Daewoo DH-6100P User Manual

Download

HDD/DVD Recorder

DH-6100P

User Manual

HELP LINE Number ; 0870 100 2525

With queries, please quote the page number,

reference number and model number.

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` A mac001 1200DPI 100LPI

INTRODUCTION

Safety Instructions

Please keep the product’s guarantee sheet and receipt in a safe place.

Precautions

• Read this booklet carefully.

• Make sure the rating of your household electricity supply matches that shown on the back of your product.

• Read this page and chapter ‘Setting up your product’ to help you set up and adjust your product correctly.

• Do not put the product in a hot or humid place.

• Do not open the product. Get a qualified technician to carry out any repairs.

• Do not connect the product to the power supply if you have just moved it from a cold environment to a warm room. This can lead to condensation inside the product, which can damage it. Wait for approx. 2 hrs for it to reach room temperature.

• Make sure the product is placed at least 10 cm apart from other home appliances or obstacles to ensure sufficient ventilation.

• The product should not be exposed to dripping or splashing and no objects filled with liquids, such as vases should be placed on top of the product.

• Before a storm and/or lightning, unplug the product from the mains supply and aerial.

• Put the product on a steady flat surface.

• Only clean the product with a soft, lint-free cloth. Do not use harsh or alcohol- based cleaning agents.

For your own Safety

• There are no components in this product you can service or repair yourself.

• Do not open the case of the product. Only allow a qualified engineer to repair or service your product.

• This product is designed to work continuously. Switching it off (stand-by mode) does not disconnect it from the mains. To disconnect it from the mains you have to unplug it.

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 1 mac001 1200DPI 100LPI

Important Safeguards

IMPORTANT FOR LASER PRODUCTS LASER

This Digital Video Disc Player employs a Laser System. To ensure proper use of this product please read this owner’s manual carefully and retain for future reference. Should the unit require maintenance, contact an authorized service location - see service procedure.

Use of control adjustments or the performance of procedures other than those specified may result in hazardous radiation exposure.

To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible laser radiation when open and interlocks defeated. DO NOT STARE INTO THE BEAM.

DANGER

Visible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam.

CAUTION

Do not open the top cover. There are no user serviceable parts inside the Unit; leave all servicing to qualified service personnel.

CLASS 1 LASER PRODUCT

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated ‘dangerous voltage‘ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

CAUTION

Any changes or modification in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 2 mac001 1200DPI 100LPI

INTRODUCTION

Important Safeguards

This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user.

1 READ INSTRUCTIONS

All the safety and operating instructions should be read before the unit is operated.

2 RETAIN INSTRUCTIONS

The safety and operating instructions should be retained for future reference.

3 HEED WARNINGS

All warnings on the unit and in the operating instructions should be adhered to.

4 FOLLOW INSTRUCTIONS

All operating and use instructions should be followed.

5 CLEANING

Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

6 ATTACHMENTS

Do not use attachments unless recommended by the unit’s manufacturer as they may cause hazards.

7 WATER AND MOISTURE

Do not use this unit near water- for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool.

8 ACCESSORIES

Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury to a child or adult as well as serious damage to the unit. Use this unit only with a cart, stand , tripod, bracket, or table recommended by the manufacturer.

A unit and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

9 VENTILATION

Slots and openings in the case are provided for ventilation to ensure reliable operation of the unit

and to protect it from overheating. These openings must not be blocked or covered. These openings must not be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat radiator. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10 POWER SOURCES

This unit should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. For units intended to operate from battery power, or other sources, refer to the operating instructions.

11 POWER-CORD PROTECTION

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, mains sockets, and the point where they exit from the unit.

12 LIGHTNING

For added protection for this unit during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line surges.

13 DISC TRAY

Keep your fingers well clear of the disc as it is closing. It may cause serious personal injury.

14 OVERLOADING

Do not overload wall outlets of extension cords as this can result in a risk of fire or electric shock.

15 OBJECT AND LIQUID ENTRY

Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or ‘short-out’ parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.

16 BURDEN

Do not place a heavy object on or step on the product. The object may fall, causing serious personal injury and serious damage to the

PORTABLE CART WARNING (symbol provided by RETAC)

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 3 mac001 1200DPI 100LPI

Important Safeguards

product.

17 DISC

Do not use a cracked, deformed or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

18 SERVICING

Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19 DAMAGE REQUIRING SERVICE

Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions.

A. When the power-supply cord or plug is

damaged.

B. If liquid has been spilled, or objects have fallen

into the unit. C. If the unit has been exposed to rain or water. D. If the unit does not operate normally by

following the operating instructions. Adjust only

those controls that are covered by the operating

instructions. Improper adjustment of other

controls may result in damage and will often

require extensive work by a qualified technician

to restore the unit to its normal operation. E. If the unit has been dropped or the cabinet has

been damaged. F. When the unit exhibits a distinct change in

performance-this indicates a need for service.

20 REPLACEMENT PARTS

When replacement parts are required, have the

service technician verify that the replacements

he uses have the same safety characteristics as

the original parts. Use of replacements

specified by the unit manufacturer can prevent

fire, electric shock, or other hazards.

21 SAFETY CHECK

Upon completion of any service or repairs to

this unit, ask the service technician to perform

safety checks recommended by the

manufacturer to determine that the unit is in

safe operating condition.

22 WALL OR CEILING MOUNTING

The product should be mounted to a wall or

ceiling only as recommended by the

manufacturer.

23 HEAT

The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

To prevent battery electrolyte leakage, which may result in injury and damage to the unit or other objects, observe the following precautions;

A. All batteries must be installed with the proper

polarity. B. Do not mix new with old or used batteries. C. Only use batteries of the same type and brand. D. Remove the batteries when they are not to be

used for a long period time. E. When the batteries have become discharged,

they must be disposed of in a safe manner

which complies with all applicable laws.

25 WEEE (Waste of electrical and electronic

equipment)

The meaning of the symbol on

the product, its accessory or

packaging indicates that this

product shall not be treated as

household waste. Please,

dispose of this equipment at

your applicable collection

point for the recycling of

electrical & electronic equipments waste. In the

European Union and Other European countries

which there are separate collection systems for

used electrical and electronic product. By

ensuring the correct disposal of this product,

you will help prevent potential hazards to the

environment and to human health, which could

otherwise be caused by unsuitable waste

handling of this product. The recycling of

materials will help conserve natural resources.

Please do not therefore dispose of your old

electrical and electronic equipment with your

household waste. For more detailed information

about recycling of this product, please contact

your local city office, your household waste

disposal service or the shop where you

purchased the product.

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 4 mac001 1200DPI 100LPI

Recording

Basic Recording________________________________41

Recording to DVD or HDD 41 One Touch Record (OTR) 41 To Pause the Recording 42 Playing under recording 42

Timer Recording _______________________________42

Timer Recording using Manual Set Record Screen 42

Timer Recording using VideoPlus system 43

Canceling a Timer Recording 44 Stopping a Timer Recording in

Progress 44 Timer Recording Troubleshooting 44

Recording from an External Input _____________45 Dubbing _______________________________________46

Media files Copying ___________________________47

Editing

HDD Playback and Editing ____________________49

Playing a HDD title 49 Deleting a HDD title 49 Editing a HDD title 50 Sorting a HDD title 52 Dubbing a HDD title to DVD disc 52

Disc Manager__________________________________53

Disc Editing in DVD±RW disc 53 Disc Editing in DVD±R, DVD-RW disc 55 Title Editing 56 Advanced Disc Editing 57

Reference

Troubleshooting _______________________________59 Technical Specifications________________________61

INTRODUCTION

Safety Instructions ____________________________1 Important Safeguards _________________________2 Table of Contents ______________________________5 Overview______________________________________6 Identification of Controls ______________________10

Introduction

Connecting Antenna/Cable ____________________15 Connecting a TV _______________________________15 Connecting an Amplifier/Receiver _____________16 Connecting Optional Equipment ______________17 Connecting a Digital Camcorder ______________17

Connections

Initial Installation ______________________________18 Setup menu____________________________________19

Setup Menu Overview 19 Menu Navigation 19 INSTALLATION Settings 19 RECORDING OPTIONS Settings 22 LANGUAGE Settings 23 PREFERENCES / Video Settings 24 PREFERENCES / Audio Settings 25 PREFERENCES / Parental Controls 26 PREFERENCES / Auto Settings 28 PREFERENCES / Hard Disk 29 System Information 31 Restore Defaults 31

On-Screen Display Overview __________________32

Setup

DVD Playback _________________________________34 Playing a Picture or Music files _______________36 Time shifting & Saving ________________________39

Time shifting in HDD mode 39 Saving to HDD 40

Playback

Table of Contents

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 5 mac001 1200DPI 100LPI

The following discs can be used in your HDD/DVD Recorder:

Playback and recording

DVD+RW (Digital Versatile Disc + ReWritable) DVD+R (Digital Versatile Disc + Write-Once) DVD-R (DVD-Recordable) / DVD-RW (DVD-

Rewritable): Recording with +VR Format (Dual media support).

These discs can only be played back in other DVD players or recorders if the recording was made in ‘Video mode‘ and the recording was finalised.

Playback only

DVD Video (Digital Versatile Disc) Audio CD (Compact Disc Digital Audio) CD-R (CD recordable) Audio, MP3 files CD-RW (CD rewritable) Audio, MP3 files VCD, SVCD

Which discs you can useOverview

Not all recordable CDs may be played by your player.

Overview

Time Shifting

: Simultaneous video recording and playback

• Pause and resume the live TV broadcast. Issue trick mode commands like fast forward, fast rewind, jump and instant replay

• Play a previously recorded program while another program is being simultaneously recorded

Program Recording

: Recording from TV tuner or analog AV input

• Full support for VideoPlus technologies - simply enter the program code number (published in newspapers or on the internet) to setup timer recording

• Manually set up timer recording for a TV program or a recurring TV program

Personal video copying by external input

• Analog and DV camcorder tapes

• VCR tapes

High-speed dubbing

• Select program(s) from HDD and copy them to DVD

Also copy from DVD to HDD (Available with +VR Format, JPEG, MP3)

• Watch a TV program while high-speed dubbing is in progress

Simple, easy video editing

• Rename programs, Delete programs, Split programs, Segment programs

• Identify and keep the desired video and remove the parts you do not need.

DVD Playback

DVD, VCD, SVCD, MPEG file video, MPEG-1 Layer 2, MP3, CD stereo audio, Dolby Digital& DTS digital audio output.

Regional code

If the region number on your DVD disc does not correspond to the region number of this player, the disc cannot be played.

ALL

About the Symbol

‘ ‘ may appear on the TV screen during operation. This icon means the function explained in this User's Guide is not available on that specific disc.

About Symbols

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 6 mac001 1200DPI 100LPI

Disc-related Terms

Title (DVD only)

The main film, accompanying feature content, or music album. Each title is assigned a title reference number enabling you to locate it easily.

Chapter (DVD only)

Sections of a movie or a musical piece that are smaller than titles. A title is composed of one or several chapters. Each chapter is assigned a number to enable you to easily locate the chapter you want. Depending on the disc, chapters may not be labeled.

Track (Audio CD only)

Sections of a movie or a musical piece on an audio CD. Each track is assigned a number, enabling you to easily locate the track you want.

DVD, DVD+R, DVD+RW?

What is a DVD?

DVD (Digital Versatile Disc) is a storage medium that combines the convenience of the compact disc with the latest digital video technology. DVD video uses modern MPEG2 data compression technology that enables an entire feature film to be stored on a single five inch disc.

How good is the resolution of DVD compared with VHS?

The razor-sharp digital images have more than 500 lines of resolution at 720 pixels per line. This is more than twice as high as VHS and even better than laser disc quality. DVD picture quality is easily comparable to the digital masters produced in recording studios.

What is a DVD+RW?

DVD+ReWritable uses ‘phase change‘ media, the same technology on which rewritable CDs are based. A high-performance laser is used to change the reflective properties of the recording layer; this process can be repeated more than a thousand times.

What is a DVD+R?

Unlike a DVD+RW disc, a DVD+R (write-once DVD) can only be written to once. If it is not finalised after a recording, further recordings can be added to it. Old recordings can be deleted but they can no longer be overwritten. The deleted recordings (titles) are marked 'deleted title'.

Before a DVD+R can be played in a DVD player, it must be finalised in the HDD/DVD Recorder. Once this process is complete, no further recordings can be added.

What can I do with my HDD/DVD Recorder?

Your HDD/DVD Recorder is a machine for recording and playing back digital video discs with ‘two-way‘ compatibility with the universal DVD video standard. This means:

• existing DVD video discs can be played on the recorder.

• recordings made on your HDD/DVD Recorder can be played on other DVD video players and DVD-ROM drives.

INTRODUCTION

Dual Media

Supporting Disc

±RW / ±R

Recording Format

±Disc + VR format

Finalize

-RW, -R, +R

After finalising other DVD playback

All discs can playback

Consumer

Does not need selection

(recording format)

Remark :

A DVD Recorder that supports ‘dual media’ recording allows DVD+RW format recording (+VR) on either DVD-R, DVD-RW, DVD+R or DVD+RW media. Any editing feature that is available with the +RW logical format is available on any of the media types. This system allows the flexibility for the consumer to use any of the above media formats for recording in the same system. Since the +VR format is DVD-Video compatible, the consumer can take any disk recorded on this platform and should be capable of playing it back on the majority of DVD players on the market.

Overview

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 7 mac001 1200DPI 100LPI

Notes on Recording

• The recording times shown are not exact because the HDD/DVD Recorder uses variable bit-rate video compression. This means that the exact recording time will depend on the material being recorded.

• When recording a TV broadcast, if the reception is poor or the picture contains interference, the recording times may be shorter.

• Discs recorded at high speeds (equal to or greater than 2X) may not be recognized.

• If you record still pictures or audio only, the recording time may be longer.

• The displayed times for recording and time remaining may not always add up to the exact length of the disc.

• The available recording time may decrease if you heavily edit a disc.

• When using a DVD+R disc, you can keep recording until the disc is full, or until you finalise the disc. Before you start a recording session, check the amount of recording time left on the disc.

Recording TV Audio Channels

The HDD/DVD Recorder can record one or two channel audio. For TV broadcasts, this usually means mono or stereo, but some programs are broadcast in bilingual audio channel. You can record either BIL I, BIL II or both.

Restrictions on Video Recording

• You cannot record copy-protected video using this HDD/DVD Recorder. Copy-protected video includes DVD-Video discs and some satellite broadcasts. If copy-protected material is encountered during a recording, recording will pause or stop automatically and an error message will be displayed on-screen.

• Video that is ‘copy-once only’ can only be recorded using DVD+RW discs with CPRM.

• Audio and video recordings you make using the HDD/DVD Recorder are for your personal use only. You may not sell, lend, or rent them to other people.

• This product incorporates copyright protection technology that is protected by method claims

Overview

About DVD Recording

of certain U.S.patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision corporation. Reverse engineering or disassembly is prohibited.

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 8 mac001 1200DPI 100LPI

INTRODUCTION

Overview

Handling the Unit

When shipping the unit

The original shipping carton and packing materials come in handy. For maximum protection, re-pack the unit as it was originally packaged at the factory.

When setting up the unit

The picture and sound of a nearby TV, VCR, or radio may be distorted during playback. In this case, position the unit away from the TV, VCR, or radio, or turn off the unit after removing the disc.

To keep the surface clean

Do not use volatile liquids, such as insecticide spray, near the unit. Do not leave rubber or plastic products in contact with the unit for a long period of time. They will leave marks on the surface.

Cleaning the Unit

To clean the cabinet

Use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinners, as these might damage the surface of the unit.

To obtain a clear picture

The HDD/DVD Recorder is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality will be poor. Regular inspection and maintenance are recommended after every 1,000 hours of use. (This depends on the operating environment.) For details, please contact your nearest dealer.

Remote Control Operation Range

Point the remote control at the remote sensor and press the buttons.

Distance: Within 23 ft (7 m) of the remote sensor. Angle: Within 30° in each direction of the remote

sensor.

Remote Control Battery Installation

Detach the battery cover on the rear of the remote control, and insert two AAA batteries. Make sure the polarities (+ and

-) are aligned correctly.

Precautions

Caution

Do not mix old and new batteries. Never mix different types of batteries (standard, alkaline, etc.).

Notes on Discs

Handling Discs

Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints will not get on the surface. Do not stick paper or tape on the disc.

Storing Discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources

of heat, or leave it in a parked car exposed to direct sunlight, as there may be a considerable temperature increase inside the car, which could distort the disc.

Cleaning Discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the centre outward.

Do not use strong solvents such as alcohol, benzine, thinners, commercially available cleaners, or antistatic spray intended for older vinyl records.

Note on HDD

• Do not move the recorder immediately after switching it off. Wait at least 2minutes after power-off.

• If the HDD/DVD Recorder is used improperly or in an unsuitable environment, it is possible that the HDD will fail.

• Power failure may cause data loss on the HDD.

• We recommend that you back up your important data to DVD discs in order to protect against accidental loss or possible HDD failure.

NoYes

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 9 mac001 1200DPI 100LPI

AVF Input (VIDEO, L-AUDIO-R)

Connects to the audio/video output of an external source (VCR, Camcorder, etc.).

S-VIDEO Input

Connects to the S-Video output of an external source (VCR, Camcorder, etc.).

Disc Tray (DVD deck)

Insert a disc here.

Front Panel Display

Shows the current status of the HDD/DVD Recorder.

OPEN/CLOSE (DVD)

Opens or closes the disc tray.

PLAY/PAUSE (ENTER)

Starts playback of a disc or HDD. Pauses playback or recording temporarily.

STOP

Stops playback.

PREV/REW

Skips to previous chapter. Searches backward.

NEXT/FF

Skips to next chapter. Searches forward.

STANDBY/ON

Turns the HDD/DVD Recorder on and off.

(

REC

Starts recording. Press repeatedly to set the recording time.

)

SELECT DVD/HDD

Toggles control between the DVD mode and the HDD mode.

Accesses media browser or return to previous menu.

PR+/– (……/††)

Scans up or down through memorized channels. Also moves up and down in menus.

Identification of Controls

! @ # %

^ *$

Front Panel

( ) 1 4

2 3

• HDD capacity is displayed in front panel or Setup-Preferences-Hard Disk.

DG-M12D1P-SA(GB) 2005.11.1 11:27 AM ˘ ` 10 mac001 1200DPI 100LPI

INTRODUCTION

Front Panel Display

Identification of Controls

Channel

PR23

TV Channel

Input mode

Au-1

AV1 input

Au-2

AV2 input

Recording on disc

Recording on HDD

11:15

Indicates a DVD Timer recording is set.

11:15

Indicates a DVD Timer Recording is in standby mode.

11:15

Indicates the DVD is recording.

RECP

Recording Pause mode
