DVD Recorder
			DR-4705B
			Instruction Manual

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` i mac001 1200DPI 90LPI

Safetyty InstructionsI t ti

Please keep the DVD Recorder’s guarantee sheet and receipt in a safe place.

Precautions

• Read this booklet carefully.

• Make sure the rating of your household electricity supply matches that shown on the back of your DVD Recorder.

• Read this page and chapter ‘Setting up your DVD Recorder’ to help you set up and adjust your product correctly.

• Do not put the DVD Recorder in a hot or humid place.

• Do not open the DVD Recorder. Get a qualified technician to carry out any repairs.

• Do not connect the DVD Recorder to the power supply if you have just moved it from a cold environment to a warm room. This can lead to condensation inside the DVD Recorder, which can damage it. Wait for approx. 2 hrs for it to reach room temperature.

• Make sure the DVD Recorder is placed at least 10 cm apart from other home appliances or obstacles to ensure sufficient ventilation.

• The apparatus should not be exposed to dripping or splashing and no objects filled with liquids, such as vases should be placed on top of the recorder.

•Before a storm and/or lightning, unplug the DVD Recorder from the mains supply and aerial.

•Put the recorder on a steady flat surface.

•Only clean the recorder with a soft, lint-free cloth. Do not use harsh or

alcoholbased cleaning agents.

INTRODUCTION

For your own Safety

•There are no components in this product you can service or repair yourself.

•Do not open the case of the DVD Recorder. Only allow a qualified engineer to repair or service your DVD Recorder.

•This DVD Recorder is designed to work continuously. Switching it off (standby mode) does not disconnect it from the mains. To disconnect it from the mains you have to unplug it.

i

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` ii mac001 1200DPI 90LPI

ImportantI t t Safeguards

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated ‘dangerous voltage‘ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance.

WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

IMPORTANT FOR LASER PRODUCTS

LASER This Digital Video Disc Player employs a Laser System. To ensure proper use of this product please read this owner’s manual carefully and retain for future reference. Should the unit require maintenance, contact an authorized service location - see service procedure.

Use of control adjustments or the performance of procedures other than those specified may result in hazardous radiation exposure.

To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible laser radiation when open and interlocks defeated.

DO NOT STARE INTO THE BEAM.

DANGER Visible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam.

CAUTION Do not open the top cover. There are no user serviceable parts inside the Unit; leave all servicing to qualified service personnel.

CLASS 1

LASER PRODUCT

CAUTION Any changes or modification in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

•Make sure the unit should be placed at least 8cm apart from the other home appliances or the obstacles to get sufficient ventilation.

•This unit shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on this unit.

•Switching it off does not disconnect it from the mains (stand-by). To disconnect it from the mains, you have to unplug it.

ii

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` iii mac001 1200DPI 90LPI

Important Safeguards

This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user.

1READ INSTRUCTIONS

All the safety and operating instructions should be read before the unit is operated.

2RETAIN INSTRUCTIONS

The safety and operating instructions should be retained for future reference.

3HEED WARNINGS

All warnings on the unit and in the operating instructions should be adhered to.

4FOLLOW INSTRUCTIONS

All operating and use instructions should be followed.

5CLEANING

Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

6ATTACHMENTS

Do not use attachments unless recommended by the unit’s manufacturer as they may cause hazards.

7WATER AND MOISTURE

Do not use this unit near waterfor example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool.

8ACCESSORIES

Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury to a child or adult as well as serious damage to the unit. Use this unit only with a cart, stand , tripod, bracket, or table recommended by the manufacturer.

8A A unit and cart combination	PORTABLE CART WARNING
should be moved with care.	(symbol provided by RETAC)
Quick stops, excessive force,
and uneven surfaces may
cause the product and cart
combination to overturn.

9VENTILATION

Slots and openings in the case are provided for

ventilation to ensure reliable operation of the unit and to protect it from overheating. These openings must not be blocked or covered. These openings must not be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat radiator. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10POWER SOURCES

This unit should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. For units intended to operate from battery power, or other sources, refer to the operating instructions.

11POWER-CORD PROTECTION

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the unit.

12LIGHTNING

For added protection for this unit during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line surges.

13DISC TRAY

Keep your fingers well clear of the disc as it is closing. It may cause serious personal injury.

14OVERLOADING

Do not overload wall outlets of extension cords as this can result in a risk of fire or electric shock.

15OBJECT AND LIQUID ENTRY

Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or ‘short-out’ parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.

16BURDEN

Do not place a heavy object on or step on the product. The object may fall, causing serious

iii

INTRODUCTION

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` iv mac001 1200DPI 90LPI

Important Safeguards

personal injury and serious damage to the product.

17DISC

Do not use a cracked, deformed or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

18SERVICING

Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19DAMAGE REQUIRING SERVICE

Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions.

A.When the power-supply cord or plug is damaged.

B.If liquid has been spilled, or objects have fallen into the unit.

C.If the unit has been exposed to rain or water.

D.If the unit does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the unit to its normal operation.

E.If the unit has been dropped or the cabinet has been damaged.

F.When the unit exhibits a distinct change in performance-this indicates a need for service.

20REPLACEMENT PARTS

When replacement parts are required, have the service technician verify that the replacements he uses have the same safety characteristics as the original parts. Use of replacements specified by the unit manufacturer can prevent fire, electric shock, or other hazards.

21SAFETY CHECK

Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks recommended by the manufacturer to determine that the unit is in safe operating condition.

22WALL OR CEILING MOUNTING

The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

23HEAT

The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

24To prevent battery electrolyte leakage, which may result in injury and damage to the unit or other objects, observe the following precautions;

A.All batteries must be installed with the proper polarity.

B.Do not mix new with old or used batteries.

C.Only use batteries of the same type and brand.

D.Remove the batteries when they are not to be used for a long period time.

E.When the batteries have become discharged, they must be disposed of in a safe manner which complies with all applicable laws.

25WEEE (Waste Electrical and Electronic Equipment)

The meaning of the symbol on the

product, its accessory or packaging indicates that this product shall not be treated as household waste. Please, dispose of this equipment at

your applicable collection point for the recycling of electrical &

electronic equipment waste. In the European Union and Other European countries which there are separate collection systems for used electrical and electronic product. By ensuring the correct disposal of this product, you will help prevent potentially hazardous to the environment and to human health, which could otherwise be caused by unsuitable waste handling of this product. The recycling of materials will help conserve natural resources. Please do not therefore dispose of your old electrical and electronic equipment with your household waste. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

26 RoHS (Directive 2002/95/EC) Compliant

This environment-friendly product does not contain the EU RoHS restricted substances (Pb, Hg, Cd, Cr6+, PBB, and PBDE).

iv

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 1 mac001 1200DPI 90LPI

Table of Contents

INTRODUCTION

Overview ______________________________________2

Identification of Controls_______________________6

CONNECTIONS

Connecting Antenna/Cable ____________________11 Connecting a TV _______________________________12 Connecting an Amplifier/Receiver _____________13 Connecting Optional Equipment ______________14 Connecting a Digital Camcorder ______________14

RECORDING

Basic Recording________________________________43

Recording from TV	43
One Touch Record (OTR)	44
Checking the Recording Time	44
To Pause the Recording	44

Timer Recording _______________________________45 Recording from an External Input _____________48

REFERENCE

Troubleshooting _______________________________50 Technical Specifications ________________________53

SETUP

Initial Installation ______________________________15

Setup __________________________________________17

‘Installation’ Settings	17
‘Recording’ Settings	21
‘Language’ Settings	22
‘Preference’ / Video Settings	23
‘Preference’ / Audio Settings	24
‘Preference’ / Parental Controls	25
Auto Setting	27
‘System’ / System Info	28
‘System’ / DivX(R) VOD DRM	28
‘System’ / Restore Defaults	28

Disc Operation ________________________________29

Disc Initialize	29
Disc Operation	29

Title Edit _______________________________________32

Edit Menu

32

PLAYBACK

On-Screen Display Overview __________________34

DVD Playback _________________________________36

Other Disc Playback __________________________40

1

INTRODUCTION

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 2 mac001 1200DPI 90LPI

Overviewi

DVD, DVD+R, DVD+RW?

What is a DVD?

DVD (Digital Versatile Disc) is a storage medium that combines the convenience of the compact disc with the latest digital video technology. DVD video uses modern MPEG2 data compression technology that enables an entire feature film to be stored on a single five inch disc.

How good is the resolution of DVD compared with VHS?

The razor-sharp digital images have more than 500 lines of resolution at 720 pixels per line. This is more than twice as high as VHS and even better than laser disc quality. DVD picture quality is easily comparable to the digital masters produced in recording studios.

What is a DVD+RW?

DVD+ReWritable uses ‘phase change‘ media, the same technology on which rewritable CDs are based. A highperformance laser is used to change the reflective properties of the recording layer; this process can be repeated more than a thousand times.

What is a DVD+R?

Unlike a DVD+RW disc, a DVD+R (write-once DVD) can only be written to once. If it is not finalized after a recording, further recordings can be added to it. Old recordings can be deleted but they can no longer be overwritten. The deleted recordings (titles) are marked 'deleted title'.

Before a DVD+R can be played in a DVD player, it must be finalized in the DVD Recorder. Once this process is complete, no further recordings can be added.

What can I do with my DVD Recorder?

Your DVD Recorder is a machine for recording and playing back digital video discs with ‘two-way‘ compatibility with the universal DVD video standard. This means:

•existing DVD video discs can be played on the recorder.

•recordings made on your DVD Recorder can be played on other DVD video players and DVD-ROM drives.

Dual Media

Supporting Disc	±RW / ±R
Recording Format	±Disc + VR format
Finalise	-RW, -R, +R
After finalize other DVD playback	All disc can playback
Consumer	Does not need selection (recording format)
Remark :

A DVD Recorder that supports ‘dual media’ recording allows DVD+RW format recording (+VR) on either DVD-R, DVD-RW, DVD+R or DVD+RW media. Any editing feature that is available with the +RW logical format is available on any of the media types. This system allows the flexibility for the consumer to use any of the above media formats for recording in the same system. Since the +VR format is DVD-Video compatible, the consumer can take any disk recorded on this platform and should be capable of playing it back on the majority of DVD players on the market.

2

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 3 mac001 1200DPI 90LPI

Overview

Regional code

2	ALL	If the region number on your DVD disc does not correspond to the region
		number of this player, the disc cannot be played.

Which discs you can use

The following discs can be used in your DVD Recorder:

Playback and recording

DVD+RW (Digital Versatile Disc + ReWritable)

DVD-RW (DVD-Rerecordable)

DVD+R (Digital Versatile Disc + Recordable)

DVD-R (DVD-Recordable)

Playback only

DVD Video (Digital Versatile Disc)

VCD (Video CD)

Audio CD (Compact Disc Digital Audio)

CD-R (CD recordable) Audio/ CD-RW (CD rewritable) Audio

Video Format : JPEG

Audio Format : CDDA / MP3

Not all recordable CDs may be played by your player.

INTRODUCTION

Disc-related Terms

Title (DVD only)

The main film, accompanying feature content, or music album. Each title is assigned a title reference number enabling you to locate it easily.

Chapter (DVD only)

Sections of a movie or a musical piece that are smaller than titles. A title is composed of one or several chapters. Each chapter is assigned a number to enable you to easily locate the chapter you want. Depending on the disc, chapters may not be labeled.

Track (Audio CD only)

Sections of a movie or a musical piece on an audio CD. Each track is assigned a number, enabling you to easily locate the track you want.

3

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 4 mac001 1200DPI 90LPI

Overview

About DVD Recording

Notes on Recording

•The recording times shown are not exact because the DVD Recorder uses variable bit-rate video compression. This means that the exact recording time will depend on the material being recorded.

•When recording a TV broadcast, if the reception is poor or the picture contains interference, the recording times may be shorter.

•Discs recorded at high speeds (equal to or greater than 2X) may not be recognized.

•If you record still pictures or audio only, the recording time may be longer.

•The displayed times for recording and time remaining may not always add up to the exact length of the disc.

•The available recording time may decrease if you heavily edit a disc.

•When using a DVD+R disc, you can keep recording until the disc is full, or until you finalize the disc. Before you start a recording session, check the amount of recording time left on the disc.

Recording TV Audio Channels

The DVD Recorder can record one or two channel audio. For TV broadcasts, this usually means mono or stereo, but some programs are broadcast in bilingual audio channel. You can record either BIL I, BIL II or both.

Restrictions on Video Recording

•You cannot record copy-protected video using this DVD Recorder. Copy-protected video includes DVD-Video discs and some satellite broadcasts. If copy-protected material is encountered during a recording, recording will pause or stop automatically and an error message will be displayed on-screen.

•Video that is ‘copy-once only’ can only be recorded using DVD+RW discs with CPRM.

Copyright Notice

•Audio and video recordings you make using the DVD Recorder are for your personal use only. You may not sell, lend, or rent them to other people.

•This product incorporates copyright protection technology that is protected by method claims of certain U.S.patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision corporation. Reverse engineering or disassembly is prohibited.

Precautions

Handling the Unit

When shipping the unit

The original shipping carton and packing materials come in handy. For maximum protection, re-pack the unit as it was originally packaged at the factory.

When setting up the unit

The picture and sound of a nearby TV, VCR, or radio may be distorted during playback. In this case, position the unit away from the TV, VCR, or radio, or turn off the unit after removing the disc.

To keep the surface clean

Do not use volatile liquids, such as insecticide spray, near the unit. Do not leave rubber or plastic products in contact with the unit for a long period of time. They will leave marks on the surface.

4

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 5 mac001 1200DPI 90LPI

Overview

Cleaning the Unit

To clean the cabinet

Use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

To obtain a clear picture

The DVD Recorder is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality will be poor. Regular inspection and maintenance are recommended after every 1,000 hours of use. (This depends on the operating environment.) For details, please contact your nearest dealer.

Remote Control Operation Range

Point the remote control at the remote sensor and press the buttons. Distance: Within 23 ft (7 m) of the remote sensor.

Angle: Within 30° in each direction of the remote sensor.

Remote Control Battery Installation

Detach the battery cover on the rear of the remote control, and insert two AAA batteries. Make sure the polarities (+ and -) are aligned correctly.

AAA

AAA

Caution

Do not mix old and new batteries. Never mix different types of batteries (standard, alkaline, etc.).

INTRODUCTION

Notes on Discs

Handling Discs

Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints will not get on the surface. Do not stick paper or tape on the disc.

Storing Discs

After playing, store the disc in its case.

Do not expose the disc to direct sunlight or sources of heat, or leave it in a parked car exposed to direct sunlight, as there may be a considerable temperature increase inside the car.

Cleaning Discs

Fingerprints and dust on the disc can cause poor picture quality and
sound distortion. Before playing, clean the disc with a clean cloth.		Yes	No
Wipe the disc from the center outward.
Do not use strong solvents such as alcohol, benzine, thinner,
commercially available cleaners, or anti-static spray intended for older
vinyl records.
About Symbols
About the	Symbol

‘ ‘ may appear on the TV screen during operation. This icon means the function explained in this User's Guide is not available on that specific disc.

5

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 6 mac001 1200DPI 90LPI

Identification of Controls

Front Panel

$%^ )

! @

# &*( 1 2

!STANDBY/ON

Turns the DVD Recorder on and off.

@ Disc Tray (DVD deck)

Insert a disc here.

# Front Panel Display

Shows the current status of the DVD Recorder.

$PLAY/PAUSE

Starts playback of a disc. Pauses playback or recording temporarily.

%STOP

Stops playback.

^PREV

Skips to previous chapter.

&OPEN/CLOSE

Opens or closes the disc tray.

*REC

Starts recording. Press repeatedly to set the recording time.

( NEXT

Skips to next chapter.

)PR+/–

Scans up or down through memorized channels. Also moves up and down in DVD navigation menus.

1AVF (VIDEO, L-AUDIO-R)

Connects to the audio/video output of an external source (VCR, Camcorder, etc.).

2DV IN

Connects to the DV output of an external source (Digital Camcorder).

6

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 7 mac001 1200DPI 90LPI

Identification of Controls

Front Panel Display

Channel

Pr10	TV Channel		CC23	CATV Channel
Input mode
Av-1	AV1 input		Av-2	AV2 input
DV	DV input
	Front AV input
F-Av
Recording on disc
				Indicates a DVD Timer Recording is in
1 1 : 1 5	Indicates a DVD Timer recording is set.		1 1 : 1 5
				standby mode.
1 1 : 1 5	Indicates the DVD is recording.		0:30	OTR Recording mode
RECP	Recording Pause mode
Others
	Indicates when the DVD Recorder is locked.
SAFE
TV	Indicates the DVD Recorder is in TV mode.
	Indicates the dts title is playing.

7

INTRODUCTION

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 8 mac001 1200DPI 90LPI

Identification of Controls

Remote Control

- Turns the DVD Recorder on and off.

- Lock the front panel by pressing and holding it over 5 seconds in power on status.

- Unlock the front panel in stand by off status.

Opens and closes the disc tray in DVD mode.

Switches between the DVD Recorder tuner and your TV tuner.

Displays a disc’s Title menu, if available.

Switches the DVD Recorder input to Tuner, AV1, AV2, AVF or DV.

- Selects numbered options in menus. - Selects TV channels.

Shows the general information of the loaded DVD disc. It is hot key of “Disc info” in “Setup” menu.

Clears all characters in edit box when changing disc name or channel name.

Accesses DVD disc menus.

Displays or exits the Setup menu.

Displays the Timer Recording menu.

Displays information about the currently loaded disc or TV channel.

-œ …† : Selects menu options.

-PR(+/–) : Selects channels.

Confirms menu selections.

Starts recording. Press repeatedly to set the recording time. For more details, Refer to One Touch Record (OTR) on page 44.

Selects Recording mode: Approx 1 Hour (HQ mode), 2 Hours (SP mode), 4

Hours (EP mode), 8 Hours (SEP mode)

Selects a subtitle language, if available.

Selects an audio language (DVD), audio channel (CD) or audio type (TV).

- Starts playback.

- Pauses playback or recording temporarily. Press again to exit Pause mode.

8

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 9 mac001 1200DPI 90LPI

Identification of Controls

Searches backward/forward.

Stops playback or recording.

Skips to the next or previous chapter/track.

Displays the edit menu for recordable DVD disc.

Displays the finalize menu for DVD±R, DVD-RW discs.

Increases or decreases the slow motion speed when playing a DVD.

Repeats the current chapter, track, title or the entire disc.

Repeats playback between two points (A and B).

Enlarges the DVD video image.

Selects a DVD camera angle, if available.

Progressive Scan Mode

•If your TV supports Progressive Scan, you can view high quality video by setting the DVD Recorder to Progressive Scan mode. If your TV does not support Progressive Scan, do NOT change to Progressive Scan mode.

•As component outputs have their own Jacks on the back side, change the TV input into Component input, after connecting the component cables from the DVD Recorder to TV.

•Changing from Interlace or Progressive to RGB, should be the opposite of above.

INTRODUCTION

9

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 10 mac001 1200DPI 90LPI

Identification of Controls

Rear panel

! @ # $ % ^ &

*

!ANT OUT (TO TV)

Connect to a TV with an RF coaxial input.

@ANT IN (FROM ANT.)

Connect to your antenna or cable TV outlet.

#Scart socket 2

Connection of an additional device (satellite receiver, set-top box, video recorder, camcorder, etc.)

$Scart socket 1

Connection of a TV set. Composite-output and RGB-output.

%AUDIO OUT (L-AUDIO-R)

Connect to other equipment with audio inputs.

Caution

^COMPONENT/PROGRESSIVE VIDEO OUT (Y Pb Pr)

Connect to a TV with Component Video (Y Pb Pr) inputs.

&COAXIAL (Digital Audio Out)

Connect to an amplifier with a coaxial digital audio input.

*AC Power Cord

Plug into a power outlet.

Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the DVD Recorder.

10

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 11 mac001 1200DPI 90LPI

Connectionsti

•There are a variety of ways to connect the DVD Recorder to your TV and other equipment. Use only one of the connections described below. Whichever TV connection you use will work with all input sources.

•Please refer to the manuals for your TV, VCR, stereo system, or other devices as necessary to make the best connections.

•For better sound reproduction, connect the DVD Recorder’s AUDIO OUT jacks to the audio in jacks of your amplifier, receiver, stereo, or audio/video equipment. See ‘Connecting an Amplifier/Receiver‘ on page 13.

Caution

•Make sure the DVD Recorder is connected directly to the TV, and the TV is set to the correct video input.

•Do not connect the DVD Recorder’s AUDIO OUT jack to the phono in jack (record deck) of your audio system.

•Do not connect the DVD Recorder via your VCR. The DVD image could be distorted by the copy protection system.

CONNECTIONS INTRODUCTION

Connecting Antenna/Cable

1Disconnect the antenna/cable from the rear of your TV.

2Connect this cable to the jack marked ANT IN (FROM ANT.) on the rear panel of the DVD Recorder.

Antenna Antenna

Antenna Antenna

Cable TV

Cable TV

Wall Jack

Wall Jack

FlatWire (300ohm)

300/75 ohm	ORor	ORor
300/75ohm Adapter
Adaptor
(Not(Notsupplied)supplied)

Rear of DVD Recorder

If your cable wire is connected to your TV without a converter or descrambler box, unscrew the wire from your TV and attach it to the ANT IN (FROM ANT.) jack on the rear panel of the DVD Recorder.

Use the supplied coaxial cable to connect between the DVD Recorder’s OUT (TO TV) jack and the antenna input jack on your TV. With this connection, you can receive all midband, superband, and hyperband channels (all cable channels).

11

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 12 mac001 1200DPI 90LPI

Connections

Connecting a TV

Choose one of the following TV connections, depending on the capabilities of your equipment.

RF Connection

Connect the ANT OUT (TO TV) jack on the DVD Recorder to the antenna in jack on your TV using the supplied 75-ohm RF cable (R).

This set doesn’t apply the modulator output. However, still apply the RF through Output.

Scart Connection

1Plug a scart cable (V) into the scart socket EURO AV1 at the back of the DVD Recorder and the corresponding scart socket at the back of the TV set.

2Plug a scart cable into the blue scart socket EURO AV2/DECODER at the back of the DVD Recorder and the corresponding scart socket at the back of the Decoder.

Rear of TV

	ANTENNA	COMPONENT/PROGRESSIVE VIDEO INPUT			S-VIDEO
	INPUT				INPUT
		Pr	Pb	Y

R

V

C

Rear of DVD Recorder

Progressive Scan Connection

•If your television is a high-definition or ‘digital ready‘ television, you may take advantage of the DVD Recorder’s Progressive Scan output for the highest video resolution possible.

•If your TV does not accept the Progressive Scan format, the picture will appear scrambled.

1Connect the COMPONENT/PROGRESSIVE VIDEO OUT jacks on the DVD Recorder to the corresponding in jacks on your TV using an optional Y Pb Pr cable (C) if the Component Video jacks (Y, Pb, Pr) are available on your TV.

2Connect the Left and Right AUDIO OUT jacks from the DVD Recorder to the left/right audio in jacks on your TV using the supplied audio cables.

Change the video output to “Progressive” in the “Setup” menu to see the progressive video.

12

DW-R77D1D-JB-I(GB) 2008.4.11 1:53 PM ˘ ` 13 mac001 1200DPI 90LPI

Connections

Connecting an Amplifier/Receiver

Connecting to an amplifier equipped with two channel analog stereo or Dolby Pro Logic ll/Pro Logic

Connect the Left and Right AUDIO OUT jacks on the DVD Recorder to the left and right audio in jacks on your amplifier, receiver, or stereo system, using the audio cables (A).

Connecting to an amplifier equipped with two channel digital stereo (PCM) or to an Audio/Video receiver equipped with a multi-channel decoder (Dolby Digital™, MPEG 2, or DTS)

1Connect the DVD Recorder’s DIGITAL AUDIO OUT jack (COAXIAL) to the corresponding in jack on your amplifier. Use an optional digital coaxial audio cable.

2You will need to activate the DVD Recorder’s digital output; see ‘AUDIO Settings‘ on page 24.

Digital Multi-Channel Sound?

A digital multi-channel connection provides the best sound quality. For this you need a multi-channel audio/video receiver that supports one or more of the audio formats supported by your DVD Recorder (MPEG audio, Dolby Digital, and DTS). Check the receiver manual and the logos on the front of the receiver.

•Due to the DTS Licensing agreement, the digital output will be in DTS digital out when DTS audio stream is selected.

•If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

•5.1 channel digital surround sound via the digital connection can only be obtained if your receiver is equipped with a digital multi-channel decoder.

•To see the audio format of the current DVD on the on-screen display, press [AUDIO].

The DVD Recorder does not perform internal (2- channel) decoding of DTS sound tracks. To enjoy DTS multi-channel surround, you must connect the DVD Recorder to a DTS compatible receiver via one of the DVD Recorder’s digital audio outputs.

CONNECTIONS

Rear of DVD Recorder

A X

L	R	COAXIAL
AUDIO INPUT		DIGITAL INPUT

Amplifier (Receiver)

13
