Professional Firmware Manual ver.1.0
Odnosi se na modele iClock-880, iClock-580, iClock 700, iClock-S680, iClockS900, iClock-S500, iClock-360, iClock-560, iClock-260 / 360, iClock-S560,
iClock-660, iClock-S880
PROFESSIONAL FIRMWARE VERSION
2013
1
Index:
Getting started ....................................................................................................................... 3
1.1 Fingerprint Placement ........................................................................................................ 3
1.2 Instruction for Card Swipe.................................................................................................. 3
1.3 Precautions ......................................................................................................................... 4
Introduction of Device ........................................................................................................ 4
2.1 Overview of Device Functions ............................................................................................ 4
2.2 Important Safeguards ......................................................................................................... 4
2.2.1 Installation Location .................................................................................................... 4
2.2.2 Use of Sensor ............................................................................................................... 5
2.2.3 Product Appearance .................................................................................................... 5
2.3 Using the Fingerprint Terminal .......................................................................................... 5
2.4 Date / Time Adjustment ..................................................................................................... 6
2.5 Enroll Administrator / User ................................................................................................ 6
2.6 Password Enrolment .......................................................................................................... 7
2.7 RFID Card Enrolment .......................................................................................................... 7
2.7.1 ID Technology .............................................................................................................. 7
2.7.2 MF Technology (Only for terminals which include MF Module) ............................... 8
2.8 Manage Users ..................................................................................................................... 8
2.9 Events .................................................................................................................................. 9
2.10 Access (only for terminals with relay) ............................................................................. 9
SYSTEM .................................................................................................................................... 10
3.1 Communications ............................................................................................................... 10
3.1.1 Network ..................................................................................................................... 11
3.1.2 Serial Port options ..................................................................................................... 11
3.1.3 Security options ......................................................................................................... 12
3.1.4 Wiegand ..................................................................................................................... 12
3.1.5 Wireless setup (Only for terminals with WI-FI) ........................................................ 14
................................................................................................................................................. 14
PROFESSIONAL FIRMWARE VERSION
2013
2
3.1.6 Dial –Up settings GPRS (Only for terminals with GPRS) ........................................... 15
3.2 Language ........................................................................................................................... 15
3.3 Fingerprint ........................................................................................................................ 16
3.4 Update .............................................................................................................................. 17
3.5 Display ............................................................................................................................... 17
3.6 Advanced options ............................................................................................................. 18
3.7 System info ....................................................................................................................... 18
3.7.1 Record capacity ......................................................................................................... 19
3.7.2 Device information .................................................................................................... 19
Terminal settings ................................................................................................................ 20
4.1 Keypad .............................................................................................................................. 20
................................................................................................................................................. 21
4.2 Barcode settings ............................................................................................................... 21
4.3 Pen drive Management .................................................................................................... 22
4.3.1. Download .................................................................................................................. 22
4.3.2. Upload ....................................................................................................................... 22
4.3.2. Pen drive Settings ..................................................................................................... 23
4.3 Bell .................................................................................................................................... 24
4.4 Log Settings ....................................................................................................................... 24
4.4 Multi-verify settings ......................................................................................................... 25
4.5 Reset ................................................................................................................................. 25
4.6 Auto test ........................................................................................................................... 26
Data Management ............................................................................................................. 27
5.1 Data Management ............................................................................................................ 27
PROFESSIONAL FIRMWARE VERSION
2013
3
Getting started
1.1 Fingerprint Placement
Recommended fingers: The index finger, middle finger or the ring finger; the thumb
and little finger are not recommended (because they are usually clumsy on the
fingerprint Collection screen).
Please enroll and verify your fingerprint by using the proper finger placement mode.
We shall not be held accountable for any consequences arising out of the degradation
in verification performance due to improper user operations. We shall reserve the
right of final interpretation and revision of this document.
1.2 Instruction for Card Swipe
This device is supplied with an integrated non-contact RFID (125 MHz) card reader
module. By offering multiple verification modes such as fingerprint, RF card and
fingerprint + RF card verification, this device can accommodate diversified user needs.
Swipe your card across the sensor area after the voice prompt and remove your card
after the device has sensed it. For the swipe area, please see 2.2.3 Product
appearance.
PROFESSIONAL FIRMWARE VERSION
2013
4
1.3 Precautions
Protect the device from exposure to direct sunlight or bright light, this greatly affects
the fingerprint collection and leads to fingerprint verification failure. It is
recommended to use the device under a temperature of 0–50°C so as to achieve the
optimal performance. In the event of exposure of the device to the outdoors for long
periods of time, it is recommended to adopt sunshade and heat dissipation facilities
because excessively high or low temperature may slow down the device operation and
result in high false rejection rate (FRR). When installing the device, please connect the
power cable after connecting other cables. If the device does not operate properly, be
sure to shut down the power supply before performing necessary inspections. Note
that any live-line working may cause damage to the device and the device damage
arising out of live-line working falls beyond the scope of our normal warranty.
For matters that are not covered in this document, please refer to related materials
including the installation guide, access control software user manual.
Introduction of Device
2.1 Overview of Device Functions
As an integrated fingerprint & access control device, our product can be connected
with either an electronic lock or an access controller. This device features simple and
flexible operations and supports the use of administrators. The screen displays will
guide you through all the operations. It supports access control function for a security
management and supports multiple communication modes.
2.2 Important Safeguards
2.2.1 Installation Location
Do not install terminal in areas which are exposed to bright sunlight or rain, as
the fingerprint readers are not designed to work in those areas. Bright light will
interfere with reading of the sensor and fingerprint readers are not waterproof
or vandal proof. It is recommended to protect your fingerprint terminal with
enclosure.
PROFESSIONAL FIRMWARE VERSION
2013
5
2.2.2 Use of Sensor
Do not abuse the fingerprint sensor by scratching the surface, contacting the
sensor’s surface with heat, pressing hard during placement of fingerprint for
verification. Clean the sensor occasionally with cellophane tape to maintain the
performance of the sensor.
2.2.3 Product Appearance
Front view:
2.3 Using the Fingerprint Terminal
This chapter will guide on how to use the fingerprint terminal effectively. To get a good
reading every time, initial fingerprint enrollment must be done properly. The
fingerprint terminal provides 4 types of enrolment methods:
• Fingerprint enrolment
User enrolls his fingerprint template into a terminal and the template will be used for
future verifications.
• Password enrolment
For user who has difficulty to enroll fingerprint due to poor fingerprint quality,
enrolment of password is recommended. Password enrolment is also suitable for
visitors and temporary workers.
PROFESSIONAL FIRMWARE VERSION
2013
6
• Fingerprint and password enrolment
Under this option, a user can enroll both fingerprint and password at the same time.
The user can either use fingerprint or password to report attendance or to gain access.
• RFID card enrolment
User can enroll RFID Card
2.4 Date / Time Adjustment
When first installing a fingerprint terminal, it is important to set the correct date and
time.
Follow the steps shown to access the Date/Time adjustment menu:
You can insert inputs into the terminals through the keypad. It contains
numbers from 0-9, an OK button, an ESC/Cancel button, a Scroll up/down
button, a doorbell button and a Menu button.
2.5 Enroll Administrator / User
Once the fingerprint terminal is switched on, a display on the screen will appear. Enroll
a supervisor or an administrator, who is the in-charge person to administer the
fingerprint templates and the transaction data in the terminal. Choose trustworthy
people for this particular role
PROFESSIONAL FIRMWARE VERSION
2013
7
2.6 Password Enrolment
If a user cannot enroll his fingerprint or wants also another kind of verification, he can
choose to use passwords. Password may contain numbers ranging from 1 – 8 digits.
2.7 RFID Card Enrolment
2.7.1 ID Technology
If a user cannot enroll his fingerprint, he can choose to use a RFID Card. RFID card is for
added security on the unit, or if the user can’t use a fingerprint.
PROFESSIONAL FIRMWARE VERSION
2013
8
2.7.2 MF Technology (Only for terminals which include MF Module)
This menu only will be showed when the terminal includes Mifare module and the
configuration about how we want the MF cards work will be defined here. MF cards
are special and we can read and write data, so we can set the cards as PIN Card, or
store the templates in the MF Card which is very useful to ensure data protection laws
in some countries
2.8 Manage Users
To open the manage screen, you may click on F5 key. When you are in the manage
user screen you can make some actions related with the users pressing menu key as
search, record, edit, delete and create.
