Clarion MS2007 User Manual

ongratulations on your purchase of this Ungo System. Please read this manual thoroughly to familiarize yourself with your

system’s components and operation. Discuss any questions you

might have with your installing dealer.

Record the serial number of your Ungo System and keep all dealer records and receipts. Be sure to discuss the installation with the dealer so that you understand the specifics of the installation in your vehicle.

CAUTIONS

• USE OF THE UNGO MS2007 IS THE RESPONSIBILITY OF THE OWNER.

• KEEP THE REMOTE TRANSMITTERS OUT OF THE REACH OF CHILDREN.

• THE UNGO MS2007 IS NOT INTENDED FOR USE ON VEHICLES EQUIPPED

WITH A MANUAL TRANSMISSION.

• BE SURE THE TRANSMISSION IS IN PARK BEFORE LEAVING THE VEHICLE.

• ONLY REMOTE START THE VEHICLE IN A WELL VENTILATED AREA.

Table of Contents

1. About Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1

2. Remote Transmitters

3. Security Features

4. Remote Start Features

5. Other Features

6. Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 12

7. Reference Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 13

8. System Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 14

9. Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 14

10. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 15

Remote Transmitter Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2

Optional Driver Door Priority Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2

Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

Adding a New Transmitter into the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

Additional Remote Transmitters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

Remote Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 4

Remote Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 4

Tamper Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5

Silent Arming / Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5

Arming Mode Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5

Passive Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5

Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 6

Emergency Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 6

Automatic System Rearming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 7

Remote Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 8

Shut Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 8

Stop and Go Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 8

Automatic Cold Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 9

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10

Ignition Controlled Door Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10

Ignition Controlled Door Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10

Dome Light Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 11

Auxiliary Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 11

Remote Sensor Bypass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 11

Note: Certain features described in this manual may require additional parts and/or labor. Also, some features of

the Ungo MS2007 system have selectable options that must be activated or programmed during the system’s installation. These items will be identified in the following sections. Your Authorized Ungo Dealer will be happy to discuss these features with you and help you design your system to meet your needs.

About Your Ungo System

The Ungo MS2007 is a state-of-the-art combination vehicle security and remote controlled car starter system. The MS2007 offers security features designed to deter and detect potential intrusions to your vehicle. It will alert and inform the driver and people in the vicinity of your vehicle when a zone is violated.

The MS2007 will inform the user of any defective zones while arming, and in the event that the system is triggered, the MS2007 transmitter will even specify which zone was violated. The MS2007 protects both you and the contents of your vehicle with features such as panic mode, dome light illumination, and ignition controlled door locking.

In addition to its security features, the MS2007 will safely start your car by remote control, without your key in the ignition. If your vehicle is powered by a diesel engine, the MS2007 will turn on the ignition for several seconds prior to starting the engine, in order for the glow plugs to warm up.

Once the MS2007 has started the engine, it will turn on your preset accessories (heater/air conditioner) to provide you with the maximum comfort when you enter your vehicle. After activation, the MS2007 will allow the vehicle to run for approximately 15 minutes (or 30 minutes if selected by your installer at the time of installation) before automatically shutting off.

Each Ungo MS2007 System comes with:

• Main Unit

• One 4-Button LCD Remote Transceiver

• 125dB Siren

• Extended Range Transceiver

• Status LED

• 2 Stage Electronic Shock Sensor

• Emergency Override / Valet Switch

Safety Features

• Brake Pedal Shutdown - Shuts down the remote start when the brake pedal is pressed.

• Hood Pin Switch Protection (optional) - Prevents the engine from being started while the hood is open.

• Valet Mode - Prevents the vehicle from being started when being serviced.

Options and Convenience Features

The advanced design of the Ungo system incorporates a number of optional inputs and outputs allowing you to create a customized security / convenience system by easily accommodating many optional convenience and security features such as:

• Remote Door Locking

• Remote Window Control

• Power Trunk / Hatch Release

• Glass Breakage Sensor

• Radar Sensor

• Back-up Battery

MS2007 Owner’s Manual - Page 1

Remote Transmitters

Remote Transmitter Layout

LED

Button 1 Button 2

II III

Button 3 Button 4

The Ungo MS2007 comes with a multi-function LCD Remote Transmitter featuring two-way communication with the vehicle. Each time a transmitter button is pressed, the LED will flash and the transmitter will beep to indicate that a transmission is taking place. If the transmitter is within two-way communication range, the LCD will display the status of the system. The transmitter is also equipped with a built-in chime that will play a tune as confirmation of some features such as remote starting, clock setting, etc.

Button 1 Arms and Disarms the system. This button also activates the system’s Panic feature.

Button 2 Activates the system’s Auxiliary Function, commonly used for trunk release.*

Button 3 Activates the system’s Remote Start Feature.

Button 4 Confirms the system’s status. This button also activates the LCD backlight for night

time use.

LCD Display

The MS2007 Remote Transmitter is equipped with an LCD panel that displays the system’s status information. If the transmitter is within range of the vehicle and a button is pressed, or the vehicle is tampered with, the LCD display will show what action is taking place. The LCD display is backlit for easy viewing at night and will illuminate wihen Button 4 is pressed, or when confirmation of any action is received by the transmitter.

Setting the Clock

The remote transmitter has a built-in clock that displays the current time.

To set the clock:

1. Press transmitter Button 2 and Button 3 simultaneously for two seconds.

• The LCD will show .

Page 2 - MS2007 Owner’s Manual

2. Press transmitter Button 2 to set the hour.

3. Press transmitter Button 3 to set the minutes. Hold Button 3 to advance the minutes rapidly.

• The hour will be displayed followed by either an “A” or “P” to indicate AM or PM.

4. Press transmitter Button 4 to save the time setting.

• The transmitter will play a tune to confirm the time is set.

Setting the Alarm Clock

The built-in alarm clock function that plays an alert tone when .

To set the Alarm Clock:

1. Press transmitter Button 2 and Button 3 simultaneously for four seconds.

• The LCD will show then show and .

2. Press transmitter Button 2 to set the hour.

3. Press transmitter Button 3 to set the minutes. Hold Button 3 to advance the minutes rapidly.

• The hour will be displayed followed by either an “A” or “P” to indicate AM or PM.

4. Press transmitter Button 4 to save the time setting.

• The transmitter will play a tune to confirm the alarm clock is set.

• When the alarm goes off, the transmitter will play an alert tune for 10 seconds or until Button 4 is pressed.

Battery Replacement

Your Ungo Remote Transmitter uses a standard AAA battery, which will need to be replaced from time to time. Under normal conditions, the battery should last for up to three months before it needs replacement.

When your Remote Transmitter’s battery is in need of replacement, the battery symbol on the LCD display panel will flash.

To change the battery, slide down the battery cover on the back of the transmitter and insert the new battery. Make sure the positive and negative terminals are positioned correctly and replace the cover.

Adding a New Transmitter into the System

Have all desired transmitters ready (up to 2 transmitters) and follow the steps below:

1. Turn the ignition on, off, on, off, on within 4 seconds.

• The status LED and parking lights will flash once.

MS2007 Owner’s Manual - Page 3
