Introduction

This chapter describes the features of the Cisco RV120W, guides you through the installation process, and gets you started using the Device Manager, a browserbased utility for configuring the Cisco RV120W.

• Product Overview, page 1

• Getting to Know the Cisco RV120W, page 4

• Mounting the Cisco RV120W, page 6

• Connecting the Equipment, page 8

• Setting Up the Cisco RV120W Using the Setup Wizard, page12

• Using the Getting Started Page, page 13

• Navigating through the Pages, page 15

• Saving Your Changes, page 17

• Viewing the Help Files, page 18

• Connecting Devices to Your Wireless Network, page 18

Product Overview

Thank you for choosing the Cisco Small Business RV120W Wireless-N VPN Firewall.

The Cisco RV120W is an advanced Internet-sharing network solution for your small business needs. It allows multiple computers in your office to share an Internet connection through both wired and wireless connections.

The Cisco RV120W provides a Wireless-N access point, combined with support for Virtual Private Networks (VPNs) to make your network more secure. Its 10/100 Ethernet WAN interface connects directly to your broadband DSL or Cable modem.

Cisco RV120W Administration Guide 1

Introduction

Product Overview

LAN Ethernet Interfaces

The Cisco RV120W provides four full-duplex 10/100 Ethernet LAN interfaces that can connect up to four devices.

Wireless Access Point

The wireless access point supports the 802.11n standard with MIMO technology, which multiplies the effective data rate. This technology provides better throughput and coverage than 802.11g networks.

Firewall and VPN Client Access

The Cisco RV120W incorporates a Stateful Packet Inspection (SPI)-based firewall with Denial of Service (DoS) prevention and a Virtual Private Network (VPN) engine for secure communication between mobile or remote workers and branch offices.

The Cisco RV120W supports up to ten gateway-to-gateway IP Security (IPsec) tunnels to facilitate branch office connectivity through encrypted virtual links. Users connecting through a VPN tunnel are attached to your company’s network with secure access to files, e-mail, and your intranet as if they were in the building.

You can also use the VPN capability to allow users on your small office network to securely connect out to a corporate network

Wireless Distribution System

The Cisco RV120W’s wireless access point supports Wireless Distribution System (WDS), which allows the wireless coverage to be expanded without wires.

Virtual Networks

The access point also supports multiple SSIDs for the use of virtual networks (up to 4 separate virtual networks), with 802.1Q-based VLAN support for traffic separation.

Cisco RV120W Administration Guide 2

Introduction

Product Overview

Security

The Cisco RV120W implements WPA2-PSK, WPA2-ENT, and WEP encryption, along with other security features including the disabling of SSID broadcasts, MAC-based filtering, and allowing or denying “time of day” access per SSID.

Quality of Service

The Cisco RV120W supports Wi-Fi Multimedia (WMM) and Wi-Fi Multimedia Power Save (WMM-PS) for wireless Quality of Service (QoS). It supports 802.1p, Differentiated Services Code Point (DSCP), and Type of Service (ToS) for wired QoS, which can improve the quality of your network when using delay-sensitive Voice over IP (VoIP) applications and bandwidth-intensive video streaming applications.

Configuration and Administration

With the Cisco RV120W’s embedded web server, you can configure the firewall’s settings using the browser-based Device Manager. The Cisco RV120W supports Internet Explorer, Firefox, and Safari web browsers.

Cisco RV120W Administration Guide 3

Introduction

Getting to Know the Cisco RV120W

The Cisco RV120W also provides a setup wizard. The setup wizard allows you to easily configure the Cisco RV120W’s basic settings.

Getting to Know the Cisco RV120W

Front Panel

POWER—The Power LED lights up green to indicate the device is powered on.

Flashes green when the power is coming on or software is being upgraded.

WAN LED—The WAN (Internet) LED lights up green when the device is connected to your cable or DSL modem. The LED flashes green when the device is sending or receiving data over the WAN port.

WIRELESS—The Wireless LED lights up green when the wireless module is enabled. The LED is off when the wireless module is disabled. The LED flashes green when the device is transmitting or receiving data on the wireless module.

LAN—These four LEDs correspond to the four LAN (Ethernet) ports of the Cisco RV120W. If the LED is continuously lit green, the Cisco RV120W is connected to a device through the corresponding port (1, 2, 3, or 4). The LED for a port flashes green when the Cisco RV120W is actively sending or receiving data over that port.

Cisco RV120W Administration Guide 4

Introduction

Getting to Know the Cisco RV120W

Back Panel

RESET Button—The Reset button has two functions:

• If the Cisco RV120W is having problems connecting to the Internet, press

the RESET button for less than five seconds with a paper clip or a pencil tip. This is similar to pressing the reset button on your PC to reboot it.

• If you are experiencing extreme problems with the Cisco RV120W and have

tried all other troubleshooting measures, press and hold in the RESET button for 10 seconds. This will restore the factory defaults and clear all of the Cisco RV120W settings.

LAN Ports (1-4)—These ports provide a LAN connection to network devices, such as PCs, print servers, or additional switches.

WAN Por t—The WAN port is connected to your Internet device, such as a cable or DSL modem.

ON/OFF Power Switch—Press this button to turn the Cisco RV120W on and off. When the button is pushed in, power is on.

Power Port—The power port is where you connect the AC power cable.

Cisco RV120W Administration Guide 5

Introduction

195114

Wall

mount

slots

2-7/16

Mounting the Cisco RV120W

You can place your Cisco RV120W on a desktop or mount it on a wall.

Installation Guidelines

• Ambient Temperature—To prevent the device from overheating, do not

operate it in an area that exceeds an ambient temperature of 104°F (40°C).

• Air Flow—Be sure that there is adequate air flow around the device.

• Mechanical Loading—Be sure that the device is level and stable to avoid

any hazardous conditions.

For desktop placement, place the Cisco RV120W device horizontally on a flat surface so that it sits on its four rubber feet.

Wall Mounting

STEP 1 Determine where you want to mount the device and install two screws (not

supplied) that are 2-7/16 in. apart (approximately 61 mm). Mounting screws should have a head that is approximately 5.5 mm in diameter and 2 mm deep, with a shaft that is at least15.5 mm long and approximately 3.5 mm wide. (Your wall may require shorter or longer screws, or drywall anchors.)

Do not mount the screw heads flush with the wall; the screw heads must fit inside the back of the device.

STEP 2 With the back panel pointing up (if installing vertically), line up the device so that

the wall-mount slots on the bottom of the device line up with the two screws.

Cisco RV120W Administration Guide 6

Introduction

Mounting the Cisco RV120W

STEP 3 Place the wall-mount slots over the screws and slide the device down until the

screws fit snugly into the wall-mount slots.

Cisco RV120W Administration Guide 7

Introduction

Connecting the Equipment

Before you begin the installation, make sure that you have the following equipment and services:

Required

• Functional Internet Connection (Broadband DSL or cable modem).

• Ethernet cable for WAN (Internet) connection.

• PC with functional network adapter (Ethernet connection) to run the Setup

Wizard or the Device Manager. The Setup Wizard is supported on Microsoft Windows 2000, Windows XP, Windows Vista, and Windows 7. The Device Manager is supported on the following web browsers:

- Microsoft Internet Explorer 6.0 and later

- Mozilla Firefox 3.0 and later

- Apple Safari 3.0 or later.

• Ethernet cable (provided) to connect the firewall to a PC for configuration.

Optional

• Uninterruptible Power Supply (UPS) to provide backup power to essential

devices (strongly recommended).

• Ethernet cables for LAN interfaces, if you want to connect additional

devices to the firewall’s LAN ports.

Cisco RV120W Administration Guide 8

Introduction

Connecting the Equipment

STEP 1 Power off all equipment, including the cable or DSL modem, the PC you will use to

STEP 2 Use an Ethernet cable to connect the WAN port of the Cisco RV120W to your

To connect your firewall to the Internet:

connect to the RV120W, and the RV120W.

cable or DSL modem.

Cisco RV120W Administration Guide 9

Introduction

Connecting the Equipment

STEP 3 Connect one end of a different Ethernet cable to one of the LAN (Ethernet) ports on

the back of the RV120W. (In this example, the LAN 2 port is used.) Connect the other end of the cable to an Ethernet port on the PC.

STEP 4 Power on the cable or DSL modem and wait until the connection is active.

Cisco RV120W Administration Guide 10

Introduction

Connecting the Equipment

STEP 5 Connect the power adapter to the Cisco RV120W power port (12VDC).

CAUTION Use only the power adapter that is supplied with the device. Using a different

power adapter could damage the device.

STEP 6 Plug the other end of the adapter into an electrical outlet. You may need to use a

specific plug (supplied) for your country.

Cisco RV120W Administration Guide 11

Introduction

Setting Up the Cisco RV120W Using the Setup Wizard

STEP 7 On the Cisco RV120W, push in the ON/OFF power button.

The power light on the front panel is green when the power adapter is connected properly and the unit is turned on.

Setting Up the Cisco RV120W Using the Setup Wizard

With the RV120W powered on and connected to a PC, use the Setup Wizard to configure the Cisco RV120W.

To use the Setup Wizard:

STEP 1 Start the PC connected to the RV120W.

Your computer becomes a DHCP client of the RV120W and receives an IP address in the 192.168.1.xxx range.

STEP 2 Launch a web browser and enter 192.168.1.1 in the Address field.

This is the default IP address of the RV120W.

STEP 3 When the login page appears, enter the user name and password.

The default user name is admin. The default password is admin. The password is case sensitive.

Cisco RV120W Administration Guide 12

Introduction

Using the Getting Started Page

STEP 4 Click Log In.

The Setup Wizard starts.

STEP 5 Follow the Setup Wizard’s on-screen instructions to set up the RV120W.

The Setup Wizard tries to automatically detect and configure your connection. If it cannot, the Setup Wizard asks you for information about your Internet connection. If you don not have it, contact your Internet Service Provider (ISP) to obtain this information.

During the setup process, the Setup Wizard asks you to enter a new password. To protect your firewall from unauthorized access, create a new password that is hard to figure out by others. While you are entering the password, the Setup Wizard provides you with instant feedback regarding the strength of the password.

After the Setup Wizard is done configuring the RV120W, the Getting Started page appears. See Using the Getting Started Page, page 13 for more information.

Using the Getting Started Page

The Getting Started page displays the most common Cisco RV120W configuration tasks. Use the links on this page to jump to the relevant configuration page.

By default, this page appears when you start the Device Manager. However, you can change this behavior by checking Don’t show this on start up at the bottom of the page.

Cisco RV120W Administration Guide 13

Introduction

Using the Getting Started Page

Initial Settings

Run Setup Wizard Click this link to launch the Setup Wizard.

Configure WAN (Internet) Settings

Configure LAN (Local Network) Settings

Configure Wireless Settings

Add VPN Clients See Configuring VPN Users, page 105.

Click this link to open the Internet Setup page.

See Configuring the IPv4 WAN (Internet),

page 20.

Click this link to open the LAN Configuration page.

See Configuring IPv4 LAN (Local Network)

Settings, page 27.

Click this link to open the Basic Settings page.

See Configuring Basic Wireless Settings,

page 54.

Quick Access

Upgrade Device Firmware

Click this link to open the Firmware Upgrade page.

See Upgrading Firmware, page 134.

Backup/Restore Settings

Configure Site to Site VPN

Configure Web Access Click this link to open the Web Access page.

Cisco RV120W Administration Guide 14

Click this link to open the Backup and Restore page.

See Backing Up and Restoring the System,

page132

Click this link to open the Basic VPN Setup page.

See Configuring a Basic VPN, page 93.

See Configuring Web Access, page 119.

Introduction

Navigating through the Pages

Device Status

Dashboard Click this link to open the Dashboard page.

See Viewing the Dashboard, page 136.

System Summary Click this link to open the System Summary page.

See Viewing the System Summary, page 139.

Wireless Status Click this link to open the Wireless Statistics page.

See Viewing the Wireless Statistics, page 142.

VPN Status Click this link to open the IPsec Connection Status

page.

See IPsec Connection Status, page 143.

Other Resources

Support Click this link to open Cisco’s support page.

Forums Click this link to visit Cisco’s online support forums.

Navigating through the Pages

Use the navigation tree in the left pane to open the configuration pages.

Cisco RV120W Administration Guide 15

Introduction

Navigating through the Pages

Click a menu item on the left panel to expand it. Click the menu names displayed underneath to perform an action or view a sub-menu.

Cisco RV120W Administration Guide 16

Introduction

Saving Your Changes

When you finish making changes on a configuration page, click Save to save the changes, or click Cancel to undo your changes.

Cisco RV120W Administration Guide 17

Introduction

Viewing the Help Files

To view more information about a configuration page, click the Help link near the top right corner of the page.

Connecting Devices to Your Wireless Network

To connect a device such as a PC or printer to your wireless network, you must configure the wireless connection on the device using the security information you configured for the Cisco RV120W:

• Network name or Service Set Identifier (SSID). The default SSID is

ciscosb-1.

• If applicable, the encryption type and security key.

Cisco RV120W Administration Guide 18

Configuring Networking

The networking page allows you to configure networking settings. This chapter contains the following sections:

• Configuring the WAN (Internet) Settings, page 19

• Configuring the LAN (Local Network) Settings, page 27

• Configuring Routing, page 34

• Configuring Port Management, page 40

• Configuring Dynamic DNS (DDNS), page 40

• Configuring IPv6, page 42

NOTE Cisco recommends you use the Setup Wizard to configure basic networking on the

Cisco RV120W. You can then make changes and provision advanced features using the Device Manager.

Configuring the WAN (Internet) Settings

If you have an IPv4 network, use these sections to configure your network. If you have an IPv6 network, see Configuring IPv6, page 42.

Cisco RV120W Administration Guide 19

Configuring Networking

Configuring the WAN (Internet) Settings

Configuring the IPv4 WAN (Internet)

STEP 1 Choose Networking > WAN (Internet) > IPV4 WAN (Internet).

STEP 2 Choose the type of Internet connection you have. The type of connection you have

determines the rest of the information you need to enter. See the sections below for more information:

• Configuring Automatic Configuration (DHCP), page 20

• Configuring Static IP, page 21

• Configuring PPPoE, page 21

• Configuring PPTP, page 22

• Configuring L2TP, page 23

Configuring Automatic Configuration (DHCP)

If your Internet Service Provider (ISP) uses the Dynamic Host Configuration Protocol (DHCP) to assign you an IP address, you receive a dynamic IP address from your ISP.

To configure DHCP WAN settings:

STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).

STEP 2 From the Internet Connection Type drop-down menu, choose

Automatic Configuration - DHCP.

STEP 3 Enter MTU information. (See Configuring MTU Settings, page 24.)

STEP 4 Enter MAC Address information. (See Configuring the MAC Address, page 24.)

STEP 5 Click Save.

Cisco RV120W Administration Guide 20

Configuring Networking

Configuring the WAN (Internet) Settings

Configuring Static IP

If your ISP assigned you a permanent IP address, perform the following steps to configure your WAN settings:

STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).

STEP 2 From the Internet Connection Type drop-down menu, choose Static IP.

STEP 3 Enter this information:

IP Address Enter the IP address of the WAN port.

Subnet mask Enter subnet mask of the WAN port.

Default Gateway Enter the IP address of the default gateway.

Primary DNS Server Enter the IP address of the primary DNS server.

Secondary DNS Server (Optional) Enter the IP address of the secondary

DNS server.

STEP 4 Enter MTU information. (See Configuring MTU Settings, page 24.)

STEP 5 Enter MAC Address information. (See Configuring the MAC Address, page 24.)

STEP 6 Click Save.

Configuring PPPoE

If you have a Point-to-Point Protocol over Ethernet (PPPoE) connection to the Internet:

STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).

STEP 2 From the Internet Connection Type drop-down menu, choose PPPoE.

STEP 3 From the PPPoE Profile Name drop-down menu, choose a PPPoE profile.

If no profile is listed, click Configure Profile to create a new profile.

To see the details of available profiles, choose

Networking > WAN (Internet) > PPPoE Profiles. See Configuring PPPoE

Profiles, page 25 for more information.

STEP 4 Enter MTU information. (See Configuring MTU Settings, page 24.)

Cisco RV120W Administration Guide 21

Configuring Networking

Configuring the WAN (Internet) Settings

STEP 5 Enter MAC Address information. (See Configuring the MAC Address, page 24.)

STEP 6 Click Save.

Configuring PPTP

If you have a Point-to-Point Tunneling Protocol (PPTP) connection to the Internet:

STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).

STEP 2 From the Internet Connection Type drop-down menu, choose PPTP.

STEP 3 Enter this information:

User Name Enter your username assigned to you by the ISP.

Password Enter your password assigned to you by the ISP.

MPPE Encryption If your ISP supports Microsoft Point-to-Point

Encryption (MPPE), check to enable MPPE encryption.

Connection Type Choose the connection type:

• Keep connected—The Internet connection is

always on.

• Idle Time—The Internet connection is on

only when traffic is present. If the connection is idle—that is, no traffic is occurring—the connection is closed. You might want to choose this option if your ISP charges based on connection time.

Idle Time If you choose Idle Time as the connection type,

enter the number of minutes after which the connection terminates. The valid range is 5–999.

My IP Address Enter the IP address assigned to you by your ISP.

Server IP Address Enter the IP address of the PPTP server.

STEP 4 Enter MTU information. (See Configuring MTU Settings, page 24.)

Cisco RV120W Administration Guide 22

Configuring Networking

Configuring the WAN (Internet) Settings

STEP 5 Enter MAC Address information. (See Configuring the MAC Address, page 24.)

STEP 6 Click Save.

Configuring L2TP

If you have a Layer 2 Tunneling Protocol (L2TP) connection to the Internet:

STEP 1 Choose Networking > WAN.

STEP 2 From the Internet Connection Type drop-down menu, choose L2TP.

STEP 3 Enter this information:

User Name Enter your username assigned to you by the ISP.

Password Enter your password assigned to you by the ISP.

Secret (Optional) Enter your secret phrase. This phrase is

known to you and your ISP for use in authenticating your logon.

Connection Type Choose the connection type:

• Keep connected—The Internet connection is

always on.

• Idle Time—The Internet connection is on

Idle Time If you choose Idle Time as the connection type,

enter the number of minutes after which the connection terminates. The valid range is 5–999.

My IP Address Enter the IP address assigned to you by your ISP.

Server IP Address Enter the IP address of the L2TP server.

STEP 4 Enter MTU information. (See Configuring MTU Settings, page 24.)

Cisco RV120W Administration Guide 23

Configuring Networking

Configuring the WAN (Internet) Settings

STEP 5 Enter MAC Address information. (See Configuring the MAC Address, page 24.)

STEP 6 Click Save.

Configuring MTU Settings

The Maximum Transmission Unit (MTU) is the size of the largest packet that can be sent over the network. The default MTU value for Ethernet networks is usually 1500 bytes and for PPPoE connections, it is 1492 bytes.

To configure the MTU settings:

STEP 1 Choose Networking > Choose Networking > WAN (Internet) > IPv4 WAN

(Internet).

STEP 2 Choose the MTU type:

• Default—Unless a change is required by your ISP, we recommend that

you choose Default in the MTU Type field. The default MTU size is 1500 bytes.

• Custom—If your ISP requires a custom MTU setting, choose Custom and

enter the MTU size in the MTU Size field.

STEP 3 Click Save.

Configuring the MAC Address

The Cisco RV120W has a unique 48-bit local Ethernet hardware address. In most cases, the default MAC address is used to identify your Cisco RV120W to your ISP. However, you can change this setting if required by your ISP.

Cisco RV120W Administration Guide 24

Configuring Networking

Configuring the WAN (Internet) Settings

To configure the MAC address settings:

STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).

STEP 2 From the Router MAC Address drop-down menu, choose one of these options:

• Use Default Address—(Recommended) choose this option to use the

default MAC address.

• Use This Computer's Address—Choose this option to assign the MAC

address of your computer.

• Use This MAC—Choose this option if you want to use the MAC address of

the PC on which you are connecting to the Device Manager.

STEP 3 Click Save.

Configuring PPPoE Profiles

If you have a PPPoE connection to the Internet, you can create profiles for multiple PPPoE accounts. This can be useful if you connect to the Internet using different service provider accounts.

STEP 1 Choose Networking > WAN (Internet) > PPPoE Profiles.

STEP 2 Click Add to create a new profile.

STEP 3 Enter the following information (you may need to contact your ISP to obtain your

PPPoE login information):

Profile Name Enter the name of the profile.

Username Enter your username assigned to you by the ISP.

Password Enter your password assigned to you by the ISP.

Cisco RV120W Administration Guide 25

Configuring Networking

Configuring the WAN (Internet) Settings

Authentication Type Choose the authentication type from the

drop-down menu:

Auto-negotiate—The server sends a configuration request specifying the security algorithm set on it. Then, the Cisco RV120W sends back authentication credentials with the security type sent earlier by the server.

PAP—The Cisco RV120W uses the Password Authentication Protocol (PAP) to connect to the ISP.

CHAP—The Cisco RV120W uses the Challenge Handshake Authentication Protocol (CHAP) when connecting with the ISP.

MS-CHAP or MS-CHAPv2—The Cisco RV120W uses Microsoft Challenge Handshake Authentication Protocol when connecting with the ISP.

Connection Type Choose the connection type:

Idle Time If you choose Idle Time as the connection type,

STEP 4 Click Save.

The profile is added to the Profile Table.

To edit a PPPoE profile listed in the Profile Table, select the profile and click Edit. To delete selected profiles, click Delete.

• Keep connected—The Internet connection is

always on.

• Idle Time—The Internet connection is on

enter the number of minutes after which the connection terminates. The valid range is 5–999.

Cisco RV120W Administration Guide 26

Configuring Networking

Configuring the LAN (Local Network) Settings

If you have an IPv4 network, use these sections to configure your LAN settings. If you have an IPv6 network, see Configuring IPv6 LAN Properties, page 43.

Configuring IPv4 LAN (Local Network) Settings

If you have an IPv4 LAN, you can configure the following settings:

Configuring the Host Name

To configure the host name of the Cisco RV120W:

STEP 1 Choose Networking > LAN (Local Network) > IPv4 LAN (Local Network).

STEP 2 In the Host Name field, enter the host name of the Cisco RV120W. You can use

only alpha-numeric characters and the hyphen.

The default hostname (for example, “router9BA120”) consists of the word “router” followed by the last 3 bytes of firewall’s LAN MAC address (in Hex-decimal form). This format allows the FindIT application to use Bonjour to identify Cisco Small Business devices on the LAN.

STEP 3 Click Save.

Configuring the IP Address

You might want to change the default IP address if that address is assigned to another piece of equipment in your network.

Cisco RV120W Administration Guide 27

Configuring Networking

Configuring the LAN (Local Network) Settings

To configure the IP address of the Cisco RV120W:

STEP 1 Choose Networking > LAN (Local Network) > IPv4 LAN (Local Network).

STEP 2 Enter this information:

IP Address Enter the LAN IP address of the RV120W.

Subnet mask Choose the subnet mask for the new IP address

STEP 3 Click Save.

Make sure the address is not in use by another device on the same network. The default IP address is 192.168.1.1.

from the drop-down menu. The default subnet is

255.255.255.0.

After changing the Cisco RV120W’s LAN IP address, your PC is no longer connected to the Cisco RV120W.

STEP 4 To reconnect your PC to the Cisco RV120W:

• If DHCP is configured on the Cisco RV120W, release and renew your PC’s IP

address.

• If DHCP is not configured on the Cisco RV120W, manually assign an IP

address to your PC. The address must be on the same subnet as the Cisco RV120W. For example, if you change the Cisco RV120W’s IP address to

10.0.0.1, assign your PC an IP address in the range of 10.0.0.2 to 10.0.0.254.

STEP 5 Open a new browser window and enter the new IP address of the Cisco RV120W

to reconnect.

Configuring DHCP

By default, the Cisco RV120W functions as a DHCP server to the hosts on the Wireless LAN (WLAN) or LAN network and assigns IP and DNS server addresses.

With DHCP enabled, the firewall's IP address serves as the gateway address to your LAN. The PCs in the LAN are assigned IP addresses from a pool of addresses. Each address is tested before it is assigned to avoid duplicate addresses on the LAN.

Cisco RV120W Administration Guide 28

Configuring Networking

Configuring the LAN (Local Network) Settings

For most applications, the default DHCP settings are satisfactory. If you want another PC on your network to be the DHCP server, or if you are manually configuring the network settings of all of your PCs, disable DHCP.

To configure the DHCP settings of the Cisco RV120W:

STEP 1 Choose Networking > LAN (Local Network) > IPv4 LAN (Local Network).

STEP 2 From the DHCP Mode drop-down menu, choose one of these options:

• None—Choose this option if the Cisco RV120W is not going to act as a DHCP

server.

• DHCP Server—Choose this option to configure the Cisco RV120W to be a

DHCP server and enter this information:

- Domain Name— (Optional) Enter the domain name for your network.

- Starting IP Address/Ending IP Address—Enter the first and last of the

- Primary DNS Server/Secondary DNS Server—DNS servers map

- Lease time—Enter the duration (in hours) for which IP addresses are

• DHCP Relay—Choose this option to configure the Cisco RV120W to be a

DHCP relay agent and enter the address of the relay agent in the Relay Gateway field. The relay agent transmits DHCP messages between multiple subnets.

STEP 3 Click Save.

contiguous addresses in the IP address pool. Any new DHCP client joining the LAN is assigned an IP address in this range. You can save part of the range for PCs with fixed addresses. These addresses should be in the same IP address subnet as the Cisco RV120W's LAN IP address.

Internet domain names (for example, www.cisco.com) to IP addresses. Enter the server IP addresses in these fields if you want to use different DNS servers than are specified in your WAN settings.

leased to clients

Configuring the DNS Proxy

You can also enable a DNS proxy. When enabled, the firewall then acts as a proxy for all DNS requests and communicates with the ISP's DNS servers. When disabled, all DHCP clients receive the DNS IP addresses of the ISP.

Cisco RV120W Administration Guide 29

Configuring Networking

Configuring the LAN (Local Network) Settings

To configure the DNS proxy server for the Cisco RV120W:

STEP 1 Choose Networking > LAN (Local Network) > IPv4 LAN (Local Network).

STEP 2 In the DNS Proxy field, check to enable the Cisco RV120W to act as a proxy for all

DNS requests and communicate with the ISP's DNS servers.

STEP 3 Click Save.

Configuring Virtual LAN (VLAN) Membership

A VLAN is a group of endpoints in a network that are associated by function or other shared characteristics. Unlike LANs, which are usually geographically based, VLANs can group endpoints without regard to the physical location of the equipment or users.

Enabling VLANs

STEP 1 Choose Networking > LAN (Local Network) > VLAN Membership.

STEP 2 Check the Enable box.

STEP 3 Click Save.

Underneath the Enable VLAN field, The VLAN Membership Table is shown. This shows available VLANs, including the VLAN ID, description, ports, and whether inter-VLAN routing is enabled or not for each configured VLAN.

Creating a VLAN

You can create up to four VLANs on the Cisco RV120W.

STEP 1 Choose Networking > LAN (Local Network) > VLAN Membership.

STEP 2 In the VLAN Membership Table, click Add Row.

STEP 3 Enter a numerical VLAN ID that will be assigned to endpoints in the VLAN

membership. The VLAN ID can range from 2 to 4094. VLAN ID 1 is reserved for the default VLAN, which is used for untagged frames received on the interface, and VLAN ID 4092 is reserved and cannot be used.

Cisco RV120W Administration Guide 30

Configuring Networking

Configuring the LAN (Local Network) Settings

STEP 4 Enter a description for the VLAN.

STEP 5 To enable routing between this and other VLANS, check the Inter VLAN Routing

box.

STEP 6 To enable device management, check the Device Management box. This allows

you to access the Device Manager from that VLAN. For example, if you created a VLAN with the VLAN ID of 2 and enabled device management, you can access the Device Manager by using the first IP address on the created VLAN (for example,

192.168.2.1).

STEP 7 Under each of the ports for the VLAN, choose one of the following:

• Tagged—Used when connecting to switches carrying multiple VLANs.

• Untagged—Access ports connecting to end devices like printers and

workstations.

STEP 8 Click Save.

Configuring Multiple VLAN Subnets

When you create a VLAN, a subnet is created automatically for the VLAN. You can then further configure the VLAN properties, such as the IP address and DHCP behavior.

To e d it a VL AN :

STEP 1 Choose Networking > LAN > Multiple VLAN Subnets. The list of subnets appears.

STEP 2 Check the box next to the VLAN you want to edit and click Edit.

STEP 3 If you want to edit the IP address of this VLAN:

a. In the IP address field, enter the new IP address.

b. Enter the Subnet Mask for the new IP address.

c. Click Save. If you are connected to the Cisco RV120W by the LAN port that is a

member of this VLAN, you might have to release and renew the IP address on the PC connected to the LAN port, or manually assign an IP address to your PC that is in the same subnet as the VLAN. Open a new browser window and reconnect to the Cisco RV120W.

Cisco RV120W Administration Guide 31

Configuring Networking

Configuring the LAN (Local Network) Settings

If you want to edit the DHCP behavior of this VLAN:

a. In the DHCP Section, in the DHCP Mode field, choose one of the following:

• DHCP Server—Choose this to allow the VLAN to act as the DHCP server in

the network. Enter the following information:

- Domain Name—Enter the domain name for your network (optional).

- Starting and Ending IP Address—Enter the first and last of the

- Primary and Secondary DNS Server—DNS servers map Internet

domain names (for example, www.cisco.com) to IP addresses. Enter the server IP addresses in these fields if you want to use different DNS servers than are specified in your WAN settings.

- Lease time—Enter the duration (in hours) for which IP addresses are

leased to clients.

• DHCP Relay—Choose this if you are using a DHCP relay gateway. The relay

gateway transmits DHCP messages between multiple subnets. Enter the address of the relay gateway in the Relay Gateway field.

• None—Use this to disable DHCP on the VLAN.

In the LAN Proxy section, to enable the VLAN to act as a proxy for all DNS requests and communicate with the ISP's DNS servers, check the Enable box.

STEP 4 Click Save.

Configuring Static DHCP

You can configure a static IP Address and MAC Address for a known computer or device on the LAN network from the LAN Interface menu.

STEP 1 Choose Networking > LAN (Local Network) > Static DHCP (LAN).

STEP 2 Click Add.

STEP 3 Enter the IP address of the device.

Cisco RV120W Administration Guide 32

Configuring Networking

Configuring the LAN (Local Network) Settings

STEP 4 Enter the MAC address of the device. The format for the MAC Address is

XX:XX:XX:XX:XX:XX where X is a number from 0 to 9 (inclusive) or an alphabetical letter between A and F (inclusive).

NOTE The IP Address assigned should be outside the pool of the DHCP addresses

configured. The DHCP pool is treated as generic pool and all reserved IPs should be outside this pool. The DHCP server will then serve the reserved IP address when the device using the corresponding MAC address requests an IP address.

STEP 5 Click Save.

Configuring Advanced DHCP Settings

Configuring Automatic Configuration Download

You can configure the Cisco RV120W to download a configuration file from a TFTP server. Upon rebooting, the firewall downloads the file.

To configure automatic configuration download:

STEP 1 Choose Networking > LAN (Local Network) > Advanced DHCP Configuration.

STEP 2 Check Enable to enable downloading of configuration files.

STEP 3 Choose the TFTP server type:

• Host Name—Enter the host name of the TFTP server in the TFTP server host

name field.

• Address—Enter the IP address of the TFTP server in the TFTP Server IP

field.

STEP 4 Click Save.

Cisco RV120W Administration Guide 33

Configuring Networking

Configuring Routing

Adding a DHCP Client to Configuration File Map

This table displays the list of currently configured DHCP Client MAC address to configuration filename mappings. It has the following fields:

• MAC Address

• Configuration Filename

Click Add to add a new DHCP Client MAC address to configuration filename mapping. Click Edit to edit the MAC address or boot filename for a particular entry. Click Delete to delete a particular entry.

Viewing DHCP Leased Clients

You can view a list of endpoints on the network (identified by MAC address) and see the IP address assigned to them by the DHCP server. The VLAN of the endpoint is also displayed.

STEP 1 Choose Networking > LAN > DHCP Leased Clients (LAN).

STEP 2 The list of endpoints is displayed; you cannot edit this list.

Configuring Routing

Choosing the Routing Mode

The Cisco RV120W provides two different routing modes. Network Address Translation (NAT), or gateway routing, is a technique that allows several endpoints on a LAN to share an Internet connection. The computers on the LAN use a “private” IP address range while the WAN port on the firewall is configured with a single “public” IP address. The Cisco RV120W translates the internal private addresses into a public address, hiding internal IP addresses from computers on the Internet. If your ISP has assigned you a single IP address, you want to use NAT so that the computers that connect through the Cisco RV120W are assigned IP addresses from a private subnet (for example, 192.168.10.0).

Cisco RV120W Administration Guide 34

Configuring Networking

Configuring Routing

STEP 1 Select Networking > Routing > Routing Mode.

STEP 2 Click the box next to the type of routing to configure.

STEP 3 Click Save.

NOTE If you have already configured DMZ or firewall settings on your firewall in gateway

The other routing mode, “router,” is used if your ISP has assigned you multiple IP addresses so that you have an IP address for each endpoint on your network. You must configure either static or dynamic routes if you use this type of routing. See

Configuring Static Routes, page 37, or Configuring Dynamic Routing, page 38.

To choose your routing mode:

(NAT) mode, selecting “router” changes those settings back to the default.

Viewing Routing Information

To view routing information your network:

STEP 1 Choose Networking > Routing > Routing Table.

STEP 2 Next to the type of network you have, click Display.

Information about your network routing is displayed, including the following:

IPv4 Routing Table

• Destination—Destination host/network IP address for which this route is

added.

• Gateway—The gateway used for this route.

• Genmask—The netmask for the destination network.

• Flags—For debugging purpose only; possible flags include:

- UP—Route is up.

- Host—Target is a host.

Cisco RV120W Administration Guide 35

Configuring Networking

Configuring Routing

- Gateway—Use gateway.

- R—Reinstate route for dynamic routing.

- D—Dynamically installed by daemon or redirect.

- M—Modified from routing daemon or redirect.

- A—Installed by

- C—Cache entry.

- !—Reject route.

• Metric—The distance to the target (usually counted in hops).

• Ref—Number of references to this route.

• Use—Count of lookups for the route. Depending on the use of -F and -C, this

is either route cache misses (-F) or hits (-C).

• Interface—Interface to which packets for this route will be sent.

• Type—Type of routing used (RIP or static).

IPv6 Routing Table

• Destination—Destination host/network IP address for which this route is

added.

• Next Hop—IP address of an adjacent or intermediate host or router through

which traffic must flow before reaching its ultimate destination.

addrconf

• Flags—For debugging purpose only; possible flags include:

- UP—Route is up.

- Host—Target is a host.

- Gateway—Use gateway.

- R—Reinstate route for dynamic routing.

- D—Dynamically installed by daemon or redirect.

- M—Modified from routing daemon or redirect.

- A—Installed by

- C—Cache entry.

- !—Reject route.

Cisco RV120W Administration Guide 36

addrconf

Configuring Networking

Configuring Routing

• Metric—The distance to the target (usually counted in hops).

• Ref—Number of references to this route.

• Use—Count of lookups for the route. Depending on the use of -F and -C, this

is either route cache misses (-F) or hits (-C).

• Interface—Interface to which packets for this route will be sent.

• Type—Type of routing used (RIP or static).

Configuring Static Routes

You can configure static routes to direct packets to the destination network. A static route is a pre-determined pathway that a packet must travel to reach a specific host or network. Some ISPs require static routes to build your routing table instead of using dynamic routing protocols. Static routes do not require CPU resources to exchange routing information with a peer router. You can also use static routes to reach peer routers that do not support dynamic routing protocols. Static routes can be used together with dynamic routes. Be careful not to introduce routing loops in your network.

To c r e a te a s t at i c r o u te :

STEP 1 Select Networking > Routing > Static Routes.

STEP 2 In the Static Route Table, click Add.

STEP 3 In the Route Name field, enter the name of the route.

STEP 4 If a route is to be immediately active, check the Active check box. When a route is

added in an inactive state, it will be listed in the routing table, but will not be used by the firewall. The route can be enabled later. This feature is useful if the network that the route connects to is not available when you added the route. When the network becomes available, the route can be enabled.

STEP 5 Check the Private check box to mark this route as private, which means that it will

not be shared in a Routing Information Protocol (RIP) broadcast or multicast. Uncheck this box if the route can be shared with other firewalls when RIP is enabled.

STEP 6 In the Destination IP Address field, enter the IP address of the destination host or

network to which the route leads. For a standard Class C IP domain, the network address is the first three fields of the Destination LAN IP; the last field should be zero.

Cisco RV120W Administration Guide 37

Configuring Networking

Configuring Routing

STEP 7 In the IP Subnet Mask field, enter the IPv4 Subnet Mask for the destination host or

STEP 8 From the Interface drop-down menu, choose the physical network interface

STEP 9 In the Gateway IP Address field, enter the IP Address of the gateway through

STEP 10 In the Metric field, enter a value between 2 and 15 to define the priority of the

STEP 11 Click Save.

network. For Class C IP domains, the Subnet Mask is 255.255.255.0.

through which this route is accessible (WAN or LAN).

which the destination host or network can be reached. If this firewall is used to connect your network to the Internet, then your gateway IP is the firewall's IP address. If you have another router handling your network's Internet connection, enter the IP address of that router instead.

route. If multiple routes to the same destination exist, the route with the lowest metric is chosen.

Configuring Dynamic Routing

RIP (Routing Information Protocol, RFC 2453) is an Interior Gateway Protocol (IGP) that is commonly used in internal networks. It allows the Cisco RV120W to exchange its routing information automatically with other routers, and allows it to dynamically adjust its routing tables and adapt to changes in the network.

NOTE RIP is disabled by default on the Cisco RV120W.

To configure dynamic routing:

STEP 1 Choose Networking > Routing > Dynamic Routing.

STEP 2 To configure how the firewall sends and receives RIP packets, choose the RIP

direction:

• None—The firewall neither broadcasts its route table nor does it accept any

RIP packets from other routers. This option disables RIP.

• In Only—The firewall accepts RIP information from other router, but does

not broadcast its routing table.

Cisco RV120W Administration Guide 38

Configuring Networking

Configuring Routing

STEP 3 Choose the RIP version:

STEP 4 RIP v2 authentication forces authentication of RIP packets before routes are

• Out Only—The firewall broadcasts its routing table periodically but does

not accept RIP information from other routers.

• Both—The firewall both broadcasts its routing table and also processes RIP

information received from other routers.

• Disabled.

• RIP-1—This is a class-based routing version that does not include subnet

information. RIP-1 is the most commonly supported version.

• RIP-2B—This version broadcasts data in the entire subnet.

• RIP-2M—This version sends data to multicast addresses.

exchanged with other routers. It acts as a security feature because routes are exchanged only with trusted routers in the network. RIP authentication is disabled by default. You can enter two key parameters so that routes can be exchanged with multiple routers present in the network. The second key also acts as a failsafe when authorization with first key fails.

To enable authentication for RIP-2B or RIP-2M, check the Enable box. (You must also choose the direction as explained in Step 2.)

If you enabled RIP v2 authentication, enter the following first and second key parameters:

• MD5 Key ID—Input the unique MD-5 key ID used to create the

Authentication Data for this RIP v2 message.

• MD5 Auth Key—Input the auth key for this MD5 key, the auth key that is

encrypted and sent along with the RIP-V2 message.

• Not Valid Before—Enter the start date when the auth key is valid for

authentication.

• Not Valid After—Enter the end date when the auth key is valid for

authentication.

STEP 5 Click Save.

Cisco RV120W Administration Guide 39

Configuring Networking

Configuring Port Management

The Cisco RV120W has four LAN ports. You can enable or disable ports, configure if the port is half- or full-duplex, and set the port speed.

To configure LAN ports:

STEP 1 Choose Networking > Port Management.

STEP 2 In the Port Management Setting Table, to enable a port, check the Enable box. To

disable the port, uncheck the Enable box. By default, all ports are enabled.

STEP 3 Check the Auto Negotiation box to let the firewall and network determine the

optimal port settings. By default, automatic mode is enabled. This setting is available only when the Enable box is checked.

STEP 4 Check the Flow Control box to enable flow control.

STEP 5 (Optional) Choose either half- or full-duplex based on the port support. The default

is full-duplex for all ports. This setting is available only when the Auto check box is unchecked.

STEP 6 (Optional) Select one of the following port speeds: 10 Mbps or 100 Mbps. The

default setting is 100 Mbps for all ports. This setting is available only when the Auto check box is unchecked. You can change the port speed if a network is designed to run at a particular speed, such as 10 Mbps mode. In this case, the endpoint also uses 10 Mbps mode either by auto-negotiation or manual setting.

STEP 7 Click Save.

Configuring Dynamic DNS (DDNS)

DDNS is an Internet service that allows routers with varying public IP addresses to be located using Internet domain names. To use DDNS, you must set up an account with a DDNS provider such as DynDNS.com or TZO.com.

The firewall will notify dynamic DNS servers of changes in the WAN IP address, so that any public services on your network can be accessed by using the domain name.

Cisco RV120W Administration Guide 40

Configuring Networking

Configuring Dynamic DNS (DDNS)

To configure DDNS:

STEP 1 Choose Networking > Dynamic DNS.

STEP 2 Select the Dynamic DNS Service you are using. Selecting None disables this

service.

STEP 3 If you selected DynDNS.com:

a. Specify the complete Host Name and Domain Name for the DDNS service.

b. Enter the DynDNS account username.

c. Enter the password for the DynDNS account.

d. Check the Use Wildcards box to enable the wildcards feature, which allows all

subdomains of your DynDNS Host Name to share the same public IP as the Host Name. This option can be enabled here if not done on the DynDNS Web site.

e. In the Update Period field, enter the number of hours before the Cisco RV120W

updates the host information on DynDNS.com.

If you selected TZO.com:

a. Specify the complete Host Name and Domain Name for the DDNS service.

b. Enter the user e-mail address for the TZO account.

c. Enter the user key for the TZO account.

d. In the Update Period field, enter the number of hours before the Cisco RV120W

updates the host information on TZO.com.

STEP 4 Click Save.

Cisco RV120W Administration Guide 41

Configuring Networking

Configuring IPv6

If you have an IPv6 network, see the following sections.

Configuring the IP Mode

To configure IPv6 properties on the Cisco RV120W, set the IP mode to IPv6:

STEP 1 Choose Networking > IPv6 > IP Mode.

STEP 2 Click the IPv4 and IPv6 Dual-Stack radio button.

STEP 3 Click Save.

Configuring IPv6 WAN Settings

Configuring WAN properties for an IPv6 network differs depending on which type of Internet connection you have. See the sections below for detailed instructions.

The Cisco RV120W can be configured to be a DHCPv6 client of the ISP for this WAN or a static IPv6 address provided by the ISP can be assigned.

Configuring DHCPv6

When the ISP allows you to obtain the WAN IP settings via DHCP, you need to provide details for the DHCPv6 client configuration.

STEP 1 Choose IPv6 > IPv6 WAN (Internet).

STEP 2 In the WAN (Internet) Address (IPv6) field, choose DHCPv6.

STEP 3 Choose if the DHCPv6 client on the gateway is stateless or stateful. If a stateful

client is selected, the gateway connects to the ISP's DHCPv6 server for a leased address. For stateless DHCP, it is not necessary to have a DHCPv6 server available at the ISP. Instead, an ICMPv6 discover message will originate from the Cisco RV120W and is used for auto-configuration.

STEP 4 Click Save.

Cisco RV120W Administration Guide 42

Configuring Networking

Configuring IPv6

STEP 1 Choose IPv6 > IPv6 WAN (Internet).

STEP 2 In the WAN (Internet) Address (IPv6) field, choose Static IPv6.

STEP 3 Enter the IPv6 IP address assigned to your firewall.

STEP 4 Enter the IPv6 prefix length defined by the ISP. The IPv6 network (subnet) is

Configuring a Static IP Address

If your ISP assigns you a fixed address to access the Internet, choose this option. The information needed for configuring a static IP address can be obtained from your ISP.

identified by the initial bits of the address which are called the prefix (for example, in the IP address 2001:0DB8:AC10:FE01::, 2001 is the prefix). All hosts in the network have identical initial bits for their IPv6 address; the number of common initial bits in the network’s addresses is set in this field.

STEP 5 Enter the default IPv6 gateway address, or the IP address of the server at the ISP

that this firewall will connect to for accessing the internet.

STEP 6 Enter the primary and secondary DNS server IP addresses on the ISP's IPv6

network. DNS servers map Internet domain names (for example, www.cisco.com) to IP addresses.

STEP 7 Click Save.

Configuring IPv6 LAN Properties

In IPv6 mode, the LAN DHCP server is enabled by default (similar to IPv4 mode). The DHCPv6 server assigns IPv6 addresses from configured address pools with the IPv6 Prefix Length assigned to the LAN.

To configure IPv6 LAN properties:

STEP 1 Choose Networking > IPv6 > IPv6 LAN (Local Area Network).

STEP 2 Under LAN TCP/IP Setup, in the IPv6 Address field, enter the IP address of the

Cisco RV120W. The default IPv6 address for the gateway is fec0::1. You can change this 128 bit IPv6 address based on your network requirements.

STEP 3 Enter the IPv6 prefix length. The IPv6 network (subnet) is identified by the initial

bits of the address called the prefix. By default, the prefix is 64 bits long. All hosts

Cisco RV120W Administration Guide 43

Configuring Networking

Configuring IPv6

STEP 4 In the DHCPv6 field, choose to disable or enable the DHCPv6 server. If enabled,

STEP 5 Choose the DHCP mode. If stateless is selected, an external IPv6 DHCP server is

in the network have the identical initial bits for their IPv6 address; the number of common initial bits in the network's addresses is set by the prefix length field.

the Cisco RV120W assigns an IP address within the specified range plus additional specified information to any LAN endpoint that requests DHCP-served addresses.

not required as the IPv6 LAN hosts are auto-configured by the Cisco RV120W. In this case, the router advertisement daemon (RADVD) must be configured on this device and ICMPv6 router discovery messages are used by the host for autoconfiguration. There are no managed addresses to serve the LAN nodes.

If stateful is selected, the IPv6 LAN host will rely on an external DHCPv6 server to provide required configuration settings.

STEP 6 (Optional) Enter the domain name of the DHCPv6 server.

STEP 7 Enter the server preference. This field is used to indicate the preference level of

this DHCP server. DHCP advertise messages with the highest server preference value to a LAN host are preferred over other DHCP server advertise messages. The default is 255.

STEP 8 Choose the DNS proxy behavior:

• Use DNS Proxy—Check this box to enable DNS proxy on this LAN, or

uncheck this box to disable this proxy. When this feature is enabled, the firewall acts as a proxy for all DNS requests and communicate with the ISP’s DNS servers (as configured in the WAN settings page).

• Use DNS from ISP—This option allows the ISP to define the DNS servers

(primary/secondary) for the LAN DHCP client.

• Use below—If selected, the primary/secondary DNS servers configured

are used. If you chose this option, enter the IP address of the primary and secondary DNS servers.

STEP 9 Enter the lease/rebind time. Enter the duration (in seconds) for which IP addresses

will be leased to endpoints on the LAN.

STEP 10 Click Save.

Cisco RV120W Administration Guide 44

Configuring Networking

Configuring IPv6

STEP 1 Choose Networking > IPv6 > IPv6 LAN (Local Area Network).

STEP 2 In the IPv6 Address Pool Table, click Add.

STEP 3 Enter the starting IP address and ending IP address of the pool.

STEP 4 Enter the prefix length. The number of common initial bits in the network’s

STEP 5 Click Save.

Configuring IPv6 Address Pools

This feature allows you to define the IPv6 delegation prefix for a range of IP addresses to be served by the Cisco RV120W’s DHCPv6 server. Using a delegation prefix, you can automate the process of informing other networking equipment on the LAN of DHCP information specific for the assigned prefix.

addresses is set by the prefix length field.

Configuring IPv6 Routing

To configure IPv6 routing, see the following sections.

Configuring Dynamic Routing

RIPng (RFC 2080) is a routing protocol based on the distance vector (D-V) algorithm. RIPng uses UDP packets to exchange routing information through port

521. RIPng uses a hop count to measure the distance to a destination. The hop count is referred to as metric, or cost. The hop count from a router to a directlyconnected network is 0. The hop count between two directly-connected routers is

1. When the hop count is greater than or equal to 16, the destination network or host is unreachable. By default, the routing update is sent every 30 seconds. If the router receives no routing updates from a neighbor after 180 seconds, the routes learned from the neighbor are considered as unreachable. After another 240 seconds, if no routing update is received, the router will remove these routes from the routing table.

On the Cisco RV120W, RIPng is disabled by default.

Cisco RV120W Administration Guide 45

Configuring Networking

Configuring IPv6

STEP 1 Select Networking > IPv6 > Routing.

STEP 2 Under RIPng, check Enable.

STEP 3 Click Save.

To configure RIPng:

Configuring Static Routing

To c r e a te a s t at i c r o u te :

STEP 1 Select Networking > IPv6 > Routing.

STEP 2 In the list of static routes, click Add.

STEP 3 Enter the route name.

STEP 4 If a route is to be immediately active, check the Active box. When a route is added

in an inactive state, it will be listed in the routing table, but will not be used by the firewall. The route can be enabled later. This feature is useful if the network that the route connects to is not available when you added the route. When the network becomes available, the route can be enabled.

STEP 5 In the IPv6 destination field, enter the IPv6 address of the destination host or

network for this route.

STEP 6 In the IPv6 prefix length field, enter the number of prefix bits in the IPv6 address

that define the destination subnet.

STEP 7 Choose the physical network interface through which this route is accessible:

• WAN—The route goes through the WAN interface.

• LAN—The route goes through the LAN interface.

Cisco RV120W Administration Guide 46

Configuring Networking

Configuring IPv6

STEP 8 Enter the IP Address of the gateway through which the destination host or network

STEP 9 In the metric field, specify the priority of the route by choosing a value between 2

STEP 10 Click Save.

• 6 to 4 Tunnel—Uses the tunnel interface to route traffic from an IPv6 network

to other IPv6 networks over an IPv4 network.

can be reached.

and 15. If multiple routes to the same destination exist, the route with the lowest metric is used.

Configuring Tunneling

The Cisco RV120W provides several IPv6 tunneling methods. 6to4 tunneling allows IPv6 packets to be transmitted over an IPv4 network. 6to4 tunneling is typically used when a site or end user wants to connect to the IPv6 Internet using the existing IPv4 network.

NOTE You must use static routes when tunneling. See Configuring Static Routing,

page 46.

To configure 6to4 Tunneling:

STEP 1 Select Networking > IPv6 > Tunneling.

STEP 2 Check the Automatic Tunneling box.

STEP 3 Click Save.

Viewing IPv6 Tunnel Information

To view IPv6 tunnel information, choose Networking > IPv6 > Tunneling. Click Refresh to get the latest information.

The IPv6 Tunnel Status table shows the name of tunnel and the IPv6 address that is created on the device.

Cisco RV120W Administration Guide 47

Configuring Networking

Configuring IPv6

STEP 1 Choose Networking > IPv6 > Tu n n el i n g.

STEP 2 In the ISATAP Tunnel Table, click Add.

STEP 3 Enter the tunnel name.

Configuring Intra-Site Automatic Tunnel Addressing Protocol (ISATAP) Tunnels

Intra-site automatic tunnel addressing protocol (ISATAP) is a method to transmit IPv6 packets between dual-stack nodes over an IPv4 network. The Cisco RV120W is one endpoint (a node) for the tunnel. You must also set a local endpoint, as well as the ISATAP Subnet Prefix that defines the logical ISATAP subnet to configure a tunnel.

To add an ISATAP tunnel:

STEP 4 Choose the local endpoint address, or the endpoint address for the tunnel that

starts with the Cisco RV120W. The endpoint can be the LAN interface (if the LAN is configured as an IPv4 network), or another LAN IPv4 address.

STEP 5 If you chose Other IP in Step 4, enter the IPv4 address of the endpoint.

STEP 6 Enter the ISATAP subnet prefix. This is the 64-bit subnet prefix that is assigned to

the logical ISATAP subnet for this intranet. This can be obtained from your ISP or internet registry, or derived from RFC 4193.

STEP 7 Click Save.

To modify the settings of an ISATAP tunnel:

STEP 1 Choose Networking > IPv6 > Tu n n el i n g.

STEP 2 Check the check boxes for the tunnels you want to modify.

STEP 3 Click Edit, make the changes, and click Save.

Cisco RV120W Administration Guide 48

Configuring Networking

Configuring IPv6

STEP 1 Choose Networking > IPv6 > Tu n n el i n g.

STEP 2 Check the check boxes for the tunnels you want to delete.

STEP 3 Click Delete.

To delete an ISATAP tunnel:

Configuring Router Advertisement

The Router Advertisement Daemon (RADVD) on the Cisco RV120W listens for router solicitations in the IPv6 LAN and responds with router advertisements as required. This is stateless IPv6 auto configuration, and the Cisco RV120W distributes IPv6 prefixes to all nodes on the network.

To configure the RADVD:

STEP 1 Choose Networking > IPv6 > Router Advertisement.

STEP 2 Under Router Advertisement Status, choose Enable.

STEP 3 Under Advertise Mode, choose one of the following:

• Unsolicited Multicast—Select this option to send router advertisements

(RAs) to all interfaces belonging to the multicast group.

• Unicast only—Select this option to restrict advertisements to well-known

IPv6 addresses only (router advertisements [RAs] are sent to the interface belonging to the known address only).

STEP 4 If you chose Unsolicited Multicast in Step 3, enter the advertise interval. The

advertise interval is a random value between the Minimum Router Advertisement Interval and Maximum Router Advertisement Interval. (MinRtrAdvInterval = 0.33 * MaxRtrAdvInterval.) The default is 30 seconds.

STEP 5 Under RA Flags, check Managed to use the administered/stateful protocol for

address auto configuration. Check Other to use the administered/stateful protocol of other, non-address information auto configuration.

STEP 6 Under router preference, choose Low, Medium, or High. The router preference

provides a preference metric for default routers. The low, medium and high values are signaled in unused bits in Router Advertisement messages. This extension is backward compatible, both for routers (setting the router preference value) and hosts (interpreting the router preference value). These values are ignored by hosts

Cisco RV120W Administration Guide 49

Configuring Networking

Configuring IPv6

STEP 7 Enter the MTU size. The MTU is the size of the largest packet that can be sent over

STEP 8 Enter the router lifetime value, or the time in seconds that the advertisement

STEP 9 Click Save.

that do not implement router preference. This feature is useful if there are other RADVD-enabled devices on the LAN. The default is high.

the network. The MTU is used in RAs to ensure all nodes on the network use the same MTU value when the LAN MTU is not well-known. The default is 1500 bytes.

messages will exist on the route. The default is 3600 seconds.

Configuring Router Advertisement Prefixes

To configure the RADVD available prefixes:

STEP 1 Choose Networking > IPv6 > Advertisement Prefixes.

STEP 2 Click Add.

STEP 3 Choose the IPv6 Prefix Type:

• 6to4—6to4 is a system that allows IPv6 packets to be transmitted over an

IPv4 network. It is used when an end user wants to connect to the IPv6 Internet using their existing IPv4 connection

• Global/Local/ISATAP—By using ISATAP, you can integrate IPv6 traffic into a

IPv4 network environment. ISATAP uses a locally assigned IPv4 address to create a 64-bit interface identifier for IPv6.

STEP 4 If you chose 6to4 in Step 3, enter the Site-level aggregation identifier (SLA ID.) The

SLA ID in the 6to4 address prefix is set to the interface ID of the interface on which the advertisements are sent.

If you chose Global/Local/ISATAP in Step 3, enter the IPv6 prefix and prefix length. The IPv6 prefix specifies the IPv6 network address. The prefix length variable is a decimal value that indicates the number of contiguous, higher-order bits of the address that make up the network portion of the address.

STEP 5 Enter the prefix lifetime, or the length of time over which the requesting router is

allowed to use the prefix.

STEP 6 Click Save.

Cisco RV120W Administration Guide 50

Configuring the Wireless Network

This chapter describes how to configure your wireless network and includes the following sections:

• A Note About Wireless Security, page 51

• Understanding the Cisco RV120W’s Wireless Networks, page 54

• Configuring Basic Wireless Settings, page 54

• Configuring Advanced Wireless Settings, page 61

• Configuring Wi-Fi Protected Setup, page 62

• Configuring a Wireless Distribution System (WDS), page 63

A Note About Wireless Security

Wireless networks are convenient and easy to install, so small businesses with high-speed Internet access are adopting them at a rapid pace. Because wireless networking operates by sending information over radio waves, it can be more vulnerable to intruders than a traditional wired network. Like signals from your cellular or cordless phones, signals from your wireless network can also be intercepted. The following information will help you to improve your security:

• Wireless Security Tips, page 52

• General Network Security Guidelines, page 53

Cisco RV120W Administration Guide 51

Configuring the Wireless Network

A Note About Wireless Security

Wireless Security Tips

Since you cannot physically prevent someone from connecting to your wireless network, you need to take some additional steps to keep your network secure:

• Change the default wireless network name or SSID

Wireless devices have a default wireless network name or Service Set Identifier (SSID) set by the factory. This is the name of your wireless network, and can be up to 32 characters in length.

You should change the wireless network name to something unique to distinguish your wireless network from other wireless networks that may exist around you, but do not use personal information (such as your Social Security number) because this information may be available for anyone to see when browsing for wireless networks.

• Change the default password

For wireless products such as access points, routers, and gateways, you will be asked for a password when you want to change their settings. These devices have a default password set by the factory. The default password is often admin. Hackers know these defaults and may try to use them to access your wireless device and change your network settings. To thwart any unauthorized changes, customize the device’s password so it will be hard to guess.

• Enable MAC address filtering

Cisco routers and gateways give you the ability to enable Media Access Control (MAC) address filtering. The MAC address is a unique series of numbers and letters assigned to every networking device. With MAC address filtering enabled, wireless network access is provided solely for wireless devices with specific MAC addresses. For example, you can specify the MAC address of each computer in your network so that only those computers can access your wireless network.

Cisco RV120W Administration Guide 52

Configuring the Wireless Network

A Note About Wireless Security

• Enable encryption

Encryption protects data transmitted over a wireless network. Wi-Fi Protected Access (WPA/WPA2) and Wired Equivalency Privacy (WEP) offer different levels of security for wireless communication. Currently, devices that are Wi-Fi certified are required to support WPA2, but are not required to support WEP.

A network encrypted with WPA/WPA2 is more secure than a network encrypted with WEP, because WPA/WPA2 uses dynamic key encryption. To protect the information as it passes over the airwaves, you should enable the highest level of encryption supported by your network equipment.

WEP is an older encryption standard and may be the only option available on some older devices that do not support WPA.

• Keep wireless routers, access points, or gateways away from exterior walls

and windows.

• Turn wireless routers, access points, or gateways off when they are not

being used (at night, during vacations).

• Use strong passphrases that are at least eight characters in length.

Combine letters and numbers to avoid using standard words that can be found in the dictionary.

General Network Security Guidelines

Wireless network security is useless if the underlying network is not secure. Cisco recommends that you take the following precautions:

• Password protect all computers on the network and individually password

protect sensitive files.

• Change passwords on a regular basis.

• Install anti-virus software and personal firewall software.

• Disable file sharing (peer-to-peer). Some applications may open file sharing

without your consent and/or knowledge.

Cisco RV120W Administration Guide 53

Configuring the Wireless Network

Understanding the Cisco RV120W’s Wireless Networks

The Cisco Small Business RV 120W Wireless-N VPN Firewall provides four separate virtual wireless networks. These networks can be configured and enabled with individual settings. You can set up the multiple networks to segment the network traffic, to allow different levels of access, such as guest access, or to allow access for different functions such as accounting, billing, and so on.

Configuring Basic Wireless Settings

The following sections contain information on how to configure basic wireless settings on the Cisco RV120W. These settings apply to all of the wireless networks.

Configuring Radio, Mode, and Channel Settings

STEP 1 Choose Wireless > Basic Settings.

STEP 2 In the Radio field, choose Enable to enable wireless functionality for the

Cisco RV120W. Choosing Disable turns off wireless functionality for the firewall.

STEP 3 In the Wireless Network Mode field, choose the type of wireless network based

on the devices you have that will connect to the network:

• B/G Mixed—Select this mode if you have devices in the network that

support 802.11b and 802.11g.

• G Only—Select this mode if all devices in the wireless network only

support 802.11g.

• B/G/N Mixed—Select this mode if you have devices in the network that

support 802.11b, 802.11g and 802.11n.

• N Only—Select this mode only if all devices in the wireless network

support 802.11n.

STEP 4 Select the channel bandwidth. Available choices depend on the wireless network

mode chosen in Step 3.

STEP 5 The Control Side Band field defines the sideband which is used for the secondary

or extension channel when the AP is operating in 40 Mhz channel width. Choose lower or upper. This field is only available when channel spacing is set to auto. The

Cisco RV120W Administration Guide 54

Configuring the Wireless Network

Configuring Basic Wireless Settings

signal components above the carrier frequency constitute the upper sideband (USB) and those below the carrier frequency constitute the lower sideband (LSB).

STEP 6 The channel field specifies the frequency that the radio uses to transmit wireless

frames. Select a channel from the list of channels or choose auto to let the Cisco RV120W determine the best channel to use based on the environment noise levels for the available channels.

STEP 7 In the U-APSD field, choose Enable to enable the Unscheduled Automatic Power

Save Delivery (also referred to as WMM Power Save) feature that allows the radio to conserve power. This feature is disabled by default.

STEP 8 Click Save.

Configuring Wireless Security and Other Settings

At a minimum, you should edit the default profiles to enable wireless security. See

A Note About Wireless Security, page 51.

You can configure wireless security and other settings for each wireless network. To configure wireless settings:

STEP 1 Choose Wireless > Basic Settings.

STEP 2 In the Wireless Basic Settings Table, check the box on the left of the wireless

network you want to configure.

STEP 3 Click Edit to configure these network properties:

a. Enter the SSID name, or the unique name for this wireless network. Include up

to 32 characters, using any of the characters on the keyboard. For added security, you should change the default value to a unique name.

b. Check the Broadcast SSID box if you want to allow all wireless clients within

range to be able to detect this wireless network when they are scanning the local area for available networks. Disable this feature if you do not want to make the SSID known. When this feature is disabled, wireless users can connect to your wireless network only if they know the SSID (and provide the required security credentials).

c. Enter the VLAN, or network for this wireless network. (See Chapter 2,

Configuring Networking, for more information on VLANs.) Devices connecting to this network are assigned addresses on this VLAN. The default VLAN is 1 and if all the devices are on the same network, this can be left unchanged.

Cisco RV120W Administration Guide 55

Configuring the Wireless Network

Configuring Basic Wireless Settings

d. (Optional) Check the Wireless Isolation within SSID box to separate this

network from the other three networks on the Cisco RV120W. When this feature is enabled, the network can communicate with the Cisco RV120W, but not with any of the other networks.

e. In the Max Associated Clients field, enter the maximum number of endpoints

that can connect to this network. The default value is 8. You can change this number if you want to restrict traffic on the network to prevent it from being overloaded, for example. The number of clients connected across all four virtual access points cannot exceed 100.

f. Click Save.

Configuring Security

STEP 1 Choose Wireless > Basic Settings.

STEP 2 In the Wireless Basic Settings Table, check the box on the left of the wireless

network you want to configure.

STEP 3 Click Edit Security Mode to configure security.

STEP 4 Select the SSID to configure.

STEP 5 Click Enable under Wireless Isolation within SSID to separate this network from

the other three wireless networks on the Cisco RV120W. When this feature is enabled, the network can communicate with the Cisco RV120W, but not with any of the other three networks.

STEP 6 In the Security field, select the type of security. All devices on this network must

use the same security mode and settings to work correctly. Cisco recommends using the highest level of security that is supported by the devices in your network.

• Disabled—Any device can connect to the network. Not recommended.

• Wired Equivalent Privacy (WEP)— Weak security with a basic encryption

method that is not as secure as WPA. WEP may be required if your network devices do not support WPA; however, it is not recommended.

• Wi-Fi Protected Access (WPA) Personal—WPA is part of the wireless

security standard (802.11i) standardized by the Wi-Fi Alliance and was intended as an intermediate measure to take the place of WEP while the

802.11i standard was being prepared. It supports TKIP/AES encryption. The

Cisco RV120W Administration Guide 56

Configuring the Wireless Network

Configuring Basic Wireless Settings

personal authentication is the preshared key (PSK) that is an alphanumeric passphrase shared with the wireless peer.

• WPA Enterprise—Allows you to use WPA with RADIUS server

authentication.

• WPA2 Personal—WPA2 is the implementation of security standard

specified in the final 802.11i standard. It supports AES encryption and this option uses preshared key (PSK) based authentication.

• WPA2 Personal Mixed—Allows both WPA and WPA2 clients to connect

simultaneously using PSK authentication.

• WPA2 Enterprise—Allows you to use WPA2 with RADIUS server

authentication.

• WPA2 Enterprise Mixed—Allows both WPA and WPA2 clients to connect

simultaneously using RADIUS authentication.

The Encryption Type appears based on the type of network you chose in Step 3:

• WPA Personal, WPA Enterprise, WPA2 Personal Mixed, WPA2 Enterprise

Mixed—TKIP+AES

• WPA2 Personal, WPA2 Enterprise—AES

STEP 7 If you chose WEP:

a. In the Authentication field, choose Open System or Shared Key. If you choose

Open System, a wireless client doesn't need to provide a shared key in order to access the wireless network. Any client can associate to the router. If you choose Shared Key, a wireless client must provide the correct shared key (password) in order to access the wireless network.

b. Select the Encryption Type (64- or 128-bit WEP). The larger size keys provide

stronger encryption, making the key more difficult to crack (for example, 64-bit WEP has a 40-bit key which is less secure than the 128-bit WEP, which has a 104-bit key).

c. (Optional) In the WEP Passphrase field, enter an alphanumeric phrase (longer

than eight characters for optimal security) and click Generate Key to generate four unique WEP keys in the WEP Key fields below.

d. Select one of the four keys to use as the shared key that devices must have in

order to use the wireless network. If you did not generate a key in Step 7c, enter a key directly into the WEP Key field. The length of the key should be 5 ASCII characters (or 10 hexadecimal characters) for 64-bit WEP and 13 ASCII

Cisco RV120W Administration Guide 57

Configuring the Wireless Network

Configuring Basic Wireless Settings

characters (or 26 hexadecimal characters) for 128-bit WEP. Valid hexadecimal characters are “0” to “9” and “A” to “F”.

If you chose WPA Personal, WPA2 Personal, or WPA2 Personal Mixed:

a. Enter the WPA Key, or password/phrase that will secure the network. Devices

connecting to the network must use this phrase for authentication.

b. If you want to see the password as you are entering it, check the Unmask

Password box.

c. In the Key Renewal field, enter the number of seconds after which the Cisco

RV120W will generate a new key. These keys are internal keys exchanged between the Cisco RV120W and connected devices. The default value (3600 seconds) is usually adequate unless you are experiencing network problems.

If you chose WPA Enterprise or WPA2 Enterprise Mixed, no further configuration is required.

If you chose WPA2 Enterprise, you can check the Pre-Authentication box (optional). Pre-authentication allows wireless clients to quickly switch between connected wireless networks sharing the same security configuration. When a wireless client disconnects from a wireless network, a notification is sent to the network, which then sends the pre-authentication info to other wireless networks.

STEP 8 Click Save.

Configuring MAC Filtering

You can use MAC filtering to permit or deny access to the wireless network based on the MAC (hardware) address of the requesting device. For example, you can enter the MAC addresses of a set of PCs and only allow those PCs to access the network. MAC filtering is configured for each wireless network.

STEP 1 Choose Wireless > Basic Settings.

STEP 2 In the Wireless Basic Settings Table, check the box on the left of the wireless

network you want to configure.

STEP 3 Click Edit MAC Filtering.

STEP 4 Choose Enable.

Cisco RV120W Administration Guide 58

Configuring the Wireless Network

Configuring Basic Wireless Settings

STEP 5 Under Connection Control, choose one of the following:

• Block following MAC addresses from connecting to wireless network—

Blocks MAC addresses specified below from connecting to the wireless network.

• Allow only following MAC addresses to connect to wireless network—

Allows only the MAC addresses specified below to connect to the wireless network.

STEP 6 Enter the MAC addresses of the endpoints to allow or deny. To see a list of

currently-connected clients, click Wireless Clients List.

STEP 7 Click Save.

Configuring Wi-Fi Multimedia

Wi-Fi Multimedia (WMM) is used to prioritize different types of traffic. You can configure QoS settings to provide different priority to different applications, users, or data flows, or to guarantee a certain level of performance to a data flow.

To configure WMM:

STEP 1 Choose Wireless > Basic Settings.

STEP 2 In the Wireless Basic Settings Table, check the box on the left of the wireless

network you want to configure.

STEP 3 Click Edit WMM.

STEP 4 In the SSID field, select SSID that clients use to connect to the AP.

STEP 5 Check the WMM Enable box to enable WMM based on the IEEE 802.11e standard

for this profile. WMM helps in prioritizing wireless traffic according to four access categories:

• Voice (highest priority, 4)

• Video (high priority, 3)

• Best effort (medium priority, 2)

• Background (lowest priority, 1)

STEP 6 In the DSCP to Queue table, for each ingress DSCP, you can choose the output

queue for the traffic. The Differentiated Services Code Point (DSCP) field identifies

Cisco RV120W Administration Guide 59

Configuring the Wireless Network

Configuring Basic Wireless Settings

the data packet and the output queue identifies the output queue in which the packet is transmitted:

• Voice (4) or Video (3)—High priority queue, minimum delay. Typically used

to send time-sensitive data such as video and other streaming media.

• Best Effort (2)—Medium priority queue, medium throughput and delay. Most

traditional IP data is sent to this queue.

• Background (1)—Lowest priority queue, high throughput. Bulk data that

requires maximum throughput and is not time-sensitive is typically sent to this queue (FTP data, for example).

If you want to change the output queue for packets marked with a particular DSCP, select the new output queue from the drop-down list.

STEP 7 Click Save.

Configuring Wireless Network (SSID) Scheduling

You can configure each of the four available wireless networks on the Cisco RV120W to be active during certain times of the day. To configure the schedule for a wireless network:

STEP 1 Choose Wireless > Basic Settings.

STEP 2 In the Wireless Basic Settings Table, check the box on the left of the wireless

network you want to configure.

STEP 3 Click Edit SSID Scheduling.

STEP 4 Select the wireless network for which you want to create a schedule.

STEP 5 Check the Enable box to allow you to create a schedule to make the network

active during certain times.

STEP 6 Enter the start and stop times for the network to be active.

STEP 7 Click Save.

Cisco RV120W Administration Guide 60

Configuring the Wireless Network

Configuring Advanced Wireless Settings

To configure advanced wireless settings on the Cisco RV120W:

STEP 1 Choose Wireless > Advanced Settings.

STEP 2 In the Beacon Interval field, enter the time in milliseconds between beacon

transmissions. The default interval is 100 milliseconds.

STEP 3 In the DTIM Interval field, enter the interval at which the delivery traffic indication

message should be sent. A DTIM field is a countdown field informing clients of the next window for listening to broadcast and multicast messages. When the Cisco RV120W has buffered broadcast or multicast messages for associated clients, it sends the next DTIM with a DTIM Interval value. Its clients hear the beacons and awaken to receive the broadcast and multicast messages.The default interval is 2 beacon intervals.

STEP 4 The Request to Send (RTS) Threshold is the packet size, in bytes, that requires the

AP to check the transmitting frames to determine if an RTS/Clear to Send (CTS) handshake is required with the receiving client. Using a small value causes RTS packets to be sent more often, consuming more of the available bandwidth, reducing the apparent throughput of the network packets. The default value is 2346, which effectively disables RTS.

STEP 5 The Fragmentation Threshold is the maximum length of the frame, in bytes,

beyond which packets must be fragmented into two or more frames. Collisions occur more often for long frames because while sending them, they occupy the channel for a longer time. The default value is 2346, which effectively disables fragmentation. If you experience a high packet error rate, you can slightly increase the fragmentation threshold; setting the fragmentation threshold too low may result in poor network performance. Only minor reduction of the default value is recommended.

STEP 6 Choose the Preamble Mode. The 802.11b standard requires that a preamble be

appended to every frame before it is transmitted through the air. The preamble may be either the traditional “long” preamble, which requires 192 μs for transmission, or it may be an optional “short” preamble that requires only 96 μs. A long preamble is needed for compatibility with the legacy 802.11 systems operating at 1 and 2 Mbps. The default selection is long.

STEP 7 Choose the Protection Mode. Select none (the default) to turn off CTS. The CTS-

to-Self Protection option enables the CTS-to-Self protection mechanism, which is used to minimize collisions among stations in a mixed 802.11b and 802.11g

Cisco RV120W Administration Guide 61

Configuring the Wireless Network

Configuring Wi-Fi Protected Setup

environment. This function boosts the Cisco RV120W’s ability to catch all wireless transmissions but severely decreases performance.

STEP 8 The Short Retry Limit and Long Retry Limit fields determine the number of times

the Cisco RV120W will reattempt a frame transmission that fails. The limit applies to both long and short frames of a size less than or equal to the RTS threshold.

STEP 9 Click Save.

Configuring Wi-Fi Protected Setup

You can configure Wi-Fi Protected Setup (WPS) on the Cisco RV120W to allow WPS-enabled devices to more easily connect to the wireless network.

STEP 1 Choose Wireless > WPS.

STEP 2 In the VA P field, select the wireless network on which you want to enable WPS.

The network must use WPA, WPA2, or WPA+WPA2 security.

NOTE You can enable WPS on only one of the four networks, or virtual access points.

STEP 3 Under WPS Status, choose Enable to allow WPS configuration. By default, WPS is

disabled.

STEP 4 Click Save.

Cisco RV120W Administration Guide 62

Configuring the Wireless Network

Configuring a Wireless Distribution System (WDS)

To set up a WPS-enabled device in the network:

STEP 1 Choose Wireless > WPS.

STEP 2 Choose the WPS setup method:

• Setup Using a PIN—In the WPS Setup Method section, in the Station PIN

field, enter the personal identification number (PIN) of the device you want to connect to the network. You must log in to that device to obtain its WPS PIN. Then click Configure via PIN. After clicking this button on the Cisco RV120W, on the WPS-enabled device, select the necessary option to begin WPS. The device should begin communication with the Cisco RV120W.

• Setup Using a WPS Button—If the device you want to connect has a WPS

button, push the button on the device. Then, on the Cisco RV120W, click Configure via PBC (push button configuration).

Configuring a Wireless Distribution System (WDS)

A Wireless Distribution System (WDS) is a system that enables the wireless interconnection of access points in a network. It allows a wireless network to be expanded using multiple access points without the need for a wired backbone to link them.

WDS peers are other access points in the network connected in the WDS. All base stations in a WDS must be configured to use the same radio channel, method of encryption (none, WEP, or WPA) and encryption keys.

To configure a WDS:

STEP 1 Choose Wireless > WDS.

STEP 2 Check the Enable box to enable WDS in the Cisco RV120W.

STEP 3 Enter a WPA Key (password) for authentication.

STEP 4 Click Save.

Cisco RV120W Administration Guide 63

Configuring the Wireless Network

Configuring a Wireless Distribution System (WDS)

You can manually add WDS peers that can connect to the Cisco RV120W:

STEP 1 In the WDS Peer Table, click Add.

STEP 2 Enter the MAC (hardware) address of the WDS peer and click Save.

Cisco RV120W Administration Guide 64

Configuring the Firewall

This chapter contains information about configuring the firewall properties of the Cisco RV120W and includes the following sections:

• Cisco RV120W Firewall Features, page 65

• Configuring Access Rules, page 67

• Configuring Attack Prevention, page 71

• Configuring Content Filtering, page 72

• Configuring URL Blocking, page 74

• Configuring Port Triggering, page 75

• Configuring Port Forwarding, page 76

• Configuring a DMZ Host, page 80

• Configuring Advanced Firewall Settings, page 80

• Firewall Configuration Examples, page 87

Cisco RV120W Firewall Features

You can secure your network by creating and applying access rules that the Cisco RV120W uses to selectively block and allow inbound and outbound Internet traffic. You then specify how and to what devices the rules apply. You can configure the following:

• Services or traffic types (examples: web browsing, VoIP, other standard

services and also custom services that you define) that the router should allow or block.

• Rules for outbound (from your LAN to the Internet) or inbound (from the

Internet to your LAN) traffic.

Cisco RV120W Administration Guide 65

Configuring the Firewall

Cisco RV120W Firewall Features

You can, for example, establish restricted-access policies based on time-of-day, web addresses, and web address keywords. You can block Internet access by applications and services on the LAN, such as chat rooms or games. You can block just certain groups of PCs on your network from being accessed by the WAN or public network.

• Schedules as to when the router should apply rules.

• Keywords (in a domain name or on a URL of a web page) that the router

should allow or block.

• MAC addresses of devices whose inbound access to your network the

router should block.

• Port triggers that signal the router to allow or block access to specified

services as defined by port number.

• Reports and alerts that you want the router to send to you.

Inbound (Internet to LAN) rules restrict access to traffic entering your network, selectively allowing only specific outside users to access specific local resources. By default, all access from the insecure WAN side is blocked from accessing the secure LAN, except in response to requests from the LAN or DMZ. To allow outside devices to access services on the secure LAN, you must create a firewall rule for each service.

If you want to allow incoming traffic, you must make the router's WAN port IP address known to the public. This is called “exposing your host.” How you make your address known depends on how the WAN ports are configured; for the Cisco RV120W, you may use the IP address if a static address is assigned to the WAN port, or if your WAN address is dynamic, a DDNS (Dynamic DNS) name can be used.

Outbound (LAN to Internet) rules restrict access to traffic leaving your network, selectively allowing only specific local users to access specific outside resources. The default outbound rule is to allow access from the secure zone (LAN) to the insecure WAN. To block hosts on the secure LAN from accessing services on the outside (insecure WAN), you must create a firewall rule for each service.

Cisco RV120W Administration Guide 66

Configuring the Firewall

Configuring Access Rules

Configure access rules to control traffic to and from your network. To configure access rules, choose Firewall > Access Rules. All configured firewall rules on the Cisco RV120W are displayed in the Access Rule Table.

Configuring the Default Outbound Policy

You can configure the default outbound policy for the traffic that is directed from your secure network (LAN) to the Internet. The default flowing from the Internet to your LAN is always blocked and cannot be changed. The

default outbound policy

firewall rules that you have configured. For example, you may have specific firewall rules restricting outbound instant messaging and video traffic, but all other traffic would be permitted if you choose allow as the default outbound policy.

inbound

applies to traffic that is not covered by the specific

policy for traffic

To configure the default outbound policy:

STEP 1 Choose Firewall > Access Rules.

STEP 2 Under Default Outbound Policy, choose Allow or Block. Allow permits traffic from

your LAN to the Internet. Block does not permit traffic from your LAN to the Internet.

STEP 3 Click Save.

Creating an Access Rule

Access rules specify the type of traffic that is allowed into and out of your network. To create access rules:

STEP 1 Choose Firewall > Access Rules.

STEP 2 Click Add Rule.

STEP 3 Under Connection Type, choose the destination of traffic covered by this rule:

• Inbound—Traffic from the Internet (WAN) to your network (LAN)

• Outbound—Traffic from your network (LAN) to the Internet (WAN)

Cisco RV120W Administration Guide 67

Configuring the Firewall

Configuring Access Rules

STEP 4 Choose the action:

STEP 5 Choose the service to allow or block for this rule. Choose Any Traffic to allow the

• Always Block—Always block the selected type of traffic.

• Always Allow—Never block the selected type of traffic.

• Block by schedule, otherwise allow—Blocks the selected type of traffic

according to a schedule. Choose the schedule from the drop-down list. See

Creating Firewall Schedules, page 84.

• Allow by schedule, otherwise block—Allows the selected type of traffic

according to a schedule. Choose the schedule from the drop-down list. See

Creating Firewall Schedules, page 84.

rule to apply to all applications and services, or you can choose a single application to block:

• AIM (AOL Instant Messenger)

• BGP (Border Gateway Control)

• BOOTP_CLIENT (Bootstrap Protocol client)

• BOOTP_SERVER (Bootstrap Protocol server)

• CU-SEEME (videoconferencing) UDP or TCP

• DNS (Domain Name System), UDP or TCP

• FINGER

• FTP (File Transfer Protocol)

• HTTP (Hyptertext Transfer Protocol)

• HTTPS (Secure Hypertext Transfer Protocol)

• ICMP (Internet Control Message Protocol) type 3 through 11 or 13

• ICQ (chat)

• IMAP (Internet Message Access Protocol) 2 or 3

• IRC (Internet Relay Chat)

• NEWS

• NFS (Network File System)

• NNTP (Network News Transfer Protocol)

Cisco RV120W Administration Guide 68

Configuring the Firewall

Configuring Access Rules

• PING

• POP3 (Post Office Protocol)

• PPTP (Point-to-Point Tunneling Protocol)

• RCMD (command)

• REAL-AUDIO

• REXEC (Remote execution command)

• RLOGIN (Remote login)

• RTELNET (Remote telnet)

• RTSP (Real-Time Streaming Protocol) TCP or UDP

• SFTP (Secure Shell File Transfer Protocol)

• SMTP (Simple Mail Transfer Protocol)

• SNMP (Simple Network Management Protocol) TCP or UDP

• SNMP-TRAPS (TCP or UDP)

• SQL-NET (Structured Query Language)

• SSH (TCP or UDP)

• STRMWORKS

• TACACS (Terminal Access Controller Access-Control System)

• TELNET (command)

• TFTP (Trivial File Transfer Protocol)

• RIP (Routing Information Protocol)

• IKE

• SHTTPD (Simple HTTPD web server)

• IPSEC-UDP-ENCAP (UDP Encapsulation of IPsec packets)

• IDENT protocol

• VDOLIVE (live web video delivery)

• SSH (secure shell)

• SIP-TCP or SIP-UDP

Cisco RV120W Administration Guide 69

Configuring the Firewall

Configuring Access Rules

STEP 6 In the Source IP field, configure the IP address to which the firewall rule applies:

STEP 7 If you are configuring an inbound firewall access rule:

• Any—The rule applies to traffic originating from any IP address in the local

network.

• Single Address—The rule applies to traffic originating from a single IP

address in the local network. Enter the address in the Start field.

• Address Range—The rule applies to traffic originating from an IP address

located in a range of addresses. Enter the starting IP address in the Start field, and the ending IP address in the Finish field.

a. Destination Network Address Translation (DNAT) maps a public IP address

(your dedicated WAN address) to an IP address on your private network. In the Send to Local Server (DNAT IP) field, specify an IP address of a machine on the Local Network which is hosting the server.

b. The router supports multi-NAT, so your Internet Destination IP address does not

have to be the address of your WAN. On a single WAN interface, multiple public IP addresses are supported. If your ISP assigns you more than one public IP address, one of these can be used as your primary IP address on the WAN port, and the others can be assigned to servers on the LAN. In this way, the LAN can be accessed from the internet by its aliased public IP address. Check the Enable box and enter the IP address you want to use.

c. Under Rule Status, choose Enabled or Disabled. You may want to configure a

rule and choose Disabled if you want to enable it at a later time.

If you are configuring an outbound firewall access rule:

a. In the Destination IP field, configure the IP address to which the firewall rule

applies:

• Any—The rule applies to traffic going to any IP address.

• Single Address—The rule applies to traffic going to a single IP address.

Enter the address in the Start field.

• Address Range—The rule applies to traffic going to an IP address located

in a range of addresses. Enter the starting IP address in the Start field, and the ending IP address in the Finish field.

b. You can configure Secure Network Address Translation (SNAT) to map a public

IP address (your Dedicated WAN address, Optional WAN address, or another address) to an IP address on your private network. Under Use This SNAT IP Address, check Enable and enter the SNAT IP Address.

Cisco RV120W Administration Guide 70

Configuring the Firewall

Configuring Attack Prevention

c. Under Rule Status, choose Enabled or Disabled. You may want to configure a

rule and choose Disabled if you want to enable it at a later time.

Configuring Attack Prevention

Attacks are malicious security breaches or unintentional network issues that render the Cisco RV120W unusable. Attack prevention allows you to manage WAN security threats such as continual ping requests and discovery via ARP scans. TCP and UDP flood attack prevention can be enabled to manage extreme usage of WAN resources.

As well, certain Denial-of-Service (DoS) attacks can be blocked. These attacks, if uninhibited, can use up processing power and bandwidth and prevent regular network services from running normally. ICMP packet flooding, SYN traffic flooding, and Echo storm thresholds can be configured to temporarily suspend traffic from the offending source.

To configure attack prevention:

STEP 1 Choose Firewall > Attack Prevention.

STEP 2 Check the boxes to enable the following functions:

WAN (Internet) Security Checks

• Respond to Ping on WAN (Internet)—To configure the Cisco RV120W to

allow a response to an Internet Control Message Protocol (ICMP) Echo (ping) request on the WAN interface, check this box. This setting is used as a diagnostic tool for connectivity problems. Not enabled by default.

• Stealth Mode—If Stealth Mode is enabled, the router will not respond to

port scans from the WAN. This feature makes the network less susceptible to discovery and attacks. Enabled by default.

• Flood— If this option is enabled, the router will drop all invalid TCP packets.

This feature protects the network from a SYN flood attack. Enabled by default.

Cisco RV120W Administration Guide 71

Configuring the Firewall

Configuring Content Filtering

LAN (Local Network) Security Checks

• Block UDP Flood—If this option is enabled, the router will not accept more

than 25 simultaneous, active UDP connections from a single computer on the LAN. Enabled by default.

ICSA (International Computer Security Association) Settings

• Block Anonymous ICMP Messages—ICSA requires the firewall to silently

block without sending an ICMP notification to the sender. Some protocols, such as MTU Path Discovery, require ICMP notifications. Enable this setting to operate in “stealth” mode. Enabled by default.

• Block Fragmented Packets—ICSA requires the firewall to block fragmented

packets from ANY to ANY. Enabled by default.

• Block Multicast Packets—ICSA requires the firewall to block multicast

packets. Enabled by default.

STEP 3 Click Save.

Configuring Content Filtering

The Cisco RV120W supports several content filtering options. You can block certain web applications or components (such as ActiveX or Java). You can set up trusted domains from which to always allow content. You can block access to Internet sites by specifying keywords to block. If these keywords are found in the site's name (for example, web site URL or newsgroup name), the site is blocked.

You also need to turn on content filtering to set up trusted domains.

Enabling Content Filtering

To enable content filtering:

STEP 1 Choose Firewall > Content Filtering.

STEP 2 Check the Enable box.

STEP 3 Click Save.

Cisco RV120W Administration Guide 72

Configuring the Firewall

Configuring Content Filtering

STEP 1 Choose Firewall > Content Filtering.

STEP 2 With content filtering enabled, under Web Components, select the check box for

Blocking Web Components

Certain commonly-used web components can be blocked for increased security. Some of these components can be used by malicious websites to infect computers that access them.

each component you wish to block:

• Proxy—A proxy server (or simply, proxy) allows computers to route

connections to other computers through the proxy, thus circumventing certain firewall rules. For example, if connections to a specific IP address are blocked by a firewall rule, the requests can be routed through a proxy that is not blocked by the rule, rendering the restriction ineffective. Enabling this feature blocks proxy servers.

• Java—Blocks java applets from being downloaded from pages that contain

them. Java applets are small programs embedded in web pages that enable dynamic functionality of the page. A malicious applet can be used to compromise or infect computers. Enabling this setting blocks Java applets from being downloaded.

• ActiveX—Similar to Java applets, ActiveX controls are installed on a

Windows computer while running Internet Explorer. A malicious ActiveX control can be used to compromise or infect computers. Enabling this setting blocks ActiveX applets from being downloaded.

• Cookies—Cookies are used to store session information by websites that

usually require login. However, several websites use cookies to store tracking information and browsing habits. Enabling this option filters out cookies from being created by a website.

NOTE Many websites require that cookies be accepted in order for the site to be

accessed properly. Blocking cookies can cause many websites to not function properly.

STEP 3 Click Save.

Cisco RV120W Administration Guide 73

Configuring the Firewall

Configuring URL Blocking

NOTE Before adding trusted domains, you must enable content filtering. See Enabling

STEP 1 Choose Firewall > Content Filtering. The Trusted Domain Table displays a list of

Adding Trusted Domains

You can add a list of trusted domains. These domains are bypassed during keyword filtering. For example, if “yahoo” is added to the blocked keywords list and www.yahoo.com is added to the trusted domain list, then www.yahoo.com will be allowed, but mail.yahoo.com will not be allowed.

Content Filtering, page 72.

To add trusted domains:

currently configured trusted domains.

STEP 2 Click Add and enter the name of the trusted domain.

STEP 3 Click Save.

Configuring URL Blocking

You can block access to websites that contain specific keywords in the URL or page contents. To configure URL blocking:

STEP 1 Choose Firewall > URL Blocking. The table displays currently blocked keywords.

STEP 2 Click Add Row.

STEP 3 Under Status, check the box to enable blocking for the new keyword.

STEP 4 Select the group to which to apply the keyword blocking. If you need to configure

a new group, click Configure LAN Groups. (See Configuring LAN (Local

Network) Groups, page 86.)

STEP 5 Enter the keyword to block.

STEP 6 Click Save.

Cisco RV120W Administration Guide 74

Configuring the Firewall

Configuring Port Triggering

Port triggering allows devices on the LAN to request one or more ports to be forwarded to them. Port triggering waits for an outbound request from the LAN on one of the defined outgoing ports, and then opens an incoming port for that specified type of traffic. Port triggering is a form of dynamic port forwarding while an application is transmitting data over the opened outgoing or incoming ports.

Port triggering opens an incoming port for a specific type of traffic on a defined outgoing port.

Port triggering is more flexible than static port forwarding (available when configuring firewall rules) because a rule does not have to reference a specific LAN IP or IP range. Ports are also not left open when not in use, thereby providing a level of security that port forwarding does not offer.

NOTE Port triggering is not appropriate for servers on the LAN, since there is a

dependency on the LAN device making an outgoing connection before incoming ports are opened.

Some applications require that, when external devices connect to them, they receive data on a specific port or range of ports in order to function properly. The router must send all incoming data for that application only on the required port or range of ports. The gateway has a list of common applications and games with corresponding outbound and inbound ports to open. You can also specify a port triggering rule by defining the type of traffic (TCP or UDP) and the range of incoming and outgoing ports to open when enabled.

To add a port triggering rule:

STEP 1 Choose Firewall > Port Triggering.

STEP 2 Click Add.

STEP 3 Specify an easily-identifiable name for this rule.

STEP 4 Check the Enable box to enable the rule.

STEP 5 Select whether the port uses TCP, UDP, or both protocols.

STEP 6 In the Outgoing (Trigger) Port Range section, specify the port number or range of

port numbers that will trigger this rule when a connection request from outgoing

Cisco RV120W Administration Guide 75

Configuring the Firewall

Configuring Port Forwarding

traffic is made. If the outgoing connection uses only one port, then specify the same port number in the Start Port and End Port fields.

STEP 7 In the Incoming (Response) Port Range section, specify the port number or range

of port numbers used by the remote system to respond to the request it receives. If the incoming connection uses only one port, then specify the same port number in the Start Port and End Port fields.

STEP 8 Click Save.

Configuring Port Forwarding

Port forwarding is used to redirect traffic from the Internet from one port on the WAN to another port on the LAN. The port forwarding rules menu allows selection of a service. Common services are available or you can define a custom service and associated ports to forward.

The Port Forwarding Rule Table lists all the available port forwarding rules for this device and allows you to configure port forwarding rules. The table contains the following information:

• Action—Whether to block or allow traffic (always or by schedule) that

meets these filter rules, and when the rule is applicable.

• Service—Service for which this port forwarding rule is applicable.

• Status—A port forwarding rule can be disabled if not in use and enabled

when needed. The port forwarding rule is disabled if the status is disabled and it is enabled if the status is enabled. Disabling a port forwarding rule does not delete the configuration.

• Source IP—The source IP address for traffic from which traffic is forwarded

(Any, Single Address or Address Range).

• Destination IP—The IP address of the server to which traffic is forwarded.

• Forward From Port—From which port traffic will be forwarded.

• Forward To Port—To which port traffic will be forwarded.

Cisco RV120W Administration Guide 76

Configuring the Firewall

Configuring Port Forwarding

STEP 1 Choose Firewall > Port Forwarding.

STEP 2 Click Add.

STEP 3 Choose the action:

To configure port forwarding:

• Always Block—Always block the selected type of traffic.

• Always Allow—Never block the selected type of traffic.

• Block by Schedule—Blocks the selected type of traffic according to a

schedule. Choose the schedule from the drop-down list. See Creating

Firewall Schedules, page 84.

• Allow by Schedule—Allows the selected type of traffic according to a

schedule. Choose the schedule from the drop-down list. See Creating

Firewall Schedules, page 84.

STEP 4 Under Service, select one of the common or custom services defined for this

device:

• AIM (AOL Instant Messenger)

• BGP (Border Gateway Control)

• BOOTP_CLIENT (Bootstrap Protocol client)

• BOOTP_SERVER (Bootstrap Protocol server)

• CU-SEEME (videoconferencing) UDP or TCP

• DNS (Domain Name System), UDP or TCP

• FINGER

• FTP (File Transfer Protocol)

• HTTP (Hyptertext Transfer Protocol)

• HTTPS (Secure Hypertext Transfer Protocol)

• ICMP (Internet Control Message Protocol) type 3 through 11 or 13

• ICQ (chat)

• IMAP (Internet Message Access Protocol) 2 or 3

• IRC (Internet Relay Chat)

Cisco RV120W Administration Guide 77

Configuring the Firewall

Configuring Port Forwarding

• NEWS

• NFS (Network File System)

• NNTP (Network News Transfer Protocol)

• PING

• POP3 (Post Office Protocol)

• PPTP (Point-to-Point Tunneling Protocol)

• RCMD (command)

• REAL-AUDIO

• REXEC (Remote execution command)

• RLOGIN (Remote login)

• RTELNET (Remote telnet)

• RTSP (Real-Time Streaming Protocol) TCP or UDP

• SFTP (Secure Shell File Transfer Protocol)

• SMTP (Simple Mail Transfer Protocol)

• SNMP (Simple Network Management Protocol) TCP or UDP

• SNMP-TRAPS (TCP or UDP)

• SQL-NET (Structured Query Language)

• SSH (TCP or UDP)

• STRMWORKS

• TACACS (Terminal Access Controller Access-Control System)

• TELNET (command)

• TFTP (Trivial File Transfer Protocol)

• RIP (Routing Information Protocol)

• IKE

• SHTTPD (Simple HTTPD web server)

• IPSEC-UDP-ENCAP (UDP Encapsulation of IPsec packets)

• IDENT protocol

Cisco RV120W Administration Guide 78

Configuring the Firewall

Configuring Port Forwarding

STEP 5 Select the Source IP:

STEP 6 If you chose Single Address in Step 6, enter the IP address in the Start field.

• VDOLIVE (live web video delivery)

• SSH (secure shell)

• SIP-TCP or SIP-UDP

• Any—Specifies that the rule being created is for traffic from the given

endpoint.

• Single Address—Limit to one host. Requires the IP address of the host to

which this rule would be applied.

• Address Range—This is used to apply this rule to a group of computers/

devices within an IP address range. Requires a from IP address and to IP address.

If you chose Address Range in Step 6, enter the starting IP address of the range in the Start field and the ending IP address of the range in the Finish field.

STEP 7 If you chose Always Allow, Block by Schedule, or Allow by Schedule in Step 3:

a. Enter the Destination IP address, or the address where traffic meeting the rule

should be sent.

b. In the Forward from Port field, choose Same as Incoming Port if the traffic

should be forwarded from the same port number on the outgoing server. Otherwise, choose Specify Port and enter the port number in the Port Number field.

c. In the Forward to Port field, Choose Same as Incoming Port if the traffic should

be sent to the same port on the receiving server. Otherwise, choose Specify Port and enter the port number in the Port Number field.

STEP 8 Click Save.

Cisco RV120W Administration Guide 79

Configuring the Firewall

Configuring a DMZ Host

The Cisco RV120W supports DMZ options. A DMZ is a sub-network that is open to the public but behind the firewall. DMZ allows you to redirect packets going to your WAN port IP address to a particular IP address in your LAN. It is recommended that hosts that must be exposed to the WAN (such as web or e-mail servers) be placed in the DMZ network. Firewall rules can be allowed to permit access to specific services and ports to the DMZ from both the LAN or WAN. In the event of an attack on any of the DMZ nodes, the LAN is not necessarily vulnerable as well.

You must configure a fixed (static) IP address for the endpoint that will be designated as the DMZ host. The DMZ host should be given an IP address in the same subnet as the router's LAN IP address but it cannot be identical to the IP address given to the LAN interface of this gateway.

STEP 1 Choose Firewall > DMZ Host.

STEP 2 Check the Enable box to enable DMZ on the network.

STEP 3 Enter the IP address for the endpoint that will receive the redirected packets. This

is the DMZ host.

STEP 4 Click Save. You must then configure firewall rules for the zone. See Creating

Custom Services, page 83.

Configuring Advanced Firewall Settings

This page allows you to configure many advanced firewall settings.

Configuring One-to-One Network Address Translation (NAT)

One-to-one NAT is a way to make systems behind a firewall that are configured with private IP addresses appear to have public IP addresses.

To configure one-to-one NAT, choose Firewall > Advanced Settings > One-to-One NAT. The One-to-One-NAT Rules Table lists the available One-To-One NAT rules that have been configured. It displays the following fields:

Cisco RV120W Administration Guide 80

Configuring the Firewall

Configuring Advanced Firewall Settings

• Private Range Begin—The starting IP address in the private (LAN) IP

address.

• Public Range Begin—The starting IP address in the public (WAN) IP

address.

• Range Length—Range length maps one to one private address to public

address up to the given range.

• Service—Shows configured services. Services for one-to-one NAT allow

you to configure the service to be accepted by the private IP (LAN) address when traffic is sent to the corresponding public IP address. Configured services on private IP addresses in the range are accepted when traffic is available on the corresponding public IP address.

To add a one-to-one NAT rule:

STEP 1 Choose Firewall > Advanced Settings > One-to-One NAT.

STEP 2 Click Add.

STEP 3 Enter information in the following fields:

• Private Range Begin—The starting IP address in the private (LAN) IP

address.

• Public Range Begin—The starting IP address in the public (WAN) IP

address.

• Range Length—Range length maps one to one private address to public

address up to the given range.

• Service—Choose the service for which the rule applies.

STEP 4 Click Save.

Configuring MAC Address Filtering

MAC address filtering allows you to block traffic coming from certain known machines or devices. The router uses the MAC address of a computer or device on the network to identify it and block or permit the access. Traffic coming in from a specified MAC address will be filtered depending upon the policy.

Cisco RV120W Administration Guide 81

Configuring the Firewall

Configuring Advanced Firewall Settings

To enable MAC address filtering:

STEP 1 Choose Firewall > Advanced Settings > MAC Filtering.

STEP 2 Check the Enable box to enable MAC Address Filtering for this device. Uncheck

the box to disable this feature.

If you enable MAC filtering, in the Policy for MAC Address listed below field, choose one of the following options:

• Block and Allow the Rest—Choose this option to block the traffic from the

specified MAC addresses and to allow traffic from all other addresses.

• Allow and Block the Rest—Choose this option to allow the traffic from the

specified MAC addresses and to block traffic from all other machines on the LAN side of the router.

For example, two computers are on the LAN with MAC addresses of 00:01:02:03:04:05 (host1), and 00:01:02:03:04:11 (host2). If the host1 MAC address is added to the MAC filtering list and the “block and allow the rest” policy is chosen, when this computer tries to connect to a website, the router will not allow it to connect. However, host2 is able to connect because its MAC address is not in the list. If the policy is “allow and block the rest,” then host1 is able to connect to a website, but host2 is blocked because its URL is not in the list. The MAC filtering policy does not override a firewall rule that directs incoming traffic to a host.

STEP 3 In the MAC Addresses table, click Add.

STEP 4 Enter the MAC address and description to add to the table and click Save. Repeat

for each address to allow or block.

STEP 5 Click Save.

Configuring IP/MAC Address Binding

IP/MAC Binding allows you to bind IP addresses to MAC address. Some machines are configured with static addresses. To prevent users from changing static IP addresses, IP/MAC Binding should be enabled. If the Cisco RV120W sees packets with matching IP address but inconsistent MAC addresses, it drops those packets.

Cisco RV120W Administration Guide 82

Configuring the Firewall

Configuring Advanced Firewall Settings

To configure IP/MAC Address binding:

STEP 1 Choose Firewall > Advanced Settings > IP/MAC Binding. The table lists all the

currently defined IP/MAC binding rules and allows several operations on the rules.

STEP 2 Click Add to add a new rule.

STEP 3 In the name field, enter the name for this rule.

STEP 4 In the MAC Addresses field, enter the MAC Addresses (the physical address of

the piece of hardware) for this rule.

STEP 5 In the IP Addresses field, enter the IP Addresses to assign to the piece of

hardware.

STEP 6 Click Save.

Creating Custom Services

When you create a firewall rule, you can specify a service that is controlled by the rule. Common types of services are available for selection, and you can create your own custom services. This page allows creation of custom services against which firewall rules can be defined. Once defined, the new service will appear in the List of Available Custom Services table.

To create a custom service:

STEP 1 Choose Firewall > Advanced Settings > Custom Services.

STEP 2 Click Add.

STEP 3 Enter a service name for identification and management purposes.

STEP 4 Enter the service type, or layer 4 protocol that the service uses (TCP, UDP, ICMP,

ICMPv6, or other).

If you chose ICMP or ICMPv6 as the service type, enter the ICMP type. This is a numeric value from 0 through 40 for ICMP and from 0 through 255 for ICMPv6.

STEP 5 If you chose TCP or UDP, in the Start Port field, enter the first TCP or UDP port of

the range that the service uses. In the Finish Port field, enter the last TCP or UDP port of the range that the service uses.

Cisco RV120W Administration Guide 83

Configuring the Firewall

Configuring Advanced Firewall Settings

If you chose Other, enter the number of the protocol in the Protocol Number field. (For example, if you are using RDP, enter 27 in the protocol number field.)

STEP 6 Click Save.

Creating Firewall Schedules

You can create firewall schedules to apply firewall rules on specific days or at specific times of the day.

To create a schedule:

STEP 1 Choose Firewall > Advanced Settings > Schedules.

STEP 2 Click Add.

STEP 3 Enter a unique name to identify the schedule. This name is then available when you

create access or port forwarding rules.

STEP 4 Under Time, check All Day if you want the schedule to apply to the entire day.

Leave the box unchecked if you want it to only apply to certain hours of the day, and enter the specific start and end times, selecting a.m. or p.m.

STEP 5 Under Repeat, check Everyday to apply the schedule to all the days of the week.

Leave the box unchecked if you want it to only apply to certain days, and check the boxes next to the days you want to include in the schedule.

STEP 6 Click Save.

Configuring Sessions

You can limit the maximum number of unidentified sessions and half-open sessions on the Cisco RV120W. You can also introduce timeouts for TCP and UDP sessions to ensure Internet traffic is not deviating from expectations in your private network.

Cisco RV120W Administration Guide 84

Configuring the Firewall

Configuring Advanced Firewall Settings

To configure session settings:

STEP 1 Choose Firewall > Advanced Settings > Session Settings.

STEP 2 In the Maximum Unidentified Sessions field, enter the maximum number of

unidentified sessions for the ALG identification process. This value can range from 2 through 128. The default is 32 sessions.

STEP 3 In the Maximum Half Open Sessions field, enter the maximum number of half-open

sessions. A half-open session is the session state between receipt of a SYN packet and the SYN/ACK packet. Under normal circumstances, a session is allowed to remain in the half-open state for 10 seconds. The maximum value ranges from 0 through 3,000. The default is 128 sessions.

STEP 4 In the TCP Session Timeout Duration field, enter the time, in seconds, after which

inactive TCP sessions are removed from the session table. Most TCP sessions terminate normally when the RST or FIN flags are detected. This value ranges from 0 through 4,294,967 seconds. The default is 1,800 seconds (30 minutes).

STEP 5 In the UDP Session Timeout Duration field, enter the time, in seconds, after which

inactive UDP sessions are removed from the session table. This value ranges from 0 through 4,294,967 seconds. The default is 120 seconds (2 minutes).

STEP 6 In the Other Session Timeout Duration (seconds) field, enter the time, in seconds,

after which inactive non-TCP/UDP sessions are removed from the session table. This value ranges from 0 through 4,294,967 seconds. The default is 60 seconds.

STEP 7 In the TCP Session Cleanup Latency (seconds) field, enter the maximum time for a

session to remain in the session table after detecting both FIN flags. This value ranges from 0 through 4,294,967 seconds. The default is 10 seconds.

STEP 8 Click Save.

Configuring Internet Group Management Protocol (IGMP)

Internet Group Management Protocol (IGMP) is an exchange protocol for routers. Hosts that want to receive multicast messages need to inform their neighboring routers of their status. In some networks, each node in a network becomes a member of a multicast group and receives multicast packets. In these situations, hosts exchange information with their local routers using IGMP. Routers use IGMP periodically to check if the known group members are active. IGMP provides a method called dynamic membership by which a host can join or leave a multicast group at any time.

Cisco RV120W Administration Guide 85

Configuring the Firewall

Configuring Advanced Firewall Settings

To configure IGMP:

STEP 1 Choose Firewall > Advanced Settings > IGMP Configuration.

STEP 2 Check the Enable box to allow IGMP communication between the router and other

nodes in the network.

STEP 3 Choose the Upstream Interface (WAN or LAN). Select the interface (LAN or WAN)

on which the IGMP proxy acts as a normal multicast client.

STEP 4 Click Save.

The Allowed Networks table lists all the allowed networks configured for the device and allows several operations on the allowed networks:

• Network Address—The network address from which the multicast packets

originate.

• Mask Length— Mask Length for the network address.

In this table you can perform the following actions:

• Check Box—Select all the allowed networks in the table.

• Delete—Deletes the selected allowed network or allowed networks.

• Add—Opens the Allowed Network Configuration page to add a new

network.

• Edit—Opens the Allowed Network Configuration page to edit the selected

network.

NOTE By default the device will forward multicast packets which are originating from its

immediate WAN network.

Configuring LAN (Local Network) Groups

You can create LAN groups, which are groups of endpoints that are identified by their IP address. After creating a group, you can then configure actions, such as blocked keywords in a firewall rule, that apply to the group. (See Configuring URL

Blocking, page 74.)

Cisco RV120W Administration Guide 86

Configuring the Firewall

Firewall Configuration Examples

To create a LAN Group:

STEP 1 Choose Firewall > Advanced Settings > LAN (Local Network) Groups.

STEP 2 Click Add.

STEP 3 Enter the group name; spaces and quotes are not supported. Click Save.

STEP 4 Choose if the group consists of a single IP address, or an range of IP addresses.

If the group consists of a single IP address, enter the address in the Start Address field. If the group consists of a range of IP addresses, enter the address in the Finish Address field.

STEP 5 Click Save.

Enabling Session Initiation Protocol Application-Level Gateway (SIP ALG)

SIP ALG can rewrite information within SIP messages (SIP headers and SDP body) making signaling and audio traffic possible between a client behind Network Address Translation (NAT) and the SIP endpoint.

To enable SIP ALG:

STEP 1 Choose Firewall > Advanced Settings > SIP ALG.

STEP 2 Check the Enable box to enable SIP ALG support. If disabled, the router will not

allow incoming calls to the UAC (User Agent Client) behind the Cisco RV120W.

STEP 3 Click Save.

Firewall Configuration Examples

Example 1: Allow inbound HTTP traffic to the DMZ

In this example, you host a public web server on your local DMZ network. You want to allow inbound HTTP requests from any outside IP address to the IP address of your web server at any time of day.

Cisco RV120W Administration Guide 87

Configuring the Firewall

Firewall Configuration Examples

Create an inbound rule as follows:

Parameter Value

Connection Type Inbound

Action Always Allow

Service HTTP

Source IP Any

Send to Local Server (DNAT IP) 192.168.5.2 (web server IP address)

Rule Status Enabled

Example 2: Allow videoconferencing from range of outside IP addresses.

In this example, you want to allow incoming videoconferencing to be initiated from a restricted range of outside IP addresses (132.177.88.2 - 132.177.88.254), from a branch office.

Create an inbound rule as follows. In the example, CUSeeMe connections are allowed only from a specified range of external IP addresses.

Parameter Value

Connection Type Inbound

Action Always Allow

Service CU-SEEME:UDP

Source IP Address Range

Start 132.177.88.2

Finish 134.177.88.254

Send to Local Server (DNAT IP) 192.168.1.11

Rule Status Enabled

Cisco RV120W Administration Guide 88

Configuring the Firewall

Firewall Configuration Examples

Example 3: Multi-NAT Configuration

In this example, you want to configure multi-NAT to support multiple public IP addresses on one WAN port interface.

Create an inbound rule that configures the firewall to host an additional public IP address. Associate this address with a web server on the DMZ. If you arrange with your ISP to have more than one public IP address for your use, you can use the additional public IP addresses to map to servers on your LAN. One of these public IP addresses is used as the primary IP address of the router. This address is used to provide Internet access to your LAN PCs through NAT. The other addresses are available to map to your DMZ servers.

The following addressing scheme is used to illustrate this procedure:

• WAN I P add r e ss : 1 0.1. 0.118

• LAN IP address: 192.168.1.1; subnet 255.255.255.0

• Web server PC in the DMZ, IP address: 192.168.1.2

• Access to Web server: (simulated) public IP address 10.1.0.52

Parameter Value

Connection Type Inbound

Action Always Allow

Service HTTP

Source IP Single Address

Start 10.1.0.52

Send to Local Server (DNAT IP) 192.168.1.2 (local IP address of your web server)

Rule Status Enabled

Cisco RV120W Administration Guide 89

Configuring the Firewall

Firewall Configuration Examples

Example 4: Block traffic by schedule if generated from specific range of machines

In this example, you want to block all HTTP traffic on the weekends if the request originates from a specific group of machines in the LAN having a known range of IP addresses, and anyone coming in through the Network from the WAN (i.e. all remote users).

STEP 1 Setup a schedule. Choose Firewall > Advanced Settings > Schedules.

STEP 2 Click Add.

STEP 3 Enter the schedule name (for example, “Weekend”).

STEP 4 Under Time, check All Day.

STEP 5 Under Repeat, leave Everyday unchecked.

STEP 6 Check Saturday and Sunday.

STEP 7 Click Save.

Create an outbound access rule with the following parameters:

Parameter Value

Connection Type Outbound

Action Block by Schedule

Schedule Weekend

Service HTTP

Source IP Address Range

Start starting IP address

Finish ending IP address

Destination IP Any

Rule Status Enabled

Cisco RV120W Administration Guide 90

Configuring the Firewall

Firewall Configuration Examples

Create an inbound access rule with the following parameters:

Parameter Value

Connection Type Inbound

Action Block by Schedule

Schedule Weekend

Service All Traffic

Source IP Any

Rule Status Enabled

Cisco RV120W Administration Guide 91

Cisco RV-120W User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Product Overview

LAN Ethernet Interfaces

Wireless Access Point

Firewall and VPN Client Access

Wireless Distribution System

Virtual Networks

Security

Quality of Service

Configuration and Administration

Getting to Know the Cisco RV120W

Front Panel

Back Panel

Mounting the Cisco RV120W

Installation Guidelines

Wall Mounting

Connecting the Equipment

Setting Up the Cisco RV120W Using the Setup Wizard

Using the Getting Started Page

Initial Settings

Quick Access

Navigating through the Pages

Device Status

Other Resources

Saving Your Changes

Viewing the Help Files

Connecting Devices to Your Wireless Network

Configuring Networking

Configuring the WAN (Internet) Settings

Configuring the IPv4 WAN (Internet)

Configuring PPPoE Profiles

Configuring the LAN (Local Network) Settings

Configuring IPv4 LAN (Local Network) Settings

Configuring Virtual LAN (VLAN) Membership

Configuring Multiple VLAN Subnets

Configuring Static DHCP

Configuring Advanced DHCP Settings

Configuring Routing

Viewing DHCP Leased Clients

Choosing the Routing Mode

Viewing Routing Information

Configuring Static Routes

Configuring Dynamic Routing

Configuring Port Management

Configuring Dynamic DNS (DDNS)

Configuring IPv6

Configuring the IP Mode

Configuring IPv6 WAN Settings

Configuring IPv6 LAN Properties

Configuring IPv6 Routing

Configuring Dynamic Routing

Configuring Static Routing

Configuring Tunneling

Configuring Router Advertisement

Configuring the Wireless Network

A Note About Wireless Security

Wireless Security Tips

General Network Security Guidelines

Understanding the Cisco RV120W’s Wireless Networks

Configuring Basic Wireless Settings

Configuring Radio, Mode, and Channel Settings

Configuring Wireless Security and Other Settings

Configuring Advanced Wireless Settings

Configuring Wi-Fi Protected Setup

Configuring a Wireless Distribution System (WDS)

Configuring the Firewall

Cisco RV120W Firewall Features

Configuring Access Rules

Configuring the Default Outbound Policy

Creating an Access Rule

Configuring Attack Prevention

Configuring Content Filtering

Enabling Content Filtering

Blocking Web Components

Configuring URL Blocking

Adding Trusted Domains
