STB90NF3LL

N-CHANNEL 30V - 0.0048 Ω - 80A D2PAK

LOW GATE CHARGE STripFET™ II POWER MOSFET

PRELIMINARY DATA

TYPE

V

DSS

STB90NF3LL 30 V < 0.0055

■ TYPICAL R

■ OPTIMAL R

■ CONDUCTION LOSSES REDUCED

■ SWITCHING LOSSES REDUCED

■ SURFACE-MOUNTING D

(on) = 0.0048 Ω @ 10 V

DS

x Qg TRADE-OFF @ 4.5 V

DS(on)

R

DS(on)

Ω

2

PAK (TO-263)

I

D

80 A(#)

POWER PACKAG E IN TU BE (NO SU FFIX) OR

IN TAPE & REEL (SUFFIX “T4”)

DESCRIPTION

This application specific Power MOSFET is the third
genaration of STMicro electronis unique "Single Feature

Size™" strip-based process. The resulting transistor
shows the best trade-off between on-resistance and gate
charge. When used as high and low side in buck
regulators, it gives the be st perfor manc e in terms of both
conduction and switching losses. This is extremely
important for motherboards where fast switching and
high efficiency are of paramount importance.

APPLICATIONS

■ SPECIFICALL Y D ESIGNED AND OP TIMISED

FOR HIGH EFFICIENCY CPU CORE DC/DC
CONVERTERS

3

1

D2PAK

TO-263

(Suffix “T4”)

INTERNAL SCHEMATIC DIAGRAM

ABSOLUTE MAXIMUM RATINGS

Symbol Parameter Value Unit

V

DS

V

DGR

V

GS

(#) Drain Current (continuous) at TC = 25°C

I

D

I

D

(

I

DM

P

tot

T

stg

T

j

Pulse wi dth limited by saf e operating area.

(•)

September 2002

This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to change without notice.

Drain-source Voltage (VGS = 0)
Drain-gate Voltage (RGS = 20 kΩ)

30 V
30 V

Gate- source Voltage ± 16 V

80 A

Drain Current (continuous) at TC = 100°C

•)

Drain Current (pulsed) 320 A
Total Dissipation at TC = 25°C

80 A

200 W
Derating Factor 1.3 W/°C
Storage Temperature
Max. Operating Junction Temperature

-55 to 175 °C

(#) Value limited by wire bonding

1/7

STB90NF3LL

THERMA L D ATA

Rthj-case

Rthj-amb

T

Thermal Resistance Junction-case
Thermal Resistance Junction-ambient
Maximum Lead Temperature For Soldering Purpose

l

Max
Max

0.75

62.5
300

°C/W
°C/W

°C

ELECTRICAL CHARACTERISTICS (T

= 25 °C UNLESS OTHERWISE SPECIFIED)

CASE

OFF

Symbol Parameter Test Conditions Min. Typ. Max. Unit

= 250 µA, VGS = 0

V

(BR)DSS

Drain-source

I

D

30 V

Breakdown Voltage

= Max Rating

V

DS

V

= Max Rating TC = 125°C

DS

V

= ± 16 V

GS

1

10

±100 nA

ON

(*)

I

DSS

I

GSS

Zero Gate Voltage
Drain Current (V

GS

Gate-body Leakage
Current (V

DS

= 0)

= 0)

Symbol Parameter Test Conditions Min. Typ. Max. Unit

V

V

GS(th)

R

DS(on)

Gate Threshold Voltage
Static Drain-source On

Resistance

= VGS I

DS

= 10 V ID = 40 A

V

GS

V

= 4.5 V ID = 40 A

GS

= 250 µA

D

1V

0.0048

0.0070

0.0055

0.0090

DYNAMIC

Symbol Parameter Test Conditions Min. Typ. Max. Unit

(*)

g

fs

C

iss

C

oss

C

rss

Forward Transconductance
Input Capacitance

Output Capacitance
Reverse Transfer
Capacitance

V

= 15 V ID= 40 A

DS

= 25V f = 1 MHz VGS = 0

V

DS

TBD S

3000

950
190

µA
µA

Ω
Ω

pF
pF
pF

2/7

STB90NF3LL

ELECTRICAL CHARACTERISTICS (continued)
SWITCHING ON

Symbol Parameter Test Conditions Min. Typ. Max. Unit

= 15 V ID = 40 A

t

d(on)

Turn-on Delay Time

t

r

Rise Time

V

DD

R

= 4.7 Ω VGS = 4.5 V

G

(Resistive Load, Figure 3)

Q

g

Q

gs

Q

gd

Total Gate Charge
Gate-Source Charge
Gate-Drain Charge

= 24 V ID= 80 A VGS= 5 V

V

DD

SWITCHING OFF

Symbol Parameter Test Conditions Min. Typ. Max. Unit

= 15 V ID = 40 A

t

d(off)

Turn-off Delay Time

t

f

Fall Time

V

DD

R

= 4.7Ω, V

G

GS

= 4.5 V

(Resistive Load, Figure 3)

SOURCE DRAIN DIODE

Symbol Parameter Test Conditions Min. Typ. Max. Unit

I

SD

I

SDM

V

SD

t

rr

Q

rr

I

RRM

(*)

Pulsed: P ul se duration = 300 µs, duty cycle 1.5 %.

(

Pulse widt h l i m i ted by safe operating area.

•)

Source-drain Current

(•)

Source-drain Current (pulsed)

(*)

Forward On Voltage
Reverse Recovery Time

Reverse Recovery Charge
Reverse Recovery Current

I

= 80 A VGS = 0

SD

= 80 A di/dt = 100A/µs

I

SD

V

= 10 V Tj = 150°C

DD

(see test circuit, Figure 5)

30

225

39
14
21

37
24

55

115

3.5

51 nC

80

320

1.3 V

ns
ns

nC
nC

ns
ns

A
A

ns

nC

A

3/7

STB90NF3LL

Fig. 1: Unclamped Inductive Load Test CircuitFig. 1: Unclamped Inductive Load Test Circuit Fig. 2: Unclamped Inductive Waveform

Fig. 3: Switching Times Test Circuits For Resistive

Load

Fig. 5: Test Circuit For Inductive Load Switching
And Diode Recovery Times

Fig. 4: Gate Charge test Circuit

4/7

STB90NF3LL

D2PAK MECHANICAL DATA

DIM.

A 4.4 4.6 0.173 0.181
A1 2.49 2.69 0.098
A2 0.03 0.23 0.001 0.009

B 0.7 0.93 0.028 0.037
B2 1.14 1.7 0.045 0.067

C 0.45 0.6 0.018 0.024
C2 1.21 1.36 0.048 0.054

D 8.95 9.35 0.352 0.368
D1 8 0.315

E 10 10.4 0.394 0.409
E1 8.5 0.334

G 4.88 5.28 0.192 0.208

L 15 15.85 0.591 0.624
L2 1.27 1.4 0.050 0.055
L3 1.4 1.75 0.055 0.069

M 2.4 3.2 0.094 0.126

R 0.4 0.015

V2 0° 8° 0° 8°

MIN. TYP. MAX. MIN. TYP. TYP.

mm. inch.

0.106

5/7

STB90NF3LL

D2PAK FOOTPRINT

TAPE AND REEL SHIPMENT (suffix ”T4”)*

TUBE SHIPMENT (no suffix)*

REEL MECHANICAL DATA

DIM.

A 330 12.992
B 1.5 0.059
C 12.8 13.2 0.504 0.520
D 20.2 0.795
G 24.4 26.4 0.960 1.039
N 100 3.937

T 30.4 1.197

mm inch

MIN. MAX. MIN. MAX.

TAPE MECHANICAL DATA

DIM.

A0 10.5 10.7 0.413 0.421
B0 15.7 15.9 0.618 0.626

D 1.5 1.6 0.059 0.063

D1 1.59 1.61 0.062 0.063

E 1.65 1.85 0.065 0.073

F 11.4 11.6 0.449 0.456
K0 4.8 5.0 0.189 0.197
P0 3.9 4.1 0.153 0.161
P1 11.9 12.1 0.468 0.476
P2 1.9 2.1 0075 0.082

R50 1.574

T0.25 0.35 .0.0098 0.0137

W 23.7 24.3 0.933 0.956

mm inch

MIN. MAX. MIN. MAX.

* on sales type

6/7

BASE QTY BULK QTY

1000 1000

STB90NF3LL
