Owner’s manual
Mode d’emploi
Manual de instrucciones
DXZ555MP
CD/MP3/WMA Receiver / CeNET Control
•
Récepteur CD/MP3/WMA / Commande CeNET
•
Reproductor de discos CD/MP3/WMA con
receptor y control CeNET
Thank you for purchasing this Clarion product.
English
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗ This manual includes the operating procedures of the CD changer and TV tuner connected via the
CeNET cable. The CD changer and TV tuner have their own manuals, but no explanations for
operating them are described.
Contents
1. FEATURES...................................................................................................................................... 2
2. PRECAUTIONS .............................................................................................................................. 3
Flip Down Panel .............................................................................................................................. 4
Handling Compact Discs ................................................................................................................. 4
3. CONTROLS .................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of the Buttons and their Functions ...................................................................................... 6
Major button operations when external equipment is connected to this unit ................................... 7
Display Items ................................................................................................................................... 8
LCD Screen ..................................................................................................................................... 8
5. DCP ................................................................................................................................................. 9
6. REMOTE CONTROL ..................................................................................................................... 10
Inserting the Battery ...................................................................................................................... 10
Functions of Remote Control Unit Buttons ..................................................................................... 11
7. OPERATIONS ............................................................................................................................... 12
Basic Operations ........................................................................................................................... 12
Radio Operations ........................................................................................................................... 14
CD/MP3/WMA Operations ............................................................................................................. 16
Operations Common to Each Mode .............................................................................................. 20
8. OPERATIONS OF ACCESSORIES .............................................................................................. 22
CD Changer Operations ................................................................................................................ 22
TV Operations ............................................................................................................................... 23
9. IN CASE OF DIFFICULTY ............................................................................................................ 24
10. ERROR DISPLAYS ....................................................................................................................... 25
11. SPECIFICATIONS ......................................................................................................................... 26
1. FEATURES
• High Visibility & Contrast Negative Display with Screen Saver
• MP3 and WMA File Playable with ID3-TAG and WMA-TAG Display
• MOS FET 53W X 4 Built in High Power Amplifier
• 4ch RCA output for Flexibility
• AUX Input for External Device
• Z-Enhancer Plus with 2 Band Parametric Equalizer and Magna Bass EX
• Flip-Down Type High Quality Aluminum Faceplate
• Remote Control and DCP Case Included
2 DXZ555MP
2. PRECAUTIONS
1. When the inside of the car is very cold and the
player is used soon after switching on the
heater moisture may form on the disc or the
optical parts of the player and proper playback
may not be possible. If moisture forms on the
disc, wipe it off with a soft cloth. If moisture
forms on the optical parts of the player, do not
use the player for about one hour. The
condensation will disappear naturally allowing
normal operation.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to consult the dealer or
an experienced radio/TV technician for help.
2. Driving on extremely bumpy roads which
cause severe vibration may cause the sound
to skip.
3. This unit uses a precision mechanism. Even
in the event that trouble arises, never open
the case, disassemble the unit, or lubricate
the rotating parts.
CAUTION
USE OF CONTROLS, ADJUSTMENTS, OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN, MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
THE COMPACT DISC PLAYER and MINI DISC
PLAYER SHOULD NOT BE ADJUSTED OR
REPAIRED BY ANYONE EXCEPT PROPERLY
QUALIFIED SERVICE PERSONNEL.
CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED BY THE
MANUFACTURER FOR COMPLIANCE COULD
VOID THE USER’S AUTHORITY TO OPERATE
THE EQUIPMENT.
INFORMATION FOR USERS:.
CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED BY THE
MANUFACTURER WILL VOID THE
WARRANTY AND WILL VIOLATE FCC
APPROVAL.
Bottom View of Source Unit
Flip Down Panel
English
This unit uses a flip-down structure that makes possible large-size displays.
CAUTION
When opening and closing the FLIP DOWN
PANEL, be careful not to catch your fingers.
They could be injured.
1. Always use this unit with the FLIP DOWN
PANEL closed.
2. Do not force operations or use this device
abnormally when opening or closing the FLIP
DOWN PANEL.
3. Do not use the FLIP DOWN PANEL as a tray
to place objects on when it is open.
4. When closing the FLIP DOWN PANEL, do
not press the [OPEN] button.
5. Strong impacts to the operating or display
section can cause damage or deformation.
6. If the FLIP DOWN PANEL does not open
fully, gently open it with your hand.
Handling Compact Discs
•
Use only compact discs bearing the or
mark.
Do not play heart-shaped, octagonal, or other
specially shaped compact discs.
Some CDs recorded in CD-R/CD-RW mode
may not be usable.
Handling
•
Compared to ordinary music CDs, CD-R and
CD-RW discs are both easily affected by high
temperature and humidity and some of CD-R
and CD-RW discs may not be played. Therefore,
do not leave them for a long time in the car.
• New discs may have some roughness around
the edges. If such
discs are used, the
player may not work
or the sound may
skip. Use a ball-point
pen or the like to
remove any
roughness from the
edge of the disc.
•
Never stick labels on the surface of the compact
disc or mark the surface with a pencil or pen.
• Never play a compact disc with any
cellophane tape or other glue on it or with
peeling off marks. If you try to play such a
compact disc, you may not be able to get it
back out of the CD player or it may damage
the CD player.
Ball-point pen
Roughness
Do not use compact discs that have large
scratches, are misshapen, cracked, etc. Use of
such discs may cause misoperation or damage.
•
To remove a compact disc from its storage case,
press down on the center of the case and lift the
disc out, holding it carefully by the edges.
• Do not use commercially available CD
protection sheets or discs equipped with
stabilizers, etc. These may damage the disc or
cause breakdown of the internal mechanism.
Storage
• Do not expose compact discs to direct sunlight
or any heat source.
• Do not expose compact discs to excess
humidity or dust.
• Do not expose compact discs to direct heat
from heaters.
Cleaning
• To remove fingermarks and dust, use a soft
cloth and wipe in a straight line from the center
of the compact disc to the circumference.
• Do not use any solvents, such as commercially
available cleaners, anti-static spray, or thinner
to clean compact discs.
• After using special compact disc cleaner, let
the compact disc dry off well before playing it.
English
Be sure to unfold and read the next page. / Veuillez déplier et vous référer à la page suivante.
DXZ555MP 38 DXZ555MP
Cerciórese de desplegar y de leer la página siguiente.
DXZ555MP 4
English
3.CONTROLS / LES COMMANDES / CONTROLES
English
4. NOMENCLATURE
Source unit / Appareil pilote / Unidad fuente
Français
[
[
OPEN
]
]
[
ROTARY
[
SENSOR
]
[
]
]
ISR
Español
]
[a, d
[
]
ADJ
[
]
A-M
[
]
SRC
[
]
SCN
[
]
RPT
[
]
RDM
With the FLIP DOWN PANEL opened / Ouvrez le PANNEAU RABATTABLE
Apertura del PANEL ABATIBLE
[ ]
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
[
DIRECT
]
[
P.LIST
[
CD SLOT
[
[
BND
[UP], [DN]
]
]
M-B
]
Note:
• Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold).
Names of the Buttons and their Functions
[OPEN] button
• Deeply push in [OPEN] button to unlock the
flip down panel.
[ ] button
[D]
[Z+]
[T]
• Play or pause a CD while in the CD/MP3/
WMA mode.
• Perform preset scan while in the radio mode.
When the button is pressed and held, auto
store is performed.
[ROTARY] knob
• Adjust the volume by turning the knob
clockwise or counterclockwise.
]
• Use the knob to perform various settings.
[SENSOR]
• Receiver for remote control unit
• Operating range: 30° in all directions
[ISR] button
• Recall ISR radio station in memory.
• Press and hold for 2 seconds or longer: Store
current station into ISR memory (radio mode
only).
[D] button
• Switch the display indication (Main display,
Title display and Clock display).
• Press and hold the button for 1 second or
longer to enter the display adjust mode.
[Z+] button
• Use the button to select one of the 3 types of
sound characteristics already stored in
memory.
[T] button
• Use the button to input a title in the Tuner,
CD mode.
• Use the button to switch the user titles or
track titles, while in the CD/MP3/WMA mode.
• Use the button to scroll the title during the
CD-text play, while in the CD/MP3/WMA
mode.
[M-B] button
• Press the button to turn on or off the MAGNA
BASS EXTENED.
[BND] button
• Switch the band, or seek tuning or manual
tuning while in the radio mode.
• Play a first track while in the CD/MP3/WMA
mode.
• Press the button to change the character.
[UP], [DN] buttons
• Select the Folder. (MP3/WMA disc only)
6 DXZ555MP
[P.LIST] button
• Press and hold for 1 second or longer to turn
on or off the play list mode. (MP3/WMA disc
only)
[DIRECT] buttons
• Store a station into memory or recall it
directly while in the radio mode.
[RDM] button
• Perform random play while in the CD/MP3/
WMA mode.
• Press and hold the button for 1 second or
longer to perform folder random play while in
the MP3/WMA mode.
[RPT] button
• Repeat play while in the CD/MP3/WMA
mode.
• Press and hold the button for 1 second or
longer to perform folder repeat play while in
the MP3/WMA mode.
[SCN] button
• Perform scan play for 10 seconds of each
track while in the CD/MP3/WMA mode.
• Press and hold the button for 1 second or
longer to perform folder scan play while in the
MP3/WMA mode.
[SRC] button
• Press the button to turn on the power.
Press and hold the button for 1 second or
longer to turn off the power.
• Switches the operation mode among the
radio mode, etc.
[A-M] button
• Use the button to switch to the audio mode
(bass/treble, balance/fader Z-Enhancer Plus)
[ADJ] button
• Press the button to enter the adjust mode.
[a, d] lever
• Select a station while in the radio mode or
select a track when listening to a CD. This
lever is used to make various settings.
•
Press the lever upward or downward and hold
in position for 1 second or longer to enter the
fast-forward or fast-backward mode.
[Q] button
• Eject a CD/MP3/WMA when it is loaded into
the unit.
[CD SLOT]
• CD insertion slot.
Major button operations when external equipment is connected to this unit
English
● When the CD/DVD changer is
connected
∗ For details, see the section “CD changer
operations”. For the DVD changer, refer
to the Owner’s Manual provided with the
DVD changer.
[ ] button
• Play or pause a CD or DVD.
[D] button
• Press the button to display the title.
• Press and hold the button for 1 second or
longer to enter the display adjust mode.
[T] button
• Press the button switches the user titles or
track titles, etc. while in the CD changer mode.
• Press and hold the button for 1 second or
longer to input a title in the CD changer mode.
• Use the button to scroll the title during CD-
text play.
[BND] button
• Move the next disc in increasing order.
[UP], [DN] buttons
• Select the disc.
[RDM] button
•
Perform random play. Also perform disc random play when the button is pressed and held.
[RPT] button
• Perform repeat play. When this button is
pressed and held, disc repeat play is performed.
[SCN] button
• Perform scan play for 10 seconds of each
track. Disc scan play is performed when the
button is pressed and held.
[a, d] lever
• Select a track when listening to a disc.
• Press the lever upward or downward and hold
in position for 1 second or longer to enter the
fast-forward or fast-backward mode.
● When the TV is connected
∗
For details, see the section “TV operations”.
[ ] button
• Perform preset scan while in the TV mode.
When the button is pressed and held, auto
store is performed.
[BND] button
• Switch the band.
• When the button is pressed and held, switch
seek tuning or manual mode.
[DIRECT] buttons
• Store a station into memory or recall it directly.
[ADJ] button
• Switch the TV picture mode or VTR (external)
picture mode.
[a, d] lever
• Select a station.
● When the Sirius Satellite
Radio is connected
∗ For details, refer to the Owner’s Manual
provided with the Sirius Satellite Radio.
[ ] button
• Performs category scan while in the SIRIUS
mode. When the button is pressed and held,
preset scan is performed.
[ISR] button
• Select a category.
[DIRECT] buttons
• Stores a station into memory or recall it
directly while in the SIRIUS mode.
[SRC] button
• Press the button to switch the operation
mode among the SIRIUS mode, etc.
[a, d] lever
• Select a station.
What is Sirius Satellite Radio?
Sirius is radio the way it was meant to be: Up to
100 new channels of digital quality programming
delivered to listeners coast to coast via satellite.
That means 50 channels of completely commercialfree music. Plus up to 50 more channels of news,
sports, and entertainment from names like CNBC,
Discovery, SCI-FI Channel, A&E, House of Blues,
E!, NPR, Speedvision and ESPN.
Sirius is live, dynamic entertainment, completely
focused on listeners. Every minute of every day of
every week will be different. All 50 commercial-free
music channels are created in-house and hosted
by DJs who know and love the music. Do you like
Reggae? How about Classic Rock or New Rock?
Sirius has an array of choices spanning a vast
range of musical tastes including the hits of the
50’s, 60’s, 70’s, & 80’s as well as Jazz, Country,
Blues, Pop, Rap, R&B, Bluegrass, Alternative,
Classical, Heavy Metal, Dance and many others...
From its state-of-the-art, digital broadcasting
facility in Rockefeller Center, New York City,
Sirius will deliver the broadest, deepest mix of
radio entertainment from coast to coast.
Sirius will bring you music and entertainment
programming that is simply not available on
traditional radio in any market across the country.
It’s radio like you’ve never heard before.
So Get Sirius and Listen Up! For more
information, visit siriusradio.com.
DXZ555MP 75 DXZ555MP
Display Items
English
: MAGNA BASS EXTEND indication
Operation status indication
Titles, frequency, PS names, clock, etc. are displayed.
Mute indication
: Stereo indication
: Manual indication
: Folder indication
: Scan indication
: Repeat indication
: Random indication
: Disc indication
: Preset channel indication (1 to 8)
: Satellite indication
: MP3 indication
: WMA indication
: Z-Enhancer Plus
indication
LCD Screen
In extreme cold, the screen movement may slow down and the screen may darken, but this is normal.
The screen will recover when it returns to normal temperature.
5. DCP
English
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the DCP (DETACHABLE CONTROL PANEL)
case to prevent scratches.
We recommend taking the DCP with you when
leaving the car.
Removing the DCP
1. Press the [SRC] button for 1 second or
longer to turn off the power.
2. Deeply push in [OPEN] button to unlock the
flip down panel.
∗ If the flip down panel does not open fully,
gently open it with your hand.
[OPEN] button
DCP
3. Pull the DCP toward you and remove it.
DCP
4. Close the HOLD FLAP.
CAUTION
Be sure to close the HOLD FLAP for safety
when removing the DCP.
Attaching the DCP
1. Insert the right side of the DCP into the main
unit.
2. Insert the left side of the DCP into the main
unit.
2.
DCP
1.
CAUTION
• The DCP can easily be damaged by
shocks. After removing it, be careful not to
drop it or subject it to strong shocks.
• If the FLIP DOWN PANEL is kept open, the
DCP may drop due to vibration of the car.
This results in damage to the DCP. So
close the FLIP DOWN PANEL or remove
the DCP to store into the case.
• The connector connecting the source unit
and the DCP is an extremely important
part. Be careful not to damage it by
pressing on it with fingernails,
screwdrivers, etc.
Note:
• If the DCP is dirty, wipe off the dirt with a soft, dry
cloth only.
HOLD FLAP
DXZ555MP 9
English
6. REMOTE CONTROL
[
]
SRC
[
], [ ]
[
]
MUTE
[
]
ISR
[
]
SCN
Inserting the Battery
Signal transmitter
[
BND
[
[a], [d]
[
DISP
[
RDM
[
RPT
]
]
]
]
]
1 Turn over the remote control unit and slide the cover
in the direction indicated by the arrow in the
illustration.
2 Insert the battery (CR2025) into the insertion guides,
with the printed side (+) facing upwards.
3 Press the battery in the direction indicated by the
arrow so that it slides into the compartment.
4 Replace the cover and slide in until it clicks into place.
Notes:
Misuse may result in rupture of the battery, producing
leakage of fluid and resulting in personal injury or
damage to surrounding materials. Always follow these
safety precautions:
• Use only the designated battery .
• When replacing the battery, insert properly, with +/–
polarities oriented correctly.
• Do not subject battery to heat, or dispose of in fire or
water. Do not attempt to disassemble the battery.
• Dispose of used batteries properly.
10 DXZ555MP
Insertion guide
R
2
C
0
2
5
Functions of Remote Control Unit Buttons
English
Mode
Button
[SRC]
[BND]
[ ] , [ ]
[ ] , [ ]
[ ]
[MUTE]
[ISR]
[DISP]
[SCN]
Radio/SIRIUS CD/MP3/WMA
Switches among radio, SIRIUS tuner, CD/MP3/WMA, CD changer, DVD changer, TV and
AUX.
Switches reception
band.
Increases and decreases volume (in all modes).
Moves preset
channels up and
down.
No function.
Turns mute on and off.
Recalls ISR radio station in memory.
Press and hold for 2 seconds or longer: Stores current station into ISR memory (radio mode only).
Switches among main display, title display and clock display.
Preset scan.
When pressed and
held for 2 seconds:
Auto store.
Plays the first track.
Top play.
Moves tracks up and down.
When pressed and held for 1 second:
Fast-forward/fast-backward.
Switches between playback and pause.
Scan play.
Press and hold the
button for 1 second
or longer to perform
folder scan play while
in the MP3/WMA
mode.
CD changer
DVD changer
Moves the next disc
in increasing order.
Scan play.
When pressed and
held for 1 second:
Disc scan play.
TV
Switches reception
band.
Moves preset
channels up and
down.
No function.
Preset scan.
When pressed and
held for 2 seconds:
Auto store.
[RPT]
[RDM]
∗ Some of the corresponding buttons on the main unit and remote control unit have different functions.
No function.
No function.
Repeat play.
Press and hold the
button for 1 second
or longer to perform
folder Repeat play
while in the
MP3/WMA mode.
Random play.
Press and hold the
button for 1 second
or longer to perform
folder Random play
while in the
MP3/WMA mode.
Repeat play.
When pressed and
held for 1 second:
Disc repeat play.
Random play.
When pressed and
held for 1 second:
Disc random play.
No function.
Switches between TV
and VTR.
DXZ555MP 11
English
7. OPERATIONS
Basic Operations
Note:Be sure to read this chapter referring to the front diagrams of
chapter “3. CONTROLS” on page 5 (unfold).
CAUTION
Be sure to lower the volume before
switching off the unit power or the ignition
key. The unit remembers its last volume
setting. If you switch the power off with the
volume up, when you switch the power back
on, the sudden loud volume may hurt your
hearing and damage the unit.
Turning on/off the power
Note:
• Be careful about using this unit for a long time
without running the engine. If you drain the car’s
battery too far, you may not be able to start the
engine and this can reduce the service life of the
battery.
1. Press the [SRC] button.
2. The illumination and display on the unit light
up. The unit automatically remembers its last
operation mode and will automatically switch
to display that mode.
3. Press and hold the [SRC] button for 1
second or longer to turn off the power for the
unit.
Notes:
• System check
The first time this unit is turned on after the wire
connections are completed, it must be checked
what equipment is connected. When the power is
turned on, the “SYSTEM CHK” appears in the
display, then the unit returns to the clock display
mode. The system check starts within the unit.
When the system check is complete, press the
[SRC] button again.
• If no operation is performed for more than 7
seconds, the audio mode is cancelled and returns
to the previous mode.
Selecting a mode
1. Press the [SRC] button to change the
operation mode.
2. Each time you press the [SRC] button, the
operation mode changes in the following
order:
Radio mode ➜ SIRIUS mode ➜ CD/MP3/
WMA mode ➜ CD changer mode ➜ DVD
changer mode ➜ TV mode ➜ AUX mode ➜
Radio mode...
∗ External equipment not connected with
CeNET is not displayed.
12 DXZ555MP
Adjusting the volume
1. Press the front part of the [ROTARY] knob.
The knob will pop up.
2. Turning the [ROTARY] knob clockwise
increases the volume; turning it
counterclockwise decreases the volume.
∗ The volume level is from 0 (minimum) to 33
(maximum).
Switching the display
Press the [D] button to select the desired
display.
Each time you press the [D] button, the display
switches in the following order:
Main display ➜ Title display ➜ Clock display ➜
Main display ...
∗ Once selected, the preferred display becomes
the display default. When a function
adjustment such as volume is made, the
screen will momentarily switch to that
function’s display, then revert back to the
preferred display several seconds after the
adjustment.
∗ When you have entered a title in a CD/MP3/
WMA, it appears in the title display. If you
have not entered a title, “NO TITLE” appears
in the title display instead. For information on
how to enter a title, refer to the subsection
“Entering titles” in section “Operations
Common to Each Mode”.
Setting the Z-Enhancer Plus
This unit are provided with 3 types of sound
tone effects stored in memory. Select the one
you prefer.
∗ The factory default setting is “Z+ OFF”.
Each time you press the [Z+] button, the tone
effect changes in the following order:
“Z+ OFF” ➜ “BASS BOOST” ➜ “IMPACT” ➜
“EXCITE” ➜ “CUSTOM” ➜ “Z+ OFF” ...
• BASS BOOST : bass emphasized
• IMPACT : bass and treble
emphasized
• EXCITE : bass and treble
emphasized mid deemphasized
• CUSTOM : user custom
• Z+ OFF : no sound effect
Basic Operations
Adjusting the Z-Enhancer Plus
1. Press the [Z+] button and select the Z-
Enhancer Plus mode to adjust.
2. Press the [A-M] button and turning the
[ROTARY] knob clockwise adjusts in the +
direction; turning it counterclockwise adjusts
in the – direction.
● When “B-BOOST 0” selected, you can
adjust the bass in the range of –3 to 3.
● When “IMPACT 0” selected, you can
adjust the bass and treble in the range of
–3 to 3.
● When “EXCITE 0” selected, you can adjust
the bass and treble in the range of –3 to 3.
∗ When Z-Enhancer Plus is selected, press and
hold the [Z+] button for 1 second or longer to
change to the “CUSTOM” mode.
Bass/treble characteristics become flat and the
indication “Z+ FLAT” is shown in the display.
Adjusting the tone
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button,
the item changes as following order:
● When “BASS BOOST” is set
“B-BOOST 0” ➜ “BAL 0” ➜ “FAD 0” ➜
Last function mode.
● When “IMPACT” is set
“IMPACT 0” ➜ “BAL 0” ➜ “FAD 0” ➜ Last
function mode.
● When “EXCITE” is set
“EXCITE 0” ➜ “BAL 0” ➜ “FAD 0” ➜ Last
function mode.
● When “CUSTOM” is set
“BASS <G 0>” ➜ “TREB <G 0>” ➜ “BAL 0”
➜ “FAD 0” ➜ Last function mode.
● When “Z+ OFF” is set
“BAL 0” ➜ “FAD 0” ➜ Last function mode.
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can be performed when the ZEnhancer Plus is set to “CUSTOM”.
1. Press the [A-M] button and select “BASS
<G 0>”.
2. Turning the [ROTARY] knob clockwise
emphasizes the bass; turning it
counterclockwise attenuates the bass.
∗ The factory default setting is “
(Adjustment range: –6 to +8)
BASS
<G 0>”.
3. Press the [a, d] lever upward or
downward to select “
Turn the [ROTARY] knob to select the
frequency.
∗ The factory default setting is “
(Adjustment 50/80/120 Hz)
4. Press the [a, d] lever upward or
downward to select “BASS <Q 1>”.
Turn the [ROTARY] knob to select the Q-
curve.
∗ The factory default setting is “
(Adjustment 1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
BASS
<F 50>”.
BASS
BASS
<F 50>”.
<Q 1>”.
Adjusting the treble (Gain,
Frequency)
This adjustment can be performed when the ZEnhancer Plus is set to “CUSTOM”.
1.
Press the [A-M] button and select “TREB
<G 0>”.
2. Turning the [ROTARY] knob clockwise
emphasizes the treble; turning it
counterclockwise attenuates the treble.
∗ The factory default setting is “
(Adjustment range: –6 to +6)
3. Press the [a, d] lever upward or
downward to select “TREB <F 12K>”.
Turning the [ROTARY] knob to select the
frequency.
∗ The factory default setting is “
(Adjustment 8 kHz/12 kHz)
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
TREB <G 0>
TREB <F 12K>
”.
Adjusting the balance
1. Press the [A-M] button and select “BAL 0”.
2. Turning the [ROTARY] knob clockwise
emphasizes the sound from the right
speaker; turning it counterclockwise
emphasizes the sound from the left speaker.
∗ The factory default setting is “BAL 0”.
(Adjustment range: L13 to R13)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
DXZ555MP 13
English
”.
Basic Operations
English
Adjusting the fader
1.
Press the [A-M] button and select “FAD 0”.
2. Turning the [ROTARY] knob clockwise
emphasizes the sound from the front
speakers; turning it counterclockwise
emphasizes the sound from the rear
speakers.
∗ The factory default setting is “FAD 0”.
(Adjustment range: F12 to R12)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low sound area like the normal sound
adjustment function, but emphasizes the deep
bass sound area to provide you with a dynamic
sound.
∗ The factory default setting is off.
1. Press the [M-B] button to turn on the
MAGNA BASS EXTEND effect. “M-B EX”
lights in the display.
2. Press the [M-B] button to turn off the
MAGNA BASS EXTEND effect. “M-B EX”
goes off from the display.
Radio Operations
Listening to the radio
1. Press the [SRC] button and select the radio
mode. The frequency appears in the display.
2. Press the [BND] button and select the radio
band. Each time the button is pressed, the
radio reception band changes in the
following order:
FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1...
3. Press the [a, d] lever upward or
downward to tune in the desired station.
Tuning
There are 3 types of tuning mode available, seek
tuning, manual tuning and preset tuning.
Seek tuning
1. Press the [BND] button and select the
desired band (FM or AM).
∗ If “MANU” is lit in the display, press and hold
the [BND] button for 1 second or longer.
“MANU” in the display goes off and seek
tuning is now available.
2. Press the [a, d] lever upward or
downward to start automatic station tuning.
When the lever is pressed upward, search
will be performing in the direction of higher
frequencies. When the lever is pressed
downward, search will be performed in the
direction of lower frequencies.
14 DXZ555MP
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
When you are in the step tuning mode, the
frequency changes one step at a time. In the
quick tuning mode, you can quickly tune the
desired frequency.
1. Press the [BND] button and select the
desired band (FM or AM).
∗ If “MANU” is not lit in the display, press and
hold the [BND] button for 1 second or longer.
“MANU” is lit in the display and manual tuning
is now available.
2. Tune into a station.
● Quick tuning:
Press the [a, d] lever upward or
downward and hold in position for 1 second
or longer to begin station tuning.
● Step tuning:
Press the [a, d] lever upward or
downward to perform manual tuning.
Radio Operations
Recalling a preset station
A total of 24 preset positions (6-FM1, 6-FM2, 6FM3, 6-AM) exists to store individual radio
stations in memory. Pressing the corresponding
[DIRECT] button recalls the stored radio
frequency automatically.
1. Press the [BND] button and select the
desired band (FM or AM).
2. Press the corresponding [DIRECT] button to
recall the stored station.
∗ Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store that station
into preset memory.
Manual memory
1. Select the desired station with seek tuning,
manual tuning or preset tuning.
2. Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store the current
station into preset memory.
Auto store
Auto store is a function for storing up to 6
stations that are automatically tuned in
sequentially. If 6 receivable stations cannot be
received, a previously stored station remains
unoverwritten at the memory position.
1. Press the [BND] button and select the
desired band (FM or AM).
2. Press and hold the [ ] button for 2
seconds or longer. The stations with good
reception are stored automatically to the
preset channels.
English
Instant station recall (ISR)
Instant station recall is a special radio preset
that instantly accesses a favorite radio station at
a touch of a button. The ISR function even
operates with the unit in other modes.
● ISR memory
1. Select the station that you wish to store in ISR
memory.
2. Press and hold the [ISR] button for 2 seconds
or longer.
● Recalling a station with ISR
In any mode, press the [ISR] button to turn on
the radio function and tune the selected radio
station. “ISR” appears in the display. Press the
[ISR] button again to return to the previous
mode.
Preset scan
Preset scan receives the stations stored in
preset memory in order. This function is useful
when searching for a desired station in memory.
1. Press the [ ] button.
2. When a desired station is tuned in, press the
[ ] button again to continue receiving that
station.
Note:
• Be careful not to press and hold the
for 2 seconds or longer, otherwise the auto store
function is engaged and the unit starts storing
stations.
[ ]
button
DXZ555MP 15
CD/MP3/WMA Operations
English
MP3/WMA
What is MP3?
MP3 is an audio compression method and
classified into audio layer 3 of MPEG standards.
This audio compression method has penetrated
into PC users and become a standard format.
This MP3 features the original audio data
compression to about 10 percent of its initial
size with a high sound quality. This means that
about 10 music CDs can be recorded on a CDR disc or CD-RW disc to allow a long listening
time without having to change CDs.
What is WMA?
WMA is the abbreviation of Windows Media
Audio, an audio file format developed by
Microsoft Corporation.
Notes:
• If you play a file with DRM (Digital Rights
Management) for WMA remaining ON, no audio
is output.
• Windows Media™, and the Windows ® logo are
trademarks, or registered trademarks of Microsoft
Corporation in the United States and/or other
countries.
●
To disable DRM (Digital Rights Management):
1. When using Windows Media Player 8, click
on TOOLS ➜ OPTIONS ➜ COPY MUSIC
tab, then under COPY SETTINGS, unclick
the check box for PROTECT CONTENT.
Then, reconstruct files.
2. When using Windows Media Player 9, click
on TOOL ➜ OPTIONS ➜ MUSIC RECORD
tab, then under Recording settings, unclick
the Check box for RECORD PROTECTED
MUSIC. Then, reconstruct files.
Personally constructed WMA files are used
at your own responsibility.
Precautions when creating MP3/WMA disc
● Usable sampling rates and bit rates:
1. MP3: Sampling rate 11.025 kHz-48 kHz,
Bit rate: 8 kbps-320 kbps / VBR
2. WMA: Bit rate 48 kbps-192 kbps
● File extensions
1. Always add a file extension “.MP3” or
“.WMA” to MP3 or WMA file by using single
byte letters. If you add a file extension other
than specified or forget to add the file
extension , the file cannot be played.
2. Files without MP3/WMA data will not play.
The indication “––:––” appears in the play
time display if you attempt to play files
without MP3/WMA data.
● Logical format (File system)
1.
When writing MP3/WMA file on a CD-R disc or
CD-RW disc, please select “ISO9660 level 1,
2 or JOLIET or Romeo” as the writing software
format. Normal play may not be possible if the
disc is recorded on another format.
2. The folder name and file name can be
displayed as the title during MP3/WMA play
but the title must be within 128 single byte
alphabetical letters and numerals (including
an extension).
3. Do not affix a name to a file inside a folder
having the same name.
● Folder structure
1. A disc with a folder having more than 8
hierarchical levels will be impossible.
● Number of files or folders
1. Up to 255 files can be recognized per folder.
Up to 500 files can be played.
2.
Tracks are played in the order that they were
recorded onto a disc. (Tracks might not always
be played in the order displayed on the PC.)
3.
Some noise may occur depending on the type
of encoder software used while recording.
Multisession function
When a disc contains both normal CD type tracks
and MP3/WMA type tracks mixedly, you can
select which type of the recorded tracks to play.
● Default value is “CD”.
Each time you press and hold the [BND] button
for 1 second or longer, the mixed mode is
switched between CD type or MP3/WMA type.
The following indication appears in the title
display when switching the track type to be
played.
● Display when CD type
track is selected:
● Display when MP3/WMA
type track is selected:
1. Types of recording that can be played are as
follows.
M-SESS CD
M-SESS MP3
16 DXZ555MP
CD/MP3/WMA Operations
Disc
Mixed with CD and
MP3/WMA type tracks
CD type track only
MP3/WMA type track only
2. After making these settings, remove the disc
3. When a mixed mode CD is loaded and CD is
Note:
• When playing a CCCD (Copy Control CD), set the
setting to CD type. When this is set to MP3/WWA
type, the CD cannot be played normally in some
cases.
Setting
and then reinsert it.
set, the track to be played first is MP3/WMA
file data and no sound is heard.
Set to CD
Play CD
Play CD Play CD
Play MP3/WMA
Set to MP3/WMA
Play MP3/WMA
Play MP3/WMA
Disc-In-Play function
As long as the ignition key is turned to the ON or
ACC position, this function allows you to turn the
power to the unit and start playing the disc
automatically when the disc is inserted even if the
power is not turned on.
CAUTION
• Do not try to put your hand or fingers in the
disc insertion slot. Also never insert
foreign objects into the slot.
• Do not insert discs where adhesive comes
out from cellophane tape or a rental CD
label, or discs with marks where
cellophane tape or rental CD labels were
removed. It may be impossible to extract
these discs from the unit and they may
cause the unit to break down.
Backup Eject function
Just pressing the [Q] button ejects the disc
even if the power to the unit was not turned on.
1. Press the [OPEN] button to open the FLIP
DOWN PANEL.
Note:
• If the FLIP DOWN PANEL will not open far
enough, open it gently with your hand.
2. Press the [Q]button. Remove the disc after it
is ejected.
3. Close the FLIP DOWN PANEL.
Note:
• Always close the FLIP DOWN PANEL once you
take out the disc.
Listening to a disc already loaded
in the unit
Press the [SRC] button to select the CD/MP3/
WMA mode.
When the unit enters the CD/MP3/WMA mode,
play starts automatically.
If there is no disc loaded, the indication “NO
DISC” appears in the title display.
∗ The mode changes each time the [SRC] button is
pressed. (Modes are not displayed for equipment
that is not connected.)
Radio ➜ (SIRIUS) ➜ CD/MP3/WMA ➜ (CD
changer) ➜ (DVD changer) ➜ (TV) ➜ AUX
➜ Radio...
Loading a CD
1. Press the [OPEN] button to access the CD
SLOT behind the FLIP DOWN PANEL.
2. Insert a CD into the center of the CD SLOT
with the labeled side facing up. The CD plays
automatically after loading.
Notes:
• Never insert foreign objects into the CD SLOT.
•
If the CD is not inserted easily, there may be another
CD in the mechanism or the unit may require service.
• Discs not bearing the or mark and
CD-ROMs cannot be played by this unit.
• Some CDs recorded in CD-R/CD-RW mode may
not be usable.
Loading 8 cm compact discs
∗ No adapter is required to play an 8 cm CD.
∗
Insert the 8 cm CD into the center of the insertion slot.
3. Close the FLIP DOWN PANEL.
CAUTION
Be careful not to catch your hand or fingers
while closing the FLIP DOWN PANEL.
Notes:
• If the FLIP DOWN PANEL does not open fully,
gently open with your hand.
• After loading a CD, always close the FLIP DOWN
PANEL.
Pausing play
1. Press the [ ] button to pause play.
“PAUSE” appears in the display.
2. To resume CD play, press the [ ] button
again.
English
DXZ555MP 17
CD/MP3/WMA Operations
English
Displaying CD titles
This unit can display title data for CD-text/MP3/
WMA disc and user titles input with this unit.
1. Press the [D] button to display the title.
2. Each time you press the [T] button, the title
display changes in the following order:
● CD-TEXT disc
User title (disc) ➜ CD-text title (disc) ➜ Artist
name ➜ CD-text title (track) ➜ User title (disc)...
● MP3/WMA disc
Folder ➜ Track ➜ Album TAG ➜ Artist TAG
➜ Title TAG ➜ Folder...
Notes:
• If the CD playing is not a CD-text CD or no user
title has been input, “NO TITLE” appears in the
display.
• If MP3/WMA disc is not input TAG, “NO TAG”
appears in the display.
• For MP3, supports ID3 Tags V2.3 / 2.2 / 1.1 / 1.0.
• Tag displays give priority to V2.3 / 2.2.
• In the case of album Tags for WMA, the
information written into the extension header is
displayed.
• Only ASCII characters can be displayed in Tags.
Selecting a track
● Track-up
1. Press the [a, d] lever upward to move to
the beginning of the next track.
2. Each time the [a, d] lever is pressed
upward, playback proceeds to another track
in the advancing direction.
● Track-down
1. Press the [a, d] lever downward to move
the beginning of the current track.
2. Press the [a, d] lever downward twice to
move to the beginning of the previous track.
Fast-forward/fast-backward
● Fast-forward
Press the [a, d] lever upward and hold in
position for 1 second or longer.
● Fast-backward
Press the [a, d] lever downward and hold in
position for 1 second or longer.
∗ For MP3/WMA discs, it takes some time until the
start of searching and between tracks. In addition,
the playing time may have a margin of error.
18 DXZ555MP
Folder Select
This function allows you to select a folder
containing MP3/WMA files and start playing
from the first track in the folder.
1. Press the [DN] or the [UP] button.
Press the [DN] button to move the previous
folder. Press the [UP] button to move the
next folder.
Root folder
1
2
3
4
5
∗ Press the [UP] button while in the final folder
to shift to the first folder.
∗ Folder without an MP3/WMA file is not
selectable.
2. To select a track, press the [a, d] lever
upward or downward.
Top function
The top function resets the CD player to the first
track of the disc. Press the [BND] button to play
the first track (track No. 1) on the disc.
∗ In case of MP3/WMA, the first track of a folder being
played will be returned.
Other various play functions
● Scan play
This function allows you to locate and play the first
10 seconds of all the tracks recorded on a disc.
1. Press the [SCN] button to perform scan play.
The indication “SCN” lights in the display.
∗ Scan play starts from the next track after the
track currently being played.
● Folder scan play
This function allows you to locate and play the
first 10 seconds of the first track of all the
folders on an MP3/WMA disc.
1. Press and hold the [SCN] button for 1
second or longer to perform folder scan play.
CD/MP3/WMA Operations
The indications “ALL
the display.
∗ Folder scan play starts from the next track
after the track currently being played.
● Repeat play
This function allows you to play the current track
repeatedly.
1.
Press the [RPT] button to perform repeat play.
The indication “RPT” lights in the display.
● Folder repeat play
This function allows you to play a track currently
being played in the MP3/WMA folder repeatedly.
1. Press and hold the [RPT] button for 1 second
or longer to perform folder repeat play.
The indications “ALL
the display.
● Random play
This function allows you to play all tracks
recorded on a disc in a random order.
1. Press the [RDM] button to perform random
play.
The indication “RDM” lights in the display.
● Folder random play
This function allows you to play all the tracks of
all the folders recorded on an MP3/WMA disc in
a random order.
1. Press and hold the [RDM] button for 1
second or longer to perform folder random
play.
The indications “ALL
the display.
● To cancel play
1. Press the operating button previously
selected.
...
” and “SCN” light in
...
” and “RPT” light in
...
” and “RDM” light in
English
3. Press the [DN] button to move to the
previous play list.
Press the [UP] button to move to the next
play list.
Notes:
• The SCN/RPT/RDM functions cannot be used
while in the play list mode.
• The title display changes from folder name to play
list name.
Making a play list
1. Write desired tracks to a CD-R/RW, etc. Be
sure to use alphanumeric/ASCII characters
for all file names.
2. Make a play list by using a multimedia
player, etc. and save the data. The file format
must be M3U.
3. Again, write this play list to the CD-R/RW,
etc.
Notes:
• When writing to a CD-R/RW, etc., be sure to use
alphanumeric/ASCII characters.
• Up to 5 layers can be recognized as a list. For
written play lists, latest 5 lists are recognized in
the order in which they are written.
• When writing to a CD-R/RW, etc., turn off the Disc
At Once function.
• When adding a play list, it is recommended to
write it in the Root folder.
Play list mode
This function allows you to play tracks, up to
latest 5 time stamps, by reading the play list
information written on the disc.
1. Press and hold the [P.LIST] button for 1
second or longer to turn on or off the play list
mode.
∗ Play list play is possible only when there is a
file whose extension is “.M3U” on the CD-R/
RW.
∗ Up to 5 play lists can be recognized, and up to
255 files can be recognized per play list.
2. Press the [a, d] lever upward or
downward to change the track.
DXZ555MP 19
Operations Common to Each Mode
English
To change display setting
1. Press and hold the [D] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a, d] lever upward or
downward to select the “item name”.
“CLOCK” ↔ “SCREEN SVR” ↔ “MSG
INP” ↔ “AUTO SCROL” ↔ “DIMMER” ↔
“CONTRAST”
3. Turn the [ROTARY] knob to select the
“desired setting value”.
∗ In the case of item names appearing with the
“E” suffix, after the item name, the [ ] button
must be pressed to display the setting value.
∗ After completing settings, press the [D] button
to return to the previous mode.
● Entering MESSAGE INFORMATION
Message up to 30 characters long can be stored
in memory and displayed as a type of screen
saver setting.
∗ The factory default setting is “WELCOME TO
2-1. Select “MSG INP <E>”.
3-1. Press the [ ] button.
3-2. Press and hold [BND] button for 1 second
3-3. Press the [a, d] lever upward or
3-4. Press the [BND] button to select a
● Setting the clock
2-1. Select “CLOCK <E>”.
3-1. Press the [ ] button.
3-2. Press the [a, d] lever upward or
downward to select the hour or the minute.
3-3. Turn the [ROTARY] knob to set the correct
time.
∗ The clock is displayed in 12-hour format.
3-4. Press the [ ] button to store the time into
memory.
Note:
•
You cannot set the clock when it is displayed with
only the ignition on. If you drain or remove the car’s
battery or take out this unit, the clock is reset. While
setting the clock, if another button or operation is
selected, the clock set mode is canceled.
● Turning the screen saver function on
or off
This unit is provided with the screen saver
function which allows you to show various kinds
of patterns and characters in the operation
status indication area of the display in a random
order. You can turn on and off this function.
If the button operation is performed with the
screen saver function on, the operation display
corresponding to the button operation is shown
for about 30 seconds and the display returns to
the screen saver display.
∗ The factory default setting is “ON”.
2-1. Select “SCREEN SVR”.
3-1. Turn the [ROTARY] knob to select the setting.
Each time you turn the [ROTARY] knob, the
setting changes in the following order:
SS OFF ➜ SS ON ➜ SS MESSAGE.
3-5. Turn the [ROTARY] knob to select the
3-6. Repeat step 3-3 to 3-5 to enter up to 30
3-7. Press and hold the [ ] button for 2
● Setting the method for title scroll
Set how to scroll in CD-TEXT, MP3/WMA title.
∗ The factory default setting is “ON”.
2-1. Select “AUTO SCROL”.
3-1. Turn the [ROTARY] knob to select “ON” or
● Dimmer control
You can setting the dimmer control “ON” or
“OFF”.
∗ The factory default setting is “ON”.
2-1. Select “DIMMER”.
3-1. Turn the [ROTARY] knob to select “ON” or
CLARION”.
or longer to clear the old message.
downward to move the cursor.
character. Each time you press the [BND]
button, the character changes in the
following orders:
Capital letters ➜ Numbers ➜ Symbols ➜
Capital letters…
desired character.
characters for message.
seconds or longer to store the message in
memory and cancel input message mode.
∗ Press and hold the [BND] button for 1second
or longer to cancel the input message. Then
press and hold the [ ] button for 2 seconds
or longer to store the message and the
message return to default setting.
“OFF”.
• ON:
To scroll automatically.
• OFF:
To scroll just 1 time when the title was
changed or the [T] button was pressed for
1 second or longer.
“OFF”.
20 DXZ555MP
Operations Common to Each Mode
● Adjusting the display contrast
You can adjust the display contrast to match the
angle of installation of the unit.
∗ The factory default setting is “5”.
2-1. Select “CONTRAST”.
3-1. Turn the [ROTARY] knob to select from 1-8.
To change other settings
1. Press the [ADJ] button to switch to the
adjustment selection display.
2. Press the [a, d] lever upward or
downward to select the “item name”.
Each time the [a, d] lever is pressed up/
down, the item display changes in the
following order:
“BLINK LED” ↔ “AMP CANCEL” ↔ “AUX
SENSE” ↔ “SYS CHK”
3. Turn the [ROTARY] knob to select the
“desired setting item”.
∗ After completing settings, press the [ADJ]
button to return to the previous mode.
● Anti-theft indicator
The red Anti-theft indicator is a function for
preventing theft. When the DCP is removed
from the unit, this indicator blinks.
∗ The factory default setting is “OFF”.
2-1. Select “BLINK LED”.
3-1. Turn the [ROTARY] knob to select “ON” or
“OFF”.
● Setting the external amplifier
∗ The factory default setting is “OFF”.
2-1. Select “AMP CANCEL”.
3-1. Turn the [ROTARY] knob to select “ON” or
“OFF”.
• ON:
Use with connected AMP.
• OFF:
Use with inside AMP.
● Selecting AUX IN sensitivity
Make the following settings to select the
sensitivity when sounds from external devices
connected to this unit are difficult to hear even
after adjusting the volume.
∗ The factory default setting is “AUX MID”.
2-1. Select “AUX SENSE”.
3-1. Turn the [ROTARY] knob to select “AUX
LOW”, “AUX MID” or “AUX HIGH”.
English
● Performing a system check
This function allows you to perform a system
check from the adjust mode when required.
2-1. Select “SYS CHK <E>“.
3-1. Press and hold the [ ] button for 1
second or longer.
“SYSTEM CHK” appears in the display,
then the unit returns to the previous
operation mode.
Entering titles
Titles up to 10 characters long can be stored in
memory and displayed for CD, CD changer and
TV stations. The number of titles that can be
entered for each mode are as follows.
Mode Number of titles
CD mode 50 titles
TV mode 20 titles
Tuner mode 30 titles
CD changer mode Number of titles
DCZ625 connected 100 titles
CDC655Tz connected 100 titles
1. Press the [SRC] button to select the mode
you want to enter a title (TUNER, CD, CD
changer or TV).
2. Select and play a CD in the CD changer or
tune in to a TV station or TUNER for which
you want to enter the title.
3. Press the [D] button and display the title
display.
4. Press and hold the [T] button for 1 second or
longer.
The display switches to the title input display.
5. Press the [a, d] lever upward or downward
to move the cursor.
6. Press the [BND] button to select a character.
Each time you press the [BND] button, the
character changes in the following order:
Capital letters ➜ Numbers ➜ Symbols ➜
Capital letters…
7. Turn the [ROTARY] knob to select the
desired character.
8. Repeat steps 5 to 7 to enter up to 10
characters for the title.
9. Press and hold the [ ] button for 2
seconds or longer to store the title into
memory and cancel title input mode.
DXZ555MP 21
Operations Common to Each Mode
English
Clearing titles
1. Select and play a CD in the CD changer or
tune in to a TV station or TUNER for which
you want to clear the title.
2. Press the [D] button and display the title
display.
3. Press and hold the [T] button for 1 second or
longer.
The display switches to the title input display.
4. Press and hold the [BND] button for 1
second or longer.
All characters in the title disappear.
5. Press and hold the [ ] button for 2
seconds or longer to clear the title and
cancel title input mode.
Triggered audio mute for cellular
telephones
This unit requires special wiring to mute the
audio signal automatically when a cellular
telephone rings in the car.
∗ This function is not compatible with all cellular telephones
Contact your local authorized Clarion dealer for
information on proper installation and compatibility.
AUX function
This system has an external input jack so you
can listen to sounds and music from external
devices connected to this unit.
8. OPERATIONS OF ACCESSORIES
CD Changer Operations
Note:
• The following operations are the same as for CD
mode:
∗
Pause
∗
Track selection
∗
Fast-forward/fast-backward
∗
Scan play
∗
Repeat play
∗
Random play
See “CD/MP3/WMA Operations” (page 17-19)
for details.
CD changer functions
When an optional CD changer is connected
through the CeNET cable, this unit controls all
CD changer functions. This unit can control a
total of 2 changers.
Press the [SRC] button and select the CD
changer mode to start play. If 2 CD changers
are connected, press the [SRC] button to select
the CD changer for play.
∗ If “NO MAG” appears in the display, insert the
magazine into the CD changer. “DISC CHECK”
appears in the display while the player loads
(checks) the magazine.
∗ If “NO DISC” appears in the display, eject the
magazine and insert discs into each slot. Then,
reinsert the magazine back into the CD changer.
Note:
• Some CDs recorded in CD-R/CD-RW mode may
not be usable.
CAUTION
CD-ROM discs cannot be played from every
CD changer, it’s depended on the model.
Displaying CD titles
This unit can display title data for CD-text CDs
and user titles input with this unit.
∗ Title data for CD-text CDs can be displayed with
this unit only when it is connected to CDC655Tz.
1. Press the [D] button to display the title.
2. Each time you press the [T] button, the title
display changes in the following order:
User title (disc) ➜ CD-text title (disc) ➜ Artist
name ➜ CD-text title (track) ➜ User title (disc)…
Notes:
• If the CD playing is not a CD-text CD or no user
title has been input, “NO TITLE” appears in the
display.
• If a CD-text CD is not input its disc title or a track
title, “NO TITLE” appears in the display.
22 DXZ555MP
CD Changer Operations
Procedure to scroll a title
Set “SCROLL” to “ON” or “OFF”.
(The factory default setting is “ON”. Refer to the
subsection “Turning the screen saver function
on or off” in section “Operation common to
each mode”.)
● When set to “ON”
The title is automatically kept scrolling.
● When set to “OFF”
To scroll just 1 time when the title was changed
or the [T] button was pressed for 1 second or
longer.
Selecting a CD
Press the [UP] or [DN] button to select the
desired disc.
∗ If a CD is not loaded in a slot of magazine, pressing
the [UP] or [DN] button can not work.
Other various play functions
● Disc scan play
Disc scan play locates and plays the first 10
seconds of the first track on each disc in the
currently selected CD changer. This function
continues automatically until it is cancelled.
∗ Disc scan play is useful when you want to select a
desired CD.
1. Press and hold the [SCN] button for 1
second or longer. “ALL
the display and disc scan play starts.
● Disc repeat play
After all the tracks on the current disc have
been played, disc repeat play automatically
replays the current disc over from the first track.
This function continues automatically until it is
cancelled.
1. Press and hold the [RPT] button for 1 second
or longer. “ALL
display and disc repeat play starts.
● Disc random play
The disc random play selects and plays
individual tracks or discs automatically in no
particular order. This function continues
automatically until it is cancelled.
1. Press and hold the [RDM] button for 1
second or longer. “ALL
the display and disc random play starts.
● To cancel play
1. Press the operating button previously
selected.
...
” and “SCN” light in
...
” and “RPT” light in the
...
” and “RDM” light in
TV Operations
Note:
• The following operations are performed the same
as for radio mode:
∗
Channel selection
∗
Storing channels in memory
∗
Calling channels from memory
∗
Auto store
∗
Preset scan
See “Radio Operations” (page 14-15) for details.
TV tuner functions
When an optional TV tuner is connected through
the CeNET cable, this unit controls all TV tuner
functions. To watch TV requires a TV tuner and
monitor.
Watching a TV
1.
Press the [SRC] button and select the TV mode.
2. Press the [BND] button to select the desired
TV band (TV1 or TV2). Each time the button
is pressed, the input selection toggles
between TV1 and TV2.
3. Press the [a, d] lever upward or
downward to tune in the desired TV station.
Watching a video
The TV tuner has a VTR input terminal to which
1 external device can be connected. Connect a
12 V video cassette player (VCP) or video
cassette recorder (VCR) to the TV tuner input
terminal.
1. Press and hold the [ADJ] button for 1 second
or longer to select VTR.
2. To return to the TV broadcast, press and
hold the [ADJ] button for 1 second or longer.
Setting the TV diver
You can change the reception setting for the TV
antenna connected to the TV tuner.
1. Press the [ADJ] button to switch to the
adjustment selection display.
2. Press the [a, d] lever upward or
downward to select “TV DIVER”.
3. Turn the [ROTARY] knob clockwise to set to
“ON” or counterclockwise to set to “OFF”.
● ON:
Sets the diver setting to ON.
● OFF:
Sets the diver setting to OFF.
4. Press the [ADJ] button to return to the
previous mode.
DXZ555MP 23
English
English
9. IN CASE OF DIFFICULTY
Problem
Power does not
turn on.
(No sound is
produced.)
No sound output
when operating
the unit with
amplifiers or
power antenna
attached.
Nothing happens
when buttons are
pressed.
General
Display is not
accurate.
No sound heard
No sound heard
Sound skips or is
noisy.
Sound is cut or
skipped.
Noise is
generated or
CD/MP3/WMA
noise is mixed
with sound.
Sound is bad
directly after
power is turned
on.
Wrong filename
Play list play is
not performed.
Cause Measure
Fuse is blown.
Incorrect wiring.
Power antenna lead is
shorted to ground or
excessive current is required
for remote-on the amplifiers
or power antenna.
The microprocessor has
malfunctioned due to noise,
etc.
DCP or main unit connectors
are dirty.
The speaker protection
circuit is operating.
MP3/WMA files are absent in
a disc.
Files are not recognized as
an MP3/WMA file.
File system is not correct.
Compact disc is dirty.
Compact disc is heavily
scratched or warped.
MP3/WMA files are not
encoded properly.
Water droplets may form on
the internal lens when the
car is parked in a humid
place.
File system is not correct.
File name or extension is not
correct.
Replace with a fuse of the same amperage. If the
fuse blows again, consult your store of purchase.
Consult your store of purchase.
1. Turn the unit off.
2. Remove all wires attached to the power antenna
lead. Check each wire for a possible short to
ground using an ohm meter.
3. Turn the unit back on.
4. Reconnect each amplifier remote wire to the
power antenna lead one by one. If the amplifiers
turn off before all wires are attached, use an
external relay to provide remote-on voltage
(excessive current required).
Turn off the power, then press
the [OPEN] button and
remove the DCP.
Press the reset button for
about 2 seconds with a thin
rod.
Wipe the dirt off with a soft cloth moistened with
cleaning alcohol.
1. Turn down sound volume. Function can also be
restored by turning the power off and on again.
(Speaker volume is reduced automatically when
the speaker protection circuit operates).
2. If the sound is muted again, consult our service
department.
Write MP3/WMA files onto the disc properly.
Use MP3/WMA files encoded properly.
Use ISO9660 level 1, 2 or JOLIET or Romeo file system.
Clean the compact disc with a soft cloth.
Replace with a compact disc with no scratches.
Use MP3/WMA files encoded properly.
Let dry for about 1 hour with the power on.
Use ISO9660 level 1, 2 or JOLIET or Romeo file system.
Use alphanumeric/ASCII characters for MP3/WMA file name.
Use “.M3U” for the file extension of a play list.
Reset button
24 DXZ555MP
10. ERROR DISPLAYS
If an error occurs, one of the following displays is displayed.
Take the measures described below to eliminate the problem.
English
ERROR 2
ERROR 3
ERROR 6
CD/MP3/WMA
ERROR 2
ERROR 3
CD changer
ERROR 6
ERROR 2
ERROR 3
ERROR 6
DVD changer
ERROR P
ERROR R
CauseError Display
A CD is caught inside the CD deck and is
not ejected.
A CD cannot be played due to scratches,
etc.
A CD is loaded upside-down inside the CD
deck and does not play.
A CD inside the CD changer is not loaded.
A CD inside the CD changer cannot be
played due to scratches, etc.
A CD inside the CD changer cannot be
played because it is loaded upside-down.
A DISC inside the DVD changer cannot be
played.
A DISC cannot be played due to scratches,
etc.
A DISC inside the DVD changer cannot be
played because it is loaded upside-down.
Parental level error
Region code error
Measure
This is a failure of CD deck’s mechanism and
consult your store of purchase.
Replace with a non-scratched,
non-warped-disc.
Eject the disc then reload it properly.
This is a failure of CD changer’s mechanism
and consult your store of purchase.
Replace with a non-scratched, non-warped
disc.
Eject the disc then reload it properly.
This is a failure of DVD mechanism and
consult your store of purchase.
Retry or replace with a non-scratched, nonwarped-disc.
Eject the disc then reload it properly
Set the correct Parental level.
Eject the disc and replace correct region
code disc.
If an error display other than the ones described above appears, press the reset button. If the problem
persists, turn off the power and consult your store of purchase.
DXZ555MP 25
English
11. SPECIFICATIONS
FM Tuner
Frequency Range:
87.9 MHz to 107.9 MHz
Usable Sensitivity:
9 dBf
50dB Quieting Sensitivity:
15 dBf
Alternate Channel Selectivity:
70 dB
Stereo Separation (1 kHz):
35 dB
Frequency Response (±3 dB):
30 Hz to 15 kHz
AM Tuner
Frequency Range:
530 kHz to 1710 kHz
Usable Sensitivity:
25 µV
CD Player
System:
Compact disc digital audio system
Usable Discs:
Compact disc
Frequency Response (±1 dB):
5 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
100 dB
Dynamic Range (1 kHz):
95 dB
Harmonic Distortion:
0.01%
Audio
Maximum Power Output:
212 W (53 W ✕ 4 ch)
Continuous Average Power Output:
18 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
Bass Control Action (50 Hz/80 Hz/120 Hz):
+16 dB, -12dB
Treble Control Action (8 kHz/12 kHz):
±12 dB
Line Output Level (CD 1 kHz):
1.8 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable), negative
ground
Current Consumption:
Less than 15 A, 3A
Speaker Impedance:
4 Ω (4 Ω to 8 Ω allowable)
Weight / Source unit:
2.86 lb. (1.3 kg)
Weight / Remote control unit:
1.41 oz. (40 g) (including battery)
Dimensions / Source unit:
7" (Width) ✕ 2" (Height) ✕ 6-3/16" (Depth)
[178 (W) ✕ 50 (H) ✕ 157 (D) mm]
Dimensions / Remote control unit:
1-3/4" (Width) ✕ 4-7/16" (Height) ✕ 7/16"
(Depth)
[44 (W) ✕ 113 (H) ✕ 11 (D) mm]
Note:
• Specifications and design are subject to change without notice for further improvement.
26 DXZ555MP
2004/12
Clarion Co., Ltd.
All Rights Reserved. Copyright © 2004: Clarion Co., Ltd.
Printed in China / Imprimé en Chine / Impreso en China
PE-2719B
280-8143-00
Loading...
