INSPIRE 1
Quick Start Guide
V1.0
INSPIRE 1 Remote Controller
The Inspire 1 is a professional aerial filmmaking and photography platform that is ready to fly right out of the box. Featuring
an onboard camera equipped with a 20mm lens and 3-axis stabilized gimbal, it shoots sharp 12mp stills and stable video at
up to 4K. Its retractable landing gear pulls up out of view, giving the camera an unobstructed 360 degree view of the world
below.
An advanced flight controller makes the Inspire 1 stable, safe and easy to fly indoors or out. The brand new Vision
Positioning System gives it the power to hover in position at low altitudes even without GPS. Like all DJI flight controllers,
it is also able to return home if remote controller signal is lost or if the low battery warning is triggered.
The Inspire 1 boasts a maximum flight speed 22m/s* and a maximum flight time of 18 minutes* using one fully charged
4500mAh Intelligent Flight Battery.
7
6
5
6
7
6
5
7
4
9
10
11
15
1
3
12
13
2
14
Travel Mode
1. Gimbal and Camera
Flight Mode
Landing Gear Up Landing Gear Down
Landing Mode
* Please note that maximum flight speed and maximum run time were tested in a lab environment. These statistics are for reference only, as
conditions in your area may vary.
2. Camera Micro-SD Card Slot
3. Vision Positioning System
4. Transformation Mechanism
5. Front LEDs
6. Motors
7. Propellers
8. Rear LEDs
9. Intelligent Flight Battery
10. Power Button
11. Battery Level Indicators
12. Aircraft Status Indicator
13. Aircraft Micro-USB Port
14. Camera Micro-USB Port
15. Gimbal Lock
8
The maximum transmission distance of the Inspire 1 remote controller is 2km*. The remote controller also allows you to
control the landing gear or activate Return to Home with a tap. Other buttons allow instant photo capture, video recording,
picture review and gimbal control.
A DJI Lightbridge-based HD video downlink is built-in, letting you see what your camera sees on your mobile device in
real time HD. The app also allows you to change camera settings and activate Master/Slave mode so that one person can
fly while other controls the gimbal independently. The master and slave controllers communicate using a 5.8Ghz wireless
signal, and have a communication range with each other of up to 50 meters.The controller’s LiPo battery has a maximum
run time of approximately four hours and can be charged by plugging directly into the controller.
1. Power Button
2. Transformation Switch
3. Return to Home (RTH) Button
4. Control Sticks
5. Status LED
6. Battery Level LEDs
7. Power Port
8. Mobile Device Holder
9. Antennas
10. Handle Bar
8
Folded
11. Gimbal Dial
12. Camera Settings Dial
13. Video Recording Button
14. Flight Mode Switch
15. Shutter Button
16. Playback Button
17. Mini-HDMI Port
18. Micro-USB Port
19. CAN-Bus Port
20. USB Port
21. Back Buttons (Reserved)
21 21
11
13
17 18 19
14
20
9
9
4
1
5
2
3
4
10
6
7
12
1615
Connect to the
mobile device
* Please note that the max transmission distance were tested in a lab environment. This statistic is for reference only, as conditions in your
area may vary.
