Dell SC1430 User Manual

Dell™ PowerEdge™
SC1430 Systems
Hardware Owner’s Manual
www.dell.com | support.dell.com
Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your computer.
problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
____________________
Information in this document is subject to change without notice. © 2006 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell, the DELL logo, Inspiron, Dell Precision, Dimension, OptiPlex, Latitude, P owerEdge, P owerV ault, P owerApp,
PowerConnect, and XPS are trademarks of Dell Inc.; Intel is a registered trademark of Intel Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation; EMC is a registered trademark of EMC Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
Model EMS01
June 2006 P/N WH819 Rev. A00

Contents

1 About Your System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Other Information You May Need . . . . . . . . . . . . . . . . . . . . . . . . . 9
Accessing System Features During Startup
Front-Panel Features and Indicators
Back-Panel Features and Indicators
Connecting External Devices NIC Indicator Codes
Diagnostics Indicator Codes
System Messages
Warning Messages
Diagnostics Messages
Alert Messages
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . . . . . 15
. . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . 13
2 Using the System Setup Program . . . . . . . . . . . . . . . . . . 27
Entering the System Setup Program . . . . . . . . . . . . . . . . . . . . . . . 27
Responding to Error Messages Using the System Setup Program
System Setup Options
Main Screen
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
CPU Information Screens Integrated Devices Screen System Security Screen Exit Screen
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
. . . . . . . . . . . . . . . . . . . . . . . 27
. . . . . . . . . . . . . . . . . . . . . . 28
. . . . . . . . . . . . . . . . . . . . . . . . . . 31
. . . . . . . . . . . . . . . . . . . . . . . . . 32
. . . . . . . . . . . . . . . . . . . . . . . . . . 33
System Event Log
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
System and Setup Password Features
Using the System Password Using the Setup Password
Disabling a Forgotten Password
. . . . . . . . . . . . . . . . . . . . . . . . 36
. . . . . . . . . . . . . . . . . . . . . . . . . 38
. . . . . . . . . . . . . . . . . . . . . . . . . 39
. . . . . . . . . . . . . . . . . . . . . . 35
Contents 3
3 Installing System Components . . . . . . . . . . . . . . . . . . . . 41
Recommended Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Inside the System
Opening the System
Closing the System
Rotatable Hard-Drive Carrier
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
. . . . . . . . . . . . . . . . . . . . . . . . . . 44
Rotating the Hard-Drive Carrier Out of the System Rotating the Hard-Drive Carrier Into the System
Removing and Replacing the Front Drive Bezel
Removing and Replacing the Front Drive Bezel Insert
Hard Drives
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Hard Drive Installation Guidelines
. . . . . . . . . . . . . . . . . . . . . 48
Removing a Hard Drive from the Rotatable Carrier Installing a Hard Drive in the Rotatable Carrier Removing an Optional Third Hard Drive Installing an Optional Third Hard Drive Removing an Optional Fourth Hard Drive Installing an Optional Fourth Hard Drive
Diskette Drive
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Removing the Diskette Drive Installing a Diskette Drive
. . . . . . . . . . . . . . . . . . . . . . . . . . 64
. . . . . . . . . . . . . . . . . . . . . . . . 63
. . . . . . . . . . . . . . . . . . 54
. . . . . . . . . . . . . . . . . . . 55
. . . . . . . . . . . . . . . . . . 58
. . . . . . . . . . . . . . . . . . 59
. . . . . . . . . . . . . 44
. . . . . . . . . . . . . . 46
. . . . . . . . . . . . . . . . . 46
. . . . . . . . . . . 47
. . . . . . . . . . . . . 49
. . . . . . . . . . . . . . 50
4 Contents
Optical and Tape Drives
Removing an Optical or Tape Drive Installing an Optical or Tape Drive
Expansion Cards
Installing an Expansion Card Removing an Expansion Card
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
. . . . . . . . . . . . . . . . . . . . . 66
. . . . . . . . . . . . . . . . . . . . . 68
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
. . . . . . . . . . . . . . . . . . . . . . . . 70
. . . . . . . . . . . . . . . . . . . . . . . . 72
Installing a SAS Controller Expansion Card
Microprocessor
Removing the Processor Replacing the Processor
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
. . . . . . . . . . . . . . . . . . . . . . . . . . 73
. . . . . . . . . . . . . . . . . . . . . . . . . . 75
. . . . . . . . . . . . . . . . . . . 72
Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
General Memory Module Installation Guidelines Non-Optimal Memory Configurations Installing Memory Modules Removing Memory Modules
. . . . . . . . . . . . . . . . . . . . . . . . . 77
. . . . . . . . . . . . . . . . . . . . . . . . 79
. . . . . . . . . . . . . . . . . . . 77
. . . . . . . . . . . . . 77
System Battery
Replacing the System Battery
Power Supply
Removing the Power Supply Installing the Power Supply
Replacing the Cooling Fans
Replacing the Card and Front Fans Replacing the Memory Fan Replacing the Fourth Hard-Drive Fan
Chassis Intrusion Switch
Removing the Chassis Intrusion Switch Installing the Chassis Intrusion Switch
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
. . . . . . . . . . . . . . . . . . . . . . . 79
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
. . . . . . . . . . . . . . . . . . . . . . . . 81
. . . . . . . . . . . . . . . . . . . . . . . . . 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . 83
. . . . . . . . . . . . . . . . . . . . . 83
. . . . . . . . . . . . . . . . . . . . . . . . . 85
. . . . . . . . . . . . . . . . . . . . 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
. . . . . . . . . . . . . . . . . . 86
. . . . . . . . . . . . . . . . . . . 87
Removing and Replacing the Bezel (Service Only Parts Procedure)
Removing the Bezel Replacing the Bezel
Front I/O Panel (Service Only Parts Procedure)
Removing the Front I/O Panel Replacing the Front I/O Panel
Thermal Diode Cable (Service Only Parts Procedure)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
. . . . . . . . . . . . . . . . . 89
. . . . . . . . . . . . . . . . . . . . . . . . 89
. . . . . . . . . . . . . . . . . . . . . . . . 90
. . . . . . . . . . . . . 91
. . . . . . 87
System Board (Service Only Parts Procedure)
Removing the System Board Installing the System Board
. . . . . . . . . . . . . . . . . . . . . . . . 91
. . . . . . . . . . . . . . . . . . . . . . . . . 93
. . . . . . . . . . . . . . . . . 91
4 Troubleshooting Your System . . . . . . . . . . . . . . . . . . . . . 95
Safety First—For You and Your System . . . . . . . . . . . . . . . . . . . . . 95
Start-Up Routine
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Contents 5
Checking the Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Troubleshooting IRQ Assignment Conflicts Troubleshooting External Connections Troubleshooting the Video Subsystem Troubleshooting the Keyboard Troubleshooting the Mouse
. . . . . . . . . . . . . . . . . . . . . . . 97
. . . . . . . . . . . . . . . . . . . . . . . . . 98
. . . . . . . . . . . . . . . . . 96
. . . . . . . . . . . . . . . . . . . 96
. . . . . . . . . . . . . . . . . . . 96
Troubleshooting Serial I/O Problems
. . . . . . . . . . . . . . . . . . . . . . 98
Troubleshooting a Serial I/O Device Troubleshooting a USB Device
Troubleshooting a NIC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Troubleshooting a Wet System
Troubleshooting a Damaged System
Troubleshooting the System Battery
. . . . . . . . . . . . . . . . . . . . . . . 99
. . . . . . . . . . . . . . . . . . . . . . . . . 100
. . . . . . . . . . . . . . . . . . . . . . 101
. . . . . . . . . . . . . . . . . . . . . . 102
Troubleshooting System Cooling Problems
Troubleshooting a Fan
Troubleshooting System Memory
Troubleshooting a Diskette Drive
Troubleshooting an Optical Drive
Troubleshooting a Hard Drive
Troubleshooting a SAS RAID Controller
Troubleshooting Expansion Cards
Troubleshooting the Microprocessors
. . . . . . . . . . . . . . . . . . . . . . . . . . 103
. . . . . . . . . . . . . . . . . . . . . . . 103
. . . . . . . . . . . . . . . . . . . . . . . 105
. . . . . . . . . . . . . . . . . . . . . . . 106
. . . . . . . . . . . . . . . . . . . . . . . . . 107
. . . . . . . . . . . . . . . . . . . . 108
. . . . . . . . . . . . . . . . . . . . . . . 109
. . . . . . . . . . . . . . . . . . . . 110
. . . . . . . . . . . . . . . . . . . . 99
. . . . . . . . . . . . . . . . . . 102
5 Running the System Diagnostics . . . . . . . . . . . . . . . . . . 113
6 Contents
Using Dell PowerEdge Diagnostics . . . . . . . . . . . . . . . . . . . . . . 113
System Diagnostics Features
When to Use the System Diagnostics
Running the System Diagnostics
System Diagnostics Testing Options
. . . . . . . . . . . . . . . . . . . . . . . . . 113
. . . . . . . . . . . . . . . . . . . . . 114
. . . . . . . . . . . . . . . . . . . . . . . 114
. . . . . . . . . . . . . . . . . . . . . . 114
Using the Custom Test Options . . . . . . . . . . . . . . . . . . . . . . . . 114
Selecting Devices for Testing Selecting Diagnostics Options Viewing Information and Results
. . . . . . . . . . . . . . . . . . . . . . . 115
. . . . . . . . . . . . . . . . . . . . . . 115
. . . . . . . . . . . . . . . . . . . . . 115
6 Jumpers and Connectors . . . . . . . . . . . . . . . . . . . . . . . 117
System Board Jumpers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Clearing CMOS Settings
. . . . . . . . . . . . . . . . . . . . . . . . . 118
System Board Connectors
Disabling a Forgotten Password
. . . . . . . . . . . . . . . . . . . . . . . . . . . 120
. . . . . . . . . . . . . . . . . . . . . . . . 122
7 Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Obtaining Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Online Services AutoTech Service Automated Order-Status Service Support Service
Dell Enterprise Training and Certification
Problems With Your Order
Product Information
Returning Items for Warranty Repair or Credit
Before You Call
Contacting Dell
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
. . . . . . . . . . . . . . . . . . . . . 124
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
. . . . . . . . . . . . . . . . . . . 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
. . . . . . . . . . . . . . . . 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Index
Contents 7
8 Contents

About Your System

This section describes the physical, firmware, and software interface features that provide and ensure the essential functioning of your system. The physical connectors on your system’s front and back panels provide convenient connectivity and system expansion capability. The system firmware, applications, and operating systems monitor the system and component status and alert you when a problem arises. System conditions can be reported by any of the following:
Front or back panel indicators
System messages
Warning messages
Diagnostics messages
Alert messages
This section describes each type of message, lists the possible causes, and provides steps to resolve any problems indicated by a message. The system indicators and features are illustrated in this section.

Other Information You May Need

CAUTION: The Product Information Guide provides important safety and regulatory information. Warranty
information may be included within this document or as a separate document.
The
CDs included with your system provide documentation and tools for configuring and managing
Systems management software documentation describes the features, requirements, installation,
Operating system documentation describes how to install (if necessary), configure, and use the
Documentation for any components you purchased separately provides information to configure
Updates are sometimes included with the system to describe changes to the system, software,
Getting Started Guide
technical specifications.
your system.
and basic operation of the software.
operating system software.
and install these options.
and/or documentation.
provides an overview of system features, setting up your system, and
NOTE: Always check for updates on support.dell.com and read the updates first because they often
supersede information in other documents.
About Your System 9
Release notes or readme files may be included to provide last-minute updates to the system or documentation or advanced technical reference material intended for experienced users or technicians.

Accessing System Features During Startup

Table 1-1 describes keystrokes that may be entered during startup to access system features. If your operating system begins to load before you enter the keystroke, allow the system to finish booting, and then restart your system and try again.
Table 1-1. Keystrokes for Accessing System Features
Keystroke Description
<F2> Enters the System Setup program. See "Using the System Setup Program" on page 27.
<F10> Opens the utility partition, allowing you to run the system diagnostics. See "Running the System
Diagnostics" on page 114.
<F11> Enters the boot menu selection screen, allowing you to choose a boot device.
<F12> Initiates PXE boot.
<Ctrl+C> Option is displayed for some SAS controller expansion cards. Enters the SAS Configuration Utility,
which includes RAID configuration options. See your SAS adapter User’s Guide for more information.
<Ctrl+R> Enters the RAID configuration utility, which allows you to configure an optional RAID expansion
card. For more information, see the documentation for your RAID card.
<Ctrl+S> Option is displayed only if you have PXE support enabled through the System Setup Program (see
"Integrated Devices Screen" on page 32). This keystroke allows you to configure NIC settings for PXE boot. For more information, see the documentation for your integrated NIC.
10 About Your System

Front-Panel Features and Indicators

1
Figure 1-1 shows the controls, indicators, and connectors located on the system's front panel. Table 1-2 provides component descriptions.
Figure 1-1. Front-Panel Features and Indicators
2
9
8
7
6
Table 1-2. Front-Panel Components
Item Component Icon Description
1 upper 5.25-inch drive
bay
2 lower 5.25-inch drive
bay
3 flex bay Holds a diskette drive or an optional third hard drive.
4 hard-drive activity
indicator
Holds an optical drive.
Holds an optional optical or half-height tape drive, or a fourth hard drive (requires mounting bracket).
Indicates hard drive activity.
3
4
5
About Your System 11
Table 1-2. Front-Panel Components (continued)
Item Component Icon Description
5 USB connectors (2) Connects USB 2.0-compliant devices to the system.
6 power button The power button controls the DC power supply output to the system.
NOTE: If you turn off the system using the power button and the system is
running an ACPI-compliant operating system, the system performs a graceful shutdown before the power is turned off. If the system is not running an ACPI-compliant operating system, the power is turned off immediately after the power button is pressed.
7 power light No light — The system is off.
Steady green — The system is powered on.
Steady amber — The power supply is probably good. Check the diagnostic indicators to see if the specific problem is identified. See "Diagnostics Indicator Codes" on page 15.
Blinking amber — The system is powering up.
• If the hard-drive indicator is off, the power supply may need to be replaced.
• If the hard-drive indicator is on, the system board is faulty. Check the diagnostic indicators to see if the specific problem is identified. See "Diagnostics Indicator Codes" on page 15.
8 network link light Lights when the system is linked to a network.
9 diagnostic lights (4) Display light-pattern codes to assist in troubleshooting system
problems.
See "Diagnostics Indicator Codes
" on page 15
.
12 About Your System

Back-Panel Features and Indicators

1
Figure 1-2 shows the connectors located on the system's back panel.
Figure 1-2. Back-Panel Features
2
3
4
1 AC power connector 2 expansion-card slots (5) 3 NIC connector
4 USB connectors (5) 5 video connector 6 parallel connector
7 serial connector
5
6
7

Connecting External Devices

When connecting external devices to your system, follow these guidelines:
Most devices must be connected to a specific connector and device drivers must be installed before the device operates properly. (Device drivers are normally included with your operating system software or with the device itself.) See the documentation that accompanied the device for specific installation and configuration instructions.
About Your System 13
Always attach an external device while your system and the device are turned off. Next, turn on any external devices before turning on the system (unless the documentation for the device specifies otherwise).
See "Using the System Setup Program" on page 27 for information about enabling, disabling, and configuring I/O ports and connectors.

NIC Indicator Codes

The NIC on the back panel has an indicator that provides information on network activity and link status. See Figure 1-3. Table 1-3 lists the NIC indicator codes.
Figure 1-3. NIC Indicators
12
1 link indicator 2 activity indicator
Table 1-3. NIC Indicator Codes
Indicator Type Indicator Code Description
Activity Off When off at the same time that the link indicator is off,
the NIC is not connected to the network or the NIC is disabled in the System Setup program. See "Using the System Setup Program" on page 27.
Blinking Indicates that network data is being sent or received.
Link Off When off at the same time that the activity indicator is
off, the NIC is not connected to the network or the NIC is disabled in the System Setup program. See "Using the System Setup Program" on page 27.
Yellow 1000-Mbps connection
Orange 100-Mbps connection
Green 10-Mbps connection
14 About Your System

Diagnostics Indicator Codes

The four diagnostic indicator lights on the system front panel display error codes during system startup. Table 1-4 lists the causes and corrective actions associated with these codes and the power light status before system POST. Table 1-5 lists the causes and possible corrective actions for these codes during POST. A highlighted circle indicates the light is on; a non-highlighted circle indicates the light is off.
Table 1-4. Diagnostic Indicator Codes Before POST
Code Power
Light
off No electrical power is
green Normal operation None
off Normal off condition; the
amber The BIOS is not executing. Ensure that the processor is seated correctly and
(blinking)
blinking amber
(blinking)
amber A possible power supply
(blinking)
amber A possible system board
Causes Corrective Action
Connect the computer to a working electrical
supplied to the computer.
system is connected to an electrical outlet.
A possible power supply or power cable failure has occurred.
failure has occurred.
failure has occurred.
outlet.
If the problem is still not resolved, see "Getting Help" on page 123.
Press the power button to turn the computer on.
If the system does not turn on and the power light is off, see "Getting Help" on page 123.
restart the system. See "Microprocessor" on page 73).
If the problem persists, see "Getting Help" on page 123.
Check the power supply connections and the condition of cables. See "Installing the Power Supply" on page 82.
If the problem persists, see "Getting Help" on page 123.
Verify that both power supply cables are plugged in to the system board. See "Installing the Power Supply" on page 82.
If the problem persists, see "Getting Help" on page 123.
See "Getting Help" on page 123.
(blinking)
About Your System 15
Table 1-4. Diagnostic Indicator Codes Before POST (continued)
Code Power
Light
off A processor mismatch exists. See "Troubleshooting the Microprocessors" on
(blinking)
Table 1-5. Diagnostic Indicator Codes During POST
Code Causes Corrective Action
BIOS checksum failure detected; system is in recovery mode.
Possible processor failure. See "Troubleshooting the Microprocessors" on page 110.
Memory failure. See "Troubleshooting System Memory" on page 103.
Possible expansion card failure. See "Troubleshooting Expansion Cards" on page 109.
Possible video failure. See "Getting Help" on page 123.
Causes Corrective Action
page 110.
Ensure that all network cards and connections are functioning properly. See "Troubleshooting Your System" on page 95.
If the problem persists, see "Getting Help" on page 123.
Diskette drive or hard drive failure.
Possible USB failure. See "Troubleshooting a USB Device" on page 99.
No memory modules detected. See "Troubleshooting System Memory" on page 103.
System board failure. See "Getting Help" on page 123.
16 About Your System
Ensure that the diskette drive and hard drives are properly connected. See "Hard Drives" on page 48 and "Diskette Drive" on page 63 for information on the drives installed in your system.
Table 1-5. Diagnostic Indicator Codes During POST (continued)
Code Causes Corrective Action
Memory configuration error. See "Troubleshooting System Memory" on page 103.
Possible system board resource and/or system board hardware failure.
Possible system resource configuration error.
Other failure. Ensure that the diskette drive, optical drive, and hard drives are
The system is in a normal operating condition after POST.
See "Troubleshooting IRQ Assignment Conflicts" on page 96. If the problem persists, see "Getting Help" on page 123.
See "Troubleshooting Your System" on page 95.
If the problem persists, see "Getting Help" on page 123.
properly connected. See "Troubleshooting Your System" on page 95 for the appropriate drive installed in your system.
If the problem persists, see "Getting Help" on page 123.
Information only.

System Messages

System messages appear on the screen to notify you of a possible problem with the system. Table 1-6 lists the system messages that can occur and the probable cause and corrective action for each message.
NOTE: If you receive a system message that is not listed in Table 1-6, check the documentation for the application
that is running when the message appears or the operating system's documentation for an explanation of the message and recommended action.
CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. See your Product Information Guide for complete information about safety precautions, working inside the computer, and protecting against electrostatic discharge.
Table 1-6. System Messages
Message Causes Corrective Actions
Alert! Air temperature sensor not detected.
The front panel thermal diode cable is improperly installed or has failed.
Verify that cables are firmly seated in the connectors on the front I/O panel and the system board. See "Front I/O Panel (Service Only Parts Procedure)" on page 89.
About Your System 17
Table 1-6. System Messages (continued)
Message Causes Corrective Actions
Alert! Cable not detected in INTRUDER connector.
Alert! FAN_CCAG was not detected.
Alert! FAN_FRONT was not detected.
Alert! FAN_HDD was not detected.
Alert! FAN_MEM was not detected.
Alert! FAN_PSU was not detected.
Alert! Cover was previously removed.
Alert! Previous FAN_CCAG failure.
Alert! Previous FAN_FRONT failure.
Alert! Previous FAN_HDD failure.
Alert! Previous FAN_MEM failure.
Alert! Previous FAN_PSU failure.
Alert! Previous thermal event.
Alert! Previous voltage failure.
The chassis intrusion switch is not connected to the system board.
Specified fan is missing, faulty, or improperly installed.
• FAN_CCAG — card fan
• FAN_FRONT — front fan
• FAN_HDD — hard-drive fan for optional fourth hard drive
• FAN_MEM — memory fan
The power supply fan is faulty. See "Getting Help" on page 123.
The system cover has been opened. Information only. To reset, enter the
Specified fan failed before last system startup.
• FAN_CCAG — card fan
• FAN_FRONT — front fan
• FAN_HDD — hard-drive fan for optional fourth hard drive
• FAN_MEM — memory fan
• FAN_PSU — power supply fan
BIOS detected a thermal event before the last system startup.
Sensor detected voltage out of range before last system startup.
Verify that the chassis intrusion switch cable is firmly seated in the INTRUDER connector on the system board. See "Installing the Chassis Intrusion Switch" on page 87.
See "Troubleshooting System Cooling Problems" on page 102.
System Setup program. See "Using the System Setup Program" on page 27.
Information only.
Ensure that thermal grease is applied to the heat sink and the heat sink is installed properly. Ensure that the system fans are functioning properly. See "Replacing the Processor" on page 75 and "Troubleshooting System Cooling Problems" on page 102.
Information only.
18 About Your System
Table 1-6. System Messages (continued)
Message Causes Corrective Actions
Alert! Processor thermal probe failure detected.
BIOS Update Attempt Failed!
CPUs with different cache sizes detected!
The processor thermal probe has
See "Getting Help" on page 123.
failed.
Remote BIOS update attempt failed. Retry the BIOS update. If problem
persists, see "Getting Help" on page 123.
Microprocessors with different cache sizes are installed.
Ensure that all microprocessors have the same cache size and that they are properly installed. See "Microprocessor" on page 73.
Decreasing available memory
DIMM pairs must be matched in size, speed, and technology. The following DIMM pair is mismatched: DIMM x and DIMM y.
Faulty or improperly installed memory modules.
Mismatched or unmatched DIMMs installed; faulty or improperly seated memory module(s).
See "Troubleshooting System Memory" on page 103.
Ensure that all pairs of memory modules are of the same type and size and that they are properly installed. See "Memory" on page 76. If the problem persists, see "Troubleshooting System Memory" on page 103.
DIMMs must be populated in sequential order beginning with slot 1. The following DIMM is electrically
The specified DIMM is inaccessible to the system due to its location. DIMMs must be populated in sequential order, beginning with slot 1.
Populate 2 or 4 DIMMs sequentially beginning with slot 1. See "Memory" on page 76.
isolated: DIMM x. DIMMs should be installed
in pairs. Pairs must be matched in size, speed, and technology.
Mismatched or unmatched DIMMs installed; faulty or improperly seated memory module(s). The system will operate in a degraded mode with reduced ECC protection. Only memory installed in channel 0 will be
Ensure that all pairs of memory modules are of the same type and size and that they are properly installed. See "Memory" on page 76. If the problem persists, see "Troubleshooting System Memory" on page 103.
accessible.
Dual-rank DIMM paired with Single-rank DIMM - The following DIMM/rank has been disabled by BIOS: DIMM x Rank y
Mismatched DIMMs installed; faulty memory module(s). The system has detected a dual-rank DIMM paired with a single-rank DIMM. The second rank of the dual-rank DIMM will be disabled.
Ensure that all pairs of memory modules are of the same type and size and that they are properly installed. See "Memory" on page 76. If the problem persists, see "Troubleshooting System Memory" on page 103.
About Your System 19
Table 1-6. System Messages (continued)
Message Causes Corrective Actions
Diskette drive n seek failure
Diskette read failure Faulty or improperly inserted diskette. Replace the diskette. If the problem
Diskette subsystem reset failed
Drive not ready Diskette missing from or improperly
Error: Incorrect memory configuration. DIMMs must be installed in pairs of matched memory size, speed, and technology.
Error: Memory failure detected. Memory size reduced. Replace the faulty DIMM as soon as possible.
FBD training error: The following branch has been disabled: Branch x
Gate A20 failure Faulty keyboard controller; faulty
Incorrect configuration settings in the System Setup program.
Faulty or improperly installed diskette drive.
Loose diskette drive interface cable, or loose power cable.
Faulty or improperly installed diskette.
inserted in diskette drive.
Mismatched or unmatched DIMMs installed; faulty or improperly seated memory module(s).
Faulty or improperly seated memory module(s).
The specified branch (channel pair) contains DIMMs that are incompatible with each other.
system board.
Run the System Setup program to correct the settings. See "Using the System Setup Program" on page 27.
Replace the diskette. If the problem persists, see "Troubleshooting a Diskette Drive" on page 105.
Reseat diskette drive interface cable, or power cable. See "Troubleshooting a Diskette Drive" on page 105.
persists, see "Troubleshooting a Diskette Drive" on page 105.
Replace the diskette. If the problem persists, see "Troubleshooting a Diskette Drive" on page 105.
Replace the diskette. If the problem persists, see "Troubleshooting a Diskette Drive" on page 105.
Ensure that all pairs of memory modules are of the same type and size and that they are properly installed. See "Memory" on page 76. If the problem persists, see "Troubleshooting System Memory" on page 103.
See "Troubleshooting System Memory" on page 103.
Ensure that only Dell-qualified memory is used. Dell recommends purchasing memory upgrade kits directly from www.dell.com or your Dell sales agent to ensure compatibility.
See "Getting Help" on page 123.
20 About Your System
Table 1-6. System Messages (continued)
Message Causes Corrective Actions
General failure The operating system is unable to
carry out the command.
n
IDE primary drive found
Invalid configuration information - please run SETUP program
Invalid NVRAM configuration, Resource Re-allocated
Keyboard Controller failure
Manufacturing mode detected
MEMBIST failure - The following DIMM/rank has been disabled by BIOS: DIMM x Rank y
Memory address line failure at
value
expecting
Memory double word logic failure at
value
expecting
Memory odd/even logic failure at
value
expecting
Memory write/read failure
address
at expecting
Memory tests terminated by keystroke.
address
address
address,
, read
value
not
, read
value
, read
value
read
value
value
IDE cables are not properly seated, or drive missing.
System has detected invalid configuration.
System detected and corrected a resource conflict.
Faulty keyboard controller; faulty system board
System is in manufacturing mode. Reboot to take the system out of
Faulty memory module(s). See "Troubleshooting System Memory"
Faulty or improperly installed memory modules.
POST memory test terminated by pressing the spacebar.
This message is usually followed by specific information. Note the information and take the appropriate action to resolve the problem.
See "Troubleshooting an Optical Drive" on page 106.
Remove the RTCST jumper if it is installed. See Figure 6-1 for the jumper location.
No action is required.
See "Getting Help" on page 123.
manufacturing mode.
on page 103.
See "Troubleshooting System Memory" on page 103.
Information only.
About Your System 21
Table 1-6. System Messages (continued)
Message Causes Corrective Actions
No boot device available Faulty or missing optical/diskette
drive subsystem, hard drive, or hard­drive subsystem, or no boot disk in drive A.
No boot sector on hard drive
No timer tick interrupt Faulty system board. See "Getting Help" on page 123. Northbound merge error -
The following DIMM has been disabled by BIOS: DIMM x
Not a boot diskette No operating system on diskette. Use a bootable diskette. PCIe Degraded Link Width
Error: Embedded
nn
Bus# Expected Link Width is Actual Link Width is
PCIe Degraded Link Width Error: Slot
Expected Link Width is Actual Link Width is
PCIe Training Error: Embedded Bus#
PCIe Training Error: Slot
/Dev#nn/Func
n
nn
/Dev#nn/Funcn
n
n
n
n
Incorrect configuration settings in System Setup program, or no operating system on hard drive.
The specified DIMM was unable to establish a successful data link with the memory controller.
Faulty or improperly installed PCIe card in the specified slot.
n
Faulty or improperly installed PCIe card in the specified slot.
n
Faulty or improperly installed PCIe card in the specified slot.
Use a bootable diskette, CD, or hard drive. If the problem persists, see "Troubleshooting a Diskette Drive" on page 105, "Troubleshooting an Optical Drive" on page 106, and "Troubleshooting a Hard Drive" on page 107. See "Using the System Setup Program" on page 27 for information about setting the order of boot devices.
Check the hard-drive configuration settings in the System Setup program. See "Using the System Setup Program" on page 27. If necessary, install the operating system on your hard drive. See your operating system documentation.
See "Troubleshooting System Memory" on page 103.
Reseat the PCIe card in the specified slot number. See "Expansion Cards" on page 70. If the problem persists, see "Getting Help" on page 123.
Reseat the PCIe card in the specified slot number. See "Expansion Cards" on page 70. If the problem persists, see "Getting Help" on page 123.
Reseat the PCIe card in the specified slot number. See "Expansion Cards" on page 70. If the problem persists, see "Getting Help" on page 123.
22 About Your System
Table 1-6. System Messages (continued)
Message Causes Corrective Actions
PCI BIOS failed to install PCI device BIOS (Option ROM)
checksum failure is detected during shadowing. Loose cables to expansion card(s); faulty or improperly installed expansion card.
Plug & Play Configuration Error
Read fault Requested sector not found
Remote configuration update attempt failed
ROM bad checksum = address Expansion card improperly installed or
n
SATA port not found
Sector not found Seek error Seek operation failed
Shutdown failure Shutdown test failure. See "Troubleshooting System Memory"
hard disk drive
Error encountered in initializing PCI device; faulty system board.
The operating system cannot read from the diskette or hard drive, the system could not find a particular sector on the disk, or the requested sector is defective.
System unable to process Remote Configuration request.
faulty.
SATA cables are not properly seated, or drive missing.
Faulty diskette or hard drive. See "Troubleshooting a Diskette Drive"
Reseat the expansion cards. Ensure that all appropriate cables are securely connected to the expansion cards. If the problem persists, see "Troubleshooting Expansion Cards" on page 109.
Install the RTCRST jumper and reboot the system. See Figure 6-1 for jumper location. If the problem persists, see "Troubleshooting Expansion Cards" on page 109.
Replace the diskette. Ensure that the diskette and hard drive cables are properly connected. See "Troubleshooting a USB Device" on page 99, "Troubleshooting a Diskette Drive" on page 105, or "Troubleshooting a Hard Drive" on page 107 for the appropriate drive(s) installed in your system.
Retry Remote Configuration.
Reseat the expansion cards. Ensure that all appropriate cables are securely connected to the expansion cards. If the problem persists, see "Troubleshooting Expansion Cards" on page 109.
See "Troubleshooting a Hard Drive" on page 107.
on page 105 or "Troubleshooting a Hard Drive" on page 107 for the appropriate drive(s) installed in your system.
on page 103.
About Your System 23
Table 1-6. System Messages (continued)
Message Causes Corrective Actions
The amount of system memory has changed
The following DIMM pair is not compatible with the memory controller: DIMM x and DIMM y
The following DIMMs are not compatible: DIMM x and DIMM y
Time-of-day clock stopped Faulty battery or faulty chip. See "Troubleshooting the System
Time-of-day not set ­please run SETUP program
Timer chip counter 2 failed
Unsupported CPU combination
Unsupported CPU stepping detected
Utility partition not available
Warning! No microcode update loaded for processor
n
Memory has been added or removed or a memory module may be faulty.
The specified DIMM(s) are incompatible with the system.
The specified DIMM(s) are incompatible with the system.
Incorrect Time or Date settings; faulty system battery.
Faulty system board. See "Getting Help" on page 123.
Microprocessor(s) is not supported by the system.
The <F10> key was pressed during POST, but no utility partition exists on the boot hard drive.
Microcode update failed. Update the BIOS firmware. See "Getting
If memory has been added or removed, this message is informative and can be ignored. If memory has not been added or removed, check the SEL to determine if single-bit or multi-bit errors were detected and replace the faulty memory module. See "Troubleshooting System Memory" on page 103.
Ensure that only Dell-qualified memory is used. Dell recommends purchasing memory upgrade kits directly from www.dell.com or your Dell sales agent to ensure compatibility.
Ensure that only ECC FBD1 memory is used. Dell recommends purchasing memory upgrade kits directly from www.dell.com or your Dell sales agent to ensure compatibility.
Battery" on page 102.
Check the Time and Date settings. See "Using the System Setup Program" on page 27. If the problem persists, replace the system battery. See "System Battery" on page 79.
Install a supported microprocessor or microprocessor combination. See "Microprocessor" on page 73.
Create a utility partition on the boot hard drive. See the CDs that came with your system.
Help" on page 123.
24 About Your System
Table 1-6. System Messages (continued)
Message Causes Corrective Actions
Warning: The current memory configuration is not optimal. Dell recommends a population of 2 or 4 DIMMs. DIMMs should be populated sequentially starting in slot 1.
Write fault Write fault on selected
drive
System has detected a legal but non­optimal population of DIMMs. The system will run with all memory accessible but will experience sub­optimal performance.
Faulty diskette, optical/diskette drive assembly, hard drive, or hard-drive subsystem.
Populate 2 or 4 DIMMs sequentially beginning with slot 1. See "Memory" on page 76.
See "Troubleshooting a Diskette Drive" on page 105, "Troubleshooting an Optical Drive" on page 106, or "Troubleshooting a Hard Drive" on page 107.
NOTE: For the full name of an abbreviation or acronym used in this table, see the "Glossary" on page 149.

Warning Messages

A warning message alerts you to a possible problem and prompts you to respond before the system continues a task. For example, before you format a diskette, a message will warn you that you may lose all data on the diskette. Warning messages usually interrupt the task and require you to respond by typing (yes) or
n (no).
NOTE: Warning messages are generated by either the application or the operating system. For more information,
see the documentation that accompanied the operating system or application.
y

Diagnostics Messages

When you run system diagnostics, an error message may result. Diagnostic error messages are not covered in this section. Record the message on a copy of the Diagnostics Checklist in "Getting Help" on page 123, and then follow the instructions in that section for obtaining technical assistance.

Alert Messages

Systems management software generates alert messages for your system. Alert messages include information, status, warning, and failure messages for drive, temperature, fan, and power conditions. For more information, see the systems management software documentation.
About Your System 25
26 About Your System

Using the System Setup Program

After you set up your system, run the System Setup program to familiarize yourself with your system configuration and optional settings. Record the information for future reference.
You can use the System Setup program to:
Change the system configuration stored in NVRAM after you add, change, or remove hardware
Set or change user-selectable options—for example, the time or date
Enable or disable integrated devices
Correct discrepancies between the installed hardware and configuration settings

Entering the System Setup Program

1
Turn on or restart your system.
2
Press <F2> immediately after you see the following message display briefly on the screen:
<F2> = System Setup
If your operating system begins to load before you press <F2>, allow the system to finish booting, and then restart your system and try again.
NOTE: To ensure an orderly system shutdown, see the documentation that accompanied your operating
system.

Responding to Error Messages

You can enter the System Setup program by responding to certain error messages. If an error message appears while the system is booting, make a note of the message. Before entering the System Setup program, see "System Messages" on page 17 for an explanation of the message and suggestions for correcting errors.
NOTE: After installing a memory upgrade, it is normal for your system to send a message the first time you
start your system.
Using the System Setup Program 27

Using the System Setup Program

Table 2-1 lists the keys that you use to view or change information on the System Setup program screens and to exit the program.
Table 2-1. System Setup Program Navigation Keys
Keys Action
Up arrow or <Shift><Tab> Moves to the previous field.
Down arrow or <Tab> Moves to the next field.
Spacebar, <+>, < right arrows
<Esc> Exits the System Setup program and restarts the
<F1> Displays the System Setup program
NOTE: For most of the options, any changes that you make are recorded but do not take effect until you restart the
system.
>, left and
Cycles through the settings in a field. In many fields, you can also type the appropriate value.
system if any changes were made.
's help file.

System Setup Options

Main Screen

When you enter the System Setup program, the main System Setup program screen appears. See Figure 2-1.
28 Using the System Setup Program
Figure 2-1. Main System Setup Program Screen
Table 2-2 lists the options and descriptions for the information fields that appear on the main System Setup program screen.
NOTE: The options for the System Setup program change based on the system configuration.
NOTE: The System Setup program defaults are listed under their respective options, where applicable.
Table 2-2. System Setup Program Options
Option Description
System Time Resets the time on the system's internal clock.
System Date Resets the date on the system's internal calendar.
Memory Information Displays information related to installed system and video memory, including size,
type, and speed of memory modules, system video memory size and system memory test option.
Using the System Setup Program 29
Table 2-2. System Setup Program Options (continued)
Option Description
CPU Information Displays information related to microprocessors (speed, cache size, and so on).
Enable or disable Hyper-Threading technology, if supported, by changing the setting of the Logical Processor option. See Table 2-3.
SATA Port X Displays type and capacity of SATA drive attached to Port X on the system board.
Boot Sequence Determines the order in which the system searches for boot devices during system
startup. Available options can include the diskette drive, CD drive, hard drives, and network. Only the first IDE device found will be available in the boot sequence.
Hard-Disk Drive Sequence
Hard-Disk Failover (
Off
default)
USB Flash Drive Type
Auto
default)
(
Integrated Devices See "Integrated Devices Screen" on page 32.
PCI IRQ Assignment Displays a screen to change the IRQ assigned to each of the integrated devices on
System Security Displays a screen to configure the system password and setup password features,
System Event Log Select to view or clear the System Event Log (SEL). See "System Event Log" on
Keyboard NumLock (
On
default)
Report Keyboard Errors
Report
default)
(
Specifies the order in which hard drives are configured in the system. The first hard drive in the system will be the bootable C: drive in DOS/DOS-like operating systems.
When this field is set to On and the first hard drive is not available, the system attempts to boot from the other hard drives in the order specified in Hard-Disk Drive Sequence before searching for the next device in Boot Sequence. This feature may be used to boot to a mirrored drive in a software RAID 1 configuration.
Determines the emulation type for a USB flash drive. Hard disk allows the USB flash drive to act as a hard drive. Floppy allows the USB flash drive to act as a removal diskette drive. Auto automatically chooses an emulation type.
the PCI bus, and any installed expansion cards that require an IRQ.
AC power recovery, and chassis intrusion detection. See Table 2-5. See "Using the System Password" on page 36 and "Using the Setup Password" on page 38 for more information.
page 34.
Determines whether your system starts up with the NumLock mode activated on 101- or 102-key keyboards (does not apply to 84-key keyboards).
Enables or disables reporting of keyboard errors during the POST. Select Report for host systems that have keyboards attached. Select Do Not Report to suppress all error messages relating to the keyboard or keyboard controller during POST. This setting does not affect the operation of the keyboard itself if a keyboard is attached to the system.
30 Using the System Setup Program

CPU Information Screens

Table 2-3 lists the options and descriptions for the information fields that appear on the CPU Information screen.
Table 2-3. CPU Information Screen
Option Description
64-bit Technology Specifies if the installed processor(s) support Intel 64-bit
extensions.
Core Speed Displays the clock speed of the processor(s).
Bus Speed Displays the bus speed of the processor(s).
Logical Processor (Enabled default)
Virtualization Technology (Disabled default)
Adjacent Cache Line Prefetch (Enabled default)
Hardware Prefetcher (Enabled default)
Demand-Based Power Management (Disabled default)
Processor X ID Displays the family and model number of each processor. A
Displays when the processor(s) support HyperThreading. Enabled permits all logical processors to be used by the operating system. Only the first logical processor of each processor installed in the system is used by the operating system if Disabled is selected.
Displays when the processor(s) support Virtualization Technology. Enabled permits virtualization software to use Virtualization Technology incorporated in the processor design. This feature can only be used by software that supports Virtualization Technology.
Enables or disables optimal use of sequential memory access. Disable this option for applications that require high use of random memory access.
Enables or disables the hardware prefetcher.
Enables or disables demand-based power management. When enabled, the CPU Performance State tables will be reported to the operating system; when disabled, the CPU Performance State tables will not be reported to the operating system. If any of the CPUs do not support demand-based power management, the field will become read-only, and automatically set to Disabled.
submenu displays processor core speed, amount of level 2 cache, and number of cores.
Using the System Setup Program 31

Integrated Devices Screen

Table 2-4 lists the options and descriptions for the information fields that appear on the Integrated Devices screen.
Table 2-4. Integrated Devices Screen Options
Option Description
Embedded SATA (Off default)
Optional Hard-Disk Drive Fan
IDE Controller (Auto default)
Diskette Controller (Auto default)
User Accessible USB Ports (All Ports On default)
Embedded Gb NIC1 (Enabled with PXE default)
MAC Address Displays the MAC address for the integrated 10/100/1000 NIC. This field does not
Serial Port 1 (Auto default)
Parallel Port (378h default)
Parallel Port Mode (PS2 default)
Allows the integrated SATA controller to be set to Off or ATA M ode.
Displays Installed if the optional fourth hard-drive carrier fan cable is connected to the system board connector and is functioning. Otherwise, displays Not Installed.
Enables the integrated IDE controller. When set to Auto, each channel of the integrated IDE controller is enabled if IDE devices are attached to the channel.
Enables or disables the system's diskette drive controller. When Auto is selected, the system turns off the controller when necessary to accommodate a controller card installed in an expansion slot. You can also configure the drive as Read-Only, or Off. When using the Read-Only setting, the drive cannot be used to write to a disk.
Enables or disables the system’s user accessible USB ports. Options are All Ports On, Only Back Ports On, and All Ports Off.
Enables or disables the system's integrated NIC. Options are Enabled without PXE, Enabled with PXE, and Disabled. PXE support allows the system to boot from the network. Changes take effect after the system reboots.
have user-selectable settings.
Serial port options are COM1, COM3, Auto, and Off.
When the serial port is set to Auto, the integrated port automatically attempts to use COM1 first, and then
If you set the serial port to Auto and add an expansion card with a port configured to the same designation, the system automatically remaps the integrated port to the next available port designation that shares the same IRQ setting.
Selects the address for the parallel port. Options are 378h, 278h, 3BCh, and Off.
The system automatically disables the built-in parallel port if an expansion card containing a parallel port at the same address is detected.
Sets the parallel port mode of operation between AT mode and PS/2 mode. In AT mode, the integrated parallel port can output data only to an attached device. In
PS/2 mode, the built-in parallel port can both input and output data.
COM3. If both addresses are in use, the port is disabled.
32 Using the System Setup Program

System Security Screen

Table 2-5 lists the options and descriptions for the information fields that appear on the System Security screen.
Table 2-5. System Security Screen Options
Option Description
System Password Displays the current status of your system's password security feature and allows
you to assign and verify a new system password.
NOTE: See "Using the System Password" on page 36 for instructions on assigning a
system password and using or changing an existing system password.
Setup Password Restricts access to the System Setup program in the same way that you restrict
access to your system using the system password feature.
NOTE: See "Using the Setup Password" on page 38 for instructions on assigning a
setup password and using or changing an existing setup password.
Password Status Setting the Setup Password option to Enabled prevents the system password from
being changed or disabled at system start-up.
To lock the system password, assign a setup password in the Setup Password option and then change the Password Status option to Locked. In this state, you cannot change the system password using the System Password option and cannot be disabled at system start-up by pressing <Ctrl><Enter>.
To unlock the system password, enter the setup password in the Setup Password field and then change the Password Status option to Unlocked. In this state, you can disable the system password at system start-up by pressing <Ctrl><Enter> and then change the password using the System Password option.
AC Power Recovery (Last default)
Chassis Intrusion (Enabled default)
Determines how the system reacts when power is restored to the system. If system is set to Last, the system returns to the last power state. On turns on the system after power is restored. When set to Off, the system remains off after power is restored.
Enables the chassis intrusion detection feature. When this option is set to Enabled-Silent, chassis intrusions are detected, but no warning message is reported during startup. When this option is set to Enabled, the field automatically shows Detected when the chassis cover has been removed. Intrusions are not detected when this option is set to Disabled

Exit Screen

After you press <Esc> to exit the System Setup program, the Exit screen displays the following options:
Save Changes and Exit
Discard Changes and Exit
Return to Setup
Using the System Setup Program 33

System Event Log

The system event log records events that have been detected on your system. If you experience problems with your system, you should check the system event log (see Table 2-2) for information to assist in troubleshooting. Events are recorded in two columns, giving an event type and event data to provide more specific component information. Table 2-6 presents the possible log entries, causes, and possible corrective actions.
Table 2-6. System Event Log Entries
Event Type Event Data Causes Corrective Actions
Log Cleared User cleared the log (or initial log
entry from factory).
PCI PERR Slot # or Bus #
and Device, Function # of the device
PCI SERR Slot # or Bus #
and Device, Function # of the device
Intrusion The cover was opened or the
PCIe Fatal Error Slot # or Bus #
and Device, Function # of the device
Chipset Error Bus, Device,
and Function #
ECC Warning Threshold
ECC Critical Threshold
Memory Log Disabled
Uncorrectable ECC Error
DIMM # Correctable ECC errors have
DIMM # Correctable ECC errors have
DIMM Pair The chipset is unable to correct
A parity error was detected on the PCI bus.
A system error was detected on the PCI bus.
chassis intrusion cable was not detected.
This error is generated when a fatal error is detected on the PCIE bus.
A chipset error was detected on the system board.
increased from a normal rate.
reached a critical rate.
The ECC single bit error rate is exceeded.
the memory errors.
Information only.
See "Troubleshooting Expansion Cards" on page 109.
See "Troubleshooting Expansion Cards" on page 109.
Information only. To reset, enter the System Security screen. See "System Security Screen" on page 33.
See "Troubleshooting Expansion Cards" on page 109.
See "Getting Help" on page 123.
See "Troubleshooting System Memory" on page 103.
See "Troubleshooting System Memory" on page 103.
Information only. Memory errors have been detected and logging is disabled.
See "Troubleshooting System Memory" on page 103.
34 Using the System Setup Program
Table 2-6. System Event Log Entries (continued)
Event Type Event Data Causes Corrective Actions
Out Of Range Thermal CPU_0 Thermal threshold exceeded on
CPU0.
Thermal CPU_1 Thermal threshold exceeded on
CPU1.
Thermal front (air)
FAN_FRONT Bad or missing fan detected. See "Troubleshooting System Cooling FAN_MEM FAN_CCAG FAN_HDD (Hard -
Disk fan) FAN_PSU Voltage CPU_0 Voltage threshold exceeded. The Voltage CPU_1 +VTT +VCC
Thermal threshold exceeded on air temperature sensor or front panel thermal diode was not detected.
power supply or the system board may be faulty.
Ensure that thermal grease is applied to the heat sink and the heat sink is installed properly. Ensure that the system fans are functioning properly. See "Replacing the Processor" on page 75 and "Troubleshooting System Cooling Problems" on page 102.
Verify that cables are firmly seated in the connectors on the front I/O panel and the system board. See "Front I/O Panel (Service Only Parts Procedure)" on page 89.
Problems" on page 102.
See "Getting Help" on page 123.
NOTE: For the full name of an abbreviation or acronym used in this table, see the "Glossary" on page 149.

System and Setup Password Features

NOTICE: The password features provide a basic level of security for the data on your system. If your data requires
more security, use additional forms of protection, such as data encryption programs.
NOTICE: Anyone can access the data stored on your system if you leave the system running and unattended
without having a system password assigned or if you leave your system unlocked so that someone can disable the password by changing a jumper setting.
Your system is shipped to you without the system password feature enabled. If system security is a concern, operate your system only with system password protection.
Using the System Setup Program 35
To change or delete an existing password, you must know the password. See "Deleting or Changing an Existing System Password" on page 37. If you forget your password, you cannot operate your system or change settings in the System Setup program until a trained service technician changes the password jumper setting to disable the passwords, and erases the existing passwords. See "Disabling a Forgotten Password" on page 39.

Using the System Password

After a system password is assigned, only those who know the password have full use of the system. When the System Password option is set to Enabled, the system prompts you for the system password after the system starts.
Assigning a System Password
Before you assign a system password, enter the System Setup program and check the System Password option.
When a system password is assigned, the setting shown for the System Password option is Enabled. If the setting shown for the Password Status is Unlocked, you can change the system password. If the Password Status option is Locked, you cannot change the system password. When the system password feature is disabled by a jumper setting, the system password is Disabled, and you cannot change or enter a new system password.
When a system password is not assigned and the password jumper on the system board is in the enabled (default) position, the setting shown for the System Password option is Not Enabled and the Password Status field is Unlocked. To assign a system password:
1
Verify that the
2
Highlight the
3
Type your new system password.
You can use up to 32 characters in your password.
Password Status
System Password
option is set to
Unlocked
.
option and press <Enter>.
As you press each character key (or the spacebar for a blank space), a placeholder appears in the field.
The password assignment is not case-sensitive. However, certain key combinations are not valid. If you enter one of these combinations, an error message appears. To erase a character when entering your password, press <Backspace> or the left-arrow key.
NOTE: To escape from the field without assigning a system password, press <Enter> to move to another field,
or press <Esc> at any time prior to completing step 5.
4
Press <Enter>.
5
To confirm your password, type it a second time and press <Enter>.
The setting shown for the
System Password
begin using your system.
36 Using the System Setup Program
changes to
Enabled
. Exit the System Setup program and
6
Either reboot your system now for your password protection to take effect or continue working.
NOTE: Password protection does not take effect until you reboot the system.
Using Your System Password to Secure Your System
NOTE: If you have assigned a setup password (see "Using the Setup Password" on page 38), the system accepts
your setup password as an alternate system password.
When the Password Status option is set to Unlocked, you have the option to leave the password security enabled or to disable the password security.
To leave the password security enabled:
1
Turn on or reboot your system by pressing <Ctrl><Alt><Del>.
2
Type your password and press <Enter>.
To disable the password security:
1
Turn on or reboot your system by pressing <Ctrl><Alt><Del>.
2
Type your password and press <Ctrl><Enter>.
When the Password Status option is set to Locked, whenever you turn on your system or reboot your system by pressing <Ctrl><Alt><Del>, type your password and press <Enter> at the prompt.
After you type the correct system password and press <Enter>, your system operates as usual.
If an incorrect system password is entered, the system displays a message and prompts you to re-enter your password. You have three attempts to enter the correct password. After the third unsuccessful attempt, the system displays an error message showing the number of unsuccessful attempts and that the system has halted and will shut down. This message can alert you to an unauthorized person attempting to use your system.
Even after you shut down and restart the system, the error message continues to be displayed until the correct password is entered.
NOTE: You can use the Password Status option in conjunction with the System Password and Setup Password
options to further protect your system from unauthorized changes.
Deleting or Changing an Existing System Password
1
When prompted, press <Ctrl><Enter> to disable the existing system password.
If you are asked to enter your setup password, contact your network administrator.
2
Enter the System Setup program by pressing <F2> during POST.
3
Select the
System Security
screen field to verify that the
Password Status
Using the System Setup Program 37
option is set to
Unlocked
.
4
When prompted, type the system password.
5
Confirm that
Not Enabled
If
Enabled
Not Enabled
is displayed for the
is displayed for the
is displayed for the
System Password
System Password
option, press the <Alt><b> key combination to restart
System Password
option.
option, the system password has been deleted. If
the system, and then repeat steps 2 through 5.

Using the Setup Password

Assigning a Setup Password
You can assign (or change) a setup password only when the Setup Password option is set to Not Enabled. To assign a setup password, highlight the Setup Password option and press the <+> or <–> key. The system prompts you to enter and verify the password. If a character is illegal for password use, an error message appears.
NOTE: The setup password can be the same as the system password. If the two passwords are different, the setup
password can be used as an alternate system password. However, the system password cannot be used in place of the setup password.
You can use up to 32 characters in your password.
As you press each character key (or the spacebar for a blank space), a placeholder appears in the field.
The password assignment is not case-sensitive. However, certain key combinations are not valid. If you enter one of these combinations, an error message appears. To erase a character when entering your password, press <Backspace> or the left-arrow key.
After you verify the password, the Setup Password setting changes to Enabled. The next time you enter the System Setup program, the system prompts you for the setup password.
A change to the Setup Password option becomes effective immediately (restarting the system is not required).
Operating With a Setup Password Enabled
If Setup Password is set to Enabled, you must enter the correct setup password before you can modify most of the System Setup options. When you start the System Setup program, the program prompts you to enter a password.
If you do not enter the correct password in three attempts, the system lets you view, but not modify, the System Setup screens—with the following exception: If System Password is not set to Enabled and is not locked through the Password Status option, you can assign a system password (however, you cannot disable or change an existing system password).
NOTE: You can use the Password Status option in conjunction with the Setup Password option to protect the
system password from unauthorized changes.
38 Using the System Setup Program
Deleting or Changing an Existing Setup Password
1
Enter the System Setup program and select the
2
Highlight the <Enter> twice to clear the existing setup password.
The setting changes to
3
If you want to assign a new setup password, perform the steps in "Assigning a Setup Password" on page 38.
Setup Password
Not Enabled
option, press <Enter> to access the setup password window, and press
.
System Security
option.

Disabling a Forgotten Password

See "Disabling a Forgotten Password
" on page 122
.
Using the System Setup Program 39
40 Using the System Setup Program

Installing System Components

This section describes how to install the following system components:
Front drive bezel
Hard drives
Diskette drive
Optical and tape drives
Expansion cards
SAS controller card
Microprocessor
•Memory
System battery
Power supply
Cooling Fans
Chassis intrusion switch
•Bezel
Front I/O panel
System board

Recommended Tools

You may need the following items to perform the procedures in this section:
#2 Phillips screwdriver
Long #2 Phillips screwdriver (blade at least 6 inches long)
Needle-nose pliers
Wire cutter (optional)
Small flat-blade drive
•W
rist grounding stra
r
p
Installing System Components 41

Inside the System

3
In Figure 3-1, the system cover is opened to provide an interior view of the system.
Figure 3-1. Inside the System
2
1
10
9
8
1 5.25-inch drive bays (2) 2 drive cage 3 power supply
4 system board 5 memory fan 6 hard drives (2)
7 rotatable hard-drive carrier 8 front fan 9 expansion-card fan
10 flex bay
7
4
6
5
The system board can accommodate two processors, five expansion cards, and four memory modules. The rotatable hard-drive carrier provides space for up to two SAS or SATA hard drives. Drive bays in the front of the system provide space for an optical drive; an optional diskette drive or third hard drive; and an optional tape drive, second optical drive, or fourth hard drive. A controller expansion card is required for SAS hard drives or for more that two SATA hard drives. The optional third hard drive requires a mounting screw kit. The fourth hard drive requires a special drive carrier for installation. Power is supplied to the system board and internal peripherals through a single nonredundant power supply.
42 Installing System Components

Opening the System

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Press the power button to ground the system board.
3
If you have installed a padlock through the padlock ring on the back panel, remove the padlock.
4
Lay the system on its side as shown in Figure 3-2.
5
Open the system by sliding the cover release tab toward the rear of the system and lifting off the cover.

Closing the System

1
Ensure that all internal cables are connected and folded out of the way.
2
Ensure that no tools or extra parts are left inside the system.
3
Reinstall the system cover:
a
Insert the bottom edge of the cover into the bottom of the system chassis. See Figure 3-2.
b
Press down on the cover until the cover release tab snaps into place.
4
If applicable, install the padlock.
5
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
After you open and close the cover, the chassis intrusion detector, if enabled, causes the following message to appear on the screen at the next system start-up:
ALERT! Cover was previously removed.
To reset the chassis intrusion detector, press <F2> to enter the System Setup program. See "Using the
6
System Setup Program" on page 27.
NOTE: If a setup password has been assigned by someone else, contact your network administrator for
information on resetting the chassis intrusion detector.
Installing System Components 43
Figure 3-2. Opening and Closing the System
1
1 release tab

Rotatable Hard-Drive Carrier

Rotating the Hard-Drive Carrier Out of the System

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3
Press the release latch on the P3 power-cable connector beside the power supply and pull the two connectors apart. See Figure 3-3
4
Press the card retention mechanism release-tab and rotate the card retention mechanism so that it rests against the rotatable hard-drive carrier.
44 Installing System Components
Figure 3-3. Rotatable Hard-Drive Carrier Retention Mechanism
3
2
1
1 P3 power connector 2 card retention mechanism 3 release tab
5
Press down against the card retention mechanism until it clicks into place, locked against the hard­drive carrier.
6
Grasp the handle on the hard-drive carrier and rotate the carrier out of the chassis. See Figure 3-4. Rotate the carrier approximately 180 degrees from its original position, as shown in Figure 3-1, but do not force it any further.
Installing System Components 45
Figure 3-4. Rotating the Hard-Drive Carrier Out of and Into the System
2
1
1 rotatable hard-drive carrier 2 handle 3 card-retention mechanism
3

Rotating the Hard-Drive Carrier Into the System

1
Grasp the handle on the hard-drive carrier and rotate the carrier back into the chassis until the metal tabs on each side of the carrier are seated, securing the carrier. See Figure 3-4.
2
Pull up on the card retention mechanism to release it from the hard-drive carrier.
3
Rotate the card retention mechanism back into its original position; push its tip so that its tab clicks into place. See Figure 3-4.
4
Reconnect the P3 power-cable connectors.

Removing and Replacing the Front Drive Bezel

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43."
NOTE: This sliding plate secures and releases the drive bezel and helps to secure the drives.
3
Pull the lever on the sliding plate to the right until it releases the front drive bezel from its side hinges.
46 Installing System Components
4
Carefully tilt the front drive bezel away from the chassis and lift it out as shown in Figure 3-5.
5
To replace the front drive bezel, reverse the steps above and snap the bezel into place.
Figure 3-5. Removing and Replacing the Front Drive Bezel
2
1
4
1 front drive bezel tabs 2 sliding plate 3 sliding plate lever
4 front drive bezel
3

Removing and Replacing the Front Drive Bezel Insert

1
To remove the front drive bezel insert, press the two insert tabs on the front drive bezel inward and lift out the insert. See Figure 3-6.
2
To replace the front drive bezel insert, reverse the step above and snap the insert into place.
Installing System Components 47
Figure 3-6. Removing and Replacing the Front Drive Bezel Insert
1
2
3
1 front drive bezel 2 insert tabs 3 drive bezel inserts

Hard Drives

NOTE: The system’s drive configuration must consist of all SATA hard drives or all SAS hard drives.

Hard Drive Installation Guidelines

Up to four hard drives are supported in internal drive bays. All drives must be either SAS or SATA; mixed configurations are not supported. Up to two SATA drives may be connected to the system’s integrated SATA controller. If more than two SATA drives or any number of SAS drives are installed, they must all be connected to an optional SAS controller expansion card. Table 3-1 describes the possible drive configurations.
Table 3-1. Hard-Drive Configurations
Drive Number
1 SATA rotatable drive carrier (HDD0) integrated SATA (SATA_0 connector)*
1 SAS rotatable drive carrier (HDD0) expansion card (primary SAS connector)
2 SATA rotatable drive carrier (HDD1) integrated SATA (SATA_1 connector)*
2 SAS rotatable drive carrier (HDD1) expansion card (primary SAS connector)
3 SAS or SATA flex bay expansion card (primary SAS connector)
4 SAS or SATA optional drive carrier in lower
*If more than two SATA drives are installed, all drives must be connected to a SAS controller expansion card.
Drive Type Location Controller
expansion card (primary SAS connector)
5.25-inch drive bay
48 Installing System Components

Removing a Hard Drive from the Rotatable Carrier

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
NOTE: If only one SATA hard drive is to be installed, it should be connected to the SATA0 connector on the
system board.
3
Rotate the hard-drive carrier out of the system. See "Rotating the Hard-Drive Carrier Out of the System" on page 44.
4
Disconnect the hard drive power cable from the hard drive that you are removing.
5
Disconnect the data cable from the hard drive that you are removing.
6
Press the drive release tabs on each side of the hard-drive bracket toward each other and slide the drive up and out of the hard-drive bay. See Figure 3-7.
Figure 3-7. Removing and Installing a Hard Drive in the Drive Carrier
1
1 drive release tabs (2) 2 hard drive in primary hard-
drive bay
2
3
3 secondary hard drive bay
Installing System Components 49
NOTE: If you do not intend to replace the drive, it is highly recommended that you remove the drive from the
guide bracket (see Figure 3-8) and insert the empty guide bracket back into the drive bay. This eliminates the likelihood that the empty bracket will be misplaced or improperly stored while not in use.
7
Rotate the hard-drive carrier back into place. See "Rotating the Hard-Drive Carrier Into the System" on page 46.
8
Close the system. See "Closing the System" on page 43.
9
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.

Installing a Hard Drive in the Rotatable Carrier

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Unpack the replacement hard drive, and prepare it for installation.
2
Check the documentation for the hard drive to verify that the drive is configured for your system.
3
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
4
Open the system. See "Opening the System" on page 43.
5
Rotate the hard-drive carrier out of the system. See "Rotating the Hard-Drive Carrier Out of the System" on page 44.
6
If you are replacing a hard drive, remove the drive that you are replacing. See "Removing a Hard Drive from the Rotatable Carrier" on page 49.
If a there is a hard-drive bracket in the empty hard-drive bay, remove the bracket by pressing its tabs toward it each other and pulling it up and out of the drive bay.
7
If a replacement hard drive does not have the hard-drive bracket attached, remove the bracket from the old drive.
Flex the hard-drive bracket open and align the side holes in the new hard drive with the pins on the bracket; release the tension upon the bracket so that the hard drive is securely fastened. See Figure 3-8.
50 Installing System Components
Figure 3-8. Installing a Hard Drive in a Drive Bracket
1
2
1 drive 2 hard-drive bracket
NOTICE: SAS drives and SATA drives cannot be mixed in the system. The drives must be either all SATA or all SAS
hard drives.
8
Slide the hard drive into the hard-drive bay until it clicks securely into place.
9
Connect a data cable and a power cable to the hard drive.
NOTE: The only SATA connectors on the board that support hard drives are those labeled SATA0 and SATA1.
If only one SATA hard drive is to be installed, it should be connected to the SATA0 connector.
If you are installing a SATA hard drive and have only one or two drives in your system, connect the integrated SATA controller data cable and the power cable as shown in Figure 3-9.
If you are installing a SATA hard drive and have three or four drives in your system, connect the data cable from the SAS controller card and the power cable as shown in Figure 3-10.
If you are installing a SAS hard drive, connect the data cable from the SAS controller card and the power cable as shown in Figure 3-10.
Installing System Components 51
Figure 3-9. Cabling a SATA Hard Drive in a One- or Two-Drive Configuration
1
2
3
1 integrated SATA connector 2 SATA data cable 3 hard-drive power cable
52 Installing System Components
Figure 3-10. Cabling a Hard Drive in the Drive Carrier (SAS or More Than Two SATA Drives)
2
1
3
5
1 SAS cable 2 hard-drive activity indicator
cable
4 power cable 5 AUX_LED connector
10
Ensure that all connectors are properly cabled and firmly seated.
3 data cable
4
Ensure that the SAS cable is connected to the blue primary connector if the SAS controller card has two connectors.
11
Rotate the hard-drive carrier back into place. See "Rotating the Hard-Drive Carrier Into the System" on page 46.
12
Close the system. See "Closing the System" on page 43.
Installing System Components 53
13
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
See the documentation that came with the drive for instructions on installing any software required for drive operation.
14
Enter the System Setup program (see "Entering the System Setup Program" on page 27), and ensure that the drive’s controller is enabled.
15
Exit the System Setup program and reboot the system.
16
Partition and logically format the drive.
See the documentation for your operating system for instructions.
17
(Optional) Test the hard drive by running the system diagnostics. See "Running the System Diagnostics" on page 113.
18
If the drive you just installed is the primary drive, install your operating system on the hard drive.

Removing an Optional Third Hard Drive

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3
Remove the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
NOTICE: If metal shields are present in your system configuration, they must be installed at all times while your
system is in use or your system may not function properly.
4
If metal shields are present in your system, slide the sliding-plate lever to the right and hold it in place as you pull to remove the vented metal insert from the flex bay.
5
Disconnect the power cable and the data cable from the back of the hard drive.
6
Slide the sliding-plate lever to the right to release the shoulder screw and slide the drive out of the flex bay. See Figure 3-11.
7
Set the drive aside in a secure location.
54 Installing System Components
Figure 3-11. Removing and Installing a Third Hard Drive
1
2
1 drive bay sliding plate 2 hard drive
NOTICE: If metal shields are present in your system configuration, they must be installed at all times while your
system is in use or your system may not function properly.
8
If you are not installing another drive in the drive bay, reinstall the vented metal insert over the flex bay and the empty space beneath it.
a
Insert the metal insert’s two upper screws and its two lower screws into the corresponding slots inside the flex bay.
b
Push the vented metal insert until it clicks into place and its metal tabs rest flush against the chassis surface.
9
Reinstall the drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
10
Close the system. See "Closing the System" on page 43.
11
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.

Installing an Optional Third Hard Drive

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
Installing System Components 55
NOTE: Four mounting screws are required to install an optional third hard drive. If you purchase an upgrade from
Dell, these screws are included in the kit.
1
If you are installing a new drive, unpack the drive and prepare it for installation.
Check the documentation for the drive to verify that it is configured for your system.
NOTE: The screws installed in the following step must be installed in the front four screw holes in order for
the drive to be installed.
2
Install four screws in the front four holes on the sides of the drive.
3
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
4
Open the system. See "Opening the System" on page 43.
5
Remove the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
NOTICE: If metal shields are present in your system configuration, they must be installed at all times while your
system is in use or your system may not function properly.
6
If the flex bay is not populated and metal shields are present in your system, slide the sliding-plate lever to the right and hold it in place as you pull to remove the vented metal insert from the flex bay.
7
If you already have a diskette drive installed in the flex bay, remove it. See "Removing the Diskette Drive" on page 63.
8
If you already have a hard drive installed in the flex bay, remove the hard drive. See "Removing an Optional Third Hard Drive" on page 54.
9
Gently slide the drive into place in the flex bay; the drive clicks through two notches before it is securely installed.
10
Ensure that the hard-drive indicator and data cables are correctly connected to the SAS controller expansion card. See Figure 3-12 and "Installing a SAS Controller Expansion Card" on page 72.
11
If you are upgrading from two SATA hard drives, connect the first two hard drives to the SAS controller card as described in the following steps:
a
Remove the SATA data cables from the hard drives in the rotatable drive carrier and the SATA_0 and SATA_1 connectors on the system board. See "Removing a Hard Drive from the Rotatable Carrier" on page 49.
b
Route the two long data cables from the SAS controller card, as shown in Figure 3-12, through the clips on chassis bottom, chassis sides, and the rotatable drive carrier, to the first two hard drives.
c
Connect the data and power cables to the first two hard drives as shown in Figure 3-12.
12
Connect a data cable and a power cable to the back of the third hard drive. See Figure 3-12.
56 Installing System Components
Figure 3-12. Cabling a Third or Fourth Hard Drive
2
1
3
4
5
6
1 SAS cable 2 hard-drive activity indicator
cable
4 long SAS data cables (2) 5 SAS data cable 6 power cable
NOTICE: If metal shields are present in your system configuration, they must be installed at all times while your
system is in use or your system may not function properly.
13
If metal shields are present in your system, install the vented metal insert over the flex bay and the
3 AUX_LED connector
empty space beneath it:
a
Insert the metal insert’s two upper screws and its two lower screws into the corresponding slots inside the flex bay.
Installing System Components 57
b
Push the vented metal insert until it clicks into place and its metal tabs rest flush against the chassis surface.
14
Reinstall the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
15
Ensure that all connectors are properly cabled and firmly seated.
Ensure that the SAS cable is connected to the blue primary connector if the SAS controller card has two connectors.
16
Close the system. See "Closing the System" on page 43.
17
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
See the documentation that came with the drive for instructions on installing any software required for drive operation.
18
Enter the System Setup program (see "Entering the System Setup Program" on page 27), and ensure that the drive’s controller is enabled.
19
Exit the System Setup program, and reboot the system.
20
Partition and logically format your drive before you proceed to the next step.
See the documentation for your operating system for instructions.
21
(Optional) Test the hard drive. See "Running the System Diagnostics" on page 113 for instructions.

Removing an Optional Fourth Hard Drive

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3
Remove the front drive bezel. See "Removing and Replacing the Front Drive Bezel" in "Troubleshooting Your System."
4
Pull the drive bay sliding plate downward in the direction of the arrow on the plate. See Figure 3-13.
5
Hold the sliding plate in position and slowly pull the optional hard-drive carrier out of the bay until you can access the cable connections to the back of the drive.
6
Disconnect the power and interface cables from the drive. See Figure 3-12.
7
Disconnect the drive carrier fan cable from the FAN_HDD connector on the system board. See Figure 6-2.
8
Pull the drive carrier out of the bay.
58 Installing System Components
Figure 3-13. Removing and Installing a Fourth Hard Drive
1
2
1 drive bay sliding plate 2 optional hard-drive carrier in
lower 5.25-inch drive bay
NOTICE: If metal shields are present, they must be installed at all times while your system is in use or your system
may not function properly.
9
If you are not installing another drive in the bay, install the 5.25-inch metal shield in its place; align its screws in the metal rails and push the shield back until it clicks into place.
10
If you are installing another drive in the bay, see "Installing an Optional Fourth Hard Drive" on page 59 or "Installing an Optical or Tape Drive" on page 68.
11
Replace the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
12
Close the system. See "Closing the System" on page 43.
13
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.

Installing an Optional Fourth Hard Drive

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
Installing System Components 59
NOTICE: If the fan cable from the optional hard-drive carrier is not correctly connected to the FAN_HDD
connector on the system board and detected by the system BIOS, premature drive failure can occur. Follow the steps in this section carefully and verify fan detection through the System Setup program as described.
NOTE: Installing a fourth hard drive requires an optional hard-drive carrier with a cooling fan.
1
If you are installing a new drive, unpack the drive and prepare it for installation.
Check the documentation for the drive to verify that it is configured for your system.
2
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
3
Open the system. See "Opening the System" on page 43.
4
Remove the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
5
If the flex bay is not populated and metal shields are present in your system, slide the sliding-plate lever to the right and hold it in place as you pull to remove the vented metal insert from the flex bay.
6
If an optical or tape drive is installed in the lower 5.25-inch drive bay, remove it. See "Removing an Optical or Tape Drive" on page 66.
7
If you are replacing a hard drive, remove the hard-drive carrier. See "Removing an Optional Fourth Hard Drive" on page 58.
8
Press the drive release tabs on each side of the hard-drive bracket toward each other and slide the drive out of the drive carrier. See Figure 3-14.
If there is a hard-drive bracket in the empty drive carrier, remove the bracket by pressing its tabs toward it each other and pulling it up and out of the drive carrier.
9
If a replacement hard drive does not have the hard-drive bracket attached, remove the bracket from the old drive.
Flex the hard-drive bracket open and align the side holes in the new hard drive with the pins on the bracket; release the tension upon the bracket so that the hard drive is securely fastened. See Figure 3-8.
10
Slide the hard drive into the hard-drive carrier until it clicks securely into place. See Figure 3-14.
60 Installing System Components
Figure 3-14. Installing a Fourth Hard Drive in the Optional Hard-Drive Carrier
1
1 optional hard-drive carrier 2 drive release tabs (2) 3 hard drive
4 hard-drive bracket
11
Carefully insert the drive carrier into the lower 5.25-inch drive bay, passing the fan cable through the
2
3
4
opening on the bottom of the drive bay, and slide the drive carrier far enough into the system to access the connectors on the back of the drive.
12
Attach the power and data cables to the hard drive. See Figure 3-12.
13
Gently slide the drive into place until you hear a click or feel the drive securely installed.
14
Route the fan cable over the card fan and through the plastic clips on the bottom of the system chassis, as shown in Figure 3-15. Connect the fan cable securely to the FAN_HDD connector on the system board. See Figure 3-15 and Figure 6-2.
Installing System Components 61
Figure 3-15. Connecting the Cooling Fan for an Optional Fourth Hard Drive
2
1
1 card fan 2 fan power cable 3 FAN_HDD connector
15
Check all cable connections, and fold cables out of the way to allow for airflow between the fan and
3
cooling vents.
16
Reinstall the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
17
Ensure that all connectors are properly cabled and firmly seated.
18
Close the system. See "Closing the System" on page 43.
19
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
See the documentation that came with the drive for instructions on installing any software required for drive operation.
20
Enter the System Setup program (see "Entering the System Setup Program" on page 27), and ensure that the drive’s controller is enabled.
NOTICE: If the fan cable from the optional hard-drive carrier is not correctly connected to the FAN_HDD
connector on the system board and detected by the system BIOS, premature drive failure can occur.
21
Verify that the
Optional Hard-Disk Drive
field in System Setup displays
Installed
Devices Screen" on page 32.
22
Exit the System Setup program, and reboot the system.
62 Installing System Components
. See "Integrated
23
Partition and logically format your drive before you proceed to the next step.
See the documentation for your operating system for instructions.
24
(Optional) Test the hard drive. See "Running the System Diagnostics" on page 113 for instructions.

Diskette Drive

Removing the Diskette Drive

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3
Remove the front drive bezel. See "Removing and Replacing the Front Drive Bezel" in "Troubleshooting Your System."
4
Disconnect the power and interface cables from the diskette drive. See Figure 3-16.
5
Pull the drive bay sliding plate downward in the direction of the arrow on the plate. See Figure 3-16.
6
Hold the sliding plate in position and slowly pull the drive out of the bay.
Installing System Components 63
Figure 3-16. Removing or Installing a Diskette Drive
1
2
3
4
1 drive bay sliding plate 2 interface cable 3 power cable
4 DSKT connector
7
If the drive is being permanently removed, install a front drive bezel insert. See "Removing and Replacing the Front Drive Bezel Insert" on page 47.
8
Replace the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
9
Close the system. See "Closing the System" on page 43.
10
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.

Installing a Diskette Drive

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
64 Installing System Components
3
Unpack the replacement diskette drive, and prepare it for installation.
4
Check the documentation for the drive to verify that it is configured for your system.
5
Attach the four shoulder screws to the drive as shown in Figure 3-17.
NOTE: Spare shoulder screws are attached to the inside of the front drive bezel.
6
Remove the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
Figure 3-17. Installing Diskette Drive Shoulder Screws
1
1 screws (4)
7
Remove the front drive bezel insert. See "Removing and Replacing the Front Drive Bezel Insert" on page 47.
8
From the front of the chassis, slide the drive into the drive bay until the shoulder screws snap securely into the sliding plate.
9
Connect the power cable to the drive. See Figure 3-16.
10
Connect the interface cable from the drive to the DSKT connector on the system board. See Figure 3-16 and Figure 6-2.
11
Close the system. See "Closing the System" on page 43.
12
Replace the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
13
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
14
Enter the System Setup program and ensure that the drive’s controller is enabled. See "Using the System Setup Program" on page 27.
15
(Optional) Test the drive by running the system diagnostics. See "Running the System Diagnostics" on page 113.
Installing System Components 65

Optical and Tape Drives

Only an optical drive can be installed in the upper 5.25-inch drive bay. Either an optical or a tape drive can be installed in the lower 5.25-inch drive bay, unless it is occupied by an optional third hard drive.

Removing an Optical or Tape Drive

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3
Remove the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
4
Disconnect the power and data cables from the back of the drive. See Figure 3-18.
5
Slide the sliding-plate lever to the right to release the shoulder screw and slide the drive out to remove it from the drive bay.
66 Installing System Components
Figure 3-18. Removing and Installing an Optical or Tape Drive
2
1
3
4
5
1 drive bay sliding plate 2 interface cable 3 power cable
4 SATA cable 5 IDE connector
NOTICE: If metal shields are present, they must be installed at all times while your system is in use or your system
may not function properly.
6
If you are not installing another drive in the bay, install the 5.25-inch metal shield in its place; align its screws in the metal rails and push the shield back until it clicks into place.
7
If you are installing another drive in the bay, see "Installing an Optical or Tape Drive" on page 68.
8
If the drive is being permanently removed, install a front drive bezel insert. See "Removing and Replacing the Front Drive Bezel Insert" on page 47.
9
Replace the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
10
Close the system. See "Closing the System" on page 43.
11
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
Installing System Components 67

Installing an Optical or Tape Drive

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Unpack the drive and prepare the drive for installation.
For instructions, see the documentation that accompanied the drive.
If you are installing a SCSI tape drive
an Expansion Card
" on page 70
, you must have a SCSI
) and configure the tape drive according to the documentation that
came with the tape drive, based on the following guidelines:
a
Each device attached to a SCSI host adapter must have a unique SCSI ID number. (Narrow SCSI devices use IDs 0 to 7; wide SCSI devices use IDs from 0 to 15.) Set the drive’s SCSI ID to avoid conflicts with other devices on the SCSI bus. For the default SCSI ID setting, see the documentation provided with the drive.
NOTE: There is no requirement that SCSI ID numbers be assigned sequentially or that devices be attached to
the cable in order by ID number.
SCSI logic requires that the two devices at opposite ends of a SCSI chain be terminated and that
b
all devices in between be unterminated. Therefore, you enable the tape drive’s termination if it is the last device in a chain of devices (or sole device) connected to the SCSI controller.
2
Attach the three shoulder screws to the drive. See Figure 3-19.
NOTE: Spare shoulder screws are attached to the inside of the front drive bezel insert.
Figure 3-19. Installing Optical or Tape Drive Shoulder Screws
controller card installed (see "Installing
3
Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
68 Installing System Components
1
1 screws (3)
4
Open the system. See "Opening the System" on page 43.
5
Remove the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
6
If necessary, remove the drive bezel insert from the empty drive bay. See "Removing and Replacing the Front Drive Bezel Insert" on page 47.
7
If another device is installed in the drive bay, remove that device. See "Removing an Optical or Tape Drive" on page 66.
NOTICE: If metal shields are present, they must be installed at all times while your system is in use or your system
may not function properly.
8
If the drive bay is unpopulated and metal shields are present, slide the sliding plate lever to the right and hold it in place as you pull to remove the 5.25-inch metal shield.
9
Gently slide the drive into place until you hear a click or feel the drive securely installed.
10
Attach the power and data cables to the optical or tape drive. See Figure 3-18.
If you are installing an IDE drive, another drive may be attached to the same data cable by another connector. The other end of the data cable should connect to the IDE connector on the system board. See Figure 6-2.
If you are installing a SATA tape drive (when available), connect the other end of the data cable to the SATA_2 or SATA_3 connector on the system board. See Figure 3-18 and Figure 6-2.
If you are installing a SCSI tape drive, connect the SCSI interface cable in the drive kit from the SCSI controller card to the drive.
11
Check all cable connections, and fold cables out of the way to allow for airflow between the fan and cooling vents.
12
Close the system. See "Closing the System" on page 43.
13
Replace the front drive bezel. See "Removing and Replacing the Front Drive Bezel" on page 46.
14
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
15
If you installed an IDE drive, enter the System Setup program and ensure that the drive’s IDE controller is enabled. See "Using the System Setup Program" on page 27.
16
(Optional) Test the drive by running the system diagnostics. See "Running the System Diagnostics" on page 113.
Installing System Components 69

Expansion Cards

Installing an Expansion Card

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3 Rotate the hard-drive carrier out of the system. See
System" on page 44
4
Press the two release tabs on the card retention door towards each other and pivot the door open. See Figure 3-20.
.
"Rotating the Hard-Drive Carrier Out of the
70 Installing System Components
Figure 3-20. Removing and Installing an Expansion Card
1
2
3
4
5
1 release tab 2 card retention door 3 alignment bar
4 alignment guide 5 filler bracket
5
If you are installing a new card, remove the filler bracket.
NOTE: Keep this bracket in case you need to remove the expansion card. Filler brackets must be installed
over empty expansion-card slots to maintain Federal Communications Commission (FCC) certification of the system. The brackets also keep dust and dirt out of the system and aid in proper cooling and airflow inside the system.
6
Prepare the card for installation.
See the documentation that came with the card for information on configuring the card, making internal connections, or otherwise customizing it for your system.
7
Place the card-edge connector in the expansion-card connector and press down firmly. Ensure that the card is fully seated in the slot and all cards and filler brackets are flush with the alignment bar.
8
Close the card retention door to secure the card(s) in the system.
Installing System Components 71
NOTICE: Do not route card cables over or behind the cards. Cables routed over the cards can prevent the system
cover from closing properly or cause damage to the equipment.
9
Connect any cables that should be attached to the card.
See the documentation for the card for information about the card’s cable connections.
10 Rotate the hard-drive carrier back into the system. See
System" on page 46
Close the system. See "Closing the System" on page 43.
11
12
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
13
Install any device drivers required for the card as described in the documentation for the card.
.
"Rotating the Hard-Drive Carrier Into the

Removing an Expansion Card

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3 Rotate the hard-drive carrier out of the system. See
System" on page 44
4
Press the two release tabs on the card retention door inward to open it. See Figure 3-20.
5
If necessary, disconnect any cables from the card.
6
Grasp the card by its top corners and ease it out of its connector.
7
If you are removing the card permanently, install a filler bracket in the empty card-slot opening.
NOTE: Filler brackets must be installed over empty expansion card slots to maintain FCC certification of the
system. The brackets also keep dust and dirt out of the system and aid in proper cooling and airflow inside the system.
8
Close the card retention door to secure the remaining card(s) in the system. See Figure 3-20.
.
9 Rotate the hard-drive carrier back into the system. See
System" on page 46
10
Close the system. See "Closing the System" on page 43.
11
Reconnect the system to the electrical outlet, and turn on the system and attached peripherals.
.
"Rotating the Hard-Drive Carrier Out of the
"Rotating the Hard-Drive Carrier Into the

Installing a SAS Controller Expansion Card

Read the installation instructions in the documentation for your SAS controller expansion card. Install the card in expansion card slot 1 (see Figure 6-2 for slot location and "Installing an Expansion Card" on page 70), and connect the hard-drive activity indicator cable from the card to the AUX_LED connector
72 Installing System Components
on the system board (see Figure 6-2 for the connector location). If your expansion card has two interface connectors, connect the data cable to the primary controller interface connector. See "Hard Drives" on page 48 for information about connecting hard drives.

Microprocessor

You can upgrade the system processor(s) to take advantage of future options in speed and functionality, or add a second processor. Each processor and its associated internal cache memory are contained in a land grid array (LGA) package that is installed in a ZIF socket on the system board.

Removing the Processor

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. See your Product Information Guide for complete information about safety precautions, working inside the computer, and protecting against electrostatic discharge.
1
Prior to upgrading your system, download the latest system BIOS version on
2
Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
3 Open the system. See
NOTICE: When you remove the heat sink, the possibility exists that the processor might adhere to the heat sink
and be removed from the socket. It is recommended that you remove the heat sink while the processor is still warm.
NOTICE: Never remove the heat sink from a processor unless you intend to remove the processor. The heat sink is
necessary to maintain proper thermal conditions.
4
Rotate the hard-drive carrier out of the system. See "Rotating the Hard-Drive Carrier Out of the
"Opening the System" on page 43
.
System" on page 44.
5
Rotate the processor access door to its open position. See Figure 3-21.
support.dell.com
.
NOTE: To loosen the four captive screws on the sides of the heat-sink assembly, you need a Phillips
screwdriver with at least a 6-inch blade.
6
Loosen but do not remove the four screws on the sides of the heat-sink assembly. Leave the screws in place to retain the springs under the screws.
7
Wait 30 seconds for the heat sink to loosen from the processor.
8
Lift to remove the heat-sink assembly from the system.
9
If the heat sink has not separated from the processor, carefully rotate the heat sink in a clockwise, then counterclockwise, direction until it releases from the processor. Do not pry the heat sink off of the processor.
10 Lift the heat sink off of the processor and set the heat sink
aside.
Installing System Components 73
Figure 3-21. Installing and Removing the Heat Sink
1
1 processor access door 2 heat-sink assembly 3 captive screw housing (4)
11
Pull the socket-release lever 90 degrees upward until the processor shield is released from the socket.
See
Figure 3-22
12
Rotate the processor shield upward and out of the way.
.
2
3
74 Installing System Components
Figure 3-22. Installing and Removing a Processor
4
3
2
1
5
1 socket key (2) 2 ZIF socket 3 processor
4 socket-release lever 5 processor shield
13 Lift the processor out of the socket and leave the release lever up so that the socket is ready for the
new processor
.
NOTICE: Be careful not to bend any of the pins on the ZIF socket when removing the processor. Bending the pins
can permanently damage the system board.

Replacing the Processor

1Unpack the new processor
2 Align the processor with the
3Install the processor in the socket.
NOTICE: Positioning the processor incorrectly can permanently damage the system board or the processor when
you turn it on. When placing the processor in the socket, be careful not to bend the pins in the socket.
If the release lever on the processor socket is not positioned all the way up, move it to that
a
position.
b With the
p
rocessor and
sure all pins are matched with the correct holes in the socket.
NOTICE: Do not use force to seat the processor. When the processor is positioned correctly, it engages easily into
the socket.
.
socket keys on t
the
socket
he ZIF socket. See
keys
aligned, set the processor lightly in the socket, making
Figure 3-22.
Installing System Components 75
c
W
hen the processor is fully seated in the socket, rotate the socket release lever back down until
it snaps into place, securing the processor.
d
Close the processor shield. See Figure 3-22.
4
Install the heat sink.
a Using a clean lint-free cloth, remove the existing thermal grease from the heat sink.
NOTE: If you did not receive a replacement heat sink, use the heat sink that you removed in "Removing the
Processor" on page 73.
Remove the protective sheet from the thermal grease layer on top of the processor. If you
b
See Figure 3-22.
receive the processor without the thermal grease pre-applied, open the grease packet included with your processor kit and apply thermal grease evenly to the top of the processor.
c Place the heat-sink assembly back onto the heat-sink assembly bracket. See
d Rotate the heat-sink assembly down towards the system base and tighten the four capture
Figure 3-21
.
screws.
5
Close the processor access door.
6
Ensure that all connectors are properly cabled and firmly seated.
7
Rotate the hard-drive carrier back into place. See "Rotating the Hard-Drive Carrier Into the System" on page 46).
8Close the system. See
9
Reconnect the system to the electrical outlet and turn on the system and attached peripherals.
A
s the system boots, it detects the presence of the new processor and automatically changes the
"Closing the System" on page 43.
system configuration information in the System Setup program.
10 Press <F2>
to enter the System Setup program, and check
new system configuration
. S
ee
"Using the System Setup Program" on page 27 for instructions about
that the processor information matches the
using the System Setup program.
. S
ee
11 Run the system diagnostics to verify that the new processor operates correctly
System Diagnostics" on page 113
for information about running the diagnostics and troubleshooting
"Running the
processor problems.

Memory

You can upgrade your system memory to a maximum of 8 GB by installing 533MHz or, when available, 667MHz fully buffered DIMMs (FBDs) in dual sets of 256-MB, 512-MB, 1-GB, or 2-GB. The memory sockets are located on the system board beneath the rotatable hard-drive carrier. See Figure 6-2.
NOTICE: If you remove your original memory modules from the system during a memory upgrade, keep them
separate from any new memory modules that you may have. Use only 533 MHz or, when available, 667 MHz FBDs.
76 Installing System Components

General Memory Module Installation Guidelines

To ensure optimal performance of your system, observe the following guidelines when configuring your system memory.
Use only qualified FBDs. FBDs can be either s
are single
-r
anked and modules marked with a 2R are dual-ranked.
ingle-ranked
or d
ual-ranked
. FBDs m
arked with a 1R
A minimum of two identical FBDs must be installed.
DIMM sockets must be populated by lowest number first.
FBDs m
ust be installed in pairs of matched memory size, speed, and technology
. For best system
performance, all FBDs should be identical memory size, speed, and technology.

Non-Optimal Memory Configurations

System performance can be affected if your memory configuration does not conform to the preceding installation guidelines. Your system may issue an error message during startup stating that your memory configuration is non-optimal.

Installing Memory Modules

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. See your Product Information Guide for complete information about safety precautions, working inside the computer, and protecting against electrostatic discharge.
1
Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
2 Open the system. See
3 Rotate the hard-drive carrier out of the system. See
System" on page 44
4 Locate the memory module sockets on the system board. See Figure 6-2.
"Opening the System" on page 43
.
.
"Rotating the Hard-Drive Carrier Out of the
CAUTION: The DIMMs are hot to the touch for some time after the system has been powered down. Allow time
for the DIMMs to cool before handling them. Handle the DIMMs by the card edges and avoid touching the DIMM components.
5 Press the ejectors on the memory module socket down and out, as shown in
Figure 3-23
, to allow the
memory module to be inserted into the socket.
Installing System Components 77
Figure 3-23. Installing and Removing a Memory Module
1
2
1 memory module 2 alignment key 3 socket
4 memory module socket
ejectors (2)
6
Align the memory module's edge connector with the alignment key on the memory module socket, and
4
3
insert the memory module in the socket.
NOTE: The memory module socket has an alignment key that allows you to install the memory module in the
socket in only one way.
7
Press down on the memory module with your thumbs while pulling up on the ejectors with your index fingers to lock the memory module into the socket.
When the memory module is properly seated in the socket, the ejectors on the memory module socket align with the ejectors on the other sockets that have memory modules installed.
8 Repeat
9 Close the system. See
10 Rotate the hard-drive carrier back into the system. See
System" on page 46
11
Reconnect the system and peripherals to power and turn them on.
12
(Optional) Press <F2> to enter the System Setup program, and check the System Memory setting on
step 3
through
.
step 7
of this procedure to install the remaining memory modules.
"Closing the System" on page 43
.
"Rotating the Hard-Drive Carrier Into the
the main System Setup screen.
The system should have already changed the value to reflect the newly installed memory.
13 If the value is incorrect, one or more of the memory modules may not be installed properly. Repeat
step 2
through
step 12
of this procedure, checking to ensure that the memory modules are firmly
seated in their sockets.
78 Installing System Components
14 Run the system memory test in the system diagnostics. See
page 113
.
"Running the System Diagnostics" on

Removing Memory Modules

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. See your Product Information Guide for complete information about safety precautions, working inside the computer, and protecting against electrostatic discharge.
1
Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
2 Open the system. See
3 Rotate the hard-drive carrier out of the system. See
System" on page 44
4 Locate the memory module sockets on the system board. See Figure 6-2.
CAUTION: The DIMMs are hot to the touch for some time after the system has been powered down. Allow time
for the DIMMs to cool before handling them. Handle the DIMMs by the card edges and avoid touching the DIMM components.
5 Press down and out on the ejectors on each end of the socket until the memory module pops out of
the socket. See
6 Rotate the hard-drive carrier back into the system. See
System" on page 46
7 Close the system. See
8
Connect the power cable to the power supply and the power outlet.
"Opening the System" on page 43
.
Figure 3-23
.
.
"Closing the System" on page 43.
.
"Rotating the Hard-Drive Carrier Out of the
"Rotating the Hard-Drive Carrier Into the

System Battery

Replacing the System Battery

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. See your Product Information Guide for complete information about safety precautions, working inside the computer, and protecting against electrostatic discharge.
1 Enter the System Setup program and record the option settings on the System Setup screens. See
"Using the System Setup Program" on page 27
Turn off the system, including any attached peripherals, and disconnect the system from the electrical
2
outlet.
3 Open the system. See
See
4
Figure 6-2
for the location of the system battery and then remove any cables that block access to
"Opening the System" on page 43
the battery.
.
.
Installing System Components 79
5
Remove the system battery.
NOTICE: To avoid damage to the battery connector, you must firmly support the connector while installing or
removing a battery.
S
upport the battery connector by pressing down firmly on the positive side of the connector.
a
See
Figure 3-24
b While supporting the battery connector,
.
push t
he battery toward the positive side of the
connector and pry it up out of the securing tabs at the negative side of the connector.
Figure 3-24. Replacing the System Battery
2
1
1 positive side of connector 2 system battery 3 negative side of connector
3
6Install the new system battery (see Figure 3-24):
a
Support the battery connector by pressing down firmly on the positive side of the connector.
b
Hold the battery with the "+" facing up, and slide it under the securing tabs at the positive side of the connector.
c
Press the battery straight down into the connector until it snaps into place.
7 Replace all the expansion cards you removed in
8 Close the system. See
9
Reconnect the system to the electrical outlet and turn on the system and attached peripherals.
10
Enter the System Setup program to confirm that the battery operates properly.
11
From the main screen, select
12
Re-enter any system configuration information that is no longer displayed on the System Setup
"Closing the System" on page 43
System Time
step 4
. See "Installing an Expansion Card
.
to enter the correct time and date.
screens, and then exit the System Setup program.
13 To test the newly installed battery, see
"Troubleshooting the System Battery" on page 102
" on page 70
.
.
80 Installing System Components

Power Supply

Removing the Power Supply

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3 Rotate the hard-drive carrier out of the system. See
System" on page 44
4
Disconnect the DC power cables from the system board (POWER1 and POWER2), the drives, and
.
any other cards or devices to which they are connected.
NOTE: Note the routing of the DC power cables underneath the tabs in the system frame as you release the
tabs and remove the cables from the system board and drives. You must route these cables properly when you replace them to prevent their being pinched or crimped.
5
Using a #2 Phillips screwdriver, remove the four Phillips screws that secure the power supply to the back panel.
6
Press the power-supply release tab down and slide the power supply toward the front of the system, then lift it out of the system chassis. See Figure 3-25.
"Rotating the Hard-Drive Carrier Out of the
Installing System Components 81
Figure 3-25. Removing the Power Supply
1
2
3
1 power supply release tab 2 power supply 3 screws (4)

Installing the Power Supply

1
Prepare the new power supply for installation.
2
Align the power supply mounting holes with the mounting holes on the back panel.
3
Slide the power supply toward the back panel, into the hooks on the side and bottom of the chassis, until it snaps into place over the power-supply release tab.
4
Using a #2 Phillips screwdriver, install the four Phillips screws that secure the power supply to the back panel.
5 Rotate the hard-drive carrier back into the system. See
System" on page 46
6
Reconnect the power-supply cables.
7
Close the system. See "Closing the System" on page 43.
.
82 Installing System Components
"Rotating the Hard-Drive Carrier Into the

Replacing the Cooling Fans

The system incorporates three cooling fans, and a fourth fan is included with the optional fourth hard­drive carrier. The card fan and front fan must be removed to access certain other system components. The memory fan on the rotatable hard-drive carrier should be removed only if it is being replaced. The fourth hard-drive fan is integrated in the optional fourth hard-drive carrier.

Replacing the Card and Front Fans

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3 Rotate the hard-drive carrier out of the system. See
System" on page 44
4
Disconnect the card fan cable from the FAN_CCAG connector on the system board. See
5
Pull to remove the full-length card retainer beside the card fan. See Figure 3-26.
6
Press the tab between the card fan and the front fan towards the card fan as you lift it up and out of the system.
.
"Rotating the Hard-Drive Carrier Out of the
Figure 6-2
.
Installing System Components 83
Figure 3-26. Removing and Installing the Card Fan
1
5
1 card fan 2 card fan cable 3 card fan system-board
4 front fan 5 full-length card retainer
2
3
4
connector (FAN_CCAG)
7
Disconnect the front fan cable from the FAN_FRONT connector on the system board. See
8
Remove the cables from the channel at the bottom of the front fan assembly.
9
Unscrew the fan case and lift to remove the front fan assembly from the system. See Figure 3-27.
10
Perform the preceding steps in reverse order to reinstall the fans.
84 Installing System Components
Figure 6-2
.
Figure 3-27. Removing and Installing the Front Fan
1
2
3
1 front fan assembly 2 front fan cable 3 front fan system-board
connector (FAN_FRONT)

Replacing the Memory Fan

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3 Rotate the hard-drive carrier out of the system. See
System" on page 44
4
Disconnect the card fan cable from the FAN_MEM connector on the system board. See
5
Remove the hard-drive from the bay beneath to the memory fan. See "Removing a Hard Drive from
.
the Rotatable Carrier" on page 49.
6
Pull the four fan grommets out of the holes in the hard-drive carrier. Optionally, cut the grommets with a wire cutter if available.
7
Place the new fan with the grommets aligned with the holes in the hard-drive carrier and press into place. Use needle-nose pliers to pull the grommets completely through the mounting holes.
"Rotating the Hard-Drive Carrier Out of the
Figure 6-2
Installing System Components 85
.
8
Reinstall the hard drive. See "Installing a Hard Drive in the Rotatable Carrier" on page 50.
9
Connect the card fan cable from the FAN_MEM connector on the system board. See
10 Rotate the hard-drive carrier back into the system. See
System" on page 46
Close the system. See "Closing the System" on page 43.
11
.
"Rotating the Hard-Drive Carrier Into the
Figure 6-2
.

Replacing the Fourth Hard-Drive Fan

The fourth hard-drive fan is integrated in the optional fourth hard-drive carrier and is replaced as part of the carrier assembly. See "Removing an Optional Fourth Hard Drive" on page 58.

Chassis Intrusion Switch

Removing the Chassis Intrusion Switch

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3
Disconnect the chassis intrusion switch cable from the INTRUDER connector on the system board. See Figure 3-28.
4
Slide the chassis intrusion switch out of the securing bracket notch. See Figure 3-28.
5
Remove the switch and its attached cable from the system.
86 Installing System Components
Figure 3-28. Removing and Installing the Chassis Intrusion Switch
1
2
3
1 chassis intrusion switch 2 securing bracket notch 3 INTRUDER connector

Installing the Chassis Intrusion Switch

1
Align the chassis intrusion switch with the securing bracket notch. See Figure 3-28.
2
Slide the switch into the securing bracket notch.
3
Connect the switch cable to the INTRUDER connector on the system board.
4
Close the system. See "Closing the System" on page 43.
5
Reconnect the system to the electrical outlet, and turn on the system.

Removing and Replacing the Bezel (Service Only Parts Procedure)

Removing the Bezel

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
Installing System Components 87
3 Rotate the hard-drive carrier out of the system. See
System" on page 44
4
Remove the card and front fans. See "Replacing the Card and Front Fans" on page 83.
5
Using a #2 Phillips screwdriver, remove the three bezel release screws. See Figure 3-29. To remove the
.
"Rotating the Hard-Drive Carrier Out of the
lower screw, angle the screwdriver over the top of the CPU1 heat sink, if populated.
6
Rotate the top of the bezel away from the system chassis and remove it.
Figure 3-29. Removing the Bezel
1
4
3
1 bezel release screws (3) 2 slots (2) 3 hooks (3)
4 bezel

Replacing the Bezel

1
Insert the hooks on the bottom of the bezel into the slots in the chassis and rotate it into position.
2
Attach the three bezel release screws to secure the bezel to the system chassis. See Figure 3-29.
3
Reinstall the front and card fans. See "Replacing the Card and Front Fans" on page 83.
88 Installing System Components
2
4
Reinstall the processor heat sink and shroud assembly. See "Replacing the Processor" on page 75.
5 Rotate the hard-drive carrier back into the system. See
System" on page 46
6
Close the system. See "Closing the System" on page 43.
7
Reconnect the system to the electrical outlet, and turn on the system.
.
"Rotating the Hard-Drive Carrier Into the

Front I/O Panel (Service Only Parts Procedure)

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.

Removing the Front I/O Panel

1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Remove the system cover. See "Opening the System" on page 43.
3
Rotate the hard-drive carrier out of the system. See "Rotating the Hard-Drive Carrier Out of the System" on page 44.
4
Remove the front bezel. See "Removing the Bezel" on page 87.
NOTICE: Carefully note the routing of each cable before you disconnect it, so that you are sure to re-route cables
correctly.
5
Note the routing of each cable as you disconnect the I/O panel ribbon cable and the thermal diode cable from the I/O panel.
Disconnect the I/O panel ribbon cable from the I/O panel connector by pulling the yellow cable loop.
6
Remove the mounting screw holding the I/O panel bracket assembly to the front chassis. See Figure 3-30.
7 Lift the I/O panel out of the system.
If you are replacing the I/O panel, perform the following steps:
8
a
Remove the screw attaching the I/O board to the mounting bracket. See Figure 3-30.
b
Slide the board to the side to remove the two hooks from the slots in the mounting bracket.
c
Disconnect the thermal diode cable and set it aside to install on the new I/O panel.
Installing System Components 89
Figure 3-30. Removing and Installing the Front I/O-Panel
1
6
2
3
4
5
1 I/O panel 2 thermal diode cable connector 3 I/O board mounting screw
4 thermal diode cable 5 holding tab 6 assembly mounting screw

Replacing the Front I/O Panel

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
If you are replacing the I/O panel, perform the following steps:
a
Remove the screw attaching the new I/O board to the mounting bracket. See Figure 3-30.
b
Slide the board to the side to disengage the two hooks from the slots in the mounting bracket.
c
Connect the thermal diode cable that you removed in step 8 of "Removing the Front I/O Panel" on page 89 to the connector on the new I/O panel board.
90 Installing System Components
d
Place the I/O panel board on the mounting bracket, routing the thermal diode cable under the board, and slide the board to the side to engage the hooks in the mounting bracket slots.
e
Reinstall the screw connecting the I/O panel board to the mounting bracket.
2
Fit the I/O panel bracket assembly into the holding tab on the front of the chassis. See Figure 3-30.
3
Secure the I/O panel bracket assembly by installing the I/O panel assembly mounting screw.
4
Connect the cables the new I/O panel that you removed in step 5 of "Removing the Front I/O Panel" on page 89.
5
Reinstall the front bezel. See "Replacing the Bezel" on page 88.
6 Rotate the hard-drive carrier back into the system. See
System" on page 46
7
Close the system. See "Closing the System" on page 43.
8
Reconnect the system to the electrical outlet, and turn on the system.
.
"Rotating the Hard-Drive Carrier Into the

Thermal Diode Cable (Service Only Parts Procedure)

To replace a faulty thermal diode cable, follow the steps in "Removing the Front I/O Panel" on page 89 to remove the front I/O panel and remove the old thermal diode cable. Then, install the new cable and reinstall the front I/O panel as described in "Replacing the Front I/O Panel" on page 90.

System Board (Service Only Parts Procedure)

CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
CAUTION: The heat sink can get hot during operation. To avoid burns, ensure that the system has sufficient time
to cool before removing the system board.

Removing the System Board

1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Remove the system cover. See "Opening the System" on page 43.
3
Rotate the hard-drive carrier out of the system. See "Rotating the Hard-Drive Carrier Out of the System" on page 44.
4
Remove the processor access door assembly:
a
Remove the green screw that attaches the processor access door assembly to the system board and to the system chassis.
b
Lift to remove the processor access door assembly from the system.
5
Remove the card and front fans. See "Replacing the Card and Front Fans" on page 83.
Installing System Components 91
6
Disconnect the following cables from the system board. See Figure 6-2.
Two power-supply cables from the POWER1 and POWER2 connectors
If applicable, diskette data cable from the DSKT connector
I/O panel cable from the FRONT PANEL connector
5.25-inch device data cable from the IDE connector
Memory cooling fan cable from the FAN_MEM connector
If applicable, data cable(s) from the SATA connector(s)
7
Remove all expansion cards and any attached cables. See "Removing an Expansion Card" on page 72.
8
Remove all memory modules. See "Removing Memory Modules" on page 79.
NOTE: Record the memory-module socket locations to ensure proper reinstallation of the memory modules.
CAUTION: The processor and heat sink can become extremely hot. Allow sufficient time for the processor and
heat sink to cool before handling.
NOTICE: To prevent damaging the processor, do not pry the heat sink off of the processor.
9
Remove the processors. See "Removing the Processor" on page 73.
10
Using a #2 Phillips screwdriver, remove the nine system board mounting screws that secure the system board to the chassis. See Figure 3-31.
NOTE: To remove all of the screws, you need a Phillips screwdriver with a blade at least 6 inches long.
92 Installing System Components
Figure 3-31. System Board Mounting Points
1
2
3
1 screws (9) 2 system board 3 mounting hole for processor
access door (green screw)
11
Carefully route any loose cables away from the edges of the system board.
12
Gently slide the system board toward the front of the system, then lift the system board up and out of the chassis.
13
Place the system board on a flat, nonconductive surface.

Installing the System Board

1
Lower the system board into the chassis, aligning the I/O ports on the system board with the I/O connector openings on the back panel of the chassis.
2
Using a #2 Phillips screwdriver, install the nine screws on the system board that secure it to the chassis. See Figure 3-31.
NOTICE: To prevent damaging the processor, clean the heat sink to remove any thermal grease and then apply
fresh thermal grease to the processor before installing the heat sink.
3
Install the processors. See "Replacing the Processor" on page 75.
4
Install the memory modules in the same sockets from which they were removed. See "Installing Memory Modules" on page 77.
5
Reinstall the processor access door assembly, using the green screw to attach it to the system board and system chassis.
Installing System Components 93
6
Install the expansion cards and connect any cables. See "Installing an Expansion Card" on page 70.
7
Connect the cables that you removed in "Removing the System Board" on page 91. See Figure 6-2.
8
Reinstall the card and front fans. See "Replacing the Card and Front Fans" on page 83.
9 Rotate the hard-drive carrier back into the system. See
System" on page 46
10
Close the system. See "Closing the System" on page 43.
11
Reconnect the system to the electrical outlet, and turn on the system.
.
"Rotating the Hard-Drive Carrier Into the
94 Installing System Components

Troubleshooting Your System

Safety First—For You and Your System
To perform certain procedures in this document, you must remove the system cover and work inside the system. While working inside the system, do not attempt to service the system except as explained in this guide and elsewhere in your system documentation.
CAUTION: Only trained service technicians are authorized to remove the system cover and access any of
the components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.

Start-Up Routine

Look and listen during the system's start-up routine for the indications described in Table 4-1.
Table 4-1. Start-Up Routine Indications
Look/listen for: Action
A code displayed on the system diagnostic indicators. See "Diagnostics Indicator Codes" on page 15.
An error message displayed on the monitor. See "System Messages" on page 17.
The monitor's power indicator. See "Troubleshooting the Video Subsystem" on
page 96.
The keyboard indicators. See "Troubleshooting the Keyboard" on page 97.
The diskette drive activity indicator. See "Troubleshooting a Diskette Drive" on page 105.
The CD drive activity indicator. See "Troubleshooting an Optical Drive" on page 106.
The hard-drive activity indicator. See "Troubleshooting a Hard Drive" on page 107.
An unfamiliar constant scraping or grinding sound when you access a drive.
See "Getting Help" on page 123.

Checking the Equipment

This section provides troubleshooting procedures for external devices attached to the system, such as the monitor, keyboard, or mouse. Before you perform any of the procedures, see "Troubleshooting External Connections" on page 96.
Troubleshooting Your System 95

Troubleshooting IRQ Assignment Conflicts

Most PCI devices can share an IRQ with another device, but they cannot use an IRQ simultaneously. To avoid this type of conflict, see the documentation for each PCI device for specific IRQ requirements. Table 4-2 lists the IRQ assignments.
Table 4-2. IRQ Assignment Defaults
IRQ Line Assignment
IRQ0 System timer
IRQ1 Keyboard controller
IRQ2 Interrupt controller 1 to enable IRQ8 through IRQ15
IRQ3 Available
IRQ4 Serial port (COM1 and COM3)
IRQ5 Parallel port
IRQ6 Diskette drive controller
IRQ7 Reserved
IRQ8 Real-time clock
IRQ9 ACPI functions (used for power management)
IRQ10 Available
IRQ11 Available
IRQ12 Mouse
IRQ13 Math coprocessor
IRQ14 IDE CD drive controller (available if disabled in System Setup program)
IRQ15 Reserved (available if IDE CD controller is disabled in System Setup program)

Troubleshooting External Connections

Loose or improperly connected cables are the most likely source of problems for the system, monitor, and other peripherals (such as a printer, keyboard, mouse, or other external device). Ensure that all external cables are securely attached to the external connectors on your system. See Figure 1-2 for the back-panel connectors on your system.

Troubleshooting the Video Subsystem

Problem
Monitor is not working properly.
Video memory is faulty.
96 Troubleshooting Your System
Action
1
Check the system and power connections to the monitor.
2
Determine whether the system has an expansion card with a video output connector.
In this system configuration, the monitor cable should normally be connected to the connector on the expansion card,
not
to the system’s integrated video connector.
To verify that the monitor is connected to the correct video connector, turn off the system and wait for 1 minute, then connect the monitor to the other video connector and turn the system on again.
3
Determine whether the system has monitors attached to both the front and rear video connectors.
The system supports only one monitor attached to either the front or rear video connector. When a monitor is connected to the front panel, the back-panel video is disabled.
If two monitors are attached to the system, disconnect one monitor. If the problem is not resolved, continue to the next step.
4
Run the appropriate online diagnostic test. See "Using Dell PowerEdge Diagnostics" on page 113.
If the tests run successfully, the problem is not related to video hardware.
If the tests fail, see "Getting Help" on page 123
.

Troubleshooting the Keyboard

Problem
System message indicates a problem with the keyboard.
Keyboard is not functioning properly.
Action
1
Enter the System Setup program and ensure that the USB ports are enabled. See "Using the System Setup Program" on page 27.
2
Examine the keyboard and its cable for signs of damage.
3
Swap the faulty keyboard with a working keyboard.
If the problem is resolved, replace the faulty keyboard. See "Getting Help" on page 123
Run the appropriate online diagnostic test. See "Using Dell PowerEdge Diagnostics" on page 113.
4
If the problem is not resolved, see "Getting Help" on page 123.
.
Troubleshooting Your System 97

Troubleshooting the Mouse

Problem
System message indicates a problem with the mouse.
Mouse is not functioning properly.
Action
1
Run the appropriate online diagnostic test. See "Using Dell PowerEdge Diagnostics" on page 113.
If the test fails, continue to the next step.
2
Examine the mouse and its cable for signs of damage.
If the mouse is not damaged, go to step 4.
If the mouse is damaged, continue to the next step.
3
Swap the faulty mouse with a working mouse.
See
If the problem is resolved, replace the faulty mouse.
Enter the System Setup program and ensure that the USB port is enabled. See "Using the System
4
Setup Program" on page 27.
If the problem is not resolved,
see
"Getting Help" on page 123
"Getting Help" on page 123
.
.

Troubleshooting Serial I/O Problems

Problem
Error message indicates a problem with a serial port.
Device connected to a serial port is not operating properly.
Action
1
Enter the System Setup program and ensure that the serial port is enabled and configured correctly for your application. See "Using the System Setup Program" on page 27.
2
If the problem is confined to a particular application, see the application documentation for specific port configuration requirements that the program may require.
3
Run the appropriate online diagnostic test. See "Using Dell PowerEdge Diagnostics" on page 113.
If the tests run successfully but the problem persists, see "Troubleshooting a Serial I/O Device" on page 99.
98 Troubleshooting Your System

Troubleshooting a Serial I/O Device

Problem
Device connected to the serial port is not operating properly.
Action
1
Turn off the system and any peripheral devices connected to the serial port.
2
Swap the serial interface cable with a working cable, and turn on the system and the serial device.
See
If the problem is resolved, replace the interface cable.
Turn off the system and the serial device, and swap the device with a comparable device.
3
4
Turn on the system and the serial device.
If the problem is resolved, replace the serial device.
"Getting Help" on page 123
See
"Getting Help" on page 123
.
.
If the problem persists,
see
"Getting Help" on page 123
.

Troubleshooting a USB Device

Problem
System message indicates a problem with a USB device.
Device connected to a USB port is not operating properly.
Action
1
Enter the System Setup program, and ensure that the USB ports are enabled. See "Using the System Setup Program" on page 27.
2
Turn off the system and any USB devices.
3
Disconnect the USB devices, and connect the malfunctioning device to the other USB connector.
4
Turn on the system and the reconnected device.
If the problem is resolved, the USB connector might be defective.
If possible, swap the interface cable with a working cable.
5
If the problem is resolved, replace the interface cable.
Turn off the system and the USB device, and swap the device with a comparable device.
6
7
Turn on the system and the USB device.
If the problem is resolved, replace the USB device.
See
"Getting Help" on page 123
See
"Getting Help" on page 123
See
"Getting Help" on page 123
.
.
.
If the problem persists,
see
"Getting Help" on page 123
.
Troubleshooting Your System 99

Troubleshooting a NIC

Problem
NIC cannot communicate with network.
Action
1
Run the appropriate online diagnostic test. See "Using Dell PowerEdge Diagnostics" on page 113.
2
Check the appropriate indicator on the NIC connector.
If the link indicator does not light, check all cable connections.
If the activity indicator does not light, the network driver files might be damaged or missing.
Remove and reinstall the drivers if applicable. See the NIC's documentation.
Change the autonegotiation setting, if possible.
Use another connector on the switch or hub.
If you are using a NIC card instead of an integrated NIC, see the documentation for the NIC card.
3
Ensure that the appropriate drivers are installed and the protocols are bound. See the NIC's documentation.
4
Enter the System Setup program and confirm that the NICs are enabled. See "Using the System Setup Program" on page 27.
5
Ensure that the NICs, hubs, and switches on the network are all set to the same data transmission speed. See the network equipment documentation.
6
Ensure that all network cables are of the proper type and do not exceed the maximum length.

Troubleshooting a Wet System

Problem
Liquid spilled on the system.
Excessive humidity.
Action
CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the
components inside the system. Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the computer and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 43.
3
Remove all expansion cards installed in the system. See "Removing an Expansion Card" on page 72.
100 Troubleshooting Your System
