Desa TRINE 598-1186-01 User Manual

FEATURES

Selectable Channels Up to 8 channels reduces the possibility of

interference from other wireless devices.

Volume Control To adjust the sound output to the desired level. On-Off Switch Shuts off all but auxiliary outlet. Long-Range Operation Up to 100 feet (operating range may be

affected by material and construction of home). Auxiliary Outlet 120 VAC, 5 AMP. (MAX.)

INSTALLATION

INSTRUCTIONS FOR

WIRELESS STROBE CHIME

598-1186-01

CHANNEL SETTING

Your new TRINE wireless door chime uses a digital coding system to create eight selectable channels. It is not necessary to change the set

ting, since the wireless door chime is factory pre-set. However, if interference from other devices occurs or if you wish to match to other TRINE wireless door chimes, the channel must have the same settings to operate properly.

On the back of the chime you will ﬁnd connectors numbered one through three. These are for your channel selections. Simply remove one or more connectors to set a new channel.

To change the push button security code, remove one or more of the connectors (1 through 3) on the push button. You must also remove the corresponding connectors on the chime receiver (also 1 through 3). If your chime receiver has more connectors (1 through 6), use only the ﬁrst 3 (1 through 3). It does not matter which connector(s) you remove on the push button. Just be sure they have the same corresponding numbers as the connector(s) that you will remove from the receiver. If connector numbers do not match, your system will not work.

SUGGESTION: Begin by removing just one push button connec

tor and one matching chime connector. Test to see if this eliminated the false triggering problem. If false triggering still occurs, repeat process.

3 2 1

1 2 3

ON/OFF

CONNECTORS

VOLUME CONTROL

AUX.

OUTLET

-2-

The push button enclosed is an eight (8) note Westminster push button which will give you 8 ﬂashes combined with an 8-note Westminster melody.

OPERATION

On the side of the chime you will ﬁnd an on/off switch. Slide switch to ON position. The volume control is also located on the side of the chime. To adjust volume, simply slide to desired volume setting. There is an electric receptacle on the opposite side of the chime, providing additional convenience.

INSTALLING THE CHIME(S)

Place the chime or chimes in logical location (that will afford the greatest usefulness). You need merely plug in to an electrical outlet. Do not place chimes near metal objects such as refrigerators, cabinets or washing machines. Doing so may prevent signal from being clearly received.

MOUNTING THE PUSH BUTTON(S)

Select an appropriate location near the entrance door. Using a ﬂat head screwdriver, press the tab on the bottom of the push button, lift the back plate and use it as a template to mark the mounting hole locations. Drill two 3/16” diameter holes, align the back with the holes. Using the screws provided, attach the push button to the surface. Snap the push button housing in place over the mounted back.

598-1186-01

-3-

INSTALLING BATTERIES INTO PUSH BUTTON(S)

Your new Strobe Chime push button uses a 12 volt battery (Trine A-23). Simply insert into battery compartment by lifting back lid, inserting and closing.

MAINTENANCE

Always replace old or weak battery In push button. Keep chime dry. If wet, dry immediately. Do not use cleaning solvents on electronic products. Solvents contain chemicals that can damage circuitry. Use damp towel or rag to clean. Dry immediately.

Regulatory Information

This device (H8A34RX or BJ4-400TX) complies with Part 15 of the FCC Rules and RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The user is cautioned that changes or modiﬁcations not expressly approved by the party responsible for regulatory compliance could void the userʼs authority to operate the equipment.

Technical Service

(Do Not Send Products)

If you experience a problem, follow this guide. You may also want to visit our Website at: www.desatech.com. If the problem persists, call* for assistance at

1-800-858-8501, 7:30 AM to 4:30 PM CST (M-F). You

may also write* to: DESA Specialty Products

P.O. Box 90004, Bowling Green, KY 42102-9004 ATTN: Technical Service Specialty Products

* If contacting Technical Service, please have the following information available: Model Number, Date of Purchase, and Place of Purchase.

No Service Parts Available for this Product

598-1186-01

-4-

598-1186-01

-5-

DESA Specialty ProductsTM reserves the right to discontinue and to change speciﬁcations at any time without notice without incurring any obligation to incorporate new features in previously sold products.

ONE YEAR LIMITED WARRANTY

This is a “Limited Warranty” which gives you speciﬁc legal rights. You may also have other rights which vary from state to state or province to province. For a period of one year from the date of purchase, any malfunction caused by factory defective parts or workmanship will be corrected at no charge to you. Batteries are not covered. To obtain a refund or a replacement, return the product to the place of purchase. Not Covered - Repair service, adjustment and calibration due to mis

use, abuse or negligence, light bulbs and other expendable items are not covered by this warranty. Unauthorized service or modiﬁcation of the product or of any furnished component will void this warranty in its entirety. This warranty does not include reimbursement for inconve

nience, installation, setup time, loss of use, or unauthorized service. This warranty covers only DESA Specialty Products

assembled products and is not extended to other equipment and components that a customer uses in conjunction with our products. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WAR

RANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY, REPRESENTATION OR CONDITION OF MERCHANT ABILITY OR THAT THE PRODUCTS ARE FIT FOR ANY PARTICULAR PUR

POSE OR USE, AND SPECIFICALLY IN LIEU OF ALL SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. REPAIR OR REPLACEMENT SHALL BE THE SOLE REMEDY OF THE CUSTOMER AND THERE SHALL BE NO LIABILITY ON THE PART OF DESA SPECIALTY PRODUCTS

FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO ANY LOSS OF BUSINESS OR PROFITS, WHETHEROR NOT FORESEEABLE. Some states or provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. Retain receipt for warranty claims.
