (continued)
Easy Setup
Click the Finish button to nish the Easy Setup Wizard. When the router has nished saving,
the Status > Device Info window will open.
Easy Setup
Click the ‘Finish’ button to nish the Easy Setup.
Tips: Please click “Setup” on the Menu, and then click
“Internet Setup” for detail settings if the router still can not
access the Internet.
Back Finish
23D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Local Network
Click Local Network on the navigation menu to change the local network settings of the
router, congure the DHCP settings, add a new DHCP reservations, and view the currenly
assigned DHCP reservations. When you have nished conguring the Local Network, click
the Apply Changes button.
DIR-608
Local Network
Setup
LAN Interface Setup
LAN Interface Setup
This section allows you to congure the IP address of the router.
IP Address: Enter the IP address of the router. The default IP address is 192.168.11.1.
If you change the IP address, once you click Apply Changes, you will
need to enter the new IP address in your browser to get back into
the conguration utility.
Subnet Mask: Enter the subnet mask. The default subnet mask is 255.255.255.0.
LAN Interface Setup
IP Address:
Subnet Mask:
192.168.11.1
255.255.255.0
Apply Changes
24D-Link DIR-608 User Manual
Section 3 - Conguration
Local Network (continued)
DHCP Server Settings
This section allows you to congure the local network and DHCP settings of your device. The
DHCP service supplies IP settings to clients congured to automatically obtain IP settings
that are connected to the device through the Ethernet port.
DHCP Mode: Choose the DHCP Server option in the pulldown menu to enable the
DHCP server on your router. Choose None to disable this function.
IP Pool Range: Enter the starting and ending IP addresses for the DHCP server’s IP
assignment.
Note: If you statically (manually) assign IP addresses to your computers
or devices, make sure the IP addresses are outside of this range or you
may have an IP conict.
Max Lease Time: The maximum length of time for the IP address lease. Enter the Lease
time in minutes.
Domain Name: Enter the domain name.
DNS Server 1: Enter the IP address of the rst DNS Server.
DHCP Server Settings
DHCP Mode:
IP Pool Range: 192.168.11.2 - 192.168.11.254
Max Lease Time:
Domain Name:
DNS Server 1:
DNS Server 2:
DNS Server 3:
Apply Changes Undo
DHCP Server
120 minutes
domain.name
192.168.11.1
▼
DNS Server 2: Enter the IP address of the second DNS Server, if there is one.
DNS Server 3: Enter the IP address of the second DNS Server, if there is one.
25D-Link DIR-608 User Manual
Section 3 - Conguration
Local Network (continued)
DHCP Static IP Configuration
If you want a computer or device to always have the same IP address assigned, you can create
a DHCP reservation. The router will assign the IP address only to that computer or device.
IP Address: Enter the IP address you want to assign to the computer or device.
This IP Address must be outside the DHCP IP Address Range.
MAC Address: Enter the MAC address of the computer or device.
When you have nished conguring the new DHCP Reservation, click the Add button to
activate your reservation. It will then be displayed in the DHCP Static IP Table below.
DHCP Static IP Table
The DHCP Static IP Table displays the IP reservations that have been created. To make
any changes, select a reservation in the table by clicking the circle next to it and click
Update. To delete a reservation, select a reservation and click Delete Selected.
DHCP Static IP Conguration
IP Address:
Mac address:
Delete Selected Add Update Reset
DHCP Static IP Conguration
Select IP Address MAC Address
192.168.11.14 00:00:40:30:05:70
0.0.0.0
000000000000
When you have nished conguring the Local Network, click the Apply Changes button.
26D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Internet Setup
Click Internet Setup on the navigation menu to congure your Internet connection
manually. This section is only recommended for advanced users. It is recommended to use
the Setup Wizard to set up your Internet connection.
DIR-608
Setup
WAN Interface
WAN Access Type: Select the Internet Connection protocol from the dropdown menu
your ISP uses. The options are DHCP, Static IP, PPPoE, and DS-Lite.
If you choose DHCP Client, please congure the following elds:
Host Name: Enter the host name of the router.
MTU Size: Enter the MTU size.
Attain DNS
Automatically:
Set DNS Manually: Select this option and manually input your DNS server information.
If you choose Static IP, please congure the following elds:
IP Address: Enter the IP address provided by your ISP.
Select this option to obtain a DNS server information automatically.
Internet Setup
WAN Interface
WAN Access Type:
Attain DNS Automatically:
Set DNS Manually:
DNS Server 1: 0.0.0.0
DNS Server 2:
WAN Interface
WAN Access Type:
WAN Interface Setup
Host Name: hostname
MTU Size:
IP Address: 0.0.0.0
DHCP Client
1500
0.0.0.0
Static IP
▼
▼
Subnet Mask: Enter the subnet mask.
Default Gateway: Enter the default gateway.
MTU Size: Enter the MTU size.
DNS Server 1, 2: Enter the DNS Server IP addresses.
Subnet Mask:
Default Gateway:
MTU Size:
DNS Server 1:
DNS Server 2:
0.0.0.0
0.0.0.0
1500
0.0.0.0
0.0.0.0 (Optional)
27D-Link DIR-608 User Manual
Section 3 - Conguration
Internet Setup (continued)
If you choose PPPoE, please congure the following elds:
User Name: Enter the username provided by your ISP.
Password: Enter the password provided by your ISP.
Service Name: Enter the ISP service name (optional).
Idle Time: Set the connection time out length. (Connect on Demand only)
MTU Size: Enter the maximum transmission unit (MTU) size.
Static IP Address: Enter the IP address of the router provided by your ISP.
Connection Type: Select either Continuous, Connect on Demand, or Manual.
Attain DNS
Select this option to obtain DNS server information automatically.
Automatically:
Set DNS Manually: Select this option to manually input your DNS server information.
WAN Interface
WAN Access Type:
User Name:
Password:
Service:
MTU:
Static IP Address:
Connection Type: Continuous
Attain DNS Automatically:
Set DNS Manually:
DNS Server 1: 0.0.0.0
DNS Server 2:
PPPoE
1452
0.0.0.0
▼
▼
If you choose DS-Lite, please congure the following elds:
DS-Lite Mode: Select either DS-Lite DHCPv6 or Manual.
If you choose Manual, please congure the AFTR Name or Address eld.
AFTR Name or
Enter the AFTR Name or Address.
Address:
WAN Interface
WAN Access Type:
DS-Lite Mode:
AFTR Name or Address:
DS-Lite
DS-Lite DHCPv6 Manual
▼
28D-Link DIR-608 User Manual
Section 3 - Conguration
Internet Setup (continued)
WAN Port Rate
Select the connection speed of the Internet WAN Ethernet port. It is recommended to leave
this on the 10/100 Mbps setting to ensure the fastest connection speeds.
MAC Clone
Select the router’s default MAC address, the PC’s, or enter it manually.
When you have nished conguring your Internet connection, click the Apply Changes
button.
WAN Port Rate
WAN port rate
MAC Clone
10/100 Mbps
Default MAC
MAC from PC
MAC manual
Apply Changes Reset
00:00:00:00:00:00
▼
29D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
PPTP
Click PPTP on the navigation menu to congure PPTP (Point-to-Point-Tunneling Protocol)
connection. Your ISP will provide you with a server address, username, and password.
PPTP Settings
Enable: Check this box to enable PPTP.
Server: Enter the PPTP server IP address provided by your ISP.
Auth: Select PAP, CHAP, CHAPMSV2, or auto. The default is auto.
Username: Enter the username provided by your ISP.
Password: Enter the password provided by your ISP.
Default GW: Check this box to use the Default Gateway provided by your ISP.
When you have nished conguring your PPTP Connection, click the Apply button.
PPTP Table
DIR-608
PPTP
PPTP Settings
PPTP Table
PPTP
Enable:
Server:
Auth: auto
Username:
Password:
Default GW:
Apply Reset
Setup
☑
▼
☐
The PPTP Table displays the currently congured PPTP connections. The Interface, State,
Address, and Gateway are displayed.
Interface State Address Gateway
30D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
L2TP
Click L2TP on the navigation menu to congure L2TP (Layer 2 Tunneling Protocol) connection.
Your ISP will provide you with a server address, username, and password.
L2TP Settings
Session: Check the radio button to enable L2TP.
Name: Enter a name for your L2TP connection.
LNS IP: Enter the L2TP Server address.
LNS Port: Enter the L2TP Server port number.
Auth: Select PAP, CHAP, CHAPMSV2, or auto. The default is auto.
User Name: Enter the username provided by your ISP.
Password: Enter the password provided by your ISP.
Connection Type: Select either Continuous, Connect on Demand, or Manual.
Idle Time(min): If Connect on Demand is selected, enter a maximum idle time during
which the Internet connection is maintained during inactivity.
DIR-608
L2TP
L2TP Settings
Connection Type: Continuous
Setup
L2TP
Session:
Name:
LNS IP:
LNS PORT: 1701
Authentication:
User Name:
Password:
Idle Time(min): 0
NAPT:
Default Route:
Disable Enable
auto
Disable Enable
Disable Enable
▼
▼
NAPT: Check the radio button to enable NAPT.
Default Route: Check the radio button to enable Default Route.
MTU: Enter the MTU size.
When you have nished conguring your L2TP Connection, click the Apply Changes button.
MTU:
Apply Changes Reset
1460
31D-Link DIR-608 User Manual
Section 3 - Conguration
L2TP (continued)
L2TP Table
The L2TP Table displays the currently congured PPTP connections. The Name, Interface, IP
Address, Gateway, and Status are displayed.
L2TP Table
Name Interface IP Address Gateway State
32D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Click IPV6 on the navigation menu to congure your IPv6 settings.
IPV6
IPv6 Connection Type
My IPv6
Connection is:
For Static IPv6 refer to page 34.
For SLAAC/DHCPv6 refer to page 36.
For PPPoE refer to page 38.
For IPv6 in IPv4 Tunnel refer to page 40.
For 6 to 4 refer to page 42.
For 6rd refer to page 44.
Choose your IPv6 connection type from the drop-down menu. You will
be presented with the appropriate options for your connection type.
DIR-608
IPV6
IPv6 Connection Type:
Choose the mode to be used by the router to the IPv6
Internet.
My IPv6 Connection is:
Setup
IPV6
▼
For Link-local only refer to page 46.
When you have nished conguring your IPv6 connection, click the Apply Changes button.
Apply Changes Reset
33D-Link DIR-608 User Manual
Section 3 - Conguration
Static IP
IPv6 Connection Type
My IPv6
Connection is:
Select Static IP if your IPv6 information is provided by your ISP.
WAN IPv6 Address Settings
IPv6 Address: Enter the address supplied by your ISP.
Subnet Prefix
Enter the subnet prex length supplied by your ISP.
Length:
Default Gateway: Enter the default gateway for your IPv6 connection.
IPv6 DNS Settings
Primary DNS
Address:
Secondary DNS
Address:
Enter the primary DNS server address.
Enter the secondary DNS server address.
IPv6 Connection Type:
Choose the mode to be used by the router to the IPv6
Internet.
My IPv6 Connection is:
WAN IPv6 Address Settings
Enter the IPv6 address information provided by your
Internet Service Provider (ISP).
IPv6 Address:
Subnet Prex Length: 64
Default Gateway:
IPv6 DNS Settings
Obtain DNS server address automatically or enter a
specic DNS server address.
Primary DNS Address:
Secondary DNS Address:
Static IP
▼
LAN IPv6 Address Settings
LAN IPv6 Address: Enter the LAN (local) IPv6 address for the router.
LAN IPv6 Link-
Local Address:
Displays the router’s LAN link-local address.
LAN IPv6 Address Settings
Use this section to congure the internal network settings of
your router. If you change the LAN IPv6 Address here, you
may need to adjust your PC’s network settings to access the
network again.
LAN IPv6 Address:
LAN IPv6 Link-Local
Address:
xx00:yy11:zz22:123/64
/64
34D-Link DIR-608 User Manual
Section 3 - Conguration
Static IP (continued)
Address Autoconfiguration Settings
Enable
Autoconfiguation:
LAN IPv6 Address: Select SLAAC+Stateless DHCP or Stateful DHCPv6.
If you choose SLAAC+Stateless DHCP, please congure the following eld:
Router
Advertisement
Lifetime:
If you choose Stateful DHCPv6, please congure the following eld:
IPv6 Address
Range(Start):
IPv6 Address
Range(End):
Router
Advertisement
Lifetime:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enter the IPv6 address lifetime (in minutes).
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in seconds).
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address: SLAAC+Stateless DHCP
Router Advertisement
Lifetime:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address: Stateful(DHCPv6)
IPv6 Address Range(Start): xxxx ::00 3
IPv6 Address Range(End):
Router Advertisement
Lifetime:
☑
30 (minutes)
☑
xxxx ::00 16
(second)
▼
▼
35D-Link DIR-608 User Manual
Section 3 - Conguration
SLAAC/DHCPv6
IPv6 Connection Type
My IPv6
Connection is:
Select SLAAC/DHCPv6 if your ISP assigns your IPv6 address when
your router requests one from the ISP’s server. Some ISPs require you
to adjust settings on your side before your router can connect to the
IPv6 Internet.
IPv6 DNS Settings
Select either Obtain DNS server address automatically or Use the following DNS address.
If you choose Use the following DNS address, please congure the following eld:
Primary DNS
Enter the primary DNS server address.
Address:
Secondary DNS
Enter the secondary DNS server address.
Address:
LAN IPv6 Address Settings
Enable DHCP-PD: Check this box to enable DHCP-PD.
LAN IPv6 Address: If you disabled DHCP-PD, enter the LAN (local) IPv6 address for the
router.
IPv6 Connection Type:
Choose the mode to be used by the router to the IPv6
Internet.
My IPv6 Connection is: SLACC/DHCPv6
IPv6 DNS Settings
Obtain DNS server address automatically or enter a
specic DNS server address.
Obtain DNS server address
Use the following DNS
Primary DNS Address:
Secondary DNS Address:
LAN IPv6 Address Settings
Use this section to congure the internal network settings of
your router. If you change the LAN IPv6 Address here, you
may need to adjust your PC’s network settings to access the
network again.
automatically
address
Enable DHCP-PD:
☑
▼
LAN IPv6 Link-
Local Address:
Displays the router’s LAN link-local address.
LAN IPv6 Address:
LAN IPv6 Link-Local
Address:
/64
xx00:yy11:zz22:123/64
36D-Link DIR-608 User Manual
Section 3 - Conguration
SLAAC/DHCPv6 (continued)
Address Autoconfiguration Settings
Enable
Autoconfiguation:
LAN IPv6 Address: Select SLAAC+Stateless DHCP or Stateful DHCPv6.
If you choose SLAAC+Stateless DHCP, please congure the following eld:
Router
Advertisement
Lifetime:
If you choose Stateful DHCPv6, please congure the following eld:
IPv6 Address
Range(Start):
IPv6 Address
Range(End):
Router
Advertisement
Lifetime:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enter the IPv6 address lifetime (in minutes).
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in seconds).
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address: SLAAC+Stateless DHCP
Router Advertisement
Lifetime:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address: Stateful(DHCPv6)
IPv6 Address Range(Start): xxxx ::00 3
IPv6 Address Range(End):
Router Advertisement
Lifetime:
☑
30 (minutes)
☑
xxxx ::00 16
(second)
▼
▼
37D-Link DIR-608 User Manual
Section 3 - Conguration
PPPoE
IPv6 Connection Type
My IPv6
Connection is:
Select PPPoE if your ISP provides and requires you to enter a PPPoE
username and password in order to connect to the Internet.
PPPoE:
User Name: Enter the username provided by your ISP.
Password: Enter the password provided by your ISP.
Service Name: Enter the ISP service name (optional).
Idle Time: Set the connection time out length. (Connect on Demand only)
MTU Size: Enter the MTU size.
Connection Type: Select either Continuous, Connect on Demand, or Manual.
IPv6 Connection Type:
Choose the mode to be used by the router to the IPv6
Internet.
My IPv6 Connection is:
PPPoE
Enter the information provided by your Internet Service
Provider (ISP).
User Name:
Password:
Service Name:
Idle Time: 5
MTU Size:
Connection Type:
PPPoE
(1-1000
minutes)
1452
Connect on Demand
connect
disconnect
▼
▼
IPv6 DNS Settings
Select either Obtain DNS server address automatically or Use the following DNS address.
If you choose Use the following DNS address, please congure the following eld:
Primary DNS
Address:
Secondary DNS
Address:
Enter the primary DNS server address.
Enter the secondary DNS server address.
IPv6 DNS Settings
Obtain DNS server address automatically or enter a
specic DNS server address.
Obtain DNS server address
automatically
Use the following DNS
address
Primary DNS Address:
Secondary DNS Address:
38D-Link DIR-608 User Manual
Section 3 - Conguration
PPPoE (continued)
LAN IPv6 Address Settings
Enable DHCP-PD: Check this box to enable DHCP-PD.
LAN IPv6 Address: If you disabled DHCP-PD, enter the LAN (local) IPv6 address for the
router.
LAN IPv6 Link-
Displays the router’s LAN link-local address.
Local Address:
Address Autoconfiguration Settings
Enable
Autoconfiguation:
LAN IPv6 Address: Select SLAAC+Stateless DHCP or Stateful DHCPv6.
If you choose SLAAC+Stateless DHCP, please congure the following eld:
Router
Advertisement
Lifetime:
If you choose Stateful DHCPv6, please congure the following eld:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enter the IPv6 address lifetime (in minutes).
LAN IPv6 Address Settings
Use this section to congure the internal network settings of
your router. If you change the LAN IPv6 Address here, you
may need to adjust your PC’s network settings to access the
network again.
Enable DHCP-PD:
LAN IPv6 Address:
LAN IPv6 Link-Local
Address:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address: SLAAC+Stateless DHCP
Router Advertisement
Lifetime:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
☑
/64
xx00:yy11:zz22:123/64
☑
30 (minutes)
☑
▼
IPv6 Address
Range(Start):
IPv6 Address
Range(End):
Router
Advertisement
Lifetime:
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in seconds).
LAN IPv6 Address: Stateful(DHCPv6)
IPv6 Address Range(Start): xxxx ::00 3
IPv6 Address Range(End):
Router Advertisement
Lifetime:
xxxx ::00 16
▼
(second)
39D-Link DIR-608 User Manual
Section 3 - Conguration
IPv6 In IPv4 Tunnel
My IPv6
Connection is:
Remote IPv4
Address:
Remote IPv6
Address:
Local IPv4
Address:
Local IPv6 Address
and Subnet Prefix
Length:
IPv6 Connection Type
Select IPv6 In IPv4 Tunnel if you wish to configure the IPv6
connection to run in IPv4 Tunnel mode. IPv6 over IPv4 tunnelling
encapsulates IPv6 packets in IPv4 packets so that IPv6 packets can
be sent over an IPv4 infrastructure.
IPv6 in IPv4 Tunnel Settings
Enter the IPv4 remote address you will use.
Enter the IPv6 remote address you will use.
Displays the current local IPv4 address.
Enter the IPv6 local address and subnet prex length.
IPv6 Connection Type:
Choose the mode to be used by the router to the IPv6
Internet.
My IPv6 Connection is:
IPv6 in IPv4 Tunnel Settings
Enter the IPv6 in IPv4 Tunnel information provided by
your Tunnel Broker.
Remote IPv4 Address:
Remote IPv6 Address:
Local IPv4 Address: 192.168.x.x
Local IPv6 Address:
IPv6 In IPv4 Tunnel
/
▼
IPv6 DNS Settings
Select either Obtain DNS server address automatically or Use the following DNS address.
If you choose Use the following DNS address, please congure the following eld:
Primary DNS
Address:
Secondary DNS
Address:
Enter the primary DNS server address.
Enter the secondary DNS server address.
IPv6 DNS Settings
Obtain DNS server address automatically or enter a
specic DNS server address.
Primary DNS Address:
Secondary DNS Address:
40D-Link DIR-608 User Manual
Section 3 - Conguration
IPv6 In IPv4 Tunnel (continue)
LAN IPv6 Address Settings
LAN IPv6 Address: Enter the LAN (local) IPv6 address for the router.
LAN IPv6 Link-
Displays the router’s LAN link-local address.
Local Address:
Address Autoconfiguration Settings
Enable
Autoconfiguation:
LAN IPv6 Address: Select SLAAC+Stateless DHCP or Stateful DHCPv6.
If you choose SLAAC+Stateless DHCP, please congure the following eld:
Router
Advertisement
Lifetime:
If you choose Stateful DHCPv6, please congure the following eld:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enter the IPv6 address lifetime (in minutes).
LAN IPv6 Address Settings
Use this section to congure the internal network settings of
your router. If you change the LAN IPv6 Address here, you
may need to adjust your PC’s network settings to access the
network again.
LAN IPv6 Address:
LAN IPv6 Link-Local
Address:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address: SLAAC+Stateless DHCP
Router Advertisement
Lifetime:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
xx00:yy11:zz22:123/64
☑
30 (minutes)
☑
/64
▼
IPv6 Address
Range(Start):
IPv6 Address
Range(End):
Router
Advertisement
Lifetime:
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in seconds).
LAN IPv6 Address: Stateful(DHCPv6)
IPv6 Address Range(Start): xxxx ::00 3
IPv6 Address Range(End):
Router Advertisement
Lifetime:
xxxx ::00 16
▼
(second)
41D-Link DIR-608 User Manual
Section 3 - Conguration
6 to 4
IPv6 Connection Type
My IPv6
Connection is:
Select IPv6 In IPv4 Tunnel if you wish to congure your router to
connect to your ISP using 6 to 4. 6 to 4 is an IPv6 address assignment
and automatic tunneling technology that is used to provide unicast
IPv6 connectivity between IPv6 sites and hosts across the IPv4
Internet.
6to4 Settings
6to4 Address: Displays the 6 to 4 address.
6to4 Relay: Enter the 6 to 4 relay supplied by your ISP.
LAN IPv6 Address Settings
LAN IPv6 Address: Enter LAN (local) IPv6 address for the router.
LAN IPv6 Link-
Local Address:
Displays the router’s LAN link-local address.
IPv6 Connection Type:
Choose the mode to be used by the router to the IPv6
Internet.
My IPv6 Connection is:
6to4 Settings
Enter the IPv6 address information provided by your
Internet Service Provider (ISP).
6to4 Address:
6to4 Relay:
LAN IPv6 Address Settings
Use this section to congure the internal network settings of
your router. If you change the LAN IPv6 Address here, you
may need to adjust your PC’s network settings to access the
network again.
LAN IPv6 Address: xxxx::xxxx::xxxx::
6 to 4
0.0.0.0
0000 ::1/64
▼
IPv6 DNS Settings
Select either Obtain DNS server address automatically or Use the following DNS address.
If you choose Use the following DNS address, please congure the following eld:
Primary DNS
Address:
Secondary DNS
Address:
Enter the primary DNS server address.
Enter the secondary DNS server address.
LAN IPv6 Link-Local
Address:
IPv6 DNS Settings
Obtain DNS server address automatically or enter a
specic DNS server address.
Primary DNS Address:
Secondary DNS Address:
xx00:yy11:zz22:123/64
42D-Link DIR-608 User Manual
Section 3 - Conguration
6 to 4 (continued)
Address Autoconfiguration Settings
Enable
Autoconfiguation:
LAN IPv6 Address: Select SLAAC+Stateless DHCP or Stateful DHCPv6.
If you choose SLAAC+Stateless DHCP, please congure the following eld:
Router
Advertisement
Lifetime:
If you choose Stateful DHCPv6, please congure the following elds:
IPv6 Address
Range(Start):
IPv6 Address
Range(End):
Router
Advertisement
Lifetime:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enter the IPv6 address lifetime (in minutes).
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in seconds).
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address: SLAAC+Stateless DHCP
Router Advertisement
Lifetime:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address:
IPv6 Address Range(Start):
IPv6 Address Range(End):
Router Advertisement
Lifetime:
☑
30 (minutes)
☑
Stateful(DHCPv6)
xxxx ::00
xxxx ::00
3
16
(second)
▼
▼
43D-Link DIR-608 User Manual
Section 3 - Conguration
6rd
IPv6 Connection Type
My IPv6
Connection is:
Select 6rd if you wish to to congure your router to connect to your
ISP using 6rd.
6rd Settings
6rd Mode: Select either 6rd DHCPv4 or Manual.
If you selected Manual:
6rd IPv6 Prefix: Enter the 6rd IPv6 prex and mask length supplied by your ISP.
IPv4 Address: Displays the router’s IPv4 address and mask length.
6rd Relay: Enter the 6rd border relay IPv4 address settings supplied by your ISP.
IPv6 DNS Settings
Select either Obtain DNS server address automatically or Use the following DNS address.
If you choose Use the following DNS address, please congure the following eld:
IPv6 Connection Type:
Choose the mode to be used by the router to the IPv6
Internet.
My IPv6 Connection is:
6rd Settings
Enter the IPv6 address information provided by your
Internet Service Provider (ISP).
6rd Mode:
6rd IPv6 Prex:
IPv4 Address: 192.168.x.x Mask Length:
6rd Relay:
IPv6 DNS Settings
Obtain DNS server address automatically or enter a
specic DNS server address.
Primary DNS Address:
6rd
6rd DHCPv4 Manual
/ 0
0.0.0.0
▼
0
Primary DNS
Address:
Secondary DNS
Address:
Enter the primary DNS server address.
Enter the secondary DNS server address.
Secondary DNS Address:
44D-Link DIR-608 User Manual
Section 3 - Conguration
6rd (continued)
LAN IPv6 Address Settings
LAN IPv6 Address: Displays the router’s LAN IPv6 address.
LAN IPv6 Link-
Displays the router’s LAN IPv6 link-local address.
Local Address:
Address Autoconfiguration Settings
Enable
Autoconfiguation:
LAN IPv6 Address: Select SLAAC+Stateless DHCP or Stateful DHCPv6.
If you choose SLAAC+Stateless DHCP, please congure the following eld:
Router
Advertisement
Lifetime:
If you choose Stateful DHCPv6, please congure the following eld:
Enable or disable the Automatic IPv6 Address Assignment feature.
Enter the IPv6 address lifetime (in minutes).
LAN IPv6 Address Settings
Use this section to congure the internal network settings of
your router. If you change the LAN IPv6 Address here, you
may need to adjust your PC’s network settings to access the
network again.
LAN IPv6 Address:
LAN IPv6 Link-Local
Address:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
LAN IPv6 Address: SLAAC+Stateless DHCP
Router Advertisement
Lifetime:
Address Autoconguration Settings
Use this section to setup IPv6 Autoconguration to assign IP
addresses to the computers on your network.
Enable Autoconguration:
xx00:yy11:zz22:123/64
☑
30 (minutes)
☑
▼
IPv6 Address
Range(Start):
IPv6 Address
Range(End):
Router
Advertisement
Lifetime:
Enter the starting IPv6 address for the DHCP server’s IPv6 assignment.
Enter the ending IPv6 address for the DHCP server’s IPv6 assignment.
Enter the IPv6 address lifetime (in seconds).
LAN IPv6 Address: Stateful(DHCPv6)
IPv6 Address Range(Start): xxxx ::00 3
IPv6 Address Range(End):
Router Advertisement
Lifetime:
xxxx ::00 16
▼
(second)
45D-Link DIR-608 User Manual
Section 3 - Conguration
Link-local only
My IPv6
Connection is:
LAN IPv6 LinkLocal Address:
IPv6 Connection Type
Select Local Connectivity Only if you want to congure your LAN
to use IPv6 but not connect to the Internet.
LAN IPv6 Address Settings
Displays the router’s IPv6 address and mask length.
IPv6 Connection Type:
Choose the mode to be used by the router to the IPv6
Internet.
My IPv6 Connection is:
LAN IPv6 Address Settings
Use this section to congure the internal network settings of
your router. If you change the LAN IPv6 Address here, you
may need to adjust your PC’s network settings to access the
network again.
LAN IPv6 Link-Local
Address:
Link-local only
xx00:yy11:zz22:123/64
▼
46D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Wireless
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
DIR-608
Wireless Basics
WPS
Advanced Wireless
Wireless Repeater
Select Language
Setup Wireless Advanced Maintenance Status Help
English
▼
To return to the Web UI Table of Contents page, simply click the D-Link logo on the top right
of each page.
DIR-608
Wizard
Setup
47D-Link DIR-608 User Manual
Section 3 - Conguration
Advanced
Wireless Basics
Click Wireless Basics on the navigation menu to congure your wireless LAN settings. You
can also congure the wireless security and wireless network parameters.
Wireless Network
Enable SSID
Broadcast:
Enable Wireless
Isolation:
Name (SSID): Enter the SSID name of the router.
Mode: Use the dropdown menu to specify the wireless mode.
Channel: Use the dropdown menu to select the wireless channel.
Band Width: Use the dropdown menu to select the channel bandwidth. If you
Enable SSID broadcast if you want the router to transmit its SSID
publicly so other wireless devices can discover it.
Note: Disabling SSID broadcast is not a form of security alone.
Enable wireless isolation to prevent connected wireless devices from
connecting to other wireless devices that are also connected to the
router.
selected the 802.11n, 802.11 b/g, or 802.11 b/g/n wireless modes,
the available options are 20 MHz and 20/40 MHz. For the others, 20
MHz is the only option.
DIR-608
Basic Wireless
Wireless Network
Enable SSID Broadcast:
Enable Wireless Isolation:
Name(SSID) : D-Link_DIR-608
Band Width:
Basic Wireless
Mode :
Channel: Auto▼Current Channel: 2
Wireless
☑
☑
802.11b/g/n
Auto 20/40M
▼
▼
Security Options
Select a wireless security encryption option. The options are None, WEP, WPA-PSK(TKIP),
WPA2-PSK(AES), and WPA-PSK/WPA2(AES). The following pages describe each type of
security option. Using WPA2-PSK(AES) security is recommended.
Security Options
Security Options :
WPA2-PSK(AES)
▼
48D-Link DIR-608 User Manual
Section 3 - Conguration
WPA2-PSK(AES)
Security Options
Security Options: WPA2-PSK(AES). WPA-PSK is the recommended security encryption
when your clients do not support WPA2(AES), otherwise it is
recommended that you select WPA(AES).
Security Options(WPA2-PSK)
Pre-Shared Key: Enter a wireless key to use on your wireless network.
When you have nished conguring your wireless network, click the Apply button.
Security Options
Security Options :
Security Options(WPA2-PSK)
Pre-Shared Key:
(8-63 characters or 64 hex digits)
Apply Cancel
WPA2-PSK(AES)
▼
49D-Link DIR-608 User Manual
Section 3 - Conguration
WPA-PSK/WPA2(AES)
Security Options
Security Options: WPA-PSK/WPA2(AES). WPA/WPA2 Mixed(AES) is a reasonably
strong wireless security encryption type. This is for wireless clients
which do not support WPA2 encryption, otherwise use of WP2(AES)
is recommended.
Security Options(WPA-PSK+WPA2-PSK)
Pre-Shared Key: Enter a wireless key to use on your wireless network.
When you have nished conguring your wireless network, click the Apply button.
Security Options
Security Options :
Security Options(WPA-PSK+WPA2-PSK)
Pre-Shared Key:
(8-63 characters or 64 hex digits)
Apply Cancel
WPA-PSK/WPA2(AES)
▼
50D-Link DIR-608 User Manual
Section 3 - Conguration
WPA-PSK(TKIP)
Security Options
Security Options: WPA-PSK(TKIP). WPA-PSK is a recommended wireless security
encryption type. Unless your clients do not support WPA2 encryption,
it is recommended that you select WPA2(AES).
Security Options(WPA-PSK)
Pre-Shared Key: Enter a wireless key to use on your wireless network.
When you have nished conguring your wireless network, click the Apply button.
Security Options
Security Options :
Security Options(WPA-PSK)
Pre-Shared Key:
(8-63 characters or 64 hex digits)
Apply Cancel
WPA-PSK(TKIP)
▼
51D-Link DIR-608 User Manual
Section 3 - Conguration
WEP
Security Options
Security Options: WEP. Using WEP encryption is not recommended, as it only oers
a trivial amount of protection for your wireless data. Unless your
clients do not support WPA encryption, it is recommended that you
select WPA2(AES) or WPA/WPA2 Mixed instead of WEP as they are
more secure.
Security Encryption(WEP)
Authentication
Type:
Encryption
Strength:
Select either Automatic or Shared Keys.
Select the Encryption cipher key bit strength. The available options
are 64 bits or 128 bits.
Security Encryption(WEP)
Key 1-4: Enter a wireless key to use on your wireless network.
Security Options
Security Options :
Security Encryption(WEP)
Authentication Type:
Encryption Strength: 128 bits
Security Encryption(WEP)
Key 1:
Key 2:
WEP
Automatic
▼
▼
▼
When you have nished conguring your wireless network, click the Apply button.
Key 3:
Key 4:
Apply Cancel
52D-Link DIR-608 User Manual
Section 3 - Conguration
None
Security Options
Security Options: None. Disabling encryption and leaving your wireless network open
is not recommended. Any wireless client will be able to access your
network, be able to use your Internet connection, and leaves you
open to security threats.
When you have nished conguring your wireless network, click the Apply button.
Security Options
Security Options :
None
Apply Cancel
▼
53D-Link DIR-608 User Manual
Section 3 - Conguration
Advanced
WPS
The easiest way to connect your wireless devices to the router is with WPS (Wi-Fi Protected
Setup). WPS was introduced with two methods of connecting: Push Button Control (PBC)
and Personal Identication Number (PIN). Using WPS-PIN is no longer recommended due
to security vulnerabilities and is disabled by default. For more information refer to WPS
Button on page 88 for steps on using the WPS button to connect wireless clients.
DIR-608
WPS
Wireless
WPS Setup
WPS Setup
Click Next to begin the WPS Setup process.
Note: In order to use this page of the web conguration utility, you must enable WPS-PIN.
Refer to Advanced Wireless on page 55 for more information.
Select
Enter a WPS-PIN and click Start PIN to begin the WPS Setup pairing process. If successful,
you will then be taken to another screen and a message will tell you to run WPS on the client
device within 2 minutes.
WPS Setup
WPS (WiFi Protected Setup), easily connect devices
to a wireless router.
To use the wizard to add a wireless client to WPS-enabled
wireless router, the client must support WPS.
Check the user manual or the box of the wireless client to
conrm whether it supports the WPS.
WEP If the wireless client does not support WPS, you must
congure it manually.
Next
Select
PIN Mode
If your card supports WPS,
pleace click “Generate PIN
code”, and input PIN Code
here.
Entry PIN of wireless NIC:
23474567
Start PIN
Applied client’s PIN successfully!
You have to run Wi-Fi Protected Setup in client within
2 minutes.
Back
54D-Link DIR-608 User Manual
Section 3 - Conguration
Advanced
Advanced Wireless
Click Advanced Wireless on the navigation menu to configure advanced operation
characteristics of your wireless LAN. These settings are provided for advanced users.
Advanced Wireless Settings
Select a wireless security encryption option. You can also choose to not use one by selecting
None, but this is not recommended.
Enable Wireless: Enable wireless on your network.
Fragment
Threshold (256-
2346):
RTS Threshold (1-
2347):
Preamble Type: Use the dropdown menu to specify whether the Router should
The fragmentation threshold, which is specied in bytes, determines
whether packets will be fragmented. Packets exceeding the 2346 byte
setting will be fragmented before transmission. 2346 is the default
setting.
This value should remain at its default setting of 2346. If inconsistent
data ow is a problem, only a minor modication should be made.
use the Short Preamble or Long Preamble type. The preamble type
denes the length of the CRC (Cyclic Redundancy Check) block for
communication between the router and roaming wireless adapters.
DIR-608
Advanced Wireless
Advanced Wireless Settings
Enable Wireless :
Fragment Threshold
(256-2346) :
RTS Threshold (1-2347:
Preamble Type :
Radio Power (Percent) : 100%
HT20/40 Coexistence :
Wireless Advanced Settings
Wireless
☑
2346
2347
Short Preamble
▼
Enable Disable
▼
Radio Power: Set the transmit power of the antennas in percentage.
HT20/40
Enable or disable HT20/40 Coexistence.
Coexistence:
55D-Link DIR-608 User Manual
Section 3 - Conguration
Advanced Wireless (continued)
WPS Setup
PIN of the router: The WPS PIN will be displayed here.
Enable WPS: Check the box to enable WPS.
Disable PIN: Check to disable WPS PIN.
Keep current
Check to keep the current conguration.
configuration:
When you have nished conguring your wireless network, click the Apply Changes button.
Access Control List
Click the ACL Setup button to edit the ACL (Access Control List). This takes you to the screen
below.
Enable Wireless
Access Control
Mode:
Check the box to enable Wireless Access Control Mode. In this mode,
only listed wireless devices will be allowed to connect to the wireless
network.
WPS Setup
PIN of the router :
Enable WPS :
Disable PIN :
Keep current conguration :
Apply Changes
Access Control List
ACL Setup
Wireless Access Control Mode
☑
☑
☑
☐ Enable Wireless Access Control Mode
Click the Apply button when you are done.
If you enabled Wireless Access Control, you may begin adding MAC addresses to the ACL list.
MAC Address: Enter the MAC address of a device you wish to allow access for to
the WLAN and click the Add button. This will add the device’s MAC
Address to the ACL table above. To remove a device from the ACL
table, select the MAC address from the above table and click the
Delete button
MAC Address Select
00e086710502
Delete Selected Delete AllApply
MAC Address:
(ex: 00e086710502)
Add Cancel
56D-Link DIR-608 User Manual
Section 3 - Conguration
Advanced
Wireless Repeater
This page allows you to congure wireless repeater settings for the DIR-608.
Wireless Repeater Setup
Repeater Enabled: Check the box and click the Apply button in order to enable the
Wireless Repeater function. Repeater function is disabled by default.
SSID of AP: If repeater mode is enabled, the name of the host network that is
being repeated is displayed here.
Click the Site Survey button to enable the router to search for nearby
wireless networks. This will take about 5 seconds.
Refer to Wireless Repeater Setup on page 58 for instructions on how to enable the
Wireless Repeater Functionality.
DIR-608
Wireless Repeater
Wireless Repeater Setup
SSID of AP
Wireless
Wireless Repeater
Repeater Enabled(DHCP
mode will be set to ‘none’
☐
if the repeater is enabled)
Site Survey
Apply
57D-Link DIR-608 User Manual
Section 3 - Conguration
Advanced
Wireless Repeater Setup
These instructions will guide you through setting up your DIR-608 as a wireless repeater in a
few easy steps. Please refer to Wireless Repeater Mode on page 9 for more information.
Step 1: Navigate to the Wireless Repeater section of the web ui, click on the Wireless tab
on the top of the web ui and click Wireless Repeater from the menu on the left hand side
of the screen.
Wireless Repeater Setup
Repeater Enabled: Check the box and click the Apply button in order to enable the
Wireless Repeater function.
SSID of AP: Click the Site Survey button to enable the router to search for nearby
wireless networks. This will take about 5 seconds.
A list of wireless networks that have been found will then appear.
Select the wireless network you wish to extend and click the Next
button.
DIR-608
Wireless Repeater
Wireless Repeater Setup
SSID of AP
# SSID MAC Address Channel Signal Security Select
1 D-Link ff:ff:ff:ff 1 100%
Click ‘Next’ to Continue repeater settings
Wireless
Wireless Repeater
Repeater Enabled(DHCP
mode will be set to ‘none’
☑
if the repeater is enabled)
Site Survey
WPA2-
PSK(TKIP)
Next
Apply
58D-Link DIR-608 User Manual
Section 3 - Conguration
Advanced
Wireless Repeater Setup (continued)
Step 2: The page will refresh prompting you to input the wireless security key of the host
network. If the host network does not have wireless security enabled, this step is omitted.
Security Options
Security Options: The host network’s wireless security encryption type is listed here. It
is not changeable.
Security Options(WPA2-PSK)
Pre-Shared Key: Enter the host network’s wireless security key.
When you have entered the wireless network’s key, click the Next button.
Step 3: Enter a new LAN IP address for the DIR-608 if necessary.
Click Finish to complete the setup. You will need to reconnect to the wireless network the
DIR-608 is now repeating.
DIR-608
Wireless Repeater
Wireless Security Settings
Enryption:
Security Options(WPA-PSK)
Pre-Shared Key:
(8-63 characters or 64 hex digits)
Previous Next
WPS Setup
Step 3: click ‘Finish’ to save the conguration.
We strongly recommend that you modify IP address of the
local gateway to avoid IP address conicts with the center
of the AP. (ex. if IP address of AP is 192.168.1.1, you can
modify IP address of the local gateway to 192.168.1.2)
Wireless
Wireless Security Settings
WPA2-PSK(TKIP)
▼
IP Address:
Subnet Mask:
Finish
192.168.11.1
255.255.255.0
59D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Advanced
The Advanced tab provides access to congure the advanced features of your DIR-608.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
DIR-608
Access Control List
Port Triggering
DMZ
URL Block
Dynamic DNS
Trafc Control
UPnP
Telnet
Virtual Server
Setup Wireless Advanced Maintenance Status Help
Hardware version:A1 Firmware version: 1.00
Select Language
English
▼
IPv6 Filter
IPv6 Routing
To return to the Web UI Table of Contents page, simply click the D-Link logo on the top right
of each page.
DIR-608
Wizard
Setup
60D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
Access Control List
This page allows you to set up an Access Control List to restrict the types of data packets
that can enter the network from the Internet.
ACL Settings
WAN Setting: Use the dropdown menu to select either WAN or IP Address.
IP Address: This option will only be seen if you have selected IP Address above.
Enter the IP address range.
Services Allowed: Select the type of Internet service from which packets can be allowed
into the network.
DIR-608
Access Control List
ACL Settings
Services Allowed:
ACL Settings
Services Allowed:
Advanced
WAN ACL Conguration
WAN Setting:
WAN
☐ web
☐ ping
WAN Setting:
IP Address: -
IP Address
(0.0.0.0 represents any IP)
☐ web
☐ ping
▼
▼
Click the Add button to save and add these settings to the Current ACL table.
Current ACL Table
The section displays the current ACL Table.
Add Reset
Current ACL Table
Select
IP Address
/Interface
1 WAN web 80
Service Port Action
Delete
61D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
Port Triggering
This page allows you to enable port triggering to specify inbound trac to be sent to specic
ports while other ports are in use for outbound trac.
Port Triggering Status
This page allows you to set up an Port Trigger Table to restrict the types of data packets that
can enter the network from the Internet.
NAT Port Trigger: Enable or disable the Nat Port Trigger.
Click the Apply Changes button to save any changes made.
Application Type
Usual Application
Name:
User-defined
Application Name:
Start Match Port: Enter a start match port.
End Match Port: Enter a end match port.
Select an application from the dropdown menu.
Enter the name of an application.
DIR-608
Port Triggering
Port Triggering Status
Nat Port Trigger:
Advanced
Port Triggering
Apply Changes
Application Type
Usual Application Name:
User-dened Application Name:
Start
Match
Port
End Match
Port
Trigger
Protocol
UDP
UDP
UDP
Start
Relate
Port
▼
▼
▼
Enable Disable
Select One
End
Relate
Port
Open
Protocol
UDP
UDP
UDP
▼
▼
▼
Nat Type
outgoing
outgoing
outgoing
▼
▼
▼
▼
Trigger Protocol: Select a protocol from the pulldown menu.
Start Relate Port: Enter a start relate port.
End Relate Port: Enter an end relate port.
Open Protocol: Select a protocol from the dropdown menu.
Apply Changes
62D-Link DIR-608 User Manual
Section 3 - Conguration
Port Triggering (continued)
Nat Type: Select whether it will be outgoing or incoming.
Click the Apply Changes button to add a port triggering rule.
Current Port Triggering Table
The section displays the current Port Forwarding Table.
Applications will then be added to the Current Port Triggering Table. Click the Delete button
in the Action eld to delete a Port Triggering rule.
Application Type
Usual Application Name:
User-dened Application Name:
Start
Match
Port
End Match
Port
Trigger
Protocol
UDP
UDP
UDP
Start
Relate
Port
▼
▼
▼
Apply Changes
Current Port Triggering Table
Server
Name
MyApp both outgoing
Trigger
Protocol
Direction Match
Port
5432-
6210
End
Relate
Port
Protocol
Open
both
Select One
Open
Protocol
▼
UDP
▼
UDP
▼
UDP
Relate
Port
4800-
4900
Nat Type
outgoing
outgoing
outgoing
Action
Delete
▼
▼
▼
▼
63D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
DMZ
Sometimes you may want a computer exposed to the outside world for certain types
of applications. If you choose to expose a computer, you can enable the Demilitarized
Zone (DMZ). This option may expose the selected computer to cyber attacks and is not
recommended for novice users.
DIR-608
DMZ
Advanced
DMZ
DMZ Configuration
Enable DMZ: Check the box to enable the DMZ function.
DMZ Host IP
Address:
Click the Apply Changes button to save any changes made.
Enter the IP address of the machine that you wish to place in the
DMZ. If the machine receives an IP address from the DHCP server, you
should create a static DHCP reservation to ensure that the machine
always receives the same address from the DHCP server.
DMZ Conguration
DMZ Host IP Address:
Apply Changes Reset
Enable DMZ
☐
64D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
URL Block
This page allows you to block specic websites or keywords in order to prevent network
clients from accessing them.
URL Blocking Capability
URL Blocking
Capability:
Click the Apply Changes button to save any changes made.
Enable or disable URL Blocking.
Keywords
Keyword: Type a keyword or a URL site that you want to prevent network users
from accessing.
Click the Add Keyword button to add a keyword to the URL block table.
To delete a keyword, select the keyword in the table and click the Delete Selected Keyword
button.
DIR-608
URL Block
URL Blocking Capability
URL Blocking Capability:
Keyword:
Keyword:
AddKeyword
URL BLocking Table:
Select Filtered Keyword
Advanced
URL Blocking Conguration
Disable Enable
Apply Changes
Delete Selected Keyword
dlink
65D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
Dynamic DNS
Most Internet Service Providers (ISPs) assign dynamic (changing) IP addresses. Using a
dynamic DNS service provider, people can enter your domain name in their web browser
to connect to your server, no matter what your IP address is.
DIR-608
Advanced
DDNS Configuration
Enable: Check the box to enable DDNS.
DDNS Provider: Choose your DDNS provider from the dropdown menu.
Host Name: Enter the Host Name that you registered with your DDNS service
provider.
Username: Enter the username for your DDNS account.
Password: Enter the password for your DDNS account.
Click the Add button to save any changes made. The DDNS Conguration will then be added
to the Dynamic DDNS Table below.
Dynamic DDNS Table
The section displays the current Dynamic DDNS settings and status.
Dynamic DNS
Dynamic DNS Conguration
DDNS provider: dlinkddns.com(free)
Account Settings:
Dynamic DDNS Table
Select State Service Hostname Username
Dynamic DNS Conguration
Enable:
Hotname:
Username:
Password:
Add Remove
☑
▼
To delete an existing DDNS Conguration, select a conguration in the table and click the
Remove button.
disable
dlinkddns.com
(free)
mytest Username
66D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
Trac Control
This page allows you to congure trac bandwidth and rules for network trac.
Traffic Control
Total Bandwidth
(0, Unlimited):
Auto Traffic
Shaping:
Click the Apply Changes button to save any changes made.
Enter the total bandwidth provided by your ISP’s service contract in
kbps for uploading and downloading.
Click to enable auto trac shaping.
QoS Rules
The section displays the currently dened Quality of Service (QoS) rules.
To delete an existing QoS rule, select a conguration in the table and click the Delete button.
To add a rule, click the Add button. The following rule creation options will appear:
Protocol: Select the data protocol which you want to set a QoS rule for.
DIR-608
Trafc Control
Trafc Control
Total Bandwidth
(0, Unlimited):
Auto Trafc Shaping
QoS Rules
Source
Protocol
Port
Dest
Port
Advanced
Trafc Control
UP Stream
kbps
☐
Apply
Source
Dest IP
IP
Add Delete
0
Guaranteed
Bandwith
Up
Down
Floor
Floor
Down Stream
kbps
Max
Bandwidth
(Kbps)
Up
Down
Ceiling
Ceiling
0
Delete
☐
Source IP: Enter the source IP.
Dest IP: Enter the destination IP.
Source Port: Enter the source port number if applicable.
Up Floor: Enter the minimum upload speed.
Down Floor: Enter the minimum download speed.
Protocol: None
Source IP:
Dest IP: Dest Netmask:
Source Port: Dest Port:
Up Floor: kb/s Up Ceiling: kb/s
Down Floor:
▼
Source
Netmask:
kb/s Down Ceiling: kb/s
67D-Link DIR-608 User Manual
Section 3 - Conguration
Trac Control (continued)
Source Netmask: Enter the source netmask.
Dest Netmask: Enter the destination netmask.
Dest Port: Enter the destination port.
Up Ceiling: Enter the maximum upload speed.
Down Ceiling: Enter maximum download speed.
When you have nished inputting your new rule, click the Add button.
Protocol: None
Source IP:
Dest IP: Dest Netmask:
Source Port: Dest Port:
Up Floor: kb/s Up Ceiling: kb/s
Down Floor:
▼
Source
Netmask:
kb/s Down Ceiling: kb/s
Add
68D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
UPnP
This page allows you to enable the Universal Plug and Play (UPnP) feature.
UPnP Configuration
UPnP: Click Enable to use the UPnP feature. UPnP provides compatibility
with networking equipment, software, and peripherals.
Current UPnP Table
The section displays the currently dened UPnP rules. These rules are automatically managed
by the DIR-608.
Click the Apply Changes button to save any changes made.
DIR-608
UPnP
UPnP Conguration
Current UPnP Table
Active Protocol
Advanced
UPnP Conguration
UPnP:
Internal
Port
Apply Changes
Disable Enable
External
Port
IP
Address
De-
scription
69D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
Telnet
This page allows you to enable telnet administration of the device. Use of this feature is not
recommended for novice users.
Telnet Configuration
Telnet: Click Enable to turn on the Telnet administration feature.
Click the Apply Changes button to save any changes made.
DIR-608
Telnet
Telnet Conguration
Advanced
Telnet Conguration
Telnet:
Apply Changes
Disable Enable
70D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
Virtual Server
This page allows you to congure the DIR-608’s virtual server so that remote users accessing
Web services via the public IP address can be automatically redirected to local servers on
the LAN (Local Area Network). The DIR-608 is also capable of port-redirection, meaning
that incoming trac to a particular port may be redirected to a dierent port on the server
computer.
DIR-608
Virtual Server
Advanced
Virtual Server
Service Type
Usual Service
Name:
User-defined
Service Name:
Protocol: Select TCP or UDP from the Protocol drop-down menu.
WAN Port: Enter the WAN port number.
LAN Open Port: Enter the LAN Open port number.
LAN IP Address: Enter the IP address of the computer on your local network that you
Click the Apply Changes button to save any changes made. The virtual server will then be
added to the Current Virtual Server Forwarding Table below. To delete or disable a virtual
server, click the Delete or Disable buttons in the Action eld of the virtual server in the table.
Select an application from the drop-down menu or type a name in
the next eld.
Enter a service name.
want to allow the incoming service to.
Service Type
Usual Service Name
User-dened Service Name
Protocol TCP
WAN Port 113 (ex.5001:5010)
LAN Open Port
LAN IP Address
Apply Changes
Current Virtual Server Forwarding Table
Server
Protocol Local IP Address Local Port WAN Port State Action
Name
FTP tcp 192.168.11.2 21-21 21-21 Enable
AUTH
113
▼
▼
Delete Disable
71D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
IPv6 Filter
This page allows you to congure IPv6 lter rules that determine what kind of trac is
allowed to pass through the network.
Default Action Status
Outgoing Default
Action:
Incoming Default
Action:
Choose the default action for outgoing IPv6 trac, either Permit or
Deny. The default is Permit.
Choose the default action for incoming IPv6 trac, either Permit or
Deny. The default is Permit.
Rule Configuration
Rule Action: Select whether to Permit or Deny IPv6 trac for this rule.
Protocol: Select the protocol to apply the rule to: IPv6, ICMP6, TCP, or UDP.
ICMP6 Type: If ICMP6 is selected PING6 is the ICMP6 Type.
Direction: Select whether to apply to rule to Upstream or Downstream trac.
Source IPv6
Address & Prefix
Length:
Enter the source IPv6 address and prex length to apply the rule to.
DIR-608
IPv6 Filter
Default Action Status
Outgoing Default Action:
Incoming Default Action:
Rule Conguration
Rule
Action:
Protocol:
Direction: Upstream
Source
IPv6
Address:
Dest IPv6
Address:
SPort: - DPort: -
Permit Deny
IPv6
Advanced
IP/Port Filtering
Permit Deny
Permit Deny
▼
▼
Icmp6
Type:
Prex
Length:
Prex
Length:
PING6
▼
Dest IPv6 Address
& Prefix Length:
SPort: Enter the source port range, if applicable.
Enter the destination IPv6 address and prex length to apply the
rule to.
Enable:
☑
Apply Changes Reset Help
72D-Link DIR-608 User Manual
Section 3 - Conguration
IPv6 Filter (continued)
DPort: Enter the destination port range, if applicable.
Enable: Check this box to enable the rule.
Click the Apply Changes to add your IPv6 lter.
Current Filter Table
The section displays the current IPv6 Filter Rules.
To enable or disable an IPv6 route lter, click its disable or enable button from the Action
column.
To delete an IPv6 route lter, select it form the table and click the Delete button.
Rule Conguration
Rule
Action:
Protocol:
Direction: Upstream
Source
IPv6
Address:
Dest IPv6
Address:
Permit Deny
IPv6
▼
▼
Icmp6
Type:
Prex
Length:
Prex
Length:
PING6
▼
SPort: - DPort: -
Enable:
☑
Apply Changes Reset Help
Current Filter Table
Rule Protocol
deny ip6 eeee: any 50 disable Downstream
deny ip6 ffff:: any enable Upstream
Source
IPv6/Prex
SPort
Dest IPv6/
Prex
DPort
Icmp6
State Direction Action
Type:
enable
Delete
disable
Delete
73D-Link DIR-608 User Manual
Section 3 - Conguration
Maintenance
IPv6 Routing
This page allows you to you to dene custom IPv6 routes to control how data trac is moved
around your network.
Configuration
Destination: This is the IPv6 address of the router used to reach the specied
destination.
Prefix Lenth: Enter the IPv6 address prex length of the packets that will take this
route.
Next Hop: Enter your next hop gateway to be taken if this route is used.
Interface: Select the interface that the IP packet must use to transit out of the
router when this route is used.
Click the Add Route to add your custom IPv6 route. It will be added to the IPv6 Static
Route Table.
IPv6 Static Route Table
DIR-608
IPv6 Routing
Conguration
Destination
Prex Length
Next Hop
Interface
Add Route Delete Selected
IPv6 Static Route Table
Advanced
IPv6 Routing Conguration
▼
The section displays the current IPv6 Static Route Table.
To delete an IPv6 route, select it from the IPv6 Static Route table and click the Delete
Selected button.
Select Destination NextHop Interface
74D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Maintenance
The Maintenance tab provides access to administration related settings of your DIR-608.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
DIR-608
Reboot
Firmware Upgrade
Backup/Restore
Admin
Time and Date
Setup Wireless Advanced Maintenance Status Help
Hardware version:A1 Firmware version: 1.00
Select Language
English
▼
To return to the Web UI Table of Contents page, simply click the D-Link logo on the top right
of each page.
DIR-608
Wizard
Setup
75D-Link DIR-608 User Manual
Section 3 - Conguration
Status
Reboot
This page allows you to reboot your device with the current setting or reset it to the factory
default setting.
Reboot/Reset System
Click the Reboot button to reboot the system. To reset the system to the factory default
setting, click the Reset button.
DIR-608
Reboot
Reboot/Reset System
Maintenance
Reboot/Reset
Reboot Reset
76D-Link DIR-608 User Manual
Section 3 - Conguration
Status
Firmware Upgrade
This page allows you to upgrade the rmware of the router. If you plan to install new rmware,
make sure the rmware you want to use is on the local hard drive of the computer. Please
check the D-Link support site for rmware updates at http://support.dlink.com. You can
download rmware upgrades to your hard drive from the D-Link support site.
DIR-608
Firmware Upgrade
Maintenance
Upgrade Firmware
Select File
Select File: After you have downloaded the new rmware, click Browse to locate
the rmware update on your hard drive.
Click the Upload button to upload the selected le to the router, or click the Reset button
to cancel the selection.
Select File
Automatically reset default after rmware upgraded
☐
Reset Upload
Browse
77D-Link DIR-608 User Manual
Section 3 - Conguration
Status
Backup/Restore
This page allows you to save the router’s current conguration le onto your computer’s
hard drive or load a saved le from your hard drive.
Save Settings to File
Click the Save button to download the current conguration settings as a le onto your
hard drive.
Load Settings From
To load a previously saved settings le, click the Browse button to locate the le on your
hard drive, then click the Upload button.
DIR-608
Backup/Restore
Save Settings to File
Load Settings From
Maintenance
Backup/Restore Settings
Save...
Browse Upload
78D-Link DIR-608 User Manual
Section 3 - Conguration
Status
Admin
This page allows you to add a user account to the router’s Web server. You can also delete
or modify existing accounts.
Configuration
User Name: Enter a username.
Privilege: The user has Root privilege. No other options are available.
Old Password: Enter the current password of the account.
New Password: Enter the new password for the account.
Confirm Password: Retype the new password.
Click the Add button to save any changes made. The user account will also be added to the
User Account Table below.
To modify an existing user account, click the Select tab next to the user account in the table,
edit the user settings you wish to change, and then click the Modify button.
DIR-608
Admin
Conguration
User Name:
Privilege: Root
Old Password:
New Password:
Conrm Password:
Add Modify Delete Reset
User Account Table
Select User Name Privilege
Maintenance
User Account Conguration
▼
Admin root
To delete an existing account, click the Select tab next to the user account in the table and
then click the Delete button.
79D-Link DIR-608 User Manual
Section 3 - Conguration
Status
Time and Date
This page allows you to edit the system time and Network Time Protocol (NTP). You can
congure, update, and maintain the correct time on the system clock, and congure Daylight
Saving.
DIR-608
Maintenance
System Time
System Time: Enter the correct year, month, day, and time.
Daylight Saving
Select the daylight saving oset if Daylight Saving time will be used.
Offset:
Click the Apply Changes button to save any changes made.
NTP Configuration:
State: Choose to enable or disable the NTP client.
Server: Enter the address of the NTP server to connect to.
Server2: Enter the address of a second NTP server to connect to.
Interval: Enter the time period that you want the NTP server to synchronize
time with the devices on the network. The default value is one hour.
Time and Date
System Time
System Time:
Daylight Saving Offset:
Apply Changes Reset
NTP Conguration:
State:
Server:
Server2:
Interval: Every 1 hours
Time Zone:
Disable Enable
ntp1.dlink.com
(GMT+08:00) China, Hong Kong, Taipei
System Time Conguration
2016 Year Jul▼Month 5 Day
16 Hour 09 min 16 sec
0:00
▼
▼
Time Zone: Select the time zone you are in from the dropdown menu.
GMT Time: This shows the current GMT (Greenwich Mean Time) time.
Click the Apply Changes button to save any changes made.
Start NTP:
NTP Start: To update the current time using NTP, click the Get GMT Time button.
GMT time: Tue July 5 16:09:10 2016
Apply Changes Reset
Start NTP:
NTP Start:
Get GMT Time
80D-Link DIR-608 User Manual
Section 3 - Conguration
Wireless
Status
The Status tab provides information about the DIR-608’s current status.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
DIR-608
Device Info
Active Client Table
IPV6
IPV6 Routing Table
Setup Wireless Advanced Maintenance Status Help
Hardware version:A1 Firmware version: 1.00
Select Language
English
▼
To return to the Web UI Table of Contents page, simply click the D-Link logo on the top right
of each page.
DIR-608
Wizard
Setup
81D-Link DIR-608 User Manual
Section 3 - Conguration
Help
Device Info
This page displays the current status and basic settings of the router.
System
Displays the device’s produce name, uptime, and the currentdate and time.
LAN Configuration
Displays the MAC address and the private (local) IP settings for the router.
WLAN Configuration
Displays the wireless settings such as SSID and Channel.
DIR-608
Device Info
System
Product Name DIR-608
Uptime 1 06:35:16
Date/Time Tue Jul 5 16:09 2016
LAN Conguration
IP Address 192.168.11.1
Subnet Mask 255.255.255.0
DHCP Server Enable
MAC Address FF:FF:FF:FF
WLAN Conguration
Wireless Enabled
Mode AP
SSID D-Link_DIR-608
Encryption WPA/WPA2 Mixed
Channel 1
Broadcast SSID Enabled
WPS Enabled
Repeater Status Disconnected
Status
Wireless Router Status
WAN Configuration
Displays the MAC address and the public IP settings for the router.
Click the Refresh button to view the most current information.
WAN Conguration
Interface Protocol IP
Address
WAN DHCP 0.0.0.0 0.0.0.0 0.0.0.0 FF:FF:FF Down
Gateway DNS Mac
Address
Refresh
Status
82D-Link DIR-608 User Manual
Section 3 - Conguration
Help
Active Client Table
This page displays all of the currently connected wired and wireless clients. The IP address
and MAC address of each client is displayed in the tables.
Active Wired Client Table
This table displays all active wired clients.
Active Wireless Client Table
This table displays all active wireless clients.
Click the Refresh button to refresh the router’s active client table.
DIR-608
Active Client Table
Active Wired Client Table
Name IP Address MAC Address
Computer 192.168.11.2 ff:ff:ff:ff:ff:ff:ff:ff
Active Wireless Client Table
Name IP Address MAC Address
Wi-Fi Computer 192.168.11.3 ff:ff:ff:ff:ff:ff:ff:ff
Status
Active Client Table
Refresh
83D-Link DIR-608 User Manual
Section 3 - Conguration
Help
Statistics
This page displays the statistics for packets that have been transmitted and received on the
network on the router’s WAN and LAN ports, and wireless bands.
Statistics
This table displays the current statistics broken down by interface.
Click the Refresh button to refresh the router’s trac statistics.
DIR-608
Statistics
Statistics
Interface Rx pkt Rx err Rx drop Tx pkt Tx err Tx drop
LAN1 56842 0 0 354862 0 0
LAN2
LAN3 54678 0 0 1482163 0 0
LAN4
WAN 1403745 0 0 15308 0 0
WLAN 44030 0 0 493 0 0
Status
Statistics
Refresh
84D-Link DIR-608 User Manual
Section 3 - Conguration
Help
IPV6
This page displays the current IPv6 connection information as well as all currently connected
IPv6 clients by their IPv6 address and MAC address.
IPv6 Connection Information
This table displays the current IPv6 connection type and IPv6 address.
Active LAN IPv6 Client
This table displays all active IPv6 clients and their associated MAC addresses.
Click the Refresh button to refresh the router’s IPv6 information.
DIR-608
IPV6
IPv6 Connection Information
IPv6 Connection Type IP Address
LAN IPv6 Link-Local
Address
Active LAN IPv6 Client
IPv6 Address Mac Address
Status
IPv6 Network Information
fe80::ffff:1dff:fe03
Refresh
85D-Link DIR-608 User Manual
Section 3 - Conguration
Help
This page displays the current IPv6 routing table.
IPV6 Routing Table
Current IPV6 Routing Table
This table displays the current IPv6 routing table.
Click the Refresh button to refresh the router’s IPv6 information.
DIR-608
IPV6 Routing Table
Current IPV6 Routing Table
Destination NextHop Metric Interface
Status
IPv6 Network Information
Refresh
86D-Link DIR-608 User Manual
Section 3 - Conguration
Help
The Help section provides documentation for each section of the web-based conguration utility.
Product Page: DIR-608
The Wireless tab provides access to congure the wireless networking feature of your DIR-608.
DIR-608
Menu
Setup
Wireless
Advanced
Maintenance
Status
Setup Wireless Advanced Maintenance Status Help
Help Menu
• Setup
• Wireless
• Advanced
• Maintenance
• Status
Setup Help
• Wizard
• Local Network
• Internet Setup
• IPV6
• PPTP
• L2TP
Hardware version:A1 Firmware version: 1.00
Select Language
English
▼
Wireless Help
• Wireless Basics
• WPS
• Advanced Wireless
• Wireless Repeater
87D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
Connect a Wireless Client to Your Router
WPS Button
The easiest and most secure way to connect your wireless devices to the router is with WPS (Wi-Fi Protected Setup). Most wireless
devices such as wireless adapters, media players, Blu-ray DVD players, wireless printers, and cameras will have a WPS button
(or a software utility with WPS) that you can press to connect to the DIR-608 router. Please refer to your user manual for the
wireless device you want to connect to make sure you understand how to enable WPS. Once you know, follow the steps below:
Step 1 - Press the WPS button on the DIR-608 for about 1 second. The wireless LED on the front will start to blink.
WPS Button
Step 2 - Within 2 minutes, press the WPS button on your wireless device (or launch the software utility and start the WPS
process).
Step 3 - Allow up to 1 minute for your connection to be congured. Once the WPS LED stops blinking, you will be connected
and your wireless connection will be secure with WPA2.
88D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
Windows® 10
When connecting to the DIR-608 wirelessly for the rst time, you will need to input the wireless network name (SSID) and WiFi password (security key) of the device you are connecting to. If your product has a Wi-Fi conguration card, you can nd the
default network name and Wi-Fi password here. Otherwise refer to the product label for the default Wi-Fi network SSID and
password, or enter the Wi-Fi credentials set during the product conguration.
To join an existing network, locate the wireless network icon in the taskbar,
next to the time display and click on it.
Wireless Icon
Clicking on this icon will display a list of wireless networks which are within
range of your computer. Select the desired network by clicking on the SSID.
89D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
To connect to the SSID, click Connect.
To automatically connect with the router when your device next detects the
SSID, click the Connect Automatically check box.
You will then be prompted to enter the Wi-Fi password (network security key)
for the wireless network. Enter the password into the box and click Next to
connect to the network. Your computer will now automatically connect to this
wireless network when it is detected.
You can also use Wi-Fi Protected Setup (WPS) to connect to the router. Press the
WPS button on your D-Link device and you will be automatically connected.
90D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
Windows® 8
WPA/WPA2
It is recommended that you enable wireless security (WPA/WPA2) on your wireless router or access point before conguring
your wireless adapter. If you are joining an existing network, you will need to know the security key (Wi-Fi password) being used.
To join an existing network, locate the wireless network icon in the taskbar
next to the time display.
Wireless Icon
Clicking on this icon will display a list of wireless networks that are within
connecting proximity of your computer. Select the desired network by clicking
on the network name.
91D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
You will then be prompted to enter the network security key (Wi-Fi password)
for the wireless network. Enter the password into the box and click Next.
If you wish to use Wi-Fi Protected Setup (WPS) to connect to the router, you
can also press the WPS button on your router during this step to enable the
WPS function.
When you have established a successful connection to a wireless network, the
word Connected will appear next to the name of the network to which you
are connected to.
92D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
Windows® 7
WPA/WPA2
It is recommended that you enable wireless security (WPA/WPA2) on your wireless router or access point before conguring
your wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.
1. Click on the wireless icon in your system tray (lower-right corner).
Wireless Icon
2. The utility will display any available wireless networks in your area.
93D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
3. Highlight the wireless connection with Wi-Fi name (SSID) you would
like to connect to and click the Connect button.
If you get a good signal but cannot access the Internet, check your TCP/
IP settings for your wireless adapter. Refer to the Networking Basics
section in this manual for more information.
4. The following window appears while your computer tries to connect
to the router.
94D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
WPS
The WPS feature of the DIR-608 can be congured using Windows® 7. Carry out the following steps to use Windows® 7 to
congure the WPS feature:
1. Click the Start button and select Computer from the Start menu.
2. Click Network on the left side.
95D-Link DIR-608 User Manual
Section 4 - Connecting to a Wireless Network
3. Double-click the DIR-608.
4. Input the WPS PIN number (on the router label) in the Setup > Wireless
Setup menu in the Router’s Web UI) and click Next.
DIR-608
96D-Link DIR-608 User Manual
Loading...
