Digitech Whammy User Manual

A Harman International Company

These symbols are internationally accepted symbols that warn of potential
hazards with electrical products.The lightning flash means that there are
dangerous voltages present within the unit.The exclamation point indicates
that it is necessary for the user to refer to the owners manual.

These symbols warn that there are no user serviceable parts inside the unit.
Do not open the unit.Do not attempt to service the unit yourself. Refer all
servicing to qualified personnel. Opening the chassis for any reason will void
the manufacturer’s warranty.Do not get the unit wet.If liquid is spilled on
the unit,shut it off immediately and take it to a dealer for service.

Disconnect the unit during storms to prevent damage

.

Electromagnetic Compatibility

Operation is subject to the following conditions:

•This device may not cause harmful interference.

•This device must accept any interference received,including interfer­ence that may cause undesired operation.

•Use only shielded interconnecting cables.

•Operation of this unit within significant electromagnetic fields should
be avoided.

Warning

For your protection,please read the following:

Water and Moisture:Appliances should not be used near water

(e.g. near a bathtub, washbowl,kitchen sink,laundry tub, in a wet
basement,or near a swimming pool,etc.) Care should be taken so
that objects do not fall and liquids are not spilled into the enclosure
through openings.

Power Sources: The appliance should be connected to a power
supply only of the type described in the operating instructions or as
marked on the appliance.

Grounding or Polarization: Precautions should be taken so that
the grounding or polarization means of an appliance is not defeated.

Power Cord Protection: Power supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them,paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
appliance.

Servicing: To reduce the risk of fire or electrical shock, the user
should not attempt to service the appliance beyond that described in
the operating instructions.All other ser vicing should be referred to
qualified service personnel.

For units equipped with externally accessible fuse recepta­cle: Replace fuse with same type and rating only.

DECLARATION OF CONFORMITY

Manufacturer’s Name: Digitech Electronics
Manufacturer’s Address: 8760 S. Sandy Parkway

Sandy, Utah 84070, USA

declares that the product:

Product Name: Whammy/Whammy4
Product Options: All (requires a Class II power adapter that conforms to the requirements of

EN60065, EN60742, or equivalent.)

conforms to the following Product Specifications:

Safety: EN 60065 (1993)

IEC 65 (1985) with Amendments 1, 2 & 3

EMC: EN 55013 (1990)

EN 55020 (1991)

Supplementary Information:

The product herewith complies with the requirements of the Low Voltage Directive
73/23/EEC and EMC Directive 89/336/EEC as amended by Directive 93/68/EEC.

Digitech

Vice-President of Engineering
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Tel: [phone]
Fax: [phone]

Effective February 15, 2000

European Contact: Your Local Digitech Sales and Service Office or

Harman Music Group
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Tel. [phone]
Fax [phone]

Warranty

We at Digitech are very proud of our products and back-up each one we sell with the following warranty:

1.The warranty registration card must be mailed within ten days after purchase date to validate this warranty.

2.Digitech warrants this product,when used solely within the U.S., to be free from defects in materials and workmanship under normal use and service.

3.Digitech liability under this warranty is limited to repairing or replacing defective materials that show evidence of defect,provided the product is
returned to Digitech WITH RETURN AUTHORIZATION,where all parts and labor will be covered up to a period of one year.A Return Authorization
number may be obtained from Digitech by telephone.The company shall not be liable for any consequential damage as a result of the product's use in
any circuit or assembly.

4.Proof-of-purchase is considered to be the burden of the consumer.

5.Digitech reserves the right to make changes in design, or make additions to, or improvements upon this product without incurring any obligation to
install the same on products previously manufactured.

6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tampered with by anyone other than a certified
Digitech technician or,if the product is used with AC voltages outside of the range suggested by the manufacturer.

7.The foregoing is in lieu of all other warranties,expressed or implied, and Digitech neither assumes nor authorizes any person to assume any obligation
or liability in connection with the sale of this product.In no event shall Digitech or its dealers be liable for special or consequential damages or from
any delay in the performance of this warranty due to causes beyond their control.

NOTE: The information contained in this manual is subject to change at any time without notification. Some information contained in this manual
may also be inaccurate due to undocumented changes in the product or operating system since this version of the manual was completed. The
information contained in this version of the owner's manual supersedes all previous versions.

Congratulations on the purchase of your new Whammy™ Pedal. When DigiTech invented
the Whammy™ pedal, it was the most revolutionary and innovative pedal to hit the guitar since
the the wah wah. Nearly a decade later, in response to your demands, we have gone to
painstaking lengths to bring back the original Whammy™. Every last detail was considered as we
recreated this classic pitch bending effect. However, we strengthened the rugged steel chassis to
endure the perils of the stage better, the addition of a MIDI input provides more flexibility, pre­set LEDs provide a visual indication of your selection, and the Dive Bomb setting bends your sig­nal a full 3 octaves down. We are proud to bring back this pedal, and we’re proud that you
wanted it. Although the Whammy™ has an extremely intuitive user interface, this User’s Guide
will help you understand the Whammy™ functions and allow you to get the most out of your
purchase for years to come.

Included Items

The utmost care was taken while your Whammy™ was being manufactured. Everything should
be included and in perfect working order. Before you get started, please make sure that the
following items have been included:

• Whammy™ Pedal

• PS750 or PS0913B Power Supply

• User’s Guide

• Warranty Card

If anything is missing, contact the factory at once. Please take a moment to complete your
warranty card. It is your safeguard should a problem arise with your Whammy™.

Page1

User’s Guide
