Owner’s Manual
WARRANTY
We at DigiTech® are very proud of our products and back-up each one we sell with the following warranty:
1.Please register online at digitech.com within ten days of purchase to validate this warranty.This warranty is valid only in the United States.
2.DigiTech warrants this product, when purchased new from an authorized U.S. DigiTech dealer and used solely within the U.S., to be free from defects in materials and workmanship under normal use and service.This warranty is valid to the original purchaser only and is non-transferable.
3.DigiTech liability under this warranty is limited to repairing or replacing defective materials that show evidence of defect, provided the product is returned to DigiTech WITH RETURN AUTHORIZATION, where all parts and labor will be covered up to a period of one year (this warranty is extended to a period of six years when the product has been properly registered through our website).A Return Authorization number may be obtained by contacting DigiTech.The company shall not be liable for any consequential damage as a result of the product’s use in any circuit or assembly.
4.Proof-of-purchase is considered to be the responsibility of the consumer.A copy of the original purchase receipt must be provided for any warranty service.
5.DigiTech reserves the right to make changes in design, or make additions to, or improvements upon this product without incurring any obligation to install the same on products previously manufactured.
6.The consumer forfeits the benefits of this warranty if the product’s main assembly is opened and tampered with by anyone other than a certified DigiTech technician or, if the product is used with AC voltages outside of the range suggested by the manufacturer.
7.The foregoing is in lieu of all other warranties, expressed or implied, and DigiTech neither assumes nor authorizes any person to assume any obligation or liability in connection with the sale of this product. In no event shall DigiTech or its dealers be liable for special or consequential damages or from any delay in the performance of this warranty due to causes beyond their control.
NOTE: The information contained in this manual is subject to change at any time without notification. Some information contained in this manual may also be inaccurate due to undocumented changes in the product since this version of the manual was completed. The information contained in this version of the owner’s manual supersedes all previous versions.
TECHNICAL SUPPORT & SERVICE
If you require technical support, contact DigiTech Technical Support. Be prepared to accurately describe the problem. Know the serial number of your device – this is printed on a sticker attached to the chassis. If you have not already taken the time to register your product, please do so now at digitech.com.
Before you return a product to the factory for service, we recommend you refer to this manual. Make sure you have correctly followed installation steps and operating procedures. For further technical assistance or service, please contact our Technical Support Department at (801) 566-8800 or visit digitech.com. If you need to return a product to the factory for service, you MUST first contact Technical Support to obtain a Return Authorization Number.
NO RETURNED PRODUCTS WILL BE ACCEPTED AT THE FACTORY WITHOUT A RETURN AUTHORIZATION NUMBER.
Please refer to the Warranty information, which extends to the first end-user.After expiration of the warranty, a reasonable charge will be made for parts, labor, and packing if you choose to use the factory service facility. In all cases, you are responsible for transportation charges to the factory. If the product is still under warranty, DigiTech will pay the return shipping.
Use the original packing material if it is available. Mark the package with the name of the shipper and with these words in red: DELICATE INSTRUMENT, FRAGILE! Insure the package properly. Ship prepaid, not collect. Do not ship parcel post.
INTRODUCTION
Thanks for choosing the DigiTech® Whammy™ Ricochet effect pedal.The Whammy Ricochet takes the popular Whammy pitch shifting effect and places it in a pedal with a small form factor. Instead of using a treadle to manipulate pitch bending rate, such as those found on traditional Whammy pedals, the Whammy Ricochet bends the pitch of the incoming note at a rate determined by the SHIFT and RETURN controls. And thanks to a true bypass design, your tone remains unaffected when the effect is bypassed.
The Whammy effect can be turned on or off using the Footswitch, which can operate as a momentary or latching switch.The TRAJECTORY LED ladder lights in sequential order to provide a visual indication of pitch shifting rate and direction.The incoming note can be pitch shifted up or down by the following intervals:
•2ND
•4TH
•5TH
•7TH
•OCTAVE
•2 OCTAVES
•OCTAVE + DRY
To use the Whammy Ricochet pedal, select the desired pitch shifting interval with the PITCH control then select the pitch direction with the RANGE switch. Set the Footswitch for momentary or latched operation using the MOMENTARY switch.To audition the rise and fall rate of the pitch shifting effect, turn the effect on/off using the Footswitch; adjust the SHIFT and RETURN controls so that the pitch effect bends to and from the selected interval at the desired rate.
FEATURES
•Pitch Shifting of up to 2 Octaves Up or Down
•Ballistics Controls with Trajectory LED Meter
•Switchable Classic & Chords Modes
•Selectable Momentary or Latched Footswitch Operation
•True Bypass
•Compact Design
•Solid Construction
1
