DigiTech Le Lyra User Manual

Owner’s Manual

NOTE: The information contained in this manual is subject to change at any time without notification. Some
information contained in this manual may also be inaccurate due to undocumented changes in the product or operating
system since this version of the manual was completed. The information contained in this version of the owner’s manual
supersedes all previous versions.

DECLARATION OF CONFORMITY

Manufacturer’s Name: DigiTech®
Manufacturer’s Address: 8760 S. Sandy Parkway
Sandy, Utah 84070, U.S.A.

declares that the product:

Product name: Le Lyra
Product option: all (requires Class II power adapter that conforms
to the requirements of EN60065, EN60742, or equivalent.)

conforms to the following Product Specifications:

Safety IEC 60065 -01+Amd 1
EMC EN 55022:2006
EN 55024:1998
FCC Part 15

Supplementary Information:

The product herewith complies with the requirements of the:
Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC.
RoHS Directive 2002/95/EC
WEEE Directive 2002/96/EC

With regard to Directive 2005/32/EC and EC Regulation 1275/2008 of 17 December 2008,
this product is designed, produced, and classified as Professional Audio Equipment and thus is
exempt from this Directive.

With regard to Directive 2005/32/EC and EC Regulation 278/2009 of 6 April 2009, this
regulation applies to Class A (single output) external power supplies. The external power supply
used with this product is a multi-output power supply and thus is exempt from this Directive.

Roger Johnsen
Director, Engineering
Signal Processing
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Date: December 20, 2010

European Contact: Your local DigiTech Sales and Service Office or

Harman Music Group
8760 South Sandy Parkway
Sandy, Utah
84070 USA
Ph: [phone]
Fax: [phone]

ELECTROMAGNETIC

COMPATIBILITY

This device complies with part 15 of the FCC Rules and
the Product Specifications noted on the Declaration of
Conformity. Operation is subject to the following two
conditions:

• this device may not cause harmful
interference, and

• this device must accept any interference received, including
interference that may cause undesired operation.

Operation of this unit within significant
electromagnetic fields should be avoided.

• use only shielded interconnecting cables.

If you want to dispose this product, do not mix it with gener al househ old waste. There is a
separate collection system for used electronic products in accordance with legislation that
requires proper treatment, recovery and recycling.

Private household in the 25 member states of the EU, in Switzerland and Norway may return their used
electronic products free of charge to designated collection facilities or to a retailer (if you purchase a similar
new one).

For Countries not mentioned above, please contact your local authorities for a correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessar y treatment, recovery and
recycling and thus prevent potential negative effects on the environment and human health.

iii

Warning

For your protection, please read the following:

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Do not use this apparatus near water.

5. Clean only with dry cloth.

6. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that

produce heat.

8. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

9. Unplug this apparatus during lightning storms or when unused for long periods of time.

10. No user serviceable parts inside. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.

11. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

12. Refer to labels on the unit, including bottom cover, or other markings and pertinent information.

Warranty

We at DigiTech® are very proud of our products and back up each one we sell with the following
warranty:

1. Please register online at www.digitech.com within ten days of purchase to validate this warranty.

2. DigiTech warrants this product, when used solely within the U.S., to be free from defects in materials and
workmanship under normal use and service.

3. DigiTech liability under this warranty is limited to repairing or replacing defective materials that show evidence
of defect, provided the product is returned to DigiTech WITH RETURN AUTHORIZATION, where all parts and
labor will be covered up to a period of one year (this warranty is extended to a period of six years when the
product has been properly registered by mail or through our website). A Return Authorization number may be
obtained from DigiTech by telephone. The company shall not be liable for any consequential damage as a result of
the product’s use in any circuit or assembly.

4. Proof-of-purchase is considered to be the burden of the consumer.

5. DigiTech reserves the right to make changes in design, or make additions to, or improvements upon this product
without incurring any obligation to install the same on products previously manufactured.

6. The consumer forfeits the benefits of this warranty if the product’s main assembly is opened and tampered with
by anyone other than a certified DigiTech technician or, if the product is used with AC voltages outside of the
range suggested by the manufacturer.

7. The foregoing is in lieu of all other warranties, expressed or implied, and DigiTech neither assumes nor
authorizes any person to assume any obligation or liability in connection with the sale of this product. In no
event shall DigiTech or its dealers be liable for special or consequential damages or from any delay in the
performance of this warranty due to causes beyond their control.

1

Congratulations and thank you for purchasing the Eternal

Descent Lyra FX Pedal by DigiTech! The DigiTech Lyra pedal is a limited edition
stompbox featuring the tones from the music behind the Eternal Descent
comic book/CD created by guitarist/comic book designer Llexi Leon. The
7 tones in Lyra were originally created using the DigiTech RP1000. These
seven sounds have been custom programmed into the 7 Lyra (song) types,
selectable using the Lyra knob control. The user interface provides further
control over each of these tones by providing Level, Gain and FX Mix
control.

Lyra’s features include:

• Custom Eternal Descent Artwork

• Signature Tones from Eternal Descent sessions Based around custom

RP1000 presets

• Controls for Level, Gain, FX Mix, and Lyra

• Guitar Input

• Mono and Stereo Amplifier Outputs

• Included PS200R DC power supply
