5 SPEED BENCH DRILL
Model Nos.
Model Nos.
CDP5DD • CDP5R
CDP5DD • CDP5R
Part Nos. 6550010 • 6550015
OPERATING & MAINTENANCE
OPERATING & MAINTENANCE
INSTRUCTIONS
INSTRUCTIONS
Serial No...........................
0307
PARTS & SERVICE CONTACTS
For Spare Parts and Service, please contact your nearest dealer,
or CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: 020 8988 7400
PARTS & SERVICE FAX: 020 8558 3622
or e-mail as follows:
PARTS: Parts@clarkeinternational.com
SERVICE: Service@clarkeinternational.com
2
19
SPECIFICATIONS
Motor ............................................................................................ 230VAC, 50Hz, 1 Phase
Power Rating ............................................................. 1/3 HP
Current Rating (Input) .............................................. 1.5 Amps
No Load Speed......................................................... 1420 RPM
No. of Speeds .............................................................................. 5
Chuck Capacity ......................................................................... 13mm (1/2”)
Spindle Taper ............................................................................... B16
Table Type .................................................................................... Square - Dry
Table Dimensions ........................................................................ 165X162mm
Max. Spindle Travel ..................................................................... 50mm
Max. Dist. Chuck to Table .......................................................... 168mm
Max. Dist. Chuck to Base ........................................................... 260mm
Column Dia. .................................................................................48mm
Quill Collar Dia. ............................................................................ 40mm
Dist. Column to Chuck Centre .................................................. 105mm
Overall Dimensions (WxDxH) ...................................................... 220x410x575mm
Base Size ....................................................................................... 180X142mm
Weight net ................................................................................... 18kg
OPTIONAL ACCESSORIES
Drill Press Vices, from 3" to 6", Cross Vices (Cast Iron),
and Table Clamps
are available from your CLARKE dealer
Thank you for purchasing this CLARKE - CDP5DD, 5 Speed bench mounted Drill Press which
is designed for DIY and light workshop use ONLY.
Before attempting to operate the machine, please read this instruction manual thoroughly,
and follow all directions carefully. By doing so you will ensure the safety of both yourself and
others around you, and at the same time, you should look forward to the Press giving you
long and trouble free service.
GUARANTEE
This product is guaranteed against faults in manufacture for 12 months from date of
purchase. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product has been found to have been abused or tampered
with in any way, or not used for the purpose for which it was intended. The reason for return
must be clearly stated.
This guarantee does not affect your statutory rights.
TABLE OF CONTENTS
PAGE
Safety Precautions ......................................................................................... 4
Additional Safety Rules for Drill Presses ........................................................ 5
Electrical Connections .................................................................................. 6
Preparation for Use ........................................................................................ 7
Assembly ......................................................................................................... 8
Settings and Adjustments ........................................................................... 10
Setting your Drill Speed ............................................................................... 11
Operation ..................................................................................................... 12
Maintenance ................................................................................................ 13
Cutting Speed Chart ................................................................................... 13
Trouble Shooting .......................................................................................... 14
Parts Lists and Diagrams ....................................................................... 15 - 17
Specifications ............................................................................................... 18
Spare Parts & Servicing .......................................................................... 2 - 19
When disposing of this product, do not dispose of with general waste. It must be disposed of according
to law at a recognised disposal facility.
18
3
GENERAL SAFETY PRECAUTIONS
FOR OPERATING MACHINERY
WARNING
As with all machinery, there are certain hazards involved with their operation and use.
Exercising respect and caution will considerably lessen the risk of personal injury.
However, if normal safety precautions are overlooked, or ignored, personal injury to the
operator, or damage to property may result.
1. KNOW YOUR MACHINE. Read the manual carefully. Learn the machines applications
and limitations, as well as the specific potential hazards peculiar to it.
2. KEEP GUARDS IN PLACE and in working order.
3. EARTH ALL MACHINES. If the machine is equipped with three-pin plug, it should be
plugged into a three-pin electrical socket. Never remove the earth pin.
4. REMOVE ALL ADJUSTING KEYS AND WRENCHES. Before starting, form the habit of
checking to ensure that keys, wrenches and tools are removed from the machine.
5. KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
6. DON’T USE IN DANGEROUS ENVIRONMENT. Don’t use machinery in damp or wet
locations, or expose them to rain. Keep work area well lit.
7. MAKE WORKSHOP CHILDPROOF - with padlocks, master switches or by removing
starter keys.
8. KEEP CHILDREN AND VISITORS AWAY. All children and visitors should be kept a safe
distance from work area
9. DON’T FORCE THE MACHINE. It will do the job better and safer, at the rate for which it
was designed.
10. USE THE RIGHT TOOL. Don’t force a tool or attachment to do a job for which it was
not designed.
11. WEAR PROPER APPAREL. Loose clothing, gloves, neckties, rings, bracelets, or other
jewellery may get caught in moving parts. Nonslip footwear is recommended. Long
hair should be contained.
12. USE SAFETY GLASSES. Everyday eyeglasses only have impact resistant lenses, they are
NOT safety glasses.
13. USE EAR DEFENDERS.
14. DON’T OVERREACH. Keep proper footing and balance at all times.
15. MAINTAIN TOOLS IN TOP CONDITION. Keep tools sharp and clean for best and safest
performance. Follow instructions for lubricating and changing accessories.
16. ALWAYS DISCONNECT THE MACHINE before servicing or changing accessories.
17. AVOID ACCIDENTAL STARTING. Ensure machine is switched OFF before plugging in.
18. CHECK FOR DAMAGE. If part of the machine (eg. A cover or guard), is damaged, it
should be carefully inspected to ensure that it can perform its’ intended function
correctly. If in doubt, the part should be renewed. Damage to moving parts or
major components should be Inspected by a qualified technician before operating
the machine. Contact your local dealer for advice.
PARTS DIAGRAM
4 17
PARTS DIAGRAM
19. DO NOT STAND ON THE MACHINE. Serious injury could occur if the machine is tipped
over. Do not store materials above or near the machine such that it is necessary to
stand on the machine to get to them.
20. NEVER operate a machine when under the influence of alcohol, drugs or
medication.
21. ALWAYS ENSURE THAT ADEQUATE LIGHTING is available. A minimum intensity of 300 lux
should be provided. Ensure that lighting is placed so that you will not be working in
your own shadow.
ADDITIONAL SAFETY RULES FOR DRILL PRESSES
WARNING:
THIS MACHINE MUST NOT BE MODIFIED, OR USED FOR ANY PURPOSE OTHER THAN THAT FOR
WHICH IT IS DESIGNED.
1. IMPORTANT: You should not operate this machine unless you are thoroughly familiar
with drilling machines and drilling techniques. If there is any doubt whatsoever, you
should consult a qualified person.
2. Do not operate the machine until it is completely assembled, and you have read, and
understood. this entire manual
3. Ensure the proper electrical regulations are followed, and that the machine is properly
earthed.
4. Before switching the machine ON, ALWAYS:-
a. Ensure all chuck keys, spanners and wrenches are removed from the machine.
b. Examine the setup carefully, ensuring that the workpiece is perfectly secure.
c. Ensure your clothing is properly adjusted.
5. Make all adjustments with the power OFF.
6. Always use the correct drilling speeds for the drill size, and the type of material being
drilled (see page 13).
7. NEVER leave the drill unattended whilst it is running. Turn the machine OFF and do not
leave until it has come to a complete stop.
8. When you have finished with the machine, always remove and store the drill bits.
9. CAUTION: This Drill Press is designed for use with Drill Bits ONLY. The use of other cutting
tools or accessories could be hazardous.
10. ALWAYS use clamps, or a drill vice bolted to the table, to hold the work. It should NEVER
be held in bare hands.
16
5
ELECTRICAL CONNECTIONS
Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an
approved 13 amp BS 1363 plug, or a suitably fused isolator switch.
WARNING! THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in the mains lead are coloured in accordance with the following
code;
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the flexible lead of this appliance may not correspond with the coloured
markings identifying terminals in your plug proceed as follows:
Connect GREEN & YELLOW cord to terminal marked with a letter “E” or Earth symbol
“ ” or coloured GREEN or GREEN & YELLOW.
Connect BROWN cord to terminal marked with a letter “L” or coloured RED.
Connect BLUE cord to terminal marked with a letter “N” or coloured BLACK.
If this appliance is fitted with a plug which is moulded onto the electric cable (i.e. nonrewirable) please note:
1. The plug must be thrown away if it is cut from the electric cable. There is a danger of
electric shock if it is subsequently inserted into a socket outlet.
2. Never use the plug without the fuse cover fitted.
3. Should you wish to replace a detachable fuse carrier, ensure that the correct
replacement is used (as indicated by marking or colour code).
4. Replacement fuse covers can be obtained from your local dealer or most electrical
stockists.
FUSE RATING
The fuse in the plug must be replaced with one of the same rating (13 amps) and this
replacement must be ASTA approved to BS1362
PARTS LIST
Item Description Part No
1 Base HC5001
2 Flange HC5002
3 Hex. Bolt HC5003
4 Column HC5004
5 Hex. Bolt HC5005
6 Table HC5006
7 Locking Handle HC5007
8 Table Support HC5008
9 Scale HC5009
10 Nut HC5010
11 Spring Cover HC5011
12 Coil Spring HC5012
13 Spring seat HC5013
14 Chuck HC5014
15 Spindle HC5015
16 Nut HC5016
17 Plastic Ring HC5017
18 Set Screw HC5018
19 Nut HC5019
20 Depth Indicator Pin HC5020
21 Nut HC5021
22 Depth Indicator HC5022
23 Bearing HC5023
24 Quill HC5024
25 Ring HC5025
26 Lock Washer HC5026
27 Set Screw HC5027
28 Earth Screw HC5028
29 Shakeproof Washer HC5029
30 Screw HC5030
31 Nut HC5031
32 Housing HC5032
33 Feed Shaft HC5033
34 Handle HC5034
35 Handle Tip HC5035
36 Lock Washer HC5036
37 Lock Washer HC5037
38 Bearing HC5038
39 Sleeve HC5039
Item Description Part No.
40 Pulley Cover HC5040
41 Washer HC5041
42 Set Screw HC5042
43 Micr Sw. Protector HC5043
44 Microswitch HC5044
45 Protector Cover HC5045
46 Screw HC5046
47 Washer HC5047
48 Set Screw HC5048
49 Set Screw HC5049
50 Washer HC5050
51 Push Arm HC5051
52 Set Screw HC5052
53 Washer HC5053
54 Washer HC5054
55 Nut HC5055
56 Set Screw HC5056
57 Washer HC5057
58 Spring HC5058
59 Rod HC5059
60 Tip HC5060
61 Nut HC5061
62 Pin HC5062
63 Hex. Bolt HC5063
64 Washer HC5064
65 Motor Mounting Plate HC5065
66 Hex. Bolt HC5066
67 Switch HC5067
68 Set Screw HC5068
69 Cable HC5069
70 Motor HC5070
71 Spindle Pulley HC5071
72 Set Screw HC5072
73 Motor Pulley HC5073
74 V-Belt HC5074
75 Chuck Guard HC5075
76 Set Screw HC5076
77 Nut HC5077
- Chuck Key HC5078
6
15
TROUBLE SHOOTING
PREPARATION
PROBLEM
Noisy operation
(under load)
Excessive
drill wobble
Motor won’t
start
Drill binds
in workpiece
Drill bit burns
or smokes
PROBABLE CAUSE REMEDY
A) Incorrect belt tension
B) Dry spindle
C) Loose pulley
D) Loose belt
E) Worn bearing
A) Loose chuck
B) Worn spindle, or bearing
C) Worn chuck
D) Bent drill bit
A) Power supply
B) Motor connection
C) NVR Switch connections
D) Faulty switch
E) Motor windings burned
F) Pulley Cover not closed.
G) Micro Switch inoperative.
A) Excessive feed pressure
B) Loose belt
C) Loose drill
D) Incorrect bit speed.
E) Drill angles incorrect for
type of material
A) Incorrect speed.
B) Chips are not discharging
C) Dull drill or not proper
clearance for material.
D) Needs coolant
E) Excessive feed pressure
A) Adjust tension
B) Remove spindle/quill assembly
and lubricate
C) Tighten pulley
D) Adjust belt tension
E) Replace bearing
A) Tighten by pressing chuck down
on to a block of wood against the
table.
B) Replace spindle shaft or bearing
C) Replace chuck
D) Renew Drill bit
A) Check power cord/fuse
B) Check motor connections
C) Check switch connections
D) Replace switch
E) Replace motor
F) Close pulley cover.
G) Check operation of micro switch,
and renew/adjust as necessary.
(Consult your Clarke dealer for advice.)
A) Apply less pressure
B) Check belt tension
C) Tighten drill with key
D) Refer to Cutting Speed chart,
and adjust drill speed accordingly
E) Consult an appropriate manual
re. Materials, Drills and Cutting
Angles, and sharpen drill
accordingly.
A) Refer to Cutting Speed chart,
and adjust drill speed accordingly
B) Clean drill
C) Check sharpness & taper
D) Use coolant whilst drilling
E) Apply less pressure
On receipt, carefully unpack the components, ensuring that no damage was suffered in
transit, and that all parts are accounted for.
The following items are to be found in the packing case.
A. Head and Motor Assy.
B. Column.
C. Base
D. Table
E. Chuck Guard Assy.
F. Chuck
G. Chuck Key
H. Feed Handles 3-off
J. Screws 3-off
K. Table Locking Lever
L. Depth Stop Assy
M. Hex. Wrench
Check the parts off against the above list.
Should there be any deficiencies or damage, you should contact your CLARKE dealer
immediately .
Remove all traces of preservative from the components with paraffin or a good quality
solvent, and wipe all parts thoroughly with a clean dry cloth. Apply a coating of wax paste
or light oil, to the table, column and base, to prevent rust.
Take the necessary precautions when lifting the head assembly, considering its weight.
Assistance will be required.
Before use, the machine must be mounted, and securely bolted, to a strong, heavy
workbench, of sufficient height so that you do not need to bend your back to perform
normal operations.
Ensure the location is adequately lit, and that you will not be working in your own shadow.
Table difficult to
raise
A) Needs lubrication
B) Table lock tightened
A) Lubricate with light oil
B) Loosen clamp
14 7
ASSEMBLY
MAINTENANCE
WARNING!
IT IS STRONGLY ADVISED THAT ASSISTANCE BE USED WHEN ASSEMBLING THIS MACHINE.
A. Column to the Base.
Bolt the column assembly to the base with the three hex. screws provided.
NOTE: Ideally, the base with column attached, should be
firmly bolted to the workbench, prior to the assembly of
other components.
B. Table to Column.
1. Thread the Table Locking Handle into the Table
Support from the left hand side, and leave it loose at
this stage.
2. Slide the Table Support with Table, over the Column,
and allow it to rest against the base, as shown in Fig.1.
C. Head to Column.
NOTE: It may be necessary to unscrew the two Head Lock
Set Screws slightly, to ensure they do not protrude
internally, as this would prevent the head from sliding fully
into position.
1. With assistance, raise the Head, and locate it on top
of the Column, ensuring it slides home fully.
2. Align the head with the base, and firmly secure to the
Column with the hex. socket Head Screws as shown
in Fig. 2
Fig. 1
Fig. 2
Fig. 3
For maximum performance, it is essential that the Drill Press is properly maintained. Always
inspect before use. Any damage should be repaired, and maladjustments rectified.
Please refer to the trouble shooting chart on page 14 . If you are unable to rectify any faults,
please contact your local dealer or Clarke International Service Division on 020 8556 4443 for
assistance.
Monthly (When in constant use)
1. Check tightness of mounting bolts, and, head and column securing set screws.
2. Check belt for wear, and replace if frayed or damaged in any way.
3. Blow out any dust that may have accumulated in the motor fan.
4. Apply a thin coat of wax paste or light oil to the table and column, for lubrication, and
to help prevent corrosion.
If the mains lead is worn or cut, or damaged in any way, it should be replaced immediately.
Lubrication
All bearings are packed with grease at the factory and require no further lubrication.
Lubricate the Quill Shaft assembly with light oil, weekly.
After use
Remove all swarf from the machine and thoroughly clean all surfaces.
Components should be dry, with machined surfaces lightly oiled.
Always remove drill bits, and store in a safe place.
CUTTING SPEEDS
Factors which determine the best speed to use in any drill press operation are:
• Kind of material being worked • Size of hole • Quality of cut desired • Type of Drill
Generally, the smaller the drill, the greater the required RPM. In soft material, the speed
should be higher than for hard metals.
As a guide, the drill speed for a given drill bit size, is according to the table below.
3. Screw the three feed handles, firmly into the hub of
the feed shaft. (Fig. 3)
8
Speed Range
(RPM)
Wood
Alum & Brass
Zinc Diecast
Iron & Mild
Steel
2530 1980 1470 950 545
in 3/8 (5/8) (7/8) (1) (1¼ )
mm 9.5 (16) (22) (25.4) (31.75)
in 7/32 11/32 15/32 1/2 (11/16)
mm 5.6 8.75 12 12.7 (17.5)
in 3/32 5/32 1/4 3/8 1/2
mm 2.4 4 6.4 9.5 12.5
13
OPERATION.
1 . Insert the drill into the jaws of the chuck by approx 1", ensuring that the jaws do not touch
the flutes of the drill. Before tightening the chuck, ensure that the drill is centred within the
jaws.
2. Ensure the table height and position is set, so that drill travel is sufficient for the job in
hand.
3. Ensure the work is securely clamped, or held in a drill vice, bolted to the table. Never hold
it with bare hands. Severe personal injury may be caused if the workpiece is whipped
out of the operator’s hand, and damage to the machine incurred if the work strikes the
column.
If the piece is of irregular shape and cannot be laid flat on the table, it should be securely
blocked and clamped.
Any tilting, twisting, or shifting, results not only
in a rough hole, but also increases drill
breakage.
4. For small workpieces that cannot be
clamped to the table, use a Drill Press Vice.
The vice must be clamped or bolted to the
table.
5. When drilling completely through wood,
always position a piece of scrap wood
between the workpiece and the table to
prevent splintering on theunderside of the
workpiece as the drill breaks through. The
scrap piece of wood must make contact
with the left side of the column as shown in
Fig 9 In addition, set the depth of drill travel
so that the drill cannot possibly come into
contact with the table, or align the table so
that the hole in its’ centre is in line with the
drill bit.
6. When completely satisfied that the setup is sound, lower the Chuck Guard into place,
and switch the machine ON by pushing the ‘I’ button. To switch OFF...push the ‘O’
button, see fig. 10.
NOTE:
1. As a safety feature, the ON/OFF switch is a
No Volt Release type. Therefore, if the
power is interrupted whilst the machine is
switched ON, it will not automatically start
when the power is restored.
2. A Micro switch is provided within the Pulley
Cover, which prevents the machine from
operating unless the Pulley Cover is firmly
closed.
A complete range of Drill Press vices, Cross Vices
and Clamps, is available from your Clarke dealer
Fig. 9.
Fig. 10.
D. Chuck Guard Assembly
Slide the Chuck Guard over the Quill Shaft and nip up the pinch bolt at the rear of the
assembly. Ensure the Quill Shaft/Spindle is at the top of its travel.
NOTE: This operation should be carried out before the chuck is installed.
E. Installing the Chuck.
1. With the chuck guard lifted clear of the
spindle nose and turned so that the pinch bolt
is facing the front, as shown in Fig.4, slide the
work table up the column to within 6" of the
spindle.
2. Open the jaws of the chuck to their
maximum, using the chuck key supplied.
3. Put a piece of scrap wood on to the table to
protect the chuck nose, see illustr. opposite.
4. Ensuring all parts are thoroughly clean, dry,
and burr free, place the chuck over the end
of the spindle, and pull the spindle down
using the feed handles, pressing the chuck
jaws hard against the piece of scrap wood
until the chuck is forced home. (See Fig.4)
5. When the chuck is installed, turn the chuck
guard around so that the shield is facing the
front, and tighten the pinch bolt to secure it in
position.
Fig. 4
Fig. 5
F. Tensioning the Drive Belt.
The drive belt is pre-installed, but should it require
tensioning or spindle speed to be changed,
proceed as follows:
1. Undo the Belt Tension Locking Knob to
relieve any tension on the belt, and referring
to the chart inside the belt cover (which is
duplicated on page 11), install the belt in the
position corresponding to the spindle speed
required.
2. Lever the motor, on its bracket, away from
the head, so that tension is applied to the
belt. Tension is correct, when the belt
deflects by approx. ½” at its centre, when
using reasonable thumb pressure. Lock the
motor in this position using the Locking Knob.
NOTE: If the belt should slip whilst drilling,adjust
the belt tension.
IMPORTANT. When closing the cover, check the
operation of the microswitch. It should operate
IMMEDIATELY the cover is opened. Undo the
microswitch fixing screws and adjust accordingly.
Locking Knob
Fig. 6
12 9
G.Assembling the Spindle Depth Stop Assy.
Fig. 7
Slide the end of the threaded rod through the
bracket on the side of the head and through the
hole in the top of the Chuck Guard. Secure with
the nut provided, from beneath, thereby locking
the Depth Stop to the Chuck Guard and hence
the Spindle.
(Therefore, as the Spindle is moved downwards,
the depth Stop will move by the same amount).
The pointer may be zeroed by sliding it up or down
on its mounting.
For adjustments, see below.
Lock Nut
Adjuster Nut
Face A
B
SETTINGS and ADJUSTMENTS
1. Table.
The table may be raised, lowered or swivelled about
the column, by slackening off the table support
locking handle, adjusting accordingly, and retightening the handle. It may also be tilted by
loosening the Set Screw beneath the table, tilting to
the required position, and re-tightening the Set
Screw.
A bevel scale, is provided on the table mounting,
measured in degrees, to assist in setting the required
angle.
For all normal operations, the table should be set to
0°.
To check to ensure the drill is entirely perpendicular to
the table, insert a piece of straight round bar in the
chuck, place a square on the table, and bring it up to
the round bar. Adjust the table tilt if necessary, so that
the table is perfectly square.
2. Spindle Depth Stop Assy (Ref Fig. 7)
To set a required depth of hole, adjust the Depth Stop as Follows:
1. Lower the Chuck with the power OFF, until the drill contacts the surface of the
workpiece, and hold in that position.
2. Spin down the adjuster nut so that the gap between its’ underside, and face of the
bracket (A fig 7) is the depth of the hole required, (shown at ‘B’). Spin down the lock nut
and lock it against the adjuster nut.
Fig. 8
The drill is now set to drill holes to your predetermined depth, from that particular start point.
i.e. Providing the surface of your workpiece is flat and level, you may drill a series of holes,
each to the same depth.
The scale and pointer can be used to drill one off, by lowering the chuck as described
above, until the drill contacts the work, setting the pointer against a set point on the scale,
switching ON the drill, and proceeding to drill to the required depth, using the scale.
3. Changing Drill (Spindle) Speed.
Before changing the speeds, ensure the machine is switched OFF, and disconnected from
the mains supply.
1. Open the pulley cover.
2. Slacken off the Belt Tension Locking Knob, to relieve any tension on the drive belt.
3. Consult the chart inside the pulley cover, and position the belt on the pulley’s,
according to the spindle speed required.
4. When the belt has been correctly positioned, re-tension by levering the motor away from
the head, until the belt deflects by approx. ½” at its centre when using reasonable
thumb pressure. Lock the motor in this position with the Belt Tension Locking Knob.
DRILL SPEED TABLE
The table below gives the belt arrangement for given drill speeds. The diagram shows the
belts fitted to step D of the Spindle Pulley, and step 4 of the Motor Pulley, giving a spindle
speed of 1,980 RPM.
A full chart is also located on the inside of the pulley cover.
SPINDLE PULLEY
E
D
C
B
A
Spindle Speed Belt Position
545 RPM A1
950 RPM B2
1470 RPM C3
1980 RPM D4
2530 RPM E5
MOTOR PULLEY
5
4
3
2
1
10
11
Loading...
