TOUCH™ TD1100
GENERAL PURPOSE CORDED HANDHELD
CONTACT LINEAR IMAGER BAR CODE
READER
The Touch™ TD1100 series of linear imaging contact readers
represent the Datalogic ADC solution for customers who
require a cost-eective solution for close contact bar code
reading without sacricing quality and performance.
Designed for low throughput applications within multiple
markets, the Touch TD1100 readers provide the guarantee
of contact reading with an excellent reading performance on
virtually all linear bar codes, including damaged or poorly
printed codes.
Small, lightweight and low on energy consumption, the Touch
TD1100 readers continue to provide robustness and a 1.5 m /
5.0 ft drop resistance, which is typically included in a higher
range of products.
The Touch readers are available with the option of two
dierent sizes of reading windows: 6.5 cm / 2.6 in (Touch 65)
or 9.0 cm / 3.5 in (Touch 90), which benets the user when
reading standard or wide bar codes.
An innovative ‘read-thru’ holder provides
the Touch TD1100 readers with hands-free
reading capability on documents or small
items.
Datalogic’s Aladdin™ conguration software
provides user-friendly features that
simplify the start-up procedure, even for
inexperienced users.
The Touch series is available in a black model
only, however, additional custom color
options are available for a minimum order
quantity.
FEATURES
• Wide reading windows: 6.5 cm / 2.6 in
and 9.0 cm / 3.5 in
• Excellent reading performance on
damaged or poorly printed bar codes
• Interface options: USB or Keyboard Wedge /
RS-232 (Touch 65/90 Lite);
USB / RS-232 / Keyboard Wedge / Wand
Emulation (Touch 65/90 Pro)
• Supports GS1 DataBar™ linear codes
• Compact and innovative ‘read-thru’
holder for hands-free reading capability
• Drop Resistance to 1.5 m / 5.0 ft
The Touch TD1100 65/90 Pro readers provide a complete
all-in-one multi-interface solution, including RS-232, USB,
Keyboard Wedge and Wand Emulation, while the Touch
65/90 Lite readers provide USB or RS-232/Keyboard Wedge
interfaces.
www.adc.datalogic.com
SPECIFICATIONS
TOUCH™ TD1100
DECODING CAPABILITY
1D / LINEAR COD ES Autodisc riminates all st andard 1D codes includ ing GS1
DataBar™ linear codes.
STACKED CO DES GS1 DataBar E xpanded Stacked; G S1 DataB ar Stacked;
GS1 DataBar Stacked Omnidirectional
ELECTRICAL
CURRENT Operati ng (Typical): < 100 mA @ 5 VDC
Standby/Idl e (Typical): 20 mA @ 5 VDC
INPUT VO LTAGE 5 VDC +/- 0.5 V
ENVIRONMENTAL
AMBIENT LIGHT 0 - 20,000 lux
DROP RE SISTANCE Withst ands repeated dro ps from 1.5 m / 5.0 ft onto a
concrete surfa ce
ESD PROTECTION AIR DISCHARGE 16 kV
HUMIDITY NONCONDENSING 5 - 95%
PARTICU LATE AND WATER SEALI NG IP30
TEMPERATURE Operati ng: 0 to 50 °C / 32 to 122 °F
Storage/ Transport: -20 to 70 °C / -4 to 158 °F
INTERFACES
INTERFACES RS-232 / Keyboar d Wedge: Touch 65/90 Lite
RS-232 / USB / Keyboar d Wedge / Wand E mulati on Multi-
Interf ace: Touch 65/90 Pro
USB: Touch 65/90 Lite
PHYSICAL CHARACTERISTICS
COLO RS AVAILA BLE Black; O ther colors and cu stom logo option s are available
for minimum quantity purchase.
DIMENSIONS 65 Pro & Lite: 16.0 x 8.4 x 5.8 cm / 6.3 x 3.3 x 2.3 in
90 Pro & LIte: 17.0 x 10.4 x 6.7 cm / 6.7 x 4.1 x 2.7 in
WEIGHT 65 Pro & Lite: 130.0 g / 4.6 oz
90 Pro & LIte: 153.0 g / 5.4 oz
READING RANGES
TYP ICAL DEPTH O F FIELD Minimum di stance determin ed by symbol leng th and scan
angle.
Printing resolution, contrast, and ambient light
dependent.
Code 39: 7.5 mils: 0 to 8.1 cm / 0 to 3.2 in
Code 39: 10 mils: 0 to 12.0 cm / 0 to 4.7 in
EAN13: 13 mils: 0 to 15.0 cm / 0 to 6.0 in
SAFETY & REGULATORY
AGENCY APPROVALS The produ ct meets nece ssary safet y and regulator y
approval s for its intended u se.
The Quick R eference Guide f or this product c an be referred
to for a comp lete list of certi cations.
ENVIRONMENTAL COMPLIANCE Compli es to China RoHS; Complie s to EU RoHS
UTILITIES
DATALOGIC ALADDIN™ Datalogic Aladdin conguration program is available for
download a t no charge.
OPO S / JAVAPOS JavaPOS Ut ilities are availab le for download at no c harge.
OPOS Utili ties are available f or download at no cha rge.
REMOT E HOST DOWNLOAD Lowers service costs and improves operations.
WARRANTY
WARRANTY 5-Year Factory Warrant y
READING PERFORMANCE
LIGHT SOURCE Illuminat ion: 640 nm LED
PRINT CO NTRAST RATIO MINI MUM 25%
READ AN GLE Pitch: +/- 65º; Roll (Til t): +/- 45º; Skew (Yaw): +/- 70º
READI NG INDICATOR S Beeper (Ad justable Tone); Good Read LED
RESOLUTION MAXIMUM 0.102 mm / 4 mil
ACCESSORIES
Mounts/Stands
• HLD-T010- 65 Desk/Wal l Holder for Touch 6 5
• HLD-T010-9 0 Desk/Wall H older for Touch 9 0
© 2012 Datalog ic ADC, Inc. • All r ights res erved. • Pro tected to the f ullest ex tent under U. S. and interna tional laws. • C opying or alt ering of this d ocument is p rohibite d without ex press writ ten consen t from Datal ogic
ADC, Inc . • Datalogic a nd the Datalo gic logo are r egistere d trademark s of Datalog ic S.p.A. in ma ny countrie s, includin g the U.S. and the E .U. • The Datalog ic Automatic D ata Capture l ogo is a trade mark of Datal ogic S.p.A. •
Datalo gic Aladdin a nd Touch are tra demarks of D atalogic AD C Group, S.r.l. • All o ther brand a nd produc t names are tr ademarks o f their resp ective own ers. Produ ct speci cations ar e subject to c hange with out notice.
DS-TOUCHTD1100-ENA4 20121106
