The symbols shown above are internationally accepted symbols
that warn of potential hazards with electrical products. The
lightning flash with arrowpoint in an equilateral triangle means
that there are dangerous voltages present within the unit. The
exclamation point in an equilateral triangle indicates that it is
necessary for the user to refer to the owner’s manual.
These symbols warn that there are no user serviceable parts
inside the unit. Do not open the unit. Do not attempt to
service the unit yourself. Refer all servicing to qualified personnel.
Opening the chassis for any reason will void the manufacturer’s
warranty. Do not get the unit wet. If liquid is spilled on the
unit, shut it off immediately and take it to a dealer for service.
Disconnect the unit during storms to prevent damage.
SAFETY INSTRUCTIONS
NOTICE FOR CUSTOMERS IF YOUR UNIT IS EQUIPPED WITH A
POWER CORD.
WARNING: THIS APPLIANCE SHALL BE CONNECTED TO A MAINS SOCKET
OUTLET WITH A PROTECTIVE EARTHING CONNECTION.
The cores in the mains lead are colored in accordance with the
following code:
GREEN and YELLOW - Earth BLUE - Neutral BROWN - Live
As colours of the cores in the mains lead of this appliance may not
correspond with the colored markings identifying the terminals in your
plug, proceed as follows:
•
The core which is colored green and yellow must be connected to
the terminal in the plug marked with the letter E, or with the
earth symbol, or colored green, or green and yellow.
•
The core which is colored blue must be connected to the terminal
marked N or colored black.
•
The core which is colored brown must be connected to the terminal
marked L or colored red.
This equipment may require the use of a different line cord, attachment
plug, or both, depending on the available power source at installation.
If the attachment plug needs to be changed, refer servicing to qualified
service personnel who should refer to the table below. The green/yellow
wire shall be connected directly to the unit’s chassis.
WARNING: If the ground is defeated, certain fault conditions in the
unit or in the system to which it is connected can result in full
line voltage between chassis and earth ground. Severe injury or
death can then result if the chassis and earth ground are touched
simultaneously.
WIRE COLOR
NormalAlt
WARNING FOR YOUR PROTECTION
PLEASE READ THE FOLLOWING:
KEEP THESE INSTRUCTIONS
HEED ALL WARNINGS
FOLLOW ALL INSTRUCTIONS
THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING
LIQUID AND NO OBJECT FILLED WITH LIQUID, SUCH AS VASES, SHALL
BE PLACED ON THE APPARATUS
CLEAN ONLY WITH A DRY CLOTH.
DO NOT BLOCK ANY OF THE VENTILATION OPENINGS. INSTALL IN
ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS.
DO NOT INSTALL NEAR ANY HEAT SOURCES SUCH AS RADIATORS, HEAT
REGISTERS, STOVES, OR OTHER APPARATUS (INCLUDING AMPLIFIERS)
THAT PRODUCE HEAT.
ONLY USE ATTACHMENTS/ACCESSORIES SPECIFIED BY THE
MANUFACTURER.
UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN
UNUSED FOR LONG PERIODS OF TIME.
Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or third prong are provided for your safety.
If the provided plug does not fit your outlet, consult an electrician
for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
Use only with the cart stand, tripod bracket, or table specified
by the manufacture, or sold with the apparatus.
When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from
tip-over. Refer all servicing to qualified service
personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
POWER ON/OFF SWITCH: For products provided with a power
switch, the power switch DOES NOT break the connection from
the mains.
MAINS DISCONNECT: The plug shall remain readily operable. For
rack-mount or installation where plug is not accessible, an all-pole
mains switch with a contact separation of at least 3 mm in
each pole shall be incorporated into the electrical installation of
the rack or building.
FOR UNITS EQUIPPED WITH EXTERNALLY ACCESSIBLE FUSE RECEPTACLE:
Replace fuse with same type and rating only.
MULTIPLE-INPUT VOLTAGE: This equipment may require the use of
a different line cord, attachment plug, or both, depending on the
available power source at installation. Connect this equipment only
to the power source indicated on the equipment rear panel. To
reduce the risk of fire or electric shock, refer servicing to qualified
service personnel or equivalent.
IMPORTANT SAFETY INSTRUCTIONS
ELECTROMAGNETIC
COMPATIBILITY
This unit conforms to the Product Specifications
noted on the Declaration of Conformity.
Operation is subject to the following two
conditions:
this device may not cause harmful
•
interference, and
this device must accept any interference
•
received, including interference that may
cause undesired operation.
Operation of this unit within significant
electromagnetic fields should be avoided.
use only shielded interconnecting cables.
•
DECLARATION OF
CONFORMITY
Manufacturer’s Name: DigiTech
Manufacturer’s Address:
Sandy, Utah 84070, USA
Declares that the product:
Product name: Vocalist Live Pro
Note: Product name may be suffixed by the letters-EU.
Product option: None
Conforms to the following Product Specifications:
Safety: IEC 60065 (7th ed. 2001)
EMC: EN 55013 (2001+A1)
EN 55020 (1998)
Supplementary Information:
8760 S. Sandy Parkway
U.K. MAINS PLUG WARNING
A molded mains plug that has been cut
off from the cord is unsafe. Discard the
mains plug at a suitable disposal facility.
NEVER UNDER ANY CIRCUMSTANCES
SHOULD YOU INSERT A DAMAGED
OR CUT MAINS PLUG INTO A 13 AMP
POWER SOCKET.
Do not use the mains plug without the
fuse cover in place. Replacement fuse
covers can be obtained from your local
retailer. Replacement fuses are 13 amps
and MUST be ASTA approved to BS1362.
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC
and the EMC Directive 89/336/EEC as amended
by Directive 93/68/EEC.
Vice-President of Engineering-MI
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Date: February 15, 2008
European Contact: Your local DigiTech Sales and
Service Office or
Harman Music Group
8760 South Sandy Parkway
Sandy, Utah
84070 USA
Ph: (801) 566-8800
Fax: (801) 566-7005
Warranty
We at DigiTech® are very proud of our products and back-up each one we sell with the following
warranty:
1. The warranty registration card must be mailed within ten days after purchase date to validate this
warranty.
2. DigiTech warrants this product, when used solely within the U.S., to be free from defects in
materials and workmanship under normal use and service.
3. DigiTech liability under this warranty is limited to repairing or replacing defective materials
that show evidence of defect, provided the product is returned to DigiTech WITH RETURN
AUTHORIZATION, where all parts and labor will be covered up to a period of one year. A
Return Authorization number may be obtained from DigiTech by telephone. The company shall
not be liable for any consequential damage as a result of the product’s use in any circuit or
assembly.
4. Proof-of-purchase is considered to be the burden of the consumer.
5. DigiTech reserves the right to make changes in design, or make additions to, or improvements
upon this product without incurring any obligation to install the same on products previously
manufactured.
6. The consumer forfeits the benefits of this warranty if the product’s main assembly is opened and
tampered with by anyone other than a certified DigiTech technician or, if the product is used
with AC voltages outside of the range suggested by the manufacturer.
7. The foregoing is in lieu of all other warranties, expressed or implied, and DigiTech neither
assumes nor authorizes any person to assume any obligation or liability in connection with the
sale of this product. In no event shall DigiTech or its dealers be liable for special or consequential
damages or from any delay in the performance of this warranty due to causes beyond their
control.
NOTE: The information contained in this manual is subject to change at any time without
notification. Some information contained in this manual may also be inaccurate due to undocumented
changes in the product or operating system since this version of the manual was completed. The
information contained in this version of the owner’s manual supersedes all previous versions.
If you want to dispose of this product, do not mix it with general household waste. There is
a separate collection system for used electronic products in accordance with legislation that
requires proper treatment, recovery and recycling.
Private household in the 25 member states of the EU, in Switzerland and Norway may return their used
free of charge to designated collection facilities or to a retailer (if you purchase a similar new one).
For Countries not mentioned above, please contact your local authorities for a correct method of disposal. By doing so you
will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential
negative effects on the environment and human health.
electronic products
Contents
Introduction .................................. 1
Features ......................................... 2
Signal Flow ............................................ 52
Separate Output Mode
Signal Flow ............................................. 53
V1+V2 V3+V4 Output Mode
Signal Flow ............................................. 53
Factory Preset List ....................... 54
Troubleshooting ............................ 58
Electrical / Audio Specifications ... 59
Introduction
Congratulations on your purchase of the Vocalist® Live Pro. The Vocalist Live Pro is a breakthrough
processor that automatically generates live multi-part vocal harmony while you maintain your natural
playing style. Armed with patent pending musIQ™ Harmony Technology (which includes both
musIQ™ Note Detection and musIQ Harmony Generation), the Vocalist Live Pro analyzes your
guitar or MIDI keyboard chord and note progressions and gives you accurate, musically correct vocal
harmonies even with complicated songs. Only Vocalist Live tracks guitar and keyboard chords and
notes along with your voice.
Overview
The Vocalist Live Pro is a revolutionary voice processor that creates musically correct harmonies
for your singing voice that automatically change to fit with the current guitar, keyboard or MIDI note
or chord and key of the music you are playing. It is an easy-to-use vocal processor that includes a
wide variety of Lead Voice and Harmony Voice effects, Vocal Harmony styles and professional vocal
effects including Lexicon® Reverbs and Delays. In addition to generating natural sounding harmonies,
the Vocalist Live Pro can also provide real-time pitch correction for the incoming vocal signal. The
Vocalist Live Pro offers 99 Factory presets to get you started and another 99 User presets where you
can save your own custom settings. It is packaged as a 1U rack device and can be controlled using the
front-panel interface, external foot controls or via MIDI.
Introduction
About musIQ™ Technology
musIQ is a revolutionary technology that eliminates the need to enter key and scale information into
the product as it listens to the notes and chords played on a guitar or MIDI keyboard and makes sure
that the Harmony Voices fit with the music. Real-time processing discerns the individual notes, chords
and key signatures that are played in order to automatically generate appropriate Vocal Harmonies
that compliment the Lead Vocal. With musIQ, you can focus on your live singing and playing
performance, and discard song programming once and for all.
VL Pro Owner’s Manual
1
Features
Vocalist® Live Pro Features
• musIQ™ Harmony Technology
• 24-bit, 44.1KHz audio quality
• Pre-Effects
• Low-Cut
• Tube Pre-Amp
• De-Esser
• Noise Gate
• Compressor/Limiter
• EQ
•Lead Voice Effects
•Pitch Correct
•Persona
•Parametric Filter
•Distortion
•Band Limiting
•Modulation
•Up to four Harmony Voices with a wide range of fully customizable voicing
characteristics and processing functionality including musIQ Guitar and MIDI Keyboard, Scalic,
Chordal, Shift, MIDI Notes and 4-Channel Notes. The four Harmony Voices can run
concurrently along with a Pitch-Corrected Lead Voice and Persona among other features.
•Lexicon® Licensed Effects
•Reverb (Vocal Hall, Vocal Plate, Room, Ambience)
•Delay and Echo (Studio, Ping Pong, Tape)
•Guitar Tuner
• Soundcraft® Studio Grade Microphone Preamp
• 48V Phantom Power
• Mic Pass-Thru
• Stereo Balanced XLR Main and 1/4” Auxiliary Outputs
• S/PDIF Digital Output
• USB I/O for MIDI Control and Preset Backup and Restore
• MIDI IN and THRU Ports for Keyboard and MIDI Control
• 198 Presets: 99 Factory Presets and 99 User Presets
• Expression Pedal Input provides real-time control of most performance parameters
• Footswitch Input provides remote control of presets, delay tempo, and effects
• Up to 16 Expression Links per Preset for real-time parameter control via Expression Pedal input
or MIDI CC messages
VL Pro Owner’s Manual
• Guitar Thru and Main Output, Aux Output and Mic Pass Thru Ground Lift Functionality
• Internal Power Supply
2
Included Items
Before you get started, please make sure that the following items have been included:
•
The Vocalist® Live Pro
•
Power Cord
•
Bag of Mounting Hardware
•
Owner’s Manual
•
Warranty Card
The utmost care was taken while your Vocalist Live Pro was being manufactured. Everything should
be included and in perfect working order. If anything is missing, contact the factory at once. Please
help us become acquainted with you and your needs by completing your warranty card or registering
online at www.digitech.com. It is your safeguard should a problem arise with your Vocalist Live Pro.
Important safety tip: Always turn on amplifiers AFTER all other connections are made to the
Vocalist Live Pro and AFTER the Vocalist Live Pro is powered up.
Included Items
VL Pro Owner’s Manual
3
Front Panel
Front Panel
1. Guitar Input: Connect your guitar here.
2. Guitar Input Signal Level: This signal LED represents the guitar input signal level. It is green when
sufficient guitar signal strength is present, amber when approaching limit, and red when the signal clips.
3. Guitar Thru Output: Outputs the unprocessed guitar signal, enabling you to utilize external
processing for the guitar. This output is muted while the guitar tuner is in use.
4. Guitar Ground Lift: Disconnects the guitar jack ground from the Vocalist® Live Pro signal ground. This is
done to solve ground loop problems when connected to a guitar amp and a PA system at the same time.
When lifted, this button lights red.
5. Vocal Input - XLR In: Connect your microphone here.
6. Vocal Input - Input Level: Adjusts the vocal input level for either the front mic input or the rear 1/4” line
input, depending on which vocal input is currently active.
7. Vocal Input - Signal LED: This signal LED represents the active (front mic input or rear 1/4” line input)
vocal input signal level. It is green when sufficient vocal signal strength is present, amber when approaching
limiting, and red when the limiter is active.
8. Vocal Input - Mic: This button selects the front panel mic input for the active vocal signal. When selected,
this button lights green.
9. Vocal Input - Line: This button selects the back panel line input for the active vocal signal. When selected,
this button lights amber.
10. Vocal Input - 48V: This button enables and disables the 48 Volt phantom power for the microphone input.
This button lights red when phantom power is enabled.
11. Graphic Display: The main display for viewing preset summaries and navigating through all of the Vocalist
Live Pro menus.
12. Numeric Display: This display numerically indicates the currently selected preset from 1-99. It works in
conjunction with the User LED to define which of the 2 banks of 99 presets is currently in use (User Preset
Bank or Factory Preset Bank).
13. User LED: Lights red when a User Preset is selected; turns off when a Factory Preset is selected. User
Presets can be copied or edited and stored to their current location or any other location in the User
Preset Bank. Factory Presets can also be copied or edited, but must be stored to a User Preset location.
VL Pro Owner’s Manual
4
14. MIDI LED: This green LED lights whenever data is present at the MIDI In port on the MIDI channels
specified in the MIDI/Expr Pedal Setup menus.
15. USB LED: This blue LED lights when a valid USB connection is made
16. Edit/Select: Turn this knob to scroll through presets, menus or parameters and to adjust parameter values.
Press this knob to enter a menu, select a parameter or accept a parameter value.
17. Back: Press this button to step back and out of the current menu or to cancel a storing procedure. The
Back button does not cancel changes you’ve made to a preset or menu.
18. Harmony Mode - musIQ™ Guitar: This button enables musIQ and selects the guitar as the source for
generated harmonies. The harmonies are then controlled by the musIQ algorithm.
19. Harmony Mode - musIQ MIDI: This button enables musIQ and selects the MIDI input as the source for
generated harmonies. The harmonies are then controlled by the musIQ algorithm.
20. Harmony Mode - Other (Menu): This button allows you to select one of the non-musIQ Harmony
Modes. The modes available are displayed on the Graphic Display for selection and include Shift, Scalic, MIDI
Chordal, MIDI Notes and MIDI 4 Channel Notes.
Front Panel
21. Lead Level: Adjusts the Lead Vocal Level in the Main Out and S/PDIF Out mixes and includes Aux Out if
the Global Output Mode is set to Aux = Main. This Lead Level defines the maximum achievable level when
using Lead Level in the Preset Expression Links.
22. Harmony Level: Adjusts the Harmony Voices Level in the Main Out and S/PDIF Out mixes and includes
Aux Out if the Global Output Mode is set to Aux = Main. This Harmony Level defines the maximum
achievable level when using Harmony Level in the Preset Expression Links.
23. Reverb Level: Adjusts the Reverb Level in the Main Out and S/PDIF Out mixes and includes Aux Out if the
Global Output Mode is set to Aux = Main.
24. Effects On/Off - Lead FX: Enables or disables all the Lead Effects of the current preset.
25. Effects On/Off - Harmony: Enables or disables all the Harmony Voices and associated settings applied to
the current preset.
26. Effects On/Off - Reverb/Delay: Enables or disables the Reverb and Delay Effects of the current preset.
27. System - Store: This button is used to store a preset to a location in the User Preset Bank. The red LED
on this button lights when the preset’s saved parameters have been changed.
28. System – Bypass: Press this button to activate or deactivate Bypass mode. When in Bypass mode, the
Graphic Display reads “BYPASSED” and the unprocessed vocal signal is heard on all outputs without any
effects or harmonies.
29. System - Tuner: This button enables and disables the guitar tuner. When the tuner is active, the button’s
green LED flashes, the Guitar Thru Output is muted and the Graphic Display shows the guitar tuning screen.
30. Power: This power switch turns the Vocalist® Live Pro on and off.
VL Pro Owner’s Manual
5
Rear Panel
Rear Panel
1. AC Power Jack: Standard IEC power cord input, to supply the Mains AC input.. This AC input jack also contains
the fuse that the unit is currently using in addition to a spare fuse.
2. USB Port: This port is USB 1.1 full-speed (12Mbits/second) and carries MIDI control information to the Vocalist® Live Pro from a personal computer. The Vocalist Live Pro uses the USB port to interface to a computer running
the Vocalist Live Pro Utilities software used to provide preset backup and restore functionality with the Preset
Librarian. The Vocalist Live Pro Utilities software and documentation can be downloaded from www.digitech.com.
3. Footswitch: This TRS 1/4” jack connects the optional DigiTech® FS3X or GNXFC 3-button footswitch to allow
hands-free control of many of the Vocalist Live Pro’s functions. Each of the 3 buttons on the optional footswitch
can be mapped to one of the following functions: Preset Up, Preset Down, Tuner, Tap Tempo, Harmony Toggle,
Harmony Momentary, Lead FX, Toggle, Lead FX Momentary, Reverb/Delay Toggle, Reverb/Delay Momentary,
Harmony/Lead FX Toggle, Harmony/Lead FX Momentary, Harmony/Reverb/Delay Toggle, Harmony/Reverb/Delay
Momentary, Lead FX/Reverb/Delay Toggle, Lead FX/Reverb/Delay Momentary, Harmony/Lead FX/Reverb/Delay
Toggle and Harmony/Lead FX/Reverb/Delay Momentary.
4. Expression Pedal: This input accepts a TS or TRS expression pedal for controlling real-time parameters. Many
elements on the Vocalist Live Pro can be controlled in real-time using the expression pedal.
5. S/PDIF Out: The S/PDIF output echoes the MAIN outputs signal in digital S/PDIF format.
6. MIDI In: This 5-pin female DIN MIDI In port is used to receive control (CC, MIDI Clock, SysEx Program Change
and Pitch Bend) and note information from an external device.
7. MIDI Thru: This port echoes data received on the MIDI In port and is typically used for daisy-chaining MIDI
devices together.
8. Main Out Left and Right: These balanced XLR outputs carry a mix of the lead and harmony vocals and effects at
line levels in mono or stereo.
9. Outputs Ground Lift: This button activates the Ground Lift for the Main Out, Aux Out and Mic Pass Thru
outputs. This switch lifts Pin 1 of the XLR Main Outputs and Mic Pass Thru Jack and the shield of the TRS ¼” Aux
outputs from all ground references and may help break troublesome ground loops that cause hum in the system,
especially when both XLR and 1/4” outputs are used together.
10. Aux Out Left and Right: These female balanced / unbalanced TRS jacks output the processed mix of the lead and
harmony vocals and effects at line levels in mono or stereo.
11. Line In: This balanced female 1/4” input accepts the line level vocal audio when selected with the Vocal Input Line
Button on the front panel. Note that the front Mic and rear Line Inputs cannot be active simultaneously.
12. Mic Pass Thru: This output provides the dry, unprocessed vocal signal obtained at the front panel Vocal Input.
VL Pro Owner’s Manual
6
Common Configurations
&ROM¬'UITAR
4O¬'UITAR¬%FFECTS
&ROM
&OOTSWITCH
&ROM
%XPRESSION
0EDAL
4O¬-IXER¬
4O¬-IXER¬3TEREO
4O
'UITAR¬!MP
4O
3PEAKERS
&ROM¬-IC
¬ ¬ ¬ ¬ ¬ ¬ , ¬ 2
Common Configurations
There are many ways to set up and use the Vocalist® Live Pro. Some common setup configurations
are shown below.
Important Note: The Vocalist Live Pro Main Out XLR outputs are line level outputs. Many mixers
accept only mic levels on the XLR inputs. You will know this is the case if you find that you have
to turn your Input Level completely down in order to avoid clipping at the mixer’s XLR input. To
remedy this you will need to either use an XLR to ¼” cable or XLR to ¼” adapter on an XLR cable
to plug into your mixer’s ¼” line inputs. Alternatively, you can use a Direct Injection (DI) box to
provide a mic level signal to the mixer’s XLR inputs.
1. Guitar and Mic with Footswitch and Expression Pedal
This configuration uses the guitar and microphone inputs. The guitar is plugged directly into the
Vocalist Live Pro and then into a guitar effects device and then an amplifier. Remote functionality is
achieved using the Footswitch and Expression Pedal inputs. The processed vocal and harmony voice
signal is provided by the Main Out and connected to the PA Mixer.
VL Pro Owner’s Manual
7
Common Configurations
¬ ¬ ¬ ¬ ¬ ¬ , ¬ 2
&ROM¬'UITAR
4O¬'UITAR¬!MP
4O¬-ONITOR
4O¬-IXER¬3TEREO
4O
3PEAKERS
&ROM¬-)$)
#ONTROLLER
&ROM¬-IC
&ROM¬0REAMP
2. Guitar and Mic Preamp with MIDI Controller and Monitor Output
In this configuration, the vocal microphone is using a mixer / preamp and is connected to the
Vocalist® Live Pro through the Line In vocal input. Assure this input is selected using the Line Vocal
Input button on the front panel in the Vocal Input section. Remote functionality is achieved using an
external MIDI floorboard controller. The processed vocal and harmony voice signal is sent directly to
the powered vocal monitor using the Aux Out and to the PA mixer using the Main Out.
VL Pro Owner’s Manual
8
Common Configurations
&ROM¬+EYBOARD¬6IA¬-)$)¬/UT
4O¬-IXER
4O¬-)$)¬3YNTHESIZER
4O¬-IXER¬-ONITOR¬-IX
4O¬-IXER¬0!¬-IX
4O¬0!
&ROM¬-IC
4O¬-ONITOR
¬ ¬ ¬ ¬ ¬ ¬ , ¬ 2
6
3. Keyboard and Mic with Separate Monitor and PA Mixes
This configuration uses the MIDI Keyboard as the vocal guide instrument. Assure that either the
front panel musIQ™ MIDI Harmony Mode is selected or the Other (Menu) Harmony Mode button
is selected with one of the desired modes. The keyboard MIDI data is echoed out through the MIDI
Thru output to the daisy chained MIDI Synthesizer that provides the FOH (Front Of House) Engineer
with the audio signal. The Main Aux Separate Output Mode in Global I/O Setup is being implemented
to provide the FOH Mixer with 2 separated mixes of the processed vocal and harmony voice signals.
The Main Out is providing a stereo mix for the monitors, governed by the front panel Levels knobs,
while the Aux Out is providing a stereo mix for the PA, controlled by the preset settings and Global
I/O settings for Aux Lead Level and Aux Harmony Level.
VL Pro Owner’s Manual
9
Common Configurations
&ROM¬+EYBOARD¬6IA¬-)$)¬/UT
4O¬-IXER
4O¬-)$)¬3YNTHESIZER
(ARMONY¬6OICE¬
(ARMONY¬6OICE¬
(ARMONY¬6OICE¬
(ARMONY¬6OICE¬
$RY¬6OCAL¬3IGNAL
4O¬3PEAKERS
&ROM¬-IC
¬ ¬ ¬ ¬ ¬ ¬ , ¬ 2
6
4. Keyboard and Mic with Individual Voice Outputs
In this configuration, the V1+V2 V3+V4 Output Mode in Global I/O Setup is being implemented to
provide the FOH Mixer with each Harmony Voice separately. The dry vocal signal obtained at the
input is provided using the Mic Pass Thru output. This allows the FOH Engineer to have full mixing or
external processing control for the lead and harmony voices.
VL Pro Owner’s Manual
10
Common Configurations
!NALOG¬'UITAR¬4RACK¬&ROM¬$!7
!NALOG¬6OCAL¬4RACK¬&ROM¬$!7
$IGITAL¬30$)&¬4O¬$!7
53"¬-)$)¬#ONTROLLED¬BY¬$!7
5. Digital Audio Workstation Recording with MIDI Control
This configuration involves using the Vocalist® Live Pro with a DAW (Digital Audio Workstation)
Computer for post processing of recorded vocal material. The vocal audio track is sent from the
DAW into the Line In and the guitar track audio is sent into the Guitar Input. Assure the Line In
is selected as the vocal input using the Line Vocal Input button on the front panel. It may also be
necessary to adjust the guitar audio output level coming from the DAW to an appropriate input level
indicated by the Guitar Signal LED. The USB is connected to the DAW for PC MIDI control of the
Vocalist Live Pro features and parameters. The resulting Digital S/PDIF processed vocal and harmony
voice signal output is fed back into the DAW for recording.
11
VL Pro Owner’s Manual
Common Configurations
0ROCESSED
!UDIO¬TO
!UDIO¬)NTERFACE
53"¬-)$)
#ONTROLLED¬BY¬0#
&ROM¬'UITAR&ROM¬-IC
$IGITAL¬!UDIO¬TO¬0#
6. PC Recording with USB MIDI Control
In this configuration, the guitar is used as the tracking input and vocal microphone is connected
to the Vocal Input. A USB cable is connected from the PC to the Vocalist® Live Pro for PC MIDI
control of the Vocalist Live Pro’s presets and parameters. The resulting processed Lead Vocal and
Harmony Voice analog audio output is routed out of the Aux Outputs and fed into a USB or Firewire
audio interface that is connected to the PC for recording.
VL Pro Owner’s Manual
12
Getting Started- Basic Setup
1. Make sure the Vocalist® Live Pro’s power switch is in the off position (up), connect the power
cord to the power input (located on the back panel) and plug it into the AC outlet.
2. Make sure the Vocal Input Level knob is turned all the way down (counter-clockwise).
3. Plug a microphone into the Vocal Mic In jack.
4. Plug your guitar directly into the Guitar Input jack.
Regarding External Effects Pedals: Do not hook up any effects pedals to your guitar prior to
plugging it into the Vocalist Live Pro, as this could affect vocal harmony generation. The only thing
between your guitar and the Vocalist Live Pro should be the guitar cable. Use the Guitar Thru to
connect your effects and stomp boxes.
5. Make sure your guitar amplifier is turned off and the volume level is turned all the way down.
6. Make sure your P.A. or mixer is turned off and the volume levels are turned all the way down.
Getting Started
7. Connect the Guitar Thru to your guitar effects, amplifier or P.A. system.
8. Plug the Vocalist Live Pro Left and Right Main or Aux Outputs into your P.A. system or mixer.
Note: The Vocalist Live Pro Main Out XLR outputs are line level outputs. Many mixers accept only
mic levels on the XLR inputs. You will know this is the case if you find that you have to turn your
Input Level completely down in order to avoid clipping at the mixer’s XLR input. To remedy this
you will need to either use an XLR to ¼” cable or XLR to ¼” adapter on an XLR cable to plug into
your mixer’s ¼” line inputs. Alternatively, you can use a Direct Injection (DI) box to provide a mic
level signal to the mixer’s XLR inputs.
9. Turn on the Vocalist Live Pro power by turning the Power switch on the front panel to the
down position exposing red button indicator.
10. Press the Vocal Input Mic Select button. If your microphone needs phantom power, press the
Vocal Input Phantom Power switch. The red Phantom Power LED will light.
Note: Phantom power is normally only needed with condenser microphones, and should never be
used with ribbon microphones. To avoid damaging the microphone, please consult your microphone
documentation to ensure phantom power is applied only when appropriate.
11. Setting the Guitar Level
Ideally the Guitar Signal LED should be green or amber while playing. Most electric and
acoustic/electric guitars send their signal at a level appropriate for the Vocalist Live Pro. Observe
the Guitar Signal LED while playing your guitar and confirm an appropriate guitar signal level is
13
VL Pro Owner’s Manual
Getting Started
being accepted. If the Guitar Signal LED does turn red while you are playing confirm the Vocalist
Live Pro Guitar Sensitivity in the Global I/O Setup menu is set to Low (see page 23). If it is and you
have a volume control on your guitar (for example, an acoustic guitar with a pre-amp built in), you
should adjust the volume so that the Guitar Signal LED is green or amber most of the time while
playing.
Some older guitars send a very low signal. If your guitar doesn’t send a strong enough signal to turn
the Guitar Signal LED green, try setting the Guitar Sensitivity in the Global I/O Setup menu to High
(see page 23).
12. Tune the Guitar with the Vocalist® Live Pro Tuner. Press the Tuner button located on the front
panel System section. The green Tuner LED will flash green and the display will enter the Tuner
screen. The built-in guitar tuner works optimally with a strong guitar signal, so don’t turn down your
guitar to tune. The guitar output will automatically be muted when you’re in tuner mode.
As you tune each guitar string to the desired note, the note closest to that being played will appear on
the screen above the + and the highlighted Tuner Symbols will show how close to that note the string
is. A highlighted + indicates the string is In Tune with the displayed note. A highlighted > symbol to
the left of the In Tune + symbol indicates the note is flat and that you need to tune up. A highlighted
< symbol to the right of the In Tune + symbol indicates the note is sharp and that you need to tune
down. The further the highlighted flat or sharp symbol is from the center In Tune + symbol, the
further out of tune your string is.
VL Pro Owner’s Manual
Note: It is important that your guitar is properly tuned in order for the musIQ™ Technology to generate
the best sounding harmonies. Alternate tunings (for example, DADGAD or tuning down) are fine, as long
as the built-in tuner shows each string as “in tune”. If you are using an external tuner, just make sure that
the reference is set to 440 Hz.
13. Set the Vocal Level. Sing into the microphone while gradually turning up the Vocal Input Level knob
until the Vocal Signal LED lights green or amber most of the time. It is recommended you adjust the
vocal level so the Vocal Input Signal LED is amber during loud vocal sections and only briefly turns red
on the very loudest vocal sections. The Vocalist Live Pro will normally prevent the Vocal Harmonies
from clipping, even when the LED is red, but for optimum voice quality the LED should turn red only
briefly or not at all.
Once the input vocal level is set, you can increase or decrease the amount of lead vocals in the mix
with the Lead Levels knob.
14
14. Turn on your amplifier and gradually turn it up until you reach a comfortable listening level.
15. Turn on your P.A. system and gradually turn it up until you reach a comfortable listening level.
16. Ground Lifts Analysis
If you hear humming or buzzing from either the guitar amplifier connected to the Guitar Thru output
signal or the mixer connected to the Main, Aux or Mic Pass Thru outputs, try a combination of the
ground lift solutions implemented on the Vocalist® Live Pro to resolve ground loop problems when
connecting to a guitar amp and a PA system at the same time and when both XLR and 1/4” outputs
are used together.
Pressing the Guitar Ground Lift button on the front panel toggles the ground lift on or off. When
the button is lit the ground is lifted. Press the Outputs Ground Lift button on the rear panel to
lift the Main Out and Mic Pass Thru XLR outputs and the Aux Out 1/4” outputs from all ground
references.
17. Change the currently selected preset, by turning the Edit/Select knob, to one that has musIQ™ and
Harmony Voicings displayed on the right Harmony Mode portion of the Preset Screen. Providing
the Main Menu Preset Load setting is Automatic instead of Manual, the preset will load when it is
selected on the Preset Screen without the need to press the Edit/Select knob. While playing a chord
on your guitar, sing a note. You should hear your guitar, your Lead Voice, plus the Harmony Voices
that are indicated in the Harmony Mode portion of the Preset Screen for your currently selected
preset.
Getting Started
18. You can increase or decrease the amount of voice harmonies in the mix with the Harmony Levels
knob.
15
VL Pro Owner’s Manual
