UNVENTED (VENT-FREE) GAS LOG HEATER

OWNER’S OPERATION AND INSTALLATION MANUAL

For more information, visit www.desatech.com

Remote-Ready and Variable Manually-Controlled Models Also Design-Certified As Vented Decorative Appliances

FLAME-MAX® Vintage

Oak Log Design

I H

F F

P i l

o t

18", 24" and 30" Variable

Manually-Controlled Models

FLAME-MAX® Golden

Oak Log Design

18", 24", 30", and 36" Variable

Manually-Controlled and

18", 24", and 30" Thermostat-

Controlled Models

18", 24", 30", and 36" Remote-

Ready Model

WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.

— Do not store or use gasoline or other

flammable vapors and liquids in the vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

— Installation and service must be performed

by a qualified installer, service agency, or the gas supplier.

FLAME-MAX® Birch Log

Design

18", 24", and 30" Variable

Manually-Controlled Model

18", 24", and 30"

Remote-Ready Models

WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause injury or property damage. Refer to this manual for correct installation and operational procedures. For assistance or additional information consult a qualified installer, service agency, or the gas supplier.

WARNING: This appliance is for installation only in a solid-fuel burning masonry or UL127 factory-built fireplace, or in a listed ventless firebox enclosure. It i s de sign-certified for these installations in accordance with ANSI Z21.11.2. Exception: Do not install this appliance in a factorybuilt fireplace that includes instructions stating it has not been tested or should not be used with unvented gas logs.

WARNING: This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided. Refer to

Air for Combustion and Ventilation

section on page 5 of this manual.

This appliance may be installed in an aftermarket,* permanently located, manufactured (mobile) home, where not prohibited by local codes.

This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases.

* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer

Save this manual for future reference.

TABLE OF CONTENTS SAFETY INFORMATION

TABLE OF CONTENTS

SAFETY INFORMATION ...................................................................2

PRODUCT IDENTIFICATION ............................................................4

OPTIONAL REMOTE CONTROL ACCESSORIES ...........................5

LOCAL CODES..................................................................................5

UNPACKING......................................................................................5

PRODUCT FEATURES .....................................................................5

AIR FOR COMBUSTION AND VENTILATION ..................................5

INSTALLATION ..................................................................................8

OPERATING HEATER .....................................................................17

INSPECTING BURNERS ................................................................22

CLEANING AND MAINTENANCE ...................................................23

SAFETY INFORMATION

TROUBLESHOOTING .....................................................................24

OPTIONAL POSITIONING OF THERMOSTAT SENSING BULB....27

SPECIFICATIONS ...........................................................................28

WIRING DIAGRAM ..........................................................................29

SERVICE HINTS..............................................................................29

TECHNICAL SERVICE ....................................................................29

REPLACEMENT PARTS .................................................................29

ILLUSTRATED PARTS BREAKDOWN AND PARTS LIST ..............30

ACCESSORIES ...............................................................................44

OWNER’S REGISTRATION FORM.................................................45

WARRANTY INFORMATION ............................................ Back Cover

WARNINGS

WARNING: This product contains and/or generates chemicals known to the State of California to cause cancer or birth defects, or other reproductive harm.

IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning.

DANGER: Carbon monoxide poisoning may lead to death!

Carbon Monoxide Poisoning: Early signs of carbon monoxide

poisoning resemble the flu, with headaches, dizziness, or nausea. If you have these signs, the heater may not be working properly. Get fresh air at once! Have heater serviced. Some people are more affected by carbon monoxide than others. These include pregnant women, people with heart or lung disease or anemia, those under the influence of alcohol, and those at high altitudes.

Natural and Propane/LP Gas: Natural and propane/LP gases are

odorless. An odor-making agent is added to the gas. The odor helps you detect a gas leak. However, the odor added to the gas can fade. Gas may be present even though no odor exists.

Make certain you read and understand all warnings. Keep this manual for reference. It is your guide to safe and proper operation of this heater.

WARNING: Any change to this heater or its controls can be dangerous.

WARNING: Do not use a blower insert, heat exchanger insert, or other accessory not approved for use with this heater.

WARNING: Do not allow fans to blow directly into the fireplace. Avoid any drafts that alter burner flame patterns. Ceiling fans can create drafts that alter burner flame patterns. Altered burner patterns can cause sooting.

Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.

Do not place clothing or other flammable material on or near the appliance. Never place any objects on the heater.

Heater base assembly becomes very hot when running heater. Keep children and adults away from hot surface to avoid burns or clothing ignition. Heater will remain hot for a time after shutdown. Allow surface to cool before touching.

Carefully supervise young children when they are in the room with heater. When using the hand-held remote accessory (Remote-Ready Models Only), keep selector switch in the OFF position to prevent children from turning on burners with remote.

For more information, visit www.desatech.com

107070-01F

SAFETY INFORMATION

Continued

SAFETY INFORMATION

You must operate this heater with a fireplace screen in place. Make sure fireplace screen is closed before running heater.

Keep the appliance area clear and free from combustible materials, gasoline, and other flammable vapors and liquids.

1. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases.

2. Do not place propane/LP supply tank(s) inside any structure. Locate propane/LP supply tank(s) outdoors (propane/LP units only).

4. If you smell gas

• shut off gas supply

• do not try to light any appliance

• do not touch any electrical switch; do not use any phone in

your building

• immediately call your gas supplier from a neighbor’s phone.

Follow the gas supplier’s instructions

• if you cannot reach your gas supplier, call the fire department

4. This heater shall not be installed in a bedroom or bathroom, unless installed as a vented appliance. See Installing Damper Clamp Accessory for Vented Operation, page 11 (RemoteReady and Variable Manually-Controlled Models Only).

5. Before installing in a solid fuel burning fireplace, the chimney flue and firebox must be cleaned of soot, creosote, ashes and loose paint by a qualified chimney cleaner. Creosote will ignite if highly heated. Inspect chimney flue for damage. If damaged, repair flue before operating heater.

6. Do not burn solid-fuel in a masonry or UL127 factory-built fireplace in which a vent-free room heater is installed.

7. If fireplace has glass doors, never operate this heater with glass doors closed. If you operate heater with doors closed, heat buildup inside fireplace will cause glass to burst. Make sure there are no obstructions across openings of fireplace.

8. To prevent the creation of soot, follow the instructions in Clean- ing and Maintenance, page 23.

9. Before using furniture polish, wax, carpet cleaner, or similar products, turn heater off. If heated, the vapors from these products may create a white powder residue within burner box or on adjacent walls and furniture.

10. This heater needs fresh, outside air ventilation to run properly . This heater has an Oxygen Depletion Sensing (ODS) safety shutoff system. The ODS shuts down the heater if enough fresh air is not available. See Air for Combustion and Ventilation, pages 5 through 7. If heater keeps shutting off, see Trouble- shooting, pages 24 through 26.

11. Do not run heater

• where flammable liquids or vapors are used or stored

• under dusty conditions

12. Do not use this heater to cook food or burn paper or other objects.

13. Do not use heater if any part has been exposed to or under water. Immediately call a qualified service technician to inspect the room heater and to replace any part of the control system and any gas control which has been under water.

14. Do not operate heater if any log is broken. Do not operate heater if a log is chipped (dime-sized or larger).

15. Turn heater off and let cool before servicing, installing, or repairing. Make sure the selector switch is in the OFF position (Remote-Ready Models Only). Only a qualified service person should install, service, or repair heater.

16. Make sure the selector switch is in the OFF position when you are away from home for long periods of time (Remote-Ready Models Only).

17. Operating heater above elevations of 4,500 feet may cause pilot outage.

18. T o prevent performance problems, do not use propane/LP fuel tank of less than 100 lb. capacity (propane/LP units only).

19. Provide adequate clearances around air openings.

107070-01F

For more information, visit www.desatech.com

PRODUCT IDENTIFICATION

Flame-Max

Birch Logs

Piezo Ignitor

Burner Assembly

Piezo Ignitor

Burner Assembly

Control Knob

One Piece Log Set

Optional Remote Control

Optional Selector Switch

Flame Adjustment Knob

Flame-Max® Golden Oak Logs

One Piece Log Set

Optional Remote Control

Optional Selector Switch

Flame Adjustment Knob

W A R

M E R

R A U T

N O F F

Piezo Ignitor

W A R

M E R

R A U T

O O N

O F F

Piezo Ignitor

One Piece Log Set

Base Assembly

Control Knob

One Piece Log Set

Base Assembly

Control Knob

Figure 1 - Product Identification

For more information, visit www.desatech.com

Flame-Max® Vintage Oak Logs

Burner

Piezo Ignitor

Burner Assembly

Control Knob

One Piece Log Set

107070-01F

OPTIONAL REMOTE CONTROL ACCESSORIES

LOCAL CODES

UNPACKING

PRODUCT FEATURES

AIR FOR COMBUSTION AND VENTILATION

Providing Adequate Ventilation

There are four optional remote controls that can be purchased separately for Remote-Ready Models Only:

• wall switch • hand-held ON/OFF remote

• wall thermostat • hand-held thermostat remote. See Accessories, page 44.

The wall thermostat or hand-held thermostat may not be used where vented decorative listing is required.

LOCAL CODES

Install and use heater with care. Follow all local codes. In the absence of local codes, use the latest edition of The National Fuel Gas Code ANSI Z223.1/NFPA 54*.

*Available from:

American National Standards Institute, Inc.

1430 Broadway

New York, NY 10018

National Fire Protection Association, Inc.

Batterymarch Park

Quincy, MA 02269

Note:

Where listed vented decorative logs are required, thermostat

operation is not permitted.

UNPACKING

CAUTION: Do not remove the data plates from the grate assembly. The data plates contain important warranty and safety information.

1. Remove logs and heater base assembly from carton. not pick up heater base assembly by burners. This could damage heater. Always handle base assembly by grate.

2. Remove all protective packaging applied to logs and heater for shipment.

3. Check all items for any shipping damage. If damaged, promptly inform dealer where you bought heater.

Note:

PRODUCT FEATURES

OPERATION

This heater is clean burning. It requires no outside venting. There is no heat loss out a vent or up a chimney. Heat is generated by both realistic flames and glowing coals. This heater is designed for ventfree operation with flue damper closed. It has been tested and approved to ANSI Z21.11.2 standard for unvented heaters. State and local codes in some areas prohibit the use of vent-free heaters. This heater may also be operated as a vented decorative (ANSI Z21.60) product by opening the flue damper (Non-Thermostat Models Only).

SAFETY DEVICE

This heater has a pilot with an Oxygen Depletion Sensing (ODS) safety shutoff system. The ODS/pilot is a required feature for ventfree room heaters. The ODS/pilot shuts off the heater if there is not enough fresh air.

PIEZO IGNITION SYSTEM

This heater has a piezo ignitor. This system requires no matches, batteries, or other sources to light heater.

AIR FOR COMBUSTION AND VENTILATION

WARNING: This heater shall not be installed in a confined space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air. Read the following instructions to insure proper fresh air for this and other fuel-burning appliances in your home.

Today’s homes are built more energy efficient than ever. New materials, increased insulation, and new construction methods help reduce heat loss in homes. Home owners weather strip and caulk around windows and doors to keep the cold air out and the warm air in. During heating months, home owners want their homes as airtight as possible.

While it is good to make your home energy efficient, your home needs to breathe. Fresh air must enter your home. All fuel-burning appliances need fresh air for proper combustion and ventilation.

Exhaust fans, fireplaces, clothes dryers, and fuel burning appliances draw air from the house to operate. You must provide adequate fresh air for these appliances. This will insure proper venting of vented fuel-burning appliances.

PROVIDING ADEQUATE VENTILATION

The following are excerpts from National Fuel Gas Code, ANSI Z223.1/NFPA 54, Section 5.3, Air for Combustion and Ventilation.

All spaces in homes fall into one of the three following ventilation classifications:

1. Unusually Tight Construction

2. Unconfined Space

3. Confined Space The information on pages 5 through 7 will help you classify your

space and provide adequate ventilation.

Unusually Tight Construction

The air that leaks around doors and windows may provide enough fresh air for combustion and ventilation. However, in buildings of unusually tight construction, you must provide additional fresh air.

107070-01F

For more information, visit www.desatech.com

AIR FOR COMBUSTION AND VENTILATION

Providing Adequate Ventilation (Cont.) Determining Fresh-Air Flow for Heater Location

AIR FOR COMBUSTION AND VENTILATION

Continued

Unusually tight construction is defined as construction where:

a. walls and ceilings e xposed to the outside atmosphere

have a continuous water vapor retarder with a rating of one perm (6 x 10 openings gasketed or sealed

-11

kg per pa-sec-m2) or less with

and

b. weather stripping has been added on openable win-

dows and doors

and

c. caulking or sealants are applied to areas such as

joints around window and door frames, between sole plates and floors, between wall-ceiling joints, between wall panels, at penetrations f or plumbing, electrical, and gas lines, and at other openings.

If your home meets all of the three criteria above, you must pro vide additional fresh air . See

Air From Outdoors

, page 7

Ventilation

If your home does not meet all of the three criteria above, proceed to

tion,

Determining Fresh-Air Flow For Heater Loca-

below.

Confined and Unconfined Space

The National Fuel Gas Code, ANSI Z223.1/NFPA 54 defines a confined space as a space whose volume is less than 50 cubic feet per 1,000 Btu per hour (4.8 m3 per kw) of the aggregate input rating of all appliances installed in that space and an unconfined space as a space whose volume is not less than 50 cubic feet per 1,000 Btu per hour (4.8 m3 per kw) of the aggregate input rating of all appliances installed in that space. Rooms communicating directly with the space in which the appliances are installed*, through openings not furnished with doors, are considered a part of the unconfined space.

* Adjoining rooms are communicating only if there are doorless passageways or ventilation grills between them.

DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION

Determining if You Have a Confined or Unconfined Space

Use this work sheet to determine if you have a confined or unconfined space. Space: Includes the room in which you will install heater plus any adjoining

rooms with doorless passageways or ventilation grills between the rooms.

1. Determine the volume of the space (length x width x height). Length x Width x Height =___________ cu. ft. (volume of space)

Example:

height) = 2560 cu. ft. (volume of space) If additional ventilation to adjoining room is supplied with grills or open-

ings, add the volume of these rooms to the total volume of the space.

Space size 20 ft. (length) x 16 ft. (width) x 8 ft. (ceiling

2. Multiply the space volume by 20 to determine the maximum Btu/Hr the space can support.

__________ (volume of space) x 20 = (Maximum Btu/Hr the space

can support)

Example:

Btu/Hr the space can support)

3. Add the Btu/Hr of all fuel burning appliances in the space.

* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.

4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.

__________________ Btu/Hr (maximum the space can support) __________________ Btu/Hr (actual amount of Btu/Hr used)

Example:

The space in the above example is a confined space because the actual Btu/ Hr used is more than the maximum Btu/Hr the space can support. You must provide additional fresh air. Your options are as follows:

A. Rework worksheet, adding the space of an adjoining room. If the ex-

tra space provides an unconfined space, remove door to adjoining room or add ventilation grills between rooms. See V entilation Air Fr om Inside Building, page 7.

B. Vent room directly to the outdoors. See Ventilation Air From Out-

doors, page 7.

C. Install a lower Btu/Hr heater, if lower Btu/Hr size makes room unconfined. If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support,

the space is an unconfined space. You will need no additional fresh air ventilation.

2560 cu. ft. (volume of space) x 20 = 51,200 (maximum

Vent-free heater _____________ Btu/Hr Gas water heater* _____________ Btu/Hr Gas furnace _____________ Btu/Hr Vented gas heater _____________ Btu/Hr Gas fireplace logs _____________ Btu/Hr Other gas appliances* + _____________ Btu/Hr Total = _____________ Btu/Hr

Example:

Gas water heater _____________ Btu/Hr Vent-free heater + _____________ Btu/Hr Total = _____________ Btu/Hr

51,200 Btu/Hr (maximum the space can support) 73,000 Btu/Hr (actual amount of Btu/Hr used)

40,000 33,000 73,000

WARNING: If the area in which the heater may be operated is smaller than that defined as an unconfined space or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of the methods described in the

National Fuel Gas Code, ANSI Z223.1/NFPA 54 Section 5.3

or applicable local codes

For more information, visit www.desatech.com

107070-01F

AIR FOR COMBUSTION AND VENTILATION

Continued

VENTILATION AIR

AIR FOR COMBUSTION AND VENTILATION

Ventilation Air

Ventilation Air From Inside Building

This fresh air would come from an adjoining unconfined space. When ventilating to an adjoining unconfined space, you must provide two permanent openings: one within 12" of the ceiling and one within 12" of the floor on the wall connecting the two spaces (see options 1 and 2, Figure 2). You can also remove door into adjoining room (see option 3, Figure 2). Follow the National Fuel

Gas Code, ANSI Z223.1/NFPA 54, Section 5.3, Air for Combustion and Ventilation for required size of ventilation grills or ducts.

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent openings: one within 12" of the ceiling and one within 12" of the floor. Connect these items directly to the outdoors or spaces open to the outdoors. These spaces include attics and crawl spaces. Follow the National Fuel Gas Code, ANSI

Z223.1/NFPA 54, Section 5.3, Air for Combustion and Ventilation

for required size of ventilation grills or ducts.

IMPORTANT:

attic if attic has a thermostat-controlled power vent. Heated air entering the attic will activate the power vent.

Do not provide openings for inlet or outlet air into

12"

Ventilation

Grills

Into Adjoining

Room,

Option 1

Figure 2 - Ventilation Air from Inside Building

Outlet Air

Remove Door into Adjoining

Room, Option

12"

Outlet Air

Ventilation Grills

Into Adjoining Room,

Option 2

Ventilated Attic

To Attic

107070-01F

Inlet Air

Figure 3 - Ventilation Air from Outdoors

For more information, visit www.desatech.com

Crawl

Space

Ventilated

Crawl Space

INSTALLATION

Check Gas Type Installation and Clearances for Vent-Free Operation

INSTALLATION

NOTICE: This heater is intended for use as supplemental heat. Use this heater along with your primary heating system. Do not install this heater as your primary heat source. If you have a central heating system, you may run system’s circulating blower while using heater. This will help circulate the heat throughout the house. In the event of a power outage, you can use this heater as your primary heat source.

WARNING: A qualified service person must in-

stall heater. Follow all local codes.

NOTICE: State or local codes may only allow operation of this appliance in a vented configuration. Check your state or local codes.

WARNING: Make sure the selector switch is in the OFF position before installing heater (Remote-Ready Models Only).

WARNING: Before installing in a solid fuel burning fireplace, the chimney flue and firebox must be cleaned of soot, creosote, ashes and loose paint by a qualified chimney cleaner. Creosote will ignite if highly heated. A dirty chimney flue and firebox may create and distribute soot within the house. Inspect chimney flue for damage. If damaged, repair flue before operating heater.

CAUTION: This heater creates warm air currents. These currents move heat to wall surfaces next to heater. Installing heater next to vinyl or cloth wall coverings or operating heater where impurities (such as, but not limited to, tobacco smoke, aromatic candles, cleaning fluids, oil or kerosene lamps, etc.) in the air exist, may discolor walls or cause odors.

IMPORTANT:

this is beneficial, installing heater in rooms without enough ventilation air may cause mildew to form from too much moisture. See Air for Combustion and Ventilation, pages 5 through 7.

Vent-free heaters add moisture to the air. Although

CHECK GAS TYPE

Use the correct gas type (natural or propane/LP) for your unit. If your gas supply is not correct, do not install log set. Call dealer where you bought log set for proper type fireplace.

INSTALLATION AND CLEARANCES FOR VENT-FREE OPERATION

WARNING: Maintain the minimum clearances. If you can, provide greater clearances from floor, ceiling, and adjoining wall.

MINIMUM FIREPLACE

CLEARANCE TO

COMBUSTIBLE MATERIALS

WARNING: Seal any fresh air vents or ash cleanout doors located on floor or wall of fireplace. If not, drafting may cause pilot outage or sooting. Use a heatresistant sealant. Do not seal chimney flue damper.

WARNING: Never install the heater

• in a bedroom or bathroom unless installed as a

vented appliance, see page 11 (Remote-Ready and Variable Manually-Controlled Models Only)

• in a recreational vehicle

• where curtains, furniture, clothing, or other flam-

mable objects are less than 42 inches from the front, top, or sides of the heater

• in high traffic areas

• in windy or drafty areas

For more information, visit www.desatech.com

Log Size Side Wall Ceiling

18", 24", 16" 42"

30", and 36"

LOG SIZING REQUIREMENTS

Log Minimum Firebox Size Height Depth Front Rear *

Width Width

18" 17" 14" 24" 20" 24" 17" 14" 28" 21" 30" 17" 14" 34" 24" 36" 17" 14" 40" 30"

* Measured at 14" depth.

107070-01F

INSTALLATION

Continued

Installation and Clearances for Vent-Free Operation (Cont.)

INSTALLATION

Carefully follow the instructions below. This will ensure safe installation into a masonry, UL127-listed manufactured fireplace, or listed vent-free firebox.

Minimum Clearances For Side Combustible Material, Side Wall, and Ceiling

A. Clearances from the side of the fireplace cabinet to any combus-

tible material and wall should follow diagram in Figure 4.

Example:

combustible material and protrudes 3 1/2" from the wall. This combustible material must be 4" from the side of the fireplace cabinet (see Figure 4).

Note:

follow firebox manufacturer’s instructions for minimum clearances to combustible materials.

B. Clearances from the top of the fireplace opening to the ceiling

should not be less than 42 inches.

*Minimum 16 inches from Side Wall

Figure 4 - Minimum Clearance for Combustible to Wall

NOTICE: Manual control heaters may be used as a vented product. If so, you must always run heater with chimney flue damper open. If running heater with damper open, noncombustible material above fireplace opening is not needed. Go to

Clamp Accessory for Vented Operation,

The face of a mantel, bookshelf, etc. is made of

When installing your gas logs into a manufactured firebox,

Example

Installing Damper

page 11.

If Using Mantel

You must have noncombustible material(s) above the fireplace opening. Noncombustible materials (such as slate, marble, tile, etc.) must be at least 1/2 inch thick. With sheet metal, you must have noncombustible material behind it. Noncombustible material must extend at least 8 inches up (for all models). If noncombustible material is less than 12", you must install the fireplace hood accessory (24", 30" and 36" Models Only). Even if noncombustible material is more than 12", you may need the hood accessory to deflect heat away from your mantel shelf. See Figure 5 and Figures 6 and 7, page 10, for minimum clearances.

IMPORTANT:

If you cannot meet these minimum clearances, you must operate heater with chimney flue damper open. Go to Install- ing Damper Clamp Accessory for Vented Operation, page 11.

Noncombustible Requirements for Material Distance (A) Safe Installation

12" or more Noncombustible material OK. Between 8" and 12" 24" ,30" or 36" Models: Install

fireplace hood accessory (GA6050, GA6052, or GA6053 see

ries

, page 44).

18" Model: Noncombustible material OK.

Less than 8" Noncombustible material must be

extended to at least 8". See

8" and 12"

extend material, you must operate heater with flue damper open.

Heat Resistant Material

, above. If you cannot

(A)

Accesso-

Between

Minimum Noncombustible Material Clearances

If Not Using Mantel

Note:

If using a mantel proceed to If Using Mantel. If not using a

mantel, follow the information on this page. You must have noncombustible material(s) above the fireplace

opening. Noncombustible materials (such as slate, marble, tile, etc.) must be at least 1/2 inch thick. With sheet metal, you must have noncombustible material behind it. Noncombustible material must extend at least 8" up (for all models). If noncombustible material is less than 12", you must install the fireplace hood accessory (24", 30" and 36" Models Only). See Figure 5 for minimum clearances.

For more information, visit www.desatech.com

107070-01F

Figure 5 - Heat Resistant Material (Slate, Marble, Tile, etc.) Above Fireplace

Hearth

5" Min.

Combustible Material

INSTALLATION

Mantel Clearances Floor Clearances

INSTALLATION

Continued

MANTEL CLEARANCES

In addition to meeting noncombustible material clearances, you must also meet required clearances between fireplace opening and mantel shelf. If you do not meet the clearances listed below, you will need a hood.

Determining Minimum Mantel Clearance

If you meet minimum clearance between mantel shelf and top of fireplace opening, a hood is not required (see Figure 6).

Determining Minimum Mantel Clearance When Using a Hood

If minimum clearances in Figure 6 are not met, you must have a hood. When using a hood there are still certain minimum mantel clearances required. Follow minimum clearances shown in Figure 7 when using hood.

NOTICE: Surface temperatures of adjacent walls and mantels become hot during operation. Walls and mantels above the firebox may become hot to the touch. If installed properly, these temperatures meet the requirement of the national product standard. Follow all minimum clearances shown in this manual.

NOTICE: If your installation does not meet the minimum clearances shown, you must do one of the following:

• operate the logs only with the flue damper open

• raise the mantel to an acceptable height

• remove the mantel

FLOOR CLEARANCES

A. If installing appliance on the floor level, you must maintain

the minimum distance of 14" to combustibles (see Figure 8).

B. If combustible materials are less than 14" to the fireplace, you

must install appliance at least 5" above the combustible flooring (see Figure 9).

Mantel Shelf

18"8"20"

14"

Distances to Underside of Mantel

22" 17"

Underside of Mantel Shelf

24" 20"

Top of Fireplace Opening

All minimum distances are in inches

Log Set

24"/30"/36" Models 18" Model

Minimum NonCombustible Material

10" 8" 6"

(A)

12" 8"

Minimum NonCombustible Material Height

Figure 6 - Minimum Mantel Clearances Without Using Hood

8" Min.

Mantel Shelf

12" 15" 18"

Distances to Underside of Mantel

Underside of Mantel Shelf

All minimum distances are in inches

20"

Top of Fireplace Opening

Minimum NonCombustible Material

12" 10" 8" 6"

Hood

(GA6050, GA6052,

(GA6050, GA6052)

or GA6053)

Figure 7 - Minimum Mantel Clearances When Using Hood

Combustible Material

14" Min.

Noncombustible

Non-Combustible Material

Material

Figure 8 - Minimum Fireplace Clearances If Installed at Floor Level

For more information, visit www.desatech.com

Figure 9 - Minimum Fireplace Clearances Above Combustible Flooring

107070-01F

INSTALLATION

Continued

Installing Damper Clamp Accessory for Vented Operation

INSTALLATION

Installing Heater Base Assembly

INSTALLING DAMPER CLAMP ACCESSORY FOR VENTED OPERATION

Note:

When used as a vented heater, appliance must be installed only in a solid-fuel burning fireplace with a working flue and constructed of noncombustible material.

If your heater is a manually-controlled model, you may use this heater as a vented product. There are three reasons for operating your heater in the vented mode.

1. The fireplace does not meet the clearance to combustibles re-

quirements for vent-free operation.

2. State or local codes do not permit vent-free operation.

3. You prefer vented operation. If reasons number 1 or 2 above apply to you, you must permanently

open chimney flue damper. You must install the damper clamp accessory (to order, see Accessories, page 44). This will insure vented operation (see Figure 10). The damper clamp will keep damper open. Installation instructions are included with clamp accessory.

See chart below for minimum permanent flue opening you must provide. Attach damper clamp so the minimum permanent flue opening will be maintained at all times.

Area of Various Standard

Round Flues

Diameter (ins.) Area (sq. ins.)

5" 20 sq. inches 6" 29 sq. inches 7" 39 sq. inches 8" 51 sq. inches

Chimney Minimum Permanent

Height (ft.) Flue Opening (sq. ins.)

6' to 15' 39 sq. inches

15' to 30' 29 sq. inches

Damper Clamp

Damper

Masonry Fireplace

Manufactured Fireplace

Damper

INSTALLING HEATER BASE ASSEMBLY

WARNING: You must secure this heater to fireplace floor. If not, heater will move when you adjust controls. Moving heater may cause a gas leak or log misplacement.

WARNING: If installing in a sunken fireplace, special care is needed. You must raise the fireplace floor to allow access to heater control panel. This will insure adequate air flow and guard against sooting and controls being damaged. Raise fireplace floor with noncombustible material. Make sure material is secure.

CAUTION: Do not pick up heater base assembly by burners. This could damage heater. Only handle base assembly by grates.

IMPORTANT:

not level, heater will not work properly. For thermostat models, avoid damage to thermostat bulb. Avoid nicks or sharp bends in thermostat bulb wire. Keep thermostat bulb in mounting bracket until ready to mount base to floor. See Optional Positioning Of Thermostat Sensing Bulb, page 27.

Installation Items Needed

• hardware package (provided with heater)

• approved flexible gas hose and fittings (not provided) (if allowed by local codes)

• sealant (resistant to propane/LP gas, not provided)

• electric drill with 3/16" drill bit (metal or masonry as applicable)

• flathead screwdriver

• pipe wrench

1. Apply pipe joint sealant lightly to male threads of gas fitting

(not provided). For Variable Manually-Controlled and Thermostat-Controlled Models connect approved flexible gas hose to gas regulator of heater (see Figure 11, page 12). For Remote-Ready models connect approved flexible gas hose to gas control fitting in heater (see Figure 12, page 12).

IMPORTANT:

ing flexible gas hose (Variable Manually-Controlled and Thermostat-Controlled Models Only). Hold gas fitting with wrench when connecting flexible gas hose (Remote-Ready Models Only).

2. Locate two masonry screws in hardware package.

3. Place heater base in fireplace.

Make sure the heater burners are level. If heater is

Hold gas regulator with wrench when connect-

Figure 10 - Attaching Damper Clamp

For more information, visit www.desatech.com

107070-01F

INSTALLATION

Installing Heater Base Assembly (Cont.)

INSTALLATION

Continued

4. Place logs in their proper position on heater base (see Installing Logs, pages 15 and 16).

5. Center heater base and logs front-to-back and side-to-side in fireplace.

6. Carefully remove logs without moving heater base.

7. Mark screw locations through one hole on each side of the mounting bracket (see Figures 13, 14 or 15, depending on your model). If installing in a brick-bottom fireplace, mark screw locations in mortar joint of bricks.

8. Remove heater base from fireplace. If installing optional control accessories, do so at this time (Remote-Ready Models Only). Follow all directions provided with accessory .

9. Drill holes at marked locations using 3/16" drill bit.

10. Attach base assembly to fireplace floor using two masonry screws (in hardware package).

Heater Gas Regulator

Masonry Screw

VINTAGE OAK LOG CHASSIS (Variable Manually-Controlled and Thermostat-Controlled Models)

Figure 13 - Attaching Heater to Fireplace Floor (Variable ManuallyControlled and Thermostat-Controlled Models Only)

Bracket with Screw Holes

Masonry Screw

Fitting

Flexible Gas Hose (if allowed by local codes)

Figure 11 - Attaching Flexible Gas Hose to Heater Gas Regulator (Variable Manually-Controlled and ThermostatControlled Models Only)

Flexible Gas Hose (if allowed by local codes)

Fitting

Figure 12 - Attaching Flexible Gas Hose to Heater (RemoteReady Models Only)

GOLDEN OAK AND BIRCH MODEL CHASSIS (Variable Manually-Controlled and Thermostat-Controlled Models)

Figure 14 - Attaching Base to Fireplace Floor (Remote-Ready Models Only)

GOLDEN OAK AND BIRCH MODEL CHASSIS (Remote-Ready Models)

Bracket with Screw Holes

Masonry Screw

Bracket with Screw Holes

Figure 15 - Attaching Base Assembly to Fireplace Floor

For more information, visit www.desatech.com

107070-01F

INSTALLATION

Continued

Connecting To Gas Supply

INSTALLATION

CONNECTING TO GAS SUPPLY

WARNING: This appliance requires a 1/2" NPT (National Pipe Thread) inlet connection to the pressure regulator.

WARNING: A qualified service person must connect heater to gas supply. Follow all local codes.

CAUTION: Never connect propane/LP fireplace directly to the propane/LP supply. This heater requires an external regulator (not supplied). Install the external regulator between the heater and propane/LP supply.

WARNING: Never connect natural gas fireplace to private (non-utility) gas wells. This gas is commonly known as wellhead gas.

Installation Items Needed

Before installing heater, make sure you have the items listed below.

• external regulator (supplied by installer)

• piping (check local codes)

• sealant (resistant to propane/LP gas)

• equipment shutoff valve *

• test gauge connection *

• sediment trap

• tee joint

• pipe wrench * A CSA design-certified equipment shutoff valve with 1/8" NPT

tap is an acceptable alternative to test gauge connection. Purchase the optional CSA design-certified equipment shutoff valve from your dealer. See Accessories, page 44.

For propane/LP units, the installer must supply an external regulator. The external regulator will reduce incoming gas pressure. You must reduce incoming gas pressure to between 11 and 14 inches of water. If you do not reduce incoming gas pressure, heater regulator damage could occur. Install external regulator with the vent pointing down as shown in Figure 16. Pointing the vent down protects it from freezing rain or sleet.

Installation must include an equipment shutoff valve, union, and plugged 1/8" NPT tap. Locate NPT tap within reach for test gauge hook up. NPT tap must be upstream from heater (see Figures 17 or 18 page 14, depending on your model).

IMPORTANT:

location. The equipment shutoff valve is for turning on or shutting off the gas to the appliance.

Check your building codes for any special requirements for locating equipment shutoff valve to fireplaces.

Apply pipe joint sealant lightly to male NPT threads. This will prevent excess sealant from going into pipe. Excess sealant in pipe could result in clogged heater valves.

WARNING: Use pipe joint sealant that is resistant

to liquid petroleum (LP) gas.

We recommend that you install a sediment trap in supply line as shown in Figures 17 or 18 page 14, depending on your model. Locate sediment trap where it is within reach for cleaning. Install in piping system between fuel supply and heater. Locate sediment trap where trapped matter is not likely to freeze. A sediment trap traps moisture and contaminants. This keeps them from going into heater controls. If sediment trap is not installed or is installed wrong, heater may not run properly.

CAUTION: Avoid damage to regulator. Hold gas regulator with wrench when connecting it to gas piping and/or fittings (Variable Manually-Controlled and Thermostat-Controlled Models Only).

CAUTION: Avoid damage to gas control. Hold gas fitting with wrench when connecting it to gas piping and/or fittings (Remote-Ready Models Only).

Install equipment shutoff valve in an accessible

External Regulator Propane/LP Supply Tank

CAUTION: Use only new, black iron or steel pipe. Internally-tinned copper tubing may be used in certain areas. Check your local codes. Use pipe of 1/2" diameter or greater to allow proper gas volume to heater. If pipe is too small, undue loss of volume will occur.

For more information, visit www.desatech.com

107070-01F

Vent Pointing Down

Figure 16 - External Regulator With Vent Pointing Down

INSTALLATION

Connecting to Gas Supply (Cont.) Checking Gas Connections

INSTALLATION

Continued

CSA Design-Certified Equipment

PROPANE/LP

From External Regulator (11" W.C.** to 14" W.C. Pressure)

NATURAL

From Gas Meter (5" W.C.** to 10.5" W.C. Pressure)

Tee Cap Pipe Joint Nipple

Figure 17 - Gas Connection (Variable Manually-Controlled and Thermostat-Controlled Models Only)

CSA Design-Certified Equipment Shutoff Valve With 1/8" NPT Tap*

Approved Flexible Gas Hose (if allowed by local codes)

Gas Control

Figure 18 - Gas Connection (Remote-Ready Models Only)

* Purchase the optional CSA design-certified equipment shutoff valve

from your dealer. See Accessories, page 44.

** Minimum inlet pressure for purpose of input adjustment.

Shutoff Valve With 1/8" NPT Tap*

Approved Flexible Gas Hose (if allowed by local codes)

3" Minimum

Sediment Trap

3" Minimum

Pipe Cap Tee Nipple Joint

Sediment Trap

Gas Regulator

PROPANE/LP From External Regulator (11" W.C.** to 14" W.C. Pressure)

NATURAL From Gas Meter (5" W.C.** to 10.5" W.C. Pressure)

CHECKING GAS CONNECTIONS

WARNING: Test all gas piping and connections, internal and external to uni t, for leaks after installing or servicing. Correct all leaks at once.

WARNING: Never use an open flame to check for a leak. Apply a noncorrosive leak detection fluid to all joints. Bubbles forming show a leak. Correct all leaks at once.

CAUTION: Make sure external regulator has been installed between propane/LP supply and heater. See guidelines under

Pressure Testing gas Supply Piping system

Test Pressures In Excess Of 1/2 PSIG (3.5 kPa)

1. Disconnect appliance with its appliance main gas valve (control valve) and equipment shutoff valve from gas supply piping system. Pressures in excess of 1/2 psig will damage heater regulator.

2. Cap off open end of gas pipe where equipment shutoff valve was connected.

3. Pressurize supply piping system by either opening propane/LP supply tank valve for propane/LP gas or opening main gas valve located on or near gas meter for natural gas, or using compressed air.

4. Check all joints of gas supply piping system. Apply noncorrosive leak detection fluid to all joints. Bubbles forming show a leak.

5. Correct all leaks at once.

6. Reconnect heater and equipment shutoff valve to gas supply. Check reconnected fittings for leaks.

Test Pressures Equal To or Less Than 1/2 PSIG (3.5 kPa)

1. Close equipment shutoff valve (see Figure 19, page 15).

2. Pressurize supply piping system by either opening propane/LP supply tank valve for propane/LP gas or opening main gas valve located on or near gas meter for natural gas, or using compressed air.

3. Check all joints from gas meter to equipment shutoff valve for natural gas or propane/LP supply to equipment shutoff valve for propane/LP (see Figures 20 and 21, page 15). Apply noncorrosive leak detection fluid to all joints. Bubbles forming show a leak.

4. Correct all leaks at once.

Connecting to Gas Supply

, page 13.

For more information, visit www.desatech.com

107070-01F

INSTALLATION

Continued

Pressure Testing Heater Gas Connections

1. Open equipment shutoff valve (see Figure 19).

2. Open main gas valve located on or near gas meter for natural gas or open propane/LP supply tank valve.

3. Make sure control knob of heater is in the OFF position.

4. Check all joints from equipment shutoff valve to thermostat gas valve (Thermostat-Controlled Models), to control valve (Manually-Controlled Models), or to gas control (RemoteReady Models)(see Figures 20 and 21). Apply noncorrosive leak detection fluid to all joints. Bubbles forming show a leak.

5. Correct all leaks at once.

6. Light heater (see Operating Heater, pages 17 through 22, depending on your model). Check all other internal joints for leaks.

7. Turn off heater (see To Turn Off Gas to Appliance, page 18 for Thermostat-Controlled models, page 19 for Manually-Controlled Models, or page 21 for Remote-Ready Models).

Gas Meter

Checking Gas Connections (Cont.)

Equipment Shutoff Valve

INSTALLATION

Installing Logs

Thermostat Gas Valve or Control Valve Location

Equipment Shutoff Valve

Figure 19 - Equipment Shutoff Valve

Equipment

Shutoff Valve Propane/LP Supply Tank

Figure 20 - Checking Gas Joints (Propane/LP Model Shown)

Open

POSITION

OFF

POSITION

Closed

Thermostat Gas Valve or Control Valve Location

Figure 21 - Checking Gas Joints (Natural Gas Only)

INSTALLING LOGS

WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this heater may result in property damage or personal injury.

CAUTION: After installation and periodically thereafter, check to ensure that no flame comes in contact with any log. With the heater set to High, check to see if flames contact any log. If so, reposition logs according to the log installation instructions in this manual. Flames contacting logs will create soot.

It is very important to install the logs exactly as instructed. Do not modify logs. Only use logs supplied with heater.

1. Place one-piece log set on grate to fit as illustrated in Figure 22 on page 16 for Vintage Oak models and Figure 23 on page 16 for Golden Oak or Birch models. For V intage Oak models make sure bottom of front log is in front of “U”-shaped cutout in center of chassis (see Figure 22, page 16). For Golden Oak or Birch models make sure middle section at bottom of log set is seated into “U”-shaped cutout in center of chassis (see Figure 23, page 16). but fit on the chassis the same. Log will fit securely on chassis.

IMPORTANT:

(see Figures 24 or 25, page 16).

2. Place lava rock around base of heater if desired.

Note:

36" and birch models have more features

Make sure log does not cover any burner ports

107070-01F

For more information, visit www.desatech.com

INSTALLATION

Installing Logs (Cont.)

INSTALLATION

Continued

One-Piece Log Set

Burner

Burner Ports

One Piece Log Set

Chassis

“U”-shaped Cutout in Chassis

Figure 22 - Installing Vintage Oak One-Piece Log Set Figure 24 - Installing Vintage Oak One-Piece Log Set (Top View)

One-Piece Log Set

Middle Section at Bottom of Log Set

Burner

Chassis

“U”-shaped Cutout in Chassis

Burner Ports

One Piece Log Set

Figure 23 - Installing Golden Oak or Birch One-Piece Log Set

For more information, visit www.desatech.com

Figure 25 - Installing Golden Oak or Birch One-Piece Log Set (Top View)

107070-01F

OPERATING HEATER (THERMOSTAT-CONTROLLED MODELS)

OPERATING HEATER

THERMOSTAT-CONTROLLED MODELS

FOR YOUR SAFETY

READ BEFORE LIGHTING

WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

For Your Safety Read Before Lighting

Note:

Home owners generally prefer to operate their heater

Lighting Instructions

with the chimney damper closed. This will put all the heat into the room. However, there may be times you will desire the full flames of the HI heat setting but will find the heat output excessive. You can open the chimney damper (if you have one) fully or partially to release some of the heat.

WARNING: Damper handle will be hot if heater has

been running.

A. This appliance has a pilot which must be lighted by hand.

When lighting the pilot, follow these instructions exactly.

B. BEFORE LIGHTING smell all around the appliance ar ea

for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

C. Use only your hand to push in or turn the gas control knob.

Never use tools. If the knob will not push in or turn by hand, don’t try to repair it, call a qualified service technician or gas supplier. Force or attempted repair may result in a fire or explosion.

D. Do not use this appliance if any part has been under water.

Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.

LIGHTING

INSTRUCTIONS

WARNING:

• If fireplace has glass doors, never operate this heater with glass doors closed. If you operate heater with doors closed, heat buildup inside fireplace will cause glass to burst. Make sure there are no obstructions across opening of fireplace.

• You must operate this heater with a fireplace screen in place. Make sure fireplace screen is closed before running heater.

NOTICE: During initial operation of new heater, burning logs will give off a paper-burning smell. Orange flame will also be present. Open damper or window to vent smell. This will only last a few hours.

1. STOP! Read the safety information column 1.

2. Make sure equipment shutoff valve is fully open.

3. Turn control knob clockwise

to the OFF position.

Clockwise

4. Wait five (5) minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the safety information, column 1. If you don’t smell gas, go to the next step.

5. Turn control knob counterclockwise

C-clockwise

to the PILOT position. Press in control knob for five (5) seconds (see Figure 26).

Note:

You may be running this heater for the first time after hooking up to gas supply . If so, the control knob may need to be pressed in for 30 seconds or more. This will allow air to bleed from the gas system.

• If control knob does not pop out when released, contact

a qualified service person or gas supplier for repairs.

6. With control knob pressed in, press and release ignitor button. This will light pilot. The pilot is attached to the front burner . If needed, keep pr essing ignitor button until pilot lights.

Note:

If pilot does not stay lit, contact a qualified service person or gas supplier for repairs. Until repairs ar e made, light pilot with match. T o light pilot with ma tch, see Manual Lighting Procedure on page 18.

7. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob.

Note:

If pilot goes out, repeat steps 3 through 7. This heater has a safety interlock system. Wait one (1) minute for system to reset before lighting pilot again.

8. Turn control knob counterclockwise to desired heating level. The b urners should light. Set control knob to any heat level between HI and LO.

Thermocouple

Pilot Burner

Appearance of pilot

I H

i l

o t

Ignitor Button

Control Knob

Figure 26 - Control Knob and Ignitor Button Location

Ignitor Electrode

Figure 27 - Pilot

(

Note:

assembly may vary by model.)

107070-01F

For more information, visit www.desatech.com

OPERATING HEATER (THERMOSTAT-CONTROLLED MODELS)

To Turn Gas Off To Appliance Thermostat Control Operation Manual Lighting Procedure

OPERATING HEATER (MANUALLY-CONTROLLED MODELS)

For Your Safety Read Before Lighting Lighting Instructions

OPERATING HEATER

Continued

CAUTION: Do not try to adjust heating levels by

using the equipment shutoff valve.

TO TURN OFF GAS

TO APPLIANCE

Shutting Off Heater

Turn control knob clockwise to the OFF position.

Shutting Off Burners Only (pilot stays lit)

Turn control knob clockwise to the PILOT position.

THERMOSTAT CONTROL

OPERATION

The thermostat control knob can be set to any comfort level between HI and LO. The thermostat will gradually modulate the heat output and flame height from higher to lower settings, or pilot, in order to maintain the comfort level you select. The ideal comfort setting will vary by household depending upon the amount of space to be heated, the output of the central heating system, etc.

Note:

Selecting the HI setting with the control knob will cause the

burner to remain fully on, without modulating down in most cases.

MANUAL LIGHTING

PROCEDURE

1. Follow steps 1 through 5 under Lighting Instructions, page 17.

2. Depress control knob and light pilot with match.

3. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob. Now follow step 8, page 17.

MANUALLY-CONTROLLED MODELS

FOR YOUR SAFETY

READ BEFORE LIGHTING

WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

A. This appliance has a pilot which must be lighted by hand.

When lighting the pilot, follow these instructions exactly.

B. BEFORE LIGHTING smell all around the appliance ar ea

for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

C. Use only your hand to push in or turn the gas control knob.

D. Do not use this appliance if any part has been under water.

Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.

LIGHTING

INSTRUCTIONS

WARNING:

• You must operate this heater with a fireplace screen in place. Make sure fireplace screen is closed before running heater.

Note:

Home owners generally prefer to operate their heater

WARNING: Damper handle will be hot if heater has

been running.

1. STOP! Read the safety information column 1 and 2.

2. Make sure equipment shutoff valve is fully open.

3. Press in and turn control knob clockwise to the OFF position.

For more information, visit www.desatech.com

107070-01F

OPERATING HEATER

Continued

OPERATING HEATER (MANUALLY-CONTROLLED MODELS)

Lighting Instructions (Cont.)

Variable Control Operation

To Turn Gas Off To Appliance

Manual Lighting Procedure

OPERATING HEATER (REMOTE-READY MODELS)

For Your Safety Read Before Lighting

4. Wait five (5) minutes to clear out any gas. Then smell for gas, including near the floor . If y ou smell gas, STOP! F ollow “B” in the safety information, starting in column 1, page 18. If you don’t smell gas, go to the next step.

5. Slightly depress and turn control knob counterclockwise

to the PILOT position. K eep control knob pressed

in for five (5) seconds (see Figure 28).

Note:

You may be running this heater for the first time

after hooking up to gas supply . If so, the contr ol knob may need to be pressed in for 30 seconds or more. This will allow air to bleed from the gas system.

6. With control knob pressed in, press and r elease ignitor button. This will light pilot. T he pilot is attached to the burner. If needed, keep pressing ignitor button until pilot lights.

Note:

If pilot does not light, contact a qualified service person or gas supplier for repairs. Until repairs ar e made, light pilot with match. T o light pilot with matc h, see Manual Lighting Procedure, column 2.

7. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob.

• If control knob does not pop out when released, contact

a qualified service person or gas supplier for repairs.

Note:

If pilot goes out, repeat steps 3 through 7.

8. Slightly depress and turn control knob counterclockwise

to the HI position. The burner should light. Set

C-clockwise

control knob to any heat level between HI and LO.

Ignitor Electrode

Thermocouple

PILOT

OFF

Pilot Burner

TO TURN OFF GAS

TO APPLIANCE

Shutting Off Heater

1. Press in and turn control knob clockwise HI position.

2. Turn the control knob clockwise

Clockwise

position.

3. Press in control knob and turn clockwise OFF position.

to the PILOT

Clockwise

to the

Shutting Off Burners Only (pilot stays lit)

1. T urn the control knob clockwise

2. Press in and turn control knob clockwise PILOT position.

to the HI position.

Clockwise

to the

MANUAL LIGHTING

PROCEDURE

1. Follow steps 1 through 5 under Lighting Instructions, pa ges 18 and 19.

2. Depress control knob and light pilot with match.

3. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob. Now follow step 8, column 1.

REMOTE-READY MODELS

FOR YOUR SAFETY READ

BEFORE LIGHTING

Ignitor Button

Figure 28 - Control Knob and Ignitor Button Location

Control Knob

Figure 29- Pilot

(

Note:

Appearance of pilot

assembly may vary by model.)

VARIABLE CONTROL

OPERATION

The variable control valve can be set to any heat setting and flame height desired, by simply turning the control knob until that setting is attained. Even the lowest setting provides realistic, dancing yellow flames. Selecting higher settings produces greater heat output. This results in increased heating comfort.

WARNING: Do not operate heater between PILOT

and HI positions.

CAUTION: Do not try to adjust heating levels by

using the equipment shutoff valve.

For more information, visit www.desatech.com

107070-01F

WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

A. This appliance has a pilot which must be lighted by hand.

When lighting the pilot, follow these instructions exactly.

B. BEFORE LIGHTING smell all around the appliance ar ea

for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

OPERATING HEATER (REMOTE-READY MODELS)

For Your Safety Read Before Lighting (Cont.) Lighting Instructions

OPERATING HEATER

Continued

C. Use only your hand to push in or turn the gas control knob.

Never use tools. If the knob will not push in or turn by hand, don’t try to repair it, call a qualified service technician or gas supplier. For ce or attempted repair may result in a fire or explosion.

D. Do not use this appliance if any part has been under water.

Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.

LIGHTING

INSTRUCTIONS

WARNING

• You must operate this heater with a fireplace screen in place. Make sure fireplace screen is closed before running heater.

Note:

Home owners generally prefer to operate their heater with the chimney damper closed. This will put all the heat into the room. However, there may be times you will desire the full flames of the HI heat setting but will find the heat output excessive. You can open the chimney damper (if you have one) fully or partially to release some of the heat.

WARNING: Damper handle will be hot if heater

has been running.

1. STOP! Read the safety information, starting in column 2,

page 19.

2. Make sure equipment shutoff valve is fully open.

3. Set selector switch in the OFF position.

WARNING: Burners will come on automatically within one minute when the selector switch is in the ON position after the pilot is lit.

4. Press in and turn control knob clockwise to the OFF position (see Figure 30).

5. Wait five (5) minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the safety information, starting in column 2, page 19. If you don’t smell gas, go to the next step.

6. Press in and turn control knob counterclockwise to the PILOT position. Press in control knob for five (5) seconds (see Figure 30).

Note:

7. With control knob pressed in, press and release ignitor button. This will light pilot. The pilot is attached to the front burner. If needed, keep pressing ignitor button until pilot lights.

Note:

8. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob.

• If control knob does not pop out when released, contact

a qualified service person or gas supplier for repairs.

Note:

If pilot goes out, repeat steps 4 through 8, page 19.

9. Slightly push in and turn control knob counterclockwise

to the ON position.

10. Wait one minute and switch selector switch to the ON position to light burners.

Note:

AUTO is only functional when

using GWMT1 or GWMS2 optional accessories.

11. Set flame adjustment knob to any level between HI and LO.

Flame Adjustment Knob

AUTO OFF ON

Ignitor Button

Selector Switch in OFF Position

Figure 30 - Control Knob and Ignitor Button Location (Shown as Supplied, No Control Options)

Control Knob

For more information, visit www.desatech.com

107070-01F

OPERATING HEATER

Continued

OPERATING HEATER (REMOTE-READY MODELS)

Lighting Instructions (Cont.)

To Turn Gas Off To Appliance

Manual Lighting Procedure

Optional Hand-Held Remote Operation

CAUTION: Do not try to adjust heating levels by

using the equipment shutoff valve.

WARNING: Make sure the selector switch is in the OFF position when you are away from home for long periods of time. Heater will come on automatically with selector switch in the ON position.

Note:

The pilot flame on natural gas units will have a slight curve,

but flame should be blue and have no yellow or orange color.

Pilot Burner

Ignitor Electrode

Figure 31 - Pilot (Propane/LP)

Pilot Burner

Figure 32 - Pilot (Natural)

Ignitor Electrode

TO TURN OFF GAS

TO APPLIANCE

Shutting Off Heater

1. T ur n control knob clockwise to the OFF position. 2a. Set selector switch in the OFF position. 2b. If Using Optional Hand-Held Remote: Set selector switch

in the OFF position to prevent draining battery.

Shutting Off Burners Only (pilot stays lit)

You may shut off the burners and keep the pilot lit by doing one of the following:

1. Tur n control knob clockwise to the PILOT position.

2. Use remote control manual OFF button.

3. Set selector switch in the OFF position.

MANUAL LIGHTING

PROCEDURE

1. Follow steps 1 through 6 under Lighting Instructions, page 20.

2. Depress control knob and light pilot with match.

3. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, r elease control knob. Now f ollow steps 9 through 11, Lighting Instructions, column 2, page 20.

OPTIONAL HAND-HELD

REMOTE OPERATION

Note:

All remote control accessories must be purchased separately (see Accessories, page 44). Follow instructions included with the remote control.

NOTICE: You must light the pilot before using the hand-held remote control unit. See

tions

on page 20.

Lighting Instruc-

1. After lighting, let pilot flame burn for about one minute.

Turn control knob to ON position. Adjust flame adjustment knob anywhere between HI and LO. Slide the selector switch to the REMOTE position (see Figure 33).

Note:

The burner may light if hand-held remote was on when selector switch was last turned off. You can now turn the burner on and off with the hand-held remote contr ol unit.

IMPORTANT:

Do not leave the selector switch in the REMOTE or ON position when the pilot is not lit. This will drain the battery.

Flame Adjustment Knob

Control

ON OFF REMOTE

Selector Switch in Remote Position (Optional Remote Control)

Figure 33 - Setting the Selector switch, Control Knob, and Flame Adjustment Knob for Hand-Held Remote Operation

Knob in On Position

ON/OFF SERIES (MODEL GHRCB)

Hold the control button on the hand-held remote until burner turns on. Hold the control button again until burner turns off (see Figure 34).

TO LOCK press both buttons on hand-held remote control until

light stops flashing. Hand-held remote control is now locked. If the fire is on it will be turned off automatically. In the locked state, the light will not light up when any button is pressed.

TO UNLOCK press both buttons together on hand-held remote

control until the light stops flashing. The hand-held remote is now unlocked.

Control Button Turns Burners On and Off

107070-01F

Figure 34 - On/Off Hand-Held Remote Control Unit (GHRCB)

For more information, visit www.desatech.com

OPERATING HEATER (REMOTE-READY MODELS)

Optional Hand-Held Remote Operation (Cont.)

INSPECTING BURNERS

Pilot Flame Pattern

OPERATING HEATER

Continued

THERMOSTAT SERIES (MODEL GHRCTB)

The hand-held remote can be operated using either the manual mode (MANU) or thermostatic mode (AUTO) (see Figure 35). To select Fahrenheit/Centigrade mode display, carefully press the ˚C/˚F mode button with the end of a paper clip or similar blunt object.

Manual Mode

1. Press the POWER and LOCK buttons together to turn on the hand-held remote control.

2. Press the MANU button to turn on the fireplace.

3. Press the POWER and LOCK b uttons together to tur n off the fireplace.

Auto (Thermostatic) Mode

1. Press the POWER and LOCK buttons together to turn on the hand-held remote control.

2. Press AUTO button to select this mode.

3. Set the desired room temperatur e by pressing the TEMP + or - buttons.

4. Press the POWER and LOCK b uttons together to tur n off the fireplace

Note:

Do not leave the hand-held remote in the AUTO mode close to the fireplace. The radiant heat from the fireplace will turn off the fireplace. Ideally, place the hand-held remote in the center of the room facing towards the fireplace.

Note:

Do not hold the hand-held remote for a long time. Body temperature will affect its operation in the AUTO mode.

Digital Display Shows Temperature and Settings

Turns Burners On or Off

Decreases Room Temperature in AUTO Mode

Turns Hand-Held Remote On or Off and Allows You to Choose the Manual Setting

Selects Auto Setting

Increases Room Temperature in AUTO Mode

Auto Shutoff Feature

1. If the average room tempera ture exceeds 82 degr ees F ahr enheit (28 degrees Centigrade), the hand-held remote control will perform a safety override and shut the fireplace off. This feature is not available in the MANU mode.

2. The receiver continuously receives signals from the handheld remote to control the room temperatur e. If the handheld remote is misplaced, obstructed, or for any reason cannot transmit to the receiver, the receiver will shut off the fireplace after 8 minutes.

Key Pad Lock Feature

This feature allows the user to lock/unlock the keypad on the hand-held remote in the MANU or AUTO mode to prevent inadvertent operation (i.e. children operating the hand-held remote control, etc.). The keypad is locked in either on or off. Press the POWER and LOCK buttons together to turn the unit on or off.

INSPECTING BURNERS

Check pilot flame pattern and burner flame patterns often.

PILOT FLAME PATTERN

Figure 36 shows a correct pilot flame pattern. Figure 37 shows an incorrect pilot flame pattern. The incorrect pilot flame is not touching the thermocouple. This will cause the thermocouple to cool. When the thermocouple cools, the heater will shut down.

If pilot flame pattern is incorrect, as shown in Figure 37

• turn heater off (see T o Turn Of f Gas to Appliance, page 18 [Ther -

mostat-Controlled Models], page 19 [Manually-Controlled Models], or page 21 [Remote-Ready Models])

• see Troubleshooting, pages 24 through 26

Note:

The pilot flame on natural gas units will have a slight curve,

but flame should be blue and have no yellow or orange color.

Pilot Burner

Locks System to Prevent Accidental Ignition

Figure 35 - Thermostat Hand-Held Remote Control Unit (GHRCTB)

Safety Features

When away from home for an extended period of time or as a child safety feature to prevent accidental ignition of the fireplace, the receiver ON/OFF/REMOTE switch should be in the OFF position.

For more information, visit www.desatech.com

Thermocouple

Figure 36 - Correct Pilot Flame Pattern (Your pilot may vary from pilots shown)

Thermocouple

Figure 37 - Incorrect Pilot Flame Pattern (Your pilot may vary from pilots shown)

107070-01F

INSPECTING BURNERS

Continued

INSPECTING BURNERS

Burner Primary Air Holes

Main Burner

CLEANING AND MAINTENANCE

Cleaning Burner Injector Holder and Pilot Air Inlet Hole

Logs

BURNER PRIMARY AIR HOLES

Air is drawn into the burner through the holes in the fitting at the burner entrance. These holes may become blocked with dust or lint. Periodically inspect these holes for any blockage and clean if needed. Blocked air holes will create soot.

MAIN BURNER

Periodically inspect all burner flame holes with the heater running. All slotted burner flame holes should be open with yellow flame present. All round burner flame holes should be open with a small blue flame present. Some burner flame holes may become blocked by debris or rust, with no flame present. If so, turn off heater and let cool. Remove blockage. Blocked burner flame holes will create soot.

CLEANING AND MAINTENANCE

WARNING: Turn off heater and let cool before

cleaning.

CAUTION: You must keep control areas, burners, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service person. Heater may need more frequent cleaning due to excessive lint from carpeting, pet hair, bedding material, etc.

1. Shut off the unit, including the pilot. Allow the unit to cool for at least thirty minutes.

2. Inspect burner, pilot, and primary air inlet holes on injector holder for dust and dirt (see Figures 38 and 39).

3. Blow air through the ports/slots and holes in the burner.

4. Check the injector holder located at the end of the burner tube again. Remove any large particles of dust, dirt, lint, or pet hair with a soft cloth or vacuum cleaner nozzle.

5. Blow air into the primary air holes on the injector holder.

6. In case any large clumps of dust have now been pushed into the burner repeat steps 3 and 4.

Clean the pilot assembly also. A yellow tip on the pilot flame indicates dust and dirt in the pilot assembly. There is a small pilot air inlet hole about two inches from where the pilot flame comes out of the pilot assembly (see Figure 39). With the unit off, lightly blow air through the air inlet hole. You may blow through a drinking straw if compressed air is not available.

Ports/Slots

Injector Holder (May Be Brass or Aluminum Depending on Model)

Burner Tube

Pilot Assembly

Pilot Air Inlet Hole

WARNING: Failure to keep the primary air opening(s) of the burner(s) clean may result in sooting and property damage.

CLEANING BURNER INJECTOR HOLDER AND PILOT AIR INLET HOLE

The primary air inlet holes allow the proper amount of air to mix with the gas. This provides a clean burning flame. Keep these holes clear of dust, dirt, lint, and pet hair. Clean these air inlet holes prior to each heating season. Blocked air holes will create soot. We recommend that you clean the unit every three months during operation and have heater inspected yearly by a qualified service person.

We also recommend that you keep the burner tube and pilot assembly clean and free of dust and dirt. To clean these parts we recommend using compressed air no greater than 30 PSI. Your local computer store, hardware store, or home center may carry compressed air in a can. You can use a vacuum cleaner in the blow position. If using compressed air in a can, please follow the directions on the can. If you don't follow directions on the can, you could damage the pilot assembly.

For more information, visit www.desatech.com

107070-01F

Primary Air Inlet Holes (Shape of Holes May Vary by Model)

Figure 38 - Injector Holder On Outlet Burner Tube

Figure 39 - Pilot Inlet Air Hole

LOGS

• If you remove logs for cleaning, refer to Installing Logs, pages 15 and 16, to properly replace logs.

• Replace log(s) if broken or chipped (dime-sized or larger).

TROUBLESHOOTING

Note:

For additional help, visit DESA

Heating Products’ technical service web site at www.desatech.com.

Note:

All troubleshooting items are listed in

order of operation.

WARNING: Turn off heater and let cool before servicing. Only a qualified service person should service and repair heater.

CAUTION: Never use a wire, needle, or similar object to clean ODS/pilot. This can damage ODS/ pilot unit.

OBSERVED PROBLEM

When ignitor button is pressed, there is no spark at ODS/pilot

When ignitor button is pressed, there is spark at ODS/pilot but no ignition

POSSIBLE CAUSE

1. Ignitor electrode not connected to ignitor cable

2. Ignitor cable pinched or wet

3. Piezo ignitor nut is loose

4. Broken ignitor cable

5. Bad piezo ignitor

6. Ignitor electrode positioned wrong

7. Ignitor electrode broken

1. Gas supply turned off or equipment shutoff valve closed

2. Control knob not in PILOT position

3. Control knob not pressed in while in PILOT position

4. Air in gas lines when installed

5. Depleted gas supply (propane/LP only)

6. ODS/pilot is clogged

7. Gas regulator setting is not correct

REMEDY

1. Reconnect ignitor cable

2. Free ignitor cable if pinched by any metal or tubing. Keep ignitor cable dry

3. Tighten nut holding piezo ignitor to base panel of log set. Nut is located behind base panel.

4. Replace ignitor cable

5. Replace piezo ignitor

6. Replace pilot assembly

7. Replace pilot assembly

1. Turn on gas supply or open equipment shutoff valve

2. Turn control knob to PILOT position

3. Press in control knob while in PILOT position

4. Continue holding down control knob. Repeat igniting operation until air is removed

5. Contact local propane/LP gas company

6. Clean ODS/pilot (see Cleaning and Maintenance, page 23) or replace ODS/ pilot assembly

7. Replace gas regulator

ODS/pilot lights but flame goes out when control knob is released

For more information, visit www.desatech.com

1. Control knob not fully pressed in

2. Control knob not pressed in long enough

3. Safety interlock system has been triggered

4. Equipment shutoff valve not fully open

5. Pilot flame not touching thermocouple, which allows thermocouple to cool, causing pilot flame to go out. This problem could be caused by one or both of the following: A) Low gas pressure B) Dirty or partially clogged ODS/pilot

6. Thermocouple connection loose at control valve

7. Thermocouple damaged

8. Control valve damaged

1. Press in control knob fully

2. After ODS/pilot lights, keep control knob pressed in 30 seconds

3. Wait one minute for safety interlock system to reset. Repeat ignition operation

4. Fully open equipment shutoff valve

5. A) Contact local natural or propane/LP gas company

B) Clean ODS/pilot (see Cleaning and Maintenance, page 23) or replace ODS/ pilot assembly

6. Hand tighten until snug, then tighten 1/4 turn more

7. Replace pilot assembly

8. Replace control valve

107070-01F

TROUBLESHOOTING

Continued

TROUBLESHOOTING

OBSERVED PROBLEM

Burner does not light after ODS/pilot is lit

Delayed ignition of one or both burners

Burner backfiring during combustion

Slight smoke or odor during initial operation

Heater produces a whistling noise when burners are lit

POSSIBLE CAUSE

1. Inlet gas pressure is too low

2. Burner orifice(s) clogged

3. Thermopile leads disconnected or improperly connected (Remote-Ready Models Only)

4. Burners will not come on in remote position (Remote-Ready Models Only)

1. Manifold pressure is too low

2. Burner orifice(s) clogged

1. Burner orifice is clogged or damaged

2. Damaged burner

3. Gas regulator defective

1. Not enough air

2. Gas regulator defective

3. Residues from manufacturing processes and logs curing

1. Turning control knob to HI position when burners are cold

2. Air in gas line

3. Air passageways on heater blocked

4. Dirty or partially clogged burner orifice(s)

REMEDY

1. Contact local natural or propane/LP gas company

2. Clean burner(s) (see Cleaning and Mainte- nance, page 23) or replace burner orifice(s)

3. Reconnect leads (see Wiring Diagram, page 29)

4. Replace battery in transmitter and receiver

1. Contact local natural or propane/LP gas company

2. Clean burner(s) (see Cleaning and Mainte- nance, page 23) or replace burner orifice(s)

1. Clean burner (see Cleaning and Mainte- nance, page 23) or replace burner orifice

2. Replace damaged burner

3. Replace gas regulator

1. Check burner for dirt and debris. If found, clean burner (see Cleaning and Mainte- nance, page 23)

2. Replace gas control

3. Problem will stop after a few hours of operation

1. Turn control knob to LO position and let warm up for a minute

2. Operate burners until air is removed from line. Have gas line checked by local natural or propane/LP gas company

3. Observe minimum installation clearances (see pages 8 through 10)

4. Clean burners (see Cleaning and Mainte- nance, page 23) or replace burner orifice

White powder residue forming within burner box or on adjacent walls or furniture

Moisture/condensation noticed on windows

Dark residue on logs inside of their fireplace

Note:

After removing all causes of residue deposits, completely clean fireplace and appliance off residue before reusing appliance

For more information, visit www.desatech.com

107070-01F

1. When heated, vapors from furniture polish, wax, carpet cleaners, etc. may turn into white powder residue

1. Not enough combustion/ventilation air

1. Improper log placement

2. Drafts or other air currents affecting flame pattern

3. Air holes at burner inlet blocked

4. Burner flame holes blocked

1. Turn heater off when using furniture polish, wax, carpet cleaners, or similar products

1. Refer to Air for Combustion and Ventila- tion requirements (page 5)

1. Properly locate logs (see Installing Logs, pages 15 and 16)

2. Eliminate source of drafts around heater

3. Clean out air holes at burner inlet. Periodically repeat as needed

4. Remove blockage or replace burner

TROUBLESHOOTING

Continued

WARNING: If you smell gas

• Shut off gas supply.

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your

building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

IMPORTANT:

supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc., create fumes. These fumes may mix with combustion air and create odors. These odors will disappear over time.

Operating heater where impurities in air exist may create odors. Cleaning

OBSERVED PROBLEM

Remote does not function (Remote-Ready Models Only)

Heater produces a clicking/ticking noise just after burners are lit or shut off

Heater produces unwanted odors

Heater shuts off in use (ODS operates)

POSSIBLE CAUSE

1. Battery is not installed. Battery power is low

1. Metal expanding while heating or contracting while cooling

1. Heater burning vapors from paint, hair spray, glues, cleaners, chemicals, new carpet, etc. (See ment above)

2. Low fuel supply (propane/LP only)

3. Gas leak. See Warning statement

at top of page

1. Not enough fresh air is available

2. Low line pressure

3. ODS/pilot is partially clogged

IMPORTANT

state-

REMEDY

1. Replace 9-volt batteries in receiver and remote control

1. This is common with most heaters. If noise is excessive, contact qualified service person

1. Open window to ventilate room. Stop using odor causing products while heater is running

2. Refill supply tank (propane/LP only)

3. Locate and correct all leaks (see Check- ing Gas Connections, page 14)

1. Open window and/or door for ventilation

2. Contact local natural or propane/LP gas company

3. Clean ODS/pilot (see Cleaning and Maintenance, page 23)

Gas odor even when control knob is in OFF position

Gas odor during combustion

For more information, visit www.desatech.com

1. Gas leak. See Warning statement at top of page

2. Control valve defective

1. Foreign matter between control valve and burner

2. Gas leak. See Warning statement

at top of page

1. Locate and correct all leaks (see Checking Gas Connections, page 14)

2. Replace control valve

1. Take apart gas tubing and remove foreign matter

2. Locate and correct all leaks (see Check- ing Gas Connections, page 14)

107070-01F

OPTIONAL POSITIONING OF THERMOSTAT SENSING BULB

(Thermostat-Controlled Models Only)

(THERMOSTAT-CONTROLLED MODELS ONLY)

For Masonry and Factory-Built Metal Fireplace

FOR MASONRY AND FACTORY-BUILT METAL FIREPLACE

If your log set cycles to pilot, but the room temperature drops to a lower than ideal comfort level before the log set comes back on, you may want to reposition the thermostat sensing bulb.

The thermostat sensing bulb is located near the gas valve assembly on the mounting bracket. This location allows the thermostat to keep the room temperature at an ideal comfort level for most fireplace applications. For positioning the thermostat sensing bulb elsewhere, an adhesive-backed mounting clip is available.

Tools needed: 1/4" hex driver or socket

1. Remove logs. Locate the gas valve assembly and thermostat sensing bulb (see Figure 40).

2. With 1/4" hex driver or socket, loosen the thermostat screw. Carefully slide the thermostat sensing bulb out of the retaining clamp (see Figure 42).

Note:

Do not remove the screw. Make sure you tighten the

screw after removing the thermostat sensing bulb.

IMPORTANT:

bulb or capillary.

3. The thermostat sensing bulb may be located to the lower right front side of fireplace. Determine location of sensing bulb, but do not mount sensing bulb until step 5. If you have a masonry fireplace, see Figure 43 for location. If you have a factorybuilt metal fireplace, see Figure 44 for location. If your fireplace has glass doors, position sensing bulb directly behind door gap on right bottom side (see Figure 45).

4. The mounting clip must be a minimum of 3" from bottom of fireplace to prevent crimping of capillary. Once you have decided on a location, clean the area thoroughly . Remove the paper backing from the adhesive on back of mounting clip. Press the clip into the new location so that the thermostat sensing bulb will be positioned vertically with the capillary at the bottom (see Figure 46). Slide the thermostat sensing bulb into the clip.

IMPORTANT:

Gas Valve Assembly

Do not force or bend the thermostat sensing

Do not crimp capillary.

Thermostat

Mounting Bracket

Sensing Bulb

Thermostat Screw

Retaining Clamp

Figure 41 - Adhesive-backed Mounting Clip

Thermostat Sensing Bulb

Adhesivebacked Mounting Clip

Figure 43 - Locating Thermostat Sensing Bulb on Masonry Fireplace

Thermostat Sensing Bulb

Adhesivebacked Mounting Clip

Glass Doors

Figure 45 - Installing Thermostat Sensing Bulb behind Glass Doors

Capillary

Figure 42 - Removing Thermostat Sensing Bulb

Thermostat Sensing Bulb

Adhesivebacked Mounting Clip

Figure 44- Locating Thermostat Sensing Bulb on Factory-built Metal Fireplace

Thermostat Sensing Bulb

Capillary

Figure 46 - Positioning the Thermostat Sensing Bulb in the Vertical Position with the Capillary at the Bottom

Thermostat Sensing Bulb

Adhesivebacked Mounting Clip

Do Not Crimp Capillary

Figure 40 - Location of Gas Valve Assembly and Thermostat Sensing Bulb

For more information, visit www.desatech.com

107070-01F

SPECIFICATIONS

Vintage Oak 18" Variable Vintage Oak 24" and 30" Golden Oak and Birch 18" Manually-Controlled Variable Manually-Controlled Variable Manually-Controlled

Btu (Variable) 16,000/27,000 20,000/31,500 16,000/30,000 Type Gas Propane/LP Only - Natural Propane/LP Only - Natural Propane/LP Only - Natural Ignition Piezo Piezo Piezo Manifold Pressure 8.0" W.C. - 3.5" W.C. 8.0" W.C. - 3.5" W.C. 8.0" W.C. - 3.5" W.C. Inlet Gas Pressure

(in. of water)

Maximum 14" - 10.5" 14" - 10.5" 14" - 10.5"

Minimum* 11" - 5" 11" - 5" 11" - 5" Shipping Weight 36 lbs. 38 lbs. 26 lbs. * For purpose of input adjustment

Golden Oak and Birch 24", 30" and 36" Variable Golden Oak 18" Golden Oak 24" and 30" Manually-Controlled Thermostat-Controlled Thermostat-Controlled

Btu (Variable) 20,000/39,000 20,000/33,000 21,500/36,000 Type Gas Propane/LP Only - Natural Propane/LP Only - Natural Propane/LP Only - Natural Ignition Piezo Piezo Piezo Manifold Pressure 8.0" W.C. - 3.5" W.C. 8.0" W.C. - 3.5" W.C. 8.0" W.C. - 3.5" W.C. Inlet Gas Pressure

(in. of water)

Maximum 14" - 10.5" 14" - 10.5" 14" - 10.5"

Minimum* 11" - 5" 11" - 5" 11" - 5" Shipping Weight 28 lbs. (24"), 30 lbs. (30") 26 lbs. 28 lbs. (24"), 30 lbs. (30")

32 lbs. (36")

* For purpose of input adjustment

Golden Oak and Birch Golden Oak and Birch 18" Remote-Ready 24", 30" and 36" Remote-Ready

Btu (Variable) 16,000/30,000 20,000/39,000 Type Gas Propane/LP Only - Natural Propane/LP Only - Natural Ignition Piezo Piezo Manifold Pressure 8.0" W.C. - 3.5" W.C. 8.0" W.C. - 3.5" W.C. Inlet Gas Pressure

(in. of water)

Maximum 14" - 10.5" 14" - 10.5"

Minimum* 11" - 5" 11" - 5" Shipping Weight 28 lbs. 30 lbs. (24")/32 lbs. (30")

34 lbs. (36”)

* For purpose of input adjustment

For more information, visit www.desatech.com

107070-01F

WIRING DIAGRAM (REMOTE-READY MODELS ONLY)

SERVICE HINTS

TECHNICAL SERVICE

REPLACEMENT PARTS

WIRING DIAGRAM

(Remote-Ready Models Only)

Thermopile

SERVICE HINTS

When Gas Pressure Is Too Low

• pilot will not stay lit

• burners will have delayed ignition

• heater will not produce specified heat

• for propane/LP units, propane/LP gas supply may be low You may feel your gas pressure is too low. If so, contact your local

propane/LP or natural gas supplier.

TECHNICAL SERVICE

You may have further questions about installation, operation, or troubleshooting. If so, contact DESA Heating Products’ Technical Service Department at 1-866-672-6040. When calling please have your model and serial numbers of your heater ready.

You can also visit DESA Heating Products’ technical services web site at www.desatech.com.

REPLACEMENT PARTS

Note:

Use only original replacement parts. This will protect your

warranty coverage for parts replaced under warranty.

PARTS UNDER WARRANTY

Contact authorized dealers of this product. If they can’t supply original replacement part(s), call DESA Heating Products’ Technical Service Department at 1-866-672-6040.

When calling DESA Heating Products, have ready

• your name

• your address

• model and serial numbers of your heater

• how heater was malfunctioning

• type of gas used (propane/LP or natural gas)

• purchase date Usually, we will ask you to return the part to the factory.

PARTS NOT UNDER WARRANTY

Contact authorized dealers of this product. If they can’t supply original replacement part(s), call DESA Heating Products at 1 -866-672-6040 for referral information.

When calling DESA Heating Products, have ready

• model number of your heater

• the replacement part number

107070-01F

For more information, visit www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

Models VYS18PA, H18P, VYS18NA, H18N, VYS24PA, H24P, VYS24NA, H24N, VYS30PA and VYS30NA

ILLUSTRATED PARTS BREAKDOWN

VARIABLE MANUALLYCONTROLLED FLAME-MAX® VINTAGE OAK LOG MODELS

VYS18PA, H18P, VYS18NA, H18N, VYS24PA, H24P, VYS24NA, H24N, VYS30PA AND VYS30NA

20 - ODS Pilot

(Natural Gas)

20 - ODS Pilot

(Propane/LP)

For more information, visit www.desatech.com

107070-01F

Models VYS18PA, H18P, VYS18NA, H18N, VYS24PA, H24P,

PARTS LIST

VYS24NA, H24N, VYS30PA and VYS30NA

PARTS LIST

VARIABLE MANUALLY-CONTROLLED FLAME-MAX® VINTAGE OAK LOG MODELS

This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 29 of this manual.

PART NUMBER FOR

KEY VYS18PA VYS18NA VYS24PA VYS24NA VYS30PA VYS30NA NO. H18P H18N H24P H24N DESCRIPTION QTY.

1 105185-01 105185-01 105185-02 105185-02 105185-03 105185-03 One-Piece Log 1 2 098276-01 098276-01 098276-01 098276-01 098276-01 098276-01 Hex Head Plug, 1/8" NPT 1 3 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 Screw, Hex Head (#8-18 x .38) 8 4 102775-02CK 102775-02CK 102775-01CK 102775-01CK 102775-01CK 102775-01CK Painted Base Assembly 1 5 102844-01 102844-01 102844-01 102844-01 102844-01 102844-01 Lower Bracket 1 6 104286-01 104285-01 104286-01 104285-01 104286-01 104285-01 ODS Pilot 1 7 098867-10 098867-14 098867-10 098867-14 098867-10 098867-14 Gas Regulator 1 8 102780-05 111331-04 102780-05 111331-04 102780-05 111331-04 Outlet Burner Tube 1 9 102798-01 102798-01 102798-01 102798-01 102798-01 102798-01 Inlet Tube 1 10 099056-21 099056-20 099056-19 099056-18 099056-19 099056-18 Burner Orifice Injector 1 11 111124-01 111124-01 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1 12 102963-01 102963-01 102773-01 102773-01 102773-01 102773-01 Burner 1 13 102568-08 102568-07 102568-08 102568-07 102568-08 102568-07 Control Valve 1 14 098508-01 098508-01 098508-01 098508-01 098508-01 098508-01 Valve Retainer Nut 1 15 098354-01 098354-01 098354-01 098354-01 098354-01 098354-01 Control Knob 1 16 102445-01 102445-01 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1 17 098249-01 098249-01 098249-01 098249-01 098249-01 098249-01 Nut, M5 2 18 099387-08 099387-08 099387-08 099387-08 099387-08 099387-08 Pilot Tube 1 19 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1

PARTS AVAILABLE — NOT SHOWN

100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 Warning Plate 1 101055-02 101055-02 101055-02 101055-02 101055-02 101055-02 Lighting Instructions Plate 1 100565-01 100565-01 100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1 100639-01 100639-01 100639-01 100639-01 100639-01 100639-01 Caution Decal 1 101449-04 101449-04 101449-04 101449-04 101449-04 101449-04 Control Position Decal 1 101137-02 101137-02 101137-02 101137-02 101137-02 101137-02 Hardware Kit 1 GA6060 GA6060 GA6060 GA6060 GA6060 GA6060 Lava Rock 1

107070-01F

For more information, visit www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

Models VYD18PA, VYBD18P, VYD24PA, VYBD24P, VYD30PA, VYBD30P and VYD36PA

ILLUSTRATED PARTS BREAKDOWN

VARIABLE MANUALLY-CONTROLLED FLAME-MAX® GOLDEN OAK LOG AND BIRCH LOG MODELS

VYD18PA, VYBD18P, VYD24PA, VYBD24P,VYD30PA, VYBD30P and VYD36PA

*Note:

The Golden Oak Log (107027-01) for the VYD36PA model differs slightly from drawing

19 - ODS Pilot

(Propane/LP)

For more information, visit www.desatech.com

107070-01F

Models VYD18PA, VYBD18P, VYD24PA, VYBD24P,

PARTS LIST

VYD30PA, VYBD30P and VYD36PA

PARTS LIST

VARIABLE MANUALLY-CONTROLLED FLAME-MAX® GOLDEN OAK LOG AND BIRCH LOG MODELS

This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 29 of this manual.

KEY PART NUMBER FOR NO. VYD18PA VYBD18P VYD24PA VYBD24P VYD30PA VYBD30P VYD36PA DESCRIPTION QTY.

1A 105268-01 — 105268-02 — 105268-03 — 107027-01 Log, Golden Oak 1 1B — 103520-01 — 103336-01 — 103522-01 — Log, Birch 1 2 098276-01 098276-01 098276-01 098276-01 098276-01 098276-01 098276-01 Hex Head Plug

1/8" NPT 1 3 098249-01 098249-01 098249-01 098249-01 098249-01 098249-01 098249-01 Nut, M5 2 4 102775-04CK 102775-04CK 102775-01CK 102775-01CK 102775-03CK 102775-03CK 102775-03CK Painted Base

Assembly 1 5 102844-02 102844-02 102844-01 102844-01 102844-01 102844-01 102844-01 Lower Bracket 1 6 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 Screw, Hex Head 8

(#8-18 x .38) 7 098867-10 098867-10 098867-10 098867-10 098867-10 098867-10 098867-10 Gas Regulator 1 8 102798-01 102798-01 102798-01 102798-01 102798-01 102798-01 102798-01 Inlet Tube 1 9 102779-04 102779-04 102779-02 102779-02 102779-02 102779-02 102779-02 Outlet Burner Tube 1 10 099056-19 099056-19 099056-17 099056-17 099056-17 099056-17 099056-17 Burner Orifice

Injector 1 11 111124-01 111124-01 111124-01 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1 12 102980-01 102980-01 102772-01 102772-01 102772-01 102772-01 102772-01 Burner 1 13 102568-08 102568-08 102568-06 102568-06 102568-06 102568-06 102568-06 Control Valve 1 14 098508-01 098508-01 098508-01 098508-01 098508-01 098508-01 098508-01 Valve Retainer Nut 1 15 098354-01 098354-01 098354-01 098354-01 098354-01 098354-01 098354-01 Control Knob 1 16 102445-01 102445-01 102445-01 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1 17 099387-08 099387-08 099387-08 099387-08 099387-08 099387-08 099387-08 Pilot Tube 1 18 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1 19 104286-01 104286-01 104286-01 104286-01 104286-01 104286-01 104286-01 ODS Pilot 1

107070-01F

PARTS AVAILABLE — NOT SHOWN

100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 Warning Plate 1 101055-02 101055-02 101055-02 101055-02 101055-02 101055-02 101055-02 Lighting Instructions

Plate 1

100565-01 100565-01 100565-01 100565-01 100565-01 100565-01 100565-01 Warning Plate

Fastener 1

100639-01 100639-01 100639-01 100639-01 100639-01 100639-01 100639-01 Caution Decal 1 101449-04 101449-04 101449-04 101449-04 101449-04 101449-04 101449-04 Control Position

Decal 1

101137-02 101137-02 101137-02 101137-02 101137-02 101137-02 101137-02 Hardware Kit 1 GA6060 GA6060 GA6060 GA6060 GA6060 GA6060 GA6060 Lava Rock 1

For more information, visit www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

Models VYD18NA, VYBD18N, VYD24NA, VYBD24N, VYD30NA, VYBD30N and VYD36NA

ILLUSTRATED PARTS BREAKDOWN

VARIABLE MANUALLY-CONTROLLED FLAME-MAX® GOLDEN OAK LOG AND BIRCH LOG MODELS

VYD18NA, VYBD18N, VYD24NA, VYBD24N, VYD30NA, VYBD30N and VYD36NA

Note:

The Golden Oak Log (107027-01) for the VYD36NA model differs slightly from drawing.

19 - ODS Pilot

(Natural Gas)

For more information, visit www.desatech.com

107070-01F

Models VYD18NA, VYBD18N, VYD24NA, VYBD24N,

PARTS LIST

VYD30NA, VYBD30N and VYD36NA

PARTS LIST

VARIABLE MANUALLY-CONTROLLED FLAME-MAX® GOLDEN OAK LOG AND BIRCH LOG MODELS

This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 29 of this manual.

KEY PART NUMBER FOR NO. VYD18NA VYBD18N VYD24NA VYBD24N VYD30NA VYBD30N VYD36NA DESCRIPTION QTY.

1A 105268-01 – 105268-02 – 105268-03 – 107027-01 Log, Golden Oak 1 1B – 103520-01 – 103336-01 – 103522-01 – Log, Birch 1 2 098276-01 098276-01 098276-01 098276-01 098276-01 098276-01 098276-01 Hex Head Plug,

1/8" NPT 1 3 098249-01 098249-01 098249-01 098249-01 098249-01 098249-01 098249-01 Nut, M5 2 4 102775-04CK 102775-04CK 102775-01CK 102775-01CK 102775-03CK 102775-03CK 102775-03CK Painted Base

Assembly 1 5 102844-02 102844-02 102844-01 102844-01 102844-01 102844-01 102844-01 Lower Bracket 1 6 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 Screw, Hex Head 8

(#8-18 x .38) 7 098867-14 098867-14 098867-14 098867-14 098867-14 098867-14 098867-14 Gas Regulator 1 8 102798-01 102798-01 102798-01 102798-01 102798-01 102798-01 102798-01 Inlet Tube 1 9 102779-03 102779-03 102779-01 102779-01 102779-01 102779-01 102779-01 Outlet Burner Tube 1 10 099056-26 099056-26 099056-16 099056-16 099056-16 099056-16 099056-16 Burner Orifice

Injector 1

111124-01 111124-01 111124-01 111124-01 111124-01 111124-01 111124-01

11 12 102980-01 102980-01 102772-01 102772-01 102772-01 102772-01 102772-01 Burner 1 13 102568-07 102568-07 102568-05 102568-05 102568-05 102568-05 102568-05 Control Valve 1 14 098508-01 098508-01 098508-01 098508-01 098508-01 098508-01 098508-01 Valve Retainer Nut 1 15 098354-01 098354-01 098354-01 098354-01 098354-01 098354-01 098354-01 Control Knob 1 16 102445-01 102445-01 102445-01 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1 17 099387-08 099387-08 099387-08 099387-08 099387-08 099387-08 099387-08 Pilot Tube 1 18 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1 19 104285-01 104285-01 104285-01 104285-01 104285-01 104285-01 104285-01 ODS Pilot 1

Burner Retainer Spring 1

107070-01F

PARTS AVAILABLE — NOT SHOWN

100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 Warning Plate 1 101055-02 101055-02 101055-02 101055-02 101055-02 101055-02 101055-02 Lighting Instructions

Plate 1

100565-01 100565-01 100565-01 100565-01 100565-01 100565-01 100565-01 Warning Plate

Fastener 1

100639-01 100639-01 100639-01 100639-01 100639-01 100639-01 100639-01 Caution Decal 1 101449-04 101449-04 101449-04 101449-04 101449-04 101449-04 101449-04 Control Position

Decal 1

101137-02 101137-02 101137-02 101137-02 101137-02 101137-02 101137-02 Hardware Kit 1 GA6060 GA6060 GA6060 GA6060 GA6060 GA6060 GA6060 Lava Rock 1

For more information, visit www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

Models VYD18PTA, VYD18NTA, VYD24PTA, VYD24NTA, VYD30PTA and VYD30NTA

ILLUSTRATED PARTS BREAKDOWN

THERMOSTAT-CONTROLLED FLAME-MAX® GOLDEN OAK LOG MODELS

VYD18PTA, VYD18NTA, VYD24PTA, VYD24NTA, VYD30PTA and VYD30NTA

For more information, visit www.desatech.com

107070-01F

PARTS LIST

THERMOSTAT-CONTROLLED FLAME-MAX® GOLDEN OAK LOG MODELS

This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 29 of this manual.

Models VYD18PTA, VYD18NTA, VYD24PTA,

PARTS LIST

VYD24NTA, VYD30PTA and VYD30NTA

KEY NO. VYD18PTA VYD18NTA VYD24PTA VYD24NTA VYD30PTA VYD30NTA DESCRIPTION QTY.

1 105268-01 105268-01 105268-02 105268-02 105268-03 105268-03 Log Set, Yellow Flame, Dual 1 2 104033-03 104033-03 3 102775-09CK 102775-09CK 102775-05CK 102775-05CK 102775-07CK 102775-07CK Painted Base Assembly 1 4 102844-02 102844-02 102844-01 102844-01 102844-01 102844-01 Lower Bracket 1 5 099211-01 099211-01 099211-01 099211-01 099211-01 099211-01 Hex Screw, 10-16 x 2.50 2 6 098867-10 098867-14 098867-10 098867-14 098867-10 098867-14 Gas Regulator 1 7 102981-01 102981-01 102981-01 102981-01 102981-01 102981-01 Inlet Tube 1 8 102983-03 102983-02 102983-02 102983-01 102983-02 102983-01 Outlet Burner Tube 1 9 099056-19 099056-26 099056-17 099056-16 099056-17 099056-16 Burner Orifice Injector 1 10 111124-01 111124-01 111124-01 111124-01 111124-01 111124-01 11 102980-01 102980-01 102772-01 102772-01 102772-01 102772-01 Burner 1 12 101329-22 101329-21 101329-19 101329-20 101329-19 101329-20 13 102979-02 102979-02 102979-01 102979-01 102979-01 102979-01 Thermostat Bracket 1 14 098544-01 098544-01 098544-01 098544-01 098544-01 098544-01 Thermobulb Clip 1 15 102445-01 102445-01 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1 16 099387-09 099387-09 099387-09 099387-09 099387-09 099387-09 Pilot Tube 1 17 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1 18 104286-01 104285-01 104286-01 104285-01 104286-01 104285-01 ODS Pilot 1 19 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 Hex Screw, #8-18 x .38 12 20 098249-01 098249-01 098249-01 098249-01 098249-01 098249-01 Nut, M5 2

100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 Warning Plate 1 101054-01 101054-01 101054-01 101054-01 101054-01 101054-01 Lighting Instructions Plate 1 100565-01 100565-01 100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1 100639-01 100639-01 100639-01 100639-01 100639-01 100639-01 Caution Decal 1 101137-02 101137-02 101137-02 101137-02 101137-02 101137-02 Hardware Kit 1 GA6060 GA6060 GA6060 GA6060 GA6060 GA6060 Lava Rock 1 102030-01 102030-01 102030-01 102030-01 102030-01 102030-01

PART NUMBER FOR

_____

PARTS AVAILABLE — NOT SHOWN

_____

Baffle, Rear 1

Burner Retainer Spring Thermostat Gas Valve Assembly

Auxiliary Thermostat Mounting Clip

1 1

107070-01F

For more information, visit www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

Models VYD18PRA, HD18PR, VYD24PRA, HD24PR, VYD30PRA, HD30PR, VYD36PRA and HD36PR

ILLUSTRATED PARTS BREAKDOWN

REMOTE-READY FLAME-MAX® GOLDEN OAK LOG MODELS

VYD18PRA, HD18PR, VYD24PRA, HD24PR, VYD30PRA, HD30PR, VYD36PRA and HD36PR

Note:

The Golden Oak Log (107027-01) for the VYD36PRA model differs slightly from the log shown.

For more information, visit www.desatech.com

107070-01F

PARTS LIST

REMOTE-READY FLAME-MAX® GOLDEN OAK LOG MODELS

This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 29 of this manual.

PART NUMBER FOR

KEY VYD18PRA VYD24PRA VYD30PRA VYD36PRA NO. HD18PR HD24PR HD30PR HD36PR DESCRIPTION QTY.

1 105268-01 105268-02 105268-03 107027-01 Log, Golden Oak 1 2 103778-01 103778-01 103778-01 103778-01 ODS Pilot (LP) 1 3 098249-01 098249-01 098249-01 098249-01 ODS Nut 2 4 104422-02 103342-02 103342-02 103342-02 Burner Outlet Tube 1 5 098264-02 098264-02 098264-02 098264-02 Male Connector 1 6 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1 7 099056-19 099056-17 099056-17 099056-17 Burner Orifice Injector 1 8 099998-01 099998-01 099998-01 099998-01 Switch 1 9 102980-01 102772-01 102772-01 102772-01 Burner 1 10 099387-13 099387-09 099387-09 099387-09 Pilot Tube 1 11 103781-02 103781-02 103781-02 103781-02 Gas Control Valve 1 12 103345-02 103345-01 103345-01 103345-01 Lower Bracket 1 13 M11084-38 M11084-38 M11084-38 M11084-38 Screw, #8 x .38 4 14 104384-01 102775-06CK 102775-08CK 102775-08CK Painted Base Assy 1 15 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1 16 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1 17 103587-02 103587-02 103587-02 103587-02 Plate, Switch 1 18 104099-01 104099-01 104099-01 104099-01 Heat Shield 1 19 098304-01 098304-01 098304-01 098304-01 Screw 2 20 103784-02 103784-02 103784-02 103784-02 Flame Adjustment Knob 1 21 103784-01 103784-01 103784-01 103784-01 Off-Pilot-On Knob 1 22 M12461-26 M12461-26 M12461-26 M12461-26 Screw, Hex Slt Wsr

23 103284-02 103284-02 103284-02 103284-02 Wiring Harness

PARTS AVAILABLE — NOT SHOWN

100563-01 100563-01 100563-01 100563-01 Warning Plate 1 103877-01 103877-01 103877-01 103877-01 Lighting Instructions

100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1 100693-01 100639-01 100639-01 100639-01 Caution Decal 1 101137-02 101137-02 101137-02 101137-02 Hardware Kit 1 GA6060 GA6060 GA6060 GA6060 Lava Rock 1

Models VYD18PRA, HD18PR, VYD24PRA, HD24PR,

PARTS LIST

VYD30PRA, HD30PR, VYD36PRA and HD36PR

10-32 x .38 4

Plate 1

107070-01F

For more information, visit www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

Models VYD18NRA, HD18NR, VYD24NRA, HD24NR, VYD30NRA, HD30NR, VYD36PNA and HD36NR

ILLUSTRATED PARTS BREAKDOWN

REMOTE-READY FLAME-MAX® GOLDEN OAK LOG MODELS

VYD18NRA, HD18NR, VYD24NRA, HD24NR, VYD30NRA, HD30NR, VYD36NRA and HD36NR

Note:

The Golden Oak Log (107027-01) for the VYD36NRA and HD36NR models differs slightly from the log shown.

For more information, visit www.desatech.com

107070-01F

PARTS LIST

REMOTE-READY FLAME-MAX® GOLDEN OAK LOG MODELS

This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 29 of this manual.

PART NUMBER FOR

KEY VYD18NRA VYD24NRA VYD30NRA VYD36NRA NO. HD18NR HD24NR HD30NR HD36NR DESCRIPTION QTY.

1 105268-01 105268-02 105268-03 107027-01 Log, Golden Oak 1 2 103779-01 103779-01 103779-01 103779-01 ODS Pilot (NG) 1 3 098249-01 098249-01 098249-01 098249-01 ODS Nut 2 4 104422-01 103342-01 103342-01 103342-01 Burner Outlet Tube 1 5 098264-02 098264-02 098264-02 098264-02 Male Connector 1 6 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1 7 099056-26 099056-16 099056-16 099056-16 Burner Orifice Injector 1 8 099998-01 099998-01 099998-01 099998-01 Switch 1 9 102980-01 102772-01 102772-01 102772-01 Burner 1 10 099387-15 099387-12 099387-12 099387-12 Pilot Tube (Valve to regulator) 1 11 103781-01 103781-01 103781-01 103781-01 Gas Control Valve 1 12 103345-02 103345-01 103345-01 103345-01 Lower Bracket 1 13 M11084-38 M11084-38 M11084-38 M11084-38 Screw, #8 x .38 4 14 104384-01 102775-06CK 102775-08CK 102775-08CK Painted Base Assy 1 15 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1 16 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1 17 103587-02 103587-02 103587-02 103587-02 Plate, Switch 1 18 104099-01 104099-01 104099-01 104099-01 Heat Shield 1 19 098304-01 098304-01 098304-01 098304-01 Screw 2 20 103784-02 103784-02 103784-02 103784-02 Flame Adjustment Knob 1 21 103784-01 103784-01 103784-01 103784-01 Off-Pilot-On Knob 1 22 M12461-26 M12461-26 M12461-26 M12461-26 Screw, Hex Slt Wsr 10-32 x .38 4 23 100609-01 100609-01 100609-01 100609-01 Pilot Tube (Regulator to Pilot) 1 24 099918-02 099918-02 099918-02 099918-02 Pilot Regulator 1 25 103284-02 103284-02 103284-02 103284-02 Wiring Harness 1

Models VYD18NRA, HD18NR, VYD24NRA, HD24NR,

PARTS LIST

VYD30NRA, HD30NR, VYD36NRA and HD36NR

107070-01F

PARTS AVAILABLE — NOT SHOWN

100563-01 100563-01 100563-01 100563-01 Warning Plate 1 103877-01 103877-01 103877-01 103877-01 Lighting Instructions Plate 1 100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1 100693-01 100639-01 100639-01 100639-01 Caution Decal 1 101137-02 101137-02 101137-02 101137-02 Hardware Kit 1 GA6060 GA6060 GA6060 GA6060 Lava Rock 1

For more information, visit www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

Models VYBD18PR, VYBD18NR, VYBD24PR, VYBD24NR, VYBD30PR and VYBD30NR

ILLUSTRATED PARTS BREAKDOWN

REMOTE-READY FLAME-MAX® BIRCH LOG MODELS

VYBD18PR, VYBD18NR, VYBD24PR, VYBD24NR, VYBD30PR and VYBD30NR

For more information, visit www.desatech.com

107070-01F

PARTS LIST

REMOTE-READY FLAME-MAX® BIRCH LOG MODELS

This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 29 of this manual.

Models VYBD18PR, VYBD18NR, VYBD24PR,

PARTS LIST

VYBD24NR, VYBD30PR and VYBD30NR

KEY NO. VYBD18PR VYBD18NR VYBD24PR VYBD24NR VYBD30PR VYBD30NR DESCRIPTION QTY.

1 103520-01 103520-01 103336-01 103336-01 103522-01 103522-01 Log, Birch 1 2 103778-01 103779-01 103778-01 103779-01 103778-01 103779-01 ODS Pilot 1 3 098249-01 098249-01 098249-01 098249-01 098249-01 098249-01 ODS Nut 2 4 104422-02 104422-01 103342-02 103342-01 103342-02 103342-01 Burner Outlet Tube 1 5 098264-02 098264-02 098264-02 098264-02 098264-02 098264-02 Male Connector 1 6 111124-01 111124-01 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1 7 099056-19 099056-26 099056-17 099056-16 099056-17 099056-16 Burner Orifice Injector 1 8 099998-01 099998-01 099998-01 099998-01 099998-01 099998-01 Switch 1 9 102980-01 102980-01 102772-01 102772-01 102772-01 102772-01 Burner 1 10 099387-13 099387-15 099387-09 099387-12 099387-09 099387-12 Pilot Tube 1 11 103781-02 103781-01 103781-02 103781-01 103781-02 103781-01 Gas Control Valve 1 12 103345-02 103345-02 103345-01 103345-01 103345-01 103345-01 Lower Bracket 1 13 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 M11084-38 Screw, #8 x .38 4 14 104384-01 104384-01 102775-06CK 102775-06CK 102775-08CK 102775-08CK Painted Base Assy 1 15 098271-10 098271-10 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1 16 102445-01 102445-01 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1 17 103587-02 103587-02 103587-02 103587-02 103587-02 103587-02 Plate, Switch 1 18 104099-01 104099-01 104099-01 104099-01 104099-01 104099-01 Heat Shield 1 19 098304-01 098304-01 098304-01 098304-01 098304-01 098304-01 Screw 2 20 103784-02 103784-02 103784-02 103784-02 103784-02 103784-02 Flame Adjustment Knob 1 21 103784-01 103784-01 103784-01 103784-01 103784-01 103784-01 Off-Pilot-On Knob 1 22 M12461-26 M12461-26 M12461-26 M12461-26 M12461-26 M12461-26 Screw, Hex Slt Wsr 10-32 x .38 4 23 – 100609-01 – 100609-01 – 100609-01 Pilot Tube

24 – 099918-02 – 099918-02 – 099918-02 Pilot Regulator (NG Only) 1 25 103284-02 103284-02 103284-02 103284-02 103284-02 103284-02 Wiring Harness 1

100563-01 100563-01 100563-01 100563-01 100563-01 100563-01 Warning Plate 1 103877-01 103877-01 103877-01 103877-01 103877-01 103877-01 Lighting Instructions Plate 1 100565-01 100565-01 100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1 100639-01 100639-01 100639-01 100639-01 100639-01 100639-01 Caution Decal 1 101137-02 101137-02 101137-02 101137-02 101137-02 101137-02 Hardware Kit 1 GA6060 GA6060 GA6060 GA6060 GA6060 GA6060 Lava Rock 1

PART NUMBER FOR

(Regulator to Pilot [NG Only]) 1

PARTS AVAILABLE — NOT SHOWN

107070-01F

For more information, visit www.desatech.com

ACCESSORIES

NOTICE: All accessories may not be available for all fireplace models.

Purchase these heater accessories from your local dealer. If they can not supply these accessories, call DESA Heating Products at 1-866-672-6040 for referral information. You can also write to the address listed on the back page of this manual.

EQUIPMENT SHUTOFF VALVE - GA5010

For all models. Equipment shutoff valve with 1/8" NPT tap. Fit s 1/2" NPT pipe.

RECEIVER AND HAND-HELD REMOTE CONTROL KIT - GHRCB

For all Remote-Ready Models. Allows the gas log heater to be turned on and off by using a hand-held remote control.

WALL-MOUNT THERMOSTAT SWITCH GWMT1

(Not Shown)

For all Remote-Ready Models. The desired comfort setting can be selected on the wall thermostat and the log heater will automatically cycle from pilot to the heat setting selected.

FIREPLACE HOOD

Black - GA6050 Brass - GA6052 Antique Brass - GA6053

For all models. Helps deflect heat away from mantel or wall above fireplace. Fits openings 28" to 48" wide.

RECEIVER AND HAND-HELD THERMOSTAT REMOTE CONTROL KIT - GHRCTB

For all Remote-Ready Models. Allows the gas log heater to be operated in a manually or thermostatically controlled mode. You can turn the gas log heater on and off without ever leaving the comfort of your easy chair.

WALL-MOUNT ON/OFF SWITCH - GWMS2

(Not Shown)

For all Remote-Ready Models. Allows the gas log heater to be turned on and off with a wall switch.

DAMPER CLAMP - GA6080

(Not Shown)

For Remote-Ready and Variable Manually-Controlled Models.

Permanently opens chimney flue damper for vented operation.

LAVA ROCK - GA6060

(Not Shown)

For all models. Order when additional rock is desired. (1.8 lb. bag)

CLEANING KIT - GCK

(Not Shown)

For all models. Your vent-free gas appliance requires regular cleaning and maintenance to prevent performance problems. This kit gives you the tools and instructions to make it easy to clean all critical areas of your appliance.

INFORMATION VIDEO - 108917-01

For all models. A care and maintenance video is available by calling 1-866-672-6040. You may also email your request to

productsupport@desaint.com.

FIRE CRACKLE - CF6-A

(Not Shown)

For all models. Creates the sound of a real burning fire.

For more information, visit www.desatech.com

107070-01F

OWNER'S REGISTRATION FORM

In order to provide better customer service for this and future purchases, we recommend that you register your product with us.

• ACCESSORIES

You can register online at www.desatech.com. If access to our website is not available to you, please complete this Owner’s Registration Form and mail to the address on the back of this owner’s manual. Please provide the following product information:

Brand: Model: Date Purchased: Serial Number:

(Comfort Glow, Vanguard, etc.) (EFP33PR, VTGH33NR, etc.)

Note:

Keep receipt for warranty verification.

7 or 9 digit number located on product or identification tag.

First Name: Last Name: Address: City: State: Zip: Country: Home Phone: ( ) - E-Mail:

Please answer the following questions to register your product with DESA Heating Products:

1. Where will the product be used? ❍ Living/Family Room ❍ Office/Warehouse ❍ Utility Shed/Outbuilding ❍ Garage ❍ Bedroom ❍ Bathroom ❍ Other

2. If you bought this product yourself, did you plan to purchase this type of product before going into the store? ❍ Yes ❍ No

3. Who selected the product? ❍ Male ❍ Female ❍ Both

4. What is the population of your area? ❍ Under 10,000 ❍ 10,000 to 25,000 ❍ 25,000 to 50,000 ❍ 50,000 to 100,000 ❍ 100,000 to 250,000 ❍ Over 250,000

5. What is your primary source of heat? ❍ Propane (LP Gas) ❍ Fuel Oil ❍ Wood ❍ Natural Gas ❍ Electric ❍ Other

6. How was the product installed? ❍ Professional Installer ❍ Self ❍ Other

7. Cost of product excluding sales tax? $___________________

8. Cost to install product? $____________________

9. Type of store where product was purchased? ❍ Hardware ❍ Propane Dealer ❍ Natural Gas/Utility Co. ❍ Home Center/Builder’s Supply ❍ Fireplace or Hearth Shop ❍ Farm Store ❍ Other

10. What motivated you to buy this product? ❍ Sudden Cold Weather ❍ Replace Older Model ❍ D.I.Y. Home Project ❍ Emergency Back-Up Heat ❍ Heater was on Sale ❍ Energy Savings/High Efficiency ❍ Construction Project ❍ Other

11. How did you learn about this product brand? ❍ Advertising ❍ Relative or Friend ❍ Store Display ❍ Other ________________________

12. Level of Education of Purchaser: ❍ Some High School ❍ Completed High School ❍ Completed College ❍ Completed Graduate School

13. Age of Purchaser: ❍ Under 20 ❍ 20 - 29 ❍ 30 - 39 ❍ 40 - 49 ❍ 50 - 59 ❍ 60 or Over

14. Buyer’s total annual household income: ❍ Under $15,000 ❍ $15,000 to $19,999 ❍ $20,000 to $34,999 ❍ $35,000 to $49,999 ❍ $50,000 to $74,999 ❍ $75,000 to $99,999 ❍ $100,000 and Over

15. Store where product was purchased: Name: ______________________________________ City: _______________________ State: __________

16. In choosing this product, how important were the following:

Availability Price Brand Name Overall Quality Heat Output Made in USA Warranty Local Service Value for Price Prior Brand Experience Controls Location Thermostat, Remote, or Manual Operation Ease of Operation Special Features Salesperson’s Recommendation Friend/Relative’s Recommendation Portability

For more information, visit www.desatech.com

Quiet Operation

107070-01F

Not Important Somewhat Important Very Important

❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍

TAPE

2701 Industrial Drive P.O. Box 90004 Bowling Green, KY 42102-9004

Postage

Required

For more information, visit www.desatech.com

TAPE

107070-01F

NOTES

_______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________

For more information, visit www.desatech.com

107070-01F

WARRANTY INFORMATION

KEEP THIS WARRANTY

Model Serial No. Date Purchased

Always specify model and serial numbers when communicating with the factory. We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty. We

make no other warranty, expressed or implied.

LIMITED WARRANTY

VENT-FREE GAS LOG HEATERS

DESA Heating Products warrants this product to be free from defects in materials and components for four (4) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions. To make a claim under this warranty the Bill of Sale or cancelled check must be presented.

This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to restore this heater to proper operating condition and an allowance for labor when provided by a DESA Heating Products Authorized Service Center. Warranty part(s) MUST be obtained through authorized dealers of this product and/or DESA Heating Products who will provide original factory replacement parts. Failure to use original factory replacement parts voids this warranty. The heater MUST be installed by a qualified installer in accordance with all local codes and instructions furnished with the unit.

This warranty does not apply to parts that are not in original condition because of normal wear and tear, or parts that fail or become damaged as a result of misuse, accidents, lack of proper maintenance or defects caused by improper installation. Travel, diagnostic cost, labor, transportation and any and all such other costs related to repairing a defective heater will be the responsibility of the owner.

TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS THE SALE OF THE PRODUCT; THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL OTHER EXPRESSED WARRANTIES AND LIMITS THE DURATION OF ANY AND ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE TO FOUR (4) YEARS ON ALL COMPONENTS FROM THE DATE OF FIRST PURCHASE; AND DESA HEATING PRODUCTS’ LIABILITY IS HEREBY LIMITED TO THE PURCHASE PRICE OF THE PRODUCT AND DESA HEATING PRODUCTS SHALL NOT BE LIABLE FOR ANY OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of incidental or consequential damages, so the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. For information about this warranty write:

2701 Industrial Drive P.O. Box 90004 Bowling Green, KY 42102-9004

www.desatech.com

107070 01

NOT A UPC

For more information, visit www.desatech.com

107070-01 Rev. F 10/03

107070-01F

Desa UNVENTED GAS LOG HEATER User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
