DELL EMC NETWORKING S4048ON SWITCH

10/40GbE top-of-rack open networking switch

The Dell EMC Networking S4048-ON switch empowers organizations to
deploy workloads and applications designed for the open networking era.

Businesses who have made the transition away from monolithic
proprietary mainframe systems to industry standard server platforms can
now enjoy even greater benets from Dell open networking platforms.
Using industry-leading hardware and a choice of leading network
operating systems to simplify data center fabric orchestration and
automation, organizations can accelerate innovation by tailoring their
network to their unique requirements.

These new oerings provide the needed exibility to transform data
centers. High-capacity network fabrics that are cost-eective and easy
to deploy provide a clear path to a software-dened data center of the
future, as well as freedom from vendor lock-in.

The Dell EMC S4048-ON supports the open source Open Network Install
Environment (ONIE) for zero-touch installation of alternate network
operating systems including feature-rich Dell Networking OS.

Ultra-low-latency, data center optimized

The Dell EMC Networking S-Series S4048-ON is an ultra-low-latency
10/40GbE top-of-rack (ToR) switch built for applications in high­performance data center and computing environments. Leveraging a
non-blocking switching architecture, the S4048-ON delivers line-rate L2
and L3 forwarding capacity with ultra-low-latency to maximize network
performance. The compact S4048-ON design provides industry-leading
density of 48 dual-speed 1/10GbE (SFP+) ports as well as six 40GbE
QSFP+ uplinks to conserve valuable rack space and simplify the migration
to 40Gbps in the data center core (each 40GbE QSFP+ uplink can also
support four 10GbE ports with a breakout cable). In addition, the S4048­ON incorporates multiple architectural features that optimize data center
network exibility, eciency and availability, including I/O panel to PSU
airow or PSU to I/O panel airow for hot/cold aisle environments, and
redundant, hot-swappable power supplies and fans.

S4048-ON supports feature-rich Dell Networking OS, VLT, network
virtualization features such as VRF-lite, VXLAN Gateway and support for
Dell Embedded Open Automation Framework.

• The S4048-ON is the only switch in the industry that provides
customers an unbiased approach to Network Virtualization by
supporting both network-centric virtualization method (VRF-lite)
and Hypervisor centric virtualization method (VXLAN).

• The S4048-ON also supports Dell Networking’s Embedded
Open Automation Framework, which provides enhanced network
automation and virtualization capabilities for virtual data center
environments.

• The Open Automation Framework comprises a suite of interrelated
network management tools that can be used together or
independently to provide a network that is exible, available and
manageable while helping to reduce operational expenses.

Key applications

Dynamic data centers ready to make the transition to software-dened
environments

• Ultra-low-latency 10GbE switching in HPC, high-speed trading
or other business-sensitive deployments that require the highest
bandwidth and lowest latency

• High-density 10GbE ToR server access in high-performance data
center environments

When running the Dell Networking OS9, Active Fabric™ implementation
for large deployments in conjunction with the Dell EMC Z-Series, creating
a at, two-tier, nonblocking 10/40GbE data center network design:

• High-performance SDN/OpenFlow 1.3 enabled with ability to inter­operate with industry standard OpenFlow controllers

• As a high speed VXLAN Layer 2 Gateway that connects the
hypervisor based ovelray networks with nonvirtualized infrastructure

When running the Dell Networking OS9, Active Fabric™ implementation
for large deployments in conjunction with the Dell Z Series, creating a at,
two-tier, nonblocking 10/40GbE data center network design

• Small-scale Active Fabric implementation via the S4048-ON switch
in leaf and spine along with S-Series 1/10GbE ToR switches enabling
cost-eective aggregation of 10/40GbE uplinks

• iSCSI storage deployment including DCB converged lossless
transactions

• High-performance SDN/OpenFlow 1.3 enabled with ability to inter­operate with industry standard OpenFlow controllers

• As a high speed VXLAN Layer 2 Gateway that connects
the hypervisor based ovelray networks with non-virtualized
infrastructure

Key features - general

• 48 dual-speed 1/10GbE (SFP+) ports and six 40GbE (QSFP+)
uplinks (totaling 72 10GbE ports with breakout cables) with OS
support

• 1.44Tbps (full-duplex) non-blocking switching fabric delivers line-rate
performance under full load with sub 600ns latency

• I/O panel to PSU airow or PSU to I/O panel airow

• Supports the open source ONIE for zero-touch

• Installation of alternate network operating systems

• Redundant, hot-swappable power supplies and fans

• Low power consumption

• Support for multi-tenancy lilke VXLAN and NVGRE in hardware

Key features with Dell EMC Networking OS9

Scalable L2 and L3 Ethernet switching with QoS and a full complement of
standards-based IPv4 and IPv6 features, including OSPF, BGP and PBR
(Policy Based Routing) support

• VRF-lite enables sharing of networking infrastructure and provides L3
trac isolation across tenants

• Increase VM Mobility region by stretching L2 VLAN within or across two
DCs with unique VLT capabilities like Routed VLT, VLT Proxy Gateway

• VXLAN gateway functionality support for bridging the nonvirtualized
and the virtualized overlay networks with line rate performance.

• Embedded Open Automation Framework adding automated
conguration and provisioning capabilities to simplify the management
of network environments. Supports Puppet agent for DevOps

• Modular Dell Networking OS software delivers inherent stability as well
as enhanced monitoring and serviceability functions.

Product Description

S4048, 48x 10GbE SFP+, 6x QSFP+, 1x AC PSU, 2x Fans, I/O Panel to PSU Airow

S4048-ON

Redundant power supplies

Fans

Optics

Cables

Supported operating systems

S4048, 48x 10GbE SFP+, 6x QSFP+, 1x AC PSU, 2x Fans, PSU to I/O Panel Airow
S4048, 48x 10GbE SFP+, 6x QSFP+, 2xDC PSU, 3x Fans, PSU to I/O Panel Airow - NEBS Certied

S4048, AC Power Supply, I/O Panel to PSU Airow
S4048, AC Power Supply, PSU to I/O Panel Airow
S4048, DC Power Supply, I/O Panel to PSU Airow
S4048, DC Power Supply, PSU to I/O Panel Airow

S4048 Fan Module, I/O Panel to PSU Airow
S4048 Fan Module, PSU to I/O Panel Airow

Transceiver, 40GbE, SR QSFP+, short reach
Transceiver, 40GbE, ESR QSFP+, extended short reach
Transceiver, 40GbE, LM4 QSFP+, universal duplex short reach
Transceiver, 40GbE, SM4 QSFP+, duplex short reach
Transceiver, 40GbE PSM4 QSFP+, parallel single mode long reach 1m, 5m, 15m tail
Transceiver, 40GbE, PSM4-LR QSFP+, MPO to 4x SFP+ long reach
Transceiver, 40GbE LR4 QSFP+, long reach
Transceiver, 40GbE QSFP+ to SFP+/SFP Adapter (QSA)
Transceiver, 10GbE, SR SFP+, short reach
Transceiver, 10GbE, LR SFP+, long reach
Transceiver, 10GbE, ER SFP+, extended reach
Transceiver, 10GbE, ZR SFP+ extra extended reach
Transceiver, 1GbE, SX SFP, short reach
Transceiver, 1GbE, LX SFP, long reach
Transceiver, 1GbE, ZX SFP, extended reach
Transceiver, 1GbE, 1000Base-T SFP, copper

Optical Cable 40/100GbE, MTP Fiber Cables in 3, 5, 7, 10, 25, 50, 75, 100 meter
Optical Cable 40GbE, QSFP+, AOC 10, 50 meter
Optical Cable 40GbE, Breakout QSFP+ to 4xSFP+, Fiber Cables in 10 and 30 meter
Cable 10GbE, SFP+, AOC 2, 3, 5, 7, 10, 15, 20 meter*
40GbE, QSFP+ to QSFP+, passive DAC 0.5, 1, 3, 5, 7, meters
40GbE, QSFP+, Breakout QSFP+ to 4x10GbE, passive DAC 0.5, 1, 3, 5, 7 meters
40GbE, QSFP+, Breakout QSFP+ to 4x1000base-T, passive DAC 1 meter
10GbE, SFP+ to SFP+, passive DAC 0.5, 1, 3, 5, 7 meters

Cumulus Linux OS
Big Switch Networks Switch Light OS
Dell Networking Operating System v9
Pluribus OS

• Enhanced mirroring capabilities including 1:4 local mirroring, Remote Port
Mirroring (RPM), and Encapsulated Remote Port Mirroring (ERPM).
Rate shaping combined with ow based mirroring enables the user to
analyze ne grained ows

• Jumbo frame support for large data transfers

• 128 link aggregation groups with up to 16 members per group, using
enhanced hashing

• Converged network support for DCB, with priority ow control
(802.1Qbb), ETS (802.1Qaz), DCBx and iSCSI TLV support Fastboot
feature enables min-loss software upgrade on a standalone S4048-ON
without VLT/stacking

• S4048-ON supports Routable RoCE to enable convergence of compute
and storage on Active Fabric

• User port stacking support for up to six units and a total stack
bandwidth of up to 320Gbps bandwidth

2 © 2016 Dell Inc. All Rights Reserved.

Technical specications

Physical

48 10 Gigabit Ethernet SFP+ ports

6 40 Gigabit Ethernet QSFP+ ports
1 RJ45 console/management port with RS232
signaling
1 USB 2.0 type A to support mass storage device
1 Micro-USB 2.0 type B Serial Console Port
Size: 1RU, 1.71 x 17.09 x 17.13” (4.35 x 43.4 x 43.5cm (H x W x D)
Weight: 18.52 lbs (8.4kg)
ISO 7779 A-weighted sound pressure level: 59.6 dBA at

73.4°F (23°C)
Power supply: 100–240V AC 50/60Hz
DC Power supply: -40.5V ~ -60V
Max. thermal output: 799.64 BTU/h
Max. current draw per system:

2.344A/1953A at 100/120V AC,

1.145A/0.954A at 200/240V AC

Max. DC current : -40.5V/23.8A , -48V/19A ,

-60V/15.6A.
Max. power consumption: 234.35 Watts (AC),
800 Watts (DC)
Typical power consumption: 153 Watts
Max. operating specications:

Operating temperature: 32°F to 113°F (0°C to
45°C)
Operating humidity: 10 to 85% (RH), non-
condensing
Max. non-operating specications:

Storage temperature: –40°F to 158°F (–40°C to
70°C)

Storage humidity: 5 to 95% (RH), non-
condensing
Redundancy
Hot swappable redundant power

Hot swappable redundant fans
Performance general
Switch fabric capacity:

1.44Tbps (full-duplex)
720Gbps (half-duplex)
Forwarding Capacity: 1080 Mpps
Latency: Sub 600ns
Packet buer memory: 12MB
CPU memory: 4GB
OS9 Performance:

MAC addresses: 160K
ARP table 128K
IPv4 routes: 128K
IPv6 hosts: 64K
IPv6 routes: 64K
Multicast hosts: 8K
Link aggregation: 16 links per group, 128 groups
Layer 2 VLANs: 4K
MSTP: 64 instances
VRF-Lite: 511 instances
LAG load balancing: Based on layer 2, IPv4 or IPv6
headers
Latency: Sub 600ns
QOS data queues: 8
QOS control queues: 12

QOS: Default 768 entries scalable to 2.5K
Ingress ACL: 2.5K
Egress ACL: 1K

IEEE compliance with Dell Networking OS9

802.1AB LLDP

802.1D Bridging, STP

802.1p L2 Prioritization

802.1Q VLAN Tagging, Double VLAN Tagging, GVRP

802.1Qbb PFC

802.1Qaz ETS

802.1s MSTP

802.1w RSTP

802.1X Network Access Control

802.3ab Gigabit Ethernet (1000BASE-T) with QSA or
breakout

802.3ac Frame Extensions for VLAN Tagging

802.3ad Link Aggregation with LACP

802.3ae 10 Gigabit Ethernet (10GBase-X) with QSA

802.3ba 40 Gigabit Ethernet (40GBase-SR4,
40GBase-CR4,40GBase-LR4) on optical ports

802.3u Fast Ethernet (100Base-TX) on mgmt ports

802.3x Flow Control

802.3z Gigabit Ethernet (1000Base-X) with QSA
ANSI/TIA-1057 LLDP-MED
Force10 PVST+
MTU 12,000 bytes

RFC and I-D compliance with Dell Networking
OS9

General Internet protocols

768 UDP
793 TCP
854 Telnet
959 FTP

General IPv4 protocols

791 IPv4
792 ICMP
826 ARP
1027 Proxy ARP
1035 DNS (client)
1042 Ethernet Transmission
1305 NTPv3
1519 CIDR
1542 BOOTP (relay)
1812 Requirements for IPv4 Routers
1918 Address Allocation for Private Internets
2474 Diserv Field in IPv4 and Ipv6 Headers
2596 Assured Forwarding PHB Group
3164 BSD Syslog
3195 Reliable Delivery for Syslog
3246 Expedited Assured Forwarding
4364 VRF-lite (IPv4 VRF with OSPF, BGP, IS-IS and V4
multicast)
5798 VRRP

General IPv6 protocols

1981 Path MTU Discovery Features
2460 Internet Protocol, Version 6 (IPv6)
Specication

2464 Transmission of IPv6 Packets over Ethernet
Networks
2711 IPv6 Router Alert Option
4007 IPv6 Scoped Address Architecture
4213 Basic Transition Mechanisms for IPv6 Hosts and Routers
4291 IPv6 Addressing Architecture
4443 ICMP for IPv6
4861 Neighbor Discovery for IPv6
4862 IPv6 Stateless Address Autoconguration
5095 Deprecation of Type 0 Routing Headers in IPv6
IPv6 Management support (telnet, FTP, TACACS,
RADIUS, SSH, NTP)
VRF-Lite (IPv6 VRF with OSPFv3, BGPv6, IS-IS)

RIP

1058 RIPv1 2453 RIPv2
OSPF (v2/v3)
1587 NSSA 4552 Authentication/
2154 OSPF Digital Signatures Condentiality for
2328 OSPFv2 OSPFv3
2370 Opaque LSA 5340 OSPF for IPv6

IS-IS

5301 Dynamic hostname exchange mechanism for
IS-IS
5302 Domain-wide prex distribution with two-level IS-IS
5303 Three way handshake for IS-IS point-to-point
adjacencies
5308 IS-IS for IPv6

BGP

1997 Communities
2385 MD5
2545 BGP-4 Multiprotocol Extensions for IPv6 Inter-Domain
Routing
2439 Route Flap Damping
2796 Route Reection
2842 Capabilities
2858 Multiprotocol Extensions
2918 Route Refresh
3065 Confederations
4360 Extended Communities
4893 4-byte ASN
5396 4-byte ASN representations
draft-ietf-idr-bgp4-20 BGPv4
draft-michaelson-4byte-as-representation-05
4-byte ASN Representation (partial)
draft-ietf-idr-add-paths-04.txt ADD PATH
Multicast
1112 IGMPv1
2236 IGMPv2
3376 IGMPv3
MSDP

Security

2404 The Use of HMACSHA- 1-96 within ESP and
AH
2865 RADIUS
3162 Radius and IPv6
3579 Radius support for EAP
3580 802.1X with RADIUS
3768 EAP
3826 AES Cipher Algorithm in the SNMP User Base
Security Model

3 © 2016 Dell Inc. All Rights Reserved.

4250, 4251, 4252, 4253, 4254 SSHv2
4301 Security Architecture for IPSec
4302 IPSec Authentication Header
4303 ESP Protocol
4807 IPsecv Security Policy DB MIB
draft-ietf-pim-sm-v2-new-05 PIM-SMw
Data center bridging

802.1Qbb Priority-Based Flow Control

802.1Qaz Enhanced Transmission Selection (ETS)
Data Center Bridging eXchange (DCBx)
DCBx Application TLV (iSCSI, FCoE)

Network management

1155 SMIv1
1157 SNMPv1
1212 Concise MIB Denitions
1215 SNMP Traps
1493 Bridges MIB
1850 OSPFv2 MIB
1901 Community-Based SNMPv2
2011 IP MIB
2096 IP Forwarding Table MIB
2578 SMIv2
2579 Textual Conventions for SMIv2
2580 Conformance Statements for SMIv2
2618 RADIUS Authentication MIB
2665 Ethernet-Like Interfaces MIB
2674 Extended Bridge MIB
2787 VRRP MIB
2819 RMON MIB (groups 1, 2, 3, 9)
2863 Interfaces MIB
3273 RMON High Capacity MIB
3410 SNMPv3
3411 SNMPv3 Management Framework
3412 Message Processing and Dispatching for the
Simple Network Management Protocol (SNMP)
3413 SNMP Applications
3414 User-based Security Model (USM) for
SNMPv3
3415 VACM for SNMP
3416 SNMPv2
3417 Transport mappings for SNMP
3418 SNMP MIB
3434 RMON High Capacity Alarm MIB
3584 Coexistance between SNMP v1, v2 and v3
4022 IP MIB
4087 IP Tunnel MIB
4113 UDP MIB
4133 Entity MIB
4292 MIB for IP
4293 MIB for IPv6 Textual Conventions
4502 RMONv2 (groups 1,2,3,9)
5060 PIM MIB
ANSI/TIA-1057 LLDP-MED MIB
Dell_ITA.Rev_1_1 MIB
draft-grant-tacacs-02 TACACS+

draft-ietf-idr-bgp4-mib-06 BGP MIBv1
IEEE 802.1AB LLDP MIB
IEEE 802.1AB LLDP DOT1 MIB
IEEE 802.1AB LLDP DOT3 MIB
sFlow.org sFlowv5
sFlow.org sFlowv5 MIB (version 1.3)
FORCE10-BGP4-V2-MIB Force10 BGP MIB
(draft-ietf-idr-bgp4-mibv2-05)
FORCE10-IF-EXTENSION-MIB
FORCE10-LINKAGG-MIB
FORCE10-COPY-CONFIG-MIB
FORCE10-PRODUCTS-MIB
FORCE10-SS-CHASSIS-MIB
FORCE10-SMI
FORCE10-TC-MIB
FORCE10-TRAP-ALARM-MIB
FORCE10-FORWARDINGPLANE-STATS-MIB

Regulatory compliance

Safety

UL/CSA 60950-1, Second Edition
EN 60950-1, Second Edition
IEC 60950-1, Second Edition Including All National
Deviations and Group Dierences
EN 60825-1 Safety of Laser Products Part 1:
Equipment Classication Requirements and User’s
Guide
EN 60825-2 Safety of Laser Products Part 2: Safety
of Optical Fibre Communication Systems
FDA Regulation 21 CFR 1040.10 and 1040.11

Emissions

Australia/New Zealand: AS/NZS CISPR 22: 2009,
Class A
Canada: ICES-003, Issue-4, Class A
Europe: EN 55022: 2006+A1:2007 (CISPR 22: 2006),
Class A
Japan: VCCI V3/2009 Class A
USA: FCC CFR 47 Part 15, Subpart B:2009, Class A

Immunity

EN 300 386 V1.4.1:2008 EMC for Network
Equipment
EN 55024: 1998 + A1: 2001 + A2: 2003
EN 61000-3-2: Harmonic Current Emissions
EN 61000-3-3: Voltage Fluctuations and Flicker
EN 61000-4-2: ESD
EN 61000-4-3: Radiated Immunity
EN 61000-4-4: EFT
EN 61000-4-5: Surge
EN 61000-4-6: Low Frequency Conducted Immunity

RoHS

All S-Series components are EU RoHS compliant.

Certications

Japan: VCCI V3/2009 Class A
USA: FCC CFR 47 Part 15, Subpart B:2009, Class A

Warranty

1 Year Return to Depot

IT Lifecycle Services
for Networking

Experts, insights and ease

Our highly trained experts, with
innovative tools and proven processes,
help you transform your IT investments
into strategic advantages.

Plan & Design

Let us analyze your
multivendor environment
and deliver a comprehensive
report and action plan to build
upon the existing network and
improve performance.

Deploy & Integrate

Get new wired or wireless
network technology installed
and congured with ProDeploy.
Reduce costs, save time, and
get up and running fast.

Educate

Ensure your sta builds the
right skills for long-term
success. Get certied on Dell
EMC Networking technology
and learn how to increase
performance and optimize
infrastructure.

Manage & Support

Gain access to technical experts
and quickly resolve multivendor
networking challenges with
ProSupport. Spend less time
resolving network issues and
more time innovating.

Optimize

Maximize performance for
dynamic IT environments with
Dell EMC Optimize. Benet
from in-depth predictive
analysis, remote monitoring
and a dedicated systems
analyst for your network.

Retire

We can help you resell or retire
excess hardware while meeting
local regulatory guidelines and
acting in an environmentally
responsible way.

Learn more at

Dell.com/lifecycleservices

Learn more at Dell.com/Networking

© 2017 Dell Inc. All rights reserved. Dell, the DELL logo and the DELL badge are trademarks of Dell Inc. Other trademarks and trade names may

4 © 2016 Dell Inc. All Rights Reserved.

be used in this document to refer to either the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the
marks and names of others. This document is for informational purposes only. Dell reserves the right to make changes without further notice to the
products herein. The content provided is as-is and without expressed or implied warranties of any kind. Additional features may be supported and not
listed. For a detailed list, please contact your Dell EMC representative.

March 2017| v1.9
Dell EMC Networking S4048-ON Spec Sheet
