UNVENTED (VENT-FREE) GAS FIREPLACE

OWNER’S OPERATION AND INSTALLATION MANUAL

Shown with optional

hearth base accessory.

CGEFP33PRB, CGEFP33NRB

EFP33PRB, EFP33NRB

Gas Fireplace with Total Control System (TCS)

WARNING: If the information in this manual is not followed exactly, a ﬁre or explosion may result causing property damage, personal injury or loss of life.

— Do not store or use gasoline or other ﬂammable

vapors and liquids in the vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the ﬁre department.

— Installation and service must be performed by a quali-

ﬁed installer, service agency or the gas supplier.

Save this manual for future reference.

For more information, visit www.desatech.com

WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual for correct installation and operational procedures. For assistance or additional information consult a qualiﬁed installer, service agency or the gas supplier.

WARNING: This is an unvented gas-ﬁred heater. It uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation section on page 6 of this manual.

This appliance may be installed in an aftermarket,* permanently located, manufactured (mobile) home, where not prohibited by local codes.

This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases.

* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer

State of Massachusetts: The installation must be made by a licensed plumber or gas ﬁtter in the Commonwealth of Massachusetts.

Sellers of unvented propane or natural gas-ﬁred supplemental room heaters shall provide to each purchaser a copy of 527 CMR 30 upon sale of the unit.

Vent-free gas products are prohibited for bedroom and bathroom installation in the Common wealth of Massachusetts.

TABLE OF CONTENTS

Safety Information ............................................... 3

Product Identiﬁcation ...........................................

Local Codes ........................................................ 5

Unpacking ........................................................... 5

Product Features ................................................. 5

Air for Combustion and Ventilation ......................

Installation ........................................................... 8

Operating Fireplace ........................................... 25

Inspecting Burners ............................................ 28

Cleaning and Maintenance ................................ 29

www.desatech.com

Troubleshooting .................................................

Speciﬁcations .................................................... 33

Service Hints ..................................................... 33

Technical

Illustrated Parts Breakdown and Parts List ....... 34

Replacement Parts ............................................ 40

Accessories ....................................................... 40

Wiring Diagram .................................................. 42

Templates ..........................................................

Parts Central ..................................................... 45

Service .............................................. 33

111245-01B

SAFETY INFORMATION

WARNING: This product contains and/or generates chemicals known to the state of California to cause cancer or birth defects or other reproductive harm.

IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate or service this ﬁreplace. Improper use of this ﬁreplace can cause serious injury or death from burns, ﬁre, explosion, electrical shock and carbon monoxide poisoning.

DANGER: Carbon monoxide poisoning may lead to death!

Carbon Monoxide Poisoning: Early signs of carbon

monoxide poisoning resemble the ﬂu, with head aches, dizziness or nausea. If you have these signs, the heater may not be working properly. Get fresh air at once! Have heater serviced. Some people are more affected by carbon monoxide than others. These include pregnant women, people with heart or lung disease or anemia, those under the inﬂuence of alcohol and those at high altitudes.

Natural and Propane/LP Gas: Natural and pro-

pane/LP gases are odorless. An odor-making agent is added to the gas. The odor helps you detect a gas leak. However, the odor added to the gas can fade. Gas may be present even though no odor exists.

Make certain you read and understand all warn ings. Keep this manual for reference. It is your guide to safe and proper operation of this heater.

WARNING: Any change to this heater or its controls can be dangerous.

WARNING: Do not use a blower insert, heat exchanger insert or other accessory not approved for use with this heater.

WARNING: Do not allow fans to blow directly into the ﬁreplace. Avoid any drafts that alter burner ﬂame patterns. Ceiling fans can create drafts that alter burner ﬂame patterns. Altered burner patterns can cause sooting.

Due to high temperatures, the appliance should be located out of trafﬁc and away from furniture and draperies.

Do not place clothing or other ﬂammable material on or near the appliance. Never place any objects on the heater.

Fireplace front and screen become very hot when running ﬁreplace. Keep children and adults

away from hot surface to avoid burns or clothing ignition. Fireplace will remain hot for a time after shutdown. Allow surfaces to cool before touching.

Carefully supervise young children when they are in the room with heater. When using the handheld remote accessory keep selector switch in the OFF position to prevent children from turning

on burners with remote.

You must operate this ﬁreplace with the ﬁreplace screen and hood in place. Make sure ﬁreplace screen and hood are in place before running heater.

Keep the appliance area clear and free from combustible ma terials, gasoline and other ﬂam mable vapors and liquids.

111245-01B 3

www.desatech.com

SAFETY INFORMATION

Continued

1. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases.

2. Do not place propane/LP supply tank(s) in side any structure. Locate propane/LP supply tank(s) outdoors (propane/LP units only).

3. If you smell gas

• shut off gas supply

• do not try to light any appliance

• do not touch any electrical switch; do not use

any phone in your building

• immediately call your gas supplier from a

neighborʼs phone. Follow the gas supplierʼs instructions

• if you cannot reach your gas supplier, call

the ﬁre department

4. This ﬁreplace shall not be installed in a bed room or bathroom.

5. Do not use this ﬁreplace as a wood-burning ﬁreplace. Use only the logs provided with the ﬁreplace.

6. Do not add extra logs or ornaments such as pine cones, vermiculite or rock wool. Using these added items can cause sooting. Do not add lava rock around base. Rock and debris could fall into the control area of ﬁreplace.

7. To prevent the creation of soot, follow the instruc tions in Cleaning and Maintenance, page 29.

8. Before using furniture polish, wax, carpet cleaner or similar products, turn heater off. If heated, the vapors from these products may create a white powder residue within burner box or on adjacent walls or furniture.

9. This ﬁreplace needs fresh air ventilation to run properly. This ﬁreplace has an Oxygen Deple tion Sensing (ODS) safety shutoff system. The ODS shuts down the ﬁreplace if not enough fresh air is available. See Air for Combustion and Ventilation, page 6. If ﬁreplace keeps shutting off, see Troubleshooting, page 30.

10. Do not run ﬁreplace

• where ﬂammable liquids or vapors are used

or stored

• under dusty conditions

11. Do not use this ﬁreplace to cook food or burn paper or other objects.

12. Do not use ﬁreplace if any part has been exposed to or under water. Immediately call a qualiﬁed service technician to inspect the ﬁreplace and to replace any part of the control system and any gas control which has been under water.

www.desatech.com

13. Do not operate ﬁreplace if any log is broken. Do not operate ﬁreplace if a log is chipped (dime-sized or larger).

14. Turn ﬁreplace off and let cool before servicing. Only a qualiﬁed service person should service and repair ﬁreplace.

15. Operating ﬁreplace above elevations of 4,500 feet could cause pilot outage.

16. To prevent performance problems with pro pane/LP units, do not use propane/LP fuel tanks of less than 100 lb. capacity.

17. Prov ide adequa te clearance s around air openings.

PRODUCT

IDENTIFICATION

Log Set

Manual Override Handle

Remote

Control

Figure 1 - Fireplace Floor Assembly

Top Louver Assembly

Firebox

Hood

Firebox Support

Screen Assembly

Piezo Ignitor

Wall Switch Assembly

Bottom Louver Assembly

Figure 2 - Fireplace

Manual Ignition Bypass Switch

Blower Assembly (Optional)

Top Outer Casing

111245-01B

LOCAL CODES

Install and use ﬁreplace with care. Follow all local codes. In the absence of local codes, use the latest edition of The National Fuel Gas Code, ANSI Z223.1/NFPA 54*.

*Available from:

American National Standards Institute, Inc.

1430 Broadway

New York, NY 10018

National Fire Protection Association, Inc.

Batterymarch Park Quincy, MA 02269

UNPACKING

CAUTION: Do not remove the data plates attached to the heater base assembly. The data plates contain important warranty and safety information.

1. With utility knife, cut the carton all the way around above the staples on the bottom tray. Lift the carton off the heater. Remove packing. Note: The hood is located in the packing on the right hand side of the heater front. Lift the heater off the bottom tray.

2. Locate two screws above top corners of the ﬁreplace screen. Remove and discard these screws. Lift ﬁreplace screen up and pull out to remove.

3. Remove protective packaging applied to logs, log base assembly and ﬁreplace.

4. Remove ﬁreplace hood from carton insert.

5. Check all items for any shipping damage. If damaged, promptly inform dealer where you bought ﬁreplace.

PRODUCT FEATURES

OPERATION

This vent-free ﬁreplace is clean burning. It requires no outside venting. There is no heat loss out a vent or up a chimney. Heat is generated by both realistic ﬂames and glowing embers. When used without the optional blower, the ﬁreplace requires no electricity making it ideal for emergency backup heat.

SAFETY DEVICE

This ﬁreplace has a pilot with an Oxygen Depletion Sensing (ODS) safety shutoff system. The ODS/ pilot is a required feature for vent-free room heat ers. The ODS/pilot system shuts off the ﬁreplace if there is not enough fresh air.

PIEZO IGNITION SYSTEM

This ﬁreplace has a piezo ignitor. This system requires no matches, batteries or other sources to light ﬁreplace.

WIRELESS REMOTE CONTROL

This ﬁreplace features an infrared wireless remote control. This control system can be used to auto matically light the pilot and adjust the burner ﬂame height at the push of a button.

WIRED WALL-MOUNTED REMOTE CONTROL

This ﬁreplace features a two-button wall switch assembly with glowing LEDʼs. The wall switch per forms the same functions as the wireless hand-held remote control with the added feature of LEDʼs for visual feedback of operation and status.

OPTIONAL BLOWER ASSEMBLY ACCESSORY

This ﬁreplace accepts an optional blower assembly (not included). The GA3650T/GA3700T Series blower operates thermostatically and features a variable speed control. The GA3700/GA3750 Series operates manually and also features a variable speed control. The blower circulates heated air from the ﬁreplace into the room. Use of blower is optional. See Accessories, page 40.

111245-01B 5

www.desatech.com

AIR FOR COMBUSTION

AND VENTILATION

WARNING: This heater shall not be installed in a conﬁned space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air. Read the following instructions to insure proper fresh air for this and other fuel-burning appliances in your home.

Todayʼs homes are built more energy efﬁcient than ever. New materials, increased insulation and new construction methods help reduce heat loss in homes. Home owners weather strip and caulk around windows and doors to keep the cold air out and the warm air in. During heating months, home owners want their homes as airtight as possible.

While it is good to make your home energy efﬁ cient, your home needs to breathe. Fresh air must enter your home. All fuel-burning appliances need fresh air for proper combustion and ventilation.

Exhaust fans, ﬁreplaces, clothes dryers and fuel burning appliances draw air from the house to operate. You must provide adequate fresh air for these appliances. This will insure proper venting of vented fuel-burning appliances.

PROVIDING ADEQUATE VENTILATION

The following are excerpts from National Fuel Gas Code, ANSI Z223.1/NFPA 54, Section 5.3, Air for Combustion and Ventilation.

All spaces in homes fall into one of the three fol lowing ventilation classiﬁcations:

1. Unusually Tight Construction

2. Unconﬁned Space

3. Conﬁned Space The information on pages 6 through 8 will help

you classify your space and provide adequate ventilation.

Unusually Tight Construction

The air that leaks around doors and windows may provide enough fresh air for combustion and ventilation. However, in buildings of unusually tight construction, you must provide additional fresh air.

Unusually tight construction is deﬁned as construction where:

a. walls and ceilings exposed to the out

side atmosphere have a continuous water vapor retarder with a rating of one perm (6 x 10 less with openings gasketed or sealed and

b. weather stripping has been added on

openable windows and doors and

c. caulking or sealants are applied to

areas such as joints around window and door frames, between sole plates and ﬂoors, between wall-ceiling joints, between wall panels, at penetrations for plumbing, electrical and gas lines and at other openings.

If your home meets all of these three

criteria, you must provide additional fresh air. See Ventilation Air From Outdoors, page 8.

If your home does not meet all of the three criteria above, proceed to Determining

Fresh-Air Flow For Fireplace Location.

Conﬁned and Unconﬁned Space

The National Fuel Gas Code, ANSI Z223.1/NFPA 54 deﬁnes a conﬁned space as a space whose

volume is less than 50 cubic feet per 1,000 Btu per hour (4.8 m rating of all appliances installed in that space and an unconﬁned space as a space whose volume is not less than 50 cubic feet per 1,000 Btu per hour

(4.8 m

per kw) of the aggregate input rating of all appliances installed in that space. Rooms com municating directly with the space in which the appliances are installed*, through openings not furnished with doors, are considered a part of the unconﬁned space.

* Adjoining rooms are communicating only if there are doorless passageways or ventilation grills between them.

-11

kg per pa-sec-m2) or

per kw) of the aggregate input

DETERMINING FRESH-AIR FLOW FOR FIREPLACE LOCATION

Determining if You Have a Conﬁned or Unconﬁned Space

Use this work sheet to determine if you have a conﬁned or unconﬁned space.

Space: Includes the room in which you will install ﬁreplace plus any adjoining rooms with doorless passageways or ventilation grills between the rooms.

www.desatech.com

111245-01B

Remove Door into Adjoining

Room, Option

Ventilation Grills

Into Adjoining Room,

Option

ntilation Grills

Into Adjoining

Room,

Option 1

12"

AIR FOR COMBUSTION

AND VENTILATION

Continued

1. Determine the volume of the space (length x width x height).

Length x Width x Height =__________cu. ft.

(volume of space)

Example: Space size 20 ft. (length) x 18 ft.

(width) x 8 ft. (ceiling height) = 2880 cu. ft. (volume of space)

If additional ventilation to adjoining room is

supplied with grills or openings, add the volume of these rooms to the total volume of the space.

2. Multiply the space volume by 20 to determine the maximum Btu/Hr the space can support.

__________ (volume of space) x 20 = (Maxi-

mum Btu/Hr the space can support)

Example: 2880 cu. ft. (volume of space) x 20 =

57,600 (maximum Btu/Hr the space can support)

3. Add the Btu/Hr of all fuel burning appliances in the space.

Vent-free ﬁreplace ___________ Gas water heater* ___________ Gas furnace ___________ Vented gas heater ___________ Gas ﬁreplace logs ___________ Other gas appliances* + ___________ Total = ___________ * Do not include direct-vent gas appliances. Di

rect-vent draws combustion air from the outdoors and vents to the outdoors.

Example: Gas water heater ________ Vent-free ﬁreplace + ________ Total = ________

40,000

33,000

73,000

Btu/Hr Btu/Hr Btu/Hr Btu/Hr Btu/Hr Btu/Hr Btu/Hr

Btu/Hr Btu/Hr Btu/Hr

C. Install a lower Btu/Hr ﬁreplace, if lower Btu/Hr

size makes room unconﬁned.

If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support,

the space is an unconﬁned space. You will need no additional fresh air ventilation.

WARNING: If the area in which the ﬁreplace may be operated is smaller than that deﬁned as an unconﬁned space or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of the methods described in the National Fuel Gas Code, ANSI Z223.1/NFPA 54 Section 5.3 or applicable local codes.

VENTILATION AIR

Ventilation Air From Inside Building

This fresh air would come from an adjoining un conﬁned space. When ventilating to an adjoining unconﬁned space, you must provide two permanent openings: one within 12" of the ceiling and one within 12" of the ﬂoor on the wall connecting the two spaces (see options 1 and 2, Figure 3). You can also remove door into adjoining room (see

option 3, Figure 3). Follow the National Fuel Gas

Code, ANSI Z223.1/NFPA 54, Section 5.3, Air for Combustion and Ventilation for required size of

ventilation grills or ducts.

4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.

_________ _________

Btu/Hr (maximum the space can support) Btu/Hr (actual amount of Btu/Hr used)

Example: 57,600 Btu/Hr (maximum the space

can support)

73,000 Btu/Hr (actual amount of

Btu/Hr used)

The space in the above example is a conﬁned space because the actual Btu/Hr used is more than the maxi

mum Btu/Hr the space can support. You must provide additional fresh air. Your options are as follows:

A. Rework worksheet, adding the space of an adjoin

ing room. If the extra space provides an unconﬁned space, remove door to adjoining room or add ventilation grills between rooms. See Ventilation

Air From Inside Building.

B. Vent room directly to the outdoors. See Ventila

tion Air From Outdoors, page 8.

111245-01B 7

Figure 3 - Ventilation Air from Inside

www.desatech.com

Building

Outlet Air

ntilated

Attic

Outlet

Inlet Air

Ventilated

Crawl Space

Crawl

Space

To Attic

AIR FOR COMBUSTION

AND VENTILATION

Continued

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent openings: one within 12" of the ceiling and one within 12" of the ﬂoor. Connect these items directly to the outdoors or spaces open to the outdoors. These spaces include attics and crawl spaces. Follow the

National Fuel Gas Code, ANSI Z223.1/NFPA 54, Section 5.3, Air for Combustion and Ventilation for

required size of ventilation grills or ducts. IMPORTANT: Do not provide openings for inlet

or outlet air into attic if attic has a thermostatcontrolled power vent. Heated air entering the attic will activate the power vent.

Figure 4 - Ventilation Air from Outdoors

INSTALLATION

NOTICE: This heater is intended for use as supplemental heat. Use this heater along with your primary heating system. Do not install this heater as your pri mary heat source. If you have a central heating system, you may run system’s circulating blower while using heater. This will help circulate the heat throughout the house. In the event of a power outage, you can use this heater as your primary heat source.

vice person must install ﬁre place. Follow all local codes.

WARNING: A qualiﬁed ser-

www.desatech.com

WARNING: Never install the

ﬁreplace

• in a bedroom or bathroom

• in a recreational vehicle

• where curtains, f urni ture, clothing or other ﬂammable objects are less than 42 inches from the front, top or sides of the ﬁreplace

• in high trafﬁc areas

• in windy or drafty areas

CAUTION: This ﬁreplace creates warm air currents. These currents move heat to wall sur

faces next to ﬁreplace. Installing ﬁreplace next to vinyl or cloth wall coverings or operating ﬁreplace where impurities (such as, but not limited to, tobacco smoke, aromatic candles, clean

ing ﬂuids, oil or kerosene lamps, etc.) in the air exist, may discolor walls or cause odors.

Note: Your ﬁreplace is designed to be used in zero clearance installations. Wall or framing material can be placed directly against any exterior surface on the rear, sides or top of your ﬁreplace, except where standoff spacers are integrally attached. If standoff spacers are attached to your ﬁreplace, these spacers can be placed directly against wall or framing materials.

Use the dimensions shown for rough openings to create the easiest installation (see Built-In Fire place Installation, page 21).

IMPORTANT: Vent-free heaters add moisture to the air. Although this is beneﬁcial, installing ﬁre place in rooms without enough ventilation air may cause mildew to form from too much moisture. See

Air for Combustion and Ventilation

IMPORTANT: Make sure the ﬁreplace is level. If ﬁreplace is not level, log set will not work properly.

CHECK GAS TYPE

Use the correct gas type (natural or propane/LP) for your unit. If your gas supply is not correct, do not install ﬁreplace. Call dealer where you bought ﬁreplace for proper type ﬁreplace.

, page 6.

111245-01B

INSTALLATION

Continued

WARNING: This appliance is equipped for (natural or propane/LP) gas. Field conversion is not permitted.

ELECTRICAL HOOKUP

Thi s fir ep lace normally operates under 120 VAC/60 Hz line voltage. The electrical cord sup plied with your ﬁreplace is ﬁve feet in length. You must locate ﬁreplace within reach of a 120 volt grounded electrical outlet. If not, you must install an electrical outlet within reach of the ﬁreplace power cord. The GA3555 outlet accessory may be used for built-in applications.

INSTALLATION CLEARANCES

WARNING: Maintain the minimum clearances. If you can, provide greater clearances from ﬂoor, ceiling and adjoining wall.

MINIMUM CLEARANCE TO

COMBUSTIBLE MATERIALS

Top Left and Bottom Right Sides and Rear

0" 16" 0"

Carefully follow the instructions below. This will ensure safe installation.

Minimum Clearances For Side Combustible Material, Side Wall and Ceiling

A. Clearances from the side of the fireplace

cabinet to any combustible material and wall should follow diagram in Figure 5.

Example: The face of a mantel, bookshelf,

etc. is made of combustible material and protrudes 3 1/2" from the wall. This combustible material must be 4" from the side of the ﬁreplace cabinet (see Figure 5).

B. Clearances from the top of the ﬁreplace open

ing to the ceiling should not be less than 42 inches.

Example

*Minimum 16 inches from Side Wall

Figure 5 - Minimum Clearance for

Combustible to Wall

INSTALLATION SEQUENCE

After unpacking ﬁreplace (see Unpacking, page 4), we suggest that you install your ﬁreplace system in the following sequence:

Removal of ﬁreplace ﬂoor assembly (required)

Electrical connections for power cord (required)

3. Relocating wall switch (optional)

4. Installing blower accessory (optional)

Connecting ﬁreplace to gas supply (required)

6. Checking gas connections (required)

7. Firebox installation, conventional or built-in (required)

8. Installing brass perimeter trim (optional)

9. Installing ﬁreplace hood (required)

10. Installing logs (required)

11. Installing ﬁreplace screen (required)

Use the following instruction s to comp le te each step.

REMOVING FIREPLACE SCREEN AND FLOOR ASSEMBLY

NOTICE: Shutoff gas supply and disconnect heater from gas supply if installing blower into previously installed ﬁreplace. Contact a qualiﬁed service person to do this.

1. Remove ﬁreplace screen. Remove two screws

that hold ﬁreplace screen in place for shipping. These screws are located near top of screen. Discard screws. Lift ﬁreplace screen up and pull out to remove.

2. If logs are installed, carefully remove the logs and set aside, noting the properly mounted location of each.

111245-01B 9

www.desatech.com

INSTALLATION

Continued

3. Remove screws that attach ﬁreplace ﬂoor assembly to ﬁreplace. Open lower louver door. Carefully lift up ﬁreplace ﬂoor assembly and remove from ﬁreplace, taking care to pull ﬂexible gas line through the access holes (see Figure 6). Note: Be careful of all wires on underside of log base.

CAUTION: Do not pick up ﬁreplace ﬂoor assembly by burners. This could damage burners. Only handle base by grates.

Flexible Gas Line

Screws

Fireplace Floor Assembly

Figure 6 - Removing Fireplace Floor

Assembly

ELECTRICAL CONNECTIONS FOR POWER CORD

This fireplace operates on 120 VAC, 60 Hz power. An electrical power cord is supplied with this unit.

For Mantel Installation

1. Determine from which side of the ﬁreplace the power cord will exit. Locate the 1.5" diameter hole near the center of ﬂoor support bracket on appropriate side of lower cavity (see Figure 7).

2. Locate power cord. Remove wire tie or tape holding plug end of power cord.

3. Power cord has 2 plastic hole bushings threaded onto it. Route cordʼs 3-prong plug through the 1.5" diameter hole in appropriate ﬂoor support bracket.

4. Push ﬁrst plastic bushing completely through hole. Squeeze bushing as needed to do this.

5. Install the second plastic bushing into the hole in the ﬂoor support bracket by snapping into place.

6. Route the 3-prong plug through the 1.5" hole in ﬁreplace outer casing.

7. Install the ﬁrst plastic bushing into this hole by snapping into place.

8. After you have connected to gas supply and checked your gas connections (see pages 17 through 20), plug power cord into any conve nient 3-prong grounded wall receptacle near ﬁreplace.

For Recessed Installation

If an outlet is not installed in ﬁreplace, install model GA3555 - Outlet Kit with Cover. This kit will supply a convenient 3-prong grounded electrical outlet for power. Refer to installation manual provided with this optional accessory for instructions on wiring. must make all electrical connections.

Hole in Floor Support Bracket

Bushings

Figure 7 - Routing Power Cord

Note: A qualiﬁed installer

Hole in Outer Casing

Power Cord

RELOCATING WALL SWITCH ASSEMBLY

Note: The decorative wall switch plate supplied is white. The wall switch plate may be painted to match your decor.

The push-button switch and decorative wall plate assembly supplied with your ﬁreplace is pre-mounted at the factory in the lower cavity of the ﬁreplace. You may relocate this wall switch assembly to a more convenient location such as the side of your mantel or directly onto the wall near the ﬁreplace. To mount the wall switch assembly, you must ﬁrst cut openings in the mantel or wall where the switch will be located.

www.desatech.com

111245-01B

INSTALLATION

Continued

Note: If you choose to relocate the wall switch assembly, do so before ﬁnal installation into a mantel or recessing into a wall. If you are installing an optional blower accessory, install it at the same time you relocate the wall switch assembly.

CAUTION: The wall switch assembly must never be mounted directly above the ﬁreplace where heat may damage it. If you relocate wall switch assembly from lower ﬁreplace cavity, it must be mounted either on side wall of mantel or on wall to side of ﬁreplace.

For Recessed Installation

If fireplace is to be recessed into a wall (see Built-In Fireplace Installation, page 21), we recommend mounting wall switch assembly to left side of ﬁreplace. The wall switch assembly should be mounted approximately 12" from left edge of ﬁreplace and less than 60" from the ﬂoor. IMPORTANT: Do not locate wall switch assembly directly in front of wall stud - there must be room behind wall board for wires from switch. If you choose to locate wall switch assembly to right side of ﬁreplace, the length of the cord restricts you to less than 6" from right edge of ﬁreplace and less than 48" from ﬂoor.

For Mantel Installation

If ﬁreplace is to be installed into a mantel, (see Conventional Fireplace Installation, page 20) the wall switch assembly may be mounted on either side of the mantel, facing to the side. Do not locate wall switch assembly anywhere on the front face of the mantel.

CAUTION: Be careful of gas lines and wiring when moving ﬂoor.

1. Determine the new location for the wall switch assembly. The wires attached to switch are six feet long.

2. Remove 2 screws securing plastic wall switch assembly to bracket in ﬁreplace lower cavity. Save screws.

3. Remove wire tie holding coiled wire attached to wall switch assembly (see Figure 8).

111245-01B 11

www.desatech.com

4. Remove wall switch assembly from bracket.

5. Carefully pass wall switch assembly and cord through large elongated hole in rear of either left or right ﬂoor support bracket, depending on desired location of switch. Pass wall switch as sembly and cord through 1.5" diameter hole in side of ﬁreplace outer casing (see Figure 9).

6. Pull wall switch assembly and cord from ﬁreplace making sure wall switch assembly will reach desired mounting location without straining cord assembly.

If you are mounting wall switch assembly to a wall, continue reading. If you are mounting your wall switch assembly to the side of the mantel, see page 12.

Burner Outlet Tube

Figure 8 - Relocating Wall Switch

Hole in Outer Casing

Wall Switch Assembly

Figure 9 - Routing Wall Switch Assembly

Through Fireplace for Relocation

Mounting Wall Switch Assembly to Wall for Recessed Fireplace

7. Create three openings on wall according to Template 1, page 41. This is best done by making a pattern to work with on your wall. Carefully cut page 41/42 from manual and tape paper template vertically onto wall at preferred location. Pierce the paper at the centers of the 2 holes with a nail or sharp pencil, leaving a mark on the wall. Do the same at centers of the four circles near the corners of the rectangle.

Firebox Bottom

Wire Tie

Gas Control Valve

Assembly

Wall Switch Assembly

Hole in Floor Support Bracket

4 3/4"

3 3/4"

3/8"

3/16"

3/4"

3/8" Diameter 2 Holes

INSTALLATION

Continued

8. Remove paper template from wall.

9. Drill 3/8" holes at each mark.

10. Using a straight edge and pencil, connect the outer edges of the 4 holes for the rectangle (see Figure 10). This will give you cutting lines for the rectangle you will cut in the wall.

11. Using a keyhole saw, hack saw blade, drill, ﬁle or other suitable tool, carefully cut out the rectangular opening. Note: The corners of the rectangle may be round. IMPORTANT: Do not exceed the size of the rectangle on template.

12. From inside the recessed opening for the ﬁreplace, carefully pass wall switch assembly through the rectangular opening to the outside of the wall.

13. Using wall anchors supplied in hardware pack age, fold wall anchor as shown in Figure 11.

14. Insert wall anchor, wings ﬁrst, into hole. Tap anchor ﬂush to wall.

15. For thin walls (1/2" or less), insert red key into wall anchor. Push red key to “pop” open anchor wings. See Figure 12. IMPORTANT: Do not hammer key! For thick walls (over 1/2" thick), do not pop open wings.

Make Marks at Centers of Holes

Template from This Manual

Figure 10 - Using Template for Wall

Switch Assembly Installation

Figure 11 - Folding

Anchor

Figure 12 - Popping

Open Anchor Wings

for Thin Walls

16. Position wall switch assembly vertically over wall openings with decal lettering upright (see Figure 13).

17. Insert mounting screws, removed in step 2 of Relocating Wall Switch Assembly on page 10, through holes in wall plate and into wall anchors.

18. Tighten screws until wall plate is ﬁrmly at tached to wall. Do not overtighten.

Figure 13 - Securing Wall Switch

Mounting Wall Switch Assembly to Side of Mantel

7. Create three openings in the mantel wall according to Template 2, page 41. This is best done by making a pattern to work with on the

Cutting Lines

mantel. Carefully cut page 39/40 from manual and tape paper template vertically onto mantel wall at preferred location. Pierce the paper at the centers of the 2 holes with a nail or sharp pencil, leaving a mark on the wall. Do the same at centers of the four circles near the corners of the rectangle.

8. Remove paper template from mantel wall.

9. Drill 1/8" pilot holes at each mark for top and bottom screw holes. Drill 3/8" holes at each mark for centers of four circles near corners of rectangle.

10. Using a straight edge and pencil, connect the outer edges of the 4 holes for the rectangle (see Figure 10). This will give you cutting lines for

Tape

the rectangle you will cut in the mantel wall.

12. Carefully pass wall switch assembly through rectangular opening from inside mantel (see Figure 13).

www.desatech.com

Opening in Wall or Mantel Wall

Wall Switch Assembly

Screws

Assembly

111245-01B

INSTALLATION

Continued

13. Position wall switch assembly vertically over opening with decal lettering upright. Make sure wires freely pass through wall without binding. Align holes in wall plate with 1/8" pilot holes in mantel wall.

14. Drive mounting screws, removed in step 2 of Relocating Wall Switch Assembly on page 10, through wall plate holes and into pilot holes in mantel wall.

15. Tighten screws until wall switch assembly is ﬁrmly attached to mantel. Do not overtighten.

INSTALLING VARIABLE SPEED BLOWER ACCESSORY

NOTICE: Shut off gas supply and disconnect heater from gas supply if installing blower into previously

on the exit side (see Figure 16). Install the second plastic bushing provided into the

1.5" hole in the outer casing through which the power cord will exit. Route power cord through both plastic bushings and plug the power cord into a properly grounded 3-prong wall receptacle near the ﬁrebox.

b. If your ﬁreplace system installation is

recessed and if an outlet is not installed in your ﬁreplace, you must install the

GA3555 Outlet kit with cover in your ﬁreplace which will supply a convenient 3-prong grounded electrical outlet for your blower. Refer to the installation manual provided with the model GA3555 accessory for instructions on wiring the duplex outlet. must make all electrical connections.

Blower

Note: A qualiﬁed installer

installed ﬁreplace. Contact a qualiﬁed service person to do this.

1. If ﬁreplace screen and ﬂoor are still installed, see Removing Fireplace Screen and Floor Assembly, page 9.

2. Attach the power cord to the blower motor by ﬁrmly pushing the two female terminals at the end of the power cord onto the two spade terminals on the blower motor.

3. Attach green ground wire from power cord to blower housing using screw provided (see Figure 14). Tighten screws securely.

4. Place the blower against lower rear wall of ﬁrebox outer wrapper with the exhaust port directed upward. Align the holes in top mount ing tabs of blower with holes in wall of wrap per (see Figure 14). Using 2 screws provided, mount blower and tighten screws securely.

5. Be certain that all wire terminals are securely at tached to terminals on blower motor and that the screw retaining the green ground wire is tight.

6. Place control knob provided on plastic control shaft of speed control.

7. Mount the speed control on the front leg of the left ﬂoor support bracket using 2 screws provided (see Figure 15).

8. Plug in blower power cord. a. If your ﬁreplace system is installed as a

freestanding unit with an accessory man tel, determine whether the power cord will

exit the left side or the right side of the ﬁre box. Install 1 plastic bushing provided into the 1.5" hole in the ﬂoor support bracket

111245-01B 13

www.desatech.com

Screws

Exhaust Port

Screw

Green Ground Wire

Figure 14 - Mounting Blower to Firebox

Left Floor Support Bracket

Screws

Speed

Control

Knob

Figure 15 - Attaching Speed Control to

Control

Control Shaft

Firebox

Lower Rear Wall of Firebox

Top Mounting Tab

INSTALLATION

ower Moto

Variable

Fan Switch

White

Black

Green

0/115

A.C.

Blower

Motor

Black

Off

Continued

9. Check to make sure that all electrical cords are completely clear of the blower wheel and that there are no other foreign objects in blower wheel. Turn blower on and check for operation. Turn blower off by rotating knob fully counterclockwise before continuing.

CAUTION: Never touch the

blower wheel while in operation.

10. Peel off backing paper and stick supplied wiring diagram decal near center of ﬁrebox bottom (Figure 17).

11. If gas connection s have been made and checked, replace ﬁreplace ﬂoor assembly. Feed ﬂexible gas supply line into ﬁreplace base area while replacing ﬁreplace ﬂoor as sembly. Make sure the entire ﬂexible gas line is in ﬁreplace base area.

IMPORTANT: Do not pick up ﬁreplace ﬂoor

assembly by burners. This could damage burners. Only handle base by grates. Note: Be careful of all wires and components on underside of ﬂoor assembly.

12. Reattac h firepla ce floor asse mbly with screws removed in step 3 of Removing Fire place Screen and Floor Assembly, page 9. Note: Discard the remaining hardware items. After assembly, make sure all wires are com pletely clear of blower wheel.

13. Install logs (see Installing Logs, page 24 and ﬁreplace screen (see Installing Screen, page

25).

WARNING: Failure to position the parts in accordance with supplied diagrams or failure to use only parts speciﬁcally approved with this heater may result in damage or personal injury.

WARNING: A qualiﬁed service person must connect ﬁreplace to gas supply. Follow all local codes.

Wiring Diagram

Figure 17 - Location of Wiring Diagram

Decal 3" from Blower

Operating the Blower

Light your gas appliance with the blower off. After about 15 minutes, turn the blower on to deliver heated air at the top louvers. The blower features a variable control which allows you to select the speed you desire. Note: Periodically check the louvers of the ﬁrebox and remove any dust, dirt

Right Floor Support Bracket

Figure 16 - Installing Plastic Bushing for

Power Cord

Plastic Bushing

www.desatech.com

or other obstructions.

111245-01B

INSTALLATION

Continued

INSTALLING THERMOSTATIC BLOWER ACCESSORY

NOTICE: Shut off gas supply and disconnect heater from gas supply if installing blower in previously installed ﬁreplace. Contact a qualiﬁed service person to do this.

1. If ﬁreplace screen and ﬂoor are still installed, see Removing Fireplace Screen and Floor Assembly, page 9.

2. Using screw provided, attach green ground wire from speed control cord to blower hous ing. Tighten screw securely (see Figure 18).

3. Place the blower against lower rear wall of ﬁrebox outer wrapper with the exhaust port directed upward. Align the holes in top mount ing tabs of blower with holes in wall of wrapper (see Figure 19). Using two #8 screws provided, mount blower and tighten screws ﬁrmly.

4. Remove the three screws (do not discard) and cover plate from center of ﬁrebox wrapper rear wall. Discard this cover plate (see Figure 18).

Thermostatic Switch and Cover Assembly

5. Mount the supplied thermostatic switch and cover assembly into ﬁrebox wrapper wall. Do this by feeding terminal ends of wire harness into the hole. Allow wires to fall to bottom of ﬁrebox cavity (see Figure 18).

6. Using three screws from step 7, attach switch and cover assembly to ﬁrebox wrapper rear wall. Tighten screws ﬁrmly (see Figure 18).

7. Firmly attach red wire from the thermostatic switch and cover assembly to either of the ter minals on the blower motor (see Figure 18).

8. Firmly attach black wire from speed control cord to blue wire from thermostatic switch and cover assembly (see Figure 18).

9. Firmly attach white wire from speed control cord to remaining terminal on blower motor (see Figure 18).

10. Place control knob provided on plastic control shaft of speed control (see Figure 20).

11. Mount the speed control onto the front leg of the left ﬂoor support bracket using 2 screws

provided (see Figure 20).

Lower Rear Wall of

Blower

Firebox

#8 Screws

Exhaust Port

Top

Blue Wire

Black Wire

White Wire

Speed Control

Green Wire

Figure 18 - Installing Switch and Cover

Assembly and Speed Control

111245-01B 15

Red Wire

Figure 19 - Mounting Blower to Firebox

Floor Support Bracket

Screws

Figure 20 - Attaching Speed Control

www.desatech.com

Control Knob

Speed Control

Mounting Tab

INSTALLATION

Blow

Moto

Red

riable

Fan Switch

(N.O.)

Green

White

0/115

A.C.

Blower

Motor

Black

Off

Black

Blue

Continued

WARNING: Failure to connect all wires properly as indicated may cause electrical short circuit or personal injury. A qualiﬁed electrician should check that all connections are made properly.

12. Plug in blower power cord. a. If your firebox is installed as a free-

standing unit with an accessory mantel, determine whether the power cord will exit the left side or the right side of the ﬁrebox. Install one plastic bushing provided into the 1 1/2" hole in the ﬂoor support on the exit side. Install the second bushing provided into the 1 1/2" hole in the outer casing through which the power cord will exit (see Figures 21 and 22). Route power cord through plastic bushings and plug the power cord into a properly grounded threeprong wall receptacle near the ﬁrebox.

b. If your ﬁreplace system installation is

recessed and if an outlet is not installed in your ﬁreplace, you must install the GA3555

Outlet kit with cover in your ﬁreplace which will supply a convenient 3-prong grounded electrical outlet for your blower. Refer to the installation manual provided with the model GA3555 accessory for instructions on wiring the duplex outlet. Note: A qualiﬁed installer must make all electrical connections.

13. Check to make sure that the power cord and all wires are completely clear of the blower wheel and that there are no other foreign objects in blower wheel.

CAUTION: Never touch the

blower wheel while in operation.

14. Peel off backing paper and stick supplied wiring diagram decal near center of ﬁrebox bottom (see Figure 23).

15. If gas connection s have been made and checked, replace ﬁreplace ﬂoor assembly in ﬁreplace. Feed ﬂexible gas supply line into ﬁreplace base area while replacing ﬁreplace ﬂoor assembly. Make sure the entire ﬂexible gas line is in ﬁreplace base area. IMPORTANT: Do not pick up ﬁreplace ﬂoor assembly by burners. This could damage burners. Only handle base by grates. Note: Be careful of all wires and components on underside of ﬂoor assembly.

www.desatech.com

Right Floor Support Bracket

Plastic Bushing

Figure 21 - Installing Plastic Bushing for

Power Cord (Right Side Exit Shown)

Plastic Bushing

Bushing Location for

Bushing Location for Recessed Installation

Freestanding Installation

Figure 22 - Installing Bushings

(Left Side Exit shown)

Wiring Diagram

Figure 23 - Location of Wiring Diagram

Decal 3" from Blower

111245-01B

INSTALLATION

Continued

16. Reattac h firepla ce floor asse mbly with screws removed in step 3 of Removing Fire place Screen and Floor Assembly, page 9. Note: Discard the remaining hardware items. After assembly, make sure all wires are com pletely clear of blower wheel.

17. Install logs (see Installing Logs, page 24) and ﬁreplace screen (see Installing Screen, page 25).

WARNING: Failure to position the parts in accordance with supplied diagrams or failure to use only parts speciﬁcally approved with this heater may result in damage or personal injury.

WARNIN G : A qu a li f ie d service person must connect ﬁreplace to gas supply. Follow all local codes.

If any of the original wire as supplied with the appliance must be replaced, it must be replaced with 105˚C wire or it's equivalent.

Operating the Blower

After ﬁnal installation of your ﬁreplace, light your gas appliance with the blower off. After about 15 minutes, turn the blower on to deliver heated air at the top louvers. The blower features a variable control which allows you to select the speed you desire. In the OFF position, the blower will not operate. In the ON position, the blower will start when the thermostat senses a sufﬁcient increase in ﬁrebox temperature (approximately 10 to 20 minutes depending on heat setting).

Your gas logs and thermostat blower will not turn on and off at the same time. The ﬁreplace may run for several minutes before the blower turns on. After the heater modulates to the pilot position, the blower will continue to run. The blower will shut off after the ﬁrebox temperature decreases.

It is safe to operate ﬁreplace with blower turned off. However, the blower helps distribute heated air from the ﬁreplace.

Note: Periodically check the louvers of the ﬁrebox and remove any dust, dirt or other obstructions.

INSTALLING GAS PIPING TO FIREPLACE LOCATION

WARNIN G : A qu a li f ie d service person must connect ﬁreplace to gas supply. Follow

all local codes.

WARNING: For propane/LP units, never connect ﬁreplace directly to propane/LP supply. This ﬁreplace requires an external regulator (not supplied). Install the external regulator between the heater and propane/LP supply.

WARNING: For natural gas units, never connect ﬁreplace to private (non-utility) gas wells. This gas is commonly known as wellhead gas.

Installation Items Needed

Before installing ﬁreplace, make sure you have the items listed below.

• external regulator (supplied by installer, for propane/LP units only)

• piping (check local codes)

• sealant (resistant to propane/LP gas)

• equipment shutoff valve *

• test gauge connection *

• sediment trap

• tee joint

• pipe wrench

• approved ﬂexible gas line with gas connector (if allowed by local codes) (not provided)

* A CSA design-certiﬁed equipment shutoff valve with 1/8" NPT tap is an acceptable alternative to test gauge connection. Purchase the optional CSA design-certiﬁed equipment shutoff valve from your dealer. See

For propane/LP units, the installer must supply an external regulator. The external regulator will reduce incoming gas pressure. You must reduce incoming gas pressure to between 11 and 14 inches of water. If you do not reduce incoming gas pres sure, heater regulator damage could occur. Install external regulator with the vent pointing down as shown in Figure 24, page 18. Pointing the vent down protects it from freezing rain or sleet.

Accessories, page 40.

111245-01B 17

www.desatech.com

INSTALLATION

Continued

CAUTION: Use only new, black iron or steel pipe. Internally-tinned copper tubing may be used in certain areas. Check your local codes. Use pipe of 1/2" diameter or greater to allow proper gas volume to ﬁreplace. If pipe is too small, undue loss of volume will occur.

Installation must include an equipment shutoff valve, union and plugged 1/8" NPT tap. Locate NPT tap within reach for test gauge hook up. NPT tap must be upstream from ﬁreplace (see Figure 24).

IMPORTANT: Install equipment shutoff valve in an accessible location. The equipment shutoff valve is for turning on or shutting off the gas to the appliance.

Check your building codes for any special re quirements for locating equipment shutoff valve to ﬁreplaces.

Apply pipe joint sealant lightly to male NPT threads. This will prevent excess sealant from going into pipe. Excess sealant in pipe could result in clogged ﬁreplace valves. Never use sealant on ﬂare threads.

WARNING: Use pipe joint sealant that is resistant to liquid petroleum (LP) gas.

External Regulator

Vent Pointing Down

Figure 24 - External Regulator with Vent

Pointing Down

Propane/LP Supply Tank

We recommend that you install a sediment trap in supply line as shown in Figure 25. Locate sediment trap where it is within reach for cleaning. Install in piping system between fuel supply and ﬁreplace. Locate sediment trap where trapped matter is not likely to freeze. A sediment trap traps moisture and contaminants. This keeps them from going into ﬁre place gas controls. If sediment trap is not installed or is installed wrong, ﬁreplace may not run properly.

CSA Design-Certiﬁed Equipment Shutoff Valve With 1/8" NPT Tap*

Natural

From Gas Meter (5" W.C. to

10.5" W.C.

3" Minimum

Pipe Cap Tee Nipple Joint

* Purchase the optional CSA design-certified equipment shutoff valve from your dealer. See Accessories, page 40.

Sediment Trap

Figure 25 - Gas Connection

Pressure)

Propane/LP

From External Regulator (11" W.C. to 14 " W.C. Pressure

CONNECTING FIREPLACE TO GAS SUPPLY

Installation Items Needed

• 5/16" hex socket wrench or nut-driver

• Phillips screwdriver

• sealant (res is tant to pro pane/LP gas, not provided)

1. If ﬁreplace screen and ﬂoor are still installed,

see Removing Fireplace Screen and Floor Assembly, page 9.

2. Route gas line (provided by installer) from

equipment shutoff valve to ﬁreplace. Route ﬂexible gas supply line through one of the access holes.

NOTICE: Most building codes do not permit concealed gas connec tions. A ﬂexible gas line is provided to allow accessibility from the ﬁreplace (see Figure 26, page 19). The ﬂexible gas supply line connection to the equipment shutoff valve should be accessible.

www.desatech.com

111245-01B

INSTALLATION

Continued

3. Attach the ﬂexible gas line to gas supply (see Figure 26). Check tightness of ﬂexible gas line attached to gas regulator of ﬁreplace (see Figure 26).

4. Check all gas connections for leaks. See Checking Gas Connections.

5. Replace ﬁreplace ﬂoor assembly. Feed ﬂexible gas line into ﬁreplace base area while replacing ﬁreplace ﬂoor assembly. Make sure the entire ﬂexible gas line is in ﬁreplace base area.

Note: Be careful of wires and components on

underside of ﬁreplace ﬂoor. Reattach ﬁreplace ﬂoor assembly with screws removed in step 3 of Removing Fireplace Screen and Floor Assembly, page 9.

To Fireplace Gas Regulator

Equipment Shutoff Valve Provided by Installer

Figure 26 - Attaching Gas Lines Together

CHECKING GAS CONNECTIONS

WARNING: Test all gas piping and connections, internal and external to unit, for leaks after installing or servicing. Correct all leaks at once.

WARNING: Never use an open ﬂame to check for a leak. Apply a noncorrosive leak detec tion ﬂuid to all joints. Bubbles forming show a leak. Correct all leaks at once.

Flexible Gas Line from Fireplace Gas Regulator

From Gas Meter (Natural) From External Regulator (Propane/LP)

WARNING: For propane/LP units, make sure external regulator has been installed between propane/LP supply and heater. See guidelines under

Gas Piping to Fireplace Loca

Installing

tion, page 17.

PRESSURE TESTING GAS SUPPLY PIPING SYSTEM

Test Pressures In Excess Of 1/2 PSIG (3.5 kPa)

1. Disconnect appliance with its appliance main gas valve (control valve) and equipment shutoff valve from gas supply piping system. Pressures in excess of 1/2 psig will damage ﬁreplace gas regulator.

2. Cap off open end of gas pipe where equipment shutoff valve was connected.

3. Pressurize supply piping system by either opening propane/LP supply tank valve for propane/LP gas or opening main gas valve located on or near gas meter for natural gas or using compressed air.

4. Check all joints of gas supply piping system. Apply noncorrosive leak detection ﬂuid to all joints. Bubbles forming show a leak.

5. Correct all leaks at once.

6. Reconnect ﬁreplace and equipment shutoff valve to gas supply. Check reconnected ﬁttings for leaks.

Test Pressures Equal To or Less Than 1/2 PSIG (3.5 kPa)

1. Close equipment shutoff valve (see Figure 27).

2. Pressurize supply piping system by either opening propane/LP supply tank valve for propane/LP gas or opening main gas valve located on or near gas meter for natural gas or using compressed air.

3. Check all joints from gas meter for natural gas or propane/LP supply to equipment shutoff valve for propane/LP gas (see Figures 28 or 29, page 20). Apply noncorrosive leak detection ﬂuid to all joints. Bubbles forming show a leak.

4. Correct all leaks at once.

Equipment Shutoff Valve

Open

Figure 27 - Equipment Shutoff Valve

111245-01B 19

www.desatech.com

Closed

INSTALLATION

Continued

PRESSURE TESTING FIREPLACE GAS CONNECTIONS

1. Open equipment shutoff valve (see Figure 27, page 19).

2. Open main gas valve located on or near gas meter for natural gas or open propane/LP supply tank valve.

3. Place manual ignition switch in the OFF position.

4. Check all joints from equipment shutoff valve to gas valve (see Figure 28 or 29). Apply noncorrosive leak detection ﬂuid to all joints. Bubbles forming show a leak.

5. Correct all leaks at once.

6. Light ﬁreplace (see Operating Fireplace, page

25). Check all other internal joints for leaks.

7. Turn off ﬁreplace (see To Turn Off Gas to Appliance, page 27).

Equipment Shutoff Valve

Gas Meter

Manual Gas Valve

Figure 28 - Checking Gas Joints for

Natural Gas Fireplace

Equipment Shutoff Valve

Propane/LP Supply Tank

CONVENTIONAL FIREPLACE INSTALLATION

Conventional installation of ﬁreplace involves installing ﬁreplace along with corner, face or cabinet mantel with hearth base accessories against a wall in your home. Follow instructions below to install ﬁreplace in this manner.

Note: The instructions below show installation us ing the cabinet mantel and hearth base accessories (see Accessories, page 40). The hearth base acces- sory shown is optional for this installation. You can install ﬁreplace and cabinet mantel directly on the ﬂoor. The corner mantel accessory cannot be installed with the hearth bases. You must install corner mantel directly on the ﬂoor.

1. Assemble cabinet mantel, hearth base and trim accessories. Assembly instructions are included with each accessory.

2. When installing blower, install a properly grounded, 120 volt three-prong electrical out let at ﬁreplace location if an outlet is not there. If possible, locate outlet so cabinet mantel will cover it when installed (see Figure 30).

3. If not already completed, install gas piping to ﬁreplace location. This installation includes an approved ﬂexible gas line (if allowed by local codes) after the equipment shutoff valve. The ﬂexible gas line must be the last item installed on the gas piping. See Installing Gas Piping

to Fireplace Location

4. Place hearth base accessory against wall at installation location. Cut an access hole in hearth top to run ﬂexible gas line to ﬁreplace (see Figure 30). Make sure to locate access hole so cabinet mantel will cover it when installed. Note: You can secure base to ﬂoor using wood screws. Countersink screw heads and putty over.

Rigid Pipe

Hearth Base

and Gas Shutoff Valve

, page 17.

Electrical Outlet

Gas Line Access Hole

Manual Gas Valve

Figure 29 - Checking Gas Joints for

Propane/LP Gas Fireplace

Figure 30 - Placing Hearth Base

www.desatech.com

Accessory Against Wall

111245-01B

INSTALLATION

Continued

5. Route ﬂexible gas line through access hole in hearth base.

6. Center cabinet mantel on hearth base (see Figure

31). Make sure mantel is ﬂush against wall.

7. Break off nailing ﬂanges (see Figure 32) with hammer or pliers.

8. Place cardboard or other protective material on top of hearth base. Carefully set ﬁreplace on protective material, with back of ﬁreplace inside mantel opening.

9. Attach ﬂexible gas line to ﬁreplace gas regula tor. See Connecting Fireplace to Gas Supply page 18.

10. Route electrical cord(s) through access holes in either side of ﬁreplace with bushing. Plug electrical cord(s) into electrical outlet.

Cabinet Mantel

11. Carefully insert ﬁreplace into cabinet mantel (see Figure 33). Be careful not to scratch or damage hearth base, cabinet mantel or any laminate trim on hearth base. Remove protective material from top of hearth base and from front of ﬁreplace (if any). Note: You can secure ﬁreplace to hearth or ﬂoor. Open lower louver. Locate screw holes in bottom of base. Tighten wood screws through these holes and into hearth or ﬂoor.

12. Check all gas connections for leaks. See Checking Gas Connections, page 19.

Figure 31 - Installing Cabinet Mantel

Nailing Flanges

Figure 32 - Location of Nailing Flanges

Figure 33 - Inserting Fireplace Into

Cabinet Mantel

BUILT-IN FIREPLACE INSTALLATION

Built-in installation of this fireplace involves installing ﬁreplace into a framed-in enclosure. This makes the front of ﬁreplace ﬂush with wall. If installing a mantel above the ﬁreplace, you must follow the clearances shown in Figure 37, page

23. Follow the instructions below to install the

ﬁreplace in this manner.

Actual Framing

Height 32

Front Width 34

Depth 16

1. Frame in rough opening. Use dimensions shown in Figure 34, page 22 for the rough opening. If installing in a corner, use dimen sions shown in Figure 35, page 22 for the rough opening. The height is 33" which is the same as the wall opening above.

2. Install and properly ground GA3555, threeprong 120 volt electrical outlet, in ﬁreplace. Follow instructions included in kit (see cessories, page 40).

" 33"

" 35

" 17

Ac-

111245-01B 21

www.desatech.com

INSTALLATION

35 1/2"

17 3/4"

33"

39 3/8"

27 7/8"

55 5/8"

35 1/2"

Continued

to Fireplace Location

4. Carefully set ﬁreplace in front of rough opening with back of ﬁreplace inside wall opening.

5. Attach ﬂexible gas line to gas supply. See Con necting Fireplace to Gas Supply, page 18.

6. Plug electrical cord(s) into electrical outlet installed in step 2.

7. Carefully insert ﬁreplace into rough opening.

8. Attach ﬁreplace to wall studs using nails or wood screws through holes in nailing ﬂange (see Figure 36).

9. Check all gas connections for leaks. See Checking Gas Connections, page 19.

10. Install brass trim. See Assembling and Attach

ing Optional Brass Trim

, page 17.

, page 23

Nails or Wood Screws

Figure 36 - Attaching Fireplace to Wall

Mantel Clearances for Built-In Installation

If placing mantel above built-in ﬁreplace, you must meet minimum clearance between mantel shelf and top of ﬁreplace opening.

Nailing Flanges

Studs

NOTICE: Surface temperatures of adjacent walls and mantels become hot during operation. Walls and mantels above the firebox may become hot to the touch. If installed properly, these temperatures meet the requirement of the national product standard. Follow all minimum clearances shown in this manual.

Figure 34 - Rough Opening for Installing

Figure 35 - Rough Opening for Installing

in Wall

in Corner

NOTICE: If your installation does not meet the minimum clearances shown, you must do one of the following:

• raise the mantel shelf to an acceptable height

• remove the mantel shelf

www.desatech.com

111245-01B

Supplied Firebox Hood Must Be Used at All Times

Wire-mesh Screen

Firebox

Noncombustible Material May Project Off this Surface above the Firebox Hood

Mantel Shelf

13"

16"

19"

21"

10"

Note: All vertical measurements are from top of fireplace hood opening to bottom of mantel shelf. These minimum clearances replace any other recommended clearances supplied with your ANSI Z21.11.2 approved gas logs.

ll board or facing material (above firebox) may be of combustible material, including decorative mantel ornaments or other similar projections off of the facing material.

Framing Material

INSTALLATION

Continued

Side Brass Trim

Slot

Top Brass Trim

Adjusting Plate

Set Screws

Shim

Mitered Edge

Slot

Figure 38 - Assembling Brass Trim

Trim Hanging Screws

Hanging Notches

Figure 37 - Minimum Mantel Clearances

on Trim

for Built-In Installation

ASSEMBLING AND ATTACHING OPTIONAL BRASS TRIM (Included with Mantel Accessory)

Note: The instructions below show assembling and attaching brass trim to ﬁreplace.

1. Remove packagi ng from three pieces of brass trim.

2. Locate four brass screws, two adjustin g plates with set screws and two shims in the hardware packet.

3. Align shim under adjusting plate as shown in Figure 38.

4. Slide one end of adjusting plate/shim in slot on mitered edge of top brass trim (see Figure 38).

5. Slide other end of adjusting plate/shim in slot on mitered edge of side brass trim (see Figure 38).

6. While ﬁrmly holding edges of brass trim to gether, tighten both set screws on the adjusting plate with slotted screwdriver.

7. Repeat steps 1 through 6 for the other side.

8. Tighten trim hanging screws (#10 x 6.25 shoulder) into holes in cabinets. Place the assembled trim onto ﬁreplace cabinet. Align hanging notches on trim with hanging screws on side of ﬁreplace (see Figure 39). Push trim ﬁrmly into place, sliding hanging notches over hanging screws.

111245-01B 23

www.desatech.com

Assembled Brass Trim

Figure 39 - Attaching Brass Trim to

Fireplace

INSTALLING HOOD

Install hood to top of ﬁrebox as shown in Figure 40. Use 3 Phillips screws provided.

Figure 40 - Installing Hood to Firebox

INSTALLATION

Continued

INSTALLING LOGS

Back Log (#3)

WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts speciﬁcally approved with this heater may result in property damage or personal injury.

CAUTION: Do not remove the warning and instruction labels attached to the heater base assembly. These markings contain important warranty information.

CAUTION: After installation and periodically thereafter, check to ensure that no ﬂame comes in contact with any log. With the heater set to HI, check to see if ﬂames contact any log. If so, reposition logs according to the log installation instructions in this manual. Flames contacting logs will create soot.

It is very important to install these logs exactly as instructed. Do not modify logs. Only use logs supplied with heater.

1. Locate pegs on the bottom of back log (#1). Slide these pegs into the holes in the grate base behind the burner (see Figure 41).

2. Place the base of the middle log (#2) in the U-shaped slots of the grate base in front of the back log. The cutout on the right of the middle log should ﬁt over the burner (see Figure 42). Make sure the front of the middle log is resting on the tabs of the grate base and the cutout area is centered over the burner “U” bend.

3. Locate the notches in the bottom of the front log (#3). Place the front log on the grate ﬁngers. Make sure the notches of the front log line up with the grate ﬁngers (see Figure 43).

4. Place left crossover log (#4) across logs #1, #2 and #3 ﬁtting holes on bottom of log #4 onto pin on front and middle logs as shown in Figure 44.

5. Place right crossover log (#5) in the same manner on right side of logs (see Figure 44, page 25).

Hole in Grate Base

Burner

Figure 41 - Installing Back Log (#1)

[CGEFP Logs Shown]

Middle Log (#3)

Tab

Burner

Figure 42 - Installing Middle Log (#2)

[CGEFP Logs Shown]

Notches

Grate Fingers

Figure 43 - Installing Front Log (#3)

[CGEFP Logs Shown]

Cutout

"U" Bend

U-shaped Slot

Front Log (#3)

www.desatech.com

111245-01B

INSTALLATION

Continued

Crossover Log (#4)

Pins

Figure 44 - Installing Crossover

Logs (#4 & #5) [CGEFP Logs Shown]

Crossover Log (#5)

INSTALLING BATTERY INTO REMOTE

1. Locate slot at bottom of remote control (see Figure 45). Firmly insert tool such as a small screwdriver, butter knife or dime into the slot and lift up to remove cover.

2. Insert supplied battery into remote control. Positive and negative are marked inside re mote control casing. Note: Remote will not function if battery is not installed correctly.

3. Slide tab on cover into remote housing and snap cover back into place.

IMPORTANT: Use only A23 12 volt battery in remote. DO NOT use AAA battery.

Slot

A23 12 Volt Battery

Positive

Negative

Figure 45 - Installing Battery

Tab

Cover

Remote Control

INSTALLING SCREEN

Install ﬁreplace screen by slipping notches of ﬁreplace screen over screws on front of ﬁreplace (see Figure 46).

Screws for

Mounting

Notches

Figure 46 - Installing Fireplace Screen

Screen

OPERATING FIREPLACE

FOR YOUR SAFETY

READ BEFORE LIGHTING

WARNING: If you do not follow these instructions exactly, a ﬁre or explosion may result causing property damage, per sonal injury or loss of life.

A. This appliance has a pilot which lights auto-

matically when using the supplied wall switch or remote control. If you have a power outage,

the pilot may be lighted by hand with pushbutton piezo ignitor. When lighting the pilot, the following warnings must be followed.

B. BEFORE LIGHTING smell all around the

appliance area for gas. Be sure to smell next to the ﬂoor because some gas is heavier than air and will settle on the ﬂoor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; use any phone in your building.

• Immediately call your gas supplier from a neig h bor ʼs phon e. Fo llo w the gas supplierʼs instructions.

• If you cannot reach your gas supplier, call the ﬁre department.

C. Electric Power Outage Only: Use only your

hand to turn the manual override handle on the gas control knob. Never use tools. If the knob will not turn by hand, donʼt try to repair it, call a qualiﬁed service technician or gas supplier. Force or attempted repair may result in a ﬁre or explosion.

D. Do not use this appliance if any part has been

under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.

do not

111245-01B 25

www.desatech.com

OPERATING FIREPLACE

Continued

NORMAL LIGHTING

INSTRUCTIONS

WARNING: You must operate this heater with the ﬁreplace screen in place. Make sure ﬁreplace screen is in place before running heater.

NOTICE: During initial operation of new heater, burning logs will give off a paper-burning smell. Open damper or window to vent smell. This will only last a few hours.

1. STOP! Read the safety information on page 25.

2. Make sure equip ment s hutoff valve is fully open.

3. Wait ﬁve (5) minutes to clear out any gas. Smell for gas around heater and near ﬂoor. If you smell gas, STOP! Follow “B” on page 25. If you donʼt smell gas, go to the next step.

A. Using Supplied Wall Switch Assembly

1. Set manual ignition bypass switch on the control panel to the OFF position (auto matic ignition position).

2. Press ON/OFF button. Hold for 6 seconds. Gas valve will open and electronic ignition will begin sparking to light pilot. LED will light. Note: You may be running this heater for the ﬁrst time after connecting to gas sup ply or at the start of your heating season. If so, the ON/OFF button may need to be pressed again. This will allow air to bleed from gas system. If several attempts to light pilot fail, contact a qualiﬁed service person or gas supplier for repairs. Until repairs are made, light and operate manually (see

Manual Lighting Instructions for Electric Power Outage, page 27).

3. When pilot ﬂame is lit, the thermocouple is heated by the ﬂame. When thermocouple becomes hot (5 to 15 seconds), main burner will automatically light on high ﬂame.

4. To lower ﬂame, push HI/LO button on wall switch once. have a pilot-only mode.

Note: This ﬁreplace does not

CAUTION: Do not try to adjust heating levels by using the equipment shutoff valve.

Manual Ignition Bypass Switch

HI/LO Button

Pilot Burner

Figure 49 - Pilot (Propane/LP Gas)

B. Using Hand-Held Wireless Remote

Control

1. Set manual ignition bypass switch on control panel to OFF position (automatic ignition position).

2. Wait ﬁve (5) minutes to clear out any gas. Smell for gas around heater and near ﬂoor. If you smell gas, STOP! Follow “B” on page 25, column 2. If you donʼt smell gas, go to the next step.

3. Point remote control toward the lower front of ﬁreplace and push both buttons at the same time. Hold for 6 seconds. The gas valve will open and electronic igni tion will begin sparking to light the pilot. Note: You will be able to hear a clicking sound during this process. LED on wall switch will light.

(Up is for Remote Control)

ON/OFF Button

Wall Switch

LED

Figure 47 - Control Locations

Manual Ignitor Electrode

Figure 48 - Pilot (Natural Gas)

Manual Ignitor Electrode

Assembly

Automatic Ignitor Electrode

www.desatech.com

111245-01B

OPERATING FIREPLACE

Continued

Note: You may be running this heater for

the ﬁrst time after connecting to gas supply or at the start of your heating season. If so, the ON button may need to be pressed again. This will allow air to bleed from gas system. If several attempts to light pilot fail, contact a qualiﬁed service person or gas supplier for repairs. Until repairs are made, light and operate manually (see Manual

Lighting Instructions for Electrical Power Outage).

4. When pilot ﬂame is lit, the thermocouple is heated by the ﬂame. When thermocouple becomes hot (5 to 15 seconds), main burner will automatically light on high ﬂame.

5. To lower ﬂame, point remote control toward lower front of ﬁreplace and push HI/LO button once.

Note: This ﬁreplace does not have a pilot-

only mode.

TO TURN OFF GAS

TO APPLIANCE

Shutting Off Heater - Wall Switch

Push ON/OFF button on wall switch once.

Shutting Off Heater - Wireless Remote Control

Point remote control toward lower front of ﬁre place and push both buttons at the same time.

MANUAL LIGHTING

INSTRUCTIONS FOR

ELECTRICAL POWER

OUTAGE

WARNING: You must operate this heater with the ﬁreplace screen in place. Make sure ﬁre place screen is in place before running heater.

Because this ﬁreplace has an electronic ignition system, in the event there is a loss of power, it will be necessary to manually light the pilot with the piezo ignitor. After the pilot is lit, the main burner will light automatically.

1. Follow steps 1 through 3 under Normal Lighting Instructions, page 26.

2. Set manual ignition bypass switch on con trol panel to ON position (manual ignition position). See Figure 50.

3. The pilot is attached to the rear of the front burner. You will be able to see the pilot and spark electrode without removing the screen or logs.

4. Place the magnetic manual override handle, provided with this unit, on the end of the gas valve stem (see Figure 50).

5. Turn the override handle fully counter clockwise to the PILOT position. The handle will not stop but will begin to slip when you have fully turned to the PILOT position.

6. While holding the valv e hand le in the PILOT position, press and release piezo ignitor button (see Figure 50). This will light the pilot. If needed, keep pressing ignitor button until pilot lights.

7. When pilot ﬂame is lit, hold manual over ride handle until thermocouple heats (ap proximately 5 to 15 seconds). If pilot goes

out, repeat process. If several attempts to light the pilot fail, contact a qualiﬁed service person or gas supplier for repairs.

8. When thermocou ple is heated, release override handle. The main burner will im mediately light on high ﬂame. Adjust ﬂame size by turning override handle.

Gas Valve

Piezo Ignitor

HI/LO Button

Manual Ignition Bypass Switch (Down is ON)

NOTICE: During initial operation of new heater, burning logs will give off a paper-burning smell. Open damper or window to vent smell. This will only last a few hours.

111245-01B 27

www.desatech.com

Magnetic Manual Override Handle

Wall Switch

Figure 50 - Control Locations

LED

ON/OFF Button

LED

OPERATING FIREPLACE

Continued

TO TURN OFF GAS

TO APPLIANCE

Shutting Off Heater When Manually Lit

Set manual ignition bypass switch on control panel to OFF (automatic ignition position). This will cause the controls to shut down the ﬁreplace.

OPTIONAL BLOWER

OPERATION

Locate the blower switch by opening lower louver on ﬁreplace. Blower switch is located at lower right inside louver door.

The GA3650T/GA3700T Series thermostatcontrolled blower has a variable speed control with an ON/OFF switch. The blower will start when the thermostat senses a sufﬁcient increase in ﬁrebox temperature. The GA3700/GA3750 Series vari ab le speed blow er also has an ON/OFF switch built into the variable speed control.

Note for GA3650T/GA3700T Series Only: If you are using this series blower, your ﬁreplace and blower will not turn on and off at the same time. The ﬁreplace may run for several minutes before the blower turns on. After the heater modulates to the pilot position, the blower will continue to run. The blower will shut off after the ﬁrebox temperature decreases.

Note: It is safe to operate ﬁreplace with blower turned off. However, the blower helps distribute heated air from the ﬁreplace.

Follow installation instructions included with the blower accessory.

INSPECTING BURNERS

Check pilot ﬂame pattern and burner ﬂame patterns often.

PILOT FLAME PATTERN

Figure 51 shows a correct pilot ﬂame pattern. Figure 52 shows an incorrect pilot ﬂame pattern. The incorrect pilot ﬂame is not properly heating the thermocouple. When the thermocouple cools, the heater will shut down.

If pilot ﬂame pattern is incorrect, as shown in Figure 52

• turn heater off (see To Turn Off Gas to Appli

ance, page 27 or 28 depending on situation)

• see Troubleshooting

Note: The pilot ﬂame on natural gas units will have a slight curve, but ﬂame should be blue and have no yellow or orange color.

Pilot Burner

Figure 51 - Correct Pilot Flame Pattern

(Natural Gas Pilot Assembly Shown)

Pilot Burner

Figure 52 - Incorrect Pilot Flame Pattern

(Natural Gas Pilot Assembly Shown)

, page 30

Thermocouple

MAIN BURNER

Periodically inspect all burner ﬂame holes with the heater running. All slotted burner ﬂame holes should be open with ﬂame present. All round burner ﬂame holes should be open with a small blue flame present. Some burner flame holes may become blocked by debris or rust, with no ﬂame present. If so, turn off heater and let cool. Remove blockage, blocked burner ﬂame holes may create soot.

www.desatech.com

111245-01B

CLEANING AND

MAINTENANCE

WARNING: Turn off ﬁreplace

and let cool before cleaning.

CAUTION: You must keep control areas, burners and circulating air passageways of ﬁreplace clean. Inspect these areas of ﬁreplace before each use. Have ﬁreplace inspected yearly by a qualiﬁed service person. Fireplace may need more frequent cleaning due to excessive lint from carpeting, bedding material, pet hair, etc.

BURNER INJECTOR HOLDER

The primary air inlet holes allow the proper amount of air to mix with the gas. This provides a clean burning ﬂame. Keep these holes clear of dust, dirt, lint and pet hair. Clean these air inlet holes prior to each heating season. Blocked air holes will create soot. We recommend that you clean the unit every three months during operation and have heater inspected yearly by a qualiﬁed service person.

We also recommend that you keep the burner tube and pilot assembly clean and free of dust and dirt. To clean these parts we recommend using compressed air no greater than 30 PSI. Your local computer store, hardware store or home center may carry compressed air in a can. You can use a vacuum cleaner in the blow position. If using compressed air in a can, please follow the directions on the can. If you don't follow directions on the can, you could damage the pilot assembly.

1. Shut off the unit, including the pilot. Allow the unit to cool for at least thirty minutes.

2. Inspect burner, pilot and primary air inlet holes on injector holder for dust and dirt (see Figure

53).

3. Blow air through the ports/slots and holes in the burner.

4. Check the injector holder located at the end of the burner tube again. Remove any large particles of dust, dirt, lint or pet hair with a soft cloth or vacuum cleaner nozzle.

5. Blow air into the primary air holes on the injector holder.

6. In case any large clumps of dust have now been pushed into the burner repeat steps 3 and 4.

Burner Tube

Primary Air Holes

Figure 53 - Injector Holder On Outlet

Injector Holder

Burner Tube

PILOT AIR INLET HOLE

Clean the pilot assembly also. A yellow tip on the pilot ﬂame indicates dust and dirt in the pilot as sembly. There is a small pilot air inlet hole about two inches from where the pilot ﬂame comes out of the pilot assembly (see Figure 54). With the unit off, lightly blow air through the air inlet hole. You may blow through a drinking straw if compressed air is not available. You may also clean the pilot air inlet hole by pushing a common pipe cleaner completely through the air inlet hole once.

Ports/Slots

Burner Tube

Pilot Assembly

Figure 54 - Pilot Inlet Air Hole

(Natural Gas Model Shown)

Pilot Air Inlet Hole

LOGS

• If you remove logs for cleaning, refer to Installing Logs, page 24 to properly replace logs.

• Replace log(s) if broken or chipped (dime-sized or larger).

111245-01B 29

www.desatech.com

TROUBLESHOOTING

WARNING: Turn off heater and let cool before servicing. Only a

qualiﬁed service person should service and repair heater.

CAUTION: Never use a wire, needle or similar object to clean

ODS/pilot. This can damage ODS/pilot unit.

Note: All troubleshooting items are listed in order of operation.

OBSERVED PROBLEM

When buttons on remote control are pressed, there is no response from ﬁreplace

POSSIBLE CAUSE

1. Battery in remote control is either missing or has low power

2. Remote control is not pointed toward ﬁreplace

3. M anual ig n i t i o n bypass switch not in OFF position

No power available to ﬁreplace

5. Ignitor electrode not connected to ignitor cable

6. Broken ignitor cable

7. Ignitor electrode broken

8. Ignitor electrode positioned wrong

REMEDY

1. Replace battery in rem ote control

2. Point remote control toward lower front panel of ﬁreplace when operating

3. Place manual ignition bypass switch in OFF position

4. Mak e su re pow er cor d is plugged into electrical outlet and outlet has power

5. Reconnect ignitor cable

6. Replace ignitor cable

7. Replace pilot assembly

8. Replace pilot assembly

Whe n wall switch button is pressed, there is no response from ﬁreplace

Burner does not light after ODS/ pilot is lit

Delayed ignition burner

Burner backﬁring during combustion

1. N o p ow e r a v a il a b le t o fir eplace

2. M anual ig n i t i o n bypass switch not in OFF position

3. Wall switch wire harness is disconnected

1. Burner oriﬁce clogged

2. Inlet gas pressure is too low

1. Man ifold pres sure is too low

2. Burner oriﬁce clogged

1. Burner oriﬁce is clogged or damaged

2. Damaged burner

3. Gas regulator defective

www.desatech.com

1. Mak e su re pow er cor d is plug ged int o an ele ctr ical outlet and outlet has power

2. Place manual ignition bypass switch in OFF position

3. Chec k conti n uit y of wa ll switch wire harness. Make sure plug on wall switch wire harness is fully inserted into socket on circuit board in ﬁreplace. Replace if necessary

1. Clean burner (see Cleaning and Maintenance, page 29) or replace burner oriﬁce

2. Contact local gas company

1. Contact local natural or propane/LP gas company

2. Clean burner (see Cleaning and Maintenance, page 29) or replace burner oriﬁce

1. Clean burner (see Cleaning and Maintenance, page 29) or replace burner oriﬁce

2. Replace damaged burner

3. Replace regulator

111245-01B

OBSERVED PROBLEM

Slight smoke or odor during initial operation

TROUBLESHOOTING

Continued

POSSIBLE CAUSE

1. Not enough air

2. Gas regulator defective

3. Residues from manufacturing processes and logs curing

REMEDY

1. Check burner for dirt and debris. If found, clean burner (see Cleaning and Mainte- nance, page 29)

2. Replace regulator

3. Problem will stop after a few hours of operation

Moisture/condensation noticed on windows

Heater produces a whistling noise when burner is lit

When ignitor button is pressed, there is no spark at ODS/pilot (manual ignition mode)

When ignitor button is pressed, there is spark at ODS/pilot but no ignition (manual ignition mode)

1. Not enough combustion/ventilation air

1. Turning control knob to HI position when burner is cold

2. Air in gas line

3. Air passageways on heater blocked

4. Dirty or partially clogged burner oriﬁce

1. Ignitor electrode not connected to ignitor cable

2. Ignitor cable pinched or wet

3. Piezo ignitor nut is loose

4. Broken ignitor cable

5. Bad piezo ignitor

6. Ignitor electrode broken

7. Ignitor electrode positioned wrong

1. Gas supply turned off or equipment shutoff valve closed

2. Control knob not in PILOT position

3. Air in gas lines when installed

4. Depleted gas supply (propane/LP only)

5. ODS/pilot is clogged

6. Gas regulator setting is not correct

1. Refer to Air for Combustion and Ventilation requirements (page 6)

1. Tu rn con t rol kn ob to LO position and let warm up for a minute

2. Operate burner until air is removed from line. Have gas line checked by local natural or propane/LP gas company

3. Observe minimum installation clearances (see page 9)

4. Clean burner (see Cleaning and Maintenance, page 29) or replace burner oriﬁce

1. Reconnect ignitor cable

2. Free ignitor cable if pinched by any metal or tubing. Keep ignitor cable dry

3. Tighten nut holding piezo ignitor to base panel of log set. Nut is located behind base panel

4. Replace ignitor cable

5. Replace piezo ignitor

6. Replace pilot assembly

7. Replace pilot assembly

1. Turn on gas supply or open equipment shutoff valve

2. Turn control knob to PILOT position full counterclockwise

3. Continue holding control knob in full counterclockwise position. Repeat igniting operation until air is removed

4. Contact local propane/LP gas company

5. Clean ODS/pilot (see Cleaning and Maintenance, page 29) or replace ODS/pilot assembly

6. Replace gas regulator

111245-01B 31

www.desatech.com

TROUBLESHOOTING

Continued

WARNING: If you smell gas

• Shut off gas supply.

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the ﬁre department.

IMPORTANT: Operating ﬁreplace where impurities in air exist may create odors. Cleaning supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc., create fumes. These fumes may mix with combustion air and create odors. These odors will disappear over time.

OBSERVED PROBLEM

ODS/pilot lights but ﬂame goes out when control knob is released (manual ignition mode)

Fireplace produces a clicking/ ticking noise just after burners are lit or shut off

Fireplace produces unwanted odors

Fireplace shuts off in use (ODS operates)

Gas odor even when wall switch and remote control buttons and switches are in OFF position

POSSIBLE CAUSE

1. Control knob not fully turned counterclockwise

2. Control knob not held long enough

3. Equipment shutoff valve not fully open

4. Pilot flame no t touch ing thermocouple, which allows thermocouple to cool, causing pilot ﬂame to go out. This problem could be caused by one or both of the following:

A) Low gas pressure B) Dirty or partially clogged

OD S/pilot

5. Thermocoup le connection loose at control valve

6. Thermocouple damaged

7. Control valve damaged

1. Metal expanding while heating or contracting while cooling

1. Fireplace burning vapo rs from paint, hair spray, glues, cleaners, chemicals, new carpet, etc. (see IMPORTANT statement above)

2. Ga s leak. See Warni ng

statement above

1. Not enough fre s h ai r is available

2. Low line pressure

3. O D S/ p i lo t is p a rt i a ll y clogged

1. Ga s leak. See Warn in g

statement above

2. Control valve defective

REMEDY

1. Turn control knob fully counterclockwise

2. After ODS/pilot lights, hold control knob for 30 seconds

3. Fully open equipment shutoff valve

4. A) Contact local natural or propane/LP gas company

B) C lean O D S/pil o t (see

Cleaning and Maintenance, page 29) or replace ODS/pilot assembly

5. Hand tighten until snug, then tighten 1/4 turn more

6. Replace pilot assembly

7. Replace control valve

1. This is common with most ﬁreplaces. If noise is excessive, contact qualiﬁed service person

1. Open window and ventilate room. Stop using odor causing products while ﬁreplace is running

2. Locate and correct all leaks (see Checking Gas Connec- tions, page 19)

1. Open window and/or door for ventilation

2. Contact local gas company

3. Clean ODS/pilot (see Cleaning and Maintenance, page 29)

1. Locate and correct all leaks (see Checking Gas Connec- tions, page 19)

2. Replace control valve

www.desatech.com

111245-01B

OBSERVED PROBLEM

Gas odor during combustion

TROUBLESHOOTING

Continued

POSSIBLE CAUSE

1. Foreign matter between control valve and burner

2. Ga s leak. See Warning

statement on t o p of page 32

REMEDY

1. Take apart gas tub ing and remove foreign matter

2. Locate and correct all leaks (see Checking Gas Connec- tions, page 19)

Dark residue on logs or inside of ﬁreplace Note: After removing all causes of residue deposits, completely clean ﬁreplace and appliances of all residue before reusing appliance.

White powder residue forming within burner box or on adjacent walls or furniture

1. Improper log placement

2. Drafts or other air currents affecting ﬂame pattern

3. Air holes at burn er inlet blocked

4. Burner ﬂame holes blocked

1. When heated, vapors from furniture polish, wax, carpet cleaners, etc. may turn into white powder residue

1. Properly locate logs (see In- stalling Logs, page 24)

2. Eliminate source of draf ts around heater

3. Clean out air holes at burner inlet. Periodically repeat as needed

4. Remove blockage

1. Turn heater off when using furniture polish, wax, carpet cleaners or similar products

SPECIFICATIONS

CGEFP33NRB CGEFP33PRB

Btu (Variable) 20,000/33,000 20,000/33,000 Type Gas Natural Propane/LP Ignition Electronic (Automatic) Electronic (Automatic)

/Piezo (Manual) /Piezo (Manual) Manifold Pressure 3.5" W.C. 8.0" W.C. Inlet Gas Pressure (in. of water) Maximum 10.5" 14" Minimum* 5" 11" Shipping Weight 122 lbs. 122 lbs. * For input adjustment

SERVICE HINTS

When Gas Pressure Is Too Low

• pilot will not stay lit

• burners will have delayed ignition

• heater will not produce speciﬁed heat

• for propane/LP units, propane/LP gas supply may be low

You may feel your gas pressure is too low. If so, con tact your local natural or propane/LP gas supplier.

TECHNICAL SERVICE

You may have further questions about installation, operation or troubleshooting. If so, contact DESA Heating Productsʼ Technical Service Department at 1-866-672-6040. When calling please have your model and serial numbers of your heater ready.

You can also visit DESA Heating Productsʼ techni cal service web site at www.desatech.com.

111245-01B 33

www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

REMOTE CONTROL LOG BASE ASSEMBLY MODELS CGEFP33PRB AND CGEFP33NRB (CGEFP33PRB SHOWN)

www.desatech.com

111245-01B

PARTS LIST

REMOTE CONTROL LOG BASE ASSEMBLY

This list contains replaceable parts used in your ﬁreplace. When ordering parts, follow the instructions listed under Replacement Parts on page 40 of this manual.

KEY PART NUMBER NO. CGEFP33PRB CGEFP33NRB DESCRIPTION QTY.

1 111625-04 111625-04 Back Log (#2) 1 2 111625-03 111625-03 Middle Log (#1) 1 3 111625-02 111625-02 Front Log (#3) 1 4 111625-06 111625-06 Left Crossover Log (#4) 1 5 111625-08 111625-08 Right Crossover Log (#5) 1 6 104286-02 104285-02 ODS Pilot 1 7 098249-01 098249-01 ODS Nut 2 8 099387-05 099387-05 Pilot Tube 1 9 101973-02 111331-17 Inlet Tube 1 10 107572-04 107572-04 Burner Outlet Tube 1 11 111124-01 111124-01 Burner Retainer Spring 1 12 099056-19 099056-26 Burner Oriﬁce Injector 1 13 102772-01 102772-01 Burner 1 14 M10908-2 M10908-2 Screw, Self-Tapping 2 15 ** ** Painted Base Assy 1 16 ** ** Firebox Bottom 1 17 107573-01 107573-01 Valve Bracket 1 18 107559-02 107559-01 Gas Control Valve 1 19 102445-01 102445-01 Piezo Ignitor 1 20 102334-01 102334-01 Palnut Fastener 1 21 107562-01 107562-01 Switch and Wire Assembly 1 22 107685-01 107685-01 Bracket, Switch and Piezo 1 23 101628-03 101628-03 Flexible Connector 1 24 098544-01 098544-01 Wire Support Clip 1 25 099415-18 099415-12 Pressure Regulator 1 26 097809-03 097809-03 Fitting 3/8" Flare to 1/2" NPT 1 27 107687-01 107687-01 Electrode Bracket 1 28 103904-02 103904-02 Electrode 1 29 100694-01 100694-01 Screw, #6 x 1 1/4" PH 2 30 107560-01 107560-01 Magnetic Manual Override Handle 1 31 107563-01 107563-01 Wall Switch and Cord 1 32 107558-01 107558-01 Wall Switch Decorative Plate 1 33 102349-02 102349-02 Support, PCB 4 34 107561-01 107561-01 Wall Plate Decal 1 35 107564-01 107564-01 Remote Control 1 36 107565-01 107565-01 Receiver Assembly 1 37 107565-02 107565-02 Sensor Assembly 1 38 107566-01 107566-01 Module, Control Board 1 39 098271-08 098271-08 Ignitor Cable 1 40 107568-01 107568-01 Main Power Cable 1 41 104015-01 104015-01 Power Cord 1 42 101629-01 101629-01 1.5" Bushing 2 43 098303-02 098303-02 Screw, #6 2 44 107743-01 107743-01 Thermocouple Wire 1 45 107847-01 107847-01 Screw, #6019 x 1/4" 2 46 103977-02 103977-02 Plug, Button 3/4" 1 47 103977-01 103977-01 Plug, Button 5/8" 1

PARTS AVAILABLE — NOT SHOWN

19724000 19724000 Cable Tie 4 901056-01 901056-01 Fitting, 3/8" NPT 1 107736-01 107736-01 Wall Plate Assembly Kit 1 (Contains Items 32, 34, 45) 107737-01 107737-01 Wall Switch Assembly Kit 1 (Contains Items 29, 31, 32, 34, 45)

** Not a ﬁeld replaceable part.

111245-01B 35

www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

REMOTE CONTROL LOG BASE ASSEMBLY MODELS EFP33PRB AND EFP33NRB (EFP33PRB SHOWN)

www.desatech.com

111245-01B

PARTS LIST

REMOTE CONTROL LOG BASE ASSEMBLY

This list contains replaceable parts used in your ﬁreplace. When ordering parts, follow the instructions listed under Replacement Parts on page 40 of this manual.

KEY PART NUMBER NO. EFP33PRB EFP33NRB DESCRIPTION QTY.

1 111625-04 111625-04 Back Log (#1) 1 2 111625-03 111625-03 Middle Log (#2) 1 3 111625-01 111625-01 Front Log (#3) 1 4 111625-05 111625-05 Left Crossover Log (#4) 1 5 111625-07 111625-07 Right Crossover Log (#5) 1 6 104286-02 104285-02 ODS Pilot 1 7 098249-01 098249-01 ODS Nut 2 8 099387-05 099387-05 Pilot Tube 1 9 101973-02 111331-17 Inlet Tube 1 10 107572-04 107572-04 Burner Outlet Tube 1 11 111124-01 111124-01 Burner Retainer Spring 1 12 099056-19 099056-26 Burner Oriﬁce Injector 1 13 102772-01 102772-01 Burner 1 14 M10908-2 M10908-2 Screw, Self-Tapping 2 15 ** ** Painted Base Assy 1 16 ** ** Firebox Bottom 1 17 107573-01 107573-01 Valve Bracket 1 18 107559-02 107559-01 Gas Control Valve 1 19 102445-01 102445-01 Piezo Ignitor 1 20 102334-01 102334-01 Palnut Fastener 1 21 107562-01 107562-01 Switch and Wire Assembly 1 22 107685-01 107685-01 Bracket, Switch and Piezo 1 23 101628-03 101628-03 Flexible Connector 1 24 098544-01 098544-01 Wire Support Clip 1 25 099415-18 099415-12 Pressure Regulator 1 26 097809-03 097809-03 Fitting 3/8" Flare to 1/2" NPT 1 27 107687-01 107687-01 Electrode Bracket 1 28 103904-02 103904-02 Electrode 1 29 100694-01 100694-01 Screw, #6 x 1 1/4" PH 2 30 107560-01 107560-01 Magnetic Manual Override Handle 1 31 107563-01 107563-01 Wall Switch and Cord 1 32 107558-01 107558-01 Wall Switch Decorative Plate 1 33 102349-02 102349-02 Support, PCB 4 34 107561-01 107561-01 Wall Plate Decal 1 35 107564-01 107564-01 Remote Control 1 36 107565-01 107565-01 Receiver Assembly 1 37 107565-02 107565-02 Sensor Assembly 1 38 107566-01 107566-01 Module, Control Board 1 39 098271-08 098271-08 Ignitor Cable 1 40 107568-01 107568-01 Main Power Cable 1 41 104015-01 104015-01 Power Cord 1 42 101629-01 101629-01 1.5" Bushing 2 43 098303-02 098303-02 Screw, #6 2 44 107743-01 107743-01 Thermocouple Wire 1 45 107847-01 107847-01 Screw, #6019 x 1/4" 2 46 103977-02 103977-02 Plug, Button 3/4" 1 47 103977-01 103977-01 Plug, Button 5/8" 1

** Not a ﬁeld replaceable part.

PARTS AVAILABLE — NOT SHOWN

111245-01B 37

www.desatech.com

ILLUSTRATED PARTS BREAKDOWN

FIREBOX MODELS CGEFP33PRB, CGEFP33NRB, EFP33PRB AND EFP33NRB

www.desatech.com

111245-01B

PARTS LIST

FIREBOX MODELS CGEFP33PRB, CGEFP33NRB, EFP33PRB AND EFP33NRB

This list contains replaceable parts used in your ﬁreplace. When ordering parts, follow the instructions listed under Replacement Parts on page 40 of this manual.

KEY NO. PART NUMBER DESCRIPTION QTY.

1 ** Top Outer Casing 1 2 ** Outer Casing 1 3 102758-02CK Right Front Side 1 4 102759-02CK Left Front Side 1 5 098304-01 Phillips Pan Head Screw, #10 9 6 104239-01CK Top Front Louver 1 7 101712-02 Firebox Hood 1 8 101348-01 Firebox Support 2 9 099230-02 Shoulder Screw 4 10 101872-03 Firebox Top 1 11 101346-01 Outer Base 1 12 ** Firebox Wrapper 1 13 101514-01 Cover 1 14 M11084-26 Hex Screw, #10 45 15 110466-01 Bottom Louvered Door 1 16 101727-02 Screen Assembly 1

PARTS AVAILABLE — NOT SHOWN

101386-02 Louvered Door Hinge 2 101784-01 Magnet Catch 2 102307-01 Strike Plate 2

** Not a ﬁeld replaceable part.

111245-01B 39

www.desatech.com

REPLACEMENT PARTS

Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty.

PARTS UNDER WARRANTY

Contact authorized dealers of this product. If they canʼt supply original replacement part(s), call DESA Heating Productsʼ Technical Service Department at 1-866-672-6040.

When calling DESA Heating Products, have ready

• your name

• your address

• model and serial numbers of your ﬁreplace

• how ﬁreplace was malfunctioning

• type of gas used (propane/LP or natural gas)

• purchase date

Usually, we will ask you to return the part to the factory.

PARTS NOT UNDER WARRANTY

Contact authorized dealers of this product or Parts Central (see page 43). If they canʼt supply original replacement part(s), call DESA Heating Products at 1-866-672-6040 for referral information.

When calling DESA Heating Products, have ready

• model number of your ﬁreplace

• the replacement part number

ACCESSORIES

Purchase these ﬁreplace accessories from your local dealer or Parts Central (see page 43). If they can not supply these accessories, call DESA Heat ing Products at 1-866-672-6040 for information. You can also write to the address listed on the back page of this manual.

BLOWER ACCESSORIES GA3700/GA3750 & GA3650T/ GA3700T SERIES

For all models. Manual variable control and automatic thermostat variable control. A blower will increase air ﬂow to maximize heat distribution.

DUPLEX OUTLET KIT - GA3555

(Not Shown)

For all models. Use for built-in installations when hard wiring your ﬁreplace.

BRASS TRIM ACCESSORY - GA7090

(Not Shown)

For all models. Optional with built-in installation. Provides a ﬁnished appearance covering rough and/or unﬁnished mantel or wall opening, edges, etc. (Included with mantel accessory.)

CLEANING KIT - CCK/GCK

(Not Shown)

For all models. Your vent-free gas appliance re quires regular cleaning and maintenance to prevent performance problems. This kit gives you the tools and instructions to make it easy to clean all critical areas of your appliance.

INFORMATION VIDEO - 108917-01

For all models. A care and maintenance video is avail-

able by calling 1-866-672-6040. You may also email

your request to productsupport@desaint.com.

FIREBOX BRICK LINER - G8005 SERIES

(Not Shown)

For all models. Ceramic ﬁber ﬁrebox liner adds the look of real brick.

EQUIPMENT SHUTOFF VALVE

- GA5010

For all models. Equipment shutoff valve with 1/8" NPT tap. Fits 1/2" NPT pipe.

www.desatech.com

111245-01B

PILO T

OFF

ACCESSORIES

Continued

CORNER MANTEL AND BASE ACCESSORY WITH FIREPLACE PERIMETER TRIM

(Not Shown)

CMA303 Series - Unﬁnished Oak Veneer, Ready to Stain or Paint

For all models. Space saving corner mantels feature moldings, ﬂuting and medallion.

CABINET MANTEL AND BASE ACCESSORY WITH FIREPLACE PERIMETER TRIM

CMA305U Series - Unﬁnished Oak Veneer, Ready to Stain or Paint CMA300F Series - Stained Oak Veneer CMA302F Series - Cherry Stained Birch Veneer

For all models. Mantel and base feature moldings, ﬂuted sides and medallion.

Mantel Dimensions (H xW xD): 44 7/8" x 55 5/8" x 23 1/8"

Base Dimensions (H xW xD): 5

/8" x 58 5/8" x 25 3/4"

CORNER MANTEL ACCESSORY WITH FIREPLACE PERIMETER TRIM

(Not Shown)

GMC36F Series - Walnut Finished Hardwood Veneer GMC37U Series - Unﬁnished Hardwood Veneer, Ready to Stain or Paint GM202F Series - Medium Stained Oak Veneer

For all models. Mantel features moldings, ﬂuted sides and medallion.

CABINET MANTEL ACCESSORY WITH FIREPLACE PERIMETER BRASS TRIM

GMC11F Series - Walnut Finished Hardwood Veneer GMC12U Series - Unﬁnished Hardwood Veneer, Ready to Stain or Paint GMC13F Series - Medium Stained Oak Veneer GM102W Series - Off-White Paint

For all models. Mantel features moldings, ﬂuted sides and medallion. Dimensions (H xW xD): 48" x 56 3/4" x 22 3/4"

CORNER HEARTH BASE (FOR USE WITH CORNER MANTEL)

(Not Shown)

G3008F Series - Walnut Stained G3009U Series - Unﬁnished G3010F Series - Oak Stained

For all models. The hearth base creates a hand some riser for the corner ﬁreplace.

HEARTH BASE (FOR USE WITH CABINET MANTEL)

GC3335F Series - Medium Stained Oak Veneer G3004W Series - Off-White Paint GC3333F Series - Walnut Stained GC3334U Series - Unﬁnished

For all models. The hearth base creates a handsome riser for the ﬁreplace. Dimensions (H xW xD):

/2" x 58" x 28 9/16"

111245-01B 41

www.desatech.com

WIRING DIAGRAM

Note: For proper operation, the wires must be connected exactly as shown in wiring diagram. See pages 35 or 37 for number key.

32 19

www.desatech.com

111245-01B

TEMPLATES

4 3/4

"4 3/4

3 3/4"

3/8"

3 3/4"

3/8"

3/16"

3/4" 3/4"

3/8" Diameter 2 Holes

1/8" Diameter 2 Holes

111245-01B 43

www.desatech.com

THIS PAGE INTENTIONALLY LEFT BLANK

www.desatech.com

111245-01B

PARTS CENTRAL

These Parts Centrals are privately owned businesses. They have agreed to support our customerʼs needs by providing original replacement parts and accessories.

Tool & Equip. Co.

5 Manila Ave. Hamden, CT 06514-0322 1-800-397-7553 203-248-7553 Parts Department

Portable Heater Parts

342 N. County Rd. 400 East Valparaiso, IN 46383-9704 All States 219-462-7441 1-888-619-7060 sales@portableheaterparts.com techservice@portableheaterparts.com

FBD

1349 Adams St. Bowling Green, KY 42103-3413 270-846-1199 1-800-654-8534 Fax: 1-800-846-0090 franktalk@aol.com

Master Parts Distributors

1251 Mound Ave. NW Grand Rapids, MI 49504-2672 616-791-0505 1-800-446-1446 Fax: 616-791-8270 www.nbmc.com

Washer Equipment Co.

1715 Main Street Kansas City, MO 64108-2195 KS, MO, AR 816-842-3911 www.washerparts.com

East Coast Energy Products

10 East Route 36 W. Long Branch, NJ 07764 732-870-8809 1-800-755-8809 www.njplaza.com/ecep

21st Century

2950 Fretz Valley Road Perkasie, PA 18944-4034 215-795-0400 800-325-4828

Laportes Parts & Service

2444 N. 5th Street Hartsville, SC 29550-7704 803-332-0191 Parts Department

Cans Unlimited, Inc.

P.O. Box 645 Taylor, SC 29687-0013 All States 803-879-3009 1-800-845-5301 cuisales@aol.com

111245-01B 45

www.desatech.com

NOTES

______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________

www.desatech.com

111245-01B

NOTES

111245-01B 47

www.desatech.com

111245 01

2701 Industrial Drive P.O. Box 90004 Bowling Green, KY 42102-9004 www.desatech.com

NOT A UPC

111245-01 Rev. B 09/04

Desa EFP33NRB, CGEFP33PRB, CGEFP33NRB, EFP33PRB User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

SAFETY INFORMATION

LOCAL CODES

UNPACKING

PRODUCT FEATURES

INSTALLATION

OPERATING FIREPLACE

INSPECTING BURNERS

TROUBLESHOOTING

SPECIFICATIONS

SERVICE HINTS

TECHNICAL SERVICE

REPLACEMENT PARTS

ACCESSORIES

WIRING DIAGRAM

TEMPLATES

PARTS CENTRAL
