D-Link DIR-601 User Manual

Page 1

Page 2

Preface

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes.

Manual Revisions

Revision Date Description

1.0 October 8, 2009 • Revision A1 with rmware version 1.0

1.1 March 24, 2010 • Updated with minor changes

2.0 April 26, 2011 • Updated to hardware revision B1

2.1 July 5, 2011 • Updated rmware version 2.00

Trademarks

D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.

iD-Link DIR-601 User Manual

Page 3

Table of Contents

Preface ..........................................................................................i

Manual Revisions ........................................................................... i

Trademarks ...................................................................................... i

Product Overview ......................................................................1

Package Contents .........................................................................1

System Requirements ................................................................. 2

Features ............................................................................................ 3

Hardware Overview ..................................................................... 4

Connections ...........................................................................4

LEDs ........................................................................................... 5

Installation ..................................................................................6

Before you Begin ........................................................................... 6

Wireless Installation Considerations ...................................... 7

Network Diagram ......................................................................... 8

Desktop Computer ....................................................................8

Web-based Conguration Utility ..........................................19

Internet Connection Setup Wizard ...............................20

Manual Conguration .......................................................25

Dynamic (Cable) .............................................................25

Dynamic IP Address (DHCP) .......................................26

PPPoE (DSL) ......................................................................27

PPTP ....................................................................................29

L2TP ....................................................................................31

Static IP Address .............................................................33

Wireless Settings .................................................................35

Manual Wireless Network Setup ..............................36

Network Settings ................................................................38

DHCP Server Settings ...................................................39

DHCP Reservation .........................................................40

Virtual Server ........................................................................41

Port Forwarding ..................................................................43

Application Rules ................................................................44

Wireless Laptop .........................................................................8

DIR-601 Router ...........................................................................8

Internet ........................................................................................8

Connect to Cable/DSL/Satellite Modem .............................. 9

Connect to Another Router ....................................................10

Getting Started ............................................................................12

Conguration .......................................................................... 13

Quick Setup Wizard ....................................................................13

QoS Engine............................................................................45

Network Filters .....................................................................46

Access Control .....................................................................47

Access Control Wizard ..................................................47

Website Filters ......................................................................50

Inbound Filters.....................................................................51

Firewall Settings ..................................................................52

Routing ...................................................................................53

Advanced Wireless Settings ............................................54

Advanced Network Settings ...........................................55

iiD-Link DIR-601 User Manual

Page 4

Table of Contents

Administrator Settings ......................................................56

Time Settings .......................................................................58

SysLog .....................................................................................59

E-mail Settings .....................................................................60

System Settings ...................................................................61

Update Firmware ................................................................62

DDNS .......................................................................................63

System Check .......................................................................64

Schedules ..............................................................................65

Device Information ............................................................66

Log ...........................................................................................68

Stats .........................................................................................69

Internet Sessions .................................................................70

Routing Table .......................................................................72

Wireless ..................................................................................73

Support ..................................................................................74

Congure WPA-PSK ............................................................90

Troubleshooting ..................................................................... 92

Wireless Basics ........................................................................ 96

What is Wireless? .........................................................................97

Wireless Modes ......................................................................... 100

Networking Basics ................................................................ 101

Check your IP address ............................................................ 101

Statically Assign an IP address ............................................ 102

Technical Specications ......................................................103

Contacting Technical Support ............................................ 104

Warranty ................................................................................. 105

Registration ........................................................................... 111

Wireless Security ..................................................................... 75

What is WPA? ................................................................................75

Wireless Connection Setup Wizard ......................................76

Add Wireless Device with WPS Wizard ................................78

Congure WPA-Personal (PSK) ...............................................79

Congure WPA-Enterprise (RADIUS) ....................................80

Connect to a Wireless Network ............................................ 82

Using Windows® 7 .......................................................................82

Using Windows Vista® ................................................................85

Congure WPA/WPA2 ........................................................86

Connect Using WCN 2.0 ...................................................88

Using Windows® XP ....................................................................89

iiiD-Link DIR-601 User Manual

Page 5

Section 1 - Product Overview

Product Overview

Package Contents

D-Link DIR-601 Wireless N

150 Home Router

Power Adapter

Ethernet Cable

CD-ROM

Note: Using a power supply with a dierent voltage rating than the one included with the DIR-601 will cause damage and void the

warranty for this product.

1D-Link DIR-601 User Manual

Page 6

Section 1 - Product Overview

System Requirements

Network Requirements

• An Ethernet-based Cable or DSL modem

• IEEE 802.11n/g wireless clients

• 10/100 Ethernet

Computer with the following:

• Windows®, Macintosh

• An installed Ethernet adapter

Browser Requirements:

Web-based Conguration

Utility Requirements

CD Installation Wizard

Requirements

• Internet Explorer® 6.0 and higher

• Mozilla Firefox 3.0 and higher

• Google™ Chrome 2.0 and higher

• Apple Safari 3.0 and higher

Windows® Users: Make sure you have the latest version of Java installed. Visit www.java.com to download the latest version.

Computer with the following:

• Windows® XP with Service Pack 2, Vista® or Windows® 7

• An installed Ethernet adapter

• CD-ROM drive

2D-Link DIR-601 User Manual

Page 7

Section 1 - Product Overview

• Faster Wireless Networking - The DIR-601 provides up to 150Mbps.* This capability allows users to participate in real-time activities online, such as video streaming, online gaming, and real-time audio.

• Compatible with 802.11g Devices - The DIR-601 is still fully compatible with the IEEE 802.11g standard, so it can connect with existing 802.11g PCI, USB and Cardbus adapters.

• Advanced Firewall Features - The Web-based user interface displays a number of advanced network management features including:

• Content Filtering - Easily applied content ltering based on MAC Address, URL, and/or Domain Name.

• Filter Scheduling - These lters can be scheduled to be active on certain days or for a duration of hours or minutes.

Features

• Secure Multiple/Concurrent Sessions - The DIR-601 can pass through VPN sessions. It supports multiple and concurrent IPSec and PPTP sessions, so users behind the DIR-601 can securely access corporate networks.

• User-friendly Setup Wizard - Through its easy-to-use Web-based user interface, you can congure your router to your specic settings within minutes.

* Maximum wireless signal rate derived from IEEE Standard 802.11g and 802.11n specications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely aect wireless signal range.

3D-Link DIR-601 User Manual

Page 8

Section 1 - Product Overview

Hardware Overview

Connections

41 32

1 LAN Ports (1-4) Connect Ethernet devices such as computers, switches, and hubs.

2 Internet Port

3 Power Receptor The Power LED will illuminate red when the camera is receiving power.

4 Reset Pressing the Reset button restores the router to its original factory default settings.

The auto MDI/MDIX Internet port is the connection for the Ethernet cable to the cable or DSL modem.

4D-Link DIR-601 User Manual

Page 9

Section 1 - Product Overview

Hardware Overview

LEDs

1 2

1 Power LED A solid light indicates a proper connection to the power supply.

2 Internet LED A solid light indicates connection on the Internet port. This LED blinks during data transmission.

3 WLAN LED

4 Local Network LEDs

A solid light indicates that the wireless segment is ready. This LED blinks during wireless data transmission.

A solid light indicates a connection to an Ethernet-enabled computer on ports 1-4. This LED blinks during data transmission.

5D-Link DIR-601 User Manual

Page 10

Section 2 - Installation

Installation

This section will walk you through the installation process. Placement of the router is very important. Do not place the router in an enclosed area such as a closet, cabinet, or in the attic or garage.

Before you Begin

• Please congure the router with the computer that was last connected directly to your modem.

• You can only use the Ethernet port on your modem. If you were using the USB connection before using the router, then you must turn o your modem, disconnect the USB cable and connect an Ethernet cable to the Internet port on the router, and then turn the modem back on. In some cases, you may need to call your ISP to change connection types (USB to Ethernet).

• If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoet, Broadjump, or Enternet 300 from your computer or you will not be able to connect to the Internet.

• When running the Setup Wizard from the D-Link CD, make sure the computer you are running the CD from is connected to the Internet and online or the wizard will not work. If you have disconnected any hardware, re-connect your computer back to the modem and make sure you are online.

6D-Link DIR-601 User Manual

Page 11

Section 2 - Installation

Wireless Installation Considerations

The D-Link wireless router lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:

1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling

can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.

2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle appears to be

almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.

3. Building Materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range. Try to position

access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and concrete will degrade your wireless signal.

4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise.

5. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your

wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use.

7D-Link DIR-601 User Manual

Page 12

Section 2 - Installation

-- -

1 2 LAN 3 4 INTERNET

RESET

INTERNET

Network Diagram

Desktop Computer

Wireless Laptop

DIR-601 Router

Internet

8D-Link DIR-601 User Manual

Page 13

Section 2 - Installation

Connect to Cable/DSL/Satellite Modem

If you are connecting the router to a cable/DSL/satellite modem, please follow the steps below:

1. Place the router in an open and central location. Do not plug the power adapter into the router.

2. Turn the power o on your modem. If there is no on/o switch, then unplug the modem’s power adapter. Shut down your computer.

3. Unplug the Ethernet cable (that connects your computer to your modem) from your computer and place it into the Internet port on the router.

4. Plug an Ethernet cable into one of the four LAN ports on the router. Plug the other end into the Ethernet port on your computer.

5. Turn on or plug in your modem. Wait for the modem to boot (about 30 seconds).

6. Plug the power adapter to the router and connect to an outlet or power strip. Wait about 30 seconds for the router to boot.

7. Turn on your computer.

8. Verify the link lights on the router. The power light, Internet light, and the LAN light (the port that your computer is plugged into) should be lit. If not, make sure your computer, modem, and router are powered on and verify the cable connections are correct.

9. Skip to page 12 to congure your router.

9D-Link DIR-601 User Manual

Page 14

Section 2 - Installation

Connect to Another Router

If you are connecting the D-Link router to another router to use as a wireless access point and/or switch, you will have to do the following before connecting the router to your network:

• Disable UPnP™

• Disable DHCP

• Change the LAN IP address to an available address on your network. The LAN ports on the router cannot accept a DHCP address from your other router.

To connect to another router, please follow the steps below:

1. Plug the power into the router. Connect one of your computers to the router (LAN port) using an Ethernet cable. Make sure your IP address on the computer is 192.168.0.xxx (where xxx is between 2 and 254). Please see the Networking Basics section for more information. If you need to change the settings, write down your existing settings before making any changes. In most cases, your computer should be set to receive an IP address automatically in which case you will not have to do anything to your computer.

2. Open a web browser and enter http://192.168.0.1 and press Enter. When the login window appears, set the user name to Admin and leave the password box empty. Click Log In to continue.

3. Click on Advanced and then click Advanced Network. Uncheck the Enable UPnP checkbox. Click Save Settings to continue.

4. Click Setup and then click Network Settings. Uncheck the Enable DHCP Server server checkbox. Click Save Settings to continue.

5. Under Router Settings, enter an available IP address and the subnet mask of your network. Click Save Settings to save your settings. Use this new IP address to access the conguration utility of the router in the future. Close the browser and change your computer’s IP settings back to the original values as in Step 1.

6. Disconnect the Ethernet cable from the router and reconnect your computer to your network.

7. Connect an Ethernet cable in one of the LAN ports of the router and connect it to your other router. Do not plug anything into the Internet port of the D-Link router.

10D-Link DIR-601 User Manual

Page 15

Section 2 - Installation

8. You may now use the other 3 LAN ports to connect other Ethernet devices and computers. To congure your wireless network, open a web browser and enter the IP address you assigned to the router. Refer to the Conguration and Wireless Security sections for more information

on setting up your wireless network.

11D-Link DIR-601 User Manual

Page 16

Section 2 - Installation

Getting Started

The DIR-601 includes a Quick Router Setup Wizard CD. Follow the simple steps below to run the Setup Wizard to guide you quickly through the installation process. You may manually congure your router without the wizard. Refer to the next page to manually setup your router.

Insert the Quick Router Setup Wizard CD in the CD-ROM drive. The step-by-step instructions that follow are shown in Windows® XP or Vista®. The steps and screens are similar for the other Windows® operating systems.

If the CD autorun function does not automatically start on your computer, go to Start > Run. In the run box type “D:\autorun.exe” (where D: represents the drive letter of your CD-ROM drive).

When the autorun screen appears, click Install and follow the on-screen instructions.

Note: It is recommended to write down the login password on the provided CD holder.

12D-Link DIR-601 User Manual

Page 17

Section 3 - Conguration

Conguration

This section will show you how to congure your new D-Link wireless router using the web-based conguration utility.

Note: If you have successfully completed the setup on your router with the CD, the Quick Setup Wizard will not appear. Please refer to page 20.

Quick Setup Wizard

To access the conguration utility, open a web-browser such as Internet Explorer and enter the IP address of the router (192.168.0.1).

13D-Link DIR-601 User Manual

Page 18

Section 3 - Conguration

This wizard is designed to guide you through a step-by step process to congure your new D-Link router and connect to the Internet.

Click Next to continue.

Select your time zone from the drop-down menu and click Next to continue.

14D-Link DIR-601 User Manual

Page 19

Section 3 - Conguration

In order to secure your new networking device, please enter a password and click Next.

Select Enable Advanced DNS Services to allow this function to improve your overall Internet experience.

Click Next to continue.

15D-Link DIR-601 User Manual

Page 20

Section 3 - Conguration

Please wait while your router detects your internet connection type.

Select your Internet connection type and click Next to continue.

16D-Link DIR-601 User Manual

Page 21

Section 3 - Conguration

If you selected DHCP Connection, make suer that you are connected to the D-Link router with the PC that was originally connected to your broadband connection. Then, click the Clone MAC button to copy your computer’s MAC address. Click Next to continue.

Please give your network a name using up to 32 characters.

It is highly recommended that you have a security key for your network. If you would like the router to automatically assign a security key, choose Automatically assign a

network key or you may choose Manually assign a network key and you may enter your own Network key.

Click Next to continue.

17D-Link DIR-601 User Manual

Page 22

Section 3 - Conguration

Once this screen appears, your setup is complete. Click Save & Connect to reboot the router.

Before your router reboots, you will be asked if you want to bookmark ‘D-Link Router Web Management,” click Ok to nish.

18D-Link DIR-601 User Manual

Page 23

Section 3 - Conguration

Web-based Conguration Utility

To access the conguration utility, open a web-browser such as Internet Explorer and enter the IP address of the router (192.168.0.1).

Select Admin from the drop-down menu and then enter your password. Leave the password blank by default.

If you get a Page Cannot be Displayed error, please refer to the Troubleshooting section for assistance.

19D-Link DIR-601 User Manual

Page 24

Section 3 - Conguration

Internet Connection Setup Wizard

Once logged into the web interface of the router, the Setup > Internet page will appear. Click the Internet Connection Setup Wizard button to quickly congure your router using the setup wizard.

If you want to enter your settings without running the wizard, click Manual Internet Conguration Wizard.

20D-Link DIR-601 User Manual

Page 25

Section 3 - Conguration

Click Next to continue.

Create a new password and then click Next to continue.

Select your time zone from the drop-down menu and then click Next to continue.

21D-Link DIR-601 User Manual

Page 26

Section 3 - Conguration

Select the type of Internet connection you use and then click Next to continue.

If you selected Dynamic, you may need to enter the MAC address of the computer that was last connected directly to your modem. If you are currently using that computer, click Clone Your PC’s MAC Address and then click Next to continue.

The Host Name is optional but may be required by some ISPs. The default host name is the device name of the Router and may be changed.

22D-Link DIR-601 User Manual

Page 27

Section 3 - Conguration

If you selected PPPoE, enter your PPPoE username and password. Click Next to cozntinue.

Select Static if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses.

Note: Make sure to remove your PPPoE software from your computer. The software is no longer needed and will not work through a router.

If you selected PPTP, enter your PPTP username and password. Click Next to continue.

23D-Link DIR-601 User Manual

Page 28

Section 3 - Conguration

If you selected L2TP, enter your L2TP username and password. Click Next to continue.

If you selected Static, enter your network settings supplied by your Internet provider. Click Next to continue.

Click Connect to save your settings. Once the router is nished rebooting, click Continue. Please allow 1-2 minutes to connect.

24D-Link DIR-601 User Manual

Page 29

Section 3 - Conguration

Manual Conguration

Dynamic (Cable)

If you opt to set up your Internet connection manually, you will be redirected to a WAN page that allows you to select your Internet type and enter the correct conguration parameters.

Select your Internet connection type using the “My Internet Connection is” drop-down menu.

Click the Save Settings button when you have congured the connection.

25D-Link DIR-601 User Manual

Page 30

Section 3 - Conguration

Dynamic IP Address (DHCP)

Enable

Advanced

DNS Service:

Host Name:

Use

Unicasting:

Advanced Domain Name System (DNS) services enhances your Internet performance by getting you the information and web pages you are looking for faster and more reliably. In addition, it improves your overall Internet experience by correcting many common typo mistakes automatically, taking you where you intended to go and saving you valuable time.

Disclaimer: D-Link makes no warranty as to the availability, reliability, functionality and operation of the Advanced DNS service or its features.

The Host Name is optional but may be required by some ISPs.

Check the box if you are having problems obtaining an IP address from your ISP.

DNS Addresses:

MTU:

MAC

Address:

Enter the Primary DNS server IP address assigned by your ISP.

Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP. 1500 is the default MTU.

The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.

26D-Link DIR-601 User Manual

Page 31

Section 3 - Conguration

PPPoE (DSL)

Choose PPPoE (Point to Point Protocol over Ethernet) if your ISP uses a PPPoE connection. Your ISP will provide you with a username and password. This option is typically used for DSL services. Make sure to remove your PPPoE software from your computer. The software is no longer needed and will not work through a router.

My Internet

Connection:

Enable

Advanced DNS

Service:

Address Mode:

Select Dynamic IP (DHCP) to obtain IP Address information automatically from your ISP. Select this option if your ISP does not give you any IP numbers to use. This option is commonly used for Cable modem services.

Disclaimer: D-Link makes no warranty as to the availability, reliability, functionality and operation of the Advanced DNS service or its features.

Select Static if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic.

IP Address:

User Name:

Password:

Service Name:

Enter the IP address (Static PPPoE only).

Enter your PPPoE user name.

Enter your PPPoE password and then retype the password in the next box.

Enter the ISP Service Name (optional).

27D-Link DIR-601 User Manual

Page 32

Section 3 - Conguration

Reconnection

Mode:

Maximum Idle

Time:

DNS Addresses:

MTU:

MAC Address:

Select either Always-on, On-Demand, or Manual.

Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, enable Auto-reconnect.

Enter the Primary and Secondary DNS Server Addresses (Static PPPoE only).

Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP. 1492 is the default MTU.

28D-Link DIR-601 User Manual

Page 33

Section 3 - Conguration

PPTP

Choose PPTP (Point-to-Point-Tunneling Protocol ) if your ISP uses a PPTP connection. Your ISP will provide you with a username and password. This option is typically used for DSL services.

My Internet

Connection:

Enabled

Advanced

DNS

Service:

Address

Mode:

Disclaimer: D-Link makes no warranty as to the availability, reliability, functionality and operation of the Advanced DNS service or its features.

Select Static if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic.

PPTP IP

Address:

PPTP

Subnet

Mask:

Enter the IP address (Static PPTP only).

Enter the Primary and Secondary DNS Server Addresses (Static PPTP only).

29D-Link DIR-601 User Manual

Page 34

Section 3 - Conguration

PPTP Gateway:

PPTP Server IP:

Username:

Password:

Reconnect

Mode:

Maximum Idle

Time:

DNS Servers:

MTU:

MAC Address:

Enter the Gateway IP Address provided by your ISP.

Enter the Server IP provided by your ISP (optional).

Enter your PPTP username.

Enter your PPTP password and then retype the password in the next box.

Select either Always-on, On-Demand, or Manual.

Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, enable Auto-reconnect.

The DNS server information will be supplied by your ISP (Internet Service Provider.)

Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP (1400 is the default MTU).

30D-Link DIR-601 User Manual

Page 35

Section 3 - Conguration

L2TP

Choose L2TP (Layer 2 Tunneling Protocol) if your ISP uses a L2TP connection. Your ISP will provide you with a username and password. This option is typically used for DSL services.

My Internet

Connection:

Enabled

Advanced DNS

Service:

Address Mode:

Disclaimer: D-Link makes no warranty as to the availability, reliability, functionality and operation of the Advanced DNS service or its features.

Select Static if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic.

L2TP IP

Address:

L2TP Subnet

Mask:

L2TP Gateway:

L2TP Server IP:

Enter the L2TP IP address supplied by your ISP (Static only).

Enter the Subnet Mask supplied by your ISP (Static only).

Enter the Gateway IP Address provided by your ISP.

Enter the Server IP provided by your ISP (optional).

31D-Link DIR-601 User Manual

Page 36

Section 3 - Conguration

Username:

Password:

Reconnect

Mode:

Maximum Idle

Time:

DNS Servers:

MTU:

Clone MAC

Address:

Enter your L2TP username.

Enter your L2TP password and then retype the password in the next box.

Select either Always-on, On-Demand, or Manual.

Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, enable Auto-reconnect.

Enter the Primary and Secondary DNS Server Addresses (Static L2TP only).

Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP. 1400 is the default MTU.

32D-Link DIR-601 User Manual

Page 37

Section 3 - Conguration

Static IP Address

Select Static IP Address if all the Internet port’s IP information is provided to you by your ISP. You will need to enter in the IP address, subnet mask, gateway address, and DNS address(es) provided to you by your ISP. Each IP address entered in the elds must be in the appropriate IP form, which are four octets separated by a dot (x.x.x.x). The Router will not accept the IP address if it is not in this format.

My Internet

Connection:

Enabled

Advanced DNS

Service:

IP Address:

Disclaimer: D-Link makes no warranty as to the availability, reliability, functionality and operation of the Advanced DNS service or its features.

Enter the IP address assigned by your ISP.

Subnet Mask:

Default

Gateway:

DNS Servers:

MTU:

Enter the Subnet Mask assigned by your ISP.

Enter the Gateway assigned by your ISP.

The DNS server information will be supplied by your ISP (Internet Service Provider.)

Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP (1500 is the default MTU).

33D-Link DIR-601 User Manual

Page 38

Section 3 - Conguration

The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not recommended

MAC

Address:

that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.

34D-Link DIR-601 User Manual

Page 39

Section 3 - Conguration

Wireless Settings

If you want to congure the wireless settings on your router using the wizard, click Wireless Connection Setup Wizard and refer to page 76.

Click Add Wireless Device with WPS if you want to add a wireless device using Wi-Fi Protected Setup (WPS) and refer to page 78.

If you want to manually congure the wireless settings on your router click Manual Wireless Network Setup and refer to the next page.

35D-Link DIR-601 User Manual

Page 40

Section 3 - Conguration

Manual Wireless Network Setup

Enable

Wireless:

Wireless

Network

Name:

802.11 Mode:

Enable Auto

Channel Scan:

Check the box to enable the wireless function. If you do not want to use wireless, uncheck the box to disable all the wireless functions. Click Add New to create your own time schedule to enable the wireless function.

Service Set Identier (SSID) is the name of your wireless network. Create a name using up to 32 characters. The SSID is case-sensitive.

Select one of the following:

802.11g Only - Select if all of your wireless clients are

802.11g.

802.11n Only - Select only if all of your wireless clients are 802.11n.

Mixed 802.11n and 802.11g - Select if you are using a mix of 802.11n and 802.11g wireless clients.

The Auto Channel Scan setting can be selected to allow the DIR-601 to choose the channel with the least amount of interference.

Wireless

Channel:

Channel

Width:

Indicates the channel setting for the DIR-601. By default the channel is set to 6. The Channel can be changed to t the channel setting for an existing wireless network or to customize the wireless network. If you enable Auto Channel Scan, this option will be greyed out.

Select the Channel Width: Auto 20/40 - Select if you are using both

802.11n and non-802.11n wireless devices. 20MHz - Select if you are not using any 802.11n wireless clients. This is the default setting. 40MHz - Select if you are using only 802.11n wireless clients.

36D-Link DIR-601 User Manual

Page 41

Section 3 - Conguration

Visibility

Status:

Wireless

Security:

Select Invisible if you do not want the SSID of your wireless network to be broadcasted by the DIR-601. If Invisible is selected, the SSID of the DIR-601 will not be seen by Site Survey utilities so your wireless clients will have to know the SSID of your DIR-601 in order to connect to it.

Refer to page 75 for more information regarding wireless security.

37D-Link DIR-601 User Manual

Page 42

Section 3 - Conguration

Network Settings

This section will allow you to change the local network settings of the router and to congure the DHCP settings.

IP Address:

Subnet Mask:

Local Domain:

Enable DNS

Relay:

Enter the IP address of the router. The default IP address is 192.168.0.1.

If you change the IP address, once you click Apply, you will need to enter the new IP address in your browser to get back into the conguration utility.

Enter the Subnet Mask. The default subnet mask is

255.255.255.0.

Enter the Domain name (Optional). Uncheck the box to transfer the DNS server information from your ISP to your computers. If checked, your computers will use the router for a DNS server.

38D-Link DIR-601 User Manual

Page 43

Section 3 - Conguration

DHCP Server Settings

DHCP stands for Dynamic Host Control Protocol. The DIR-601 has a built-in DHCP server. The DHCP Server will automatically assign an IP address to the computers on the LAN/private network. Be sure to set your computers to be DHCP clients by setting their TCP/IP settings to “Obtain an IP Address Automatically.” When you turn your computers on, they will automatically load the proper TCP/IP settings provided by the DIR-601. The DHCP Server will automatically allocate an unused IP address from the IP address pool to the requesting computer. You must specify the starting and ending address of the IP address pool.

Enable DHCP

Server:

DHCP IP

Address

Range:

Lease Time:

Always

Broadcast:

Check this box to enable the DHCP server on your router. Uncheck to disable this function.

Enter the starting and ending IP addresses for the DHCP server’s IP assignment.

Note: If you statically (manually) assign IP addresses to your computers or devices, make sure the IP addresses are outside of this range or you may have an IP conict.

The length of time for the IP address lease. Enter the Lease time in minutes.

Enable this feature to broadcast your LAN/WLAN network.

39D-Link DIR-601 User Manual

Page 44

Section 3 - Conguration

DHCP Reservation

If you want a computer or device to always have the same IP address assigned, you can create a DHCP reservation. The router will assign the IP address only to that computer or device.

Note: This IP address must be within the DHCP IP Address Range.

Enable:

Computer

Name:

IP Address:

MAC Address:

Copy Your PC’s

MAC Address:

Save:

Number of

Dynamic DHCP

Clients:

Check this box to enable the reservation.

Enter the computer name or select from the drop-down menu and click <<.

Enter the IP address you want to assign to the computer or device. This IP Address must be within the DHCP IP Address Range.

Enter the MAC address of the computer or device.

If you want to assign an IP address to the computer you are currently on, click this button to populate the elds.

Click Save to save your entry. You must click Save Settings at the top to activate your reservations.

In this section you can see what LAN devices are currently leasing IP addresses.

Revoke:

Click Revoke to cancel the lease for a specic LAN device and free an entry in the lease table. Do this only if the device no longer needs the leased IP address, because, for example, it has been removed from the network.

Note: The Revoke option will not disconnect a PC with a current network session from the network; you would need to use MAC Address Filter to do that. Revoke will only free up a DHCP Address for the very next requester. If the previous owner is still available, those two devices may both receive an IP Address Conict error, or the second device may still not receive an IP Address; in that case, you may still need to extend the “DHCP IP Address Range” to address the issue, it is located in the DHCP Server section.

40D-Link DIR-601 User Manual

Page 45

Section 3 - Conguration

Virtual Server

The DIR-601 can be congured as a virtual server so that remote users accessing Web or FTP services via the public IP address can be automatically redirected to local servers in the LAN (Local Area Network).

The DIR-601 rewall feature lters out unrecognized packets to protect your LAN network so all computers networked with the DIR-601 are invisible to the outside world. If you wish, you can make some of the LAN computers accessible from the Internet by enabling Virtual Server. Depending on the requested service, the DIR-601 redirects the external service request to the appropriate server within the LAN network.

The DIR-601 is also capable of port-redirection meaning incoming trac to a particular port may be redirected to a dierent port on the server computer.

Each virtual service that is created will be listed at the bottom of the screen in the Virtual Servers List. There are pre-dened virtual services already in the table. You may use them by enabling them and assigning the server IP to use that particular virtual service.

For a list of ports for common applications, please visit http://support.dlink.com/faq/ view.asp?prod_id=1191.

41D-Link DIR-601 User Manual

Page 46

Section 3 - Conguration

This will allow you to open a single port. If you would like to open a range of ports, refer to the next page.

Name:

IP Address:

Private Port/

Public Port:

Protocol Type:

Inbound Filter:

Schedule:

Enter a name for the rule or select an application from the drop-down menu. Select an application and click << to populate the elds.

Enter the IP address of the computer on your local network that you want to allow the incoming service to. If your computer is receiving an IP address automatically from the router (DHCP), you computer will be listed in the “Computer Name” drop-down menu. Select your computer and click <<.

Enter the port that you want to open next to Private Port and Public Port. The private and public ports are usually the same. The public port is the port seen from the Internet side, and the private port is the port being used by the application on the computer within your local network.

Select TCP, UDP, or Both from the drop-down menu.

Select Allow All (most common) or a created Inbound lter. You may create your own inbound lters in the Advanced > Inbound Filter page.

The schedule of time when the Virtual Server Rule will be enabled. The schedule may be set to Always, which will allow the particular service to always be enabled. You can create your own times in the Tools > Schedules section.

42D-Link DIR-601 User Manual

Page 47

Section 3 - Conguration

Port Forwarding

This will allow you to open a single port or a range of ports.

Name:

IP Address:

TCP/UDP:

Inbound Filter:

Enter a name for the rule or select an application from the drop-down menu. Select an application and click << to populate the elds.

Enter the TCP and/or UDP port or ports that you want to open. You can enter a single port or a range of ports. Separate ports with a common.

Example: 24,1009,3000-4000

Select Allow All (most common) or a created Inbound lter. You may create your own inbound lters in the Advanced > Inbound Filter page.

Schedule:

43D-Link DIR-601 User Manual

Page 48

Section 3 - Conguration

Application Rules

Some applications require multiple connections, such as Internet gaming, video conferencing, Internet telephony and others. These applications have diculties working through NAT (Network Address Translation). Special Applications makes some of these applications work with the DIR-601. If you need to run applications that require multiple connections, specify the port normally associated with an application in the “Trigger Port” eld, select the protocol type as TCP or UDP, then enter the rewall (public) ports associated with the trigger port to open them for inbound trac.

The DIR-601 provides some predened applications in the table on the bottom of the web page. Select the application you want to use and enable it.

Name:

Trigger:

Trac Type:

Firewall:

Trac Type:

Schedule:

Enter a name for the rule. You may select a pre-dened application from the drop-down menu and click <<.

This is the port used to trigger the application. It can be either a single port or a range of ports.

Select the protocol of the trigger port (TCP, UDP, or Both).

This is the port number on the Internet side that will be used to access the application. You may dene a single port or a range of ports. You can use a comma to add multiple ports or port ranges.

Select the protocol of the rewall port (TCP, UDP, or Both).

The schedule of time when the Application Rule will be enabled. The schedule may be set to Always, which will allow the particular service to always be enabled. You can create your own times in the Tools > Schedules section.

44D-Link DIR-601 User Manual

Page 49

Section 3 - Conguration

QoS Engine

The QoS Engine option helps improve your network gaming performance by prioritizing applications. By default the QoS Engine settings are disabled and application priority is not classied automatically.

Enable QoS

Engine:

Automatic

Uplink Speed:

Measured Uplink

Speed:

Manual Uplink

Speed:

This option is disabled by default. Enable this option for better performance and experience with online games and other interactive applications, such as VoIP.

This option is enabled by default when the QoS Engine option is enabled. This option will allow your router to automatically determine the uplink speed of your Internet connection.

This displays the detected uplink speed.

The speed at which data can be transferred from the router to your ISP. This is determined by your ISP. ISP’s oer speed as a download/upload pair. For example, 1.5Mbits/284Kbits. Using this example, you would enter 284. Alternatively you can test your uplink speed with a service such as www.dslreports.com.

45D-Link DIR-601 User Manual

Page 50

Section 3 - Conguration

Network Filters

Use MAC (Media Access Control) Filters to allow or deny LAN (Local Area Network) computers by their MAC addresses from accessing the Network. You can either manually add a MAC address or select the MAC address from the list of clients that are currently connected to the Broadband Router.

Congure MAC

Filtering:

MAC Address:

DHCP Client:

Select Turn MAC Filtering O, allow MAC addresses listed below, or deny MAC addresses listed below from the drop-down menu.

Enter the MAC address you would like to lter. To nd the MAC address on a computer, please refer to the Networking Basics section in this manual.

Select a DHCP client from the drop-down menu and click << to copy that MAC Address.

46D-Link DIR-601 User Manual

Page 51

Section 3 - Conguration

Access Control

The Access Control section allows you to control access in and out of your network. Use this feature as Parental Controls to only grant access to approved sites, limit web access based on time or dates, and/or block access from applications like P2P utilities or games.

Add Policy:

Check the Enable Access Control check box and click the Add Policy button to start the Access Control Wizard.

Access Control Wizard

Click Next to continue with the wizard.

47D-Link DIR-601 User Manual

Page 52

Section 3 - Conguration

Enter a name for the policy and then click Next to continue.

Select a schedule (I.E. Always) from the drop-down menu and then click Next to continue.

Enter the following information and then click Next to continue.

• Address Type - Select IP address, MAC address, or Other Machines.

• IP Address - Enter the IP address of the computer you want to apply the rule to.

48D-Link DIR-601 User Manual

Page 53

Section 3 - Conguration

Select the ltering method and then click Next to continue.

Enter the rule:

Enable - Check to enable the rule. Name - Enter a name for your rule. Dest IP Start - Enter the starting IP address. Dest IP End - Enter the ending IP address. Protocol - Select the protocol. Dest Port Start - Enter the starting port number. Dest Port End - Enter the ending port number.

To enable web logging, click Enable.

Click Save to save the access control rule.

49D-Link DIR-601 User Manual

Page 54

Section 3 - Conguration

Website Filters

Website Filters are used to allow you to set up a list of allowed Web sites that can be used by multiple users through the network. To use this feature select to Allow or Deny, enter the domain or website and click Add, and then click Save Settings. You must also select Apply Web Filter under the Access Control section (page 46).

Congure

Website Filter

Below:

Clear the list

below:

Website URL/

Domain:

Select Deny or Allow computers access to only these sites.

Click to delete all entries in the list.

Enter the keywords or URLs that you want to allow or deny.

50D-Link DIR-601 User Manual

Page 55

Section 3 - Conguration

Inbound Filters

The Inbound Filter option is an advanced method of controlling data received from the Internet. With this feature you can congure inbound data ltering rules that control data based on an IP address range. Inbound Filters can be used with Virtual Server, Port Forwarding, or Remote Administration features.

Name:

Action:

Enable:

Source IP Start:

Source IP End:

Save:

Inbound Filter

Rules List:

Enter a name for the inbound lter rule.

Select Allow or Deny.

Check to enable rule.

Enter the starting IP address. Enter 0.0.0.0 if you do not want to specify an IP range.

Enter the ending IP address. Enter 255.255.255.255 if you do not want to specify and IP range.

Click the Save button to apply your settings. You must click Save Settings at the top to save the settings.

This section will list any rules that are created. You may click the Edit icon to change the settings or enable/disable the rule, or click the Delete icon to remove the rule.

51D-Link DIR-601 User Manual

Page 56

Section 3 - Conguration

Firewall Settings

A rewall protects your network from the outside world. The D-Link DIR-601 oers a rewall type functionality. The SPI feature helps prevent cyber attacks. Sometimes you may want a computer exposed to the outside world for certain types of applications. If you choose to expose a computer, you can enable DMZ. DMZ is short for Demilitarized Zone. This option will expose the chosen computer completely to the outside world.

Enable SPI:

Enable Anti-Spoof

Checking:

Enable DMZ Host:

IP Address:

SPI (Stateful Packet Inspection, also known as dynamic packet ltering) helps to prevent cyber attacks by tracking more state per session. It validates that the trac passing through the session conforms to the protocol.

Enable this option to provide protection from certain kinds of “spoong” attacks.

If an application has trouble working from behind the router, you can expose one computer to the Internet and run the application on that computer.

Note: Placing a computer in the DMZ may expose that computer to a variety of security risks. Use of this option is only recommended as a last resort.

Specify the IP address of the computer on the LAN that you want to have unrestricted Internet communication. If this computer obtains its IP address automatically using DHCP, be sure to make a static reservation on the System > Network Settings page so that the IP address of the DMZ machine does not change.

52D-Link DIR-601 User Manual

Page 57

Section 3 - Conguration

Routing

The Routing option is an advanced method of customizing specic routes of data through your network.

Destination IP:

Netmask:

Gateway:

Metric:

Interface:

Enter the IP address of packets that will take this route.

Enter the netmask of the route, please note that the octets must match your destination IP address.

Enter your next hop gateway to be taken if this route is used.

The route metric is a value from 1 to 16 that indicates the cost of using this route. A value 1 is the lowest cost and 15 is the highest cost.

Select the interface that the IP packet must use to transit out of the router when this route is used.

53D-Link DIR-601 User Manual

Page 58

Section 3 - Conguration

Advanced Wireless Settings

Transmit

Power:

Beacon Period:

RTS Threshold:

Fragmentation

Threshold:

DTIM Interval:

Set the transmit power of the antennas.

Beacons are packets sent by an Access Point to synchronize a wireless network. Specify a value. 100 is the default setting and is recommended.

This value should remain at its default setting of 2432. If inconsistent data flow is a problem, only a minor modication should be made.

The fragmentation threshold, which is specied in bytes, determines whether packets will be fragmented. Packets exceeding the 2346 byte setting will be fragmented before transmission. 2346 is the default setting.

(Delivery Traffic Indication Message) 3 is the default setting. A DTIM is a countdown informing clients of the next window for listening to broadcast and multicast messages.

WLAN

Partition:

WMM Enable:

Short GI:

This feature enables client isolation. If enabling, all clients will not be able to view or access each other’s information or within the network.

WMM is QoS for your wireless network. This will improve the quality of video and voice applications for your wireless clients.

Check this box to reduce the guard interval time therefore increasing the data capacity. However, it’s less reliable and may create higher data loss.

54D-Link DIR-601 User Manual

Page 59

Section 3 - Conguration

Advanced Network Settings

UPnP Settings:

WAN Ping:

WAN Port Speed:

Multicast

Streams:

To use the Universal Plug and Play (UPnP™) feature click on Enable UPnP. UPNP provides compatibility with networking equipment, software and peripherals.

Unchecking the box will not allow the DIR-601 to respond to pings. Blocking the Ping may provide some extra security from hackers. Check the box to allow the Internet port to be “pinged”.

You may set the port speed of the Internet port to 10Mbps, 100Mbps, or Auto. Some older cable or DSL modems may require you to set the port speed to 10Mbps.

Check the box to allow multicast traffic to pass through the router from the Internet.

55D-Link DIR-601 User Manual

Page 60

Section 3 - Conguration

Administrator Settings

This page will allow you to change the Administrator and User passwords. You can also enable Remote Management. There are two accounts that can access the management interface through the web browser. The accounts are admin and user. Admin has read/write access while user has read-only access. User can only view the settings but cannot make any changes. Only the admin account has the ability to change both admin and user account passwords.

Admin Password:

User Password:

Gateway Name:

Enable Graphical

Authentication:

Remote

Management:

Enter a new password for the Administrator Login Name. The administrator can make changes to the settings.

Enter the new password for the User login. If you login as the User, you can only see the settings, but cannot change them.

Enter a name for the DIR-601 router.

Enables a challenge-response test to require users to type letters or numbers from a distorted image displayed on the screen to prevent online hackers and unauthorized users from gaining access to your router’s network settings.

Remote management allows the DIR-601 to be congured from the Internet by a web browser. A username and password is still required to access the Web-Management interface. In general, only a member of your network can browse the built-in web pages to perform Administrator tasks. This feature enables you to perform Administrator tasks from the remote (Internet) host.

Remote Admin

Port:

Remote Admin

Inbound Filter:

The port number used to access the DIR-601. Example: http://x.x.x.x:8080 whereas x.x.x.x is the Internet IP address of the DIR-601 and 8080 is the port used for the Web Management interface.

This section will list any rules that are created. You may click the Edit icon to change the settings or enable/disable the rule, or click the Delete icon to remove the rule.

56D-Link DIR-601 User Manual

Page 61

Section 3 - Conguration

Reserve:

The Reserve option converts this dynamic IP allocation into a DHCP Reservation and adds the corresponding entry to the DHCP Reservations List.

57D-Link DIR-601 User Manual

Page 62

Section 3 - Conguration

Time Settings

The Time Conguration option allows you to congure, update, and maintain the correct time on the internal system clock. From this section you can set the time zone that you are in and set the Time Server. Daylight Saving can also be congured to automatically adjust the time when needed.

Time Zone:

Daylight

Saving:

Enable NTP

Server:

NTP Server

Used:

Manual:

Select the Time Zone from the drop-down menu.

To select Daylight Saving time manually, select enabled or disabled, and enter a start date and an end date for daylight saving time.

NTP is short for Network Time Protocol. NTP synchronizes computer clock times in a network of computers. Check this box to use a NTP server. This will only connect to a server on the Internet, not a local server.

Enter the NTP server or select one from the dropdown menu.

To manually input the time, enter the values in these elds for the Year, Month, Day, Hour, Minute, and Second and then click Set Time. You can also click Copy Your Computer’s Time Settings.

58D-Link DIR-601 User Manual

Page 63

Section 3 - Conguration

SysLog

The Broadband Router keeps a running log of events and activities occurring on the Router. You may send these logs to a SysLog server on your network.

Enable Logging

to SysLog

Server:

SysLog Server

IP Address:

Check this box to send the router logs to a SysLog Server.

The address of the SysLog server that will be used to send the logs. You may also select your computer from the drop-down menu (only if receiving an IP address from the router via DHCP).

59D-Link DIR-601 User Manual

Page 64

Section 3 - Conguration

E-mail Settings

The Email feature can be used to send the system log les, router alert messages, and rmware update notication to your e-mail address.

Enable Email

Notication:

From Email

Address:

To Email

Address:

SMTP Server

Address:

Enable

Authentication:

Account Name:

Password:

When this option is enabled, router activity logs are e-mailed to a designated e-mail address.

This e-mail address will appear as the sender when you receive a log le or rmware upgrade notication via e-mail.

Enter the e-mail address where you want the e-mail sent.

Enter the SMTP server address for sending e-mail. If your SMTP server requires authentication, select this option.

Chec k t his box if you r S MTP serve r requi res authentication.

Enter your account for sending e-mail.

Enter the password associated with the account. Re-type the password associated with the account.

On Log Full:

On Schedule:

Schedule:

When this option is selected, logs will be sent via e-mail when the log is full.

Selecting this option will send the logs via e-mail according to schedule.

This option is enabled when On Schedule is selected. You can select a schedule from the list of dened schedules. To create a schedule, go to Tools > Schedules.

60D-Link DIR-601 User Manual

Page 65

Section 3 - Conguration

System Settings

Save Settings

to Local Hard

Drive:

Load Settings

from Local

Hard Drive:

Restore to

Factory Default

Settings:

Use this option to save the current router conguration settings to a le on the hard disk of the computer you are using. First, click the Save button. You will then see a le dialog, where you can select a location and le name for the settings.

Use this option to load previously saved router conguration settings. First, use the Browse control to find a previously save file of configuration settings. Then, click the Load button to transfer those settings to the router.

This option will restore all conguration settings back to the settings that were in effect at the time the router was shipped from the factory. Any settings that have not been saved will be lost, including any rules that you have created. If you want to save the current router conguration settings, use the Save button above.

Reboot Device:

Click to reboot the router.

61D-Link DIR-601 User Manual

Page 66

Section 3 - Conguration

Update Firmware

You can upgrade the rmware of the Router here. Make sure the rmware you want to use is on the local hard drive of the computer. Click on Browse to locate the rmware le to be used for the update. Please check the D-Link support site for rmware updates at http://support.dlink.com. You can download rmware upgrades to your hard drive from the D-Link support site.

Check Now:

Firmware

Upgrade:

Click on Check Now to find out if there is an updated firmware; if so, download the new rmware to your hard drive.

After you have downloaded the new rmware, click Browse to locate the rmware update on your hard drive. Click Upload to complete the rmware upgrade.

62D-Link DIR-601 User Manual

Page 67

Section 3 - Conguration

DDNS

The DDNS feature allows you to host a server (Web, FTP, Game Server, etc…) using a domain name that you have purchased (www.whateveryournameis. com) with your dynamically assigned IP address. Most broadband Internet Service Providers assign dynamic (changing) IP addresses. Using a DDNS service provider, your friends can enter in your domain name to connect to your server no matter what your IP address is.

Enable DDNS:

Server

Address:

Host Name:

Username or

Key:

Password or

Key:

Timeout:

Status:

Check to enable DDNS.

Choose your DDNS provider from the drop down menu.

Enter the Host Name that you registered with your DDNS service provider.

Enter the Username for your DDNS account.

Enter the Password for your DDNS account.

Enter a time (in hours).

Displays the current connection status to your DDNS server.

63D-Link DIR-601 User Manual

Page 68

Section 3 - Conguration

System Check

Ping Test:

Ping Results:

The Ping Test is used to send Ping packets to test if a computer is on the Internet. Enter the IP Address that you wish to Ping, and click Ping.

The results of your ping attempts will be displayed here.

64D-Link DIR-601 User Manual

Page 69

Section 3 - Conguration

Schedules

Name:

Days:

Time:

Save:

Schedule Rules

List:

Enter a name for your new schedule.

Select a day, a range of days, or All Week to include every day.

Check All Day - 24hrs or enter a start and end time for your schedule.

Click Save to save your schedule. You must click Save Settings at the top for your schedules to go into eect.

The list of schedules will be listed here. Click the Edit icon to make changes or click the Delete icon to remove the schedule.

65D-Link DIR-601 User Manual

Page 70

Section 3 - Conguration

Device Information

This page displays the current information for the DIR-601. It will display the LAN, WAN (Internet), and Wireless information.

If your Internet connection is set up for a Dynamic IP address then a Release button and a Renew button will be displayed. Use Release to disconnect from your ISP and use Renew to connect to your ISP.

If your Internet connection is set up for PPPoE, a Connect button and a Disconnect button will be displayed. Use Disconnect to drop the PPPoE connection and use Connect to establish the PPPoE connection.

See the following page for more information.

66D-Link DIR-601 User Manual

Page 71

Section 3 - Conguration

General:

WAN:

LAN:

Wireless LAN:

LAN

Computers:

IGMP Multicast

Memberships:

Displays the router’s time and rmware version.

Displays the MAC address and the public IP settings for the router.

Displays the MAC address and the private (local) IP settings for the router.

Displays the wireless MAC address and your wireless settings such as SSID and Channel.

Displays computers and devices that are connected to the router via Ethernet and that are receiving an IP address assigned by the router (DHCP).

Displays the Multicast Group IP Address.

67D-Link DIR-601 User Manual

Page 72

Section 3 - Conguration

Log

The router automatically logs (records) events of possible interest in it’s internal memory. If there isn’t enough internal memory for all events, logs of older events are deleted but logs of the latest events are retained. The Logs option allows you to view the router logs. You can dene what types of events you want to view and the level of the events to view. This router also has external Syslog Server support so you can send the log les to a computer on your network that is running a Syslog utility.

Log Options:

Apply Log

Settings:

Refresh:

Clear:

Email Now:

Save Log:

You can select the types of messages that you want to display from the log.

Will lter the log results so that only the selected options appear.

Updates the log details on the screen so it displays any recent activity.

Clears all of the log contents.

This option will send a copy of the router log to the e-mail address congured in the Tools > Email Settings screen.

This option will save the router to a log le on your computer.

68D-Link DIR-601 User Manual

Page 73

Section 3 - Conguration

Stats

The screen below displays the Trac Statistics. Here you can view the amount of packets that pass through the DIR-601 on both the Internet and the LAN ports. The trac counter will reset if the device is rebooted.

69D-Link DIR-601 User Manual

Page 74

Section 3 - Conguration

Internet Sessions

The Internet Sessions page displays full details of active Internet sessions through your router. An Internet session is a conversation between a program or application on a LAN-side computer and a program or application on a WAN-side computer.

Local:

NAT:

Internet:

Protocol:

State:

The IP address and, where appropriate, port number of the local application.

The port number of the LAN-side application as viewed by the WAN-side application.

The IP address and, where appropriate, port number of the application on the Internet.

The co mmunications protocol used for the conversation.

State for sessions that use the TCP protocol:

NO: None -- This entry is used as a placeholder for a future connection that may occur. SS: SYN Sent -- One of the systems is attempting to start a connection. EST: Established -- the connection is passing data. FW: FIN Wait -- The client system has requested that the connection be stopped. CW: Close Wait -- The server system has requested that the connection be stopped. TW: Time Wait -- Waiting for a short time while a connection that was in FIN Wait is fully closed. LA: Last ACK -- Waiting for a short time while a connection that was in Close Wait is fully closed.

CL: Closed -- The connection is no longer active but the session is being tracked in case there are any retransmitted packets still pending.

Dir:

Priority:

The direction of initiation of the conversation:

Out - Initiated from LAN to WAN. In - Initiated from WAN to LAN.

The preference given to outbound packets of this conversation by the QoS Engine logic. Smaller numbers represent higher priority.

70D-Link DIR-601 User Manual

Page 75

Section 3 - Conguration

Time Out: The number of seconds of idle time until the router considers the session terminated. The initial value of Time Out depends on the

type and state of the connection.

300 seconds - UDP connections.

240 seconds - Reset or closed TCP connections. The connection does not close instantly so that lingering packets can pass or the connection can be re-established.

7800 seconds - Established or closing TCP connections.

71D-Link DIR-601 User Manual

Page 76

Section 3 - Conguration

Routing Table

This page displays the routing details congured for your router.

72D-Link DIR-601 User Manual

Page 77

Section 3 - Conguration

Wireless

The wireless client table displays a list of current connected wireless clients. This table also displays the connection time and MAC address of the connected wireless clients.

73D-Link DIR-601 User Manual

Page 78

Section 3 - Conguration

Support

74D-Link DIR-601 User Manual

Page 79

Section 4 - Security

Wireless Security

This section will show you the dierent levels of security you can use to protect your data from intruders. The DIR-601 oers the following types of security:

• WPA2 (Wi-Fi Protected Access 2) • WPA2-PSK(Pre-Shared Key)

• WPA (Wi-Fi Protected Access) • WPA-PSK (Pre-Shared Key)

What is WPA?

WPA, or Wi-Fi Protected Access, is a Wi-Fi standard that was designed to improve the security features of WEP (Wired Equivalent Privacy).

The 2 major improvements over WEP:

• Improved data encryption through the Temporal Key Integrity Protocol (TKIP). TKIP scrambles the keys using a hashing algorithm and, by adding an integrity-checking feature, ensures that the keys haven’t been tampered with. WPA2 is based on 802.11i and uses Advanced Encryption Standard (AES) instead of TKIP.

• User authentication, which is generally missing in WEP, through the extensible authentication protocol (EAP). WEP regulates access to a wireless network based on a computer’s hardware-specic MAC address, which is relatively simple to be snied out and stolen. EAP is built on a more secure public-key encryption system to ensure that only authorized network users can access the network.

WPA-PSK/WPA2-PSK uses a passphrase or key to authenticate your wireless connection. The key is an alpha-numeric password between 8 and 63 characters long. The password can include symbols (!?*&_) and spaces. This key must be the exact same key entered on your wireless router or access point.

WPA/WPA2 incorporates user authentication through the Extensible Authentication Protocol (EAP). EAP is built on a more secure public key encryption system to ensure that only authorized network users can access the network.

75D-Link DIR-601 User Manual

Page 80

Section 4 - Security

Wireless Connection Setup Wizard

To run the security wizard, browse to the Setup page and then click the Wireless Connection Setup Wizard button.

Click Next to continue.

76D-Link DIR-601 User Manual

Page 81

Section 4 - Security

Enter the SSID (Service Set Identier). The SSID is the name of your wireless network. Create a name using up to 32 characters. The SSID is casesensitive.

Select Automatically assign a network key to have the router create a security key for you or select Manually assign a network key if you would like to create your own security key or passphrase.

If you want to use WPA, check the Use WPA encryption instead of WEP box.

If you select Manually assign a network key, enter your encryption key in the box and click Next to continue. You will need to enter this key on your wireless clients to connect to the router.

If you selected Automatically, the following screen will show you your security key to enter on your wireless clients.

Click Save to nish the Security Wizard.

77D-Link DIR-601 User Manual

Page 82

Section 4 - Security

Add Wireless Device with WPS Wizard

From the Setup > Wireless Settings screen, click Add Wireless Device with WPS.

Select Auto to add a wireless client using WPS (Wi-Fi Protected Setup). Once you select Auto and click Connect, you will have a 120 second time limit to apply the settings to your wireless client(s) and successfully establish a connection.

If you select Manual, a settings summary screen will appear. Write down the security key and enter this on your wireless clients.

PIN: Select this option to use PIN method. In order to use this method you must know the wireless client’s 8 digit PIN and click Connect.

PBC: Select this option to use PBC (Push Button) method to add a wireless client. Click Connect.

78D-Link DIR-601 User Manual

Page 83

Section 4 - Security

Congure WPA-Personal (PSK)

It is recommended to enable encryption on your wireless router before your wireless network adapters. Please establish wireless connectivity before enabling encryption. Your wireless signal may degrade when enabling encryption due to the added overhead.

1. Log into the web-based conguration by opening a web browser and entering the IP address of the router (192.168.0.1). Click on Setup and then click Wireless Settings on the left side.

2. Select the Manual Wireless Connection Setup button.

3. Next to Security Mode, select WPA-Personal.

4. Next to WPA Mode, select Auto, WPA2 Only, or WPA Only. Use Auto if you have wireless clients using both WPA and WPA2.

5. Next to Cypher Type, select TKIP and AES, TKIP, or AES. If you have wireless clients that use both types, use TKIP and AES.

6. Next to Group Key Update Interval, enter the amount of time before the group key used for broadcast and multicast data is changed (3600 is default).

7. Next to Pre-Shared Key, enter a key (passphrase). The key is entered as a pass-phrase in ASCII format at both ends of the wireless connection. The pass-phrase must be between 8-63 characters.

8. Click Save Settings to save your settings. If you are conguring the router with a wireless adapter, you will lose connectivity until you enable WPA-PSK on your adapter and enter the same passphrase as you did on the router.

79D-Link DIR-601 User Manual

Page 84

Section 4 - Security

Congure WPA-Enterprise (RADIUS)

1. Log into the web-based conguration by opening a web browser and entering the IP address of the router (192.168.0.1). Click on Setup and then click Wireless Settings on the left side.

2. Select the Manual Wireless Connection Setup button.

3. Next to Security Mode, select WPA-Enterprise.

4. Next to WPA Mode, select Auto, WPA2 Only, or WPA Only. Use Auto if you have wireless clients using both WPA and WPA2.

5. Next to Cypher Type, select TKIP and AES, TKIP, or AES. If you have wireless clients that use both types, use TKIP and AES.

6. Next to Group Key Update Interval, enter the amount of time before the group key used for broadcast and multicast data is changed (3600 is default).

7. Next to Authentication Timeout, enter the amount of time before a client is required to re-authenticate (60 minutes is default).

8. Next to RADIUS Server IP Address enter the IP Address of your RADIUS server.

9. Next to RADIUS Server Port, enter the port you are using with your RADIUS server. 1812 is the default port.

10. Next to RADIUS Server Shared Secret, enter the security key

80D-Link DIR-601 User Manual

Page 85

Section 4 - Security

11. If the MAC Address Authentication box is selected then the user will need

to connect from the same computer whenever logging into the wireless network.

12. Click Advanced to enter settings for a secondary RADIUS Server.

13. Click Apply Settings to save your settings.

81D-Link DIR-601 User Manual

Page 86

Section 5 - Connecting to a Wireless Network

Connect to a Wireless Network

Using Windows® 7

It is recommended to enable wireless security (WPA/WPA2) on your wireless router or access point before conguring your wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.

1. Click on the wireless icon in your system tray (lower-right corner).

2. The utility will display any available wireless networks in your area.

82D-Link DIR-601 User Manual

Page 87

Section 5 - Connecting to a Wireless Network

3. Highlight the wireless network (SSID) you would like to connect to and click

the Connect button.

If you get a good signal but cannot access the Internet, check your TCP/IP

settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information.

4. The following window appears while your computer tries to connect to the

router.

83D-Link DIR-601 User Manual

Page 88

Section 5 - Connecting to a Wireless Network

5. Enter the same security key or passphrase that is on your router and click

Ok.

It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router.

84D-Link DIR-601 User Manual

Page 89

Section 5 - Connecting to a Wireless Network

Using Windows Vista

Windows Vista® users may use the built-in wireless utility. If you are using another company’s utility or Windows® 2000, please refer to the user manual of your wireless adapter for help with connecting to a wireless network. Most utilities will have a “site survey” option similar to the Windows Vista® utility as seen below.

If you receive the Wireless Networks Detected bubble, click on the center of the bubble to access the utility.

Right-click on the wireless computer icon in your system tray (lower-right corner next to the time). Select Connect to a network.

The utility will display any available wireless networks in your area. Click on a network (displayed using the SSID) and click the Connect button.

If you get a good signal but cannot access the Internet, check you TCP/IP settings for your wireless adapter. Refer to the Networking Basics section in this manual

for more information.

85D-Link DIR-601 User Manual

Page 90

Section 5 - Connecting to a Wireless Network

Congure WPA/WPA2

1. Open the Windows Vista® Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower right corner of screen). Select

Connect to a network.

2. Highlight the wireless network (SSID) you would like to connect to

and click Connect.

86D-Link DIR-601 User Manual

Page 91

Section 5 - Connecting to a Wireless Network

3. Enter the same security key or passphrase that is on your router and click Connect.

87D-Link DIR-601 User Manual

Page 92

Section 5 - Connecting to a Wireless Network

Connect Using WCN 2.0

The router supports Wi-Fi protection, referred to as WCN 2.0 in Windows Vista®. The following instructions for setting this up depends on whether you are using Windows Vista® to congure the router or third party software.

When you rst set up the router, Wi-Fi protection is disabled and uncongured. To enjoy the benets of Wi-Fi protection, the router must be both enabled and congured. There are three basic methods to accomplish this: use Windows Vista’s built-in support for WCN 2.0, use software provided by a third party, or manually congure.

If you are running Windows Vista®, log into the router and click the Enable checkbox in the Basic > Wireless section. Use the Current PIN that is displayed on the Advanced > Wi-Fi Protected Setup section or choose to click the Generate New PIN button or Reset PIN to Default button.

If you are using third party software to set up Wi-Fi Protection, carefully follow the directions. When you are nished, proceed to the next section to set up the newly-congured router.

88D-Link DIR-601 User Manual

Page 93

Section 5 - Connecting to a Wireless Network

Using Windows® XP

Windows® XP users may use the built-in wireless utility (Zero Conguration Utility). The following instructions are for Service Pack 2 users. If you are using another company’s utility or Windows® 2000, please refer to the user manual of your wireless adapter for help with connecting to a wireless network. Most utilities will have a “site survey” option similar to the Windows® XP utility as seen below.

If you receive the Wireless Networks Detected bubble, click on the center of the bubble to access the utility.

Right-click on the wireless computer icon in your system tray (lower-right corner next to the time). Select View Available Wireless Networks.

The utility will display any available wireless networks in your area. Click on a network (displayed using the SSID) and click the Connect button.

If you get a good signal but cannot access the Internet, check you TCP/IP settings for your wireless adapter. Refer to the Networking Basics section in this manual

for more information.

89D-Link DIR-601 User Manual

Page 94

Section 5 - Connecting to a Wireless Network

Congure WPA-PSK

It is recommended to enable WEP on your wireless router or access point before conguring your wireless adapter. If you are joining an existing network, you will need to know the WEP key being used.

1. Open the Windows® XP Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower-right corner of screen). Select

View Available Wireless Networks.

2. Highlight the wireless network (SSID) you would like to connect to and

click Connect.

90D-Link DIR-601 User Manual

Page 95

Section 5 - Connecting to a Wireless Network

3. The Wireless Network Connection box will appear. Enter the WPA-PSK passphrase and click Connect.

It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WPA-PSK settings are correct. The WPA-PSK passphrase must be exactly the same as on the wireless router.

91D-Link DIR-601 User Manual

Page 96

Section 6 - Troubleshooting

Troubleshooting

This chapter provides solutions to problems that can occur during the installation and operation of the DIR-601. Read the following descriptions if you are having problems. (The examples below are illustrated in Windows® XP. If you have a dierent operating system, the screen shots on your computer will look similar to the following examples.)

1. Why can’t I access the web-based conguration utility?

When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website on the Internet or have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility.

• Make sure you have an updated Java-enabled web browser. We recommend the following:

• Microsoft Internet Explorer® 6.0 and higher

• Mozilla Firefox 3.0 and higher

• Google™ Chrome 2.0 and higher

• Apple Safari 3.0 and higher

• Verify physical connectivity by checking for solid link lights on the device. If you do not get a solid link light, try using a dierent cable or connect

to a dierent port on the device if possible. If the computer is turned o, the link light may not be on.

• Disable any Internet security software running on the computer. Software rewalls such as Zone Alarm, Black Ice, Sygate, Norton Personal Firewall,

and Windows® XP rewall may block access to the conguration pages. Check the help les included with your rewall software for more information on disabling or conguring it.

92D-Link DIR-601 User Manual

Page 97

Section 6 - Troubleshooting

• Congure your Internet settings:

• Go to Start > Settings > Control Panel. Double-click the Internet Options Icon. From the Security tab, click the button to restore the settings to their defaults.

• Click the Connection tab and set the dial-up option to Never Dial a Connection. Click the LAN Settings button. Make sure nothing is checked. Click OK.

• Go to the Advanced tab and click the button to restore these settings to their defaults. Click OK three times.

• Close your web browser (if open) and open it.

• Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your the web management.

• If you still cannot access the conguration, unplug the power to the router for 10 seconds and plug back in. Wait about 30 seconds and try accessing the conguration. If you have multiple computers, try connecting using a dierent computer.

2. What can I do if I forgot my password?

If you forgot your password, you must reset your router. Unfortunately this process will change all your settings back to the factory defaults.

To reset the router, locate the reset button (hole) on the rear panel of the unit. With the router powered on, use a paperclip to hold the button down for 10 seconds. Release the button and the router will go through its reboot process. Wait about 30 seconds to access the router. The default IP address is 192.168.0.1. When logging in, the username is admin and leave the password box empty.

93D-Link DIR-601 User Manual

Page 98

Section 6 - Troubleshooting

3. Why can’t I connect to certain sites or send and receive e-mails when connecting through my router?

If you are having a problem sending or receiving e-mail, or connecting to secure sites such as eBay, banking sites, and Hotmail, we suggest lowering the MTU in increments of ten (Ex. 1492, 1482, 1472, etc).

Note: AOL DSL+ users must use MTU of 1400.

To nd the proper MTU Size, you’ll have to do a special ping of the destination you’re trying to go to. A destination could be another computer, or a URL.

• Click on Start and then click Run.

• Windows® 95, 98, and Me users type in command (Windows® NT, 2000, and XP users type in cmd) and press Enter (or click OK).

• Once the window opens, you’ll need to do a special ping. Use the following syntax:

ping [url] [-f] [-l] [MTU value]

Example: ping yahoo.com -f -l 1472

94D-Link DIR-601 User Manual

Page 99

Section 6 - Troubleshooting

You should start at 1472 and work your way down by 10 each time. Once you get a reply, go up by 2 until you get a fragmented packet. Take that value and add 28 to the value to account for the various TCP/IP headers. For example, lets say that 1452 was the proper value, the actual MTU size would be 1480, which is the optimum for the network we’re working with (1452+28=1480).

Once you nd your MTU, you can now congure your router with the proper MTU size.

To change the MTU rate on your router follow the steps below:

• Open your browser, enter the IP address of your router (192.168.0.1) and click OK.

• Enter your username (admin) and password (blank by default). Click OK to enter the web conguration page for the device.

• Click on Setup and then click Manual Congure.

• To change the MTU enter the number in the MTU eld and click Save Settings to save your settings.

• Test your e-mail. If changing the MTU does not resolve the problem, continue changing the MTU in increments of ten.

95D-Link DIR-601 User Manual

Page 100

Appendix A - Wireless Basics

Wireless Basics

D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking delivers.

A wireless local area network (WLAN) is a cellular computer network that transmits and receives data with radio signals instead of wires. Wireless LANs are used increasingly in both home and oce environments, and public areas such as airports, coee shops and universities. Innovative ways to utilize WLAN technology are helping people to work and communicate more eciently. Increased mobility and the absence of cabling and other xed infrastructure have proven to be benecial for many users.

Wireless users can use the same applications they use on a wired network. Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards.

Under many circumstances, it may be desirable for mobile network devices to link to a conventional Ethernet LAN in order to use servers, printers or an Internet connection supplied through the wired LAN. A Wireless Router is a device used to provide this link.

96D-Link DIR-601 User Manual

D-Link DIR-601 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

Manual Revisions

Trademarks

Product Overview

Package Contents

System Requirements

Features

Hardware Overview

Connections

LEDs

Installation

Before you Begin

Wireless Installation Considerations

Network Diagram

Desktop Computer

Wireless Laptop

DIR-601 Router

Internet

Connect to Cable/DSL/Satellite Modem

Connect to Another Router

Getting Started

Quick Setup Wizard

Internet Connection Setup Wizard

Dynamic (Cable)

Dynamic IP Address (DHCP)

PPPoE (DSL)

PPTP

L2TP

Static IP Address

Wireless Settings

Manual Wireless Network Setup

Network Settings

DHCP Server Settings

DHCP Reservation

Virtual Server

Port Forwarding

Application Rules

QoS Engine

Network Filters

Access Control

Access Control Wizard

Website Filters

Inbound Filters

Firewall Settings

Routing

Advanced Wireless Settings

Advanced Network Settings

Administrator Settings

Time Settings

SysLog

E-mail Settings

System Settings

Update Firmware

DDNS

System Check

Schedules

Device Information

Stats

Internet Sessions

Routing Table

Wireless

Support

Wireless Security

What is WPA?

Wireless Connection Setup Wizard

Add Wireless Device with WPS Wizard

Connect to a Wireless Network

Using Windows® 7

Connect Using WCN 2.0

Using Windows® XP

Troubleshooting

Wireless Basics
