Comelit 6501 Specsheet

DATA SHEET

COD.

6501

7'' MONITOR - COLOUR 7STELLE, VIP SERIES

7'' colour touch-screen monitor with hands-free audio. Audio, ringtone, colour and contrast
adjustment. Slot for mini SD card. Ringtone customisation. Video memory function and
internal directory for intercom call management. Manages floor door calls and call
repetition as standard. Panic and alarm input. Backlit control panel consisting of: 1 key
button, 1 enable/disable audio button, 1 privacy or doctor selection button (with red
privacy enabled LED indicator), 1 self-ignition button, 2 buttons for various uses. ''Door
open'' and ''messages'' indicator light - Also equipped with a special panic call button. No
finishing bracket required. Wall-mounted or flush-mounted installation. Dimensions
230x168x28 mm

Main specifications

Backlighting colour: LED BLUE

Compatibility

Video door entry family: Yes
Vip system: Yes

Mounting/Installation

Flush-mounted: Yes
Wall-mounted: Yes
Desk base-mounted: No
Surface-mounted: No

Audio/video specifications

Display size (inches): 7
B/W or colour display: COLOR
Touch screen display: Yes
Display resolution (H x V): 800x480
Audio system: Yes
Type of display: TOUCH

Hardware specifications

Customisable housing: Yes
Total buttons: 7
SD memory card: Yes

Software/firmware specifications

IP assignment: AUTO IP

The technical specifications are subject to variations without warning

DATA SHEET

Connectivity

Type of connections/ports: mini-SD CARD

Functions - Settings

Automatic gain control (AGC): Yes
Actuator control function: Yes
Privacy conversation function: Yes
Intercom function: Yes
Privacy function: Yes
Key button function: Yes
Full Duplex hands-free function: Yes
Display colour control: Yes
Display contrast control: Yes
Display brightness control: Yes
Loudspeaker volume control: Yes
Ringtone volume control: Yes

Technical properties

Temperature range (°C): -5/55

Electrical specifications

Maximum current absorption (mA): 200

General info

Self-ignition: Yes
Intrastat code: 85176910
Customisable ringtone: Yes
Product height (mm): 168
Product width (mm): 231
Product depth (mm): 33
Product colour: WHITE RAL9016

The technical specifications are subject to variations without warning
